HP HPE MSA 2052 SAN QuickSpecs

QuickSpecs

HPE MSA 2052 SAN Storage

Overview

Page 1

HPE MSA 2052 SAN Storage

Looking for seriously simple and affordable flash storage? The hybrid flash HPE MSA 2052 SAN Storage system with Gen10 ProLiant Branding is designed for affordable application acceleration that is ideal for small and remote office deployments. not now and into the future, and advanced features you may not expect to find in an entry capac cost midline SAS

HPE MSA Storage has been the industry 500,000 storage systems sold worldwide. Delivering performance in excess of 200,000 IOPS, the hybrid flash MSA 2052 Storage system can save you up to 40% with an all affordable flash storage to help you get the most performance for the lowest cost.

- Start small and scale as needed with any combination of SSD, Enterprise or Midline SAS drives

HPE MSA 2052 SAN Storage

let the low cost fool you. The HPE MSA 2052 SAN Storage system gives you the combination of simplicity, flexibility to grow

-priced array. Start with 1.6 TB of flash

ity included and scale as needed with any combination of solid-state disks (SSD), high-performance enterprise, or lower-

-based drives.

-leading entry storage Fibre Channel platform for the past eight years, with nearly

-inclusive software suite and 1.6 TB of flash capacity included. It’s seriously simple and

• HPE MSA 2052 performs in excess of 200,000 IOPS for affordable application acceleration

- Delivers 2x IOPS performance than the previous generation MSA 2042

- Save 40% on the hybrid flash MSA 2052 with all-inclusive software and 1.6 TB of SSD capacity included

• Advanced data services with no experience required

- Easy to install, easy to use, easy to maintain—no storage expertise necessary

- Automated tiering dynamically responds to workload changes, so you don’t have to

• Keep your business running with expanded data protection features

- Virtualized snapshot technology makes data protection and instant recovery a snap

- Remote replication with FC and iSCSI supports affordable disaster recovery

• Grow flexibly now and into the future

- Data-in-place upgrades protect drive investments and eliminate data migrations

But do

QuickSpecs

HPE MSA 2052 SAN Storage

Overview

Page 2

HPE MSA 2052 SAN Storage

Host connection ports*

Expansion port

2. CLI port (mini-USB)

5. AC power supplies

3. Management Ethernet port

Notes: *8 and/or 16Gb FC, / 1 and/or 10GbE iSCSI or 12Gb SAS

What's New in the MSA 2052 array family

and SAS LFF

MSA 2052 Storage Models

Descriptions

SKU

HPE MSA 2052 SAN Dual Controller LFF Storage

Q1J02B

HPE MSA 2052 SAN Dual Controller SFF Storage

Q1J03B

HPE MSA 2052 SAS Dual Controller LFF Storage

Q1J30B

HPE MSA 2052 SAS Dual Controller SFF Storage

Q1J31B

HPE MSA 2052 SAN Dual Controller LFF TAA-compliant Storage

R4Y03A

HPE MSA 2052 SAN Dual Controller SFF TAA-compliant Storage

R4Y04A

HPE MSA 2052 SAS Dual Controller LFF TAA-compliant Storage

R4Y05A

HPE MSA 2052 SAS Dual Controller SFF TAA-compliant Storage

R4Y06A

• New TAA-compliant MSA 2052 Dual Controller Storage Array models including support for SAN SFF, SAN LFF, SAS SFF

QuickSpecs

HPE MSA 2052 SAN Storage

Standard Features

Page 3

HPE MSA 2052 SAN Storage

Array

Access Type

Block

Form Factor

2U, SFF or LFF

Number of controllers per array

Number of host ports per array

FC host connectivity

8/16Gb

iSCSI host connectivity

1Gb or 10GbI

SAS host connectivity

6/12Gb

Cache, per array

Max Read cache per array

8TB

Data (read/write) cache + system memory per array

16GB

Pool Capacity (with Large Pool Support)

562 TB (512 TiB)

RAID Levels supported: Virtual mode

RAID 0*,1, 5, 6, 10

Notes:

Enclosures

Expansion Drive Enclosures

0-7 enclosures

LFF/SFF array/enclosure mixing

Supported

Maximum number of drives per array enclosure

24 SFF/12 LFF

Maximum number of drives per drive enclosure

24 SFF/12 LFF

Drive enclosure interface type

6Gb SAS

Drives

Maximum total HDDs per array

192 SFF / 96 LFF

Maximum total SSDs per array

192 SFF / 96 LFF

Max raw capacity per array enclosure

76.8 TB SFF / 168TB LFF

Max raw capacity per drive enclosure

76.8 TB SFF / 168TB LFF

Max raw capacity per array

614.4TB SFF / 1344TB LFF

Integrated SSDs

2x800GB Mixed Use SSDs

Drive Capacities

SFF SSDs

800GB, 960GB, 1.6TB, 1.92TB, 3.2TB

LFF SSDs

800GB, 960GB, 1.92TB

SFF HDDs

15K: 600GB, 900GB 10K: 600GB, 1.2TB, 1.8TB, 2.4TB

LFF HDDs

7.2K: 4TB, 6TB, 8TB, 10TB, 12TB,14TB

SEDs

Encryption not supported

Software Features

Thin Technologies

Thin Provisioning, Space Reclamation, Thin Rebuild

Tiering

Performance Tier, Standard Tier, Archive Tier

Replication

Snapshots (512), Volume Copy, Remote Snaps

Quality of Service

Virtual Tier Affinity

Bundled/Integrated Licenses

Advanced Data Services LTU standard

Additional Features

Maximum number of volumes

512

Maximum number of snapshots

512

Maximum number of hosts

512

Maximum number of initiators

1024

Customer self-installable

Yes

Customer self-repairable

Yes

Customer self-upgradeable

Yes

Health Check analytics

Yes

*Read Cache Only

QuickSpecs

HPE MSA 2052 SAN Storage

Standard Features

Page 4

All MSA 2052 models offer a common set of valuable features

• MSA 2052 storage system architecture maximizes performance

• Includes MSA 2050-branded SFF or LFF array chassis, depending on model

• Two MSA 2050 SAN or SAS controllers

• 8 GB cache per controller.

• Battery-free cache backup with super capacitors and compact flash

• Two .7m PDU cords (IEC C14)

• One rack-mount kit

• Two pre-installed 800GB Mixed Use SSDs which allow IT managers to accelerate application performance

• One Advanced Data Services Software Suite LTU

• MSA 2050 SAN Controller allows customers to create their own Combo Controller by mixing FC and iSCSI SFPs.

• The two 800GB SSDs can be optionally deployed either as read cache, or as an SSD virtual disk group for tiered storage.

• All MSA 2052 models come standard with the Advanced Data Services (ADS) Software Suite LTU, which includes

• Storage Management Utility V3 (SMU). This MSA management GUI brings a new modern look and feel to array

• Thin Provisioning allows storage allocation of physical storage resources only once they are consumed by an application.

• All models feature a wide variety of drives: High-performance SSD drives, enterprise-class SAS, and SAS Midline drives.

• The MSA 2052 will support a maximum of 7 disk enclosures (either LFF and/or SFF). Add-on enclosures can either be

• The MSA 2050 can grow incrementally to a maximum of 96 LFF, 192 SFF drives, or a combination of SFF and LFF

• Virtual Storage Disks Groups can be spanned across multiple enclosures.

• Virtual Storage RAID levels supported; 1, 5, 6, 10.

• RAID 0 supported for Read Cache only. SSD read cache is a feature that extends the MSA controller cache. Read cache is

• Maximum hard drive counts vary by RAID levels: 2 drive max for RAID level 1; max of 16 drives for RAID levels 5, 6, and

• Multiple Disk Groups can be aggregated into a single Storage Pool.

• The maximum LUN size is 140TB (128TiB)

• Storage Pools allow data on a given LUN to span across all drives in a pool. When capacity is added to a system, the user

• Snapshot enhancements for virtual storage, including performance improvements, hierarchical snapshots, and simplified

- Four host ports per controller

- Each SAN controller supports 8 GB FC, 16 GB FC, 1GbE iSCSI or 10GbE iSCSI host connectivity

- Each SAS controller supports 6Gb and/or 12Gb SAS host connectivity

- Deploy the two embedded SSDs as Read Cache to improve random read performance. A maximum of 2 SSD’s

are supported per pool providing a maximum of 4TB of read cache per controller, max 8TB of read cache per array.

- Deploy the two embedded SSDs as tiered storage. The MSA 2052 can manage up to three tiers of storage: Performance tier, Standard tier and Archive tier.

- The Performance Auto Tiering License necessary to create an SSD virtual disk group for both read and write capabilities comes standard with all MSA 2052 models. No additional software license purchase is necessary.

automatic tiering, 512 snapshots, and remote snaps for remote replication. The Advanced Data Services LTU requires license activation.

management.

Thin Provisioning also allows over-provisioning of physical storage pool resources allowing ease of growth for volumes without predicting storage capacity upfront.

HPE MSA 2050 LFF Disk Enclosure or HPE MSA 2050 SFF Disk Enclosure.

enclosures up to the maximum of 8 total enclosures.

most effective for workloads that are high in random reads. A maximum of 2 SSDs per pool can be added for read cache.

10.

is also getting a performance benefit of the additional spindles.

resource management. Administrators can monitor and optionally control snapshot space usage.

QuickSpecs

HPE MSA 2052 SAN Storage

Standard Features

Page 5

•

Product Technology

MSA 2052 Solution

MSA 2052 SAS controller supports 12Gb host connectivity.

Modular Chassis

controller fails over to its partner controller.

Available Drives

• Midline SAS hard disk drives (7.2K RPM) are optimized to provide the best ratio of capacity to cost.

Optional Disk Enclosures

ported 12Gb SSD, Enterprise SAS,

Non-disruptive on-line controller code upgrade. Requires Multi-pathing software.

• Upgradable by design. Owners of an MSA 2040, MSA 2042 and MSA 1040 array are able to do data-in-place upgrades to the MSA 2052 array. This unique ability protects the earlier investments in drives, and JBODs.

- Certain limitations are applicable. Please review the Upgrading to the HPE MSA 2050/2052 Technical Whitepaper

before upgrading your MSA 2040, MSA 2042 or MSA 1040 systems.

The MSA 2052 is a pre-configured bundle that includes an MSA 2050-branded LFF or SFF array chassis depending on model, two AC power supplies, two MSA 2050 SAN or SAS controllers, two 800GB Mixed Use SSDs, one Advanced Data Services LTU. The two 800GB SSDs are shipped integrated in the MSA 2050 array. The Advanced Data Services LTU is shipped with the MSA 2050 array and requires license activation.

SAN controller

MSA 2052 SAN controller supports 8Gb FC, 16Gb FC, 1GbE iSCSI or 10GbE iSCSI host connectivity. .

SAS controller

2U rack height. 12 LFF or 24 SFF drive bays. All MSA 2052 Storage Systems come standard with 2 SAN or SAS controllers depending on model

Notes: The MSA 2052 does not support single controller configurations. Single-controller support is provided only when a

The MSA 2052 SAN and SAS Storage systems support a wide variety of the MSA 3.5-inch LFF drives, and the MSA 2.5-inch SFF drives.

Solid-State Drives (SSDs) deliver the highest levels of performance and reliability.

•

Enterprise-class SAS hard disk drives (10K/15K RPM) offer a balance of performance, capacity, and cost while

•

delivering enterprise grade reliability.

Just as the user has a choice of chassis for the array enclosure (LFF or SFF drive bays), they also have a choice of expansion disk enclosures accommodating either drive size. Both the MSA 2050 LFF Disk Enclosure and MSA 2050 SFF Disk Enclosure can be hot added to an operating array. SFF and LFF Array enclosures and Disk Enclosures can be mixed without limitations.

MSA 2050 LFF Disk Enclosure.

This 2U enclosure is designed to support twelve HPE Storage LFF drives and accepts MSA dualand SAS Midline (MDL) hard drives. The pre-configured MSA 2050 LFF Disk Enclosure has two I/O modules and supports the MSA 2052 dual controller arrays.

• The MSA 2050 LFF Disk Enclosure can be attached to the MSA 2052 LFF or SFF storage models.

• Each MSA 2050 LFF Disk Enclosure ships standard with two .5m mini-SAS to mini-SAS cables for connection to the MSA

2052 array expansion port or existing disk enclosure cascade port.

• LFF and/or SFF Disk Enclosures can be mixed up to the maximum of 7 total Disk Enclosures

QuickSpecs

HPE MSA 2052 SAN Storage

Standard Features

Page 6

HPE MSA 2050 SFF Disk Enclosure

• LFF and/or SFF Disk Enclosures can be mixed up to the maximum of 7 total Disk Enclosures.

Scalability

(MDL) drives technology, form factors, sizes, speeds, and

combined with economical LFF drives staged for archival purposes, all in the same array.

Disk Group

Virtual Storage features.

LUNs

storage.

Storage Pools

are expanded data automatically reflows to balance capacity utilization on all drives.

RAID 0,1, 5, 6, 10

wo sets

(Striping) is supported for Read Cache only.

This 2U enclosure is designed to support twenty four HPE Storage 2.5-inch SFF drives and accepts MSA dual ported 12Gb SSD, Enterprise SAS, or SAS Midline (MDL) hard drives. The pre-configured MSA 2050 SFF Disk Enclosure has two I/O modules and supports the MSA 2052 dual controller arrays.

• The MSA 2050 SFF Disk Enclosure can be attached to the MSA 2052 LFF or SFF storage models

• Each MSA 2050 SFF Disk Enclosure ships standard with a two .5m mini-SAS to mini-SAS cables for connection to the

MSA 2052 array expansion port or existing disk enclosure cascade port.

The MSA 2052 array configurations are designed to allow an installation to begin with smaller capacity and be able to grow gradually as needed. The flexibility of SSD, Enterprise SAS or SAS Midline costs per GB allows a system to easily fit in almost any budget.

• Large Form Factor configurations can scale up to 168TB SAS MDL per array enclosure, expandable to 1344TB SAS MDL with the addition of a maximum of seven MSA 2050 LFF Disk Enclosure.

• Small Form Factor configurations can scale up to 76.8 TB SAS SSDs per array enclosure, expandable to 614.4 TB SAS with the addition of a maximum of seven MSA 2050 SFF Disk Enclosure.

• Users may configure an MSA 2052 SFF array enclosure with MSA 2050 LFF Disk Enclosure. This is an excellent option for a configuration that supports high-speed SFF SSDs or fast SFF enterprise-class SAS drives in the array enclosure,

A Disk Group is a collection of disks in a given redundancy mode (RAID 1, 5, 6, 10). Disk Group RAID level and size can be created based on performance and/or capacity requirements. Multiple Disk Groups can be allocated into a Storage Pool for use with the

The MSA 2052 arrays support 512 volumes and up to 512 snapshots in a system. All of these volumes can be mapped to LUNs. Maximum LUN sizes up to 140TB (128 TiB). Thin Provisioning allows the user to create the LUNs independent of the physical

Storage Pools are comprised of one or more Disk Groups. A volume’s data on a given LUN can now span all disk drives in a pool. When capacity is added to a system, users will benefit from the performance of all spindles in that pool.

The MSA 2052 supports large, flexible Volumes with sizes up to 128TiB and facilitates seamless capacity expansion. As volumes

The MSA 2052 features several important additional levels. RAID 6 offers the highest level of RAID protection. It allocates t of parity data across drives and allows simultaneous write operations. It can withstand two simultaneous drive failures without downtime or data loss. RAID 10 is mirroring and striping without parity and allows large Disk Groups to be created with high performance and mirroring for fault tolerance. RAID 5 combines the block striping and parity. Because data and parity are striped across all the disks, no single disk is a bottleneck. Striping also allows users to reconstruct data in case of a disk failure. RAID 0

QuickSpecs

HPE MSA 2052 SAN Storage

Standard Features

Page 7

Configuration and Management Tools

Protocols Supported SNMP, SMI-S, SSH, SMTP, FTP, SFTP, HTTP, HTTPS, Telnet

Web Browser support

Chrome.

Hot Plug Expansion and Replacement Support

I/O modules for simple, fast installation and maintenance. Hot add expansion of disk enclosures is also supported.

HPE Server Compatibility

Notes: depends on protocol.

3rd Party server support

HBAs and drivers, and supported FC switches.

OS Support

Notes: depends on protocol.

Management access, out-of-band, Storage Management Utility (SMU), CLI. Interface Types: USB 100/1000 Ethernet.

The MSA 2052 arrays come integrated with web browser and CLI based software for storage and RAID management, setup, configuration, and troubleshooting. The MSA 2052 management supports Microsoft Internet Explorer, Mozilla Firefox, and Google

All MSA 2052 models support hot plug expansion and replacement of redundant controllers, enclosures, fans, power supplies, and

The MSA 2052 supports most HPE ProLiant, BladeSystems and Integrity servers including

• HPE ProLiant DL, ML Servers

• HPE c-Class Blade Servers

• Integrity servers, IA64

• Compatibility must be confirmed at:

http://www.hpe.com/storage/spock

The MSA 2052 supports most multi-vendor industry standard Intel and AMD based (x86) servers. Hewlett Packard Enterprise requires the Third-Party Server to be logged and listed on the Microsoft Windows Server Catalog.

Refer to the Hewlett Packard Enterprise support statements for complete current OS version support

http://www.hpe.com/storage/spock

• Hewlett Packard Enterprise recommends that the Third-Party Server Vendor is an active member of TSANet. Refer to the TSANet website for details

: http://www.tsanet.com

• Non-HPE servers will generally be supported if the HPE storage stack is used. This includes supported HPE branded

• Microsoft Windows Server 2019

• Microsoft Windows Server 2016

• Microsoft Windows Server 2012

• VMware

• HP-UX

• Red Hat Linux

• SuSE SLES Linux

• Solaris

• Oracle Linux

• Citrix XenServer

• OpenVMS

QuickSpecs

HPE MSA 2052 SAN Storage

Standard Features

Page 8

Advanced Data Services Software Suite

• Remote Snap Software

Performance Tiering and Archive Tiering

LUN tiering and automated data movement between tiers. The MSA 2052 automated tiering engine

the highest available tier delivering maximum I/O´s to the application.

Snapshot and Volume Copy

• Backup 'snapped' data to disk, virtual tape, or physical tape without a backup window

Remote Snaps

HPE Remote Snap functionality is based on existing Snapshot technology offered by HPE MSA array products. Snapshots

The HPE MSA Advanced Data Service Suite is included as a standard feature on the MSA 2052 at no extra charge. The standard MSA Advanced Data Services Software Suite includes the following functionality:

• Performance Tiering and Archive Tiering Software

• 512 Snapshots and Volume Copy Software

Disk tiers are comprised of aggregating 1 or more Disk Groups of similar physical disks. The MSA 2052 supports 3 distinct tiers:

• A Performance tier with SSDs

• A Standard SAS tier with Enterprise SAS HDDs

• An Archive tier utilizing Midline SAS HDDs.

The MSA 2052 supports submoves data between available tiers based on the access characteristics of that data. Frequently accessed “pages” will migrate to

• 512 Snapshots and Volume Copy are standard features on the MSA 2052

• Snapshots create up to 512 point-in-time copies of data

• Volume Copies create up to 128 point-in-time copies of data

• Volume copies become standard volumes when they are complete

• Recovery is instant - revert data from any previous Snapshot or Volume Copy

• HPE MSA Remote Snap Software is array-based software that provides remote replication on the HPE MSA 2050 array

products. MSA Remote Snap is a form of asynchronous replication which consists of replication of block-level data from a volume on a local system to a volume on a second independent system. This second system may be co-located with the first system or may be located at a remote site.

•

are used to track the data to be replicated as well as to determine the differences in data updated on the primary volume, minimizing the amount of data to be transferred.

• HPE Remote Snap replication technology provides the ability to accomplish key data management and protection capabilities. First, because Remote Snap uses snapshots as the underlying technology it creates multiple local recovery points which can be used for such tasks as to complement daily backups; second, replication provides the ability to access data in a remote site which could be used for dispersed operations; and third but definitely not least important replication allows for business continuance in the event of a failure on the primary site.

• In order to perform a replication, a snapshot of the volume to be replicated is taken, creating a point-in-time image of the data. This point-in-time image is then replicated to the destination volume by copying the data represented by the snapshot via a transport medium such as TCP/IP (iSCSI) or Fibre Channel. The amount of data transferred is minimized though the use of snapshots whenever possible.

• Storage based asynchronous snapshot replication

• Support of both Ethernet and Fibre Channel interconnects provides flexible options to the application environments.

• Snapshot based replication technology means only changed data will be replicated to alternate site

• Many to 1 replication (up to 4 nodes) - primary use case is to replicate from "many" branch offices to the home office for

the purpose of backing up data from the branches

QuickSpecs

HPE MSA 2052 SAN Storage

Standard Features

Page 9

•

snapshot replication supports

arrays performing replication (from Primary system to Remote System), you will need a total of 2 licenses.

HPE OneView for VMware vCenter

https://h20392.www2.hpe.com/portal/swdepot/displayProductInfo.do?productNumber=HPVPR

Advanced scheduler provides several options to IT administrators for business continuance

• Flexible architecture allows remote replication between MSA 2052 and MSA 2040 or MSA 1040 arrays using the virtual storage architecture and licensed for Remote Snap. Protects existing investments and enhances business continuity planning objectives.

• Snapshot based replication enables both local and remote recovery depending on the need. Snapshot replication isolates problems to a specific point in time which can be selected by the administrator. Additionally, longer distance replication.

• Multiple relationships provide greater storage flexibility and utilization.

• 512 Snapshots and Volume Copy integration provides better efficiencies by combining the management and array

technologies to create local copies.

• Fast application recovery with minimal or no transaction loss

• Creation of disaster tolerant copies of your critical business data

• No-single-point-of-failure solution to increase the availability of your data

Notes: One Advanced Data Services Suite License per array is required for replication. For example, if you have two MSA

HPE OneView for VMware vCenter is a component within the HPE OneView plug-in for vCenter. It enables vSphere administrators to quickly obtain context-aware information and manage supported HPE storage devices like the MSA in their VMware vSphere environment directly from within vCenter. This plug-in operates independently of the core HPE OneView product and does not require a license to use. By providing a clear relationship between VM's, datastores and storage, the VMware administrator's productivity increases, as does the ability to ensure quality of service. Roles for administrators can be defined on an individual basis, providing the ability to apply specific permissions for both view and control functions.

HPE OneView for VMware vCenter supports mixed array environments including MSA Storage, and other HPE Storage systems including 3PAR Storage, Nimble Storage, StoreVirtual and StoreOnce. When deployed with MSA Storage, HPE OneView provides the following:

• Active Management functionality for the MSA Storage:

- Create/Expand/Delete a Datastore

- Create a Virtual Machine from a template

• Monitors the health and status of the MSA Storage

• Displays LUN / volume connections from VMs and ESX servers to the arrays and provides the location and attributes of

the MSA array within the SAN

• Identifies what storage features are available to allow administrators to match the features available on the MSA array to their requirements

• Provide a cluster-level view of the storage

HPE OneView for VMware vCenter is downloadable from Software Depot:

QuickSpecs

HPE MSA 2052 SAN Storage

Standard Features

Page 10

HPE OneView for System Center

System Center provides a comprehensive integration of HPE Storage, HPE Servers, HPE Blade System

https://h20392.www2.hpe.com/portal/swdepot/displayProductInfo.do?productNumber=System_Center

vStorage API for Array Integration (VAAI)

VAAI

UNMAP reclaims space that is no longer on a thinly provisioned VMFS volume

LDAP Support

• Ability to authenticate Local or LDAP users

I/O Workload Functionality

s are being processed by what

hot” pages in the array which

s tiering functionality, the MSA array’s tiering engine will

data the graph provides.

HPE OneView for Microsoft and HPE Virtual Connect with Microsoft System Center. HPE OneView for System Center enables management and monitoring of HPE MSA Storage running in Microsoft environment with a single pane-of-glass view to events/alerts, capacity and health dashboards and detailed virtual infrastructure information. It provides seamless integration with Microsoft System Center Operations Manager (SCOM) enabling predefined discovery and monitoring policies, event processing rules and topology views fo HPE Storage including the MSA Storage Systems.

When deployed with the MSA 2052 array, HPE OneView for System Center provides the following:

• Monitors the health, events and alerts for the MSA 2052 – virtual pools, and volumes

• Provides topology information for VMs provisioned on the MSA Storage array

HPE OneView for System Center is downloadable at no charge from Software Depot:

The vStorage API for Array Integration (VAAI) is one of the storage application programming interface (API) sets in vSphere. is an API storage partners can leverage to enhance performance of virtual machine (VM) management operations by delegating these operations to the storage array. With hardware offload, ESX/ESXi hosts perform certain operations faster and consume less server CPU, memory resources, and storage port/storage fabric bandwidth. VAAI includes high performance and scalable VM data path primitives.

Storage Hardware Primitives for VAAI

• Full Copy or Hardware Assisted Move

• Block Zeroing or Hardware Assisted Zeroing

• Hardware Assisted Locking or Atomic Test and Set (ATS)

LDAP (Lightweight Directory Access Protocol) is an industry standard application protocol for accessing and maintaining distributed directory information services over an IP network. LDAP provides the ability to authenticate MSA users with a central directory.

• Domain or Directory Credentials are not stored on the MSA for authentication – avoids a security issue

• Once user groups are configured on all MSAs in your organization, users can be authenticated on any MSA through the

Active Directory

• Uses an LDAP implementation to authenticate users with a Windows Active Directory

• The MSA CLI and SMU will allow the configuration of new LDAP users groups into the MSA security scheme (manage vs

monitor users, interface restrictions Web/CLI/FTP)

A user interface element called “I/O Workload” has been added to the main screen on MSA’s WBI home screen for GL270 or later firmware. The MSA array controllers keep track of a substantial amount of data pertaining to the I/O dynamics at a logical page level (4MB chunks). From this data, it is possible to provide some visibility to what percent (%) of I/O’ percent (%) of the overall array’s capacity across a 7 day timeline. While some workloads have “transient” data access patterns, many workloads have steady access patterns on small portions of the array’s capacity. This produces “ remain hot a large amount of the array’s uptime. Users would see substantial benefits if these pages could be served from the fastest media in the array (ideally SSDs).As has been described in the MSA’ work to position the hottest pages on the fastest media at any given time.

The I/O Workload graph will show a line labeled Capacity and a line plot for each selected workload percentage (100%, 80%, or Other% value). Below are two examples of user scenarios where the I/O Workload Graph might be useful and how to utilize the

QuickSpecs

HPE MSA 2052 SAN Storage

Standard Features

Page 11

•

y line as it may be

are working together in a user’s real-world environment.

ENERGY STAR Certification

consumption and regulatory rebates. Please refer to the US EPA website for details

on ENERGY STAR certification criteria and process. MSA 2052 ENERGY STAR Certification is listed on the EPA website.

Carrier-Grade Storage System (NEBS)

QuickSpecs on how to configure and order carrier-grade components.

TAA Compliance

section for more details regarding models that are designated TAA compliant.

Application Solutions

HPE MSA Storage hyperlink to: http://www.hpe.com/storage/MSA

New User or SSD Installation

- Once the MSA array is installed and has had workloads running against it for a week’s time, the I/O Workload data will

give a representation of what Capacity is servicing 100% of I/O and 80% of I/O. Users may select a custom % value if desired. In a new installation or in an installation with no SSD tier installed, the 80% line is a reasonable starting point for an SSD tier. Based on SSD RAID settings, customers can then calculate a good starting point with regard to SSD tier sizing based on that week’s workload. While not a hard-fast rule, it is a good starting point. These values should also be compared to the Best Practices “rule of thumb” which suggest that 5-15% of the array’s capacity should be SSDs for tiered solutions.

• Users with existing SSD tiering or read caching installed and running

- For arrays running with SSDs installed (tiered or read cache), the I/O Workload graph will have a dotted line which

shows the installed SSD capacity. The I/O Workload graphs can be checked periodically to see where the 80% I/O line is with regard to the SSD capacity line. While there are no hard and fast rules which indicate good/bad situations, users can use the graph with other system performance tools to better understand specific dynamics of their installation and the normal dynamics of a system in the day-to-day activities for a specific environment.

Interpreting the I/O Workload graphs allow users to strike a balance between the SSD costs versus performance benefits. For example, some customers may be willing to have a couple of days where peak usage is far above the SSD capacit acceptable to have slower performance as the system uses HDDs for a larger percentage of the workload I/O. This may be perfectly acceptable for systems sized to optimize $/TB due to budget constraints. Other users may want to optimize the system such that a sizeable percentage of daily I/O can reside on SSD media (sized to 80% or 90%). When combined with other performance monitoring tools, the I/O Workload function gives users some representation as to how the workloads and the MSA

The HPE MSA 2052 SAN Storage systems are ENERGY STAR certified. ENERGY STAR certified products are energy efficient which result in cost savings via reduced energy

The HPE MSA 2052 SAN Storage system does not offer a NEBS certified carrier-grade bundled solution. Refer to the MSA 2050

TAA refers to the Trade Agreements Act (19 U.S.C. § 2501–2581), which is intended to foster fair and open international trade. TAA requires that products must be produced or undergo “substantial transformation” within the United States or a designated country. HPE offers multiple 2050 and 2052 models that are TAA compliant. Please refer to the “Configuration Information”

The HPE MSA 2052 SAN Storage is the ideal solution for customers running Oracle, Microsoft, SAP environments and those customers who are deploying virtual server technologies like VMware and Hyper-V. The MSA 2052 delivers enterprise functionality that enhances virtual environments, simplifies management, and reduces costs. Easy to deploy, scale and maintain, HPE MSA 2052 Arrays ensure that crucial business data remains available.

Hewlett Packard Enterprise has developed best-in-class expertise in Oracle, Microsoft, SAP, and Virtualization Hypervisor technology through extensive testing with the HPE MSA 2052, HPE servers, and management software; high availability and disaster recovery solutions; and backup and recovery on the Oracle, Microsoft, and SAP application platforms.

Learn more

To learn more about specific HPE Storage Solutions that are built with Oracle, Microsoft, SAP and Virtualization environments in mind, visit the solution sites supporting each of these applications.

QuickSpecs

HPE MSA 2052 SAN Storage

Standard Features

Page 12

HPE Complete – Zerto

HPE MSA Storage users can leverage Zerto Virtual Replication to replicate applications and data from one MSA array to another

https://h20195.www2.hpe.com/v2/getdocument.aspx?docname=a00006013enw

HPE Complete – Arxscan

For more information please refer to HPE Complete on HPE.com

MSA Health Check Tool

http://www.hpe.com/storage/MSAHealthCheck

MSA array. Popular use cases include departmental MSA storage replicated to enterprise storage, enterprise storage replicated into MSA array, or protect MSA workloads into the cloud.

Zerto operates on the hypervisor level and includes orchestration and automation built-in to enable faster recovery of workloads (RTO in minutes) at much lower Recovery Point Objective (RPO of seconds) available through other data protection tools like backup. Zerto is also a workload mobility tool and allow IT to confidently move workloads and data across heterogeneous storage or cloud.

Ordering, configuring and installing Zerto is simple. Zerto is licensed by number of Virtual Machines that are being protected or moved. For mobility use cases, order the appropriate number of migration licenses needed. For replication use cases, order the appropriate quantity of Zerto Virtual Replication licenses using a combination of the tiered licenses plus the corresponding maintenance part numbers. The license is independent of source and target array size, type or capacity being replicated. See the HPE Complete/Zerto Quickspec for a complete list of part numbers. A corresponding MSA Advanced Data Services LTU is not required for data replication when using Zerto Virtual Replication. An MSA Advanced Data Services LTU would be required if deploying MSA array-based replication.

Zerto installs as a virtual machine under VMware or Hyper-V or in the Cloud as a VM in AWS and Azure in minutes Zerto does not install any components in the guest operating system and does not depend on any specific configuration of the storage or use MSA array or VMware snapshots to replicate and recover applications.

Zerto virtual replication is available on HPE Catalog via HPE Complete program. For more information on the HPE Complete – Zerto solution, visit;

Arxscan is an HPE Complete Partner delivering innovative software that drives value through unique enterprise data center monitoring and reporting. Arxscan provides infrastructure monitoring for Storage, Network, Servers and Applications. Arxscan is fully supported on the HPE MSA 1050, 2050 and 2052 storage arrays, and is available for purchase directly from HPE. Arxscan’s intuitive dashboard delivers an unprecedented view of how organizations store, distribute and protect their data, providing relevant views around device quality and performance metrics. Benefits include:

• Remote delivery from any location to any location worldwide.

• Supports all SAN/NAS storage OEM product lines, SAN switch and server OS platforms without agents.

• Quickly installed in under two hours in SMB, midrange or enterprise customer environments.

• Presents views that are business operations and infrastructure/system operations centric.

• Creates global collaborative touch points for all users of local and remote data center resources.

• One Stop Shop – ability to purchase complete solutions from HPE that include both HPE products and best-in-class third

party branded products, all on a single HPE purchase order.

MSA Health Check is a cloud-based tool that provides users insight into the general health of their MSA array. The tool uses a powerful rules-based analytics engine which can predict failures before they happen. The MSA Health Check tool performs a full sweep of analytics and checking thousands of data points from sensors inside the MSA array. The analytics engine will pick up common failure signatures and check against MSA best practices producing a simple, easy to digest PDF report with status and suggested courses of action to correct anything found in the scan. The tool is free of charge to HPE MSA customers. The MSA Health Check tool is supported across all current MSA 1050/2050/2052 arrays as well as the prior two generations of arrays (MSA P2000 G3 and MSA 1040/2040/2042). The tool is available immediately at:

QuickSpecs

HPE MSA 2052 SAN Storage

Service and Support

Page 13

Warranty

- Firmware updates beyond the 3 year warranty period requires a support contract.

Solid State Drives (SSD) Warranty

inside the MSA array. Warranties of these components are unaffected by any substitution.

Service and Support

simple.

Connect your devices

failure alerts, automatic call logging, and automatic parts dispatch. HPE Proactive

http://www.hpe.com/services

Three-year limited warranty, parts exchange Next Business day delivery.

3 Years 9x5 telephone support, with Rights to New Versions bundled with the MSA 2052. Disk enclosures, Hard drives, and Options for the MSA 2052 carry their own warranty. Refer to

Hewlett Packard Enterprise Limited Warranty Statement

The MSA 2052 has been designed with customer self-repairable parts to minimize repair time and provide greater flexibility in performing defective parts replacement. Please refer to Hewlett Packard Enterprise limited warranty Statement and parts replacement instructions for further details.

Notes:

- The warranty of the hard drive options purchased with the MSA 2052 models is different for SAS hard drives versus SAS

MDL. SAS hard drive options have a three year warranty and SAS MDL have a one year warranty.

3/0/0 warranty; Customer Self Repair (CSR) subject to maximum usage and or maximum supported lifetime limitations, whichever occurs first. Maximum Supported Lifetime is the period in years set to equal the warranty for the device. Maximum usage limit is the maximum amount of data that can be written to the device before reaching the device's write endurance limit.

Notes: SSDs used for replacement will be of equal or greater capacity and are designed to meet or exceed the original SSD warranty. Replacement drive/s could be of the same model drive or of a different model qualified to operate interchangeably

for more information.

Protect your business beyond warranty with HPE Support Services

HPE Pointnext provides a comprehensive portfolio including Advisory and Transformational, Professional, and Operational Services to help accelerate your digital transformation. From the onset of your transformation journey, Advisory and Transformational Services focus on designing the transformation and creating a solution roadmap. Professional Services specializes in creative configurations with flawless and on-time implementation, and on-budget execution. Finally, operational services provide innovative new approaches like Flexible Capacity and Datacenter Care, to keep your business at peak performance. HPE is ready to bring together all the pieces of the puzzle for you, with an eye on the future, and make the complex

Unlock all of the benefits of your technology investment by connecting your products to Hewlett Packard Enterprise. Achieve up

to 77%

reduction in down time, near 100%2 diagnostic accuracy and a single consolidated view of your environment. By connecting, you will receive 24x7monitoring, preCare Service and HPE Datacenter Care Service customers will also benefit from proactive activities to help prevent issues and increase optimization. All these benefits are already available to you with your server storage and networking products, securely connected to HPE support

Notes:

IDC

HP CSC reports 2014-2015

Learn more about getting connected at

QuickSpecs

HPE MSA 2052 SAN Storage

Service and Support

Page 14

Optimized Care Standard Care

https://www.hpe.com/h20195/v2/GetPDF.aspx/4AA3-8855ENW.pdf

Basic Care

https://www.hpe.com/h20195/V2/GetDocument.aspx?docname=4AA4-8876ENW&cc=us&lc=en

Foundation Care

https://www.hpe.com/h20195/V2/GetDocument.aspx?docname=4AA4-8876ENW&cc=us&lc=en

Related Services

HPE Hardware Installation

options to assist you in bringing your new hardware into operation in a timely and professional manner.

HPE Installation and Startup Service

Included the HPE MSA 1050.

HPE Proactive Care with 6 hour call-to-repair commitment, three year Support Service

HPE Proactive Care gives customers an enhanced call experience. When your products are connected to HPE, Proactive Care helps prevent problems and maintains IT stability by utilizing personalized proactive reports with recommendations and advice.

This Service combines three years’ proactive reporting and advice with our highest level of hardware support; the HPE 24x7, six hour hardware call-to-repair. HPE is the only leading manufacturer who makes this level of coverage available as a standard service offering for your most valuable servers and storage, including the HPE MSA 2050/2052 Storage.

https://www.hpe.com/h20195/v2/GetPDF.aspx/4AA3-8855ENW.pdf

HPE Proactive Care with 24x7 coverage, three year Support Service

This Service combines three years proactive reporting and advice with our 24x7 coverage, four hour hardware response time when there is a problem.

HPE Foundation Care 24x7, three-year Support Service

HPE Foundation Care 24x7 gives you access to HPE 24 hours a day, seven days a week for assistance on resolving issues. This service includes need-based Hardware onsite response within four hours. In addition, collaborative software support is included in this service that provides troubleshooting assistance on industry leading software running on your HPE server. Simplify your support experience and make HPE your first call to help resolve hardware or software problems.

Provides for the basic hardware installation of HPE branded servers, HPE storage including the MSA 1050 devices and networkin

Provides for the installation and startup of HPE technology including BladeSystems, C-Class enclosure, HPE ProLiant c-Class and Integrity server blades, storage blades, SAN switch blades, HPE Virtual Connect modules (Ethernet and Fibre Channel), Ethernet network interconnects, and InfiniBand, as well as the installation of one supported operating system type (Windows® or Linux).

QuickSpecs

HPE MSA 2052 SAN Storage

Service and Support

Page 15

HPE Datacenter Care service

accountability for HPE and others’ products.

HPE Factory Express for Servers and Storage

simple configuration, racking, installation, complex configuration and design services as

f servers and storage: HPE Integrity, HPE ProLiant, HPE Apollo, HPE ProLiant Server Blades,

configurable network switches.

HPE Support Center

Parts and Materials

Enterprise due to malfunction.

Helps improve IT stability and security, increase the value of IT, and enable agility and innovation. It is a structured framework of repeatable, tested, and globally available services “building blocks.” You can deploy, operate, and evolve your datacenter wherever you are on your IT journey. With HPE Datacenter Care, you benefit from a personalized relationship with HPE via a single point of

HPE Factory Express offers configuration, customization, integration and deployment services for HPE servers and storage products. Customers can choose how their factory solutions are built, tested, integrated, shipped and deployed.

Factory Express offers service packages for well as individual factory services, such as image loading, asset tagging, and custom packaging. HPE products supported through Factory Express include a wide array o HPE BladeSystem, HPE 9000 servers as well as the HPE MSA Storage, HPE 3PAR Storage, HPE XP, rack-mount tape libraries and

The HPE Support Center is a personalized online support portal with access to information, tools and experts to support HPE business products. Submit support cases online, chat with Hewlett Packard Enterprise experts, access support resources or collaborate with peers. Learn more http://www.hpe.com/support/hpesc

HPE Insight Remote Support and HPE Support Center are available at no additional cost with a HPE warranty, HPE Support Service or HPE contractual support agreement.

For more information: http://www.hpe.com/services

Hewlett Packard Enterprise will provide HPE-supported replacement parts and materials necessary to maintain the covered hardware product in operating condition, including parts and materials for available and recommended engineering improvements.

Parts and components that have reached their maximum supported lifetime and/or the maximum usage limitations as set forth in the manufacturer's operating manual, product quick-specs, or the technical product data sheet will not be provided, repaired, or replaced as part of these services.

The defective media retention service feature option applies only to Disk or eligible SSD/Flash Drives replaced by Hewlett Packard

QuickSpecs

HPE MSA 2052 SAN Storage

Configuration Information

Page 16

Step 1 - MSA 2052 - Base Configurations

Pre-Configured Systems

Description

SKU

HPE MSA 2052 SAN Dual Controller LFF Storage

Q1J02B

HPE MSA 2052 SAN Dual Controller LFF TAA-compliant Storage

R4Y03A

Notes:

HPE MSA 2052 SAN Dual Controller SFF Storage

Q1J03B

HPE MSA 2052 SAN Dual Controller SFF TAA-compliant Storage

R4Y04A

Notes:

HPE MSA 2052 SAS Dual Controller LFF Storage

Q1J30B

HPE MSA 2052 SAS Dual Controller LFF TAA-compliant Storage

R4Y05A

Notes:

HPE MSA 2052 SAS Dual Controller SFF Storage

Q1J31B

HPE MSA 2052 SAS Dual Controller SFF TAA-compliant Storage

R4Y06A

Notes:

- The MSA 2052 is a pre-configured bundle that includes an MSA 2050-branded LFF array chassis, two AC power supplies,

two MSA 2050 SAN controllers, two 800GB Mixed Use SSDs, one Advanced Data Services LTU, two .7m PDU cords (IEC C14), and one rack-mount kit. The two 800GB SSDs are shipped integrated in the MSA 2050 array. The Advanced Data Services LTU is shipped with the MSA 2050 array and requires license activation.

- SFPs not included.

- The MSA 2052 is a pre-configured bundle that includes an MSA 2050-branded SFF array chassis, two AC power supplies,

- SFPs not included.

- The MSA 2052 is a pre-configured bundle that includes an MSA 2050-branded LFF array chassis, two AC power supplies,

two MSA 2050 SAS controllers, two 800GB Mixed Use SSDs, one Advanced Data Services LTU, two .7m PDU cords (IEC C14), and one rack-mount kit. The two 800GB SSDs are shipped integrated in the MSA 2050 array. The Advanced Data Services LTU is shipped with the MSA 2050 array and requires license activation.

- SFPs are not required for SAS Storage systems.

- The MSA 2052 is a pre-configured bundle that includes an MSA 2050-branded SFF array chassis, two AC power supplies,

- SFPs are not required for SAS Storage systems.

QuickSpecs

HPE MSA 2052 SAN Storage

Configuration Information

Page 17

Step 2 – Choose Your SFP+ Module

SFP+ Modules

Description

SKU

HPE MSA 8Gb Short Wave Fibre Channel SFP+ 4-pack Transceiver

C8R23B

HPE MSA 16Gb Short Wave Fibre Channel SFP+ 4-pack Transceiver

C8R24B

HPE MSA 10Gb Short Range iSCSI SFP+ 4-pack Transceiver

C8R25B

HPE MSA 1Gb RJ-45 iSCSI SFP+ 4-pack Transceiver

C8S75B

Notes:

Configuration Table for mixing SFPs

Configuration

Controller

Host Port 1 SFP

Host Port 2 SFP

Host Port 3 SFP

Host Port 4 SFP

Dual SAN

Controller A

16Gb FC

None

16Gb FC

8Gb FC

10GbE iSCSI

1GbE iSCSI

8Gb FC

None

16Gb FC

8Gb FC

10GbE iSCSI

1GbE iSCSI

10GbE iSCSI

None

10GbE iSCSI

1GbE iSCSI

None

10GbE iSCSI

1GbE iSCSI

Controller B

Match Controller A

Notes:

Step 3 – Select Your Drives

MSA HDDs and SSDs drives are for use with MSA Storage Systems only. Customers can mix SSD, SAS, and SAS MDL drives in the same array enclosure and disk enclosure

SFF SSDs

HPE MSA 800GB 12G SAS Mixed Use SFF (2.5in) 3yr Warranty Solid State Drive

N9X96A

HPE MSA 1.6TB 12G SAS Mixed Use SFF (2.5in) 3yr Warranty Solid State Drive

N9X91A

HPE MSA 3.2TB 12G SAS Mixed Use SFF (2.5in) 3yr Warranty Solid State Drive

N9X92A

HPE MSA 960GB SAS 12G Read Intensive SFF (2.5in) 3yr Wty SSD

R0Q35A

- MSA SFPs are for use only with MSA 2052 SAN Controllers.

- MSA SAS controllers do not require SFP modules.

- MSA 2052 SAN Controllers do not ship with any SFPs.

- Customer must select at least one of the above SFP options.

- Each MSA 2052 SAN controller can be configured with 2 or 4 SFPs.

For MSA 2052 10Gb iSCSI configuration, DAC cables can be used instead of SFPs.

Controller

- 1 SFP in Host Port 1 must match SFP in Host Port 2

SFP in Host Port 3 must match SFP in Host Port 4

QuickSpecs

HPE MSA 2052 SAN Storage

Configuration Information

Page 18

Description

SKU

HPE MSA 1.92TB SAS 12G Read Intensive SFF (2.5in) 3yr Wty SSD

R0Q37A

SFF HDDs

12G SFF 15K SAS Enterprise HDDs

HPE MSA 600GB 12G SAS 15K SFF(2.5in) Dual Port Enterprise 3yr Warranty Hard Drive

J9F42A

HPE MSA 900GB 12G SAS 15K SFF (2.5in) Enterprise 3yr Warranty Hard Drive

Q1H47A

12G SFF 10K SAS Enterprise HDDs

HPE MSA 600GB 12G SAS 10K SFF(2.5in) Dual Port Enterprise 3yr Warranty Hard Drive

J9F46A

HPE MSA 1.2TB 12G SAS 10K SFF(2.5in) Dual Port Enterprise 3yr Warranty Hard Drive

J9F48A

HPE MSA 1.8TB 12G SAS 10K SFF (2.5in) 512e Enterprise 3yr Warranty Hard Drive

J9F49A

HPE MSA 2.4TB 12G SAS 10K SFF (2.5in) Enterprise 512e 3yr Warranty Hard Drive

Q2R41A

LFF SSDs

HPE MSA 800GB 12G SAS Mixed Use LFF (3.5in) Converter Carrier 3yr Wty Solid State Drive

P9M80A

HPE MSA 960GB SAS 12G Read Intensive LFF (3.5in) 3yr Wty SSD

R0Q36A

HPE MSA 1.92TB SAS 12G Read Intensive LFF (3.5in) 3yr Wty SSD

R0Q38A

LFF HDDs

12G LFF 7.2K SAS Midline Drives

HPE MSA 4TB 12G SAS 7.2K LFF (3.5in) Midline 1yr Warranty Hard Drive

K2Q82A

HPE MSA 6TB 12G SAS 7.2K LFF(3.5in) Midline 1yr Warranty Hard Drive

J9F43A

HPE MSA 8TB 12G SAS 7.2K LFF (3.5in) 512e Midline 1yr Warranty Hard Drive

M0S90A

HPE MSA 10TB 12G SAS 7.2K rpm LFF (3.5in) Midline 512e 1yr Wty Hard Drive

P9M82A

HPE MSA 12TB 12G SAS 7.2K LFF (3.5in) Midline 512e 1yr Warranty Hard Drive

Q2R42A

HPE MSA 14TB SAS 12G Midline 7.2K LFF (3.5in) 1yr Wty 512e HDD

R0Q21A

6-Pack Drive Bundles

SFF Drive Bundles

Notes: Contains 6 x MSA 1.2TB 12G SAS 10K SFF Enterprise HDDs (J9F48A)

Notes: Contains 6 x MSA 900GB 12G SAS 15K SFF Enterprise HDDs (Q1H47A)

HPE MSA 7.2TB SAS 12G Enterprise 10K SFF (2.5in) 3yr Wty 512n 6-pack HDD Bundle R0P85A

HPE MSA 10.8TB SAS 12G Enterprise 10K SFF (2.5in) 3yr Wty 512e 6-pack HDD Bundle R0P86A

Notes: Contains 6 x MSA 1.8TB 12G SAS 10K SFF Enterprise HDDs (J9F49A)

HPE MSA 14.4TB SAS 12G Enterprise 10K SFF (2.5in) 3yr Wty 512e 6-pack HDD Bundle

Notes: Contains 6 x MSA 2.4TB 12G SAS 10K SFF Enterprise HDDs (Q2R41A)

HPE MSA 3.6TB SAS 12G Enterprise 15K SFF (2.5in) 3yr Wty 512n 6-pack HDD Bundle

Notes: Contains 6 x MSA 600GB 12G SAS 15K SFF Enterprise HDDs (J9F42A)

HPE MSA 5.4TB SAS 12G Enterprise 15K SFF (2.5in) 3yr Wty 512n 6-pack HDD Bundle

R0P87A

R0P88A

R0P89A

QuickSpecs

HPE MSA 2052 SAN Storage

Configuration Information

Page 19

LFF Drive Bundles

Description

SKU

Notes:

Step 4 – Options

Disk Enclosures

HPE MSA 2050 LFF Disk Enclosure

Q1J06B

HPE MSA 2050 SFF Disk Enclosure

Q1J07B

Notes:

with your local HPE sales representative or partner regarding current availability.

SAS Cables

HPE External Mini SAS 1m Cable ALL

407337-B21

HPE External Mini SAS 2m Cable

407339-B21

Notes: When connecting a MSA 2052 Controller to a disk enclosure if a longer cable is needed or desired.

Power Cords

HPE C13 - C14 WW 250V 10Amp 2.0m Jumper Cord

A0K02A

HPE C13 - C14 WW 250V 10Amp Flint Gray 2.0m Jumper Cord

AF573A

HPE C13 - AS3112-3 AU 250V 10Amp 2.5m Power Cord

AF569A

HPE C13 - BS-1363A UK/HK/SG 250V 10Amp 1.83m Power Cord

AF570A

HPE C13 - C14 WW 250V 10A Gray 0.7m Jumper Cord

A0K03A

HPE C13 - CEE-VII EU 250V 10Amp 1.83m Power Cord

AF568A

HPE C13 - CNS-690 TW 110V 13Amp 1.83m Power Cord

AF561A

HPE C13 - DK-2.5A DK 250V 10Amp 1.83m Power Cord

AF566A

HPE C13 - GB-1002 CN 250V 10Amp 1.83m Power Cord

AF557A

HPE MSA 48TB SAS 12G Midline 7.2K LFF (3.5in) 1yr Wty 512e 6-pack HDD Bundle R0P90A

Notes: Contains 6 x MSA 8TB 12G SAS 7.2K LFF Midline HDDs (M0S90A)

HPE MSA 60TB SAS 12G Midline 7.2K LFF (3.5in) 1yr Wty 512e 6-pack HDD Bundle

Notes: Contains 6 x MSA 10TB 12G SAS 7.2K LFF Midline HDDs (P9M82A)

HPE MSA 72TB SAS 12G Midline 7.2K LFF (3.5in) 1yr Wty 512e 6-pack HDD Bundle

Contains 6 x MSA 12TB 12G SAS 7.2K LFF Midline HDDs (Q2R42A)

HPE MSA 84TB SAS 12G Midline 7.2K LFF (3.5in) 1yr Wty 512e 6-pack HDD Bundle

Notes: Contains 6 x MSA 14TB 12G SAS 7.2K LFF Midline HDDs (R0Q21A)

R0P91A

R0P92A

R0Q22A

- Each disk enclosure includes a single rack-mount kit and two 0.5m MiniSAS to MiniSAS cables

- Add up to 7 expansion disk enclosures.

- MSA 2052 LFF Disk Enclosure can be connected to either the MSA 2052 SFF or LFF dual controller systems.

- HPE MSA 2052 SFF Disk Enclosure can be connected to either the MSA 2052 SFF or LFF dual controller systems.

- Models Q1J06A and Q1J07A may continue to have limited availability in Americas and Asia-Pacific regions. Please check

QuickSpecs

HPE MSA 2052 SAN Storage

Configuration Information

Page 20

Description

SKU

HPE C13 - IRAM -2073 AR 250V 10A 2.5m Power Cord

AF558A

HPE C13 - IS-1293 IN 240V 6Amp LV 2.0m Power Cord

AF562A

HPE C13 - JIS C8303 JP 100V 12Amp 2.0m Power Cord

AF572A

HPE C13 - KSC- 8305 KR 250V 10Amp 1.83m Power Cord

AF560A

HPE C13 - NBR-14136 BR 250V 10Amp 1.83m Power Cord

AF591A

HPE C13 - Nema 5-15P US/CA 110V 10Amp 1.83m Power Cord

AF556A

HPE C13 - SABS-164 ZA 250V 10Amp 2.5m Power Cord

AF567A

HPE C13 - SEV 1011 CH 250V 10Amp 1.83m Power Cord

AF565A

HPE C13 - SI-32 IL 250V 10Amp 1.83m Power Cord

AF564A

HPE C13-NEMA 6-15P 10A/250V 3.6m Black Power Cord

A0N33A

Notes: Two PDU cables: one 142263-008 (Black) and one 1422633-013 (Grey), ship standard with all AC-powered enclosures.

Step 5

Step 5a - Choose Supported Options For Fibre Channel Infrastructure

PremierFlexOM4 type cables

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 1m Cable

QK732A

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 2m Cable

QK733A

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 5m Cable

QK734A

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 15m Cable

QK735A

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 30m Cable

QK736A

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 50m Cable

QK737A

OM3 LC-LC cables

HPE LC to LC Multi-mode OM3 2-Fiber 0.5m 1-Pack Fiber Optic Cable

AJ833A

HPE LC to LC Multi-mode OM3 2-Fiber 1.0m 1-Pack Fiber Optic Cable

AJ834A

HPE LC to LC Multi-mode OM3 2-Fiber 2.0m 1-Pack Fiber Optic Cable

AJ835A

HPE LC to LC Multi-mode OM3 2-Fiber 5.0m 1-Pack Fiber Optic Cable

AJ836A

HPE LC to LC Multi-mode OM3 2-Fiber 15.0m 1-Pack Fiber Optic Cable

AJ837A

HPE LC to LC Multi-mode OM3 2-Fiber 30.0m 1-Pack Fiber Optic Cable

AJ838A

HPE LC to LC Multi-mode OM3 2-Fiber 50.0m 1-Pack Fiber Optic Cable

AJ839A

Step 5b - Choose Supported Options For 10GbE Infrastructure

Direct Attach Copper Cables

Aruba 10G SFP+ to SFP+ 1m Direct Attach Copper Cable

J9281D

Aruba 10G SFP+ to SFP+ 3m Direct Attach Copper Cable

J9283D

Aruba 10G SFP+ to SFP+ 7m Direct Attach Copper Cable

J9285D

HPE BladeSystem c-Class 10GbE SFP+ to SFP+ 3m Direct Attach Copper Cable

487655-B21

HPE BladeSystem c-Class 10GbE SFP+ to SFP+ 5m Direct Attach Copper Cable

537963-B21

HPE FlexNetwork X240 10G SFP+ to SFP+ 0.65m Direct Attach Copper Cable

JD095C

QuickSpecs

HPE MSA 2052 SAN Storage

Configuration Information

Page 21

Description

SKU

HPE FlexNetwork X240 10G SFP+ to SFP+ 1.2m Direct Attach Copper Cable

JD096C

HPE FlexNetwork X240 10G SFP+ to SFP+ 3m Direct Attach Copper Cable

JD097C

HPE FlexNetwork X240 10G SFP+ to SFP+ 5m Direct Attach Copper Cable

JG081C

HPE FlexNetwork X240 10G SFP+ SFP+ 7m Direct Attach Copper Cable

JC784C

Step 5c - Choose Supported Options for SAS Infrastructure

Supported options

Mini SAS Cables

HPE 1.0m External Mini SAS High Density to Mini SAS Cable

716189-B21

HPE 2.0m External Mini SAS High Density to Mini SAS Cable

716191-B21

Notes: These cables are used to connect 6Gb SAS initiator to MSA 2050 SAS controller. These are not used for connecting to a

disk enclosure.

HPE External 1.0m (3ft) Mini-SAS HD 4x to Mini-SAS HD 4x Cable

716195-B21

HPE External 2.0m (6ft) Mini-SAS HD 4x to Mini-SAS HD 4x Cable

716197-B21

Notes: These cables are used to connect 12Gb SAS initiator to MSA 2050 SAS controller. These are not used for connecting to a disk enclosure.

HPE 4.0m External Mini SAS High Density to Mini SAS Cable

716193-B21

Notes: This cable is used to connect 6Gb SAS initiator to MSA 2050 SAS controller. This is not used for connecting to a disk enclosure.

HPE External 4.0m (13ft) Mini-SAS HD 4x to Mini-SAS HD 4x Cable

716199-B21

Notes: These cables are used to connect 12Gb SAS initiator to MSA 2050 SAS controller. These are not used for connecting to

SAS Controllers/HBAs

HPE Smart Array E208e-p SR Gen10 (8 External Lanes/No Cache) 12G SAS PCIe Plug-in Controller

804398-B21

HPE Smart Array P408e-p SR Gen10 (8 External Lanes/4GB Cache) 12G SAS PCIe Plug-in Controller

804405-B21

HPE Smart Array P408e-m SR Gen10 (8 External Lanes/2GB Cache) 12G SAS Mezzanine Controller

804381-B21

Step 6 – Software

The MSA Advanced Data Services Software Suite comes standard on the MSA 2052. No optional software titles are available on the MSA 2052.

a disk enclosure

QuickSpecs

HPE MSA 2052 SAN Storage

Technical Specifications

Page 22

MSA 2052

Power requirements

Input Power Requirements

SFF/LFF arrays

110VAC 3.32A, 344-390 W; 220VAC 1.61A,374-432W

Max Input Power

100-240 VAC, 50/60 Hz., 4.5-1.9A; 48-60 VDC 10.4A/8.3A

Heat Dissipation

1622 BTU/hr

Temperature and humidity ranges

Operating Temperature

41°F to 104°F (5°C to 40°C)

Shipping Temperature

-40°F to 158°F (-40°C to 70°C)

Operating Humidity

10% to 90% RH @ 104°F (40°C) non-condensing

Non-Operating Humidity

Up to 93% RH @ 104°F (40°C)

Declared acoustic noise levels

Sound Power

A weighted sound power LWAd=6,75 B

Sound Pressure

A weighted sound pressure LpAm - 55dB

Shock and vibration

Shock, Operational

3G's for 11 milliseconds

Shock, Non-Operational

15G 11ms half sine

Vibration, Operational

5-500Hz, 0.14 Grms shaped

Vibration, Non-Operational

3-365-3Hz, 1.22 Grms, z-axis,0.85 Grms, X&Y axis shaped spectrum

Physical

Height

3.5 in/ 8.9 cm

Depth (excluding cables) (back of ear to back of controller handle)

SFF 24-bay array: 19.5 in / 49.5 cm LFF 12-bay array: 22.5in. / 57.2 cm

Width (body only)

17.6 in / 44.7 cm (w/ ears 19 in / 48.26 cm)

Weight (Includes chassis and 2 controllers. No drives)

LFF chassis: 40.6 lbs. SFF chassis: 38.7 lbs

(typical-running I/O)

QuickSpecs

HPE MSA 2052 SAN Storage

Technical Specifications

Page 23

Performance

configurations. These end-to-end performance numbers are subject to change without notice.

MSA 2052 End-to-End Performance Results

MSA 2050 Array Performance 1

HPE MSA 2052 Converged SAN Controllers with HDDs

HPE MSA 2052 Converged SAN Controllers with SSDs

Protocol (host connect)

16 Gb Fibre Channel

MSA 2050 RAID 1 SSD Performance Results 2

Random Reads (IOPs)

220,600

Random Writes (IOPs)

102,800

MSA 2050 RAID 5 Performance Results

3,4

Segmented Sequential Reads (MB/s)

5,280

Segmented Sequential Writes (MB/s)

4,650

Notes: End-to-End performance notes

Other types of sequential workloads that target specific LBA ranges may achieve higher results.

The performance figures provided here are for reference as many variables exist between array configurations, workloads, hard drive types, disk group setup parameters and host system setup. Hewlett Packard Enterprise has traditionally published a set of end-to-end MSA performance specifications that are fed into HPE Sizer tools which are based on conservative real-world

- 1Performance results were generated using internal HPE test tools. Number and type of applications, drive type and

number of drives, operating system used, and the number of hosts will affect overall performance. This table is provided strictly as a test-lab comparison.

Dual Controller configuration, (8) SSDs, RAID: 1, two drives per Disk Group; two Disk Groups per Pool, 2 volumes per Pool,

block size: 8k, average latency under 5ms, Windows Server 2012 host, 16Gb FC direct connect to array.

Dual Controller configuration, (72) 15k HDD, RAID: 5, nine drives per Disk Group, 4 Disk Groups per Pool, 32 volumes per

Pool, block size: 256k, average latency under 30ms, Windows Server 2012 host, 16Gb FC direct connect to array.

Sequential performance numbers were generated using segmented sequential workloads. For segmented sequential

workloads with a queue depth greater than 1, each sequential stream is targeted to operate on a separate LBA range.

QuickSpecs

HPE MSA 2052 SAN Storage

Technical Specifications

Page 24

End-to-End Performance Figures using Virtual Storage

HPE MSA 2050 End-to-End Performance Figures 1

Controller Model

HPE MSA 2050 SAN

HPE MSA 2050 SAS

Host Protocol 2

16 Gb FC

10 GbE iSCSI

1 GbE iSCSI

12 Gb SAS

Drive Technology

HDD

SSD

HDD

SSD

HDD

SSD

HDD

SSD

MSA 2050 RAID 10 Performance Results

Random Reads IOPS

63,600

220,800

63,500

208,400

63,200

103,700

50,800

219,100

Random Writes IOPS

37,300

103,000

37,300

94,300

37,200

93,300

37,100

97,500

Random Mix 60/40 IOPS

47,600

142,100

46,600

133,000

46,800

130,500

44,500

138,800

Sequential Reads MB/s

5,350

880 5,350

Sequential Writes MB/s

3,110

880 3,120

MSA 2050 RAID 5 Performance Results

Random Reads IOPS

56,300

219,200

55,800

201,400

56,000

103,400

47,300

209,600

Random Writes IOPS

18,100

43,400

18,000

41,400

18,300

40,600

18,000

43,100

Random Mix 60/40 IOPS

29,100

80,000

29,200

75,400

28,700

73,900

28,000

78,700

Sequential Reads MB/s

5,290

5,280

880 5,290

Sequential Writes MB/s

4,650

3,870

880 4,710

Controller Model

HPE MSA 2050 SAN

HPE MSA 2050 SAS

MSA 2050 RAID 6 Performance Results

Random Reads IOPS

56,100

219,000

55,700

201,300

55,700

105,000

47,400

209,800

Random Writes IOPS

13,000

36,000

13,000

35,600

13,200

35,300

13,000

36,700

Random Mix 60/40 IOPS

21,400

72,200

21,200

68,500

21,300

67,300

21,300

71,500

Sequential Reads MB/s

5,550

5,530

880 5,560

Sequential Writes MB/s

4,440

3,680

880 4,600

Notes:

MSA 2040 RAID 10 Hard Disk Drive sequential read results: Dual Controller configuration, (96) 15K SAS HDDs, 12 drives

group, 4 disk groups per pool, 4 volumes per pool.

3,4,5,11

6,7,12

8,9,10,13

- **RAID 1 was used for SSD testing.

- Number and type of applications, drive type and number of drives, operating system used, and the number of hosts will

affect overall performance. This table is provided strictly as a test-lab comparison. These numbers reflect a full array configuration with the maximum number of front-end ports and controllers. The test results shown for the HPE MSA 2050 are designed to give a conservative reference point for comparisons.

Sequential tests (MB/s) are based on 256K block sizes and random tests (IOPS) are based on 8K block sizes run against the storage. For sequential workloads with a queue depth greater than 1, each sequential stream is targeted to operate on a separate LBA range. Other types of sequential workloads that target specific LBA ranges may achieve higher results. Results cannot be expected with a single host.

- 2Fibre Channel results were measured using 16 Gb FC Host Bus Adapters. SAS results were measured using 12 Gb SAS

Host Bus Adapters. 10 GbE iSCSI results were measured using 10GbE iSCSI Host Bus Adapters. 1 GbE iSCSI results were measured using 1GbE network interface controllers (NICs). Hosts were directly attached to the HPE MSA 2050 array.

MSA 2050 RAID 10 Hard Disk Drive random results: Dual Controller configuration, (192) 15K HDD, 12 drives per disk group, 8 disk groups per pool, 8 volumes per pool.

per disk group, 4 disk groups per pool, 4 volumes per pool.

- 5MSA 2040 RAID 10 Hard Disk Drive sequential write results: Dual Controller configuration, (48) 15K SAS HDDs, 12

drives per disk group, 2 disk groups per pool, 4 volumes per pool.

MSA 2050 RAID 5 Hard Disk Drive random results: Dual Controller configuration, (180) 15K HDD, 9 drives per disk group, 10 disk groups per pool, 10 volumes per pool.

- 7MSA 2050 RAID 5 Hard Disk Drive sequential results: Dual Controller configuration, (72) 15K HDD, 9 drives per disk

QuickSpecs

Technical Specifications

Page 25

- 8MSA 2050 RAID 6 Hard Disk Drive random results: Dual Controller configuration, (180) 15K HDD, 10 drives per disk

per pool, 4 volumes per pool.

MSA 2052 Regulatory Info

Safety

Notes: India and EAC are not covered for TAA compliant MSA Array models.

HPE MSA 2052 SAN Storage

group, 9 disk groups per pool, 9 volumes per pool.

- 9MSA 2050 RAID 6 Hard Disk Drive sequential read results: Dual Controller configuration, (80) 15K HDD, 10 drives per

disk group, 4 disk groups per pool, 4 volumes per pool.

MSA 2050 RAID 6 Hard Disk Drive sequential write results: Dual Controller configuration, (40) 15K HDD, 10 drives per

disk group, 2 disk groups per pool, 4 volumes per pool.

MSA 2050 RAID 1 Solid State Drive results: Dual Controller configuration, (8) SSDs, 2 SSDs per disk group, 2 disk groups

per pool, 4 volumes per pool.

MSA 2050 RAID 5 Solid State Drive results: Dual Controller configuration, (6) SSDs, 3 SSDs per disk group, 1 disk group

per pool, 4 volumes per pool.

- 13MSA 2050 RAID 6 Solid State Drive results: Dual Controller configuration, (8) SSDs, 4 SSDs per disk group, 1 disk group

• UL/CSA 62368-1 (USA/Canada)

• EN 62368-1 (European Union)

• IEC 60950-1 (International)

Electromagnetic Compatibility

• VCCI Class A (Japan)

• FCC Class A (USA)

• ICES-003 Class A (Canada)

• EN55032 : (European Union Class A); CISPR 32 (International Class A)

• EN61000-3-2 : (Harmonics) (European Union)

• EN61000-3-3 : (Flicker) (European Union)

• EN 55024 (European Union, Immunity, Class A); CISPR 24 (International Immunity, Class A)

• AS/NZS CISPR 32, Class A (Australia, New Zealand)

• CNS 13438 Taiwan, Class A (Taiwan)

• KN32 Class A (Emissions Class A); KN35 (Immunity) (S Korea)

RoHS and WEEE

RoHS-6/6 Compliance, China RoHS, WEEE

Country Approvals

United States, Australia/New Zealand, Canada, European Union, Japan, South Korea, Taiwan

QuickSpecs

HPE MSA 2052 SAN Storage

Summary of Changes

Page 26

Date

Version History

Action

Description of Change

textual updates.

05-Oct-2020

Version 20

Changed

Overview, Standard Features and Configuration Information sections were updated.

03-Aug-2020

Version 19

Changed

Adjusted B SKU regional availability.

04-May-2020

Version 18

Changed

Added MSA Health Check tool.

Removed EOL SKUs.

07-Oct-2019

Version 16

Changed

Added Arxscan support.

Max capacity of array increase.

02-Apr-2019

Version 14

Changed

RAID 0 added. Edits made throughout the QuickSpec

04-Mar-2019

Version 13

Changed

Added Drive 6 Pack Options

were updated.

03-Dec-2018

Version 12

Changed

Overview and Configuration Information sections were updated

01-Oct-2018

Version 11

Changed

SKU descriptions in Configuration Information were updated.

04-Sep-2018

Version 10

Added

Added HPE Storage File Controller support. Added HPE Complete/Zerto replication support.

06-Aug-2018

Version 9

Added

Added I/O Workload Functionality.

02-Jul-2018

Version 8

Changed

Added LDAP Support.

05-Mar-2018

Version 7

Added

Added End-to-End Performance Metrics.

05-Feb-2018

Version 6

Changed

Overview, Standard Features, and Configuration Information were revised.

06-Nov-2017

Version 5

Changed

Changes made to the document.

02-Oct-2017

Version 4

Changed

Changes made to the Configuration Information section.

25-Sep-2017

Version 3

Changed

Changes made to the QuickSpecs.

11-Jul-2017

Version 2

Changed

Fixed typos.

05-Jun-2017

Version 1

Created

Document Created.

18-Jan-2021 Version 21 Changed Removed all mentions of array and expansion enclosure “A” SKUs and added

02-Mar-2020 Version 17 Changed Added “B” variants for EMEA countries only.

06-May-2019 Version 15 Changed 14TB HDD and Bundle added

Added Read Intensive SSDs Removed EOL HDDs and Cables Added Window Server 2019 support Overview, Standard Features, Software and Configuration Information sections

Standard Features, Software, and Configuration Information were revised.

QuickSpecs

HPE MSA 2052 SAN Storage

Copyright

Page 27

Make the right purchase decision. Contact our presales specialists.

Chat Email

Call

© Copyright 2021 Hewlett Packard Enterprise Development LP. The information contained herein is subject to change without notice. The only warranties for Hewlett Packard Enterprise products and services are set forth in the express warranty statements accompanying such pr be construed as constituting an additional warranty. Hewlett Packard Enterprise shall not be liable for technical or editorial errors or omissions contained herein.

Microsoft and Windows NT are US registered tra trademark of Intel Corporation. Unix is a registered trademark of The Open Group.

a00008277enw - 15936 - Worldwide - V21 - 18-January-2021

Get updates

oducts and services. Nothing herein should

demarks of Microsoft Corporation. Intel is a US registered

HP HPE MSA 2052 SAN QuickSpecs

Specifications and Main Features

Frequently Asked Questions

User Manual

Overview

Standard Features

Service and Support

Configuration Information

Technical Specifications

Summary of Changes

Copyright

a00008277enw - 15936 - Worldwide - V21 - 18-January-2021
