QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 1

Front/Left

1.

WLAN antennas (2)

14.

Left TouchPad button

2.

WWAN antennas (2)

15.

Right pointing stick button

3.

Internal microphones (2)

16.

Left pointing stick button

4.

Webcam (select models only)

17.

Hard drive light

5.

Webcam light (select models only)

18.

AC adapter/Battery light

6.

Internal display switch

19.

Power light

7.

Wireless button

20.

Wireless light

8.

Volume mute button

21.

Smart card reader

9.

Pointstick

22.

USB 3.0 port

10.

Fingerprint reader (optional)

23.

External VGA monitor port

11.

Right TouchPad button

24.

Security cable slot

12

NFC sensor (optional)

25.

Power button

13.

TouchPad zone

Overview

HP EliteBook 850 G2 Notebook PC

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 2

Right

1.

Audio-out (headphone) jack/Audio-in(microphone) jack

5.

Drop-jaw Ethernet port (RJ-45)

2.

DisplayPort

6.

Docking port

3.

Memory card reader

7.

Power connector

4.

USB 3.0 ports (2)

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 3

––––

Bottom

1.

EasyAccess panel

4.

Vents (2)

2.

EasyAccess panel release latch

5.

SIM slot (inside the panel)*

3.

Security screw

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 4

AT A GLANCE

 Windows 8.1 , Windows 7 , Ubuntu Linux or FreeDOS 2.0
 Magnesium and aluminum chassis, HP DuraFinish, HP DisplaySafe frame, HP duraKeys, precision aluminum drop hinge,

aluminum palm rest

 4-step Soft-touch paint process
 Patent-pending Drop-jaw Ethernet port
 EasyAccess door to quickly access most components for easy serviceability
 Full-sized spill-resistant keyboard; optional back-lit keyboard keeps you productive in low-light settings
 Choice of 5
 Memory options up to 16 GB
 Weight starting at 4.02 lb/1.83 kg
 Storage options up to 1 TB Hard Drives, 512 GB Solid State Drives, or 256GB PCIe Solid State Drive
 M.2 32GB Flash Cache for Intel Smart Response Technology installed in the factory
 M.2 120GB Solid State Drive & 256GB PCIe Solid State Drive can be configured as primary storage or combined with a SATA

drive for dual storage performance

 Integrated Intel® HD Graphics 5500 or AMD Radeon™ R7 M260X discrete graphics with 1 GB dedicated GDDR5 video

memory

 Choice of Touch or Non Touch 15.6” diagonal displays
 Easily hot dock with the 2013 UltraSlim Docking Station
 DisplayPort for high resolution support
 Touchpad with scroll zone, on/off button with LED indicator
 Enhanced security features including HP Sure Start self-healing BIOS, HP Client Security and optional HP Fingerprint

Reader

 Optional HD webcam with dual-microphone array for video conferencing
 HD Audio with DTS Studio Sound™ optimized for high fidelity audio
 Wireless and speaker mute buttons
 Supports a broad range of wireless LAN and wireless WAN options, including 4G LTE, for connectivity on the go.
 UEFI BIOS Compliant with 2.3.1 UEFI Specification

th

Generation Intel® Core™ i7, i5 and i3 processors

NOTE: See important legal disclosures for all listed specs in their respective features sections.

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 5

Preinstalled

Windows 8.1 Pro 64*
Windows 8.1 64*
Windows 7 Professional 64 (available through downgrade rights from Windows 8.1 Pro 64)**
Windows 7 Professional 32 (available through downgrade rights from Windows 8.1 Pro 64)**
Windows 7 Professional 32*
Windows 7 Professional 64*
Ubuntu Linux
FreeDOS 2.0

Web-only Support

Windows 8.1 Enterprise 64*
Windows 8 Chinese Market 64*
Windows 8 Emerging Markets 64*
Windows 8 Multi-Language 64*
Windows 8 Professionals 64*
Windows 7 Enterprise 32*
Windows 7 Enterprise 64*

* Not all features are available in all editions or versions of Windows. Systems may require upgraded and/or separately
purchased hardware, drivers and/or software to take full advantage of Windows functionality. See http://www.microsoft.com
for details.
** This system is preinstalled with Windows 7 Pro software and also comes with a license and media for Windows 8 Pro software.
You may only use one version of the Windows software at a time. Switching between versions will require you to uninstall one
version and install the other version. You must back up all data (files, photos, etc.) before uninstalling and installing operating
systems to avoid loss of your data.

5th Generation Intel® Core™ i3-5010U 2.1-GHz 3-MB L3 Cache, 15W
5th Generation Intel® Core™ i5-5200U 2.2-GHz (max turbo frequency 2.7-GHz), 3 MB L3 cache, 15W
5th Generation Intel® Core™ i5-5300U 2.3-GHz (max turbo frequency 2.9-GHz), 3 MB L3 Cache, 15W
5th Generation Intel® Core™ i7-5500U 2.4-GHz (max turbo frequency 3.0-GHz), 4 MB L3 Cache, 15W
5th Generation Intel® Core™ i7-5600U 2.6-GHz (max turbo frequency 3.2-GHz), 4 MB L3 Cache, 15W

* Multi-Core is designed to improve performance of certain software products. Not all customers or software applications
will necessarily benefit from use of this technology. 64-bit computing on Intel® architecture requires a computer system
with a processor, chipset, BIOS, operating system, device drivers, and applications enabled for Intel® 64 architecture.
Processors will not operate (including 32-bit operation) without an Intel® 64 architecture-enabled BIOS. Performance will
vary depending on your hardware and software configurations. Intel's numbering is not a measurement of higher
performance.
** Not available with Intel iAMT (*Not available with vPro)
NOTE: Processor speed denotes maximum performance mode; processors will run at lower speeds in battery optimization
mode.

PRODUCT NAME

HP ELITEBOOK 850 G2 NOTEBOOK PC

OPERATING SYSTEM

PROCESSOR

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 6

Intel Turbo Boost is a feature that speeds up the CPU for a short time. It is similar to overclocking the processor, except
within a framework provided by Intel. This feature provides additional performance and allows the computer to perform
certain tasks more quickly. It also draws additional power and generates additional heat. Therefore, if Turbo Boost is used
while powered from battery, it causes additional stress on the battery.

Using Turbo Boost while powered from battery might impact battery cycle life. Cycle life describes how long the battery will
last before it needs to be replaced. A cycle refers to one complete charge/discharge cycle of the battery. Because Turbo
Boost causes extra stress on the battery, it often shortens the lifetime of the battery.

HP decided not to enable Turbo Boost when powered from battery. This decision was based on the desire to give customers
the greatest battery cycle life possible. Turbo Boost is enabled when powered from AC adapter.

Based on customer requests, HP will provide an option to enable Turbo Boost while powered from battery. For the 2013
platform, it will be an F10 option. Turbo Boost will be available for devices powered from battery by the end of the year. The
additional performance might cause a slight reduction in battery cycle life, but will not void the battery warranty.

*Implementing Turbo Boost in F10 option is only allowed for batteries over 40WHr. Intel® Turbo Boost technology requires a
PC with a processor with Intel Turbo Boost capability. Intel Turbo Boost performance varies depending on hardware, software
and overall system configuration. See www.intel.com/technology/turboboost for more information.

Chipset integrated with processor

Intel Core i5 with vPro and Core i7 with vPro technology is a selectable feature that is available on units configured with
select processors, an Intel Centrino® Advanced-N or Ultimate-N WLAN module and a preinstalled Windows operating
system. It provides advances in remote manageability, security, energy efficient performance, and wireless connectivity.
Intel Active Management Technology 9.0 (iAMT) offers built-in manageability and proactive security for networked
notebook PCs, even when they are powered off* or when the operating system is inoperable. It can help identify threats
before they reach the network, isolate infected systems, and update PCs regardless of their power state.
*Requires a Windows operating system, network hardware and software, connection with a power source, and a direct (non­VPN) corporate network connection which is either cable or wireless LAN.

NOTE: Some functionality of this technology, such as Intel® Active management technology and Intel Virtualization
technology, requires additional 3rd party software in order to run. Availability of future "virtual appliances" applications for
Intel vPro technology is dependent on 3rd party software providers. Microsoft Windows required.

INTEL TURBO BOOST TECHNOLOGY*

CHIPSET

INTEL CORE I5 WITH VPRO/CORE I7 WITH VPRO TECHNOLOGY CAPABLE

GRAPHICS

Integrated:
Intel® HD* Graphics 5500
Discrete
AMD Radeon™ R7 M260X*, with 1 GB dedicated DDR5 video memory**

*HD content required to view HD images.

**AMD Dynamic Switchable Graphics technology requires an Intel processor, plus an AMD Radeon™ discrete graphics configuration
and is not available on FreeDOS and Linux OS. With AMD Dynamic Switchable Graphics technology, full enablement of all discrete

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 7

Internal
Non Touch

15.6" diagonal LED-backlit HD anti-glare SVA flat (1366x768)

15.6" diagonal LED-backlit HD anti-glare SVA flat (1366x768) with camera

15.6" diagonal LED-backlit FHD anti-glare SVA Slim (1920x1080)

15.6" diagonal LED-backlit FHD anti-glare SVA Slim (1920x1080) with camera

Touch

15.6" FHD diagonal LED-backlit SVA Slim (1920x1080) with camera

Touch panel has chemically-strengthened Corning® Gorilla® Glass 3 top cover

External
Up to 32-bit per pixel color depth

VGA
Port supports resolutions up to 1920 x 1200 external resolution@75 Hz

DisplayPort
Supports resolutions up to 3840 x 2160 @ 60Hz. Supports Multi-Stream Transport (MST) where three displays can be daisy
chained with digital displays through DisplayPort Only. The full resolution of each display will be limited as you reach 3
displays due to the bandwidth limitations with a maximum resolution of:

 2560x1600@60Hz for 2 displays
 1920x1200@60Hz for 3 displays

Number of Displays supported
3 With Optional 2013 UltraSlim Docking Station
Sold separately.

Primary Storage Bay
Hard Drives*

320 GB 7200rpm SATA Hard Drive
500 GB 7200rpm SATA Hard Drive
500 GB 7200rpm Self-Encrypting Drive
500 GB 5400rpm Self-Encrypting Drive (FIPS-140-2)
1TB 7200rpm SATA Hard Drive

Solid State Drive*

120 GB M.2 Solid State Drive
128 GB SATA-3 Solid State Drive
180 GB SATA-3 Solid State Drive
180 GB SATA-3 Self-Encrypting Drive
240 GB SATA-3 Solid State Drive
256 GB SATA-3 Solid State Drive

graphics video and display features may not be supported on all systems (e.g. OpenGL applications will run on the integrated GPU
or the APU as the case may be).

DISPLAY

STORAGE AND DRIVES

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 8

256 GB SATA-3 Self-Encrypting Drive
256 GB M.2 PCIe Solid State Drive
512 GB SATA-3 Solid State Drive

HP 3D DriveGuard (Windows only)

HP 3D DriveGuard mitigates the risk of hard drive failures, safeguarding your data when you are on the go by sensing
sudden movement and protecting the hard drive. The hard drive is mounted directly to the notebook frame, reducing the
transmission of shock to the hard drive.

*For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 16
GB (for Windows 7) and 30 GB (for Windows 8) of system disk is reserved for the system recovery software.

FLASH CACHE

32 GB M.2 (NGFF)
Optional 32 GB M.2 flash cache module support for Intel Smart Response Technology.
Available only with standard non-SED hard drive.

Standard

DDR3L SDRAM (1600 MHz)
Two SODIMM slots supporting dual-channel memory
4 GB Total System Memory (4 GB x 1)
8 GB Total System Memory (4 GB x 2) (Not available with Windows 7 Professional 32)
8 GB Total System Memory (8 GB x 1) ) (Not available with Windows 7 Professional 32)
16 GB Total System Memory (8 GB x 2) ) (Not available with Windows 7 Professional 32)

Maximum

Upgradeable to 16 GB with optional 8 GB SODIMMs in slots 1 and 2*

Dual-channel

Maximized dual-channel performance requires SODIMMs of the same size and speed in both memory slots.

* Maximum memory capacities assume Windows 64-bit operating systems or Linux. With Windows 32-bit operating
systems, memory above 3 GB may not all be available due to system resource requirements.
NOTE: Due to the non-industry standard nature of some third-party memory modules, we recommend HP branded memory
to ensure compatibility. If you mix memory speeds, the system will perform at the lower memory speed.

Wireless
Support for a broad range of secure, integrated wireless LAN and wireless WAN options featuring support for the latest
industry standards. Broadband Wireless (WWAN) requires a Windows operating system and is available in select countries
as a standard, factory configurable feature only. Integrated Bluetooth is also available (factory configurable only) and can
be combined with any of the supported wireless LAN and wireless WAN options.

Broadband Wireless (WWAN)*

HP lt4112 LTE/HSPA+ Qualcomm® Gobi™ 4G Module
HP lt4211 LTE/EV-DO/HSPA+ Qualcomm® Gobi™ 4G Module
HP hs3110 HSPA+ Mobile Broadband Module

* WWAN is an optional feature sold separately or as an add on feature. WWAN connection requires wireless data service
contract, network support, and is not available in all areas. Contact service provider to determine the coverage area and

MEMORY

NETWORKING/COMMUNICATIONS

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 9

availability. Connection speeds will vary due to location, environment, network conditions, and other factors.
** 4G LTE WWAN is an optional feature, not available on all products, in all regions and requires separately purchased
service contract. Check with service provider for coverage and availability. Connection speeds will vary due to location,
environment, network conditions, and other factors.

Wireless LAN (WLAN)*

Intel® Dual Band Wireless-AC 7265 802.11 ac (2X2) Wi-Fi + Bluetooth®
Intel® Dual Band Wireless-7265AN 802.11 a/b/g/n (2X2) Wi-Fi + Bluetooth®
Intel® Dual Band Wireless-AC 3160 802.11 ac (1x1) Wi-Fi + Bluetooth®

*Wireless access point and Internet service is required and is not included. Availability of public wireless access points
limited.

Communications
Intel® I218LM Gigabit* Network Connection (10/100/1000 NIC)
* The term "10/100/1000" or "Gigabit" Ethernet indicates compatibility with IEEE standard 802.3ab for Gigabit Ethernet, and
does not connote actual operating speed of 1 Gb/s. For high-speed transmission, connection to a Gigabit Ethernet server
and network infrastructure is required.

Optional Near Field Communication (NFC)

Audio

HD Audio with DTS Studio SoundTM
2 Integrated stereo speakers
Integrated dual-microphone array; located in the display
Function keys for microphone mute, volume up, volume down
Stereo headphone/line out
Stereo microphone/line in

Webcam
Optional* 720p HD** webcam

 HD format (widescreen)
 Supports videoconferencing (non-HD) and still image capture
 High quality fixed focus lens
 Video capture at various resolutions up to 1280x720 resolution (720p) and up to 30fps
 M-JPEG compression supports higher frame rates for video capture and videoconferencing
 Improved low light sensitivity
 Improved dynamic range
 Skype-ready ***

*Sold separately or as an optional feature.
** HD content required to view HD images.
***Internet access required.

Keyboard
The HP spill-resistant keyboard is designed using a thin layer of Mylar film under the keyboard and includes an all-metal
keyboard deck for greater rigidity, as well as HP DuraKeys. The 101/102-key compatible keyboard features a full-pitch key

AUDIO/MULTIMEDIA

KEYBOARDS/POINTING DEVICES/BUTTONS & FUNCTION KEYS

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 10

layout with desktop keyboard features, such as editing keys, both left and right control and alt keys, and function keys. US and
International key layouts are available. Backlit keyboard available as an option.

Pointing Devices
Touchpad with scroll zone, on/off button with LED indicator, two-way scroll, two pick buttons

Buttons and Function Keys
Separate discrete buttons provide easy access to WLAN on/off and speaker mute. Function keys provide control of features
including: standby mode, display brightness, external display, microphone mute, volume down, and volume up.

* In independent testing conducted by Trace Laboratories, HP DuraKeys showed no wear after 250,000 cycles. Competitor
notebooks showed significant wear after only 5,000 cycles.)

Preinstalled Software with Windows Operating System

BIOS

HP BIOSphere*
HP Sure Start
HP DriveLock | HP Automatic Drive Lock
HP BIOS Protection***
HP Disk Sanitizer ****
HP SpareKey*****
Update via Network
Master Record Security
Power On Authentication
Pre-Boot Security
Secure Erase******
Hybrid Boot
Measured Boot
Secure Boot
Absolute Persistence Module*******

* Available only on business PCs with HP BIOS.
*** May require a manual recovery step if all copies of BIOS are compromised or deleted.
**** For the use cases outlined in the DOD 5220.22-M Supplement.Does not support solid state drives.
***** Requires initial user set up.
****** For the methods outlined in the National Institute of Standards and Technology Special Publication 800-88.
******* Absolute agent is shipped turned off, and will be activated when customers activate a purchased subscription.
Subscriptions can be purchased for terms ranging multiple years. Service is limited, check with Absolute for availability
outside the U.S. The Absolute Recovery Guarantee is a limited warranty. Certain conditions apply. For full details visit:
http://www.absolute.com/company/legal/agreements/computrace-agreement. Data Delete is an optional service provided
by Absolute Software. If utilized, the Recovery Guarantee is null and void. In order to use the Data Delete service, customers
must first sign a Pre-Authorization Agreement and either obtain a PIN or purchase one or more RSA SecurID tokens from
Absolute Software.

MultiMedia

CyberLink PowerDVD
CyberLink YouCam BE

Communication

HP Connection Manager (Windows 7 only)

SOFTWARE AND SECURITY

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 11

HP GPS and Location*
HP Mobile Connect (Windows 8 only)**
HP Wireless Hotspot*** (Windows 8 only)
Intel WiDi Software****
Intel My WiFi and Wireless Drivers

HP Value Add Software

Getting Started with Windows 8
HP 3D DriveGuard (Windows required)
HP ePrint Driver (HP Exclusive)*****
HP Hotkey Support
HP PageLift
HP Recovery Manager (Windows 7 only)
HP Support Assistant
HP Recovery Disc Creator (Windows 7 only)
UEFI System Diagnostics W8

3rd Party

Adobe® Flash Player (Commercial)
Foxit PhantomPDF Express for HP
Bing Search
Skype******
Buy Office

NOTE: HP Recovery Manager enables fast recovery of the factory preinstalled image if the system becomes corrupted or if
important system files are accidentally deleted. Up to 16 GB (for Windows 7) and 36 GB (for Windows 8) of system disk is
reserved for the system recovery software.

*GPS access requires an unobstructed path to multiple satellites. Performance may be affected if/when used inside of
buildings, bridges or heavily congested metropolitan areas. Requires separately purchased GPS navigation software
available from multiple GPS applications.
** HP Mobile Connect is only available on selective devices with wwan. For geographical availability refer to
www.hp.com/go/mobileconnect
***The wireless hotspot application requires an active internet connection that is shared with the connecting devices.
Wireless hotspot data usage may incur additional charges. Check with your service provider for plan details.
**** Integrated Intel Wi-Di feature is available on select configurations only and requires separately purchased projector, tv
or computer monitor with an integrated or external Wi-Di receiver. External Wi-Di receivers connect to the projector, tv or
computer monitor via a standard HDMI cable, also sold separately.
*****Requires an Internet connection to HP web-enabled printer and HP ePrint account registration (for a list of eligible
printers, supported documents and image types and other HP ePrint details, see www.hp.com/go/businessmobileprinting.
****** Skype is not offered in China.

Manageability
HP Driver Packs *
HP SoftPaq Download Manager (SDM)*
HP System Software Manager (SSM)*
HP BIOS Config Utility (BCU) *
HP Client Catalog / HP CIK for Microsoft SCCM *
LANDESK Management *

* Not preinstalled
For more information on HP Client Management Solutions refer to: http://www.hp.com/go/clientmanagement.

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 12

Standard Security Features

HP Client Security with Credential Manager and Password Manager (Windows only)
HP Device Access Manager with Just in Time Authentication
HP Drive Encryption (FIPS 140-2 certified)*
HP File Sanitizer**
Microsoft Security Essentials (Windows 7 only)***
Central Management of Client Security Credential Manager with DigitalPersona Pro Workgroup*****
Computrace Support

Security Hardware
TPM 2.0
Security lock slot
Fingerprint Reader
Integrated Smart Card Reader

NOTE: The Absolute Persistence agent is shipped turned off, and must be activated by customers when they purchase a
subscription. Subscriptions can be purchased for terms ranging multiple years. Service is limited, check with Absolute for
availability outside the U.S.

* Requires Windows. Data is protected prior to Drive Encryption login. Turning the PC off or into hibernate logs out of Drive
Encryption and prevents data access.
** For the use cases outlined in the DOD 5220.22-M Supplement. Supports standard Hard Drives. Initial setup
required.
*** Opt in and internet connection required for updates.
***** In order to deploy and receive updated policies, the client needs to be connected to the network server and requires
separately purchased DigitalPersona Pro software. System access may not prevent users from logging into the system on the
first attempt if policy updates haven't yet been received and applied. Not all features are remotely manageable.
******** Intel Anti-Theft security is supported on Intel Core i processors and requires a separately purchased Absolute
Computrace service subscription and must be activated and configured. Check with Absolute for availability in your country.
Intel and HP assume no liability for lost or stolen data and/or systems or any other damages resulting therefrom. See
http://www.intel.com/technology/anti-theft/.
********* Intel Identity Protection feature is only available with Intel Core Processors. Intel® IPT security requires separate
Symantec VIP software service subscription and must be activated and configured. Requires a website that uses Symantec
VIP Authentication Service and Microsoft® Windows. Intel® and HP assume no liability for lost or stolen data and/or systems
or any other damages resulting therefrom.

For more information on HP security solutions refer to: http://www.hp.com/go/protecttools.

Power Supply

HP 45W Smart AC Adapter
45W 2-prong 7.4mm DC jack AC Adapter (Only for Japan)
HP 65W Smart AC Adapter
HP 65W Smart EM AC Adapter (China and India only)
Power cord is configurable; either 3.2 feet or 6 feet (1.0 or 1.8 meter)
Total length including external AC adapter is 9.2 feet or 12 feet (2.86 or 3.66 meter).

Primary Battery

3-cell HP Long Life Polymer 24 WHr
3-cell HP Long Life Polymer 50 WHr

POWER

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 13

Battery Life*

Hardware details

Battery

With UMA Graphics

With Discrete Graphics

HDD

3-cell (50 WHr)

Up to 12 hrs 15 mins

Up to 12 hrs 45 mins

SSD

3-cell (24 Whr)

Up to 7 hrs 30 mins

Up to 7 hrs

SSD

3-cell (50 WHr)

Up to 15 hrs 30 mins

Up to 15 hrs 15 mins

*Windows 7 MM07 battery life will vary depending on various factors including product model, configuration, loaded
applications, features, use, wireless functionality, and power management settings. The maximum capacity of the battery
will naturally decrease with time and usage. See www.bapco.com for additional details.

System Standby Time**

With UMA Graphics

With Discrete Graphics

Up to 180 hrs

Up to 171 hrs

**Standby life will vary depending on various factors including battery, Memory, CPU, EC and LAN chip. The maximum capacity
of the battery will naturally decrease with time and usage.

Power Conservation

Supports enhanced Intel SpeedStep technology (allows Battery Optimized Mode, Maximum Performance Mode, or Automatic
mode)
AMD PowerPlay technology (discrete models)
Hibernation
Standby
ACPI compliance

Weight
Non Touch

Starting at 4.02 lb/1.83 kg
Weight will vary by configuration.
3-cell (24Whr) battery, HD panel, UMA, no FPR, one SODIMM, WLAN, lightest M.2 SSD primary storage module, no camera, no
WWAN

Touch
Starting at 4.54 lb/2.06 kg
Weight will vary by configuration.
3-cell (24Whr) battery, FHD Touch panel, UMA, no FPR, one SODIMM, WLAN, lightest M.2 SSD primary storage module, no
camera, no WWAN

Dimensions (w x d x h)
Non Touch

14.78 x 9.98 x 0.84 in (at front)

37.55 x 25.36 x 2.14 cm (at front)

WEIGHTS & DIMENSIONS

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 14

Touch

14.78 x 9.98 x 1.02 in (at front)

37.55 x 25.36 x 2.58 cm (at front)
Ports

(1) DisplayPort 1.2
(1) USB 3.0 Charging Port
(3) USB 3.0 Port
(1) RJ-45 / Ethernet
(1) Side Docking connector
(1) Secondary battery connector
(1) Headphone/Microphone Combo
(1) AC Port

Expansion Slots
Media Card Reader
Supports SD, SDHC, SDXC

HP Services offers 3-year, 1-year and 90 day limited warranty options depending on country. Batteries have a default one year
limited warranty except for Long Life batteries which will have same 1-year or 3-year limited warranty as the platform. On-site
service and extended coverage is also available. HP Care Pack Services are optional extended service contracts that go beyond
the standard limited warranties.* To choose the right level of service for your HP product, use the HP Care Pack Services
Lookup Tool at: http://www.hp.com/go/cpc.

NOTE: Certain restrictions and exclusions apply. Consult the HP Customer Support Center for details.
http://h20000.www2.hp.com/bizsupport/TechSupport/ProductRoot.jsp

*HP Care Packs are sold separately. Service levels and response times for HP Care Services may vary depending on your
geographic location. Service starts on date of hardware purchase. Restrictions and limitations apply. Consult the HP
Customer Support Center for details. http://h20000.www2.hp.com/bizsupport/TechSupport/ProductRoot.jsp

PORTS/SLOTS

SERVICE AND SUPPORT

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 15

Stand-Alone Power
Requirements (AC Power)
Nominal Operating Voltage

19.5 V

Average Operating Power

Windows 7 (64-bit)

Windows8.1 (64-bit)

Integrated graphics

4.75 W

4.26 W

Max Operating Power

Discrete < 90W
UMA < 65W

Temperature

Operating

32° to 95° F (0° to 35° C) (not writing optical)
41° to 95° F (5° to 35° C) (writing optical)

Non-operating

-4° to 140° F (-20° to 60° C)

Relative Humidity

Operating

10% to 90%, non-condensing

Non-operating

5% to 95%, 101.6° F (38.7° C) maximum wet bulb
temperature

Shock

Operating

40 G, 2 ms, half-sine

Non-operating

200 G, 2 ms, half-sine

Random Vibration

Operating

0.75 grms

Non-operating

1.50 grms

Altitude (unpressurized)

Operating

-50 to 10,000 ft (-15.24 to 3,048 m)

Non-operating

-50 to 40,000 ft (-15.24 to 12,192 m)

Planned Industry Standard
Certifications
UL

Yes

CSA

Yes

FCC Compliance

Yes

ENERGY STAR®

Select models*

EPEAT®

Registered Gold in United States**

ICES

Yes

Australia /
NZ A-Tick Compliance

Yes

CCC

Yes

Japan VCCI Compliance

Yes

KC

Yes

BSMI

Yes

CE Marking Compliance

Yes

BNCI or BELUS

Yes

CIT

Yes

GOST

Yes

Saudi Arabian Compliance
(ICCP)

Yes

SABS

Yes

UKRSERTCOMPUTER

Yes

For accessibility information on HP products, please visit: http://www.hp.com/accessibility.

15.6" diagonal LED­backlit HD anti-glare SVA
flat (1366 x 768)

Outline Dimensions

(W x H x D)

14.17 x 8.83 x 0.15 in (36.0 x 22.43 x 0.38 cm)

Active Area

13.55 x 7.62 in (34.42 x 19.35 cm)

Weight

< 1.1 lb (500 g) (max)

SYSTEM UNIT

DISPLAYS

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 16

Diagonal Size

15.6 in (39.62 cm)

Surface Treatment

Anti-glare

Contrast Ratio

300:1 (min)

Refresh Rate

60 Hz

Brightness

200 nit (typical)

Pixel Resolution
Format

1366 x 768 (HD)

Configuration

RGB Stripe

Interface

eDP 1.2 (1 lane)

LCD Mode

TN

PPI

101 ppi

Viewing Angle

SVA 30/30/20/10 (min) (Left/Right/Down/Up)

15.6" diagonal LED­backlit FHD anti-glare
SVA flat (1920 x 1080)

Outline Dimensions

(W x H x D)

14.17 x 8.83 x 0.15 in (36.0 x 22.43 x 0.32 cm)

Active Area

13.55 x 7.62 in (34.42 x 19.36 cm)

Weight

< 0.84 lb (380 g) (max)

Diagonal Size

15.6 in (39.62 cm)

Surface Treatment

Anti-glare

Contrast Ratio

300:1 (typical)

Refresh Rate

60 Hz

Brightness

300 nit (typical)

Pixel Resolution
Format

1920 x 1080 (FHD)

Configuration

RGB Stripe

Interface

eDP 1.2 (2 lane)

LCD Mode

TN

PPI

142 ppi

Viewing Angle

SVA 30/30/20/10 (min) (Left/Right/Down/Up)

15.6" diagonal LED­backlit FHD anti-glare
SVA flat (1920 x 1080) +
touch

Outline Dimensions

(W x H x D)

14.17 x 8.83 x 0.15 in (36.0 x 22.43 x 0.32 cm)

Active Area

13.55 x 7.62 in (34.42 x 19.36 cm)

Weight

< 0.84 lb (380 g) (max)

Diagonal Size

15.6 in (39.62 cm)

Touch enabled

Yes

TSP Type

Capacitive

Touch point supported

Min 5-point & Max 10-point for Win8

Surface Treatment

Anti-glare

Contrast Ratio

400:1 (typical)

Refresh Rate

60 Hz

Brightness

300 nit (typical)

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 17

Pixel Resolution
Format

1920 x 1080 (FHD)

Configuration

RGB Stripe

Interface

eDP 1.2 (2 lane)

LCD Mode

TN

PPI

142 ppi

Viewing Angle

SVA 45/45/25/35 (Left/Right/Down/Up)

320 GB* 7200 rpm SATA
Hard Drive

Drive Weight

0.21 lbs (95 g)

Capacity

320 GB

Height

0.28 in (7 mm)

Width

2.75 in (69.85 mm)

Interface

ATA-8, SATA 3.0

Transfer Rate

Synchronous (maximum)

600 MB/s (Drive Capability)

Seek Time
(typical reads, including
settling)

Single Track

1.5 ms-2ms

Average

12 ms-13ms

Maximum

18ms-22 ms

Cache

Up to 32 MB

Rotational Speed

7200 rpm

Logical Blocks

625,142,448

Operating Temperature

32° to 140° F (0° to 60° C) [case temp]

Features

ATA Security; S.M.A.R.T. IV, NCQ, Ultra DMA

500 GB* 7200 rpm
SATA Hard Drive

Drive Weight

0.20lbs(92g- 0.21 lbs (95g)

Capacity

500 GB

Height

0.28 in (7 mm)

Width

2.75 in (69.85 mm)

Interface

ATA-8, SATA 3.0

Transfer Rate

Synchronous (maximum)

600 MB/s (Drive Capability)

Seek Time
(typical reads, including
settling)

Single Track

1.5 ms-2ms

Average

12 ms-13ms

Maximum

18ms-22 ms

Rotational Speed

7200 rpm

Logical Blocks

976,773,168

Operating Temperature

32° to 140° F (0° to 60° C) [case temp]

Features

ATA Security; S.M.A.R.T.IV, NCQ, Ultra DMA

STORAGE AND DRIVES

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 18

500 GB* 5400 rpm
SMART SATA II FIPS
Self Encrypting Drive

Drive Weight

0.21 lbs (95g)

Capacity

500 GB

Height

0.28 in (7 mm)

Width

2.75 in (69.85 mm)

Interface

ATA-8, SATA 3.0

Transfer Rate

Synchronous (maximum)

600 MB/s (Drive Capability)

Seek Time
(typical reads, including
settling)

Single Track

1.5 ms

Average

12 ms

Maximum

22 ms

Cache

32 MB

Rotational Speed

5400 rpm

Logical Blocks

976,773,168

Operating Temperature

32° to 140° F (0° to 60° C) [case temp]

Features

ATA Security; TCG Opal 2.x, FIPS

1 TB* 7200 rpm
SATA Hard Drive
Drive Weight

0.25 lb (115 g)

Capacity

1 TB

Height

0.37 in (9.5 mm)

Width

2.75 in (69.85 mm)

Interface

ATA-8, SATA 3.0

Transfer Rate

Synchronous

(maximum)

600 MB/s (Drive Capability)

Seek Time
(typical reads, including
settling)

Single Track

2 ms

Average

13 ms

Maximum

15 ms

Rotational Speed

7200 rpm

Logical Blocks

1,953,525,168

Operating
Temperature

32° to 140° F (0° to 60° C) [case temp]

Features

ATA Security; S.M.A.R.T. IV, NCQ, Ultra DMA

SATA 3 Gb/s 32 GB*,
M.2 2242 Solid State
Drive

Drive Weight

10 Grams

Capacity

32 GB

Height

0.09 in (3.7 mm)

Width

0.87 in (22 mm)

Interface

ATA-8, SATA 3.0

Performance
Maximum Sequential

Read

Maximum Sequential Write

Up to 380 MB/s

Up to 110 MB/s

Logical Blocks

62,533,296

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 19

Operating Temperature

32° to 158°F (0° to 70°C) [ambient temp]

Features

ATA Security; DIPM; TRIM; DEVSLP

SATA 3 Gb/s 120 GB*, M.2
2242 Solid State Drive

Drive Weight

10 Grams

Capacity

120 GB

Height

0.09 in (3.7 mm)

Width

0.87 in (22 mm)

Interface

ATA-8, SATA 3.0

Performance
Maximum Sequential Read

Maximum Sequential Write

Up to 540 MB/s

Up to 480 MB/s

Logical Blocks

234,441,648

Operating Temperature

32° to 158°F (0° to 70°C) [ambient temp]

Features

ATA Security; DIPM; TRIM; DEVSLP

SATA 3 Gb/s 128 GB*, 2.5­inch MLC Solid State
Drive

Drive Weight

78 Grams

Capacity

128 GB

Height

0.28 in (7 mm)

Width

2.75 in (69.85 mm)

Interface

ATA-8, SATA 3.0

Performance
Maximum Sequential Read

Maximum Sequential Write

Up to 550 MB/s

Up to 350 MB/s

Logical Blocks

250,069,680

Operating Temperature

32° to 158°F (0° to 70°C) [ambient temp]

Features

ATA Security; DIPM; TRIM; DEVSLP

SATA 3 Gb/s 128 GB*, 2.5­inch TLC Solid State Drive

Drive Weight

78 Grams

Capacity

128 GB

Height

0.28 in (7 mm)

Width

2.75 in (69.85 mm)

Interface

ATA-8, SATA 3.0

Performance
Maximum Sequential Read

Maximum Sequential Write

Up to 520 MB/s

Up to 140 MB/s

Logical Blocks

250,069,680

Operating Temperature

32° to 158°F (0° to 70°C) [ambient temp]

Features

ATA Security; DIPM; TRIM; DEVSLP

SATA 3 Gb/s 180 GB*, 2.5­inch SATA Solid State
Drive

Drive Weight

78 Grams

Capacity

180 GB

Height

0.28 in (7 mm)

Width

2.75 in (69.85 mm)

Interface

ATA-8, SATA 3.0

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 20

Performance
Maximum Sequential

Read

Maximum Sequential Write

Up to 540 MB/s

Up to 490 MB/s

Logical Blocks

351,651,888

Operating Temperature

32° to 158°F (0° to 70°C) [ambient temp]

Features

ATA Security; DIPM; TRIM; DEVSLP

SATA 3 Gb/s 180 GB*, 2.5­inch SATA SED Solid State
Drive

Drive Weight

Up to 78 Grams

Capacity

180 GB

Height

0.28 in (7 mm)

Width

2.75 in (69.85 mm)

Interface

ATA-8, SATA 3.0

Performance
Maximum Sequential

Read

Maximum Sequential Write

Up to 540 MB/s

Up to 490 MB/s

Logical Blocks

351,651,888

Operating Temperature

32° to 158°F (0° to 70°C) [ambient temp]

Features

ATA Security; DIPM; TRIM; DEVSLP; TCG Opal 1x

SATA 3 Gb/s 240 GB*, 2.5­inch Solid State Drive

Drive Weight

78 Grams

Capacity

240 GB

Height

0.28 in (7 mm)

Width

2.75 in (69.85 mm)

Interface

ATA-8, SATA 3.0

Performance
Maximum Sequential

Read

Maximum Sequential Write

Up to 540 MB/s

Up to 490 MB/s

Logical Blocks

468,862,128

Operating Temperature

32° to 158°F (0° to 70°C) [ambient temp]

Features

ATA Security; DIPM; TRIM; DEVSLP

SATA 3 Gb/s 256 GB*, 2.5­inch Solid State Drive

Drive Weight

78 Grams

Capacity

256 GB

Height

0.28 in (7 mm)

Width

2.75 in (69.85 mm)

Interface

ATA8, SATA 3.0

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 21

Performance

Maximum Sequential
Read

Maximum Sequential Write

Up to 520 MB/s

Up to 280 MB/s

Logical Blocks

500,118,192

Operating Temperature

32° to 158°F (0° to 70°C) [ambient temp]

Features

ATA Security; TCG Opal 2.x; DIPM; TRIM; DEVSLP

SATA 3 Gb/s 256 GB*, 2.5­inch Self Encrypting Solid
State Drive

Drive Weight

78 Grams

Capacity

256 GB

Height

0.28 in (7 mm)

Width

2.75 in (69.85 mm)

Interface

ATA8, SATA 3.0

Performance
Maximum Sequential

Read

Maximum Sequential Write

Up to 550 MB/s

Up to 500 MB/s

Logical Blocks

500,118,192

Operating Temperature

32° to 158°F (0° to 70°C) [ambient temp]

Features

ATA Security; TCG Opal 2.x; DIPM; TRIM; DEVSLP

SATA 3 Gb/s 256 GB*, 2.5­inch M2 PCIe Solid State
Drive

Drive Weight

10 Grams

Capacity

256 GB

Height

0.24 in (60 mm)

Width

0.87 in (22 mm)

Interface

ATA-8, PCIe 2.0

Performance
Maximum Sequential
Read

Maximum Sequential Write

Up to 730 MB/s

620 MB/s

Logical Blocks

500,118,192

Operating Temperature

32° to 158°F (0° to 70°C) [ambient temp]

Features

ATA Security; DIPM; TRIM; DEVSLP

SATA 3 Gb/s 512 GB*, 2.5­inch Solid State Drive

Drive Weight

78 Grams

Capacity

512 GB

Height

0.28 in (7 mm)

Width

2.75 in (69.85 mm)

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 22

Interface

ATA-8, SATA 3.0

Performance
Maximum Sequential

Read

Maximum Sequential Write

Up to 550 MB/s

Up to 550 MB/s

Logical Blocks

1,000,215,216

Operating Temperature

32° to 158°F (0° to 70°C) [ambient temp]

Features

ATA Security; DIPM; TRIM; DEVSLP

HP lt4211 LTE/EV-DO/
HSPA+ Gobi 4G Module

Technology/Operating
bands

LTE: 1900 (Band 2), 1700/2100 (Band 4), 850 (Band 5), 700 (Band 13 upper SMH), 700 (Band 17
lower SMH), 1900 MHz (Band 25, extended PCS) MHz
HSPA+: 2100 (Band 1), 1900 (Band 2), 1700/2100 (Band 4), 850 (Band 5), 900 (Band 8) MHz
E-GPRS: 1900 (Band 2), 1800 (Band 3), 850 (Band 5), 900 (Band 8) MHz
EV-DO: 800 (BC0), 1900 (BC1) MHz

Wireless protocol
standards

3GPP Release 8 LTE Specification
WCDMA R99, 3GPP Release 5, 6 and 7 UMTS Specification
E-GPRS: Class B, Multi-slot class 33, coding schemes CS1 - CS4 and MSC1 - MSC9
EVDO Release 0 and Release A

GPS

Standalone, A-GPS

GPS bands

1575.42 MHz ± 1.023 MHz, GLONASS 1596-1607MHz

Maximum data rates

LTE: 100 Mbps (Download), 50 Mbps (Upload)
DC-HSPA+: 42 Mbps (Download), 5.76 Mbps (Upload)
HSPA+: 21.6 Mbps (Download), 5.76 Mbps (Upload)
EDGE: 236.8 kbps (Download), 236.8 kbps (Upload)
GPRS: 85.6 kbps(Download), 85.6 kbps (Upload)
CDMA 1x: DL 153.6 kbps/UL 153.6 kbps

EVDO Rev.A: DL 3.1 Mbps/UL 1.8 Mbps

Maximum output power

LTE: 23 dBm
HSPA+: 23.5 dBm
E-GPRS 1900/1800: 26.5 dBM
E-GPRS 900/850: 27.5 dBM
GPRS 1900/1800: 29.5 dBm
GPRS 900/850: 32.5 dBm
CDMA/EVDO: 24dBm

Maximum power
consumption

LTE: 1,200 mA (peak); 900 mA (average)
HSPA+: 1,100 mA (peak); 800 mA (average)
E-GPRS: 2,800 mA (peak); 700 mA (average)
EVDO: 1000mA (peak); 720mA (average)

NETWORKING/COMMUNICATIONS

Broadband Wireless (WWAN)*

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 23

Form Factor

M.2, 3042-S3 Key B

Weight

6 g

Dimensions

(Length x Width x
Thickness)

1.65 x 1.18 x 0.09 in (42 x 30 x 2.3 mm)

HP lt4112 LTE/HSPA+
Gobi 4G Module**

Technology/Operating
bands

LTE FDD all bands with diversity: 2100 MHz (Band I), 1900 MHz (Band
II), 1800 MHz (Band III), 850 MHz (Band V), 2600 MHz (Band VII), 900
MHz (Band VIII), 800 MHz (Band XX, DD800)
WCDMA/HSDPA/HSUPA/HSPA+ all bands with diversity: 2100 MHz
(Band I), 1900 MHz (Band II), 800 MHz (Band V), 900 MHz (Band VIII)
GSM/GPRS/EDGE: 1900 MHz (Band II), 1800 MHz (Band III), 850 MHz
(Band V), 900 MHz (Band VIII)

Wireless protocol
standards

3GPP Release 8 LTE Specification
WCDMA R99, 3GPP Release 5, 6 and 7 UMTS Specification

Wireless parametric
standards

Complies with 3GPP specifications Release 8 for LTE

Maximum data rates

LTE (Category 3): 100 Mbps (Download), 50Mbps (Upload)
DC-HSPA+: 42 Mbps (Download), 5.76 Mbps (Upload)
HSPA+: 21.6 Mbps (Download), 5.76 Mbps (Upload)
EDGE: 236.8 kbps (Download), 236.8 kbps (Upload)
GPRS: 85.6 kbps(Download), 85.6 kbps (Upload)

GPS

Standalone

GPS bands

1575.42 MHz (± 1.023 MHz), GLONASS 1596-1607MHz

Maximum output power

LTE: +23 dBm (+/- 2 dBm)
WCDMA: +23.5 dBm (+/- 1 dBm)
GPRS Band II, III: +29.5 dBm (+/- 1 dBm)
GPRS Band V, VIII: +32.5 dBm (+/- 1 dBm)
EGPRS Band II, III: +26.5 dBM (+/-1.5 dBm)
EGPRS Band V, VIII: +27.5 dBM (+/-1.5 dBm)

Maximum power
consumption

LTE: 1,200 mA (peak); <900 mA (average)
WCDMA: 1,100 mA (peak); <800 mA (average)
EGPRS: 2,800 mA (peak); <700 mA (average)

Power consumption,
sleep mode

3 mA

Power management

USB selective suspend, Integrated notebook wireless button

Antenna type

Dual high efficiency multi-band antennae with spatial diversity

Form Factor

M.2, USB 2.0 interface

Weight

6 g

Dimensions
(Length x Width x
Thickness)

42 mm × 30 mm × 2.3 mm

Voltage, Operating

3.135 V to 4.4 V (3.3 V +1.1V/-0.165V)

Temperature, operating
(from TIA/EIA/IS-98-D)

14° to 131° F (–10° to 55° C)

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 24

Temperature, non­operating, 96 hours (from

MIL-STD 202 Method 108)

–40° to 185° F (–40° to 85° C)

Humidity, non-operating

95% relative humidity for 48 hours @ 185° F (85° C) (non-condensing)

LED activity

LED Off - Radio Off; Solid LED On - Radio On

* 4G LTE not available on all products, in all regions and only available on products featuring Intel
processors. WWAN use requires separately purchased service contract. Check with service provider
for coverage and availability in your area. Connection speeds will vary due to location,
environment, network conditions, and other factors.

HP hs3110 HSPA+ Mobile
Broadband Module

Technology/Operating
bands

HSPA+: 2100 (Band 1), 1900 (Band 2), 850 (Band 5), 700 (Band 17) MHz
E-GPRS: 1900 (Band 2), 1800 (Band 3), 850 (Band 5), 900 (Band 8) MHz

Wireless protocol
standards

WCDMA R99, 3GPP Release 5, 6 and 7 UMTS Specification
E-GPRS: Class B, Multi-slot class 33, coding schemes CS1 - CS4 and MSC1 - MSC9

GPS

Standalone, A-GPS

GPS bands

1575.42 MHz ± 1.023 MHz, GLONASS 1596-1607MHz

Maximum data rates

DC-HSPA+: 42 Mbps (Download), 5.76 Mbps (Upload)
HSPA+: 21.6 Mbps (Download), 5.76 Mbps (Upload)
EDGE: 236.8 kbps (Download), 236.8 kbps (Upload)
GPRS: 85.6 kbps(Download), 85.6 kbps (Upload)

Maximum output power

HSPA+: 23.5 dBm
E-GPRS 1900/1800: 26.5 dBM
E-GPRS 900/850: 27.5 dBM
GPRS 1900/1800: 29.5 dBm
GPRS 900/850: 32.5 dBm

Maximum power
consumption

HSPA+: 1,100 mA (peak); 800 mA (average)
E-GPRS: 2,800 mA (peak); 700 mA (average)

Form Factor

M.2, 3042-S3 Key B

Weight

6g

Dimensions

(Length x Width x
Thickness)

1.65 x 1.18 x 0.09 in (42 x 30 x 2.3 mm)

Wireless LAN (WLAN)

Intel® 802.11 a/b/g/n ac
(2X2) + Bluetooth®

Wireless LAN Standards

IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 25

Interoperability

Wi-Fi certified

Frequency Band

802.11b/g/n

 2.402 – 2.482 GHz

Note:
The FCC has declared as of January 1, 2015 products that utilize
passive scanning on channel 12/13 and are capable of
transmitting must fully comply with requirements of 15.247 or
otherwise disable those channels.

802.11a

 4.9 – 4.95 GHz (Japan)
 5.15 – 5.25 GHz
 5.25 – 5.35 GHz
 5.47 – 5.725 GHz
 5.825 – 5.850 GHz

Note:
Indonesia only supports 5.725 - 5.825 GHz (CH149 - CH161)

Data Rates

802.11b: 1, 2, 5.5, 11 Mbps

802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)

802.11ac : MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, and 80MHz)

Modulation

Direct Sequence Spread Spectrum
BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM

Security1

 IEEE and WiFi compliant 64 / 128 bit WEP encryption for a/b/g

mode only

 AES-CCMP: 128 bit in hardware
 802.1x authentication
 WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.
 WPA2 certification
 IEEE 802.11i
 Cisco Certified Extensions, all versions through CCX4 and CCX

Lite

 WAPI

Network Architecture
Models

Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)

Roaming

IEEE 802.11 compliant roaming between access points

Output Power2

802.11b : +16dBm minimum

802.11g : +14dBm minimum

802.11a : +14dBm minimum

802.11n HT20(2.4GHz) : +13dBm minimum

802.11n HT40(2.4GHz) : +13dBm minimum

802.11n HT20(5GHz) : +12dBm minimum

802.11n HT40(5GHz) : +12dBm minimum

802.11ac 80MHz(5GHz) : +11dBm minimum

Power Consumption

Transmit: 2.0 W (max)
Receive: 1.6 W (max)
Idle mode (PSP): 180 mW (WLAN Associated)
Idle mode: 60 mW (WLAN unassociated)
Radio disabled: 30 mW

Power Management

ACPI and PCI Express compliant power management

802.11 compliant power saving mode

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 26

Receiver Sensitivity3

802.11b, 1Mbps : -94dBm maximum

802.11b, 11Mbps : -86dBm maximum

802.11g, 6Mbps : -88dBm maximum

802.11g, 54Mbps : -74dBm maximum

802.11a, 6Mbps : -86dBm maximum

802.11a, 54Mbps : -72dBm maximum

802.11n, MCS07 : -69dBm maximum

802.11n, MCS15 : -66dBm maximum

802.11ac, 1SS, MCS-0 : -86dBm maximum

802.11ac, 1SS, MCS-9 : -61dBm maximum

802.11ac, 2SS, MCS-0 : -83dBm maximum

802.11ac, 2SS, MCS-9 : -58dBm maximum

Antenna type

High efficiency antenna with spatial diversity, mounted in the display
enclosure
Two embedded dual band 2.4/5 GHz antennas are provided to the card
to support WLAN MIMO communications and Bluetooth communications

Form Factor

PCI-Express M.2 MiniCard

Dimensions

Type 2230 : 2.3 x 22.0 x 30.0 mm
Or
Type 1630 : 2.3 x 16.0 x 30.0 mm

Weight

Type 2230 : 2.8g
Or
Type 1630 : 2g

Operating Voltage

3.3v +/- 9%

Temperature

Operating
Non-operating

14° to 158° F (–10° to 70° C)
–40° to 176° F (–40° to 80° C)

Humidity

Operating
Non-operating

10% to 90% (non-condensing)
5% to 95% (non-condensing)

Altitude

Operating
Non-operating

0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)

LED Activity

LED Amber – Radio OFF; LED White – Radio ON

1. Check latest software/driver release for updates on supported security features.

2. Maximum output power may vary by country according to local regulations.

3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation)
and a packet error rate of 10% for 802.11a/g (OFDM modulation).

HP Integrated Module with Bluetooth 4.0+EDR Wireless Technology

Bluetooth Specification

4.0+EDR Compliant

Frequency Band

2402 to 2480 MHz

Number of Available Channels

79 (1 MHz) available channels

Data Rates and Throughput

3 Mbps data rate; throughput up to 2.17 Mbps

Synchronous Connection Oriented links up to 3, 64 kbps, voice channels

Asynchronous Connection Less links 2178.1 kbps/177.1 kbps
asymmetric or 1306.9 kbps symmetric

Transmit Power

The Bluetooth component shall operate as a Class II Bluetooth device
with a maximum transmit power of +4 dBm for BR and EDR.

Receiver Sensitivity

Modulation

0.01% BER

0.001% BER

GFSK

-80 dBm

-70 dBm

π/4-DQPSK

-80 dBm

-70 dBm

8DPSK

-80 dBm

-70 dBm

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 27

Power Consumption

Peak (Tx) 330 mW
Peak (Rx) 230 mW
Selective Suspend 17 mW

Range

Up to 33 ft (10 m)

Electrical Interface

USB 2.0 compliant

Bluetooth Software Supported
Link Topology

Microsoft Windows Bluetooth Software

Electrical Interface
Bluetooth Software Supported
Security

Point to Point, Multipoint Pico Nets up to 7 slaves

Full support of Bluetooth Security Provisions

Power Management
Power Management
Certifications

Microsoft Windows ACPI, and USB Bus Support

Self-configurable to optimize power conservation in all operating
modes, including Standby, Hold, Park, and Sniff

Security

All necessary regulatory approvals for supported countries, including:

Certifications
Bluetooth Profiles Supported

FCC (47 CFR) Part 15C, Section 15.247 & 15.249

Power Management
Certifications

ETS 300 328, ETS 300 826

Low Voltage Directive IEC950

Certifications
Bluetooth Profiles Supported

UL, CSA, and CE Mark

Serial Port Profile (SPP)1
Service Discovery Application Profile (SDAP)
Dial-Up Networking (DUN)

1,2

Generic Object Exchange Profile (GOEP)

1,2

Object Push Profile (OPP)

1,2

File Transfer Profile (FTP)
Synchronization Profile (SYNC)
Hard Copy Cable Replacement (HCRP)

1,2

Personal Area Networking Profile (PAN)

1,2

Human Interface Device Profile (HID)

1,2

FAX Profile (FAX)
Basic Imaging Profile (BIP)2
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)

Intel® 802.11 a/b/g/n
(2X2) +Bluetooth®

Wireless LAN
Standards

IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n

Interoperability

Wi-Fi certified

Frequency Band

802.11b/g/n

 2.402 – 2.482 GHz

Note:
The FCC has declared as of January 1, 2015 products that utilize
passive scanning on channel 12/13 and are capable of transmitting
must fully comply with requirements of 15.247 or otherwise disable
those channels.

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 28

802.11a

 4.9 – 4.95 GHz (Japan)
 5.15 – 5.25 GHz
 5.25 – 5.35 GHz
 5.47 – 5.725 GHz
 5.825 – 5.850 GHz

Note:

Indonesia only supports 5.725 - 5.825 GHz (CH149 - CH161)

Antenna Structure

2 transmit; 2 receive (2x2)

Data Rates

802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11b: 1, 2, 5.5, 11 Mbps

802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)

Modulation

Direct Sequence Spread Spectrum
CCK, BPSK, QPSK, 16-QAM, 64-QAM

Security1

 IEEE and WiFi compliant 64 / 128 bit WEP encryption for a/b/g

mode only

 AES-CCMP: 128 bit in hardware
 802.1x authentication
 WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.
 WPA2 certification
 IEEE 802.11i
 Cisco Certified Extensions, all versions through CCX4 and CCX

Lite

 WAPI

Sub-channels

Multinational support with frequency bands and channels compliant to
local regulations.

Network Architecture
Models

Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)

Roaming

IEEE 802.11 compliant roaming between band Access Points

Output Power2

 802.11b : +16dBm minimum
 802.11g : +14dBm minimum
 802.11a : +14dBm minimum
 802.11n HT20(2.4GHz) : +13dBm minimum
 802.11n HT40(2.4GHz) : +13dBm minimum
 802.11n HT20(5GHz) : +12dBm minimum
 802.11n HT40(5GHz) : +12dBm minimum

Power Consumption

Transmit: 2.0 W (max)
Receive: 1.6 W (max)
Idle mode (PSP): 180 mW (WLAN Associated)
Idle mode: 60 mW (WLAN unassociated)
Radio disabled: 30 mW

Power Management

ACPI and PCI Express compliant power management

802.11 compliant power saving mode

Receiver Sensitivity4

802.11b, 1Mbps : -94dBm maximum

802.11b, 11Mbps : -86dBm maximum

802.11g, 6Mbps : -88dBm maximum

802.11g, 54Mbps : -74dBm maximum

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 29

802.11a, 6Mbps : -86dBm maximum

802.11a, 54Mbps : -72dBm maximum

802.11n, MCS07 : -69dBm maximum

802.11n, MCS15 : -66dBm maximum

Antenna type

High efficiency antenna with spatial diversity, mounted in the display
enclosure
Two embedded dual band 2.4/5 GHz antennas are provided to the card
to support WLAN MIMO and Bluetooth communications

Form Factor

PCI-Express M.2 MiniCard

Dimensions

Type 2230 : 2.3 x 22.0 x 30.0 mm
Or
Type 1630 : 2.3 x 16.0 x 30.0 mm

Weight

Type 2230 : 2.8g
Or
Type 1630 : 2g

Operating Voltage

3.3v +/- 9%

Temperature

Operating
Non-operating

14° to 158° F (-10° to 70° C)

-40° to 176° F (-40° to 80° C)

Humidity

Operating
Non-operating

10% to 90% (non­condensing)
5% to 95% (non-condensing)

Altitude

Operating
Non-operating

0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)

LED Activity

LED Amber - Radio OFF; LED White - Radio ON

1. Check latest software/driver release for updates on supported security features.

2. Maximum output power may vary by country according to local regulations.

3. In Power Save Polling mode and on battery power.

4. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CCK modulation) and a packet
error rate of 10% for 802.11a/g (OFDM modulation).

5. WLAN supplier's client utility is required for Cisco Compatible Extensions support with Microsoft Windows
XP. WLAN may also be compatible with certain third-party software supplicants. WLAN supplier IHV
extensions required for Cisco Compatible Extensions support for Microsoft Windows Vista.

HP Integrated Module with Bluetooth 4.0+EDR Wireless Technology

Bluetooth Specification

4.0+EDR Compliant

Frequency Band

2402 to 2480 MHz

Number of Available Channels

79 (1 MHz) available channels

Data Rates and Throughput

3 Mbps data rate; throughput up to 2.17 Mbps

Synchronous Connection Oriented links up to 3, 64 kbps, voice channels

Asynchronous Connection Less links 2178.1 kbps/177.1 kbps
asymmetric or 1306.9 kbps symmetric

Transmit Power

The Bluetooth component shall operate as a Class II Bluetooth device
with a maximum transmit power of +4 dBm for BR and EDR.

Receiver Sensitivity

Modulation

0.01% BER

0.001% BER

GFSK

-80 dBm

-70 dBm

π/4-DQPSK

-80 dBm

-70 dBm

8DPSK

-80 dBm

-70 dBm

Power Consumption

Peak (Tx) 330 mW
Peak (Rx) 230 mW
Selective Suspend 17 mW

Range

Up to 33 ft (10 m)

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 30

Electrical Interface

USB 2.0 compliant

Bluetooth Software Supported
Link Topology

Microsoft Windows Bluetooth Software

Electrical Interface
Bluetooth Software Supported
Security

Point to Point, Multipoint Pico Nets up to 7 slaves

Full support of Bluetooth Security Provisions

Power Management
Power Management
Certifications

Microsoft Windows ACPI, and USB Bus Support

Self-configurable to optimize power conservation in all operating
modes, including Standby, Hold, Park, and Sniff

Security

All necessary regulatory approvals for supported countries, including:

Certifications
Bluetooth Profiles Supported

FCC (47 CFR) Part 15C, Section 15.247 & 15.249

Power Management
Certifications

ETS 300 328, ETS 300 826

Low Voltage Directive IEC950

Certifications
Bluetooth Profiles Supported

UL, CSA, and CE Mark

Serial Port Profile (SPP)1
Service Discovery Application Profile (SDAP)
Dial-Up Networking (DUN)

1,2

Generic Object Exchange Profile (GOEP)

1,2

Object Push Profile (OPP)

1,2

File Transfer Profile (FTP)
Synchronization Profile (SYNC)
Hard Copy Cable Replacement (HCRP)

1,2

Personal Area Networking Profile (PAN)

1,2

Human Interface Device Profile (HID)

1,2

FAX Profile (FAX)
Basic Imaging Profile (BIP)2
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)

Intel® 802.11 ac (2x2) WiFi +
Bluetooth® 4.0 combo
(Indonesia only)

Wireless LAN Standards

IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac

Interoperability

Wi-Fi certified

Frequency Band

802.11b/g/n

 2.402 – 2.482 GHz

Note:
The FCC has declared as of January 1, 2015 products that utilize
passive scanning on channel 12/13 and are capable of
transmitting must fully comply with requirements of 15.247 or
otherwise disable those channels.

802.11a

 4.9 – 4.95 GHz (Japan)

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 31

 5.15 – 5.25 GHz
 5.25 – 5.35 GHz
 5.47 – 5.725 GHz
 5.825 – 5.850 GHz

Note:
Indonesia only supports 5.725 - 5.825 GHz (CH149 - CH161)

Data Rates

802.11b: 1, 2, 5.5, 11 Mbps

802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)

802.11ac : MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, and 80MHz)

Modulation

Direct Sequence Spread Spectrum
BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM

Security1

 IEEE and WiFi compliant 64 / 128 bit WEP encryption for a/b/g

mode only

 AES-CCMP: 128 bit in hardware
 802.1x authentication
 WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.
 WPA2 certification
 IEEE 802.11i
 Cisco Certified Extensions, all versions through CCX4 and CCX

Lite

 WAPI

Network Architecture
Models

Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)

Roaming

IEEE 802.11 compliant roaming between access points

Output Power2

802.11b : +16dBm minimum

802.11g : +14dBm minimum

802.11a : +14dBm minimum

802.11n HT20(2.4GHz) : +13dBm minimum

802.11n HT40(2.4GHz) : +13dBm minimum

802.11n HT20(5GHz) : +12dBm minimum

802.11n HT40(5GHz) : +12dBm minimum

802.11ac 80MHz(5GHz) : +11dBm minimum

Power Consumption

Transmit: 2.0 W (max)
Receive: 1.6 W (max)
Idle mode (PSP): 180 mW (WLAN Associated)
Idle mode: 60 mW (WLAN unassociated)
Radio disabled: 30 mW

Power Management

ACPI and PCI Express compliant power management

802.11 compliant power saving mode

Receiver Sensitivity3

802.11b, 1Mbps : -94dBm maximum

802.11b, 11Mbps : -86dBm maximum

802.11g, 6Mbps : -88dBm maximum

802.11g, 54Mbps : -74dBm maximum

802.11a, 6Mbps : -86dBm maximum

802.11a, 54Mbps : -72dBm maximum

802.11n, MCS07 : -69dBm maximum

802.11n, MCS15 : -66dBm maximum

802.11ac, 1SS, MCS-0 : -86dBm maximum

802.11ac, 1SS, MCS-9 : -61dBm maximum

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 32

802.11ac, 2SS, MCS-0 : -83dBm maximum

802.11ac, 2SS, MCS-9 : -58dBm maximum

Antenna type

High efficiency antenna with spatial diversity, mounted in the display
enclosure
Two embedded dual band 2.4/5 GHz antennas are provided to the card
to support WLAN MIMO communications and Bluetooth communications

Form Factor

PCI-Express M.2 MiniCard

Dimensions

Type 2230 : 2.3 x 22.0 x 30.0 mm
Or
Type 1630 : 2.3 x 16.0 x 30.0 mm

Weight

Type 2230 : 2.8g
Or
Type 1630 : 2g

Operating Voltage

3.3v +/- 9%

Temperature

Operating
Non-operating

14° to 158° F (–10° to 70° C)
–40° to 176° F (–40° to 80° C)

Humidity

Operating
Non-operating

10% to 90% (non-condensing)
5% to 95% (non-condensing)

Altitude

Operating
Non-operating

0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)

LED Activity

LED Amber – Radio OFF; LED White – Radio ON

4. Check latest software/driver release for updates on supported security features.

5. Maximum output power may vary by country according to local regulations.

6. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation)
and a packet error rate of 10% for 802.11a/g (OFDM modulation).

HP Integrated Module with Bluetooth 4.0+EDR Wireless Technology

Bluetooth Specification

4.0+EDR Compliant

Frequency Band

2402 to 2480 MHz

Number of Available Channels

79 (1 MHz) available channels

Data Rates and Throughput

3 Mbps data rate; throughput up to 2.17 Mbps

Synchronous Connection Oriented links up to 3, 64 kbps, voice channels

Asynchronous Connection Less links 2178.1 kbps/177.1 kbps
asymmetric or 1306.9 kbps symmetric

Transmit Power

The Bluetooth component shall operate as a Class II Bluetooth device
with a maximum transmit power of +4 dBm for BR and EDR.

Receiver Sensitivity

Modulation

0.01% BER

0.001% BER

GFSK

-80 dBm

-70 dBm

π/4-DQPSK

-80 dBm

-70 dBm

8DPSK

-80 dBm

-70 dBm

Power Consumption

Peak (Tx) 330 mW
Peak (Rx) 230 mW
Selective Suspend 17 mW

Range

Up to 33 ft (10 m)

Electrical Interface

USB 2.0 compliant

Bluetooth Software Supported
Link Topology

Microsoft Windows Bluetooth Software

Electrical Interface
Bluetooth Software Supported
Security

Point to Point, Multipoint Pico Nets up to 7 slaves

Full support of Bluetooth Security Provisions

Power Management

Microsoft Windows ACPI, and USB Bus Support

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 33

Power Management
Certifications

Self-configurable to optimize power conservation in all operating
modes, including Standby, Hold, Park, and Sniff

Security

All necessary regulatory approvals for supported countries, including:

Certifications
Bluetooth Profiles Supported

FCC (47 CFR) Part 15C, Section 15.247 & 15.249

Power Management
Certifications

ETS 300 328, ETS 300 826

Low Voltage Directive IEC950

Certifications
Bluetooth Profiles Supported

UL, CSA, and CE Mark

Serial Port Profile (SPP)1
Service Discovery Application Profile (SDAP)
Dial-Up Networking (DUN)

1,2

Generic Object Exchange Profile (GOEP)

1,2

Object Push Profile (OPP)

1,2

File Transfer Profile (FTP)
Synchronization Profile (SYNC)
Hard Copy Cable Replacement (HCRP)

1,2

Personal Area Networking Profile (PAN)

1,2

Human Interface Device Profile (HID)

1,2

FAX Profile (FAX)
Basic Imaging Profile (BIP)2
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)

Intel® Dual Band Wireless-AC 3160 802.11 ac (1x1) Wi-Fi + Bluetooth®

Wireless LAN Standards

IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac

Interoperability

Wi-Fi certified

Frequency Band

802.11b/g/n

 2.402 – 2.482 GHz

Note:
The FCC has declared as of January 1, 2015 products that utilize
passive scanning on channel 12/13 and are capable of
transmitting must fully comply with requirements of 15.247 or
otherwise disable those channels.

802.11a/n

 4.9 – 4.95 GHz (Japan)
 5.15 – 5.25 GHz
 5.25 – 5.35 GHz
 5.47 – 5.725 GHz
 5.825 – 5.850 GHz

Note:
Indonesia only supports 5.725 - 5.825 GHz (CH149 - CH161)

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 34

Data Rates

 802.11b: 1, 2, 5.5, 11 Mbps
 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
 802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)
 802.11ac : MCS0 ~ MCS7, (1SS) (20MHz, 40MHz, and

80MHz)

Modulation

Direct Sequence Spread Spectrum
BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM

Security1

 IEEE and WiFi compliant 64 / 128 bit WEP encryption for a/b/g

mode only

 AES-CCMP: 128 bit in hardware
 802.1x authentication
 WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.
 WPA2 certification
 IEEE 802.11i
 Cisco Certified Extensions, all versions through CCX4 and CCX

Lite

 WAPI

Network Architecture
Models

Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)

Roaming

IEEE 802.11 compliant roaming between access points

Output Power2

 802.11b : +16dBm minimum
 802.11g : +14dBm minimum
 802.11a : +14dBm minimum
 802.11n HT20(2.4GHz) : +13dBm minimum
 802.11n HT40(2.4GHz) : +13dBm minimum
 802.11n HT20(5GHz) : +12dBm minimum
 802.11n HT40(5GHz) : +12dBm minimum
 802.11ac 80MHz(5GHz) : +11dBm minimum

Power Consumption

Transmit: 2.0 W (max)
Receive: 1.6 W (max)
Idle mode (PSP): 180 mW (WLAN Associated)
Idle mode: 60 mW (WLAN unassociated)
Radio disabled: 30 mW

Power Management

ACPI and PCI Express compliant power management

802.11 compliant power saving mode

Receiver Sensitivity3

802.11b, 1Mbps : -94dBm maximum

802.11b, 11Mbps : -86dBm maximum

802.11g, 6Mbps : -88dBm maximum

802.11g, 54Mbps : -74dBm maximum

802.11a, 6Mbps : -86dBm maximum

802.11a, 54Mbps : -72dBm maximum

802.11n, MCS07 : -69dBm maximum

802.11n, MCS15 : -66dBm maximum

802.11ac, 1SS, MCS-0 : -86dBm maximum

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 35

802.11ac, 1SS, MCS-9 : -61dBm maximum

802.11ac, 2SS, MCS-0 : -83dBm maximum

802.11ac, 2SS, MCS-9 : -58dBm maximum

Antenna type

High efficiency antenna with spatial diversity, mounted in the display
enclosure
Two embedded dual band 2.4/5 GHz antennas are provided to the card
to support WLAN MIMO communications and Bluetooth communications

Form Factor

PCI-Express M.2 MiniCard

Dimensions

Type 2230 : 2.3 x 22.0 x 30.0 mm
Or
Type 1630 : 2.3 x 16.0 x 30.0 mm

Weight

Type 2230 : 2.8g
Or
Type 1630 : 2g

Operating Voltage

3.3v +/- 9%

Temperature

Operating
Non-operating

14° to 158° F (–10° to 70° C)
–40° to 176° F (–40° to 80° C)

Humidity

Operating
Non-operating

10% to 90% (non-condensing)
5% to 95% (non-condensing)

Altitude

Operating
Non-operating

0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)

LED Activity

LED Amber – Radio OFF; LED White – Radio ON

7. Check latest software/driver release for updates on supported security features.

8. Maximum output power may vary by country according to local regulations.

9. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation)

and a packet error rate of 10% for 802.11a/g (OFDM modulation).

Hardware

Implementation

Realtek ALC3228 HD

Function Key Volume
Controls

Volume up, volume down, and mute

Full Duplex

Yes

Microphone In

Stereo

Headphone/Line Out

Stereo

Integrated Microphone

Yes, dual digital microphone array

Audio Output Quality

Frequency Response

20 Hz – 20 kHz

Signal to Noise Ratio

>85 dB

Total Harmonic
Distortion

0.01%

Noise Floor

–110 dB

AUDIO/MULTIMEDIA - DTS SOUND+

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 36

Play/Record Sampling
Rate(s)

8 kHz – 48kHz

DAC

16, 20 or 24-bit

ADC

16 or 20-bit

Integrated Stereo
Speakers

Power Rating

2 Watts

Impedance

4 Ohms

HP Fingerprint Reader
(optional)

Mobile Voltage Operation

3.0V-3.6V

Operating Temperature

14° – 167°F (-10° – 75°C)

Current Consumption

36 mA peak

Low Latency Wait for
Finger

950 uA

Capture Rate

6000 lines/sec

ESD Resistance

IEC 61000-4-2 4B (±15KV)

Detection Matrix

200*1 (plus another secondary line)
508 dpi
12*3 mm sensor area

Smart Card Reader

Smart card standard

PC/SC 2.0 for Windows smart card standard

Dimensions (L x W x H)

0.41x 0.08 x 0.32 in (10.5 x 2 x 8.2 mm)

Smart Card support

ISO 7816 Class A and AB smart cards

Smart Card Interface

Smart Card Interface with T = 0 and T = 1 support
Support I2C memory card, SLE4418, SLE4428, SLE4432, SLE4442, SLE4436,
SLE5536, SLE6636, AT88SC1608, AT45D041 card and AT45DB041 card via
external EEPROM

Operating systems

No driver is required for this device. Native support is provided by the
operating system.

Power

Normal Mode

With card present, before being suspended: 40.9 mA
Without card present, before being suspended:

33.16 mA
After being suspended with smart card present: 380
μA
After being suspended without smart card present:
380 μA

Power Saving

Mode

With card present, before being suspended: 40.6 mA
Without card present: 380 μA
After being suspended with smart card present: 380
μA

Features

 Support single slot
 Support T0, T1 protocol

SECURITY

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 37

 Support I2C memory card, SLE4418, SLE4428, SLE4432, SLE4442,

SLE4436,

 SLE5536, SLE6636, AT88SC1608, AT45D041 card and AT45DB041

card via external EEPROM

 Support ISO7816 Class A, B and C (5V/3V/1.8V) card
 Implemented as an USB full speed device with bulk transfer

endpoint, Mass

 Storage endpoint
 Built-in PLL for USB and Smart Card clocks requirement
 Support EEPROM for USB descriptors customization (PID/VID/

iManufacturer/iProduct/Serial Number), Direct Web Page Link, and
accessing memory card module.

 EEPROM programmable via USB interface
 Support software update for memory card module
 Support Direct Web Page Link via configuration in external EEPROM
 Support short APDU and extended APDU
 Compatible with Microsoft USB-CCID driver
 Support remote wake up through inserting card/removing card
 Support USB selective suspend
 Support Power Saving Mode (Using one pin to select between

Normal/PWR Saving Mode)

 Support card power over current protection mechanism
 Built in resonator.
 Support USB LPM (Link Power Management) features.
 Embedded clock source.

HP 45W Smart AC Adapter
Non-Slim (740015)& Non­Slim 2 Prong (742313)

Dimensions

95.0 x 40.0 x 26.5mm

Input

90 to 265 VAC

Input Efficiency

88% min at 115 VAC / 89% min at 230VAC

Input frequency range

47 to 63 Hz

Input AC current

1.4 A at 90 VAC and maximum load

Output

Output power

45W

DC output

19.5V

Hold-up time

5 msec at 115 VAC input

Output current limit

<8A, Over voltage protection- 29V max
automatic shutdown

Connector

3 pin/grounded, mates with interchangeable cords

Environmental Design

Operating
temperature

32° to 95° F (0° to 35° C)

Non-operating (storage)
temperature

-4° to 121° F (-20° to 85° C)

Altitude

0 to 16,405 ft (0 to 5,000 m)

Humidity

0% to 95%

Storage Humidity

0% to 95%

POWER

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 38

EMI and Safety
Certifications

CE Mark - full compliance with LVD and EMC directives; Worldwide safety
standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals

- C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B,
CCC, NOM-1 NYCE; Reliability - failure rate of less than 0.1% annually within
the first three years of operation.

HP 65W Smart AC
Adapter

Dimensions

4.17 x 1.85 x 1.1 in (10.6 x 4.7 x 2.8 cm)

Weight

0.62 lb (280 g)

Input

100 to 240 VAC

Input Efficiency

87% min at 115 VAC

Input frequency range

47 to 63 Hz

Input AC current

1.7 A at 90 VAC, 0.85 A at 180 VAC

Output

Output power

65W

DC output

18.5V

Hold-up time

5 msec at 115 VAC input

Output current limit

<11A, Over voltage protection- 29V max
automatic shutdown

Connector

3 pin/grounded, mates with interchangeable cords

Environmental Design

Operating temperature

32° to 104° F (0° to 40° C)

Non-operating (storage)
temperature

-4° to 149° F (-20° to 65° C)
Altitude

0 to 16,405 ft (0 to 5, 000 m)

Humidity

20% to 80%

Storage Humidity

10% to 90%

EMI and Safety
Certifications

CE Mark - full compliance with LVD and EMC directives; Worldwide safety
standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals

- C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class
B, CCC, NOM-1 NYCE; MTBF - over 200,000 hours at 25°C ambient condition.

HP 65W EM Smart AC
Adapter

Dimensions

4.98 x 1.97 x 1.18 in (12.65 x 5.0 x 3.0 cm)

Weight

0.62 lb (300 g) max

Input

90 to 265 VAC

Input Efficiency

87% min at 115 VAC

Input frequency range

47 to 63 Hz

Input AC current

1.7 A at 90 VAC

Output

Output power

65W

DC output

19.5V

Hold-up time

5 msec at 115 VAC input

Output current limit

<11A, Over voltage protection- 29V max
automatic shutdown

Connector

3 pin/grounded, mates with 4.5mm barrel type Smart ID DC connector

Environmental Design

Operating
temperature

32° to 95° F (0° to 35° C)

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 39

Non-operating (storage)
temperature

-4° to 185° F (-20° to 85° C)

Altitude

0 to 16,405 ft (0 to 5,000 m)

Humidity

20% to 95%

Storage Humidity

10% to 95%

EMI and Safety
Certifications

CE Mark - full compliance with LVD and EMC directives; Worldwide safety
standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals

- C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B,
CCC, NOM-1 NYCE; MTBF - over 200,000 hours at 25°C ambient condition.

3-cell HP Long Life
(24WHr) Lithium-Ion
Polymer

Dimensions (H x W x L)

7.8 x 4.01 x 0.3 in(19.89x10.28x0.84 cm)

Weight

180 g

Cells/Type

3-cell Lithium-Ion Polymer

Energy

Voltage

11.1

Amp-hour capacity

2.2 Ah

Watt-hour capacity

24Wh

Temperature

Operating (Charging)

32° to 113° F (0° to 45° C)

Operating (Discharging)

14° to 140° F(-10° to 50° C)

Non-operating

-4° to 140° F (-20° to 50° C)

Battery
Re-Charge Time

System in OFF or
Standby Mode

3 hours

Fuel Gauge LED

No

Warranty

1 year or 3 years*
*Battery warranty depends on the platform warranty.

Optional Travel Battery
Available

No

3-cell HP Long Life (50
WHr) Lithium-Ion
Polymer

Dimensions (H x W x L)

7.8 x 4.01 x 0.3 in(19.89x10.28x0.84 cm)

Weight

280 g

Cells/Type

3-cell Lithium-Ion Polymer

Energy

Voltage

11.1

Amp-hour capacity

4.504Ah

Watt-hour capacity

50Wh

Temperature

Operating (Charging)

32° to 113° F (0° to 45° C)

Operating (Discharging)

14° to 140° F(-10° to 60° C)

Primary Battery

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 40

Non-operating

-4° to 140° F (-20° to 60° C)

Battery
Re-Charge Time

System in OFF or
Standby Mode

3 hours

Fuel Gauge LED

No

Warranty

1 year or 3 years*
*Battery warranty depends on the platform warranty.

Optional Travel Battery
Available

No

ENVIRONMENTAL

Eco-Label
Certification
s &
declarations

This product has received or is in the process of being certified to the following approvals and may be labeled
with one or more of these marks:

 IT ECO declaration
 US ENERGY STAR®
 EPEAT Gold registered in the United States. See http://www.epeat.net for registration status in your

country.

System
Configuratio
n

The configuration used for the Energy Consumption and Declared Noise Emissions data for the Notebook model
is based on a “Typically Configured Notebook”.

Energy
Consumptio
n
(in
accordance
with US
ENERGY
STAR® test
method)

115VAC, 60Hz

230VAC, 50Hz

100VAC, 60Hz

Normal
Operation
(Sort idle)

11.76 W

11.45 W

11.26 W

Normal
Operation
(Long idle)

5.06 W

4.97 W

4.92 W

Sleep

0.73 W

0.78 W

0.73 W

Off

0.35 W

0.4 W

0.35 W

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 41

Note:

Energy efficiency data listed is for an ENERGY STAR® compliant product if offered within the model family. HP
computers marked with the ENERGY STAR® Logo are compliant with the applicable U.S. Environmental
Protection Agency (EPA) ENERGY STAR® specifications for computers. If a model family does not offer ENERGY
STAR® compliant configurations, then energy efficiency data listed is for a typically configured PC featuring a
hard disk drive, a high efficiency power supply, and a Microsoft Windows® operating system.

Heat
Dissipation*

115VAC, 60Hz

230VAC, 50Hz

100VAC, 60Hz

Normal
Operation
(Short idle)

40 BTU/hr

39 BTU/hr

39 BTU/hr

Normal
Operation
(Long idle)

17 BTU/hr

17 BTU/hr

17 BTU/hr

Sleep

2 BTU/hr

3 BTU/hr

2 BTU/hr

Off

1 BTU/hr

1 BTU/hr

1 BTU/hr

*NOTE: Heat dissipation is calculated based on the measured watts, assuming the service level is attained for
one hour.

Declared
Noise
Emissions
(in
accordance
with
ISO 7779 and
ISO 9296)

Sound Power

(L

WAd

, bels)

Sound Pressure

(L

pAm

, decibels)

Typically
Configured –
Idle

2.9

22

Fixed Disk –
Random
writes

3.0

22

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 42

Batteries

This battery(s) in this product comply with EU Directive 2006/66/EC

Batteries used in the product do not contain:

Mercury greater the1ppm by weight
Cadmium greater than 20ppm by weight

Battery size: CR2032 (coin cell)
Battery type: Lithium
Battery size: 6-cell high capacity Lithium-Ion battery (optional 8 cell available)
Battery type:

Additional
Information

 This product is in compliance with the Restrictions of Hazardous Substances (RoHS) directive -

2011/65/EC.

 This HP product is designed to comply with the Waste Electrical and Electronic Equipment (WEEE)

Directive – 2002/96/EC.

 This product is in compliance with California Proposition 65 (State of California; Safe Drinking Water

and Toxic Enforcement Act of 1986).

 This product is in compliance with the IEEE 1680 (EPEAT) standard at the gold level, see

www.epeat.net

 Plastics parts weighing over 25 grams used in the product are marked per ISO11469 and ISO1043.
 This product contains 8.4 % post-consumer recycled plastic (by wt.)
 This product is 98.1 % recycle-able when properly disposed of at end of life.

Packaging
Materials

External:

PAPER/Corrugated

475 g

Internal:

PLASTIC/EPE (Expanded Polyethylene)

47 g

PLASTIC/Polyethylene low density

26 g

The plastic packaging material contains at least 50 % recycled content.

The corrugated paper packaging materials contains at least 70 % recycled content.

Material
Usage

This product does not contain any of the following substances in excess of regulatory limits (refer to the HP
General Specification for the Environment at

http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/gse.pdf):

 Asbestos
 Certain Azo Colorants
 Certain Brominated Flame Retardants – may not be used as flame retardants in plastics
 Cadmium
 Chlorinated Hydrocarbons
 Chlorinated Paraffins
 Formaldehyde
 Halogenated Diphenyl Methanes
 Lead carbonates and sulfates
 Lead and Lead compounds
 Mercuric Oxide Batteries
 Nickel – finishes must not be used on the external surface designed to be frequently handled or

carried by the user.

 Ozone Depleting Substances
 Polybrominated Biphenyls (PBBs)
 Polybrominated Biphenyl Ethers (PBBEs)

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 43

 Polybrominated Biphenyl Oxides (PBBOs)
 Polychlorinated Biphenyl (PCB)
 Polychlorinated Terphenyls (PCT)
 Polyvinyl Chloride (PVC) – except for wires and cables, and certain retail packaging has been

voluntarily removed from most applications.

 Radioactive Substances
 Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)

Packaging
Usage

HP follows these guidelines to decrease the environmental impact of product packaging:

 Eliminate the use of heavy metals such as lead, chromium, mercury and cadmium in packaging

materials.

 Eliminate the use of ozone-depleting substances (ODS) in packaging materials.
 Design packaging materials for ease of disassembly.
 Maximize the use of post-consumer recycled content materials in packaging materials.
 Use readily recyclable packaging materials such as paper and corrugated materials.
 Reduce size and weight of packages to improve transportation fuel efficiency.
 Plastic packaging materials are marked according to ISO 11469 and DIN 6120 standards.

End-of-life
Management
and
Recycling

Hewlett-Packard offers end-of-life HP product return and recycling programs in many geographic areas. To
recycle your product, please go to: http://www.hp.com/go/reuse-recycle or contact your nearest HP sales
office. Products returned to HP will be recycled, recovered or disposed of in a responsible manner.

The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each
product type for use by treatment facilities. This information (product disassembly instructions) is posted on
the Hewlett Packard web site at: http://www.hp.com/go/recyclers. These instructions may be used by
recyclers and other WEEE treatment facilities as well as HP OEM customers who integrate and re-sell HP
equipment.

Hewlett­Packard
Corporate
Environment
al
Information

For more information about HP’s commitment to the environment:

Global Citizenship Report

http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html

Eco-label certifications

http://www8.hp.com/us/en/hp-information/environment/ecolabels.html

ISO 14001 certificates:

http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/PC_GBU_Product_Design_ISO_14K_C
ertificate.pdf

and

http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/cert.pdf

Country of Origin

China

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 44

Options and Accessories (sold separately and availability may vary by country)

Type

Description

Part #

HP Slim Ultrabook Messenger (up to 15.6" x .88"/22/5mm)

F3W14AA

Cases

HP Slim Ultrabook Top Load (up to 15.6" x .88"/22/5mm)

F3W15AA

Docking

HP 3001pr USB 3 Port Replicator

F3S42AA

HP 3005pr USB 3.0 Port Replicator

H1L08AA#xxx

HP 2013 UltraSlim Docking Station

D9Y32AA#xxx

HP Universal Port Replicator

E6D70AA#xxx

HP Display and Notebook Stand

AW662AA

Input/Output – Mice

HP Comfort Grip Wireless Mouse

H2L63AA

HP X4000b Bluetooth Mouse

H3T50AA#xxx

HP 3-Button USB Laser Mouse

H4B81AA

HP Ultra Mobile Wireless Mouse

H6F25AA#xxx

HP Slim Bluetooth Mouse

F3J92AA#xxx

Input/Output – Keyboards

HP Stylish USB Keyboard and Mouse

H4B80AA#xxx

HP Stylish Wireless Keyboard and Mouse

H4B79AA#xxx

HP USB Essential Keyboard and Mouse

H6L29AA

HP 2.4 GHz Keyboard and Mouse

G1K29AA#xxx

Input/Output – Adapters

HP Wireless Display Adapter

J1V25AA#xxx

USB Graphics Adapter Dual output

C5U89AA

DisplayPort to VGA

F7W97AA

DisplayPort to DVI Adapter

F7W96AA

DisplayPort to HDMI Cable

F3W43AA

Power

HP 65W Slim AC Adapter

H6Y82AA#xxx

HP 90W Slim AC Adapter

H6Y83AA#xxx

HP 90W Slim Combo AC Adapter w/USB

H6Y84AA#xxx

HP 45W Smart AC Adapter

H6Y88AA#xxx

HP 65W Smart AC Adapter

H6Y89AA#xxx

HP 90W Smart AC Adapter

H6Y90AA#xxx

90W Smart AC/Auto/Air Combo Adapter

AJ652AA#xxx

90W Smart Auto/Truck Adapter

ED493AA

Batteries

HP CA06XL Notebook Battery

E7U21AA

Security

HP Docking Station Cable Lock

AU656AA#XXX

HP UltraSlim Keyed Cable Lock

H4D73AA

Storage - External Storage

HP USB External DVDRW Drive

F2B56AA

Misc.

HP 15.6" Notebook PC Privacy Filter

J7H71AA

Displays

HP EliteDisplay S231d 23-in IPS LED BLU Notebook Docking
Monitor

F3J72AA

QuickSpecs

HP EliteBook 850 G2 Notebook PC

c04472797 – World Wide – Version 3 – January 26, 2015

Page 45

Copyright © 2015 Hewlett-Packard Development Company, L.P.

All rights reserved. Intel, Core, and Celeron are registered trademarks or trademarks of Intel Corporation in the U.S. and/or other
countries. Bluetooth is a trademark owned by its proprietor and used by Hewlett-Packard Company under license.Microsoft and
Windows are U.S. registered trademarks of Microsoft Corporation. Adobe is a trademark of Adobe Systems Incorporated. ENERGY
STAR is a registered mark owned by the U.S. government.
The information contained herein is subject to change without notice and is provided "as is" without warranty of any kind. The
warranties for HP products are set forth in the express limited warranty statements accompanying such products. Nothing herein
should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions
contained herein.

QuickSpecs

HP EliteBook 850 G2 Notebook PC

Summary of Changes

c04472797 – World Wide – Version 3 – January 26, 2015

Page 46

Date of change:

Version
History:

Description of change:

January 20, 2015

V1 to V2

Added

The words ‘up to’ to all battery life specs

January 26, 2015

V2 to V3

Added

Environmental information and stand by time
