QuickSpecs
Overview
hp iPAQ Pocket PC h5400 Series
At A Glance
•
Integrated Wireless LAN 802.11b
•
Integrated Bluetooth
•
Integrated Biometri c Fingerprint
Reader
•
Removable/Rechargeable
Battery
•
Dazzling Transf lective TFT color
liquid crys tal display
•
Integrated SD slot
•
Intel XScale processor
•
Increased memory
•
Advanced Power Management
•
Consumer Infrared and IrDA SIR
•
3.5 mm 4-way Audio Jack
•
Microsoft Pocket PC 2002
DA-11427 North America — Version 3 — January 7, 2003 1
QuickSpecs
Standard Features
MODELS
iPAQ Pocket PC h5450 – 48-MB ROM/64-MB RAM WLAN/BT/Biometrics/SD
264493-001 – U.S. Commercial
264493-121 – French Canadian
iPAQ Pocket PC h5455 –48-MB ROM/64-MB RAM WLAN/BT/Biometrics/SD
264493-002 – U.S. Retail
Processor 400 MHz Intel PXA250 Application Processor
Memory 64-MB SDRAM; 48-MB Flash ROM Memory
Input Method Handwriting recognition, soft keyboard, character recognition, voice recorder, inking
Interfaces 3-mode alarm notification
Cradle Interfaces
Display Transflective TFT liquid crystal display
Power Supply
Expansion Capabilities Supports Expansion Packs
Audio Capabilities Audio record and playback (play MP3 music or audio programs from the Web, as well as records and plays back
Ergonomic Design Features Multifunction power button
Vibrate, Flashing green LED, tone, pop-up message
Charge active: flashing / solid amber LED
Bluetooth active: flashing /solid blue LED
WLAN active: Flashing green LED
WLAN enabled, searching, but not connected: flashing amber LED
Connector 1
Cable 1 USB or Serial cable connects to PC
DC Jack connector for AC
Adapter
Stylus Holder 2 holes, on left and right front
Stabilizing Tab Release Button 2 Tabs engage the sides of Pocket PC when no Expansion Pack is in use
Base extension An extendable base which can be used to raise cradle to enhance biometric
64K color (65,536 colors) 16-bit touch-sensitive transflective thin film transistor (TFT) liquid crystal display (LCD)
Viewable image size – 2.26 in wide x 3.02 in tall (57.6 mm wide x 76.8 mm tall), 3.8 in Diagonal (96 mm)
1250 mAh Lithium-Ion Polymer removable / rechargeable battery (in docking cradle or with AC Adapter)
Internal Back up battery - Allows user to swap main removable battery with the system power in standby
2500 mAh Lithium-Ion Polymer Extended Battery (sold as an accessory)
Battery Re-Charge Time System in OFF mode or Standby 2.5 hours
NOTE: Battery life will vary based on the usage pattern of an individual user and the configuration of the
handheld. Use of some attachments may significantly decrease battery life.
Integrated SD slot - supports SD/MMC type standard, SDIO ready
voice notes or meeting notes)
Volume up/down/mute
Integrated speaker, 3.5 mm stereo headphone and microphone jack
5-way Joypad
Volume up/down/mute
Biometric Fingerprint Reader
Touch-sensitive display for stylus or fingertip
Microphone and Speaker on front-side of unit
1
fingerprint swipe motion while in cradle
System ON (depending on system power consumption) 3 to 6 hours
hp iPAQ Pocket PC h5400 Series
DA-11427 North America — Version 3 — January 7, 2003 2
QuickSpecs
Standard Features
hp iPAQ Pocket PC h5400 Series
HP Exclusive Applications
(On device)
Companion CD from HP
CD LINKS
CheckPoint
Additional Documentation
NOTE: Programs could vary based on SKU. Some programs are accessed through CD links to download web
NOTE: * = This product features the Macromedia Flash Player. For further information on the Macromedia Flash
Operating System Applications Powered by Microsoft Windows
Applications from Microsoft on
Companion CD
These are the extras that HP put in ROM
iPAQ Fingerprint Reader: enhanced security
iPAQ File Store: non-volatile storage in flash ROM;
iPAQ Task Manager: access and launch programs easily,
iPAQ Backup: utility for Backup/Restore to Main Memory, Memory Card, or iPAQ File Store:
iPAQ Image Viewer: view images and create slide shows,
Nevo: Universal Remote Control,
Adjustable Standby Settings: Utility for adjusting power conservation modes, Utilities:
Self Test, Expansion pack, iPAQ Audio, Power Status
APPLICATIONS
Full Versions Trial Versions
Jeode Java Virtual Machine
Macromedia
Quick View Plus
FileCrypto Data Encryption
Colligo
Bust’em game
SuperScape interactive game
Adobe PDF Viewer
RealOne Player for Pocket PC
iPresenter PowerPoint converter
Pocket Watch World Clock
NetMotion
Avaya IP Softphone
IP Blue VTGO!
Cisco CallManager
Pocket Presence Running Voice IP
Vindigo
Audible Manager and Audible Player (Service plan
equired to download and play Audible content – link)
SingleTap
Handango
Infowave SymmetryPro
GoAmerica Document Manager
CNM Network Xpress Conferencer
iPAQ Reference Guide on PDF and ebook (certain countries only)
Calendar, Contacts, Tasks, Voice Recorder, Notes, Pocket Word (with Spellchecker), Pocket Excel, Pocket
Internet Explorer, Windows Media Player 8 (MP3, audio and video streaming), Calculator, Solitaire, Inbox (with
Spell Checker for email), Microsoft Reader (eBooks), File Explorer, MSN Messenger, Terminal Services Client,
VPN Client, Infrared Beaming, Clock, Align Screen, File Explorer, Memory, Volume control
Additional Software from Microsoft
Outlook 2000, Microsoft ActiveSync 3.5 (Desktop device synchronization), Microsoft Reader eBooks, Links to
Microsoft websites for additional downloadable applications (some programs may require purchase of additional
desktop software to utilize Pocket PC versions)
Flash™ Player*
sites.
Player, visit http://www.macromedia.com/software/flash/about/
for Pocket PC 2002
Xcellenet Device Management Agent
Wordlogic Predictive Keyboard
Eletel Messaging Software
Margi Presenter-to-Go (requires purchase of additional
hardware)
Ewallet
ListPro
Peacemaker Pro application on SKU 264493-002 –
U.S. Retail
.
DA-11427 North America — Version 3 — January 7, 2003 3
QuickSpecs
Standard Features
hp iPAQ Pocket PC h5400 Series
WLAN Specifications*
Radio Specifications
RF Network Standa rd IEEE 802 Part 11b (802.11b)
Frequency Band 2,4000 to 2.4835 GHz
channels
Data Rates 1, 2, 5.5, 11 Mbps
Antenna type High performance ½ wavelength stub, connected via micro strip touch pad
WEP Security 64 bit encryption keys compliant to IEEE 802.11
Network Architecture Models Ad-hoc (Peer to Peer)
Modulation Technique Direct Sequence Spread Spectrum
Modulation Schemes DBPSK, DQPSK, CCK
Receiver Sensitivity – Bit Error
Rate (1E-5)
Maximum Receive Level - 4 dBm (1/2 Mbits)
Output Power (approximately) 17 dBm
Power Management Radio On/Off control through Wireless Control or iPAQ WLAN application
Power Consumption Transfer mode: < 500 mA, maximum
Power Saving Option 802.11 Compliant Power Saving, 50 mA
Media Access Protocol CSMA/CA (Collision Avoidance) with ACK
Protocols Supported TCP/IP
Throughput Data Rate Operating Distance
> 4.5 Mbps 11 Mbps • 1000 feet – Open sight
> 2 Mbps 5.5 Mbps • 1100 feet – Open sight
> 700 Kbps 1 Mbps • 1200 feet – Open sight
Certifications All necessary regulatory approvals for countries we support including:
2,4465 to 2.4835 GHz (France)
2,4000 to 2,4697 GHz (Japan)
United States (FCC) 11 Number of Selectable Sub-
France (FR) 4
Japan (JP) 14
Other countries (ETSI) 13
128 bit encryption key compliant to IEEE 802.11
Infrastructure (Access Points Required)
11 Mbps: <-80 dBm
5.5 Mbps: <-82 dBm
2 Mbps: <-85 dBm
1 Mbps: <-88 dBm
-10dBm (5.5/11 Mbits)
Receive mode: < 260 mA, maximum
Standby mode: < 20 mA, nominal
Power Saving Mode selectable through the configuration utility
ACPI compliant power management
IPX/SPX
UDP
• 100 feet – Closed space (Steel Space)
• 200 feet – Closed space (Steel Space)
• 300 feet – Closed space (Steel Space)
WECA Wi-Fi approval
FCC (47 CFR) Part 15C, Section 15.247&15.249
ETS 300 328, ETS 300 826
Low Voltage Directive IEC950
UL, CSA, and CE Mark
DA-11427 North America — Version 3 — January 7, 2003 4
QuickSpecs
Standard Features
Bl u e t o o t h S p e c i f ic a t i o n s * Technology high-speed, low-power, short-range
Bluetooth specification 1.1 compliant (2.4-GHz Industrial Scientific Medical Band)
System interface 921k high-speed UART processor interface
User Interface Bluetooth Manager
Operating system support Microsoft Pocket PC and Pocket PC 2002
Device type Class II device; up to 4 dBm transmit, typical 10 meter range
Power 3.3V ± 5% Peak current - typical TX current at approximately 140 mA
Receiver sensitivity –78 dBm or greater
Regulatory standards R&TT#-EN 300 328 and EN 300 826, UL 1950, CB Safety Scheme inclusive of
Usage Models *
File Transfer
Serial Port
Access Point
LAN Access
Object Push
Personal Area Ne tworking
Basic Printing and Hard Copy Replacement Profiles
Certifications All necessary regulatory approvals for countries we support including:
NOTE: * A standard WLAN infrastructure, other devices enabled with Bluetooth, and a service contract with a
Profile Support
EN 60950 and IEC 950, FCC Part 15 subpart C, Canadian, CE,
General Access Profile
Service Discovery Application Profile
Serial Port Profile
Generic Object Exchange Profile
File Transfer Profile
Dial-Up Networking Profile
LAN Access Profile
Object Push Profile
Personal Area Networking Profile
Basic Printing Profile
Hard Copy Replacement Profile (printing)
Service Discovery
Determine what Bluetooth devices are within range and support authorization
File and directory browsing and navigation on another Bluetooth device.
File copying
Object manipulation – including add, delete, create new folders etc.
Synchronization between PDAs and PCs
Wireless link to WAN thru cell phone
Agnostic to WAN technology
Send/receive SMS messages
Connect your printer and scanner to your personal network wirelessly
Adhoc Bluetooth Pico-networking (point to multi-point)
Wireless link to Corporate LAN using Bluetooth
Corporate email, network neighborhood, access to LAN applications, file transfer,
ftp, Internet browsing, etc, using TCP/IP
Access the Internet by connecting to your desktop or notebook over Bluetooth
nd using its network connection
Exchange business cards, tasks, documents, appointments and more
Collaborate, chat, play games, exchange data
Adhoc peer to peer networking
Print to any HP Bluetooth printer without the need for cables or specific print
rivers
Bluetooth logo (FCC (47 CFR) Part 15C, Section 15.247&15.249 ETS 300 328,
ETS 300 826 Low Voltage Directive IEC950 UL and CE Mark
wireless airtime provider may be required for applicable wireless communication. Wireless Internet use
requires a separately purchased service contract. Check with a service provider for availability and
coverage in your area. Not all web content available.
hp iPAQ Pocket PC h5400 Series
DA-11427 North America — Version 3 — January 7, 2003 5
QuickSpecs
Standard Features
hp iPAQ Pocket PC h5400 Series
Biometric Fingerprint Reader Thermal Silicon Sensor - measures the temperature differential between the skin ridges and the air caught in the
Operating System Microsoft Pocket PC 2002
Service and Support One-year parts and labor in most regions; two-year warranty in Europe (one-year warranty for rechargeable
fingerprint valleys.
280 pixel image width
500 dpi pixel pitch
Small sensor size (0.4 x 14 mm) optimized for handheld devices.
Full fingerprint image is captured by sweeping the finger across the sensor area
High quality image even with dry or difficult fingerprints
Self-cleaning - no latent print is left on the imaging surface
battery pack) 90 days technical support for software in all regions. Optional CarePAQ available in North
America for Next Business Day replacement (at additional charge)
DA-11427 North America — Version 3 — January 7, 2003 6
QuickSpecs
Technical Specifications
hp iPAQ Pocket PC h5400 Series
System Unit
TFT Color Display
AC Adapter
Dimensions
Length of Unit
(without LAN antenna)
Length of Unit
(with LAN antenna)
Width 3.30 to 3.03 in tapering (84.0 to 77.0 mm tapering)
Depth 0.63 in (15.9 mm)
Weight 7.26 oz (206 g)
Operating Temperature 32° to 104° F (0° to 40° C)
Operating Humidit y 10% to 90%
Regulatory Marks Electrical FCC Class B, VCCI, CE, C-Tick,
Safety CE Marking, C-UL, NOM
RAM 64 MB
ROM (Flash) 48 MB (Flash ROM)
Number of Colors 65,536 (64K 16-bit)
Resolution (W x H) 240 x 320
Dot Pitch 0.24 mm
Viewable Image (W x H) 2.26 x 3.02 in (57.6 x 76.8 mm), 3.8 in Diagonal (96 mm)
Display Type Color (65,536 colors (16 bit) transflective thin film transistor (TFT) liquid crystal
Dimensions (H x W x D) 3 x 1.9 x 1.8 in (76 x 48 x 44 mm) (including prongs)
Cord Length (approximate) 6 ft (1.83 m)
Power Supply Ratings Voltage Range 100 to 240 V Switching
Input Current 0.3 A
Input Frequency 50 to 60 Hz
Output Voltage 5 VDC
Output Current 2 Amp
5.23 in (133.0 mm)
5.43 in (138.0 mm)
display (LCD))
Up to 20 MB non-volatile flash ROM storage
available in iPAQ File Store (varies by SKU)
DA-11427 North America — Version 3 — January 7, 2003 7
QuickSpecs
Technical Specifications
hp iPAQ Pocket PC h5400 Series
Removable/Rechargeable Battery
Battery Life Estimations
1250 mAh Lithium Polymer
Internal backup battery (not removable)
Usage Scenarios using Slim Removable 1250 mAh battery
Idle Mode (screen active with no
user Input or Output)
Active Mode, Backlight off
(frequent user input)
Idle Mode, WLAN receive only
(Power Management On)
Idle Mode, Backlight off, WLAN
transmit and receive (Power
Management On)
NOTE: These scenarios are estimations using the default Standby Setting of 72 hours. Battery life will vary
based on an estimated typical use pattern of an average user, the configuration of the computer and the
usage pattern of the individual user. Use of some attachments may significantly decrease battery life.
Up to 12 hours
Up to 10 hours
Up to 7 hours
Up to 4 hours
DA-11427 North America — Version 3 — January 7, 2003 8
QuickSpecs
Options
Expansion Packs CF Card Expansion Pack Plus 249709-B21
PC Card Expansion Pack Plus 249708-B21
CF Card Expansion Pack 170339-B22
Dual-Slot PC Card Expansion Pack 216198-B21
Style Packs Cover Pack 249707-B21
Memory/Storage IBM Microdrive with PC Card Adapter 217390-B25
64-MB SD Memory Card 253478-B21
128-MB SD Memory Card 253479-B21
256-MB SD Memory Card 287464-B21
CompactFlash (CF) 32-MB Memory Card 104703-004
CompactFlash (CF) 64-MB Memory Card 104703-003
NOTE: Any CF Card Expansion Pack required.
Power AC Adapter 253629-001
Auto Adapter 253508-B21
Slim Battery for Expansion Pack Plus Products 253512-B21
Extended Battery for Expansion Pack Plus Products 253514-B21
iPAQ Pocket PC Slim Battery 290484-B21
iPAQ Pocket PC Extended Battery 290486-B21
Battery Charger 253516-001
Charger Adapter 274707-B21
Slim Keyboard Expansion Pack 312391-001
H5400 Slim Battery 290484-B21
H5400 Extended Battery 290486-B21
Synchronization AutoSync Cable (USB and Serial) 250178-B21
Desktop Cradle (USB and Serial) 250182-B21
Communications WL110 Wireless PC Card (requires PC Card Expansion Pack) 191808-B21
CompactFlash Modem 56K V.90 (requires CF Card Expansion Pack) 268927-001
Cases Expandable Case 217883-B22
Premier Leather Case 253504-B21
Zippered Leather Case 262207-B21
Rugged Case 230465-B21
Three Pack of Screen Protectors 253517-B21
hp iPAQ Pocket PC h5400 Series
DA-11427 North America — Version 3 — January 7, 2003 9
QuickSpecs
Options
Other Stylus Three-Pack Replacement Kit 253510-B21
Micro Keyboard 250111-001
Foldable Keyboard 249693-001
NOTE: Options are sold separately
HP PCs use genuine Microsoft
http://www.microsoft.com/piracy/howtotell
2003 Hewlett-Packard Company
Hewlett-Packard Company shall not be liable for technical or editorial errors or omissions contained herein or for incidental or consequential
damages in connection with the furnishing, performance, or use of this material. The information in this document is provided ″as is″ without
warranty of any kind, including, but not limited to, the implied warranties of merchantability and is subject to change without notice. The warranties
for HP products are set forth in the express limited warranty statements accompanying such products. Nothing herein should be
construed as constituting an additional warranty.
Microsoft, Windows, and ActiveSync, are registered trademarks or trademarks of Microsoft Corporation. Intel is a registered
trademark of Intel Corporation in the United States and/or other countries. Macromedia, Flash and Macromedia Flash are registered
trademarks or trademarks of Macromedia, Inc. in the United States and/or other countries. Adobe, Acrobat and Acrobat Reader are
trademarks or registered trademarks of Adobe Systems Incorporated. All other product names mentioned herein may be trademarks of their
respective companies.
Windows
hp iPAQ Pocket PC h5400 Series
DA-11427 North America — Version 3 — January 7, 2003 10
Loading...
