HP H470wbt User Manual

HP Officejet H470 Printer series

User Guide

Podręcznik użytkownika

HP Officejet H470 Printer series

User Guide

Edition 1, 2/2007 Reproduction, adaptation or

translation without prior written permission is prohibited, except as allowed under the copyright laws.

The information contained herein is subject to change without notice.

The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

License to copy and use this software is granted provided that it is identified as the "RSA Data Security, Inc. MD4 Message-Digest Algorithm" in all material mentioning or referencing this software or this function.

License is also granted to make and use derivative works provided that such works are identified as "derived from the RSA Data Security, Inc. MD4 Message-Digest Algorithm" in all material mentioning or referencing the derived work.

RSA Data Security, Inc. makes no representations concerning either the merchantability of this software or the suitability of this software for any particular purpose. It is provided "as is" without express or implied warranty of any kind.

These notices must be retained in any copies of any part of this documentation and/or software.

Hewlett-Packard Company notices

The information contained in this document is subject to change without notice.

liable for technical or editorial errors or omissions contained herein.

Acknowledgements

Windows and Windows XP are U.S. registered trademarks of Microsoft Corporation. Windows Vista is either a registered trademark or trademark of Microsoft Corporation in the United States and/or other countries.

Adobe® and Acrobat® are trademarks of Adobe Systems Incorporated.

The Bluetooth trademarks are owned by its proprietor and used by HewlettPackard Company under license.

Safety information

Always follow basic safety precautions when using this product to reduce risk of injury from fire or electric shock.

1. Read and understand all instructions in the documentation that comes with the HP Printer.

2. Use only a grounded electrical outlet when connecting this product to a power source. If you do not know whether the outlet is grounded, check with a qualified electrician.

3. Observe all warnings and instructions marked on the product.

4. Unplug this product from wall outlets before cleaning.

5. Do not install or use this product near water, or when you are wet.

6. Install the product securely on a stable surface.

7. Install the product in a protected location where no one can step on or trip over the line cord, and the line cord cannot be damaged.

8. If the product does not operate normally, see

troubleshoot.

9. There are no user-serviceable parts inside. Refer servicing to qualified service personnel.

Maintain and

Contents

1 Get started

Find other resources for the product .........................................................................................6

Accessibility ..............................................................................................................................7

Understand the device parts .....................................................................................................8

Front view .................................................... .......................................................................8

Back and side view ...................................................................................................... .......9

Control Panel ....................................................................................................................10

Bottom view ................................................ ......................................................................11

Travel tips ...............................................................................................................................11

2 Install the accessories

Install and use the battery .......................................................................................................13

Battery safety ....................................................................................................................13

Understand the battery ..................................................................................................... 14

Charge and use the battery .......................................................... ....................................15

Install and use 802.11 and Bluetooth accessories ...................................................... ............16

Install the 802.11 or Bluetooth wireless USB accessory ...................................................16

802.11 and Bluetooth wireless printing .............................................................................17

About 802.11 ................................ ..............................................................................17

About Bluetooth ................................. .........................................................................18

3 Use the device

Select print media ...................................................................................................................19

Tips for selecting and using print media ...........................................................................19

Understand specifications for supported media ........................................ ........................21

Understand supported sizes .......................................................... .............................21

Understand supported media types and weights ........................................................23

Set minimum margins .......................................................................................................23

Load media .............................................................................................................................24

Change print settings ..............................................................................................................24

To change settings from an application for current jobs (Windows) ..................................25

To change default settings for all future jobs (Windows) ..................................................25

To change settings (Mac OS) ...........................................................................................25

Use the HP Solution Center (Windows) ..................................................................................25

Print on both sides (duplexing) ............................ ...................................................................26

Guidelines for printing on both sides of a page .................................................................26

To perform duplexing (Windows) ........................................... ...........................................26

To perform duplexing (Mac OS) ........................................................................................ 27

Print on special and custom-sized media ...............................................................................27

To print on special or custom-sized media (Windows) ......................................................27

To print on special or custom-sized media (Mac OS) .......................................................27

Print borderless ...................................................................................... ................................28

To print a borderless document (Windows) ......................................................................28

To print a borderless document (Mac OS) ........................................................................29

Print from mobile devices ...................................................... .......................... .......................29

Print digital photographs ...................................................................................................29

To print with six-ink color ......................................................... ......................... . .........30

Guidelines for printing photographs ............................................................................30

To print from a PictBridge-compatible camera ................................................. ...........31

To transfer photos to your computer .................................................. .........................31

Print from mobile phones ..................................................................................................31

To install the Mobile Printing Application on the phone ..............................................32

To print from a mobile phone ......................................................................................32

Print from Pocket PC devices .................................................................. .........................32

To install HP Mobile Printing for Pocket PC ................................................... .............33

To print from Pocket PC dev ices ................................................................................33

Print from Palm OS devices ..............................................................................................34

To install Printboy .......................................................................................................34

To install a wireless card ............................................................................................34

To print using standard Palm OS applications .................................. ..........................35

To choose a default printer (optional) .........................................................................35

To print using Documents To Go ......................................................................... .......35

Use memory devices ..............................................................................................................35

Print from memory cards and USB Flash drives .......................................................... .....35

Cancel a print job ....................................................................................................................37

4 Configure and manage

Manage the device .................................................................................................................38

Monitor the device ............................................................................................................38

Administer the device ........................................................... ............................................39

Use device management tools ...............................................................................................39

Toolbox (Windows) ...........................................................................................................40

To open the Toolbox ...................................................................................................40

Toolbox tabs ...............................................................................................................40

HP Printer Utility (Mac OS) ....................................................................... ........................41

To open the HP Printer Utility .......................... ...........................................................41

HP Printer Utility panels ..............................................................................................42

Network Printer Setup Utility (Mac OS) .............................................................................42

Toolbox software for PDAs (Pocket PC and Palm OS) .....................................................42

HP Instant Support ...........................................................................................................43

Security and privacy ...................................................................................................43

To gain access to HP Instant Support ........................................................................43

myPrintMileage .................................................................................................................43

Understand the device information pages ................................. ................. ............................44

Print device information pages from the control panel ........................................... ...........44

Print device information pages from the software .............................................................45

Configure the device (Windows) ................................................ .............................................45

Direct connection ..............................................................................................................46

To install the software before connecting the device (recommended) ........................46

To connect the device before installing the software ..................................................46

To share the device on a locally shared network .................................................. ......47

Configure the device (Mac OS) ...................... ........................................................................47

To install the software .......................................................................................................47

To share the device on a locally shared network ..............................................................48

Uninstall and reinstall the software .........................................................................................48

Contents

802.11 wireless connection ................................................................................ ....................50

About the wireless profile switch .......................................................................................51

About 802.11 wireless network settings ............................................................................51

Set up for 802.11 using factory defaults ...........................................................................52

To set up using ad hoc mode and factory defaults with a USB cable (Windows

and Mac OS) ............................................................................................................... 53

To set up using ad hoc mode and factory defaults with no USB cable (Windows) .....53

To set up a computer to computer (ad hoc) connection using factory defaults

with no USB cable (Mac OS) ......................................................................................54

Set up for 802.11 on existing (non-default) networks ........................................................54

To set up on an existing network with a USB cable (Windows or Mac OS) ................55

To set up on an existing network with no USB cable ..................................................55

Configure and use 802.11 wireless profiles ............................ ..........................................56

To configure 802.11 wireless profiles (Windows) ........................................................56

To configure 802.11 wireless profiles (Mac OS) .........................................................57

Use the wireless profile switch ..........................................................................................57

Reset 802.11 wireless profiles to factory defaults .............................................................58

Configure multiple printers for 802.11 (Windows) .............................................................59

Bluetooth wireless connection ........................ ........................................................................59

Set up a Bluetooth wireless connection ............................................................................60

Configure Bluetooth wireless settings ...............................................................................61

Bluetooth wireless settings options ...................................................................................62

Bluetooth device address ...........................................................................................62

Bluetooth device name ............................. .............................. ............................ ........62

PIN code (Pass Key) .......................... ........................ ........................ ........................63

Reset device access ...................................................................................................64

To reset to factory default settings ..............................................................................64

To turn off Bluetooth ...................................................................................................64

Bluetooth discovery ..........................................................................................................64

Bluetooth fonts ..................................................................................................................64

Wireless configuration page ..................... .......................... ..............................................65

Bonding ................................ .................................................................. ..........................65

Bluetooth wireless profiles ................................................................................................65

5 Maintain and troubleshoot

Work with print cartridges .......................................................................................................67

Replace the print cartridges ...................................................... .. ......................................67

Align the print cartridges ............................................... ......................................... ...........70

Print with a single print cartridge .......................................................................................71

Calibrate color ..................................................................................................................71

Maintain the device ...........................................................................................................71

Clean the device .........................................................................................................72

Clean the print cartridges ........................................................................................... .72

Store printing supplies ......................................................................................................75

Store print cartridges ..................................................................................................75

Replace the ink service module ..............................................................................................76

Troubleshooting tips and resources ........................................................................................76

Solve printing problems ..........................................................................................................77

The device shuts down unexpectedly ........................................ .......................................77

All device lights are on or flashing ....................................................................................78

The device is not responding (nothing prints) ...................................................................78

Device does not accept print cartridge ..............................................................................79

Device takes a long time to print .......................................................................................79

Blank or partial page printed .............................................................................................80

Something on the page is missing or incorrect .......................... ...................... .................80

Placement of the text or graphics is wrong .......................................................................81

Poor print quality and unexpected printouts ............................................................................82

General tips .................................. ...................................................................... ..............82

Meaningless characters print ......................................................... ...................................83

Ink is smearing .................................................................................................................84

Ink is not filling the text or graphics completely .................................................................85

Output is faded or dull colored ..........................................................................................85

Colors are printing as black and white ..............................................................................86

Wrong colors are printing ..................................................................................................86

Printout shows bleeding colors .........................................................................................87

Colors do not line up properly ........................................................ ...................................87

Lines or dots are missing from text or graphics ................................................................87

Solve paper-feed problems .....................................................................................................88

Media is not supported for the device .................................... ...........................................88

Media is not picked up ......................................................................................................88

Media is not coming out correctly ..................... .......................................... ......................88

Pages are skewing ...........................................................................................................89

Multiple pages are being picked up ......................................... .........................................89

Troubleshoot installation issues ..............................................................................................89

Hardware installation suggestions ....................................................................................89

Software installation suggestions ...................................................................................... 90

Problems setting up 802.11 or Bluetooth wireless communication ...................................90

Check the wireless printer accessory ....................................... . ............. ....................91

Check the wireless settings ....................... .................................................................91

Check the network communication .............................................................................91

Check the wireless signal ................................................... ........................................92

Clear jams ................................ ..............................................................................................93

Clear a jam in the device ............................... .............................. .....................................93

Tips for avoiding jams .......................................................................................................94

6 Control-panel lights reference

Interpret control-panel lights ................................................................ .. .................................95

A HP supplies and accessories

Order printing supplies online ...............................................................................................101

Accessories ..........................................................................................................................101

Supplies .................................................................................... ............................................101

Print cartridges ................................................................................................................ 101

HP media ................................................................... .....................................................102

B Support and warranty

Hewlett-Packard limited warranty statement .........................................................................104

Obtain electronic support ............................................................................ ..........................105

Contents

Obtain HP telephone support ...............................................................................................105

Before you call ................................................................................................................105

Support process .............................................................................................................. 106

HP support by phone .......................................................................................... ............106

Phone support period ...............................................................................................106

Telephone support numbers .....................................................................................106

Placing a call .............................................................................................................108

After the phone support period .................................................................................108

Additional warranty options .............................................................................................108

HP Quick Exchange Service (Japan) ..............................................................................109

Prepare the device for shipment ...........................................................................................109

Remove the print cartridges before shipment .................................................................109

Pack the device ....................................................................................................................110

C Device specifications

Physical specifications ......................................................................... .................................112

Product features and capacities ...........................................................................................112

Processor and memory specifications ..................................................................................113

System requirements ............................................................................................................113

Print resolution ......................................................................................................................114

Environmental specifications ................................................................................................114

Electrical specifications .........................................................................................................114

Acoustic emission specifications (noise levels per ISO 7779) ..............................................115

Memory card specifications .................................... ..............................................................115

D Regulatory information

Environmental sustainability program .............................. ............................................ .........116

Reduction and elimination ..............................................................................................116

Energy consumption ............................................................................................ ...........116

Energy Star® notice ........................................................................................................ 116

Material safety data sheets ...................................................... .......................................117

Recycling ..................................................... ...................................................................117

Product packaging ....................................................................................................117

Plastics .................................. ...................................................................................117

HP products and supplies .........................................................................................117

Disposal of waste equipment by users in private households in the European Union ....118

FCC statement .....................................................................................................................119

Other regulatory information .................................................................................................119

Notice to users in Korea ............................ ..................................................................... 120

VCCI (Class B) compliance statement for users in Japan ..............................................120

Notice to users in Japan about the power cord ...............................................................120

Noise emission statement for Germany ..........................................................................120

RoHS notices (China only) ....................................................................................... ......121

LED indicator statement .................................................................................................121

Regulatory model number .................... ............................................ ..............................121

Declaration of conformity ......................................................................................................122

Index...................................................................................................... .....................................123

1 Get started

This guide provides details about how to use the device and to resolve problems.

•

Find other resources for the product Accessibility

• Understand the device parts

• Travel tips

•

Find other resources for the product

You can obtain product information and further troubleshooting resources that are not included in this guide from the following resources:

Resource Description Location

Readme file and release notes

Toolbox (Microsoft Windows®)

HP Printer Utility (Mac OS) Contains tools to configure

Toolbox software for PDAs (Pocket PC and Palm OS)

Control panel Provides status, error, and

Logs and reports Provides information about

Provide late-breaking information and troubleshooting tips.

Provides information about print cartridge health and access to maintenance services.

For more information, see

Toolbox (Windows).

print settings, calibrate the device, clean the print cartridges, print the self-test diagnostic page, order supplies online, and find support information from the Web site.

For more information, see

Printer Utility (Mac OS).

Provides status and maintenance information about the device. You can view ink levels and battery charge level, understand device lights, align print cartridges, and also configure

802.11 and Bluetooth wireless settings for wireless printing.

warning information about operations.

events that have occurred.

Included on the Starter CD.

Typically installed with the device software.

For more information, see

Toolbox software for PDAs (Pocket PC and Palm OS).

For more information, see

Control-panel lights reference.

For more information, see

Monitor the device.

6 Get started

(continued)

Resource Description Location

Self-test diagnostic page

HP Web sites Provide the latest printer

HP telephone support Lists information to contact

HP photo and imaging software help

HP Solution Center (Windows) Allows you to change device

Device information:

•

Product name

Model number

Serial number

Firmware version

number

Accessories installed (for

•

example, the duplexer) Number of pages printed

•

from the trays and accessories

Printing supply status

•

software, and product and support information.

HP. During the warranty period, this support is often free of charge.

Provides information about using the software.

settings, order supplies, start, and access the onscreen Help. Depending on the devices you have installed, the HP Solution Center provides additional features, such as access to the HP photo and imaging software and the Fax Setup Wizard. For more information, see

Use the HP Solution Center (Windows).

For more information, see

Understand the device information pages.

www.hp.com/support www.hp.com

For more information, see

Obtain HP telephone support.

Typically installed with the device software.

Accessibility

The device provides a number of features that make it accessible for people with disabilities.

Visual

The device software is accessible for users with visual impairments or low vision through the use of your operating system's accessibility options and features. It also supports most assistive technology such as screen readers, Braille readers, and voiceto-text applications. For users who are color blind, colored buttons and tabs used in the software and on the control panel have simple text or icon labels that convey the appropriate action.

Mobility

Accessibility

Chapter 1

For users with mobility impairments, the device software functions can be executed through keyboard commands. The software also supports Windows accessibility options such as StickyKeys, ToggleKeys, FilterKeys, and MouseKeys. The device doors, buttons, paper trays, and paper guides can be operated by users with limited strength and reach.

Support

For more details about the accessibility of this product and HP's commitment to product accessibility, visit HP's Web site at

For accessibility information for the Mac OS, visit the Apple Web site at

www.apple.com/accessibility.

Understand the device parts

• Front view Back and side view

• Control Panel

• Bottom view

•

Front view

www.hp.com/accessibility.

1 Input tray extension (not included in models for some countries/regions) – Slides

2 Input tray – Holds the media. Remove media and close this tray when the device is not

3 Wide media paper guide – Letter, legal, and A4 are loaded flush against this guide.

8 Get started

up to support legal size print media. This prevents possible media feed problems.

in use.

(continued)

4 Media width guide – Adjusts to accommodate different media sizes. Slide to the right to

accommodate narrow media. This automatically slides the narrow media guide to the left to ensure that media is aligned for correct print margins.

5 Narrow media guide – When you move the media width guide to the right, this guide

automatically slides to the left to accommodate narrower media.

6 Print cartridge latches – Lift these latches for easy removal and insertion of print

cartridges. 7 Print cartridge cradle compartments – Holds the print cartridges. 8 Front access cover – Provides access to the print cartridges and for clearing paper

jams. This cover must be closed before printing can begin. 9 Output slot – Media exits the device from here. 10 Output door – Drops open automatically when the device is turned on. Allows media to

exit the device.

Back and side view

1 Battery contacts – Provides contact for power from the optional battery. For more

information, see HP supplies and accessories.

2 Battery contact cover – Covers the battery contacts when the optional battery is not

installed. 3 Battery slot – Battery installs here. 4 PictBridge/USB Host Port – Connects a PictBridge device, such as a digital camera, a

USB Flash drive, or an 802.11 or USB device. 5 USB port – Connect a USB cable here. 6 Wireless profile switch – Store settings for up to three 802.11 computers or networks.

This allows you to easily move the device from home to the office or between any three

wireless network environments. 7 Power connector – Connect the power cord here.

Understand the device parts 9

Chapter 1

(continued)

8 Security lock slot – Connect a security lock here. 9 SD, MMC slots – Accepts a Secure Digital (SD) card or Multimedia Card (MMC) for

10 USB slot – Accepts 802.11 or Bluetooth wireless USB accessory.

Control Panel

printing digital images.

1 (Cancel button) – Cancels the current print job. The time it takes to cancel

3 Resume light – Lights up in amber when a print job is waiting, and blinks or turns on

4 Battery charging light – Lights up in green when the battery is charging. 5 Left print cartridge light – Blinks when the left print cartridge is absent or improperly

6 Right print cartridge light – Blinks when the right print cartridge is absent or

7 8 Power light – Lights up in green when the printer is turned on using the AC adapter

depends on the size of the print job. Press this button only once to cancel a queued print job.

(Resume button) – Resumes a print job that is waiting or after temporary

interruption (for example, when adding print media to the printer).

to relay status or a need for intervention.

functioning. Turns on solid when the ink is low or empty.

improperly functioning. Turns on solid when the ink is low or empty.

(Power button) – Turns the printer off or on.

or a 41-100% charged battery. When powered by battery, lights up in amber when battery is 10-40% charged, and red when battery is below 10% charged. Blinks during printing.

10 Get started

Bottom view

1 Card holder – Holds a name card or business card. 2 Cover of replaceable ink service module – Provides access to the ink service module.

Travel tips

The following tips will help you prepare for traveling with your device:

• If you are bringing an extra black or photo print cartridge, follow these guidelines: For a partially used black print cartridge or a partially used or full photo print cartridge, store it in the travel holder to prevent ink leakage (see

supplies). A newly opened black print cartridge will leak slightly at high altitudes

(such as in airplanes). To avoid this, wait to install new black cartridges until you reach your destination. Until then, keep them in their original, taped packaging.

• You can bring the device in a carrying case. For more information, see

supplies and accessories. The carrying case has compartments for both your

notebook and the device. The compartments also detach if you want to carry the notebook and device separately.

•

Turn off the device using return to the home position at the left side of the device and lock in place.

(See Replace the ink service module.)

Store printing

(Power button). This ensures that the print cartridges

WARNING! To help prevent damaging the device, wait until all lights have turned off completely before removing the battery or power cord. This process might take approximately 16 seconds.

• Disconnect the device cable and power adapter from the device. Slide down the input tray extension and close the input tray.

• If you are traveling to another country/region, bring the necessary plug adapter with you.

• If you need to buy print cartridges while traveling to another country/region, see the online help called “Traveling with your HP Mobile Printer” for regional cartridge compatibility information. This help is available through the Toolbox (Windows), HP Printer Utility (Mac OS), or Toolbox software for PDAs (Pocket PC and Palm OS).

Travel tips

Chapter 1

• Use only the power adapter that is supplied with the device. Do not use any other voltage transformer or converter. The power adapter can be used with AC power sources of 100 to 240 volts, 50 or 60 Hz.

• Remove the battery if you will not be using the device for more than a month.

• When traveling with photo paper, pack it flat so it doesn't warp or curl. Photo paper should be flat before printing. If the corners of the photo paper curl more than 10 mm (3/8 inch), flatten the paper by putting it in the resealable storage bag, then rolling the bag on a table edge until the paper is flat.

12 Get started

Install the accessories

This chapter provides information on optional accessories such as the battery and wireless printer accessories that are included with certain device models. To order accessories, see

This section contains the following topics:

•

Install and use the battery Install and use 802.11 and Bluetooth accessories

•

Order printing supplies online.

Install and use the battery

The lithium-ion rechargeable battery comes with HP Officejet H470b and HP Officejet H470wbt printers. It is also available for purchase as an optional accessory. For more information, see

This section contains the following topics:

•

Battery safety

• Use only the battery designed specifically for the device. For more information, see

• When discarding a battery, contact your local waste disposal provider regarding

• Battery might explode if incorrectly replaced or disposed of in fire. Do not short-

• To purchase a replacement battery, contact your local dealer or HP sales office.

• To avoid risk of fire, burns, or damage to your battery, do not allow a metal object

• Do not disassemble the battery. There are no serviceable parts inside.

• Handle a damaged or leaking battery with extreme care. If you come in contact

• Do not expose the battery to storage temperatures above 50°C (122°F) or below

Battery safety Understand the battery Charge and use the battery

HP supplies and accessories and Device specifications.

local restrictions on the disposal or recycling of batteries. Though the lithium-ion rechargeable battery is mercury-free, it might require recycling or proper disposal at end-of-life. For more information, see

circuit.

For more information, see

to touch the battery contacts.

with the electrolyte, wash the exposed area with soap and water. If it contacts the eye, flush the eye with water for 15 minutes and seek medical attention.

-20°C (4°F).

HP supplies and accessories.

Recycling.

Install the accessories

Chapter 2

Important notes

Take note of the following when charging or using the battery:

• Charge the battery for 4 hours before using the battery for the first time. For subsequent charges, it takes approximately 2 hours to fully charge the battery.

• The battery charge light is green when the battery is charging. If it is red, the battery might be faulty and need to be replaced.

• The Power light is green when the battery is 41-100% charged, amber when 10-40% charged, and red when less than 10% charged. Charge the battery when the Power light turns amber. If it turns red, charge the battery as soon as possible. The battery status is also displayed on the Printer Status tab in the Toolbox (Windows) and the Power Management panel in the HP Printer Utility (Mac OS). If you are using a Pocket PC or Palm OS device, you can use the Toolbox software for PDAs. For more information, see

Toolbox software for PDAs (Pocket PC and

Palm OS).

• If your battery is running low, either plug in the AC adapter to charge it or replace the battery with one that is charged.

• A fully charged battery can print up to approximately 450 pages, depending on the complexity of print jobs.

• By default, if the device is using battery power and left idle for 15 minutes, it will turn off to conserve the battery power. You can configure this feature in the Toolbox (Windows), the HP Printer Utility (Mac OS), or the Toolbox software for PDAs (Pocket PC and Palm OS). For more information, see

Toolbox software for

PDAs (Pocket PC and Palm OS).

• Prior to long-term storage, fully charge the battery. Do not leave the battery in a discharged (empty) state for more than 6 months.

• To maximize battery life and capacity, observe the following temperature guidelines:

ƕ Charging: 0° to 40°C (32° to 104°F) ƕ Using and storing: -20° to 50°C (-4° to 122°F)

Understand the battery

1 Battery – Supplies power to the device. 2 Battery release slider – Slides to release the battery.

Install the accessories

Charge and use the battery

WARNING! Charge the battery for 4 hours before using the battery for the first

time. Because the battery is normally warm while it is charging, do not charge it in a briefcase or other confined space as this might cause the battery to overheat.

NOTE: The AC adapter is normally warm to the touch when plugged into an AC outlet.

NOTE: Wireless printing uses more battery power than wired printing. For information on checking the battery charge level, see

To install the battery

NOTE: You can install the battery with the device turned on or off.

1. Slide the battery into the battery slot at an angle, until the contacts on the battery

are flush with the contacts in the battery slot. The battery contact cover slides open.

Install and use the battery.

2. Push the battery into the battery slot until the battery clicks into place.

3. Plug in the AC adapter and turn on the device. Allow the battery to charge for four

hours before using the battery for the first time. Subsequently, the battery charge light is green when the battery is charging, and turns off when the battery is fully charged.

4. After the battery is fully charged, you can use the device without connecting to the AC power supply.

Install and use the battery

Chapter 2

To remove the battery

1. Slide the battery release slider in the direction of the arrow.

2. Remove the battery.

Install and use 802.11 and Bluetooth accessories

Some models of the device include an 802.11 wireless or Bluetooth wireless USB accessory.

See

www.hp.com/support to learn more about supported wireless accessories.

This section contains the following topics:

•

Install the 802.11 or Bluetooth wireless USB accessory

802.11 and Bluetooth wireless printing

•

Install the 802.11 or Bluetooth wireless USB accessory

Insert the HP 802.11 or Bluetooth wireless USB accessory into the slot. The 802.11 accessory has one blue light. When the dongle is plugged in, the blue light

will be on, and when there is 802.11 data communication, the light will blink.

Install the accessories

The LED on the Bluetooth accessory provides information about its current state.

• On steady - This is the default state and means the accessory is installed and has power.

• Rapid blinking - A sending device is discovering the Bluetooth accessory.

• Blinking - The Bluetooth accessory is receiving data. NOTE: Make sure that your Bluetooth host device and operating system are

supported by the device. For more information, visit

802.11 and Bluetooth wireless printing

The 802.11 and Bluetooth features in this device allow you to print wirelessly. 802.11 printing allows wireless printing up to 100 meters (300 feet). Bluetooth printing allows wireless printing up to 10 meters (30 feet).

For instructions on wireless printing from mobile devices, see

NOTE: Wireless communication is available through wireless printer accessories that are included with certain device models. Also, the sending device must have built-in wireless capability or a wireless card installed.

NOTE: Wireless printing uses more battery power than wired printing. For information on checking the battery charge level,

This section contains the following topics:

•

About 802.11 About Bluetooth

•

www.hp.com/support.

Print from mobile devices.

Install and use the battery.

About 802.11

802.11 wireless technology allows you to wirelessly connect to your device by setting

up “ad hoc” communication between your computer and the device. 802.11 does not require a direct line of sight between the sending device and the receiving device.

When you set up ad hoc communication between your computer and the device, you are creating a network of two devices. This is the recommended setup for 802.11 printing to this mobile printer.

802.11 also lets you set up the device on an existing “infrastructure” network. Setting it

up on an infrastructure network puts the device directly onto a local area network (LAN) using a wireless connection to an 802.11 wireless access point (WAP). Once the device is successfully connected to the network wirelessly, then all the computers on the same subnet can use the device.

Before setting up the device, it is recommended that you temporarily connect the device to the computer with a USB cable to set up the wireless connection. Once the wireless connection is established, you will remove the cable and print wirelessly. You can also set up the device without using a USB cable.

To set up and configure the device for 802.11 wireless printing, see

802.11 wireless

connection.

Install and use 802.11 and Bluetooth accessories

Chapter 2

About Bluetooth

Bluetooth wireless technology allows you to wirelessly connect to your device using radio waves in the 2.4 GHz spectrum. Bluetooth is typically used for short distances (up to 10 meters or 30 feet) and does not require a direct line of sight between the sending device and the receiving device.

Different Bluetooth profiles emulate different types of standard cable connections and have different capabilities. For more information about Bluetooth profiles, see

Configure Bluetooth wireless settings.

When your device is directly connected to your computer (either by cable or Bluetooth), it is possible to share it on a network using “printer sharing”. However, your computer has to be connected to the network for others to use the device.

To set up and configure the device for Bluetooth wireless printing, see

Bluetooth

wireless connection.

NOTE: To configure Bluetooth settings or monitor device status (such as ink levels) using the Toolbox, you must connect the device to your computer with a USB cable.

Install the accessories

3 Use the device

This section contains the following topics:

•

Select print media Load media

• Change print settings

• Use the HP Solution Center (Windows)

• Print on both sides (duplexing)

• Print on special and custom-sized media

• Print borderless

• Print from mobile devices

• Use memory devices

• Cancel a print job

•

Select print media

The device is designed to work well with most types of office media. It is best to test a variety of print media types before buying large quantities. Use HP media for optimum print quality. Visit the HP Web site at media.

This section contains the following topics:

•

Tips for selecting and using print media Understand specifications for supported media

• Set minimum margins

•

www.hp.com for more information about HP

Tips for selecting and using print media

For the best results, observe the following guidelines.

• Always use media that conforms to the device specifications. For more information, see

• Load only one type of media at a time.

• On models that have an input tray extension, make sure the input tray extension is fully extended.

• Load media print-side up and aligned squarely against the alignment guides. For more information on loading media, see

• Do not overload the trays. For more information, see

supported media.

• To prevent jams, poor print quality, and other printing problems, avoid the following media:

ƕ Multipart forms ƕ Media that is damaged, curled, or wrinkled ƕ Media with cutouts or perforations

Understand specifications for supported media.

Load media.

Understand specifications for

Use the device 19

Chapter 3

ƕ Media that is heavily textured, embossed, or does not accept ink well ƕ Media that is too lightweight or stretches easily

• Do not leave media in the input tray overnight. This might cause it to bend.

• Remove each sheet of media as it prints and set aside to dry. Allowing wet media to stack up might cause smearing.

• For instructions on calibrating color, see

Calibrate color.

Cards and envelopes

• Avoid envelopes that have a very slick finish, self-stick adhesives, clasps, or windows. Also avoid cards and envelopes with thick, irregular, or curled edges, or areas that are wrinkled, torn, or otherwise damaged.

• Use tightly constructed envelopes, and make sure the folds are sharply creased.

• Always load envelopes into the printer with the flap facing the back of the printer and the stamp position oriented according to the envelope icon.

Photo media

•Use the Best mode to print photographs. Note that in this mode, printing takes longer and more memory is required from your computer.

• Remove each sheet as it prints and set it aside to dry. Allowing wet media to stack up may cause smearing.

• Photo paper should be flat before printing. If the corners of the photo paper curl more than 10 mm (3/8 inch), flatten the paper by putting it in a resealable plastic bag, and roll them into a tube. Roll the sheets so the curve of the tube is in the opposite direction of the original curl of the paper. Roll the tube no smaller than a

1.5 inch (4 cm) in diameter.

20 Use the device

Transparencies

• Insert transparencies with the rough side up and the adhesive strip pointing down.

•Use the Normal mode to print transparencies. This mode provides longer drying time and ensures that the ink dries completely before the next page is delivered to the output tray.

• Remove each sheet as it prints and set it aside to dry. Allowing wet media to stack up may cause smearing.

Custom-sized media

• Use only custom-sized media that is supported by the device.

• If your application supports custom-sized media, set the media size in the application before printing the document. If not, set the size in the print driver. You might need to reformat existing documents to print them correctly on custom-sized media.

Understand specifications for supported media

Use the Understand supported sizes and Understand supported media types and

weights tables to determine the correct media to use with your device, and determine

what features will work with your media. This section contains the following topics:

•

Understand supported sizes Understand supported media types and weights

•

Understand supported sizes

Media size Standard media sizes

U.S. Letter (216 x 279 mm; 8.5 x 11 inches)* U.S. Legal (216 x 356 mm; 8.5 x 14 inches)* A4 (210 x 297 mm; 8.3 x 11.7 inches)* U.S. Executive (184 x 267 mm; 7.25 x 10.5 inches)* U.S. Statement (140 x 216 mm; 5.5 x 8.5 inches)* JIS B5 (182 by 257 mm; 7.2 by 10.1 inches)* A5 (148 x 210 mm; 5.8 x 8.3 inches)*

8.5 x 13 inches (216 x 330 mm)

Envelopes

U.S. #10 Envelope (105 x 241 mm; 4.12 x 9.5 inches) Monarch Envelope (98 x 191 mm; 3.88 x 7.5 inches) A2 Envelope (111 x 146 mm; 4.37 x 5.75 inches) DL Envelope (110 x 220 mm; 4.3 x 8.7 inches)

Select print media

Chapter 3

(continued)

Media size

C5 Envelope (162 x 229 mm; 6.4 x 9 inches) C6 Envelope (114 x 162 mm; 4.5 x 6.4 inches)

Cards

Index card (76.2 x 127 mm; 3 x 5 inches)* Index card (102 x 152 mm; 4 x 6 inches)* Index card (127 x 203 mm; 5 x 8 inches)* A6 card (105 x 148.5 mm; 4.13 x 5.83 inches)*

Photo media

Photo (76 x 127 mm; 3 x 5 inches) Photo (88.9 x 127 mm; 3.5 x 5 inches) Photo (101.6 by 152.4 mm; 4 by 6 inches) Photo with tab (101.6 by 152.4 mm; 4 by 6 inches) Photo (127 by 177.8 mm; 5 by 7 inches) Photo (203.2 by 254 mm; 8 by 10 inches) Photo 10 by 15 cm (100 by 150 mm; 4 by 6 inches) Photo 10 by 15 cm with tab (100 by 150 mm; 4 by 6 inches) Borderless Photo (101.6 by 152.4 mm; 4 by 6 inches) Borderless Photo with tab (101.6 by 152.4 mm; 4 by 6 inches) Borderless Photo 10 by 15 cm (100 by 150 mm; 3.93 x 5.9 inches) Borderless Photo 10 by 15 cm with tab (100 by 150 mm; 3.93 x 5.9 inches) Photo L (89 by 127 mm; 3.5 by 5 inches) Photo 2L (178 by 127 mm; 7 by 5 inches) Borderless Photo L (89 by 127 mm; 3.5 by 5 inches) Borderless Photo L with tear-off tab (89 by 127 mm; 3.5 by 5 inches) Photo media sizes between 89 by 127 mm (3.5 by 5 inches) and 216 by 279 mm (8.5 by 11

inches)

Other media

L (89 by 127 mm; 3.5 by 5 inches) 2L with tab (178 by 127 mm; 5 by 7 inches) Custom-sized media between 76.2 to 216 mm wide and 102 to 356 mm long (3 to 8.5 inches

wide and 4 to 14 inches long)*

* These media sizes support manual duplex printing. For more information on duplex printing, see

22 Use the device

Print on both sides (duplexing).

Understand supported media types and weights

Type Weight Capacity

Paper

Photo paper 5 to 12 mils Up to 10 sheets Transparencies Up to 20 sheets Labels Up to 20 sheets Cards

Envelopes

Set minimum margins

The document margins must match (or exceed) these margin settings in portrait orientation.

64 to 90 g/m

(16 to 24 lb bond)

Up to 162 g/m

(90 lb index) 75 to 200 g/m

(20 to 53 lb bond)

Up to 50 sheets of plain paper

(5 mm or 0.2 inch stacked)

Up to 5 sheets

Up to 5 envelopes

Media (1) Left

margin

A4 U.S. Executive

3.3 mm (0.13 inch)

U.S. Statement B5 A5

U.S. Letter U.S. Legal

6.35 mm (0.25 inch)

Custom-sized media

8.5 x 13 inch Cards 2 mm (0.08

inch)

(2) Right margin

3.3 mm (0.13 inch)

6.35 mm (0.25 inch)

2 mm (0.08 inch)

(3) Top margin

3.3 mm (0.13 inch)

2 mm (0.08 inch)

Select print media

(4) Bottom margin*

3.3 mm (0.13 inch)

3 mm (0.12 inch)

0.5 mm (0.02 inch)

Chapter 3

(continued)

Media (1) Left

Photo media Envelopes 3.3 mm (0.13

* To achieve this margin setting on a computer running Windows, click the Advanced tab in the print driver, and select Minimize Margins.

Load media

This section provides instructions for loading media into the device.

To load media

1. Remove all media from the input tray.

2. Insert the media print-side up and align it squarely against the media paper guide.

Adjust the media width guide so it fits snugly against the sides of the media.

margin

inch)

(2) Right margin

3.3 mm (0.13 inch)

(3) Top margin

14.2 mm (0.56 inch)

(4) Bottom margin*

14.2 mm (0.56 inch)

3. If printing on legal media, extend the input tray extension, if available on your model.

4. Change any other print settings if necessary, then click OK to print.

Change print settings

You can change print settings (such as paper size or type) from an application or the printer driver. Changes made from an application take precedence over changes

24 Use the device

made from the printer driver. However, after the application is closed, the settings return to the defaults configured in the driver.

NOTE: To set print settings for all print jobs, make the changes in the printer driver.

For more information about the features of the Windows printer driver, see the online help for the driver. For more information about printing from a specific application, see the documentation that came with the application.

• To change settings from an application for current jobs (Windows) To change default settings for all future jobs (Windows)

• To change settings (Mac OS)

•

To change settings from an application for current jobs (Windows)

1. Open the document that you want to print.

2. On the File menu, click Print, and then click Setup, Properties, or Preferences.

(Specific options may vary depending on the application that you are using.)

3. Change the settings that you want, and then click OK, Print, or a similar command.

To change default settings for all future jobs (Windows)

1. Click Start, point to Settings, and then click Printers or Printers and Faxes.

- Or Click Start, click Control Panel, and then double-click Printers.

2. Right-click the printer icon, and then click Properties, Document Defaults , or Printing Preferences.

3. Change the settings that you want, and then click OK.

To change settings (Mac OS)

1. On the File menu, click Page Setup.

2. Change the settings that you want (such as paper size), and then click OK.

3. On the File menu, click Print to open the print driver.

4. Change the settings that you want (such as media type), and then click OK or Print.

Use the HP Solution Center (Windows)

Use the HP Solution Center to change print settings, order supplies, and access the onscreen Help.

The features available in the HP Solution Center vary depending on the devices you have installed. The HP Solution Center is customized to show icons that are associated with the selected device. If the selected device is not equipped with a particular feature, then the icon for that feature does not appear in the HP Solution Center.

If the HP Solution Center on your computer does not contain any icons, an error might have occurred during the software installation. To correct this, use the Control Panel in Windows to completely uninstall and reinstall the software.

Use the HP Solution Center (Windows)

Chapter 3

Print on both sides (duplexing)

You can print on both sides manually using the Windows printer software. You can print on both sides of a sheet using a Mac by first printing the odd-numbered

pages, turning the pages over, and then printing the even-numbered pages.

•

Guidelines for printing on both sides of a page To perform duplexing (Windows)

• To perform duplexing (Mac OS)

•

Guidelines for printing on both sides of a page

• Always use media that conforms to the device specifications. For more information, see

• Specify duplex options in your application or in the printer driver.

• Do not print on both sides of transparencies, envelopes, photo paper, glossy media, or paper lighter than 18 lb bond (75 g/m media types.

• Several kinds of media require a specific orientation when you print on both sides of a page, such as letterhead, preprinted paper, and paper with watermarks and prepunched holes. When you print from a computer running Windows, the device prints the first side of the media first. When you print from a computer using the Mac OS, the device prints the second side first. Load the media with the front side facing down.

Understand specifications for supported media.

). Jams might occur with these

To perform duplexing (Windows)

1. Load the appropriate media. See Guidelines for printing on both sides of a page

and

Load media.

2. With a document open, on the File menu, click Print, and then click Properties.

3. Click the Features tab.

4. Choose Manual from the two-sided printing drop-down list.

5. To automatically resize each page to match the document's onscreen layout,

ensure Preserve Layout is selected. Clearing this option might result in unwanted page breaks.

6. Select or clear the Flip Pages Up check box to match the way you want the binding. See the graphics in the printer driver for examples.

7. Change any other desired settings and click OK.

8. Print your document.

9. After the first side of the document is printed, follow the onscreen instructions and

reload the paper into the tray to complete printing.

10. After reloading the paper, click Continue in the onscreen instructions to continue the print job.

26 Use the device

+ 102 hidden pages
