QuickSpecs

Overview

hp StorageWorks ESL9322S2 tap e library

At A Glance

• The Ultimate in High-Capacity Unattended Back u p and Res tore:

• The HP Storag eWorks ESL9322S2 provides the ult imate in high-capacity unattended backup and restore for customers with large server pools an d centralize d backup and restore requirements, serviced by network attached storage devices or storage area networks. The consolidati on of tape backup into a single shared storage device requires these devices to provide both high capacity and high performance, and the need for redundancy and high availability. With High availability features, component level redundancy and high capacity, the ESL9322S2 can provide years of fully aut omated operation for backup, save and restore, and hierarchical storage management of critical data, it is qualified with a variety of industrystandard backu p appl ic at io n solutions and operating systems. With 222 or 322 slots and up to eight hot plug SDLT drives, the ESL9322S2 offer s up to 51.52 TB of native data storage and native transfer rates up to 460.8 GB/hr.

DA-11437 Canada — Versi on 5 — March 18, 20 03 1

QuickSpecs

Standard Features

hp StorageWorks ESL9322S2 tap e library

HP StorageWorks ESL9322S2 Tape Library Model

The ESL9000 Series Library Family

High Availability

Hot Pluggable Drives

Proven Reliability

The HP StorageWorks ESL9322S2 Tape Library comes with up to 8 HP SDLT 160/320 GB tape drives (number of drives determined by SKU chosen) and has two models with 222 and 322 slots respectively.

ESL9322S2, 222 slot, 2 SDLT 160/320 drive, enterprise library 293409-B22 ESL9322S2, 222 slot, 8 SDLT 160/320 drive, enterprise library 293409-B28 ESL9322S2, 322 slot, 2 SDLT 160/320 drive, enterprise library 293410-B22 ESL9322S2, 322 slot, 8 SDLT 160/320 drive, enterprise library 293410-B28 The ESL9322S2 comes with a complete 222 or 322 slot library system configured with the associated number of

drives, installation and user’s manual, one-piece SDLT media, a copy of the Hewlett-Packard Storage Management Solutions CD. Customers are required to also purchase the necessary number of add-on drives, host bus adapters, SCSI cables, SDLT media, country specific power cords (pair) and applications software licenses in order to complete the library solution.

Due to the size and weight of the unit, a pre- sales site survey is required. The pre-sales site survey document is on http://www.compaq.com/support/techpubs/installation_guides/146587-001.html

NOTE: This Web site is available in English only.

Installation services can be ordered separately on Hewlett-Packard Services as part of each library order (requires scheduling with local Hewlett-Packard Services provider). NOTE: Does not include special site work, which may

be required as a result of not meeting minimum site survey requirements.

HP StorageWorks ESL9000 series of DLT libraries offer customers both high performance and high reliability. With its high availability feature set, the ESL9000 series provides for maximum uptime. Based on PCI backplane architecture, the ESL9000 series also provides a simple upgrade path for future “plug-in” features. The ESL9322S2 library is part of the ESL9000 series libraries.

As data becomes more and more mission critical, and downtime becomes more costly to the enterprise, customers are requiring high availability consolidated storage solutions which offer hot swappable components and redundancies of key operating sub-systems (tape drives, controllers, power supplies). With redundant power distribution, power supplies, and cooling fans, coupled with “hot pluggable” drive carriers, hot swap power supplies and cooling fan modules, the ESL9322S2 offers the best in high availability for continuous operation.

The ESL9322S2 uses hot pluggable drive carriers, allowing drive replacement and additional drives to be added for capacity expansion without interrupting backup and restore functions. These hot pluggable drive trays allow for easy scalability of per formance, as well as provide an easy upgrade p ath towards future drive technologies.

NOTE: The ESL9322S2 accepts only library ready drives specifically modified for use in the ESL9322S2 library.

Using SDLT 160/320 tape drives, and proven library robotics with a rating of 2,000,000 load/unload cycles, the ESL9322S2 provides the necessary high reliability.

DA-11437 Canada — Versi on 5 — March 18, 20 03 2

QuickSpecs

Standard Features

hp StorageWorks ESL9322S2 tap e library

SDLT Technology

Manageability

Warranty

Server Support

Digital Linear Tape uses a proven linear recording technology, a highly accurate tape guide system, and a read after write correction system to provide high-capacity, high reliability data backup and restoration. DLT has fast become the industry-standard secondary storage tape format for departmental and enterprise backup. The new generation SDLT tape drive, in addition to enhanced capacity and backup performance provides advantages several new features such as Laser Guided Magnetic Recording (LGMR™) technology, Pivoting Optical Servo (POS), Magneto-Resistive Cluster Heads (MRC) , Partial Response Maximum Likelihood (PRML) channel technology and Backward Read Compatible with earlier generation of DLT drives, to be able to read media written in DLT IV format.

The ESL9322S2 configurations are fully supported through Insight Manager, providing information to administrators for both robotic and tape status changes, and fault status of redundant components. HP TSMC (Tape Storage Management Console) software provides diagnostics and easy firmware upgrade capabilities. Other data and automation manageability features, including multi-host direct connectivity, are provided via specific, third party applications software packages.

One year parts exchange, one year on-site next day service Additional Warranty protection can be purchased for all ESL9322S2 DLT library products at the following URL:

http://h18006.www1.hp.com/products/storageworks/warranty.html

NOTE: This Web site is available in English only.

High-End ProLiant Servers ProLiant DL760

ProLiant ML750

Departmental ProLiant Servers

Workgroup ProLiant Servers ProLiant DL380G2

AlphaServer Systems AlphaServer GS320, GS160, GS 80

SCSI controller supported Hewlett-Packard ProLiant servers

Hewlett-Packard AlphaServer systems

HP-UX servers Superdome

ProLiant DL580G2 ProLiant ML570G2 ProLiant ML530G2

ProLiant ML370 ProLiant ML350

AlphaServer ES45 AlphaServer ES40 AlphaServer DS20E 64-bit/66 MHz dual channel dual channel Wide Ultra3

SCSI Adapter 64-bit/66 MHz Single Channel Wide Ultra3 SCSI

Adapter StorageWorks Ultra LVD single channel 3X-KZPCA-AA

rp8400 rp7400 (N class) rp5400 series (L Class) rp2450/2470 (A class) K class D Class

129803-B21

154457-B21

DA-11437 Canada — Versi on 5 — March 18, 20 03 3

QuickSpecs

Standard Features

Fibre Channel Controllers

Application Support

Device/ISV/OS ESL

SDLT160/320 Models

Direct Attach

VERITAS NetBackup 4.5 9 9 VERITAS NetBackup 3.4.3 9 9 Legato NetWorker 6.1.2 9 9 VERITAS Backup Exec 8.6 9 9

CA BrightStor ARCServe 2000

CA BrightStor ARCServe 7

HP/EBS SAN

HP Omniback 4.x 9 9 HP Data Protector 9 9 VERITAS NetBackup 4.5 9 9 9 9 VERITAS NetBackup 3.4.3 9 9 9 9 Legato NetWorker 6.1.2 9 9 9 9 VERITAS Backup Exec 8.6 9 9 VERITAS Backup Exec 9.0

CA BrightStor ARCServe 2000

* HP-UX commands fbackup\frecover and backups launched using HP-UX Site Area Manager are not supported

ProLiant Servers 64-bit/66 MHZ PCI to FC HBA (Persian/NetWare

AlphaServer systems KGPSA-CA HBA (Alpha lp8000)

HP-UX Servers A6684A FC

Fibre Channel Routers NSR m2402

For the latest updated compatibility matrix for ISV backup software supported go to:

http://www.compaq.com/products/storageworks/ebs/EBScompatmatrix.html

NOTE: This Web site is available in English only.

Automation and Network Utilities

Windows



SP6a

9 9

Windows

2000 SP2

4.0

Tru64

UNIX 4.0g

5.1a

hp StorageWorks ESL9322S2 tap e library

fca2101 HBA (lp952) QLA2200 (Linux) QLA2340 (Linux and NetWare 6.0) FCA-2101 HBA (lp952) KGPSA-CB HBA (NT lp8000)

FCA-2354 HBA (lp9002)

A6685A FC A5158A 1G FC A6795A 2G FC

FC router e2400

Insight Manager v7.0 HP Tape Storage Management Console v2.3 (NT/2000), 2.0 (NetWare) MRU (Media Robot Utility) v1.4 HP Library and Tape Tools V 2.9

HP-UX* 11i,

11.0, 10.2,

NetWare 5.1

SP3

9 9

NetWare 6.0 Linux RH 7.1,



)

7.2

Linux SuSe

7.0

9 9

Sun

Solaris 2.6,



2.7, 2.8

9 9

AIX 4.3.3

DA-11437 Canada — Versi on 5 — March 18, 20 03 4

QuickSpecs

hp StorageWorks ESL9322S2 tap e library

HP Service & Support, CarePaq and Warranty Information

Hewlett-Packard Installation and CarePaq Information

Software Product Services

Hardware Product Services

Warranty Upgrade Options

Installation Services

Sample part numbers:

Compaq Services provides a three-year, limited warranty, fully supported by a worldwide network of resellers and service providers, and also provides hardware technical phone support. In addition, available service offerings include a full range of hardware and software services:

• Installation and start up

• Extended coverage hours and enhanced response times

• System management and performance services

Additional Warranty protection and/or HP Installation packages can be purchased for the ESL9322S2 library products:

• Stand-alone telephone support

• Rights to a new license

• Media and documentation updates

• Installation services

• On-site Maintenance (includes warranty support)

• Response time upgrades during the warranty period

• Post-warranty coverage

For additional hardware installation and maintenance information please refer to the URLs listed below:

English: http://www.compaq.ca/English/service/cusserv/carepaq/carepaq.htm French: http://www.compaq.ca/Francais/service/ccs/carepaqf/carepaqf.htm

• Response - Upgrade on-site response from next business day to same day 4-hours

• Coverage - Extend hours of coverage from 5 days x 9 hours to 7 days x 24 hours

• Duration - Select duration of coverage for a minimum period of 1year or multiple years

For library SKUs (0 to 8 drive units) 163463-002

NOTE: Certain restrictions and exclusions apply. Consult the Hewlett-Packard

Customer Support Centre for details.

FM-T6INS-IN

DA-11437 Canada — Versi on 5 — March 18, 20 03 5

QuickSpecs

Related Options

hp StorageWorks ESL9322S2 tap e library

ESL9322S2 Library System

Supplied with each Library Unit

Supplied with each library 2 Line Cords (IEC 320 C19), US/Canada

Power Cord (Pair Required) NOTE: Shipped with all units.

Drive, capacity, and memory upgrade kits

ESL9322S2 222 slot 2 DRV SDLT 160/320 293409-B22 ESL9322S2 222 slot 8 DRV SDLT160/320 293409-B28 ESL9322S2 322 slot 2 DRV SDLT160/320 293410-B22 ESL9322S2 322 slot 8 DRV SDLT160/320 293410-B28

Library unit (pre-configured with drives) Documentation kit Documentation CD including translations Users Guide Unpacking and Installation Guide Pre-Installation Site Survey Diagnostic CD Diagnostic Software Guide Warranty Card Safety Card Driver CD (1) SDLT 160/320 Media Cartridge Bar code labels Cleaning Labels (2) Keys SCSI terminators (1 per drive, installed) Diagnostic cable (for PC attach)

ESL9000 POWER CORDS 2X* 146210-001

ESL9000 LVD SDLT 160/320 upgrade drive in hot plug canister 293414-B21 ESL9322S2, slot upgrade 222 TO 322 slots* 293588-B21 ESL9000 5 MB Memory Module for ESL9198 & ESL9326 libraries, (required to support

firmware versions 3.00 and later)

NOTE: *Serial number of your existing library is required when ordering these capacity upgrade SKUs, please

enter the serial number in the comments section of the purchase order, and inform your Secondary Storage Product Manager.

Part Numbe

274673-B21

DA-11437 Canada — Versi on 5 — March 18, 20 03 6

QuickSpecs

Related Options

hp StorageWorks ESL9322S2 tap e library

Media and Bar Code Labels

Supplied with each Power Cord

SCSI Cables

* Requires 221249-B21 LVD extender kit

SCSI Host Bus Adapter/HewlettPackard Fibre Channel to SCSI Router (optional)

NOTE: Host Bus adapter for SCSI connectivity from server to tape library in direct SCSI environment

LVD Extender Kit

ESL9000 magazine

MSL5000 dual magazine DLT/SDLT pack (2 x 13 slot magazines, left and right) 188527-B21 SDLT media 5-pack 188527-B22 SDLT media 10-pack 188527-B26

Additional media Additional magazines Bar code labels

Wide/Wide SCSI cable, 5 m 328215-001 Wide/Wide SCSI cable, 10 m 328215-002 Wide/Wide SCSI cable, 15 m 328215-003 Wide/Wide SCSI cable, 20 m* 328215-004 SCSI Cable, VHDCI/Wide, 6 ft 341176-B21 SCSI Cable, VHDCI/Wide, 12 ft 341177-B21 SCSI Cable, VHDCI/Wide, 10 m 201160-B21 SCSI Cable, VHDCI/Wide, 20 m* 201160-B23

NOTE: Check the cable-adapter matrix for tape libraries on:

ftp://ftp.compaq.com/pub/products/storageworks/tape-and-optical-storage/adapter-cable-matrix.pdf

NOTE: This Web site is available in English only.

ProLiant Controllers

64-bit/66 MHz PCI dual channel Wide Ultra3 SCSI adapter

Alpha Controllers

Single Channel Ultra LVD Controller

Network Storage Router (required for SAN configuration)

Network Storage Router m2402 (2FC X 4 LVD SCSI) Embedded Data Router, ESL9000embedded fibre option e2400 – Base 2 FC X 4 LVD

SCSI ports (Includes card cage for installation of embedded router which is required for configuration) (Includes two router cards each with 1 FC X 2 LVD SCSI ports, 4 VHDCIWIDE SCSI cable, user guide CD, and the ESL9000 cPCI card cage)

It is recommended that the installation CarePaq be ordered with this SKU. Embedded Data Router, ESL9000embedded fibre option e2400 – Upgrade 2 FC X 4

LVD SCSI ports (Includes: two 1FC x 2LVD SCSI router cards, four

Network Storage Router, Embedded FC Router to connect SCSI Library to Fibre Channel Hub/Switch.

LVD Extender kit (Required for HBA to Library SCSI cable lengths exceeding 10 m)

ESL9000 UNIVERSAL LOAD PORT magazine (2x4 slot)(fixed)

Part Numbe

129803-B21

3X-KZPCA-

262653-B21 262665-B21

262664-B21

221249-B21

302254-B21

DA-11437 Canada — Versi on 5 — March 18, 20 03 7

QuickSpecs

Related Options

hp StorageWorks ESL9322S2 tap e library

Data Protection Suites for Backup and Restores

DP Suite, SAN standard − Entry level SAN kit that contains:

DP Suite, SAN advanced − Data centre SAN kit that contains:

DP Suite, SAN standard − Entry level SAN kit that contains:

DP Suite, SAN advanced − Data centre SAN kit that contains:

Part Numbe

CommVault Galaxy Phan Kit, CommVault Galaxy 281593-B21 DP Suite, SAN standard 281585-B21 DP Suite, SAN advanced 281588-B21 DP Suite, Network 281582-B21 Additional CommVault Galaxy Suite Descripitions Phan Kit, CommVault Galaxy − Media Kit that contains live trial software

ISV application software for six servers on the SAN Two server clients for backing up over the LAN Each SAN server has a choice of a database agent or open file systems option Support for up to eight shared automated, tape drives

ISV application software for fourteen servers on the SAN Two server clients for backing up over the LAN Each SAN server has a choice of a database agent or open file systems option Support of up to sixteen shared, automated tape drives DP Suite, Network − Designed for backing up a single server and server clients over the

network using a tape drive, an autoloader or business class automation. Includes choice of one database agent or open file systems option.

CA BrightStor ARCserve Phan Kit, CA ARCserve 283915-B21 DP Suite, single server 281576-B21 DP Suite, SAN standard 281583-B21 DP Suite, SAN advanced 281586-B21 DP Suite, Network 281581-B21 Additional CA BrightStor ARCserve Suite Descripitions Phan Kit, CA ARCserve − Media Kit that contains live trial software DP Suite, single server − Designed for backing up a single server, with no server

clients, using a single internal or external tape drive.

network using a tape drive, an autoloader or business class automation. Includes choice of one database agent or open file systems option.

DA-11437 Canada — Versi on 5 — March 18, 20 03 8

QuickSpecs

Related Options

hp StorageWorks ESL9322S2 tap e library

Data Protection Suites for Backup and Restores (continued)

DP Suite, SAN standard − Entry level SAN kit that contains:

DP Suite, SAN advanced − Data centre SAN kit that contains:

Part Numbe

VERITAS Backup Exec Phan Kit, VERITAS Backup Exec 283914-B21 DP Suite, SAN standard 281584-B21 DP Suite, SAN advanced 281587-B21 Additional VERITAS Backup Exec Suite Descripitions Phan Kit, VERITAS Backup Exec − Media Kit that contains live trial software

ISV application software for fourteen servers on the SAN

DA-11437 Canada — Versi on 5 — March 18, 20 03 9

QuickSpecs

Technical Specifications

hp StorageWorks ESL9322S2 tap e library

SCSI Identification

Control Panel

SCSI Interface

Form Factor Dimensions (H x W x D)

Unit Weight

Performance (native) (16 MB/s per drive)

Storage Capacity

Input/Output Port Initialization Time Cartridge Swap time Cartridge Passthrough time - end

to end Swaps Electrical Specifications

Acoustic Noise

Product ID ESL9000 Series Vendor ID HP Library and Drive Status Move tape cartridges

Load/Unload tape drives Maintenance (drive cleaning,

diagnostics) Library Configuration Statistics Ultra2 SCSI LVD, 68HD Interconnect

(External cable length between library and HBA, limited to 10 m without LVD extender, extends up to 25 m when using the LVD extender)

Free Standing Unit Packaged Height

idth 40 in/101.6 cm 52 in/132.1 cm

Depth 29 in/73.7 cm 48 in/121.9 cm

Without data cartridges, 0 drives 1072 lb/487 kg Without data cartridges, 8 drives 1180 lb/536 kg 1362 lb/617.8 kg 322 data cartridges, 8 drives 1335 lb/606.6 kg Minimum configuration 2 Hewlett-Packard SDLT 160/320 drives, native transfer rates up to 115.2 GB/hr

Maximum configuration 8 Hewlett-Packard SDLT 160/320 drives, native transfer rates up to 460.8 GB/hr ESL9322S2 (222 slots) - Supports 222 SDLT cartridges for native capacity up to 35.52 TB native, 71.04 TB

compressed (2:1) ESL9322S2 (322 slots) - Supports 322 SDLT cartridges for native capacity up to 51.52 TB native, 103.04 TB

compressed (2:1) 2 x 4-slot fixed < 7 minutes 33 seconds average

78 seconds average

135 swap/hour AC Voltage Auto-range to domestic and international AC voltages AC Voltage Range: 90 to 132 VAC or 180 to 264 VAC, single phase

Nominal: 100 to 120 VAC or 220 to 240 VAC Line Frequency Range: 47 to 63Hz

Power Consumption 1200 VA Maximum Noise Power Emission Level Idle 7.8 bels Operating 8.1 bels

75 in/190.5 cm 80 in/203.2 cm

AC Receptacle: IEC-320 C19 Type 100-120V/200-240V, 50/60 Hz, 20A/16A (520P plug for U.S. and Canada)

DA-11437 Canada — Versi on 5 — March 18, 20 03 10

QuickSpecs

Technical Specifications

hp StorageWorks ESL9322S2 tap e library

Reliability (Library Only)

Regulatory Compliance

© 2003 Compaq Canada Corp. (an HP Company) All rights reserved. Printed in Canada. Hewlett-Packard, the Hewlett-Packard logo, AlphaServer, CarePaq, Insight Manager, ProLiant, StorageWorks and Tru64 are trademarks of Hewlett-Packard Company in the U.S. and/or other countries. Windows NT is a registered trademark or trademark of Microsoft Corporation in the U.S. and/or other countries. NetWare is a registered trademark or trademark of Novell, Inc. Sun and Solaris are registered trademarks or trademarks of Sun Microsystems, Inc., in the U.S. and/or other countries. Linux is a registered trademark or trademark of Linus Torvalds in the U.S. and/or other countries. SuSE and its logo are registered trademarks or trademarks of SuSE AG in the U.S. and/or other countries. UNIX is a registered trademark of The Open Group in the U.S. and other countries. All other product names mentioned herein may be trademarks of their respective companies.

Hewlett-Packard shall not be liable for technical or editorial errors or omissions contained herein. The information is provided “as is” without warranty of any kind and is subject to change without notice. The warranties for Hewlett-Packard products are set forth in the express limited warranty statements accompanying such products. Nothing herein should be construed as constituting an additional warranty.

MTBF 250,000 hours MSBF 2,000,000 load/unload cycles Safety

EMI

EMC EN6100-3-2, EN50082-1: 1992, EN50022: 1994

UL1950, CSA C22.2 950, EN 60950:1992/A11, IEC 60950:1992/A11, DHHS/FDA (US CFR21 part 1040, Class 1 laser) EN 60825:1994/A11, FCC Part 15 Class A, CISPR Publication 22 Class A, ICES-

003 Class A, VCCI Class 1, SMA AZ/NZS 3548 Class A

DA-11437 Canada — Versi on 5 — March 18, 20 03 11
