HP ENVY 17-2100, ENVY 17 3D Getting Started Manual

17

GETTING STARTED

HP ENVY17 3D Getting Started

© Copyright 2011 Hewlett-Packard
Development Company, L.P.

AMD is a trademark of Advanced Micro
Devices, Inc. Microsoft and Windows are U.S.
registered trademarks of Microsoft Corporation.
Bluetooth is a trademark owned by its proprietor
and used by Hewlett-Packard Company under
license. Intel is a trademark of Intel Corporation
in the U.S. and other countries. SD Logo is a
trademark of its proprietor.

The information contained herein is subject to
change without notice. The only warranties for
HP products and services are set forth in the
express warranty statements accompanying
such products and services. Nothing herein
should be construed as constituting an
additional warranty. HP shall not be liable for
technical or editorial errors or omissions
contained herein.

First Edition: May 2011

Document Part Number: 651676-001

Product notice

This guide describes features that are common
to most models. Some features may not be
available on your computer.

Software terms

By installing, copying, downloading, or
otherwise using any software product
preinstalled on this computer, you agree to be
bound by the terms of the HP End User License
Agreement (EULA). If you do not accept these
license terms, your sole remedy is to return the
entire unused product (hardware and software)
within 14 days for a refund subject to the refund
policy of your place of purchase.

For any further information or for requesting a
full refund of the computer, please contact your
local point of sale (the seller).

User Guides

HP is committed to reducing the environmental
impact of our products. As part of this effort, we
provide user guides and learning centers on
your computer hard drive in Help and Support.
Additional support and updates to the user
guides are available on the Web.

Safety warning notice

WARNING! To reduce the possibility of heat-related injuries or of overheating

the computer, do not place the computer directly on your lap or obstruct the
computer air vents. Use the computer only on a hard, flat surface. Do not allow
another hard surface, such as an adjoining optional printer, or a soft surface,
such as pillows or rugs or clothing, to block airflow. Also, do not allow the AC
adapter to contact the skin or a soft surface, such as pillows or rugs or clothing,
during operation. The computer and the AC adapter comply with the user­accessible surface temperature limits defined by the International Standard for
Safety of Information Technology Equipment (IEC 60950).

v

vi Safety warning notice

Table of contents

1 Welcome ...................................................................................................................... 1

What's new ..................................................................................................... 2

HP CoolSense .............................................................................. 2

HP 3D Cinema Technology .......................................................... 2

Intel Wireless Display ................................................................... 2

Beats Audio .................................................................................. 3

Switching between graphics modes ............................................. 4

AMD Eyefinity Multi-Display technology ....................................... 5

Example display configuration for single large

surface (SLS) ............................................................. 5

Switching the screen image ....................................... 6

Using the AMD Catalyst Control Center .................... 6

Finding information ......................................................................................... 7

2 Using HP 3D Cinema Technology ........................................................................... 10

3D safety information .................................................................................... 11

What are stereoscopic vision and 3D ........................................................... 13

What is HP 3D Cinema Technology ............................................................. 13

Using the HP 3D Active Shutter Glasses ...................................................... 14

Identifying the 3D glasses components ...................................... 14

Turning the 3D glasses on and off ............................................. 15

Using 3D Cinema Technology ...................................................................... 15

Understanding 3D formats ............................................................................ 17

Using CyberLink PowerDVD ......................................................................... 17

Playing 3D games ......................................................................................... 17

Viewing 3D content on a 3D TV .................................................................... 18

Caring for the 3D glasses ............................................................................. 19

Using the nose pieces ................................................................ 19

Replacing the battery ................................................................. 20

Cleaning the 3D glasses ............................................................ 21

Handling the glasses .................................................................. 22

vii

Troubleshooting and frequently asked questions ......................................... 22

I cannot see 3D content ............................................................. 22

What 3D formats are supported on my computer ...................... 22

Can I play stereoscopic 3D games on my computer .................. 23

Can I wear the 3D glasses to a 3D movie in a movie theater ... . 23

Can I wear my 3D glasses over my prescription glasses ........... 23

How do I clean my 3D glasses ................................................... 23

How close do I need to be to the computer to view 3D

content ........................................................................................ 23

I see flickering when watching 3D content ................................. 23

Can I use the 3D glasses in bright sunlight next to a window .... 23

What type of batteries do I need for the 3D glasses .................. 24

Can I use my computer to watch 3D content on my external

3D TV ......................................................................................... 24

3 Getting to know your computer ............................................................................... 25

Top ................................................................................................................ 25

TouchPad ................................................................................... 25

Lights .......................................................................................... 26

Button ......................................................................................... 28

Keys ........................................................................................... 29

Front ............................................................................................................. 30

Right-side ...................................................................................................... 31

Left-side ........................................................................................................ 32

Display .......................................................................................................... 34

Bottom .......................................................................................................... 35

4 Networking ................................................................................................................. 37

Using an Internet service provider (ISP) ....................................................... 37

Connecting to a wireless network ................................................................. 38

Connecting to an existing WLAN ................................................ 38

Setting up a new WLAN network ................................................ 39

Configuring a wireless router ................................... 39

Protecting your WLAN ............................................. 39

viii

5 Keyboard and pointing devices ............................................................................... 40

Using the keyboard ....................................................................................... 40

Using the action keys ................................................................. 40

Using the hotkeys ....................................................................... 42

Using the keypad ........................................................................ 43

Using the integrated numeric keypad ...................... 43

Using pointing devices .................................................................................. 43

Setting pointing device preferences ........................................... 43

Using the TouchPad ................................................................... 44

Turning the TouchPad off and on ............................ 44

Navigating ................................................................ 45

Selecting .................................................................. 45

Using TouchPad gestures ........................................ 46

Scrolling ................................................. 47

Pinching/Zooming .................................. 47

Rotating ................................................. 48

Flicking .................................................. 49

6 Maintenance .............................................................................................................. 50

Removing or inserting the battery ................................................................. 50

Removing the battery ................................................................. 50

Inserting the battery .................................................................... 51

Replacing or upgrading the hard drive .......................................................... 52

Removing the hard drive ............................................................ 52

Installing a hard drive ................................................................. 54

Adding or replacing memory modules .......................................................... 55

Cleaning your computer ................................................................................ 62

Cleaning the display ................................................................... 62

Cleaning the TouchPad and keyboard ....................................... 62

Updating programs and drivers .................................................................... 62

7 Backup and recovery ................................................................................................ 63

Restore ......................................................................................................... 63

Creating restore media ................................................................................. 63

ix

Performing a system restore ......................................................................... 64

Restoring using the dedicated recovery partition (select

models only) ............................................................................... 65

Restoring using the restore media ............................................. 66

Changing the computer boot order ............................................. 66

Backing up and recovering your information ................................................ 66

Using Windows Backup and Restore ......................................... 68

Using Windows system restore points ....................................... 68

When to create restore points .................................. 68

Create a system restore point .................................. 69

Restore to a previous date and time ........................ 69

8 Customer support ..................................................................................................... 70

Contacting customer support ........................................................................ 70

Labels ........................................................................................................... 71

9 Specifications ............................................................................................................ 72

Input power ................................................................................................... 72

DC plug of external HP power supply ........................................ 72

Operating environment ................................................................................. 72

Appendix A RAID 0 (select models only) ................................................................... 74

Disabling RAID 0 .......................................................................................... 74

Index ............................................................................................................................... 76

x

1Welcome

The following sections are included in this chapter:

●

What's new

●

Finding information

After you set up and register the computer, it is important to take the following
steps:

●

Connect to the Internet—Set up your wired or wireless network so that you
can connect to the Internet. For more information, refer to

Networking

on page 37.

●

Update your antivirus software—Protect your computer from damage
caused by viruses. The software is preinstalled on the computer and
includes a limited subscription for free updates. For more information, refer
to the HP Notebook Reference Guide.

●

Get to know your computer—Learn about your computer features. Refer
to

Getting to know your computer on page 25 and Keyboard and pointing

devices on page 40 for additional information.

●

Create recovery discs or a recovery flash drive—Recover the operating
system and software to factory settings in case of system instability or
failure. For instructions, refer to

Backup and recovery on page 63.

●

Find installed software—Access a list of the software preinstalled on the
computer. Select Start > All Programs. For details about using the software
included with the computer, refer to the software manufacturer's instructions,
which may be provided with the software or on the manufacturer's Web site.

1

What's new

HP CoolSense

HP CoolSense gives you more control over your computer's thermal

settings through the use of predefined modes that emphasize computer
performance, temperature, and internal fan speed and noise.

●

On—Configures the thermal settings to avoid temperature increases and
makes the computer feel cooler to the touch.

● Off—With CoolSense turned off, your computer will operate at peak

performance, but this setting may result in higher temperatures than in On
mode.

● Auto (default setting)—Automatically detects whether the computer is

stationary or mobile, and optimizes the thermal settings to match your usage
environment. When the computer is stationary, HP CoolSense prioritizes
performance and is set to Off mode. When the computer is mobile, HP
CoolSense prioritizes temperature and is set to On mode.

To change the cooling preferences, follow these steps:

1. Select Start > All Programs > HP > HP CoolSense.

2. Select a cooling mode.

HP 3D Cinema Technology

You will enjoy an exceptional cinema-quality experience of stereoscopic 3D Blu­ray movies, stereo 3D game play, and vivid 3D photos and videos. The
integrated 3D features, along with the 3D glasses, provide everything you need
for an outstanding 3D sensory experience. For more information, refer to

Using

HP 3D Cinema Technology on page 10.

NOTE: Before using 3D Cinema Technology and the 3D glasses, read the 3D

safety information. Consult a physician if you suspect that you may have a
physical problem seeing stereoscopic 3D. Refer to

3D safety information

on page 11 for more information.

Intel Wireless Display

Intel® Wireless Display allows you to share your computer content wirelessly on
your TV. To experience wireless display, a wireless third-party TV adapter
(purchased separately) is required. Content that asserts output protection, such
as Blu-ray discs, will not play on Intel Wireless Display. For details about using
the wireless adapter, refer to the device manufacturer's instructions.

NOTE: Be sure that wireless is enabled on your computer before using the

wireless display.

NOTE: Intel Wireless Display does not support 3D playback on external display

devices.

2 Chapter 1 Welcome

Beats Audio

Beats™ Audio is an enhanced audio profile that provides a deep, controlled bass
while maintaining a clear sound. Beats Audio is enabled by default.

▲

To increase or decrease the Beats Audio bass settings, press fn+b.

NOTE: You can also view and control the bass settings through the

Windows® operating system. Select Start > Control Panel > Hardware
and Sound > Beats Audio Control Panel to view and control the bass

properties.

The following table describes the Beats Audio icons that appear when you press

fn+b.

Icon Description

Indicates that Beats Audio is enabled.

Indicates that Beats Audio is disabled.

What's new

3

Switching between graphics modes

The computer is equipped with switchable graphics and has two modes for
processing graphics. When you switch from AC power to battery power, the
computer can switch from using the high-performance mode to using the power­saving mode to conserve battery life. Similarly, when you switch from battery
power to AC power, the computer can switch back to the high-performance
mode.

NOTE: 3D playback on the computer display requires high-performance GPU.

NOTE: In some instances, in order to optimize performance of the computer,

the system does not allow you to switch modes, or it may prompt you to switch. It
may also be necessary to close all programs before switching.

When you switch between AC and battery power, you are notified that the
computer is about to switch graphics modes. If you prefer, you can choose to
continue using the same graphics mode. While the computer switches modes,
the screen goes blank for a few seconds. When the switch is complete, a
notification appears in the notification area, and the screen image reappears.

4 Chapter 1 Welcome

AMD Eyefinity Multi-Display technology

Your computer supports the new AMDTM Eyefinity technology that provides the
following features:

●

You can now have up to 3 external displays, as long as one of the displays
is connected to the Mini DisplayPort on the computer.

● Provides a new display configuration by spanning the image across a group

of external displays into a massive single large surface (SLS).

NOTE: 3D playback is not supported on AMD Eyefinity technology.

Example display configuration for single large surface (SLS)

When you use 3 external displays and span the image across them as an SLS,
the computer display is turned off. The 3 external displays are connected to the
computer using the external monitor port (VGA), the Mini DisplayPort, and the
HDMI port.

NOTE: Identical resolution is required among all displays to form the SLS

mode. Displays with different native resolutions can still form an SLS mode by
using non-native resolutions.

NOTE: Windows 7 only supports 2 external displays. To configure 3 external

displays in Windows 7, refer to

Using the AMD Catalyst Control Center

on page 6.

What's new

5

Switching the screen image

Press the switch screen image action key to open a dialog box that shows the 4
configuration choices, independent of the number of connected display devices.

●

Computer only mode—Turns off the external display and displays the image
only on the computer display.

●

Duplicate mode—Clones the computer display onto an external display that
is connected to the external monitor port (VGA) on the computer.

●

Extend mode—Extends the desktop to all connected external displays along
with the computer display.

●

Projector only mode—Turns off the computer display and sets all connected
external displays to extended desktop.

NOTE: You can manage the video output and default output devices using the

AMD Catalyst™ Control Center.

Using the AMD Catalyst Control Center

To configure desktops and displays and to manage AMD Eyefinity, you must use
the AMD Catalyst Control Center.

To access the AMD Catalyst Control Center:

1. Select Start > All Programs > Catalyst Control Center > CCC.

2. Select Desktops and Displays.

NOTE: For additional information on using the AMD Catalyst Control Center,

refer to the software Help.

6 Chapter 1 Welcome

Finding information

The computer comes with several resources to help you perform various tasks.

Resources For information about

Quick Setup poster ● How to set up the computer

● Help to identify computer components

Getting Started

To access this guide:

Select Start > Help and Support > User

Guides.

– or –

Select Start > All Programs > HP > HP

Documentation.

● Computer features

●

How to connect to a wireless network

● How to use the keyboard and pointing devices

●

How to replace or upgrade the hard drive and

memory modules

● How to perform a backup and recovery

●

How to contact customer support

● Computer specifications

HP Notebook Reference Guide

To access this guide:

Select Start > Help and Support > User

Guides.

– or –

Select Start > All Programs > HP > HP

Documentation.

●

Power management features

● How to maximize battery life

●

How to use the multimedia features of the

computer

● How to protect the computer

●

How to care for the computer

● How to update the software

Help and Support

To access Help and Support, select Start

>

Help and Support.

NOTE:

For country- or region-specific

support, go to

http://www.hp.com/support,

select your country or region, and follow the

on-screen instructions.

●

Operating system information

● Software, driver, and BIOS updates

●

Troubleshooting tools

● How to access technical support

Finding information

7

Resources For information about

Regulatory, Safety and Environmental

Notices

To access this guide:

Select Start > Help and Support > User

Guides.

– or –

Select Start > All Programs > HP > HP

Documentation.

● Regulatory and safety information

● Battery disposal information

Safety & Comfort Guide

To access this guide:

Select Start > Help and Support > User

Guides.

– or –

Select Start > All Programs > HP > HP

Documentation.

– or –

Go to

http://www.hp.com/ergo.

● Proper workstation setup, posture, health, and

work habits

● Electrical and mechanical safety information

Worldwide Telephone Numbers booklet

This booklet is provided with your computer.

HP support telephone numbers

HP Web site

To access this Web site, go to

http://www.hp.com/support.

● Support information

●

Ordering parts and finding additional help

● Software, driver, and BIOS updates

●

Accessories available for the device

8 Chapter 1 Welcome

Resources For information about

Limited Warranty*

To access the warranty:

Select Start > Help and Support > User

Guides > View Warranty Information.

– or –

Select Start > All Programs > HP > HP

Documentation > View Warranty

Information.

– or –

Go to

http://www.hp.com/go/

orderdocuments.

Warranty information

*You may find the expressly provided HP Limited Warranty applicable to your product located with the

electronic guides on your computer and/or on the CD/DVD provided in the box. Some countries/

regions may provide a printed HP Limited Warranty in the box. In countries/regions where the

warranty is not provided in printed format, you may request a printed copy at

http://www.hp.com/go/

orderdocuments or write to:

●

North America: Hewlett-Packard, MS POD, 11311 Chinden Blvd, Boise, ID 83714, USA

● Europe, Middle East, Africa: Hewlett-Packard, POD, Via G. Di Vittorio, 9, 20063, Cernusco s/

Naviglio (MI), Italy

● Asia Pacific: Hewlett-Packard, POD, P.O. Box 200, Alexandra Post Office, Singapore 911507

Please include your product number, warranty period (found on your serial number label), name, and

postal address.

Finding information

9

2 Using HP 3D Cinema Technology

The following sections are included in this chapter:

●

3D safety information

●

What are stereoscopic vision and 3D

●

What is HP 3D Cinema Technology

●

Using the HP 3D Active Shutter Glasses

●

Using 3D Cinema Technology

●

Understanding 3D formats

●

Using CyberLink PowerDVD

●

Playing 3D games

●

Viewing 3D content on a 3D TV

●

Caring for the 3D glasses

●

Troubleshooting and frequently asked questions

10 Chapter 2 Using HP 3D Cinema Technology

3D safety information

Carefully read all of the following safety precautions before using the 3D glasses
and 3D Cinema Technology.

WARNING! If you cannot see 3D content after you set up 3D Cinema

Technology, HP recommends that you discontinue use. Consult a physician if
you suspect a physical problem seeing stereoscopic 3D.

Photosensitive Epileptic Seizures—Some individuals may experience a seizure
or other complications when exposed to certain visual images, including flashing
lights or patterns that may appear in 3D content. If you or any of your relatives
have a history of seizures or epilepsy, consult a physician before using the 3D
glasses and 3D Cinema Technology. Even those without a personal family
history of epilepsy or stroke may have an undiagnosed condition that can cause
photosensitive epileptic seizures.

If you experience any of the following symptoms, immediately stop watching 3D
content and consult a physician: altered vision, light-headedness, dizziness,

involuntary movements such as eye or muscle twitching, convulsions,
nausea, loss of awareness, confusion, cramps, and/or disorientation.

Parents should monitor and ask their children if they have any of the above
symptoms. Children and teenagers may be more likely than adults to experience
these symptoms.

Do not watch 3D content when you feel sleepy, tired, or sick. Watching 3D with
the 3D glasses for an extended period of time may cause a headache or fatigue.
If you feel headache, fatigue, or dizziness, stop using the 3D glasses and rest.

Your vision can change to accommodate viewing through the 3D glasses. After
removing the 3D glasses, wait several minutes before resuming regular activities.

Some 3D content may startle viewers. People who are pregnant, elderly, or
epileptic, and those suffering from severe physical conditions are advised to
avoid using the computer's 3D functionality.

The vision of young children (especially children under the age of 6) is still under
development. Consult your doctor (such as a pediatrician or eye doctor) before
allowing young children to watch 3D video images or play 3D videos games.
Parents or guardians should supervise young children to ensure they follow these
recommendations.

Choking Hazard—The 3D glasses contain small parts and are not intended for
babies and small children.

Do not use the 3D glasses near water.

The lenses in the 3D glasses contain glass. To prevent damage to the lenses,
use caution when using the glasses and properly store them when not in use. Do
not use the glasses if there is any sign of damage or cracking in the lenses.

3D safety information

11

The 3D glasses are not prescription eyewear, sunglasses, or protective goggles.
To prevent personal injury, do not use the glasses for any general eyewear
purposes.

12 Chapter 2 Using HP 3D Cinema Technology

What are stereoscopic vision and 3D

When you see the world through both eyes, you are actually looking at two
pictures merged into one. Your right eye and your left eye each deliver a
separate image to your brain, which meshes these two images into one three­dimensional picture.

Most movies in the past were only able to provide one image on the screen, and
3D effects had to be simulated by other means. However, the HP 3D Active
Shutter Glasses provide a different view for each eye, which more closely
simulates 3D vision.

Each scene of the 3D content has two images, one drawn from the right eye view
and the other from the left eye view. The computer display shows these
alternating views so fast that your eyes cannot see the change.

The 3D glasses are equipped with shutters in each lens. When the right eye
image is displayed on the screen, the left lens of the 3D glasses is closed,
allowing only the right eye to see the image. When the left eye image is
displayed, the process is reversed and only the left eye can see the image.
These images alternate so quickly that the eyes only see one smooth picture,
making it look like you are actually inside a 3D environment.

What is HP 3D Cinema Technology

3D Cinema Technology delivers a vivid, immersive 3D experience. When you
watch Blu-ray 3D movies, stereo 3D games, or 3D photos or videos on the
computer with your 3D glasses, the images appear to leap from the screen. 3D
creates an entirely new viewing experience. With 3D Cinema Technology, you
have all the necessary components for an exceptional 3D experience. No
additional software is required to experience the 3D cinema-quality visuals.

The following items are provided for your 3D experience:

●

3D technology specifically designed and optimized for 3D Blu-ray content

●

3D Active Shutter Glasses that wirelessly synchronize with the 3D computer
display

●

3D full high-definition 1080p display

●

TriDef 3D Experience Ignition Game Player

●

CyberLink PowerDVD

NOTE: Select computer models may include 3D content so you can

immediately begin enjoying 3D.

The computer supports both 2D and 3D formats. The computer operates in
standard 2D mode until stereoscopic 3D is detected and the 3D glasses are
activated.

What are stereoscopic vision and 3D

13

Using the HP 3D Active Shutter Glasses

Your 3D experience begins with active 3D content and the 3D glasses. The 3D
glasses are battery powered and linked wirelessly to the infrared (IR) emitters in
your 3D computer.

WARNING! Before using the 3D glasses, read the 3D safety information.

NOTE: For optimal 3D viewing, you should be no more than approximately 1.5

meters (5 feet) from the computer display. Depending on the viewing angle, the

operational distance from the display can vary.

When watching stereoscopic 3D images, do not incline your head relative to the
horizontal direction of the images.

Keep the areas immediately around the IR emitters free from obstructions. For
information on the location of the IR emitters, refer to

Getting to know your

computer on page 25.

NOTE: Before using the glasses, remove the clear protective film from both

sides of the lenses (select models only).

Identifying the 3D glasses components

14 Chapter 2 Using HP 3D Cinema Technology

Component

(1) Battery compartment

NOTE:

The battery is preinstalled and may have a protective tab. If the tab is attached,

simply pull the tab to remove it.

(2) Nose pieces (3)

NOTE:

There are 3 nose pieces in different sizes. One nose piece is installed on the

glasses and two additional nose pieces ship with the glasses.

Turning the 3D glasses on and off

Your 3D glasses are easy to use:

●

The 3D glasses turn on and off automatically. There is no on or off switch.

●

When 3D content begins to play, the glasses detect an IR signal from the
computer and turn on automatically.

●

Once the 3D content begins to play, the lenses may appear to darken and
you may see some flickering as the glasses begin to turn on.

●

The battery installed in the glasses provides approximately 150 hours of 3D
viewing time. To help conserve battery power, the glasses enter Standby if
no IR signal is detected for 5 seconds.

Using 3D Cinema Technology

After you set up your 3D computer, you are ready to verify that you can properly
view the 3D content.

NOTE: Be sure that your computer is connected to AC power when viewing 3D

content. 3D playback on the computer display requires high-performance GPU.

NOTE: The stereoscopic 3D effect works best in a darkened room. For optimal

3D viewing, the screen brightness controls are also disabled when watching 3D
content.

1. To access 3D content, do one of the following:

● Double-click the 3D demo icon on the computer desktop and select a

3D clip from the menu.

●

Insert a Blu-ray 3D movie (purchased separately) into the slot-load
optical drive on the computer and follow the on-screen instructions.

Using 3D Cinema Technology

15

NOTE: Insert the disc into the optical drive until it clicks into place. To

eject the disc, press the optical drive eject key located at the top right
of the keyboard.

2. Put on your 3D glasses. If needed, adjust the glasses using the nose pieces

provided.

3. The 3D glasses turn on automatically when the 3D content begins to play

and the infrared (IR) signal is detected. Your lenses may darken, or you may
see flickering while the glasses start operation.

If you can see clearly in 3D, the setup is complete and you can begin
viewing 3D cinema content!

NOTE: Differences in the frequencies at which the lighting in your room

and 3D Cinema Technology operate may cause flickering or interfere with
the operation of the glasses. This can be avoided by dimming or turning off
the lights.

WARNING! If you still cannot see 3D content, remove the 3D glasses and

stop using 3D Cinema Technology. Refer to the 3D safety information and
consult a physician if you suspect a physical problem seeing stereoscopic
3D.

16 Chapter 2 Using HP 3D Cinema Technology

Understanding 3D formats

Your computer supports the following 3D formats:

●

Blu-ray 3D movies

●

Stereoscopic 3D games

●

3D MPEG 4 MVC files for 3D video playback

●

3D H.264 MVC and Fujifilm AVI dual-stream video file formats for 3D video
playback

● 3D Fujifilm MPO for 3D photo viewing

NOTE: 3D playback is only supported in full-screen mode.

Using CyberLink PowerDVD

CyberLink PowerDVD supports the playback of 3D Blu-ray DVDs, 3D video files,
and native 3D photos. When you insert a native 3D Blu-ray DVD, or play a native
3D video or photo file, it automatically plays back in 3D if 3D mode is enabled.

During playback, you can also manually adjust the 3D configuration settings for
improved stereoscopic 3D viewing. For information on using CyberLink
PowerDVD, refer to the software Help.

▲

To open CyberLink PowerDVD, select Start > All Programs > CyberLink
PowerDVD, and then click CyberLink PowerDVD.

Playing 3D games

You can play stereo 3D games on your computer using TriDef 3D Experience
Ignition Game Player.

▲ To access the game player, select Start > TriDef 3D > TriDef 3D Ignition.

Understanding 3D formats

17

Viewing 3D content on a 3D TV

The HDMI 1.4 connector allows you to play back Blu-ray 3D movies on an
external 3D HDTV or 3D projector (purchased separately). To view content on a
3D TV, the computer must be in Projector only mode and connected to the TV
with a high-speed HDMI cable. You must use the 3D glasses that came with your
TV, not the glasses that came with your computer.

NOTE: Only Checkerboard, Row-Interleave, and HDMI 1.4 Time-sequential 3D

TVs are supported.

NOTE: 3D playback of photos and videos is only supported on the computer

display.

18 Chapter 2 Using HP 3D Cinema Technology

Caring for the 3D glasses

Using the nose pieces

The 3D glasses come with 3 nose pieces in different sizes. One nose piece is
installed at the factory and two additional nose pieces ship with the glasses. Try
on the glasses, and change the nose piece if needed to find a comfortable fit.
You can also wear the glasses without a nose piece if needed.

NOTE: The 3D glasses are designed to fit over most standard prescription

glasses.

▲

To add a nose piece, insert the nose piece onto the glasses. To remove a
nose piece, pull the nose piece away from the glasses.

Caring for the 3D glasses

19

Replacing the battery

The battery in the 3D glasses ships preinstalled in the battery compartment and
provides approximately 150 hours of 3D viewing time. HP recommends that the
battery be replaced once a year. The glasses can stay in Standby mode for up to
one year. The 3D glasses use a basic CR2032 type battery. These batteries can
easily be replaced and can be purchased anywhere batteries are sold.

WARNING! Replace the battery with only a CR2032 type battery. Use of

another battery may cause fire or explosion.

Dispose of the used battery promptly and according to local regulations. Be sure
to keep the battery away from children.

To replace the battery:

1. Slide the battery compartment cover (1) down, and then remove the used

battery (2).

20 Chapter 2 Using HP 3D Cinema Technology

2. Carefully insert the new battery (1) with the positive (+) side facing the

battery compartment cover, and then replace the battery compartment cover

(2).

CAUTION: To prevent damage to the glasses, use caution when inserting

the battery.

Cleaning the 3D glasses

To remove smudges and lint, clean the 3D glasses with a soft, damp, lint-free
cloth as needed. The cloth can be dampened with mild cleaning agents with less
than 10% alcohol.

CAUTION: To prevent permanent damage to the 3D glasses:

Do not use paper-based towels, because they can scratch the lenses.

Do not spray cleaning fluids or chemicals directly on the lenses.

Do not use ammonia-based cleaning products.

Caring for the 3D glasses

21

Handling the glasses

The 3D glasses are durable but sensitive to physical pressure, and need to be
handled with care. The 3D glasses should be held by the frame in order to avoid
getting fingerprints on the lenses. When you are not using the 3D glasses, store
them in the protective pouch.

CAUTION: To prevent the lenses from cracking, never twist or rotate the 3D

glasses.

Troubleshooting and frequently asked questions

I cannot see 3D content

If you are watching in 3D mode and cannot see 3D content, HP recommends that
you not use the 3D glasses. Refer to the information below and

3D safety
information on page 11. Consult a physician if you suspect a physical problem

seeing stereoscopic 3D.

● You may be trying to watch 3D content in 2D mode.

● The clear protective film on both sides of the glasses lenses (select models

only) may need to be removed.

●

The battery in the 3D glasses may need to be replaced. Refer to

Replacing

the battery on page 20 for additional information.

●

The IR emitters on the computer display may be obstructed. For optimal
transmission, keep the areas immediately around the IR emitters free from
obstructions. For information on the location of the IR emitters, refer to

Getting to know your computer on page 25.

●

You may be sitting too far from the computer display. You should be no
more than approximately 1.5 meters (5 feet) from the display when viewing
3D content.

NOTE: Depending on your viewing angle, the operational distance from

the display can vary.

What 3D formats are supported on my computer

The following 3D formats are supported on your computer:

●

Blu-ray 3D movies

●

Stereoscopic 3D games

● 3D MPEG 4 MVC files for 3D video playback

●

3D H.264 MVC and Fujifilm AVI dual-stream video file formats for 3D video
playback

● 3D Fujifilm MPO for 3D photo viewing

22 Chapter 2 Using HP 3D Cinema Technology

Can I play stereoscopic 3D games on my computer

Yes, you can play stereo 3D games on your computer using TriDef® 3D
Experience Ignition Game Player.

▲

To access the game player, select Start > TriDef 3D > TriDef 3D Ignition.

Can I wear the 3D glasses to a 3D movie in a movie theater

The 3D glasses are optimized to work with the HP ENVY17 3D computer and
integrated IR emitters. The 3D glasses are not guaranteed to work optimally in
any other 3D environment.

Can I wear my 3D glasses over my prescription glasses

Yes. The 3D glasses are designed to fit over most prescription glasses. If you
normally wear glasses when viewing the computer screen, keep them on and put
the 3D glasses on over your eyewear. You can use the additional replaceable
nose pieces to find a comfortable fit. Refer to

Using the HP 3D Active Shutter

Glasses on page 14 for more information.

How do I clean my 3D glasses

Use a soft, damp, lint-free cloth to clean your 3D glasses. Refer to Caring for the

3D glasses on page 19 for more information.

How close do I need to be to the computer to view 3D content

The effective range of the integrated IR emitters is approximately 1.5 meters (5
feet) from the computer display. Depending on the viewing angle, the operational
distance from the display can vary.

I see flickering when watching 3D content

Flickering in your 3D glasses can be caused by one of the following:

●

Differences in the frequencies at which the lighting in your room and 3D
Cinema Technology operate may cause flickering or interfere with the
operation of the glasses. This can be avoided by dimming or turning off the
lights.

●

Low battery in the glasses. You should try replacing the battery.

Can I use the 3D glasses in bright sunlight next to a window

The stereoscopic 3D effect works best in a darkened room.

Troubleshooting and frequently asked questions

23

What type of batteries do I need for the 3D glasses

The 3D glasses use a basic CR2032 type battery. These batteries can easily be
replaced and can be purchased anywhere batteries are sold. Refer to

Replacing

the battery on page 20 for more information.

Can I use my computer to watch 3D content on my external 3D TV

Yes, you can watch 3D content on your external 3D TV (purchased separately)
using a high-speed HDMI 1.4 cable connected to the computer and the 3D TV.

NOTE: Only Checkerboard, Row-Interleave, and HDMI 1.4 Time-sequential 3D

TVs are supported.

NOTE: To watch 3D content on your external 3D TV, you must use the 3D

glasses that came with your TV, not the glasses that came with your computer.

24 Chapter 2 Using HP 3D Cinema Technology

3 Getting to know your computer

The following sections are included in this chapter:

●

Top

●

Front

●

Right-side

●

Left-side

●

Display

●

Bottom

Top

TouchPad

Component Description

(1)

TouchPad light Turns the TouchPad on and off. Quickly double-

tap the TouchPad light to turn the TouchPad on

and off.

Top

25

Component Description

(2)

Left TouchPad button Functions like the left button on an external

mouse.

(3)

Right TouchPad button Functions like the right button on an external

mouse.

(4)

TouchPad zone Moves the pointer and selects or activates items

on the screen.

Lights

Component Description

(1)

TouchPad light

●

Amber: The TouchPad is off.

● Off: The TouchPad is on.

(2)

Caps lock light ● White: Caps lock is on.

●

Off: Caps lock is off.

26 Chapter 3 Getting to know your computer

Component Description

(3)

Power light ● White: The computer is on.

● Blinking white: The computer is in the Sleep

state.

● Off: The computer is off or in Hibernation.

(4)

Mute light ● Amber: Computer sound is off.

● Off: Computer sound is on.

(5)

Wireless light ● White: An integrated wireless device, such

as a wireless local area network (WLAN)

device, is on.

NOTE:

Wireless devices are enabled at

the factory.

●

Amber: All wireless devices are off.

Top

27

Button

Component Description

Power button ● When the computer is off, press the button to turn on the

computer.

●

When the computer is on, press the button briefly to initiate

Sleep.

●

When the computer is in the Sleep state, press the button

briefly to exit Sleep.

● When the computer is in Hibernation, press the button briefly to

exit Hibernation.

If the computer has stopped responding and Windows shutdown

procedures are ineffective, press and hold the power button for at

least 5 seconds to turn off the computer.

To learn more about your power settings, select Start > Control

Panel > System and Security > Power Options, or refer to the HP

Notebook Reference Guide.

28 Chapter 3 Getting to know your computer

Keys

Component Description

(1)

esc key Displays system information when pressed in

combination with the fn key.

(2)

fn key Executes frequently used system functions when

pressed in combination with the b key or the esc key.

(3)

Windows logo key Displays the Windows Start menu.

(4)

Action keys Execute frequently used system functions.

(5)

Windows applications key Displays a shortcut menu for items beneath the

pointer.

(6)

Integrated numeric keypad Can be used like an external numeric keypad.

(7)

Optical drive eject key Ejects the optical disc from the optical drive.

Top

29

Front

Component Description

(1)

Power light

●

White: The computer is on.

●

Blinking white: The computer is in the Sleep state.

● Off: The computer is off or in Hibernation.

(2)

Hard drive light ● Blinking white: The hard drive is being accessed.

●

Amber: HP ProtectSmart Hard Drive Protection has

temporarily parked the hard drive.

NOTE:

For information on HP ProtectSmart Hard Drive

Protection, refer to the HP Notebook Reference Guide.

(3)

Speakers (2) Produce sound.

30 Chapter 3 Getting to know your computer

Right-side

Component Description

(1)

USB ports (2) Connect optional USB devices.

(2)

Digital Media Slot Supports the following digital card formats:

● Memory Stick

●

Memory Stick Pro

● MultiMediaCard

●

Secure Digital (SD) Memory Card

●

Secure Digital High Capacity Memory Card

● xD-Picture Card

(3)

Optical drive Reads and writes to an optical disc.

CAUTION:

Do not insert 8-cm optical discs into the

optical drive. This can cause damage to the computer.

(4)

Battery light ● White: The computer is connected to external

power and the battery is fully charged.

● Amber: A battery is charging.

● Blinking amber: The battery has reached a low

battery level, a critical battery level, or there is a

battery error.

● Off: The computer is running on battery power.

(5)

Power connector Connects an AC adapter.

(6)

Security cable slot Attaches an optional security cable to the computer.

NOTE:

The security cable is designed to act as a

deterrent, but it may not prevent the computer from

being mishandled or stolen.

Right-side

31

Left-side

Component Description

(1)

Vent Enables airflow to cool internal components.

NOTE:

The computer fan starts up automatically

to cool internal components and prevent overheating.

It is normal for the internal fan to cycle on and off

during routine operation.

(2)

External monitor port Connects an external VGA monitor or projector.

(3)

RJ-45 (network) jack Connects a network cable.

(4)

Mini DisplayPort Connects an optional digital display device, such as

a high-performance monitor or projector.

(5)

HDMI port Connects an optional video or audio device, such as

a high-definition television, any compatible digital or

audio component, or a high-speed HDMI 1.4 device.

(6)

eSATA/USB port Connects a high-performance eSATA component,

such as an eSATA external hard drive, or connects

an optional USB 2.0 device.

(7)

SuperSpeed USB port Connects an optional USB 3.0 device and provides

enhanced USB power performance.

NOTE:

The SuperSpeed USB port is also

compatible with USB 1.0 and 2.0 devices.

32 Chapter 3 Getting to know your computer

Component Description

(8)

Audio-out (headphone) jack/

Audio-in (microphone) jack

Produces sound when connected to optional

powered stereo speakers, headphones, earbuds, a

headset, or television audio. Also connects an

optional headset microphone.

WARNING!

To reduce the risk of personal injury,

adjust the volume before putting on headphones,

earbuds, or a headset. For additional safety

information, refer to the Regulatory, Safety, and

Environmental Notices.

NOTE:

When a device is connected to the jack,

the computer speakers are disabled.

(9)

Audio-out (headphone) jack Produces sound when connected to optional

powered stereo speakers, headphones, ear buds, a

headset, or television audio.

WARNING!

To reduce the risk of personal injury,

adjust the volume before putting on headphones,

earbuds, or a headset. For additional safety

information, refer to the Regulatory, Safety, and

Environmental Notices.

NOTE:

When a device is connected to the jack,

the computer speakers are disabled.

Left-side

33

Display

Component Description

(1) WLAN antennas (2)* Send and receive wireless signals to communicate with

wireless local area networks (WLAN).

(2) IR emitters (2)* Wirelessly synchronize the 3D glasses with the computer

display.

(3) Internal microphones (2) Record sound.

(4) Webcam light On: The webcam is in use.

(5) Webcam Records video and captures still photographs.

To access the webcam, select Start > All Programs >

CyberLink YouCam.

34 Chapter 3 Getting to know your computer

Component Description

(6) Internal display switch Turns off the display and initiates Sleep if the display is closed

while the power is on.

NOTE:

The internal display switch is not visible from the

outside of the computer.

*The antennas and IR emitters are not visible from the outside of the computer. For optimal

transmission, keep the areas immediately around the antennas and IR emitters free from obstructions.

To see wireless regulatory notices, refer to the section of the Regulatory, Safety, and Environmental

Notices that applies to your country or region. These notices are located in Help and Support.

Bottom

Component Description

(1)

Subwoofer Provides superior bass sound.

Bottom

35

Component Description

(2)

Battery bay Holds the battery.

NOTE:

The battery is preinstalled in the battery bay at

the factory.

(3)

Vents (7) Enable airflow to cool internal components.

NOTE:

The computer fan starts up automatically to

cool internal components and prevent overheating. It is

normal for the internal fan to cycle on and off during

routine operation.

(4)

Hard drive bay Holds the hard drive.

(5)

Memory module

compartment

Holds the memory modules.

(6)

Battery release latch Releases the battery from the battery bay.

36 Chapter 3 Getting to know your computer

4Networking

●

Using an Internet service provider (ISP)

●

Connecting to a wireless network

NOTE: Internet hardware and software features vary depending on computer

model and your location.

Your computer may support one or both of the following types of Internet access:

●

Wireless—For mobile Internet access, you can use a wireless connection.
Refer to

Connecting to an existing WLAN on page 38 or Setting up a new

WLAN network on page 39.

●

Wired—You can access the Internet by connecting to a wired network. For
information on connecting to a wired network, refer to the HP Notebook
Reference Guide.

Using an Internet service provider (ISP)

Before you can connect to the Internet, you must establish an ISP account.
Contact a local ISP to purchase Internet service and a modem. The ISP will help
set up the modem, install a network cable to connect your wireless computer to
the modem, and test the Internet service.

NOTE: Your ISP will give you a user ID and password to access the Internet.

Record this information and store it in a safe place.

The following features will help you set up a new Internet account or configure
the computer to use an existing account:

●

Internet Services & Offers (available in some locations)—This utility
assists with signing up for a new Internet account and configuring the
computer to use an existing account. To access this utility, select Start > All
Programs > Online Services > Get Online.

● ISP-provided icons (available in some locations)—These icons may be

displayed either individually on the Windows desktop or grouped in a
desktop folder named Online Services. To set up a new Internet account or
configure the computer to use an existing account, double-click an icon, and
then follow the on-screen instructions.

●

Windows Connect to the Internet Wizard—You can use the Windows
Connect to the Internet Wizard to connect to the Internet in any of these
situations:

Using an Internet service provider (ISP)

37

◦

You already have an account with an ISP.

◦ You do not have an Internet account and want to select an ISP from

the list provided within the wizard. (The list of ISP providers is not
available in all regions.)

◦ You have selected an unlisted ISP, and the ISP has provided you with

information such as a specific IP address and POP3 and SMTP
settings.

To access the Windows Connect to the Internet Wizard and instructions for
using it, select Start > Control Panel > Network and Internet > Network

and Sharing Center.

NOTE: If you are prompted within the wizard to choose between enabling

or disabling Windows Firewall, choose to enable the firewall.

Connecting to a wireless network

Wireless technology transfers data across radio waves instead of wires. Your
computer may be equipped with one or more of the following wireless devices:

● Wireless local area network (WLAN) device

●

HP Mobile Broadband Module, a wireless wide area network (WWAN)
device

● Bluetooth® device

For more information on wireless technology and connecting to a wireless
network, refer to the HP Notebook Reference Guide and information and Web
site links provided in Help and Support.

Connecting to an existing WLAN

1. Turn on the computer.

2. Be sure that the WLAN device is on.

3. Click the network icon in the notification area, at the far right of the taskbar.

4. Select a network to connect to.

5. Click Connect.

6. If required, enter the security key.

38 Chapter 4 Networking

Setting up a new WLAN network

Required equipment:

● A broadband modem (either DSL or cable) (1) and high-speed Internet

service purchased from an Internet service provider (ISP)

●

A wireless router (purchased separately) (2)

● Your new wireless computer (3)

NOTE: Some modems have a built-in wireless router. Check with your ISP to

determine what type of modem you have.

The illustration shows an example of a completed WLAN network installation that
is connected to the Internet. As your network grows, additional wireless and
wired computers can be connected to the network to access the Internet.

Configuring a wireless router

For help in setting up a WLAN, refer to the information provided by your router
manufacturer or your ISP.

The Windows operating system also provides tools to help you set up a new
wireless network. To use the Windows tools to set up your network, select

Start > Control Panel > Network and Internet > Network and Sharing
Center > Set up a new connection or network > Set up a new network. Then

follow the on-screen instructions.

NOTE: It is recommended that you initially connect your new wireless computer

to the router by using the network cable provided with the router. When the
computer successfully connects to the Internet, you can disconnect the cable,
and then access the Internet through your wireless network.

Protecting your WLAN

When you set up a WLAN or access an existing WLAN, always turn on security
features to protect your network from unauthorized access.

For information on protecting your WLAN, refer to the HP Notebook Reference
Guide.

Connecting to a wireless network

39

5 Keyboard and pointing devices

The following sections are included in this chapter:

●

Using the keyboard

●

Using pointing devices

Using the keyboard

Using the action keys

Action keys are used for performing customized actions that are assigned to
specific keys at the top of the keyboard.

The icons on the f1 through f10 keys represent the action key functions. To use
an action key, press and hold this key to activate the assigned function.

NOTE: The action key feature is enabled at the factory. You can disable this

feature in Setup Utility (BIOS) and revert back to standard settings by pressing
the fn key and one of the function keys to activate the assigned function. Refer to
the “Setup Utility (BIOS) and System Diagnostics” chapter in the HP Notebook
Reference Guide for instructions.

CAUTION: Use extreme care when making changes in Setup Utility. Errors can

prevent the computer from operating properly.

Icon Key Description

f1 Opens Help and Support, which provides information about your Windows

operating system and computer, answers to questions and tutorials, and updates to

your computer.

Help and Support also provides automated troubleshooting and links to support

specialists.

f2 Decreases the screen brightness level when you hold down this key.

f3 Increases the screen brightness level when you hold down this key.

40 Chapter 5 Keyboard and pointing devices

Icon Key Description

f4 Switches the screen image among display devices connected to the system. For

example, if a monitor is connected to the computer, this key alternates the screen

image from computer display to monitor display to simultaneous display on both the

computer and the monitor.

Most external monitors receive video information from the computer using the

external VGA video standard. The switch screen image key can also alternate

images among other devices that are receiving video information from the

computer.

The computer also supports multiple display outputs. When you press the switch

screen image key, you can select from four different video outputs:

●

Computer only mode

●

Duplicate mode

● Extend mode

●

Projector only mode

f5 Turns the keyboard backlight on and off.

NOTE:

The keyboard backlight is turned on at the factory. To extend battery

power, turn off the keyboard backlight.

f6 Opens a Web browser.

NOTE:

Until you set up your Internet or network services, this key opens the

Internet Connection Wizard.

f7 Decreases speaker volume incrementally when you hold down this key.

f8 Increases speaker volume incrementally when you hold down this key.

f9 Mutes or restores speaker sound.

f10 Turns the wireless feature on or off.

NOTE:

This key does not establish a wireless connection. To establish a wireless

connection, a wireless network must be set up.

Using the keyboard

41

Using the hotkeys

A hotkey is a combination of the fn key (1) and either the esc key (2) or the b key
(3).

To use a hotkey:

▲

Briefly press the fn key, and then briefly press the second key of the hotkey
combination.

Function Hotkey Description

Display system information. fn+esc Displays information about system hardware components

and the system BIOS version number.

Control the bass settings. fn+b Increases or decreases the Beats Audio bass settings.

Beats Audio is an enhanced audio profile that provides a

deep, controlled bass while maintaining a clear sound.

Beats Audio is enabled by default.

You can also view and control the bass settings through the

Windows operating system. Select Start > Control Panel >

Hardware and Sound > Beats Audio Control Panel to

view and control the bass properties.

42 Chapter 5 Keyboard and pointing devices

Using the keypad

Using the integrated numeric keypad

Component Description

Integrated numeric keypad Can be used like an external numeric keypad.

NOTE:

The computer does not have a num lock key.

Using pointing devices

NOTE: In addition to the pointing devices included with your computer, you can

use an external USB mouse (purchased separately) by connecting it to one of the
USB ports on the computer.

Setting pointing device preferences

Use Mouse Properties in Windows to customize settings for pointing devices,
such as button configuration, click speed, and pointer options.

To access Mouse Properties, select Start > Devices and Printers. Then right-
click the device representing your computer, and select Mouse settings.

Using pointing devices

43

Using the TouchPad

To move the pointer, slide one finger across the TouchPad in the direction you
want the pointer to go. Use the left and right TouchPad buttons like the
corresponding buttons on an external mouse.

Turning the TouchPad off and on

To turn the TouchPad off and on, quickly double-tap the TouchPad light.

NOTE: The TouchPad light is off when the TouchPad is on.

44 Chapter 5 Keyboard and pointing devices

Navigating

To move the pointer, slide one finger across the TouchPad in the direction you
want the pointer to go.

Selecting

Use the left and right TouchPad buttons like the corresponding buttons on an
external mouse.

Using pointing devices

45

Using TouchPad gestures

The TouchPad supports a variety of gestures. To use TouchPad gestures, place
two fingers on the TouchPad at the same time.

NOTE: TouchPad gestures are not supported in all computer programs.

To view the demonstration of a gesture:

1. Click the Show hidden icons icon in the notification area, at the far right of

the taskbar.

2.

Right-click the Synaptics Pointing Device icon

, and then click

TouchPad Properties.

3. Click a gesture to activate the demonstration.

To turn the gestures on and off:

1. Click the Show hidden icons icon in the notification area, at the far right of

the taskbar.

2.

Right-click the Synaptics Pointing Device icon

, and then click

TouchPad Properties.

3. Select the check box next to the gesture that you want to turn on or off.

4. Click Apply, and then click OK.

46 Chapter 5 Keyboard and pointing devices

Scrolling

Scrolling is useful for moving up, down, or sideways on a page or image. To
scroll, place two fingers slightly apart on the TouchPad, and then drag them
across the TouchPad in an up, down, left, or right motion.

NOTE: Scrolling speed is controlled by finger speed.

NOTE: Two-finger scrolling is enabled at the factory.

Pinching/Zooming

Pinching allows you to zoom in or out on images or text.

●

Zoom in by placing two fingers together on the TouchPad, and then moving
them apart.

●

Zoom out by placing two fingers apart on the TouchPad, and then moving
them together.

NOTE: Pinching/zooming is enabled at the factory.

Using pointing devices

47

Rotating

Rotating allows you to rotate items such as photos. To rotate, anchor your left
forefinger in the TouchPad zone. Move the right forefinger around the anchored
finger in a sweeping motion, moving from 12 o’clock to 3 o’clock. To reverse the
rotation, move your right forefinger from 3 o’clock to 12 o’clock.

NOTE: Rotating is disabled at the factory.

48 Chapter 5 Keyboard and pointing devices

Flicking

Flicking allows you to navigate through screens or quickly scroll through
documents. To flick, use three fingers to touch the TouchPad zone in a light,
quick flicking motion up, down, left, or right.

NOTE: Three-finger flicking is disabled at the factory.

Using pointing devices

49

6 Maintenance

The following sections are included in this chapter:

●

Removing or inserting the battery

●

Replacing or upgrading the hard drive

●

Adding or replacing memory modules

●

Cleaning your computer

●

Updating programs and drivers

Removing or inserting the battery

NOTE: The battery is preinstalled in the battery bay at the factory.

NOTE: For additional information on using the battery, refer to the HP

Notebook Reference Guide.

Removing the battery

CAUTION: Removing a battery that is the sole power source for the computer

can cause loss of information. To prevent loss of information, save your work and
initiate Hibernation or shut down the computer through Windows before removing
the battery.

1. Slide the battery release latch (1) to release the battery.

2. Pivot the battery (2) upward and remove it from the computer (3).

50 Chapter 6 Maintenance

Inserting the battery

▲ Align the tabs on the battery (1) with the notches on the outer edge of the

battery bay, and rotate the battery (2) into the battery bay until it is seated.

The battery release latch (3) automatically locks the battery into place.

Removing or inserting the battery

51

Replacing or upgrading the hard drive

CAUTION: To prevent information loss or an unresponsive system:

Shut down the computer before removing the hard drive from the hard drive bay.
Do not remove the hard drive while the computer is on, in the Sleep state, or in
Hibernation.

If you are not sure whether the computer is off or in Hibernation, turn the
computer on by pressing the power button. Then shut down the computer
through the operating system.

NOTE: Select computer models can support up to two drives. To view the

drives installed on the computer, select Start > Computer.

Removing the hard drive

1. Save your work and shut down the computer.

2. Disconnect all external devices connected to the computer.

3. Remove external power from the AC outlet and remove the battery.

4. Loosen the 2 hard drive cover screws (1).

5. Remove the hard drive cover (2).

52 Chapter 6 Maintenance

6. Disconnect the hard drive cable (1) from the computer, and then lift the hard

drive (2) out of the hard drive bay.

7. Disconnect the hard drive cable from the hard drive.

Replacing or upgrading the hard drive

53

Installing a hard drive

1. Connect the hard drive cable to the hard drive.

2. Insert the hard drive (1) into the hard drive bay, and then connect the hard

drive cable (2) to the computer.

54 Chapter 6 Maintenance

3. Align the tabs (1) on the hard drive cover with the notches on the computer.

4. Close the cover (2).

5. Tighten the hard drive cover screws (3).

6. Replace the battery.

7. Reconnect external power and external devices.

8. Turn on the computer.

Adding or replacing memory modules

The computer has two memory module slots. The memory module slots are
located on the bottom of the computer under the hard drive cover. The memory
capacity of the computer can be upgraded by adding a memory module or
replacing the existing memory module in one of the memory module slots.

WARNING! To reduce the risk of electric shock and damage to the equipment,

unplug the power cord and remove all batteries before installing a memory
module.

CAUTION: Electrostatic discharge (ESD) can damage electronic components.

Before beginning any procedure, ensure that you are discharged of static
electricity by touching a grounded metal object.

Adding or replacing memory modules

55

NOTE: To use a dual-channel configuration when adding a second memory

module, be sure that both memory modules are the same capacity.

To add or replace a memory module:

CAUTION: To prevent information loss or an unresponsive system:

Shut down the computer before removing a memory module from the computer.
Do not remove a memory module while the computer is on, in the Sleep state, or
in Hibernation.

If you are not sure whether the computer is off or in Hibernation, turn the
computer on by pressing the power button. Then shut down the computer
through the operating system.

1. Save your work and shut down the computer.

2. Disconnect all external devices connected to the computer.

3. Remove external power from the AC outlet and remove the battery.

4. Remove the hard drive cover.

a. Loosen the 2 hard drive cover screws (1).

b. Remove the hard drive cover (2).

5. Remove the memory module compartment cover.

a. Loosen the 2 memory module compartment cover screws (1).

56 Chapter 6 Maintenance

b. Remove the memory module compartment cover (2).

6. If you are replacing a memory module, remove the existing memory module:

a. Pull away the retention clips (1) on each side of the memory module.

The memory module tilts up.

Adding or replacing memory modules

57

b. Grasp the edge of the memory module (2), and then gently pull the

module out of the memory module slot.

CAUTION: To prevent damage to the memory module, hold the

memory module by the edges only. Do not touch the components on
the memory module. To protect a memory module after removal, place
it in an electrostatic-safe container.

7. Insert a new memory module:

CAUTION: To prevent damage to the memory module, hold the memory

module by the edges only. Do not touch the components on the memory
module, and do not bend the memory module.

a. Align the notched edge (1) of the memory module with the tab in the

memory module slot.

b. With the memory module at a 45-degree angle from the surface of the

memory module compartment, press the module (2) into the memory
module slot until it is seated.

58 Chapter 6 Maintenance

c. Gently press the memory module (3) down, applying pressure to both

the left and right edges of the memory module, until the retention clips
snap into place.

8. Replace the memory module compartment cover.

a. Align the tabs (1) on the memory module compartment cover with the

notches on the computer.

b. Close the cover (2).

Adding or replacing memory modules

59

c. Tighten the 2 memory module compartment cover screws (3).

9. Replace the hard drive cover.

a. Align the tabs (1) on the hard drive cover with the notches on the

computer.

b. Close the cover (2).

60 Chapter 6 Maintenance

c. Tighten the 2 hard drive cover screws (3).

10. Replace the battery.

11. Reconnect external power and external devices.

12. Turn on the computer.

Adding or replacing memory modules

61

Cleaning your computer

Cleaning the display

CAUTION: To prevent permanent damage to the computer, never spray water,

cleaning fluids, or chemicals on the display.

To remove smudges and lint, frequently clean the display with a soft damp, lint­free cloth. If the screen requires additional cleaning, use premoistened antistatic
wipes or an antistatic screen cleaner.

Cleaning the TouchPad and keyboard

Dirt and grease on the TouchPad can cause the pointer to jump around on the
screen. To avoid this, clean the TouchPad with a damp cloth, and wash your
hands frequently when using the computer.

WARNING! To reduce the risk of electric shock or damage to internal

components, do not use a vacuum cleaner attachment to clean the keyboard. A
vacuum cleaner can deposit household debris on the keyboard surface.

Clean the keyboard regularly to prevent keys from sticking, and to remove dust,
lint, and particles that can become trapped beneath the keys. A can of
compressed air with a straw extension can be used to blow air around and under
the keys to loosen and remove debris.

Updating programs and drivers

HP recommends that you update your programs and drivers on a regular basis
with the latest versions. Go to

http://www.hp.com/support to download the latest

versions. You can also register to receive automatic update notifications when
they become available.

62 Chapter 6 Maintenance

7 Backup and recovery

●

Restore

●

Creating restore media

●

Performing a system restore

●

Backing up and recovering your information

Your computer includes tools provided by the operating system and HP to help
you safeguard your information and restore it if ever needed.

This chapter provides information on the following topics:

●

Creating a set of recovery discs or a recovery flash drive (HP Recovery
Manager software feature)

●

Performing a system restore (from the partition, recovery discs, or a
recovery flash drive)

● Backing up your information

● Recovering a program or driver

Restore

In the event of hard drive failure, to restore your system to its factory image you
will need a set of recovery discs or a recovery flash drive that you can create
using HP Recovery Manager. HP recommends that you use this software to
create either a set of recovery discs or a recovery flash drive immediately after
software setup.

If for some other reason you need to restore your system, this can be achieved
using the HP Recovery partition (select models only), without the need for
recovery discs or a recovery flash drive. To check for the presence of a recovery
partition, click Start, right-click Computer, click Manage, and then click Disk
Management. If the recovery partition is present, a Recovery drive is listed in the
window.

CAUTION: HP Recovery Manager (partition or discs/flash drive) restores only

software that was preinstalled at the factory. Software not provided with this
computer must be reinstalled manually.

NOTE: Recovery discs have been included if your computer does not have a

recovery partition.

Creating restore media

HP recommends that you create either a set of recovery discs or a recovery flash
drive to be sure that you can restore your computer to its original factory state if
the hard drive fails, or if for any reason you cannot restore using the recovery
partition tools. Create these discs or the flash drive after setting up the computer
for the first time.

Restore

63

NOTE: HP Recovery Manager allows the creation of only one set of recovery

discs or one recovery flash drive. Handle these discs or the flash drive carefully
and keep them in a safe place.

NOTE: If your computer does not include an integrated optical drive, you can

use an optional external optical drive (purchased separately) to create recovery
discs, or you can purchase recovery discs for your computer from the HP Web
site. If you use an external optical drive, it must be connected directly to a USB
port on the computer, not to a USB port on an external device, such as a USB
hub.

Guidelines:

●

Purchase high-quality DVD-R, DVD+R, DVD-R DL, or DVD+R DL discs.

NOTE: Read-write discs, such as CD-RW, DVD±RW, double-layer DVD

±RW, and BD-RE (rewritable Blu-ray) discs, are not compatible with the HP
Recovery Manager software.

● The computer must be connected to AC power during this process.

●

Only one set of recovery discs or one recovery flash drive can be created
per computer.

NOTE: If you are creating recovery discs, number each disc before

inserting it into the optical drive.

●

If necessary, you can exit the program before you have finished creating the
recovery discs or recovery flash drive. The next time you open HP Recovery
Manager, you will be prompted to continue the backup creation process.

To create a set of recovery discs or a recovery flash drive:

1. Select Start > All Programs > HP > HP Recovery Manager > HP

Recovery Media Creation.

2. Follow the on-screen instructions.

Performing a system restore

HP Recovery Manager software allows you to repair or restore the computer to
its original factory state. HP Recovery Manager works from recovery discs or a
recovery flash drive, or from a dedicated recovery partition (select models only)
on the hard drive.

NOTE: A system restore needs to be performed if the computer hard drive has

failed or if all attempts to correct any functional computer issues fail. A system
restore should be used as a final attempt to correct computer issues.

Note the following when performing a system restore:

64 Chapter 7 Backup and recovery

●

You can restore only the system that you have previously backed up. HP
recommends that you use Recovery Manager to create either a set of
recovery discs or a recovery flash drive as soon as you set up the computer.

●

Windows has its own built-in repair features, such as System Restore. If you
have not already tried these features, try them before using HP Recovery
Manager.

●

HP Recovery Manager restores only software that was preinstalled at the
factory. Software not provided with this computer must be downloaded from
the manufacturer's Web site or reinstalled from the disc provided by the
manufacturer.

Restoring using the dedicated recovery partition (select models
only)

When using the dedicated recovery partition, there is an option to back up
pictures, music and other audio, videos and movies, recorded TV shows,
documents, spreadsheets and presentations, e-mails, and Internet favorites and
settings during this process.

To restore the computer from the recovery partition, follow these steps:

1. Access HP Recovery Manager in either of the following ways:

●

Select Start > All Programs > HP > HP Recovery Manager > HP
Recovery Manager.

– or –

● Turn on or restart the computer, and then press esc while the “Press

the ESC key for Startup Menu” message is displayed at the bottom of
the screen. Then, press f11 while the “F11 (System Recovery)”
message is displayed on the screen.

2. Click System Recovery in the HP Recovery Manager window.

3. Follow the on-screen instructions.

Performing a system restore

65

Restoring using the restore media

1. If possible, back up all personal files.

2. Insert the first recovery disc into the optical drive on your computer or an

optional external optical drive, and then restart the computer.

– or –

Insert the recovery flash drive into a USB port on your computer, and then
restart the computer.

NOTE: If the computer does not automatically restart in HP Recovery

Manager, the computer boot order needs to be changed.

3. Press f9 at system bootup.

4. Select the optical drive or the flash drive.

5. Follow the on-screen instructions.

Changing the computer boot order

To change the boot order for recovery discs:

1. Restart the computer.

2. Press esc while the computer is restarting, and then press f9 for boot

options.

3. Select Internal CD/DVD ROM Drive from the boot options window.

To change the boot order for a recovery flash drive:

1. Insert the flash drive into a USB port.

2. Restart the computer.

3. Press esc while the computer is restarting, and then press f9 for boot

options.

4. Select the flash drive from the boot options window.

Backing up and recovering your information

It is very important to back up your files and keep any new software in a safe
place. As you add new software and data files, continue to create backups on a
regular basis.

How completely you are able to recover your system depends on how recent
your backup is.

NOTE: A recovery from your most recent backup needs to be performed if the

computer has a virus attack or if any major system components fail. In order to
correct computer issues, a recovery should first be attempted before a system
restore is attempted.

You can back up your information to an optional external hard drive, a network
drive, or discs. Back up your system at the following times:

66 Chapter 7 Backup and recovery

●

At regularly scheduled times

TIP: Set reminders to back up your information periodically.

●

Before the computer is repaired or restored

●

Before you add or modify hardware or software

Guidelines:

●

Create system restore points using the Windows® System Restore feature,
and periodically copy them to an optical disc or an external hard drive. For
more information on using system restore points, refer to

Using Windows

system restore points on page 68.

●

Store personal files in the Documents library and back up this folder
periodically.

●

Save customized settings in a window, toolbar, or menu bar by taking a
screen shot of your settings. The screen shot can be a time-saver if you
have to re-enter your preferences.

To create a screen shot:

1. Display the screen you want to save.

2. Copy the screen image:

To copy only the active window, press alt+prt sc.

To copy the entire screen, press prt sc.

3. Open a word-processing document, and then select Edit > Paste. The

screen image is added to the document.

4. Save and print the document.

Backing up and recovering your information

67

Using Windows Backup and Restore

Guidelines:

● Be sure that the computer is connected to AC power before you start the

backup process.

●

Allow enough time to complete the backup process. Depending on file sizes,
it may take over an hour.

To create a backup:

1. Select Start > Control Panel > System and Security > Backup and

Restore.

2. Follow the on-screen instructions to schedule and create a backup.

NOTE: Windows® includes the User Account Control feature to improve the

security of the computer. You may be prompted for your permission or password
for tasks such as installing software, running utilities, or changing Windows
settings. Refer to Help and Support for more information.

Using Windows system restore points

A system restore point allows you to save and name a snapshot of your hard
drive at a specific point in time. You can then recover back to that point if you
want to reverse subsequent changes.

NOTE: Recovering to an earlier restore point does not affect data files saved or

e-mails created since the last restore point.

You also can create additional restore points to provide increased protection for
your files and settings.

When to create restore points

●

Before you add or modify software or hardware

●

Periodically, whenever the computer is functioning optimally

NOTE: If you revert to a restore point and then change your mind, you can

reverse the restoration.

68 Chapter 7 Backup and recovery

Create a system restore point

1. Select Start > Control Panel > System and Security > System.

2. In the left pane, click System Protection.

3. Click the System Protection tab.

4. Follow the on-screen instructions.

Restore to a previous date and time

To revert to a restore point (created at a previous date and time), when the
computer was functioning optimally, follow these steps:

1. Select Start > Control Panel > System and Security > System.

2. In the left pane, click System Protection.

3. Click the System Protection tab.

4. Click System Restore.

5. Follow the on-screen instructions.

Backing up and recovering your information

69

8 Customer support

The following sections are included in this chapter:

●

Contacting customer support

●

Labels

Contacting customer support

If the information provided in this user guide, in the HP Notebook Reference
Guide, or in Help and Support does not address your questions, you can contact

HP Customer Support at:

http://www.hp.com/go/contactHP

NOTE: For worldwide support, click Contact HP worldwide on the left side of

the page, or go to

http://welcome.hp.com/country/us/en/wwcontact_us.html.

Here you can:

● Chat online with an HP technician.

NOTE: When technical support chat is not available in a particular

language, it is available in English.

●

E-mail HP Customer Support.

●

Find HP Customer Support worldwide telephone numbers.

●

Locate an HP service center.

70 Chapter 8 Customer support

Labels

The labels affixed to the computer provide information you may need when you
troubleshoot system problems or travel internationally with the computer:

●

Serial number label—Provides important information, including the following:

Component

(1) Product name

(2) Serial number (s/n)

(3) Part number/Product number (p/n)

(4) Warranty period

(5) Model description

Have this information available when you contact technical support. The
serial number label is affixed inside the battery bay.

● Microsoft® Certificate of Authenticity—Contains the Windows Product Key.

You may need the Product Key to update or troubleshoot the operating
system. The Microsoft Certificate of Authenticity is located on the bottom of
the computer.

●

Regulatory label—Provides regulatory information about the computer. The
regulatory label is affixed inside the battery bay.

● Wireless certification label or labels (select models only)—Provide

information about optional wireless devices and the approval markings of
some of the countries or regions in which the devices have been approved
for use. If your computer model includes one or more wireless devices, one
or more certification labels are included with your computer. You may need
this information when traveling internationally. Wireless certification labels
are affixed inside the battery bay.

Labels

71

9 Specifications

●

Input power

●

Operating environment

Input power

The power information in this section may be helpful if you plan to travel
internationally with the computer.

The computer operates on DC power, which can be supplied by an AC or a DC
power source. The AC power source must be rated at 100–240 V, 50–60 Hz.
Although the computer can be powered from a standalone DC power source, it
should be powered only with an AC adapter or a DC power source supplied and
approved by HP for use with this computer.

The computer can operate on DC power within the following specifications.

Input power Rating

Operating voltage and current 19.5 V dc @ 6.5 A - 120 W

DC plug of external HP power supply

NOTE: This product is designed for IT power systems in Norway with phase-to-

phase voltage not exceeding 240 V rms.

NOTE: The computer operating voltage and current can be found on the

system regulatory label.

Operating environment

Factor Metric U.S.

Temperature

Operating (writing to optical

disc)

5°C to 35°C 41°F to 95°F

Nonoperating -20°C to 60°C -4°F to 140°F

Relative humidity (noncondensing)

72 Chapter 9 Specifications

Operating 10% to 90% 10% to 90%

Nonoperating 5% to 95% 5% to 95%

Maximum altitude (unpressurized)

Operating -15 m to 3,048 m -50 ft to 10,000 ft

Nonoperating -15 m to 12,192 m -50 ft to 40,000 ft

Operating environment

73

A RAID 0 (select models only)

Select computer models with two hard drives ship in a RAID 0 configuration. RAID benefits
users who frequently work with large files and want to improve the storage performance of
their computer. With RAID 0, data is distributed across both drives. This allows data,
especially large files, to be read faster, because data is read simultaneously from both
drives. However, RAID 0 offers no fault tolerance, which means that the entire array fails if
one drive fails.

To enhance the write performance of RAID 0, Intel® Rapid Storage Technology has
implemented a volume write-back cache. The volume write-back cache allows writes to be
buffered and improves coalescing. The cache is enabled by default and can be disabled or
reenabled in Intel Rapid Storage Technology. An Uninterrupted Power Supply (UPS) is
recommended for use if the cache is enabled.

Disabling RAID 0

CAUTION:

Disabling RAID 0 completely erases hard drive contents and reformats the
hard drive. All files you have created and any software installed on the computer are
permanently removed. Before you disable RAID 0, be sure to back up your information and
create a set of recovery discs. Refer to

Backup and recovery on page 63 for additional

information.

To disable RAID 0:

1. Create a set of recovery discs. The hard drive contents will be completely erased after

disabling RAID 0. Refer to

Backup and recovery on page 63 for more information.

For a full image recovery, be sure that you have the service recovery discs. For a
minimized factory image recovery, be sure that you have the set of recovery discs you
created with Recovery Manager.

NOTE:

Make sure that you back up all personal files. Software not provided with
this computer must be downloaded from the manufacturer's Web site or reinstalled
from the disc provided by the manufacturer.

2. Turn on or restart the computer. While the “Press the ESC key for Startup Menu”

message is displayed in the lower-left corner of the screen, press esc. When the
Startup Menu is displayed, press f10.

3. Use the arrow keys to select System Configuration, and then change RAID OROM

UI to enable.

4. Use the arrow keys to select Exit > Exit Saving Changes, and then click Yes to save

your change and restart the computer.

5. When the POST screen opens, press ctrl+I to enter the configuration utility.

6. In the Main menu, use the up or down arrow key to select 3. Reset Disks to Non-

RAID, and then press enter. The Reset RAID Data window is displayed.

7. Press the spacebar to select the first hard drive, and then press the down arrow key

and the spacebar to select the second hard drive.

74 Appendix A RAID 0 (select models only)

8. Press enter, and then press Y to confirm the selection.

CAUTION:

Once you confirm the selection, your hard drive contents are

completely erased and the hard drive is reformatted.

9. Use the down arrow key to select 5. Exit.

10. Press enter, and then press Y. You will see the "No bootable device" message

displayed on the screen.

11. Insert the first service recovery disc or the first recovery disc you created, and then

reboot the computer.

12. Press F9 for the boot option menu, and then select Internal CD/DVD ROM Drive as

the boot device.

13. If you used the set of service recovery discs, follow the on-screen instructions to

complete the recovery.

-or-

If you used the set of recovery discs you created, select Minimized System Recovery,
and then follow the on-screen instructions to complete the recovery.

Disabling RAID 0

75

Index

Symbols/Numerics

3D Active Shutter Glasses

battery compartment 15
caring 19
cleaning 21
handling 22
identifying 14
nose pieces 15, 19
replacing the battery 20
turning on and off 15
using 14

3D Cinema Technology 2

3D games 23
effective range 23
flickering 23
frequently asked questions 22
safety information 11
using 15
watching content 17

3D games, playing 17

A

action keys

adjusting volume 41
Help and Support 40
identifying 29
keyboard backlight 41
muting speaker sound 41
screen brightness down 40
screen brightness up 40
switching screen image 41
using 40

wireless 41
AMD Catalyst Control Center 6
AMD Eyefinity 5
audio-in (microphone) jack, identifying 33
audio-out (headphone) jack, identifying 33

B

backing up

customized window, toolbar, and menu bar

settings 67

personal files 67
bass settings hotkey 42
battery bay 71
battery bay, identifying 36
battery light 31
battery release latch 36
battery, replacing 50

bays

battery 36, 71

hard drive 36
Beats Audio 3, 42
Bluetooth label 71
buttons 28

left TouchPad 26

right TouchPad 26

C

caps lock light, identifying 26
Certificate of Authenticity label 71
components

bottom 35

display 34

front 30

left-side 32

right-side 31

top 25
connector, power 31
CyberLink PowerDVD 13, 17

D

DC plug of external HP power supply 72
Digital Media Slot, identifying 31
display image, switching 41
drives, hard 54

E

eSATA port, identifying 32
esc key, identifying 29
external monitor port, identifying 32
Eyefinity 5

F

f11 65
flicking TouchPad gesture 49
fn key, identifying 29, 42

G

games, 3D 17
graphics modes, switching 4

H

hard drive

installing 54

removing 52
hard drive bay, identifying 36
hard drive light 30

76 Index

HDMI port, identifying 32
headphone (audio-out) jack 33
Help and Support key 40
hotkeys

bass settings 42
description 42
display system information 42
using 42

HP Recovery Manager 64

I

input power 72
integrated numeric keypad, identifying 29, 43
integrated webcam light, identifying 34
internal display switch, identifying 35
internal microphones, identifying 34
Internet connection setup 39
IR emitters, identifying 34
ISP, using 37

J

jacks

audio-in (microphone) 33
audio-out (headphone) 33
RJ-45 (network) 32

K

keyboard backlight action key 41
keyboard hotkeys, identifying 42
keypad, integrated 29, 43
keys

action 29
esc 29
fn 29
optical drive eject 29
Windows applications 29
Windows logo 29

L

labels

Bluetooth 71
Microsoft Certificate of Authenticity 71
regulatory 71
serial number 71
wireless certification 71

WLAN 71
latch, battery release 36
lights

battery 31

caps lock 26

hard drive 30

mute 27

power 27, 30

TouchPad 25, 26
webcam 34
wireless 27

M

memory module

inserting 58
removing 57
replacing 55

memory module compartment cover

removing 57

replacing 59
memory module compartment, identifying 36
microphone (audio-in) jack, identifying 33
Microsoft Certificate of Authenticity label 71
Mini DisplayPort, identifying 32
mouse, external

setting preferences 43
mute key, identifying 41
mute light, identifying 27

N

network jack, identifying 32
nose pieces

identifying 15

using 19

O

operating environment 72
operating system

Microsoft Certificate of Authenticity label 71

Product Key 71
optical drive eject key, identifying 29
optical drive, identifying 31

P

photosensitive epileptic seizures 11
pinching TouchPad gesture 47
pointing devices, setting preferences 43
ports

eSATA 32

external monitor 32

HDMI 32

SuperSpeed USB 32

USB 31
power button, identifying 28
power connector, identifying 31
power lights, identifying 27, 30
Product Key 71
product name and number, computer 71

Index

77

R

RAID 0 74
recovering from the dedicated recovery partition 65
recovering from the recovery discs 66
recovery discs 63
recovery, system 64
regulatory information

regulatory label 71

wireless certification labels 71
restore points 68
RJ-45 (network) jack, identifying 32
rotating TouchPad gesture 48

S

safety information, 3D 11
screen brightness keys 40
screen image, switching 41
scrolling TouchPad gesture 47
security cable slot, identifying 31
serial number label 71
serial number, computer 71
setup of WLAN 39
single large surface 5
slots

Digital Media 31

security cable 31
speakers, identifying 30
stereoscopic vision 13
subwoofer, identifying 35
SuperSpeed USB port, identifying 32
supported discs 64
switchable graphics 4
system information hotkey 42
system recovery 64
system restore points 68

T

TouchPad

buttons 26

using 44
TouchPad gestures

flicking 49

pinching 47

rotating 48

scrolling 47

zooming 47
TouchPad light 25, 26
TouchPad zone, identifying 26
traveling with the computer 71
TriDef 3D Experience Ignition Game Player 17
troubleshooting

3D 22

3D games 23

cannot see 3D content 22
flickering 23
supported 3D formats 22

U

USB ports, identifying 31
using system restore 68

V

vents, identifying 32, 36
volume keys, identifying 41

W

webcam light, identifying 34
webcam, identifying 34
Windows applications key, identifying 29
Windows logo key, identifying 29
wireless certification label 71
wireless key, identifying 41
wireless light 27
wireless network (WLAN), equipment needed 39
wireless network, connecting 38
wireless router, configuring 39
wireless setup 39
WLAN

connecting 38

protecting 39
WLAN antennas, identifying 34
WLAN device 71
WLAN label 71

Z

zooming TouchPad gesture 47

78 Index
