HP E3800 Access Security Manual

Download

HP Switch Software

E3800 switches

Software version KA.15.03 September 201 1

Access Security Guide

HP Networking E3800 Switches

Access Security Guide

September 2011

KA.15.03

This document contains proprietary information, which is protected by copyright. No part of this document may be photocopied, reproduced, or translated into another language without the prior written consent of HewlettPackard.

Publication Number

5998-2707 September 2011

Applicable Products

HP E3800-24G-PoE+-2SFP+ Switch J9573A

HP E3800-48G-PoE+-4SFP+ Switch J9574A

HP E3800-24G-2SFP+ Switch J9575A

HP E3800-48G-4SFP+ Switch J9576A

HP E3800-24GS-2XG tl Switch J9

800-24G-2XGT tl Switch J9

E3800-48G-4XGT tl Switch J9

HP E3800-24G-2XGT-PoE+ tl Switch J9

HP E3800-48G-4XGT-PoE+ tl Switch J9

HP E3800 4-port Stacking

Module J9577A

584A

585A

586A

587A

588A

Disclaimer

The information contained in this document is subject to change without notice.

HEWLETT-PACKARD COMPANY MAKES NO WARRANTY OF ANY KIND WITH REGARD TO THIS MATERIAL, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Hewlett-Packard shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.

The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

Hewlett-Packard assumes no responsibility for the use or reliability of its software on equipment that is not furnished by Hewlett-Packard.

Software End User License Agreement and Hardware Limited Warranty

For the software end user license agreement and the hardware limited warranty information for HP Networking products, visit www.hp.com/networking/support.

Trademark Credits

Microsoft, Windows, and Microsoft Windows NT are US registered trademarks of Microsoft Corporation. Java™ is a US trademark of Sun Microsystems, Inc.

Hewlett-Packard Company 8000 Foothills Boulevard, m/s 5551 Roseville, California 95747-5551 www.hp.com

Product Documentation

About Your Switch Manual Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxi

Printed Publications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxi

Electronic Publications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxi

Software Feature Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xxiii

1 Security Overview

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

About This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

For More Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

Access Security Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Network Security Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7

Getting Started with Access Security . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10

Physical Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10

Quick Start: Using the Management Interface Wizard . . . . . . . . . . . . 1-11

CLI: Management Interface Wizard . . . . . . . . . . . . . . . . . . . . . . . . 1-12

WebAgent: Management Interface Wizard . . . . . . . . . . . . . . . . . . 1-13

SNMP Security Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-14

Precedence of Security Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-16

Precedence of Port-Based Security Options . . . . . . . . . . . . . . . . . . . . 1-16

Precedence of Client-Based Authentication:

Dynamic Configuration Arbiter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-16

Network Immunity Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-17

Arbitrating Client-Specific Attributes . . . . . . . . . . . . . . . . . . . . . . 1-18

HP Identity-Driven Manager (IDM) . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-20

iii

2 Configuring Username and Password Security

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Configuring Local Password Security . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4

Menu: Setting Passwords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4

CLI: Setting Passwords and Usernames . . . . . . . . . . . . . . . . . . . . . . . . . 2-6

WebAgent: Setting Passwords and Usernames . . . . . . . . . . . . . . . . . . . 2-9

Saving Security Credentials in a Config File . . . . . . . . . . . . . . . . . . . 2-10

Benefits of Saving Security Credentials . . . . . . . . . . . . . . . . . . . . . . . . 2-10

Enabling the Storage and Display of Security Credentials . . . . . . . . 2-11

Security Settings that Can Be Saved . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12

Local Manager and Operator Passwords . . . . . . . . . . . . . . . . . . . . . . . 2-12

Password Command Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13

SNMP Security Credentials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14

802.1X Port-Access Credentials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-15

TACACS+ Encryption Key Authentication . . . . . . . . . . . . . . . . . . . . . 2-15

RADIUS Shared-Secret Key Authentication . . . . . . . . . . . . . . . . . . . . 2-16

SSH Client Public-Key Authentication . . . . . . . . . . . . . . . . . . . . . . . . . 2-16

Operating Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-19

Restrictions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-21

Front-Panel Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-23

When Security Is Important . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-23

Front-Panel Button Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-24

Clear Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-24

Reset Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-25

Restoring the Factory Default Configuration . . . . . . . . . . . . . . . . 2-25

Configuring Front-Panel Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-26

Disabling the Clear Password Function of the Clear Button . . . 2-29 Re-Enabling the Clear Button and Setting or

Changing the “Reset-On-Clear” Operation . . . . . . . . . . . . . . . . . . 2-30

Changing the Operation of the Reset+Clear Combination . . . . . 2-31

Password Recovery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-32

Disabling or Re-Enabling the Password Recovery Process . . . . . . . . 2-32

Password Recovery Process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-34

3 Virus Throttling (Connection-Rate Filtering)

Overview of Connection-Rate Filtering . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

Features and Benefits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2

General Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3

Filtering Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3

Sensitivity to Connection Rate Detection . . . . . . . . . . . . . . . . . . . . 3-4

Application Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4

Operating Rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6

Unblocking a Currently Blocked Host . . . . . . . . . . . . . . . . . . . . . . 3-6

General Configuration Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7

For a network that is relatively attack-free: . . . . . . . . . . . . . . . . . . . . . 3-7

For a network that appears to be under significant attack: . . . . . . . . . 3-8

Configuring Connection-Rate Filtering . . . . . . . . . . . . . . . . . . . . . . . . . 3-9

Global and Per-Port Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9

Enabling Connection-Rate Filtering and Configuring

Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10

Configuring the Per-Port Filtering Mode . . . . . . . . . . . . . . . . . . . 3-11

Example of a Basic Connection-Rate Filtering Configuration . . 3-12

Viewing and Managing Connection-Rate Status . . . . . . . . . . . . . . . . . 3-14

Viewing Connection-Rate Configuration . . . . . . . . . . . . . . . . . . . 3-14

Listing Currently-Blocked Hosts . . . . . . . . . . . . . . . . . . . . . . . . . . 3-15

Unblocking Currently-Blocked Hosts . . . . . . . . . . . . . . . . . . . . . . 3-15

Configuring and Applying Connection-Rate ACLs . . . . . . . . . . . . . . 3-17

Connection-Rate ACL Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-18

Configuring a Connection-Rate ACL Using

Source IP Address Criteria . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-19

Configuring a Connection-Rate ACL Using UDP/TCP Criteria . . . . . 3-21

Applying Connection-Rate ACLs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-24

Using CIDR Notation To Enter the ACE Mask . . . . . . . . . . . . . . . . . . 3-24

Example of Using an ACL in a Connection-Rate Configuration . . . . 3-25

Connection-Rate ACL Operating Notes . . . . . . . . . . . . . . . . . . . . . . . . 3-27

4 Web and MAC Authentication

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

Web Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2

MAC Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2

Concurrent Web and MAC Authentication . . . . . . . . . . . . . . . . . . . . . . 4-3

Authorized and Unauthorized Client VLANs . . . . . . . . . . . . . . . . . . . . . 4-3

RADIUS-Based Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4

Wireless Clients . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4

How Web and MAC Authentication Operate . . . . . . . . . . . . . . . . . . . . 4-5

Web-based Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5

MAC-based Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7

Terminology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9

Operating Rules and Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10

Setup Procedure for Web/MAC Authentication . . . . . . . . . . . . . . . . . 4-12

Before You Configure Web/MAC Authentication . . . . . . . . . . . . . . . . 4-12

Configuring the RADIUS Server To Support MAC Authentication . . 4-15

Configuring the Switch To Access a RADIUS Server . . . . . . . . . . . . . 4-15

Configuring Web Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-18

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-18

Configuration Commands for Web Authentication . . . . . . . . . . . . . . 4-19

Show Commands for Web Authentication . . . . . . . . . . . . . . . . . . . . . . 4-26

Customizing Web Authentication HTML Files (Optional) . . . . . . . 4-32

Implementing Customized Web-Auth Pages . . . . . . . . . . . . . . . . . . . . 4-32

Operating Notes and Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-32

Customizing HTML Templates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-33

Customizable HTML Templates . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-34

Configuring MAC Authentication on the Switch . . . . . . . . . . . . . . . . 4-48

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-48

Configuration Commands for MAC Authentication . . . . . . . . . . . . . . 4-49

Configuring the Global MAC Authentication Password . . . . . . . 4-49

Configuring a MAC-based Address Format . . . . . . . . . . . . . . . . . 4-51

Configuring Custom Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-54

Web Page Display of Access Denied Message . . . . . . . . . . . . . . . 4-56

HTTP Redirect When MAC Address Not Found . . . . . . . . . . . . . . . . . 4-59

How HTTP Redirect Works . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-60

Diagram of the Registration Process . . . . . . . . . . . . . . . . . . . . . . . 4-62

Using the Restrictive-Filter Option . . . . . . . . . . . . . . . . . . . . . . . . 4-63

Show Command Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-63

Reauthenticating a MAC-Auth Client . . . . . . . . . . . . . . . . . . . . . . . 4-63

Configuring the Registration Server URL . . . . . . . . . . . . . . . . . . . 4-64

Unconfiguring a MAC-Auth Registration Server . . . . . . . . . . . . . 4-64

Operating Notes for HTTP Redirect . . . . . . . . . . . . . . . . . . . . . . . 4-64

Show Commands for MAC-Based Authentication . . . . . . . . . . . . . . . 4-65

Client Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-71

5 TACACS+ Authentication

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1

Terminology Used in TACACS Applications: . . . . . . . . . . . . . . . . . . . . 5-2

General System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4

General Authentication Setup Procedure . . . . . . . . . . . . . . . . . . . . . . . 5-4

Configuring TACACS+ on the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7

Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7

CLI Commands Described in this Section . . . . . . . . . . . . . . . . . . . . . . . 5-8

Viewing the Switch’s Current Authentication Configuration . . . . . . . 5-8

Viewing the Switch’s Current TACACS+

Server Contact Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-9

Configuring the Switch’s Authentication Methods . . . . . . . . . . . . . . . 5-10

Using the Privilege-Mode Option for Login . . . . . . . . . . . . . . . . . 5-10

Authentication Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-12

Configuring the TACACS+ Server for Single Login . . . . . . . . . . . . . . 5-13

Configuring the Switch’s TACACS+ Server Access . . . . . . . . . . . . . . 5-17

How Authentication Operates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-24

General Authentication Process Using a TACACS+ Server . . . . . . . . 5-24

Local Authentication Process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-25

Using the Encryption Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-26

General Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-26

Encryption Options in the Switch . . . . . . . . . . . . . . . . . . . . . . . . . 5-27

vii

Controlling WebAgent Access When

Using TACACS+ Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-28

Messages Related to TACACS+ Operation . . . . . . . . . . . . . . . . . . . . . 5-29

Operating Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-30

6 RADIUS Authentication, Authorization, and Accounting

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1

Authentication Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1

Accounting Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2

RADIUS-Administered CoS and Rate-Limiting . . . . . . . . . . . . . . . . . . . 6-2

RADIUIS-Administered Commands Authorization . . . . . . . . . . . . . . . . 6-2

SNMP Access to the Switch’s Authentication Configuration MIB . . . 6-2

Terminology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3

Switch Operating Rules for RADIUS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4

General RADIUS Setup Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5

Configuring the Switch for RADIUS Authentication . . . . . . . . . . . . . 6-6

Outline of the Steps for Configuring RADIUS Authentication . . . . . . 6-8

1. Configure Authentication for the Access Methods

You Want RADIUS To Protect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-9

2. Enable the (Optional) Access Privilege Option . . . . . . . . . . . . . . . . 6-12

3. Configure the Switch To Access a RADIUS Server . . . . . . . . . . . . 6-14

4. Configure the Switch’s Global RADIUS Parameters . . . . . . . . . . . 6-17

Using Multiple RADIUS Server Groups . . . . . . . . . . . . . . . . . . . . . . . . 6-21

Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-21

Enhanced Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-22

Displaying the RADIUS Server Group Information . . . . . . . . . . . 6-24

viii

Cached Reauthentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-26

Timing Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-27

Using SNMP To View and Configure

Switch Authentication Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-30

Changing and Viewing the SNMP Access Configuration . . . . . . . . . . 6-31

Local Authentication Process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-34

Controlling WebAgent Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-35

Commands Authorization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-36

Enabling Authorization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-37

Displaying Authorization Information . . . . . . . . . . . . . . . . . . . . . . . . . 6-38

Configuring Commands Authorization on a RADIUS Server . . . . . . 6-38

Using Vendor Specific Attributes (VSAs) . . . . . . . . . . . . . . . . . . . 6-38

Example Configuration on Cisco Secure ACS for MS Windows 6-40

Example Configuration Using FreeRADIUS . . . . . . . . . . . . . . . . . 6-43

VLAN Assignment in an Authentication Session . . . . . . . . . . . . . . . . 6-44

Tagged and Untagged VLAN Attributes . . . . . . . . . . . . . . . . . . . . . . . . 6-44

Additional RADIUS Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-45

Accounting Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-48

Accounting Service Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-48

Operating Rules for RADIUS Accounting . . . . . . . . . . . . . . . . . . . . . . 6-49

Acct-Session-ID Options in a Management Session . . . . . . . . . . . . . . 6-50

Unique Acct-Session-ID Operation . . . . . . . . . . . . . . . . . . . . . . . . 6-50

Common Acct-Session-ID Operation . . . . . . . . . . . . . . . . . . . . . . . 6-52

Configuring RADIUS Accounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-53

Steps for Configuring RADIUS Accounting . . . . . . . . . . . . . . . . . . . . . 6-53

1. Configure the Switch To Access a RADIUS Server . . . . . . . . . 6-54

2. (Optional) Reconfigure the Acct-Session-ID Operation . . . . . 6-56

3. Configure Accounting Types and the Controls for Sending

Reports to the RADIUS Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-57

4. (Optional) Configure Session Blocking and Interim

Updating Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-61

Viewing RADIUS Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-62

General RADIUS Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-62

RADIUS Authentication Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-64

RADIUS Accounting Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-66

Changing RADIUS-Server Access Order . . . . . . . . . . . . . . . . . . . . . . . 6-67

Dynamic Removal of Authentication

Limits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-70

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-70

Configuring the RADIUS VSAs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-70

Displaying the Port-access Information . . . . . . . . . . . . . . . . . . . . . . . . 6-72

Operating Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-73

7 Configuring RADIUS Server Support for Switch Services

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1

RADIUS Client and Server Requirements . . . . . . . . . . . . . . . . . . . . 7-1

Optional PCM and IDM Network Management Applications . . . . 7-2

RADIUS Server Configuration for CoS

(802.1p Priority) and Rate-Limiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3

Applied Rates for RADIUS-Assigned Rate Limits . . . . . . . . . . . . . . . . . 7-5

Viewing the Currently Active Per-Port CoS and Rate-Limiting

Configuration Specified by a RADIUS Server . . . . . . . . . . . . . . . . . . . . 7-7

Configuring and Using Dynamic

(RADIUS-Assigned) Access Control Lists . . . . . . . . . . . . . . . . . . . . . . 7-11

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-11

Terminology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-11

Overview of RADIUS-Assigned, Dynamic ACLs . . . . . . . . . . . . . . . . . 7-14

Traffic Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-14

Contrasting RADIUS-Assigned and Static ACLs . . . . . . . . . . . . . . . . . 7-16

How a RADIUS Server Applies a RADIUS-Assigned ACL

to a Client on a Switch Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-18

General ACL Features, Planning, and Configuration . . . . . . . . . . . . . 7-19

The Packet-filtering Process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-20

Operating Rules for RADIUS-Assigned ACLs . . . . . . . . . . . . . . . . . . . 7-20

Configuring an ACL in a RADIUS Server . . . . . . . . . . . . . . . . . . . . . . . 7-22

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-22

Nas-Filter-Rule-Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-23

ACE Syntax in RADIUS Servers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-25

Example Using the Standard Attribute (92) In an IPv4 ACL . . . 7-27

Example Using HP VSA 63 To Assign IPv6 and/or IPv4 ACLs . . 7-29

Example Using HP VSA 61 To Assign IPv4 ACLs . . . . . . . . . . . . 7-32

To configure the above ACL, you would enter the username/

password and ACE information shown in figure 7-11 into the

FreeRADIUS “users” file. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-33

Configuration Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-34

Configuring the Switch To Support RADIUS-Assigned

ACLs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-35

Displaying the Current RADIUS-Assigned ACL Activity

on the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-37

Event Log Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-42

Causes of Client Deauthentication Immediately

After Authenticating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-42

Monitoring Shared Resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-42

8 Configuring Secure Shell (SSH)

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1

Terminology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-3

Prerequisite for Using SSH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-4

Public Key Formats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-4

Steps for Configuring and Using SSH

for Switch and Client Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-5

General Operating Rules and Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-7

Configuring the Switch for SSH Operation . . . . . . . . . . . . . . . . . . . . . . 8-8

1. Assigning a Local Login (Operator) and

Enable (Manager) Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9

2. Generating the Switch’s Public and Private Key Pair . . . . . . . . . . . 8-9

Configuring Key Lengths . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-12

3. Providing the Switch’s Public Key to Clients . . . . . . . . . . . . . . . . . . 8-12

4. Enabling SSH on the Switch and Anticipating SSH

Client Contact Behavior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-15

5. Configuring the Switch for SSH Authentication . . . . . . . . . . . . . . . 8-20

6. Use an SSH Client To Access the Switch . . . . . . . . . . . . . . . . . . . . . 8-24

Further Information on SSH Client Public-Key Authentication . 8-25

Messages Related to SSH Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-31

Logging Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-31

Debug Logging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-31

9 Configuring Secure Socket Layer (SSL)

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-1

Terminology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-2

Prerequisite for Using SSL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-4

Steps for Configuring and Using SSL for Switch and Client

Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-4

General Operating Rules and Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-5

Configuring the Switch for SSL Operation . . . . . . . . . . . . . . . . . . . . . . 9-6

1. Assigning a Local Login (Operator) and

Enabling (Manager) Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-6

2. Generating the Switch’s Server Host Certificate . . . . . . . . . . . . . . . 9-6

To Generate or Erase the Switch’s Server Certificate

with the CLI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-7

Comments on Certificate Fields. . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-8

Generate a Self-Signed Host Certificate with the WebAgent . . . 9-10

Generate a CA-Signed server host certificate with the

WebAgent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-11

3. Enabling SSL on the Switch and Anticipating SSL

Browser Contact Behavior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-13

Using the CLI Interface to Enable SSL . . . . . . . . . . . . . . . . . . . . . 9-14

Using the WebAgent to Enable SSL . . . . . . . . . . . . . . . . . . . . . . . . 9-14

Common Errors in SSL Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-16

10 IPv4 Access Control Lists (ACLs)

xii

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-1

Overview of Options for Applying IPv4 ACLs on the Switch . . . . . 10-3

Static ACLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-3

RADIUS-Assigned ACLs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-3

Command Summary for Standard IPv4 ACLs . . . . . . . . . . . . . . . . . . . 10-5

Command Summary for IPv4 Extended ACLs . . . . . . . . . . . . . . . . . . 10-6

Command Summary for Enabling, Disabling, and

Displaying ACLs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-7

Terminology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-8

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-13

Types of IPv4 ACLs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-13

ACL Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-13

RACL Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-14

VACL Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-16

Static Port ACL and RADIUS-Assigned ACL Applications . . . . 10-16

RADIUS-Assigned (Dynamic) Port ACL Applications . . . . . . . . 10-17

Multiple ACLs on an Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-19

Features Common to All ACL Applications . . . . . . . . . . . . . . . . . . . . 10-22

General Steps for Planning and Configuring ACLs . . . . . . . . . . . . . . 10-23

IPv4 Static ACL Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-25

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-25

The Packet-filtering Process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-26

Planning an ACL Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-29

IPv4 Traffic Management and Improved Network Performance . . 10-29

Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-31

Guidelines for Planning the Structure of a Static ACL . . . . . . . . . . . 10-31

IPv4 ACL Configuration and Operating Rules . . . . . . . . . . . . . . . . . . 10-32

How an ACE Uses a Mask To Screen Packets for Matches . . . . . . . 10-35

What Is the Difference Between Network (or Subnet)

Masks and the Masks Used with ACLs? . . . . . . . . . . . . . . . . . . . 10-35

Rules for Defining a Match Between a Packet and an

Access Control Entry (ACE) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-36

Configuring and Assigning an IPv4 ACL . . . . . . . . . . . . . . . . . . . . . . 10-40

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-40

General Steps for Implementing ACLs . . . . . . . . . . . . . . . . . . . . 10-40

Options for Permit/Deny Policies . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-41

ACL Configuration Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-41

Standard ACL Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-42

Extended ACL Configuration Structure . . . . . . . . . . . . . . . . . . . 10-43

ACL Configuration Factors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-45

The Sequence of Entries in an ACL Is Significant . . . . . . . . . . . 10-45

Allowing for the Implied Deny Function . . . . . . . . . . . . . . . . . . . 10-47

A Configured ACL Has No Effect Until You Apply It

to an Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-47

You Can Assign an ACL Name or Number to an Interface

Even if the ACL Does Not Exist in the Switch’s Configuration 10-47

Using the CLI To Create an ACL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-48

General ACE Rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-48

Using CIDR Notation To Enter the IPv4 ACL Mask . . . . . . . . . 10-49

xiii

Configuring Standard ACLs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-50

Command Summary for Standard ACLs . . . . . . . . . . . . . . . . . . . . . . 10-50

Configuring Named, Standard ACLs . . . . . . . . . . . . . . . . . . . . . . 10-52

Creating Numbered, Standard ACLs . . . . . . . . . . . . . . . . . . . . . . 10-55

Configuring Extended ACLs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-59

Command Summary for Extended ACLs . . . . . . . . . . . . . . . . . . . . . . 10-59

Configuring Named, Extended ACLs . . . . . . . . . . . . . . . . . . . . . . 10-61

Configuring Numbered, Extended ACLs . . . . . . . . . . . . . . . . . . . 10-74

Adding or Removing an ACL Assignment On an Interface . . . . . . 10-81

Filtering Routed IPv4 Traffic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-81

Filtering IPv4 Traffic Inbound on a VLAN . . . . . . . . . . . . . . . . . . . . . 10-82

Filtering Inbound IPv4 Traffic Per Port . . . . . . . . . . . . . . . . . . . . . . . 10-83

Deleting an ACL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-85

Editing an Existing ACL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-86

Using the CLI To Edit ACLs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-86

General Editing Rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-86

Sequence Numbering in ACLs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-87

Inserting an ACE in an Existing ACL . . . . . . . . . . . . . . . . . . . . . . 10-88

Deleting an ACE from an Existing ACL . . . . . . . . . . . . . . . . . . . 10-90

Resequencing the ACEs in an ACL . . . . . . . . . . . . . . . . . . . . . . . 10-91

Attaching a Remark to an ACE . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-92

Operating Notes for Remarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-95

xiv

Displaying ACL Configuration Data . . . . . . . . . . . . . . . . . . . . . . . . . . 10-97

Display an ACL Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-98

Display the Content of All ACLs on the Switch . . . . . . . . . . . . . . . . . 10-99

Display the RACL and VACL Assignments for a VLAN . . . . . . . . . 10-100

Display Static Port (and Trunk) ACL Assignments . . . . . . . . . . . . . 10-101

Displaying the Content of a Specific ACL . . . . . . . . . . . . . . . . . . . . 10-103

Display All ACLs and Their Assignments in the Routing

Switch Startup-Config File and Running-Config File . . . . . . . . . . . 10-106

Creating or Editing ACLs Offline . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-107

Creating or Editing an ACL Offline . . . . . . . . . . . . . . . . . . . . . . . . . . 10-107

The Offline Process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-107

Example of Using the Offline Process . . . . . . . . . . . . . . . . . . . . 10-108

Enable ACL “Deny” Logging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-112

Requirements for Using ACL Logging . . . . . . . . . . . . . . . . . . . . . . . . 10-112

ACL Logging Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-113

Enabling ACL Logging on the Switch . . . . . . . . . . . . . . . . . . . . . . . . 10-114

Configuring the Logging Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-116

Monitoring Static ACL Performance . . . . . . . . . . . . . . . . . . . . . . . . . 10-117

Example of ACL Performance Monitoring . . . . . . . . . . . . . . . . 10-119

Example of Resetting ACE Hit Counters to Zero . . . . . . . . . . . 10-121

IPv6 Counter Operation with Multiple Interface Assignments 10-122

IPv4 Counter Operation with Multiple Interface Assignments 10-123

General ACL Operating Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-128

11 Configuring Advanced Threat Protection

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-1

DHCP Snooping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-2

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-3

Enabling DHCP Snooping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-4

Enabling DHCP Snooping on VLANS . . . . . . . . . . . . . . . . . . . . . . . . . . 11-6

Configuring DHCP Snooping Trusted Ports . . . . . . . . . . . . . . . . . . . . 11-6

Configuring Authorized Server Addresses . . . . . . . . . . . . . . . . . . . . . . 11-7

Using DHCP Snooping with Option 82 . . . . . . . . . . . . . . . . . . . . . . . . . 11-8

Changing the Remote-id from a MAC to an IP Address . . . . . . 11-10

Disabling the MAC Address Check . . . . . . . . . . . . . . . . . . . . . . . 11-10

The DHCP Binding Database . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-11

Operational Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-12

Log Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-13

Dynamic ARP Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-15

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-15

Enabling Dynamic ARP Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-17

Configuring Trusted Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-17

Adding an IP-to-MAC Binding to the DHCP Database . . . . . . . . . . . 11-19

Configuring Additional Validation Checks on ARP Packets . . . . . . 11-20

Verifying the Configuration of Dynamic ARP Protection . . . . . . . . 11-20

Displaying ARP Packet Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-21

Monitoring Dynamic ARP Protection . . . . . . . . . . . . . . . . . . . . . . . . . 11-22

Dynamic IP Lockdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-22

Protection Against IP Source Address Spoofing . . . . . . . . . . . . . . . . 11-23

Prerequisite: DHCP Snooping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-23

Filtering IP and MAC Addresses Per-Port and Per-VLAN . . . . . . . . 11-24

Enabling Dynamic IP Lockdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-25

Operating Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-25

Adding an IP-to-MAC Binding to the DHCP Binding Database . . . . 11-27

Potential Issues with Bindings . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-27

Adding a Static Binding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-28

Verifying the Dynamic IP Lockdown Configuration . . . . . . . . . . . . . 11-28

Displaying the Static Configuration of IP-to-MAC Bindings . . . . . . 11-29

Debugging Dynamic IP Lockdown . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-30

Differences Between Switch Platforms . . . . . . . . . . . . . . . . . . . . . . . 11-31

Using the Instrumentation Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . 11-33

Operating Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-34

Configuring Instrumentation Monitor . . . . . . . . . . . . . . . . . . . . . . . . 11-35

Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-36

Viewing the Current Instrumentation Monitor Configuration . . . . . 11-37

xvi

12 Traffic/Security Filters and Monitors

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-1

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-2

Filter Limits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-2

Using Port Trunks with Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-2

Filter Types and Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-3

Source-Port Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-3

Operating Rules for Source-Port Filters . . . . . . . . . . . . . . . . . . . . 12-3

Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-4

Named Source-Port Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-5

Operating Rules for Named Source-Port Filters . . . . . . . . . . . . . 12-6

Defining and Configuring Named Source-Port Filters . . . . . . . . 12-6

Viewing a Named Source-Port Filter . . . . . . . . . . . . . . . . . . . . . . . 12-8

Using Named Source-Port Filters . . . . . . . . . . . . . . . . . . . . . . . . . 12-8

Static Multicast Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-14

Protocol Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-15

Configuring Traffic/Security Filters . . . . . . . . . . . . . . . . . . . . . . . . . . 12-16

Configuring a Source-Port Traffic Filter . . . . . . . . . . . . . . . . . . . . . . 12-17

Example of Creating a Source-Port Filter . . . . . . . . . . . . . . . . . . 12-18

Configuring a Filter on a Port Trunk . . . . . . . . . . . . . . . . . . . . . . 12-18

Editing a Source-Port Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-19

Configuring a Multicast or Protocol Traffic Filter . . . . . . . . . . . . . . 12-20

Filter Indexing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-21

Displaying Traffic/Security Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-22

13 Configuring Port-Based and

User-Based Access Control (802.1X)

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-1

Why Use Port-Based or User-Based Access Control? . . . . . . . . . . . . 13-1

General Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-1

User Authentication Methods . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-2

802.1X User-Based Access Control . . . . . . . . . . . . . . . . . . . . . . . . 13-3

802.1X Port-Based Access Control . . . . . . . . . . . . . . . . . . . . . . . . 13-3

Alternative To Using a RADIUS Server . . . . . . . . . . . . . . . . . . . . . 13-4

Accounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-4

Terminology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-4

General 802.1X Authenticator Operation . . . . . . . . . . . . . . . . . . . . . . 13-8

Example of the Authentication Process . . . . . . . . . . . . . . . . . . . . . . . . 13-8

VLAN Membership Priority . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-9

General Operating Rules and Notes . . . . . . . . . . . . . . . . . . . . . . . . . . 13-11

General Setup Procedure for 802.1X Access Control . . . . . . . . . . 13-13

Do These Steps Before You Configure 802.1X Operation . . . . . . . . 13-13

Overview: Configuring 802.1X Authentication on the Switch . . . . . 13-16

Configuring Switch Ports as 802.1X Authenticators . . . . . . . . . . . 13-17

1. Enable 802.1X Authentication on Selected Ports . . . . . . . . . . . . . 13-18

A. Enable the Selected Ports as Authenticators and Enable

the (Default) Port-Based Authentication . . . . . . . . . . . . . . . . . . 13-18

xvii

B. Specify User-Based Authentication or Return to

Port-Based Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-19

Example: Configuring User-Based 802.1X Authentication . . . . 13-20

Example: Configuring Port-Based 802.1X Authentication . . . . 13-20

2. Reconfigure Settings for Port-Access . . . . . . . . . . . . . . . . . . . . . . . 13-21

3. Configure the 802.1X Authentication Method . . . . . . . . . . . . . . . . 13-24

4. Enter the RADIUS Host IP Address(es) . . . . . . . . . . . . . . . . . . . . . 13-25

5. Enable 802.1X Authentication on the Switch . . . . . . . . . . . . . . . . 13-26

6. Optional: Reset Authenticator Operation . . . . . . . . . . . . . . . . . . . . 13-27

7. Optional: Configure 802.1X Controlled Directions . . . . . . . . . . . . 13-27

Wake-on-LAN Traffic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-28

Operating Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-29

Example: Configuring 802.1X Controlled Directions . . . . . . . . 13-29

Unauthenticated VLAN Access (Guest VLAN Access) . . . . . . . . . . . 13-29

Characteristics of Mixed Port Access Mode . . . . . . . . . . . . . . . . 13-30

Configuring Mixed Port Access Mode . . . . . . . . . . . . . . . . . . . . . 13-31

802.1X Open VLAN Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-32

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-32

VLAN Membership Priorities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-33

Use Models for 802.1X Open VLAN Modes . . . . . . . . . . . . . . . . . . . . 13-33

Operating Rules for Authorized-Client and

Unauthorized-Client VLANs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-39

Setting Up and Configuring 802.1X Open VLAN Mode . . . . . . . . . . . 13-43

802.1X Open VLAN Operating Notes . . . . . . . . . . . . . . . . . . . . . . . . . 13-48

xviii

Option For Authenticator Ports: Configure Port-Security

To Allow Only 802.1X-Authenticated Devices . . . . . . . . . . . . . . . . . 13-49

Port-Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-50

Configuring Switch Ports To Operate As

Supplicants for 802.1X Connections to Other Switches . . . . . . . . 13-51

Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-51

Supplicant Port Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-53

Displaying 802.1X Configuration, Statistics, and Counters . . . . 13-55

Show Commands for Port-Access Authenticator . . . . . . . . . . . . . . . 13-55

Viewing 802.1X Open VLAN Mode Status . . . . . . . . . . . . . . . . . . . . . 13-64

Show Commands for Port-Access Supplicant . . . . . . . . . . . . . . . . . . 13-68

How RADIUS/802.1X Authentication Affects VLAN Operation . 13-69

VLAN Assignment on a Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-70

Operating Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-70

Example of Untagged VLAN Assignment in a RADIUS-Based

Authentication Session . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-72

Enabling the Use of GVRP-Learned Dynamic VLANs

in Authentication Sessions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-75

14 Configuring and Monitoring Port Security

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-1

Port Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-2

Basic Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-2

Eavesdrop Prevention . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-3

Disabling Eavesdrop Prevention . . . . . . . . . . . . . . . . . . . . . . . . . . 14-3

Feature Interactions When Eavesdrop Prevention is Disabled . 14-4

MIB Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-5

Blocking Unauthorized Traffic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-5

Trunk Group Exclusion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-6

Planning Port Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-7

Port Security Command Options and Operation . . . . . . . . . . . . . . . . 14-8

Port Security Display Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-8

Configuring Port Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-12

Retention of Static Addresses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-17

MAC Lockdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-23

Differences Between MAC Lockdown and Port Security . . . . . . . . 14-24

MAC Lockdown Operating Notes . . . . . . . . . . . . . . . . . . . . . . . . 14-26

Deploying MAC Lockdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-27

MAC Lockout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-31

Port Security and MAC Lockout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-33

Reading Intrusion Alerts and Resetting Alert Flags . . . . . . . . . . . 14-34

Notice of Security Violations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-34

How the Intrusion Log Operates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-35

Keeping the Intrusion Log Current by Resetting Alert Flags . . . . . . 14-35

xix

CLI: Checking for Intrusions, Listing Intrusion Alerts,

and Resetting Alert Flags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-36

Using the Event Log To Find Intrusion Alerts . . . . . . . . . . . . . . . . . . 14-38

Operating Notes for Port Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-39

15 Using Authorized IP Managers

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-1

Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-3

Access Levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-3

Defining Authorized Management Stations . . . . . . . . . . . . . . . . . . . . 15-4

Overview of IP Mask Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-4

Menu: Viewing and Configuring IP Authorized Managers . . . . . . . . . 15-5

CLI: Viewing and Configuring Authorized IP Managers . . . . . . . . . . . 15-6

Listing the Switch’s Current Authorized IP Manager(s) . . . . . . . 15-6

Configuring IP Authorized Managers for the Switch . . . . . . . . . . 15-7

WebAgent: Configuring IP Authorized Managers . . . . . . . . . . . . . . . 15-9

Web Proxy Servers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-10

How to Eliminate the Web Proxy Server . . . . . . . . . . . . . . . . . . 15-10

Using a Web Proxy Server to Access the WebAgent . . . . . . . . . 15-10

Building IP Masks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-11

Configuring One Station Per Authorized Manager IP Entry . . . . . . 15-11

Configuring Multiple Stations Per Authorized Manager IP Entry . . 15-11

Additional Examples for Authorizing Multiple Stations . . . . . . . . . 15-13

Operating Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-14

16 Key Management System

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16-1

Terminology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16-1

Configuring Key Chain Management . . . . . . . . . . . . . . . . . . . . . . . . . . . 16-2

Creating and Deleting Key Chain Entries . . . . . . . . . . . . . . . . . . . . . . . 16-2

Assigning a Time-Independent Key to a Chain . . . . . . . . . . . . . . . . . . 16-3

Assigning Time-Dependent Keys to a Chain . . . . . . . . . . . . . . . . . . . . 16-5

Product Documentation

For the latest version of all HP switch documentation, including Release Notes covering recently added features, please visit the HP Networking Web site at www.hp.com/Networking/support

Electronic Publications

The latest version of each of the publications listed below is available in PDF format on the HP Web site, as described in the Note at the top of this page.

■ Installation and Getting Started Guide—Explains how to prepare and

perform the physical installation and connect the switch to your network.

■ Basic Operation Guide—Covers basic switch operating features, includ-

ing set-up, user interfaces, memory and configuration, interface access (including console operation), system information, and IP addressing.

■ Management and Configuration Guide—Describes how to configure,

manage, and monitor basic switch operation.

■ Advanced Traffic Management Guide—Explains how to configure traffic

management features such as VLANs, MSTP, QoS, and Meshing.

■ Multicast and Routing Guide—Explains how to configure IGMP, PIM, IP

routing, and VRRP features.

■ Access Security Guide—Explains how to configure access security fea-

tures and user authentication on the switch.

■ IPv6 Configuration Guide—Describes the IPv6 protocol operations that

are supported on the switch.

■ Command Line Interface Reference Guide—Provides a comprehensive

description of CLI commands, syntax, and operations.

■ Event Log Message Reference Guide—Provides a comprehensive descrip-

tion of event log messages.

■ Release Notes—Describe new features, fixes, and enhancements that

become available between revisions of the main product guide.

xxi

Software Feature Index

For the software manual set supporting your E3800 switch model, this feature index indicates which manual to consult for information on a given software feature.

Software Features Manual

Management

and

Configuration

Advanced

Traffic

Management

Multicast

and

Routing

Access

Security

Guide

IPv6

Configuration

Guide

802.1Q VLAN Tagging X

802.1X Port-Based Priority X

802.1X Multiple Authenticated Clients

Per Port

Access Control Lists (ACLs) X

Access Control Lists (ACLs) (IPv6) X

AAA Authentication X

Authorized IP Managers X

Authorized IP Managers (IPv6) X

Authorized Manager List (Web, Telnet,

TFTP)

Auto MDIX Configuration X

BOOTP X

Config File X

Console Access X

Basic

Operation

Guide

Copy Command X

Core Dump X

CoS (Class of Service) X

Debug X

DHCP Configuration X

DHCPv6 Relay X

DHCP Option 82 X

xxii

Software Features Manual

Management

and

Configuration

Advanced

Traffic

Management

Multicast

and

Routing

Access

Security

Guide

IPv6

Configuration

Guide

Basic

Operation

Guide

DHCP Snooping X

DHCP/Bootp Operation X

Diagnostic Tools X

Diagnostics and Troubleshooting (IPv6) X

Distributed Trunking X

Downloading Software X

Dynamic ARP Protection X

Dynamic Configuration Arbiter X

Dynamic IP Lockdown X

Eavesdrop Protection X

Equal Cost Multi-Path (ECMP) X

Event Log X

Factory Default Settings X

Flow Control (802.3x) X

File Management X

File Transfers X

Friendly Port Names X

Guaranteed Minimum Bandwidth (GMB) X

GVRP X

Identity-Driven Management (IDM) X

IGMP X

Interface Access (Telnet, Console/ Serial, Web)

IP Addressing X

IPv6 Addressing X

IP Preserve (IPv6) X

xxiii

Software Features Manual

Management

and

Configuration

Advanced

Traffic

Management

Multicast

and

Routing

Access

Security

Guide

IPv6

Configuration

Guide

IP Routing X

IPv6 Static Routing X

Jumbo Packets X

Key Management System (KMS) X

LACP X

LLDP X

LLDP-MED X

Loop Protection X

MAC Address Management X

MAC Lockdown X

MAC Lockout X

MAC-based Authentication X

Management VLAN X

Management Security (IPv6) X

Meshing X

Basic

Operation

Guide

MLD Snooping (IPv6) X

Monitoring and Analysis X

Multicast Filtering X

Multiple Configuration Files X

Network Management Applications

(SNMP)

Nonstop Switching (8200zl switches) X

Out-of-Band Management (OOBM) X

OpenView Device Management X

OSPFv2 (IPv4) X

OSPFv3 (IPv6) X

xxiv

Software Features Manual

Management

and

Configuration

Passwords and Password Clear

Advanced

Traffic

Management

Multicast

and

Routing

Access

Security

Guide

IPv6

Configuration

Guide

Basic

Operation

Guide

Protection

PCM/PCM+ X

PIM-DM (Dense Mode) X

PIM-SM (Sparse Mode) X

Ping X

Port Configuration X

Port Monitoring X

Port Security X

Port Status X

Port Trunking (LACP) X

Port-Based Access Control (802.1X) X

Power over Ethernet (PoE and PoE+) X

Protocol Filters X

Protocol VLANS X

QinQ (Provider Bridging) X

Quality of Service (QoS) X

RADIUS Authentication and Accounting X

RADIUS-Based Configuration X

Rate-Limiting X

RIP X

RMON 1,2,3,9 X

Routing X

Routing - IP Static X

Route Redistribution X

SavePower Features X

xxv

Software Features Manual

Management

and

Configuration

Advanced

Traffic

Management

Multicast

and

Routing

Access

Security

Guide

IPv6

Configuration

Guide

Secure Copy X

Secure Copy (IPv6) X

Secure FTP (IPv6) X

sFlow X

SFTP X

SNMPv3 X

SNMP (IPv6) X

Software Downloads (SCP/SFTP, TFPT,

Xmodem)

Source-Port Filters X

Spanning Tree (STP, RSTP, MSTP) X

SSHv2 (Secure Shell) Encryption X

SSH (IPv6) X

SSL (Secure Socket Layer) X

Stack Management (Stacking) X

Basic

Operation

Guide

Syslog X

System Information X

TACACS+ Authentication X

Telnet Access X

Telnet (IPv6) X

TFTP X

Time Protocols (TimeP, SNTP) X

Time Protocols (IPv6) X

Traffic Mirroring X

Traffic/Security Filters X

Troubleshooting X

xxvi

Software Features Manual

Management

and

Configuration

Advanced

Traffic

Management

Multicast

and

Routing

Access

Security

Guide

IPv6

Configuration

Guide

Basic

Operation

Guide

Uni-Directional Link Detection (UDLD) X

UDP Forwarder X

USB Device Support X

Virus Throttling (Connection-Rate

Filtering)

VLANs X

VLAN Mirroring (1 static VLAN) X

Voice VLAN X

VRRP X

Web Authentication RADIUS Support X

Web-based Authentication X

Web UI X

xxvii

xxviii

Security Overview

Introduction

This chapter provides an overview of the security features included on your switch. Table 1-1 on page 1-3 outlines the access security and authentication features, while Table 1-2 on page 1-7 highlights the additional features designed to help secure and protect your network. For detailed information on individual features, see the references provided.

Before you connect your switch to a network, HP recommends that you review the section titled “Getting Started with Access Security” on page 1-10. It outlines potential threats for unauthorized switch and network access, and provides guidelines on how to prepare the switch for secure network operation.

Security Overview

Introduction

About This Guide

This Access Security Guide describes how to configure security features on your switch.

Note For an introduction to the standard conventions used in this guide, refer to

the Getting Started chapter in the Management and Configuration Guide for your switch.

For More Information

For IPv6-specific security settings and features, refer to the IPV6 Configuration Guide for your switch.

For information on which product manual to consult for a specific software feature, refer to the “Software Feature Index” on page xxiii of this guide.

1-1

Security Overview

Introduction

For the latest version of all HP networking switch documentation, including Release Notes covering recently added features and other software topics, visit the HP networking web site at www.hp/support/manuals.

1-2

Security Overview

Access Security Features

This section provides an overview of the switch’s access security features, authentication protocols, and methods. Table 1-1 lists these features and provides summary configuration guidelines. For more in-depth information, see the references provided (all chapter and page references are to this Access Security Guide unless a different manual name is indicated).

Note The Management Interface wizard provides a convenient step-by-step method

to prepare the switch for secure network operation. See “Quick Start: Using the Management Interface Wizard” on page 1-11 for details.

Table 1-1. Access Security and Switch Authentication Features

Feature Default

Setting

Manager password

no password Configuring a local Manager password is a fundamental

Security Guidelines More Information and

Configuration Details

“Configuring Local

step in reducing the possibility of unauthorized access through the switch’s WebAgent and console (CLI and Menu) interfaces. The Manager password can easily be set by any one of the following methods:

• CLI: password manager command, or Management interface wizard

• WebAgent: the password options under the Security tab, or Management interface wizard

• Menu interface: Console Passwords option

•SNMP

Password Security” on page 2-4

“Quick Start: Using the Management Interface Wizard” on page 1-11

“Using SNMP To View and Configure Switch Authentication Features” on page 6-21

1-3

Security Overview

Access Security Features

Feature Default

Setting

Telnet and Web-browser access (WebAgent)

SSH disabled SSH provides Telnet-like functions through encrypted,

enabled The default remote management protocols enabled on

Security Guidelines More Information and

the switch are plain text protocols, which transfer passwords in open or plain text that is easily captured. To reduce the chances of unauthorized users capturing your passwords, secure and encrypted protocols such as SSH and SSL (see below for details) should be used for remote access. This enables you to employ increased access security while still retaining remote client access.

Also, access security on the switch is incomplete without disabling Telnet and the standard Web browser access (WebAgent). Among the methods for blocking unauthorized access attempts using Telnet or the WebAgent are the following two CLI commands:

• no telnet-server: This command blocks inbound Telnet access.

• no web-management: This command prevents use of the WebAgent through http (port 80) server access.

If you choose not to disable Telnet and the WebAgent, you may want to consider using RADIUS accounting to maintain a record of password-protected access to the switch.

authenticated transactions of the following types:

• client public-key authentication: uses one or more public keys (from clients) that must be stored on the switch. Only a client with a private key that matches a stored public key can gain access to the switch.

• switch SSH and user password authentication: this option is a subset of the client public-key authentication, and is used if the switch has SSH enabled without a login access configured to authenticate the client’s key. In this case, the switch authenticates itself to clients, and users on SSH clients then authenticate themselves to the switch by providing passwords stored on a RADIUS or TACACS+ server, or locally on the switch.

• secure copy (SC) and secure FTP (SFTP): By opening a secure, encrypted SSH session, you can take advantage of SC and SFTP to provide a secure alternative to TFTP for transferring sensitive switch information. For more on SC and SFTP, refer to the section titled “Using Secure Copy and SFTP” in the “File Transfers” appendix of the Management and Configuration Guide for your switch.

Configuration Details

“Quick Start: Using the Management Interface Wizard” on page 1-11

For more on Telnet and the WebAgent, refer to the chapter on “Interface

Access and System Information” in the Management and Configuration Guide.

For RADIUS accounting, refer to Chapter 6, “RADIUS

Authentication and Accounting”

“Quick Start: Using the Management Interface Wizard” on page 1-11

Chapter 8 “Configuring Secure Shell (SSH)”

1-4

Security Overview

Access Security Features

Feature Default

Setting

SSL disabled Secure Socket Layer (SSL) and Transport Layer Security

SNMP public,

Authorized IP Managers

Secure Management VLAN

ACLs for Management Access Protection

TAC ACS + Authentication

unrestricted

none This feature uses IP addresses and masks to determine

disabled This feature creates an isolated network for managing

none ACLs can also be configured to protect management

disabled This application uses a central server to allow or deny

Security Guidelines More Information and

(TLS) provide remote Web browser access (WebAgent) to the switch via authenticated transactions and encrypted paths between the switch and management station clients capable of SSL/TLS operation. The authenticated type includes server certificate authentication with user password authentication.

In the default configuration, the switch is open to access by management stations running SNMP management applications capable of viewing and changing the settings and status data in the switch’s MIB (Management Information Base). Thus, controlling SNMP access to the switch and preventing unauthorized SNMP access should be a key element of your network security strategy.

whether to allow management access to the switch across the network through the following :

• Telnet and other terminal emulation applications

• The WebAgent

• SNMP (with a correct community name)

the HP switches that offer this feature. When a secure management VLAN is enabled, CLI, Menu interface, and WebAgent access is restricted to ports configured as members of the VLAN.

access by blocking inbound IP traffic that has the switch itself as the destination IP address.

access to TACACS-aware devices in your network. TACACS+ uses username/password sets with associated privilege levels to grant or deny access through either the switch’s serial (console) port or remotely, with Telnet.

If the switch fails to connect to a TACACS+ server for the necessary authentication service, it defaults to its own locally configured passwords for authentication control. TACACS+ allows both login (read-only) and enable (read/write) privilege level access.

Configuration Details

“Quick Start: Using the Management Interface Wizard” on page 1-11

Chapter 9, “Configuring Secure Socket Layer (SSL)”

“SNMP Security Guidelines” on page 1-14

“Quick Start: Using the Management Interface Wizard” on page 1-11

Management and Configuration Guide, Chapter 14, refer to the section “Using SNMP Tools To Manage the Switch”

Chapter 15, “Using Authorized IP Managers”

Advanced Traffic Management Guide, refer to the chapter “Static Virtual LANs (VLANs)”

“Access Control Lists (ACLs)” on page 1-8

Chapter 10, “IPv4 Access Control Lists (ACLs)”

Chapter 5, “TACACS+ Authentication”

1-5

Security Overview

Access Security Features

Feature Default

Setting

RADIUS Authentication

802.1X Access Control

Web and MAC Authentication

disabled For each authorized client, RADIUS can be used to

none This feature provides port-based or user-based

none These options are designed for application on the edge

Security Guidelines More Information and

Configuration Details

authenticate operator or manager access privileges on the switch via the serial port (CLI and Menu interface), Telnet, SSH, and Secure FTP/Secure Copy (SFTP/SCP) access methods.

authentication through a RADIUS server to protect the switch from unauthorized access and to enable the use of RADIUS-based user profiles to control client access to network services. Included in the general features are the following:

• user-based access control supporting up to 32 authenticated clients per port

• port-based access control allowing authentication by a single client to open the port

• switch operation as a supplicant for point-to-point connections to other 802.1X-compliant HP switches

of a network to provide port-based security measures for protecting private networks and the switch itself from unauthorized access. Because neither method requires clients to run any special supplicant software, both are suitable for legacy systems and temporary access situations where introducing supplicant software is not an attractive option.

Both methods rely on using a RADIUS server for authentication. This simplifies access security management by allowing you to control access from a master database in a single server. It also means the same credentials can be used for authentication, regardless of which switch or switch port is the current access point into the LAN. Web authentication uses a web page login to authenticate users for access to the network. MAC authentication grants access to a secure network by authenticating device MAC addresses for access to the network.

Chapter 6, “RADIUS Authentication and Accounting”

Chapter 13 “Configuring Port-Based and User-Based Access Control (802.1X)”

Chapter 4, “Web and MAC Authentication”

1-6

Security Overview

Network Security Features

This section outlines features and defence mechanisms for protecting access through the switch to the network. For more detailed information, see the indicated chapters.

Table 1-2. Network Security—Default Settings and Security Guidelines

Feature Default

Setting

Secure File Transfers

USB Autorun enabled

Traffic/Security Filters

not applicable

(disabled once a password has been set)

none These statically configured filters enhance in-band

Security Guidelines More Information and

Configuration Details

Secure Copy and SFTP provide a secure alternative to TFTP and auto-TFTP for transferring sensitive information such as configuration files and log information between the switch and other devices.

Used in conjunction with HP E-PCM Plus, this feature allows diagnosis and automated updates to the switch via the USB flash drive. When enabled in secure mode, this is done with secure credentials to prevent tampering. Note that the USB Autorun feature is disabled automatically, once a password has been set on the switch.

security (and improve control over access to network resources) by forwarding or dropping inbound network traffic according to the configured criteria. Filter options include:

• source-port filters: Inbound traffic from a designated, physical source-port will be forwarded or dropped on a per-port (destination) basis.

• multicast filters: Inbound traffic having a specified multicast MAC address will be forwarded to outbound ports or dropped on a per-port (destination) basis.

• protocol filters: Inbound traffic having the selected frame (protocol) type will be forwarded or dropped on a per-port (destination) basis.

Management and Configuration Guide, Appendix A “File Transfers”, refer to the section “Using Secure Copy and SFTP”

Management and Configuration Guide, Appendix A “File Transfers”, refer to the section “USB Autorun”

Chapter 12, “Traffic/Security Filters and Monitors”

1-7

Security Overview

Network Security Features

Feature Default

Setting

Access Control Lists (ACLs)

Port Security, MAC Lockdown, and MAC Lockout

none ACLs can filter traffic to or from a host, a group of hosts,

none The features listed below provide device-based access

Security Guidelines More Information and

Configuration Details

Chapter 10, “IPv4 Access

or entire subnets. Layer 3 IP filtering with Access Control Lists (ACLs) enables you to improve network performance and restrict network use by creating policies for:

• Switch Management Access: Permits or denies inband management access. This includes preventing the use of certain TCP or UDP applications (such as Telnet, SSH, WebAgent, and SNMP) for transactions between specific source and destination IP addresses.)

• Application Access Security: Eliminating unwanted IP, TCP, or UDP traffic by filtering packets where they enter or leave the switch on specific interfaces.

Note on ACL Security Use: ACLs can enhance network security by blocking

selected IP traffic, and can serve as one aspect of maintaining network security. However, because ACLs do not provide user or device authentication, or protection from malicious manipulation of data carried in IP packet transmissions, they should not be relied upon for a complete security solution.

security in the following ways:

• Port security: Enables configuration of each switch port with a unique list of the MAC addresses of devices that are authorized to access the network through that port. This enables individual ports to detect, prevent, and log attempts by unauthorized devices to communicate through the switch. Some switch models also include eavesdrop prevention in the port security feature.

• MAC lockdown: This “static addressing” feature is used as an alternative to port security to prevent station movement and MAC address “hijacking” by allowing a given MAC address to use only one assigned port on the switch. MAC lockdown also restricts the client device to a specific VLAN.

• MAC lockout: This feature enables blocking of a specific MAC address so that the switch drops all traffic to or from the specified address.

Control Lists (ACLs)”

Chapter 14, “Configuring and Monitoring Port Security”

See also “Precedence of Port-Based Security Options” on page 1-16

1-8

Security Overview

Network Security Features

Feature Default

Setting

Key Management System (KMS)

ConnectionRate Filtering based on Virus-Throttling Technology

ICMP Rate-Limiting

Spanning Tree Protection

DHCP Snooping, Dynamic ARP Protection, and Dynamic IP Lockdown

none KMS is available in several HP switch models and is

none This feature helps protect the network from attack and

none This feature helps defeat ICMP denial-of-service

none These features prevent your switch from malicious

none These features provide the following additional

Security Guidelines More Information and

Configuration Details

designed to configure and maintain key chains for use with KMS-capable routing protocols that use timedependent or time-independent keys. (A key chain is a set of keys with a timing mechanism for activating and deactivating individual keys.) KMS provides specific instances of routing protocols with one or more Send or Accept keys that must be active at the time of a request.

is recommended for use on the network edge. It is primarily focused on the class of worm-like malicious code that tries to replicate itself by taking advantage of weaknesses in network applications behind unsecured ports. In this case, the malicious code tries to create a large number of outbound connections on an interface in a short time. Connection-Rate filtering detects hosts that are generating traffic that exhibits this behavior, and causes the switch to generate warning messages and (optionally) to throttle or drop all traffic from the offending hosts.

attacks by restricting ICMP traffic to percentage levels that permit necessary ICMP functions, but throttle additional traffic that may be due to worms or viruses (reducing their spread and effect).

attacks or configuration errors:

• BPDU Filtering and BPDU Protection: Protects the network from denial-of-service attacks that use spoofing BPDUs by dropping incoming BPDU frames and/or blocking traffic through a port.

• STP Root Guard: Protects the STP root bridge from malicious attacks or configuration mistakes.

protections for your network:

• DHCP Snooping: Protects your network from common DHCP attacks, such as address spoofing and repeated address requests.

• Dynamic ARP Protection: Protects your network from ARP cache poisoning.

• Dynamic IP Lockdown: Prevents IP source address spoofing on a per-port and per-VLAN basis

• Instrumentation Monitor. Helps identify a variety of malicious attacks by generating alerts for detected an

omalies on the switch.

Chapter 16, “Key Management System”

Chapter 3, “Virus Throttling (Connection-Rate Filtering)”

Management and Configuration Guide, in the chapter on “Port Traffic Controls” refer to the section “ICMP Rate-Limiting”

Advanced Traffic Management Guide, refer to the chapter “Multiple Instance Spanning-Tree Operation”

Chapter 11, “Configuring Advanced Threat Protection”

1-9

Security Overview

Getting Started with Access Security

HP switches are designed as “plug and play” devices, allowing quick and easy installation in your network. In its default configuration the switch is open to unauthorized access of various types. When preparing the switch for network operation, therefore, HP recommends that you enforce a security policy to help ensure that the ease in getting started is not used by unauthorized persons as an opportunity for access and possible malicious actions.

Since security incidents can originate with sources inside as well as outside of an organization, your access security provisions must protect against internal and external threats while preserving the necessary network access for authorized clients and users. It is important to evaluate the level of management access vulnerability existing in your network and take steps to ensure that all reasonable security precautions are in place. This includes both configurable security options and physical access to the switch.

Switch management access is available through the following methods:

■ Front panel access to the console serial port (see “Physical Security”)

■ Inbound Telnet access

■ Web-browser access (WebAgent)

■ SNMP access

1-10

For guidelines on locking down your switch for remote management access, see “Quick Start: Using the Management Interface Wizard” on page 1-11.

Physical Security

Physical access to the switch allows the following:

■ use of the console serial port (CLI and Menu interface) for viewing and

changing the current configuration and for reading status, statistics, and log messages.

■ use of the switch’s USB port for file transfers and autorun capabilities.

■ use of the switch’s Clear and Reset buttons for these actions:

• clearing (removing) local password protection

• rebooting the switch

• restoring the switch to the factory default configuration (and erasing any non-default configuration settings)

Getting Started with Access Security

Security Overview

Keeping the switch in a locked wiring closet or other secure space helps to prevent unauthorized physical access.

As additional precautions, you can do the following:

■ Disable or re-enable the password-clearing function of the Clear button.

■ Configure the Clear button to reboot the switch after clearing any local

usernames and passwords.

■ Modify the operation of the Reset+Clear button combination so that the

switch reboots, but does not restore the switch’s factory default settings.

■ Disable or re-enable password recovery.

■ Disable USB autorun by setting a Manager password, or enable USB

autorun in secure mode so that security credentials are required to use this feature.

For the commands used to configure the Clear and Reset buttons, refer to “Front-Panel Security” on page 2-23. For information on using USB Autorun, refer to the sections on “Using USB to Transfer Files to and from the Switch” and “Using USB Autorun” in the Management and Configuration Guide, Appendix A “File Transfers”.

Quick Start: Using the Management Interface Wizard

The Management Interface wizard provides a convenient step-by-step method to prepare the switch for secure network operation. It guides you through the process of locking down the following switch operations or protocols:

■ setting local passwords

■ restricting SNMP access

■ enabling/disabling Telnet

■ enabling/disabling SSH

■ enabling/disabling remote Web management (WebAgent)

■ restricting WebAgent access to SSL

■ enabling/disabling USB autorun

■ setting timeouts for SSH/Telnet sessions

The wizard can also be used to view the pre-configured defaults and see the current settings for switch access security. The wizard can be launched either via the CLI (see page 1-12) or the WebAgent (see page 1-13).

Note The wizard’s security settings can also be configured using standard

commands via the CLI, Menu, or WebAgent. For full details on preparing and configuring the switch for SSH and SSL operation, refer to chapters 8 and 9 respectively.

1-11

Security Overview

Welcome to the Management Interface Setup Wizard

This wizard will help you with the initial setup of the various management interfaces. The current values are shown in brackets[]. Type in a new value, or press <Enter> to keep the current value. Press CTRL-C at any time to quit the wizard without saving any changes. Press ? for help.

Operator password [not configured]: Confirm password: Manager password [*******]: Confirm password: Restrict SNMP access to SNMPv3 only [no]: SNMPv2 community name [notpublic]: SNMPv2 Community access level [unrestricted]: Telnet enabled [yes]: SSH enabled [no]: Web management enabled [yes]: Restrict Web access to SSL [no]: Timeout for ssh/telnet sessions [0]:

Operator password : Manager password :******* Restrict SNMP access to SNMPv3 only :no SNMPv2 community name :notpublic SNMPv2 Community access level :unrestricted Telnet enabled :yes SSH enabled :no Web management enabled :yes Restrict Web access to SSL :no Timeout for ssh/telnet sessions :0

Do you want to save these changes? [yes]:

Current values are shown in brackets (Password entries must be entered twice and will appear as asterisks.)

Type in a new value to change a setting, or press <Enter> to keep the current value.

To save these settings, press [Enter]. To cancel any changes, type [n] (for no), then press [

Enter].

Summary of current settings (displayed after last wizard option has been set)

Getting Started with Access Security

CLI: Management Interface Wizard

To configure security settings using the CLI wizard, follow the steps below:

1. At the command prompt, type setup mgmt-interfaces.

The welcome banner appears and the first setup option is displayed (Operator password). As you advance through the wizard, each setup option displays the current value in brackets [ ] as shown in Figure 1-1.

Figure 1-1. Example of Management Interface Wizard Configuration

1-12

Getting Started with Access Security

Security Overview

2. When you enter the wizard, you have the following options:

• To update a setting, type in a new value, or press [Enter] to keep the current value.

• To quit the wizard without saving any changes, press [CTRL-C] at any time.

• To access online Help for any option, press [?].

After you have gone through each setup option, the wizard displays the summary configuration together with a prompt to save the changes (see Figure 1-1 on page 1-12 for an example).

3. When the message appears asking if you want to save these changes, you have the following options:

• To save your changes, press [Enter].

• To cancel any changes without saving, type [n] and then press [Enter].

After pressing [Enter], the wizard exits to the command line prompt.

CLI Wizard: Operating Notes and Restrictions.

■ Once a password has been configured on the switch, you cannot remove

it using the CLI wizard. Passwords can be removed by executing the no password command directly from the CLI.

■ When you restrict SNMP access to SNMPv3 only, the options SNMPv2

community name and access level will not appear.

■ The wizard displays the first available SNMPv2 community and allows the

user to modify the first community access parameters.

■ The wizard creates a new SNMP community only when no communities

have been configured on the switch.

■ The USB Autorun feature is disabled as soon as an operator or manager

password is set on the switch. Once a password has been set, the USB autorun option is no longer provided as part of the wizard.

WebAgent: Management Interface Wizard

To use the Management Interface wizard from the WebAgent, follow the steps below:

1. In the navigation tree, select Security.

2. Click on the Security Wizard. The Welcome window appears.

1-13

Security Overview

Getting Started with Access Security

This page allows you to choose between two setup types:

• Typical—provides a multiple page, step-by-step method to configure

• Advanced—provides a single summary screen in which to configure

Refer to the WebAgent Online Help for detailed information about using the Management Interface wizard.

SNMP Security Guidelines

In the default configuration, the switch is open to access by management stations running SNMP (Simple Network Management Protocol) management applications capable of viewing and changing the settings and status data in the switch’s MIB (Management Information Base). Thus, controlling SNMP access to the switch and preventing unauthorized SNMP access should be a key element of your network security strategy.

General SNMP Access to the Switch. The switch supports SNMP versions 1, 2c, and 3, including SNMP community and trap configuration. The default configuration supports versions 1 and 2c compatibility, which uses plain text and does not provide security options.

security settings, with on-screen instructions for each option.

all security settings at once.

1-14

HP recommends that you enable SNMP version 3 for improved security. SNMPv3 includes the ability to configure restricted access and to block all non-version 3 messages (which blocks version 1 and 2c unprotected operation).

SNMPv3 security options include:

■ configuring device communities as a means for excluding management

access by unauthorized stations

■ configuring for access authentication and privacy

■ reporting events to the switch CLI and to SNMP trap receivers

■ restricting non-SNMPv3 agents to either read-only access or no access

■ co-existing with SNMPv1 and v2c if necessary

SNMP Access to the Authentication Configuration MIB. A management station running an SNMP networked device management application, such as HP E-PCM Plus or HP OpenView, can access the switch’s management information base (MIB) for read access to the switch’s status and read/write access to the switch’s authentication configuration (hpSwitchAuth). This means that the switch’s default configuration now allows SNMP access to security settings in hpSwitchAuth.

Getting Started with Access Security

Security Overview

Note on SNMP Access to Authentication MIB

Downloading and booting from the K.12.xx or greater software version for the first time enables SNMP access to the authentication configuration MIB (the default action). If SNMPv3 and other security safeguards are not in place, the switch’s authentication configuration MIB is exposed to unprotected SNMP access and you should use the command shown below to disable this access.

If SNMP access to the hpSwitchAuth MIB is considered a security risk in your network, then you should implement the following security

precautions:

■ If SNMP access to the authentication configuration (hpSwitchAuth) MIB

described above is not desirable for your network, then immediately after downloading and booting from the K.12.xx or greater software for the first time, use the following command to disable this feature:

snmp-server mib hpswitchauthmib excluded

■ If you choose to leave the authentication configuration MIB accessible,

then you should do the following to help ensure that unauthorized workstations cannot use SNMP tools to access the MIB:

a. Configure SNMP version 3 management and access security on the

switch.

b. Disable SNMP version 2c on the switch.

For details on this feature, refer to the section titled “Using SNMP To View and Configure Switch Authentication Features” on page 6-30.

For more information on configuring SNMP, refer to the section “Using SNMP

Tools To Manage the Switch” in the chapter “Configuring for Network Management Applications” in the Management and Configuration Guide

for your switch.

1-15

Security Overview

Precedence of Security Options

This section explains how port-based security options, and client-based attributes used for authentication, get prioritized on the switch.

Precedence of Port-Based Security Options

Where the switch is running multiple security options, it implements network traffic security based on the OSI (Open Systems Interconnection model) precedence of the individual options, from the lowest to the highest. The following list shows the order in which the switch implements configured security features on traffic moving through a given port.

1. Disabled/Enabled physical port

2. MAC lockout (Applies to all ports on the switch.)

3. MAC lockdown

4. Port security

5. Authorized IP Managers

6. Application features at higher levels in the OSI model, such as SSH.

(The above list does not address the mutually exclusive relationship that exists among some security features.)

Precedence of Client-Based Authentication: Dynamic Configuration Arbiter

The Dynamic Configuration Arbiter (DCA) is implemented to determine the client-specific parameters that are assigned in an authentication session.

A client-specific authentication configuration is bound to the MAC address of a client device and may include the following parameters:

■ Untagged client VLAN ID

■ Tagged VLAN IDs

■ Per-port CoS (802.1p) priority

■ Per-port rate-limiting on inbound traffic

■ Client-based ACLs

1-16

Precedence of Security Options

DCA allows client-specific parameters configured in any of the following ways to be applied and removed as needed in a specified hierarchy of precedence. When multiple values for an individual configuration parameter exist, the value applied to a client session is determined in the following order (from highest to lowest priority) in which a value configured with a higher priority overrides a value configured with a lower priority:

1. Attribute profiles applied through the Network Immunity network-management application using SNMP (see “Network Immunity Manager”)

2. 802.1X authentication parameters (RADIUS-assigned)

3. Web- or MAC-authentication parameters (RADIUS-assigned)

4. Local, statically-configured parameters

Although RADIUS-assigned settings are never applied to ports for nonauthenticated clients, the Dynamic Configuration Arbiter allows you to configure and assign client-specific port configurations to non-authenticated clients, provided that a client’s MAC address is known in the switch in the forwarding database. DCA arbitrates the assignment of attributes on both authenticated and non-authenticated ports.

DCA does not support the arbitration and assignment of client-specific attributes on trunk ports.

Security Overview

Network Immunity Manager

Network Immunity Manager (NIM) is a plug-in to HP E-PCM Plus and a key component of the HP Network Immunity security solution that provides comprehensive detection and per-port-response to malicious traffic at the HP network edge. NIM allows you to apply policy-based actions to minimize the negative impact of a client’s behavior on the network. For example, using NIM you can apply a client-specific profile that adds or modifies per-port ratelimiting and VLAN ID assignments.

Note NIM actions only support the configuration of per-port rate-limiting and VLAN

ID assignment; NIM does not support CoS (802.1p) priority assignment and ACL configuration.

NIM-applied parameters temporarily override RADIUS-configured and locally configured parameters in an authentication session. When the NIM-applied action is removed, the previously applied client-specific parameter (locally configured or RADIUS-assigned) is re-applied unless there have been other configuration changes to the parameter. In this way, NIM allows you to minimize network problems without manual intervention.

1-17

Security Overview

Precedence of Security Options

NIM also allows you to configure and apply client-specific profiles on ports that are not configured to authenticate clients (unauthorized clients), provided that a client’s MAC address is known in the switch’s forwarding database.

The profile of attributes applied for each client (MAC address) session is stored in the hpicfUsrProfile MIB, which serves as the configuration interface for Network Immunity Manager. A client profile consists of NIM-configured, RADIUS-assigned, and statically configured parameters. Using show commands for 802.1X, web or MAC authentication, you can verify which RADIUS -assigned and statically configured parameters are supported and if they are supported on a per-port or per-client basis.

A NIM policy accesses the hpicfUsrProfileMIB through SNMP to perform the following actions:

■ Bind (or unbind) a profile of configured attributes to the MAC address of

■ Configure or unconfigure an untagged VLAN for use in an authenticated

Note that the attribute profile assigned to a client is often a combination of NIM-configured, RADIUS-assigned, and statically configured settings. Precedence is always given to the temporarily applied NIM-configured parameters over RADIUS-assigned and locally configured parameters.

a client device on an authenticated or unauthenticated port.

or unauthenticated client session.

1-18

For information on Network Immunity Manager, go to the HP Networking Web site at www.hp.com/solutions,

Arbitrating Client-Specific Attributes

In previous releases, client-specific authentication parameters for 802.1X Web, and MAC authentication are assigned to a port using different criteria. A RADIUS-assigned parameter is always given highest priority and overrides statically configured local passwords. 802.1X authentication parameters override Web or MAC authentication parameters.

DCA stores three levels of client-specific authentication parameters and prioritizes them according to the following hierarchy of precedence:

1. NIM access policy (applied through SNMP)

2. RADIUS-assigned a. 802.1X authentication b. Web or MAC authentication

3. Statically (local) configured

Precedence of Security Options

Security Overview

Client-specific configurations are applied on a per-parameter basis on a port. In a client-specific profile, if DCA detects that a parameter has configured values from two or more levels in the hierarchy of precedence described above, DCA decides which parameters to add or remove, or whether to fail the authentication attempt due to an inability to apply the parameters.

For example, NIM may configure only rate-limiting for a specified client session, while RADIUS-assigned values may include both an untagged VLAN ID and a rate-limiting value to be applied. In this case, DCA applies the NIMconfigured rate-limiting value and the RADIUS-assigned VLAN (if there are no other conflicts).

Also, you can assign NIM-configured parameters (for example, VLAN ID assignment or rate-limiting) to be activated in a client session when a threat to network security is detected. When the NIM-configured parameters are later removed, the parameter values in the client session return to the RADIUS-configured or locally configured settings, depending on which are next in the hierarchy of precedence.

In addition, DCA supports conflict resolution for QoS (port-based CoS priority) and rate-limiting (ingress) by determining whether to configure either strict or non-strict resolution on a switch-wide basis. For example, if multiple clients authenticate on a port and a rate-limiting assignment by a newly authenticating client conflicts with the rate-limiting values assigned to previous clients, by using Network Immunity you can configure the switch to apply any of the following attributes:

■ Apply only the latest rate-limiting value assigned to all clients.

■ Apply a client-specific rate-limiting configuration to the appropriate client

session (overwrites any rate-limit previously configured for other client sessions on the port).

For information about how to configure RADIUS-assigned and locally configured authentication settings, refer to:

■ RADIUS-assigned 802.1X authentication: “Configuring Port-Based and

User-Based Access Control (802.1X)” on page 13-1.

■ RADIUS-assigned Web or MAC authentication: “Web and MAC Authenti-

cation” on page 4-1.

■ RADIUS-assigned CoS, rate-limiting, and ACLS: “Configuring RADIUS

Server Support for Switch Services” on page 7-1.

■ Statically (local) configured: “Configuring Username and Password

Security” on page 2-1.

1-19

Security Overview

HP Identity-Driven Manager (IDM)

IDM is a plug-in to HP E-PCM Plus and uses RADIUS-based technologies to create a user-centric approach to network access management and network activity tracking and monitoring. IDM enables control of access security policy from a central management server, with policy enforcement to the network edge, and protection against both external and internal threats.

Using IDM, a system administrator can configure automatic and dynamic security to operate at the network edge when a user connects to the network. This operation enables the network to:

■ approve or deny access at the edge of the network instead of in the core;

■ distinguish among different users and what each is authorized to do;

■ configure guest access without compromising internal security.

Criteria for enforcing RADIUS-based security for IDM applications includes classifiers such as:

■ authorized user identity

■ authorized device identity (MAC address)

■ software running on the device

■ physical location in the network

■ time of day

1-20

Responses can be configured to support the networking requirements, user (SNMP) community, service needs, and access security level for a given client and device.

For more information on IDM, go to the HP Web site at www.hp.com/solutions, click on Security.

Configuring Username and Password Security

Overview

Feature Default Menu CLI WebAgent

Set Usernames none — — page 2-9

Set a Password none page

Delete Password Protection n/a page

show front-panel-security n/a — page 1-13 —

front-panel-security — page 1-13 —

password-clear enabled — page 1-13 —

reset-on-clear disabled — page 1-14 —

factory-reset enabled — page 1-15 —

password-recovery enabled — page 1-15 —

page 2-6 page 2-9

2-4

page 2-6 page 2-9

2-5

Console access includes both the menu interface and the CLI. There are two levels of console access: Manager and Operator. For security, you can set a password pair (username and password) on each of these levels.

Notes Usernames are optional. Also, in the menu interface, you can configure

passwords, but not usernames. To configure usernames, use the CLI or the WebAgent.

Usernames and passwords for Manager and Operator access can also be configured using SNMP. For more information, refer to “Using SNMP To View and Configure Switch Authentication Features” on page 6-30.

Usernames and passwords for Manager and Operator access can also be configured using the Management Interface Wizard. For more information, refer to “Quick Start: Using the Management Interface Wizard” on page 1-11.

2-1

Configuring Username and Password Security

Overview

Level Actions Permitted

Manager: Access to all console interface areas.

This is the default level. That is, if a Manager password has not been set prior to starting the current console session, then anyone having access to the console can access any area of the console interface.

Operator: Access to the Status and Counters menu, the Event Log, and the CLI*, but no

Configuration capabilities. On the Operator level, the configuration menus, Download OS, and Reboot

Switch options in the Main Menu are not available.

*Allows use of the ping, link-test, show, menu, exit, and logout commands, plus the enable command if you can provide the Manager password.

To configure password security:

1. Set a Manager password pair (and an Operator password pair, if applicable for your system).

2. Exit from the current console session. A Manager password pair will now be needed for full access to the console.

2-2

If you do steps 1 and 2, above, then the next time a console session is started for either the menu interface or the CLI, a prompt appears for a password. Assuming you have protected both the Manager and Operator levels, the level of access to the console interface will be determined by which password is entered in response to the prompt.

If you set a Manager password, you may also want to configure an inactivity timer. This causes the console session to end after the specified period of inactivity, thus giving you added security against unauthorized console access. You can use either of the following to set the inactivity timer:

■ Menu Interface: System Information screen (Select “2. Switch Configu-

ration.)

■ CLI: Use the console inactivity-timer < 0 | 1 | 5 | 10 | 15 | 20 | 30 | 60 | 120 >

Configuring Username and Password Security

Overview

Notes The manager and operator passwords and (optional) usernames control

access to the menu interface, CLI, and WebAgent.

If you configure only a Manager password (with no Operator password), and in a later session the Manager password is not entered correctly in response to a prompt from the switch, then the switch does not allow management access for that session.

If the switch has a password for both the Manager and Operator levels, and neither is entered correctly in response to the switch’s password prompt, then the switch does not allow management access for that session.

Passwords are case-sensitive.

When configuring an operator or manager password a message will appear indicating that (USB) autorun has been disabled. For more information on the autorun feature, refer to the Appendix A on “File Transfers” in the Manage- ment and Configuration Guide for your switch.

Caution If the switch has neither a Manager nor an Operator password, anyone

having access to the switch through either Telnet, the serial port, or the WebAgent can access the switch with full manager privileges. Also, if you configure only an Operator password, entering the Operator password enables full manager privileges.

The rest of this chapter covers how to:

■ Set passwords

■ Delete passwords

■ Recover from a lost password

■ Maintain front-panel security

2-3

Configuring Username and Password Security

Configuring Local Password Security

Menu: Setting Passwords

As noted earlier in this section, usernames are optional. Configuring a username requires either the CLI or the WebAgent.

1. From the Main Menu select:

3. Console Passwords

2-4

Figure 2-1. The Set Password Screen

2. To set a new password: a. Select Set Manager Password or Set Operator Password. You will then

be prompted with Enter new password.

b. Type a password of up to 16 ASCII characters with no spaces and

press [Enter]. (Remember that passwords are case-sensitive.)

c. When prompted with Enter new password again, retype the new pass-

word and press [Enter].

After you configure a password, if you subsequently start a new console session, you will be prompted to enter the password. (If you use the CLI or WebAgent to configure an optional username, the switch will prompt you for the username, and then the password.)

Configuring Username and Password Security

Configuring Local Password Security

To Delete Password Protection (Including Recovery from a Lost Password): This procedure deletes all usernames (if configured) and pass-

words (Manager and Operator).

If you have physical access to the switch, press and hold the Clear button (on the front of the switch) for a minimum of one second to clear all password protection, then enter new passwords as described earlier in this chapter.

If you do not have physical access to the switch, you will need Manager-Level access:

1. Enter the console at the Manager level.

2. Go to the Set Passwords screen as described above.

3. Select Delete Password Protection. You will then see the following prompt:

Continue Deletion of password protection? No

4. Press the Space bar to select Ye s, then press [Enter].

5. Press [Enter] to clear the Password Protection message.

To Recover from a Lost Manager Password: If you cannot start a console session at the Manager level because of a lost Manager password, you can clear the password by getting physical access to the switch and pressing and holding the Clear button for a minimum of one second. This action deletes all passwords and usernames (Manager and Operator) used by both the console and the WebAgent.

2-5

Configuring Username and Password Security

• Password entries appear as asterisks.

• You must type the password entry twice.

Press [Y] (for yes) and press [Enter].

Configuring Local Password Security

CLI: Setting Passwords and Usernames

Commands Used in This Section

password See below.

Configuring Manager and Operator Passwords.

Note The password command has changed. You can now configure manager and

operator passwords in one step. See “Saving Security Credentials in a Config File” on page 2-10 of this guide.

Syntax: [ no ] password <manager | operator | all | port-access> [ user-name ASCII-STR ] [<plaintext | sha1> ASCII-STR]

Figure 2-2. Example of Configuring Manager and Operator Passwords

To Remove Password Protection. Removing password protection means to eliminate password security. This command prompts you to verify that you want to remove one or both passwords, then clears the indicated password(s). (This command also clears the username associated with a password you are removing.) For example, to remove the Operator password (and username, if assigned) from the switch, you would do the following:

Figure 2-3. Removing a Password and Associated Username from the Switch

The effect of executing the command in figure 2-3 is to remove password protection from the Operator level. (This means that anyone who can access the switch console can gain Operator access without having to enter a username or password.)

2-6

Configuring Username and Password Security

Configuring Local Password Security

If you want to remove both operator and manager password protection, use the no password all command.

Username and Password Length.

The limit on usename and password length is 64 characters for the following authentication methods:

■ Front-end—WEB User Interface, SSH, and Telnet

■ Back-end—RADIUS, TACACS+, and Local

General Rules for Usernames and Passwords

Usernames and passwords are case-sensitive. ASCII characters in the range of 33-126 are valid, including:

■ A through Z uppercase characters

■ a through z lower case characters

■ 0 through 9 numeric characters

■ Special characters ‘ ~ ! @ # $ % ^ & * ( ) - _ = + [ ] { } \ | ; : ‘ “ , < > / ?

(see Restrictions, below)

The SPACE character is allowed to form a username or password pass-phrase. The username must be in quotes, for example “The little brown fox”. A space is not allowed as part of a username without the quotes. A password that includes a space or spaces should not have quotes.

Restrictions for the Setmib Command

Usernames and passwords can be set using the CLI command setmib. They cannot be set using SNMP.

■ Quotes are permitted for enclosing other characters, for example, a

username or password of abcd can be enclosed in quotes “abcd” without the quotes becoming part of the username or password itself. Quotes can also be inserted between other characters of a username or password, for example, ab”cd. A pair of quotes enclosing characters followed by any additional characters is invalid, for example, “abc”d.

■ Spaces are allowed in usernames and passwords. The username or

password must be enclosed in quotes, for example, “one two three”. A blank space or spaces between quotes is allowed, for example, “ ”.

2-7

Configuring Username and Password Security

Configuring Local Password Security

Additional Restrictions

Some authentication servers prevent the usage of special symbols such as the backslash (\) and quotes (“”). The switch allows the use of these symbols in configurable credentials, but using them may limit access for some users who may use different client software. Please refer to the vendor’s documentation for specific information about these restrictions.

Operating Notes on Upgrading or Downgrading Software Versions

When you update software from a version that does not support long passwords to a version that supports long passwords, the existing usernames and passwords continue to be there; no further action is required.

Before downgrading to a software version that does not include this feature, use one of the following procedures:

1. Reset the username and/or password to be no more than 16 characters in length, and without any special characters, using the CLI command

password or the equivalent in the WebAgent. Then execute a CLI write

memory command (required if the include-credentials feature has ever

been enabled).

HP Switch(config)# password manager New password: ******** Please retype new password: ******* HP Switch(config)# write mem

2-8

2. Execute the CLI command no password all. This clears all the passwords.

Then execute a CLI write memory command (required if the include-

credentials feature has ever been enabled).

HP Switch(config)# no password all Password protections will be deleted, do you want to continue [y/n]? y HP Switch(config)# write mem

3. Clear the password by using the "Clear" button on the switch. Then execute a CLI write memory command (required if the include-credentials feature has ever been enabled).

Configuring Username and Password Security

If You Cannot Access the Switch Using the Previous Password

If you cannot access the switch after a software version downgrade, clear the password by using the "Clear" button on the switch to regain access. Then boot into a software version that supports long passwords, and perform steps 1, 2, or 3 in the preceding section.

Configuring Local Password Security

WebAgent: Setting Passwords and Usernames

In the WebAgent you can enter passwords and (optional) usernames. See the WebAgent Online Help for detailed information.

2-9

Configuring Username and Password Security

Saving Security Credentials in a Config File

You can store and view the following security settings in the running-config file associated with the current software image by entering the include- credentials command (formerly this information was stored only in internal flash memory):

■ Local manager and operator passwords and (optional) user names that

control access to a management session on the switch through the CLI, menu interface, or WebAgent

■ SNMP security credentials used by network management stations to

access a switch, including authentication and privacy passwords

■ Port-access passwords and usernames used as 802.1X authentication

credentials for access to the switch

■ TACACS+ encryption keys used to encrypt packets and secure

authentication sessions with TACACS+ servers

■ RADIUS shared secret (encryption) keys used to encrypt packets and

secure authentication sessions with RADIUS servers

■ Secure Shell (SSH) public keys used to authenticate SSH clients that try

to connect to the switch.

2-10

Benefits of Saving Security Credentials

The benefits of including and saving security credentials in a configuration file are as follows:

■ After making changes to security parameters in the running configuration,

you can experiment with the new configuration and, if necessary, view the new security settings during the session. After verifying the configuration, you can then save it permanently by writing the settings to the startup-config file.

■ By permanently saving a switch’s security credentials in a configuration

file, you can upload the file to a TFTP server or Xmodem host, and later download the file to the HP switches on which you want to use the same security settings without having to manually configure the settings (except for SNMPv3 user parameters) on each switch.

Configuring Username and Password Security

Saving Security Credentials in a Config File

■ By storing different security settings in different files, you can test

different security configurations when you first download a new software version that supports multiple configuration files, by changing the configuration file used when you reboot the switch.

For more information about how to experiment with, upload, download, and use configuration files with different software versions, refer to the following:

■ The chapter on “Switch Memory and Configuration” in the Management

and Configuration Guide.

■ “Configuring Local Password Security” on page 2-4 in this guide.

Enabling the Storage and Display of Security Credentials

To enable the security settings, enter the include-credentials command.

Syntax: [no] include-credentials

Enables the inclusion and display of the currently configured manager and operator usernames and passwords, RADIUS shared secret keys, SNMP and 802.1X authenticator (port-access) security credentials, and SSH client public-keys in the running configuration. (Earlier software releases store these security configuration settings only in internal flash memory and do not allow you to include and view them in the running-config file.)

To view the currently configured security settings in the running configuration, enter one of the following commands:

■ show running-config: Displays the configuration settings in the

current running-config file.

■ write terminal: Displays the configuration settings in the current

running-config file.

For more information, refer to “Switch Memory and Configuration” in the Management and Configuration Guide.

The “no” form of the command disables only the display and copying of these security parameters from the running configuration, while the security settings remain active in the running configuration.

Default: The security credentials described in “Security Settings that Can Be Saved” on page 2-12 are not stored in the running configuration.

2-11

Configuring Username and Password Security

password manager user-name George SHA1 2fd4e1c67a2d28fced849ee1bb76e7391b93eb12

Saving Security Credentials in a Config File

Security Settings that Can Be Saved

The security settings that can be saved to a configuration file are:

■ Local manager and operator passwords and user names

■ SNMP security credentials, including SNMPv1 community names and

SNMPv3 usernames, authentication, and privacy settings

■ 802.1X port-access passwords and usernames

■ TACACS+ encryption keys

■ RADIUS shared secret (encryption) keys

■ Public keys of SSH-enabled management stations that are used by the

switch to authenticate SSH clients that try to connect to the switch

Local Manager and Operator Passwords

The information saved to the running-config file when the include-credentials command is entered includes:

password manager [user-name <name>] <hash-type> <pass-hash> password operator [user-name <name>] <hash-type> <pass-hash>

where <name> is an alphanumeric string for the user name assigned to the manager or operator. <hash-type> indicates the type of hash algorithm used: SHA-1 or plain text. <pass-hash> is the SHA-1 authentication protocol’s hash of the password or clear ASCII text.

For example, a manager username and password may be stored in a runningconfig file as follows:

Use the write memory command to save the password configurations in the startup-config file. The passwords take effect when the switch boots with the software version associated with that configuration file.

Caution If a startup configuration file includes other security credentials, but does not

contain a manager or operator password, the switch will not have password protection and can be accessed through Telnet, the serial port, or WebAgent with full manager privileges.

2-12

Configuring Username and Password Security

Saving Security Credentials in a Config File

Password Command Options

The password command has the following options:

Syntax: [no] password <manager | operator | port-access> [user-name <name>]

<hash-type> <password>

Set or clear a local username/password for a given access level.

manager: configures access to the switch with manager-level privileges.

operator: configures access to the switch with operator-level privileges.

port-access: configures access to the switch through 802.1X authentication with operator-level privileges.

user-name <name>: the optional text string of the user name associated with the password.

<hash-type>: specifies the type of algorithm (if any) used to hash the password. Valid values are plaintext or sha-1

<password>: the clear ASCII text string or SHA-1 hash of the password.

You can enter a manager, operator, or 802.1X port-access password in clear ASCII text or hashed format. However, manager and operator passwords are displayed and saved in a configuration file only in hashed format; port-access passwords are displayed and saved only as plain ASCII text.

After you enter the complete command syntax, the password is set. You are not prompted to enter the password a second time.

This command enhancement allows you to configure manager, operator, and

802.1X port-access passwords in only one step (instead of entering the

password command and then being prompted twice to enter the actual password).

■ For more information about configuring local manager and operator

passwords, refer to “Configuring Username and Password Security” on page 2-1 in this guide.

■ For more information about configuring a port-access password for

802.1X client authentication, see “802.1X Port-Access Credentials” on page 2-15 in this guide.

2-13

Configuring Username and Password Security

snmpv3 user “<name>" [auth <md5|sha> “<auth-pass>”] [priv “<priv-pass>"]

auth md5 “9e4cfef901f21cf9d21079debeca453” \ priv “82ca4dc99e782db1a1e914f5d8f16824”

snmpv3 user boris \

priv “5bc4313e9fd7c2953aaea9406764fe8bb629a538”

auth sha “8db06202b8f293e9bc0c00ac98cf91099708ecdf” \

snmpv3 user alan \

Saving Security Credentials in a Config File

SNMP Security Credentials

SNMPv1 community names and write-access settings, and SNMPv3 usernames continue to be saved in the running configuration file even when you enter the include-credentials command.

In addition, the following SNMPv3 security parameters are also saved:

where: <name> is the name of an SNMPv3 management station. [auth <md5 | sha>] is the (optional) authentication method used for the management station. <auth-pass> is the hashed authentication password used with the configured authentication method. [priv <priv-pass>] is the (optional) hashed privacy password used by a privacy protocol to encrypt SNMPv3 messages between the switch and the station.

The following example shows the additional security credentials for SNMPv3 users that can be saved in a running-config file:

Figure 2-4. Example of Security Credentials Saved in the Running-Config

Although you can enter an SNMPv3 authentication or privacy password in either clear ASCII text or the SHA-1 hash of the password, the password is displayed and saved in a configuration file only in hashed format, as shown in the preceding example.

For more information about the configuration of SNMP security parameters, refer to the chapter on “Configuring for Network Management Applications” in the Management and Configuration Guide for your switch.

2-14

Configuring Username and Password Security

Saving Security Credentials in a Config File

802.1X Port-Access Credentials

802.1X authenticator (port-access) credentials can be stored in a

configuration file. 802.1X authenticator credentials are used by a port to authenticate supplicants requesting a point-to-point connection to the switch.

802.1X supplicant credentials are used by the switch to establish a point-to-

point connection to a port on another 802.1X-aware switch. Only 802.1X authenticator credentials are stored in a configuration file. For information about how to use 802.1X on the switch both as an authenticator and a supplicant, see “Configuring Port-Based and Client-Based Access Control (802.1X)” in this guide.

The local password configured with the password command is no longer accepted as an 802.1X authenticator credential. A new configuration command (password port-access) is introduced to configure the local operator username and password used as 802.1X authentication credentials for access to the switch.

The password port-access values are now configured separately from the manager and operator passwords configured with the password manager and password operator commands and used for management access to the switch. For information on the new password command syntax, see “Password Command Options” on page 2-13.

After you enter the complete password port-access command syntax, the password is set. You are not prompted to enter the password a second time.

TACACS+ Encryption Key Authentication

You can use TACACS+ servers to authenticate users who request access to a switch through Telnet (remote) or console (local) sessions. TACACS+ uses an authentication hierarchy consisting of:

■ Remote passwords assigned in a TACACS+ server

■ Local manager and operator passwords configured on the switch.

When you configure TACACS+, the switch first tries to contact a designated TACACS+ server for authentication services. If the switch fails to connect to any TACACS+ server, it defaults to its own locally assigned passwords for authentication control if it has been configured to do so.

For improved security, you can configure a global or server-specific encryption key that encrypts data in TACACS+ packets transmitted between a switch and a RADIUS server during authentication sessions. The key configured on the switch must match the encryption key configured in each

2-15

Configuring Username and Password Security

Saving Security Credentials in a Config File

TACACS+ server application. (The encryption key is sometimes referred to as “shared secret” or “secret” key.) For more information, see “TACACS+ Authentication” on page 5-1 in this guide.

TACACS+ shared secret (encryption) keys can be saved in a configuration file by entering this command:

HP Switch(config)# tacacs-server key <keystring>

The option <keystring> is the encryption key (in clear text) used for secure communication with all or a specific TACACS+ server.

RADIUS Shared-Secret Key Authentication

You can use RADIUS servers as the primary authentication method for users who request access to a switch through Telnet, SSH, WebAgent, console, or port-access (802.1X). The shared secret key is a text string used to encrypt data in RADIUS packets transmitted between a switch and a RADIUS server during authentication sessions. Both the switch and the server have a copy of the key; the key is never transmitted across the network. For more information, refer to “3. Configure the Switch To Access a RADIUS Server” on page 6-14 in this guide.

RADIUS shared secret (encryption) keys can be saved in a configuration file by entering this command:

HP Switch(config)# radius-server key <keystring>

The option <keystring> is the encryption key (in clear text) used for secure communication with all or a specific RADIUS server.

SSH Client Public-Key Authentication

Secure Shell version 2 (SSHv2) is used by HP switches to provide remote access to SSH-enabled management stations. Although SSH provides Telnetlike functions, unlike Telnet, SSH provides encrypted, two-way authenticated transactions. SSH client public-key authentication is one of the types of authentication used.

Client public-key authentication uses one or more public keys (from clients) that must be stored on the switch. Only a client with a private key that matches a public key stored on the switch can gain access at the manager or operator level. For more information about how to configure and use SSH public keys to authenticate SSH clients that try to connect to the switch, refer to “Configuring Secure Shell (SSH)” on page 8-1 in this guide.

2-16

Configuring Username and Password Security

Saving Security Credentials in a Config File

The SSH security credential that is stored in the running configuration file is configured with the ip ssh public-key command used to authenticate SSH clients for manager or operator access, along with the hashed content of each SSH client public-key.

Syntax: ip ssh public-key <manager |operator> keystring

Set a key for public-key authentication.

manager: allows manager-level access using SSH public-key authentication.

operator: allows operator-level access using SSH public-key authentication.

“keystring”:. a legal SSHv2 (RSA or DSA) public key. The text string for the public key must be a single quoted token. If the keystring contains double-quotes, it can be quoted with single quotes ('keystring'). The following restrictions for a keystring apply:

■ A keystring cannot contain both single and double quotes.

■ A keystring cannot have extra characters, such as a blank

space or a new line. However, to improve readability, you can add a backlash at the end of each line.

Note The ip ssh public-key command allows you to configure only one SSH client

public-key at a time. The ip ssh public-key command behavior includes an implicit append that never overwrites existing public-key configurations on a running switch.

If you download a software configuration file that contains SSH client publickey configurations, the downloaded public-keys overwrite any existing keys, as happens with any other configured values.

2-17
