HP Dock Solutions Technical Specifications

Download

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 1

HP DOCK SOLUTIONS

Models

Docking Stations

HP USB-C Dock G5

5TW10AA

HP USB-C/A Universal Dock G2

5TW13AA

HP 4.5 mm and USB-C Dock Adapter G2

6LX61AA

HP Thunderbolt™ Dock 120W G2

2UK37AA

HP Thunderbolt™ Dock 230W G2

2UK38AA

HP Thunderbolt™ Dock G2 w/ Combo Cable

3TR87AA

HP Thunderbolt™ Dock 120W G2 w/Audio

3YE87AA

HP Thunderbolt™ Dock G2 Audio Module

3AQ21AA

HP USB-C® Dock G4

3FF69AA

HP USB-C® Universal Dock w/4.5mm Adapter

2UF95AA

HP USB-C® Universal Dock

1MK33AA

HP USB-C® Mini Dock

1PM64AA

HP USB Travel Dock

T0K30AA

HP UltraSlim Docking Station

D9Y32AA

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 2

HP USB-C Dock G5

Front and Side View

1 LED power button

2 USB 3.0 charging ports

1 Type-C® USB 3.0 port with data and power out (15W)

1 Combo audio jack

1 USB-C® cable to connect to host system (1 meter length)

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 3

HP USB-C Dock G5

Back View

2 USB 3.0 charging ports

1 HDMI 2.0 port

2 DisplayPortTM 1.4 ports

1 RJ45 port

1 Standard lock slot

Bottom View

1. Insert 4.5 mm barrel from included 120W power supply.

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 4

Components

Part number

5TW10AA

Product dimensions (L x W x H)

4.80 x 4.80 x 1.77 in (122 x 122 x 45 mm)

Package dimensions (L x W x H)

7.63 x 6.18 x 6.57 in (194 x 157 x 167 mm)

Weight

1.49 lb (0.68 kg)

Top components

LED and power button to power or wake host system1

Front components

One Type-C® USB 3.0 port with data and power out (15W) One USB-C® cable to connect to host system (1 meter cable length)

Side components

Two USB 3.0 charging ports One combo audio jack

Back components

Two USB 3.0 charging ports Two DisplayPortTM 1.4 ports One RJ45 port One HDMI 2.0 port One standard lock slot

External monitor support

3 displays is the maximum displays supported, depending on the capabilities of the host machine. Triple 4K displays requires a DP 1.4 machine with DSC2 in high res mode.

Power to system

Up to 100W via USB-C® (up to 75W on non HP machines)

Power to host (USB-C PD)

5V , 9V, 10V, 12V, 15V, 20V all at 5A MAX

Operating systems1

Win 7 Win 10 MacOS

Power Supply

120W

Power Barrel Connector

4.5mm

1. For USB-C® functionality, host PC must support the DisplayPort™ Alt mode protocol through its USB-C® port. Thunderbolt™-enabled notebooks will function at USB-C® speeds. Charging and port replication is supported on notebooks that have implemented USB-C® industry specifications. Power button to turn on or wake the system, Wake-on LAN from warm and cold dock, Wake-on LAN from S4/S5, and MAC Address

Pass-Through S0, S3, S4, S5 warm and cold dock features only function on HP or HP-supported notebooks. HP does not provide Ethernet and audio drivers on Mac PCs.

2. The DSC supported version and color format depends on GFX capability. DSC is disabled when display is attached to the VGA port or to an external DP2 VGA dongle.

Video Resolution (Continue on the next page)

This table shows which ports to use to achieve the display configuration. You must refer to the next table to see the limitations and

requirements to achieve these resolutions.

For Chrome users, dual displays are supported at full HD. Triple displays are only supported on select Chromebox machines.

For Apple users, the maximum display resolution using Apple is one display on a DP 1.4 host at UHD@60Hz.

On an Apple DP 1.2 host you will get QHD~2.5K

Display Configurations

Output ports

Single Display

(1) 2.5k Display

Any port

(1) 4k Display

Any port

(1) 5K single cable*

Either DP port

(1) 5K dual cable

Both DP ports

(1) 8K dual cable

Both DP ports

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 5

(1) 8K single cable*

Either DP port

Dual Displays

(2) FHD Displays

Any 2 ports

(2) 2.5k Displays

Any 2 ports

(1) 4K and (1) FHD

Any 2 ports

(2) 4k Displays

Any 2 ports

(1) 5K single* + 1 FHD

5K on either DP, FHD on any other port

(1) 5K dual cable + 1 FHD

Both DP ports for 5K and FHD on HDMI

Triple Displays

(3) 1680 x 1050 Displays

All 3 ports

(3) FHD Displays

All 3 ports

(2) 2.5K and (1) FHD

Any 3 ports

(3) 2.5K

All 3 ports

(1) 4K + (1) 2.5k + (1) FHD

Any 3 ports

(1) 4k and (2) 2.5k Displays

Any 3 ports

(2) 4K and (1) FHD

Any 3 ports

(3) 4K

Any 3 ports

(2) 5K single cable* and (1) 4K

5K on either DP, 4K on HDMI

*Information provided for when single cable 5K and 8K displays are available on the market.

Video Resolution

Display Configurations1

Host

High Res mode DP Alt Mode (DP x4)

Multi-Function (default)(DP x2)

DP 1.2

DP 1.3/1.4

DP 1.4w/DSC**

DP 1.2 MF

DP1.3/1.4MF

DP1.4 MF

w/DSC**

Single Display

(1) 2.5K Display

Y Y Y Y Y

(1) 4K Display

Y Y Y Y

(1) 5K single cable*

Y Y

(1) 5K dual cable

Y (D5)

(1) 8K dual cable

Y (D5)

(1) 8K single cable*

Dual Displays

(2) FHD Displays

Y Y Y Y Y

(2) 2.5K Displays

Y Y Y Y

(1) 4K and (1) FHD

Y Y Y

Y (D3)

(2) 4K Displays

Y (D1) Y Y

(1) 5K single* + 1 FHD

Y (D4) Y Y

(1) 5K dual cable + 1 FHD

Y (D5)

Triple Displays

(3) 1680 x 1050 Displays

Y Y Y Y Y

(3) FHD Displays

Y Y Y Y

(2) 2.5K and (1) FHD

Y Y Y

(3) 2.5K

Y Y

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 6

(1) 4K + (1) 2.5K + (1) FHD

Y Y

(1) 4K and (2) 2.5K Displays

Y (D1) Y Y

(2) 4K and (1) FHD

Y (D2)

(3) 4K

(2) 5K single cable* and (1) 4K

1. Assumes the host supports up to 3 simultaneous displays with no resolution limitations. Some lower power processors may have a resolution limitation.

NOTES:

D1 - Only supports up to 3840 x 2160 (UHD 4K) D2 - Only supports up to dual 3840 x 2160 (UHD 4K) and 1920 x 1080 (FHD) D3 - Only supports up to 4096 x 2160 (4K) @ 30Hz D4 - Supports up to 5120 x 2880 (5K) and 1920 x 1080 (FHD) with reduced blanking timing D5 - Both DP cables must be connected to the same graphics controller and the graphics driver must support the tile display feature under MST. Currently, no GPU (in 2019) supports tiled 5K and 8K over MST. However, it is possible that future GPUs may add this support. Unless noted, displays are driven @ 60Hz, 8bpp *Information provided for when single cable 5K and 8K displays are available on the market. ** The DSC supported version and color format depends on GFX capability. DSC is disabled when display is attached to the VGA port or to an external DP2VGA dongle FHD = 1920 x1200 or 1920 x 1080

2.5K = 2560 x 1600 or 2560 x 1440 4K = 4096 x 2160 or 3840 x 2160 5K = 5120 x 2880

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 7

HP USB-C/A Universal Dock G2

Front and Side View

1 LED power button

USB-A Adapter

1 Type-C® USB 3.0 port with data and power out (15W)

1 Combo audio jack

1 USB-C® cable to connect to host system (1 meter length)

2 USB 3.0 charging ports

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 8

HP USB-C/A Universal Dock G2

Back View

2 USB 3.0 charging ports

1 HDMI 2.0 port

2 DisplayPortTM 1.2 ports

1 RJ45 port

1 Standard lock slot

Bottom View

1. Insert 4.5 mm barrel from included 120W power supply.

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 9

Components

This table shows how to achieve the resolutions provided in the previous table. Please refer to the notes at the bottom of the table.

Part number

5TW13AA

Product dimensions (L x W x H)

4.80 x 4.80 x 1.77 in (122 x 122 x 45 mm)

Package dimensions (L x W x H)

7.63 x 6.18 x 6.57 in (194 x 157 x 167 mm)

Weight

1.53 lb (0.695 kg)

Top components

LED and power button to power or wake host system1

Front components

One Type-C® USB 3.0 port with data and power out (15W) One USB-C® cable to connect to host system (1 meter cable length)

Side components

Two USB 3.0 charging ports One combo audio jack

Back components

Two USB 3.0 charging ports Two DisplayPortTM 1.2 ports One RJ45 port One HDMI 2.0 port One standard lock slot

External monitor support

Maximum resolution is triple 4K displays, depending on the capabilities of the host machine (see below tables for configurations required).

Power to system

Up to 100W via USB-C® (up to 75W on non HP machines)

Power to host (USB-C PD)

5V, 9V, 10V, 12V, 15V, 20V all at 5A MAX

Operating systems

Win 7 Win 10 Chrome OS MacOS

Drivers

DisplayLink drivers must be downloaded either through the HP support site or via Microsoft Windows updates.

Power Supply

120W

Power Barrel Connector

4.5mm

Address Pass-Through S0, S3, S4, S5 warm and cold dock features only function on HP or HP-supported notebooks. HP does not provide Ethernet and audio drivers on Mac PCs.

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 10

Video Resolution

Display Configurations1

DP1

DP2

HDMI

Host

Multi-Function (default)(x2 DP)

DP 1.2 MF

DP1.3/1.4MF

DP1.4 MF

w/DSC

Single Display

(1) 4K Display

Any port

(1) 5K dual cable

Both DP ports

Dual Displays

(2) 4K Displays

Any 2 ports *D1

(1) 5K dual cable + (1) 2.5K

Both DP ports for 5K and 2.5K on

HDMI

Y Y Y

(1) 5K dual cable + (1) 4K

Both DP ports for 5K and 4K on HDMI

Y (D2)

Y (D1)

Triple Displays

(3) 2.5K Displays

All 3 ports

Y Y Y

(2) 4K Displays + (1) 2.5K

4K on DP ports *D1, 2.5k on HDMI

Y Y Y

(3) 4K Displays

4K on DP ports *D1 and 4K on HDMI

Y (D2)

Y (D1)

High Res Video Resolution

Display

Configurations/High

Resolution Mode1

DP1

DP2

HDMI

Host

High Res mode DP Alt Mode (DP x4) **

DP 1.2

DP1.3/1.4

DP1.4 w/DSC

Single Display

(1) 4K Display

Any port2 Y Y

Dual Displays

(2) 4k Displays

Any 2 ports; DP ports limited to UHD 4K2

Y Y Y

Triple Displays

(3) 4K Displays

4K on both DP ports (D1) and 4K on HDMI2

Y Y Y

1. Assumes the host supports up to 3 simultaneous displays with no resolution limitations. Some lower power processors may have a resolution limitation.

2. In High Res mode, DisplayLink is running at USB2.0 speeds. This has a significant performance impact on DP1 and DP2 output.

NOTES:

D1 - Only supports 3840 x 2160 (UHD 4K) D2 - Only supports 4096 x 2160 (4K @ 30Hz) on HDMI **DP host is only applicable to the HDMI output when BOTH DP ports are active, or when the host is in High Res mode Unless noted, displays are driven @ 60Hz, 8bpp FHD = 1920 x 1200 or 1920 x 1080

2.5K = 2560 x 1600 or 2560 x 1440 4K = 4096 x 2160 or 3840 x 2160 5K = 5120 x 2880

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 11

HP 4.5 mm and USB-C Dock Adapter G2

1 Type-C® USB 3.0 port to connect your HP USB-C/A Universal Dock G2 Type-C® cable

1 4.5 mm barrel AC adapter (65 W)

1 Type-A USB 3.0 Plug Port

HP 4.5 mm and USB-C Dock Adapter G2 shown with the HP USB-C/A Universal Dock G2

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 12

Components

Part number

6LX61AA

Model Number

HSA-Q001

Dimensions

without cable: 1.77 x 1.33 x 0.39 in (45 x 34 x 10 mm) with cable: 8.14 x 1.33 x 0.39 in (206.9 x 34 x 10 mm)

Weight

0.053 lb (0.024 kg)

Front components

1 Type-A USB 3.0 Plug Port (USB signal only) 1 x 4.5 mm DC Barrel Plug Connector (Power only)

Rear components

USB-C Receptacle (USB signal + PD power)

Input power

20V/3.3A (66W) max

Output power

20V/3.25A (65W) max

Operating systems

Windows 7 and above, Windows10 S4, Chrome

Normal operation voltage

20V

Average operation power

0.7W

Max operation power

Temperature (operation)

32~104 F (0~°C)

Temperature (non-operation)

-4~140 F (-20~+60°C)

Relative humidity (operation)

20%~90% RH, non-condensing

Relative humidity (non-operation)

20%~95% RH, non-condensing

Altitude (operation)

10000ft (3048m)

Altitude (non-operation)

30000ft (9144m)

Shock (operation)

40G, 2 ms, half-sine

Shock (non-operation)

240G, 2 ms, half-sine

Random vibration (operation)

~0.21Grms, 50~2000 Hz

Random vibration (non-operation)

~2.09Grms, 50~2000, non-operating

Option kit contents

HP 4.5mm and USB-C Dock Adapter G2

Dock compatibility

HP USB-C/A Universal Dock G2

NOTE: The HP 4.5mm and USB-C Dock Adapter G2 is only compatible with the HP USB-C/A Universal Dock G2.

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 13

HP Thunderbolt™ Dock G2– Left View (120W/230W)

1 power button

1 headphone/microphone combo jack

1 Type-C® USB 3.1 Gen 2 port with data and power out (15W)

1 USB 3.0 charging port

1 USB-C® cable to connect to host system (0.7m cable length)

1 standard lock slot

1. The dock power button is not functional when connected to non-supported HP notebooks or non-HP notebooks.

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 14

HP Thunderbolt™ Dock G2 – Back side (120W/230W)

2 USB 3.0 ports

11.

1 Ethernet port

1 VGA port

12.

1 AC Adapter connector (7.4mm)

2 DisplayPort™ 1.4 ports

13.

1 Thunderbolt™ port

10.

1 Type-C® USB 3.1 Gen 2 port with DisplayPort™ 1.4 data and power out (15W)

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 15

Components

Part Number

2UK37AA

Ports

1 Type-C® USB 3.1 Gen 2 port with data and power out (15W) 1 Type-C® USB 3.1 Gen 2 port with DisplayPort™ 1.4 data and power out (15W) 1 USB-C® Thunderbolt™ port 2 USB 3.0 ports 1 USB 3.0 charging port 1 power adapter port 2 DisplayPort™ 1.4 ports 1 Ethernet port (10/100/1000) 1 combo audio port 1 standard lock slot

Dimensions (H x W x D)

3.9 x 3.9 x 2.7 in (98 x 98 x 69 mm)

Weight

1.76 lb (0.8 kg)

Top components

LED and power button to power or wake host system1

Front components

One Type-C® USB 3.1 Gen 2 port with data and power out (15W) One USB-C® cable to connect to host system (0.7meter cable length)

Side components

One USB 3.0 charging port One combo audio Jack One standard lock slot

Back components

One Thunderbolt™ port One Type-C® USB 3.1 Gen 2 port with DisplayPort™ 1.4 data and power out (15W) Two DisplayPort™ 1.4 ports One VGA port Two USB 3.0 ports One RJ45 port AC adapter connector (7.4mm)

Network manageability features

PXE Boot Wake on LAN (from the Off, Sleep or Hibernation States2) MAC Address Pass-Through (from the On, Off, Sleep or Hibernation States3) WLAN-LAN Switching4

External monitor support

Up to 4

Power delivery (PD) Profiles

5V/5A, 9V/5A, 12V/5A, 15V/5A, 20V/5A

Power to system

Up to 100W (up to 75W on non HP machines)

Operating voltage and current

19.7 V dc @ 6.1 A – 120W

19.7 V dc @ 11.8 A – 230W

Temperature (operating)

0 C to 35 C (32 F to 95 F)

Relative humidity noncondensing (operating)

10 % to 90 %

Maximum altitude unpressurized (operating)

15 m to 3,048 m (- 50 ft to 10,000 ft)

Operating Systems5

Win 7, Win 10 and MacOS

1. Requires host notebook to support in its BIOS.

2. Your computer might support Wake On LAN from the Off, Sleep or Hibernate States, or only when the computer is On or in Sleep.

3. Your computer might support MAC Address Pass-Through the On, Off, Sleep or Hibernate States, or only when the computer is On or in Sleep.

4. WLAN – LAN switching is supported only on select computers running Windows 10 operating system.

5. The HP Thunderbolt™ Dock G2 is designed to USB-C®/Thunderbolt™ Industry specs and will support charging and port replication for

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 16

notebooks that have implemented USB-C® and Thunderbolt™ industry specifications. Thunderbolt™ host systems require Thunderbolt™ software (minimum SW17.x). Ethernet and audio drivers need to be installed separately on non-HP Windows systems for headset auto switching functionality. Drivers available on HP Support website. For MacOS PCs, HP does not provide Ethernet and audio drivers. Firmware updates on Window-based host systems only. Certain features are not functional on non-HP supported nor non-HP notebooks (see points below): Power button to turn on or wake the system. Wake on LAN from warm and cold dock. Wake on LAN from S4/S5. MAC Address Pass-Through S0, S3, S4, S5 warm and cold dock.

HP Thunderbolt™ Dock G2 Video resolution specifications

HP Thunderbolt™ Dock G2 video resolution specifications when the dock is connected to a Thunderbolt™ system:

Host Specification

# of displays

Resolution

Supported configuration

DP 1.2 Thunderbolt™ host

(1) 4096x2160 @ 60Hz

1 DP or 1 TB or

1 USB-C® alt mode

(2) 4096 x 2160 @

60Hz

1 DP + 1 TB port or

1 USB-C® Alt mode port + 1 TB port

(1) 4096 x 2160 @

60Hz +

(2) 2560 x 1440 @

60Hz

(1) 4096 x 2160 @ 60Hz from TB port

(2) 2560x1440 @ 60Hz from DP ports or DP + USB-

C® Alt

(1) 4096 x 2160 @

60Hz +

(2) 2560 x 1440 @

60Hz+

(1) 1920 x 1080 @

60Hz

(1) 4096 x 2160 @ 60Hz from TB port

(2) 2560x1440 @ 60Hz from DP ports or DP + USB-

C® alt

(1) 1920 x 1080 @ 60Hz from DP or USB-C® Alt

mode

Host Specification

# of displays

on dock

Resolution

Supported configuration

DP 1.3 Thunderbolt™ host

(1) 5120 × 2880 @

60Hz

1 DP or 1 TB or

1 USB-C® alt mode

(2) 4096 x 2160 @

60Hz

1 DP + 1 TB port or

1 USB-C® alt mode + 1 TB port

(2) 3840 x 2160 @

60Hz

2 DP ports or

1 DP + 1 USB-C® Alt mode port or

1 DP + 1 TB port or

1 TB + 1 USB-C® alt mode

(2) 3840 x 2160 @

60Hz +

(1) 1920 x 12000 @

60Hz

(2) 3840 x 2160@60Hz from DP ports or DP + USB-

C® alt

(1) 1920x1200 @ 60Hz from TB port

(3) 2560 x 1600 @

60hz

2 DP ports + USB-C® Alt mode

(1) 3840 x 2160 @

60Hz +

(2) 2560 x 1440 @

60Hz+

(1)1920 x 1200 @ 60Hz

(1) 3840x2160 @ 60Hz from DP or USB-C® Alt

mode

(2) 2560x1440 @ 60Hz from DP ports or DP + USB-

C® alt

(1) 1920 x 1200@ 60Hz from TB port

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 17

NOTE: Chart is based on 8bit DP1.2 displays (except for 5120x2880 single cable display) NOTE: with a DP1.3 Thunderbolt™ host, when 3 or more displays are attached, the Thunderbolt™ port is limited to a 1920x1200 @ 60hz DP1.2 display, or a 2560x1440@60hz DP1.3 display.

HP Thunderbolt™ Dock G2 video resolution specifications when the dock is connected to a USB-C® alt-mode system1:

Host Specification

# of monitors

DP 1.2 USB-C® host

2560x1440 @ 60Hz

1920x1200 @ 60Hz

(1) 1920x1200 @ 60Hz (2) 1280x768 @ 60Hz

DP 1.3 USB-C® host

3840x2160 @ 60hz

2560x1600 @ 60Hz

(1) 2560x1600 @ 60Hz (2) 1680x1050 @ 60Hz

1680 x 1050 @ 60Hz (requires MST)

1. USB-C® systems will perform at USB 3.0 Gen1 speeds Thunderbolt™ port will function as a USB 2.0 port with only data and power out (15W); no video

HP Thunderbolt™ Dock G2 cable types

HP TB Dock G2 120W cable

HP TB Dock G2 230W cable*

HP TB Dock G2 Combo Cable*

Part #: 3XB94AA

Part #: 3XB95AA

Part #: 3XB96AA

*NOTE: Requires 230W AC adapter

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 18

HP Thunderbolt™ Dock 120W G2 w/Audio– Left View

LED indicator (power button to power, wake, sleep host system)1

Hang up / decline call

1 Type-C(R) USB 3.1 Gen 2 port with data and power out (15W)

Pick up / accept / hold call

1 headphone/microphone combo jack

Mic Mute

1 USB 3.0 charging port

Volume down

10.

1 standard lock slot

Volume up

11.

1 USB-C® cable to connect to host system (0.7m cable length)

1. The dock power button is not functional when connected to non-supported HP notebooks or non-HP notebooks.

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 19

HP Thunderbolt™ Dock 120W G2 w/Audio – Back View

11.

2 USB 3.0 ports

15.

1 Ethernet port

12.

1 VGA port

16.

1 AC adapter connector (7.4mm)

13.

2 DisplayPort™ 1.4 ports

17.

1 Thunderbolt™ port

14.

Type-C® USB 3.1 Gen 2 port with DisplayPort™ 1.4 data and power out (15W)

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 20

Components

Part Number

3YE87AA

Ports

1 Type-C® USB 3.1 Gen 2 port with data and power out (15W) 1 USB-C® cable to connect to host system (0.7m cable length) 1 USB 3.0 charging port 1 combo audio jack 1 standard lock slot 1 Thunderbolt™ port 1 Type-C® USB 3.1 Gen 2 port with DisplayPort™ 1.4 data and power out (15W) 2 DisplayPort™ 1.4 ports 1 VGA port 2 USB 3.0 ports 1 RJ45 port 1 AC adapter

Dimensions (H x W x D)

3.9 x 3.9 x 4.5 in (98 x 98 x 114 mm)

Weight

2 lb (0.91 kg)

Top components

LED indicator (power button to power1, wake, sleep host system) Pick up / accept / hold call Mic mute Volume up Volume down Hang up / decline call

Front components

One USB-C® port with data and power out (15W) One USB-C® cable to connect to host system (0.7m cable length)

Side components

One USB 3.0 charging port One combo audio jack One standard lock slot

Back components

One Thunderbolt™ port One Type-C® USB 3.1 Gen 2 port with DisplayPort™ 1.4 data and power out (15W) Two DisplayPort™ 1.4 ports One VGA port Two USB 3.0 ports One RJ45 port One AC adapter

Network manageability features

PXE Boot Wake on Lan (from the Off, Sleep or Hibernation States2) MAC Address Pass-Through (from the On, Off, Sleep or Hibernation States3) WLAN-LAN Switching4

External monitor support

Maximum resolution is triple 4K5 displays, depending on the capabilities of the host machine (see below tables for configurations required).

Power delivery (PD) profiles

PD 3.0: 5V/5A, 9V/5A, 12V/5A, 15V/5A, 20V/5A

Speaker rated power

Operating voltage and current

19.7 V dc @ 6.1 A – 120W

19.7 V dc @ 11.8 A – 230W

Temperature (operating)

0° C to 35° C (32° F to 95° F)

Relative humidity noncondensing (operating)

10 % to 90 %

Maximum altitude unpressurized

15 m to 3,048 m (- 50 ft to 10,000 ft)

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 21

(operating)

Operating systems

Win 7, Win 10 and MacOS5

LED colored ring

Incoming call (blinking green) On call (solid green) On muted call (solid red) Hold (blinking green)

Speakers/mics

Two side-firing speakers and two microphones

Microphone type

Omni-directional

Analog audio

Yes

Number of channels

Stereo (left and right channels)

Power to system

Up to 100W via USB-C® (up to 75W on non HP machines)

1. The dock power button is not functional when connected to non-supported HP notebooks or non-HP notebooks.

2. Your computer might support Wake On Lan from the Off, Sleep or Hibernate States, or only when the computer is On or in Sleep.

3. Your computer might support MAC Address Pass-Through the On, Off, Sleep or Hibernate States, or only when the computer is On or in Sleep.

4. WLAN – LAN switching is supported only on select computers running Windows 10 operating system.

5. The HP Thunderbolt™ Dock G2 is designed to USB-C®/Thunderbolt™ Industry specs and will support charging and port replication for notebooks that have implemented USB-C® and Thunderbolt™ industry specifications. Thunderbolt™ host systems require Thunderbolt™ software (minimum SW17.x).

Ethernet and audio drivers need to be installed separately on non-HP Windows systems for headset auto switching functionality. Drivers available on HP website. For MacOS PCs, HP does not provide Ethernet and audio drivers. Firmware updates on Window-based host systems only. Certain features are not functional on non-HP supported nor non-HP notebooks:

• Power button to turn on or wake the system.

• Wake on LAN from warm and cold dock.

• Wake on LAN from S4/S5.

• MAC Address Pass-Through S0, S3, S4, S5 warm and cold dock.

NOTE: For video specifications, please refer to page 16 of this quick specs

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 22

HP Thunderbolt™ Dock G2 Audio Module

LED indicator (power button to power, wake, sleep host system)

Volume down

Pick up / accept / hold call

Volume up

Mic Mute

Hang up / decline call

1. The dock power button is not functional when connected to non-supported HP notebooks or non-HP notebooks.

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 23

Components

Part Number

3AQ21AA

Dimensions (H x W x D)

3.9 x 3.9 x 1.28 in (98 x 98 x 32.5 mm)

Weight

0.66 lb (0.30 kg)

Top cover buttons

LED indicator (power button to power, wake, sleep host system) Pick up / accept / hold call Mic Mute Volume up Volume down Hang up / decline call

LED colored ring

Incoming call (blinking green) On call (solid green) On muted call (solid red) Hold (blinking green)

Speakers/mics

Two side-firing speakers and two microphones

Microphone type

Omni-directional

Analog audio

Yes

Number of channels

Stereo (left and right channels)

Speaker rated power

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 24

HP USB-C® Dock G4 - Front View

1 power button

1 USB 3.0 port with data and power out only

1 combo audio jack

1 USB-C® port connects to computers

1 USB-C® port with power and data out only

1 standard lock slot

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 25

HP USB-C® Dock G4- Rear View

1 Smart AC adapter

10.

1 HDMI 2.0 port

1 powered USB 3.0 port, 2 USB 2.0 ports

11.

2 DisplayPort™ ports

1 Gigabit Ethernet port

Components

Part Number

3FF69AA

Ports

1 USB 3.0 port with data and power out only 1 USB-C® port with data and power out only 1 Combo audio jack connects to headphone 1 power button to power and wake host system4 1 Smart AC adapter 1 powered USB 3.0 port 2 USB 2.0 ports 1 Gigabit Ethernet port 1 HDMI 2.0 port 2 DisplayPort™ ports 1 USB-C® port3 connects to computers 1 standard lock slot

Dimensions (H x W x D)

7.79 x 2.71 x 0.87 in (198 x 69 x 22 mm)

Weight

0.77 lb (0.36 kg)

Resolution

Single display: up to 3840 x 1440 @ 60Hz Dual display: up to 1920 x 1200 @ 60Hz Triple display: up to 1680 x 1050 @ 60Hz

Front components

One USB 3.0 port with data and power out only USB-C® port with power and data out only Combo audio jack connects to headphone Power button to power and wake host system4

Side / rear components

Smart AC adapter One powered USB 3.0 port Two USB 2.0 ports Gigabit Ethernet port

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 26

One HDMI 2.0 port Two DisplayPort™ ports One USB-C® port3 connects to computers One standard lock slot

Normal operating power

90W

Average operation power 65W

Max operating power 100W

Power Delivery (PD) profile

USB-C® PD 3.0 supporting 5V/3A, 9V/3A,10V/3A, 12V/3A, 15V/3A and 20V/3A

USB-C® power to Host

Up to 60W

Temperature (operating)

32 to 104 F (0 to +40C)

Relative humidity (operating)

0%~90%RH

Altitude (operating)

10000 ft (3048m)

Shock (operating)

40G, 2ms duration, half-sine wave shock

Random vibration (operating)

1.043g

Operating Systems

Windows 10, Windows 10 mobile

Option kit contents

HP USB-C® Dock G4, AC power cable, 90W A/C Adapter, USB-C® (1m) cable, documentation

1. Supports DisplayPort™ Alt Mode (video, charging and USB 3.1) over the USB-C® connector. Also compatible with USB Type-C® Thunderbolt™ enabled ports.

2. The dock power button is not functional when connected to non-supported HP notebooks or non-HP notebooks. Power button is not functional with Chromebooks.

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 27

HP USB-C® Universal Dock - Front View

1 USB 3.0 charging/data port

1 Combo audio port

1 USB-C® charging/data port

HP USB-C® Universal Dock - Rear View

2 Dual DisplayPort™ ports

1 power adapter port

1 Ethernet port

1 standard lock slot

3 USB 2.0 ports

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 28

Components

Part Number

1MK33AA

Ports

1 USB-C® charging/data port 4 USB ports (1 USB 3.0, 3 USB 2.0) 1 power adapter port 2 DisplayPort™ ports 1 Ethernet port (10/100/1000) 1 combo audio port 1 standard lock slot

Dimensions (H x W x D)

7.87 x 2.76 x 1.1 in (200 x 70 x 28 mm)

Weight

0.77 lb (0.35 kg)

Video resolution

Single display: up to 5120 x 2880 @ 60Hz, Dual display: up to 3840 x 2160 @ 60Hz

Front components

One powered USB 3.0 port, One USB-C® port (data), Combo Audio Jack

Rear components

Two DisplayPort™ ports, Gigabit Ethernet port, Three USB 2.0 ports, AC adapter power connector

Side components

One standard lock slot, One USB-C® cable that connects to computers

Network manageability features

PXE Boot Wake On Lan (WoL)

NOTE: your computer might support WoL from the Off, Sleep or Hibernation States, or only when the computer is On or in Sleep.

MAC Address Pass Through

WLAN – LAN switching

Power Delivery (PD) profile

USB-C® PD 3.0 supporting 5V/3A, 9V/3A, 10V/3A, 12/3A, 15V/3A, 20V/3A

USB-C® power to Host

Up to 60W

Operating systems

Windows 7 and above, Windows10 S3, Chrome4, MacOS

1. Your computer might support MAC Address Pass Through from the On, Off, Sleep or Hibernation States, or only when the computer is On or in Sleep; supported for UEFI PXE Boot);

2. Supported only on select computers running Windows 10 operating system.

3.To install the dock drivers on computers running Windows 10 S operating system, run Windows Update.

4. Chrome PCs: native DisplayLink Driver into the OS. Realtek Ethernet drivers not available on Chrome PCs

5. MacOS PCs: DisplayLink drivers for MacOS PCs must be downloaded separately from DisplayLink website. Realtek driver for Ethernet must also be installed (drivers not provided by HP)

NOTE: The HP USB-C® Universal Dock is designed to USB-C® Industry specs and will support charging and port replication for notebooks that have implemented USB-C® and Thunderbolt™ industry specifications. Certain features are not functional on non-HP supported nor non-HP notebooks (see points below): Wake on LAN from warm and cold dock. Wake on LAN from S4/S5. MAC Address Pass-Through S0, S3, S4, S5 warm and cold dock.

Stand-alone power requirements

Normal Operating Voltage

19.5V

Average Operating Power

77W

Max Operating Power

88W

Temperature

Operating

32~104 °F (0~40 °C)

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 29

Non-operating

-4~140 °F (-20~+60 °C)

Relative humidity

Operating

5%~90% RH, non-condensing

Non-operating

5%~95% RH, non-condensing

Altitude

Operating

10000 ft (3048 m)

Non-operating

30000 ft (9144 m)

Shock

Operating

40G, 2ms, half-sine

Non-operating

240G, 2ms, half-sine

Random vibration

Operating

~0.21g, 5~500 Hz

Non-operating

~2.09g, 5-500 Hz, Non-Operating

Option Kit Contents

HP USB-C® Universal Dock, AC power cord, 90W A/C adapter, USB-A to USB-C® adapter, and documentation

Part Number

1MK33AA

HP USB-C® Universal Dock w/4.5mm Adapter- Front View

1 USB 3.0 charging/data port

1 Combo audio port

1 USB-C® charging/data port

1 Adapter (4.5mm)

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 30

Components

Part Number

See Option Kit Contents for part numbers below

Ports

1 USB-C® charging/data port 4 USB ports (1 USB 3.0, 3 USB 2.0) 1 power adapter port 2 DisplayPort™ ports 1 Ethernet port (10/100/1000) 1 combo audio port 1 standard lock slot

Dimensions (H x W x D)

7.87 x 2.76 x 1.1 in (200 x 70 x 28 mm)

Weight

0.77 lb (0.35 kg)

Video resolution

Single display: up to 5120 x 2880 @ 60Hz, Dual display: up to 3840 x 2160 @ 60Hz

Front components

One powered USB 3.0 port One USB-C® port (data) One combo audio jack

Rear components

Two DisplayPort™ ports One Gigabit Ethernet port Three USB 2.0 ports One AC adapter power connector

Side components

One standard lock slot, One USB-C® cable that connects to computers

Network manageability features

PXE Boot Wake On Lan (WoL) MAC Address Pass Through

WLAN – LAN switching

NOTE: Your computer might support WoL from the Off, Sleep or Hibernation States, or only when the computer is On or in Sleep

Power Delivery (PD) profile

USB-C® PD 3.0 supporting 5V/3A, 9V/3A, 10V/3A, 12/3A, 15V/3A, 20V/3A

Operating systems

Windows 7, Windows10 S3, Chrome4, MacOS5

1. Your computer might support MAC Address Pass-Through from the On, Off, Sleep or Hibernation States, or only when the computer is On or in Sleep; supported for UEFI PXE Boot);

2. Supported only on select computers running Windows 10 operating system.

3.To install the dock drivers on computers running Windows 10 S operating system, run Windows Update.

4. Chrome PCs: native DisplayLink Driver into the OS. Realtek Ethernet drivers not available on Chrome PCs

5. MacOS PCs: DisplayLink drivers for MacOS PCs must be downloaded separately from DisplayLink website. Realtek driver for Ethernet must also be installed (drivers not provided by HP) NOTE: The HP USB-C® Universal Dock is designed to USB-C® Industry specs and will support charging and port replication for notebooks that have

implemented USB-C® and Thunderbolt™ industry specifications. Certain features are not functional on non-HP supported nor non-HP notebooks (see points below): Wake on LAN from warm and cold dock. Wake on LAN from S4/S5. MAC Address Pass-Through S0, S3, S4, S5 warm and cold dock.

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 31

Stand-alone power requirements

Normal Operating Voltage

19.5V

Average Operating Power

77W

Max Operating Power

88W

Temperature

Operating

32~104 °F (0~40 °C)

Non-operating

-4~140 °F (-20~+60 °C)

Relative humidity

Operating

5%~90% RH, non-condensing

Non-operating

5%~95% RH, non-condensing

Altitude

Operating

10000 ft (3048 m)

Non-operating

30000 ft (9144 m)

Shock

Operating

40G, 2ms, half-sine

Non-operating

240G, 2ms, half-sine

Random vibration

Operating

~0.21g, 5~500 Hz

Non-operating

~2.09g, 5-500 Hz, Non-Operating

Contents

HP USB-C® Universal Dock with no Flash Drive, 4.5mm and USB Dock Adapter, AC power cord, 90W A/C adapter and documentation

Drivers

HP USB-C® Universal Dock (1MK33AA) Drivers are on the dock HP USB-C® Universal Dock with USB & 4.5mm Adapter (2UF95AA) Drivers are on the dock. HP USB-C® Universal Dock Non-Flash with USB & 4.5mm Adapter (3DV65AA) Dock drivers

need to be downloaded via the web:

1. Go to http://www.hp.com/support

2. Follow the online instructions to get software and drivers

Option Kit Contents

HP USB-C® Universal Dock (1MK33AA)

HP USB-C® Universal Dock, AC power cord, 90W A/C adapter, USB-A to USB-C® adapter, and documentation HP USB-C® Universal Dock with USB & 4.5mm Adapter (2UF95AA) HP USB-C® Universal Dock, AC power cord, 90W A/C adapter, USB-A to USB-C® adapter, and documentation

HP USB-C® Universal Dock Non-Flash with USB & 4.5mm Adapter (3DV65AA) HP USB-C® Universal Dock with no Flash Drive, 4.5mm and USB Dock Adapter, AC power cord, 90W A/C adapter and documentation

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 32

HP USB-C® Universal Dock Cables and Adapters

HP USB-A to USB-C® Adapter (3RV49AA)

NOTE: Included with HP USB-C® Universal Dock (1MK33AA)

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 33

HP USB-C® Mini Dock - Front View

1 USB-C® charging/data port

HP USB-C® Mini Dock - Rear View

1 HDMI port

1 Ethernet port

1 VGA port

2 USB-A ports (1 USB 3.0, 1 USB 2.0)

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 34

Components

Part Number

1PM64AA

1 USB-C® charging/data port 2 USB ports (1 USB 3.0, 1 USB 2.0) 1 Ethernet port (10/100/1000) 1 VGA port 1 HDMI

Dimensions (H x W x D)

5.7 x 2.17 x 0.69 in (145x55x17.5 mm)

Weight

0.29 lb (0.132 kg)

Video resolution

Only single display supported HDMI: 4096 x 2160 @ 30Hz VGA: 1920 x 1080

Network manageability features

PXE Boot Wake On Lan (WoL)

NOTE: Your computer might support WoL from the Off, Sleep or Hibernation States, or only when the computer is On or in Sleep.

MAC Address Pass Through

NOTE: Your computer might support MAC Address Pass-Through from the On, Off, Sleep or Hibernation States, or only when the computer is On or in Sleep; supported for UEFI PXE Boot)

WLAN – LAN switching

NOTE: Supported only on select computers running Windows 10 operating system.

Power Delivery (PD) profiles

USB-C® PD 3.0 supporting 90W, 65W, 45W, 15W and 10W USB-C® AC Adapters (not included) 90W USB-C® AC Adapter supports 5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/3A 65W USB-C® AC Adapter supports 5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/2.25A 45W USB-C® AC Adapter supports 5V/3A, 9V/3A, 12V/2.3A, 15V/2A 15W USB-C® AC Adapter supports 5V/1A 10W USB-C® AC Adapter supports 5V/0.5A

Option Kit Contents

HP USB-C® Mini Dock, Documentation

Maximum power provided to the notebook

60W (requires 90W power supply)

Stand-alone power requirements

Normal Operating Voltage

Average Operating Power

12W

Max Operating Power

15W

Temperature

Operating

32~104 °F (0~40 °C)

Non-operating

-4~140 °F (-20~+60 °C)

Relative humidity

Operating

5%~90% RH, non-condensing

Non-operating

5%~95% RH, non-condensing

Altitude

Operating

10000 ft (3048 m) @2 hours

Non-operating

30000 ft (9144 m) @ 2 hours

Shock

Operating

40G, 2ms, half-sine

Non-operating

240G, 2ms, half-sine

Random vibration

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 35

Operating

~0.21g, 5~500 Hz

Non-operating

~2.09g, 5-500 Hz, Non-Operating

HP USB Travel Dock - Front View

USB ports (2)

HP USB Travel Dock - Rear View

1 Ethernet port

1 HDMI port

1 VGA port

Components

Ports

2 USB ports (1 USB 3.0, 1 USB 2.0) 1 Ethernet port (10/100/1000) 1 VGA port 1 HDMI

Dimensions (W x D x H)

5.0 x 1.5 x 0.75 in (127 x 38.1 x 19 mm)

Weight

0.21 lb (0.095 kg)

Power requirements

Powered from VBUS

5 Volts/3 Amps

Operating Systems Supported

Microsoft-Windows XP/Vista/Win7/Win8.1/Win10 (install updated driver)

Option Kit Contents

HP USB Travel Dock, documentation

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 36

HP UltraSlim Docking Station – Front side

2 docking posts

1 connection button

2 locking mechanism

1 power on/off

1 docking station cable lock slot

HP UltraSlim Docking Station – Rear side

1 standard lock slot

12.

3 USB 3.0 ports

1 docking station cable lock slot

13.

1 USB 3.0 charging port

1 side docking connector

14.

1 power connector

1 VGA port

15.

1 line in jack

10.

1 LAN/Ethernet port

16.

1 line out jack

11.

2 DisplayPort™

Components

Part Number

D9Y32AA

Ports

1 standard lock slot 1 docking station cable lock slot 1 side docking connector 1 VGA port 1 LAN/Ethernet port 1 1Gb LAN/Ethernet port (10/100/1000) 3 USB 3.0 ports 1 USB 3.0 charging port 1 power connector 1 line in jack 1 line out jack

Dimensions (H x W x D)

1.7 x 14.5 x 4.2 in (44 x 368x 107 mm)

Weight

1.69 lb (0.76 kg)

Front components

Two Docking posts Two Computer connect/ release mechanisms One Docking connector

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 37

One Connect button One Power on/off button

Rear components

One standard lock slot One docking station cable lock slot One Side docking connector One VGA port One LAN/Ethernet port One 1Gb LAN/Ethernet port (10/100/1000) Three USB 3.0 ports One USB 3.0 charging port One Power connector One Line in jack One Line out jack

NOTE: Your computer, docking station, and monitor must all support USB 3.0 and DisplayPort™ 1.2 to benefit from the advanced speeds or features that these technologies provide. If one of the devices does not support these technologies, you will still have USB 2.0 and DisplayPort™

1.1 functionality.

Stand-alone power requirements

Normal Operating Voltage

18.5 V

Average Operating Power

18.5 W

Max Operating Power

< 65 W

Temperature

Operating

32° to 95° F (0° to 35° C)

Non-operating

4° to 140° F (-20° to 60° C)

Relative humidity

Operating

10% to 90%, non-condensing

Non-operating

5% to 95%, 101.6° F (38.7° C) maximum wet bulb temperature

Altitude

Operating

-50 to 10,000 ft (-15.24 to 3,048 m)

Non-operating

-50 to 40,000 ft (-15.24 to 12,192 m)

Shock

Operating

125 G, 2 ms, half-sine

Non-operating

200 G, 2 ms, half-sine

Random vibration

Operating

0.75g

Non-operating

1.50g

Option Kit Contents

HP UltraSlim Docking Station, AC power adapter, documentation

Part Number

D9Y32AA

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 38

COMPATIBILITY

HP Dock Solutions are compatible with HP notebooks as follows:

Docking Station

Compatible Notebooks

Check your notebook power requirements. If your HP notebook requires more than 100W of power, you must use your notebook power supply in addition to the USB-C dock connection. This is true for most workstations and notebooks that have discreet graphics cards, including models listed below with *.

HP USB-C® Dock G5

HP Elite x2 1012 G2, G4 HP Elite x2 1013 G1, G3, G4 HP EliteBook Folio G1 HP Elite Dragonfly HP EliteBook 1030 G4 HP EliteBook x360 1030 G2, G3, G4, G7 HP EliteBook x360 1040 G4, G5, G6, G7 HP EliteBook 1050 G1 HP EliteBook 800 series G5, G6, G7 HP EliteBook 800 HC series G5, G6 HP EliteBook 840r G4 HP EliteBook 700 series G5, G6 HP ProBook 600 series G4, G5, G7 HP ProBook 400 series G5, G6, G7, G8 HP Probook x360 435 G7 HP ProBook x360 440 G1 HP Pro x2 612 G2 HP ZBook x2 G4 HP ZBook Firefly 14 G7 HP ZBook Firefly 15 G8 HP ZBook 14u/15u G5 HP ZBook 15/17 G5* HP ZBook Power G7 HP ZBook Fury 15/17 G7* HP ZBook Create G7* HP ZBook Studio G7* HP ZBook Studio x360 G5* HP ZHAN 66 Pro 13/14/15 G2 HP ZHAN 66 Pro 14 G4 HP ZHAN 66 Pro 14/A14/15 G3 HP ZHAN 66 AMD Pro 14 G3

HP USB-C/A Universal Dock G2

HP Elite x2 1012 G2, G4 HP Elite x2 1013 G1, G3, G4 HP EliteBook Folio G1 HP Elite Dragonfly HP EliteBook 1030 G4 HP Elitebook 1040 G4 HP EliteBook x360 1020 G2 HP EliteBook x360 1030 G2, G3, G4, G7 HP EliteBook x360 1040 G4, G5, G6, G7 HP EliteBook 1050 G1 HP EliteBook 800 series G5, G6, G7 HP EliteBook 820 G5 HP EliteBook 840 G32 HP EliteBook 800 HC series G5, G6 HP EliteBook 840/820 G3

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 39

HP EliteBook 850 G42 HP EliteBook 840r G4 HP EliteBook 700 series G5, G6 HP ProBook 600 series G4, G5, G7 HP ProBook 640 G22 HP ProBook 400 series G5, G6, G7, G8 HP ProBook 430 G4 HP ProBook 470 G7 HP Probook x360 435 G7 HP ProBook x360 440 G1 HP Pro x2 612 G2 HP ProBook x360 11 EE G3, G4 G5, G61 HP 340/340S/348 G7, G81 HP 240/245/255 G7, G82 HP Chromebook 11/11a EE G6, G7 HP Chromebook 14 G5 HP Chromebook x360 11 G1, G2 HP Chromebox G3 HP ZBook x2 G4 HP ZBook Firefly 14 G7 HP ZBook Firefly 15 G8 HP ZBook 14u/15u G5 HP ZBook 15/17 G5* HP ZBook Power G7 HP ZBook Fury 15/17 G7* HP ZBook Create G7* HP ZBook Studio G7* HP ZBook Studio x360 G5* HP ZHAN 66 Pro 13/14/15 G2 HP ZHAN 66 Pro 14 G4 HP ZHAN 66 Pro 14/A14/15 G3 HP ZHAN 66 AMD Pro 14 G3

HP Thunderbolt™ Dock 120W G2

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 40

HP ZBook Firefly 15 G7, G8 HP Zbook 17 G3 HP ZHAN 66 Pro series G1, G2, G3, G4 HP ZHAN Pro 13, 14, 15 G2 HP ZAHN X13 G2

HP Thunderbolt™ Dock 230W G2

HP ZBook 15/17 G3, G4, G5, HP ZBook Studio G3, G4, G5, G7 HP ZBook x2 G4 HP ZBook 14u/15u G5, G6 HP ZBook Create G7 HP ZBook Fury15/17 G7 HP ZBook Power G7 HP EliteBook 800/700 G5, G6 HP ZHAN 99 G2 Mobile Workstation

HP Thunderbolt™ Dock w/Combo Cable (This dock comes with 230W power)

HP Elite x2 1012 G1, G2, G4 HP Elite x2 1013 G1, G4 HP Pro x2 612 G2 HP EliteBook Folio G1 HP EliteBook x360 1030 G2, G3, G4, G7 HP EliteBook x360 1040 G5, G6, G7 HP Elitebook 1020 G2 HP EliteBook 1040 G4 HP EliteBook 1030 G4 HP EliteBook 800 series G5, G6, G7, G8 HP EliteBook HC G5, G6 HP EliteBook x360 830 G6, G7 HP EliteBook 700 series G5, G6 HP ProBook 640 G4, G5, G7 HP ProBook 645 G4 HP ProBook 650 G5, G7, G8 HP ProBook 400 series G5, G6, G7 HP ProBook x360 435 G7 HP ZBook x2 G4 HP ZBook 14u G1, G5 HP ZBook 15u G3, G5, G7 HP ZBook Firefly 14 G7, G8 HP ZBook Firefly 15 G7, G8 HP Zbook 17 G3 HP ZHAN 66 Pro series G1, G2, G3, G4 HP ZHAN Pro 13, 14, 15 G2 HP ZAHN X13 G2 HP ZBook 15 G3, G4, G5, G6 HP ZBook 17 G4, G5, G6 HP ZBook Power G7 HP ZBook Fury 15 G7 HP ZBook Fury 17 G7 HP ZBook Studio x360 G5 HP ZBook Studio G3, G4, G7 HP ZBook X2 G4 HP ZBook Create G7 HP ZHAN 99 G2 Mobile Workstation

HP Thunderbolt™ Dock 120W G2 w/Audio

HP Elite x2 1012 G1, G2, G4 HP Elite x2 1013 G1, G4 HP Pro x2 612 G2

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 41

HP EliteBook Folio G1 HP EliteBook x360 1030 G2, G3, G4, G7 HP EliteBook x360 1040 G6, G7 HP Elitebook 1020 G2 HP EliteBook 1040 G4 HP EliteBook 1030 G4 HP EliteBook 800 series G5, G6, G7, G8 HP EliteBook HC G5, G6 HP EliteBook x360 830 G6, G7 HP EliteBook 700 series G5, G6 HP Elite Dragonfly HP ProBook 640 G4, G5, G7 HP ProBook 645 G4 HP ProBook 650 G5, G8 HP ProBook 400 series G5, G6, G7 HP ProBook x360 435 G7 HP ZBook x2 G4 HP ZBook 14u G1, G5 HP ZBook 15u G5, G7 HP Zbook 17 G3 HP ZBook Firefly 14 G7, G8 HP ZBook Firefly 15 G7, G8 HP ZBook Power G7 HP ZBook Fury 17 G7 HP ZBook Studio G3 HP ZHAN 66 Pro series G1, G2, G3, G4 HP ZHAN Pro 14, 15 G2

HP Thunderbolt™ Dock G2 Audio Module

HP Thunderbolt™ Dock G2 required HP Elite x2 1012 G1, G2, G4 HP Elite x2 1013 G1, G4 HP Pro x2 612 G2 HP EliteBook Folio G1 HP EliteBook x360 1030 G2, G3, G4, G7 HP EliteBook x360 1040 G6, G7 HP Elitebook 1020 G2 HP EliteBook 1040 G4 HP EliteBook 1030 G4 HP EliteBook 800 series G5, G6, G7, G8 HP EliteBook HC G5, G6 HP EliteBook x360 830 G6, G7 HP EliteBook 700 series G5, G6 HP ProBook 640 G4, G5, G7 HP ProBook 645 G4 HP ProBook 650 G5, G8 HP ProBook 430, 440, 450, 470 G5 HP ProBook 430, 440, 445R, 70 G6 HP ProBook 430, 435, 440, 445, 470 G7 HP ProBook x360 435 G7 HP ProBook 430, 440, 450 G8 HP ZBook x2 G4 HP ZBook 14u G1, G5 HP ZBook 15u G5, G7 HP Zbook 17 G3 HP ZBook Firefly 14 G7, G8

QuickSpecs

HP Dock Solutions

Technical Specifications

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 42

HP ZBook Firefly 15 G7, G8 HP ZBook Power G7 HP ZBook Fury 17 G7 HP ZBook Studio G3 HP ZHAN 66 Pro series G1, G2, G3, G4 HP ZHAN Pro 14, 15 G2

HP USB-C® Dock G4

HP ProBook 600 G4, 400 G5, G6 HP EliteBook 800 G5, 700 G5 HP EliteBook x360 1030 G6 & 1020 G2, G3, G4 HP EliteBook 1040 G4 ChromeBook x360 HP Elite x2 1012 G2 HP Elite x2 1013 G3, G4 HP Pro x2 612 G2 HP ChromeBook 13 HP Spectre Pro 13 G1 Notebook PC HP EliteBook Folio G1; HP Elite x2 1012 G1

HP USB Travel Dock

All HP notebooks with a powered USB-A port

HP UltraSlim Docking Station

HP EliteBook Folio 1020 G1 HP EliteBook Folio 1040 G1, G3 HP EliteBook 1040 G2 HP EliteBook Revolve 810 G1, G3 HP EliteBook 800 G7 HP EliteBook 820 G1, G2, G3, G4 HP EliteBook 840 & 850 G1, G2, G3, G4, G5, G6 HP EliteBook 830 G5, G6 HP EliteBook 720, 740, 750 G1, G2 HP EliteBook 725 G3, G4, G5 HP EliteBook 745, 755 G3, G4, G5, G6 HP EliteBook 735 G5, G6 HP ProBook 640, 650 G2, G3, G4, G5 HP ProBook 645 G2, G3, G4, G5 HP ProBook 655 G2, G3, G4 HP EliteBook Folio 9480m, 9470m HP ZBook 14u G4, G5, G6 HP ZBook 15u G3, G4, G5, G6

1. Limited support: USB-C data and power is not supported.

2. Notebook AC Adapter or HP 4.5mm and USB-C Dock Adapter G2 (part number: 6LX61AA) required for charging. *Notebook AC Adapter connection required.

NOTE: Your computer, docking station, and monitor must all support USB 3.0 and DisplayPort™ 1.2 at minimum to benefit from the advanced speeds or features that these technologies provide. If one of the devices does not support these technologies, you will still benefit from USB 2.0 and DisplayPort™ 1.1 functionality.

Service and Support

HP Dock Solutions are supported by a one-year limited warranty. Additional support is available 24 hours a day, seven days a week by phone as well as online support forums.

NOTE: Certain restrictions and exclusions apply. Consult the HP Customer Support Center for details.

QuickSpecs

HP Dock Solutions

Summary of Changes

Not all configuration components are available in all regions/countries.

c04168358 – DA 13639 – Worldwide – Version 14– April 26, 2021

Page 43

Date of change

Version 1 to 2

Description of change

V1 to V2

Launch

July 6, 2018

V1 to V2

Update

Typo corrected on “LED colored ring” specs

October 5, 2018

V2 to V3

Update

1050 G1 added to HP Thunderbolt Dock 230W G2 (2UK38AA) and HP Thunderbolt Dock 230W G2 cable (3XB95AA) compatibility

May 7, 2019

V3 to V4

Update

HP USB-C Dock G5, HP USB-C/A Universal Dock G2 and HP 4.5 mm and USB-C Dock Adapter G2 added

June 25, 2019

V4 to V5

Update

General update

September, 2019

V5 to V6

Update

General Update

March 10,2020

V6 to V7

Update

HP UltraSlim Docking Station – Rear side image call out #11 corrected

May 27, 2020

V7 to V8

Update

HP USB-C Dock G5 operating systems updated

July 29, 2020

V8 to V9

Update

Image call outs and call outs section corrected for Thunderbolt Dock G2 Typo in HP ZHANN Pro 13 G2 corrected ZBook Firefly 14/15 G7added to Thunderbolt Dock 120W G2 HP ZHAN 99 Mobile Workstation added to HP ZHAN 99 G1, G2, added G7 to Studio, added ZBook Create G7, added ZBook Firefly 14/ 15 G7 into compatibility table.

October 16, 2020

V9 to V10

Update

General update

January 5, 2020

V10 to V11

Update

HP ZBook Firefly 14/15 G7, G8 from HP Thunderbolt™ Dock 230W G2 compatible notebooks

January 19, 2020

V11 to V12

Update

ZBook 15u G7 removed Reference footnote sign removed from Firefly 14/15 G7 and G8 HP 4.5mm and USB Dock Adapter and HP USB-C® Universal Dock NonFlash with USB & 4.5mm Adapter removed

March 2, 2021

V12 to V13

Update

Video Resolution table updated (p5 and p6)

Arpil 26, 2021

V13 to V14

Removal

HP EliteBook 800/700 G7 and G8 from HP Thunderbolt™ Dock 230W G2 compatibility statement.

© Copyright 2021 HP Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein. Thunderbolt™ is a trademark of Intel Corporation in the U.S. and other countries. USB TypeC® and USB-C® are trademarks of USB Implementers Forum.

HP Dock Solutions Technical Specifications

Specifications and Main Features

Frequently Asked Questions

User Manual

Technical Specifications

Summary of Changes
