HP D8911 User Manual
hp
91
D8911
www.hp.com/go/monitorsupport
19-inch CRT monitor
(18-inch viewable image)
user’s guide
Full scan screen
r
that gives an
edge-to-edge
1
0.26 mm dot pitch for
excellent graphics
Non-glare, antistatic screen
On/Off Switch
Status Indicato
Image adjustment controls to operate
on-screen display menus
hp 91
D8911
19-inch Color Monitor
(18-inch Viewable Image)
User’s Guide
HP 19” Color Monitor User’s Guide
Important Safety Instructions
Important Safety Instructions
WARNING
Working in
Comfort
CAUTION
For your safety always connect equipment to a grounded wall outlet.
Always use a power cord with a properly grounded plug, such as the one
provided with the equipment, or one in compliance with your national
safety standards. This equipment can be disconnected from the power
by removing the power cord from the power outlet. This means the
equipment must be located close to an easily accessible power outlet.
To avoid electrical shock, do not open the monitor's cover. There are no
user-serviceable parts inside. Only qualified service personnel should
service these parts.
Make sure your computer is powered off before connecting or
disconnecting a display peripheral.
Thank you for selecting HP monitor equipment.
To optimize your comfort and productivity, it's important that you set
up your work area correctly and use your HP equipment properly. With
that in mind, we have developed some setup and user recommendations
for you to follow based on established ergonomic principles.
You can consult the online version of Working in Comfort preloaded on
the hard disk of HP computers, or visit HP's Working in Comfort web
site at:
http://www.hp.com/ergo/
The monitor is quite heavy (the weight is shown in the technical
specifications). We recommend you ask the assistance of a second
person when lifting or moving it.
!
The lightning flash with arrowhead symbol, situated within an equilateral
triangle, is intended to alert the user to the presence of uninsulated
"dangerous voltage" which may be of sufficient magnitude to constitute
a risk of electric shock.
The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and servicing
instructions in the literature accompanying the appliance.
2 English
HP 19” Color Monitor User’s Guide
What Your New Monitor Offers
What Your New Monitor Offers
Your HP monitor is a 19-inch (18.0-inch viewable image), high
resolution, multi-synchronous color monitor. Multi-synchronous
means that the monitor supports a range of video modes. It is
optimized for use with all Hewlett-Packard computers.
Your HP color monitor has the following features:
A 19-inch flat square tube with a 18.0-inch viewable image.
• €
0.26mm dot pitch for excellent graphics and anti-static and antiglare coating to minimize reflection.
Support for Ultra VGA 1600 x 1200 at 75 Hz refresh rate.
•
Image adjustment using on-screen display menus. Includes color
• €
adjustment to optimize the quality of the image.
1
Monitor power management system (VESA
• €
from suitably equipped HP computers to automatically reduce the
power consumption of the monitor. Complies with the Energy Star
Computers Program initiated by US EPA
HP has determined that this product meets the ENERGY STAR
guidelines for energy efficiency
Monitor Plug and Play capability (VESA DDC1/2B standard) that
• €
3
.
enables the monitor to identify itself to suitably equipped HP
computers.
Compliance with ISO 9241-3/-7/-8 ergonomic standards.
•
Complies with MPRII and MPRIII level B guidelines for upper limits
• €
of electrostatic and magnetic field emissions from the Swedish
National Board for Measurement and Testing.
Your monitor complies with TCO99 requirements. (Refer to
• €
“TCO99 Ecology Energy Emission Ergonomics” on page 17).
Your monitor is Blue Angel compliant. Its cathode ray tube does
• €
not contain cadmium.
standard) controlled
2
. As an ENERGY partner,
1. VESA is the Video Electronics Standards Association.
2. The US EPA is the United States Environmental Protection Agency.
3. ENERGY STAR is a US-registered service mark of the US EPA.
English 3
HP 19” Color Monitor User’s Guide
Setting Up Your Monitor
Setting Up Your Monitor
Attaching the Tilt and Swivel Base
Your display has a tilt and swivel base. To fit the swivel base:
Turn the monitor on its side (never on the screen). Identify the front
1€
of the base.
Locate the slots in the underside of the monitor.
2
Slide the base towards the front of the monitor until the locking tab
3€
on the base clicks into place.
1
2
3
Where to Place the Monitor
Place your monitor on a flat sturdy surface. Ensure the operating site is
free from excessive heat, moisture, dust and sources of electromagnetic
fields. Sources of electromagnetic fields include transformers, motors,
and other monitors. Avoid exposing the monitor to direct sunlight.
4 English
CAUTION
HP 19” Color Monitor User’s Guide
Setting Up Your Monitor
Connecting the Cables
Before you connect any cables or install your HP monitor, refer to the
safety instructions at the beginning of this manual. Refer to the user
manual which accompanies your computer and video adapter to
ensure this equipment is correctly installed.
1
2
3
NOTE
Ensure your computer is switched off.
1
Connect the video cable (it has a 15-pin plug) to the video outlet
2€
on your computer. Tighten the thumbscrews on the plug.
Connect the power cord to the monitor.
3
Plug the power cord into the power outlet.
4
The location of your computer's video cable connector may be
different to the one shown. Refer to the manual that came with your
computer, if necessary.
English 5
