DATA SHEET

ARUBA CX 8325 SWITCH SERIES

High Performance Enterprise Campus and Data Center Switch

PRODUCT OVERVIEW

The Aruba CX 8325 Switch Series oers a exible and

innovative approach to addressing the application, security,

and scalability demands of the mobile, cloud and IoT era.

Theseswitches serve the needs of the next generation

core and aggregation layer, as well as emerging data center

requirements at the Top of Rack (ToR) and End of Row (EoR).

They provide over 6.4Tbps of capacity, with line-rate Gigabit

Ethernet interfaces including 1Gbps, 10Gbps, 25Gbps,

40Gbps, and 100Gbps.

The 8325 series includes industr y-leading line rate

ports 1/10/25GbE (SFP/SFP+/SFP28) and 40/100GbE

(QSFP+/QSFP28) with connectivity in a compact 1U form

factor. These switches oer a fantastic investment for

customers wanting to migrate from older 1GbE/10GbE to

faster 25GbE, or 10GbE/40GbE to 100GbE ports.

PRODUCT DIFFERENTIATORS

AOS-CX - a modern software system

The Aruba CX 8325 Switch Series is based on AOS-CX, a

modern, database-driven operating system that automates

and simplies many critical and complex network tasks.

A built-in time series database enables customers and

developers to utilize software scripts for historical

troubleshooting, as well as analysis of past trends. This helps

predict and avoid future problems due to scale, security, and

performance bottlenecks.

Our AOS-CX software also includes Aruba Network Analytics

Engine (NAE) and support for Aruba NetEdit. Because AOS-

CX is built on a modular Linux architecture with a stateful

database, our operating system provides the following

unique capabilities:

• Easy access to all network state information allows unique

visibility and analytics

• REST APIs and Python scripting for ne-grained

programmability of network tasks

• A micro-services architecture that enables full integration

with other workow systems and services

• Continual state synchronization that provides superior

fault tolerance and high availability

KEY FEATURES

• High performance 6.4Tbps with 2,000 Mpps

• High availability with industry-leading VSX

redundancy, and redundant power supplies and fans

• Designed for core/aggregation in the campus or Top

of Rack or End of Row in the data center

• AOS-CX automation and programmability using built-

in REST APIs and Python scripts

• Advanced Layer 2/3 feature set includes BGP, OSPF,

VRF-Lite, and IPv6

• Dynamic VXLAN with BGP-EVPN for deep

segmentation in data center and campus networks

• Intelligent monitoring, visibility, and remediation

with Aruba Network Analytics Engine

• One touch deployment with the Aruba CX Mobile

App

• Aruba NetEdit support for automated conguration

and verication

• Compact 1U switch with 1/10/25GbE and

40/100GbE connectivity

• All software processes communicate with the database

rather than each other, ensuring near real-time state and

resiliency and allowing individual software modules to be

independently upgraded for higher availability

Aruba Network Analytics Engine

For enhanced visibility and troubleshooting, Aruba’s Network

Analytics Engine (NAE) automatically interrogates and

analyzes events that can impact a networks health. Advanced

telemetr y and automation provide the ability to easily identify

and troubleshoot network, system, application and security

related issues easily, through the use of python agents and

REST APIs.

DATA SHEET

ARUBA CX 8325 SWITCH SERIES

The Time Series Database (TSDB) stores conguration and

operational state data, making it available to quickly resolve

network issues. The data may also be used to analyze trends,

identify anomalies and predict future capacity requirements.

Aruba NetEdit – automated switch conguration and

management

The entire Aruba CX portfolio empowers IT teams to

orchestrate multiple switch conguration changes for

smooth end-to-end service rollouts. Aruba NetEdit

introduces automation that allows for rapid network-wide

changes, and ensures policy conformance post network

updates. Intelligent capabilities include search, edit,

validation (including conformance checking), deployment and

audit features. Capabilities include:

• Centralized conguration with validation for consistency

and compliance

• Time savings via simultaneous viewing and editing of

multiple congurations

• Customized validation tests for corporate compliance

and network design

• Automated largescale conguration deployment without

programming Network health and topology visibility via

Aruba NAE integration

Note: A separate software license is required to use Aruba

NetEdit.

Aruba CX Mobile App – unparalleled deployment

convenience

An easy to use mobile app simplies connecting and

managing Aruba CX switches for any size project. Switch

information can also be imported into Aruba NetEdit for

simplied conguration management and to continuously

validate the conformance of congurations anywhere in the

network. The Aruba CX Mobile App is available for download.

Aruba Virtual Switching Extension

The ability of AOS-CX to maintain synchronous state

across dual control planes allows a unique high availability

solution called Aruba Virtual Switching Extension (VSX).

VSX is delivered through redundancy gained by deploying

two chassis with an inter-switch link, with each chassis

maintaining its independent control.

Designed using the best features of existing HA technologies

such as Multi-chassis Link Aggregation (MC-LAG) and Virtual

Switching Framework (VSF), Aruba VSX enables a distributed

architecture that is highly available during upgrades or

control plane events. Features include:

• Continuous conguration synchronization via AOSCX

• Flexible activeactive network designs at Layers 2 and 3

• Operational simplicity and usability for easy conguration

• High availability by design during upgrades including

support for VSX Live Upgrade with LACP trac draining.

PRODUCT CAPABILITIES

Performance

• High-speed fully distributed architecture

Provides 6.4Tbps for switching and 2,000 Mpps for

forwarding. All switching and routing are wire-speed to

meet the demands of bandwidth-intensive applications

today and in the future

• Scalable system design

Provides investment protection to support future

technologies and higher-speed connectivity

Connectivity

• High-density port options

 - 32 ports of 40GbE/100GbE (QSFP+/QSFP28), or

 - 48 ports of 1GbE/10GbE/25GbE (SFP/SFP+/SFP28) and

8 ports of 40GbE/100GbE (QSFP+/QSFP28) SFP+ ports

(with an optional 10GBASE-T transceiver)

• Jumbo frames

Supports high-performance backups and disaster-

recovery systems; provides a maximum frame size of

9K bytes

• Packet storm protection

Protects against unknown broadcast, multicast, or unicast

storms with user-dened thresholds

Quality of Service (QoS)

Supports the following congestion actions: strict priority (SP)

queuing and Decit Weighted Round Robin (DWRR)

• Data Center Bridging (DCB)

Supports lossless Ethernet networking standard PFC,

ETS and DCBX support.

Resiliency and high availability

• Aruba Virtual Switching Extension (VSX)

VSX enables a distributed and redundant architecture

by deploying two switches with each switch maintaining

independent control yet staying synchronized during

upgrades or failover. Also supports upgrades during

liveoperation.

DATA SHEET

ARUBA CX 8325 SWITCH SERIES

• Virtual Router Redundancy Protocol (VRRP)

VRRP allows a group of switches to dynamically

back each other up to create highly available

routed environments

• Ethernet Ring Protection Switching (ERPS)

Supports rapid protection and recovery in a ring topology.

• Unidirectional Link Detection (UDLD)

Monitors link connectivity and shuts down ports at both

ends if unidirectional trac is detected, preventing loops

in STP-based networks

• IEEE 802.3ad LACP

Supports up to 54 LAGs, each with eight links per LAG,

with a user-selectable hashing algorithm

• Redundant power supplies

Provides N+1 high reliability with hot swappable,

redundant power supplies

• Redundant and load-sharing fans and power supplies

Increases total performance and power availability while

providing hitless, stateful failover

• Hot swappable power supply and fan modules

Allows replacement of modules without any operational

impact on other modules

• Separate data and control paths

Separates control from services and keeps service

processing isolated; increases security and performance

Management

In addition to the Aruba CX Mobile App, Aruba NetEdit and

Aruba Network Analytics Engine, the 8325 series oers the

following:

• Built-in programmable and easy to use REST API interface

• Management interface control

Enables or disables each of the following interfaces

depending on security preferences: console port, or

reset button

• Industry-standard CLI with a hierarchical structure

Reduces training time and expenses, and increases

productivity in multivendor installations

• Management security

Restricts access to critical conguration commands; oers

multiple privilege levels with password protection; ACLs

provide SNMP access; local and remote Syslog capabilities

allow logging of all access

• IPSLA

 - Monitors the network for degradation of various

services, including voice

 - Monitoring is enabled via the NAE for history and for

automated gathering of additional information when

anomalies are detected

• SNMP v2c/v3

Provides SNMP read and trap support of industry

standard Management Information Base (MIB), and

private extensions

• sFlow (RFC 3176)

Provides scalable ASIC-based wire speed network

monitoring and accounting with no impact on network

performance; this allows network operators to gather

a variety of sophisticated network statistics and

information for capacity planning and real-time network

monitoring purposes

• Remote monitoring (RMON)

Uses standard SNMP to monitor essential network

functions and supports events, alarms, history,

and statistics groups as well as a private alarm

extension group

• TFTP and SFTP support

 - Oers dierent mechanisms for conguration updates;

trivial FTP (TFTP) allows bidirectional transfers over a

TCP/IP network

 - Secure File Transfer Protocol (SFTP) runs over an SSH

tunnel to provide additional security

• Debug and sampler utility

Supports ping and traceroute for IPv4 and IPv6

• Network Time Protocol (NTP)

 - Synchronizes timekeeping among distributed time

servers and clients; keeps timekeeping consistent among

all clock-dependent devices within the network

 - Can serve as the NTP server in a customer network

• IEEE 802.1AB Link Layer Discovery Protocol (LLDP)

Advertises and receives management information from

adjacent devices on a network, facilitating easy mapping

by network management applications

• Dual ash images

Provides independent primary and secondary operating

system les for backup while upgrading

• Multiple conguration les

Stores les easily to the ash image

Layer 2 Switching

• VLAN

Supports up to 4,040 port-based or IEEE

802.1Q-based VLANs

• VLAN Translation

Remaps VLANs during transit across a core network

• Static VXLAN

Supports static VXLAN. Allows operators to manually

connect two or more VXLAN tunnel endpoints (VTEP)
