HP COMPAQ T5520 User Manual

Administrator’s Guide

Microsoft Windows CE Image for HP
Compaq Thin Clients

Image Version 5.0

Document Part Number: 349401-005

June 2005

This guide provides network administrators with basic instructions
for configuring CE-based thin clients.

© Copyright 2005 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice.

Microsoft, MS-DOS, Windows, and Windows NT are trademarks of Microsoft
Corporation in the U.S. and other countries.

The only warranties for HP products and services are set forth in the express
warranty statements accompanying such products and services. Nothing herein
should be construed as constituting an additional warranty. HP shall not be liable
for technical or editorial errors or omissions contained herein.

This document contains proprietary information that is protected by copyright.
No part of this document may be photocopied, reproduced, or translated to
another language without the prior written consent of Hewlett-Packard
Company.

WARNING: Text set off in this manner indicates that failure to follow

Å

directions could result in bodily harm or loss of life.

CAUTION: Text set off in this manner indicates that failure to follow

Ä

directions could result in damage to equipment or loss of information.

Administrator’s Guide

Microsoft Windows CE Image for HP Compaq Thin Clients

Fifth Edition (June 2005)

Document Part Number: 349401-005

Introduction

Image Updates. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–2

Setup Wizard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–2

Updates for Image Refresh Version 5.0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–3

The Desktop

Taskbar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–2

Start Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–2

Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–3

HP Connection Administrator

Accessing HP Connection Administrator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–1

Main HP Connection Administrator Window. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–2

Adding, Editing, and Deleting Connections in HP Connection Administrator Window 3–4

The HP Connection Administrator Advanced Window

Advanced Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–1

Assign Connections Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–2

Global UI Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–3

Security Window. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–6

System Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–6

Users Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–6

Adding, Editing, and Deleting Connections in the Advanced Window . . . . . . . . . . . . 4–8

Assigning Connections to Users in the Advanced Window . . . . . . . . . . . . . . . . . . . . . 4–9

Designating Connections as Primary or Secondary . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–9

Making a Connection Automatically Connect when HP Connection Administrator is

Launched . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–11

Making a Connection Automatically Reconnect if it Disconnects . . . . . . . . . . . . . . . 4–12

Assigning a Server Port to Ping before Connecting . . . . . . . . . . . . . . . . . . . . . . . . . . 4–12

Setting Time Constraints for a Valid Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–13

Setting the Terminal to Kiosk Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–14

Switching to a Different User . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–14

Enabling Automatic Log On. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–15

Creating a User Account . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–16

Contents

Administrator’s Guide www.hp.com 1

Control Panel

Accessibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–1

Certificates. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–2

Date/Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–3

DHCP Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–4

Dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–5

Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–6

Global ICA Client Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–8

Hotkeys Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–8

Preferences Tab. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–9

Server Location Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–10

Firewall Settings Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–11

Internet Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–11

JETCET PRINT 4.0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–12

Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–13

LPD Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–14

Modems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–14

Mouse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–15

Network and Dial-up Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–15

Dial-Up Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–16

Direct Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–16

Virtual Private Network (PPTP) Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–16

Virtual Private Network (L2TP) Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–17

PPP Over Ethernet (PPPoE) Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–17

Port Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–17

RDP/ICA Printers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–18

Adding a Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–18

Modifying an Existing Printer Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–19

Regional and Language Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–20

Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–21

Enabling Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–21

Creating a User’s Account . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–22

SNMP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–23

SNTP Client . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–

System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–26

System Update. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–26

Direct from HP Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–27

FTP Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–27

Contents

25

Administrator’s Guide www.hp.com 2

Terminal Server Client Licenses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–28

View or Remove Programs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–28

VNC Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–28

Volumes & Sounds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–29

Programs and Add-ons

Programs and Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–1

ELO Touch Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–1

HP Connections for Citrix Software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–1

To create a shortcut, right-click on the connection and select Send to Desktop. A

shortcut to the connection appears on the desktop. . . . . . . . . . . . . . . . . . . . . . . . . 6–2

HP Registry Import/Export Tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–3

RDP 5.5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–5

VNC Server. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–6

Settings for VNC Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–7

TxtPad. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–8

Add-ons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–8

Messenger 5.0 Add-on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–8

Contents

Administrator’s Guide www.hp.com 3

Contents

4 www.hp.com Administrator’s Guide

1

Introduction

The CE-based terminal offers greater user flexibility than previous
CE products because it can be used from the Explorer shell (desktop),
used strictly with the HP Connection Administrator, or further locked
down into Kiosk mode.

This guide provides the network administrator with instructions for
local and remote configuration of the CE-based terminal and explains
the various utilities used to accomplish this. Typically, a terminal is
configured locally then used as a template for other terminals, which
can then be configured via remote administration tools.

Server and application connections can be created through the HP
Connection Window or the HP Connection Administrator. A
connection created with one utility will also be available for editing
and configuring in the other utility. Although you can create and edit
connections with either utility, only HP Connection Administrator
provides the functionality to create connections and set up user
profiles. HP Connection Administrator is also used to determine the
start mode and user interface for the terminal.

Chapters in this guide are specific to the desktop interface, the HP
Connection Window utility, the HP Connection Administrator utility,
and all the programs in the Control Panel.

Administrator’s Guide www.hp.com 1-1

Introduction

Image Updates

HP provides periodic updates to the image for the HP Compaq t53x0
and t55x0 thin clients. Check the HP support site for important
documentation that provides specific information for your image
version. Support documentation can be found at

http://welcome.hp.com/country/us/en/support.html.

For the latest version of the HP Compaq t53x0 and t55x0 Thin Clients
Microsoft Windows CE Image, visit the HP website at

http://h18004.www1.hp.com/support/files/thinclients/us/index.html

Setup Wizard

Microsoft Windows CE HP Image version 4.21 and later include a
Setup Wizard. Setup Wizard provides a simplified method to
configure a thin client device. After you unbundle the image, the
Setup Wizard will launch.

There is a 20 second delay after the Setup Wizard launches. If the

✎

administrator does not click Next before the timer expires, the default
settings for the thin client will load.

1-2 www.hp.com Administrator’s Guide

Updates for Image Refresh Version 5.0

■ Dynamic DNS added. Secure updates are supported with

Kerberos encryption, which is only supported with Windows
2000 and 2003 Servers.

■ DMA flash enabled.

■ Windows CE 5.0 adds support for the EHCI USB controller

driver (i.e. USB 2.0) on select models.

■ VNC Server Add-on.

■ TxtPad Add-on - Text Editor.

■ RDP 5.5 Add-on

■ Messenger 5.0 Add-on

■ Auto DHCP Update Feature enabled by default.

Introduction

Administrator’s Guide www.hp.com 1-3

Introduction

1-4 www.hp.com Administrator’s Guide

2

The Desktop

The Microsoft Windows CE image includes an Explorer shell
(desktop) that resembles the typical Windows desktop features that
should be familiar to most users of desktop computers. The desktop
includes a taskbar, start menu, shortcut icons, and a background
image.

The desktop has the typical desktop functionality. To change the
display settings, right-click on the desktop and select Properties from
the pop-up list. This brings up the Display Properties dialog where
you can make changes to the background, appearance, resolution and
color quality settings, and screen saver.

Administrator’s Guide www.hp.com 2-1

The Desktop

✎

Taskbar

Start Menu

You can change the background image to one of your own

preference, but the image must be a .bmp format.

If you change the screen resolution setting, you must reboot for the
change to take effect. If you do not know if the screen resolution
mode you selected is supported by your monitor, click the Tes t button
on the Display Properties Settings tab.

The taskbar includes a Start button, active task buttons (currently
running programs), and a notification area (system tray).

By default, the taskbar is automatically hidden. You must move the
pointer to the bottom of the screen to bring up the taskbar. If you want
to change it so that the taskbar is always displayed, right-click on the
taskbar, select Properties, and clear the Auto hide check box.

Open the Start menu by clicking the Start button on the taskbar. The
Start menu includes a Programs list, a Settings list, a Run dialog, and
a Shut Down dialog.

2-2 www.hp.com Administrator’s Guide

Icons

The icons on the desktop are shortcuts to programs that include HP
Connections for Citrix Software, Internet Explorer, and RDP. You
can also add icons for shortcuts to connections that have been created
by right-clicking on the connection icon in the HP Connection
Window utility and selecting Send to Desktop.

To launch a program or connection from the desktop, double-click the
respective icon.

Due to Windows CE architecture, properties for the programs on the

✎

desktop can not be changed from the desktop. In other words, if you
right-click on a desktop icon and select Properties, the property
values for that program can not be changed. Only property values for
the shortcut can be changed.

The Desktop

Administrator’s Guide www.hp.com 2-3

The Desktop

2-4 www.hp.com Administrator’s Guide

HP Connection Administrator

The HP Connection Administrator allows you to manage server and
application connections by setting up ICA Connections, assigning the
connections to Connections, and creating Profiles made up of users
and their assigned Connections.

Connections can also be established through the HP Connections for

✎

Citrix Software. If a Connection is created in HP Connections for
Citrix Software, it will also appear in HP Connection Administrator.
Likewise, if a Connection is created in HP Connection Administrator,
it will also appear in HP Connections for Citrix Software.

Accessing HP Connection Administrator

HP Connection Administrator can be accessed through the Start menu
(Start > Programs > HP Connection Administrator).

3

Administrator’s Guide www.hp.com 3-1

HP Connection Administrator

Main HP Connection Administrator Window

When HP Connection Administrator is launched, the first window
displayed is the main HP Connection Administrator window.

The main HP Connection Administrator window includes the
following features.

■ Connection display: The area on the left side of the window

shows the Connections and their status as either “CONNECTED”
or “NOT CONNECTED.” The display only shows the
Connections assigned to the person who is currently logged on to
the terminal.

■ Connect button: Click this button to connect one of the

connections on the left side of the window. Highlight the
connection and click the Connect button.

■ Control Panel button: This button is used access the Control

Panel when the system is in Kiosk mode so that the Administrator
or user with permission can access the Control Panel icons.

3-2 www.hp.com Administrator’s Guide

HP Connection Administrator

■ Delete button: Select a connection in the connections display

then click this button to delete the connection. Note that the
connection is deleted from the list of connections available to all
users, not just the user currently logged on to the terminal.

■ Add button: Click this button to create a new connection and add

it to the list of connections assigned to the user currently logged
on to the terminal. The new connection will also be available for
assignment to other users in the Advanced window.

■ Edit button: Select a connection in the connections display then

click this button to edit the connection.

■ Help button: Click this button to access HP Connection

Administrator's online help.

■ Advanced button: Click this button to access the Advanced

window, where you can configure and assign connections, set up
user security accounts, and configure the user interface for the
terminal.

■ Exit button: Click this button to exit HP Connection

Administrator.

Administrator’s Guide www.hp.com 3-3

HP Connection Administrator

Adding, Editing, and Deleting Connections in HP Connection Administrator Window

You can add, edit, or delete connections in the HP Connection
Administrator window or in the Advanced window. Adding a
connection in the HP Connection Administrator window adds it to the
list of connections assigned to the user currently logged on to the
terminal. The new connection will also be available in the Advanced
window for assignment to other users.

1. To add a connection in the HP Connection Administrator
window, click the Add button.

2. In the Choose type dialog box, select the type of connection you
want to create and click the OK button. A Wizard or setup dialog
for the connection type is displayed.

3. Follow the on-screen instructions in the Wizard or setup dialog to
add the connection to the user's connections list and to the list of
available connections that can be assigned to other users in the
Advanced window.

4. To edit the connection, select the connection and click the Edit
button. Make the appropriate changes in the Wizard or setup
dialog.

5. To delete the connection, select the connection and click the
Delete button. The connection is deleted from all user connection
lists, not just the user currently logged on to the terminal.

Do not rename a connection once the connection has been established

✎

and assigned to users. Renaming a connection effectively deletes the
connection from all user accounts.

3-4 www.hp.com Administrator’s Guide

The HP Connection Administrator

Advanced Window

The Advanced window is accessed by clicking the Advanced button
on the main HP Connection Administrator window.

4

Advanced Window

The Advanced window allows you to configure and assign
connections, set up user security accounts, and configure the user
interface for the terminal.

Administrator’s Guide www.hp.com 4-1

The HP Connection Administrator Advanced Window

You must be logged in with Administrator permissions or with the

✎

"User may add, edit, or delete connections" permission to access the
Advanced window.

The Advanced window includes two tabs, the Assign Connections tab
and the Global UI tab.

Assign Connections Tab

■ User select list: This drop-down list includes all users accounts

associated with the system. Select a user from the list to configure
connections for the user.

■ Security button: Click this button to access the Security

window, where you can create and configure user accounts.

■ Available connections list: This panel on the left side of the

window displays all available connections that can be assigned to
users.

❏ Name: This column displays the name of the connection

assigned when the connection was created.

❏ Type: This column displays the type of connection.

❏ Ping Type: This column in the available connections list

shows the server port to ping for the connection.
Double-click on an entry in this column to allow "Smart
Ping," which automatically assigns the port to ping based on
the connection type, or you can manually enter the port to
ping.

■ Delete button: Select a connection in the available connections

list then click this button to delete the connection from the list.
Note that the connection will also be deleted from the lists of
connections assigned to all users.

■ Add button: Click this button to create a new connection and add

it to the list of available connections.

■ Edit button: Select a connection in the available connections list

then click this button to edit the connection.

■ Connections for "selected user" list: This panel on the right

side of the window shows the connections assigned to the user
displayed in the User field near the top of the window.

4-2 www.hp.com Administrator’s Guide

The HP Connection Administrator Advanced Window

❏ Name: This column displays the name of the connection

assigned when the connection was created.

❏ Type: This column displays the type of connection.

❏ Primary: This column is used to designate a connection as

either a primary or secondary connection. If Yes is displayed,
the connection is a primary connection. If No is displayed,
the connection is a secondary connection. Click on Yes or No
to toggle between the two choices.

❏ Auto: This column is used to determine whether the system

automatically connects when HP Communication
Administrator starts up. If Yes is displayed, the system will
automatically connect. If No is displayed, the system will not
automatically connect. Click on Yes or No to toggle between
the two choices.

❏ Persistent: This column is used to determine whether the

system will attempt to reconnect when a connection fails. If
Yes is displayed, the system will automatically attempt to
reconnect. If No is displayed, the system will not attempt to
reconnect. Click on Yes or No to toggle between the two
choices.

■ Save button: Click this button to save changes made to user

connections on the Assign Connections tab and user interface
settings on the Global UI tab.

■ Cancel button: Click this button to cancel unsaved changes

made to user connections on the Assign Connections tab and user
interface settings on the Global UI tab, and exit the Advanced
window.

■ OK button: Click this button to save changes made to user

connections on the Assign Connections tab and user interface
settings on the Global UI tab, and exit the Advanced window.

Global UI Tab

The Global UI tab on the Advanced window has the following fields:

■ Auto start Connection Administrator when logging into

Windows check box: Select this check box if you want HP
Connection Administrator to automatically start when the user
logs into Microsoft Windows CE.

Administrator’s Guide www.hp.com 4-3

The HP Connection Administrator Advanced Window

■ Kiosk mode check box: This check box is available as an option

if the Auto start Connection Administrator when logging into
Windows check box is selected. Check this box if you want the
terminal to start up in Kiosk mode, which limits the terminal's
functionality by hiding all icons on the desktop and all options in
the Start menu other than Shut Down.

❏ Hide connection task bar check box: This check box is

available as an option if the Kiosk mode check box is
selected. Select this check box to further lock down the
terminal in Kiosk mode by hiding the task bar at the bottom
of the desktop.

❏ Hide the User interface not allowing changes to

connection settings check box: This check box is available
as an option if the Kiosk mode check box is selected. Select
this check box to further lock down the terminal in Kiosk
mode by hiding the user interface to connection settings.

4-4 www.hp.com Administrator’s Guide

The HP Connection Administrator Advanced Window

■ Preview display: The display on the right side of the Global UI

tab provides a preview of how the user interface will appear when
the various check boxes on the left side of the tab are selected.

■ Save button: Click this button to save changes made to user

connections on the Assign Connections tab and user interface
settings on the Global UI tab.

■ Cancel button: Click this button to cancel unsaved changes

made to user connections on the Assign Connections tab and user
interface settings on the Global UI tab, and exit the Advanced
window.

■ OK button: Click this button to save changes made to user

connections on the Assign Connections tab and user interface
settings on the Global UI tab, and exit the Advanced window.

Administrator’s Guide www.hp.com 4-5

The HP Connection Administrator Advanced Window

Security Window

To access the Security window, click the Security button on the
Advanced window's Assign Connections tab. The Security window
allows you to create and modify user accounts. You can also access
the Security window by double-clicking the Security icon in the
Microsoft Windows CE Control Panel.

The Security window includes two tabs, the System tab and the Users
tab.

System Tab

The System tab on the Security window features the following fields:

■ System Statistics: This section at the top of the tab displays

system statistics, such as the number and type of users associated
with the system.

■ Lock Screen check box: Select this check box to allow the

terminal to be locked through the Ctrl+Alt+Delete keyboard
command.

■ Automatic Log On check box: Select this check box to bypass

the need for the user to enter a password when logging in to the
system. Selecting this check box also activates the Single Button
Log On check box and the Account drop-down list.

■ Single Button Log On check box: Select this check box to

enable the single button connect feature, which invokes a dialog
box that requires the terminal operator to press a keyboard key or
click the Logon button on the dialog box to log in.

■ Account drop-down list: From this list, select the account the

terminal operator will automatically log in with.

■ Enable Reset Hotkey check box: Selecting this check box

allows the terminal to be reset to factory defaults (registry and
shortcuts) by pressing and holding the F9 key during boot.

Users Tab

The Users tab on the Security window is used to add, modify, and
delete user accounts. The Users tab features the following fields:

4-6 www.hp.com Administrator’s Guide

The HP Connection Administrator Advanced Window

■ Users display: This panel displays all user accounts associated

with the system and shows which accounts are enabled and which
users are assigned administrator permissions.

■ Add button: Click this button to create a new user account. In

the Add New User window, enter the name of the user and the
user's password on the Global UI tab, then grant the user the
appropriate permissions on the Permissions tab.

■ Modify button: Select a user from the list and click this button to

modify the user's account.

■ Delete button: Select a user from the list and click this button to

delete the user's account.

Administrator’s Guide www.hp.com 4-7

The HP Connection Administrator Advanced Window

Adding, Editing, and Deleting Connections in the Advanced Window

You can add, edit, or delete connections in the HP Connection
Administrator window or in the Advanced window. However, the
Advanced window allows you to further configure the connections
and assign them to users.

1. From the HP Connection Administrator window, click the
Advanced button to access the Advanced window.

2. On the Assign Connections tab of the Advanced window, click
the Add button below the list of available connections.

3. In the Choose type dialog box, select the type of connection you
want to create and click the OK button. A Wizard or setup dialog
for the connection type is displayed.

4. Follow the on-screen instructions in the Wizard or setup dialog to
add the connection to the list of available connections.

5. To edit the connection, select the connection and click the Edit
button. Make the appropriate changes in the Wizard or setup
dialog.

6. To delete the connection, select the connection and click the
Delete button. The connection is deleted from the list of available
connections and from the connections lists for all users.

4-8 www.hp.com Administrator’s Guide

The HP Connection Administrator Advanced Window

Assigning Connections to Users in the Advanced Window

Once a connection has been created, you can assign it to users in the
Advanced window

1. In the HP Connection Administrator window, click the Advanced
button to access the Advanced window.

2. On the Assign Connections tab of the Advanced window, select
the appropriate user from the User drop-down list.

3. Double-click the connection in the list of available connections
(left panel), or select the connection and click the > button. The
connection is copied to the list of connections for the user (right
panel).

4. Click the Save button to save the updated list of connections for
the user

Designating Connections as Primary or Secondary

Connections can be designated as primary or secondary in the
Advanced window. A primary connection is the first connection that
will be attempted in a group of connections.

Secondary connections are connections within the group that will be
attempted if the primary connection fails to connect. Secondary
connections attempt to connect in the order in which they are listed.

There can be several primary connections and each primary
connection can have several secondary connections associated with it.

1. In the HP Connection Administrator window, click the Advanced
button to access the Advanced window.

2. On the Assign Connections tab of the Advanced window, select
the appropriate user from the User drop-down list.

3. Select the connection in the user's connection list that you want to
make a primary connection.

Administrator’s Guide www.hp.com 4-9

The HP Connection Administrator Advanced Window

4. In the Primary column, if the entry for the selected connection is
No, click on No to change it to Yes. (Clicking on Yes or No
toggles between the two choices, thus designating the connection
as primary or secondary.)

5. To assign a secondary connection to the primary connection,
select the connection that you want to be secondary and click on
Yes in the Primary column to change it to No. The connection
becomes a secondary connection to the first primary connection
directly above the secondary connection in the list.

6. To arrange the connections in the order that you want them to
connect, select a connection and click the U button to move it up
in the list or the D button to move it down in the list. Remember
that secondary connections are always associated with the first
primary connection above them in the list.

7. Click the Save button to save your changes.

Since each secondary connection must have an associated primary

✎

connection listed above the secondary connection, the connection at
the very top of the list of connections must be a primary connection.

4-10 www.hp.com Administrator’s Guide

The HP Connection Administrator Advanced Window

Making a Connection Automatically Connect when HP Connection Administrator is Launched

In the Advanced window, primary connections assigned to users can
be set to automatically connect when HP Connection Administrator
starts up

1. In the HP Connection Administrator window, click the Advanced
button to access the Advanced window.

2. On the Assign Connections tab of the Advanced window, select
the appropriate user from the User drop-down list.

3. Select the primary connection in the user's connection list that
you want to automatically connect.

4. In the Auto column, if the entry for the selected connection is No,
click on No to change it to Ye s.

5. Click the Save button to save your changes.

Only primary connections can be set to automatically connect when

✎

HP Connection Administrator is launched.

Administrator’s Guide www.hp.com 4-11

The HP Connection Administrator Advanced Window

Making a Connection Automatically Reconnect if it Disconnects

In the Advanced window, primary connections assigned to users can
be set to automatically reconnect in the event that the connection
disconnects. This feature will reconnect whether the disconnect was
intentional or unintentional.

1. In the HP Connection Administrator window, click the Advanced
button to access the Advanced window.

2. On the Assign Connections tab of the Advanced window, select
the appropriate user from the User drop-down list.

3. Select the connection in the user's connection list that you want to
make automatically reconnect.

4. In the Persistent column, if the entry for the selected connection
is No, click on No to change it to Ye s .

5. Click the Save button to save your changes.

Only primary connections can be set to automatically reconnect.

✎

Assigning a Server Port to Ping before Connecting

The system automatically pings the server before connecting. You
can designate which server port to ping by double-clicking an entry in
the Ping Type column and selecting the "Smart Ping" feature, which
automatically assigns a port to ping based on the connection type

1. In the HP Connection Administrator window, click the Advanced
button to access the Advanced window.

2. On the Assign Connections tab of the Advanced window,
double-click an entry in the Ping Type column. A Properties
dialog box for the connection is displayed.

4-12 www.hp.com Administrator’s Guide

The HP Connection Administrator Advanced Window

3. In the Properties dialog box for the connection, select the Use
"Smart Ping" check box. The Port to open field is automatically
assigned based on the connection type. If desired, you can change
the entry in the Port to open field by typing over the default entry.

4. Click the OK button on the Properties dialog box. The Ping Type
column in the Available connections list now shows which server
port will be pinged.

Setting Time Constraints for a Valid Connection

You can adjust the number of seconds a connection must remain
connected before it is considered a valid connection. If the connection
is lost before the designated number of seconds, the system will move
to the next connection.

The default value for a valid connection is 1 second.

✎

1. In the HP Connection Administrator window, click the Advanced
button to access the Advanced window.

2. On the Assign Connections tab of the Advanced window,
double-click an entry in the Ping Type column. A Properties
dialog box for the connection is displayed.

3. In the Properties dialog box for the connection, enter the
appropriate number of seconds in the Valid after (secs) field.

4. Click the OK button on the Properties dialog box to save your
changes.

Administrator’s Guide www.hp.com 4-13

The HP Connection Administrator Advanced Window

Setting the Terminal to Kiosk Mode

Kiosk mode limits the terminal's functionality by hiding the desktop
icons and limiting the Start menu to Shut Down only. There are also
Kiosk mode options for hiding the task bar and hiding HP Connection
Administrator.

To set a terminal to run in Kiosk mode, you must first create a

✎

connection. For more information, refer to “Adding, Editing, and
Deleting Connections in the Advanced Window”in this chapter.

To set the terminal to run in Kiosk mode:

1. On the HP Connection Administrator window, click the
Advanced button.

2. On the Advanced window, click the Global UI tab.

3. On the Global UI tab, select the Auto start Connection
Administrator check box when logging into Windows check box.
This makes the Kiosk mode option available.

4. Select the Kiosk mode check box. Two more check boxes
become available as options.

5. If you want to hide the task bar, select the Hide connection task
bar check box.

6. If you want to hide HP Connection Administrator, select the Hide
the User interface not allowing changes to connection settings
check box.

7. Create the necessary ICA connection.

8. Click the Save button to save your changes, or click the OK
button to save your changes and exit the Advanced window.

9. Reboot the terminal for all changes to take effect.

Switching to a Different User

To switch to a different user when booting, perform the following
steps:

1. Press the power button to start the system.

2. Enter Alt-F4 at the five-second log on display or Log on button.

4-14 www.hp.com Administrator’s Guide

The HP Connection Administrator Advanced Window

3. Log on as the user of your choice.

Enabling Automatic Log On

In the Security window, you can enable automatic log on and bypass
a user's password requirement when logging on to the system.

You can access the Security window by clicking the Security button

✎

in the Advanced window or by double-clicking the Security icon in
the Microsoft Windows CE Control Panel.

To enable automatic log on for a user:

1. On the HP Connection Administrator window, click the
Advanced button.

2. On the Assign Connections tab of the Advanced window, click
the Security button.

3. On the System tab of the Security window, select the Automatic
Log On check box to bypass the need for the user to enter a
password. This selection activates the Single Button Log On
check box and the Account drop-down list.

4. If desired, select the optional Single Button Log On check box to
enable the single button connect feature, which invokes a dialog
box that requires the terminal operator to press a keyboard key or
click the Logon button on the dialog box to log in.

5. In the Account field, select the account that the terminal operator
will automatically log in with.

6. Click the OK button at the top of the Security window to save
your changes

Administrator’s Guide www.hp.com 4-15

The HP Connection Administrator Advanced Window

Creating a User Account

Terminal operator user accounts are set up in the Security window.
This Users tab on the Security window lists all operator accounts and
shows which accounts are set up with Administrator security
permissions and which accounts are enabled.

There are three default accounts already set up (Administrator, Guest,
and User) that can be used as templates for new accounts. The default
Guest and User accounts can be modified as needed.

To create a new user account:

1. On the HP Connection Administrator window, click the
Advanced button.

2. On the Assign Connections tab of the Advanced window, click
the Security button.

3. On the Security window, select the Users tab and click the Add
button. The Add New User dialog box is displayed.

4. On the Global UI tab, enter a name for the new user account in
the Name field.

5. Enter a password for the new user in the Password field.

6. Enter the password again in the Confirm Password field.

7. Leave the Account is disabled check box clear unless you want to
disable the account.

8. If you want to use the same permissions assigned to an account
that was previously created, click the Set from Template button.
The Set from Template dialog box is displayed

a. Select the account type that you want to use as a template

from the drop-down list of accounts in the Based on field.

b. Click the OK button to apply the selected template and return

to the Add New User dialog box.

c. Click the OK button on the Add New User dialog box to save

the settings and return to the Users tab on the Security
window.

9. If you are not basing the permissions on a template and want to
choose which permissions will be assigned to the new account,
select the Permissions tab on the Add New User dialog box.

4-16 www.hp.com Administrator’s Guide

The HP Connection Administrator Advanced Window

a. Select the items in the permissions list that you want to allow

the user to access. If the user is an Administrator, select the
User is Administrator check box to provide the user with
access to all the listed items.

b. Click the OK button on the Add New User dialog box tab to

save the settings and return to the Users tab on the Security
window.

10. After completing all the above steps, click the OK button on the
Security window.

Administrator’s Guide www.hp.com 4-17

The HP Connection Administrator Advanced Window

4-18 www.hp.com Administrator’s Guide

Control Panel

This chapter provides an overview of all the programs in the Control
Panel, and in some cases provides step-by-step instructions to
perform certain tasks. Many of the programs are used for local
administration, while others such as DHCP Options and SNMP are
used for remote administration.

To open the Control Panel, do one of the following:

■ From the desktop, select Start > Settings > Control Panel.

■ From the HP Connection Window utility, double-click the HP

Connection Administrator icon to launch HP Connection
Administrator, then click the Control Panel button in HP
Connection Administrator.

The LPD Control and Port Lock programs are only available to

✎

terminals equipped with a serial port.

5

Accessibility

The Accessibility dialog box is used to configure the terminal with
508 Accessibility features.

To open the Accessibility dialog box, double-click the Accessibility
icon in the Control Panel.

Accessibility options are available for the keyboard, sound, display,
and mouse.

■ Keyboard tab: Allows you to apply StickyKeys if you want to

use the
rather than holding them down while pressing other keys. You
can also apply ToggleKeys if you want to hear tones when
pressing the

Administrator’s Guide www.hp.com 5-1

Shift, Ctrl, and Alt keys by pressing one key at a time

Caps Lock, Num Lock, and Scroll Lock keys.

Control Panel

Certificates

■ Sound tab: Used to apply SoundSentry, which causes Windows

to generate visual warnings when the system makes a sound.

■ Display tab: Used to apply High Contrast, which causes

Windows to use colors and fonts designed for easy reading.

■ Mouse tab: Used to apply MouseKeys, which allows you to

control the pointer with the numeric keypad on the keyboard.

■ General tab: Used to automatically turn off accessibility features

after a set amount of idle time.

The Certificates dialog box is used to import, store, and view security
certificates.

Certificates and certificate authorities are used to ensure that an SSL
connection is made to the intended secure server. Certificate
information is exchanged between the terminal browser and the
secure server when establishing a connection. If the certificate can be
authenticated by a trusted certificate authority, the secure page will
come up automatically.

A private key is also used to encrypt data over an SSL connection.

To open the Certificates dialog box, double-click the Certificates
icon in the Control Panel.

To import a certificate or private key:

1. Select the type of certificate you would like to import from the
drop-down list.

❏ Trusted Authorities are certificates from authorities you can

trust. The Windows CE browser comes with a pre-defined list
of trusted certificate authorities that include Thwarte, Entrust,
GlobalSign, GTE, and others.

❏ My Certificates are your personal digital certificates.

❏ Other Authorities are intermediate certificate authorities.

2. Click the Import button. The Import Certificate or Key dialog
box is displayed.

5-2 www.hp.com Administrator’s Guide

Date/Time

Control Panel

3. Select the location source of the certificate or key then click the
OK button.

❏ From a File brings up a dialog box that allows you to import

a certificate or key from the network. Browse to the
certificate or key and select it, or select the Type (Certificate
or Private Key) and enter the name of the certificate or key in
the Name field.

❏ From a Smart Card allows you to import a certificate from a

Smart Card. Make sure the Smart Card is inserted and select a
Reader from the drop-down list.

❏ Friendly name allows you to rename a certificate that you

import.

The Date/Time Properties dialog box is used to set the date and
current time, select the appropriate time zone, and enable automatic
clock adjustment for daylight savings time for the terminal.

To open the Date/Time Properties dialog box, double-click the
Date/Time icon in the Control Panel.

Select the appropriate date and time information and click the Apply
button.

Administrator’s Guide www.hp.com 5-3

Control Panel

DHCP Options

The DHCP Options dialog is used to set the DHCP tags that identify
the FTP location of the upgrade image.

Open the DHCP dialog box by double-clicking the DHCP Options
icon in the Control Panel.

To change the FTP Option IDs, type over the current numbers in the
File Server and Path and Filename fields (range is 128 through 254)
and click OK. The values must match those set up on the DHCP
server.

To reset the option IDs to the default values, click the Reset to

Defaults button. The default for File Server is 161. The default for
Path and Filename is 162.

The root path entry on the server should contain both the path and the

✎

filename.

5-4 www.hp.com Administrator’s Guide

Dialing

Control Panel

The Dialing Properties dialog box is used to select (or add) a dialing
location and enter dial-up settings for the selected location. Local
settings include the area code, county/region code, and tone or pulse
dialing. You also have the option of disabling call waiting.

You can also set up dialing patterns for local, long distance, and
international calls.

The dialing properties are used in conjunction with ICA connections.

✎

To open the Dialing Properties dialog box, double-click the Dialing
icon in the Control Panel.

Select or add a “dialing from” location and enter the local settings for
the location. Click OK after entering the information.

Administrator’s Guide www.hp.com 5-5

Control Panel

Display

The Display Properties dialog box is used to configure the monitor’s
background image, appearance scheme, screen resolution, color
quality, refresh frequency, and screen saver.

You must reboot the terminal after changing any of the display
properties for the changes to take effect.

You can change the background image to one of your preference, but

✎

the image must be a .bmp format.

To open the Display Properties dialog box, double-click the Display
icon in the Control Panel.

You can also access the Display Properties dialog box by

✎

right-clicking on the desktop and selecting Properties.

The Settings tab includes a Test button that can be used to test the
resolution and refresh settings.

5-6 www.hp.com Administrator’s Guide

Control Panel

The following table lists the available screen resolutions, color
quality settings, and refresh frequencies. The default is 800x600x16
@ 60Hz.

Resolution/Color 60Hz 70Hz 72Hz 75Hz 85Hz

640x480x8 XXXXX

640x480x16 XXXXX

640x480x32 XXXXX

800x600x8 XXXXX

800x600x16 XXXXX

800x600x32 XXXXX

1024x768x8 XXXXX

1024x768x16 XXXXX

1024x768x32 XXXXX

*1152x864x16 X X X X

*1152x864x32 X X X

1280x1024x8 XXXXX

1280x1024x16 XXXXX

1280x1024x32 X

*1600x1200x8 XXXX

*1600x1200x16XXXX

*These resolutions are not supported on all thin client models.

If you set the display settings out of range, you must reset the terminal

✎

to factory defaults by rebooting the terminal and holding down the

F9

key until you see a window that says “Loading...” at the bottom. All
configuration settings and connections will be lost when resetting the
terminal to factory defaults.

Administrator’s Guide www.hp.com 5-7

Control Panel

Global ICA Client Settings

The Global ICA Client Settings dialog box is used to configure ICA
client settings used during ICA sessions.

To open the ICA Client Settings dialog box, double-click the Global
ICA Client Settings icon in the Control Panel.

There are five tabs on the ICA Client Settings dialog box: Hotkeys,
Preferences, Server Location, and Firewall Settings.

Hotkeys Tab

The Hotkeys tab is used to configure hotkeys that can be used during
ICA sessions. Hotkeys are used to perform various functions.

You can assign the hotkeys used to perform a function by selecting
the hotkey combinations from the drop-down list next to each
function.

■ The Connection Status hotkey invokes a message about the

status of the connection.

■ The Close Session hotkey disconnects the terminal from the

server but does not actually close the session on the server. The
session will continue to run on the server until the terminal
operator logs off.

■ The Esc hotkey performs the same function as the Esc key on a

keyboard.

■ The CTRL-ALT-DEL hotkey invokes the terminal Security

dialog box.

■ The CTRL-ESC hotkey displays the Remote Task list on

WinFrame servers, or displays the Start menu on MetaFrame
servers.

■ The ALT-ES C hotkey cycles the focus through the minimized

icons.

■ The ALT-TAB hotkey cycles through open applications in

sequential order.

■ The ALT-BAC KTAB hotkey also cycles through open

applications sequentially, but in the opposite direction.

5-8 www.hp.com Administrator’s Guide

Control Panel

Preferences Tab

The Preferences tab is used to set color preferences during an ICA
session.

The Preferences tab contains the following fields:

■ Serial Number: Enter the serial number of the ICA Client

software exactly as it appears on the serial number card. This is
necessary when using the ICA Windows CE Client with certain
products, such as WinFrame Host/Terminal. It is not necessary
for MetaFrame servers.

■ Default Window Colors: Select the color option for the ICA

client. If the ICA server does not support 16-bit color, then 8-bit
color will be used.

■ PNAgent: Click the check box to enable PNAgent

Administrator’s Guide www.hp.com 5-9

Control Panel

Server Location Tab

The Server Location tab is used to view/add Citrix servers on the
network that have ICA connections configured.

The Server Location tab contains the following fields and buttons:

■ Network protocol drop-down list: Select the network protocol

to use from this drop-down list located near the top of the tab.

■ Server address list: Lists the server locations that have been

entered.

■ Add button: Click this button to add a server address.

■ Delete button: Click this button to delete a server address.

■ Default List button: Click this button to recall the previous

server address list.

■ Server Group list: Use this drop-down list to select whether the

servers entered in the server address list belong to your Primary,
Backup 1, or Backup 2 group.

■ Rename Group button: Click this button to rename the selected

server group.

5-10 www.hp.com Administrator’s Guide

Firewall Settings Tab

The Firewall Settings tab is used to set up a firewall by placing a
proxy server between a server and a client.

In the Proxy section, select a protocol from the drop-down list then
enter the proxy address and port.

In the SSL/TLS Relay section, enter the relay address and port for
the Socket Security Layer (SSL) or Transport Layer Security (TLS)
protocol.

Internet Options

The Internet Settings dialog box is used to configure Internet browser
settings on the terminal.

To open the Internet Settings dialog box, double-click the Internet
Options icon in the Control Panel.

The Internet Settings dialog box includes the following tabs:

■ General tab: Used to enter start and search pages, set the cache

size (as well as clear cache and history), and set the font size.

Control Panel

■ Connection tab: Used to select LAN or autodial connections,

and to enter proxy server settings.

■ Security tab: Used to allow cookies, TLS 1.0 security, SSL 2.0

security, and/or SSL 3.0 security. There is also an option to warn
you when switching across secure and insecure areas and an
option that allows you to enable favorites.

■ Advanced tab: Used to enable local browser window resizing,

display images in pages, play sounds in pages, enable scripting,
display a notification about every script error, and underline links.

Due to CE architecture, proxy exceptions are not available.

✎

Administrator’s Guide www.hp.com 5-11

Control Panel

JETCET PRINT 4.0

The JETCET PRINT Professional dialog box is used to set up the
terminal for local browser printing.

To open the JETCET PRINT Professional dialog box, double-click
the JETCET PRINT 4.0 icon in the Control Panel.

Select a default printer and manufacturer model, set the appropriate
print spooler options, and if printing serial choose either hardware or
software for serial handshaking between the terminal and printer.
Click the Properties button to configure the chosen printer’s settings.

For more information, refer to the JETCET user’s guide which can be

✎

found at http://www.westtek.com/support/pocketpc/jetcet.html.

5-12 www.hp.com Administrator’s Guide

Keyboard

Control Panel

To open the Keyboard Properties dialog box, double-click the

Keyboard icon in the Control Panel.

Repeat delay determines how quickly the same character displays on

screen when typed more than once.

Repeat rate determines how quickly the same character displays on
screen when the associated key is held down.

Legacy users should go to “Regional and Language Settings” to
change keyboard settings.

Administrator’s Guide www.hp.com 5-13

Control Panel

LPD Control

✎

The LPD Control dialog box allows you to set the terminal up as a
line printer (print server).

To open the LPD Control dialog box, double-click the LPD Control
icon in the Control Panel.

HP Compaq t5300 thin client models do not have legacy ports.
Therefore, the LPD Control program will not appear in the Control
Panel for those systems.

To set the terminal up as a print server:

1. Select the Enable Printer check box.

2. Enter the Printer Name and Network Port.

3. Select the appropriate printer port from the drop-down list. If you
select a ComPort, you have the option of configuring the serial
port by clicking the Configure button and entering the
appropriate parameters.

4. Select the Send Form Feed check box if form feeds are
necessary. This is needed primarily for older printer technology.

You must enable the terminal’s serial port in BIOS and in the Control

✎

Panel’s Port Lock utility. You must also set up the application server
for LPD printing.

Modems

The Modem Settings dialog box is used to access and modify settings
for external serial modems.

To open the Modem Settings dialog box, double-click the Modems
icon in the Control Panel

Refer to the modem device instructions for listings of modem “AT”
commands available for the modem.

5-14 www.hp.com Administrator’s Guide

Mouse

The Mouse Properties dialog box is used to set the mouse
double-click sensitivity for speed and physical distance between
clicks.

To open the Mouse Properties dialog box, double-click the Mouse
icon in the Control Panel.

Set the double-click sensitivity by double-clicking the grid icon, then
test the setting by double-clicking the test icon.

Use the Button Configuration tab to configure for left handed use.

Network and Dial-up Connections

The Network and Dial-up Connections utility is used to configure
connectivity between the terminal and the Internet, a network, or a
computer.

To open the Network and Dial-up Connections utility, double-click
the Network and Dial-up Connection icon in the Control Panel.

Control Panel

To make a new connection, double-click the Make New Connection
icon, select the type of connection you want to make, then configure
the connection as appropriate.

There are five connection types to choose from: Dial-up, Direct, VPN
(PPTP), VPN (L2TP), or Ethernet (PPPoE).

Administrator’s Guide www.hp.com 5-15

Control Panel

Dial-Up Connection

A serial dial-up modem can be used with the thin client to access a
dial-up server. With this method there are two ways to access the
enterprise intranet:

■ An enterprise dial-up server will connect directly to the enterprise

intranet.

■ An Internet Service Provider (ISP) dial-up server provides access

to the Internet, from which the thin client must access an
enterprise Point-to-Point Tunneling Protocol (PPTP) Virtual
Private Network (VPN) server that connects to the enterprise
intranet.

The dial-up server must be a Microsoft Remote Access Server or

✎

another server that supports industry-standard protocols.

Direct Connection

This type of connection is used to connect directly to another
computer through the serial port on the terminal.

This option is only available to thin clients with serial ports.

✎

Virtual Private Network (PPTP) Connection

Point-to-Point Tunneling Protocol (PPTP) is a network protocol that
enables the secure transfer of data between a remote client (in this
case the thin client) and an enterprise server environment by creating
a VPN across TCP/IP-based data networks such as the Internet. It
provides a password-protected path through the enterprise firewall to
the enterprise server environment in which the network and session
services required by the thin client reside.

An ISP must be available to provide access to the Internet. Any of the
standard means of connecting to the ISP may be used, such as a
dial-up modem, cable modem, and DSL modem.

5-16 www.hp.com Administrator’s Guide

Control Panel

The connection to the ISP must be established first, before contacting
the enterprise PPTP VPN server. This includes dial-up access as well
as direct access through the cable modem and DSL modem paths.

Virtual Private Network (L2TP) Connection

Layer Two Tunneling Protocol (L2TP) merges Microsoft’s PPTP
protocol with Cisco’s Layer Two Forwarding (L2F) protocol. L2TP is
basically the same as PPTP; the primary difference is that L2TP
supports encryption.

PPP Over Ethernet (PPPoE) Connection

This is a connection from the thin client Ethernet port directly to the
enterprise intranet. No additional hardware is required.

In this configuration all network services may be used, including the
enterprise DHCP server. A DHCP server on the network may provide
not only the terminal’s IP address, but also the location of the file
server containing the software updates.

Port Lock

The Port Lock dialog box allows you to enable or disable COM 1 and
LPT ports.

Open the Port Lock dialog box by double-clicking the Port Lock icon
in the Control Panel.

To enable (lock) a port, select the appropriate check box(es) and click
OK.

HP Compaq t5300 thin client models do not have legacy ports.

✎

Therefore, the Port Lock program will not appear in the Control Panel
for those systems.

Administrator’s Guide www.hp.com 5-17

Control Panel

RDP/ICA Printers

The RDP Printers dialog box is used to add local RDP printer
configurations and modify existing RDP printer configurations. This
enables the terminal to print from an RDP server session to a local
printer.

To open the RDP Printers dialog box, double-click the RDP Printers
icon in the Control Panel.

The RDP Printers dialog box contains an Add Printer icon and an
icon for each configured printer.

Adding a Printer

To add a printer configuration from the Printers dialog box:

1. Double-click the Add Printer icon or select it and click the Open
button. This invokes the Printer Wizard, which is used to
configure a new printer.

2. In the first panel of the wizard, select the appropriate port that you
want the printer to use and click the Next button.

3. In the next wizard panel, select the printer manufacturer and
model. If the desired printer is not listed, select the User Defined
check box. Click the Next button.

CAUTION: It is critical that the model name entered in step 3 matches

Ä

EXACTLY with the model name of the driver installed on the terminal
server. Otherwise, printing will fail.

5-18 www.hp.com Administrator’s Guide

Control Panel

4. The following panel appears only if you selected “Network” in
step 2. In this panel, enter the network path for the printer. If the
User Defined check box was selected in the previous wizard
panel, also enter the manufacturer and model of the printer.

5. In the next wizard panel, enter a name for the printer then click
the Next button.

6. In the next wizard panel, select whether you want to configure
another printer then click the Next button.

7. After all printer configuration selections have successfully been
completed, click the Finish button.

8. Connect to an RDP session, add the printer, and verify that it is
working properly.

Modifying an Existing Printer Configuration

To modify an existing printer configuration in the Printers dialog box:

1. Double-click the desired printer icon or select the icon and click
the Properties button. The Printer Properties dialog box is
displayed.

2. Make any necessary modifications, then click the OK button to
save the changes.

Administrator’s Guide www.hp.com 5-19

Control Panel

Regional and Language Settings

The Regional and Language Settings Properties dialog box is used to
customize regional settings for the terminal. You can change the way
Windows CE displays numbers, currency amounts, times, and dates.

To open the Regional Settings Properties dialog box, double-click the
Regional Settings icon in the Control Panel.

The Regional Settings Properties dialog box includes the following
tabs:

■ Regional Settings tab: Used to select an input locale, which

determines how some programs format numbers, currency, time,
and dates. The options available on the other tabs are determined
by the selected region. Click the Customize button to configure
the following items:

❏ Number tab: Used to change the way Windows displays

numbers.

❏ Currency tab: Used to change the way Windows displays

currency values.

❏ Time tab: Used to change the way Windows displays the

time.

❏ Date tab: Used to change the way Windows displays the

date.

■ User Interface Language tab: This option is used to determine

the language used for the menus, dialogs and alerts. Note that
only English is supported.

■ Input Language tab: Used to select desired language for

keyboard. Note that you can select multiple languages if desired.
You can toggle between languages by clicking on the language
system tray icon.

5-20 www.hp.com Administrator’s Guide

Security

Control Panel

The Security dialog box is used to control various terminal functions
related to security and terminal operator accounts.

To open the Security dialog box, double-click the Security icon in the
Control Panel.

Enabling Security

Select the Enable Security check box on the System tab to enable
terminal security. This forces a user to log in if the automatic login
feature is not enabled. It also activates the Enable Screen Lock and
Automatic Log On check boxes.

■ Select Enable Screen Lock to allow the terminal to be locked

through the

■ Select Automatic Log On to bypass the need for the user to enter

a password to log in. This also activates the Single Button Log
On check box and Account drop-down list.

❏ Select Single Button Log On to enable the single button

connect feature, which invokes a dialog box that requires the
terminal operator to press a keyboard key or click the Logon
button on the dialog box to log in.

Ctrl+Alt+Delete keyboard command.

❏ In the Account field, select the account the terminal operator

will automatically log in with. Refer to the next section,

“Creating a User’s Account,” for information on creating a

new account.

Select the Enable Reset Hotkey check box if you want to allow the
terminal to be reset to factory defaults (registry and shortcuts) by
pressing and holding the

Administrator’s Guide www.hp.com 5-21

F9 key during boot.

Control Panel

Creating a User’s Account

To create a new security account for a terminal operator, select the
Users tab on the Security dialog box. This tab lists all the operator
accounts and shows which accounts are set up with Administrator
security privileges and which accounts are enabled.

To create a new account:

1. Click the Add button on the Users tab. The Add New User dialog
box is displayed.

2. Enter a name for the new user account in the Name field.

3. Enter a password for the new user in the Password field.

4. Enter the password again in the Confirm Password field.

5. Leave the Account is disabled check box unchecked unless you
want to disable the account.

6. If you want to use the same Permissions assigned to an account
that was previously created, click the Set from Template button.
The Set from Template dialog box is displayed.

There are three default accounts already set up (Administrator, Guest,

✎

and User) that can be used as templates. You can also modify the
Guest and User accounts and use the modified accounts as templates.

a. Select the account type that you want to use as a template

from the drop-down list of accounts in the Based on field.

b. Click the Apply button to apply the selected template and

return to the Add New User dialog box.

5-22 www.hp.com Administrator’s Guide

7. If you are not basing the Permissions on a template and want to
choose which Permissions will be assigned to the new account,
select the Permissions tab on the Add New User dialog box.

8. The Permissions tab contains check boxes for all the items
available in the Control Panel plus a check box for access rights
to Windows Explorer and a check box to give the user permission
to change the password. Select the items in the list that you want
to allow the user to access. If the user is an Administrator, select
the User is an Administrator check box to provide the user with
access to all the listed items.

9. After completing all the above steps, click the OK button on any
of the Add New User tabs. You will return to the Users tab on the
Security dialog box with the new account listed in the accounts
list.

Refer to the previous section, “Enabling Security,” to enable security

✎

for the new account.

To modify a current account, select the account from the list on the

✎

Users tab of the Security dialog box and click the Modify button,
then make the appropriate modifications. Note that modifying the
default User or Guest accounts will also change the template
properties when using the Set from Template feature.

Control Panel

SNMP

The terminal can be managed through standard third-party simple
network management protocol (SNMP) tools. The SNMP Network
Administration dialog box is used to enter parameters required for
SNMP management.

SNMP agents run in network elements and respond to Network
Management Station (NMS) queries (GETs). SNMP provides a
means to query all terminals assigned to a specific community. Each
community should have a unique name and all members of a
community have the same access privileges. A single terminal can be
assigned to multiple communities.

Administrator’s Guide www.hp.com 5-23

Control Panel

Agents send unsolicited reports (traps) back to a specified IP address
when a particular network activity occurs. Five traps are supported:
cold start, warm start, authentication failure, link down, and link up.

To open the SNMP Network Administration dialog box, double-click
the SNMP icon in the Control Panel.

1. On the Agent tab, enter the physical location of the terminal in
the Location field.

2. Enter the name of the contact person responsible for the terminal
in the Contact field.

3. Assign the terminal to a community by selecting a community
from the Community Name drop-down list. If you want to create
a new community, do the following:

a. Click the Add Community button. The Community

Configuration dialog is displayed.

b. Enter a name for the new community and click the OK

button.

4. To add a trap destination:

a. Click the Add button. The SNMP Configuration dialog is

displayed.

b. Enter the host name or IP address of the NMS trap server and

click the OK button.

5-24 www.hp.com Administrator’s Guide

Control Panel

5. Select the Security tab to add/change SNMP security settings.

6. To enable an authentication failure trap, make sure the Enable
Authentication Failure Trap check box is selected.

7. To add an accepted community and assign rights to the
community:

a. Click the Add button in the Accepted Community Names

section. The Community Configuration dialog is displayed.

b. Enter the name of the community in the Community Name

field.

c. Select the rights to the community from the Rights

drop-down list and click the OK button.

8. Select the hosts from which SNMP packets may be accepted.
Choose either Accept SNMP packets from any host or Accept
SNMP packets from these hosts. If you choose the latter, enter
the host(s) as follows:

a. Click the Add button in the SNMP packets section. The

SNMP Configuration dialog is displayed.

b. Enter the host name or IP address and click the OK button.

c. Repeats steps a and b above to add as many hosts as

necessary.

9. After entering all the necessary SNMP information, click the OK
button in the upper right corner of the SNMP Network
Administration dialog box.

SNTP Client

The SNTP GUI Applet allows administrators to synchronize the
clocks on all thin clients. Administrators can set thin clients to
automatically synchronize with an Internet time server or with a boot
server.

Synchronization can occur only when your computer is connected to

✎

the Internet.

Administrator’s Guide www.hp.com 5-25

Control Panel

System

The System Properties dialog box is used to view terminal
manufacturer and product information, network settings, and
copyright information. You can also reset the terminal to the default
factory settings, adjust the memory allocated for storage and running
programs, enter a device name for network identification purposes,
and configure the network card.

To open the System Properties dialog box, double-click the System
icon in the Control Panel.

The System Properties dialog box includes the following tabs:

■ General tab: Displays manufacturer and product information for

the terminal. Includes a Reset button that can be used to reset the
terminal to factory default property settings. It also includes
Export and Import buttons to allow for easy registry
import/export.

■ Memory tab: Used to adjust memory allocation between

memory for storage room and memory needed to run programs.

■ Network tab: Used to enter a device name and description for

the terminal that identifies the terminal across the network. You
have the option of entering a name or accepting the name
provided by the DHCP server. The default device name is “HP”
followed by the MAC address. If the device is reset to factory
defaults, the device name will revert to the factory default name.

This tab also displays network settings and provides a Configure
Network Card button that can be used to adjust the speed/duplex
for the card.

■ Copyrights tab: Displays copyright information for the terminal.

System Update

The System Upgrade define the means by which the image is
upgraded on the terminal. The image can be upgraded directly from
HP, by manually entering the FTP file server information for the
server that contains the upgrade files, or by allowing the DHCP server
to locate the FTP file server that contains the upgrade files.

5-26 www.hp.com Administrator’s Guide

Open the System Update dialog box by double-clicking the System
Update icon in the Control Panel. The dialog box contains two tabs:
Direct from HP and FTP.

Direct from HP Tab

The Direct from HP tab in the FTP Upgrade Settings dialog box is
used to upgrade the terminal with the latest available image directly
from Hewlett-Packard or restore the image currently installed on the
terminal.

To upgrade or restore the image, select the appropriate radio button
and press the Continue button.

CAUTION: DO NOT power off the terminal during the upgrade process.

Ä

Turning off the power before the upgrade is complete may corrupt the
flash memory on the terminal.

FTP Tab

The FTP tab in the System Update dialog box is used to
automatically upgrade the image by having the DHCP server provide
the location of the file server on which the upgrade files are located.

Control Panel

For more information on setting DHCP values, refer to the “DHCP

✎

Options” section in this chapter.

To upgrade the image via the DHCP server:

1. Select the Use Values from DHCP Setting tab on the System
Update dialog box.

2. Enter the Server Name/IP.

3. Enter the Path and File name

4. Enter the Server Port.

5. Enter the user ID required by the FTP file server in the User ID
field.

6. Enter the password required by the FTP file server in the
Password field.

Administrator’s Guide www.hp.com 5-27

Control Panel

7. To automatically upgrade the image each time the terminal is
restarted, select the Automatically Check for Updates on
Startup check box.

8. Click the Update button to begin the update process.

CAUTION: DO NOT power off the terminal during the upgrade process.

Ä

Turning off the power before the upgrade is complete may corrupt the
flash memory on the terminal.

Terminal Server Client Licenses

The Terminal Server Client Licenses dialog box is used to view
stored licenses. You can use this window to delete or save licenses.

View or Remove Programs

The View or Remove Programs dialog box is used to view or remove
software programs currently installed on the terminal.

To open the View or Remove Programs dialog box, double-click the
View or Remove Programs icon in the Control Panel.

To remove a program, select the program from the list and click the
Remove button.

VNC Server

Virtual Network Computing (VNC) is a remote control program that
allows you to view and interact with one computer (the "server")
using a simple program (the "viewer") on another computer anywhere
on the Internet.

For additional information please see the “VNC Server” on page 6 in
Chapter Six of this guide.

5-28 www.hp.com Administrator’s Guide

Volumes & Sounds

The Volumes & Sounds Properties dialog box is used to adjust the
volume setting and enable sounds for various events and conditions.
You can also create custom sound schemes for various events.

To open the Volumes and Sounds Properties dialog box, double-click
the Volumes & Sounds icon in the Control Panel.

Control Panel

Administrator’s Guide www.hp.com 5-29

Control Panel

5-30 www.hp.com Administrator’s Guide

Programs and Add-ons

This chapter provides detailed information about programs and
add-on programs for the CE 5.0 image. Add-ons are available for
download at the HP Support Web site.

Programs and Features

ELO Touch Screen

The ELO Touch Screen dialog box is used to enable or disable the
cable connection. You can also calibrate the touch screen by clicking
the Align button.

To open the ELO Touch Screen dialog box, double-click the ELO
Touch icon in the Control Panel.

HP Connections for Citrix Software

6

The HP Connections for Citrix Software utility provides a quick and
easy means of creating new ICA connections. You can also delete and
edit connections, as well as create desktop shortcuts for connections.

Connections can also be established through the HP Connection

✎

Administrator utility. If a Connection is created in HP Connection
Window, it will also appear in HP Connection Administrator.
Likewise, if a Connection is created in HP Connection Administrator,
it will also appear in HP Connections for Citrix Software.

The HP Connections for Citrix Software utility is launched when the
terminal boots. It is also available in the Start menu (Start >
Programs > HP Connections for Citrix Software) and as a shortcut
icon on the desktop.

Administrator’s Guide www.hp.com 6-1

Programs and Add-ons

Creating a New ICA Connection

The upper section of the window contains the ICA connection and an
icon that launches HP Connection Administrator.

To create a new connection, do one of the following:

■ Double-click the icon in the top section.

■ From the File menu, highlight New Connection and select the

type of connection you want to make. Follow the instructions in
the Wizard or dialog that is displayed.

Deleting a Connection

To delete a connection that has already been established:

1. Right-click on the connection you want to delete and select
Delete Connection; or, select the connection and press the
key on the keyboard. A Confirm Delete dialog is displayed.

2. Click the Ye s button in the Confirm Delete dialog to delete the
connection.

Deleting a connection through HP Connections for Citrix Software

✎

also deletes the connection from HP Connection Adminstrator.

Delete

Editing a Connection

To edit a connection that has already been established:

1. Right-click on the connection you want to edit and select Edit
Connection. A dialog or Wizard for the connection is displayed.

2. Reconfigure the connection as appropriate.

Creating a Desktop Shortcut to a Connection

You can create a shortcut to a connection on the desktop through HP
Connections for Citrix Software (shortcuts can not be created through
HP Connection Administrator).

To create a shortcut, right-click on the connection and select Send to

Desktop. A shortcut to the connection appears on the desktop.

6-2 www.hp.com Administrator’s Guide

Programs and Add-ons

HP Registry Import/Export Tool

Microsoft Windows CE HP Image versions 4.21 and later include the
Registry Import/Export tool, an HP engineered software technology
that makes it significantly easier and more cost efficient for IT
professionals to manage HP thin clients. Registry Import/Export
allows thin client devices to inherent properties of other thin client
devices.

CAUTION: The HP Registry Import/Export Tool requires extensive

Ä

knowledge of Altiris Deployment Server.

Currently, Registry Import/Export between the HP Compaq t5510

✎

thin client and the HP Compaq t53x0 and t5500 thin clients is not
supported.

Your source and target machine must have the same image with the

✎

same quantity of software add-ons. These software add-ons must be
of the same revision. The Registry Import/Export Tool cannot
upgrade or downgrade application versions..

Extracting the settings of one device and re-deploying the same
settings to other devices reduces network congestion. Registry
settings can be 100 to 10,000 times smaller than the entire image.

NOTE: The Import/Export process may take approximately two
minutes to complete.

Clearing the Destination Registry

Before importing a new registry to a thin client, you must make sure
that the destination machine has a clear registry. To clear the registry,
drag and drop CE_RegReset from the Job window to the

Destination Computer.

NOTE: This process will take two to three minutes to complete.

Administrator’s Guide www.hp.com 6-3

Programs and Add-ons

Exporting and Importing a Registry

To export a registry, perform the following steps:

1. Open the Deployment Server Console.

2. Select CE_RegExport from the Job window and drag and drop
the Job to the source unit under the Computers window. This will
copy the source computer's registry and prepare it to be imported.

3. Select CE_RegImport from the Job window and drag and drop
the job to the destination computer under the Computers window.
This will import the settings from the source computer to the
destination computer.

NOTE: This process will take two to three minutes to complete.

Importing a Registry to Multiple Units

A single registry can be imported to multiple units. To import a
registry to multiple units, perform the following steps:

1. Select CE_RegExport from the Job window and drag and drop
the Job to the source unit under the Computers window. This will
copy the source computer's registry and prepare it to be imported.

2. Select CE_RegImport from the Job window and drag and drop
the job to "All Computers" under the Computers window. This
will import the settings from the source computer to the entire
network.

Exporting Registries from Multiple Units

While it is possible to export registries from multiple thin clients, it is
important to ensure the registry files have different names. The export
process uses a time stamp and saves the time stamp as part of the
name for the saved file (for example, 051304840.reg, which is May
30, 2004 at 8:40). If you export multiple units at the same time, the
registry file names will be identical. It is recommended that you
capture each registry a minute apart in order to create distinct file
names for each registry.

6-4 www.hp.com Administrator’s Guide

Programs and Add-ons

RDP 5.5

RDP 5.5 replaces RDP 5.1, and provides the following functionality:

■ Unicode compatibility, which enables you to send Unicode

values of characters as virtual key codes to the keyboard input.

■ RDP supports operation in any environment that allows network

localization, automatic disconnect and remote configuration.

■ Variable bandwidth allocation through client-side bitmap caching

and optional compression for low-bandwidth connections,
significantly improving performance over low-bandwidth
connections.

■ Multichannel-capable protocol that permits separate virtual

channels for carrying presentation data, serial-device
communication, licensing information, and heavily encrypted
data.

■ Remote control which lets the support staff view and control a

Terminal Services session. Sharing input and display graphics
between two Terminal Services sessions lets support staff
diagnose and resolve problems remotely.

■ Network Load Balancing (NLB), available in Windows 2000

Advanced Server and Datacenter Server.

■ High color 8-bit, 16-bit, and 24-bit graphics are supported if they

are also supported in the graphics driver.

■ Clipboard sharing, also known as clipboard redirection. The local

clipboard becomes a part of the clipboard viewer chain in the
remote session, allowing the user to copy and paste between
applications running in both the remote session and on the local
client.

■ Local-printer redirection so server applications can print locally

to the client device.

■ Local audio playback so server applications can direct audio to

the client device or play at the Terminal Server.

■ Local-port redirection so server applications can use parallel and

COM ports of the client device.

■ Local drive redirection so server applications can use the file

system (including ATA) of the client device.

Administrator’s Guide www.hp.com 6-5

Programs and Add-ons

■ File redirection filter that permits exposing only specific

directories. If you specify that only external storage, such as
Compact Flash or USB storage, be exposed through the
redirected drive, information is saved only to the redirected drive.

■ TS CAL maintenance tool. This control panel utility is available

in any OS design that supports Control Panel programs, such as
the Enterprise Web Pad. It requires that RDP client be in the
run-time image.

RDP now runs in Graphics, Windowing, and Events Subsystem
(GWES) rather than in its own process space. This provides faster
display updates by reducing the protected server library (PSL) and
kernel overhead. RDP running in GWES can improve performance
up to 30%.

NOTE: If you configured RDP to run in GWES, you cannot run RDP
inside a Web browser. Optionally, you can configure RDP to run in
Microsoft ActiveX Control.

RDP can run in windowed mode, allowing you to have two
simultaneous RDP sessions visible at the same time.

VNC Server

Virtual Network Computing (VNC) is a remote control program that
allows you to view and interact with one computer (the "server")
using a simple program (the "viewer") on another computer anywhere
on the Internet.

The VNC Server runs as a service and therefore is available even
when the user is logged off the thin client.

6-6 www.hp.com Administrator’s Guide

Programs and Add-ons

Settings for VNC Server

Configure VNC Server on your thin client by checking the following
check boxes:

Check Box Explanation

Prompt local user to accept
incoming connections

Enable Viewer Cursor This setting allows the viewer to

Accept input events from clients Enabling this setting will allow the

Autoport Select This setting will be deprecated,

The default should ENABLED and
Auto Accept should be ENABLED

show its cursor on the screen while
moving the mouse. The viewer
shows a small dot that points to the
actual location of the "hot spot" of
the remote cursor location.
Enabling this setting will show the
local cursor of the viewer;
however, the remote dot will lag
behind the local viewer cursor as it
tries to synchronize the local
viewer cursor.

viewer to control the keyboard and
mouse of the unit remotely.

leaving only the "Accept
connections on port" and "Allow
HTTP connections on port".

Accept connections on port Defaults to the standard VNC port

of 5900.

Allow HTTP connections on port Defaults to the standard VNC port

of 5800 for JVM (Java) enabled
Web Browser Viewers.

Additional information about VNC Server features can be found at:

http://www.realvnc.com/documentation.html

Administrator’s Guide www.hp.com 6-7

Programs and Add-ons

Add-ons

TxtPad

The TxtPad Add-on adds a text editor to the CE 5.0 image.

TxtPad associates with the following file extensions: .txt, .ini, .log,
and .arp.

NOTE: The maximum character limit is 5MB of ASCII data.

TxtPad feature the following functionality through both key shortcut
and through the Edit menu: Copy, Cut, Paste Find and Find Next.

There will be a shortcut in the Start-Programs menu.

The following section provides information about add-ons that can be
added to your CE-based thin client image.

Messenger 5.0 Add-on

The Windows Messenger 5.0 add-on adds the folowing functionality:

■ Support for categorizing contacts into groups and for dragging

and dropping contacts.

■ User Interface (UI) improvements, including system tray

notifications (known as alerts) for incoming messages, and
ToolTip support.

■ An updated .NET Messenger Service.

■ Microsoft Windows Messenger for Windows CE real-time

communications software combines real-time voice and text
communications with file transfer capability. The .NET
Messenger Service is one of two Windows Messenger client
application server types. It enables a user to communicate with
contacts using a .NET Passport account.

6-8 www.hp.com Administrator’s Guide
