Modem and Networking Guide
First Edition April 2002
Document Part Number: 267639-001

Contents

1 Using an Internal Modem

Connecting the Modem Cable . . . . . . . . . . . . . . . . . . . . . 1–2

Using the RJ-11 Cable. . . . . . . . . . . . . . . . . . . . . . . . 1–2

Using a Country-Specific Modem Cable Adapter. . . 1–4

Adding New Locations When Travelling . . . . . . . . . 1–6

Solving Travel Connection Problems . . . . . . . . . . . . 1–7

Accessing Preinstalled Communication Software . . . . . 1–12

2 Connecting to a Network

Connecting a Network Cable . . . . . . . . . . . . . . . . . . . . . . 2–2

Modem & Networking iii

1

Using an Internal Modem

Your notebook has an internal modem, an RJ-11 telephone jack,
preinstalled modem drivers, and a modem cable. The internal
modem:

Supports applications running under Microsoft Windows 98,

■

Windows 2000 Professional, Windows XP Home, and
Windows XP Professional operating systems.

Supports V.34 ITU (International Telecommunications

■

Union) analog modem recommendations for speeds up to

33.6 Kbps. Supports V.44 data compression algorithm.

Supports V.90/V.92 ITU digital/analog modem pair

■

recommendations for speeds up to 56 Kbps.

The digital/analog modem pair rates allow faster downloads
only from compliant digital sources. Maximum achievable
download rates are currently unknown, may not reach
56 Kbps, and will vary with line conditions. Maximum
achievable upload rates are limited to 31.2 Kbps, may not
reach 31.2 Kbps, and will vary with line conditions.

Uses a universal Direct Access Arrangement (DAA) that

■

supports multiple countries. An adapter may be required to
connect the modem to the standard telephone jack in some
countries.

Does not support the modem pass-through connection

■

available on some optional port replicators.

Modem & Networking 1–1

Using an Internal Modem

Connecting the Modem Cable

Using the RJ-11 Cable

The modem cable may have noise suppression circuity that
prevents interference with TV and radio reception. The modem
cable must be connected to an analog telephone line.

CAUTION: Jacks for digital PBX systems may resemble analog

Ä

telephone jacks, but are not compatible with the modem.

1. If the modem cable has noise suppression circuitry 1, orient
the circuitry end of the cable toward the computer.

2. Plug the cable into the RJ-11 telephone jack
notebook.

WARNING: To reduce the risk of electrical shock, fire, or damage to

Å

the equipment, do not plug a telephone cable into the RJ-45 jack.

on the

2

1–2 Modem & Networking

Using an Internal Modem

3. Plug the modem cable into the RJ-11 telephone jack 3.

Connecting the modem using an RJ-11 jack

WARNING: To reduce the risk of electrical shock, always ensure

Å

that the modem line is disconnected from the telephone network
when opening the notebook’s enclosure.

Modem & Networking 1–3

Using an Internal Modem

Using a Country-Specific Modem Cable Adapter

Software for the internal modem supports multiple countries, but
telephone jacks vary by country. To use the modem and the RJ-11
cable outside the country in which you purchased the notebook,
you must obtain a country-specific modem adapter and define
your location in Dialing Properties.

To connect the modem to an analog telephone line that does not
have an RJ-11 telephone jack:

1. If the modem cable has noise suppression circuitry
the circuitry end of the cable toward the notebook.

2. Plug the modem cable into the RJ-11 telephone jack
notebook.

3. Plug the country-specific modem adapter

into the

3

telephone jack.

4. Plug the modem cable

into the country-specific modem

4

adapter.

, orient

1

on the

2

Connecting the modem using a country-specific modem
adapter

1–4 Modem & Networking

Using an Internal Modem

Viewing the Current Country Selection

To see the current country setting for your modem, follow
these steps:

Windows 98:

Select Start > Settings > Control Panel > Modems > Dialing
Properties. The current country selection appears in the
I Am In box.

Windows 2000 Professional:

1. Select Start > Settings > Control Panel.

2. Double-click the Regional Options icon.

3. Under Settings for the Current User, view the country that is
displayed under Your Locale.

Windows XP Home and XP Professional:

1. Select Start > Control Panel.

2. Double-click the Regional & Language Options icon.

3. Under Location, view your present location.

Modem & Networking 1–5

Using an Internal Modem

Adding New Locations When Travelling

The internal modem is configured to meet only the operating
standards in the country where you purchased the notebook.
When travelling internationally, you can add new location
configurations that comply with standards in other countries.

CAUTION: Do not delete your current modem country settings. To

Ä

enable modem use in other countries while preserving your home
country configuration, add a new configuration for each location in
which you will use the modem.

The drop-down lists described below may include countries not
supported by the modem. Unless you select a supported country,
the country selection will default to USA or UK.

CAUTION: Selecting a country other than the one in which it is

Ä

located may cause your modem to be configured in a way that
violates the telecommunications regulations/laws of that country.
In addition, your modem may not function properly if the correct
country selection is not made.

To add a new country location, follow these steps:

Windows 98:

1. Select Start > Settings > Control Panel.

2. Double-click the Modems icon > General tab > Select your
modem > Dialing Properties.

3. Assign the Location name (home, work, etc.).

4. Select the Country/Region from the drop-down list.

5. Click OK > OK.

Windows 2000 Professional:

1. Select Start > Settings > Control Panel.

2. Double-click the Phone and Modem Options icon >
Select New.

1–6 Modem & Networking

Using an Internal Modem

3. Assign the New Location Name (home, work, etc.).

4. Select the Country/Region from the drop-down list.

5. Click OK > OK.

Windows XP Home and XP Professional:

1. Select Start > Control Panel.

2. Double-click the Network and Internet Connections icon.

3. Select Phone and Modem Properties (menu in the left
column) > Dialing Rules tab.

4. Select the New button and assign it a name (home,
work, etc.).

5. Select the Country/Region from the drop-down list.

6. Click OK > OK.

Solving Travel Connection Problems

If you experience connection problems while using the modem
outside your home country, the following suggestions may help:

Check the telephone line type

■

The modem requires an analog, not a digital, telephone line.
A line described as a PBX line is usually a digital line. A
telephone line described as a data line, fax machine line,
modem line, or standard telephone line, is probably an
analog line.

Modem & Networking 1–7

Using an Internal Modem

Check for pulse or tone dialing

■

Dial a few digits on the telephone and listen for clicks
(pulses) or tones. Then select:

Windows 98:

1. Select Start > Settings > Control Panel.

2. Double-click the Modems icon > General tab.

3. Select your modem > Dialing Properties > Tone or

Pulse Dialing.

4. Select OK > OK.

Windows 2000 Professional:

1. Select Start > Settings > Control panel.

2. Double-click the Phone and Modem Options icon.

3. Select your location > Edit > Tone or Pulse Dialing.

4. Select OK > OK.

Windows XP Home and XP Professional:

1. Select Start > Control Panel.

2. Double-click the Network and Internet Connections

icon > Phone and Modem Properties (menu in the left
column).

3. Select the Dialing Rules tab.

4. Select your location.

5. Select Edit > Tone or Pulse Dialing.

6. Select OK > OK.

1–8 Modem & Networking

Using an Internal Modem

Check the telephone number you are dialing and the

■

response of the remote modem

Dial the telephone number on the telephone, wait for the
remote modem to answer, then hang up.

Set the modem to ignore dial tones

■

If the modem receives a dial tone it does not recognize, it will
not dial and will display a No Dial Tone error message. Use
the following procedures to set the modem to ignore all dial
tones before dialing:

Windows 98:

1. Select Start > Settings > Control Panel.

2. Double-click the Modems icon > Select your modem.

3. Select Properties > Connection tab > Clear the Wait for

Dial Tone Before Dialing check box.

4. If you continue to receive the No Dial Tone error

message after clearing the check box:

a. Select Start > Settings > Control Panel >

Double-click Modem > Dialing Properties.

b. Select your location in the I Am In drop-down box.

c. Clear the Wait for Dial Tone Before Dialing

check box.

Windows 2000 Professional:

1. Select Start > Settings > Control Panel.

2. Double-click the Phone and Modem Options icon >

Modem tab.

3. Select your modem.

4. Select Properties > General tab.

Modem & Networking 1–9

Using an Internal Modem

5. Clear the Wait for Dial Tone Before Dialing check box.

6. If you continue to receive the No Dial Tone error

message after clearing the check box:

a. Select Start > Settings > Control Panel > Phone and

Modems Options icon.

b. Select the Dialing Rules tab.

c. In the Locations list, select the location from which

you are dialing.

d. Select Edit.

e. Select your location from the drop-down list in the

Country/Region box.

f. Select Apply > OK.

g. Select the Modem tab.

h. Select your modem.

i. Select Properties > General tab.

j. Clear the Wait for Dial Tone Before Dialing

check box.

1–10 Modem & Networking

Using an Internal Modem

Windows XP Home and XP Professional:

1. Select Start > Control Panel > Network and Internet

Connections icon.

2. Select Phone and Modem Properties (menu in the left

column) > Modem Tab.

3. Select your modem > Properties > Modem tab.

4. Clear the Wait for Dial Tone Before Dialing check box.

5. If you continue to receive the No Dial Tone error

message after clearing the check box:

a. Select Start > Control Panel > Network and Internet

Connections icon.

b. Select Phone and Modem Properties (menu in the left

column).

c. Select the Dialing Rules tab.

d. Select your location > Edit.

e. Select your location from the drop-down list in the

Country/Region box.

f. Select Apply > OK.

7. Select the Modem tab.

8. Select your modem > Properties.

9. Clear the Wait for Dial Tone Before Dialing check box.

Modem & Networking 1–11

Using an Internal Modem

Accessing Preinstalled Communication Software

To use preinstalled modem software for terminal emulation and
data transfer, follow these steps:

Windows 98:

Select Start > Programs > Accessories > HyperTerminal.

Windows 2000 Professional:

1. Start > Programs > Accessories > Communications.

2. Select the appropriate terminal emulation program or internet
connection wizard.

Windows XP Home or Windows XP Professional:

1. Start > All Programs > Accessories > Communications.

2. Select the appropriate fax or terminal emulation program or
internet connection wizard.

1–12 Modem & Networking

Connecting to a Network

Your notebook has an RJ-45 network jack, an internal NIC
(network interface card), preinstalled network drivers, and may
have a network cable.

Networking requiring connection to domains is not supported in

✎

Windows XP Home Edition.

Your notebook supports:

Network speeds up to 10 Mbps when connected to a 10BaseT

■

network and 100 Mbps when connected to a 100BaseTX
network.

Can be connected to a network whether or not the internal

■

modem is connected to a telephone line.

56bitDES or 3DES or “null” encryption with MD5 or SHA-1

■

integrity.

2

IPSec Authentication Header (AH) transform algorithms:

■

MD5 and SHA-1.

If your notebook is connected to a network, you may want to

✎

confer with your network administrator before changing network
settings.

Modem & Networking 2–1

Connecting to a Network

Connecting a Network Cable

A network cable has an 8-pin RJ-45 network connector at each
end and may contain noise suppression circuitry, which prevents
interference with TV and radio reception.

1. Orient the end of a network cable with noise suppression
circuitry

toward the RJ-45 network jack on the notebook.

1

2. Plug the network cable into the RJ-45 network jack
notebook.

3. Plug the other end of the cable into an RJ-45 network jack

4. Start or restart the notebook.

5. Connect to the network.

Connecting a network cable

on the

2

3

.

2–2 Modem & Networking
