HP Compaq LA1905wg, Compaq LA2205wg, Compaq LA22f, Compaq LA2405x, Passport 1912nm Reference Guide
HP LCD Monitors
Reference Guide
© 2011 Hewlett-Packard Development
Company, L.P.
Microsoft, Windows, and Windows Vista are
either trademarks or registered trademarks
of Microsoft Corporation in the United
States and/or other countries.
The only warranties for HP products and
services are set forth in the express
warranty statements accompanying such
products and services. Nothing herein
should be construed as constituting an
additional warranty. HP shall not be liable
for technical or editorial errors or omissions
contained herein.
This document contains proprietary
information that is protected by copyright.
No part of this document may be
photocopied, reproduced, or translated to
another language without the prior written
consent of Hewlett-Packard Company.
First Edition (September 2011)
Document Part Number: 672303-001
About This Guide
This guide provides information on safety and maintenance guidelines, operating the monitor, and
troubleshooting common problems.
WARNING! Text set off in this manner indicates that failure to follow directions could result in bodily
harm or loss of life.
CAUTION: Text set off in this manner indicates that failure to follow directions could result in
damage to equipment or loss of information.
NOTE: Text set off in this manner provides important supplemental information.
ENWW iii
iv About This Guide ENWW
Table of contents
1 Optimizing Monitor Performance .................................................................................................................. 1
Use Caution When Setting Up the Monitor .......................................................................................... 1
To Get the Best Performance from Your Monitor ................................................................................. 2
2 Safety and Maintenance Guidelines .............................................................................................................. 3
Important Safety Information ................................................................................................................ 3
Maintenance Guidelines ....................................................................................................................... 3
Cleaning the Monitor ............................................................................................................ 4
Shipping the Monitor ............................................................................................................ 4
3 Operating the Monitor .................................................................................................................................... 5
Setting Up the Monitor .......................................................................................................................... 5
Software and Utilities ............................................................................................................................ 5
The Information File ............................................................................................................. 5
The Image Color Matching File ............................................................................................ 5
Installing the .INF and .ICM Files ......................................................................................................... 6
Installing from the CD .......................................................................................................... 6
Downloading from the Internet ............................................................................................. 6
Using and Adjusting the Monitor .......................................................................................................... 6
Using the Auto-Adjustment Function ................................................................................... 6
Adjusting the Monitor Settings ............................................................................................. 7
Using the On-Screen Display Menu .................................................................... 7
Optimizing Image Performance (Analog Input) ................................................... 8
Sleep Timer Mode ............................................................................................. 10
Using the HP Display Assistant Utility (select models) ..................................... 11
Identifying Monitor Conditions ........................................................................................... 11
Appendix A Troubleshooting .......................................................................................................................... 13
Solving Common Problems ................................................................................................................ 13
Online Technical Support ................................................................................................................... 14
Preparing to Call Technical Support ................................................................................................... 14
Locating the Rating Labels ................................................................................................................. 14
Appendix B Agency Regulatory Notices ....................................................................................................... 15
Federal Communications Commission Notice ................................................................................... 15
Modifications ...................................................................................................................... 15
ENWW v
Cables ................................................................................................................................ 15
Declaration of Conformity for Products Marked with the FCC Logo (United States Only) ................. 15
Canadian Notice ................................................................................................................................. 16
Avis Canadien .................................................................................................................................... 16
European Union Regulatory Notice .................................................................................................... 16
German Ergonomics Notice ............................................................................................................... 17
Japanese Notice ................................................................................................................................. 17
Korean Notice ..................................................................................................................................... 17
Power Cord Set Requirements ........................................................................................................... 17
Japanese Power Cord Requirements ................................................................................ 17
Product Environmental Notices .......................................................................................................... 18
ENERGY STAR® Qualification .......................................................................................... 18
Materials Disposal ............................................................................................................. 18
Disposal of Waste Equipment by Users in Private Household in the European Union ..... 19
HP Recycling Program ...................................................................................................... 19
Chemical Substances ........................................................................................................ 19
Restriction of Hazardous Substances (RoHS) ................................................................... 19
Turkey EEE Regulation ..................................................................................................... 20
Ukraine Restriction of Hazardous Substances .................................................................. 20
Appendix C LCD Monitor Quality and Pixel Policy ....................................................................................... 21
vi ENWW
1 Optimizing Monitor Performance
Use Caution When Setting Up the Monitor
To prevent damage to the monitor, do not touch the surface of the LCD panel. Pressure on the panel
may cause non-uniformity of color or disorientation of the liquid crystals. If this occurs the screen will
not recover to its normal condition.
If installing a base, lay the monitor face down on a flat surface covered with a protective sheet foam
or non-abrasive cloth. This prevents the screen from getting scratched, defaced or broken as well as
damage to the front panel buttons.
Figure 1-1 Handling the Monitor
NOTE: Your monitor may look different from the monitor in this illustration.
ENWW Use Caution When Setting Up the Monitor 1
To Get the Best Performance from Your Monitor
1. Be sure to install the latest graphics card driver from your graphics card manufacturer.
2. For monitors using VGA signal input, once the monitor is operating, press the Auto button on the
monitor to optimize the display. If the Auto function does not fully correct the display, run the
Auto-Adjustment software available on the CD included with the monitor and then press the Auto
button.
3. Using the Display Properties settings of the computer’s operating system, set your screen to the
optimal resolution for your monitor size as indicated in the following table.
Monitor Size Aspect Ratio
Format
15 in 38.1 cm 4:3 1024 x 768 60
15 in 38.1 cm 16:9 1280 x 720 60
15.6 in
18.5 in
17 in
19 in
17 in
19 in
20 in 50.8 cm 16:9 1600 x 900 60
20.1 in 51.1 cm 4:3 1600 x 1200 60
20.1 in
22 in
21.5 in
42 in
47 in
39.6 cm
47 cm
43.2 cm
48.3 cm
43.2 cm
48.3 cm
51.1 cm
55.9 cm
54.6 cm
106.7 cm
119.4 cm
16:9 1366 x 768 60
5:4 1280 x 1024 60
16:10 1440 x 900 60
16:10 1680 x 1050 60
16:9 1920 x 1080 60
Optimal Resolution Refresh
Rate (Hz)
23 in
24 in
27 in
30 in 76.2 cm 16:10 2560 x 1600 60
58.4 cm
61 cm
68.6 cm
16:10
16:9
1920 x 1200 60
4. Install the most up-to-date driver on the computer if it is not already installed. The latest driver is
on the CD included with the monitor, or you can download the latest driver from the HP monitors
support Web site,
http://www.hp.com/support.
IMPORTANT: For optimal video performance, use only the video cable(s) included with the monitor.
To maximize the display life and avoid burn-in damage, activate a screen saver application or turn off
the monitor when it is not in use for a prolonged period of time (12 consecutive hours of non-use).
2 Chapter 1 Optimizing Monitor Performance ENWW
2 Safety and Maintenance Guidelines
Important Safety Information
A power cord is included with the monitor. If another cord is used, use only a power source and
connection appropriate for this monitor. For information on the correct power cord set to use with the
monitor, refer to the
WARNING! To reduce the risk of electric shock or damage to the equipment:
• Do not disable the power cord grounding feature. The grounding plug is an important safety feature.
• Plug the power cord in a grounded (earthed) outlet that is easily accessible at all times.
• Disconnect power from the product by unplugging the power cord from the electrical outlet.
For your safety, do not place anything on power cords or cables. Arrange them so that no one may
accidentally step on or trip over them. Do not pull on a cord or cable. When unplugging from the
electrical outlet, grasp the cord by the plug.
Power Cord Set Requirements on page 17.
To reduce the risk of serious injury, read the
workstation, setup, posture, and health and work habits for computer users, and provides important
electrical and mechanical safety information. This guide is located on the Web at
ergo and/or on the documentation CD, if one is included with the monitor.
CAUTION: For the protection of the monitor, as well as the computer, connect all power cords for
the computer and its peripheral devices (such as a monitor, printer, scanner) to some form of surge
protection device such as a power strip or Uninterruptible Power Supply (UPS). Not all power strips
provide surge protection; the power strips must be specifically labeled as having this ability. Use a
power strip whose manufacturer offers a Damage Replacement Policy so you can replace the
equipment, if surge protection fails.
Use the appropriate and correctly sized furniture designed to properly support your HP LCD monitor.
WARNING! LCD monitors that are inappropriately situated on dressers, bookcases, shelves, desks,
speakers, chests, or carts may fall over and cause personal injury.
Care should be taken to route all cords and cables connected to the LCD monitor so that they can not
be pulled, grabbed, or tripped over.
Maintenance Guidelines
To enhance the performance and extend the life of the monitor:
Do not open the monitor cabinet or attempt to service this product yourself. Adjust only those
●
controls that are covered in the operating instructions. If the monitor is not operating properly or
has been dropped or damaged, contact an authorized HP dealer, reseller, or service provider.
Safety and Comfort Guide
. It describes proper
http://www.hp.com/
Use only a power source and connection appropriate for this monitor, as indicated on the label/
●
back plate of the monitor.
Be sure the total ampere rating of the products connected to the outlet does not exceed the
●
current rating of the electrical outlet, and the total ampere rating of the products connected to the
cord does not exceed the rating of the cord. Look on the power label to determine the ampere
rating (AMPS or A) for each device.
ENWW Important Safety Information 3
