Deskpro Service Reference Guide

152611-001

123385-001

Deskpro Service Reference Guide

Notice

The information in this guide is subject to change without notice. COMPAQ COMPUTER CORPORATION SHALL NOT BE LIABLE FOR TECHNICAL OR

EDITORIAL ERRORS OR OMISSIONS CONTAINED HEREIN; NOR FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE FURNISHING, PERFORMANCE, OR USE OF THIS MATERIAL.

This guide contains information protected by copyright. No part of this guide may be photocopied or reproduced in any form without prior written consent from Compaq Computer Corporation.



1999 Compaq Computer Corporation.

Compaq and Deskpro are registered in the U. S. Patent and Trademark Office.

PREMIER

Microsoft, MS-DOS, Windows, Windows NT, and other names of Microsoft products referenced herein are trademarks or registered trademarks of Microsoft Corporation.

SOUND

•

is a trademark of Compaq Computer Corporation.

Intel and Pentium are registered trademarks of Intel Corporation. Celeron and MMX are trademarks of Intel Corporation.

Product names mentioned herein may be trademarks and/or registered trademarks of their respective companies.

The software described in this guide is furnished under a license agreement or nondisclosure agreement. The software may be used or copied only in accordance with the terms of the agreement.

Deskpro Service Reference Guide

First Edition (July 1999) Part Number 123385-001 Spare Part Number 152611-001

Compaq Computer Corporation

preface

About This Guide

Symbols and Conventions.........................................................................................................vii

Technician Notes.......................................................................................................................vii

Additional Documentation .......................................................................................................viii

chapter 1

Installing the Operating System

1.1 Microsoft Windows 95 or 98..............................................................................................1-1

1.2 Microsoft Windows NT Workstation 4.0...........................................................................1-1

1.2.1 Installing Windows NT Workstation 4.0 over a Network.........................................1-1

1.2.2 Installing or Upgrading Device Drivers.....................................................................1-2

1.2.3 Creating an Emergency Repair Diskette....................................................................1-2

1.2.4 Using the Emergency Repair Diskette.......................................................................1-2

1.3 Registering the Computer...................................................................................................1-3

1.4 Compaq Software...............................................................................................................1-3

chapter 2

Setup Utilities and Diagnostic Features

2.1. Computer Setup Utilities...................................................................................................2-1

2.1.1 Using Computer Setup Utilities.................................................................................2-2

2.1.2 Computer Setup Menu...............................................................................................2-3

2.2 Computer Diagnostics ........................................................................................................2-6

2.2.1 Create a Diagnostics Diskette...................................................................................2-6

DOS-Based....................................................................................................................2-6

Windows-Based............................................................................................................2-6

2.2.2 Computer Checkup (TEST).......................................................................................2-6

2.2.3 View System Information (INSPECT)......................................................................2-6

Using Computer Checkup (TEST) or View System Information (INSPECT).............2-7

2.2.4 Enhanced Compaq Insight Personal Edition (Windows)...........................................2-8

Using Compaq Insight Personal Edition.......................................................................2-8

Running Diagnostic Tests.............................................................................................2-9

2.3 Protecting Your Software...................................................................................................2-9

2.3.1 Ordering Backup Diskettes........................................................................................2-9

2.3.2 Compaq Restore CD................................................................................................2-10

2.4 Unique Universal Identification (UUID)..........................................................................2-10

ONTENTS

chapter 3

Intelligent Manageability

3.1 Initial Configuration and Deployment................................................................................3-1

3.1.1 Remote System Installation .......................................................................................3-1

3.2 Asset Tracking and Security...............................................................................................3-2

3.2.1 Password Security......................................................................................................3-3

Establishing a Setup Password Using Computer Setup................................................3-3

Establishing a Power-On Password Using Computer Setup.........................................3-4

Entering a Power-On Password ....................................................................................3-4

iii

Changing a Power-On or Setup Password....................................................................3-4

Deleting a Power-On Password ....................................................................................3-5

National Keyboard Delimiter Characters......................................................................3-5

Clearing Passwords.......................................................................................................3-5

3.2.2 Smart Cover Sensor...................................................................................................3-6

Setting the Smart Cover Sensor Protection Level.........................................................3-6

3.2.3 Smart Cover Lock......................................................................................................3-6

Locking the Smart Cover Lock.....................................................................................3-6

Unlocking the Smart Cover Lock .................................................................................3-7

Using the Smart Cover FailSafe Key............................................................................3-7

3.2.4 Cable Lock Provision.................................................................................................3-7

3.3 Fault Notification and Recovery.........................................................................................3-7

3.3.1 Processor Fault Prediction and Prefailure Warranty..................................................3-7

3.3.2 SMART Hard Drive Fault Prediction........................................................................3-8

3.3.3 Drive Protection System............................................................................................3-8

3.3.4 Ultra ATA Integrity Monitoring................................................................................3-8

3.3.5 ECC Fault Prediction and Prefailure Warranty..........................................................3-8

3.3.6 Surge-Tolerant Power Supply....................................................................................3-8

3.3.7 Thermal Sensor..........................................................................................................3-8

3.4 Software Updating and Management .................................................................................3-9

3.4.1 Remote ROM Flash...................................................................................................3-9

Using Remote ROM Flash............................................................................................3-9

FailSafe Boot Block ROM..........................................................................................3-10

3.4.2 Remote Security Management.................................................................................3-12

3.4.3 Remote Wakeup and Remote Shutdown .................................................................3-12

3.4.4 Replicating Original Setup.......................................................................................3-13

3.4.5 Dual-State Power Button .........................................................................................3-13

3.4.6 Power Management .................................................................................................3-13

3.4.7 Enhanced Support Software CD and World Wide Web Site...................................3-14

3.4.8 Compaq Integrated Software ...................................................................................3-14

3.5 Building Blocks and Partners...........................................................................................3-15

3.5.1 Desktop Management Interface (DMI)....................................................................3-15

3.5.2 Compaq Insight Manager and the Insight Management Agents..............................3-15

3.5.3 Compaq Management Solutions Partners Program.................................................3-15

appendix A

Connector Pin Assignments

appendix B

Power Cord Set Requirements

appendix C

Hard Drives

.........................................................................................................................................C-1

appendix D

POST Error Messages

appendix E

Diagnostic Indicator Lights

Contents

..............................................................................................................A-1

.........................................................................................................B-1

........................................................................................................................D-1

.............................................................................................................. E-1

appendix F

Troubleshooting Without Diagnostics

..............................................................................................F-1

appendix G

System Board and Riser Board Reference Designators

...............................................................G-1

appendix H

Model Number Naming

..................................................................................................................................................... I-1

Index

.....................................................................................................................H-1

Contents

preface

BOUT THIS GUIDE

Deskpro Service Reference Guide

This reference when servicing the Compaq Deskpro Personal Computers. Only authorized technicians trained by Compaq should attempt to repair this equipment.

Compaq Computer Corporation reserves the right to make changes to the Compaq Deskpro Family of Personal Computers without notice.

Symbols and Conventions

The following text and symbols mark special messages throughout this guide:

is a troubleshooting and repair guide that can be used for

WARNING:

result in bodily harm or loss of life.

CAUTION:

to equipment or loss of data.

✎

Text set off in this manner presents commentary, sidelights, or clarifying information.

Technician Notes

WARNING:

troubleshooting and repair procedures are detailed to allow only subassembly/module level repair. Because of the complexity of the individual boards and subassemblies, no one should attempt to make repairs at the component level or to make modifications to any printed wiring board. Improper repairs can create a safety hazard. Any indications of component replacement or printed wiring board modifications may void any warranty.

CAUTION:

the front and back of the computer.

CAUTION:

AC power cord into a properly grounded AC outlet only.

Text set off in this manner indicates that failure to follow directions in the warning could

Text set off in this manner indicates that failure to follow directions could result in damage

Only authorized technicians trained by Compaq should attempt to repair this equipment. All

To properly ventilate your system, you must provide at least 3 inches (7.6 cm) of clearance at

The computer is designed to be electrically grounded. To ensure proper operation, plug the

Deskpro Service Reference Guide

vii

Additional Documentation

The following documentation is available to support these products:

T

User Documentation

T

Technical Training Guides

T

Compaq Service Advisories and Bulletins

T

Compaq QuickFind

T

Technical Reference Guide

T

Compaq Service Quick Reference Guide

T

Compaq Maintenance & Service Guide

viii

About This Guide

chapter

NSTALLING THE OPERATING SYSTEM

Depending on the model, Microsoft Windows 95, 98, or Microsoft Windows NT is preinstalled on the computer and will be configured automatically the first time the computer is turned on.

CAUTION:

successfully installed. Doing so may cause errors and may prevent the operating system from installing properly.

CAUTION:

PROCESS IS COMPLETE. Turning off the computer during the installation process might damage the software that runs the computer.

Do not add optional hardware devices to your computer until the operating system is

Once the automatic installation has begun, DO NOT TURN OFF THE COMPUTER UNTIL THE

1.1 Microsoft Windows 95 or 98

The first time the computer is turned on, Microsoft Windows is automatically installed. This takes approximately 5 to 15 minutes, depending on the system hardware configuration. At the beginning of the installation process, the user is prompted to select the appropriate language for the operating system. Read and follow the instructions that appear on the screen to complete the installation.

When the Welcome to Windows screen is displayed, Internet Explorer is installed and the installation process is completed.

1.2 Microsoft Windows NT Workstation 4.0

The first time you turn on your computer, Microsoft Windows NT Workstation is automatically installed for you. This takes approximately 30 minutes, depending on the system hardware configuration. At the beginning of the installation process, the user is prompted to select the appropriate language for the operating system. Read and follow the instructions that appear on the screen to complete the installation.

1.2.1 Installing Windows NT Workstation 4.0 over a Network

Network installation is used primarily for installing or upgrading Microsoft Windows NT Workstation over a local area network. It can also be used to install additional drivers or files with Windows NT.

✎

This installation method should be used to deploy Windows NT using a distribution share point over a network connection.

This capability does not imply the grant of a site license for Microsoft Windows NT Workstation and should only be used to install the operating system on computers for which the appropriate software license has already been obtained.

Deskpro Service Reference Guide

1-1

The initial Windows NT installation (completed when the computer is first turned) on creates an I386 directory. This directory and its subdirectories provide the Compaq-specific integration of Windows NT for the computer model. This image, license permitting, can be used as a distribution share point to deploy Windows NT over a network connection.

To use a distribution share point to install or upgrade Windows NT, see the Windows NT Resource Kit and its documentation.

1.2.2 Installing or Upgrading Device Drivers

To install hardware devices such as a printer, a display adapter, or network adapter after the Windows NT installation is completed, Windows NT needs access to the appropriate software drivers for the devices.

The I386 directory and its subdirectories provide the Compaq-specific integration of Windows NT for the computer model and include device drivers supported by Windows NT.

When prompted for the I386 directory on the Windows NT CD, replace the path specification with C:\I386 or use the browse button of the dialog box to browse the computer for the I386 folder. This points Windows NT to the appropriate drivers and allows installation of the device to be completed.

1.2.3 Creating an Emergency Repair Diskette

✎

After installing Microsoft Windows NT, Compaq recommends that you create an Emergency Repair Diskette. Using one blank, formatted diskette, complete the following steps:

1. Click Start Æ Compaq Information Center Æ Create Emergency Repair Diskette.

2. Read and follow the instructions that appear on the screen. A set of boot diskettes should also be created. These diskettes are required to start the computer

should the Emergency Repair Diskette be needed. To create boot diskettes, you need three blank, formatted diskettes.

1. Click Start Æ Compaq Information Center Æ Create Boot Diskettes.

2. Read and follow the instructions that appear on the screen.

The following section applies only to computers equipped with a diskette drive.

1.2.4 Using the Emergency Repair Diskette

✎

To use the Emergency Repair Diskette if the computer is not equipped with the LS-120 drive, insert the first boot diskette in the diskette drive and restart the computer. Follow the instructions displayed on the screen.

To use the Emergency Repair Diskette if the computer is equipped with the LS-120 drive, follow the instructions below:

1. Restart the computer using the Microsoft Windows NT Boot Disk 1.

The following section applies only to computers equipped with a diskette drive.

1-2

2. Press the F6 key when the message “Setup is inspecting your computer’s hardware

configuration…” appears on your screen.

3. When asked if you want to specify a storage device, press S and select the Compaq

ATAPI/IDE/LS-120 Controller from the list.

4. When asked again if you want to specify a storage device, press the Enter key. Follow the rest of

the installation procedures as outlined in the operating system documentation from Microsoft.

Installing the Operating System

1.3 Registering the Computer

The computer should be registered with Compaq. Registration establishes a record of ownership and gives the user an opportunity to receive product announcements, updates, and other communications periodically. To register one machine, just visit Compaq’s Web site at www.compaq.com/products/registration and follow the instructions that appear on the screen. To register more than one machine, either telephone in the information or enter the units one at a time on the Compaq Web site.

1.4 Compaq Software

The Microsoft Windows 95, 98, or Windows NT Workstation operating system is preinstalled on the computer and will be configured automatically the first time the computer is turned on. The following Compaq software will also be installed at that time on selected models:

Computer Setup Utilities and diagnostic features



Compaq Support Software including device drivers



Online



Intelligent Manageability



Enhanced Compaq Insight Personal Edition (Diagnostics for Windows)



DMI Support



Power Management with energy saver features



Security Management tools



Support Software Management tools



Compaq Safety & Comfort Guide

Certain drivers and utilities are available only in selected languages. You can obtain the latest version of these files, in English and selected other languages, in one of three ways:

Compaq Support Software CD for Compaq Desktop, Portable, and Workstation Products



(refer to Section 3.4.7, “Enhanced Support Software CD and World Wide Web Site,” for ordering information)

Compaq Web Site at www.compaq.com



Compaq Deskpro Supplement CD,



which is supplied with many desktop models

Deskpro Service Reference Guide

1-3

chapter

ETUP UTILITIES AND DIAGNOSTIC FEATURES

Compaq Computer Setup Utilities and diagnostic features provide information needed about the computer system when contacting Compaq Customer Support. These tools can also be used to:



Change factory default settings and to set or change the system configuration, which may be necessary when you add or remove hardware.



Determine if all of the devices installed on the computer are recognized by the system and functioning properly.



Determine information about the operating environment of the computer.



Solve system configuration errors detected but not automatically fixed during the PowerOn Self-Test (POST).



Establish and manage passwords and other security features.



Establish and manage energy-saving timeouts.

2.1. Computer Setup Utilities

Use Computer Setup Utilities to do the following:



Modify or restore factory default settings.



Set the system date and time.



Set, view, change, or verify the system configuration including settings for processor, graphics, memory, audio, storage, communications, and input devices.



Modify the boot order of bootable devices such as hard drives, diskette drives, CD-ROM drives, DVD-ROM drives, or PD-CD drives.



Enable Quick Boot which is faster than Full Boot but does not run all of the diagnostic tests run during a Full Boot. You can set your system to:

❏

always Quick Boot (default);

❏

periodically Full Boot (from every 1 to 30 days); or

❏

always Full Boot.



Enable or disable Network Server Mode, which allows the computer to boot the operating system when the power-on password is enabled. The keyboard and mouse remain locked until the power-on password is entered.



Select Clean or Descriptive mode for displaying Power-On Self-Test (POST) messages. Clean mode suppresses most POST messages, such as memory count, product name, and other non-error text messages. If a POST error occurs, the error is displayed regardless of the mode selected. To manually switch to Descriptive mode during POST, press any key (except F10 or F12).



Establish Ownership Tag, the text of which is displayed each time the system is turned on or restarted.

Deskpro Service Reference Guide

2-1



Enter the Asset Tag or property identification number assigned by your company to this computer.



Enable power-on password prompting during system restarts (warm boots) as well as during power-on.



Establish a setup password that controls access to Computer Setup and the settings described in this section.

T

Secure the serial, USB, or parallel ports so that they cannot be used until they are unsecured.



Enable or disable removable media boot ability.



Enable or disable removable media write ability.



Solve system configuration errors detected but not automatically fixed during the PowerOn Self-Test (POST).



Replicate your system setup by saving system configuration information on diskette and restoring it on one or more computers.

2.1.1 Using Computer Setup Utilities

To access the Computer Setup Utilities menu, complete the following steps:

1. Turn on or restart the computer. If you are in Windows, click Start Æ Shut Down Æ Restart the

Computer.

2. When the F10 Setup message appears in the lower-right corner of the screen, press the F10 key.

Press Enter to bypass the title screen, if necessary.

✎

If you do not press the F10 key while the message is displayed, you must turn the computer off, then on again, to access the utility.

A choice of five headings appears in the Computer Setup Utilities menu: File, Storage, Security, Power, and Advanced.

3. Using the arrow keys or the Tab key, select the option you want and press the Enter key. To

return to the Computer Setup Utilities menu, press the Esc key.

4. To apply and save changes, select File Æ Save Changes and Exit. If you selected an option that

automatically restarted the computer, changes were applied at that time. If you have made changes that you do not want applied, select Ignore Changes and Exit. If you have already applied changes you now want to eliminate, select Set Defaults and Exit. This option will restore the original system defaults.

2-2

Setup Utilities and Diagnostic Features

2.1.2 Computer Setup Menu

Heading Option Description

File System Information Lists product name, processor type/speed/stepping, CPU

Set Time and Date Allows you to set system time and date. Save to Diskette Saves system configuration to a blank 1.44-MB diskette. Restore from Diskette Restores system configuration from a diskette.

File Set Defaults and Exit Restores factory default settings.

Ignore Changes and Exit Exits Computer Setup without applying or saving any changes. Save Changes and Exit Saves changes to system configuration and exits Computer

Storage Diskettes Lists the currently installed drive A (preinstalled diskette drive)

Removable Media Enables/disables removable media booting and removable

serial number, cache size, system ROM family and version, installed memory size, and asset tracking number.

Setup.

and drive B devices.

media writing. Note: After saving changes to Removable Media, the

computer will restart. Turn the computer off, then on, manually.

IDE Devices Lists information regarding IDE devices connected to the

system. ATAPI devices (CD-ROM, DVD-ROM, tape) are listed as ATAPI devices.

IDE Drive Timing Allows you to set hard drive to Ultra-DMA (Ultra-ATA),

Enhanced DMA, or PIO mode operation. IDE Options Enables/disables IDE drive translation. Boot Order Allows you to specify boot order of installed peripheral devices

(such as LS-120 drive, diskette drive, hard drive, SCSI drive,

CD-ROM drive, or DVD-ROM drive).

Security Setup Password Enables setup (administrator) password.

See Section 3.2, “Asset Tracking and Security,” for more

information. Power-On Password Enables power-on password.

Specifies prompting for Power-On Password.

See Section 3.2, “Asset Tracking and Security” for more

information.

continued

Deskpro Service Reference Guide

2-3

Computer Setup Menu

Continued

Heading Option Description

Security Password Options Enables/disables network server mode, keyboard QuickLock,

QuickBlank screen when locked, and QuickLock in energy saver mode.

See Section 3.2, “Asset Tracking and Security,” for more information.

Note: This selection will appear only if a power-on password is set.

Smart Cover Enables/disables Smart Cover Sensor and Cover Lock.

(Feature supported on select models only.) Lists most recent cover removal. (Feature supported on select

models only.) See Section 3.2, “Asset Tracking and Security,” for more

information.

Device Security Enables/disables serial, parallel, and USB ports and audio

security.

Security Network Service Boot Enables/disables Network Service Boot. (Feature supported on

select models only.)

System IDs Allows you to set Asset Tag and Ownership Tag.

Allows setting of Chassis Serial Number if current number is invalid.

Also allows you to set keyboard locale setting (e.g., English or German) for System ID entry.

Allows setting of Ownership Tag and UUID. See Section 3.2, “Asset Tracking and Security,” for more

information.

2-4

Power Energy Saver Allows you to set energy saver mode to advanced, disabled, or

minimal.

Timeouts Allows you to enable/disable timeouts or manually select

timeout values. Note: This selection will appear only when energy saver mode

is set to advanced.

Energy Saver Options Allows you to set power button configuration (on/off or

suspend/wakeup.) Allows user to enable/disable power LED blink in suspend

mode. Note: This selection will appear only if the energy saver mode

is enabled.

continued

Setup Utilities and Diagnostic Features

Computer Setup Menu

Continued

Heading Option Description

Advanced*Power-On Self Test Allows you to set POST mode (QuickBoot or FullBoot) and

enables/disables POST messages. Onboard Devices Allows you to set resources for onboard system devices (serial

port, parallel port, etc.). PCI Devices Lists currently installed PCI devices and their IRQ settings.

Allows you to reconfigure IRQ settings for these devices or to

disable them entirely. ISA PnP Devices Lists current settings of Plug and Play (PnP) devices.

Enables or disables Plug and Play devices.

Note: Appears only when Plug and Play devices are currently

installed. Bus Options Enables/disables PCI bus mastering, PCI reset on warm boot,

and PCI VGA palette snooping.

Allows you to set ISA back-to-back I/O (fast/legacy) delay and

bus priority (ISA/PCI). Device Options Allows you to set printer mode (flexible/standard), NumLock

state at power-on, and Erase-Eaze Keyboard support. PCI VGA Configuration Allows users to specify which VGA controller will be the “boot”

or primary VGA controller.

Appears only if there are multiple PCI video adapters in the

system.

These options should be used by advanced users only.

Deskpro Service Reference Guide

2-5

2.2 Computer Diagnostics

✎

Compaq strongly recommends that you create a diagnostics diskette as soon as you begin to use the computer. This diskette will play an important role in the restoration process if you ever experience a major system failure. It will also allow you to run the Computer Checkup (TEST) or View System Information (INSPECT) diagnostic programs.

Another Compaq diagnostic feature is Enhanced Compaq Insight Personal Edition (Diagnostics for Windows), described later in this guide.

The following section applies only to computers equipped with a diskette drive.

2.2.1 Create a Diagnostics Diskette

DOS-Based

✎

To create a bootable, DOS-based Diagnostic Diskette (some models may require two 1.44-MB diskettes), files. Insert a blank, 1.44MB formatted diskette into the diskette drive, then run C:\DIAGDISK\PDIAG\MAKEDISK.BAT.

✎

Windows-Based

Using the Windows or Windows NT operating system:

The following section applies only to computers equipped with a diskette drive.

run the SOFTPAQ executable file found in C:\DIAGDISK\ to extract the necessary

To obtain the SOFTPAQ executable filename, run DIR C:\DIAGDISK\SP*.EXE.

Click Start Æ Compaq Information Center Æ Create Diagnostics Disk. Insert a diskette into the diskette drive and follow the instructions on the screen.

2.2.2 Computer Checkup (TEST)

Use Computer Checkup (TEST) in the following instances to:



Determine if all the devices installed on the computer are recognized by the system and functioning properly. Running Test is optional but recommended after installing or connecting a new device.



Save, print, or display the information generated by TEST. You should run TEST and have the printed report available before placing a call to the Compaq Customer Support Center.



Reproduce the same environment on another computer for testing.

2.2.3 View System Information (INSPECT)

Use View System Information (INSPECT) to:



View information about the system once it has been configured.



Save, print, or display the information generated by INSPECT. You should run INSPECT and have the printed report available before placing a call to the Compaq Customer Support Center.



Assist your Compaq authorized dealer, reseller, or service provider in analyzing the system by allowing the service provider to reproduce the same environment on another computer for testing.

2-6

Setup Utilities and Diagnostic Features

The information provided by INSPECT includes:



Contents of the operating system startup files



Current memory configuration



ROM versions



Type of processor and coprocessor



Diskette, CD-ROM, DVD-ROM tape, or hard drives installed



Active printer and communications interfaces



Modem type installed



Graphics settings



Windows

✎

WIN.INI

file details

Categories or items of information displayed by INSPECT are similar to but may vary slightly from those available in Compaq Diagnostics for Windows.

Using Computer Checkup (TEST) or View System Information (INSPECT)

✎

Before you run TEST or INSPECT, you must create a diagnostics diskette. See Section 2.2.1, “Create a Diagnostics Diskette,” for instructions.

1. Cold boot your computer from the diagnostics diskette you have created. Press Enter to bypass the title screen, if necessary.

2. Select either Computer Checkup (TEST) or View System Information (INSPECT).

When running TEST:

1. Select the option to view the device list. A list of the installed hardware devices appears.

2. Verify that TEST correctly detected the devices installed. This utility will detect all devices manufactured by Compaq; devices from other manufacturers may not be detected.

❏

If the list is correct, select OK and go on to step 3.

❏

If the list is incorrect, be sure that any new devices are installed properly.

3. Select one of the following from the test option menu:

❏

Quick Check Diagnostics—

This option runs a quick, general test on each device with a minimal number of prompts. If errors occur, they are displayed when the testing is complete.

❏

Automatic Diagnostics—

This option runs unattended, maximum testing of each device with minimal prompts. You can choose how many times to run the tests, to stop on errors, or to print or file a log of errors.

❏

Prompted Diagnostics—

This option allows maximum control over the device testing process. You can choose attended or unattended testing, decide to stop on errors, or choose to print or file a log of errors.

Follow the instructions on the screen as the diagnostic tests are run on the devices. To exit either TEST or INSPECT, press the Esc key to reach the Exit option. Then press Enter.

Deskpro Service Reference Guide

2-7

2.2.4 Enhanced Compaq Insight Personal Edition (Windows)

Enhanced Compaq Insight Personal Edition is a component of Intelligent Manageability that allows you to view:



System



AssetControl information



Input devices



Communications ports



Storage devices



Graphics information



Memory configuration



Security management settings



System health



Operating system



Windows version

Depending on the version, Compaq Insight Personal Edition may include diagnostic tests to determine if all the devices installed on the computer are recognized by the system and are functioning properly.

overview

Using Compaq Insight Personal Edition

1. Select the Compaq Insight Personal Edition icon or the Compaq Diagnostics icon, located in the Control Panel.

The screen displays an overview of the computer hardware and software.

2. For specific hardware and software information, select a category from the Categories menu or from the toolbar.

✎

3. To display more detailed information in a selected category, click More in the Information

✎

4. Review and print this information.

✎

5. To exit Compaq Insight Personal Edition, click File, then click Exit.

As you move your cursor over the toolbar icons, the corresponding category names appear near the cursor.

Level box.

Categories or items of information displayed by Compaq Insight Personal Edition are similar to but may vary slightly from the information presented in View System Information (INSPECT).

To print the information, click File, then select Print. Select one of the following options: Detailed Report (All Categories), Summary Report (All Categories), or Current Category. Click OK to print the report you selected.

2-8

Setup Utilities and Diagnostic Features

Running Diagnostic Tests

If your version of Compaq Insight Personal Edition includes diagnostic testing utilities, four tabs will appear next to Overview: Test, Status, Log, and Error.

1. Select the Test tab.

2. Select one of the following options:

Quick Test—

❏

Complete Test—

❏

Custom Test—

❏

device in the list, then click the box beside each test to select or deselect it. When selected, a red check mark appears in the box.

3. Select Interactive Mode or Unattended Mode.

4. In Interactive Mode, the diagnostic software will prompt you for input during tests that require it. Some tests require interaction and will display errors or halt testing if selected in conjunction with Unattended Mode.

5. Click the Begin Testing button. Test Status is displayed, showing the progress and result of each test.

6. If errors are found, click the Error tab to display more detailed information and recommended actions. By following the recommended actions, you may be able to solve some problems yourself.

Runs a quick, general test on each device with a minimal number of prompts.

Runs maximum testing of each device with minimal prompts.

Runs only the tests you select. To select specific devices or tests, find the

7. Click Print or Save the error information in case you need to contact your Compaq authorized dealer, reseller, or service provider for assistance.

8. To exit Compaq Insight Personal Edition, click File, then click Exit.

2.3 Protecting Your Software

To protect software from loss or damage, you should keep a backup copy of all system software, applications, and related files stored on the hard drive. You can order a set of backup diskettes from Compaq at nominal cost for all of the software preinstalled on the computer, or you can make a set. Refer to the operating system or backup utility documentation for instructions on making backup copies of data files. Another option is the which accompanies many desktop models and enables the user to selectively restore the original system software.

2.3.1 Ordering Backup Diskettes

You can order all software as a single set, or you can order the various software packages separately.

✎

For a list of Compaq support telephone numbers, consult the

Support

Before calling Compaq to place your order, be sure to have the serial number of your computer available. This number is necessary for all diskette purchases.

guide.

Compaq Deskpro Supplement CD,

Contacting Compaq Customer

Deskpro Service Reference Guide

2-9

2.3.2 Compaq Restore CD

Compaq Restore CD

The the Microsoft operating system CD, the restore the original system software. This can be extremely helpful in the event of hard drive failure or corruption.

Compaq Restore CD

The models along with the Microsoft operating system CD.

offers easy deployment and recovery of the system software. Along with

Compaq Restore CD

is specific to each desktop model and accompanies many desktop

2.4 Unique Universal Identification (UUID)

This feature is available on all 1999 and later model computers. Each computer has a randomly generated 32-digit identification that may be used for asset management purposes. The random number is generated during the pretest process in the Compaq factory, is flashed onto the ROM, and is then printed on the shipping label. Users and service providers may turn off the UUID number by following these instructions:

1. Turn on or restart the computer. In Windows, click Start Æ Shut Down Æ Restart the Computer.

2. When the F10=Setup message appears in the lower-right corner of the screen, press the F10 key.

enables the user to selectively

✎

3. Select the language from the list and press Enter.

4. Select Advanced Æ Power-On Options Æ UUID Æ Disable.

5. To apply and save changes, select File Æ Save Changes and Exit.

If you do not press the F10 key while the message is displayed, you must turn off the computer, then on again, to access the utility.

A choice of five headings appears in the Computer Setup Utilities menu: File, Storage, Security, Power, and Advanced.

2-10

Setup Utilities and Diagnostic Features

chapter

NTELLIGENT MANAGEABILITY

Compaq Intelligent Manageability is the best, most comprehensive set of desktop management solutions in the industry. Providing easy control and management of the desktop and portable PC, Intelligent Manageability delivers significant financial and intangible returns when used to manage distributed PC environments.

Intelligent Manageability is built upon industry-standard building blocks, including DMI 2.0, Web-Based Enterprise Management, Intel's “Wired for Management,” SNMP, and Net PC technologies. It is tightly integrated with Compaq Management Solutions Partners and Compaq Insight Manager.

Intelligent Manageability delivers solutions in five areas of primary concern for today’s businesses:



Initial Configuration and Deployment



Asset Tracking and Security



Fault Notification and Recovery



Software Updating and Management



Building Blocks and Partners

This section provides an introduction to Intelligent Manageability concepts and features. For more detailed information on specific features, refer to the online

and Configuration Guide

(INTMGT3.HLP).

✎

Support for specific features described in this chapter and in the online

Manageability Guide

(IMINST.HLP) and the online

may vary by model or software version.

3.1 Initial Configuration and Deployment

Compaq computers come with a preinstalled set of system software. Automated System Installation and Remote System Installation enable you to replace the preinstalled software with a customized set of system and application software for consistent, standard software deployment.

Compaq Deskpro Supplement CD

The further assistance with selective recovery of system software, configuration management and troubleshooting, and power management.

3.1.1 Remote System Installation

Remote System Installation allows you to start and set up your system using the software and configuration information located on a network server. The Remote System Installation feature is usually used as a system setup and configuration tool, and can be used for the following tasks:

, ROM-based setup, and ACPI-ready hardware provide

Intelligent Manageability Installation

Intelligent Manageability Guide

Intelligent



Installing the optional Setup partition. The partition should be installed only if you wish to use the previous generation of Compaq Computer Setup and Diagnostics utilities.



Formatting a hard drive.

Deskpro Service Reference Guide

3-1



Installing an operating system.



Installing application software or drivers.

To initiate Remote System Installation, press F12 when the F12=Network Service Boot message appears in the lower-right corner of the Compaq logo screen. Follow the instructions on the screen to continue the process.

3.2 Asset Tracking and Security

Compaq AssetControl features incorporated into the computer provide key asset tracking data that can be managed using Management Solutions Partners products. Seamless, automatic integration between AssetControl features and Solutions Partners products enables you to choose the management tool that is best suited to your environment and to leverage your investment in existing tools.

Compaq computers are manufactured with the hardware and firmware required to fully support the DMI 2.0 standard.

Compaq also offers several solutions for controlling access to valuable computer components and information. DriveLock prevents unauthorized access to data stored on the hard disk, even when removed from the computer. Remote Security Management enables the system administrator to centrally establish and manage policies for hardware-based security features, such as the Smart Cover Lock and the Ownership tag, for networked PCs. Another solution integrates Memory Change and Smart Cover Sensor alerts with Compaq Insight Manager to deliver proactive notification of tampering with a computer's internal components.

✎

Security features described in the table below can be established from the Compaq Computer Setup Utilities menu.

Feature Purpose

Removable Media Boot Control

Removable Media Write Control

Serial, Parallel, USB, or Infrared Interface Control

Power-On Password Prevents use of the computer until the password is entered. This can apply to

Setup Password Prevents reconfiguration of the computer (use of the Computer Setup utility)

Smart Cover Indicates that computer cover or side panel has been removed. Can be set to

Prevents booting from the removable media drives.

Prevents writing to the removable media drives.

Prevents transfer of data through the integrated serial, parallel, USB (universal serial bus), or infrared interface.

both initial computer startup and restarts.

until the password is entered.

require the setup password to restart the computer, after the cover or side panel has been removed.

continued

3-2

Intelligent Manageability

Setup Utilities Menu

Feature Purpose

Smart Cover Lock Prevents unauthorized access to the internal components. This is a software-

Memory Change Alerts Detects when DIMMs (dual inline memory modules) have been added,

Ownership Tag Displays ownership information, as defined by the system administrator,

Cable Lock Provision Inhibits access to the interior of the computer to prevent unwanted

For more information about Computer Setup, refer to Section 2.1, “Setup.” In some cases switches may need to be set. For more information about these switches, refer to the “Connectors, Jumpers, and Switches” chapter in the product-specific MSG.

continued

controllable cover lock, controlled by the setup password.

The Smart Cover FailSafe Key is a device for manually disabling the

✎

Smart Cover Lock, is available from Compaq. You’ll need the FailSafe Key in case of forgotten password, power loss, or computer malfunction.

moved, or removed; notifies end-user and system administrator.

For information on enabling Memory Change Alerts, refer to the online

✎

Intelligent Manageability Guide.

during system startup (protected by setup password).

configuration changes or component removal. Can also be used to secure the computer to a fixed object to prevent theft of the computer.

Install a padlock with the security bracket to inhibit access to the

✎

interior of the computer; add a cable lock to secure the computer to a fixed object.

3.2.1 Password Security

The computer supports security password features, which can be established through the Compaq Computer Setup Utilities menu.

Establishing a Setup Password Using Computer Setup

Establishing a setup password through Computer Setup prevents reconfiguration of the computer (use of the Computer Setup utility) until the password is entered.

1. Turn on or restart the computer. If you are in Windows, click Start Æ Shut Down Æ Restart the Computer.

2. When the F10 Setup message appears in the lower-right corner of the screen, press the F10 key. Press Enter to bypass the title screen, if necessary.

✎

3. Select Security, then select Setup Password and follow the instructions on the screen.

4. Before exiting, click File Æ Save Changes and Exit.

If you do not press the F10 key while the message is displayed, you must turn the computer off, then on again, to access the utility.

Deskpro Service Reference Guide

3-3

Establishing a Power-On Password Using Computer Setup

Establishing a power-on password through Computer Setup prevents access to the computer when power is turned on, unless the password is entered. The password must be entered each time the computer is turned on, when the key icon appears on the monitor.

1. Turn on or restart the computer. If you are in Windows, click Start Æ Shut Down Æ Restart the Computer.

2. When the F10 Setup message appears in the lower-right corner of the screen, press the F10 key. Press Enter to bypass the title screen, if necessary.

✎

3. Select Security, then Power-On Password and follow the instructions on the screen.

4. Before exiting, click File Æ Save Changes and Exit.

Entering a Power-On Password

To enter a power-on password the following steps:

1. Turn on or restart the computer. If you are in Windows, click Start Æ Shut Down Æ Restart the

2. When the key icon appears on the monitor, enter your current password.

✎

If you enter the password incorrectly, a broken key icon appears. Try again. After three unsuccessful tries, you must turn off the computer, then turn it on again before you can continue.

Changing a Power-On or Setup Password

1. Turn or restart the computer. If you are in Windows, click Start Æ Shut Down Æ Restart the

2. When the key icon appears, type your current password, a slash (/) or alternate delimiter

If you do not press the F10 key while the message is displayed, you must turn the computer off, then on again, to access the utility.

Computer.

Type carefully; for security reasons, the characters you type do not appear on the screen.

Computer. To change the setup password, run Computer Setup.

character, your new password, another slash (/) or alternate delimiter character, and your new password again as shown:

3-4

current password/new password/new password

✎ ✎

The new password takes effect the next time you turn on the computer.

Intelligent Manageability

Refer to the “National Keyboard Delimiter Characters” section in this chapter for information about the alternate delimiter characters.

Type carefully; for security reasons, the characters you type do not appear on the screen.

Deleting a Power-On Password

1. Turn on or restart the computer. If you are in Windows, click Start Æ Shut Down Æ Restart the Computer. To delete the setup password, run Computer Setup.

2. When the key icon appears, type your current password followed by a slash (/) or alternate delimiter character as shown:

current password/

✎

Refer to the “National Keyboard Delimiter Characters” section in this chapter for information about alternate delimiter characters.

National Keyboard Delimiter Characters

Each keyboard is designed to meet country-specific requirements. The syntax and keys that you use for changing or deleting your password depend on the keyboard that came with your computer.

Arabic

Belgian

BHCSY*

Brazilian

Chinese

Czech

Danish

French

French Canadian

German

For Bosnia-Herzegovina, Croatia, Slovenia, and Yugoslavia

Greek

Hebrew

Hungarian

Italian

Japanese

Korean

Latin American

Norwegian

Polish

Portuguese

Russian

Slovakian

Spanish

Swedish/Finnish

Swiss

Taiwanese

Thai

Turkish

U.K. English

U.S. English

Clearing Passwords

If you forget your password you cannot access the computer. Refer to the “Connectors, Jumpers, and Switches” chapter in the product-specific MSG for instructions on clearing passwords.

Deskpro Service Reference Guide

3-5

3.2.2 Smart Cover Sensor

Smart Cover Sensor is a combination of hardware and software technology that can alert you when the computer cover or side panel has been removed. There are three levels of protection, as described in the following table:

Level Setting Description

Level 0 Disabled Smart Cover Sensor is disabled (default). Level 1 Notify User When the computer is restarted, the screen displays a message indicating

Level 2 Setup Password When the computer is restarted, the screen displays a message indicating

Setting the Smart Cover Sensor Protection Level

To set the Smart Cover Sensor protection level, complete the following steps:

1. Turn on or restart the computer. If you are in Windows, click Start Æ Shut Down Æ Restart the Computer.

2. When the F10 Setup message appears in the lower-right corner of the screen, press the F10 key. Press Enter to bypass the title screen, if necessary.

that the computer cover or side panel has been removed.

that the computer cover or side panel has been removed. You must enter the setup password to continue.

✎

3. Select Security, then Smart Cover and follow the instructions on the screen.

4. Before exiting, click File Æ Save Changes and Exit.

If you do not press the F10 key while the message is displayed, you must turn the computer off, then on again, to access the utility.

3.2.3 Smart Cover Lock

The Smart Cover Lock is a software-controllable cover lock featured on some desktop computers. This lock prevents unauthorized access to the internal components. Computers ship with the Smart Cover Lock in the unlocked position.

CAUTION:

password prevents unauthorized access to the Computer Setup utility.

Locking the Smart Cover Lock

To activate and lock the Smart Cover Lock, complete the following steps:

1. Turn on or restart the computer. If you are in Windows, click Start Æ Shut Down Æ Restart the Computer.

2. When the F10 Setup message appears in the lower-right corner of the screen, press the F10 key. Press Enter to bypass the title screen, if necessary.

✎

If you do not press the F10 key while the message is displayed, you must turn the computer off, then on again, to access the utility.

For maximum cover lock security, be sure to establish a setup password. The setup

3-6

3. Select Security, then select Smart Cover and follow the instructions on the screen.

4. Before exiting, click File Æ Save Changes and Exit.

Intelligent Manageability

Unlocking the Smart Cover Lock

1. Turn on or restart the computer. If you are in Windows, click Start Æ Shut Down Æ Restart the Computer.

2. When the F10 Setup message appears in the lower-right corner of the screen, press the F10 key. Press Enter to bypass the title screen, if necessary.

✎

3. Select Security, then select Smart Cover and the Unlocked option.

4. Before exiting, click File Æ Save Changes and Exit.

Using the Smart Cover FailSafe Key

If you enable the Smart Cover Lock and cannot enter your password to disable the lock, you will need a Smart Cover FailSafe Key to open the computer cover. You will need the key in any of the following circumstances:



If you do not press the F10 key while the message is displayed, you must turn the computer off, then on again, to access the utility.

Power outage Startup failure PC component failure (e.g., processor or power supply) Forgotten password

CAUTION:

this key before you need one.

The Smart Cover FailSafe Key is a specialized tool available from Compaq. Be prepared; order

3.2.4 Cable Lock Provision

A physical security device for your computer may also be available, through the cable lock provision. See your the cable lock provision.

Guide to Features & Upgrades

for more information on using and installing

3.3 Fault Notification and Recovery

Fault Notification and Recovery features combine innovative hardware and software technology to prevent the loss of critical data and minimize unplanned downtime.

When a fault occurs, the computer displays a Local Alert message containing a description of the fault and any recommended actions. You can then view current system health by using Compaq Insight Personal Edition. If the computer is connected to a network managed by Compaq Insight Manager or other SNMP-based management products from Compaq Management Solutions Partners, the computer also sends a fault notice to the network management application.

3.3.1 Processor Fault Prediction and Prefailure Warranty

When the processor encounters an excessive number of error checking and correcting (ECC) cache memory errors, the computer displays a Local Alert Message. This message contains detailed information about the faulty processor, allowing you to take action before you experience non-correctable cache memory errors. The Prefailure Warranty allows you to replace these processors, free of charge, before they actually fail. Processors with ECC cache memory are available on select Compaq personal computers.

Deskpro Service Reference Guide

3-7

3.3.2 SMART Hard Drive Fault Prediction

The SMART hard drive monitors hard drive activity to predict failures and, in some cases, fix faults before failures occur. Fault prediction and failure indication parameters, such as abnormal variations in spinup and seek times, or non-correctable read and write errors, are tracked to determine the hard drive condition. Should these errors become significant, the computer displays a warning message. The warning gives you time to back up the hard drive and replace it prior to experiencing downtime or loss of data. The Prefailure Warranty for SMART hard drives allows you to replace these drives, free of charge, before the drives fail.

SMART hard drives are compliant with the Small Form Factor Committee Specification for SelfMonitoring, Analysis, and Reporting Technology (SMART). SMART is the industry standard technology, pioneered by Compaq and originally called IntelliSafe, that allows you to prevent data loss and minimize downtime, in concert with Compaq Insight Management Agents.

3.3.3 Drive Protection System

The Compaq Drive Protection System (DPS) is a diagnostic tool built into the hard drives installed in select Compaq Deskpro computers. DPS is designed to help diagnose problems that might result in unwarranted hard drive replacement. When Compaq Deskpro Computers are built, each installed hard drive is tested using DPS and a permanent record of key information is written onto the drive. Each time DPS is run, test results are written to the hard drive. You can use this information to help diagnose conditions that caused you to run the DPS software.

3.3.4 Ultra ATA Integrity Monitoring

Ultra ATA Integrity Monitoring monitors the integrity of data as it is transferred between an Ultra ATA hard drive and the system’s core logic. If the computer detects an abnormal number of transmission errors, the computer displays a Local Alert message with recommended actions. An alert is also sent over the network to the system administrator.

3.3.5 ECC Fault Prediction and Prefailure Warranty

When the computer encounters an excessive number of error checking and correcting (ECC) memory errors, the computer displays a Local Alert message. This message contains detailed information about the errant memory module, allowing you to take action before you experience non-correctable memory errors. The Prefailure Warranty for ECC memory modules allows you to replace these modules, free of charge, before the modules actually fail. ECC memory modules are optional on all Compaq personal computers.

✎

To use this feature, you must replace the standard DIMMs with ECC DIMMs.

3.3.6 Surge-Tolerant Power Supply

An integrated surge-tolerant power supply provides greater reliability when the computer is hit with an unpredictable power surge. This power supply is rated to withstand a power surge of up to 2000 volts without incurring any system downtime or data loss.

3.3.7 Thermal Sensor

The thermal sensor is a hardware and software feature that tracks the internal temperature of the computer. This feature displays a warning message when the normal range is exceeded, which gives you time to take action before internal components are damaged or data is lost.

3-8

Intelligent Manageability

3.4 Software Updating and Management

Remote ROM Flash, Remote Wakeup, and Remote Shutdown, when integrated with Management Solutions Partners products, deliver ongoing management of firmware, 24 hours a day. This supplements the software distribution capabilities of the Solutions Partners products, which can also be used to distribute new applications, device drivers, and other system software. The

Support Software CD

be distributed to client PCs using these software tools.

and Web site includes updated ROM images and device drivers which can

For more information, refer to the online

Management Administrators Guide

Tools, and is available on the www.compaq.com.

3.4.1 Remote ROM Flash

Your computer comes with reprogrammable flash ROM (read only memory). By establishing a setup password in Security Management, you can protect the ROM from being unintentionally updated or overwritten. This is important to ensure computer operating integrity. Should you need or want to upgrade your ROM, you may:



Order an upgraded ROMPaq diskette from Compaq.



Order the



Download the latest ROMPaq images from the Compaq World Wide Web site (www.compaq.com).

Using Remote ROM Flash

Remote ROM Flash allows the system administrator to safely upgrade the ROM on remote Compaq desktop personal computers, directly from the centralized network management console. Enabling the system administrator to perform this task remotely, on multiple computers, results in a consistent deployment of and greater control over Compaq desktop ROM images over the network. It also results in greater productivity and lower total cost of ownership.

Support Software CD

CAUTION:

prevents unauthorized ROM upgrades.

For maximum ROM protection, be sure to establish a setup password. The setup password

Remote Management Administrators Guide.

is included with the Remote Management Administration

Support Software CD

or on the Compaq World Wide Web site at

The

Remote

Compaq created the Remote ROM Flash capability to be secure and fail-safe. All desktop ROMPaq ROM images from Compaq are digitally signed to ensure authenticity and minimize potential corruption. The ROM firmware includes a Boot Block that is protected during the flash process and allows the computer to be restarted, in the unlikely event of an unsuccessful ROM flash.

✎

For more information on enabling Remote ROM Flash, refer to the online

Administrators Guide.

Remote Management Administration Tools, and is available on the Compaq Web Site at www.compaq.com.

Your computer must be powered on, or turned on through Remote Wakeup, to take advantage of Remote ROM Flash. Use of Remote ROM Flash also requires an established setup password.

Remote Management

Remote Management Administrators Guide

The

is included with the

Support Software CD

Deskpro Service Reference Guide

or at the

3-9

FailSafe Boot Block ROM

The FailSafe Boot Block ROM allows for system recovery in the unlikely event of a ROM flash failure, for example, if a power failure occurs during a ROM upgrade. The Boot Block is a flashprotected section of the ROM that checks to validate the system ROM each time power to the system is turned on.



If the system ROM is valid, the system starts normally.



If the system ROM fails the validation check, the FailSafe Boot Block ROM provides enough support to start the system from a ROMPaq diskette, which will program the system ROM with a valid image.

Because there is no video or hard drive support from the Boot Block ROM, the keyboard lights communicate information. When the Boot Block detects an invalid system ROM, the system sounds a series of beeps (one long and three short) and flashes the three keyboard lights.

To recover the system after hearing the FailSafe Boot Block beeps, complete the following steps:

1. Remove any diskettes from the diskette drive and turn off the power.

2. Insert a ROMPaq diskette into the diskette drive.

3. Turn on power to the system. If a setup password has been established, the Caps Lock light will turn on.

4. Enter the setup password. If the system successfully starts from the diskette and successfully reprograms the ROM, then

the three keyboard lights will turn on. A “rising tone” series of beeps also signals successful completion.

3-10

Intelligent Manageability

The following table lists the various keyboard light combinations as well as the meaning and action associated with each combination.

Num Lock

OFF ON OFF System requires setup password.

ON OFF OFF System could not start from diskette because the ROMPaq diskette

OFF OFF ON ROM upgrade failed.

ON ON ON ROM upgrade successfully completed.

Caps Lock

Scroll Lock

Meaning and Required Action

Enter the setup password. The light remains turned on until you enter a valid setup password.

is not present, is bad, or the drive is not ready. Insert a valid ROMPaq diskette, turn the power off, then turn the

power on.

Try another ROMPaq diskette. If the light remains turned on, contact Compaq customer support.

Turn power off and back on to resume normal system operation.

Keyboard Lights

Deskpro Service Reference Guide

3-11

3.4.2 Remote Security Management

Remote Security Management allows the system administrator to safely set or modify security features on remote Compaq desktops, directly from the centralized network management console. Enabling the system administrator to perform these tasks remotely, on multiple computers, results in consistent deployment of and greater control over desktop security parameters over the network. It also results in greater productivity and lower total cost of ownership.

✎

For more information about the Remote Management Setup software and enabling Remote Security Management, refer to the online

Management Administrators Guide

Tools, and is available on the www.compaq.com.

Your computer must be powered on, or turned on through Remote Wakeup, to take advantage of Remote Security Management. Use of Remote Security Management also requires an established setup password.

Remote Management Administrators Guide

is included with the Remote Management Administration

Support Software CD

3.4.3 Remote Wakeup and Remote Shutdown

If the computer has an optional network card installed, it may support the Compaq Remote Wakeup and Remote Shutdown functions. These functions allow a system administrator to power on and power off a client computer from a remote location, supported by PC LAN management tools.

✎

Remote Wakeup allows the network interface controller to continue functioning, even when power to the computer has been turned off.

✎

To enable Remote Wakeup and Remote Shutdown, complete the following steps:

Third-party software tools are required to remotely distribute software.

The computer continues to consume a small amount of electricity even after you turn it off. Only when you disconnect the power cord from the electrical outlet does the computer stop consuming electricity.

or at the Compaq Web site at

. The

Remote

3-12

1. Double-click the Network Icon, located in the Control Panel.

2. Double-click the appropriate network controller.

3. Click the Advanced Properties tab.

4. Select Remote Wakeup.

5. Change the value to ON.

6. Click OK to save and apply changes, then click OK to exit the Network dialog.

For more information on using Remote Wakeup and Remote Shutdown, refer to the online

Remote Management Administrators Guide.

included with the Remote Management Administration Tools, and is available on the

Software CD

Intelligent Manageability

or at the Compaq Web site at www.compaq.com.

Remote Management Administrators Guide

The

Support

3.4.4 Replicating Original Setup

This procedure gives an administrator the ability to easily copy one setup configuration to other computers of the same model. This allows for faster, more consistent configuration of multiple computers. To replicate your setup:

1. Access the Computer Setup Utilities menu.

2. Click File Æ Save to Floppy. Follow the instructions on the screen.

3. To replicate the configuration, click File Æ Restore from Floppy, and follow the instructions on the screen.

3.4.5 Dual-State Power Button

In Windows 95 or Windows 98, the power button can function either as an on/off switch or as a suspend button. The suspend feature does not turn off power altogether, but instead causes the computer to enter a low-power standby. This allows you to quickly power down without closing applications and to quickly return to the same operational state without any data loss.

To change the power button’s configuration, complete the following steps:

1. Access the Computer Setup Utilities menu.

2. Select Power Æ Energy Saver Options. Set the power button configuration to either Advanced or Minimal Energy Saver, or Disabled, as desired.

For more information about the various screen and configuration options, refer to Section

2.1.2, “Using Computer Setup Utilities.”

3. Select File Æ Save Changes and Exit.

After configuring the power button to function as a suspend button (Energy Saver mode), press the power button to put the system in a very low power state (suspend). Press the button again to quickly bring the system out of suspend to full power status. To completely turn off all power to the system, press and hold the power button for four seconds.

✎

If you have selected the “Blink LED during Energy Save” option in Computer Setup, the power-on light will blink once every second while the computer is in suspend. Refer to Section 2.1.1, “Using Computer Setup Utilities” for more information.

3.4.6 Power Management

Use the Timeouts option under the Power menu in Computer Setup to enable, customize, or disable standby timeouts. This feature shuts down certain components of the computer when they are not in use, saving energy without having to shut down the computer.

✎

When using Windows 95 or Windows 98, disable monitor timeouts in Computer Setup first, then establish the settings in Windows, to avoid potential conflicts.

Use Display Properties to establish, modify, or disable Power Management settings for the monitor. To access Display Properties, right-click on the Windows Desktop, then choose Properties.

Deskpro Service Reference Guide

3-13

3.4.7 Enhanced Support Software CD and World Wide Web Site

Compaq engineers rigorously test and debug software developed by Compaq and third-party suppliers, and develop operating-system specific support software, to ensure the highest level of performance, compatibility, and reliability for Compaq personal computers.

When making the transition to new or revised operating systems, it is important to implement the support software designed for that operating system. If you plan to run any of the following operating systems on your computer, you must install corresponding Compaq device drivers and utilities to ensure all features are supported and functioning properly:



Microsoft Windows 3.1



IBM OS/2



A version of Microsoft Windows or Microsoft Windows NT Workstation that is different from the version included with your computer

Compaq has made the task of locating, accessing, evaluating, and installing the latest support software easier. There are three methods you can use to access support software:



You can order the drivers, utilities, and flashable ROM images needed to run MS-DOS, Microsoft Windows

3.1, Windows 95, Windows 98, Windows NT Workstation, and IBM OS/2 on your Compaq commercial desktop product.



You can download the software from the Compaq World Wide Web site at www.compaq.com.

✎



You can purchase backup diskettes.

If you choose to purchase the



You can purchase a single CD-ROM that gives you one-time access to the latest support software (North America only, Compaq part number 272505-001).



You can purchase a yearly subscription that delivers up to 12 monthly CD-ROMs (Compaq part number 183426-xxx).

The annual subscription ensures your continuous access to the latest developments.

✎

Both the CD and the Compaq Web site include a comprehensive listing of the device drivers, utilities, flashable ROM images, and more, categorized by operating system, personal computer family, and model for easy retrieval. Decision Support provides detailed information for each support software file, including descriptions, features, enhancements, dependencies, and update information.

If you call Compaq to place an order, be sure to have the serial number of the computer available. This number is necessary for all purchases.

Support Software CD

Support Software CD,

. This compact disc contains the latest device

you have two options:

3.4.8 Compaq Integrated Software

Additional support software is available on the from the Compaq World Wide Web site at www.compaq.com. This software supplements the installation of off-the-shelf Microsoft operating systems and lets you quickly and easily install the correct device drivers and other software required for top performance.

3-14

Intelligent Manageability

Support Software CD

and may be downloaded

3.5 Building Blocks and Partners

Compaq management solutions are based on industry standards, including DMI 2.0, Web-Based Enterprise Management, Intel’s “Wired for Management,” SNMP, and Net PC technologies. Microsoft, Intel, Hewlett-Packard, Novell, Seagate, and other industry leaders work closely with Compaq to integrate their management solutions with Compaq products and initiatives, giving you, the Compaq customer, extraordinary flexibility and functionality in client management and PC ownership cost reduction.

3.5.1 Desktop Management Interface (DMI)

The Desktop Management Task Force (DMTF) is an industry body created in 1992 with the goal of standardizing systems manageability. DMTF established the Desktop Management Interface (DMI) framework to standardize access to PC configuration data. Compaq, as a Steering Committee and Technical Committee member of the DMTF, delivers hardware and software instrumentation that supports the DMI standard.

For more information on configuring the DMI software, refer to the online

Manageability Guide

Intelligent

3.5.2 Compaq Insight Manager and the Insight Management Agents

Using the industry-standard Simple Network Management Protocol (SNMP) found in Microsoft operating systems, Compaq has continued the migration of management tools from servers to desktops by enhancing Compaq Insight Manager. Compaq Insight Manager allows the LAN administrator to remotely view AssetControl data, configuration data, memory change alerts, NIC performance data, and contact information. The tool also provides access to the Fault Management features of the Compaq Personal Computers.

3.5.3 Compaq Management Solutions Partners Program

The Compaq Deskpro can be easily integrated into leading desktop and enterprise management solutions such as Microsoft SMS, Computer Associates’ Unicenter TNG, and Tivoli 10 among others. Compaq has established close partnerships with these vendors to ensure that the Deskpro is a well-managed PC client in their environments.

Compaq’s PC Lifecycle Solutions offer a comprehensive suite of tools and service which can help in more easily managing PC clients throughout their lifecycle in the areas of planning, deployment, management, and transition. Intelligent Manageability tools like the Compaq Insight Manager LC and the System Software Manager can be used side-by-side with other third-party management solutions.

Deskpro Service Reference Guide

3-15

appendix

ONNECTOR PIN ASSIGNMENTS

This appendix contains the pin assignments for many computer connectors. Some of these connectors may not be used on the computer being serviced.

Enhanced Keyboard

Connector and Icon Pin Signal

6345

KEY

Mouse

Connector and Icon Pin Signal

6345

KEY

1 2 3 4 5 6

Data Unused Ground +5 VDC Clock Unused

Ethernet BNC

Connector and Icon Pin Signal

1 (Inside) 2 (Outside)

Data Ground

Ethernet RJ-45

Connector and Icon Pin Signal

2 3 4 5 6 7 8

(+) Transmit Data (-) Transmit Data (+) Receive Data Unused Unused (-) Receive Data Unused Unused

Deskpro Service Reference Guide

A-1

Ethernet AUI

Connector and Icon Pin Signal

15 14

5643

13 12 11 1089

2 3 4 5 6 7 8 9 10 11 12 13 14 15 16

Ground Negative AUI Differential Collision Positive AUI Differential Collision Negative AUI Differential Transmit Positive AUI Differential Transmit Ground Ground Negative AUI Differential Receive Positive AUI Differential Receive +12V Ground Ground Not Used Not Used Not Used Not Used

Parallel Interface

Connector and Icon Pin Signal

1 2

12345678910111213

141516171819202122232425

3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18-25

Strobe Data Bit 0 Data Bit 1 Data Bit 2 Data Bit 3 Data Bit 4 Data Bit 5 Data Bit 6 Data Bit 7 Acknowledge Busy Paper End Select Auto Linefeed Error Initialize Printer Select IN Signal Ground

A-2

Connector Pin Assignments

Serial Interface

Connector and Icon Pin Signal

12345

6789

1 2 3 4 5 6 7 8 9

Carrier Detect Receive Data Transmit Data Data Terminal Ready Signal Ground Data Set Ready Request to Send Clear to Send Ring Indicator

USB Connector

Connector and Icon Pin Signal

1234

1 2 3 4

VCC

- Data + Data Ground

Microphone Connector

Connector and Icon (1/8” miniphone) Pin Signal

1 (Tip) 2 (Ring) 3 (Shield)

Audio Power Ground

Headphone Connector

Connector and Icon (1/8” miniphone) Pin Signal

1 (Tip) 2 (Ring) 3 (Shield)

Audio_Left Audio_Right Ground

Line-In Audio

Connector and Icon (1/8” miniphone) Pin Signal

1 (Tip) 2 (Ring) 3 (Shield)

Audio_In_Left Audio_In_Right Ground

Line-Out Audio

Connector and Icon (1/8” miniphone) Pin Signal

1 (Tip) 2 (Ring) 3 (Shield)

Audio_Out_Left Audio_Out_Right Ground

Deskpro Service Reference Guide

A-3

External Infrared Transceiver

Connector and Icon Pin Signal

1 2 3 4 5 6 7 8

Transmit Receive Ground 5V Mode Not Used Not Used Not used

Monitor

Connector Pin Signal

54321

109876

15 14 13 12 11

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

Red Analog Green Analog Blue Analog Not Connected Ground Ground Ground Ground +5V DC Ground Not Connected DCC Serial Data Horizontal Sync Vertical Sync DCC Serial Clock

A-4

Connector Pin Assignments

IDE/EIDE Drive Cable

139

240

Pin Signal Pin Signal Pin Signal

1 RESET 15 DD1 29 DMAK 2 GROUND 16 DD14 30 GROUND 3 DD7 17 DD0 31 INTRQ

4 DD8 18 DD15 32 IOCS16 5 DD6 19 GROUND 33 DA1 6 DD9 20 (KEY) 34 PDIAG (80-pin cable detect)

7 DD5 21 DMARQ 35 DA0 8 DD10 22 GROUND 36 DA2 9 DD4 23 DIOW 37 CS1FX

10 DD11 24 Ground 38 CS3FX 11 DD3 25 DIOR 39 DASP 12 DD12 26 GROUND 40 GROUND

13 DD2 27 IORDY 14 DD13 28 CSEL

Deskpro Service Reference Guide

A-5

Slimline CD-ROM Adapter

Pin Signal Pin Signal Pin Signal Pin Signal

1 RESDRV_ 18 D15 35 A0 52 FP05 2 GROUND 19 GROUND 36 A2 53 FP06 3 DO7 20 (KEY) 37 CS1FX 54 FP07

4 D08 21 DRQ 38 CS3FX 55 FP08 5 D06 22 GROUND 39 DASP 56 FP09 6 D09 23 IOW 40 GROUND 57 FP10

7 D05 24 GROUND 41 +5VMLOG 58 FP11 8 D10 25 IOR 42 +5VMOT 59 FP12 9 D04 26 GROUND 43 GROUND 60 FP13

10 D11 27 IOCHRDY 44 AUDIO_L 61 FP14 11 D03 28 CABLE SELECT 45 A_GROUND_R 62 FP15 12 D12 29 DAK 46 A_GROUND_L 63 FP16

13 D02 30 GROUND 47 AUDIO_R 64 FP17 14 D13 31 IRQ 48 FP01 65 FP18 15 D01 32 IO16 49 FP02 66 FP19

16 D14 33 A1 50 FP03 67 FP20 17 D00 34 PDIAG 51 FP04 68 FP21

A-6

Connector Pin Assignments

AGP Connector

Signal

1 +12 V OVRCNT# 23 Ground Ground 45 VCC 3.3 VCC 3.3 2 TYPEDET# + 5V 24 Reserved 3.3 Vaux 46 TRDY# DEVSEL# 3 Reserved + 5V 25 VCC 3.3 VCC 3.3 47 STOP# Vddq

4 USB- USB+ 26 AD30 AD31 48 PME# PERR# 5 Ground Ground 27 AD28 AD29 49 Ground Ground 6 INTA# INTB# 28 VCC 3.3 VCC 3.3 50 PAR SERR#

7 RST# CLK 29 AD26 AD27 51 AD15 C/BE1# 8 GNT# REQ# 30 AD24 AD25 52 Vddq Vddq 9 VCC3.3 VCC3.3 31 Ground Ground 53 AD13 AD14

10 ST1 ST0 32 AD_STB1# AD_STB1 54 AD11 AD12 11 Reserved ST2 33 C/BE3# AD23 55 Ground Ground 12 PIPE# RBF# 34 Vddq Vddq 56 AD9 AD10

13 Ground Ground 35 AD22 AD21 57 C/BEO# AD8 14 WBF# Reserved 36 AD20 AD19 58 Vddq Vddq 15 SBA1 SBA0 37 Ground Ground 59 AD_STBO# AD_STBO

16 VCC 3.3 VCC 3.3 38 AD18 AD17 60 AD6 AD7 17 SBA3 SBA2 39 AD16 C/BE2# 61 Ground Ground 18 SB_STB# SB_STB 40 Vddq Vddq 62 AD4 AD5

Signal B Pin

Signal A

Signal B Pin

Signal A

Signal B

19 Ground Ground 41 FRAME# IRDY# 63 AD2 AD3 20 SBA5 SBA4 42 Reserved 3.3VAux 64 Vddq Vddq 21 SBA7 SBA6 43 Ground Ground 65 AD0 AD1 22 Reserved Reserved 44 Reserved Reserved 66 VREFGC VREFCG

Deskpro Service Reference Guide

A-7

Ultra SCSI

Connector and Icon

Pin Signal Pin Signal Pin Signal

1-11 Ground 31 DB5 41 ATN # 12 Reserved 32 DB6 42 Ground 13 Open 33 DB7 43 BSY # 14 Reserved 34 DBP 44 ACK # 15-25 Ground 35 Ground 45 RST # 26 DB0 36 Ground 46 MSG # 27 DB1 37 Reserved 47 SEL # 28 DB2 38 TERMPWR 48 C/D 29 DB3 39 Reserved 49 REQ # 30 DB5 40 Ground 50 Input/Output

IDE CD-ROM Cable

Pin Signal Pin Signal Pin Signal Pin Signal

1 RESDRV_ 14 GROUND 27 D07 40 D08 2 D06 15 D09 28 D05 41 D10 3 D04 16 D11 29 D03 42 D12 4 D02 17 D13 30 D01 43 D14 5 D00 18 D15 31 Ground 44 (KEY) 6 DREQ 19 Ground 32 IOW 45 Ground 7 IOR 20 Ground 33 OCHRDY 46 CABLE SELECT 8 DAK 21 Ground 34 IRQ 47 IO16 9 A1 22 PDIAG 35 A0 48 A2 10 CS1FX 23 CS3FX 36 DASP 48 Ground 11 AUDIO_R 24 AUDIO_L 37 A_GND_R 49 A_GND_L 12 +5VMOT1 25 +5VMOT2 38 +5VMOT3 50 +5VMOT4 13 +5VMLOG1 26 +5VMLOG2 39 DASP

A-8

Connector Pin Assignments

14-Pin Power Connector

Pin Signal Pin Signal Pin Signal Pin Signal

1 +3.3 V 5 RTN 9 -12 V 13 Fan 2 +3.3 V Aux 6 +5 V 10 Fan OFF 14 +12 V 3 RTN 7 RTN 11 ON/STBY 4 +5 V 8 +3.3 V 12 +5 V Aux

20-Pin Power Connector - Deskpro EP

Pin Signal Pin Signal Pin Signal Pin Signal

1 +3.3 V 6 +5 V 11 +3.3 V 16 RTN 2 +3.3 V 7 RTN 12 -12 V 17 RTN 3 RTN 8 Fan OFF 13 RTN 18 -5 V 4 +5 V 9 +5 V Aux 14 ON/STBY 19 +5 V 5 RTN 10 +12 V 15 RTN 20 +5 V

20-Pin Power Connector - Deskpro EN

Pin Signal Pin Signal Pin Signal Pin Signal

1 3 V 6 5 V 11 3 V 16 RTN/RS 2 3 V/RS 7 Aux RTN 12 -12 V 17 RTN 3 RTN 8 Fan OFF 13 RTN 18 -5 V 4 5 V 9 5 Vaux 14 ON/STBY 19 5 V 5 RTN 10 12 V 15 RTN 20 5 V

Deskpro Service Reference Guide

A-9

24-Pin Power Connector

Pin Signal Pin Signal Pin Signal Pin Signal

1 +3.3 V 7 aux RTN 13 +3.3V 19 RTN 2 +3.3 V 8 Fan OFF 14 -12 V 20 -5 V 3 RTN 9 +5 V aux 15 RTN 21 +5 V 4 +5 V 10 +12 V 16 ON/STBY 22 +5 V 5 RTN 11 3.3 Vaux 17 RTN 23 3.3 V R/S 6 +5 V 12 Fan CMD 18 RTN / (R/S) 24 Fan Sink

A-10

Connector Pin Assignments

appendix

OWER CORD SET REQUIREMENTS

The voltage select switch feature on the computer permits it to operate from any line voltage between 100-120 or 220-240 volts AC.

The power cord set received with the computer meets the requirements for use in the country where you purchased the equipment.

Power cord sets for use in other countries must meet the requirements of the country where you use the computer. For more information on power cord set requirements, contact your authorized Compaq dealer, reseller, or service provider.

General Requirements

The requirements listed below are applicable to all countries:

1. The length of the power cord set must be at least 6.00 feet (1.8 m) and a maximum of 9.75 feet (3.0 m).

2. All power cord sets must be approved by an acceptable accredited agency responsible for evaluation in the country where the power cord set will be used.

3. The power cord set must have a minimum current capacity of 10A and a nominal voltage rating of 125 or 250 volts AC, as required by each country’s power system.

4. The appliance coupler must meet the mechanical configuration of an EN 60 320/IEC 320 Standard Sheet C13 connector, for mating with appliance inlet on the Switch Box.

Compaq Deskpro EN Series of Personal Computers

B-1

Country-Specific Requirements

Additional requirements specific to a country are shown in parentheses and explained below.

Country Accrediting Agency Country Accrediting Agency

Australia (1) EANSW Italy (1) IMQ Austria (1) OVE Japan (3) JIS Belgium (1) CEBC Norway (1) NEMKO

Canada (2) CSA Sweden (1) SEMKO Denmark (1) DEMKO Switzerland (1) SEV Finland (1) SETI United Kingdom (1) BSI

France (1) UTE United States (2) UL Germany (1) VDE

Notes: (1) The flexible cord must be <HAR> Type HO5VV-F, 3-conductor, 1.0 mm

set fittings (appliance coupler and wall plug) must bear the certification mark of the agency responsible for evaluation in the country where it will be used.

(2) The flexible cord must be Type SJT or equivalent, No. 18 AWG, 3-conductor. The wall plug must be a two-pole grounding type with a NEMA 5-15P (15A, 125V) or NEMA 6-15P (15A 250V) configuration.

(3) The appliance coupler, flexible cord, and wall plug must bear a "T" mark and registration number in accordance with the Japanese Dentori Law. The flexible cord must be Type VCT or VCTF, 3-conductor,

0.75 mm Standard C8303 (15A, 125V) configuration.

conductor size. The wall plug must be a two-pole grounding type with a Japanese Industrial

conductor size. Power cord

B-2

Power Cord Set Requirements

appendix

ARD DRIVES

Compaq Computer Corporation uses IDE hard disk drives that conform to two different primary/secondary implementations. These are Conner mode and ATA-compatible mode. These two modes are incompatible with one another.

Device 0/Device 1 Relationship

A device 0/device 1 relationship exists when there are two hard drives connected to a single port. In this situation, one drive must be designated as the device 0 or primary drive and the other as the device 1, or secondary drive. This designation is necessary because both drives cannot work simultaneously.

SMART

The SMART IDE hard drives for the Compaq Deskpro Personal Computers have built-in drive failure prediction that warns the user or the network administrator of an impending failure or crash of the hard drive.

Automatic Soft-Drive Types

An automatic soft-drive type is a mechanism where the system ROM and Computer Setup automatically build a soft-drive type to provide support for IDE hard drives that are not in the hard drive parameter table.

The soft-drive types are assigned according to the table below:

Drive Hard Drive Type Controller

0 1

For hard drives that are greater than 528 MB, the system automatically translates the hard drive parameter for DOS by logically halving the cylinders and doubling the heads. This allows DOS to access greater than 528 MB. The translated hard drive parameters are put into the hard drive parameter table in the shadow RAM copy of the system ROM. When using any operating system other than DOS, you must use F10 Setup to set up the hard drive parameter table without translation.

65 66

68 15

Primary Primary

Secondary Secondary

Deskpro Service Reference Guide

C-1

appendix

POST E

An error message results if the Power-On Self-Test (POST) encounters a problem. This test runs when the system is turned on, checking assemblies within the computer and reporting any errors found.

Screen Message Beeps* Probable Cause Recommended Action

101-Option ROM Error 1L, 1S System ROM checksum. 1. Verify the correct ROM.

102-System Board Failure

103-System Board Failure None DMA, timers, etc.

RROR MESSAGES

2. Flash the ROM if needed.

3. If an expansion card was recently added, remove it and see if the problem remains.

4. If the message disappears, there may be a problem with the expansion card.

5. Replace the system board.

None DMA, timers, etc. 1. Clear CMOS.

2. Remove expansion boards.

3. Replace the system board.

1. Clear CMOS.

2. Remove expansion boards.

3. Replace the system board.

162-System Options Not Set

163-Time & Date Not Set 2S Invalid time or date in

* L = Long, S = Short

2S Configuration incorrect.

RTC (real-time clock) battery may need to be replaced. Battery life is approximately 5 years.

configuration memory. RTC (real-time clock)

battery may need to be replaced. Battery life is approximately five years.

CMOS jumper may not be properly installed.

Run Computer Setup (F10 Setup). Reset the date and time under

Control Panel. If the problem persists, replace the RTC battery.

Set the date and time under Control Panel.

If the problem persists, replace the RTC battery.

Check for proper placement of the CMOS jumper.

continued

Deskpro Service Reference Guide

D-1

POST Error Messages

Continued

Screen Message Beeps* Probable Cause Recommended Action

164-Memory Size Error 2S Memory configuration

is incorrect.

183-Invalid Processor Jumper Setting

201-Memory Error None RAM failure. 1. Run computer Setup (F10

2S System board jumper

improperly set.

1. Run Computer Setup (F10 Setup) or Windows utilities.

2. Make sure memory module(s) (if any) are installed properly.

3. Verify proper memory module type.

Reset system board jumpers to match processor and bus speeds.

Setup) or Windows utilities.

2. Ensure memory and continuity

modules are installed correctly.

3. Verify proper memory module

type.

4. Remove and replace memory

module(s) one at a time to isolate faulty module.

5. Replace the faulty memory

module(s).

6. If error persists after replacing

memory modules, replace the system board.

202-Memory Type Mismatch None Memory modules do not

match each other.

207-ECC Corrected Single Bit Errors in DIMM/SIMM Pair(s) X,X,... in Memory Socket(s) y,y

213-Incompatible DIMM Module in DIMM Socket(s) X,X, X

* L = Long, S = Short

2S Single Bit ECC error. 1. Verify proper memory module

2S A DIMM module in DIMM

socket identified in the error message is missing critical SPD information, or is incompatible with the chipset.

Replace memory modules with matched sets.

type.

2. Try another memory socket.

3. Replace memory module if

problem persists.

1. Verify proper memory module

type.

2. Try another memory socket.

3. Replace DIMM with a module

conforming to the SPD standard.

continued

D-2

POST Error Messages

Continued

Screen Message Beeps* Probable Cause Recommended Action

301-Keyboard Error None Keyboard failure. 1. Reconnect keyboard with

computer turned off.

2. Check connector for bent or missing pins.

3. Ensure that none of the keys are depressed.

4. Replace keyboard.

304-Keyboard or System Unit Error

401-Parallel Port 1 Address Assignment Conflict

403-Parallel Port 3 Address Assignment Conflict

404-Parallel Port Address Conflict Detected

410-Audio Interrupt Conflict 2S IRQ address conflicts with

None Keyboard failure. 1. Reconnect the keyboard with

2S IRQ address conflicts with

another device.

2S IRQ address conflicts with

another device.

2S Both external and internal

ports are assigned to parallel port X.

another device.

computer turned off.

2. Ensure that none of the keys are depressed.

3. Replace keyboard.

4. Replace system board.

Reset the IRQ.

1. Remove any parallel expansion cards.

2. Clear CMOS.

3. Reconfigure card resources and/or run Computer Setup (F10 Setup).

Reset the IRQ.

411-Network Interface Card Interrupt Conflict

501-Display Adapter Failure

* L = Long, S = Short

2S IRQ address conflicts with

another device.

1L, 2S Graphics display controller. 1. Reseat the graphics card (if

Reset the IRQ.

applicable).

2. Clear CMOS.

3. Verify the monitor is attached and turned on.

4. Replace the graphics controller.

continued

Deskpro Service Reference Guide

D-3

POST Error Messages

Continued

Screen Message Beeps* Probable Cause Recommended Action

601-Diskette Controller Error

602-Diskette Boot Record Error

605-Diskette Drive Type Error

610-External Storage Device Failure

611-Primary Floppy Port Address Assignment Conflict

None Diskette controller circuitry

or floppy drive circuitry incorrect.

None Diskette in drive A not

bootable.

2S Mismatch in drive type. 1. Run Computer Setup (F10

None External tape drive not

connected.

2S Configuration error. 1. Run Computer Setup (F10

1. Run Computer Setup (F10 Setup).

2. Check and/or replace cables.

3. Clear CMOS.

4. Replace diskette drive.

5. Replace the system board.

Replace the diskette.

Setup) or Windows NT, Windows 95, or Windows 98 utilities.

2. Disconnect any other diskette controller devices (tape drives).

3. Clear CMOS.

Reinstall tape drive or press F1 and allow system to reconfigure without the drive.

Setup).

2. Remove expansion cards.

3. Clear CMOS.

D-4

612-Secondary Floppy Port Address Assignment Conflict

660-Display Cache is Detected Unreliable

912-Computer Cover Has Been Removed Since Last System Start Up

* L = Long, S = Short

POST Error Messages

2S Configuration error. 1. Run Computer Setup (F10

Setup).

2. Remove expansion cards

3. Clear CMOS.

None Integrated video controller

display cache not working properly and will be disabled.

None No action required.

Replace system board if minimal video degrading is an issue.

continued

POST Error Messages

Continued

Screen Message Beeps* Probable Cause Recommended Action

914-Hood Lock Coil is not Connected

916-Thermal Sensor from Processor Heatsink is not Connected.

917-Expansion Riser not Detected

1151-Serial Port 1 Address Conflict Detected

1152-Serial Port 2 Address Conflict Detected

None Hood lock mechanism is

missing or not connected.

None Processor heatsink cable not

connected to system board.

None Riser board not seated or not

installed.

2S Both external and internal

serial ports are assigned to COM1.

2S Both external and internal

serial ports are assigned to COM2.

1. Reconnect or replace hood locking mechanism.

2. Reseat or replace hood locking mechanism cable.

Reseat or replace the processor heatsink cable going to the system board.

Install riser board if missing or remove and reseat to ensure good connection.

1. Remove any Comm port expansion cards.

2. Clear CMOS.

3. Reconfigure card resources and/or run Computer Setup (F10 Setup).Run Computer Setup or Windows utilities.

1. Remove any Comm port expansion cards.

2. Clear CMOS.

3. Reconfigure card resources and/or run Computer Setup (F10 Setup).Run Computer Setup or Windows utilities.

1155- Serial Port Address Conflict Detected

1201-System Audio Address Conflict Detected

1202-MIDI Port Address Conflict Detected

1203-Game Port Address Conflict Detected

* L = Long, S = Short

2S Both external and internal

serial ports are assigned to same IRQ.

2S Device IRQ address conflicts

with another device.

2S Device IRQ address conflicts

with another device.

Device IRQ address conflicts with another device.

1. Remove any Comm port expansion cards.

2. Clear CMOS.

3. Reconfigure card resources and/or run Computer Setup (F10 Setup).Run Computer Setup or Windows utilities.

Reset the IRQ.

continued

Deskpro Service Reference Guide

D-5

POST Error Messages

Continued

Screen Message Beeps* Probable Cause Recommended Action

1720-SMART Hard Drive Detects Imminent Failure

1721-SMART SCSI Hard Drive Detects Imminent Failure

1771-Primary Disk Port Address Assignment Conflict

None Hard drive is about to fail.

(Some hard drives have a firmware patch that will fix an erroneous error message.)

None Hard drive is about to fail.

(Some hard drives have a firmware patch that will fix an erroneous error message.)

2S Internal and external hard

drive controllers are both assigned to the primary address.

1. Determine if hard drive is giving correct error message. Run the Drive Protection System test available.

2. Apply firmware patch if applicable.

3. Back up contents and replace hard drive.

1. Determine if hard drive is giving correct error message. Run the Drive Protection System test available.

2. Apply firmware patch if applicable.

3. Back up contents and replace hard drive.

1. Remove any Comm port expansion cards.

2. Clear CMOS.

3. Reconfigure card resources and/or run Computer Setup (F10 Setup).

1772-Secondary Disk Port Address Assignment Conflict

1780-Disk 0 Failure None Hard drive/format error. 1. Run Computer Setup (F10

* L = Long, S = Short

2S Internal and external hard

drive controllers are both assigned to the primary address.

1. Remove any Comm port expansion cards.

2. Clear CMOS.

3. Reconfigure card resources and/or run Computer Setup (F10 Setup).

Setup).

2. Clear CMOS.

3. Check cables/jumper settings.

4. Run hard drive diagnostics.

5. Disconnect additional drives.

6. Run the Drive Protection System test if available.

7. Replace the hard drive.

continued

D-6

POST Error Messages

Continued

Screen Message Beeps* Probable Cause Recommended Action

1781-Disk 1 Failure None Hard drive/format error. 1. Run Computer Setup (F10

Setup).

2. Clear CMOS.

3. Check cable seating/jumper settings.

4. Run hard drive diagnostics.

5. Disconnect additional drives.

6. Run the Drive Protection System test if available.

7. Replace the hard drive.

1782-Disk Controller Failure

1790-Disk 0 Failure None Hard drive error or wrong

* L = Long, S = Short

None Hard drive circuitry error. 1. Run Computer Setup (F10

drive type.

Setup).

2. Clear CMOS.

3. Check cable seating /jumper settings.

4. Run hard drive diagnostics.

5. Disconnect additional drives.

6. Run the Drive Protection System test if available.

7. Replace the hard drive.

8. Replace the system board.

1. Run Computer Setup (F10 Setup).

2. Clear CMOS.

3. Check cable seating /jumper settings.

4. Run hard drive diagnostics.

5. Disconnect additional drives.

6. Confirm drive is supported on this computer (Large drive ROM support.)

7. Run the Drive Protection System test if available.

8. Replace the hard drive.

9. Replace the system board.

continued

Deskpro Service Reference Guide

D-7

POST Error Messages

Continued

Screen Message Beeps* Probable Cause Recommended Action

1791-Disk 1 Failure None Hard drive error or wrong

drive type.

1792-Secondary Disk Controller Failure

None Hard drive circuitry error. 1. Run Computer Setup (F10

1. Run Computer Setup (F10 Setup).

2. Clear CMOS.

3. Check cable seating /jumper settings.

4. Run hard drive diagnostics.

5. Disconnect additional drives.

6. Confirm drive is supported on this computer (Large drive ROM support).

7. Run the Drive Protection System test if available.

8. Replace the hard drive.

9. Replace the system board.

Setup).

2. Clear CMOS.

3. Check cable seating /jumper settings.

4. Run hard drive diagnostics.

5. Disconnect additional drives.

6. Run the Drive Protection System test if available.

7. Replace the hard drive.

D-8

1793-Secondary Controller or Disk Failure

* L = Long, S = Short

POST Error Messages

None Hard drive circuitry error. 1. Run Computer Setup (F10

Setup).

2. Clear CMOS.

3. Check cable seating /jumper settings.

4. Run hard drive diagnostics.

5. Disconnect additional drives.

6. Run the Drive Protection System test if available.

7. Replace the hard drive.

continued

POST Error Messages

Continued

Screen Message Beeps* Probable Cause Recommended Action

1800-Temperature Alert None Internal temperature

exceeds specification.

1801 None Processor not supported by

ROM Bios.

Audible 1L, 3S System ROM is bad;

system is running in Failsafe Boot Block mode.

1. Check that computer air vents

2. Verify processor speed

3. Replace the processor.

4. Replace the system board.

Upgrade Bios to proper version.

Reflash the ROM using a ROMPaq diskette. Refer to the “Failsafe Boot Block ROM” section of the

Reference Guide

Audible 2S Power-on successful. None

Flashing Caps Lock LED on Keyboard

Flashing Num Lock LED on Keyboard

1L. 2S Graphics controller not

present or incorrectly initialized.

1S, 2L System memory not

present

1. Clear CMOS.

2. If graphics card has been

1. Check memory module.

2. Remove and reseat memory module.

3. See “Memory Problems” in Appendix F.

are not blocked and cooling fan is running.

selection.

Software

added, remove and reseat.

Num Lock LED on Keyboard

Flashing Scroll Lock LED on Keyboard

Green Power LED Blinks Once per Second

Green Power LED ON None Computer on. None

Invalid Electronic Serial Number

* L = Long, S = Short

None Failed Boot Block. Reflash the ROM using a ROMPaq

diskette.

2L, 1S System board hardware

failure (prior to video)

None Computer in normal Suspend

mode.

None Electronic serial number has

become corrupted.

Replace system board.

None

Run Computer Setup (F10 Setup). If Setup already has data in the field or will not allow the serial number to be entered, download and run SP5572.EXE (SNZERO.EXE).

Deskpro Service Reference Guide

continued

D-9

POST Error Messages

Continued

Screen Message Beeps* Probable Cause Recommended Action

Flashing Power and Hard Drive Green LEDs

Red Power LED Blinks Every 2 or More Seconds

Red Power LED Blinks Every Second

None Unseated riser board. 1. Remove riser board.

2. Wipe connector.

3. Reinstall riser board.

None Power supply overloaded. 1. Push in power button. LED

should be green.

2. Remove all AC power from computer, wait 30 seconds, then apply power.

3. Remove load from power supply by removing options one at a time until computer runs.

4. Check for damage to system board.

5. Replace system board.

6. Replace power supply.

None System memory error. 1. Check memory module.

2. Remove and reseat memory module.

3. See the "Solving Memory Problems" section of this guide.

Red power LED ON None Processor unseated. Reseat processor in system board. * L = Long, S = Short

D-10

POST Error Messages

appendix

IAGNOSTIC INDICATOR LIGHTS

LED Color LED Activity State/Message

Power Green On Computer on Power Green 1 blink/second Normal suspend mode Power Green 1 blink/second Suspend to RAM

Power None Computer off Power Red 4 blinks/second CPU thermal shutdown Power Red On CPU not installed/fetching code

Power Red 1 blink/second ROM error Power Red 1 blink/2 or more

seconds

Power and Hard Drive Red On Riser board not seated

Power supply overloaded

Num Lock Green Flashing Memory error Caps Lock Green Flashing No video Scroll Lock Green Flashing System board failure, prior to video

Deskpro Service Reference Guide

E-1

appendix

ROUBLESHOOTING WITHOUT DIAGNOSTICS

Preliminary Checklist

This section describes some simple, preliminary tests and guidelines for troubleshooting the computer without using the diagnostics.

If you encounter some minor problem with the computer or a software application, go through the following checklist for possible solutions before running any of the diagnostic utilities:



Are the computer and monitor connected to a working electrical outlet?



Is the computer turned on?



Is the green power light illuminated?



Is the monitor turned on?



Is the green monitor light illuminated?



Turn up the monitor brightness and contrast controls if the monitor is dim.



Press and hold any key. If the system beeps, then the keyboard should be operating correctly.



Check all cables for loose or incorrect connections.



Reconfigure the computer after installing a non Plug and Play expansion board or other option, such as a diskette drive.



Are all of the necessary device drivers installed?



Have all printer drivers been installed for each application?



Remove all diskettes from the diskette drives before you turn on the system.



Are all switches set correctly?



Is the NIC Remote Wakeup cable (featured on some models) connected between the NIC and the riser/system board?

Deskpro Service Reference Guide

F-1

Solving Minor Problems

Problem Possible Solution

Computer will not turn on. 1. Ensure that the computer is properly connected to an external

power source and the wall outlet is active.

2. A PCI or ISA card that has been installed is defective. Remove any expansion card that was just installed.

3. Reseat drive power, data, and power supply cables.

Computer appears locked up and won’t turn off when the power button is pressed.

Computer date and time display is incorrect.

Computer powered off automatically.

Computer appears to pause periodically.

Cannot remove computer cover or side panel.

Software control of the power button may not be functional. Press and hold the button for four seconds, then release. This invokes the hardware override for the power button.

First, reset the date and time under Control Panel. If the problem persists, the real-time clock (RTC) battery may need to be replaced. Refer to the “Removal and Replacement Procedures” chapter in the product-specific MSG.

1. The unit temperature was exceeded because the unit is in an

exceedingly hot environment or the fan is blocked. Let the unit cool down.

2. The fan may not be functioning correctly or the air vents are blocked.

3. The unit temperature was exceeded because the computer was

functioning with the cover or side panel removed. Replace cover or side panel, and let the computer cool down before turning power back on.

Network driver is loaded and no network connection is established. Establish a network connection, or use Computer Setup or Windows Device Manager to disable the network controller.

1. Smart Lock, featured on some computers, is locked. Unlock the

Smart Cover Lock using Computer Setup.

2. The Smart Cover FailSafe Key, a device for manually disabling the

Smart Cover Lock, is available from Compaq. You’ll need the FailSafe Key in cases of forgotten password, power loss, or computer malfunction.

F-2

Computer does not boot up and power and hard drive LEDs are blinking.

Computer does not boot up and Num Lock LED is blinking; you may hear one short and two long beeps.

The Caps Lock LED is flashing; you may hear one long and two short beeps.

Computer does not boot up and the Scroll Lock LED is flashing; you may hear two long and one short beeps.

✎

If the standard keyboard has been replaced with a Universal Serial Bus (USB) keyboard, you will hear the beep sequences mentioned above but will not see the flashing lights.

Troubleshooting Without Diagnostics

Ensure that the riser board is properly seated.

Memory may be improperly installed or may be bad.

The video controller is not present or is incorrectly initialized. Clear configuration memory (CMOS). If a video board has been added, remove and reseat it.

System board hardware failure (prior to video). Replace system board.

Diskette Drive

Problem Possible Solution

Diskette drive light stays on. 1. Diskette is damaged. In Windows 95 or 98, run ScanDisk. Click Start

Programs Æ Accessories Æ System Tools Æ ScanDisk.

In Windows NT, right click Start, click Explore, and select a drive. Select File Æ Properties Æ Tools. Under Error-checking, click Check Now.

2. Diskette is incorrectly inserted. Remove the diskette and reinsert.

3. Software program may be damaged. Check the program diskettes.

4. Drive button is not pushed in. Push in drive button.

5. Drive cable is not properly connected. Reconnect drive cable.

Diskette drive cannot write to a diskette.

Cannot format diskette. Invalid media reported. When formatting a diskette in DOS, you may

Diskette drive cannot read a diskette.

A problem has occurred with a disk transaction.

1. Diskette is not formatted. Format the diskette.

2. Diskette is write-protected. Either use another diskette that is not write-protected or disable the write protection on the diskette.

3. Writing to the wrong drive. Check the drive letter in the path statement.

4. Not enough space is left on the diskette. Use another diskette.

5. Diskette write control is enabled. Check the Removable Media write settings in Computer Setup.

need to specify diskette capacity. For example, to format a 1.44-MB diskette, type the following command at the DOS prompt:

FORMAT A:/F:1440

1. Diskette is not formatted. Format the diskette.

2. Using the wrong diskette type for the drive type. Check the drive type and use a compatible diskette.

3. Reading the wrong drive. Check the drive letter in the path statement.

4. Diskette drive has been disabled by Computer Setup, Windows NT, Windows 95, or Windows 98 utilities. Run Computer Setup and enable the diskette drive.

The directory structure is bad, or there is a problem with a file. In Windows 95 or 98, run ScanDisk. Click Start Æ Programs Accessories Æ System Tools Æ ScanDisk.

In Windows NT, right click Start, click Explore, and select a drive. Select File Æ Properties Æ Tools. Under Error-checking, click Check Now.

Non-system disk message. The system is trying to start from a nonsystem diskette. Remove the

diskette from the drive.

Drive not found. 1. Reseat the diskette drive cable.

2. If a second diskette drive has been installed, follow the computer reconfiguration directions in the “Hardware Installation Problems” section.

System has misidentified the diskette drive type.

If a diskette drive other than a 3.5-inch, 1.44-MB drive has been installed, ensure that the drive type is identified correctly under Computer Setup.

Deskpro Service Reference Guide

F-3

Display

Problem Possible Solution

Screen is blank 1. Monitor is not turned on and the monitor light is not on. Turn on the

monitor and check that the monitor light is on.

2. Screen save has been initiated. Press any key or move the mouse to light the screen.

3. The cable connections are not correct. Check the cable connection from the monitor to the computer and to the electrical outlet.

4. The brightness need adjusting. Adjust the brightness control.

5. The energy saver feature has been enabled. Press any key or click the mouse button and, if one has been set, type the password.

7. The RGB (Red, Green, Blue) input switch on the back of the monitor is incorrectly set. Set the monitor's input switch to 75 ohms and, if there is a sync switch, set it to External.

8. System ROM is bad and system is running in FailSafe Boot Block mode (indicated by one long beep and three short beeps). Reflash the ROM using a ROMPaq diskette. Refer to “FailSafe Boot Block ROM” in section 3.4.1 of this book.

9. If a fixed-sync monitor is used, be sure that the monitor can

accept the same sweep rate as the resolution chosen.

10. Ensure the VGA/BNC selector is properly set.

Graphics colors are wrong. Either the cabling or the monitor impedance is incorrect.

1. Ensure that the Red, Green, and Blue BNC cables are connected to the corresponding monitor connectors.

2. Be sure the monitor's RGB inputs are set to 75 ohms.

Characters are dim. 1. Adjust the monitor's brightness and contrast controls.

2. Check that the video cable is securely connected to the graphics card and monitor.

3. Set the RGB switch (and sync options, if available) to 75 ohms, with the sync set to External. Refer to the documentation included with the monitor.

Monitor does not function properly when used with the energy saver features.

Blurry display or requested resolution cannot be set.

The picture is broken up; it rolls, jitters, or blinks.

Screen goes blank. A screen blanking utility may be installed or energy saver features

Monitor without the energy saver feature is being used with energy saver features enabled. Disable the monitor energy saver features.

If the graphics controller was upgraded, the correct display drivers may not be loaded. Install the correct display drivers on the diskette included in the upgrade kit.

1. Be sure the monitor cable is securely connected to the computer.

2. In a two-monitor system or if another monitor is in close proximity, move the monitors apart to be sure they are not interfering with one other's magnetic field.

3. Fluorescent lights or fans may be too close to the monitor.

may be enabled. Press any key or type password.

continued

F-4

Troubleshooting Without Diagnostics

Display Problems

Continued

Problem Possible Solution

Monitor overheats. There is not enough ventilation space for proper airflow. Leave at least

3 inches (7.6 cm) of ventilation space. Be sure there is nothing on top of the monitor obstructing the air flow.

SCSI

Printer

Cursor will not move using the arrow keys on the numeric keypad.

The Num Lock key is on. Press the key to turn it off. The Num Lock light should not be on when you want to use the arrow keys.

Problem Possible Solution

System with IDE and SCSI drives will not boot from SCSI hard drive.

System will not boot from a SCSI drive.

The IDE drive needs to be disabled. Under the Computer Setup Advanced menu, disable the primary IDE controller.

1. The SCSI drive is not configured correctly.

2. Ensure that drive cabling and jumpers are set correctly. To boot a SCSI drive, the drive ID number must be set to 0.

Problem Possible Solution

Printer will not print. 1. Printer is not turned on and online. Turn the printer on and ensure it

is online.

2. Run printer self-test.

3. Reseat both ends of the printer cable.

4. Verify that printer port is enabled in BIOS and in Windows using F10 Setup.

5. Try printing using the DOS command C:\>DIR>PRN. If printer works, problem is with the printer driver. Reload driver.

6. If the computer is on a network, you may not have made the connection to the printer. Make the proper network connections to the printer.

Printer will not turn on. The cables may not be connected properly. Reconnect all cables and

check the power cord and electrical outlet.

Prints garbled information. 1. The correct printer drivers for the application are not installed.

Install the correct printer driver for the application.

2. The cables may not be connected properly. Reconnect all cables.

Printer is off line. The printer may be out of paper. Check the paper tray and refill it if

empty. Select online.

Deskpro Service Reference Guide

F-5

Hard Drive

This section identifies some quick checks for hard drive-related problems. The information provided by the diagnostics tests includes: error code, system serial number,

drive serial number, drive model, and drive firmware revision. Specific details of the drive failure are not included.

When you run the diagnostics, the test results are stored in a log. After completing the test, you can print this log to a local printer or save it to a file. Alternatively, before running the test, you can configure the test options to send the results to a local printer or file.

Solutions for some typical hard drive problems are presented in the following table:

Problem Possible Solution

Hard drive error occurs. Hard disk has bad sectors or has failed. Use a utility to locate and

block usage of bad sectors. If necessary, reformat the hard disk.

Disk transaction problem. Either the directory structure is bad or there is a problem with a file. In

Windows 95 and 98, run ScanDisk. Click Start Æ Programs Accessories Æ System Tools Æ ScanDisk.

In Windows NT, right click Start, click Explore, and select a drive. Select File Æ Properties Æ Tools. Under Error-checking, click Check Now.

Drive not found. 1. Cable could be loose. Check cable connections.

2. The system may not have automatically recognized a newly installed device. See reconfiguration directions in the “Hardware Installation Problems” section. If system still does not recognize the new device, check to see if the device is listed within Computer Setup. If it is listed, the probable cause is a driver problem. If it is not listed, the probable cause is a hardware problem.

3. Check drive jumper settings. If the drive is a secondary drive that has just been installed on the same controller as the primary drive, verify that the jumpers for both drives are set correctly.

F-6

Nonsystem disk message. 1. The system is trying to start from a diskette that is not bootable.

Remove the diskette from the diskette drive.

2. The system is trying to start from the hard drive but the hard drive may have been damaged. Insert a bootable diskette into the diskette drive and restart the computer.

3. Diskette boot has been disabled in Computer Setup. Run Computer Setup and enable diskette boot.

Second Ultra ATA hard drive does not perform optimally.

Troubleshooting Without Diagnostics

The cable is not compatible with the drive type. Reinstall the second Ultra ATA hard drive using an 80-conductor cable.

Hardware Installation

You may need to reconfigure the computer when you add or remove hardware, such as an additional diskette drive. If you install a Plug and Play device, Windows 95 and 98 automatically recognizes the device and configures the computer. If you install a non-Plug and Play device, you must reconfigure the computer after completing installation of the new hardware. In Windows 95 and 98, select the Add New Hardware icon in the Control Panel and follow the instructions that appear on the screen. To reconfigure the computer in Windows NT Workstation 4.0 after installing new hardware, use the utility provided with the hardware.

Problem Possible Solutions

A new device is not automatically recognized as part of the computer system.

1. The computer needs to be reconfigured to recognize the new device. Follow the reconfiguration instructions above. If system still does not recognize the new device, but the device is listed within Computer Setup, use Computer Setup to address any resource conflicts.

2. When the system advised you of changes to the configuration, you did not accept them. Reboot the computer and follow the instructions for accepting the changes.

3. A Plug and Play board may not automatically configure when added if the default configuration conflicts with other devices. Use Windows 95 or 98 Device Manager to deselect the automatic settings for the board and choose a basic configuration that doesn’t cause a resource conflict. You can also use Computer Setup to reconfigure or disable devices to resolve the resource conflict.

4. The cables for the new external device are loose or the power cables are unplugged. Check all cables, and check that pins in the cable or connector are not bent down.

5. The power switch for the new external device is not turned on. Turn off the computer, turn on the external device, and then turn the computer on to integrate the new device with the computer.

6. If the drive is a secondary drive that has just been installed on the same controller as the primary drive, verify that the jumpers for both drives are set correctly.

Deskpro Service Reference Guide

F-7

DVD and CD-ROM

Problem Possible Solution

Cannot read compact disc. 1. CD is not properly seated in the drive. Eject the CD, correctly seat it

in the drive, then reload.

2. CD has been loaded upside down. Eject the CD, turn it over, then reload.

System will not boot from CD-ROM or DVD drive.

Cannot eject compact disc (tray-load unit).

Cannot eject compact disc (slot-load unit).

CD-ROM or DVD device is not detected; driver is not loaded.

Movie will not play in the DVD drive

1. The CD-ROM or DVD boot is not enabled through the Computer Setup utility. Run the Computer Setup utility and set the drive priorities.

2. Ensure that drive cabling and jumpers are set correctly. To boot a SCSI drive, the drive ID number must be set to 0.

CD is not properly seated in the drive. Turn off the computer and insert a thin metal rod into the emergency eject hole and push firmly (a straightened paper clip can be used). Slowly pull the tray out from the drive until the tray is fully extended, then remove the CD.

1. Remove the drive from the chassis.

2. Remove the front bezel from the drive.

3. Remove the top and bottom drive covers.

4. Release the clamping mechanism to retrieve the CD.

CD-ROM or DVD drive is not connected properly or not properly terminated. Open the computer and check the drive cable.

Movie may be regionalized for a different country. Refer to the documentation that came with the device.

F-8

Troubleshooting Without Diagnostics

Memory

Problem Possible Solution

System won't boot or does not function properly after installing additional memory modules

Out of Memory error. 1. Memory configuration may not be set up correctly; check memory

Memory module is not the correct type or speed grade for the system. Replace module with the correct industry-standard device for the computer.

configuration using Device Manager.

2. The computer has run out of memory for the application. Check the application documentation to determine the memory requirements.

Memory count during POST is wrong.

Insufficient memory error during operation.

Memory modules may not have been installed correctly or incorrect modules may have been used.

1. Too many Terminate and Stay Resident programs (TSRs) are installed. Delete any unnecessary TSRs.

2. There is not enough memory for the application. Check the memory requirements for the application or add more memory.

Deskpro Service Reference Guide

F-9

Network

Some common causes and solutions for network problems are listed in the following table. These guidelines do not discuss the process of debugging network cabling.

Problem Possible Solution

The Remote Wakeup feature is not functioning.

1. The feature is not available when using an AUI network connection; use an RJ-45 network connection.

2. Remote Wakeup is not enabled. Use the network control application to enable Remote Wakeup.

Network driver does not detect network controller.

Network status link light does not turn on or flashes.

Diagnostics reports a failure. 1. The cable is not securely connected or is attached incorrectly.

Network controller is disabled. Run Computer Setup and enable network controller.

1. No active network is detected. Check cabling and network equipment for proper connection.

2. Network connection is not set up properly. Use the network control application to verify that the device is working properly.

3. System is configured for AUI connection; link LED does not apply to AUI connections.

4. Network driver is not properly loaded. Reinstall network drivers.

5. System cannot autosense the network. Disable autosensing capabilities and force the system into the correct operating mode.

Ensure that the cable is securely attached to the network connector and that the other end of the cable is securely attached to the correct device.

2. There is a problem with the cable or a device at the other end of the cable. Ensure that the cable and device at the other end are operating correctly.

3. The network controller is defective. Replace the controller or the system board.

4. Network controller interrupt is shared with an expansion board. Under the Computer Setup Advanced menu, change the resource settings for the board.

F-10

Diagnostics passes, but the computer does not communicate with the network.

Troubleshooting Without Diagnostics

1. Network drivers are not loaded, or driver parameters do not match current configuration. Make sure the network drivers are loaded and the driver parameters match the configuration of the network controller.

2. The network controller is not configured for this computer. In Windows 95, 98, or Windows NT, select the Network icon at the Control Panel.

3. Network controller interrupt with an expansion board. Under the Computer Setup Advanced menu, change the resource settings for the board.

continued

Network Problem

Continued

Problem Possible Solution

Network controller stopped working when an expansion board was added to the computer.

1. Network drivers are not loaded or driver parameters do not match the current configuration. Make sure that the drivers are loaded and that the driver parameters match the configuration of the network controller.

2. The cable is not securely connected or is attached incorrectly. Ensure that the cable is securely attached to the network connector and that the other end of the cable is securely attached to the correct device.

3. Network controller interrupt is shared with an expansion board. Under the Computer Setup Advanced menu, change the resource settings for the board.

4. Network drivers were accidentally deleted when the drivers for the new expansion board were installed, or the files containing the network drivers are corrupted. Reinstall the network drivers, using backup diskettes.

Network controller stopped working without apparent cause.

Cannot connect to the network server when attempting Remote System Installation.

1. The files containing the network drivers are corrupted. Reinstall the network drivers, using backup diskettes.

3. The network controller is defective. Replace the network controller or system board.

The network controller is not configured properly. Run Computer Setup and modify the Embedded NIC Settings.

Deskpro Service Reference Guide

F-11

Resolving Audio Hardware Conflicts

Hardware conflicts occur when two or more peripheral devices contend for the same signal lines or channels. Conflicts between the audio interface and another peripheral device may be due to the settings of the base I/O addresses, interrupts, or DMA channels. The audio interface typically has the following settings:

Item Setting

Base I/O address 220H FM Synthesizer I/O address 388-38Bh Interrupt IRQ 5 8-bit DMA Channel 1

To resolve hardware conflicts:

Change the hardware settings of your audio card or the peripheral card in your system if the

1. peripheral card is using the audio interface setting. You can change settings for integrated audio using Computer Setup.

If you are unsure of the settings of the peripheral cards, you can isolate the source of the

2. problem by temporarily removing all cards and other essential cards such as the disk controller. After that, add the cards back one at a time until the card that is causing the conflict is found.

Problem Possible Solution

Sound does not come out of the speaker.

Software volume control is turned down electronically, or CD-ROM volume control on the front or back of the computer is turned down.

Double click on the speaker icon located on the taskbar, then set the volume by adjusting the volume slider.

Troubleshooting Using Compaq Intelligent Manageability Features

The Local Alert Pop-Up Dialog notifies you of an impending or actual hardware failure. If the computer is connected to a network and the Compaq Insight Management Agents are installed and configured, an Simple Network Management Protocol (SNMP) trap (message) is sent to the specified SNMP-compliant management application.

The Local Alert Pop-Up Dialog also tells you the steps you need to take prior to a hardware failure to avoid loss of data and damage to the computer. The system administrator can create a customized action message that might include contact telephone or pager numbers.

To close the Local Alert Pop-Up Dialog, click the Close button. To retrieve fault information after closing the dialog, run Compaq Insight Personal Edition.

For more detailed information, refer to the online

Intelligent Manageability Guide

F-12

Troubleshooting Without Diagnostics

appendix

YSTEM BOARD AND RISER BOARD REFERENCE

ESIGNATORS

Designator Component

E49 Clear Password header E50 CMOS header E51 Video pass through header

J6 BNC J7 RJ-45 Jack J8 IEEE 1394

J10 - 19 ISA slots

J20 -29 PCI slots

J30 Riser board

J31 - J35 Device bay connectors

J40 AGP J50 First parallel port J51 Second parallel port J52 Double-stacked parallel port

Top Port B Bottom Port A

J55 Double-stacked serial port

Top Serial B

Bottom Serial A J66 Keyboard connector (Closest to monitor connector) J67 Mouse connector J68 Double-stacked mouse/keyboard connector

Top Mouse

Bottom Keyboard J69 Video connector J70 Single USB connector J71 Double-stacked USB J72 Microphone jack J73 Line-in jack

continued

Deskpro Service Reference Guide

G-1

Reference Designators

Continued

Designator Component

J74 Line-out jack J75 Headphone jack J76 Volume control J77 Double-stacked headphone/microphone connector

Top Microphone Bottom Headphone

J78 Double-stacked line-in/line-out connector

Top Line in

Bottom Line out P1 P/S connector P2 Second P/S connector (as required) P3 Third P/S connector (as required) P5 Main Power HDD LED connector P6 Speaker connector P7 Audio connector (from CD-ROM P8 Second fan connector P9 WOL connector (NIC cable)

P10 Diskette drive connector P11 Second Audio connector P15 AUI connector P20 Primary IDE connector P21 Secondary IDE connector P22 CD-ROM connector

P25 - P26 Video memory upgrade connector

P30 Primary SCSI connector P31 Secondary SCSI connector P53 First serial port P54 Second serial port P70 Processor fan header P89 Floating Serial Port Connector

P100 ITP connector

SW50 Clear CMOS switch

XMM1 Memory slot. The first slot populated (DIMM1 or RIMM1) and tested.

XMM2 - XMM5 Following memory slots

XU1 Primary processor socket XU2 Secondary processor socket

XU15 ROM socket

G-2

System Board and Riser Board Reference Designators

appendix

ODEL NUMBER NAMING

The following is an example of the 21-character model number information.

END/P333/10a/5/128c/n

Platform/Family

EN EP

Form Factor

- Small Form Factor

- Desktop

- Minitower

- Convertible

blank

Processor Type

- Celeron

- Pentium

Processor Speed, MHz

Hard Drive Capac it y

10 13

- 10.0 GB

- 13.5 GB

Operating System

- Win NT 4.0

- Win 95

- Win 98

Core Logic (chip set)

- BX

blank

- 810

MB RAM

64 128

NIC (EN only)

blank

- no NIC

Removable Storage

- none

blank

- CD-ROM

- NIC

Deskpro Service Reference Guide

H-1

Index

additional documentation, viii

backup diskettes, ordering, 2-9 broken key icon, 3-4

Computer Checkup (TEST),

2-6

Computer Setup

replicating, 3-13

Computer Setup Utilities

using, 2-2

device drivers

install or upgrade, 1-2 diagnostic tests, 2-9 diagnostics diskette, 2-6

emergency repair diskette, 1-2 Enhanced Compaq Insight

Personal Edition, 2-8 Enhanced Support Software

CD, 3-14 error checking and correcting

(ECC)

fault prediction, 3-8

prefailure warranty, 3-8

FailSafe Boot Block ROM,

3-10 FailSafe key, 3-7 fault prediction, 3-7

icon,broken key, 3-4 INSPECT.

Information

install or upgrade device

drivers, 1-2

See

View System

keyboard

light combinations, 3-11

Microsoft Windows NT,

installing, 1-1

Microsoft Windows,

installing, 1-1

network

service boot, 3-2

operating system, installing,

1-1

password

delete, 3-5 establish, 3-3 power-on, 3-4

setup, 3-3 power button, dual state, 3-13 Power Management, 3-13 prefailure warranty, 3-7 protecting software, 2-9

registering the computer, 1-3 remote

ROM flash, 3-9 Security Management, 3-12 System Installation, 3-1 Wakeup and Shutdown, 3-12

security features, 3-2 Smart Cover Lock, 3-6 Smart Cover Sensor,protection

level, 3-6

software

protecting, 2-9 recovery, 2-10

Support Software CD

ordering, 3-14

symbols and conventions, vii

technician notes, vii

See

TEST. thermal sensor, 3-8

Computer Checkup

Ultra ATA integrity

monitoring, 3-8

View System Information

(INSPECT), 2-6

Index

I-1

HP Compaq Deskpro E 2-12e, Compaq Deskpro E 3-20e, Compaq Deskpro E 3-25e, Compaq Deskpro I 3-25i, Compaq Deskpro I 3-33i Service and Maintain

Specifications and Main Features

Frequently Asked Questions

User Manual

Notice

Contents

Symbols and Conventions

Technician Notes

Additional Documentation

1.1 Microsoft Windows 95 or 98

1.2 Microsoft Windows NT Workstation 4.0

1.3 Registering the Computer

1.4 Compaq Software

2.1. Computer Setup Utilities

2.2 Computer Diagnostics

2.3 Protecting Your Software

2.4 Unique Universal Identification (UUID)

3.1 Initial Configuration and Deployment

3.2 Asset Tracking and Security

3.3 Fault Notification and Recovery

3.4 Software Updating and Management

3.5 Building Blocks and Partners

Enhanced Keyboard

Mouse

Ethernet BNC

Ethernet RJ-45

Ethernet AUI

Parallel Interface

Serial Interface

USB Connector

Microphone Connector

Headphone Connector

Line-In Audio

Line-Out Audio

External Infrared Transceiver

IDE/EIDE Drive Cable

Slimline CD-ROM Adapter

AGP Connector

Ultra SCSI

IDE CD-ROM Cable

14-Pin Power Connector

20-Pin Power Connector - Deskpro EP

20-Pin Power Connector - Deskpro EN

24-Pin Power Connector

General Requirements

Country-Specific Requirements

Device 0/Device 1 Relationship

SMART

Automatic Soft-Drive Types

Preliminary Checklist

Solving Minor Problems

Diskette Drive

Display

SCSI

Printer

Hard Drive

Hardware Installation

DVD and CD-ROM

Memory

Network

Resolving Audio Hardware Conflicts

Troubleshooting Using Compaq Intelligent Manageability Features

Index
