HP Color LaserJet CM6040 MFP series
See productivity soar with this high performing Color LaserJet MFP. Create A3 colour documents with excellent line and image quality. Enjoy fast print speeds; print, copy, scan, fax1and digital sending functionality plus exceptional ease of use.
HP Color LaserJet
CM6040 MFP
HP Color LaserJet
CM6040f MFP
Ideal for workgroups (of 6 to 15 users) and departmental environments (up to 20 users) within large and medium enterprise managed office environments who need print, copy, scan, fax and digital sending functionality, up to A3 format as well as high quality colour capabilities to produce a range of internal and external business communications.
Boost workgroup productivity with fast print speeds, more functionality and outstanding performance.
Increase output with speeds of up to 40 ppm in colour and black, with a first page printed in around 12 seconds. Process complex documents quickly with an 835 MHz Microprocessor and 512 MB memory expandable up to 1 GB. Capture documents electronically
and speed up workflows with scan-to e-mail, printer, network folder and fax2. Enjoy peace of mind with a variety of security solutions including job authentication, encryption and network protection.
Exceptionally easy to use and manage with an intuitive design and touch screen control panel.
Find applications quickly and experience consistency with the Easy Select3control panel’s intuitive display. Feature and device management compatibility across your MFP fleet ensures ease of use. Cut costs and save time with HP Web Jetdadmin 10.0 fleet management software: install, configure and manage remotely, automate routine tasks and track supplies usage. Extend your MFP’s capabilities: streamline workflows with advanced solutions like integrated capture, job accounting and security.
Achieve outstanding results with superior colour accuracy and excellent output quality.
Create high quality colour documents up to A3 that make a big impact with HP ImageREt 4800. Get exceptional line acuity with up to 1200x600 dpi operating mode, ideal for detailed plans and architectural drawings. Ensure superior colour accuracy with support for colour matching standards and Pantone certification. Produce reliable, consistent, high gloss, colour print quality with improved HP ColorSphere toner. Advanced paper handling options include a booklet maker and a stapler/stacker.
1
Optional accessory Please purchase separately Available as standard with HP Color LaserJet CM6040f MFP.
2
Optional accessory Please purchase separately Available as standard with HP Color LaserJet CM6040f MFP
3
Buyer's Lab gave HP a "Pick of the Year" award in December 2006 for Outstanding Achievement for the User Interface Design of its Multifunction Printers.
HP Color LaserJet CM6040 MFP series
Series at a glance
HP Color LaserJet CM6040 MFP
Print and copy speed up to 40ppm A4 and 20ppm A3
Effective output quality with up to 1200 x 600 dpi and ImageREt4800
600x600 dpi scan resolution
512MB RAM expandable to 1GB
80GB Hard Disk drive capacity
835MHz processor
Automatic two-sided printing
50-sheet Automatic Document Feeder (ADF)
Input capacity of 1100-sheet from 100-sheet MP tray and 2 x 500-sheet
trays
Standard 500-sheet output capacity
Colour Access Controls
Recommended accessories
HP Color LaserJet CM6040f MFP
Base model plus: analog fax
Input capacity of 2100-sheet with the addition of 2 x 500-sheet trays
CB458A
HP Color LaserJet CB458A 220V Fuser Kit
CC516A
HP Color LaserJet CM6000 Series Booklet Maker
CB459A
HP Color LaserJet CB459A Roller Kit
T1936AA
HP Digital Sending Software 4
CB463A
HP Color LaserJet CB463A Imaging Transfer Kit
Q3701A
HP LaserJet MFP Analog Fax Accessory 300
J7961G
HP Jetdirect 635n IPv6/IPsec Internal Print Server (EIO, 10/100/1000TX)
C6518A
HP USB Cable, 2m
C8091A
HP Staple Cartridge
CE487A
HP CM6000 MFP Series ADF Roller Kit
CC517A
HP Color LaserJet CM6000 Series Stapler/Stacker
CC383A
HP Staple Cartridge Booklet Maker (2 x 2000 staples)
Operating and warranty specifications
Operating environment
Certifications
Warranty
Operating temperature: 15 to 27° C. Recommended operating temperature: 15 to 27° C. Operating humidity: 10 to 80% RH. Operating humidity recommended: 30 to 70% RH. Storage temperature: 0 to 35° C. Storage humidity: 35 to 85% RH. Noise level per ISO 9296: sound power: LwAd 6.8 B(A) (active/printing), 7.3 B(A) (active/copy or scan), 4.3 B(A) (ready). Sound pressure: LpAm 56.8 dB(A) (active/printing), 57.1 B(A) (active/copy or scan), 40.3 dB(A) (ready)
CISPR 22: 2005/EN 55022: 2006 Class B, EN 61000-3-2: 2000 +A2, EN 61000-3-3: 1995+A1, EN 55024: 1998+A1 +A2, FCC Title 47 CFR, Part 15 Class B (USA), ICES-003, Issue 4, (Canada), GB9254-1998, EMC Directive 2004/108/EC with CE Marking (Europe), other EMC approvals as required by individual countries . Regulatory standards: IEC 60950-1 (International), EN 60950-1 +A11 (EU), IEC 60825-1+A1+A2, UL/cUL Listed (US/Canada), GS License (Europe), EN 60825-1+A1+A2 Class 1, 21 CFR Ch. 1/SubCh. J and Laser Notice#50 (July 26th 2001)(Class 1 Laser/LED Device) GB4943-2001, Low Voltage Directive 2006/95/EC with CE Marking (Europe). Other safety approvals as required by individual countries . ENERGY STAR: Yes
1 year Next Business Day On-Site standard
Ordering information
HP Color LaserJet CM6040 MFP (Q3938A)
HP Color LaserJet CM6040 MFP, CD Assembly (Driver/User Guide), Digital Sending Software (DSS) Trial Version CD, Getting Started Guide, Wall Poster with Helpful Tips, Telephone Support Flyer, Power Cords, Control Panel Overlays, and the Cyan, Magenta, Yellow and Black Toner Cartridges already installed within the device.
Accessories, Supplies and Support
CB383A
Accessories
CB458A CB459A CB463A C8091A CC517A CC516A T1936AA Q3701A CE487A CC383A
Supplies
CB390A
CB381A
CB382A
HP Color LaserJet CB458A 220V Fuser Kit
HP Color LaserJet CB459A Roller Kit
HP Color LaserJet CB463A Imaging Transfer Kit
HP Color LaserJet CM6000 Series Stapler/Stacker
HP Color LaserJet CM6000 Series Booklet Maker
HP LaserJet MFP Analog Fax Accessory 300
HP Staple Cartridge Booklet Maker (2 x 2000 staples)
HP Color LaserJet CB390A Black Print Cartridge with
standard pages. Declared yield value in accordance
HP Color LaserJet CB381A Cyan Print Cartridge with
Average continuous composite Cyan/Yellow/Magenta
Cartridge yield 21,000 standard pages. Declared yield
HP Color LaserJet CB382A Yellow Print Cartridge with
Average continuous composite Cyan/Yellow/Magenta
Cartridge yield 21,000 standard pages. Declared yield
HP CM6000 MFP Series ADF Roller Kit
Average continuous Black Cartridge yield 19,500
value in accordance with ISO/IEC 19798*
value in accordance with ISO/IEC 19798*
HP Staple Cartridge
HP Digital Sending Software 4
ColorSphere Toner
with ISO/IEC 19798*
ColorSphere Toner
ColorSphere Toner
HP Color LaserJet CB383A Magenta Print Cartridge with
Average continuous composite Cyan/Yellow/Magenta
Cartridge yield 21,000 standard pages. Declared yield
CB384A
CB385A
CB386A
CB387A
value in accordance with ISO/IEC 19798*
HP Color LaserJet CB384A Black Imaging Drum
HP Color LaserJet CB385A Cyan Imaging Drum
HP Color LaserJet CB386A Yellow Imaging Drum
HP Color LaserJet CB387A Magenta Imaging Drum
Connectivity
J7961G
C6518A
HP Jetdirect 635n IPv6/IPsec Internal Print Server (EIO,
HP Color LaserJet CM6040f MFP (Q3939A)
HP Color LaserJet CM6040f MFP, fax cable
ColorSphere Toner
35,000 pages*
35,000 pages*
35,000 pages*
35,000 pages*
10/100/1000TX)
HP USB Cable, 2m
Service & support
UJ165A/E HP Care Pack, Next Business Day On site Response, 3
years UJ169E HP Care Pack, Same Business Day On site Response, 4-Hour, 13x5, 3 years UJ166E HP Care Pack, Next Business Day On site Response, 4 years UJ167E HP Care Pack, Next Business Day On site Response, 5 years UJ174PE HP Care Pack, Post Warranty, Next Business Day On site Response, 1 year UJ176PE HP Care Pack, Post Warranty Same Business Day On site Response, 4-Hour, 13x5, 1 year
For a complete list of supplies, accessories and services, please refer to http://www.hp.com For workflow, device management and other solutions, please visit the Global Solutions catalog: www.hp.com/go/gsc
Technical specifications
Print technology Print speed
Processor Memory
Print
Fax
Digital sending
Scan
Copy
Media handling Input: Capacity Weight Size
Media types Interface and connectivity
Operating systems compatibility
Network operating systems compatibility
Minimum system requirements
Standard software
Control panel Power
Dimensions (w x d x h) Weight Printer management
Laser A3: Up to 20 ppm . A4: Up to 40 ppm. First page out black: < 11.5 sec (from ready) Colour: < 11.5 sec (from ready). Warm-up time: less than 112 sec
Exact speed varies depending on the system configuration, software program and document complexity. 835 MHz . PMC-Sierra RM7965 64-bit Microprocessor 512 MB. Expandable to 1GB via one DDR SODIMM slot: 128 MB (Q7557A), 256 MB (Q7558A), 512 MB (Q7559A), all memories being 167 MHz 200-pin DDR DIMM.. Hard Disk
Capacity: Standard, 80 GB Quality HP ImageREt 4800
Resolution Up to 1200 x 600 dpi Printer languages HP PCL 5, HP PCL 6, HP Postscript level 2 emulation (default), HP Postscript level 3 emulation is supported Economical printing Two-sided printing and N-up printing/copying (saves paper), Colour Access Control (printing/copying in black saves toner) Typefaces/fonts Set of 80 HP fonts (plus Greek, Hebrew, Cyrillic, Arabic) Recommended monthly page volume Print margins (mm) Top: 4.2 mm . Left: 4.2 mm . Right: 4.2 mm . Bottom: 4.2 mm
Modem speed 13 sec per page Telecom compliance ES 203 021, R&TTE Directive 1999/5/EC (Annex II) with CE Marking (Europe), FCC Part 68, Industry Canada CS03, NOM-151-SCTI-1999 (Mexico),
Fax resolution Standard: 100 x 100 dpi. Superfine: 300 x 300 dpi File formats PDF, JPEG, TIFF, or MTIFF. (OCR supports PDF, TEXT, RTF (Microsoft® Word® Compatible), XML, HTML; send to workflow (DSS) supported file types include
Installation Fast Ethernet, Gigabit Ethernet, 802.11b wireless Features Standard: Scan to folder (includes shared address book for fax), scan direct to e-mail server, send to e-mail, analog fax, LDAP e-mail addressing;
Type Flatbed, ADF . Colour scanning: Yes Scan resolution Optical: Up to 600 dpi Grey scale levels 256 Scannable area Minimum media size: Flatbed: No Minimum, ADF: 127 x 127 mm. Maximum media size: 297 x 432 mm Margins for scanned items Left: 4.2. Top: 4.2. Right: 4.2. Bottom: 4.2
Copy speed Up to 40 cpm Copy resolution Up to 600 x 600 dpi Multiple copies Up to 999 Reduce/enlarge 25 to 200%
Tray 1 sheets 100, envelopes 10 60 to 220 g/m² A3, A4, A4-R, A5, A6, RA3, SRA3, B4 (JIS), B5
Tray 2 sheets: 500 60 to 220 g/m² A3, A4, A4-R, A5, B4 (JIS), B5 (JIS), 8K, 16K; 148
Tray 3 sheets: 500 60 to 220 g/m² A3, A4, A4-R, A5, RA3, SRA3, B4 (JIS), B5 (JIS),
ADF sheets: 50 60 to 220 g/m² A3, A4, B4, B6
Output:
Duplex printing: Automatic (standard) Paper (bond, recycled, glossy, mid-weight, heavy, heavy glossy, extra heavy, extra heavy glossy, tough, rough), transparencies, labels, envelopes, cardstock Hi-Speed USB (compatible with USB 2.0 specifications) device port, one open EIO slot, HP Jetdirect Gigabit Ethernet embedded print server, fax port, Foreign Interface Harness (FIH) port,
PCI express. Optional: HP Jetdirect EIO internal print servers, HP Jetdirect external print servers, wireless print server, printer adapter Microsoft® Windows® 2000, XP, Server 2003; Windows Vista®; Mac OS X v10.2.8, v10.3, v10.4 and higher. Updated drivers and other valuable product information for the HP Color
LaserJet CM6040 MFP will be available on the HP Customer Care Web site http://www.hp.com/support Microsoft® Windows® 2000, Server 2003, XP, 2003 64-bit, XP 64-bit; Windows Vista®, 64-bit (For Microsoft® IPv6 compatible with Microsoft® Windows® 2003, XP, and Windows
Vista®); Novell® 5.1 or higher; Mac OS X v10.2, v10.3, v10.4 or higher; RED HAT Linux 7.x or higher; SUSE Linux 8.x or higher; HP-UX 10.20, 11.x, 11.i; Solaris® 2.5 or higher (SPARC® systems only); IBM® AIX 3.2.5 or higher 1; MPE-iX; Citrix® MetaFrame Server; Windows® Terminal Services
Microsoft® Windows® 2000: 333 MHz processor with 64 MB RAM; Microsoft® Windows® XP: 333 MHz processor with 128 MB RAM; Microsoft® Windows® Server 2003: 550 MHz processor with 128 MB RAM; Windows Vista®: 800 MHz processor with 512 MB RAM; CD-ROM/DVD drive, Internet connection, USB or network port connection. Mac OS X v10.2.8, v10.3, v10.4 and higher with 128 MB RAM, CD-ROM, 160 MB of free hard disk space (For Mac OS v10.4 and higher, PowerPC and Intel® Core Processor Macs are supported)
Print drivers and installation software on CD-ROM: HP common installer, HP Internet installer, HP common drivers, HP Installation Wizard, Postscript Printer Description (PPD) files, Printer Dialog Extensions (PDEs), HP Printer Utility for use with Macintosh computers
5 LED indicator lights, 10-key numeric pad, graphical touch screen display (192 x 72 mm) 640 x 240 resolution with adjustable contrast Requirements: Input voltage 110 to 127 VAC (+/- 10%), 50/60 Hz (+/- 2 Hz), 10.5 amp; 220 to 240 VAC (+/- 10%), 50/60 Hz (+/- 2 Hz), 5.5 amp. Consumption: 881 watts maximum
(active/printing), 920 watts maximum (active/copy or scan), 230 watts maximum (ready), 208 watts maximum (sleep1), 24.5 watts maximum (sleep2), 0.24 watts maximum (off); Typical Electricity Consumption (TEC): 15.24 kWhr/Week*
Out of package: CM6040: 704 x 635 x 1194 mm; CM6040f: 704 x 635 x 1194 mm. Packaged: CM6040: 935 x 800 x 1439 mm; CM6040f: 935 x 800 x 1439 mm Out of package: CM6040: 139.87 kg; CM6040f: 144.91 kg. Packaged: 156 kg HP Toolbox, HP Web Jetadmin, HP Embedded Web Server
8000 to 15000
PTC-200 (New Zealand), AS/ACIF S002: 2001 (Australia), IDA PSTN1 (Singapore), TPS002-01 (Malaysia), IG 0005-11 (Taiwan), HKTA 2011 (Hong Kong SAR), YD514, YD/T589, YD703, GB3382 (China), other Telecom approvals as required by individual countries
XML, searchable PDF, TXT, RTF (Microsoft® Word® Compatible), HTML, PDF, JPEG, TIFF, and MTIFF
authentication: Windows® negotiated (Kerberos and NTLM), group 1 and group 2 PIN, LDAP, authentication manager. Optional: Advanced digital sending capabilities via optional HP Digital Sending Software
(JIS), B6 (JIS), 8K, 16K, D postcard, envelopes (#9, #10, Monarch, B5, C5, C6, DL); 99 x 140 mm to 320 x 457 mm
x 210 mm to 297 x 432 mm
8K, 16K; 148 x 210 mm to 320 x 457 mm
Sheets: Up to 500
http://www.hp.com/uk
© Copyright 2008 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP Products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
Published in EMEA 02/08 4AA1-3943EEE
