HP DDS-DC, C1536A User Manual

HP DDS-DC T
User’s Guide
ape Drive
Workstation Systems Group
Order No. A1658–90696
Edition E0796
Printed in U.S.A.
Hewlett-Packard Co. 1996
First Printing: July 1996
UNIX
is a registered trademark in the United States and other countries, licensed exclusively
X/Open Company Limited.
NOTICE
The information contained in this document is subject to change without notice.
HEWLETT–PACKARD MAKES NO WARRANTY OF ANY KIND WITH REGARD TO THIS MATERIAL INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Hewlett-Packard shall
be liable
not
for errors contained herein or for incidental or consequential damages in connection with
the furnishing, performance or use of this material.
through
Hewlett-Packard
assumes no responsibility for the use or reliability of its software on equipment that is
not furnished by Hewlett-Packard.
This
document contains proprietary information which is protected by copyright. All rights reserved.
No
part of
this document may be photocopied, reproduced or translated to another language without the
prior written consent of Hewlett-Packard Company.
RESTRICTED RIGHTS LEGEND. Use, duplication, or disclosure by government is subject to restrictions
as set forth in subdivision (c) (1) (ii) of the Rights in T
echnical Data and Computer Software
Clause at DFARS 252.227.7013. Hewlett-Packard Co., 3000 Hanover St., Palo Alto, CA 94304.
10 9 8 7 6 5 4 3 2 1
Contents
Preface
Audience vii. Safety and Regulatory Statements viii Installation Notice ix
Related Manuals x. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Revision Historyx. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Questions, Suggestions, or Problems xi
Documentation Conventionsxi. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 1 Introduction
General Description 1–2.
DDS-DC Drive Environmental Requirements 1–3 DDS-DC Drive Physical Specifications 1–5
Preparing to Install the DDS-DC Drive 1–6
T
ools Required Verifying Kit Contents 1–6 Operating System Support 1–6 Setting the SCSI-2 Address 1–7 Address Jumpers
Preparing the System 1–11
SCSI-2 Connection and Termination 1–13
Powering Off the Workstation and Any Peripherals 1–14 Adding or Removing the DDS-DC Drive Bezels or Expansion Brackets 1–15
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1–6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1–8
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . .
iii
Contents
Chapter 2 Using the DDS-DC Drive
Your DDS-DC Drive Configuration 2–2. Controls and Features of the DDS-DC Drive 2–2
LEDs 2–3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Data Cassettes
Media Life 2–3 Cleaning the T Media Restrictions Setting the Write-Protect T
Using the DDS-DC Drive 2–6
Loading and Unloading a Data Cassette 2–6 Verifying the DDS-DC Tape Drive Operation 2–7 Media Interchangeability Restrictions Ordering Information 2–8
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ape Heads
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ab on a Data Cassette
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . .
Chapter 3 Troubleshooting and Removal/Replacement Procedures
Troubleshooting 3–2.
Checking the Address Settings for Single-Ended Drives 3–2 Checking the Hardware Installation 3–4 Rechecking the Address Settings Verifying the System Operation Using the Support T
Removal/Replacement Procedures
Field Replaceable Units Powering Off the System 3–9 Removing and Replacing the DDS-DC Drive 3–10 Adding or Removing the DDS-DC Drive Bezels and Expansion Brackets 3–10
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ools Manager
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . .
. . . . . .
2–3
2–4 2–4 2–4
2–8
3–6 3–6 3–9
3–9
Appendix
iv
A
SCSI Connector Pinouts
Figures
Contents
Tables
1–1. HP DDS-DC Drive 1–2. 1–2. HP DDS-DC Drive Physical Specifications 1–5 1–3. Rear View of DDS-DC Drive and SCSI Address/Jumper Settings 1–9 1–4. Switch Settings for Data Compression Mode 1–10 1–5. Adding a Bezel to the DDS-DC Drive 1–15 1–6. Removing a Bezel from the DDS-DC Drive 1–16 1–7 Adding or Removing Expansion Brackets 1–16
2–1. DDS-DC Drive Controls and Indicators 2–2 2–2. Setting the Write-Protect Tab on a DDS Tape 2–5 2–3.
Loading a Data Cassette
3–1. Adding a Bezel to the DDS-DC Drive 3–15 3–2. Removing a Bezel from the DDS-DC Drive 3–15 3–3. Adding or Removing Expansion Brackets 3–16
2–1. LED Display Codes 2–3 2–2. HP DDS Drive Compatibility 2–8
A–1. SCSI Connector Pinouts A–1
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2–6
v
Preface
The HP DDS-DC T the DDS-DC drive.
We’ve organized this guide as follows:
Chapter 1 Provides a general description of the DDS-DC drive and the procedures
Chapter 2 Describes the DDS-DC drive configurations, its controls and features, and
Chapter 3 Provides information on caring for DDS tapes, troubleshooting
Appendix A Lists the pinouts for the SCSI connector on the DDS-DC drive.
Audience
This guide is intended for use by anyone familiar with the the HP workstations who wants to install and configure the DDS drive.
ape Drive User’s Guide
for installing it into a system.
provides directions for using it.
information, and removal/replacement procedures for the DDS-DC drive.
describes how to install, configure, and use
vii
Preface
Safety and Regulatory Statements
See the Owner’s Guide that came with your system for safety informtion.
Emissions Regulations
Federal Communications Commission (FCC)
The Federal Communications Commission of the U.S. government regulates the radio frequency energy emanated by computing devices through published regulations. These regulations specify the limits of radio frequency emission to protect radio and television reception. All HP Apollo nodes and peripherals have been tested and comply with these limits. The FCC regulations also require that computing devices used in the U.S. display the agency’s label and that the related documentation include the following statement:
NOTICE: This equipment has been tested and found to comply with the limits
for a Class A digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.
Canadian Department of Communications (CDC)
This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus as set out in the Radio Interference Requirements of the Canadian Department of Communications.
viii
Preface
Emissions Regulations Compliance
Any third-party I/O device installed in HP system(s) must be in accordance with the requirements set forth in the preceding Emissions Regulations statements. In the event that a third-party noncompliant I/O device is installed, the customer assumes all responsibility and liability arising therefrom.
Electrostatic Discharge (ESD) Precautions
Electrostatic charges can damage the integrated circuits on printed circuit boards. To prevent such damage from occurring, observe the following precautions during board unpacking and installation:
Stand on a static-free mat.
Wear a static strap to ensure that any accumulated electrostatic char
discharged from your body to ground.
Connect all equipment together, including the static-free mat, static strap, routing
nodes, and peripheral units.
Keep uninstalled printed circuit boards in their protective antistatic bags.
Handle
protective antistatic bags.
Installation Notice
Products designated in the applicable Hewlett-Packard price list as customer-installable can be installed by computer-knowledgeable customers who carefully read and follow the instructions provided. Customers who elect to have the product installed by our field personnel are charged the applicable field installation charge, as covered under the standard terms and conditions. For more information, please contact your local sales representative.
ge is
printed circuit boards by their edges, once you have removed them from their
ix
Preface
Related Manuals
For more information, refer to the following documents:
The Owner’s Guide that came with your system
HP-UX Installing Peripherals: HP 9000 Series 700 (B2355–90006)
Using Your HP Workstation (A2615–90003)
HP V
System Administration T
Using HP-UX (B2910–90001)
Documents specific to HP DDS drives:
HP DDS-2 T
Integration Guide, Vol 2 of HP DDS Technical Manual (C1533–90906)
The SCSI Interface, Vol 3 of HP DDS Technical Manual (C1533–90907)
Background
HP
Contact your HP supplier for copies.
Revision History
The revision history for each edition of the manual is listed below:
isual User Envir
ape Drive User
to DDS Pr
DDS Configuration Guide
onment User
asks HP 9000 Series 700 Computers
’s Guide (A1658–90689)
oducts
’s Guide (B1171–90061)
, V
ol 4 of HP DDS T
, V
ol 5 of HP DDS T
(B2355–90040)
echnical Manual (C1533–90908) echnical Manual
(C1533–90915)
Edition E0796 First Printing
x
Revision History
Questions, Suggestions, or Problems
If you have any questions, suggestions, or problems with our hardware, software, or documentation, please call 1–888–301–5932 (U.S. and Canada), or contact the HP Response Center for your country.
Documentation Conventions
Unless otherwise noted in the text, this guide uses the following symbolic conventions:
literal values Bold words or characters in formats and command descriptions
represent commands that you must use literally. Pathnames are also in bold.
Preface
user-supplied Italic words or characters in formats and command descriptions values represent values that you must supply. Italics are also used in
text for emphasis.
screen display Information that the system displays appears in this typeface.
Return
A rectangle with rounded corners and a key label denotes a key on your keyboard. (In this manual we refer to the Return key. On your keyboard the key may be labeled either Return or Enter.)
This symbol indicates the end of a chapter or appendix.
xi
Chapter 1
Introduction
This document describes the HP DDS-DC drive (HP model number C1536A), its installation, operation, troubleshooting, and removal/replacement procedures.
This chapter introduces the DDS-DC drive and contains the following information:
General description of the drive
Preparing to install the drive
Preparing the system
Powering off the workstation and any peripherals
Adding or removing the DDS-DC drive bezels or expansion brackets
1–1
Introduction
General Description
The HP DDS-format drives have been developed by Hewlett Packard for data storage drives that build on DAT technology. The DDS-DC drive has 2-GB native capacity, yielding up to 4 GB of stored data. Figure 1–1 shows the DDS-DC drive.
1–2
Figure 1–1. HP DDS-DC Drive
DDS-DC Drive Environmental Requirements
The DDS-DC drive has the following environmental requirements:
Ambient Temperature
Operating 5_ C to 40_ C
(41_ F to 104_ F)
Non-Operating –40_ C to 70_ C
(–40_ F to 158_ F)
Humidity
Operating 20% to 80%RH (non-condensing) Non-Operating 5% to 95%RH
Maximum wet bulb temperature = 26_ C
Vibration
Operating (3 axes for drives, 1 axis for autoloaders)
Swept Sine 0.3 g peak, 5–500 Hz @ 1 octave/min Random 5–350 Hz @ 0.00053 g HP C1534A/ 350–500 Hz @ –6 dB/octave 36A/53A 500 Hz @ 0.000271 g Random 5–350 Hz @ 0.0002 g HP C1533A/ 350–500 Hz @ –6 dB/octave HP C1537A 500 Hz @ 0.0001 g2/Hz (0.3 g rms)
Non-Operating
Swept Sine 0.75 g peak, 5–500 Hz @ 1 octave/min Random 5–100 Hz @ 0.020 g
100–137 Hz @ –6 dB/octave 137–350 Hz @ 0.0107 g 350–500 Hz @ –6 dB/octave 500 Hz @ 0.0052 g
2
Introduction
2
/Hz
2
/Hz (0.5 g rms)
2
/Hz
2
/Hz
2
/Hz
/Hz (2.41 g rms)
1–3
Introduction
Shock
Operating (3 axes for drives) no performance change 5.0 g peak for 3 ms: half sine Operating (3 axes for drives) no data loss Non-Operating (3 axes) no damage 0 km to 15.2 km (0 to 50,000 ft)
8.0 g peak for 11 ms: half sine
Altitude
Operating 0 km to 4.6 km (0 to 15,000 ft) Non-Operating 0 km to 15.2 km (0 to 50,000 ft)
Transportation
Vibration Type 1 package (3 axes)
Swept Sine 0.5 g peak, 5–200–5 Hz @ 1 octave/min
5 min dwell at peak resonance
Random 5–100 Hz @ 0.015 g
100–200 Hz @ –6 dB/octave 200 Hz @ 0.0038 g (30 min/axis)
Impact Type 1 package
10 vertical impacts (6 faces and 4 bottom package corners from 910 mm height)
2
/Hz
2
/Hz(1.47 g rms)
1–4
Suspended Particles
Operating and Non–Operating Suspended particle environment,
particles <200 microgram/cubic meter
Acoustic Noise Emissions
<5.0 bel soundpower
DDS-DC Drive Physical Specifications
Figure 1–2 describes the physical specifications of the DDS-DC drive.
41.3 mm
+++
(1.61 in.)
Introduction
4 mm (0.15 in.)
101.6 mm (3.96 in.)
21 mm (0.82 in.)
41.3 mm
(1.61 in.)
30.9 mm (1.20 in.)
60 mm
(2.34 in.)
90 mm (3.51 in.)
101.6 mm (3.96 in.)
150 mm (5.85 in.)
5 mm
(0.20 in.)
++
94 mm (3.66 in.)
++
70 mm
(2.73 in.)
3.8 mm
(.15 in.)
Figure 1–2. HP DDS-DC Drive Physical Specifications
1–5
Introduction
Preparing to Install a New DDS-DC Drive
The following information describes how to prepare the DDS-DC drive for installation.
Tools Required
The following tools are needed to install the DDS-DC drive:
#2 Phillips screwdriver
Small needlenose pliers
T10 torx wrench
Verifying Kit Contents
Verify that the kit contains one of each of the following:
1–6
DDS-DC drive (part number 0950–3002) and bezel.
Set of 4 screws (M4x6)
Power adapter cable
SCSI I/O cable
Static strap
HP DDS-DC T
NOTICE: If any contents of your kit are missing, contact your sales
representative.
Operating System Support
The HP DDS-DC drive supports HP-UX 9.01 and later. This drive does not require any patches.
ape Drive User’s Guide
(A1658–90696)
