QuickSpecs

Overview

HP ProBook 4710s Notebook PC

HP ProBook 4710s Notebook PCHP ProBook 4710s Notebook PC

HP recommends Windows Vista® Business

HP recommends Windows Vista® BusinessHP recommends Windows Vista® Business

WLAN antennas

Integrated microphone

Webcam light (works with optional webcam)

Optional 2 MP webcam

Quick Look button

Power button with LED indicator

Stereo speakers

Battery charging LED indicator

Power connector

10.

Optical drive

11.

Optional RJ-11/modem port

12.

(2) USB 2.0 ports

13.

Touchpad with scroll zone

14.

Stereo microphone in

15.

Stereo headphone/line out

16.

Media Card Reader

17.

Wireless switch with LED indicator

18.

Hard drive activity LED indicator

DA - 13252 North America — Version 4 — May 15, 2009

Page 1

QuickSpecs

Overview

ExpressCard/34 slot

(2) USB 2.0 ports

HDMI port

HP ProBook 4710s Notebook PC

HP ProBook 4710s Notebook PCHP ProBook 4710s Notebook PC

VGA connector (external monitor/projector)

RJ-45/Ethernet port

Kensington Lock slot

Battery release latches

Battery bay

DA - 13252 North America — Version 4 — May 15, 2009

Page 2

QuickSpecs

HP ProBook 4710s Notebook PC

HP ProBook 4710s Notebook PCHP ProBook 4710s Notebook PC

Overview

At A Glance

At A GlanceAt A Glance

Genuine Windows Vista Business 32, Genuine Windows Vista Business with downgrade to Windows XP Professional custom installed, Genuine Windows Vista Home Premium 32, Genuine Windows Vista Home Basic 32 and SuSE Linux, Thin, lightweight design starting at 6.8 lb/3.08 kg and 1.26 in/32.0 mm thin at front Widescreen 17.3-inch diagonal LED-backlit HD+ display with 16:9 aspect ratio BrightView optional Flexible wireless connectivity options:

Integrated 802.11 a/b/g/n draft 2.0 wireless LAN module

Bluetooth® 2.0 ATI Mobility Radeon HD 4330 discrete graphics HDMI port for connecting to high-resolution displays Optional optical drives include Blu-ray ROM DVD+/-RW SuperMulti DL LightScribe Drive for high-definition playback and burning custom labels directly to your discs Available with Intel® Core™2 Duo Integrated Media Card Reader Enhanced security features including HP ProtectTools Security Manager, Disk Sanitizer, and HP SpareKey Optional integrated 2 MP webcam Full-sized spill-resistant keyboard with separate numeric keypad Up to 500 GB 5400 rpm hard drive with HP 3D DriveGuard protection Up to 8 GB of 800 MHz DDR2 SDRAM supported, dual channel memory support

DA - 13252 North America — Version 4 — May 15, 2009

Page 3

QuickSpecs

Standard Features

Processors

ProcessorsProcessors

Operating System

Operating SystemOperating System

Intel Core 2 Duo Processor T9600 (2.8 GHz, 6 MB L2 cache, 1066 MHz FSB) Intel Core 2 Duo Processor P8700 (2.53 GHz, 3 MB L2 cache, 1066 MHz FSB) Intel Core 2 Duo Processor P7370 (2.0 GHz, 3 MB L2 cache, 1066 MHz FSB) Intel Core 2 Duo Processor T6570 (2.10 GHz, 2 MB L2 cache, 800 MHz FSB)

NOTE:

Processor speed denotes maximum performance mode; processors will run at lower speeds in

NOTE:NOTE: battery optimization mode.

* Intel's numbering is not a measurement of higher performance.

Preinstalled

PreinstalledPreinstalled

Supported

SupportedSupported Certified

Certified

CertifiedCertified

* Certain Windows Vista product features require advanced or additional hardware. See:

http://www.microsoft.com/windowsvista/getready/hardwarereqs.mspx http://www.microsoft.com/windowsvista/getready/capable.mspx

Advisor can help you determine which features of Windows Vista will run on your computer. To download the tool, visit:

HP ProBook 4710s Notebook PC

HP ProBook 4710s Notebook PCHP ProBook 4710s Notebook PC

Genuine Windows Vista Business 32 Genuine Windows Vista Home Basic 32 Genuine Windows Vista Home Premium 32 Genuine Windows Vista Business with downgrade to Windows XP Professional custom installed SuSE Linux

Genuine Windows Vista Business 64 SuSE Linux Enterprise Desktop 10

http://www.windowsvista.com/upgradeadvisor

*†

and:

for details. Windows Vista Upgrade

Chipset

ChipsetChipset

Graphics

GraphicsGraphics

† Windows Vista Business disk may be included for future upgrade if desired. To qualify for this downgrade an end user must be a business (including governmental or educational institutions) and is expected to order annually at least 25 customer systems with the same custom image.

Mobile Intel PM45 Express Chipset with ICHM9, 1066 MHz front side bus

ATI Mobility Radeon HD 4330 graphics with 512 MB dedicated video memory

- up to 1024 MB HyperMemory* in units with Windows XP and 2 GB or more of system memory

- up to 1280 MB HyperMemory* in units with Windows Vista Business and 2 GB or more of system memory

Microsoft DirectX 10.1 capable

* Indicates 512 MB dedicated video memory and 512 MB shared system memory.

DA - 13252 North America — Version 4 — May 15, 2009

Page 4

QuickSpecs

Standard Features

Display

DisplayDisplay

Memory

MemoryMemory

Internal

InternalInternal

External

ExternalExternal

Standard

StandardStandard

Maximum

MaximumMaximum Dual-channel

Dual-channel

Dual-channelDual-channel

NOTE:

Due to the non-industry standard nature of some third-party memory modules, we recommend

NOTE:NOTE: HP branded memory to ensure compatibility. If you mix memory speeds, the system will perform at the lower memory speed. Full availability of 4 GB or more of memory requires Windows Vista Business 64bit or Linux. With Windows 32-bit operating systems, the amount of usable memory is dependent upon your configuration, so that above 3 GB all memory may not be available due to system resource requirements.

HP ProBook 4710s Notebook PC

HP ProBook 4710s Notebook PCHP ProBook 4710s Notebook PC

17.3-inch diagonal LED-backlit HD+ anti-glare (1600 x 900 resolution)

17.3-inch diagonal LED-backlit HD+ BrightView (1600 x 900 resolution) Up to 32-bit per pixel color depth

VGA

port supports resolutions up to 1600 x 1200 at 75 Hz, and lower

VGAVGA resolutions at up to 100 Hz. HDMI 1.3

HDMI 1.3

HDMI 1.3HDMI 1.3 to 1920 x 1080 resolution and 7-channel audio with one convenient cable (not included).

NOTE:

NOTE:NOTE: and color depth settings.

800 MHz DDR2 SDRAM; two slots supporting dual channel memory 1024 MB or 2048 MB

Upgradeable to 8192 MB with 4096 MB SODIMMs in slots 1 and 2 Maximized dual-channel performance requires SODIMMs of the same size

and speed in both memory slots.

port supports direct connection to high-definition displays with up

Resolutions are dependent upon monitor capability, and resolution

Communications

CommunicationsCommunications

Marvell Ethernet (10/100/1000 NIC) Optional 56K V.92 modem

* The term "10/100/1000" or "Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab for Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/s. For high-speed transmission, connection to a Gigabit Ethernet server and network infrastructure is required.

** Designed for downloads from 56K modem compliant sources. Maximum achievable download transmission rates currently do not reach 56 KB/s, and will vary with line conditions. Modem availability is subject to country regulatory approval.

DA - 13252 North America — Version 4 — May 15, 2009

Page 5

QuickSpecs

Standard Features

Wireless Devices

Wireless DevicesWireless Devices

Support for a broad range of secure, integrated wireless LAN options featuring support for the latest industry standards. Wireless LAN is factory configurable or available as an option to be added later. Integrated Bluetooth is also available (factory configurable only) and can be combined with any of the supported wireless LAN options.

All 802.11 integrated

All 802.11 integratedAll 802.11 integrated wireless LAN options

wireless LAN options

wireless LAN optionswireless LAN options

Intel WiFi Link 5100

Intel WiFi Link 5100Intel WiFi Link 5100

Broadcom 4322AGN

Broadcom 4322AGNBroadcom 4322AGN

802.11a/b/g/draft-n Wi-

802.11a/b/g/draft-n Wi-802.11a/b/g/draft-n WiFi Adapter

Fi Adapter

Fi AdapterFi Adapter HP Integrated Module

HP Integrated Module

HP Integrated ModuleHP Integrated Module with Bluetooth Wireless

with Bluetooth Wireless

with Bluetooth Wirelesswith Bluetooth Wireless Technology

Technology

TechnologyTechnology

* The specifications for 802.11n draft 2.0 are draft specifications and are not final. If the final specifications differ from the draft specifications, it may affect the ability of the notebook to communicate with other 802.11n WLAN devices. In countries where n draft 2.0 is not allowed, this capability is not enabled (Intel 802.11a/b/g only).

HP ProBook 4710s Notebook PC

HP ProBook 4710s Notebook PCHP ProBook 4710s Notebook PC

Wi-Fi certified Wired Equivalent Privacy (WEP) support up to 128-bit keys Wi-Fi Protected Access (WPA) and WPA2 support

802.1x authentication support, including EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP-MSCHAPv2, and LEAP Advanced Encryption Standard (AES) support Dual antennas integrated in the display enclosure

Integrated support for 802.11a, b, g, and n draft 2.0 Cisco Compatible Extensions support Up to 450 mbps data rate

Integrated support for 802.11a, b, g, and n draft 2.0 Cisco Compatible Extensions support Up to 300 mbps data rate

Bluetooth Specification v2.0 compliant Works with a wide range of Bluetooth devices

Keyboard

KeyboardKeyboard

Pointing device

Pointing devicePointing device

Expansion card slots

Expansion card slotsExpansion card slots

The HP spill-resistant keyboard is designed using a Mylar film that minimizes the risk of damage to sensitive components underneath. The 101/102-key compatible keyboard features a full-pitch key layout with desktop keyboard features, such as the isolated inverted-T cursor control keys, editing keys, both left and right control and alt keys, and 12 function keys. US and International key layouts are available. Other features include a full numeric keypad, hotkeys for instant access to power conservation and brightness, and 19.05 x 19.05 mm key pitch (center-to-center spacing).

Touchpad with scroll zone, two pick buttons

ExpressCard/34 slot

ExpressCard/34 slotExpressCard/34 slot Media Card Reader

Media Card Reader

Media Card ReaderMedia Card Reader

* Memory Stick Duo Adapters are required and sold separately. Inserting a Memory Stick Duo Card directly into your notebook could damage the memory card and/or notebook.

Supports ExpressCard/34 (34 mm x 75 mm x 5 mm) card sizes Supports SD (Secure Digital), MMC (MultiMedia Card), Memory Stick,

Memory Stick Pro, Memory Stick Duo*, xD-Picture card

DA - 13252 North America — Version 4 — May 15, 2009

Page 6

QuickSpecs

Standard Features

Storage

StorageStorage

Interfaces

InterfacesInterfaces

Internal Storage Device

Internal Storage DeviceInternal Storage Device

NOTE:

Up to 10 GB is reserved for the system recovery software.

NOTE:NOTE:

HP 3D DriveGuard

HP 3D DriveGuardHP 3D DriveGuard (Windows models only)

Fixed optical drives

Fixed optical drivesFixed optical drives

External monitor

External monitorExternal monitor HDMI

HDMI

HDMIHDMI Stereo microphone in

Stereo microphone in

Stereo microphone inStereo microphone in Stereo headphone/line

Stereo headphone/line

Stereo headphone/lineStereo headphone/line out

out

outout Power connector

Power connector

Power connectorPower connector RJ-11/modem (optional)

RJ-11/modem (optional)

RJ-11/modem (optional)RJ-11/modem (optional) RJ-45/Ethernet

RJ-45/Ethernet

RJ-45/EthernetRJ-45/Ethernet USB 2.0

USB 2.0

USB 2.0USB 2.0 LED status indicators

LED status indicators

LED status indicatorsLED status indicators

HP ProBook 4710s Notebook PC

HP ProBook 4710s Notebook PCHP ProBook 4710s Notebook PC

160/250/320/500 GB 5400 rpm SMART SATA II Hard Drive

The hard drive is mounted directly to the notebook frame, reducing the transmission of shock to the hard drive. Uses three-axis digital motion detection with intelligent sensitivity to help protect the hard drive during normal use from shock and vibration. The digital accelerometer temporarily halts all data transfer and parks the hard drive when abrupt motion is detected.

Blu-ray ROM DVD+/-RW SuperMulti DL LightScribe Drive DVD+/-RW SuperMulti DL LightScribe Drive

One (VGA) One - 1.3 compliant One One

One One One Four Seven

Audio/Visual

Audio/VisualAudio/Visual

High Definition Audio support Integrated stereo speakers Integrated microphone Stereo headphone/line out Stereo microphone in

Optional 2 MP webcam

Supports videoconferencing and still image capture Improved quality for video streaming and still image capture (1600x1200 resolution) Up to 30 frames/sec Fixed focus lens 16-bit true color (camera sensor up to UXGA resolution)

DA - 13252 North America — Version 4 — May 15, 2009

Page 7

QuickSpecs

Standard Features

Software

SoftwareSoftware

Preinstalled software with

Preinstalled software withPreinstalled software with Windows Vista

Windows Vista

Windows VistaWindows Vista

Additional software

Additional softwareAdditional software available from the web

available from the web

available from the webavailable from the web

* 60 day trial period for McAfee Total Protection for Small Business software. Internet access required to receive updates. First update included. Subscription required for updates thereafter.

HP ProBook 4710s Notebook PC

HP ProBook 4710s Notebook PCHP ProBook 4710s Notebook PC

HP Recovery Manager HP Help and Support Center HP ProtectTools Security Manager HP QuickLaunch Buttons Software HP QuickLook 2 HP Wireless Assistant HP 3D DriveGuard Microsoft Office Ready with 60-day Office Professional 2007 Trial Edition (select models) PDF Complete SE Intervideo WinDVD - DVD Player Roxio Creator Business (for optional DVD+/-RW and DVD/CDRW drives) McAfee Total Protection* Synaptics Touchpad Driver Microsoft Windows Live Messenger (select models) Webcam Software (with optional 2 MP webcam)

HP SoftPaq Download Manager

HP Recovery Manager

HP Recovery ManagerHP Recovery Manager

HP ProtectTools Security

HP ProtectTools SecurityHP ProtectTools Security Manager

Manager

ManagerManager

Models shipped with Windows Vista include HP Recovery Manager. HP Recovery Manager enables fast recovery of the factory preinstalled image if the system becomes corrupted or if important system files are accidentally deleted. Up to 10 GB of the hard drive is reserved for the system recovery software.

HP ProtectTools Security Manager is the security platform for business notebooks and desktops. The HP ProtectTools Security Manager is an extensible client security console that delivers enhanced security capabilities through add-on software modules. The following modules are available on the hard drive (also downloadable from the web) and can be configured in Software Setup:

BIOS Configuration for HP ProtectTools Credential Manager for HP ProtectTools Device Access Manager for HP ProtectTools Drive Encryption for HP ProtectTools File Sanitizer for HP ProtectTools Privacy Manager for HP ProtectTools

DA - 13252 North America — Version 4 — May 15, 2009

Page 8

QuickSpecs

Standard Features

Security

SecuritySecurity

Power Supply

Power SupplyPower Supply

Standard Features

Standard FeaturesStandard Features

For more information on HP security solutions refer to:

External 90-watt Smart AC adapter 6-foot (1.8-meter) power cord included; total length including external AC adapter is 12 feet (3.66 meter) HP Fast Charge

* HP Fast Charge recharges your battery up to 90% within 90 minutes when the system is off.

HP ProBook 4710s Notebook PC

HP ProBook 4710s Notebook PCHP ProBook 4710s Notebook PC

HP ProtectTools Security Manager Easy Setup Wizard One Step Login Enhanced Pre-Boot Security HP SpareKey Disk Sanitizer Configuration Control Hardware Memory Change Alert Ownership Tag Setup Password Power-On Password HP 3D DriveGuard (Windows models only) Kensington Lock Slot Support for Computrace / LoJack for Laptops (must be purchased separately)

http://www.hp.com/go/security

Battery

BatteryBattery

Battery Life

Battery LifeBattery Life

System Standby Time

System Standby TimeSystem Standby Time

Power Conservation

Power ConservationPower Conservation

Primary battery

Primary batteryPrimary battery

Primary battery

Primary batteryPrimary battery

NOTE:

The listed battery life measurements were taken on models running Microsoft Windows Vista.

NOTE:NOTE: Battery life will vary depending on the product configuration, product model, applications loaded on the product, power management settings of the product, and the product features used by the customer. As with all batteries, the maximum capacity of this battery will decrease with time and usage.

Up to 1 week

Supports enhanced Intel SpeedStep technology with Intel Core 2 Duo (allows Battery Optimized Mode, Maximum Performance Mode, or Automatic mode)

ATI PowerPlay technology Hibernation Standby ACPI compliance

8-cell (63 WHr) Li-Ion battery

Up to 4 hours and 30 minutes

DA - 13252 North America — Version 4 — May 15, 2009

Page 9

QuickSpecs

Standard Features

Service and Support

Service and SupportService and Support

Select Model(s)

Select Model(s)Select Model(s)

4710s

4710s4710s FM850UT#ABA Smart Buy

HP Services offers limited 3-year, 1-year and 90-day warranty options depending on country; 1-year limited warranty on primary battery. Warranty upgrades are also available. HP Care Pack Services extend service contracts beyond the standard warranties. To choose the right level of service for your HP product, use the HP Care Pack Services Lookup Tool at: Additional HP Care Pack Services information by product is available at:

http://www.hp.com/hps/carepack

NOTE:

Certain restrictions and exclusions apply. Consult the HP Customer Support Center for details.

NOTE:NOTE:

http://h20000.www2.hp.com/bizsupport/TechSupport/ProductRoot.jsp

Processor

ProcessorProcessor

Operating System

Operating SystemOperating System

Chipset

ChipsetChipset System Memory

System Memory

System MemorySystem Memory Hard Drive

Hard Drive

Hard DriveHard Drive Display

Display

DisplayDisplay Graphics

Graphics

GraphicsGraphics

Audio

AudioAudio

Integrated Web Cam

Integrated Web CamIntegrated Web Cam Communications

Communications

CommunicationsCommunications

Integrated Wireless

Integrated WirelessIntegrated Wireless

Pointing Device

Pointing DevicePointing Device Optical Drive

Optical Drive

Optical DriveOptical Drive Battery

Battery

BatteryBattery Power

Power

PowerPower Warranty

Warranty

WarrantyWarranty

HP ProBook 4710s Notebook PC

HP ProBook 4710s Notebook PCHP ProBook 4710s Notebook PC

http://www.hp.com/go/lookuptool

Intel Core 2 Duo Processor T6570 (2.10 GHz, 2 MB L2 cache, 800 MHz FSB)*

Genuine Windows Vista Business with downgrade to Windows XP Professional custom installed

Mobile Intel PM45 Express Chipset with ICHM9, 1066 MHz front side bus 3072-MB 800-MHz DDR2 SDRAM (2 DIMM) 320-GB 5400 rpm SATA HDD

17.3-inch diagonal LED-backlit HD+ BrightView (1600 x 900 resolution) ATI Mobility Radeon HD 4330 graphics with 512 MB dedicated video

memory High Definition Audio support; Integrated stereo speakers

Integrated microphone; Stereo headphone/line out; Stereo microphone in 2 MP Camera included Marvell Ethernet (10/100/1000 NIC)

56K V.92 modem Intel WiFi Link 5100; supports 802.11a, b, g, and n draft 2.0;

Bluetooth 2.0 Touchpad with scroll zone, two pick buttons DVD+/-RW SuperMulti DL LightScribe Drive 8-cell (63 WHr) Lithium-Ion External 90-watt Smart AC adapter 1 Year Limited Warranty

DA - 13252 North America — Version 4 — May 15, 2009

Page 10

+ 22 hidden pages
