A7V133-VM

PC133/VC133

200/266 MHz FSB AGP 4X

Socket A Motherboard

USER’S MANUAL

USER'S NOTICE

No part of this manual, including the products and software described in it, may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means, except documentation kept by the purchaser for backup purposes, without the express written permission of ASUSTeK COMPUTER INC. (“ASUS”).

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED T O THE IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A PAR TICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE OR DA TA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.

Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.

Products and corporate names appearing in this manual may or may not be registered trademarks or copyrights of their respective companies, and are used only for identification or explanation and to the owners’ benefit, without intent to infringe.

• VIA and KT133 are trademarks of VIA Technologies, Inc.

• AMD, Athlon™ are trademarks of Advanced Micro Devices, Inc.

• Windows and MS-DOS are registered trademarks of Microsoft Corporation.

• Adobe and Acrobat are registered trademarks of Adobe Systems Incorporated.

• Trend and ChipAwayVirus are trademarks of Trend Micro, Inc.

• Other company and product names may be trademarks or registered trademarks of the respective companies with which they are associated.

The product name and revision number are both printed on the product itself. Manual revisions are released for each product design represented by the digit before and after the period of the manual revision number . Manual updates are represented by the third digit in the manual revision number.

For previous or updated manuals, BIOS, drivers, or product release information, contact ASUS at http://www .asus.com.tw or through any of the means indicated on the following page.

SPECIFICA TIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR INFORMA TIONAL USE ONL Y, AND ARE SUBJECT TO CHANGE A T ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MA Y APPEAR IN THIS MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

Product Name: ASUS A7V133-VM Manual Revision: 1.07 E698 Release Date: June 2001

ASUS A7V133-VM User’s Manual

ASUS CONTACT INFORMATION

ASUSTeK COMPUTER INC. (Asia-Pacific)

Marketing

Address: 150 Li-Te Road, Peitou, Taipei, Taiwan 112 Telephone: +886-2-2894-3447 Fax: +886-2-2894-3449 Email: info@asus.com.tw

Technical Support

MB/Others (Tel): +886-2-2890-7121 (English) Notebook (Tel): +886-2-2890-7122 (English) Desktop/Server (Tel):+886-2-2890-7123 (English) Fax: +886-2-2893-7775 Email: tsd@asus.com.tw WWW: www.asus.com.tw FTP: ftp.asus.com.tw/pub/ASUS

ASUS COMPUTER INTERNATIONAL (America)

Marketing

Address: 6737 Mowry Avenue, Mowry Business Center, Building 2

Newark, CA 94560, USA Fax: +1-510-608-4555 Email: tmd1@asus.com

Technical Support

Fax: +1-510-608-4555 Email: tsd@asus.com WWW: www.asus.com FTP: ftp.asus.com/Pub/ASUS

ASUS COMPUTER GmbH (Europe)

Marketing

Address: Harkortstr. 25, 40880 Ratingen, BRD, Germany Fax: +49-2102-442066 Email: sales@asuscom.de (for marketing requests only)

Technical Support

Hotline: MB/Others: +49-2102-9599-0 Notebook: +49-2102-9599-10 Fax: +49-2102-9599-11 Support (Email): www.asuscom.de/de/support (for online support) WWW: www.asuscom.de FTP: ftp.asuscom.de/pub/ASUSCOM

ASUS A7V133-VM User’s Manual 3

CONTENTS

1. INTRODUCTION 7

1.1 How This Manual Is Organized................................................. 7

1.2 Item Checklist ............................................................................ 7

2. FEATURES 8

2.1 The ASUS A7V133-VM ............................................................ 8

2.1.1 Specifications.................................................................. 8

2.1.2 Special Features ............................................................ 10

2.1.3 Optional Components ................................................... 10

2.1.4 Performance Features.................................................... 10

2.1.5 Intelligence.................................................................... 11

2.2 Motherboard Components ....................................................... 12

2.2.1 Component Locations ................................................... 13

3. HARDWARE SETUP 14

3.1 Motherboard Layout ................................................................ 14

3.2 Layout Contents ....................................................................... 15

3.3 Hardware Setup Procedure ...................................................... 16

3.4 Motherboard Settings............................................................... 16

3.5 System Memory (DIMM) ........................................................ 20

3.5.1 General DIMM Notes ................................................... 20

3.5.2 Memory Installation...................................................... 21

3.6 Central Processing Unit (CPU)................................................ 23

3.7 Expansion Cards ...................................................................... 24

3.7.1 Expansion Card Installation Procedure......................... 24

3.7.2 Assigning IRQs for Expansion Cards ........................... 25

3.7.3 Accelerated Graphics Port (AGP)................................. 26

3.8 External Connectors................................................................. 27

3.9 Starting Up the First Time ....................................................... 39

4. BIOS SETUP 41

4.1 Managing and Updating Your BIOS........................................ 41

4.1.1 Upon First Use of the Computer System ...................... 41

4.1.2 Updating BIOS Procedures........................................... 42

4.2 BIOS Setup Program ............................................................... 44

4.2.1 BIOS Menu Bar ............................................................ 45

4.2.2 Legend Bar.................................................................... 46

4.3 Main Menu............................................................................... 48

4.3.1 Primary & Secondary Master/Slave.............................. 49

ASUS A7V133-VM User’s Manual

CONTENTS

4.3.2 Keyboard Features ........................................................ 52

4.4 Advanced Menu ....................................................................... 54

4.4.1 Chip Configuration ....................................................... 57

4.4.2 I/O Device Configuration ............................................. 60

4.4.3 PCI Configuration......................................................... 63

4.4.4 Shadow Configuration .................................................... 67

4.5 Power Menu ............................................................................. 68

4.5.1 Power Up Control ......................................................... 70

4.5.2 Hardware Monitor......................................................... 72

4.6 Boot Menu ............................................................................... 73

4.7 Exit Menu ................................................................................ 75

5. SOFTWARE SETUP 77

5.1 Install Operating System.......................................................... 77

5.2 Start Windows.......................................................................... 77

5.3 A7V133-VM Series Support CD ............................................. 78

6. SOFTWARE REFERENCE 79

6.1 ASUS PC Probe ....................................................................... 79

6.2 CyberLink PowerPlayer SE ..................................................... 84

6.3 CyberLink PowerDVD ............................................................ 84

6.4 CyberLink VideoLive Mail...................................................... 86

6.5 ASUS LiveUpdate ................................................................... 88

7. APPENDIX 89

7.1 Glossary ................................................................................... 89

INDEX 93

ASUS A7V133-VM User’s Manual 5

FCC & DOC COMPLIANCE

Federal Communications Commission Statement

This device complies with FCC Rules Part 15. Operation is subject to the following two conditions:

• This device may not cause harmful interference, and

• This device must accept any interference received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with manufacturer's instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Re-orient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

WARNING! Any changes or modifications to this product not expressly ap-

proved by the manufacturer could void any assurances of safety or performance and could result in violation of Part 15 of the FCC Rules.

Reprinted from the Code of Federal Regulations #47, part 15.193, 1993. Washington DC: Office of the Federal Register, National Archives and Records Administration, U.S. Government Printing Office.

Canadian Department of Communications Statement

This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications.

This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

ASUS A7V133-VM User’s Manual

1. INTRODUCTION

1.1 How This Manual Is Organized

This manual is divided into the following sections:

1. INTRODUCTION Manual information and checklist

2. FEATURES Production information and specifications

3. HARDWARE SETUP Intructions on setting up the motherboard.

4. BIOS SETUP Intructions on setting up the BIOS

5. SOFTWARE SETUP Intructions on setting up the included software

6. SOFTWARE REFERENCE Reference material for the included software

7. APPENDIX Optional items and general reference

1.2 Item Checklist

Check that your package is complete. If you discover damaged or missing items, contact your retailer.

Manual / Checklist

1. INTRODUCTION

Package Contents

(1) ASUS Motherboard (1) 40-pin 80-conductor ribbon

cable for internal UltraDMA/ 100, UltraDMA/66 or UltraDMA/33 devices

(1) Ribbon cable for one 5.25” and

two 3.5” floppy disk drives

(1) ASUS 2-port USB Connector Set (1) Bag of spare jumper caps (1) ASUS Support CD with drivers

and utilities

(1) This Motherboard User’s

Manual

(1) COM2 Bracket

Optional Items

ASUS CIDB chassis intrusion detection module

ASUS IrDA-compliant infrared module

ASUS PCI-L101 W ake-On-LAN 10/ 100 Ethernet Card

ASUS A7V133-VM User’s Manual 7

2.1 The ASUS A7V133-VM

The ASUS A7V133-VM motherboard is carefully designed for the demanding PC user who wants advanced features processed by the fastest processors.

2.1.1 Specifications

• AMD Athlon™/Duron™ Processor Support: Supports Socket A-based AMD

2. FEATURES

Specifications

• North Bridge System Chipset: Features the VIA VT8365A (VIA KM133A)

• “Super South” South Bridge System PCIset: VIA VT82C686B PCI set with

• PC100 SDRAM: Equipped with two Dual Inline Memory Module (DIMM)

• JumperFree™ Mode: Allows processor settings and easy overclocking of fre-

2. FEATURES

Athlon™/Duron™ processors.

system controller with support for 200/266 MHz Front Side Bus (FSB); up to 1GB of PC133/PC100 SDRAM; S3 Savage4 Integrated Graphics with 2D/3D Video Accelerator; complies with AGP 2.0 specifications for 4X, 2X, and 1X AGP modes; and PCI 2.2. bus interface with support for 3 PCI masters. It is optimized to deliver enhanced AMD Athlon™/Duron™ processor system performance.

PCI Super-I/O Integrated Peripheral Controller (PSIPC) with support for UltraDMA/100, which allows burst mode data transfer rates of up to 100MB/ sec; AC97 audio; USB controller with root hub and four function ports.

sockets to support Intel PC100-compliant (8, 16, 32, 64, 128, 256, or 512MB) SDRAM up to 1GB.

quency and Vcore voltage all through BIOS setup when JumperFree™ mode is enabled. Easy-to-use DIP switches instead of jumpers are included to allow manual adjustment of the processor’s external frequency.

• AGP Slot: Supports AGP cards for high performance, component level inter-

connection targeted at 3D graphical applications supporting 133MHz 4X mode.

• UltraDMA/100 Support: Comes with an onboard PCI Bus Master IDE con-

troller with two connectors that support four A T A100/66/33 devices on two channels. Supports UltraDMA/100, UltraDMA/66, UltraDMA/33, PIO Modes 3 & 4 and Bus Master IDE DMA Mode 2, and Enhanced IDE devices, such as DVDROM, CD-ROM, CD-R/RW, LS-120, and Tape Backup drives.

• USB: Supports up to 4 USB ports, two on the back panel and two midboard, for

more peripheral connectivity options.

• PC Health Monitoring: Provides an easy way to examine and manage system

status information, such as CPU and systerm voltages, temperatures, and fan status through the onboard hardware ASUS ASIC and the bundled ASUS PC Probe.

• SMBus: Features the System Management Bus interface, which is used to physi-

cally transport commands and information between SMBus devices.

ASUS A7V133-VM User’s Manual

2. FEATURES

• PCI Expansion Slots: Provides three 32-bit PCI (Rev. 2.2) expansion slots,

which can support Bus Master PCI cards, such as SCSI or LAN cards (PCI supports up to 133MB/s maximum throughput).

• Super Multi-I/O: Provides two high-speed UART compatible serial ports and

one parallel port with EPP and ECP capabilities.

• Enhanced ACPI & Anti-Boot Virus Protection: Programmable BIOS (Flash

EEPROM), offering enhanced ACPI for W indows 98 compatibility , built-in firmware-based virus protection, and autodetection of most devices for virtually automatic setup.

• Concurrent PCI: Concurrent PCI allows multiple PCI transfers from PCI mas-

ter busses to the memory and processor.

• Smart BIOS: 2Mb firmware provides Vcore and CPU/SDRAM frequency ad-

justments, boot block write protection, and HD/SCSI/MO/ZIP/CD/Floppy boot selection. Power supply autodetects to enable/disable suspend-to-RAM.

• Integrated Infrared (IrDA) Support: Integrated IR supports an optional re-

mote control package for wireless interfacing with external peripherals, personal gadgets, or an optional remote controller.

Specifications

2. FEATURES

• Desktop Management Interface (DMI): Supports DMI through BIOS, which

allows hardware to communicate within a standard protocol creating a higher level of compatibility. (Requires DMI-enabled components.)

• Color-coded Connectors: To enhance user accessibility to system components and

to meet PC 99 compliancy , major connectors in this motherboard are color -coded.

ASUS A7V133-VM User’s Manual 9

2. FEATURES

Performance

2. FEATURES

2.1.2 Special Features

• ACPI Ready: Advanced Configuration Power Interface (ACPI) provides more

Energy Saving Features for operating systems that support OS Direct Power Management (OSPM) functionality . W ith these features implemented in the OS, PCs can be ready around the clock, yet satisfy all the energy saving standards. T o maximize functions, an ACPI-supported OS, like W indows 98 must be used.

• Easy Installation: Incorporates BIOS that supports autodetection of hard disk

drives, PS/2 mouse, and Plug and Play devices to make the setup of hard disk drives, expansion cards, and other devices virtually automatic.

• New Compliancy: Both the BIOS and hardware levels of this motherboard meet

the stringent requirements for PC 99 certification The new PC 99 requirements for systems and components are based on the following high-level goals: Support for Plug and Play compatibility and power management for configuring and managing all system components, and 32-bit device drivers and installation procedures for W indows95/98/NT. Color-coded connectors and descriptive icons make identification easy as required by PC 99.

2.1.3 Optional Components

• Realtek RTL8139C Ethernet: single chip fast ethernet controller for 100/10

Mbps capacity and supports WOL (Wake-on-LAN) feature.

• Onboard AC’97 Audio Contr oller: Supports advanced automated audio per-

formance.

• PCI Controller: Creative CT5880 Audio Controller Chipset with AC97 Audio

CODEC complete with software support.

2.1.4 Performance Features

• Concurrent PCI: Concurrent PCI allows multiple PCI transfers from PCI mas-

ter busses to the memory and processor.

• High-Speed Data Transfer Interface: IDE transfers using UltraDMA/33 Bus

Master IDE can handle rates up to 33MB/s. This motherboard with its chipset and support for UltraDMA/100 triples the data transfer rate to 100MB/s. UltraDMA/100 is backward compatible with both DMA/33 and DMA and with existing DMA devices and systems so there is no need to upgrade current EIDE/ IDE drives and host systems. (UltraDMA/100 requires a 40-pin 80-conductor cable to be enabled.)

ASUS A7V133-VM User’s Manual

2. FEATURES

• VCM/SDRAM Optimized Performance: This motherboard supports a new gen-

eration memory, NEC’s 64Mb V irtual Channel Memory (VCM) Synchronous Dy- namic Random Access Memory (SDRAM), which is compatible to the industry standard SDRAM. The VCM’s core design provides up to 50% higher SDRAM speed at reduced power consumption of about 30%. This motherboard also supports standard SDRAM, which increases the data transfer rate (1.064GB/s max using PC133-compliant SDRAMs and 800MB/s max using PC100-compliant SDRAMs).

2.1.5 Intelligence

• Auto Fan Off: The system fans will power off automatically even in sleep mode. This function reduces both energy consumption and system noise, and is

an important feature in implementing silent PC systems.

• Dual Function Power Button: Pushing the power button for less than 4 sec- onds when the system is in the working state places the system into one of two states: sleep mode or soft-off mode, depending on the BIOS or OS setting (see PWR Button < 4 Secs in 4.5 Power Menu). When the power button is pressed for more than 4 seconds, the system enters the soft-off mode regardless of the BIOS setting.

Intelligence

2. FEATURES

• Fan Status Monitoring and Alarm: To prevent system overheat and system damage, the CPU, power supply, and system fans can be monitored for RPM and failure. All fans are set for its normal RPM range and alarm thresholds.

• Remote Ring On (requires modem): This allows a computer to be turned on remotely through an internal or external modem. With this benefit on-hand, users can access vital information from their computers from anywhere in the world!

• System Resources Alert: Today’s operating systems such as Windows 95/98/ NT and OS/2, require much more memory and hard drive space to present enormous user interfaces and run large applications. The system resource monitor will warn the user before the system resources are used up to prevent possible application crashes. Suggestions will give the user information on managing their limited resources more efficiently.

• Temperature Monitoring and Alert: CPU temperature is monitored by the ASUS ASIC to prevent system overheat and system damage.

• Voltage Monitoring and Alert: System voltage levels are monitored to ensure stable voltage to critical motherboard components. Voltage specifications are more critical for future processors, so monitoring is necessary to ensure proper system configuration and management.

ASUS A7V133-VM User’s Manual 11

2. FEATURES

2.2 Motherboard Components

See opposite page for locations.

Processor Support Socket A for AMD Athlon/Duron Processors........................... 3

Motherboard Parts

2. FEATURES

Expansion Slots 3PCI Slots ............................................................................... 17

Location

(NOTE: CPU thermal sensor is integrated on the motherboard, located near the center of the CPU heat source, just below the CPU socket)

Feature Setting DIP Switches ................................................... 6

Chipsets VIA VT8365 (VIA KM133A) system controller ...................... 2

VIA VT82C686B PCIset......................................................... 14

2Mbit Programmable Flash EEPROM ..................................... 9

Main Memory Maximum 1GB support

2 DIMM Sockets ...................................................................... 4

VC133/PC133 memory support

1 Accelerated Graphics Port (AGP) Slot ................................ 19

System I/O 1 Floppy Disk Driver Connector .............................................. 8

2 IDE Connectors (UltraDMA/100 Support) ........................... 5

1 Parallel Port Connector ............................................. (Top) 22

1 Serial COM1 Port Connector .............................. (Bottom) 23

1 VGA Connector ................................................... (Bottom) 21

1 Serial COM2 Port Connector ............................................. 15

USB Connectors (Port 0 & Port 1) ........................ (Bottom) 24

USB Connectors (Port 2 & Port 3) ......................................... 13

1 PS/2 Mouse Connector .............................................. (Top) 25

1 PS/2 Keyboard Connector ................................... (Bottom) 25

Audio AC’97 V2.1 Audio Codec ..................................... (optional) 18

Creative Audio Controller .......................................... (optional)

1 Game/MIDI Connector (on audio model only) .............. (Top)

1 Line Out Connector (on audio model only) ........ (Bottom) 20

1 Line In Connector (on audio model only) ........... (Bottom) 20

1 Microphone Connector (on audio model only) ... (Bottom) 20

Network Features Realtek RTL 8139C Fast Ethernet Controller.............. (optional)

1 LAN (RJ45) Connector ............................. (optional) (top) 24

Wake-On-LAN Connector...................................................... 16

Wake-On-Ring Connector ...................................................... 11

Hardware Monitoring System Voltage Monitoring (integrated in ASUS ASIC) ......... 9

3 Fan Power and Speed Monitoring Connectors

Power ATX Power Supply Connector ................................................. 1

Others Onboard LED ........................................................................... 7

SMBus Connector .................................................................. 12

Form Factor Micro A TX

ASUS A7V133-VM User’s Manual

2. FEATURES

2.2.1 Component Locations

25 24

1 2 345

6 78

2. FEATURES

Motherboard Parts

18 17

911121315

1014

ASUS A7V133-VM User’s Manual 13

3. HARDWARE SETUP

3.1 Motherboard Layout

24.5cm (9.6in)

PS/2

T: Mouse B: Keyboard

USB

T: USB1 B: USB2

COM1

Top:

RJ-45

Socket A

CPU_FAN

CR2032 3V Lithium Cell

CMOS Power

CLRTC

LED

VGA

Motherboard Layout

3. H/W SETUP

Line Out

Line

Mic

GAME_AUDIO

Audio

Codec

Grayed components are optional at the time of purchase.

PS_FAN

PARALLEL PORT

HPHONE

MODEM

Audio

Chip

AUXCD

ATXPWR

Realtek

Fast

Enternet

WOLCON

VIA

VT8365A

Chipset

Accelerated Graphics Port (AGP)

PCI Slot 1

PCI Slot 2

A7V133-VM

PCI Slot 3

COM2

SW1

CHASS_FAN

JEN

VIA

VT82C686B

Chipset

IDELED

CHASS

DIMM Socket 1 (64/72-bit, 168-pin module)

DIMM Socket 2 (64/72-bit, 168-pin module)

PRIMARY IDE

SECONDARY IDE

USB2

SMB

WOR

HPANEL

24.5cm (9.6in)

FLOPPY

Flash EEPROM

(Programable BIOS)

ASCI

ASUS A7V133-VM User’s Manual

3. HARDWARE SETUP

3.2 Layout Contents

Motherboard Settings

1) JEN p. 17 JumperFree Mode (JumperFree/Jumper Mode)

2) JF p. 18 CPU / FSB Frequency Selection

2) SW1 1–4 p. 19 CPU External Frequency Setting

Expansion Slots/Sockets

1) System Memory p.20 System Memory Support

2) DIMM1/2 p.21 DIMM Memory Module Support

3) Socket 462 (Socket A) p.23 CPU Support

4) PCI1/2/3 p.24 32-bit PCI Bus Expansion Slots

5) AGP p.26 Accelerated Graphics Port (AGP)

Connectors

1) PS2KBMS p.27 PS/2 Mouse Port Connector (6 pin female)

2) PS2KBMS p.27 PS/2 Keyboard Port Connector (6 pin female)

3) USB p.28 Universal Serial Bus Connectors 0 & 1 (T wo 4 pin female)

4) PRINTER p.28 Parallel Port Connector (25 pin female)

5) VGA p.28 Monitor Output Connector and bracket (15 pin male)

6) COM1/2 p.29 Serial Port Connector (9 pin male)

7) GAME_AUDIO p.29 Game/MIDI Connector (15 pin female) (optional)

8) GAME_AUDIO p.30 Audio Port Connectors (Three 1/8” female) (optional)

9) RJ45 p.30 Fast-Ethernet Port Connector (RJ45) (optional)

10) PRIMARY I D E p.31 IDE Connectors (Two 40-1 pin) SECONDARY IDE

11) FLOPPY p.31 Floppy Disk Drive Port Connector (34 pin)

12) IR p.32 Infrared Module Connector (5 pin)

13) CPU_FAN, PS_FAN p.33 CPU Supply, PowerFan Connectors (3 pin) CD_IN, AUX, MODEM

14)

15) HPHONE p.34 Headphone True-Level Out Header (3 pin)

16) USB2 p.35 USB Header (10-1 pin)

17) SMB p.35 SMBus Connector (5-1 pin)

18) ATXPWR p.36 ATX Power Supply Connector (20 pin)

19) IDELED p.36 IDE Activity LED (2 pin)

20) SPEAKER (PANEL) p.37 System Warning Speaker Connector (4 pin)

21) PWR.LED (PANEL) p.37 System Power LED Lead (3 pin)

22) RESET (PANEL) p.37 Reset Switch Lead (2 pin)

23) PWR.SW (PANEL) p.37 ATX / Soft-Off Switch Lead (2 pin)

24) SMI (PANEL) p.37 System Management Interrupt Lead (2 pin)

p.34 Internal Audio Connectors (Three 4 pin)

3. H/W SETUP

Layout Contents

ASUS A7V133-VM User’s Manual 15

3.3 Hardware Setup Procedure

Before using your computer, you must complete the following steps:

1. Check Motherboard Settings

2. Install Memory Modules

3. Install the Central Processing Unit (CPU)

4. Install Expansion Cards

5. Connect Ribbon Cables, Panel Wires, and Power Supply

6. Setup the BIOS Software

3.4 Motherboard Settings

This section explains in detail how to change your motherboard’s function settings through the use of switches and/or jumpers.

W ARNING! Computer motherboards and expansion cards contain very delicate

3. H/W SETUP

Integrated Circuit (IC) chips. To protect them against damage from static electricity, you should follow some precautions whenever you work on your computer.

3. HARDWARE SETUP

1. Unplug your computer when working on the inside.

2. Use a grounded wrist strap before handling computer components. If you do not have one, touch both of your hands to a safely grounded object or to a metal object, such as the power supply case.

3. Hold components by the edges and try not to touch the IC chips, leads o r connectors, or other components.

4. Place components on a grounded antistatic pad or on the bag that came with the component whenever the components are separated from the system.

5. Ensure that the ATX power supply is switched off before you plug in or remove the ATX power connector on the motherboard.

WARNING! Make sure that you unplug your power supply when adding or re-

moving system components. Failure to do so may cause severe damage to your motherboard, peripherals, and/or components. The onboard LED when lit acts as a reminder that the system is in suspend or soft-off mode and not powered OFF.

A7V133-VM

A7V133-VM Onboard LED

ASUS A7V133-VM User’s Manual

Standby

Power

LED

OFF

Powered

Off

3. HARDWARE SETUP

Motherboard Features Settings (DSW Switches - SW1)

The motherboard’s onboard functions are adjusted through the DIP switches. The white block represents the switch’s position. The example below shows all the

switches in the OFF position.

DSW

ONOFF

ON 34

1. Frequency Selection

A7V133-VM

2. Frequency Selection

3. Frequency Selection

4. Frequency Selection

A7V133-VM DIP Switches

1) Jumper Setting (JEN)

This jumper allows you to enable or disable the JumperFree™ mode. The JumperFree™ mode allows processor settings to be made through the BIOS setup (see 4.4 Advanced Menu).

3. H/W SETUP

Motherboard Settings

Jumper Setting JEN

JumperFree™ [2-3] (default) Jumper Mode [1-2]

DSW Setting : In JumperFree™ mode, DIP switches (SW1) must be set to “OFF”

SW1

OFF

Enable

A7V133-VM

A7V133-VM JumperFree™ Mode Setting

JEN

Disable

Jumper Mode

JEN

JumperFree Mode (Default)

ASUS A7V133-VM User’s Manual 17

2) CPU / FSB Frequency Selection (JF)

The JF jumper is set to a default that operates with AMD 133 FSB capacity processors. The factory default is set to run the FSB at 133 MHz and the JF jumper is preset to [2-3] and all DSW (SW1) switches are preset to OFF . If AMD 100 MHz capacity processors are used, then reset the JF jumper to [1-2] and change the DSW (SW1) switches to the 100 MHz setting shown below. If the JF and switch settings do not match the capacity of the processor, the motherboard may not boot up.

2 3

133MHz 100MHz

Motherboard Settings

3. H/W SETUP

A7V133-VM CPU/FSB Setting (JF)

A7V133-VM

CPU

133MHz

(Default)

CPU 100MHz

ASUS A7V133-VM User’s Manual

3) CPU External Frequency Setting (SW1 Switches 1–4)

This option tells the clock generator what frequency to send to the CPU, SDRAM, and the chipset. This allows the selection of the CPU’s External frequency . The CPU External Frequency multiplied by the Frequency Multiple equals the CPU’s Internal frequency (the advertised CPU speed).

IMPORTANT:

1. For normal frequencies, 100, 103 and 105 MHz, the JF jumpers must be set to [1-2]. For the purpose of overclocking, 133 MHz and above, the JF jumper must be set to [2-3] and speed adjustments must be made through BIOS using JumperFree Mode and a 133 MHz capacity processor.

2. To use the manual DSW (SW1) switches as shown below, the JEN must be set to Jumper Mode: [1-2]; (See 1, p. 18).

3. Otherwise, if JumperFree Mode is enabled, all DSW (SW1) switches must be set to OFF and the JEN jumper must be set to [2-3]. (See #1 on the previ- ous page). Then, the BIOS setup can be used in place of these switches (Set Operating Frequency Setting to User Define under 4.4 Advanced Menu in BIOS Setup to set the CPU Frequency).

4. If processor settings above 133 MHz are required, then you must use a 133 MHz capacity processor, JumperFree Mode and BIOS to make adjustments.

A7V133-VM

A7V133-VM CPU External Frequency Selection

CPU 100MHz

CPU

105MHz

103MHz

133MHz

External Frequency Table

CPU PCI Frequency Selection Switches

(MHz) (MHz) 1 2 3 4

100.00 33.33 [ON] [ON] [OFF] [ON]

103.00 34.33 [OFF] [ON] [OFF] [ON]

105.00 35.00 [ON] [OFF] [OFF] [ON]

133.00 33.33 [OFF] [OFF] [OFF] [OFF]

3. H/W SETUP

Motherboard Settings

WARNING! Frequencies other than the recommended CPU bus frequencies are

not guaranteed to be stable. Overclocking your processor is not recommended. It may result in a slower speed and premature wearing of the processor.

NOTE: For updated processor settings, visit the ASUS at: WWW.ASUS.COM

ASUS A7V133-VM User’s Manual 19

3.5 System Memory (DIMM)

This motherboard uses only Dual Inline Memory Modules (DIMMs). Two sockets are available for 3.3Volt (power level) unbuffered Synchronous Dynamic Random Access Memory (SDRAM) of 8, 16, 32, 64, 128, 256, or 512MB to form a memory size between 8MB to 1GB. One side (with memory chips) of the DIMM takes up one row on the motherboard.

Memory speed setup is recommended through SDRAM Configuration under “Chipset Features Setup”.

IMPORTANT (see General DIMM Notes below for more):

• SDRAMs used must be compatible with the current Intel PC133 SDRAM specification.

• DO NOT attempt to replace PC133 SDRAMs with VCM SDRAMs.

• The motherboard only supports PC100 / PC133 DIMMs

System Memory

3. H/W SETUP

SDRAMs for system memory. Registered DIMMs are not supported.

3. HARDWARE SETUP

Install memory in any combination as follows:

DIMM Location 168-pin DIMM Total Memory

Socket 1 (Rows 0&1) SDRAM 8, 16, 32, 64, 128, 256, 512MB x1 Socket 2 (Rows 2&3) SDRAM 8, 16, 32, 64, 128, 256, 512MB x1

Total System Memory (Max 1024MB) =

3.5.1 General DIMM Notes

• DIMMs that have more than 18 chips are not supported on this motherboard.

• For the system CPU bus to operate at 100MHz/133MHz, use only PC100-/PC133-

compliant DIMMs.

• ASUS motherboards support SPD (Serial Presence Detect) DIMMs. This is the memory of choice for best performance vs. stability.

• BIOS shows SDRAM memory on bootup screen.

• Single-sided DIMMs come in 16, 32, 64,128, 256MB; double-sided come in 32, 64,

128, 256, 512MB.

WARNING! Be sure that the DIMM you use can handle the specified SDRAM

MHz or else bootup will not be possible.

ASUS A7V133-VM User’s Manual

3. HARDWARE SETUP

3.5.2 Memory Installation

WARNING! Make sure that you unplug your power supply when adding or

removing memory modules or other system components. Failure to do so may cause severe damage to both your motherboard and expansion cards (see 3.3 Hardware Setup Procedure for more information).

Insert the module(s) as shown. Because the number of pins are different on either side of the breaks, the module will only fit in the orientation shown. DRAM SIMM modules have the same pin contacts on both sides. SDRAM DIMMs have different pin contacts on each side and therefore have a higher pin density.

20 Pins

60 Pins

88 Pins

A7V133-VM

A7V133-VM 168-Pin DIMM Sockets

The DIMMs must be 3.3Volt unbuffered SDRAMs. To determine the DIMM type, check the notches on the DIMMs (see figure below).

168-Pin DIMM Notch Key Definitions (3.3V)

DRAM Key Position

RFU

Buffered

Unbuffered

Voltage Key Position

5.0V

Reserved

3.3V

3. H/W SETUP

System Memory

The notches on the DIMM will shift between left, center, or right to identify the type and also to prevent the wrong type from being inserted into the DIMM slot on the motherboard. You must tell your retailer the correct DIMM type before purchasing. This motherboard supports four clock signals per DIMM.

ASUS A7V133-VM User’s Manual 21

(This page was intentionally left blank.)

System Memory

3. H/W SETUP

3. HARDWARE SETUP

ASUS A7V133-VM User’s Manual

3. HARDWARE SETUP

3.6 Central Processing Unit (CPU)

The motherboard provides a Socket 462 or Socket A for CPU installation. A fan and heatsink should be attached to the CPU to prevent overheating. Purchase and install a fan and heatsink before turning on the system.

CPU NOTCH TO INNER CORNER

LOCK

LEVER

AMD™ CPU

A7V133-VM

A7V133-VM Socket A

1. Locate the Socket 462 and open it by pulling the lever gently sideways away from the socket. Then lift the lever upwards. The socket lever must be fully opened (90 to 100 degrees).

2. Insert the CPU with the correct orientation. The notched corner of the CPU must be oriented toward the inner corner of the socket base nearest to the lever hinge.

CAUTION! The CPU fits in one orientation

and should drop easily into place. Do not force the CPU into the socket to avoid bending the

pins. If the CPU does not fit, check its alignment and look for bent pins.

CPU NOTCH

CPU

3. H/W SETUP

3. Once completely inserted, press the CPU firmly and close the socket lever until it snaps into its locked position.

4. Place the CPU fan and heatsink on the CPU. The heatsink should entirely cover the CPU. Carefully attach the heatsink locking brace to the plastic clips on the socket base. With the added weight of the CPU fan and heatsink locking brace, no extra force is required to keep the CPU in place.

CAUTION! Take care not to scrape the motherboard surface when mounting a

clamp-style processor fan, or else damage may occur . When mounting a heatsink onto your CPU, make sure that exposed CPU capacitors do not touch the heatsink, or else damage may occur! Refer to heatsink/CPU documentation.

NOTE! Do not forget to set the correct Bus Frequency and Multiple (available

only on unlocked processors) to avoid start-up problems.

ASUS A7V133-VM User’s Manual 23

3.7 Expansion Cards

WARNING! Unplug your power supply when adding or removing expansion

cards or other system components. Failure to do so may cause severe damage to both your motherboard and expansion cards.

3.7.1 Expansion Card Installation Procedure

1. Read the documentation for your expansion card and make any necessary hard-

2. Remove your computer system’s cover and the bracket plate on the slot you

3. Carefully align the card’s connectors and press firmly.

4. Secure the card on the slot with the screw you removed above.

Expansion Cards

3. H/W SETUP

5. Replace the computer system’s cover.

6. Set up the BIOS if necessary

7. Install the necessary software drivers for your expansion card.

3. HARDWARE SETUP

ware or software settings for your expansion card, such as jumpers.

intend to use. Keep the bracket for possible future use.

(such as IRQ XX Reserved for Legacy Device: Yes in 4.4.3 PCI Configuration)

24 ASUS A7V133-VM User’s Manual

3. HARDWARE SETUP

3.7.2 Assigning IRQs for Expansion Cards

Some expansion cards need an IRQ to operate. Generally, an IRQ must be exclusively assigned to one use. In a standard design, there are 16 IRQs available but most of them are already in use, leaving 6 IRQs free for expansion cards. If your motherboard has PCI audio onboard, an additional IRQ will be used. If your motherboard also has MIDI enabled, another IRQ will be used, leaving 4 IRQs free.

The following table lists the default IRQ assignments for standard PC devices. Use this table when configuring your system and for resolving IRQ conflicts.

Standard Interrupt Assignments

IRQ Priority Standard Function

0 1 System Timer 1 2 Keyboard Controller 2 N/A Programmable Interrupt 3* 11 Communications Port (COM2) 4* 12 Communications Port (COM1) 5* 13 Sound Card (sometimes LPT2) 6 14 Floppy Disk Controller 7* 15 Printer Port (LPT1) 8 3 System CMOS/Real Time Clock 9* 4 ACPI Mode when used 10* 5 IRQ Holder for PCI Steering 11* 6 IRQ Holder for PCI Steering 12* 7 PS/2 Compatible Mouse Port 13 8 Numeric Data Processor 14* 9 Primary IDE Channel 15* 10 Secondary IDE Channel

3. H/W SETUP

Expansion Cards

*These IRQs are usually available for PCI devices.

Interrupt Request Table for this Motherboard

INT-A INT-B INT-C INT-D

PCI slot 1 shared —— — PCI slot 2 — shared —— PCI slot 3 ——not shared — AGP slot shared ——— Onboard USB controller ———not shared Onboard audio/SMBus — shared —

IMPORTANT: If using PCI cards on shared slots, make sure that the drivers support “Share IRQ” or that the cards do not need IRQ assignments. Conflicts will arise between the two PCI groups that will make the system unstable or cards inoperable.

ASUS A7V133-VM User’s Manual 25

3. HARDWARE SETUP

3.7.3 Accelerated Graphics Port (AGP)

This motherboard provides an Accelerated Graphics Port (AGP) slot to support AGP graphics cards, such as an ASUS AGP-V7700 GeForce2 GTS graphics card.

CAUTION! To avoid damaging your AGP graphics card, your computer’s power

supply should be unplugged before inserting your graphics card into the slot.

Expansion Cards

3. H/W SETUP

A7V133-VM

A7V133-VM Accelerated Graphics Port (AGP)

26 ASUS A7V133-VM User’s Manual

3. HARDWARE SETUP

3.8 External Connectors

WARNING! Some pins are used for connectors or power sources. These are

clearly distinguished from jumpers in the Motherboard Layout. Placing jumper caps over these connector pins will cause damage to your motherboard.

IMPORTANT: Ribbon cables should always be connected with the red stripe to

Pin 1 on the connectors. Pin 1 is usually on the side closest to the power connector on hard drives and CD-ROM drives, but may be on the opposite side on floppy disk drives. Check the connectors before installation because there may be exceptions. IDE ribbon cable must be less than 46 cm (18 in.), with the second drive connector no more than 15 cm (6 in.) from the first connector.

1) PS/2 Mouse Connector (Green 6-pin PS2KBMS)

The system will direct IRQ12 to the PS/2 mouse if one is detected. If one is not detected, expansion cards can use IRQ12. See PS/2 Mouse Function Control in 4.4 Advanced Menu.

PS/2 Mouse (6-pin female)

Connectors

3. H/W SETUP

2) PS/2 Keyboard Connector (Purple 6-pin PS2KBMS) This connection is for a standard keyboard using an PS/2 plug (mini DIN). This connector will not allow standard AT size (large DIN) keyboard plugs. You may use a DIN to mini DIN adapter on standard AT keyboards.

PS/2 Keyboard (6-pin female)

ASUS A7V133-VM User’s Manual 27

3. HARDWARE SETUP

3) Universal Serial BUS Ports 0 & 1 (Black two 4-pin USB)

Two USB ports are available for connecting USB devices. For additional USB ports, you can use the USB headers (see USB Headers later in this section) and mount it to the chassis.

USB 1

Universal Serial Bus (USB) 2

3. H/W SETUP

4) Parallel Port Connector (Burgundy 25-pin PRINTER)

Connectors

5) Monitor Output Connector (Blue 15-pin VGA)

You can enable the parallel port and choose the IRQ through Onboard Parallel Port (see 4.4.2 I/O Device Configuration). NOTE: Serial printers must be connected to the serial port.

Parallel (Printer) Port (25-pin female)

This connector is for output to a VGA-compatible device.

VGA Monitor (15-pin female)

28 ASUS A7V133-VM User’s Manual

3. HARDWARE SETUP

6) Serial Port Connectors (Teal/Turquoise 9-pin COM1, 10-1 pin COM2)

One serial port is ready for a mouse or other serial devices. A second serial port is available using a serial port bracket connected from the motherboard to an expansion slot opening. See Onboard Serial Port 1/2 in 4.4.2 I/O Device Configuration for settings.

COM 1

Serial Port (9-pin male)

COM2

PIN 1

A7V133-VM

A7V133-VM Serial COM2 Bracket

7) Game/MIDI Connector (Gold 15-pin GAME_AUDIO) (optional)

You may connect game joysticks or game pads to this connector for playing games. Connect MIDI devices for playing or editing professional audio.

Joystick/MIDI (15-pin female)

Connectors

3. H/W SETUP

ASUS A7V133-VM User’s Manual 29

8) Audio Port Connectors (Three 1/8” GAME_AUDIO) (optional)

3. H/W SETUP

Connectors

3. HARDWARE SETUP

Line Out (lime) can be connected to headphones or preferably powered speakers. Line In (light blue) allows tape players or other audio sources to be re- corded by your computer or played through the Line Out (lime). Mic (pink) allows microphones to be connected for inputting voice.

MicLine InLine Out

1/8" Stereo Audio Connectors

9) Fast-Ethernet Port Connectors (RJ45) (optional)

The RJ45 connector is located on top of the USB Ports 0 & 1. The connector allows the motherboard to connect to a Local Area Network (LAN) through a network hub.

RJ-45

30 ASUS A7V133-VM User’s Manual

3. HARDWARE SETUP

10) Primary (Blue) / Secondary IDE Connectors (40-1 pin IDE1/IDE2)

These connectors support the provided UltraDMA/66/100 IDE hard disk ribbon cable. Connect the cable’s blue connector to the motherboard’s primary (rec- ommended) or secondary IDE connector, and then connect the gray connector to your UltraDMA/66/100 slave device (hard disk drive) and the black connector to your UltraDMA/66/100 master device. It is recommended that nonUltraDMA/66/100 devices be connected to the secondary IDE connector . If you install two hard disks, you must configure the second drive to Slave mode by setting its jumper accordingly. Refer to your hard disk documentation for the jumper settings. BIOS now supports specific device bootup (see 4.6 Boot Menu).

(Pin 20 is removed to prevent inserting in the wrong orientation when using ribbon cables with pin 20 plugged). If you have more than two UltraDMA/66/

100 devices, you will need to purchase another UltraDMA/66/100 cable. NOTE: The hole near the blue connector on the UltraDMA/66/100 cable is intentional. TIP: You may configure two hard disks to be both Masters with two ribbon

cables – one for the primary IDE connector and another for the secondary IDE connector . You may install one operating system on an IDE drive and another on a SCSI drive and select the boot disk through BIOS 4.6 Boot Menu.

NOTE: Orient the red markings (usually zigzag) on the IDE ribbon cable to PIN 1.

A7V133-VM

A7V133-VM IDE Connectors

Secondary IDE Connector

Primary IDE Connector

PIN 1

11) Floppy Disk Drive Connector (34-1 pin FLOPPY)

This connector supports the provided floppy drive ribbon cable. After connecting the single end to the board, connect the two plugs on the other end to the floppy drives. (Pin 5 is removed to prevent inserting in the wrong orienta-

tion when using ribbon cables with pin 5 plugged).

NOTE: Orient the red markings on the floppy ribbon cable to

PIN 1

Connectors

3. H/W SETUP

A7V133-VM

A7V133-VM Floppy Disk Drive Connector

ASUS A7V133-VM User’s Manual 31

PIN 1

3. HARDWARE SETUP

12) Standard and Consumer Infrared Module Connector (5 pin IR)

This connector supports an optional wireless transmitting and receiving infrared module. This module mounts to a small opening on system cases that support this feature. You must also configure the setting through UART2 Use Infrared (see 4.4.2 I/O Device Configuration) to select whether UART2 is directed for use with COM2 or IrDA. Use the five pins as shown in Back View and connect a ribbon cable from the module to the motherboard’s SIR connector according to the pin definitions.

3. H/W SETUP

Connectors

+5V

IRRX

A7V133-VM

A7V133-VM Infrared Module Connector

GND

IRTX

Front View

Back View

IRTX GND

IRRX

+5V (NC)

32 ASUS A7V133-VM User’s Manual

3. HARDWARE SETUP

13) CPU, Power Supply, Chassis Fan Connectors (3 pin CPU_FAN, PS_FAN)

These connectors support cooling fans of 350mA (4.2 Watts) or less. Orientate the fans so that the heat sink fins allow airflow to go across the onboard heat sink(s) instead of the expansion slots. Depending on the fan manufacturer, the wiring and plug may be different. The red wire should be positive, while the black should be ground. Connect the fan’s plug to the board taking into consid- eration the polarity of the connector.

NOTE: The “Rotation” signal is to be used only by a specially designed fan with rotation signal. The Rotations per Minute (RPM) can be monitored using ASUS PC Probe (see 6. SOFTWARE REFERENCE).

WARNING! The CPU and/or motherboard will overheat if there is no airflow

across the CPU and onboard heatsinks. Damage may occur to the motherboard and/or the CPU fan if these pins are incorrectly used. These are not jumpers,

do not place jumper caps over these pins.

A7V133-VM

A7V133-VM 12-Volt Cooling Fan Power

GND

+12V

Rotation

GND

+12V

GND

CPU_FAN

Connectors

3. H/W SETUP

PS_FAN

ASUS A7V133-VM User’s Manual 33

3. HARDWARE SETUP

14) Internal Audio Connectors (4 pin CD_IN, AUX, MODEM)

These connectors allow you to receive stereo audio input from such sound sources as a CD-ROM, TV tuner, or MPEG card. The MODEM connector allows the onboard audio to interface with a voice modem card with a similar connector.

3. H/W SETUP

Connectors

(Black)

Left Audio Channel

Ground

MODEM

A7V133-VM

AUX

(White)

Right Audio Channel

Modem-In Ground Ground Modem-Out

Left Audio Channel

Ground

Right Audio Channel

A7V133-VM Internal Audio Connectors

15) Headphone True-Level Out Header (3 pin HPHONE)

This connector allows you to connect a chassis mounted headphone to the motherboard instead of having to attach an external headphone onto the ATX connectors.

HP OUT LT

GND

HP OUT RT

HPHONE

A7V133-VM

A7V133-VM True-Level Line Out Header

34 ASUS A7V133-VM User’s Manual

3. HARDWARE SETUP

16) USB Header (10-1 pin USB2)

If the USB port connectors on the back panel are inadequate, this USB header is available for two additional USB port connectors. Connect the USB headers to the 2-port USB connector set and mount the bracket to an open slot on your chassis.

USB2

A7V133-VM

USBP3+

GND

USBP2+

GND

USB Power

USBP3–

610 1

USB Power

USBP2–

A7V133-VM USB Port

17) SMBus Connector (5-1 pin SMB)

This connector allows you to connect SMBus (System Management Bus) devices. SMBus devices communicate by means of the SMBus with an SMBus

host and/or other SMBus devices. SMBus is a specific implementation of an I

C bus, which is a multi-device bus; that is, multiple chips can be connected to the same bus and each one can act as a master by initiating data transfer.

Connectors

3. H/W SETUP

A7V133-VM

A7V133-VM SMBus Connector

ASUS A7V133-VM User’s Manual 35

Ground

SMBCLK

SMB

+5V

SMBDATA

3. HARDWARE SETUP

18) ATX Power Supply Connector (20 pin block ATXPWR)

This connector connects to an ATX power supply. The plug from the power supply will only insert in one orientation because of the different hole sizes. Find the proper orientation and push down firmly making sure that the pins are aligned.

IMPORTANT: Make sure that your ATX power supply can supply at least 10mA

on the +5-volt standby lead (+5VSB). You may experience difficulty in powering ON your system if your power supply cannot support the load. For WakeOn-LAN support, your ATX power supply must supply at least 720mA +5VSB.

3. H/W SETUP

Connectors

19) IDE Activity LED (2 pin IDELED)

+3.3 Volts

-12.0 Volts

Power Supply On

A7V133-VM

Ground

Ground Ground Ground

-5.0 Volts +5.0 Volts +5.0 Volts

+3.3 Volts +3.3 Volts Ground +5.0 Volts Ground +5.0 Volts Ground Power Good +5V Standby +12.0 Volts

A7V133-VM ATX Power Connector

This connector supplies power to the cabinet’s IDE activity LED. Read and write activity by devices connected to the Primary/Secondary IDE and Primary/ Secondary ATA100 connectors will cause the LED to light up.

TIP: If the case-mounted LED does not light, try reversing the 2-pin plug.

A7V133-VM

IDELED

A7V133-VM IDE Activity LED

36 ASUS A7V133-VM User’s Manual

3. HARDWARE SETUP

The following HPANEL illustration is used for items 20–24:

HPANEL

Power LED

PLED

+5 V

Speaker

Connector

Ground

+5V

Ground

SPKR

Ground

ResetCon

Reset SW

Ground

ExtSMI#

PWR_SW

A7V133-VM

SMI Lead

Requires an ATX power supply.

ATX Power Switch*

A7V133-VM System Panel Connectors

20) System Warning Speaker Connector (4-pin SPEAKER)

This 4-pin connector connects to the case-mounted speaker. Two sources (LINE_OUT and SPEAKER) will allow you to hear system beeps and warnings. Only SPEAKER will allow you to hear system beeps before the integrated audio has been properly initialized.

21) System Power LED Lead (3-1 pin PWR.LED)

This 3-1 pin connector connects the system power LED, which lights when the system is powered on and blinks when it is in sleep mode.

22) Reset Switch Lead (2-pin RESET)

This 2-pin connector connects to the case-mounted reset switch for rebooting your computer without having to turn off your power switch. This is a preferred method of rebooting to prolong the life of the system’s power supply.

Connectors

3. H/W SETUP

223) ATX Power Switch Lead (2-pin PWR.SW)

The system power is controlled by a momentary switch connected to this lead. Pressing the button once will switch the system between ON and SOFT OFF. Pushing the switch while in the ON mode for more than 4 seconds will turn the system off. The system power LED shows the status of the system’s power.

24) System Management Interrupt Lead (2-pin SMI)

This allows the user to manually place the system into a suspend mode or “Green” mode, where system activity is decreased to save electricity and expand the life of certain components when the system is not in use. This 2-pin connector connects to the case-mounted suspend switch. If you do not have a switch for the connector, you may use the “Turbo Switch.” SMI is activated when it detects a short to open moment and therefore leaving it shorted will not cause any problems. This may require one or two presses depending on the position of the switch. W ake-up can be controlled by settings in the BIOS but the keyboard will always allow wake-up (the SMI lead cannot wake up the system).

ASUS A7V133-VM User’s Manual 37

(This page was intentionally left blank.)

3. H/W SETUP

Connectors

3. HARDWARE SETUP

38 ASUS A7V133-VM User’s Manual

3. HARDWARE SETUP

3.9 Starting Up the First Time

1. After all connections are made, close the system case cover.

2. Be sure that all switches are off (in some systems, marked with

3. Connect the power supply cord into the power supply located on the back of your system case according to your system user’s manual.

4. Connect the power cord into a power outlet that is equipped with a surge protector .

5. You may then turn on your devices in the following order: a. Your monitor b. External SCSI devices (starting with the last device on the chain) c. Your system power. For ATX power supplies, you need to switch on

the power supply as well as press the ATX power switch on the front of the case.

6. The power LED on the front panel of the system case will light. For ATX power supplies, the system LED will light when the ATX power switch is pressed. The LED on the monitor may light up or switch between orange and green after the system’s if it complies with “green” standards or if it has a power standby feature. The system will then run power-on tests. While the tests are running, the BIOS will alarm beeps or additional messages will appear on the screen. If you do not see anything within 30 seconds from the time you turn on the power, the system may have failed a power-on test. Recheck your jumper settings and connections or call your retailer for assistance.

Powering Up

3. H/W SETUP

Award BIOS Beep Codes

Beep Meaning

One short beep when No error during POST displaying logo Long beeps in an endless loop No DRAM installed or detected One long beep followed by Video card not found or video card three short beeps memory bad High frequency beeps when CPU overheated

system is working System running at a lower frequency

ASUS A7V133-VM User’s Manual 39

7. During power-on, hold down <Delete> to enter BIOS setup. Follow the

* Powering Off your computer: You must first exit or shut down your

3. H/W SETUP

Powering Up

3. HARDWARE SETUP

instructions in 4. BIOS SETUP.

operating system before switching off the power switch. For ATX power supplies, you can press the ATX power switch after exiting or shutting down your operating system. If you use Windows 9X, click the Start button, click Shut Down, and then click Shut down the computer? The power supply should turn off after Windows shuts down.

NOTE: The message “Y ou can now safely turn of f your computer” will not appear when shutting down with ATX power supplies.

ASUS A7V133-VM User’s Manual40

4. BIOS SETUP

4.1 Managing and Updating Your BIOS

4.1.1 Upon First Use of the Computer System

It is recommended that you save a copy of the original motherboard BIOS along with a Flash Memory Writer utility (AFLASH.EXE) to a bootable floppy disk in case you need to reinstall the BIOS later . AFLASH.EXE is a Flash Memory Writer utility that updates the BIOS by uploading a new BIOS file to the programmable flash ROM on the motherboard. This file works only in DOS mode. To determine the BIOS version of your motherboard, check the last four numbers of the code displayed on the upper lefthand corner of your screen during bootup. Larger numbers represent a newer BIOS file.

1. Type FORMAT A:/S at the DOS prompt to create a bootable system floppy disk. DO NOT copy AUTOEXEC.BAT & CONFIG.SYS to the disk.

2. Type COPY D:\AFLASH\AFLASH.EXE A:\ (assuming D is your CD- ROM drive) to copy AFLASH.EXE to the just created boot disk.

NOTE: AFLASH works only in DOS mode. It will not work with DOS prompt in Windows and will not work with certain memory drivers that may be loaded when you boot from your hard drive. It is recommended that you reboot using a floppy.

3. Reboot your computer from the floppy disk. NOTE: BIOS setup must specify “Floppy” as the first item in the boot sequence.

4. In DOS mode, type A:\AFLASH <Enter> to run AFLASH.

Updating BIOS

4. BIOS SETUP

IMPORTANT! If “unknown” is displayed after Flash Memory:, the memory

chip is either not programmable or is not supported by the ACPI BIOS and therefore, cannot be programmed by the Flash Memory Writer utility.

ASUS A7V133-VM User’s Manual 41

4. BIOS SETUP

5. Select 1. Save Current BIOS to File from the Main menu and press <Enter>. The Save Current BIOS To File screen appears.

6. Type a filename and the path, for example, A:\XXX-XX.XXX and then press <Enter>.

4.1.2 Updating BIOS Procedures

WARNING! Only update your BIOS if you have problems with your mother-

board and you know that the new BIOS revision will solve your problems. Careless updating can result in your motherboard having more problems!

4. BIOS SETUP

Updating BIOS

1. Download an updated ASUS BIOS file from the Internet (WWW or

2. Boot from the disk you created earlier.

3. At the “A:\” prompt, type AFLASH and then press <Enter>.

4. At the Main Menu, type 2 and then press <Enter>. The Update BIOS

5. T ype the filename of your new BIOS and the path, for example, A:\XXX-

FTP) (see ASUS CONTACT INFORMATION on page 3 for details) and save to the disk you created earlier.

Including Boot Block and ESCD screen appears.

XX.XXX, and then press <Enter>. NOTE: To cancel this operation, press <Enter>.

ASUS A7V133-VM User’s Manual42

4. BIOS SETUP

6. When prompted to confirm the BIOS update, press Y to start the update.

7. The utility starts to program the new BIOS information into the flash ROM. The boot block will be updated automatically only when necessary. This will minimize the chance that a failed update will prevent your system from booting up. When the programming is finished, Flashed Successfully will be displayed.

8. Follow the onscreen instructions to continue.

WARNING! If you encounter problems while updating the new BIOS, DO NOT

turn off your system since this might prevent your system from booting up. Just repeat the process, and if the problem still persists, update the original BIOS file you saved to disk above. If the Flash Memory Writer utility was not able to successfully update a complete BIOS file, your system may not be able to boot up. If this happens, your system will need servicing.

ASUS A7V133-VM User’s Manual 43

Updating BIOS

4. BIOS SETUP

4.2 BIOS Setup Program

This motherboard supports a programmable EEPROM that can be updated using the provided utility as described in 4.1 Managing and Updating Your BIOS.

The utility is used if you are installing a motherboard, reconfiguring your system, or prompted to “Run Setup”. This section describes how to configure your system using this utility.

Even if you are not prompted to use the Setup program, at some time in the future you may want to change the configuration of your computer. For example, you may want to enable the Security Password Feature or make changes to the power management settings. It will then be necessary to reconfigure your system using the BIOS Setup program so that the computer can recognize these changes and record them in the CMOS RAM of the EEPROM.

The EEPROM on the motherboard stores the Setup utility. When you start up the computer, the system provides you with the opportunity to run this program. This appears during the Power-On Self Test (POST). Press <Delete> to call up the Setup utility . If you are a little bit late in pressing the mentioned key, POST will continue with its test routines, thus preventing you from calling up Setup. If you still need to call Setup, restart the system by pressing <Ctrl> + <Alt> + <Delete>, or by pressing the Reset button on the system chassis. You can also restart by turning the

4. BIOS SETUP

Updating BIOS

system off and then back on again. But do so only if the first two methods fail.

4. BIOS SETUP

The Setup program has been designed to make it as easy to use as possible. It is a menu-driven program, which means you can scroll through the various sub-menus and make your selections among the predetermined choices.

To access the BIOS Setup program, press the <Delete> key after the computer has run through its POST.

NOTE: Because the BIOS software is constantly being updated, the following BIOS screens and descriptions are for reference purposes only and may not reflect your BIOS screens exactly.

ASUS A7V133-VM User’s Manual44

4. BIOS SETUP

4.2.1 BIOS Menu Bar

The top of the screen has a menu bar with the following selections:

MAIN Use this menu to make changes to the basic system configuration. ADVANCED Use this menu to enable and make changes to the advanced

features.

POWER Use this menu to configure and enable Power Management fea-

tures.

BOOT Use this menu to configure the default system device used to lo-

cate and load the Operating System.

EXIT Use this menu to exit the current menu or specify how to exit the

Setup program.

To access the menu bar items, press the right or left arrow key on the keyboard until the desired item is highlighted.

ASUS A7V133-VM User’s Manual 45

4. BIOS SETUP

Program Information

4. BIOS SETUP

4.2.2 Legend Bar

At the bottom of the Setup screen you will notice a legend bar. The keys in the legend bar allow you to navigate through the various setup menus. The following table lists the keys found in the legend bar with their corresponding alternates and functions.

Navigation Key(s) Function Description

<F1> or <Alt + H> Displays the General Help screen from anywhere in the BIOS

Setup

<Esc> Jumps to the Exit menu or returns to the main menu from a sub-

← or → (keypad arrow) Selects the menu item to the left or right ↑ or ↓ (keypad arrow) Moves the highlight up or down between fields

- (minus key) Scrolls backward through the values for the highlighted field + (plus key) or spacebar Scrolls forward through the values for the highlighted field <Enter> Brings up a selection menu for the highlighted field <Home> or <PgUp> Moves the cursor to the first field <End> or <PgDn> Moves the cursor to the last field

<F5> Resets the current screen to its Setup Defaults <F10> Saves changes and exits Setup

Menu Introduction

4. BIOS SETUP

ASUS A7V133-VM User’s Manual46

4. BIOS SETUP

General Help

In addition to the Item Specific Help window, the BIOS setup program also provides a General Help screen. This screen can be called up from any menu by simply pressing <F1> or the <Alt> + <H> combination. The General Help screen lists the legend keys with their corresponding alternates and functions.

Saving Changes and Exiting the Setup Program

See 4.7 Exit Menu for detailed information on saving changes and exiting the setup program.

Scroll Bar

When a scroll bar appears to the right of a help window, it indicates that there is more information to be displayed that will not fit in the window. Use <PgUp> and <PgDn> or the up and down arrow keys to scroll through the entire help document. Press <Home> to display the first page, press <End> to go to the last page. To exit the help window, press <Enter> or <Esc>.

Sub-Menu

Note that a right pointer symbol (as shown in the left view) appears to the left of certain fields. This pointer indicates that a sub-menu can be launched from this field. A sub-menu contains additional options for a field parameter . To call up a submenu, simply move the highlight to the field and press <Enter>. The sub-menu will then immediately appear. Use the legend keys to enter values and move from field to field within a sub-menu just as you would within a menu. Use the <Esc> key to return to the main menu.

Take some time to familiarize yourself with each of the legend keys and their corresponding functions. Practice navigating through the various menus and submenus. If you accidentally make unwanted changes to any of the fields, use the set default hot key <F5>. While moving around through the Setup program, note that explanations appear in the Item Specific Help window located to the right of each menu. This window displays the help text for the currently highlighted field.

NOTE: The item heading in square brackets represents the default setting for that field.

4. BIOS SETUP

Menu Introduction

ASUS A7V133-VM User’s Manual 47

4. BIOS SETUP

4.3 Main Menu

When the Setup program is accessed, the following screen appears:

System Time [XX:XX:XX]

Sets your system to the time that you specify (usually the current time).

4. BIOS SETUP

Main Menu

The format is hour, minute, second. Valid values for hour, minute and second are Hour: (00 to 23), Minute: (00 to 59), Second: (00 to 59). Use the <Tab> or <Shift> + <Tab> keys to move between the hour, minute, and second fields.

System Date [XX/XX/XXXX]

Sets your system to the date that you specify (usually the current date). The format is month, day , year . Valid values for month, day, and year are Month: (1 to 12), Day: (1 to 31), Y ear: (100 year range). Use the <T ab> or <Shift> + <Tab> keys to move between the month, day, and year fields.

Legacy Diskette A [1.44M, 3.5 in.], Legacy Diskette B [None]

Sets the type of floppy drives installed. Configuration options: [None] [360K, 5.25 in.] [1.2M , 5.25 in.] [720K , 3.5 in.] [1.44M, 3.5 in.] [2.88M, 3.5 in.]

Floppy 3 Mode Support [Disabled]

This is required to support older Japanese floppy drives. Floppy 3 Mode support will allow reading and writing of 1.2MB (as opposed to 1.44MB) on a 3.5-inch diskette. Configuration options: [Disabled] [Drive A] [Drive B] [Both]

ASUS A7V133-VM User’s Manual48

4. BIOS SETUP

4.3.1 Primary & Secondary Master/Slave

NOTE: Before attempting to configure a hard disk drive, make sure you have the configuration information supplied by the manufacturer of the drive. Incorrect settings may cause your system to not recognize the installed hard disk. To allow the BIOS to detect the drive type automatically, select [Auto].

Type [Auto]

Select [Auto] to automatically detect an IDE hard disk drive. If automatic detection is successful, the correct values will be filled in for the remaining fields on this sub-menu. If automatic detection fails, your hard disk drive may be too old or too new. You can try updating your BIOS or enter the IDE hard disk drive parameters manually.

NOTE: After the IDE hard disk drive information has been entered into BIOS, new IDE hard disk drives must be partitioned (such as with FDISK) and then formatted before data can be read from and write on. Primary IDE hard disk drives must have its partition set to active (also possible with FDISK).

4. BIOS SETUP

Master/Slave Drives

Other options for the Type field are:

[None] - to disable IDE devices

ASUS A7V133-VM User’s Manual 49

4. BIOS SETUP

IMPORTANT: If your hard disk was already formatted on an older previous system,

incorrect parameters may be detected. You will need to enter the correct parameters manually or use low-level format if you do not need the data stored on the hard disk.

If the parameters listed differ from the ones used when the disk was formatted, the disk will not be readable. If the auto-detected parameters do not match the ones that should be used for your disk, you should enter the correct ones manually by setting [User Type HDD].

[User Type HDD]

Master/Slave Drives

4. BIOS SETUP

Manually enter the number of cylinders, heads and sectors per track for your drive. Refer to your drive documentation or look on the drive for this information. If no drive is installed or if you are removing a drive and not replacing it, select [None].

Translation Method [LBA]

Select the hard disk drive type in this field. When Logical Block Addressing is enabled, 28-bit addressing of the hard drive is used without regard for cylinders, heads, or sectors. Note that LBA Mode is necessary for drives with greater than 504MB in storage capacity . Configuration options: [LBA] [LARGE] [Normal] [Match Partition Table] [Manual]

Cylinders

This field configures the number of cylinders. Refer to your drive documentation to determine the correct value to enter into this field. NOTE: To make changes to this field, the Type field must be set to [User Type HDD] and the Translation Method field must be set to [Manual].

ASUS A7V133-VM User’s Manual50

4. BIOS SETUP

Head

This field configures the number of read/write heads. Refer to your drive documentation to determine the correct value to enter into this field. NOTE: To make changes to this field, the Type field must be set to [User Type HDD] and the Translation Method field must be set to [Manual].

Sector

This field configures the number of sectors per track. Refer to your drive documentation to determine the correct value to enter into this field. NOTE: To make changes to this field, the Type field must be set to [User Type HDD] and the Translation Method field must be set to [Manual].

CHS Capacity

This field shows the drive’s maximum CHS capacity calculated automati- cally by the BIOS from the drive information you entered.

Maximum LBA Capacity

This field shows the drive’s maximum LBA capacity calculated automati- cally by the BIOS from the drive information you entered.

Multi-Sector Transfers [Maximum]

This option automatically sets the number of sectors per block to the highest number supported by the drive. This field can also be configured manually . Note that when this field is automatically configured, the set value may not always be the fastest value for the drive. Refer to the documentation that came with your hard drive to determine the optimal value and set it manually. NOTE: To make changes to this field, the Type field must be set to [User Type HDD]. Configuration options: [Disabled] [2 Sectors] [4 Sectors] [8 Sectors] [16 Sectors] [32 Sectors] [Maximum]

SMART Monitoring [Disabled]

This allows the enabling or disabling of the S.M.A.R.T. (Self-Monitoring, Analysis and Reporting Technology) system which utilizes internal hard disk drive monitoring technology . This feature is normally disabled because system resources used in this feature may decrease system performance. Configuration options: [Disabled] [Enabled]

PIO Mode [4]

This option lets you set a PIO (Programmed Input/Output) mode for the IDE device. Modes 0 through 4 provide successively increased performance. Configuration options: [0] [1] [2] [3] [4]

4. BIOS SETUP

Master/Slave Drives

Ultra DMA Mode [Disabled]

Ultra DMA capability allows improved transfer speeds and data integrity for compatible IDE devices. Set to [Disabled] to suppress Ultra DMA capability. NOTE: To make changes to this field, the Type field must be set to [User Type HDD]. Configuration options: [0] [1] [2] [3] [4] [Disabled]

ASUS A7V133-VM User’s Manual 51

4. BIOS SETUP

Other options for “Type:” are: [None] - for nothing

[CD-ROM] - for IDE CD-ROM drives [LS-120] - for LS-120 compatible floppy disk drives [ZIP] - for ZIP compatible disk drives [MO] - for IDE magneto optical disk drives [Other ATAPI Device] - for IDE devices not listed here

After using the legend keys to make your selections on this sub-menu, press the <Esc> key to exit back to the Main menu. When the Main menu appears, you will notice that the drive size appear in the field for the hard disk drive that you just configured.

4.3.2 Keyboard Features

4. BIOS SETUP

Main Menu

Boot Up NumLock Status [On]

This field enables users to activate the Number Lock function upon system boot. Configuration options: [Off] [On]

Keyboard Auto-Repeat Rate [12/Sec]

This controls the speed at which the system registers repeated keystrokes. Options range from 6 to 30 characters per second. Configuration options: [6/Sec] [8/Sec] [10/Sec] [12/Sec] [15/Sec] [20/Sec] [24/Sec] [30/Sec]

Keyboard Auto-Repeat Delay [1/4 Sec]

This field sets the time interval for displaying the first and second characters. Configuration options: [1/4 Sec] [1/2 Sec] [3/4 Sec] [1 Sec]

ASUS A7V133-VM User’s Manual52

4. BIOS SETUP

Language [English]

This allows selection of the BIOS’ displayed language. Currently only English is available.

Supervisor Password [Disabled] / User Password [Disabled]

These fields allow you to set the passwords. To set the password, highlight the appropriate field and press <Enter>. T ype in a password and press <Enter>. You can type up to eight alphanumeric characters. Symbols and other keys are ignored. To confirm the password, type the password again and press the <Enter>. The password is now set to [Enabled]. This password allows full access to the BIOS Setup menus. To clear the password, highlight this field and press <Enter>. The same dialog box as above will appear . Press <Enter> and the password will be set to [Disabled].

A Note about Passwords

The BIOS Setup program allows you to specify passwords in the Main menu. The passwords control access to the BIOS during system startup. The passwords are not case sensitive. In other words, it makes no difference whether you enter a password using upper or lowercase letters. The BIOS Setup program allows you to specify two separate passwords:

a Supervisor password and a User password. When disabled, anyone may access all BIOS Setup program functions. When enabled, the Supervisor password is required for entering the BIOS Setup program and having full access to all configuration fields.

Forgot the Password?

If you forgot the password, you can clear the password by erasing the CMOS Real Time Clock (RTC) RAM. The RAM data containing the password information is powered by the onboard button cell battery. To erase the R TC RAM: (1) Unplug your computer, (2) Short the solder points, (3) Turn ON your computer, (4) Hold down <Delete> during bootup and enter BIOS setup to re-enter user preferences.

Short solder points to Clear CMOS

A7V133-VM

A7V133-VM Clear RTC RAM

Halt On [All Errors]

This field determines which types of errors will cause the system to halt. Configuration options: [All Errors] [No Error] [All but Keyboard] [All but Disk] [All but Disk/Keyboard]

Main Menu

4. BIOS SETUP

Installed Memory [XXX MB]

This display-only field displays the amount of conventional memory detected by the system during bootup. You do not need to make changes to this field.

ASUS A7V133-VM User’s Manual 53

4. BIOS SETUP

4.4 Advanced Menu

Operating Frequency Setting [User Define]

When the motherboard is set to JumperFree™ mode, this field allows you to configure the external frequency of your CPU. Select [User Define] if you want to make changes to the CPU Frequency field. When [Standard] is selected, CPU (external) Frequency will be fixed at 100MHz. Configu-

4. BIOS SETUP

Advanced Menu

ration options: [Standard] [User Define]

CPU Frequency (if Operating Frequency is set to [User Define])

This feature tells the clock generator which frequency to send to the system bus and PCI bus. The bus frequency (external frequency0 multiplied by the bus frequency equals the CPU speed (the CPU’s internal frequency). Note that selecting a frequency higher than what the CPU manufacturer recommends may cause the system to hang or crash. See System Hangup later in this section.

DRAM Frequency

This field determines whether the memory clock frequency is set to be in synchronous or asynchronous mode with respect to the CPU Frequency. This must be set in conjunction with CPU (external) Frequency to match the speed of your SDRAM. When you press <Enter> on this field, the first available option in the pop-up menu equals the CPU Frequency you select for the previous field, and the second available option is the CPU Frequency multiplied by 4/3. To maintain and ensure system stability, DRAM Fre- quency is set to [100 MHz] when the BIOS setup default settings are loaded/ selected.

ASUS A7V133-VM User’s Manual54

4. BIOS SETUP

System Performance Setting [Normal]

T o optimize the speed performance of the motherboard circuits and the CPU, change the setting to [Optimal]. For system stability, keep the default setting, [Normal]. Configuration options: [Optimal] [Normal]

CPU Level 1 Cache, CPU Level 2 Cache [Enabled]

These fields allow you to choose from the default of [Enabled] or choose [Disabled] to turn on or off the CPU’s Level 1 and Level 2 built-in cache. Configuration options: [Disabled] [Enabled]

CPU Level 2 Cache ECC Check [Disabled]

This function controls the ECC capability in the CPU level 2 cache. Configuration options: [Disabled] [Enabled]

BIOS Update [Enabled]

This functions as an update loader integrated into the BIOS to supply the processor with the required data. In the default position of [Enabled], the BIOS will load the update on all processors during system bootup. Configuration options: [Disabled] [Enabled]

PS/2 Mouse Function Control [Auto]

The default of [Auto] allows the system to detect a PS/2 mouse on startup. If detected, IRQ12 will be used for the PS/2 mouse. IRQ12 will be reserved for expansion cards only if a PS/2 mouse is not detected. [Enabled] will always reserve IRQ12, whether on startup a PS/2 mouse is detected or not. Configuration options: [Enabled] [Auto]

USB Legacy Support [Auto]

This motherboard supports Universal Serial Bus (USB) devices. The default of [Auto] allows the system to detect a USB device on startup. If detected, the USB controller will be enabled. If not detected, the USB controller will be disabled. When this field is set to [Disabled], the USB controller is disabled no matter whether you are using a USB device or not. Configuration options: [Disabled] [Enabled] [Auto]

OS/2 Onboard Memory > 64M [Disabled]

When using OS/2 operating systems with installed DRAM of greater than 64MB, you need to set this option to [Enabled]; otherwise, leave this on [Disabled]. Configuration options: [Disabled] [Enabled]

Advanced Menu

4. BIOS SETUP

ASUS A7V133-VM User’s Manual 55

4. BIOS SETUP

Notes for JumperFree Mode

System Hangup

If your system crashes or hangs due to improper frequency settings, power OFF your system and restart. The system will start up in safe mode running at a DRAM-to-CPU frequency ratio of 3:3 and a bus speed of 100MHz. You will then be led to BIOS setup to adjust the configurations.

JumperFree Mode

4. BIOS SETUP

ASUS A7V133-VM User’s Manual56

4. BIOS SETUP

4.4.1 Chip Configuration

(Scroll down to see more items as shown.)

Onboard PCI IDE Enable [Both]

You can select to enable the primary IDE channel, secondary IDE channel, both, or disable both channels. Configuration options: [Both] [Primary] [Secondary] [Disabled]

Spread Spectrum Control [Enabled]

Leave on default setting. Spread spectrum typically reduces system electromagnetic interference (EMI) by 8dB to 10dB.

AGP 4X Drive Strength [Auto]

Configuration options: [Auto] [Manual]

AGP Drive Strength P Ctrl [C]

Configuration options: [0] [1] [2]...[F]

AGP Drive Strength N Ctrl [E]

Configuration options: [0] [1] [2]...[F]

AGP Fast Write [Disabled]

Configuration options: [Disabled] [Enabled]

(When AGP 4X Drive Strength set to [Manual])

4. BIOS SETUP

Chip Configuration

ASUS A7V133-VM User’s Manual 57

4. BIOS SETUP

SDRAM Configuration [By SPD]

This sets the optimal timings for SDRAM related fields, depending on the memory modules that you are using. Default setting is [By SPD], which configures the subsequent 3 items by reading the contents in the SPD (Serial Presence Detect) device. The EEPROM on the memory module stores critical parameter information about the module, such as memory type, size, speed, voltage interface, and module banks. Configuration options: [User Define] [7ns(143MHz)] [8ns(125MHz)] [By SPD]

SDRAM CAS Latency

This controls the latency between the SDRAM read command and the time that the data actually becomes available. NOTE: This field will only be adjustable when SDRAM Configuration is set to [User Define].

SDRAM RAS Precharge Time

This controls the idle clocks after issuing a precharge command to the SDRAM. NOTE: This field will only be adjustable when SDRAM Con- figuration is set to [User Define].

SDRAM RAS to CAS Delay

This controls the latency between the SDRAM active command and the read/write command. NOTE: This field will only be adjustable when SDRAM Configuration is set to [User Define].

Chip Configuration

4. BIOS SETUP

Dynamic Burst [Disabled]

Configuration options: [Disabled] [Enabled]

PCI Master Read Caching [Disabled]

Default: [Enabled] for Athlon Processors / [Disabled] for Duron Processors

Leave on default setting. Configuration options: [Disabled] [Enabled]

Delayed Transaction [Disabled]

Default: [Enabled] for Athlon Processors / [Disabled] for Duron Processors

Leave on default setting. Enabled, this frees the PCI Bus when the CPU is accessing 8-bit ISA devices that normally consume about 50-60 PCI Clocks without PCI delayed transaction. Select [Disabled] for ISA devices that are not PCI 2.1 compliant. Configuration options: [Disabled] [Enabled]

PCI to DRAM Prefetch [Enabled]

Configuration options: [Disabled] [Enabled]

PCI to DRAM Post-Write [Enabled]

Configuration options: [Disabled] [Enabled]

ASUS A7V133-VM User’s Manual58

4. BIOS SETUP

Byte Merge [Disabled]

To optimize the data transfer on PCI, this merges a sequence of individual memory writes (bytes or words) into a single 32-bit block of data. However, byte merging may only be done when the bytes within a data phase are in a prefetchable address range. Configuration options: [Disabled] [Enabled]

DRAM Read Latch Delay [Auto]

Configuration options: [-0.01 ns] [0.75 ns] [1.72 ns] [2.69 ns] [-0.01 ns] [2.11 ns] [3.08 ns] [4.05 ns]...[Auto]

Memory Early/Delay Write [Auto]

Configuration options: [0.0 ns] [0.5 ns] [1.0 ns] [1.5 ns] [-0.5 ns] [-1.0 ns] [-1.5 ns] [Auto]

DIMM Interleave Setting [Auto]

Configuration options: [Auto] [Disabled]

Graphics Aperture Size [64MB]

This feature allows you to select the size of mapped memory for AGP graphic data. Configuration options: [4MB] [8MB] [16MB] [32MB] [64MB] [128MB] [256MB]

VGA Shared Memory Size [16MB]

Configuration options: [8MB] [16MB] [32MB]

Video Memory Cache Mode [UC]

USWC (uncacheable, speculative write combining) is a new cache technology for the video memory of the processor. It can greatly improve the display speed by caching the display data. You must set this to UC (uncacheable) if your display card cannot support this feature; otherwise your system may not boot. Configuration options: [UC] [USWC]

4. BIOS SETUP

ASUS A7V133-VM User’s Manual 59

4. BIOS SETUP

4.4.2 I/O Device Configuration

Onboard FDC Swap A & B [No Swap]

This field allows you to reverse the hardware drive letter assignments of your floppy disk drives. Configuration options: [No Swap] [Swap AB]

Onboard Serial Port 1 [3F8H/IRQ4]

I/O Device Config

4. BIOS SETUP

Onboard Serial Port 2 [2F8H/IRQ3]

These fields allow you to set the addresses for the onboard serial connectors. Serial Port 1 and Serial Port 2 must have different addresses. Configuration options: [3F8H/IRQ4] [2F8H/IRQ3] [3E8H/IRQ4] [2E8H/IRQ10] [Disabled]

UART2 Use Infrared [Disabled]

When enabled, this field activates the onboard standard infrared feature and sets the second serial UART to support the infrared module connector on the motherboard. If your system already has a second serial port connected to the onboard COM2 connector, it will no longer work if you enable the infrared feature. See Standard and Con- sumer Infrared Module Connector in 3.8 External Connectors. Configuration options: [Disabled] [Enabled]

ASUS A7V133-VM User’s Manual60

4. BIOS SETUP

Onboard Parallel Port [378H/IRQ7]

This field sets the address of the onboard parallel port connector. If you disable this feature, Parallel Port Mode and ECP DMA Select configurations will not be available. Configuration options: [Disabled] [378H/IRQ7] [278H/IRQ5]

Parallel Port Mode [ECP+EPP]

This field allows you to set the operation mode of the parallel port. [Normal] allows normal-speed operation but in one direction only; [EPP] allows bidirectional parallel port operation; [ECP] allows the parallel port to operate in bidirectional DMA mode; [ECP+EPP] allows normal speed operation in a two-way mode. Configuration options: [Normal] [ECP] [EPP] [ECP+EPP]

ECP DMA Select [3]

This field allows you to configure the parallel port DMA channel for the selected ECP mode. This selection is available only if you select [ECP] or [ECP+EPP] in Parallel Port Mode above. Configuration options: [1] [3]

Onboard Peripheral Resource Control

Onboard Creative Audio Controller [Auto]

[Auto] allows the motherboard’s BIOS to detect whether any network/ audio device is funtional through the onboard Creative Audio Controller chipset. If a network/audio device is detected, the onboard Creative Audio Controller chipset controller will be enabled. If no device is detected, the controller will be disabled. If conflicts arise with the onboard network/ audio controller, set the appropriate field to [Disabled]. Configuration options: [Auto] [Disabled]

4. BIOS SETUP

I/O Device Config

ASUS A7V133-VM User’s Manual 61

4. BIOS SETUP

Onboard AC97 Audio Controller [Auto]

[Auto] allows the motherboard’s BIOS to detect whether you are using any net- work/audio device. If a network/audio device is detected, the onboard network/ audio controller will be enabled; if no network/audio device is detected, the onboard network/audio controller will be disabled. If you have conflicts with the onboard network/audio controller, you may set the appropriate field to [Disabled].

Onboard Legacy Audio Support [Disabled]

The onboard chipset is integrated with a SoundBlaster Pro controller . To use it, you must enable this field. Leave on the default setting [Disabled] if you want to use an add-on audio device. NOTE: To display the rest of the setup items, this field must be enabled (as shown below).

I/O Device Config

4. BIOS SETUP

Sound Blaster Emulation [Disabled]

Select [Enabled] for this field if you want to use the Sound Blaster™ emulation feature.

Sound Blaster I/O Base Address [220h-22Fh] Sound Blaster IRQ [IRQ5] Sound Blaster DMA [DMA 1]

These fields set the I/O address, IRQ, and DMA channel for the Sound Blaster™ feature.

MPU 401 [Enabled]

Enable this field if you want to use the MIDI device onboard.

MPU 401 I/O Base Address [300h-303h]

This sets the I/O address for the onboard MIDI device.

FM Enable (388h-38Bh) [Disabled]

This field enables or disables the FM modulation feature.

Game Port Function [Enable (200]

Enable this field to use the game port. Configuration options: [Disabled] [Enable (200h-207h)]

ASUS A7V133-VM User’s Manual62

4. BIOS SETUP

4.4.3 PCI Configuration

Slot 1, Slot 2, Slot 3, Slot 4/5/6 IRQ [Auto]

These fields set how IRQ use is determined for each PCI slot. The default setting for each field is [Auto], which utilizes auto-routing to determine IRQ use. Configuration options: [Auto] [NA] [3] [4] [5] [7] [9] [10] [11] [12] [14] [15]

PCI/VGA Palette Snoop [Disabled]

Some nonstandard VGA cards, such as graphics accelerators or MPEG video cards, may not show colors properly. The setting [Enabled] should correct this problem. Otherwise, leave this on the default setting of [Disabled]. Configuration options: [Disabled] [Enabled]

PCI Latency Timer [32]

Leave on default setting for best performance vs. stability.

SYMBIOS SCSI BIOS [Auto]

[Auto] allows the motherboard’s BIOS to detect whether you have a Symbios SCSI card. If the Symbios SCSI card is detected, the motherboard’s Symbios BIOS will be enabled; if no Symbios SCSI card is detected, the onboard Symbios SCSI BIOS will be disabled.

4. BIOS SETUP

PCI Configuration

[Disabled] will disable the motherboard’s Symbios SCSI BIOS so that the BIOS on an add-on Symbios SCSI card can be used. If your Symbios SCSI card does not have a BIOS, the Symbios SCSI card will not function. Configuration options: [Auto] [Disabled]

ASUS A7V133-VM User’s Manual 63

4. BIOS SETUP

USB Function [Enabled]

This motherboard supports Universal Serial Bus (USB) devices. Set to [Enabled] if you want to use USB devices. Configuration options: [Disabled] [Enabled]

Primary VGA BIOS [PCI Card]

If your computer has a PCI VGA card and on-board VGA is available, this field allows you to select which of the VGA devices will act as your primary graphics controller. The default, [PCI Card], allows your PCI graphics card to take precedence when detected. [On-Board] uses on-board VGA as the primary graphics controller. Configuration options: [PCI Card] [On-Board]

PCI/PNP IRQ Resource Exclusion

PCI Configuration

4. BIOS SETUP

IRQ XX Reserved for Legacy Device [No/ICU]

These fields indicate whether or not the displayed IRQ for each field is being used by an onboard legacy (non-PnP) device. The default value indicates either that the displayed IRQ is not used or that ISA Configuration Utility (ICU) is being used to determine if a legacy device is using that IRQ. Configuration options: [No/ICU] [Yes]

ASUS A7V133-VM User’s Manual64

4. BIOS SETUP

PCI/PNP DMA Resource Exclusion

DMA x Reserved for Legacy Device [No/ICU]

These fields indicate whether or not the displayed DMA channel for each field is being used by an onboard legacy (non-PnP) device. The default setting indicates either that the displayed DMA channel is not used or an ICU is being used to determine if an ISA device is using that channel. Configuration options: [No/ICU] [Yes]

4. BIOS SETUP

PCI Configuration

ASUS A7V133-VM User’s Manual 65

4. BIOS SETUP

PCI/PNP UMB Resource Exclusion

Reserved MEM Block BASE [No/ICU]

This field allows you to set the base address and block size of an onboard legacy ISA device that uses any memory segment within the C800 and DFFF address range. If you have such a device and you are not using an ICU to specify its address range, select a base address from the six available op-

PCI Configuration

4. BIOS SETUP

tions; the Reserved MEM Block SIZE field will then appear for selecting the block size. If you have more than one legacy device onboard that requires the use of this address range, you can increase the block size to 8K, 16K, 32K, or 64K. If you are using an ICU to accomplish this task, leave Reserved MEM Block BASE to its default setting of [No/ICU]. Configuration options: [No/ICU] [C800] [CC00] [D000] [D400] [D800] [DC00]

ASUS A7V133-VM User’s Manual66

4. BIOS SETUP

4.4.4 Shadow Configuration

Video ROM BIOS Shadow [Enabled]

This field allows you to change the video BIOS location from ROM to RAM. Relocating to RAM enhances system performance, as information access is faster than the ROM. Configuration options: [Disabled] [Enabled]

C8000-DFFFF Shadow [Disabled]

These fields are used for shadowing other expansion card ROMs. If you install other expansion cards with ROMs on them, you will need to know which addresses the ROMs use to shadow them specifically. Shadowing a ROM reduces the memory available between 640K and 1024K by the amount used for this purpose. Configuration options: [Disabled] [Enabled]

4. BIOS SETUP

Shadow Configuration

ASUS A7V133-VM User’s Manual 67

4. BIOS SETUP

4.5 Power Menu

The Power menu allows you to reduce power consumption. This feature turns off the video display and shuts down the hard disk after a period of inactivity.

Power Management [User Define]

This option must be enabled to use any of the automatic power saving features. If this menu item is set to [Disabled], power management features will not function

4. BIOS SETUP

Power Menu

regardless of other field settings on this menu. The [User Define] option allows you to make your own selections in the Power menu. When set to [Max Saving], system power will be conserved to its greatest amount. The Suspend Mode field will then be set to predefined value that ensures maximum power savings.

This field acts as the master control for the power management modes. [Max Saving] puts the system into power saving mode after a brief period of system inactivity; [Min Saving] is almost the same as [Max Saving] except that the system inactivity period is longer; [Disabled] disables the power saving features; [User Define] allows you to set power saving options according to your preference. Configuration options: [User Define] [Disabled] [Min Saving] [Max Saving]

IMPORT ANT: Advanced Power Management (APM) should be installed to keep

the system time updated when the computer enters suspend mode activated by the BIOS Power Management. For DOS environments, you need to add the statement, DEVICE=C:\DOS\POWER.EXE, to your CONFIG.SYS file. For Windows 3.x and Windows 95, you need to install Windows with the APM feature. For Windows 98 and later, APM is automatically installed. A battery and power cord icon labeled “Power Management” will appear in the “Control Panel.” Choose “Advanced” in the Power Management Properties dialog box.

ASUS A7V133-VM User’s Manual68

4. BIOS SETUP

Video Off Option [Suspend -> Off ]

This field determines when to activate the video off feature for monitor power management. Configuration options: [Always On] [Suspend -> Off]

Video Off Method [DPMS OFF]

This field defines the video off features. The DPMS (Display Power Management System) feature allows the BIOS to control the video display card if it supports the DPMS feature. [Blank Screen] only blanks the screen (use this for monitors without power management or “green” features. If set up in your system, your screen saver will not display with [Blank Screen] selected). [V/ H SYNC+Blank] blanks the screen and turns off vertical and horizontal scan- ning. Configuration options: [Blank Screen] [V/H SYNC+Blank] [DPMS Standby] [DPMS Suspend] [DPMS OFF] [DPMS Reduce ON]

HDD Power Down [Disabled]

Shuts down any IDE hard disk drives in the system after a period of inactivity as set in this user-configurable field. This feature does not affect SCSI hard drives. Configuration options: [Disabled] [1 Min] [2 Min] [3 Min]...[15 Min]

Suspend Mode [Disabled]

Sets the time period before the system goes into suspend mode. Configuration options: [Disabled] [30 Sec] [1 Min]... [40 Min]

PWR Button < 4 Secs [Soft Off]

When set to [Soft off], the ATX switch can be used as a normal system power-off button when pressed for less than 4 seconds. [Suspend] allows the button to have a dual function where pressing less than 4 seconds will place the system in sleep mode. Regardless of the setting, holding the ATX switch for more than 4 seconds will power off the system. Configuration options: [Soft off] [Suspend]

Power Menu

4. BIOS SETUP

ASUS A7V133-VM User’s Manual 69

4. BIOS SETUP

4.5.1 Power Up Control

AC PWR Loss Restart [Disabled]

This allows you to set whether you want your system to reboot after the power has been interrupted. [Disabled] leaves your system off and [Enabled] reboots your system. [Previous State] sets your system back to the state it is before the power interruption. Configuration options: [Disabled]

Power Up Control

4. BIOS SETUP

[Enabled] [Previous State]

PWR Up On External Modem Act [Enabled]

This allows either settings of [Enabled] or [Disabled] for powering up the computer when the external modem receives a call while the computer is in Soft-off mode. NOTE: The computer cannot receive or transmit data until the computer and applications are fully running. Thus connection cannot be made on the first try . T urning an external modem off and then back on while the computer is off causes an initialization string that will also cause the system to power on. Configuration options: [Disabled] [Enabled]

Wake On LAN or PCI Modem [Disabled]

Wake-On-LAN/PCI Modem allows your computer to be booted from another computer via a network by sending a wake-up frame or signal. Configuration options: [Disabled] [Enabled]

IMPORTANT: This feature requires an optional network interface card with W ake-

On-LAN and an ATX power supply with at least 720mA +5V standby power.

ASUS A7V133-VM User’s Manual70

4. BIOS SETUP

Automatic Power Up [Disabled]

This allows an unattended or automatic system power up. You may configure your system to power up at a certain time of the day by selecting [Everyday] or at a certain time and day by selecting [By Date]. NOTE: Automatic Power Up will not work if the system is powered down by operating systems, such as Windows 98, that have ACPI support enabled. Configuration options: [Disabled] [Everyday] [By Date]

ASUS A7V133-VM User’s Manual 71

4. BIOS SETUP

Power Up Control

4. BIOS SETUP

4.5.2 Hardware Monitor

CPU Temperature [xxxC/xxxF]

The onboard hardware monitor is able to detect the MB (motherboard) and CPU temperatures. Set to [Ignore] only if necessary.

CPU Fan Speed [xxxxRPM]

Hardware Monitor

4. BIOS SETUP

The onboard hardware monitor is able to detect the CPU fan speed and the chassis fan speed in rotations per minute (RPM). The presence of the fans is automatically detected. Set to [Ignore] only if necessary.

NOTE: If any of the monitored items is out of range, an error message will appear: “Hardware Monitor found an error. Enter Power setup menu for details”. You will then be prompted to “Press F1 to continue, DEL to enter SETUP”.

ASUS A7V133-VM User’s Manual72

4. BIOS SETUP

4.6 Boot Menu

Boot Sequence

The Boot menu allows you to select among the four possible types of boot devices listed using the up and down arrow keys. By using the <+> or <Space> key, you can promote devices and by using the <-> key, you can demote devices. Promotion or demotion of devices alters the priority which the system uses to search for a boot device on system power up. Configuration fields include Removable Devices, IDE Hard Drive, A T API CD-ROM, and Other Boot Device.

Removable Device [Legacy Floppy]

Configuration options: [Disabled] [Legacy Floppy] [LS120] [ZIP-100] [ATAPI MO] [USB FDD] [USB ZIP]

IDE Hard Drive

This field allows you to select which IDE hard disk drive to use in the boot sequence. Pressing [Enter] will show the product IDs of all connected IDE hard disk drives.

ATAPI CD-ROM

This field allows you to select which ATAPI CD-ROM drive to use in the boot sequence. Pressing [Enter] will show the product IDs of all your connected ATAPI CD-ROM drives.

Boot Menu

4. BIOS SETUP

IMPORTANT: Make sure the ATAPI CD-ROM drive that you want to use in the

boot sequence is connected to either the PRIMARY or SECONDARY IDE connectors, not to the ATA100 connectors. Currently, the Promise® Ultra DMA/100 chip does not support this feature.

ASUS A7V133-VM User’s Manual 73

4. BIOS SETUP

Other Boot Device Select [INT18 Device (Network)]

Configuration options: [Disabled] [SCSI/Onboard A T A Boot Device] [INT18 Device (Network)] [LANDesk (R) Service Agent]

Plug & Play O/S [No]

This field allows you to use a Plug-and-Play (PnP) operating system to configure the PCI bus slots instead of using the BIOS. When [Yes] is selected, interrupts may be reassigned by the OS. When a non-PnP OS is installed or you want to prevent reassigning of interrupt settings, select the default setting of [No]. Configuration options: [No] [Yes]

Reset Configuration Data [No]

The Extended System Configuration Data (ESCD) contain information about non-PnP devices. It can also hold the complete record of how the system was configured the last time it was booted. Select [Yes] only if you want to clear these data during the Power-On Self Test (POST). Configuration options: [No] [Yes]

Boot Virus Detection [Enabled]

This field allows you to set boot virus detection, ensuring a virus-free boot sector. The system halts and displays a warning message when it detects a virus. If this occurs, you can either allow the operation to continue or use a virus-free bootable floppy disk to restart and investigate your system. Con-

4. BIOS SETUP

Boot Menu

figuration options: [Disabled] [Enabled]

Quick Power On Self Test [Enabled]

This field speeds up the Power-On-Self Test (POST) routine by skipping retesting a second, third, and fourth time. Configuration options: [Disabled] [Enabled]

Boot Up Floppy Seek [Disabled]

When enabled, the BIOS will seek the floppy disk drive to determine whether the drive has 40 or 80 tracks. Configuration options: [Disabled] [Enabled]

ASUS A7V133-VM User’s Manual74

4. BIOS SETUP

4.7 Exit Menu

Once you have made all of your selections from the various menus in the Setup program, you should save your changes and exit Setup. Select Exit from the menu bar to display the following menu:

NOTE: Pressing <Esc> does not exit this menu. You must select one of the options from this menu or <F10> from the legend bar to exit this menu.

Exit Saving Changes

Once you are finished making your selections, choose this option from the Exit menu to ensure the values you selected are saved to the CMOS RAM. The CMOS RAM is sustained by an onboard backup battery and stays on even when the PC is turned off. Once this option is selected, a confirmation is asked. Select [Yes] to save changes and exit.

NOTE: If you attempt to exit the Setup program without saving your changes, the program will prompt you with a message asking if you want to save your changes before exiting. Pressing <Enter> will then save changes while exiting.

Exit Discarding Changes

This option should only be used if you do not want to save the changes you have made to the Setup program. If you have made changes to fields other than system date, system time, and password, the system will ask for confirmation before exiting.

Exit Menu

4. BIOS SETUP

ASUS A7V133-VM User’s Manual 75

4. BIOS SETUP

Load Setup Defaults

This option allows you to load the default values for each of the parameters on the Setup menus. When this option is selected or if <F5> is pressed, a confirmation is requested. Select [Yes] to load default values. You can now select Exit Saving Changes or make other changes before saving the val- ues to the non-volatile RAM.

Discard Changes

This option allows you to discard the selections you made and restore the values you previously saved. After selecting this option, a confirmation is requested. Select [Y es] to discard any changes and load the previously saved values.

Save Changes

This option saves your selections without exiting the Setup program. You can then return to other menus and make changes. After selecting this option, all selections are saved and a confirmation is requested. Select [Yes] to save any changes to the non-volatile RAM.

4. BIOS SETUP

Exit Menu

ASUS A7V133-VM User’s Manual76

5. SOFTWARE SETUP

5.1 Install Operating System

You should always use the latest operating system and updates when using new hardware to ensure full compliancy . You may use any version of W indows 98/2000/ Millenium, but for Windows 95, you must use OSR 2.0 or later. For Windows NT

4.0, you must use Service Pack 3.0 or later.

5.2 Start Windows

When you start Windows 98 for the first time after installing your motherboard, Windows will detect all plug-and play devices. Follow the Add New Hardware W izard to install all necessary device drivers. When prompted to restart, select No and then follow the setup procedures in this section.

NOTE: Because there are various motherboard settings, options, and expansion cards, the following can only be used as a general reference and may not reflect exactly the screen contents displayed on your screen.

Windows 98

5. S/W SETUP

77ASUS A7V133-VM User’s Manual

5. SOFTWARE SETUP

5.3 A7V133-VM Series Support CD

NOTE: The support CD contents are subject to change at any time without notice. T o begin using your support CD disc, just insert it into your CD-ROM drive and the

support CD installation menu should appear. If the menu does not appear, doubleclick or run D:\ASSETUP.EXE (assuming that your CD-ROM drive is drive D:).

5.3.1 Installation Menu

• VIA® 4 in 1 drivers: Installs Bus Master PCI IDE Driver , AGP VxD Driver , VIA

• VIA

• S3® ProSavage™ KM133A Display Driver: Installs the S3 graphical display

• Audio Driver Vx.xxx: Installs the Audio Driver.

• Realtek

• USB Patch File for AMD

• ASUS® PC Probe™ Vx.xx: Installs a smart utility to monitor your computer’s fan,

• ASUS

• Microsoft® DirectX™V8.0 Driver: Installs the DirectX driver.

5. S/W SETUP

• PC-CILLIN 2000 Vx.xx: Installs the PC-Cillin virus protection software.

Windows 98

• ADOBE® Acrobat™ Reader Vx.xx: Installs the Adobe Acrobat Reader software nec-

• Install Cyberlink

• ASUS

• Show Motherboard Information: Allows you to view information about your

• Browse Support CD: Allows you to view the contents of the CD.

• ReadMe: Allows you to view the support CD file list and contact information.

• Exit: Exits the CD installation menu.

Additonal CD Content: Flash BIOS writer in the AFLASH folder

INF Driver, and IRQ Routing Miniport Driver.

Bus Master PCI IDE Driver: Installs the PCI IDE driver.

driver

RTL8139C PCI Fast Ethernet NIC Driver: Installs the Realtek driver .

K7: Executes the USB Patch file.

temperature, and voltages.

Update™ Vx.xx: Installs ASUS\Update to help you update your BIOS or

download BIOS image file from the Internet.

(CLICK RIGHT ARROW ON THE LOWER-RIGHT CORNER OF THE MAIN MENU)

essary to view user’s manuals saved in PDF format. Updated or other language versions of this motherboard's manual is available in PDF format at any ASUS web site.

Video and Audio Applications: (optional) Installs Cyberlink

PowerPlayer

™

SE, PowerDVD™ Trial, and Cyberlink VideoLive Mail™.

Screen Saver: Installs the latest ASUS screen saver.

motherboard, such as product name, BIOS version, and CPU.

(TO RETURN TO THE MAIN MENU, CLICK THE LEFT ARROW ON THE MENU)

ASUS A7V133-VM User’s Manual

6. SOFTWARE REFERENCE

6.1 ASUS PC Probe

ASUS PC Probe is a convenient utility to continuously monitor your computer system’s vital components, such as fan rotations, voltages, and tem- peratures. It also has a utility that lets you review useful information about your computer, such as hard disk space, memory usage, and CPU type, CPU speed, and internal/external frequencies through the DMI Explorer.

6.1.1 Starting ASUS PC Probe

When ASUS PC Probe starts, a splash screen appears allowing you to select whether to show the screen again when you open PC Probe or not. To bypass this startup screen, clear the Show up in next execution check box.

ASUS PC Probe

6. S/W REFERENCE

To open ASUS PC Probe, click the Windows Start button, point to Programs, and then ASUS Utility, and then click Probe Vx.xx.

The PC Probe icon that ASUS PC Probe is running. Clicking the icon will allow you to see the status of your PC.

will appear on the taskbar’s system tray indicating

ASUS A7V133-VM User’s Manual 79

6. SOFTWARE REFERENCE

6. S/W REFERENCE

ASUS PC Probe

6.1.2 Using ASUS PC Probe

Monitoring

Monitor Summary

Shows a summary of the items being monitored.

Temperature Monitor

Shows the PC’s temperature (for supported processors only).

(Move the slider up to increase the threshold level or down to decrease

Temperature Warning

threshold adjustment

the threshold level)

Fan Monitor

Shows the PC’s fan rotation.

Fan Warning

threshold adjustment

(Move the slider up to increase the threshold level or down to decrease

the threshold level)

Voltage Monitor

Shows the PC’s voltages.

ASUS A7V133-VM User’s Manual80

6. SOFTWARE REFERENCE

Settings

Lets you set threshold levels and polling intervals or refresh times of the PC’s temperature, fan rotation, and voltages.

CPU Cooling System Setup

Lets you select when to enable software CPU

cooling. When When CPU Overheated is selected,

the CPU cooling system is enabled whenever the

CPU temperature reaches the threshold value.

History

Lets you record the monitoring activity of a certain component of your PC for future reference.

ASUS PC Probe

6. S/W REFERENCE

Fan Control

Lets you enable/disable Smart Fan Control. Smart Fan Control adjusts the fan speed automatically based on the current CPU temperature and predefined threshold.

NOTE: This feature is not available on ASUS Probe version 2.12.01/2.12.02

Information

Hard Drives

Shows the used and free space of the PC’s hard disk drives and the file allo- cation table or file system used.

ASUS A7V133-VM User’s Manual 81

6. SOFTWARE REFERENCE

6. S/W REFERENCE

ASUS PC Probe

Memory

Shows the PC’s memory load, memory usage, and paging file usage.

Device Summary

Shows a summary of devices in your PC.

DMI Explorer

Shows information pertinent to the PC, such as CPU type, CPU speed, and internal/external frequencies, and memory size.

Utility

Lets you run programs outside of the ASUS Probe modules. T o run a program, click Execute Program. NOTE: This feature is currently unavailable.

ASUS A7V133-VM User’s Manual82

6. SOFTWARE REFERENCE

6.1.3 ASUS PC Probe Task Bar Icon

Right clicking the PC Probe icon will bring up a menu to open or exit ASUS PC Probe and pause or resume all system monitoring.

When the ASUS PC Probe senses a problem with your PC, portions of the ASUS PC Probe icon changes to red, the PC speaker beeps, and the ASUS PC Probe monitor is displayed.

ASUS PC Probe

6. S/W REFERENCE

ASUS A7V133-VM User’s Manual 83

6. SOFTWARE REFERENCE

6. S/W REFERENCE

6.2 CyberLink PowerPlayer SE

PowerPlayer

CyberLink PowerPlayer SE is an intelligent software player that can automatically detect and playback all kinds of video/audio files, CD and MP3 files as well. This is the only software you need for all types of video and audio files. No need to waste time identifying your file types.

6.2.1 Starting CyberLink PowerPlayer SE

To start CyberLink Power Player, click the Windows Start button, point to Programs, and then CyberLink PowerPlayer SE, and then click PowerPlayer.

6.2.2 CyberLink PowerPlayer Control Panel

Minimize

Zoom About

Eject Help

Power Off

Stop

Backward Scan

Backstep Frame

Stop

Configuration

i-Power!

CD Mode

Shuffle

Karaoke Next angle Next audio stream Next subtitle Add bookmark

Forward Scan Step Frame

Play

Increase Volume Mute

Decrease Volume

Capture frame Go-Up Repeat Menu Go to bookmark

ASUS A7V133-VM User’s Manual84

6. SOFTWARE REFERENCE

6.3 CyberLink PowerDVD

CyberLink PowerDVD is the flagship of CyberLink’s complete range of video and audio software products. It features unrivaled functions allowing users to view high quality video and media-rich DVD contents on the personal computer. With the iPower Internet Enabling feature, PowerDVD opens DVD enthusiasts to on-line DVD resources via the PowerDVD Desktop Portal Page.

6.3.1 Starting CyberLink PowerDVD

To start CyberLink PowerDVD, click the Windows Start button, point to Programs, and then CyberLink PowerDVD, and then click PowerDVD.

6.3.2 CyberLink PowerDVD User Interface

Minimize

Main Display

Exit

PowerDVD

6. S/W REFERENCE

Control

Panel

(closed)

Full Screen /

Video Window

CD/File

Mode

Control

Wheel

Functions

EjectHelp

ASUS A7V133-VM User’s Manual 85

6. SOFTWARE REFERENCE

6. S/W REFERENCE

VideoLive Mail

6.4 CyberLink VideoLive Mail

CyberLink’s VideoLive Mail Plus Ver 3.0 (a.k.a. VLM 3) is a convenient and excel- lent way to create professional quality video mails from PC video/audio input devices and to send the mails to any recipients via VLM 3’s built-in e-mail system through the Internet. VLM 3’s mails comprise video, sound, or snapshot informa- tion; and thus may convey the most profound information to target audiences. It is very convenient for mail recipients who do not need to install additional software component in order to view VLM 3 mails.

VLM 3 works as a very applicant sales tool. It efficiently delivers profound and live product information to your target customers without costing a fortune. VLM 3 also helps corporate managers easily give vivid speeches and broadcast through corporate E-mail system. For personal or home users, VLM 3 easily records live video clips allowing users to send them to friends or family members across the Internet.

VLM 3 loads video messages from PC cameras, digital camcorders, analog camcorder via video capture cards, or from an existing AVI video clips, and captures audio messages from PC microphones. Video and audio messages are encoded at a very high compressed rate in a real-time mode. From data input, data conversion, to sending video mails via Internet, or saving data to disks, the whole procedure is done in an easy and continuous process.

VLM 3’s video clip compression rate is up to 1:900, and its playback rate is up to 30 frame per second. VLM 3 provides CIF (352 x 288 pixel) display resolution, and support true color configuration. A one-minute video mail with QCIF (176 x 144) resolution takes up less than 500KB of memory , making it easy to transmit and save mail. Users may always adjust resolution and recording parameters for different purpose.

VLM 3 supports all the hardware devices that are compliant with Video for Windows standard. V ideo for W indows is a well-accepted and well-tested standard. Thus, users do not have to worry about compatibility issues.

ASUS A7V133-VM User’s Manual86

6. SOFTWARE REFERENCE

6.4.1 Starting VideoLive Mail

To start VideoLive Mail, click the Windows Start button, point to Programs, and then CyberLink VideoLive Mail, and then click VideoLive Mail x.x. VLM 3’s Setup Wizard will start and guide you through configuring the video and audio input peripherals and to setup the e-mail environment.

1. Setup Wizard first will prompt a dialog to confirm that you want to configure

the hardware and E-mail setting. Click Yes to continue the system parameter configuration.

2. The e-mail configuration screen appears. You will need to enter your name and

the e-mail address. Click Next to continue.

3. The Internet e-mail configuration screen appears. You may choose to use the VLM 3 built-in E-mail functionality (SMTP mail), or use MAPI compliant email system. Consult your ISP or MIS staff for the E-mail server IP address if you are not sure. Click Next to continue.

4. Then the Video Configuration screen shows up. You may have to specify the video driver for VLM 3, if there are several video-input devices installed. Then configure the number of video frames to be captured per second. Note that the more frames you choose, the bigger the file size will be. Click Next to continue.

VideoLive Mail

6. S/W REFERENCE

5. Then the Setup Wizard will then search for the GSM CODECS module for audio compression, and prompt you with the result. Click Next to continue.

6. Setup Wizard then tests the audio volume during playing and recording. Click Next when ready.

7. Configuration done. Click Finish to complete the environmental setting procedure.

6.4.2 CyberLink VideoLive Mail User Interface

Exit Minimize

Help Video Mail Wizard

Snapshot to File

Video Configuration

Start Playback

Stop Recording / Playback

Start Recording

Pause

Save Video File Send Mail

Load Video File

Send Mail

Increase MIC volume

Decrease MIC volume

Increase speaker volume Decrease speaker volume

ASUS A7V133-VM User’s Manual 87

6. SOFTWARE REFERENCE

6. S/W REFERENCE

6.5 ASUS LiveUpdate

ASUS LiveUpdate is a utility that allows you to update your motherboard’s BIOS and drivers. The use of this utility requires that you are properly connected to the Internet through an Internet Service Provider (ISP).

1. Start ASUS Update. Launch the utility from Start | Programs | ASUS

Utility | ASUS LiveUpdate.

2. Select an update method.

3. If you selected updating/downloading from the

Internet, you will need to select an Internet site. Choose the site that is closest to you or click Auto Select.

If you selected Update from a file, you will be prompted to locate the file.

ASUS A7V133-VM User’s Manual88

7. APPENDIX

7.1 Glossary

1394

1394 is the IEEE designation for the high performance serial bus at 12.5, 25 or 50MBytes/sec speeds. This serial bus defines both a back plane physical layer and a point-to-point cable-connected virtual bus. The primary application of the cable version is the integration of I/O connectivity at the back panel of personal computers using a low-cost, scalable, high-speed serial interface. The 1394 standard also provides new services such as live connect/disconnect capability for external devices including disk drives, printers and hand-held peripherals such as scanners and cameras. This is a new standard to complement the slower USB interface and to compete with the more expensive SCSI interface.

AC97 (Audio Codec '97)

AC '97 is the next step in enabling PCs with audio quality comparable to consumer electronics devices. The specification defines new cost-effective options to help integrate the components necessary to support next-generation auto-intensive PC applications such as DVD, 3-D multiplayer gaming and interactive music. The specification also defines new extensions supporting modem and docking to help both desktop and mobile manufacturers adopt these new technologies more quickly and cost-effectively . This specification uses software emulation to compete with the PCI SoundBlaster specification.

ACPI (Advanced Configuration and Power Interface)

The ACPI specification defines a cross-platform interface designed to support many operating systems. ACPI defines a flexible and abstract hardware interface that provides a standard way to integrate power management features throughout a PC system, including hardware, operating system and application software. This enables the system to automatically turn ON and OFF peripherals such as CD-ROMs, network cards, hard disk drives, and printers, as well as consumer devices connected to the PC such as VCRs, TVs, phones, and stereos. With this technology, peripherals will also be able to activate the PC. For example, inserting a tape into a VCR can turn on the PC, which could then activate a large-screen TV and high-fidelity sound system.

AGP (Accelerated Graphics Port)

An interface specification that enables high-performance 3D graphics on mainstream PCs. AGP was designed to offer the necessary bandwidth and latency to perform texture mapping directly from system memory.

Glossary

7 . APPENDIX

Bus Bus Frequency Bandwidth Data Transfer Rate

PCI 33MHz 33MHz 133MByte/sec AGP 1X 66MHz 66MHz 266MByte/sec AGP 2X 66MHz 133MHz 512MByte/sec

AGP 4X 66MHz 266MHz 1024MByte/sec

BIOS (Basic Input/Output System)

BIOS is a set of routines that affect how the computer transfers data between computer components, such as memory, disks, and the display adapter. The BIOS instructions are built into the computer’s read-only memory. BIOS parameters can be configured by the user through the BIOS Setup program. The BIOS can be updated using the provided utility to copy a new BIOS file into the EEPROM.

Bit (Binary Digit)

Represents the smallest unit of data used by the computer . A bit can have one of two values: 0 or 1.

ASUS A7V133-VM User’s Manual 89

7. APPENDIX

Glossary

7. APPENDIX

Boot

Boot means to start the computer operating system by loading it into system memory . When the manual instructs you to “boot” your system (or computer), it means to turn ON your computer . “Reboot” means to restart your computer . When using W indows 95 or later, selecting “Restart” from “Start | Shut Down...” will reboot your computer.

Bus Master IDE

PIO (Programmable I/O) IDE requires that the CPU be involved in IDE access and waiting for mechanical events. Bus master IDE transfers data to/from the memory without interrupting the CPU. Bus master IDE driver and bus master IDE hard disk drives are required to support bus master IDE mode.

Byte (Binary Term)

One byte is a group of eight contiguous bits. A byte is used to represent a single alphanumeric character, punctuation mark, or other symbol.

COM Port

COM is a logical device name used by to designate the computer serial ports. Pointing devices, modems, and infrared modules can be connected to COM ports. Each COM port is configured to use a different IRQ and address assignment.

Concurrent PCI

Concurrent PCI maximizes system performance with simultaneous CPU, PCI and ISA bus activities. It includes multi-transaction timing, enhanced write performance, a passive release mechanism and support for PCI 2.1 compliant delayed transactions. Concurrent PCI provides increased bandwidth, reduced system latencies, improves video and audio performance, and improves processing of host based applications.

CPU (Central Processing Unit)

The CPU, sometimes called “Processor,” actually functions as the “brain” of the computer. It interprets and executes program commands and processes data stored in memory. Currently, there are socket 370 (for Pentium III FC-PGA and CeleronPPGA), socket 7 (for Pentium, AMD, Cyrix, IBM), slot 1 (for Pentium II and III), slot 2 (for Xeon), and slot A (for AMD) processors.

Device Driver

A device driver is a special set of instructions that allows the computer’s operating system to communicate with devices such as VGA, audio, printer, or modem.

DOS (Disk Operating System)

DOS is the foundation on which all other programs and software applications operate, including W indows. DOS is responsible for allocating system resources such as memory, CPU time, disk space, and access to peripheral devices. For this reason, DOS constitutes the basic interface between you and your computer.

DRAM (Dynamic Random Access Memory)

There are several different types of DRAM such as, EDO DRAM (Extended Data Output DRAM), SDRAM (Synchronous DRAM), and RDRAM (Rambus DRAM).

Flash ROM

The flash ROM is designed to be a resident program and can be updated by a specific programming method. Normally , the flash ROM is used for system BIOS which initiates hardware devices and sets up necessary parameters for the OS. Since the contents of flash ROM can be modified, users are able to update the BIOS by themselves.

IDE (Integrated Drive Electronics)

IDE devices integrate the drive control circuitry directly on the drive itself, eliminating the need for a separate adapter card (in the case for SCSI devices). UltraDMA/ 33 IDE devices can achieve up to 33MB/Sec transfer.

ASUS A7V133-VM User’s Manual90

7. APPENDIX

LPT Port (Line Printer Port)

Logical device name reserved by DOS for the computer parallel ports. Each LPT port is configured to use a different IRQ and address assignment.

MMX

A set of 57 new instructions based on a technique called Single Instruction, Multiple Data (SIMD), which is built into the new Intel Pentium PP/MT (P55C) and Pentium II (Klamath) CPU as well as other x86-compatible microprocessors. The MMX instructions are designed to accelerate multimedia and communications applications, such as 3D video, 3D sound, video conference.

OnNow

The OnNow design initiative is a comprehensive, system-wide approach to system and device power control. OnNow is a term for PC that is always ON but appears OFF and responds immediately to user or other requests. The OnNow design initiative involves changes that will occur in the Microsoft Windows operating system, device drivers, hardware, and applications, and also relies on the changes defined in the Advanced Configuration and Power Interface (ACPI) specification.

PC100

SDRAM is Intel's goal is to ensure that memory subsystems continue to support evolving platform requirements and to assure that memory does not become a bottleneck to system performance. It is especially important to ensure that the PC memory roadmap evolves together with the performance roadmaps for the processors, I/O and graphics.

PCI Bus (Peripheral Component Interconnect Local Bus)

PCI bus is a specification that defines a 32-bit data bus interface. PCI is a standard widely used by expansion card manufacturers.

PCI Bus Master

The PCI Bus Master can perform data transfer without local CPU help and furthermore, the CPU can be treated as one of the Bus Masters. PCI 2.1 supports concurrent PCI operation to allow the local CPU and bus master to work simultaneously.

Plug and Play BIOS

The ISA bus architecture requires the allocation of memory and I/O address, DMA channels and interrupt levels among multiple ISA cards. However, configuration of ISA cards is typically done with jumpers that change the decode maps for memory and I/O space and steer the DMA and interrupt signals to different pins on the bus. Further, system configuration files may need to be updated to reflect these changes. Users typically resolve sharing conflicts by referring to documentation provided by each manufacturer. For the average user, this configuration process can be unreliable and frustrating. Plug and play (PnP) BIOS eliminates the ISA add-on card hardware conflict problem. The PnP BIOS uses a memory block to define and remember each card's configuration, which allows the user to change the card's IRQs and DMA in BIOS either automatically or manually.

POST (Power On Self Test)

When you turn ON the computer, it will first run through the POST, a series of software-controlled diagnostic tests. The POST checks system memory, the motherboard circuitry, the display, the keyboard, the diskette drive, and other I/O devices.

PS/2 Port

PS/2 ports are based on IBM Micro Channel Architecture. This type of architecture transfers data through a 16-bit or 32-bit bus. A PS/2 mouse and/or keyboard may be used on ATX motherboards.

Glossary

7 . APPENDIX

RDRAM (Rambus DRAM)

Developed by Rambus, Inc., this type of memory can deliver up to 1.6GB of data per second. RDRAM is the first interface standard that can be directly implemented on high performance VLSI components such as, CMOS DRAMs, memory control-

lers, and graphics/video ICs.

ASUS A7V133-VM User’s Manual 91

7. APPENDIX

Glossary

7. APPENDIX

ROM (Read Only Memory)

ROM is nonvolatile memory used to store permanent programs (called firmware) used in certain computer components. Flash ROM (or EEPROM) can be reprogrammed with new programs (or BIOS).

SCSI (Small Computer System Interface)

High speed multi-threaded I/O interface defined by the X3T9.2 committee of the American National Standards Institute (ANSI) for connecting many peripheral devices. The standard started from 10MBytes/sec to 160MBytes/sec available today.

SDRAM (Synchronous DRAM)

The SDRAM features a fully synchronous operation referenced to a positive edge clock whereby all operations are synchronized at a clock input which enables the coexistence of high performance and a simple user interface. SDRAM takes memory access away from the CPU's control; internal registers in the chips accept the request, and let the CPU do something else while the data requested is assembled for the next time the CPU talks to the memory. As they work on their own clock cycle, the rest of the system can be clocked faster. There is a version optimized for video cards, and main memory for motherboards.

SPD for SDRAM module

Serial Presence Detect (SPD) is most like an ID detect for SDRAM module, it using a EEPROM component on DIMM module for storing module configuration information inside. The Serial Presence Detect function is implemented using a 2048 bit EEPROM component. This nonvolatile storage device contains data programmed by the DIMM manufacturer that identifies the module type and various SDRAM organization and timing parameters.

SSE (Streaming SIMD Extensions)

A set of new instructions added to existing architectures that enables a better visual experience with an accelerated 3D geometry pipeline and support for new applications, such as real-time video encoding and speech recognition.

System Disk

A system disk contains the core file of an operating system and is used to boot up the operating system.

UltraDMA

Ultra DMA/33 is a "synchronous DMA" protocol designed by Intel. This function is included into Intel's PIIX4 chipset. The traditional IDE transfer only uses one edge of the data stroke as the data transfer. Ultra DMA/33 uses both edges of data strobe when the data is transferred. Hence, the data transfer rate is double of the PIO mode 4 or DMA mode 2 (16.6MB/s x2 = 33MB/s) on ATA-2 devices.

Ultra ATA/66, also known as Ultra DMA/66, is an extension of current Ultra ATA/ 33 interface. This new high-speed interface has doubled the Ultra AT A/33 burst data transfer rate to 66.6 Mbytes/sec and maximized disk performance under current PCI local bus environment

USB (Universal Serial Bus)

A 4-pin serial cable bus that allows up to 127 plug and play computer peripherals such as keyboard, mouse, joystick, scanner, printer, modem, and monitor to share a bandwidth through a host scheduled token based protocol. This allows attaching or detaching while the host and other peripherals are in operation. Supports synchronous and asynchronous transfer types over the same set of wires up to 12Mbit/sec. USB 2.0 provides twice the transfer rate compared to USB 1.0 and competes with the 1394 standard.

Wake-On-LAN

Computer will automatically wake-up upon receiving a wake-up packet through a Network interface when it is under power soft-off, suspend or sleep mode.

ASUS A7V133-VM User’s Manual92

INDEX

AC PWR Loss Restart 70 ASUS PC Probe

Using 79 ATAPI CD-ROM 73 ATX Power Supply Connector 37 Audio Controller 61

BIOS

Beep Code 39 BIOS Beep Codes 39 Boot Sequence 73 Boot Up Floppy Seek 74 Boot Up NumLock Status 52 Boot Virus Detection 74

CyberLink V ideoLive Mail

Using 86

Cylinders 50

Discard Changes 76 DMA x Used By ISA 65

ECP DMA Select 61 Exit Discarding Changes 75 Exit Saving Changes 75 Expansion Cards

Assigning IRQs 25

Floppy 3 Mode Support 48 Floppy Disk Access Control 60

Central Processing Unit 23 Chassis Fan Speed 72 Chassis Intrusion Lead 32 CHS Capacity 51 Connectors

ATX Power Supply 37

Floppy Disk Drive 31

IDE 31

Infrared Module 32

Internal Audio 35

SMBus 36

Wake-On-LAN 33

Wake-On-Ring 33 CPU Fan Speed 72 CPU Temperature 72 CyberLink

PowerDVD 84

PowerPlayer SE 84

VideoLive Mail 86 CyberLink PowerDVD

Using 84 CyberLink PowerPlayer SE

Using 84

Floppy Disk Drive Connector 31

Halt On 53 Hardware Setup

CPU Installation 23

Memory Installation 21 HDD Power Down 69 Head 51 Headers

USB 36

IDE Activity LED Lead 35, 37 IDE Connectors 31 IDE Hard Drive 73 Infrared Module Connector 32 Installation

CPU 23 Installed Memory 53 Internal Audio Connector 35

ASUS A7V133-VM User’s Manual 93

INDEX

Interrupts

Standard Assignments 25 IRQ XX Used By ISA 64 ISA MEM Block BASE 66

Language 53 Leads

Chassis Intrusion 32

IDE Activity LED 35, 37 Legacy Diskette A 48 Legacy Diskette B 48 LiveUpdate 88

Using 88 Load Setup Defaults 76

Maximum LBA Capacity 51 MB Temperature 72

Power Fan Speed 72 Power Management 68 PowerDVD 84

Using 84

PowerPlayer SE

Using 84

Procedure

CPU Installation 23

Procedures

Updating BIOS 42

PWR Up On Modem Act 70

Quick Power On Self Test 74

Removable Device 73

Memory Hole At 15M-16M 57 Memory Installation 21 Multi-Sector Transfers 51

Onboard CIR IRQ 62 Onboard Parallel Port 61 Onboard Serial Port 1 60 Onboard Serial Port 2 60 OS/2 Onboard Memory > 64M 55

Parallel Port Mode 61 PCI Latency Timer 63 PCI/VGA Palette Snoop 63 PIO Mode 51 Plug & Play O/S 74

Save Changes 76 SDRAM CAS Latency 58 SDRAM Configuration 57 SDRAM RAS Precharge Time 58 Sector 51 SMART Monitoring 51 SMBus Connector 36 Starting Up 39 Supervisor Password 53 Suspend Mode 69 Suspend-to-RAM Capability 69 SYMBIOS SCSI BIOS 63 System Date 48 System Time 48

Translation Method 50 Type 49

94 ASUS A7V133-VM User’s Manual

UART2 Use Standard Infrared 60 Ultra DMA Mode 51 Updating Your BIOS 41 USB Function 64 USB Headers 36 USB Legacy Support 55 Using

ASUS PC Probe 79 LiveUpdate 88 PowerPlayer SE 84

VCORE Voltage 72 Video Off Method 69

INDEX

Video Off Option 69 Video ROM BIOS Shadow 67 VideoLive Mail 86

Using 86

Voltage

+12 72 +3.3 72 +5 72

-12 72

-5 72 VCORE 72

Wake On LAN 70 Wake-On-LAN Connector 33 Wake-On-Ring Connector 33

ASUS A7V133-VM User’s Manual 95

NOTES

96 ASUS A7V133-VM User’s Manual

HP A7V133-VM User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
