QuickSpecs

HP 3600 EI Switch Series

Overview

c04111664 — DA – 13790 Worldwide — Version 12 — December 1, 2014

Page 1

HP 3600 EI Switch Series

Models

HP 3600-24 v2 EI Switch

JG299A

HP 3600-48 v2 EI Switch

JG300A

HP 3600-24-PoE+ v2 EI Switch

JG301B

HP 3600-48-PoE+ v2 EI Switch

JG302B

HP 3600-24-SFP v2 EI Switch

JG303A

Key features

 Robust switching at the enterprise network edge
 Advanced Layer 3 and multicast routing
 IRF-automated stack and switching fabric setup
 Integrated and distributed security enforcement
 Enterprise-level nonblocking performance

Product overview

The HP 3600 EI Switch Series delivers premium levels of intelligent and resilient performance, security, and reliability for robust
switching at the enterprise network edge. The series consists of Layer 3 Fast Ethernet and PoE/PoE+ switches, with advanced
features that can accommodate the most demanding applications. Secure, resilient connectivity and the latest traffic­prioritization technologies enhance converged networks. Designed for increased flexibility and scalability, HP 3600 EI series
switches come with 24 or 48 10/100 ports, four active SFP-based Gigabit Ethernet ports for stacking and uplinks, and a 24-port
100BASE-FX switch with two or four Gigabit Ethernet SFP slots.

Features and benefits

Quality of Service (QoS)

 Broadcast control

allows limitation of broadcast traffic rate to cut down on unwanted network broadcast traffic

 Advanced classifier-based QoS

classifies traffic using multiple match criteria based on Layer 2, 3, and 4 information; applies QoS policies such as setting
priority level and rate limit to selected traffic on a per-port or per-VLAN basis

 Powerful QoS feature

supports the following congestion actions: strict priority (SP) queuing, weighted round robin (WRR), weighted fair queuing
(WFQ), and WRED

 Traffic policing

supports Committed Access Rate (CAR) and line rate

 RRPP

enables ultra high levels of network resiliency, with failover times of less than 50 ms

Management

 Friendly port names

allow assignment of descriptive names to ports

 Remote configuration and management

is available through a secure Web browser or a command-line interface (CLI)

 Manager and operator privilege levels

enable read-only (operator) and read/write (manager) access on CLI and Web browser management interfaces

 Command authorization

leverages HWTACACS to link a custom list of CLI commands to an individual network administrator's login; also provides

QuickSpecs

HP 3600 EI Switch Series

Overview

c04111664 — DA – 13790 Worldwide — Version 12 — December 1, 2014

Page 2

an audit trail

 Secure Web GUI

provides a secure, easy-to-use graphical interface for configuring the module via HTTPS

 Multiple configuration files

can be stored to the flash image

 Complete session logging

provides detailed information for problem identification and resolution

 SNMPv1, v2c, and v3

facilitate centralized discovery, monitoring, and secure management of networking devices

 Remote monitoring (RMON)

uses standard SNMP to monitor essential network functions; supports events, alarm, history, and statistics group plus a
private alarm extension group

 Local and Remote Intelligent Mirroring

mirrors traffic from a switch port or to a remote switch port anywhere on the network, or mirrors ACL-selected traffic to a
local switch port

 Management VLAN

segments traffic to and from management interfaces, including CLI/telnet, a Web browser interface, and SNMP

 IEEE 802.1AB Link Layer Discovery Protocol (LLDP)

advertises and receives management information from adjacent devices on a network, facilitating easy mapping by
network management applications

 Device Link Detection Protocol (DLDP)

monitors a cable between two switches and shuts down the ports on both ends if the cable is broken, preventing network
problems such as loops

 sFlow (RFC 3176)

provides scalable ASIC-based wirespeed network monitoring and accounting with no impact on network performance;
this allows network operators to gather a variety of sophisticated network statistics and information for capacity
planning and real-time network monitoring purposes

 IPv6 management

future-proofs networking, as the switch is capable of being managed whether the attached network is running IPv4 or
IPv6;
supports pingv6, tracertv6, Telnetv6, TFTPv6, DNSv6, syslogv6, FTPv6, SNMPv6, DHCPv6, and RADIUS for IPv6

 Troubleshooting

ingress and egress port monitoring enable network problem solving; virtual cable tests provide visibility into cable
problems

Connectivity

 IPv6

o Telnet

for allowing CLI access via IPv6

o SNMP

for IPv6 switch management

o DNS

for IPv6 host management

o DHCP

for auto IPv6 address configuration of a switch

 Auto-MDIX

provides automatic adjustments for straight-through or crossover cables on all 10/100 and 10/100/1000 ports

 Jumbo packet support

supports up to 9216-byte frame size to improve the performance of large data transfers

 Gigabit Ethernet uplinks

are dual-personality ports for either 10/100/1000 or mini-GBIC SFP connectivity for increased connectivity flexibility

 High-density access

provides up to 48 fixed 10/100BASE-T PoE or non-PoE ports or 24 SFP 100BASE-X ports in a Layer 2/Layer 3 switch

QuickSpecs

HP 3600 EI Switch Series

Overview

c04111664 — DA – 13790 Worldwide — Version 12 — December 1, 2014

Page 3

 Ethernet operations, administration and maintenance (OAM)

detects data link layer problems that occurred in the "last mile" using the IEEE 802.3ah OAM standard; monitors the
status of the link between two devices

 IEEE 802.3af Power over Ethernet (PoE)

provides up to 15.4 W per port to IEEE 802.3af-compliant PoE-powered devices such as IP phones, wireless access points,
and security cameras

 IEEE 802.3at Power over Ethernet (PoE+) support

simplifies deployment and dramatically reduces installation costs by helping to eliminate the time and cost involved in
supplying local power at each access point location

Performance

 Nonblocking performance

up to 17.6 Gbps nonblocking switching fabric provides wire-speed switching with up to 13.1 million pps throughput

 Gigabit Ethernet interface

provides a connection to the network that eliminates the network as a bottleneck

 Hardware-based wire-speed access control lists

feature-rich ACL implementation helps ensure high levels of security and ease of administration without impacting
network performance

Resiliency and high availability

 Separate data and control paths

keeps control separated from services and keeps service processing isolated; increases security and performance

 External redundant power supply

provides high reliability

 Smart link

allows 50 ms failover between links

 Spanning Tree/MSTP, RSTP

provides redundant links while preventing network loops

 Intelligent Resilient Framework (IRF)

creates virtual resilient switching fabrics, where two or more switches perform as a single L2 switch and L3 router;
switches do not have to be co-located and can be part of a disaster recovery system; servers or switches can be attached
using standard LACP for automatic load balancing and high availability; can eliminate the need for complex protocols like
Spanning Tree Protocol, Equal-Cost Multipath (ECMP), or VRRP, thereby simplifying network operation

 IEEE 802.3ad Link Aggregation Control Protocol (LACP)

supports up to 24 trunks, each with 8 links per trunk; supports static or dynamic groups

 Virtual Router Redundancy Protocol (VRRP)

allows a group of routers to dynamically back each other up to create highly available routed environments

 IRF capability

provides single IP address management for a resilient virtual switching fabric of up to nine switches

Manageability

 RMON (remote monitoring)

provides advanced monitoring and reporting capabilities for statistics, history, alarms, and events

Layer 2 switching

 16/32K MAC address table

provides access to many Layer 2 devices

 VLAN support and tagging

support IEEE 802.1Q with 4,094 simultaneous VLAN IDs

QuickSpecs

HP 3600 EI Switch Series

Overview

c04111664 — DA – 13790 Worldwide — Version 12 — December 1, 2014

Page 4

 GARP VLAN Registration Protocol

allows automatic learning and dynamic assignment of VLANs

 IEEE 802.1ad QinQ and Selective QinQ

increase the scalability of an Ethernet network by providing a hierarchical structure; connect multiple LANs on a high­speed
campus or metro network

 Gigabit Ethernet port aggregation

allows grouping of ports to increase overall data throughput to a remote device

 Internet Group Management Protocol (IGMP) and Multicast Listener Discovery (MLD) protocol snooping

effectively control and manage the flooding of multicast packets in a Layer 2 network

Layer 3 services

 Address Resolution Protocol (ARP)

determines the MAC address of another IP host in the same subnet

 Dynamic Host Configuration Protocol (DHCP)

simplifies the management of large IP networks and supports client and server; DHCP Relay enables DHCP operation
across subnets

 Loopback interface address

defines an address in Routing Information Protocol (RIP) and OSPF, improving diagnostic capability

 User Datagram Protocol (UDP) helper function

allows UDP broadcasts to be directed across router interfaces to specific IP unicast or subnet broadcast addresses and
prevents server spoofing for UDP services such as DHCP

 Route maps

provide more control during route redistribution; allow filtering and altering of route metrics

Layer 3 routing

 IPv4 routing protocols

support static routes, RIP, OSPF, ISIS, and BGP

 IPv6 routing protocols for v2 switches

provide routing of IPv6 at wire speed; support static routes, RIPng, OSPFv3, ISIS for IPv6, and BGP4+ for IPv6

 IPv6 tunneling

allows a smooth transition from IPv4 to IPv6 by encapsulating IPv6 traffic over an existing IPv4 infrastructure

 Equal-Cost Multipath (ECMP)

enables multiple equal-cost links in a routing environment to increase link redundancy and scale bandwidth

 Bidirectional Forwarding Detection (BFD)

enables link connectivity monitoring and reduces network convergence time for RIP, OSPF, BGP, IS-IS, VRRP, and IRF

 PIM-SSM, PIM-DM, and PIM-SM (for IPv4 and IPv6)

support IP Multicast address management and inhibition of DoS attacks

 Multicast Source Discovery Protocol (MSDP)

is used for inter-domain multicast applications, allowing multiple PIM-SM domains to interoperate

 IGMPv1, v2, and v3

allow individual hosts to be registered on a particular VLAN

Security

 Access control lists (ACLs)

provides IP Layer 2 to Layer 4 traffic filtering; supports VLAN ACL and port ACL

 Multiple user authentication methods

o IEEE 802.1X

is an industry-standard method of user authentication using an IEEE 802.1X supplicant on the client in
conjunction with a RADIUS server

QuickSpecs

HP 3600 EI Switch Series

Overview

c04111664 — DA – 13790 Worldwide — Version 12 — December 1, 2014

Page 5

o Web-based authentication

similar to IEEE 802.1X, it provides a browser-based environment to authenticate clients that do not support the
IEEE 802.1X supplicant

o MAC-based authentication

authenticates the client with the RADIUS server based on the client's MAC address

 Identity-driven security and access control

o Per-user ACLs

permits or denies user access to specific network resources based on user identity and time of day, allowing
multiple types of users on the same network to access specific network services without risking network security
or allowing unauthorized access to sensitive data

o Automatic VLAN assignment

automatically assigns users to the appropriate VLAN based on their identities

 Secure management access

securely encrypts all access methods (CLI, GUI, or MIB) through SSHv2, SSL, and/or SNMPv3

 Secure FTP

allows secure file transfer to and from the switch; protects against unwanted file downloads or unauthorized copying of a
switch configuration file

 Guest VLAN

similar to IEEE 802.1X, it provides a browser-based environment to authenticated clients

 Endpoint Admission Defense (EAD)

provides security policies to users accessing a network

 Port security

allows access only to specified MAC addresses, which can be learned or specified by the administrator

 Port isolation

secures and adds privacy, and prevents malicious attackers from obtaining user information

 STP BPDU port protection

blocks Bridge Protocol Data Units (BPDUs) on ports that do not require BPDUs, preventing forged BPDU attacks

 STP Root Guard

protects the root bridge from malicious attacks or configuration mistakes

 DHCP protection

blocks DHCP packets from unauthorized DHCP servers, preventing denial-of-service attacks

 Dynamic ARP protection

blocks ARP broadcasts from unauthorized hosts, preventing eavesdropping or theft of network data

 IP Source Guard

helps prevent IP spoofing attacks

 RADIUS/HWTACACS

eases switch management security administration by using a password authentication server

 Multiple Customer Edge (MCE)

facilitates MPLS VPN network integration with support for up to 63 VPNs

 ICMP throttling

defeats ICMP denial-of-service attacks by enabling any switch port to automatically throttle ICMP traffic

Convergence

 IEEE 802.1AB Link Layer Discovery Protocol (LLDP)

is an automated device discovery protocol that provides easy mapping of network management applications

 LLDP-MED

is a standard extension that automatically configures network devices, including LLDP-capable IP phones

 LLDP-CDP compatibility

receives and recognizes CDP packets from Cisco's IP phones for seamless interoperation

 PoE allocations

support multiple methods (automatic, IEEE 802.3af class, LLDP-MED, or user specified) to allocate PoE power for more
efficient energy savings

 Voice VLAN

QuickSpecs

HP 3600 EI Switch Series

Overview

c04111664 — DA – 13790 Worldwide — Version 12 — December 1, 2014

Page 6

automatically assigns VLAN and priority for IP phones, simplifying network configuration and maintenance

 IP multicast snooping and data-driven IGMP

automatically prevent flooding of IP multicast traffic

 Multicast VLAN

allows multiple VLANs to receive the same multicast traffic, reducing network bandwidth demand by eliminating multiple
streams to each VLAN

 Protocol Independent Multicast (PIM)

is used for multicast applications; supports PIM Dense Mode (PIM-DM) and Sparse Mode (PIM-SM)

 Multicast Source Discovery Protocol (MSDP)

is used for inter-domain multicast applications, allowing multiple PIM-SM domains to interoperate

Device support

 Cisco prestandard PoE support

detects and provides power to Cisco's prestandard PoE devices such as wireless LAN access points and IP phones

Additional information

 Green initiative support

provides support for RoHS and WEEE regulations

 Green IT and power

uses the latest advances in silicon development and shuts off unused ports to improve power efficiency provides support
for RoHS and WEEE regulations

Warranty and support

 Limited Lifetime Warranty v2.0

advance hardware replacement with next-business-day delivery (available in most countries). See

www.hp.com/networking/warrantysummary for duration details.

 Electronic and telephone support (for Limited Lifetime Warranty 2.0)

limited 24x7 telephone support is available from HP for the first 3 years; limited electronic and business hours telephone
support is available from HP for the entire warranty period; to reach our support centers, refer to

www.hp.com/networking/contact-support; for details on the duration of support provided with your product purchase,

refer to www.hp.com/networking/warrantysummary

 Software releases

to find software for your product, refer to www.hp.com/networking/support; for details on the software releases
available with your product purchase, refer to www.hp.com/networking/warrantysummary

QuickSpecs

HP 3600 EI Switch Series

Configuration

c04111664 — DA – 13790 Worldwide — Version 12 — December 1, 2014

Page 7

Build To Order:

BTO is a standalone unit with no integration. BTO products ship standalone are not part of a CTO or Rack-Shippable solution.

HP 3600-24 v2 EI Switch

JG299A

 24 RJ-45 autosensing 10/100 ports
 2 dual-personality 10/100/1000 ports/ SFP 1000 Mbps ports
 2 SFP 1000 Mbps ports
 min=0 \ max=4 SFP 1000 Transceivers
 1U - Height

See Configuration

Note:1, 2

HP 3600-24-SFP v2 EI Switch

JG303A

 24 SFP 100 Mbps ports
 min=0 \ max=24 SFP 100 Transceivers
 2 dual-personality 10/100/1000 ports/ SFP 1000 Mbps ports
 2 SFP 1000 Mbps ports
 min=0 \ max=4 SFP 1000 Transceivers
 1U - Height

See Configuration

Note:1, 2, 3

HP 3600-24-PoE+ v2 EI Switch

JG301B

 24 RJ-45 autosensing 10/100 PoE+ ports
 2 dual-personality 10/100/1000 ports/ SFP 1000 Mbps ports
 2 SFP 1000 Mbps ports
 min=0 \ max=4 SFP 1000 Transceivers
 1U - Height

See Configuration

Note:1, 4,5,6

PDU Cable NA/MEX/TW/JP

JG301B#B2B

 C15 PDU Jumper Cord (NA/MEX/TW/JP)

PDU Cable ROW

JG301B#B2C

 C15 PDU Jumper Cord (ROW)

High Volt Switch/Router to Wall Power Cord

JG301B#B2E

 NEMA L6-20P Cord (NA/MEX/JP/TW)

HP 3600-48 v2 EI Switch

JG300A

 48 RJ-45 autosensing 10/100 PoE ports
 2 dual-personality 10/100/1000 ports/ SFP 1000 Mbps ports
 2 SFP 1000 Mbps ports
 min=0 \ max=4 SFP 1000 Transceivers
 1U - Height

See Configuration

Note:1, 2

QuickSpecs

HP 3600 EI Switch Series

Configuration

c04111664 — DA – 13790 Worldwide — Version 12 — December 1, 2014

Page 8

HP 3600-48-PoE+ v2 EI Switch

JG302B

 48 RJ-45 autosensing 10/100 PoE ports
 2 dual-personality 10/100/1000 ports/ SFP 1000 Mbps ports
 2 SFP 1000 Mbps ports
 min=0 \ max=4 SFP 1000 Transceivers
 1U - Height

See Configuration

Note:1, 4,5,6

PDU Cable NA/MEX/TW/JP

JG302B#B2B

 C15 PDU Jumper Cord (NA/MEX/TW/JP)

PDU Cable ROW

JG302B#B2C

 C15 PDU Jumper Cord (ROW)

High Volt Switch/Router to Wall Power Cord

JG302B#B2E

 NEMA L6-20P Cord (NA/MEX/JP/TW)

Configuration Rules:

Note 1

The following Transceivers install into this switch: (SFP 1000 Mbps ports only)

HP X125 1G SFP LC SX Transceiver

JD118B

HP X120 1G SFP LC LX Transceiver

JD119B

HP X125 1G SFP LC LH70 Transceiver

JD063B

HP X125 1G SFP RJ45 T Transceiver

JD089B

HP X120 1G SFP LC BX 10-D Transceiver

JD098B

HP X120 1G SFP LC BX 10-D Transceiver

JD099B

HP X124 1G SFP LC LH40 1310nm Transceiver

JD061A

HP X120 1G SFP LC LH40 1550nm Transceiver

JD062A

Note 2

Localization required. (See Localization Menu for list.)

Note 3

The following Transceivers install into this switch: (SFP 100 Mbps ports only)

HP X110 100M SFP LC BX 10-U Transceiver

JD100A

HP X110 100M SFP LC BX 10-D Transceiver

JD101A

HP X115 100M SFP LC FX Transceiver

JD102B

HP X110 100M SFP LC LH40 Transceiver

JD090A

HP X110 100M SFP LC LH80 Transceiver

JD091A

HP X110 100M SFP LC LX Transceiver

JD120B

Note 4

When Switches are Not Factory Racked, Then Switch to Wall Power Cord should be the
Defaulted Power Cable option on the Switches.

Note 5

Localization (Wall Power Cord) required on orders without #B2B, #B2C (PDU Power Cord) or
#B2E. (See Localization Menu)

Note 6

#B2E is Offered only in NA, Mexico, Taiwan and Japan.

QuickSpecs

HP 3600 EI Switch Series

Configuration

c04111664 — DA – 13790 Worldwide — Version 12 — December 1, 2014

Page 9

Remarks

Drop down under power supply should offer the following options and results:
Switch/Router/Power Supply to PDU Power Cord - #B2B in North America, Mexico, Taiwan,
and Japan or #B2C ROW. (Watson Default B2B or B2C for Rack Level CTO)
Switch/Router/Power Supply to Wall Power Cord - Localized Option (Watson Default for BTO
and Box Level CTO)
High Volt Switch/Router/Power Supply to Wall Power Cord - #B2E Option. (Offered only in
North America, Mexico, Taiwan, and Japan)

Rack Level Integration CTO Models

HP 3600-24-PoE+ v2 EI Switch

JG301B

 24 RJ-45 autosensing 10/100 PoE+ ports
 2 dual-personality 10/100/1000 ports/ SFP 1000 Mbps ports
 2 SFP 1000 Mbps ports
 min=0 \ max=4 SFP 1000 Transceivers
 1U - Height

See Configuration

Note:1, 3, 4, 5

PDU Cable NA/MEX/TW/JP

JG301B#B2B

 C15 PDU Jumper Cord (NA/MEX/TW/JP)

PDU Cable ROW

JG301B#B2C

 C15 PDU Jumper Cord (ROW)

HP 3600-48-PoE+ v2 EI Switch

JG302B

 48 RJ-45 autosensing 10/100 PoE ports
 2 dual-personality 10/100/1000 ports/ SFP 1000 Mbps ports
 2 SFP 1000 Mbps ports
 min=0 \ max=4 SFP 1000 Transceivers
 1U - Height

See Configuration

Note:1, 3, 4, 5

PDU Cable NA/MEX/TW/JP

JG302B#B2B

 C15 PDU Jumper Cord (NA/MEX/TW/JP)

PDU Cable ROW

JG302B#B2C

 C15 PDU Jumper Cord (ROW)

Configuration Rules:

Note 1

The following Transceivers install into this switch: (SFP 1000 Mbps ports only)

HP X125 1G SFP LC SX Transceiver

JD118B

HP X120 1G SFP LC LX Transceiver

JD119B

HP X125 1G SFP LC LH70 Transceiver

JD063B

HP X125 1G SFP RJ45 T Transceiver

JD089B

HP X120 1G SFP LC BX 10-D Transceiver

JD098B

QuickSpecs

HP 3600 EI Switch Series

Configuration

c04111664 — DA – 13790 Worldwide — Version 12 — December 1, 2014

Page 10

HP X120 1G SFP LC BX 10-D Transceiver

JD099B

HP X124 1G SFP LC LH40 1310nm Transceiver

JD061A

HP X120 1G SFP LC LH40 1550nm Transceiver

JD062A

Note 3

When Switches are Factory Racked, Then #B2B, or #B2C should be the Defaulted Power Cable option on the
Switches.

Note 4

Localization (Wall Power Cord) required on orders without #B2B, #B2C (PDU Power Cord). (See Localization Menu)

Note 5

If the CTO Switch Chassis needs to be racked, Then the CTO Base Model needs to integrate (with #0D1) to the HP
Network Rack.

Remarks

Drop down under power supply should offer the following options and results:
Switch/Router/Power Supply to PDU Power Cord - #B2B in North America, Mexico, Taiwan, and Japan or #B2C
ROW. (Watson Default B2B or B2C for Rack Level CTO)
Switch/Router/Power Supply to Wall Power Cord - Localized Option (Watson Default for BTO and Box Level CTO)

Internal Power Supplies

Power Supplies included

Transceivers

SFP Transceivers

HP X120 1G SFP LC BX 10-U Transceiver

JD098B

HP X120 1G SFP LC BX 10-D Transceiver

JD099B

HP X120 1G SFP LC SX Transceiver

JD118B

HP X120 1G SFP LC LX Transceiver

JD119B

HP X125 1G SFP LC LH40 1310nm XCVR

JD061A

HP X120 1G SFP LC LH40 1550nm XCVR

JD062A

HP X125 1G SFP LC LH70 Transceiver

JD063B

HP X120 1G SFP RJ45 T Transceiver

JD089B

HP X110 100M SFP LC LH40 Transceiver

JD090A

HP X110 100M SFP LC LH80 Transceiver

JD091A

HP X110 100M SFP LC BX 10-U Transceiver

JD100A

HP X110 100M SFP LC BX 10-D Transceiver

JD101A

HP X115 100M SFP LC FX Transceiver

JD102B

HP X110 100M SFP LC LX Transceiver

JD120B

Switch Enclosure Options

Stacking Cable kit

HP 3600 Switch SFP Stacking Kit

JD324B

External Redundant Power Supplies

HP RPS 800 Redundant Power Supply

JD183A

QuickSpecs

HP 3600 EI Switch Series

Configuration

c04111664 — DA – 13790 Worldwide — Version 12 — December 1, 2014

Page 11

 Height = 1U
 includes 1 x c13, 800w

See Configuration

Note:2

HP RPS1600 Redundant Power System

JG136A

 Height = 1U
 includes 1 x c13, 1600w and Power Supply port

See Configuration

Note:2

HP RPS1600 1600W AC Power Supply

JG137A

 Installs into JG136A only

See Configuration

Note:1

Configuration Rules:

Note 1

If this power supply is selected, The JG136A - HP A-RPS1600 Redundant Power System must
be on order or onsite.

Note 2

Localization required. (See Localization Menu for list.)

External Redundant Power Cables

HP X290 500 V 1m RPS Cable

JD186A

HP X290 1000 A JD5 2m RPS Cable

JD187A

HP X290 1000 A JD5 Non-PoE 2m RPS Cable

JD188A

HP X290 1000 B JD5 2m RPS Cable

JD189A

QuickSpecs

HP 3600 EI Switch Series

Technical Specifications

c04111664 — DA – 13790 Worldwide — Version 12 — December 1, 2014

Page 12

HP 3600-24 v2 EI Switch (JG299A)

Ports

24 RJ-45 autosensing 10/100 ports; Duplex: half or full (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type
100BASE-TX)

4 SFP 1000 Mbps ports

2 dual-personality 1000 Mbps ports (IEEE 802.3ab Type 1000BASE-T)

1 RJ-45 serial console port

Physical characteristics
Dimensions

17.32(w) x 10.24(d) x 1.72(h) in (43.99 x 26.01 x 4.37 cm) (1U height)

Weight

11.02 lb (5 kg)

Memory and processor

256 MB SDRAM, 128 MB flash; packet buffer size: 2 MB

Mounting

Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included)

Performance

100 Mb Latency

< 6 µs

1000 Mb Latency

< 5 µs

Throughput

9.5 million pps

Routing/Switching
capacity

12.8 Gb/s

Routing table size

12000 entries (IPv4)

MAC address table size

32000 entries

Environment

Operating temperature

32°F to 122°F (0°C to 50°C)

Operating relative
humidity

5% to 95%, noncondensing

Nonoperating/Storage
temperature

-40ºF to 158ºF (-40ºC to 70ºC)

Nonoperating/Storage
relative humidity

5% to 95%, noncondensing

Acoustic

Low-speed fan: 42.8 dB, High-speed fan: 49.9 dB

Electrical characteristics

Frequency

50/60 Hz

Maximum heat
dissipation

106 BTU/hr (111.83 kJ/hr)

AC Voltage

100-240 VAC

Maximum power rating

31 W

Safety

UL 60950-1; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety of Laser Products-Part 2;
IEC 60950-1; CAN/CSA-C22.2 No. 60950-1; EN 60950-1/A11; FDA 21 CFR Subchapter J; ROHS
Compliance

Emissions

FCC part 15 Class A; VCCI Class A; EN 55022 Class A; CISPR 22 Class A; ICES-003 Class A; ANSI C63.4
2003; ETSI EN 300 386 V1.3.3; AS/NZS CISPR22 Class A; EN 61000-3-2; EN 61000-3-3; EN 61000-4-2;
EN 61000-4-3; EN 61000-4-4; EN 61000-4-5; EN 61000-4-6; EN 61000-4-11; EN 61000-3-2:2006; EN
61000-3-3:1995 +A1:2001+A2:2005; EMC Directive 2004/108/EC; FCC (CFR 47, Part 15) Class A

Management

IMC - Intelligent Management Center; command-line interface; Web browser; SNMP Manager

Services

3-year, 4-hour onsite, 13x5 coverage for hardware (UV822E)
3-year, 4-hour onsite, 24x7 coverage for hardware (UV825E)
3-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone support (UV828E)
3-year, 24x7 SW phone support, software updates (UV831E)
1-year, post-warranty, 4-hour onsite, 13x5 coverage for hardware (HR589E)
1-year, post-warranty, 4-hour onsite, 24x7 coverage for hardware (HR590E)
1-year, post-warranty, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone support
(HR591E)
4-year, 4-hour onsite, 13x5 coverage for hardware (UV823E)

QuickSpecs

HP 3600 EI Switch Series

Technical Specifications

c04111664 — DA – 13790 Worldwide — Version 12 — December 1, 2014

Page 13

4-year, 4-hour onsite, 24x7 coverage for hardware (UV826E)
4-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone (UV829E)
4-year, 24x7 SW phone support, software updates (UV832E)
5-year, 4-hour onsite, 13x5 coverage for hardware (UV824E)
5-year, 4-hour onsite, 24x7 coverage for hardware (UV827E)
5-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone (UV830E)
5-year, 24x7 SW phone support, software updates (UV833E)
3 Yr 6 hr Call-to-Repair Onsite (UW431E)
4 Yr 6 hr Call-to-Repair Onsite (UW432E)
5 Yr 6 hr Call-to-Repair Onsite (UW433E)
1-year, 6 hour Call-To-Repair Onsite for hardware (HR593E)
1-year, 24x7 software phone support, software updates (HR592E)
1-year, 24x7 software phone support, software updates + Next Business Day Hardware Exchange
(HS690E)
1-year, 24x7 software phone support, software updates + 4 hour hardware exchange (HS691E)
3-year, 24x7 software phone support, software updates + Next Business Day Hardware Exchange
(HS692E)
3-year, 24x7 software phone support, software updates + 4 hour Hardware Exchange (HS693E)
4-year, 24x7 software phone support, software updates + Next Business Day Hardware Exchange
(HS694E)
4-year, 24x7 software phone support, software updates + 4 hour Hardware Exchange (HS695E)
5-year, 24x7 software phone support, software updates + Next Business Day Hardware Exchange
(HS696E)
5-year, 24x7 software phone support, software updates + 4 hour Hardware Exchange (HS697E)

Refer to the HP website at: www.hp.com/networking/services for details on the service-level
descriptions and product numbers. For details about services and response times in your area, please
contact your local HP sales office.

HP 3600-48 v2 EI Switch (JG300A)

Ports

48 RJ-45 autosensing 10/100 ports; Duplex: half or full (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type
100BASE-TX)

4 SFP 1000 Mbps ports

2 dual-personality 1000 Mbps ports (IEEE 802.3ab Type 1000BASE-T)

1 RJ-45 serial console port

Physical characteristics
Dimensions

17.32(w) x 10.24(d) x 1.72(h) in (43.99 x 26.01 x 4.37 cm) (1U height)

Weight

11.02 lb (5 kg)

Memory and processor

256 MB SDRAM, 128 MB flash; packet buffer size: 2 MB

Mounting

Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included)

Performance

100 Mb Latency

< 6 µs

1000 Mb Latency

< 5 µs

Throughput

13.1 million pps

Routing/Switching
capacity

17.6 Gb/s

Routing table size

12000 entries (IPv4)

MAC address table size

32000 entries

Environment

Operating temperature

32°F to 122°F (0°C to 50°C)

Operating relative
humidity

5% to 95%, noncondensing

Nonoperating/Storage
temperature

-40ºF to 158ºF (-40ºC to 70ºC)

QuickSpecs

HP 3600 EI Switch Series

Technical Specifications

c04111664 — DA – 13790 Worldwide — Version 12 — December 1, 2014

Page 14

Nonoperating/Storage
relative humidity

5% to 95%, noncondensing

Acoustic

Low-speed fan: 43.5 dB, High-speed fan: 55.0 dB

Electrical characteristics

Frequency

50/60 Hz

Maximum heat
dissipation

147 BTU/hr (155.08 kJ/hr)

AC Voltage

100-240 VAC

Maximum power rating

43 W

Safety

UL 60950-1; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety of Laser Products-Part 2;
IEC 60950-1; CAN/CSA-C22.2 No. 60950-1; EN 60950-1/A11; FDA 21 CFR Subchapter J; ROHS
Compliance

Emissions

FCC part 15 Class A; VCCI Class A; EN 55022 Class A; CISPR 22 Class A; ICES-003 Class A; ANSI C63.4
2003; ETSI EN 300 386 V1.3.3; AS/NZS CISPR22 Class A; EN 61000-3-2; EN 61000-3-3; EN 61000-4-2;
EN 61000-4-3; EN 61000-4-4; EN 61000-4-5; EN 61000-4-6; EN 61000-4-11; EN 61000-3-2:2006; EN
61000-3-3:1995 +A1:2001+A2:2005; EMC Directive 2004/108/EC; FCC (CFR 47, Part 15) Class A

Management

IMC - Intelligent Management Center; command-line interface; Web browser; SNMP Manager

Services

3-year, 4-hour onsite, 13x5 coverage for hardware (UV822E)
3-year, 4-hour onsite, 24x7 coverage for hardware (UV825E)
3-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone support (UV828E)
3-year, 24x7 SW phone support, software updates (UV831E)
1-year, post-warranty, 4-hour onsite, 13x5 coverage for hardware (HR589E)
1-year, post-warranty, 4-hour onsite, 24x7 coverage for hardware (HR590E)
1-year, post-warranty, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone support
(HR591E)
4-year, 4-hour onsite, 13x5 coverage for hardware (UV823E)
4-year, 4-hour onsite, 24x7 coverage for hardware (UV826E)
4-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone (UV829E)
4-year, 24x7 SW phone support, software updates (UV832E)
5-year, 4-hour onsite, 13x5 coverage for hardware (UV824E)
5-year, 4-hour onsite, 24x7 coverage for hardware (UV827E)
5-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone (UV830E)
5-year, 24x7 SW phone support, software updates (UV833E)
3 Yr 6 hr Call-to-Repair Onsite (UW431E)
4 Yr 6 hr Call-to-Repair Onsite (UW432E)
5 Yr 6 hr Call-to-Repair Onsite (UW433E)
1-year, 6 hour Call-To-Repair Onsite for hardware (HR593E)
1-year, 24x7 software phone support, software updates (HR592E)
1-year, 24x7 software phone support, software updates + Next Business Day Hardware Exchange
(HS690E)
1-year, 24x7 software phone support, software updates + 4 hour hardware exchange (HS691E)
3-year, 24x7 software phone support, software updates + Next Business Day Hardware Exchange
(HS692E)
3-year, 24x7 software phone support, software updates + 4 hour Hardware Exchange (HS693E)
4-year, 24x7 software phone support, software updates + Next Business Day Hardware Exchange
(HS694E)
4-year, 24x7 software phone support, software updates + 4 hour Hardware Exchange (HS695E)
5-year, 24x7 software phone support, software updates + Next Business Day Hardware Exchange
(HS696E)
5-year, 24x7 software phone support, software updates + 4 hour Hardware Exchange (HS697E)

Refer to the HP website at: www.hp.com/networking/services for details on the service-level
descriptions and product numbers. For details about services and response times in your area, please
contact your local HP sales office.

QuickSpecs

HP 3600 EI Switch Series

Technical Specifications

c04111664 — DA – 13790 Worldwide — Version 12 — December 1, 2014

Page 15

HP 3600-24-PoE+ v2 EI Switch (JG301B)

Ports

24 RJ-45 autosensing 10/100 PoE+ ports; Duplex: half or full (IEEE 802.3 Type 10BASE-T, IEEE 802.3u
Type 100BASE-TX, IEEE 802.3at PoE+)

4 SFP 1000 Mbps ports

2 dual-personality 1000 Mbps ports (IEEE 802.3ab Type 1000BASE-T)

1 RJ-45 serial console port

Physical characteristics
Dimensions

17.32(w) x 16.54(d) x 1.72(h) in (43.99 x 42.01 x 4.37 cm) (1U height)

Weight

22.05 lb (10 kg)

Memory and processor

256 MB SDRAM, 128 MB flash; packet buffer size: 2 MB

Mounting

Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included)

Performance

100 Mb Latency

< 6 µs

1000 Mb Latency

< 5 µs

Throughput

9.5 million pps

Routing/Switching
capacity

12.8 Gb/s

Routing table size

12000 entries (IPv4)

MAC address table size

32000 entries

Environment

Operating temperature

32°F to 122°F (0°C to 50°C)

Operating relative
humidity

5% to 95%, noncondensing

Nonoperating/Storage
temperature

-40ºF to 158ºF (-40ºC to 70ºC)

Nonoperating/Storage
relative humidity

5% to 95%, noncondensing

Acoustic

Low-speed fan: 44.7 dB, High-speed fan: 53.8 dB

Electrical characteristics

Frequency

50/60 Hz

Maximum heat
dissipation

143 BTU/hr (150.86 kJ/hr)

AC Voltage

100-240 VAC

Maximum power rating

795 W

PoE power

720 W

Safety

UL 60950-1; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety of Laser Products-Part 2;
IEC 60950-1; CAN/CSA-C22.2 No. 60950-1; EN 60950-1/A11; FDA 21 CFR Subchapter J; ROHS
Compliance

Emissions

FCC part 15 Class A; VCCI Class A; EN 55022 Class A; CISPR 22 Class A; ICES-003 Class A; ANSI C63.4
2003; ETSI EN 300 386 V1.3.3; AS/NZS CISPR22 Class A; EN 61000-3-2; EN 61000-3-3; EN 61000-4-2;
EN 61000-4-3; EN 61000-4-4; EN 61000-4-5; EN 61000-4-6; EN 61000-4-11; EN 61000-3-2:2006; EN
61000-3-3:1995 +A1:2001+A2:2005; EMC Directive 2004/108/EC; FCC (CFR 47, Part 15) Class A

Management

IMC - Intelligent Management Center; command-line interface; Web browser; SNMP Manager

Services

Refer to the HP website at: www.hp.com/networking/services for details on the service-level
descriptions and product numbers. For details about services and response times in your area, please
contact your local HP sales office.

HP 3600-48-PoE+ v2 EI Switch (JG302B)

Ports

48 RJ-45 autosensing 10/100 PoE+ ports; Duplex: half or full (IEEE 802.3 Type 10BASE-T, IEEE 802.3u
Type 100BASE-TX, IEEE 802.3at PoE+)

4 SFP 1000 Mbps ports

QuickSpecs

HP 3600 EI Switch Series

Technical Specifications

c04111664 — DA – 13790 Worldwide — Version 12 — December 1, 2014

Page 16

2 dual-personality 1000 Mbps ports (IEEE 802.3ab Type 1000BASE-T)

1 RJ-45 serial console port

Physical characteristics
Dimensions

17.32(w) x 16.54(d) x 1.72(h) in (44 x 42 x 4.36 cm) (1U height)

Weight

22.05 lb (10 kg)

Memory and processor

256 MB SDRAM, 128 MB flash; packet buffer size: 4 MB

Mounting

Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included)

Performance

100 Mb Latency

< 6 µs

1000 Mb Latency

< 5 µs

Throughput

up to 13.1 million pps

Routing/Switching
capacity

17.6 Gb/s

Routing table size

12000 entries (IPv4)

MAC address table size

32000 entries

Environment

Operating temperature

32°F to 122°F (0°C to 50°C)

Operating relative
humidity

5% to 95%, noncondensing

Nonoperating/Storage
temperature

-40ºF to 158ºF (-40ºC to 70ºC)

Nonoperating/Storage
relative humidity

5% to 95%, noncondensing

Acoustic

Low-speed fan: 43.5 dB, High-speed fan: 55 dB

Electrical characteristics

Frequency

50/60 Hz

Maximum heat
dissipation

198 BTU/hr (208.89 kJ/hr)

AC Voltage

100-240 VAC

Maximum power rating

440 W

PoE power

320 W

Safety

UL 60950-1; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety of Laser Products-Part 2;
IEC 60950-1; CAN/CSA-C22.2 No. 60950-1; EN 60950-1/A11; FDA 21 CFR Subchapter J; ROHS
Compliance

Emissions

FCC part 15 Class A; VCCI Class A; EN 55022 Class A; CISPR 22 Class A; ICES-003 Class A; ANSI C63.4
2003; ETSI EN 300 386 V1.3.3; AS/NZS CISPR22 Class A; EN 61000-3-2; EN 61000-3-3; EN 61000-4-2;
EN 61000-4-3; EN 61000-4-4; EN 61000-4-5; EN 61000-4-6; EN 61000-4-11; EN 61000-3-2:2006; EN
61000-3-3:1995 +A1:2001+A2:2005; EMC Directive 2004/108/EC; FCC (CFR 47, Part 15) Class A

Management

IMC - Intelligent Management Center; command-line interface; Web browser; SNMP Manager

Services

Refer to the HP website at: www.hp.com/networking/services for details on the service-level
descriptions and product numbers. For details about services and response times in your area, please
contact your local HP sales office.

HP 3600-24-SFP v2 EI Switch (JG303A)

Ports

24 SFP 100 Mbps ports

4 SFP 1000 Mbps ports

2 dual-personality 1000 Mbps ports; Media Type: Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or
full; 1000BASE-T: full only (IEEE 802.3ab Type 1000BASE-T)

1 RJ-45 serial console port

Physical characteristics
Dimensions

17.32(w) x 10.24(d) x 1.72(h) in (43.99 x 26.01 x 4.37 cm) (1U height)

Weight

11.02 lb (5 kg)

QuickSpecs

HP 3600 EI Switch Series

Technical Specifications

c04111664 — DA – 13790 Worldwide — Version 12 — December 1, 2014

Page 17

Memory and processor

256 MB SDRAM, 128 MB flash; packet buffer size: 2 MB

Mounting

Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included)

Performance

100 Mb Latency

< 6 µs

1000 Mb Latency

< 5 µs

Throughput

9.5 million pps

Routing/Switching
capacity

12.8 Gb/s

Routing table size

12000 entries (IPv4)

MAC address table size

32000 entries

Environment

Operating temperature

32°F to 122°F (0°C to 50°C)

Operating relative
humidity

5% to 95%, noncondensing

Nonoperating/Storage
temperature

-40ºF to 158ºF (-40ºC to 70ºC)

Nonoperating/Storage
relative humidity

5% to 95%, noncondensing

Acoustic

Low-speed fan: 43.5 dB, High-speed fan: 50.1 dB

Electrical characteristics

Frequency

50/60 Hz

Maximum heat
dissipation

205 BTU/hr (216.27 kJ/hr)

AC Voltage

100-240 VAC

Maximum power rating

60 W

Safety

UL 60950-1; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety of Laser Products-Part 2;
IEC 60950-1; CAN/CSA-C22.2 No. 60950-1; EN 60950-1/A11; FDA 21 CFR Subchapter J; ROHS
Compliance

Emissions

FCC part 15 Class A; VCCI Class A; EN 55022 Class A; CISPR 22 Class A; ICES-003 Class A; ANSI C63.4
2003; ETSI EN 300 386 V1.3.3; AS/NZS CISPR22 Class A; EN 61000-3-2; EN 61000-3-3; EN 61000-4-2;
EN 61000-4-3; EN 61000-4-4; EN 61000-4-5; EN 61000-4-6; EN 61000-4-11; EN 61000-3-2:2006; EN
61000-3-3:1995 +A1:2001+A2:2005; EMC Directive 2004/108/EC; FCC (CFR 47, Part 15) Class A

Management

IMC - Intelligent Management Center; command-line interface; Web browser; SNMP Manager

Services

3-year, 4-hour onsite, 13x5 coverage for hardware (UV822E)
3-year, 4-hour onsite, 24x7 coverage for hardware (UV825E)
3-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone support (UV828E)
3-year, 24x7 SW phone support, software updates (UV831E)
1-year, post-warranty, 4-hour onsite, 13x5 coverage for hardware (HR589E)
1-year, post-warranty, 4-hour onsite, 24x7 coverage for hardware (HR590E)
1-year, post-warranty, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone support
(HR591E)
4-year, 4-hour onsite, 13x5 coverage for hardware (UV823E)
4-year, 4-hour onsite, 24x7 coverage for hardware (UV826E)
4-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone (UV829E)
4-year, 24x7 SW phone support, software updates (UV832E)
5-year, 4-hour onsite, 13x5 coverage for hardware (UV824E)
5-year, 4-hour onsite, 24x7 coverage for hardware (UV827E)
5-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone (UV830E)
5-year, 24x7 SW phone support, software updates (UV833E)
3 Yr 6 hr Call-to-Repair Onsite (UW431E)
4 Yr 6 hr Call-to-Repair Onsite (UW432E)
5 Yr 6 hr Call-to-Repair Onsite (UW433E)
1-year, 6 hour Call-To-Repair Onsite for hardware (HR593E)

QuickSpecs

HP 3600 EI Switch Series

Technical Specifications

c04111664 — DA – 13790 Worldwide — Version 12 — December 1, 2014

Page 18

1-year, 24x7 software phone support, software updates (HR592E)
1-year, 24x7 software phone support, software updates + Next Business Day Hardware Exchange
(HS690E)
1-year, 24x7 software phone support, software updates + 4 hour hardware exchange (HS691E)
3-year, 24x7 software phone support, software updates + Next Business Day Hardware Exchange
(HS692E)
3-year, 24x7 software phone support, software updates + 4 hour Hardware Exchange (HS693E)
4-year, 24x7 software phone support, software updates + Next Business Day Hardware Exchange
(HS694E)
4-year, 24x7 software phone support, software updates + 4 hour Hardware Exchange (HS695E)
5-year, 24x7 software phone support, software updates + Next Business Day Hardware Exchange
(HS696E)
5-year, 24x7 software phone support, software updates + 4 hour Hardware Exchange (HS697E)

Refer to the HP website at: www.hp.com/networking/services for details on the service-level
descriptions and product numbers. For details about services and response times in your area, please
contact your local HP sales office.

Standards and protocols
(applies to all products in
series)

Device management
RFC 1157 SNMPv1/v2c
RFC 1901-1907 SNMPv2c, SMIv2 and Revised MIB­II
RFC 2573 (SNMPv3 Applications)
RFC 2578-2580 SMIv2
RFC 2819 (RMON groups Alarm, Event, History and
Statistics only)
RFC 3410 (Management Framework)
RFC 3416 (SNMP Protocol Operations v2)
RFC 3417 (SNMP Transport Mappings)
HTML and telnet management
Multiple Configuration Files
SNMP v3 and RMON RFC support
SSHv1/SSHv2 Secure Shell

General protocols
IEEE 802.1ad Q-in-Q
IEEE 802.1D MAC Bridges
IEEE 802.1p Priority
IEEE 802.1Q VLANs
IEEE 802.1s (MSTP)
IEEE 802.1v VLAN classification by Protocol and
Port
IEEE 802.1w Rapid Reconfiguration of Spanning
Tree
IEEE 802.1X PAE
IEEE 802.3 Type 10BASE-T
IEEE 802.3ab 1000BASE-T
IEEE 802.3ac (VLAN Tagging Extension)
IEEE 802.3ad Link Aggregation Control Protocol
(LACP)
IEEE 802.3af Power over Ethernet
IEEE 802.3at Power over Ethernet Plus
IEEE 802.3i 10BASE-T
IEEE 802.3u 100BASE-X
IEEE 802.3x Flow Control

MIBs
RFC 1213 MIB II
RFC 1493 Bridge MIB
RFC 1724 RIPv2 MIB
RFC 1757 Remote Network Monitoring MIB
RFC 1850 OSPFv2 MIB
RFC 1907 SNMPv2 MIB
RFC 2233 Interfaces MIB
RFC 2571 SNMP Framework MIB
RFC 2572 SNMP-MPD MIB
RFC 2573 SNMP-Notification MIB
RFC 2573 SNMP-Target MIB
RFC 2574 SNMP USM MIB
RFC 2618 RADIUS Authentication Client MIB
RFC 2620 RADIUS Accounting Client MIB
RFC 2665 Ethernet-Like-MIB
RFC 2674 802.1p and IEEE 802.1Q Bridge MIB
RFC 2819 RMON MIB
RFC 2863 The Interfaces Group MIB
RFC 3414 SNMP-User based-SM MIB
RFC 3415 SNMP-View based-ACM MIB

Network management
IEEE 802.1AB Link Layer Discovery Protocol (LLDP)
RFC 1157 SNMPv1
RFC 1757 RMON 4 groups: Stats, History, Alarms
and Events
RFC 1901 Introduction to Community-based
SNMPv2
RFC 1902 Structure of Management Information
for
Version 2 of the Simple Network Management
Protocol (SNMPv2)
RFC 1903 SNMPv2 Textual Conventions
RFC 1904 SNMPv2 Conformance
RFC 1905 SNMPv2 Protocol Operations
RFC 1906 SNMPv2 Transport Mappings

QuickSpecs

HP 3600 EI Switch Series

Technical Specifications

c04111664 — DA – 13790 Worldwide — Version 12 — December 1, 2014

Page 19

IEEE 802.3z 1000BASE-X
RFC 768 UDP
RFC 783 TFTP Protocol (revision 2)
RFC 791 IP
RFC 792 ICMP
RFC 793 TCP
RFC 826 ARP
RFC 1058 RIPv1
RFC 1213 Management Information Base for
Network Management of TCP/IP-based internets
RFC 1812 IPv4 Routing
RFC 2131 DHCP
RFC 2236 IGMP Snooping
RFC 2338 VRRP
RFC 2453 RIPv2
RFC 2644 Directed Broadcast Control
RFC 2665 Definitions of Managed Objects for the
Ethernet-like Interface Types
RFC 2711 IPv6 Router Alert Option
RFC 3410 Applicability Statements for SNMP
RFC 3414 User-based Security Model (USM) for
version 3 of the Simple Network Management
Protocol (SNMPv3)
RFC 3415 View-based Access Control Model
(VACM) for the Simple Network Management
Protocol (SNMP)
RFC 3416 Protocol Operations for SNMP
RFC 3417 Transport Mappings for the Simple
Network Management Protocol (SNMP)
RFC 4594 Configuration Guidelines for DiffServ
Service Classes

IP multicast
RFC 1112 IGMP
RFC 2236 IGMPv2
RFC 2362 PIM Sparse Mode
RFC 3618 Multicast Source Discovery Protocol
(MSDP)
RFC 3973 PIM Dense Mode

IPv6
RFC 1881 IPv6 Address Allocation Management
RFC 1887 IPv6 Unicast Address Allocation
Architecture
RFC 1981 IPv6 Path MTU Discovery
RFC 2080 RIPng for IPv6
RFC 2373 IPv6 Addressing Architecture
RFC 2375 IPv6 Multicast Address Assignments
RFC 2460 IPv6 Specification
RFC 2461 IPv6 Neighbor Discovery
RFC 2462 IPv6 Stateless Address Auto­configuration
RFC 2463 ICMPv6
RFC 2464 Transmission of IPv6 over Ethernet
Networks

RFC 2570 SNMPv3 Overview
RFC 2571 An Architecture for Describing SNMP
Management Frameworks
RFC 2572 Message Processing and Dispatching for
the
Simple Network Management Protocol (SNMP)
RFC 2573 SNMP Applications
RFC 2574 SNMPv3 User-based Security Model
(USM)
RFC 2575 SNMPv3 View-based Access Control
Model
(VACM)
RFC 2578 Structure of Management Information
Version
2 (SMIv2)
RFC 2579 Textual Conventions for SMIv2
RFC 2580 Conformance Statements for SMIv2
RFC 2819 Four groups of RMON: 1 (statistics), 2
(history), 3 (alarm) and 9 (events)
RFC 3410 Introduction to Version 3 of the
Internet-standard Network Management
Framework
RFC 3414 SNMPv3 User-based Security Model
(USM)
RFC 3415 SNMPv3 View-based Access Control
Model VACM)
ANSI/TIA-1057 LLDP Media Endpoint Discovery
(LLDP-MED)
SNMPv1/v2c/v3

OSPF
RFC 1583 OSPFv2
RFC 1587 OSPF NSSA
RFC 1850 OSPFv2 Management Information Base
(MIB), traps
RFC 2328 OSPFv2

QoS/CoS
RFC 4594 Configuration Guidelines for DiffServ
Service Classes

QuickSpecs

HP 3600 EI Switch Series

Technical Specifications

c04111664 — DA – 13790 Worldwide — Version 12 — December 1, 2014

Page 20

RFC 2475 IPv6 DiffServ Architecture
RFC 2710 Multicast Listener Discovery (MLD) for
IPv6
RFC 2711 IPv6 Router Alert Option
RFC 2740 OSPFv3 for IPv6
RFC 2893 Transition Mechanisms for IPv6 Hosts
and Routers
RFC 2925 Definitions of Managed Objects for
Remote Ping, Traceroute, and Lookup Operations
(Ping only)
RFC 2925 Remote Operations MIB (Ping only)
RFC 3056 Connection of IPv6 Domains via IPv4
Clouds
RFC 3162 RADIUS and IPv6
RFC 3306 Unicast-Prefix-based IPv6 Multicast
Addresses
RFC 3307 IPv6 Multicast Address Allocation
RFC 3315 DHCPv6 (client and relay)
RFC 3484 Default Address Selection for IPv6
RFC 3493 Basic Socket Interface Extensions for
IPv6
RFC 3513 IPv6 Addressing Architecture
RFC 3542 Advanced Sockets API for IPv6
RFC 3587 IPv6 Global Unicast Address Format
RFC 3596 DNS Extension for IPv6
RFC 3810 MLDv2 (host joins only)
RFC 4113 MIB for UDP
RFC 4293 MIB for IP
RFC 4443 ICMPv6
RFC 5340 OSPFv3 for IPv6

QuickSpecs

HP 3600 EI Switch Series

Accessories

c04111664 — DA – 13790 Worldwide — Version 12 — December 1, 2014

Page 21

HP 3600 EI Switch Series
accessories

Transceivers

HP X124 1G SFP LC LH40 1310nm Transceiver

JD061A

HP X120 1G SFP LC LH40 1550nm Transceiver

JD062A

HP X125 1G SFP LC LH70 Transceiver

JD063B

HP X125 1G SFP RJ45 T Transceiver

JD089B

HP X110 100M SFP LC LH40 Transceiver

JD090A

HP X110 100M SFP LC LH80 Transceiver

JD091A

HP X120 1G SFP LC BX 10-U Transceiver

JD098B

HP X120 1G SFP LC BX 10-D Transceiver

JD099B

HP X115 100M SFP LC BX 10-U Transceiver

JD100A

HP X115 100M SFP LC BX 10-D Transceiver

JD101A

HP X110 100M SFP LC FX Transceiver

JD102B

HP X120 1G SFP LC LH100 Transceiver

JD103A

HP X120 1G SFP LC SX Transceiver

JD118B

HP X120 1G SFP LC LX Transceiver

JD119B

Cables

HP 3600 Switch SFP Stacking Kit

JD324B

HP 0.5 m Multimode OM3 LC/LC Optical Cable

AJ833A

HP 1 m Multimode OM3 LC/LC Optical Cable

AJ834A

HP 2 m Multimode OM3 LC/LC Optical Cable

AJ835A

HP 5 m Multimode OM3 LC/LC Optical Cable

AJ836A

HP 15 m Multimode OM3 LC/LC Optical Cable

AJ837A

HP 30 m Multimode OM3 LC/LC Optical Cable

AJ838A

HP 50 m Multimode OM3 LC/LC Optical Cable

AJ839A

HP Premier Flex LC/LC Multi-mode OM4 2 fiber 1m Cable

QK732A

HP Premier Flex LC/LC Multi-mode OM4 2 fiber 2m Cable

QK733A

HP Premier Flex LC/LC Multi-mode OM4 2 fiber 5m Cable

QK734A

HP Premier Flex LC/LC Multi-mode OM4 2 fiber 15m Cable

QK735A

HP Premier Flex LC/LC Multi-mode OM4 2 fiber 30m Cable

QK736A

HP Premier Flex LC/LC Multi-mode OM4 2 fiber 50m Cable

QK737A

Power Supply

HP RPS800 Redundant Power System

JD183A

HP RPS1600 Redundant Power System

JG136A

HP RPS1600 1600W AC Power Supply

JG137A

Power cords

HP X290 H2.7 JD5-A 1m RPS800 Cable

JD186A

HP X290 JD5 JD5 2m RPS1600 Cable

JD187A

HP X290 JD5-A JD5-A 2m RPS1600 Cable

JD188A

HP X290 JD5 JD5-A 2m RPS1600 Cable

JD189A

HP 3600-24-SFP v2 EI Switch (JG303A)

HP X110 100M SFP LC LX Transceiver

JD120B

HP X110 100M SFP LC FX Transceiver

JD102B

HP gl/xl/vl Switch Redundant Power Supply

J4839A

QuickSpecs

HP 3600 EI Switch Series

Accessory Product Details

c04111664 — DA – 13790 Worldwide — Version 12 — December 1, 2014

Page 22

NOTE: Details are not available for all accessories. The following specifications were available at the time of publication.

HP X124 1G SFP LC LH40
1310nm Transceiver

(JD061A)

A small form-factor
pluggable SFP Gigabit
LH40 transceiver that
provides a full duplex
Gigabit solution up to
40km on a single-mode
fiber.

Ports

1 LC 1000Base-LH port (no IEEE standard exists for 1550 nm optics)

Connectivity

Connector type

LC

Wavelength

1310 nm

Physical characteristics
Dimensions

2.17(d) x 0.6(w) x 0.46(h) in. (5.51 x 1.52 x 1.17
cm)

Full configuration weight

0.04 lb. (0.02 kg)

Electrical characteristics

Power consumption
typical

0.8 W

Power consumption
maximum

1.0 W

Cabling
Cable type:

Single-mode fiber optic, complying with ITU-T G.652;

Maximum distance:

 40km distance

Fiber type

Single Mode

Services

Refer to the HP website at www.hp.com/networking/services for details on
the service-level descriptions and product numbers. For details about
services and response times in your area, please contact your local HP sales
office.

HP X120 1G SFP LC LH40
1550nm Transceiver

(JD062A)

A small form-factor
pluggable (SFP) Gigabit
LH40 transceiver that
provides a full-duplex
Gigabit solution up to 40
km on a single mode fiber.

Ports

1 LC 1000BASE-LH port (no IEEE standard exists for 1550 nm optics)

Connectivity

Connector type

LC

Wavelength

1550 nm

Physical characteristics
Dimensions

2.17(d) x 0.6(w) x 0.46(h) in. (5.51 x 1.52 x 1.17
cm)

Full configuration weight

0.04 lb. (0.02 kg)

Electrical characteristics

Power consumption
typical

0.8 W

Power consumption
maximum

1.0 W

Cabling
Cable type:

Single-mode fiber optic, complying with ITU-T G.652;

Maximum distance:

 40km distance

Fiber type

Single Mode

Services

Refer to the HP website at www.hp.com/networking/services for details on
the service-level descriptions and product numbers. For details about
services and response times in your area, please contact your local HP sales
office.

HP X125 1G SFP LC LH70
Ports

1 LC 1000BASE-LH port (no IEEE standard exists for 1550 nm optics)

Connectivity

Connector type

LC

QuickSpecs

HP 3600 EI Switch Series

Accessory Product Details

c04111664 — DA – 13790 Worldwide — Version 12 — December 1, 2014

Page 23

Transceiver (JD063B)

A small form-factor
pluggable (SFP) Gigabit
LH70 transceiver that
provides a full-duplex
Gigabit solution up to
70km on a single-mode
fiber.

Wavelength

1550 nm

Physical characteristics
Dimensions

2.17(d) x 0.6(w) x 0.46(h) in. (5.51 x 1.52 x 1.17
cm)

Full configuration weight

0.04 lb. (0.02 kg)

Electrical characteristics

Power consumption
typical

0.8 W

Power consumption
maximum

1.0 W

Cabling
Cable type:

Single-mode fiber optic, complying with ITU-T G.652;

Maximum distance:

• 70km

Fiber type

Single Mode

Services

Refer to the HP website at www.hp.com/networking/services for details on
the service-level descriptions and product numbers. For details about
services and response times in your area, please contact your local HP
sales office.

HP X125 1G SFP
RJ45 T
Transceiver

(JD089B)

A small form
factor pluggable
(SFP) Gigabit
1000Base-T
transceiver that
provides a full
duplex Gigabit
solution up to
100m on a Cat­5+ cable.

Ports

1 RJ-45 1000BASE-T port (IEEE 802.3ab Type 1000BASE-T)

Connectivity

Connector type

RJ-45

Physical
characteristics

Dimensions

2.71(d) x 0.54(w) x 0.55(h) in. (6.88 x 1.37 x 1.4 cm)

Full configuration weight

0.07 lb. (0.03 kg)

Electrical
characteristics

Power consumption typical

0.8 W

Power consumption maximum

1.0 W

Cabling

Cable type:
1000BASE-T: Category 5 (5E or better recommended), 100 Ù differential 4-pair unshielded
twisted pair (UTP) or shielded twisted pair (STP) balanced, complying with IEEE 802.3ab
1000BASE-T;

Maximum distance:

• 100m

Services

Refer to the HP website at www.hp.com/networking/services for details on the service­level descriptions and product numbers. For details about services and response times in
your area, please contact your local HP sales office.

HP X120 1G SFP LC BX 10­U Transceiver (JD098B)

A small form-factor
pluggable (SFP) Gigabit
LX-BX10-U transceiver
that provides a full duplex
Gigabit solution up to
10km on a single mode
cable.

Ports

1 LC 1000BASE-BX10 port (IEEE 802.3ah Type 1000BASE-BX10-U); Duplex:
full only

Connectivity

Connector type

LC

Physical characteristics
Dimensions

2.17(d) x 0.6(w) x 0.46(h) in. (5.51 x 1.52 x 1.17
cm)

Full configuration weight

0.04 lb. (0.02 kg)

Electrical characteristics

Power consumption
typical

0.8 W

Power consumption
maximum

1.0 W

Cabling
Maximum distance:

• 10km

Fiber type

Single Mode

QuickSpecs

HP 3600 EI Switch Series

Accessory Product Details

c04111664 — DA – 13790 Worldwide — Version 12 — December 1, 2014

Page 24

Notes

TX 1310nm RX 1490nm

Services

Refer to the HP website at: www.hp.com/networking/services for details
on the service-level descriptions and product numbers. For details about
services and response times in your area, please contact your local HP
sales office.

HP X120 1G SFP LC BX 10­D Transceiver (JD099B)

A small form-factor
pluggable (SFP) Gigabit
LX-BX10-D transceiver
that provides a full duplex
Gigabit solution up to
10km on a single mode
cable.

Ports

1 LC 1000BASE-BX10 port (IEEE 802.3ah Type 1000BASE-BX10-D); Duplex:
full only

Connectivity

Connector type

LC

Physical characteristics
Dimensions

2.17(d) x 0.6(w) x 0.46(h) in. (5.51 x 1.52 x 1.17
cm)

Full configuration weight

0.04 lb. (0.02 kg)

Electrical characteristics

Power consumption
typical

0.8 W

Power consumption
maximum

1.0 W

Cabling
Maximum distance:

• Up to 10km

Fiber type

Single Mode

Notes

TX 1490nm RX 1310nm

Services

Refer to the HP website at www.hp.com/networking/services for details on
the service-level descriptions and product numbers. For details about
services and response times in your area, please contact your local HP
sales office.

HP X120 1G SFP LC SX
Transceiver (JD118B)

A small form-factor
pluggable (SFP) Gigabit SX
transceiver that provides
a full-duplex Gigabit
solution up to 550m on a
Multimode fiber.

Ports

1 LC 1000BASE-SX port

Connectivity
Connector type

LC

Wavelength

850 nm

Physical characteristics
Dimensions

2.17(d) x 0.6(w) x 0.46(h) in. (5.51 x 1.52 x 1.17
cm)

Full configuration weight

0.04 lb. (0.02 kg)

Electrical characteristics

Power consumption
typical

0.8 W

Power consumption
maximum

1.0 W

Cabling

Maximum distance:

• FDDI Grade distance = 220m

• OM1 = 275m

• OM2 = 500m

• OM3 = Not Specified by standard

Cable length

up to 550m

Fiber type

Multi Mode

Services

Refer to the HP website at www.hp.com/networking/services for details on
the service-level descriptions and product numbers. For details about
services and response times in your area, please contact your local HP
sales office.

HP X120 1G SFP LC LX
Ports

1 SFP 1000BASE-LX port (IEEE 802.3z Type 1000BASE-LX)

Connectivity

Connector type

LC

QuickSpecs

HP 3600 EI Switch Series

Accessory Product Details

c04111664 — DA – 13790 Worldwide — Version 12 — December 1, 2014

Page 25

Transceiver (JD119B)

A small form-factor
pluggable (SFP) Gigabig
LX transceiver that
provides a full duplex
Gigabit solution up to
550m on MMF or 10Km on
SMF

Wavelength

1300 nm

Physical characteristics
Dimensions

2.17(d) x 0.6(w) x 0.46(h) in. (5.51 x 1.52 x 1.17
cm)

Full configuration weight

0.04 lb. (0.02 kg)

Electrical characteristics

Power consumption
typical

0.8 W

Power consumption
maximum

1.0 W

Cabling
Cable type:

Either single mode or multimode;

Maximum distance:

• 550m for Multimode

• 10km for Singlemode

Fiber type

Both

Services

Refer to the HP website at www.hp.com/networking/services for details on
the service-level descriptions and product numbers. For details about
services and response times in your area, please contact your local HP
sales office.

HP 0.5 m Multimode OM3
LC/LC Optical Cable

(AJ833A)

Cabling

Cable type:

50/125 µm (core/cladding) diameter, mulitimode fiber optic, with effective
modal bandwidth of 2000 MHz/km as detailed in TIA-492AAAC for
distances of up to 300 m

Maximum distance:
10Gbps Transfer Rate (Ethernet): 300m

Notes

Cable Specs: Tight buffered duplex fiber optic multimode OM3 50/125 um
fiber optic cable and Ethernet assembly with LC duplex connectors on one
end and LC duplex connectors on other end.

 Dimensions: Core diameter: 50 ± 3.0um Cladding diameter: 125 ±

2.0um Coating diameter: 245 ± 10um

 Optical glass: Bandwidth: For LED sources: 1500/500 MHz-km

@850/1300nm.

 Optical glass: Bandwidth: For Laser sources: 2000/500 MHz-km

@850/1300nm. VCSEL Laser sources: 600 / 600 meters
@850/1300nm for Gigabit Ethernet compliant links.

 CABLE: The cable is duplex zipcord graded index 50/125um

multimode optical fiber and designed to work in both the 850 and
1300 nm wavelength windows.

 BULK CABLE & CABLE ASSEMBLY CONFIGURATION:
 Jacket Material: Riser Grade - Low Smoke Zero Halogen

thermoplastic.

 Jacket Color: Aqua for OM3 multimode per TIA 598
 Boot Color: White
 Insertion Loss: less than 0.5 dB @ 850 with LED source, 0.003

dB/M added for lengths > 30 meters.

 Maximum Cable attenuation: 3.0 dB/km @ 850 nm, 1.0 dB/Km @

1310 nm @ 23°C as tested in accordance with EIA 455-46.

 Weight: Air Packed Weight: 1 LB Net Weight: 0.454Kg

QuickSpecs

HP 3600 EI Switch Series

Accessory Product Details

c04111664 — DA – 13790 Worldwide — Version 12 — December 1, 2014

Page 26

Services

Refer to the HP website at www.hp.com/networking/services for details on
the service-level descriptions and product numbers. For details about
services and response times in your area, please contact your local HP
sales office.

HP 1 m Multimode OM3
LC/LC Optical Cable

(AJ834A)

Cabling

Cable type:

50/125 µm (core/cladding) diameter, mulitimode fiber optic, with effective
modal bandwidth of 2000 MHz/km as detailed in TIA-492AAAC for
distances of up to 300 m

Maximum distance:
10Gbps Transfer Rate (Ethernet): 300m

Notes

Cable Specs: Tight buffered duplex fiber optic multimode OM3 50/125 um
fiber optic cable and Ethernet assembly with LC duplex connectors on one
end and LC duplex connectors on other end.

 Dimensions: Core diameter: 50 ± 3.0um Cladding diameter: 125 ±

2.0um Coating diameter: 245 ± 10um

 Optical Glass Bandwidth: For LED sources: 1500/500 MHz-km

@850/1300nm.

 Optical Glass: For Laser sources: 2000/500 MHz-km

@850/1300nm. VCSEL Laser sources: Shall achieve 600 / 600
meters @850/1300nm for Gigabit Ethernet compliant links.

 CABLE: The cable is duplex zipcord graded index 50/125um

multimode optical fiber. The cable is designed to work in both the
850 and 1300 nm wavelength windows.

 BULK CABLE & CABLE ASSEMBLY CONFIGURATION:
 Jacket Material: Riser Grade - Low Smoke Zero Halogen

thermoplastic.

 Jacket Color: Aqua for OM3 multimode per TIA 598
 Boot Color: White
 Insertion Loss: less than 0.5 dB @ 850 with LED source, 0.003

dB/M added for lengths > 30 meters.

 Maximum Cable attenuation: 3.0 dB/km @ 850 nm, 1.0 dB/Km @

1310 nm @ 23°C as tested in accordance with EIA 455-46.

 Weight: Air Packed Weight: 1 LB Net Weight: 0.454Kg

Services

Refer to the HP website at www.hp.com/networking/services for details on
the service-level descriptions and product numbers. For details about
services and response times in your area, please contact your local HP
sales office.

HP 2 m Multimode OM3
LC/LC Optical Cable

(AJ835A)

Cabling

Cable type:

50/125 µm (core/cladding) diameter, mulitimode fiber optic, with effective
modal bandwidth of 2000 MHz/km as detailed in TIA-492AAAC for
distances of up to 300 m;

Maximum distance:
10Gbps Transfer Rate (Ethernet): 300m

Notes

Cable Specs: Tight buffered duplex fiber optic multimode OM3 50/125 um
fiber optic cable and Ethernet assembly with LC duplex connectors on one
end and LC duplex connectors on other end.

QuickSpecs

HP 3600 EI Switch Series

Accessory Product Details

c04111664 — DA – 13790 Worldwide — Version 12 — December 1, 2014

Page 27

 Dimensions: Core diameter: 50 ± 3.0um Cladding diameter: 125 ±

2.0um Coating diameter: 245 ± 10um

 Optical Glass Bandwidth: For LED sources: 1500/500 MHz-km

@850/1300nm.

 Optical Glass: For Laser sources: 2000/500 MHz-km

@850/1300nm. VCSEL Laser sources: Shall achieve 600 / 600
meters @850/1300nm for Gigabit Ethernet compliant links.

 CABLE: The cable is duplex zipcord graded index 50/125um

multimode optical fiber. The cable is designed to work in both the
850 and 1300 nm wavelength windows.

 BULK CABLE & CABLE ASSEMBLY CONFIGURATION:
 Jacket Material: Riser Grade - Low Smoke Zero Halogen

thermoplastic.

 Jacket Color: Aqua for OM3 multimode per TIA 598
 Boot Color: White
 Insertion Loss: less than 0.5 dB @ 850 with LED source, 0.003

dB/M added for lengths > 30 meters.

 Maximum Cable attenuation: 3.0 dB/km @ 850 nm, 1.0 dB/Km @

1310 nm @ 23°C as tested in accordance with EIA 455-46.

 Weight: Air Packed Weight: 1 LB Net Weight: 0.454Kg

Services

Refer to the HP website at www.hp.com/networking/services for details on
the service-level descriptions and product numbers. For details about
services and response times in your area, please contact your local HP
sales office.

HP 5 m Multimode OM3
LC/LC Optical Cable

(AJ836A)

Cabling

Cable type:

50/125 µm core/cladding) diameter, mulitimode fiber optic, with effective
modal bandwidth of 2000 MHz/km as detailed in TIA-492AAAC for
distances of up to 300 m;

Maximum distance:
10Gbps Transfer Rate (Ethernet): 300m

Notes

Cable Specs: This specification defines the detail requirements for a tight
buffered duplex fiber optic multimode OM3 50/125 um fiber optic cable
and Ethernet assembly with LC duplex connectors on one end and LC
duplex connectors on other end.

 Dimensions: Core diameter: 50 ± 3.0um Cladding diameter: 125 ±

2.0um Coating diameter: 245 ± 10um

 Optical Glass Bandwidth: For LED sources: 1500/500 MHz-km

@850/1300nm.

 Optical Glass: For Laser sources: 2000/500 MHz-km

@850/1300nm. VCSEL Laser sources: Shall achieve 600 / 600
meters @850/1300nm for Gigabit Ethernet compliant links.

 CABLE: The cable is duplex zipcord graded index 50/125um

multimode optical fiber. The cable is designed to work in both the
850 and 1300 nm wavelength windows.

 BULK CABLE & CABLE ASSEMBLY CONFIGURATION:
 Jacket Material: Riser Grade - Low Smoke Zero Halogen

thermoplastic.

 Jacket Color: Aqua for OM3 multimode per TIA 598
 Boot Color: White

QuickSpecs

HP 3600 EI Switch Series

Accessory Product Details

c04111664 — DA – 13790 Worldwide — Version 12 — December 1, 2014

Page 28

 Insertion Loss: less than 0.5 dB @ 850 with LED source, 0.003

dB/M added for lengths > 30 meters.

 Maximum Cable attenuation: 3.0 dB/km @ 850 nm, 1.0 dB/Km @

1310 nm @ 23°C as tested in accordance with EIA 455-46.

 Weight: Air Packed Weight: 1 LB Net Weight: 0.454Kg

Services

Refer to the HP website at www.hp.com/networking/services for details on
the service-level descriptions and product numbers. For details about
services and response times in your area, please contact your local HP
sales office.

HP 15 m Multimode OM3
LC/LC Optical Cable

(AJ837A)

Cabling

Cable type:

50/125 µm (core/cladding) diameter, mulitimode fiber optic, with effective
modal bandwidth of 2000 MHz/km as detailed in TIA-492AAAC for
distances of up to 300 m;

Maximum distance:
10Gbps Transfer Rate (Ethernet): 300m

Notes

Cable Specs: Tight buffered duplex fiber optic multimode OM3 50/125 um
fiber optic cable and Ethernet assembly with LC duplex connectors on one
end and LC duplex connectors on other end.

 Dimensions: Core diameter: 50 ± 3.0um Cladding diameter: 125 ±

2.0um Coating diameter: 245 ± 10um

 Optical Glass Bandwidth: For LED sources: 1500/500 MHz-km

@850/1300nm.

 Optical Glass: For Laser sources: 2000/500 MHz-km

@850/1300nm. VCSEL Laser sources: Shall achieve 600 / 600
meters @850/1300nm for Gigabit Ethernet compliant links.

 CABLE: The cable is duplex zipcord graded index 50/125um

multimode optical fiber. The cable is designed to work in both the
850 and 1300 nm wavelength windows.

 BULK CABLE & CABLE ASSEMBLY CONFIGURATION:
 Jacket Material: Riser Grade - Low Smoke Zero Halogen

thermoplastic.

 Jacket Color: Aqua for OM3 multimode per TIA 598
 Boot Color: White
 Insertion Loss: less than 0.5 dB @ 850 with LED source, 0.003

dB/M added for lengths > 30 meters.

 Maximum Cable attenuation: 3.0 dB/km @ 850 nm, 1.0 dB/Km @

1310 nm @ 23°C as tested in accordance with EIA 455-46.

 Weight: Air Packed Weight: 1 LB Net Weight: 0.454Kg

Services

Refer to the HP website at www.hp.com/networking/services for details on
the service-level descriptions and product numbers. For details about
services and response times in your area, please contact your local HP
sales office.

HP 30 m Multimode OM3
LC/LC Optical Cable

(AJ838A)

Cabling

Cable type:

50/125 µm (core/cladding) diameter, mulitimode fiber optic, with effective
modal bandwidth of 2000 MHz/km as detailed in TIA-492AAAC for
distances of up to 300 m;

QuickSpecs

HP 3600 EI Switch Series

Accessory Product Details

c04111664 — DA – 13790 Worldwide — Version 12 — December 1, 2014

Page 29

Maximum distance:
10Gbps Transfer Rate (Ethernet): 300m

Notes

Cable Specs: Tight buffered duplex fiber optic multimode OM3 50/125 um
fiber optic cable and Ethernet assembly with LC duplex connectors on one
end and LC duplex connectors on other end.

 Dimensions: Core diameter: 50 ± 3.0um Cladding diameter: 125 ±

2.0um Coating diameter: 245 ± 10um

 Optical Glass Bandwidth: For LED sources: 1500/500 MHz-km

@850/1300nm.

 Optical Glass: For Laser sources: 2000/500 MHz-km

@850/1300nm. VCSEL Laser sources: Shall achieve 600 / 600
meters @850/1300nm for Gigabit Ethernet compliant links.

 CABLE: The cable is duplex zipcord graded index 50/125um

multimode optical fiber. The cable is designed to work in both the
850 and 1300 nm wavelength windows.

 BULK CABLE & CABLE ASSEMBLY CONFIGURATION:
 Jacket Material: Riser Grade - Low Smoke Zero Halogen

thermoplastic.

 Jacket Color: Aqua for OM3 multimode per TIA 598
 Boot Color: White
 Insertion Loss: less than 0.5 dB @ 850 with LED source, 0.003

dB/M added for lengths > 30 meters.

 Maximum Cable attenuation: 3.0 dB/km @ 850 nm, 1.0 dB/Km @

1310 nm @ 23°C as tested in accordance with EIA 455-46.

 Weight: Air Packed Weight: 1 LB Net Weight: 0.454Kg

Services

Refer to the HP website at www.hp.com/networking/services for details on
the service-level descriptions and product numbers. For details about
services and response times in your area, please contact your local HP
sales office.

HP 50 m Multimode OM3
LC/LC Optical Cable

(AJ839A)

Cabling

Cable type:

50/125 µm (core/cladding) diameter, mulitimode fiber optic, with effective
modal bandwidth of 2000 MHz/km as detailed in TIA-492AAAC for
distances of up to 300 m;

Maximum distance:
10Gbps Transfer Rate (Ethernet): 300m

Notes

Cable Specs: Tight buffered duplex fiber optic multimode OM3 50/125 um
fiber optic cable and Ethernet assembly with LC duplex connectors on one
end and LC duplex connectors on other end.

 Dimensions: Core diameter: 50 ± 3.0um Cladding diameter: 125 ±

2.0um Coating diameter: 245 ± 10um

 Optical Glass Bandwidth: For LED sources: 1500/500 MHz-km

@850/1300nm.

 Optical Glass: For Laser sources: 2000/500 MHz-km

@850/1300nm. VCSEL Laser sources: Shall achieve 600 / 600
meters @850/1300nm for Gigabit Ethernet compliant links.

 CABLE: The cable is duplex zipcord graded index 50/125um

multimode optical fiber. The cable is designed to work in both the
850 and 1300 nm wavelength windows.

QuickSpecs

HP 3600 EI Switch Series

Accessory Product Details

c04111664 — DA – 13790 Worldwide — Version 12 — December 1, 2014

Page 30

 BULK CABLE & CABLE ASSEMBLY CONFIGURATION:
 Jacket Material: Riser Grade - Low Smoke Zero Halogen

thermoplastic.

 Jacket Color: Aqua for OM3 multimode per TIA 598
 Boot Color: White
 Insertion Loss: less than 0.5 dB @ 850 with LED source, 0.003

dB/M added for lengths > 30 meters.

 Maximum Cable attenuation: 3.0 dB/km @ 850 nm, 1.0 dB/Km @

1310 nm @ 23°C as tested in accordance with EIA 455-46.

 Weight: Air Packed Weight: 1 LB Net Weight: 0.454Kg

Services

Refer to the HP website at www.hp.com/networking/services for details on
the service-level descriptions and product numbers. For details about
services and response times in your area, please contact your local HP
sales office.

HP Premier Flex LC/LC
Multi-mode OM4 2 fiber
1m Cable (QK732A)

Notes

Cable Specs: Graded-index, "bendable" fiber optic multimode OM3+
50/125um duplex cable and Ethernet assembly with LC duplex connectors
on each end.

• Core Diameter: 50um ±3um, Cladding diameter: 125um ±2um; Coating

diameter: 245 ± 10um

• Bandwidth: 3000 MHz-km @ 850nm (Laser)

• Jacket Color: Blue

• Jacket Material: Riser Grade – Low Smoke Zero Halogen (LSZH)

thermoplastic

• Boot Color: White

• Outer Jacket Print: HP PremierFlex OM3+ Fiber Optic Cable, 50/125um,

Type OFNR (UL), LSZH, cUL, OFN FT4, ROHS. Cable also has a longitudinal
white stripe that runs the entire length of the cable.

• Insertion Loss: Less than 0.5dB @ 850nm with LED source, 0.003dB/m

added for lengths >30m

• Maximum Cable Attenuation: 3.0 dB/km @ 850nm, 1.0 dB/km @ 1310nm
@ 23°C as tested in accordance with EIA 455-45

Services

Refer to the HP website at www.hp.com/networking/services for details on
the service-level descriptions and product numbers. For details about
services and response times in your area, please contact your local HP
sales office.

HP Premier Flex LC/LC
Multi-mode OM4 2 fiber
2m Cable (QK733A)

Notes

Cable Specs: Graded-index, "bendable" fiber optic multimode OM3+
50/125um duplex cable and Ethernet assembly with LC duplex connectors
on each end.

• Core diameter: 50um ±3um, Cladding diameter: 125um ±2um; Coating

diameter: 245 ± 10um

• Bandwidth: 3000 MHz-km @ 850nm (Laser)

• Jacket Color: Blue

• Jacket Material: Riser Grade – Low Smoke Zero Halogen (LSZH)

thermoplastic

• Boot Color: White

• Outer Jacket Print: HP PremierFlex OM3+ Fiber Optic Cable, 50/125um,

Type OFNR (UL), LSZH, cUL, OFN FT4, ROHS. Cable also has a longitudinal
white stripe that runs the entire length of the cable.

• Insertion Loss: Less than 0.5dB @ 850nm with LED source, 0.003dB/m

QuickSpecs

HP 3600 EI Switch Series

Accessory Product Details

c04111664 — DA – 13790 Worldwide — Version 12 — December 1, 2014

Page 31

added for lengths >30m

• Maximum Cable Attenuation: 3.0 dB/km @ 850nm, 1.0 dB/km @ 1310nm

@ 23°C as tested in accordance with EIA 455-45

Services

Refer to the HP website at www.hp.com/networking/services for details on
the service-level descriptions and product numbers. For details about
services and response times in your area, please contact your local HP
sales office.

HP Premier Flex LC/LC
Multi-mode OM4 2 fiber
5m Cable (QK734A)

Notes

Cable Specs: Graded-index, "bendable" fiber optic multimode OM3+
50/125um duplex cable and Ethernet assembly with LC duplex connectors
on each end.

• Core diameter: 50um ±3um, Cladding diameter: 125um ±2um; Coating
diameter: 245 ± 10um

• Bandwidth: 3000 MHz-km @ 850nm (Laser)

• Jacket Color: Blue

• Jacket Material: Riser Grade – Low Smoke Zero Halogen (LSZH)

thermoplastic

• Boot Color: White

• Outer Jacket Print: HP PremierFlex OM3+ Fiber Optic Cable, 50/125um,

Type OFNR (UL), LSZH, cUL, OFN FT4, ROHS. Cable also has a longitudinal
white stripe that runs the entire length of the cable.

• Insertion Loss: Less than 0.5dB @ 850nm with LED source, 0.003dB/m

added for lengths >30m

• Maximum Cable Attenuation: 3.0 dB/km @ 850nm, 1.0 dB/km @ 1310nm
@ 23°C as tested in accordance with EIA 455-45

Services

Refer to the HP website at www.hp.com/networking/services for details on
the service-level descriptions and product numbers. For details about
services and response times in your area, please contact your local HP
sales office.

HP Premier Flex LC/LC
Multi-mode OM4 2 fiber
15m Cable (QK735A)

Notes

Cable Specs: Graded-index, "bendable" fiber optic multimode OM3+
50/125um duplex cable and Ethernet assembly with LC duplex connectors
on each end.

• Core diameter: 50um ±3um, Cladding diameter: 125um ±2um; Coating

diameter: 245 ± 10um

• Bandwidth: 3000 MHz-km @ 850nm (Laser)

• Jacket Color: Blue

• Jacket Material: Riser Grade – Low Smoke Zero Halogen (LSZH)

thermoplastic

• Boot Color: White

• Outer Jacket Print: HP PremierFlex OM3+ Fiber Optic Cable, 50/125um,

Type OFNR (UL), LSZH, cUL, OFN FT4, ROHS. Cable also has a longitudinal
white stripe that runs the entire length of the cable.

• Insertion Loss: Less than 0.5dB @ 850nm with LED source, 0.003dB/m

added for lengths >30m

• Maximum Cable Attenuation: 3.0 dB/km @ 850nm, 1.0 dB/km @ 1310nm

@ 23°C as tested in accordance with EIA 455-45

Services

Refer to the HP website at www.hp.com/networking/services for details on
the service-level descriptions and product numbers. For details about
services and response times in your area, please contact your local HP
sales office.

QuickSpecs

HP 3600 EI Switch Series

Accessory Product Details

c04111664 — DA – 13790 Worldwide — Version 12 — December 1, 2014

Page 32

HP Premier Flex LC/LC
Multi-mode OM4 2 fiber
30m Cable (QK736A)

Notes

Cable Specs: Graded-index, "bendable" fiber optic multimode OM3+
50/125um duplex cable and Ethernet assembly with LC duplex connectors
on each end.

• Core diameter: 50um ±3um, Cladding diameter: 125um ±2um; Coating
diameter: 245 ± 10um

• Bandwidth: 3000 MHz-km @ 850nm (Laser)

• Jacket Color: Blue

• Jacket Material: Riser Grade – Low Smoke Zero Halogen (LSZH)

thermoplastic

• Boot Color: White

• Outer Jacket Print: HP PremierFlex OM3+ Fiber Optic Cable, 50/125um,

Type OFNR (UL), LSZH, cUL, OFN FT4, ROHS. Cable also has a longitudinal
white stripe that runs the entire length of the cable.

• Insertion Loss: Less than 0.5dB @ 850nm with LED source, 0.003dB/m

added for lengths >30m

• Maximum Cable Attenuation: 3.0 dB/km @ 850nm, 1.0 dB/km @ 1310nm

@ 23°C as tested in accordance with EIA 455-45

Services

Refer to the HP website at www.hp.com/networking/services for details on
the service-level descriptions and product numbers. For details about
services and response times in your area, please contact your local HP
sales office.

HP Premier Flex LC/LC
Multi-mode OM4 2 fiber
50m Cable (QK737A)

Notes

Cable Specs: Graded-index, "bendable" fiber optic multimode OM3+
50/125um duplex cable and Ethernet assembly with LC duplex connectors
on each end.

• Core diameter: 50um ±3um, Cladding diameter: 125um ±2um; Coating

diameter: 245 ± 10um

• Bandwidth: 3000 MHz-km @ 850nm (Laser)

• Jacket Color: Blue

• Jacket Material: Riser Grade – Low Smoke Zero Halogen (LSZH)

thermoplastic

• Boot Color: White

• Outer Jacket Print: HP PremierFlex OM3+ Fiber Optic Cable, 50/125um,

Type OFNR (UL), LSZH, cUL, OFN FT4, ROHS. Cable also has a longitudinal
white stripe that runs the entire length of the cable.

• Insertion Loss: Less than 0.5dB @ 850nm with LED source, 0.003dB/m

added for lengths >30m

• Maximum Cable Attenuation: 3.0 dB/km @ 850nm, 1.0 dB/km @ 1310nm

@ 23°C as tested in accordance with EIA 455-45

Services

Refer to the HP website at www.hp.com/networking/services for details on
the service-level descriptions and product numbers. For details about
services and response times in your area, please contact your local HP
sales office.

HP RPS1600 Redundant
Power System (JG136A)

Ports

8 redundant power supply ports
Restrictions: two -56V/25A DC(PoE); six -56V/8A DC(non-PoE)

Physical characteristics

Dimensions

15.63(d) x 17.32(w) x 1.74(h) in. (39.7 x 44 x

4.42 cm)

Weight

14.11 lb. (6.4 kg)

Full configuration weight

16.75 lb. (7.6 kg)

Environment

Operating temperature

14°F to 122°F (-10°C to 50°C)

QuickSpecs

HP 3600 EI Switch Series

Accessory Product Details

c04111664 — DA – 13790 Worldwide — Version 12 — December 1, 2014

Page 33

Operating relative
humidity

5% to 95%

Nonoperating/Storage
temperature

-40°F to 158°F (-40°C to 70°C)

Nonoperating/Storage
relative humidity

5% to 95%

Altitude

up to 13,123 ft. (4 km)

Acoustic

Pressure: 53 dB; ISO 7779, ISO 9296

Electrical characteristics

Voltage

100-120/200-240 VAC

Current

30/60 A

Idle power

38 W

Maximum power rating

3550 W

RPS power

3200 W

PoE power

2800 W

RPS

-55 V

PoE

-55 V

Frequency

50/60 Hz

Notes

Idle power is the actual power consumption of
the device with no ports connected.
Maximum power rating and maximum heat
dissipation are the worst-case theoretical
maximum numbers provided for planning the
infrastructure with fully loaded PoE (if
equipped), 100% traffic, all ports plugged in,
and all modules populated.
With one RPS1600 Power Supply, the PRS1600
Redundant Power System can provide 1600W
power output; With two PRS1600 Power
Supplies, the output power is 3200W.

Safety

CE Labeled; UL 60950-1; IEC 60950-1; ICES-003; FCC Part 15, Subpart B; EU
RoHS Compliant; EN 60950-1/A11; C-Tick; VCCI Class A; ROHS Compliance;
EN 300386

Services

Refer to the HP website at: www.hp.com/networking/services for details on
the service-level descriptions and product numbers. For details about
services and response times in your area, please contact your local HP
sales office.

HP RPS1600 1600W AC
Power Supply (JG137A)

Physical characteristics
Dimensions

8.19(d) x 4.96(w) x 1.63(h) in. (20.8 x 12.6 x

4.15 cm)

Weight

3.02 lb. (1.37 kg)

Environment

Operating temperature

14°F to 122°F (-10°C to 50°C)

Operating relative
humidity

5% to 95%

Nonoperating/Storage
temperature

-40°F to 158°F (-40°C to 70°C)

Nonoperating/Storage
relative humidity

5% to 95%

Electrical characteristics
Voltage

100-120/200-240 VAC

Current

15/30 A

QuickSpecs

HP 3600 EI Switch Series

Accessory Product Details

c04111664 — DA – 13790 Worldwide — Version 12 — December 1, 2014

Page 34

Maximum power rating

1600 W

Frequency

50/60 Hz

Notes

Maximum power rating and maximum heat
dissipation are the worst-case theoretical
maximum numbers provided for planning the
infrastructure with fully loaded PoE (if
equipped), 100% traffic, all ports plugged in,
and all modules populated.

Services

Refer to the HP website at: www.hp.com/networking/services for details on
the service-level descriptions and product numbers. For details about
services and response times in your area, please contact your local HP
sales office.

QuickSpecs

HP 3600 EI Switch Series

Summary of Changes

c04111664 — DA – 13790 Worldwide — Version 12 — December 1, 2014

Page 35

Date

Version History

Action

Description of Change:

01-Dec-2014

From Version 11 to
12

Changed

Warranty and support updated

21-Apr-2014

From Version 10 to
11

Changed

Standards and Protocols were revised.

08-Apr-2014

From Version 9 to 10

Removed

Removed several items from the Transceivers section of
Accessories.

18-Dec-2013

From Version 7 to 9

Changed

Notes were revised throughout Configuration.

19-Jul-2013

From Version 6 to 7

Added

Configuration was added.

10-Jun-2013

From Version 5 to 6

Added

OM4 cables were added.

24-Aug-2012

From Version 4 to 5

Changed

The QuickSpecs were completely revised, including
adding several new models.

07-Nov-2011

From Version 3 to 4

Changed

The product name was updated throughout the
document.

29-Sep-2011

From Version 2 to 3

Added

Accessory Product Details was added.

08-Mar-2011

From Version 1 to 2

Changed

Revisions were made throughout.

To learn more, visit: www.hp.com/networking

© Copyright 2010-2014 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change
without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying
such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for
technical or editorial errors or omissions contained herein.

Microsoft is a U.S. registered trademark of Microsoft Corporation.
