HP 5120-48G EI, 5120-24G Quickspecs
HP 5120-48G EI Switch with 2 Interface Slots
HP 5120-48G EI Switch
HP 5120-24G EI Switch with 2 Interface Slots
QuickSpecs
HP 5120 EI Switch Series
Overview
DA - 13850 North America — Version 19 — August 19, 2013
Page 1
HP 5120-24G EI Switch
HP 5120-48G-PoE+ EI Switch with 2 Interface Slots
HP 5120-24G-PoE+ EI Switch with 2 Interface Slots
Models
HP 5120-48G EI Switch with 2 Interface Slots
JE069A
HP 5120-48G EI Switch
JE067A
HP 5120-24G EI Switch with 2 Interface Slots
JE068A
HP 5120-24G EI Switch
JE066A
QuickSpecs
HP 5120 EI Switch Series
Overview
DA - 13850 North America — Version 19 — August 19, 2013
Page 2
HP 5120-48G-PoE+ EI Switch with 2 Interface Slots
JG237A
HP 5120-24G-PoE+ EI Switch with 2 Interface Slots
JG236A
Key features
High scalability for investment protection
Support for multiple services
Comprehensive security control policies
Diversified Quality of Service (QoS) policies
Excellent manageability
Product overview
The HP 5120 EI Switch Series is comprised of Gigabit Ethernet switches that support static Layer 3 routing, diversified services, and
IPv6 forwarding, as well as provide up to four 10-Gigabit Ethernet (10 GbE) extended interfaces. Unique Intelligent Resilient Framework
(IRF) technology creates a virtual fabric by managing several switches as one logical device, which increases network resilience,
performance, and availability while reducing operational complexity. These switches provide Gigabit Ethernet access and can be used
at the edge of a network or to connect server clusters in data centers. High scalability provides investment protection with two
expansion slots, each of which can support two-port 10 GbE expansion modules. High availability, simplified management, and
comprehensive security control policies are among the key features that distinguish this series.
Features and benefits
Quality of Service
(QoS)
Broadcast control
: allows limitation of broadcast traffic rate to cut down on unwanted network broadcast traffic
Advanced classifier-based QoS
: classifies traffic using multiple match criteria based on Layer 2, 3, and 4 information; applies
QoS policies such as setting priority level and rate limit to selected traffic on a port, VLAN, or whole switch
Powerful QoS feature
: supports the following congestion actions: strict priority (SP) queuing, weighted round robin (WRR), and
SP+WRR
Traffic policing
: supports Committed Access Rate (CAR) and line rate
Management
Friendly port names
: allow assignment of descriptive names to ports
Remote configuration and management
: is available through a secure Web browser or a CLI
Manager and operator privilege levels
: enable read-only (operator) and read/write (manager) access on CLI and Web browser
management interfaces
Command authorization
: leverages HWTACACS to link a custom list of CLI commands to an individual network administrator's
login; also provides an audit trail
Secure Web GUI
: provides a secure, easy-to-use graphical interface for configuring the module via HTTPS
Multiple configuration files
: can be stored to the flash image
Complete session logging
: provides detailed information for problem identification and resolution
SNMPv1, v2c, and v3
: facilitate centralized discovery, monitoring, and secure management of networking devices
Remote monitoring
(RMON): uses standard SNMP to monitor essential network functions; supports events, alarm, history, and
statistics group plus a private alarm extension group
IEEE 802.1AB Link Layer Discovery Protocol
(LLDP): advertises and receives management information from adjacent devices
on a network, facilitating easy mapping by network management applications
sFlow
(RFC 3176): provides scalable ASIC-based wire-speed network monitoring and accounting with no impact on network
QuickSpecs
HP 5120 EI Switch Series
Overview
DA - 13850 North America — Version 19 — August 19, 2013
Page 3
performance; this allows network operators to gather a variety of sophisticated network statistics and information for capacity
planning and real-time network monitoring purposes
Management VLAN
: segments traffic to and from management interfaces, including CLI/telnet, a Web browser interface, and
SNMP
Remote Intelligent Mirroring
: mirrors ingress/egress ACL-selected traffic from a switch port or VLAN to a local or remote
switch port anywhere on the network
Device Link Detection Protocol
(DLDP): monitors a cable between two switches and shuts down the ports on both ends if the
cable is broken, this prevents network problems such as loops
IPv6 management
: provides future-proof networking because the switch is capable of being managed whether the attached
network is running IPv4 or IPv6; supports pingv6, tracertv6, Telnetv6, TFTPv6, DNSv6, syslogv6, FTPv6, SNMPv6, DHCPv6, and
RADIUS for IPv6
Troubleshooting
: ingress and egress port monitoring enable network problem solving; virtual cable tests provide visibility into
cable problems
Connectivity
Auto-MDIX
: automatically adjusts for straight-through or crossover cables on all 10/100/1000 ports
Flow control
: provides back pressure using standard IEEE 802.3x, reducing congestion in heavy traffic situations
Jumbo packet support
: supports up to 9216-byte frame size to improve the performance of large data transfers
High-density connectivity
: provides up to 48 fixed 10/100/1000BASE-T ports in a Layer 2/Layer 3 switch
Optional 10 GbE ports
: through the use of optional modules, additional 10 GbE connections are available for uplinks or high-
bandwidth server connections; flexibly supports XFP, SFP+, or CX4 local connections
IEEE 802.3at Power over Ethernet (PoE+) support:
simplifies deployment and dramatically reduces installation costs by
helping to eliminate the time and cost involved in supplying local power at each access point location
Ethernet OAM
(IEEE 802.3ah):
operations, administration and maintenance (OAM) management capability detects data link layer problems that occurred in the
“last mile"; monitors the status of the link between the two devices
High-bandwidth CX4 local stacking
: when stacked using CX4 local stacking, achieves 12 Gbps per connection, allowing for up to
96 Gbps total stacking bandwidth (full duplex) in a resilient stacking configuration
Performance
Nonblocking architecture
: up to 192 Gbps nonblocking switching fabric provides wire-speed switching with up to 143 million
pps throughput
Hardware-based wire-speed access control lists
(ACLs): feature-rich ACL implementation (TCAM-based) helps provide high
levels of security and ease of administration without impacting network performance
Resiliency and high availability
Separate data and control paths
: keeps control separated from services and keeps service processing isolated; increases
security and performance
External redundant power supply
: provides high reliability
Smart link
: allows 50 ms failover between links
Spanning Tree/MSTP, RSTP
: provides redundant links while preventing network loops
Rapid Ring Protection Protocol
(RRPP): connects multiple switches in a high-performance ring using standard Ethernet
technology; traffic can be rerouted around the ring in less than 50 ms, reducing the impact on traffic and applications
Intelligent Resilient Framework
(IRF): creates virtual resilient switching fabrics, where two or more switches perform as a
single L2 switch and L3 router; switches do not have to be co-located and can be part of a disaster recovery system; servers or
switches can be attached using standard LACP for automatic load balancing and high availability; can eliminate the need for
complex protocols like Spanning Tree Protocol, Equal-Cost Multipath (ECMP), or VRRP, thereby simplifying network operation
QuickSpecs
HP 5120 EI Switch Series
Overview
DA - 13850 North America — Version 19 — August 19, 2013
Page 4
Layer 2 switching
16K MAC address table
: provides access to many Layer 2 devices
VLAN support and tagging
: support IEEE 802.1Q with 4,094 simultaneous VLAN IDs
GARP VLAN Registration Protocol
: allows automatic learning and dynamic assignment of VLANs
IEEE 802.1ad QinQ and Selective QinQ
: increase the scalability of an Ethernet network by providing a hierarchical structure;
connect multiple LANs on a high-speed campus or metro network
10GbE port aggregation:
allows grouping of ports to increase overall data throughput to a remote device
Internet Group Management Protocol
(IGMP)
and Multicast Listener Discovery
(MLD)
protocol snooping
: effectively control
and manage the flooding of multicast packets in a Layer 2 network
Per-VLAN Spanning Tree Plus
(PVST+)
allows each VLAN to build a separate spanning tree to improve link bandwidth usage in network environments with multiple
VLANs
Layer 3 services
Address Resolution Protocol
(ARP): determines the MAC address of another IP host in the same subnet; supports static ARPs;
gratuitous ARP allows detection of duplicate IP addresses; proxy ARP allows normal ARP operation between subnets or when
subnets are separated by a Layer 2 network
Dynamic Host Configuration Protocol
(DHCP): simplifies the management of large IP networks; supports client; DHCP Relay
enables DHCP operation across subnets
Loopback interface address
: defines an address that can always be reachable, improving diagnostic capability
User Datagram Protocol (UDP) helper function
: allows UDP broadcasts to be directed across router interfaces to specific IP
unicast or subnet broadcast addresses and prevents server spoofing for UDP services such as DHCP
Route maps
: provide more control during route redistribution; allow filtering and altering of route
metric
Layer 3 routing
Static IP routing
: provides manually configured routing for both IPv4 and IPv6 networks
Security
Access control lists
(ACLs): provides IP Layer 2 to Layer 4 traffic filtering; supports global ACL, VLAN ACL, port ACL, and IPv6 ACL
IEEE 802.1X
: industry-standard method of user authentication using an IEEE 802.1X supplicant on the client in conjunction with
a RADIUS server
MAC-based authentication
: client is authenticated with the RADIUS server based on the client's MAC address
Identity-driven security and access control
:
Per-user ACLs: permits or denies user access to specific network resources based on user identity and time of day,
allowing multiple types of users on the same network to access specific network services without risking network
security or providing unauthorized access to sensitive data
Automatic VLAN assignment: automatically assigns users to the appropriate VLAN based on their identities
Secure management access
: securely encrypts all access methods (CLI, GUI, or MIB) through SSHv2, SSL, and/or SNMPv3
Secure FTP
: allows secure file transfer to and from the switch; protects against unwanted file downloads or unauthorized
copying of a switch configuration file
Guest VLAN
: similar to IEEE 802.1X, it provides a browser-based environment to authenticated clients
Endpoint Admission Defense
(EAD): provides security policies to users accessing a network
Port security
: allows access only to specified MAC addresses, which can be learned or specified by the administrator
Port isolation
: secures and adds privacy, and prevents malicious attackers from obtaining user information
QuickSpecs
HP 5120 EI Switch Series
Overview
DA - 13850 North America — Version 19 — August 19, 2013
Page 5
STP BPDU port protection
: blocks Bridge Protocol Data Units (BPDUs) on ports that do not require BPDUs, preventing forged
BPDU attacks
STP Root Guard
: protects the root bridge from malicious attacks or configuration mistakes
DHCP protection
: blocks DHCP packets from unauthorized DHCP servers, preventing denial-of-service attacks
IP Source guard
: helps prevent IP spoofing attacks
Dynamic ARP protection
: blocks ARP broadcasts from unauthorized hosts, preventing eavesdropping or theft of network data
RADIUS/HWTACACS
: eases switch management security administration by using a password authentication server
Convergence
IEEE 802.1AB Link Layer Discovery Protocol
(LLDP): is an automated device discovery protocol that provides easy mapping of
network management applications
LLDP-MED
: is a standard extension that automatically configures network devices, including LLDP-capable IP phones
LLDP-CDP compatibility
: receives and recognizes CDP packets from Cisco's IP phones for seamless interoperation
IEEE 802.3af Power over Ethernet
: provides up to 15.4 W per port to PoE-powered devices such as IP phones, wireless access
points, and video cameras
PoE allocations
: support multiple methods (automatic, IEEE 802.3af class, LLDP-MED, or user specified) to allocate PoE power
for more efficient energy savings
Voice VLAN
: automatically assigns VLAN and priority for IP phones, simplifying network configuration and maintenance
IP multicast snooping
(data-driven IGMP): automatically prevents flooding of IP multicast traffic
Device support
Cisco prestandard PoE support
: detects and provides power to Cisco's prestandard PoE devices such as wireless LAN access
points and IP phones
Additional information
Green IT and power
: use the latest advances in silicon development, shut off unused ports, and use variable-speed fans to
improve energy efficiency
Green initiative support
: provides support for RoHS and WEEE regulations
Warranty and support
Lifetime warranty
: for as long as you own the product with advance replacement and next-business-day delivery (available in
most countries)†
Electronic and telephone support
: limited electronic and telephone support is available from HP; to reach our support centers,
refer to
www.hp.com/networking/contact-support
; for details on the duration of support provided with your product purchase,
refer to
www.hp.com/networking/warrantysummary
Software releases
: to find software for your product, refer to
www.hp.com/networking/support
; for details on the software
releases available with your product purchase, refer to
www.hp.com/networking/warrantysummary
†HP warranty includes repair or replacement of hardware for as long as you own the product, with next business day advance
replacement (available in most countries). The disk drive included with HP AllianceOne Advanced Services and Services zl Modules, HP
Threat Management Services zl Module, HP AllianceOne Extended zl Module with Riverbed Steelhead, HP MSM765zl Mobility Controller
and HP Survivable Branch Communication zl Module powered by Microsoft Lync has a five-year hardware warranty. For details, refer to
the Software license and hardware warranty statements at
www.hp.com/networking/warranty
.
QuickSpecs
HP 5120 EI Switch Series
Overview
DA - 13850 North America — Version 19 — August 19, 2013
Page 6
Build To Order:
BTO is a standalone unit with no integration. BTO products ship standalone are not part of a CTO or Rack-Shippable solution.
Standard Switch Chassis
HP 5120-24G EI Switch
JE066A
24 RJ-45 autosensing 10/100/1000 ports
4 dual-personality ports; PoE auto-sensing 10/100/1000Base-T or SFP
0 port expansion module slots
Power supply included
1U - Height
See Configuration
Note:1, 3
C15 PDU NA
JE066A#B2B
C15 to C14 Jumper Cord (NA)
C15 PDU ROW
JE066A#B2C
C15 to C14 Jumper Cord (ROW)
HP 5120-24G EI Switch with 2 Slots
JE068A
24 RJ-45 autosensing 10/100/1000 ports
4 dual-personality ports; PoE auto-sensing 10/100/1000Base-T or SFP
2 port expansion module slots
Power supply included
1U - Height
See Configuration
Note:1, 3
C15 PDU NA
JE068A#B2B
C15 to C14 Jumper Cord (NA)
C15 PDU ROW
JE068A#B2C
C1
5 to C14 Jumper Cord (ROW)
HP 5120-24G-PoE+ EI Switch w/2 Intf Slts
JG236A
24 RJ-45 autosensing 10/100/1000 ports
4 dual-personality ports; PoE auto-sensing 10/100/1000Base-T or SFP
2 port expansion module slots
Power supply included
1U - Height
See Configuration
Note:1, 3
C15 PDU NA
JG236A#B2B
C15 to C14 Jumper Cord (NA)
C15 PDU ROW
JG236A#B2C
C15 to C14 Jumper Cord (ROW)
HP 5120-48G EI Switch
JE067A
QuickSpecs
HP 5120 EI Switch Series
Configuration
DA - 13850 North America — Version 19 — August 19, 2013
Page 7
48 RJ-45 autosensing 10/100/1000 ports
4 dual-personality ports; PoE auto-sensing 10/100/1000Base-T or SFP
0 port expansion module slots
Power supply included
1U - Height
See Configuration
Note:1, 3
C15 PDU NA
JE067A#B2B
C15 to C14 Jumper Cord (NA)
C15 PDU ROW
JE067A#B2C
C15 to C14 Jumper Cord (ROW)
HP 5120-48G EI Switch with 2 Slots
JE069A
48 RJ-45 autosensing 10/100/1000 ports
4 dual-personality ports; PoE auto-sensing 10/100/1000Base-T or SFP
2 port expansion module slots
Power supply included
1U - Height
See Configuration
Note:1, 3
C15 PDU NA
JE069A#B2B
C15 to C14 Jumper Cord (NA)
C15 PDU ROW
JE069A#B2C
C15 to C14 Jumper Cord (ROW)
HP 5120-48G-PoE+ EI Switch w/2 Intf Slts
JG237A
48 RJ-45 autosensing 10/100/1000 ports
4 dual-personality ports; PoE auto-sensing 10/100/1000Base-T or SFP
2 port expansion module slots
Power supply included
1U - Height
See Configuration
Note:1, 3
C15 PDU NA
JG237A#B2B
C15 to C14 Jumper Cord (NA)
C15 PDU ROW
JG237A#B2C
C15 to C14 Jumper Cord (ROW)
Configuration Rules:
Note 1
The following Transceivers install into this Module: (Use #0D1 if switch is CTO)
HP X110 100M SFP LC FX Dual Mode Transceiver
JD497A
HP X120 1G SFP LC SX Transceiver
JD118B
HP X120 1G SFP LC LX Transceiver
JD119B
HP X120 1G SFP RJ45 T Transceiver
JD089B
HP X120 1G SFP LC BX 10-U Transceiver
JD098B
HP X120 1G SFP LC BX 10-D Transceiver
JD099B
QuickSpecs
HP 5120 EI Switch Series
Configuration
DA - 13850 North America — Version 19 — August 19, 2013
Page 8
HP X124 1G SFP LC LH40 1310nm Transceiver
JD061A
HP X120 1G SFP LC LH40 1550nm Transceiver
JD062A
HP X125 1G SFP LC LH70 Transceiver
JD063B
Note 3
Localization required on orders without #B2B, #B2C or #B2E options.
Box Level Integration CTO Models
CTO Switch Chassis
HP 5120-24G EI Switch - CTO
JE066AC
24 RJ-45 autosensing 10/100/1000 ports
4 dual-personality ports; PoE auto-sensing 10/100/1000Base-T or SFP
min=0 \ max=4 SFP Transceivers
0 port expansion module slots
1 - Power Supply Included
1U - Height
See Configuration
Note:1, 3, 5,7
HP 5120-24G EI Switch with 2 Slots - CTO
JE068AC
24 RJ-45 autosensing 10/100/1000 ports
4 dual-personality ports; PoE auto-sensing 10/100/1000Base-T or SFP
min=0 \ max=4 SFP Transceivers
2 - port expansion module slots
1 - Power Supply Included
1U - Height
See Configuration
Note:1, 3, 5,7
HP 5120-24G-PoE+ EI Switch w/2 Intf Slts - CTO
JG236AC
24 RJ-45 autosensing 10/100/1000 ports
4 dual-personality ports; PoE auto-sensing 10/100/1000Base-T or SFP
min=0 \ max=4 SFP Transceivers
2 - port expansion module slots
1 - Power Supply Included
1U - Height
See Configuration
Note:1, 3, 5,7
HP 5120-48G EI Switch - CTO
JE067AC
48 RJ-45 autosensing 10/100/1000 ports
4 dual-personality ports; PoE auto-sensing 10/100/1000Base-T or SFP
min=0 \ max=4 SFP Transceivers
0 - port expansion module slots
1 - Power Supply Included
1U - Height
See Configuration
Note:1, 3, 4, 5,7
HP 5120-48G EI Switch with 2 Slots - CTO
JE069AC
QuickSpecs
HP 5120 EI Switch Series
Configuration
DA - 13850 North America — Version 19 — August 19, 2013
Page 9
48 RJ-45 autosensing 10/100/1000 ports
4 dual-personality ports; PoE auto-sensing 10/100/1000Base-T or SFP
min=0 \ max=4 SFP Transceivers
2 - port expansion module slots
1 - Power Supply Included
1U - Height
See Configuration
Note:1, 3, 5,7
HP 5120-48G-PoE+ EI Switch w/2 Intf Slts - CTO
JG237AC
48 RJ-45 autosensing 10/100/1000 ports
4 dual-personality ports; PoE auto-sensing 10/100/1000Base-T or SFP
min=0 \ max=4 SFP Transceivers
2 - port expansion module slots
1 - Power Supply Included
1U - Height
See Configuration
Note:1, 3, 5,7
Configuration Rules:
Note 1
The following Transceivers install into this Module: (Use #0D1 if switch is CTO)
HP X110 100M SFP LC FX Dual Mode Transceiver
JD497A
HP X120 1G SFP LC SX Transceiver
JD118B
HP X120 1G SFP LC LX Transceiver
JD119B
HP X120 1G SFP RJ45 T Transceiver
JD089B
HP X120 1G SFP LC BX 10-U Transceiver
JD098B
HP X120 1G SFP LC BX 10-D Transceiver
JD099B
HP X124 1G SFP LC LH40 1310nm Transceiver
JD061A
HP X120 1G SFP LC LH40 1550nm Transceiver
JD062A
HP X125 1G SFP LC LH70 Transceiver
JD063B
Note 3
Localization required on orders without #B2B, #B2C or #B2E options.
Note 5
If this Switch is selected, Then a Minimum of 1 factory integrated accessory must be ordered and integrated to CTO
chassis. See Menu below, option must have a #0D1 to be integrated to the CTO Chassis.
Note 7
If the Switch Chassis is to be Box Level Factory Integrated (CTO), Then the #0D1 is required on the Switch Chassis
and integrated to the JG706A - HP 51xx CTO Enablement. (Max 1 switch per SSP)
Remarks:
Option JxxxxC is used to indicate a Switch Chassis that has factory integrated options BUT NOT integrated into HP
Universal Rack by the HP Factory.
Rack Level Integration CTO Models
Switch Chassis
HP 5120-24G EI Switch
JE066A
QuickSpecs
HP 5120 EI Switch Series
Configuration
DA - 13850 North America — Version 19 — August 19, 2013
Page 10
24 RJ-45 autosensing 10/100/1000 ports
4 dual-personality ports; PoE auto-sensing 10/100/1000Base-T or SFP
0 port expansion module slots
Power supply included
1U - Height
See Configuration
Note:1, 3, 10
C15 PDU NA
JE066A#B2B
C15 to C14 Jumper Cord (NA)
C15 PDU ROW
JE066A#B2C
C15 to C14 Jumper Cord (ROW)
HP 5120-24G EI Switch with 2 Slots
JE068A
24 RJ-45 autosensing 10/100/1000 ports
4 dual-personality ports; PoE auto-sensing 10/100/1000Base-T or SFP
2 port expansion module slots
Power supply included
1U - Height
See Configuration
Note:1, 3, 10
C15 PDU NA
JE068A#B2B
C15 to C14 Jumper Cord (NA)
C15 PDU ROW
JE068A#B2C
C15 to C14 Jumper Cord (ROW)
HP 5120-24G-PoE+ EI Switch w/2 Intf Slts
JG236A
24 RJ-45 autosensing 10/100/1000 ports
4 dual-personality ports; PoE auto-sensing 10/100/1000Base-T or SFP
2 port expansion module slots
Power supply included
1U - Height
See Configuration
Note:1, 3, 10
C15 PDU NA
JG236A#B2B
C15 to C14 Jumper Cord (NA)
C15 PDU ROW
JG236A#B2C
C15 to C14 Jumper Cord (ROW)
HP 5120-48G EI Switch
JE067A
48 RJ-45 autosensing 10/100/1000 ports
4 dual-personality ports; PoE auto-sensing 10/100/1000Base-T or SFP
0 port expansion module slots
Power supply included
1U - Height
See Configuration
Note:1, 3, 10
C15 PDU NA
JE067A#B2B
C15 to C14 Jumper Cord (NA)
QuickSpecs
HP 5120 EI Switch Series
Configuration
DA - 13850 North America — Version 19 — August 19, 2013
Page 11
C15 PDU ROW
JE067A#B2C
C15 to C14 Jumper Cord (ROW)
HP 5120-48G EI Switch with 2 Slots
JE069A
48 RJ-45 autosensing 10/100/1000 ports
4 dual-personality ports; PoE auto-sensing 10/100/1000Base-T or SFP
2 port expansion module slots
Power supply included
1U - Height
See Configuration
Note:1, 3, 10
C15 PDU NA
JE069A#B2B
C15 to C14 Jumper Cord (NA)
C15 PDU ROW
JE069A#B2C
C15 to C14 Jumper Cord (ROW)
HP 5120-48G-PoE+ EI Switch w/2 Intf Slts
JG237A
48 RJ-45 autosensing 10/100/1000 ports
4 dual-personality ports; PoE auto-sensing 10/100/1000Base-T or SFP
2 port expansion module slots
Power supply included
1U - Height
See Configuration
Note:1, 3, 10
C15 PDU NA
JG237A#B2B
C15 to C14 Jumper Cord (NA
C15 PDU ROW
JG237A#B2C
C15 to C14 Jumper Cord (ROW)
Configuration Rules:
Note 1
The following Transceivers install into this Module:
HP X110 100M SFP LC FX Dual Mode Transceiver
JD497A
HP X110 100M SFP LC LX Dual Mode Transceiver
JD498A
HP X120 1G SFP LC SX Transceiver
JD118B
HP X120 1G SFP LC LX Transceiver
JD119B
HP X120 1G SFP RJ45 T Transceiver
JD089B
HP X120 1G SFP LC BX 10-U Transceiver
JD098B
HP X120 1G SFP LC BX 10-D Transceiver
JD099B
HP X124 1G SFP LC LH40 1310nm Transceiver
JD061A
HP X120 1G SFP LC LH40 1550nm Transceiver
JD062A
HP X125 1G SFP LC LH70 Transceiver
JD063B
Note 3
If the CTO Base Model is ordered #0D1, Then #B2B, or #B2C is Required on the Switch. (Optional when Switch is not
Factory Racked. See Drop down remark in "Remarks" section.)
QuickSpecs
HP 5120 EI Switch Series
Configuration
DA - 13850 North America — Version 19 — August 19, 2013
Page 12
Note 10
If the CTO Switch Chassis needs to be racked, Then the CTO Base Model needs to integrate (with #0D1) to the HP
Universal Rack.
Remarks:
Drop down under power supply should offer the following options and results:
Switch to PDU Power Cord - Should replace localized option with #B2B in AMS or #B2C in APJ or EMEA.
Switch to Wall Power Cord - Should leave existing Localized Option (no #B2x options)
Switch Enclosure Options
External/Redundant Power Supplies
HP RPS 800 Redundant Power Supply
JD183A
Height = 1U
includes 1 x c13, 800w
See Configuration
Note:2, 3
HP RPS1600 Redundant Power System
JG136A
Height = 1U
includes 1 x c13, 1600w and Power Supply port
See Configuration
Note:2, 3
HP RPS1600 1600W AC Power Supply
JG137A
Installs into JG136A only
See Configuration
Note:1
Configuration Rules:
Note 1
If this power supply is selected, The JG136A - HP A-RPS1600 Redundant Power System must be on order or onsite.
Note 2
Localization required. (See Localization Menu for list.)
Note 3
Only 1 JD183A or JG136A can be connected per switch.
External/Redundant Power Cables
HP X290 1000 A JD5 2m RPS Cable
JD187A
HP X290 500/800 1m RPS Cable
JD190A
Enter the following menu selections as integrated to the CTO Model X above if order is factory built.
Modules
(Switch JE066x and JE067x ) No Modules supported
(All other Switches ) System (std 0 // max 2) User Selection (min 0 // max 2)
QuickSpecs
HP 5120 EI Switch Series
Configuration
DA - 13850 North America — Version 19 — August 19, 2013
Page 13
HP 5500 2-port 10GbE XFP Module
JD359B
min=0 \ max=2 XFP Transceivers
See Configuration
Note:2
HP A5500/A5120-EI 2p 10-GbE CX4 Module
JD360B
min=0 \ max=2 CX4 Cables
See Configuration
Note:4
HP 5500 1-port 10GbE XFP Module
JD361B
min=0 \ max=1 XFP Transceivers
See Configuration
Note:2
HP 5500/5120 2-port 10GbE SFP+ Module
JD368B
min=0 \ max=2 SFP+ Transceivers
See Configuration
Note:1
HP 5500/4800 2-port GbE SFP Module
JD367A
min=0 \ max=2 SFP Transceivers
See Configuration
Note:3
Configuration Rules:
Note 1
The following Transceivers install into this Module: (Use #0D1 if switch is CTO)
HP X130 10G SFP+ LC ER 40km Transceiver
JG234A
HP X130 SFP+ LC SR Transceiver
JD092B
HP X130 SFP+ LC LRM Transceiver
JD093B
HP X130 SFP+ LC LR Transceiver
JD094B
HP X240 10G SFP+ SFP+ 0.65m DAC Cable
JD095C
HP X240 10G SFP+ SFP+ 1.2m DAC Cable
JD096C
HP X240 10G SFP+ SFP+ 3m DAC Cable
JD097C
HP X240 10G SFP+ 7m DAC Cable
JC784C
HP X240 10G SFP+ SFP+ 5m DAC Cable
JG081C
HP X240 10G SFP+ 7m DAC Cable
JC784C
Note 2
The following Transceivers install into this Module: (Use #0D1 if switch is CTO)
HP X135 10G XFP LC ER Transceiver
JD121A
HP X130 10G XFP SC LR Transceiver
JD108B
HP X130 10G XFP LC SR Transceiver
JD117B
Note 3
The following Transceivers install into this Module: (Use #0D1 if switch is CTO)
HP X110 100M SFP LC FX Dual Mode Transceiver
JD497A
HP X120 1G SFP LC SX Transceiver
JD118B
HP X120 1G SFP LC LX Transceiver
JD119B
HP X120 1G SFP RJ45 T Transceiver
JD089B
HP X120 1G SFP LC BX 10-U Transceiver
JD098B
HP X120 1G SFP LC BX 10-D Transceiver
JD099B
HP X124 1G SFP LC LH40 1310nm Transceiver
JD061A
QuickSpecs
HP 5120 EI Switch Series
Configuration
DA - 13850 North America — Version 19 — August 19, 2013
Page 14
HP X120 1G SFP LC LH40 1550nm Transceiver
JD062A
HP X125 1G SFP LC LH70 Transceiver
JD063B
Note 4
The following Cables install into this Module:
HP X230 Local Connect 50cm CX4 Cable
JD363B
HP X230 Local Connect CX4 300 cm Cable
JD364B
HP X230 CX4 to CX4 3m Cable
JD365A
Note: Two JD365A - HP X230 CX4 to CX4 3m Cable should be added by default if Module is selected.
Transceivers
SFP Transceivers
HP X110 100M SFP LC FX DM Transceiver
JD497A
HP X120 1G SFP LC SX Transceiver
JD118B
HP X120 1G SFP LC LX Transceiver
JD119B
HP X120 1G SFP RJ45 T Transceiver
JD089B
HP X120 1G SFP LC BX 10-U Transceiver
JD098B
HP X120 1G SFP LC BX 10-D Transceiver
JD099B
HP X120 1G SFP LC LH40 1550nm XCVR
JD062A
HP X125 1G SFP LC LH40 1310nm XCVR
JD061A
HP X125 1G SFP LC LH70 Transceiver
JD063B
SFP+ Transceivers
HP X130 10G SFP+ LC ER 40km Transceiver
JG234A
HP X130 SFP+ LC SR Transceiver
JD092B
HP X130 SFP+ LC LRM Transceiver
JD093B
HP X130 SFP+ LC LR Transceiver
JD094B
HP X240 10G SFP+ SFP+ 0.65m DAC Cable
JD095C
HP X240 10G SFP+ SFP+ 1.2m DAC Cable
JD096C
QuickSpecs
HP 5120 EI Switch Series
Configuration
DA - 13850 North America — Version 19 — August 19, 2013
Page 15
HP X240 10G SFP+ SFP+ 3m DAC Cable
JD097C
HP X240 10G SFP+ SFP+ 5m DAC Cable
JG081C
HP X240 10G SFP+ 7m DAC Cable
JC784C
XFP Transceivers
HP X130 10G XFP LC LR 1310nm Transceiver
JD108B
HP X130 LC SR XFP Transceiver
JD117B
HP X135 10G XFP LC ER Transceiver
JD121A
Cables
Local Connect Cables
HP X230 Local Connect 50cm CX4 Cable
JD363B
HP X230 Local Connect CX4 300 cm Cable
JD364B
HP X230 CX4 to CX4 3m Cable
JD365A
HP X230 Local Connect 50cm CX4 Cable
JD363B
HP X230 Local Connect CX4 300 cm Cable
JD364B
HP X230 CX4 to CX4 3m Cable
JD365A
Multi-Mode Cables
HP .5m Multi-mode OM3 LC/LC FC Cable
AJ833A
HP 1m Multi-mode OM3 LC/LC FC Cable
AJ834A
HP 2 m Multimode OM3 LC/LC FC Cable
AJ835A
HP 5 m Multimode OM3 LC/LC FC Cable
AJ836A
HP 15 m Multimode OM3 LC/LC FC Cable
AJ837A
HP 30 m Multimode OM3 LC/LC FC Cable
AJ838A
HP 50 m Multimode OM3 LC/LC FC Cable
AJ839A
QuickSpecs
HP 5120 EI Switch Series
Configuration
DA - 13850 North America — Version 19 — August 19, 2013
Page 16
Loading...
