HP Mini 5103

Maintenance and Service Guide

SUMMARY

This guide is a troubleshooting reference used for maintaining and servicing the computer. It provides
comprehensive information on identifying computer features, components, and spare parts;
troubleshooting computer problems; and performing computer disassembly procedures.

© Copyright 2010 Hewlett-Packard
Development Company, L.P.

Bluetooth is a trademark owned by its
proprietor and used by Hewlett-Packard
Company under license. Intel and Atom are
trademarks of Intel Corporation in the U.S.
and other countries. Microsoft, Windows,
and Windows Vista are U.S. registered
trademarks of Microsoft Corporation. SD
Logo is a trademark of its proprietor.

The information contained herein is subject
to change without notice. The only
warranties for HP products and services are
set forth in the express warranty statements
accompanying such products and services.
Nothing herein should be construed as
constituting an additional warranty. HP shall
not be liable for technical or editorial errors
or omissions contained herein.

First Edition: August 2010

Document Part Number: 627066-001

Safety warning notice

WARNING! To reduce the possibility of heat-related injuries or of overheating the computer, do not

place the computer directly on your lap or obstruct the computer air vents. Use the computer only on
a hard, flat surface. Do not allow another hard surface, such as an adjoining optional printer, or a soft
surface, such as pillows or rugs or clothing, to block airflow. Also, do not allow the AC adapter to
contact the skin or a soft surface, such as pillows or rugs or clothing, during operation. The computer
and the AC adapter comply with the user-accessible surface temperature limits defined by the
International Standard for Safety of Information Technology Equipment (IEC 60950).

iii

iv Safety warning notice

Table of contents

1 Product description ........................................................................................................................................ 1

2 External component identification ................................................................................................................ 4

Top components ................................................................................................................................... 5

TouchPad ............................................................................................................................ 5

Lights ................................................................................................................................... 6

Buttons ................................................................................................................................. 7

Keys ..................................................................................................................................... 8

Front components ................................................................................................................................ 9

Right-side components ....................................................................................................................... 10

Left-side components ......................................................................................................................... 11

Display components ........................................................................................................................... 12

Bottom components ........................................................................................................................... 13

Carrying handle .................................................................................................................................. 14

Wireless antennas .............................................................................................................................. 15

Additional hardware components ....................................................................................................... 16

3 Illustrated parts catalog ............................................................................................................................... 17

Service tag ......................................................................................................................................... 17

Device major components .................................................................................................................. 18

Display assembly components ........................................................................................................... 23

Miscellaneous parts ............................................................................................................................ 25

Sequential part number listing ............................................................................................................ 26

4 Removal and replacement procedures ....................................................................................................... 31

Preliminary replacement requirements ............................................................................................... 31

Tools required .................................................................................................................... 31

Service considerations ....................................................................................................... 31

Plastic parts ....................................................................................................... 31

Cables and connectors ..................................................................................... 31

Drive handling ................................................................................................... 32

Grounding guidelines ......................................................................................................... 33

Electrostatic discharge damage ........................................................................ 33

v

Packaging and transporting guidelines ............................................. 34

Workstation guidelines ..................................................................... 34

Equipment guidelines ....................................................................... 35

Component replacement procedures ................................................................................................. 36

Service tag ......................................................................................................................... 36

Device feet ......................................................................................................................... 37

Battery ............................................................................................................................... 38

SIM .................................................................................................................................... 39

Memory module ................................................................................................................. 40

Carrying Handle (select models only) ................................................................................ 41

Keyboard ........................................................................................................................... 43

Mass storage devices ........................................................................................................ 50

WLAN module .................................................................................................................... 53

SIM module ........................................................................................................................ 55

Top cover ........................................................................................................................... 56

Speaker ............................................................................................................................. 59

WWAN module .................................................................................................................. 60

RTC battery ....................................................................................................................... 62

Bluetooth module ............................................................................................................... 63

Power button board ........................................................................................................... 64

Display assembly ............................................................................................................... 65

System board ..................................................................................................................... 74

Fan and heat sink assembly .............................................................................................. 76

5 Computer Setup ............................................................................................................................................ 79

Computer Setup in Windows 7 ........................................................................................................... 79

Starting Computer Setup ................................................................................................... 79

Using Computer Setup ...................................................................................................... 79

Navigating and selecting in Computer Setup .................................................... 79

Restoring factory settings in Computer Setup ................................................... 80

Computer Setup menus ..................................................................................................... 81

File menu .......................................................................................................... 81

Security menu ................................................................................................... 82

System Configuration menu .............................................................................. 83

Computer Setup in Windows Vista® .................................................................................................. 86

Starting Computer Setup ................................................................................................... 86

Using Computer Setup ...................................................................................................... 86

Navigating and selecting in Computer Setup .................................................... 86

Restoring factory settings in Computer Setup ................................................... 87

Computer Setup menus ..................................................................................................... 88

File menu .......................................................................................................... 88

Security menu ................................................................................................... 89

System Configuration menu .............................................................................. 90

vi

Computer Setup in SUSE Linux ......................................................................................................... 94

Starting Computer Setup ................................................................................................... 94

Computer Setup menus ..................................................................................................... 94

File menu .......................................................................................................... 94

Security menu ................................................................................................... 96

System Configuration menu .............................................................................. 97

6 Specifications .............................................................................................................................................. 100

Device specifications ........................................................................................................................ 100

25.7-cm (10.1-in), high-definition, 16:9, AntiGlare display specifications ......................................... 102

25.7-cm (10.1-in), WSVGA, AntiGlare display specifications ........................................................... 103

Hard drive specifications .................................................................................................................. 104

Solid state drive specifications ......................................................................................................... 105

System resource specifications ........................................................................................................ 106

7 Backup and recovery .................................................................................................................................. 107

Windows 7 backup and recovery ..................................................................................................... 107

Backing up ....................................................................................................................... 107

Recovering ....................................................................................................................... 108

Windows Vista backup and recovery ............................................................................................... 110

Backing up ....................................................................................................................... 110

Recovering ....................................................................................................................... 112

SUSE Linux backup and recovery .................................................................................................... 113

8 Connector pin assignments ....................................................................................................................... 114

Audio-in (microphone) ...................................................................................................................... 114

Audio-out (headphone) ..................................................................................................................... 115

External monitor ............................................................................................................................... 116

RJ-45 (network) ................................................................................................................................ 117

Universal Serial Bus ......................................................................................................................... 118

9 Power cord set requirements .................................................................................................................... 119

Requirements for all countries and regions ...................................................................................... 119

Requirements for specific countries and regions ............................................................................. 120

10 Recycling ................................................................................................................................................... 121

Battery .............................................................................................................................................. 121

Display .............................................................................................................................................. 121

Index ................................................................................................................................................................. 127

vii

viii

1 Product description

Category Description

Product name HP Mini 5103

Processor Intel® Atom™ Dual core N550 1.5-GHz processor, 512-KB Level 2 cache,

667-MHz front-side bus (FSB)

Intel Atom N475 1.83-GHz processor, 512-KB Level 2 cache, 667-MHz front-side

bus (FSB)

Intel Atom N455 1.66-GHz processor, 512-KB Level 2 cache, 667-MHz front-side

bus (FSB)

Chipset Intel NM10 Express

Graphics Intel Universal Memory Architecture (UMA) graphics subsystem

Broadcom Crystal HD Enhanced Video Decoder (32 MB × 16 DDR2) optional

NOTE: Not supported by computers with WWAN option installed.

Panel Wide-aspect 16:9 ratio panels

All display assemblies include 1 webcam, 2 microphones, and 2 wireless local­area network (WLAN) antennas/cables (WWAN is optional).

Capacitive touch screen optional

25.7-cm (10.1-in) high-definition (1366 × 768) AntiGlare LED

25.7-cm (10.1-in) standard-definition (1024 × 600) AntiGlare LED

Memory One customer-accessible/upgradable memory module slot

Supports up to 2 GB of system memory

PC2-5300, 800 MHz, DDR2 (running at 667-MHz)

Supports the following configurations:

Mass storage devices Hard drive

Supports the following 9.5-mm, 6.35-cm (2.50-in) SATA hard drives:

2048-MB total system memory (2048 × 1)

●

NOTE: Not supported by computers with Windows® 7 Home Basic or with

Windows 7 Starter in select countries and regions.

1024-MB total system memory (1024 × 1)

●

1

Category Description

Solid state drive (SSD)

Supports the following 6.35-cm (2.50-in) SATA solid state drives:

Optical drive Supports external USB optical drives only

Diskette drive Supports external USB diskette drives only

Audio/Visual High-definition (HD) audio

Integrated speakers (2)

Fixed integrated stereo microphones (2)

Fixed integrated 2-MP webcam

320-GB, 7200-RPM

●

NOTE: Not supported by computers with Windows 7 Home Basic or with

Windows 7 Starter in select countries and regions.

250-GB, 7200-RPM

●

160-GB, 7200-RPM

●

80 GB

●

NOTE: Not supported by computers with Windows 7 Starter.

128 GB

●

NOTE: Not supported by computers with Windows 7 Starter.

Modem Supports external USB modems only

Ethernet Integrated 10/100/1000 Wake-On-LAN network interface card (NIC)

Wireless 2 WLAN antennas built into display assembly. WWAN antennas (2) with WWAN

option (worldwide 5-band antenna configured with select models)

Integrated WLAN modules:

802.11/a/b/g/n

●

802.11 b/g/n

●

802.11b/g/n with Bluetooth

●

Support for No WLAN option

Integrated WWAN option

NOTE: Not supported by computers with Linux installed.

NOTE: Not supported by computers with HD Enhanced Video Accelerator

installed.

Integrated WPAN Bluetooth® module

Support for No WPAN option.

External media cards Media Card Reader with push-push technology supporting:

MultiMediaCard (MMC)

●

2 Chapter 1 Product description

Secure Digital (SD) Memory Card

●

Category Description

Ports Audio-in (stereo microphone)

Audio out (stereo headphone)

RJ-45 (Ethernet, includes link and activity lights)

USB (2)

USB+ (powered) (1)

VGA (D-sub 15) supporting 1920 × 1440 external monitor (hot plug/unplug with

auto-detect)

3-pin AC power

Keyboard/pointing device 92%, spill-resistant keyboard

Dura-Keys

TouchPad, with 2 TouchPad buttons and 2-way scrolling (taps enabled as

default)

Power requirements AC adapter

40-W Smart AC adapter

●

NOTE: AC adapter includes connector on cable and localized plug support.

Battery

6 cell Li-Ion (66-Wh) 3.0-Ah

●

4-cell Li-ion (29-Wh) 2.0-Ah

●

Security Supports HP Kensington Security Lock

Operating system Preinstalled:

Windows 7 Professional 32

Windows 7 Home Premium 32

Windows 7 Starter 32

FreeDOS

SUSE Linux (SLED 11)

Serviceability Customer Self-Replacement (CSR):

AC adapter

●

Battery (system)

●

Keyboard

●

Memory module

●

Hard drive

●

3

2 External component identification

Components included with the computer may vary by region and model. The illustrations in this
chapter identify the standard features on most computer models.

To see a list of hardware installed in the computer, follow these steps:

Select Start > Control Panel > System and Security > Device Manager.

▲

You can also add hardware or modify device configurations using Device Manager.

NOTE: Windows includes the User Account Control feature to improve the security of your

computer. You may be prompted for your permission or password for tasks such as installing
applications, running utilities, or changing Windows settings. Refer to Help and Support for more
information.

4 Chapter 2 External component identification

Top components

TouchPad

Component Description

(1) TouchPad* Moves the pointer and selects or activates items on the screen.

(2) Left TouchPad button* Functions like the left button on an external mouse.

(3) Right TouchPad button* Functions like the right button on an external mouse.

(4) TouchPad scroll zone Scrolls up or down.

*This table describes factory settings.

To view or change the pointing device preferences:

1. Select Start > Devices and Printers.

2. Right-click the device representing the computer.

3. Select Mouse settings.

Top components 5

Lights

Component Description

(1) Caps lock light On—Caps lock is on.

(2) QuickWeb light On—The Web browser is in use.

(3) QuickLook light

(4) Power light

On—The computer is on.

●

Off—The computer is off or in Sleep or Hibernation.

●

On—The computer is on.

●

Flashing—The computer is in Sleep.

●

Off—The computer is off or in Hibernation.

●

6 Chapter 2 External component identification

Buttons

Component Description

(1) QuickWeb button

(2) QuickLook button

(3) Power button

When the computer is off, press the button to open

●

HP QuickWeb.

When the computer is on, press the button to open

●

the default Web browser.

When the computer is off, press the button to open

●

HP QuickLook.

When the computer is on, press the button to open

●

Software Setup.

NOTE: If Software Setup is not available, the default

Web browser opens.

When the computer is off, press the button to turn

●

on the computer.

When the computer is on, press the button to shut

●

down the computer.

When the computer is in Sleep, press the button to

●

exit Sleep.

When the computer is in Hibernation, press the

●

button to exit Hibernation.

If the computer has stopped responding and Windows
shutdown procedures are ineffective, press and hold the
power button for at least 5 seconds to turn off the
computer.

To learn more about your power settings, select Start >

Control Panel > System and Security > Power
Options.

Top components 7

Keys

Component Description

(1) esc key Displays system information when pressed in combination with

(2) fn key Displays system information when pressed in combination with

(3) Windows logo key Displays the Windows Start menu.

(4) Windows applications key Displays a shortcut menu for items where the cursor is pointed.

(5) Embedded numeric keypad keys Used like the keys on an external numeric keypad.

(6) Function keys Executes the action represented by the icon on the key.

the fn key.

the esc key.

8 Chapter 2 External component identification

Front components

Component Description

(1) Drive light Flashing—The hard drive is being accessed.

(2) Wireless light

(3) Wireless switch Turns the wireless feature on or off, but does not create a

(4) Speakers (2) Two integrated speakers produce sound.

Blue—An integrated wireless device, such as a wireless

●

local area network (WLAN) device and/or a Bluetooth®
device, is on.

Amber—No wireless devices are detected.

●

NOTE: The wireless light turns amber when the computer turns

on and all wireless devices are off.

wireless connection.

NOTE: To establish a wireless connection, a wireless network

must already be set up.

Front components 9

Right-side components

Component Description

(1) SD Card Reader Supports the following optional digital card formats:

MultiMediaCard (MMC)

●

Secure Digital (SD) Memory Card

●

(2) Audio-out (headphone) jack Produces sound when connected to optional powered stereo

(3) Audio-in (microphone) jack Connects an optional computer headset microphone, stereo

(4) Powered USB port Provides power to a USB device, such as an optional external

(5) RJ-45 (network) jack Connects a network cable.

(6) Security cable slot Attaches an optional security cable to the computer.

speakers, headphones, ear buds, a headset, or television audio.

NOTE: When a device is connected to the headphone jack, the

computer speakers are disabled.

array microphone, or monaural microphone.

optical drive, if used with a powered USB cable.

NOTE: The security cable is designed to act as a deterrent, but

it may not prevent the computer from being mishandled or stolen.

10 Chapter 2 External component identification

Left-side components

Component Description

(1) Battery light

(2) Power connector Connects an AC adapter.

(3) External monitor port Connects an external VGA monitor or projector.

(4) Vent Enables airflow to cool internal components.

(5) USB ports (2) Connects optional USB devices.

Amber—A battery is charging.

●

Turquoise—A battery is close to full charge capacity.

●

Flashing amber—A battery that is the only available power

●

source has reached a low battery level. When the battery
reaches a critical battery level, the battery light begins
blinking rapidly.

Off—If the computer is plugged into an external power

●

source, the light turns off when all batteries in the computer
are fully charged. If the computer is not plugged into an
external power source, the light stays off until the battery
reaches a low battery level..

NOTE: The computer fan starts up automatically to cool internal

components and prevent overheating. It is normal for the internal
fan to cycle on and off during routine operation.

Left-side components 11

Display components

Component Description

(1) Webcam light On—The webcam is in use.

(2) Webcam Records audio and video and captures still photographs.

(3) Internal microphones (2) Record sound.

NOTE: If there is a microphone icon next to each microphone

opening, your computer has internal microphones.

12 Chapter 2 External component identification

Bottom components

Component Description

(1) Battery bay Holds the battery.

(2) Battery release latches (2) Release the battery from the battery bay.

(3) SIM slot (select models only) Contains a wireless subscriber identity module (SIM).

(4) Service tag Provides the product brand and series name, serial number (s/n),

(5) Memory module compartment Contains the memory module slot.

(6) Vents (2) Enable airflow to cool internal components.

and product number (p/n) of your computer. Have this information
available when you contact technical support.

NOTE: The computer fan starts up automatically to cool internal

components and prevent overheating. It is normal for the internal
fan to cycle on and off during routine operation.

Bottom components 13

Carrying handle

Select models of the computer have an optional carrying handle that is attached to the bottom of the
computer. The handle can be extended by rotating it away from the computer as shown in the
following illustration.

14 Chapter 2 External component identification

Wireless antennas

On select models of the computer, at least two antennas send and receive signals from one or more
wireless devices.

Component Description

(1) WWAN antennas (2)* (select models only) Send and receive wireless signals to communicate with

wireless wide-area networks (WWANs).

(2) WLAN antennas (2)* (select models only) Send and receive wireless signals to communicate with

wireless local area networks (WLANs).

*The antennas are not visible from the outside of the computer. For optimal transmission, keep the areas immediately
around the antennas free from obstructions.

To see wireless regulatory notices, refer to the section of the Regulatory, Safety and Environmental
Notices that applies to your country or region. These notices are located in Help and Support.

Wireless antennas 15

Additional hardware components

Component Description

(1) Power cord* Connects an AC adapter to an AC outlet.

(2) AC adapter Converts AC power to DC power.

(3) Battery* Powers the computer when the computer is not plugged into

external power.

*Batteries and power cords vary in appearance by region and country.

16 Chapter 2 External component identification

3 Illustrated parts catalog

Service tag

When ordering parts or requesting information, provide the computer serial number and model
description provided on the service tag located on the bottom of the computer.

(1) Product name (4) Warranty period

(2) Product number (5) Model description (select models)

(3) Serial number

Service tag 17

Device major components

18 Chapter 3 Illustrated parts catalog

Item Description Spare part number

(1) Display panel assembly (includes 1 webcam, 2 microphones, and 2 WLAN antennas with

cables; 2 WWAN antennas with cables on select models)

See

Display assembly components on page 23 for a comprehensive list of display

assembly spare parts.

25.7-cm (10.1-in), high-definition, AntiGlare, touch-screen display for use with

●

webcam and WWAN option, espresso

25.7-cm (10.1-in), high-definition, AntiGlare, touch-screen display for use with

●

webcam and WWAN option, red

25.7-cm (10.1-in), high-definition, AntiGlare, touch-screen display for use with

●

webcam and WWAN option, blue

25.7-cm (10.1-in), high-definition, AntiGlare display assembly for use with webcam

●

and WWAN option, espresso

25.7-cm (10.1-in), high-definition, AntiGlare display assembly for use with webcam

●

and WWAN option, red

25.7-cm (10.1-in), high-definition, AntiGlare display assembly for use with webcam

●

and WWAN option, blue

25.7-cm (10.1-in), WSVGA, AntiGlare, touch-screen display for use with webcam and

●

WWAN option, espresso

25.7-cm (10.1-in), WSVGA, AntiGlare, touch-screen display for use with webcam and

●

WWAN option, red

25.7-cm (10.1-in), WSVGA, AntiGlare, touch-screen display for use with webcam and

●

WWAN option, blue

625728-001

607178-001

607180-001

625730-001

607182-001

607184-001

625727-001

607177-001

607179-001

(2) Keyboard, 25.7 cm (10.1 in)

25.7-cm (10.1-in), WSVGA, AntiGlare display assembly for use with webcam and

●

WWAN option, espresso

25.7-cm (10.1-in), WSVGA, AntiGlare display assembly for use with webcam and

●

WWAN option, red

25.7-cm (10.1-in), WSVGA, AntiGlare display assembly for use with webcam and

●

WWAN option, blue

For use in Belgium 578364-A41

●

For use in Brazil 578364-201

●

For use in Bulgaria 578364-261

●

For use in the Czech Republic 578364-221

●

For use in Czechoslovakia, and Slovakia 578364–A81

●

For use in Denmark 578364-081

●

For use in Europe 578364-B31

●

For use in France 578364-051

●

For use in French Canada 578364-121

●

For use in Finland, and Sweden 578364-B71

●

For use in Germany 578364-041

●

625729-001

607181-001

607183-001

Device major components 19

Item Description Spare part number

For use in Greece 578364-DJ1

●

For use in Hungary 578364-211

●

For use in Iceland 578364-DD1

●

For use in Israel 578364-BB1

●

For use in Italy 578364-061

●

For use in Japan 578364-291

●

For use in Latin America 578364-161

●

For use in Norway 578364-091

●

For use in Portugal 578364-131

●

For use in Russia 578364-251

●

For use in Saudi Arabia 578364-171

●

For use in Slovakia 578364-231

●

For use in Slovenia 578364-BA1

●

For use in South Korea 578364-AD1

●

For use in Spain 578364-071

●

For use in Switzerland 578364-BG1

●

(3) Top cover (includes TouchPad)

(4) Speaker assembly (includes cable) 577967-001

(5) Hard drive

For use in Taiwan 578364-AB1

●

For use in Thailand 578364-281

●

For use in Turkey 578364-141

●

For use in the United Kingdom 578364-031

●

For use in the United States 578364-001

●

Espresso 625726-001

●

Red 598461-001

●

Blue 598462-001

●

Espresso, dual-core 627792–001

●

NOTE: Hard drive spares include mounting bracket and screws.

320-GB, 7200-RPM, for use with WWAN option 593643-001

●

320-GB, 7200-RPM, SATA 577974-001

●

250-GB, 7200-RPM, for use with WWAN option 593642-001

●

250-GB, 7200-RPM, SATA 538972-001

●

160-GB, 7200-RPM, for use with WWAN option 593641-001

●

20 Chapter 3 Illustrated parts catalog

Item Description Spare part number

Solid state drive (SSD)

(6) Fan and heat sink assembly (includes replacement thermal material) 598452-001

Fan and heat sink assembly (for use with dual-core models) 627790–001

(7) WLAN module

Broadcom 43224 802.11a/b/g/n 2x2 WiFi Adapter

160-GB, 7200-RPM, SATA 577972-001

●

NOTE: Solid state drive spares include mounting bracket and screws.

128-GB, SATA 606971-001

●

80-GB, SATA 583004-001

●

For use in Antigua and Barbuda, Barbados, Belize, Canada, the Cayman Islands,

●

Guam, Puerto Rico, Trinidad and Tobago, the U.S. Virgin Islands, and the United
States

For use in Afghanistan, Albania, Algeria, Andorra, Angola, Argentina, Armenia, Aruba,

●

Australia, Austria, Azerbaijan, the Bahamas, Bahrain, Bangladesh, Barbados, Belarus,
Belgium, Belize, Benin, Bermuda, Bhutan, Bolivia, Bosnia and Herzegovina,
Botswana, Brazil, the British Virgin Islands, Brunei, Bulgaria, Burkina Faso, Burundi,
Cambodia, Cameroon, Cape Verde, the Central African Republic, Chad, Chile,
Colombia, Comoros, the Congo, Costa Rica, Croatia, Cyprus, the Czech Republic,
Denmark, Djibouti, Dominica, the Dominican Republic, East Timor, Ecuador, Egypt, El
Salvador, Equatorial Guinea, Eritrea, Estonia, Ethiopia, Fiji, Finland, France, French
Guiana, Gabon, Gambia, Georgia, Germany, Ghana, Gibraltar, Greece, Grenada,
Guadeloupe, Guatemala, Guinea, Guinea-Bissau, Guyana, Haiti, Honduras, Hong
Kong, Hungary, Iceland, India, Indonesia, Ireland, Italy, the Ivory Coast, Jamaica,
Japan, Jordan, Kazakhstan, Kenya, Kiribati, Kuwait, Kyrgyzstan, Laos, Latvia,
Lebanon, Lesotho, Liberia, Liechtenstein, Lithuania, Luxembourg, Macedonia,
Madagascar, Malawi, Malaysia, the Maldives, Mali, Malta, the Marshall Islands,
Martinique, Mauritania, Mauritius, Mexico, Micronesia, Monaco, Mongolia,
Montenegro, Morocco, Mozambique, Namibia, Nauru, Nepal, the Nether Antilles, the
Netherlands, New Zealand, Nicaragua, Niger, Nigeria, Norway, Oman, Pakistan,
Palau, Panama, Papua New Guinea, Paraguay, the People’s Republic of China, Peru,
the Philippines, Poland, Portugal, Qatar, the Republic of Moldova, Romania, Russia,
Rwanda, Samoa, San Marino, Sao Tome and Principe, Saudi Arabia, Senegal, Serbia,
the Seychelles, Sierra Leone, Singapore, Slovakia, Slovenia, the Solomon Islands,
Somalia, South Africa, South Korea, Spain, Sri Lanka, St. Kitts and Nevis, St. Lucia,
St. Vincent, Suriname, Swaziland, Sweden, Switzerland, Taiwan, Tajikistan, Tanzania,
Thailand, Togo, Tonga, Tunisia, Turkey, Turkmenistan, Tuvalu, Uganda, Ukraine, the
United Arab Emirates, the United Kingdom, Uruguay, Uzbekistan, Vanuatu,
Venezuela, Vietnam, Yemen, Zaire, Zambia, and Zimbabwe

518434-001

518434-002

Broadcom 4313AGN 802.11a/b/g/draft-n WiFi Adapter 593836–001

Broadcom 4313 802.11b/g/n 1x1 WiFi and 2070 Bluetooth 2.1+EDR Combo Adapter 600370–001

(8) System board (includes processor, replacement thermal material, and RTC battery)

Includes Intel Atom N455 1.66-GHz processor, 512-KB Level 2 cache, 667-MHz front-

●

side bus (FSB)

Includes Intel Atom N475 1.83-GHz processor, 512-KB Level 2 cache, 667-MHz front-

●

side bus (FSB)

Includes Intel Atom N550 1.50-GHz processor, 512-KB Level 2 cache, 667-MHz front-

●

side bus (FSB)

625687-001

625688-001

625689-001

Device major components 21

Item Description Spare part number

(9a) Bluetooth cable

(9b) Audio connector cover

(9c) Memory module compartment cover

(9d) Blank for Media Card Reader

(10) Bluetooth module 537921-001

(11) RTC battery 507707-001

(12) Optional minicard:

WWAN module, Qualcomm EV-DO HSPA (includes mounting bracket)

HD Enhanced Video Accelerator (graphics decoder) 578237-001

Includes Intel Atom N455 1.66-GHz processor, 512-KB Level 2 cache, 667-MHz front-

●

side bus (FSB) for use in the People's Republic of China and Russia

Includes Intel Atom N475 1.83-GHz processor, 512-KB Level 2 cache, 667-MHz front-

●

side bus (FSB) for use in the People's Republic of China and Russia

Includes Intel Atom N550 1.50-GHz processor, 512-KB Level 2 cache, 667-MHz front-

●

side bus (FSB) for use in the People's Republic of China and Russia

Plastics kit with Bluetooth cable 605743-001

NOTE: Not supported by computers with Linux installed.

NOTE: Not supported by computers with the HD Enhanced Video Accelerator installed.

626582-001

626583–001

626584–001

531993-001

HD Video Decoder 627791–001

(13) Power button board (includes cable) 598451-001

(14) SIM board (includes cable) 577923-001

(15) Battery

(16) Base enclosure (includes 4 rubber device feet) 607111-001

(17) Memory module (PC2-6400, shared)

6 cell Li-ion (66 Wh) 3.0 Ah 535629-001

●

4-cell Li-ion (29-Wh) 2.0-Ah 579026-001

●

1-GB

●

NOTE: Not supported by computers with Windows 7 Home Basic or with Windows 7

Starter installed.

2-GB 621567-001

●

621563-001

22 Chapter 3 Illustrated parts catalog

Display assembly components

NOTE: The first figure below shows the non-touch display assembly and the second figure shows

the touch-screen display assembly.

NOTE: The following figure shows the components of the touch-screen display assembly. The

display bezel thickness increases to accommodate the touch-screen glass and board.

Item Description Spare part number

(1) Display bezel

For use with touch screen with webcam 598460-001

●

For use with non-touch screen with webcam 577929-001

●

Display assembly components 23

Item Description Spare part number

(2) Display hinge kit

(Includes left and right display panel hinges)

(3) LCD panel

NOTE: The non-touch display assembly includes the LCD panel. See the display

assembly part number in

(4) Webcam module 577927-001

(5) Display panel/webcam cable for use in:

Display cable kit includes the following cables: 577933-001

(6)

(7)

(8)

LCD with touch glass for use with high definition display assembly 624216-001

●

LCD with touch glass for use with WSVGA display assembly 624218-001

●

High-definition display assembly 577932-001

●

WSVGA display assembly 577931-001

●

High-definition display assembly w/ touchscreen 617082–001

●

WSVGA display assembly w/ touchscreen 617081–001

●

WLAN antennas (2) with cable

●

Dual microphone with cable

●

WWAN antennas (2) with cable

●

Device major components on page 18.

577930-001

(9) Display back cover (includes logo)

Espresso for use with touch screen 625724-001

●

Red for use with touch screen 598458-001

●

Blue for use with touch screen 598459-001

●

Espresso for use with non-touch screen 625725-001

●

Red for use with non-touch screen 606201-001

●

Blue for use with non-touch screen 606970-001

●

24 Chapter 3 Illustrated parts catalog

Miscellaneous parts

Description Spare part number

40-W, 3-pin Smart AC adapter (for use in all countries and regions) 613151-001

Power cord

For use in Argentina 490371-D01

●

For use in Australia 490371-011

●

For use in Brazil 490371-201

●

For use in Denmark 490371-081

●

For use in Europe 490371-021

●

For use in India 490371-D61

●

For use in Israel 490371-BB1

●

For use in Italy 490371-061

●

For use in Japan 490371-291

●

For use in North America 490371-001

●

For use in the People's Republic of China 490371-AA1

●

For use in Singapore and the United Kingdom 490371-031

●

For use in South Africa 490371-AR1

●

For use in South Korea 490371-AD1

●

For use in Switzerland 490371-111

●

For use in Taiwan 490371-AB1

●

Rubber kit (contains 4 rubber device feet – 2 front and 2 rear) 578361-001

Optional carrying handle (see

Screw kit

Includes the following replacement screws:

PM1.6×2.5×3.5

●

PM2.0×2.0×6.8 broad head

●

PM2.0×2.5

●

PM2.0×3.0×4.0

●

PM2.0x2.5x4.5

●

PM2.5×4.0

●

PM2.5×5.0×5.5

●

PM2.6×4.5

●

Carrying handle on page 14) 606384-001

578362-001

Miscellaneous parts 25

Sequential part number listing

Spare part number Description

490371-001 Power cord for use in North America

490371-011 Power cord for use in Australia

490371-021 Power cord for use in Europe

490371-031 Power cord for use in Singapore and the United Kingdom

490371-061 Power cord for use in Italy

490371-081 Power cord for use in Denmark

490371-111 Power cord for use in Switzerland

490371-201 Power cord for use in Brazil

490371-291 Power cord for use in Japan

490371-AA1 Power cord for use in the People's Republic of China

490371-AB1 Power cord for use in Taiwan

490371-AD1 Power cord for use in South Korea

490371-AR1 Power cord for use in South Africa

490371-BB1 Power cord for use in Israel

490371-D01 Power cord for use in Argentina

490371-D61 Power cord for use in India

507707-001 RTC battery

518434-001 WLAN module, Broadcom 43224 802.11a/b/g/n 2x2 WiFi Adapter for use in Antigua and Barbuda,

Barbados, Belize, Canada, the Cayman Islands, Guam, Puerto Rico, Trinidad and Tobago, the U.S.
Virgin Islands, and the United States

518434-002 WLAN module, Broadcom 43224 802.11a/b/g/n 2x2 WiFi Adapter for use in Afghanistan, Albania,

Algeria, Andorra, Angola, Argentina, Armenia, Aruba, Australia, Austria, Azerbaijan, the Bahamas,
Bahrain, Bangladesh, Barbados, Belarus, Belgium, Belize, Benin, Bermuda, Bhutan, Bolivia,
Bosnia and Herzegovina, Botswana, Brazil, the British Virgin Islands, Brunei, Bulgaria, Burkina
Faso, Burundi, Cambodia, Cameroon, Cape Verde, the Central African Republic, Chad, Chile,
Colombia, Comoros, the Congo, Costa Rica, Croatia, Cyprus, the Czech Republic, Denmark,
Djibouti, Dominica, the Dominican Republic, East Timor, Ecuador, Egypt, El Salvador, Equatorial
Guinea, Eritrea, Estonia, Ethiopia, Fiji, Finland, France, French Guiana, Gabon, Gambia, Georgia,
Germany, Ghana, Gibraltar, Greece, Grenada, Guadeloupe, Guatemala, Guinea, Guinea-Bissau,
Guyana, Haiti, Honduras, Hong Kong, Hungary, Iceland, India, Indonesia, Ireland, Italy, the Ivory
Coast, Jamaica, Japan, Jordan, Kazakhstan, Kenya, Kiribati, Kuwait, Kyrgyzstan, Laos, Latvia,
Lebanon, Lesotho, Liberia, Liechtenstein, Lithuania, Luxembourg, Macedonia, Madagascar,
Malawi, Malaysia, the Maldives, Mali, Malta, the Marshall Islands, Martinique, Mauritania, Mauritius,
Mexico, Micronesia, Monaco, Mongolia, Montenegro, Morocco, Mozambique, Namibia, Nauru,
Nepal, the Nether Antilles, the Netherlands, New Zealand, Nicaragua, Niger, Nigeria, Norway,
Oman, Pakistan, Palau, Panama, Papua New Guinea, Paraguay, the People’s Republic of China,
Peru, the Philippines, Poland, Portugal, Qatar, the Republic of Moldova, Romania, Russia,
Rwanda, Samoa, San Marino, Sao Tome and Principe, Saudi Arabia, Senegal, Serbia, the
Seychelles, Sierra Leone, Singapore, Slovakia, Slovenia, the Solomon Islands, Somalia, South
Africa, South Korea, Spain, Sri Lanka, St. Kitts and Nevis, St. Lucia, St. Vincent, Suriname,
Swaziland, Sweden, Switzerland, Taiwan, Tajikistan, Tanzania, Thailand, Togo, Tonga, Tunisia,
Turkey, Turkmenistan, Tuvalu, Uganda, Ukraine, the United Arab Emirates, the United Kingdom,
Uruguay, Uzbekistan, Vanuatu, Venezuela, Vietnam, Yemen, Zaire, Zambia, and Zimbabwe

26 Chapter 3 Illustrated parts catalog

Spare part number Description

531993-001 Optional WWAN module, Qualcomm EV-DO HSPA (includes mounting bracket)

NOTE: Not supported by computers with Linux installed.

NOTE: Not supported by computers with HD Enhanced Video Accelerator installed.

535629-001 Battery, 6 cell Li-ion (66 Wh) 3.0 Ah

537921-001 Bluetooth module

538972-001 Hard drive, 250-GB, 7200-RPM, SATA

577923-001 SIM board with cable

577927-001 Webcam module

577929-001 Display bezel for use with non-touch screen with webcam

577930-001 Display hinge kit (includes left and right display panel hinges and screws)

577931-001 Display panel/webcam cable for use in WSVGA display assembly

577932-001 Display panel/webcam cable for use in high-definition display assembly

577933-001 Display cable kit with the WLAN antennas (2) and cable, dual array microphone with cable, and

WWAN antennas (2) with cable on select models.

577967-001 Speaker assembly with cable

577972-001 Hard drive, 160-GB, 7200-RPM, SATA

577974-001 Hard drive, 320-GB, 7200-RPM, SATA

578237-001 HD Enhanced Video Accelerator (graphics decoder)

578361-001 Rubber kit (contains 2 front and 2 rear rubber device feet)

578362-001 Screw kit

578364-001 Keyboard, 25.7-cm (10.1-in) for use in the United States

578364-031 Keyboard, 25.7-cm (10.1-in) for use in the United Kingdom

578364-041 Keyboard, 25.7-cm (10.1-in) for use in Germany

578364-051 Keyboard, 25.7-cm (10.1-in) for use in France

578364-061 Keyboard, 25.7-cm (10.1-in) for use in Italy

578364-071 Keyboard, 25.7-cm (10.1-in) for use in Spain

578364-081 Keyboard, 25.7-cm (10.1-in) for use in Denmark

578364-091 Keyboard, 25.7-cm (10.1-in) for use in Norway

578364-121 Keyboard, 25.7-cm (10.1-in) for use in French Canada

578364-131 Keyboard, 25.7-cm (10.1-in) for use in Portugal

578364-141 Keyboard, 25.7-cm (10.1-in) for use in Turkey

578364-161 Keyboard, 25.7-cm (10.1-in) for use in Latin America

578364-171 Keyboard, 25.7-cm (10.1-in) for use in Saudi Arabia

578364-201 Keyboard, 25.7-cm (10.1-in) for use in Brazil

Sequential part number listing 27

Spare part number Description

578364-211 Keyboard, 25.7-cm (10.1-in) for use in Hungary

578364-221 Keyboard, 25.7-cm (10.1-in) for use in the Czech Republic

578364-231 Keyboard, 25.7-cm (10.1-in) for use in Slovakia

578364-251 Keyboard, 25.7-cm (10.1-in) for use in Russia

578364-261 Keyboard, 25.7-cm (10.1-in) for use in Bulgaria

578364-281 Keyboard, 25.7-cm (10.1=in) for use in Thailand

578364-291 Keyboard, 25.7-cm (10.1-in) for use in Japan

578364-A41 Keyboard, 25.7-cm (10.1-in) for use in Belgium

578361–A81 Keyboard, 25.7-cm (10.1-in) for use in Czechoslovakia, and Slovakia

578364-AB1 Keyboard, 25.7-cm (10.1-in) for use in Taiwan

578364-AD1 Keyboard, 25.7-cm (10.1-in) for use in South Korea

578364-B31 Keyboard, 25.7-cm (10.1-in) for use in Europe

578364-B71 Keyboard, 25.7-cm (10.1-in) for use in Finland, and Sweden

578364-BA1 Keyboard, 25.7-cm (10.1-in) for use in Slovenia

578364-BB1 Keyboard, 25.7-cm (10.1-in) for use in Israel

578364-BG1 Keyboard, 25.7-cm (10.1-in) for use in Switzerland

578364-DD1 Keyboard, 25.7-cm (10.1-in) for use in Iceland

578364-DJ1 Keyboard, 25.7-cm (10.1 in) for use in Greece

579026-001 Battery, 4-cell Li-ion (29-Wh) 2.0-Ah

583004-001 Solid state drive (SSD), 80-GB, SATA

593641-001 Hard drive, 160-GB, 7200-RPM, for use with WWAN option

593642-001 Hard drive, 250-GB, 7200-RPM, for use with WWAN option

593643-001 Hard drive, 320-GB, 7200-RPM, for use with WWAN option

593836–001 WLAN module, Broadcom 4313AGN 802.11a/b/g/draft-n WiFi Adapter

598451-001 Power button board with cable

598452-001 Fan and heat sink assembly with replacement thermal material

598458-001 Display back cover with logo for use with touch screen, red

598459-001 Display back cover with logo for use with touch screen, blue

598460-001 Display bezel for use with touch screen with webcam

598461-001 Top cover with TouchPad, red

598462-001 Top cover with TouchPad, blue

600370-001 WLAN module, Broadcom 4313 802.11b/g/n 1x1 WiFi and 2070 Bluetooth 2.1+EDR Combo

Adapter

605743-001 Plastics kit with Bluetooth cable

606201-001 Display back cover with logo for use with non-touch screen, red

28 Chapter 3 Illustrated parts catalog

Spare part number Description

606384-001 Optional carrying handle

606970-001 Display back cover with logo for use with non-touch screen, blue

606971-001 Solid state drive (SSD), 128-GB, SATA

607111-001 Base enclosure (includes 2 front and 2 rear device feet)

607177-001 Display panel assembly, 25.7-cm (10.1-in), WSVGA, AntiGlare, touch-screen display for use with

webcam and WWAN option, red

607178-001 Display panel assembly, 25.7-cm (10.1-in), high-definition, AntiGlare, touch-screen display for use

with webcam and WWAN option, red

607179-001 Display panel assembly, 25.7-cm (10.1-in), WSVGA, AntiGlare, touch-screen display for use with

webcam and WWAN option, blue

607180-001 Display panel assembly, 25.7-cm (10.1-in), high-definition, AntiGlare, touch-screen display for use

with webcam and WWAN option, blue

607181-001 Display panel assembly, 25.7-cm (10.1-in), WSVGA, AntiGlare display assembly for use with

webcam and WWAN option, red

607182-001 Display panel assembly, 25.7-cm (10.1-in), high-definition, AntiGlare display assembly for use with

webcam and WWAN option, red

607183-001 Display panel assembly, 25.7-cm (10.1-in), WSVGA, AntiGlare display assembly for use with

webcam and WWAN option, blue

607184-001 Display panel assembly, 25.7-cm (10.1-in), high-definition, AntiGlare display assembly for use with

webcam and WWAN option, blue

613151–001 40-W, 3-pin, Smart AC adapter for use in all countries and regions

617081–001 LCD with touch glass for use with WSVGA display assembly

617082–001 LCD with touch glass for use with high definition display assembly

621563–001 Memory module, PC2-6400, shared, 1-GB

621567–001 Memory module, PC2-6400, shared, 2-GB

624216–001 25.7-cm (10.1-in) LCD panel with touch glass for use with high definition display assembly

624218–001 25.7-cm (10.1-in) LCD panel with touch glass for use with WSVGA display assembly

625687–001 System board (including replacement thermal material and RTC battery), Intel Atom N455 1.66-

GHz processor, 512-KB Level 2 cache, 667-MHz front-side bus (FSB)

625688–001 System board (including replacement thermal material and RTC battery), Intel Atom N475 1.83-

GHz processor, 512-KB Level 2 cache, 667-MHz front-side bus (FSB)

625689–001 System board (including replacement thermal material and RTC battery), Intel Atom N550 1.50-

GHz processor, 512-KB Level 2 cache, 667-MHz front-side bus (FSB)

625724–001 Display back cover with logo for use with touch screen, espresso

625725–001 Display back cover with logo for use with non-touch screen, espresso

625726–001 Top cover with TouchPad, espresso

625727–001 Display panel assembly, 25.7-cm (10.1-in), WSVGA, AntiGlare, touch-screen display for use with

webcam and WWAN option, espresso

625728–001 Display panel assembly, 25.7-cm (10.1-in), high-definition, AntiGlare, touch-screen display for use

with webcam and WWAN option, espresso

Sequential part number listing 29

Spare part number Description

625729–001 Display panel assembly, 25.7-cm (10.1-in), WSVGA, AntiGlare display assembly for use with

webcam and WWAN option, espresso

625730–001 Display panel assembly, 25.7-cm (10.1-in), high-definition, AntiGlare display assembly for use with

webcam and WWAN option, espresso

626582–001 System board (including replacement thermal material and RTC battery), Intel Atom N455 1.66-

GHz processor, 512-KB Level 2 cache, 667-MHz front-side bus (FSB) for use in the People's
Republic of China and Russia

626583–001 System board (including replacement thermal material and RTC battery), Intel Atom N475 1.83-

GHz processor, 512-KB Level 2 cache, 667-MHz front-side bus (FSB) for use in the People's
Republic of China and Russia

626584–001 System board (including replacement thermal material and RTC battery), Intel Atom N550 1.50-

GHz processor, 512-KB Level 2 cache, 667-MHz front-side bus (FSB) for use in the People's
Republic of China and Russia

627790–001 Dual-core fan and heat sink assembly with replacement thermal material

627791–001 HD Video Decoder

627792–001 Dual-core top cover with TouchPad, espresso

30 Chapter 3 Illustrated parts catalog

4 Removal and replacement procedures

Preliminary replacement requirements

Tools required

You will need the following tools to complete the removal and replacement procedures:

Flat-bladed screwdriver

●

Magnetic screwdriver

●

Phillips P0 and P1 screwdrivers

●

Service considerations

The following sections include some of the considerations that you must keep in mind during
disassembly and assembly procedures.

NOTE: As you remove each subassembly from the device, place the subassembly (and all

accompanying screws) away from the work area to prevent damage.

Plastic parts

CAUTION: Using excessive force during disassembly and reassembly can damage plastic parts.

Use care when handling the plastic parts. Apply pressure only at the points designated in the
maintenance instructions.

Cables and connectors

CAUTION: When servicing the device, be sure that cables are placed in their proper locations

during the reassembly process. Improper cable placement can damage the device.

Cables must be handled with extreme care to avoid damage. Apply only the tension required to
unseat or seat the cables during removal and insertion. Handle cables by the connector whenever
possible. In all cases, avoid bending, twisting, or tearing cables. Be sure that cables are routed in
such a way that they cannot be caught or snagged by parts being removed or replaced. Handle flex
cables with extreme care; these cables tear easily.

Preliminary replacement requirements 31

Drive handling

CAUTION: Drives are fragile components that must be handled with care. To prevent damage to

the device, damage to a drive, or loss of information, observe these precautions:

Before removing or inserting a hard drive, shut down the device. If you are unsure whether the device
is off or in Hibernation, turn the device on, and then shut it down through the operating system.

Before handling a drive, be sure that you are discharged of static electricity. While handling a drive,
avoid touching the connector.

Handle drives on surfaces covered with at least one inch of shock-proof foam.

Avoid dropping drives from any height onto any surface.

After removing a hard drive, an optical drive, or a diskette drive, place it in a static-proof bag.

Avoid exposing a hard drive to products that have magnetic fields, such as monitors or speakers.

Avoid exposing a drive to temperature extremes or liquids.

If a drive must be mailed, place the drive in a bubble pack mailer or other suitable form of protective
packaging and label the package “FRAGILE.”

32 Chapter 4 Removal and replacement procedures

Grounding guidelines

Electrostatic discharge damage

Electronic components are sensitive to electrostatic discharge (ESD). Circuitry design and structure
determine the degree of sensitivity. Networks built into many integrated circuits provide some
protection, but in many cases, ESD contains enough power to alter device parameters or melt
silicon junctions.

A discharge of static electricity from a finger or other conductor can destroy static-sensitive devices or
microcircuitry. Even if the spark is neither felt nor heard, damage may have occurred.

An electronic device exposed to ESD may not be affected at all and can work perfectly throughout a
normal cycle. Or the device may function normally for a while, then degrade in the internal layers,
reducing its life expectancy.

CAUTION: To prevent damage to the device when you are removing or installing internal

components, observe these precautions:

Keep components in their electrostatic-safe containers until you are ready to install them.

Use nonmagnetic tools.

Before touching an electronic component, discharge static electricity by using the guidelines
described in this section.

Avoid touching pins, leads, and circuitry. Handle electronic components as little as possible.

If you remove a component, place it in an electrostatic-safe container.

The following table shows how humidity affects the electrostatic voltage levels generated by different
activities.

CAUTION: A product can be degraded by as little as 700 V.

Typical electrostatic voltage levels

Relative humidity

Event 10% 40% 55%

Walking across carpet 35,000 V 15,000 V 7,500 V

Walking across vinyl floor 12,000 V 5,000 V 3,000 V

Motions of bench worker 6,000 V 800 V 400 V

Removing DIPS from plastic tube 2,000 V 700 V 400 V

Removing DIPS from vinyl tray 11,500 V 4,000 V 2,000 V

Removing DIPS from Styrofoam 14,500 V 5,000 V 3,500 V

Removing bubble pack from PCB 26,500 V 20,000 V 7,000 V

Packing PCBs in foam-lined box 21,000 V 11,000 V 5,000 V

Preliminary replacement requirements 33

Packaging and transporting guidelines

Follow these grounding guidelines when packaging and transporting equipment:

To avoid hand contact, transport products in static-safe tubes, bags, or boxes.

●

Protect ESD-sensitive parts and assemblies with conductive or approved containers or

●

packaging.

Keep ESD-sensitive parts in their containers until the parts arrive at static-free workstations.

●

Place items on a grounded surface before removing items from their containers.

●

Always be properly grounded when touching a component or assembly.

●

Store reusable ESD-sensitive parts from assemblies in protective packaging or nonconductive

●

foam.

Use transporters and conveyors made of antistatic belts and roller bushings. Be sure that

●

mechanized equipment used for moving materials is wired to ground and that proper materials
are selected to avoid static charging. When grounding is not possible, use an ionizer to dissipate
electric charges.

Workstation guidelines

Follow these grounding workstation guidelines:

Cover the workstation with approved static-shielding material.

●

Use a wrist strap connected to a properly grounded work surface and use properly grounded

●

tools and equipment.

Use conductive field service tools, such as cutters, screwdrivers, and vacuums.

●

When fixtures must directly contact dissipative surfaces, use fixtures made only of static-safe

●

materials.

Keep the work area free of nonconductive materials, such as ordinary plastic assembly aids and

●

Styrofoam.

Handle ESD-sensitive components, parts, and assemblies by the case or PCM laminate. Handle

●

these items only at static-free workstations.

Avoid contact with pins, leads, or circuitry.

●

Turn off power and input signals before inserting or removing connectors or test equipment.

●

34 Chapter 4 Removal and replacement procedures

Equipment guidelines

Grounding equipment must include either a wrist strap or a foot strap at a grounded workstation.

When seated, wear a wrist strap connected to a grounded system. Wrist straps are flexible

●

straps with a minimum of one megohm ±10% resistance in the ground cords. To provide proper
ground, wear a strap snugly against the skin at all times. On grounded mats with banana-plug
connectors, use alligator clips to connect a wrist strap.

When standing, use foot straps and a grounded floor mat. Foot straps (heel, toe, or boot straps)

●

can be used at standing workstations and are compatible with most types of shoes or boots. On
conductive floors or dissipative floor mats, use foot straps on both feet with a minimum of one
megohm resistance between the operator and ground. To be effective, the conductive strips
must be worn in contact with the skin.

The following grounding equipment is recommended to prevent electrostatic damage:

Antistatic tape

●

Antistatic smocks, aprons, and sleeve protectors

●

Conductive bins and other assembly or soldering aids

●

Nonconductive foam

●

Conductive tabletop workstations with ground cords of one megohm resistance

●

Static-dissipative tables or floor mats with hard ties to the ground

●

Field service kits

●

Static awareness labels

●

Material-handling packages

●

Nonconductive plastic bags, tubes, or boxes

●

Metal tote boxes

●

Electrostatic voltage levels and protective materials

●

The following table lists the shielding protection provided by antistatic bags and floor mats.

Material Use Voltage protection level

Antistatic plastic Bags 1,500 V

Carbon-loaded plastic Floor mats 7,500 V

Metallized laminate Floor mats 5,000 V

Preliminary replacement requirements 35

Component replacement procedures

This chapter provides removal and replacement procedures.

There are as many as 65 screws, in 9 different sizes, that must be removed, replaced, or loosened
when servicing the device. Make special note of each screw size and location during removal and
replacement.

Service tag

When ordering parts or requesting information, provide the computer serial number and model
description provided on the service tag located on the bottom of the computer.

(1) Product name: This is the product name affixed to the front of the device.

(2) Product number: This number provides specific information about the product's hardware

components. The part number helps a service technician to determine what components and parts
are needed.

(3) Serial number: This is an alphanumeric identifier that is unique to each product.

(4) Warranty period: This number describes the duration of the warranty period for the device.

(5) Model description (select models): This is the alphanumeric identifier used to locate documents,

drivers, and support for the device.

36 Chapter 4 Removal and replacement procedures

Device feet

The device feet are adhesive-backed rubber pads. The rear feet are attached and the front feet are
tethered to the bottom of the base enclosure.

NOTE: The front and rear device feet are not interchangeable. Due to the adhesive nature of the

rubber pads, they should be replaced after removal.

NOTE: The rear device feet may not be applied on models that use the optional carrying handle

(see

Description Spare part number

Rubber kit (contains 4 rubber device feet – 2 front and 2 rear) 578361-001

Carrying handle on page 14).

Component replacement procedures 37

Battery

Description Spare part number

6 cell Li-ion (66 Wh) 3.0 Ah 535629-001

4-cell Li-ion (29-Wh) 2.0-Ah 579026-001

Before removing the battery:

1. Shut down the device. If you are unsure whether the device is off or in Hibernation, turn the

device on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the device.

3. Disconnect the power from the device by first disconnecting the power cord from the AC outlet

and then disconnecting the AC adapter from the device.

Remove the battery:

1. Turn the device upside down on a flat surface with the battery bay toward you.

2. Slide the battery release latches (1) to release the battery.

3. Remove the battery (2).

Reverse this procedure to install a battery.

38 Chapter 4 Removal and replacement procedures

SIM

NOTE: This section applies only to device models with WWAN capability.

NOTE: If there is a SIM inserted in the SIM slot, it must be removed before disassembling the

computer. Be sure that the SIM is reinserted in the SIM slot after reassembling the computer.

Before removing the SIM:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn

the computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first disconnecting the power cord from the AC

outlet and then disconnecting the AC adapter from the computer.

4. Remove the battery (see

Remove the SIM:

1. Press in on the SIM (1). (The module is partially ejected from the SIM slot.)

2. Remove the SIM (2) from the SIM slot.

Battery on page 38).

Reverse this procedure to insert the SIM.

Component replacement procedures 39

Memory module

Description Spare part number

Memory module, PC2-6400, shared, 1-GB

NOTE: Not supported by computers with Windows 7 Home Basic or with Windows 7 Starter in

select countries and regions.

Memory module, PC2-6400, shared, 2-MB 621567-001

621563-001

Before removing the memory module:

1. Shut down the device. If you are unsure whether the device is off or in Hibernation, turn the

device on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the device.

3. Disconnect the power from the device by first disconnecting the power cord from the AC outlet

and then disconnecting the AC adapter from the device.

4. Remove the battery (see

5. If your device has WWAN capability, remove the SIM (see

Battery on page 38).

SIM on page 39).

Remove the memory module:

1. With the battery removed, slide the battery release latch in front of the memory module

compartment (1) to release the memory module cover from the computer.

2. Swing the cover up and away from the outside of the computer to remove the cover (2).

3. Spread the retaining tabs (1) on each side of the memory module slot to release the memory

module. (The module tilts up.)

40 Chapter 4 Removal and replacement procedures

4. Remove the memory module (2) by pulling the module away from the slot at an angle.

NOTE: Memory modules are designed with a notch (3) to prevent incorrect insertion into the

memory module slot.

Reverse this procedure to install a memory module.

Carrying Handle (select models only)

Description Spare part number

Carrying handle (select models only) 606384-001

Before removing the memory module:

1. Shut down the device. If you are unsure whether the device is off or in Hibernation, turn the

device on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the device.

3. Disconnect the power from the device by first disconnecting the power cord from the AC outlet

and then disconnecting the AC adapter from the device.

4. Remove the battery (see

5. If your device has WWAN capability, remove the SIM (see

Battery on page 38).

SIM on page 39).

Remove the memory module:

1. Remove the mylar screw coverings (1) and remove the two screws that secure the carrying

handle to the device (2).

Component replacement procedures 41

2. Lift up (3) and remove the carrying handle from the device.

Reverse this procedure to install a carrying handle.

42 Chapter 4 Removal and replacement procedures

Keyboard

Description Spare part number

For use in Belgium 578364-A41

For use in Brazil 578364-201

For use in Bulgaria 578364-261

For use in the Czech Republic 578364-221

For use in Czechoslovakia, and Slovakia 578364–A81

For use in Denmark 578364-081

For use in Europe 578364-B31

For use in France 578364-051

For use in French Canada 578364-121

For use in Finland, and Sweden 578364-B71

For use only in Germany 578364-041

For use in Greece 578364-DJ1

For use in Hungary 578364-211

For use in Iceland 578364-DD1

For use in Israel 578364-BB1

For use in Italy 578364-061

For use in Japan 578364-291

For use in Latin America 578364-161

For use in Norway 578364-091

For use in Portugal 578364-131

For use in Russia 578364-251

For use in Saudi Arabia 578364-171

For use in Slovakia 578364-231

For use in Slovenia 578364-BA1

For use in South Korea 578364-AD1

For use in Spain 578364-071

For use in Switzerland 578364-BG1

For use in Taiwan 578364-AB1

For use in Thailand 578364-281

For use in Turkey 578364-141

For use in the United Kingdom 578364-031

For use only in the United States 578364-001

Component replacement procedures 43

Before removing the keyboard:

1. Shut down the device. If you are unsure whether the device is off or in Hibernation, turn the

device on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the device.

3. Disconnect the power from the device by first disconnecting the power cord from the AC outlet

and then disconnecting the AC adapter from the device.

4. Remove the battery (see

5. If your device has WWAN capability, remove the SIM (see

Battery on page 38).

SIM on page 39).

Remove the keyboard:

1. Remove the 3 Phillips PM2.0×3.0 screws that secure the keyboard to the device.

2. Open the display 90 degrees.

3. Use a tool to push the screw tabs directly down to release the rear edge of the keyboard.

44 Chapter 4 Removal and replacement procedures

4. Turn the device right-side up, and release the retention tab (1) on the left side of the keyboard

(2).

Component replacement procedures 45

5. Release the retention tab (1) on the right side of the keyboard (2).

46 Chapter 4 Removal and replacement procedures

6. Use your right hand to lift up (1) and remove the retention tab from the right side of the top cover

(2).

7. Use your right hand to lift up (1) and remove the retention tab from the middle of the top cover

(2).

Component replacement procedures 47

8. Use your left hand to lift up (1) and remove the retention tab from the left side of the top cover

(2)..

9. Swing the keyboard forward (1), and slide the keyboard back until its top edge rests on the

display assembly (2).

NOTE: You can also rest the keyboard upside down on the palm rest to access the keyboard

cable.

10. Release the zero insertion force (ZIF) connector (1) to which the keyboard cable is attached.

48 Chapter 4 Removal and replacement procedures

11. Disconnect the cable (2).

12. Remove the keyboard.

Reverse this procedure to install the keyboard.

Component replacement procedures 49

Mass storage devices

NOTE: Each hard drive spare part kit and solid state drive spare part kit includes a bracket and

screws.

Description Spare part number

Hard drive, 320-GB, 7200-RPM, for use with WWAN option 593643-001

Hard drive, 320-GB, 7200-RPM, SATA 577974-001

Hard drive, 250-GB, 7200-RPM, for use with WWAN option 593642-001

Hard drive, 250-GB, 7200-RPM, SATA 538972-001

Hard drive, 160-GB, 7200-RPM, for use with WWAN option 593641-001

Hard drive, 160-GB, 7200-RPM, SATA 577972-001

Solid state drive, 128-GB, SATA 606971-001

Solid state drive, 80-GB, SATA 583004-001

Before removing the hard drive or solid state drive:

1. Shut down the device. If you are unsure whether the device is off or in Hibernation, turn the

device on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the device.

3. Disconnect the power from the device by first disconnecting the power cord from the AC outlet

and then disconnecting the AC adapter from the device.

4. Remove the battery (see

5. If your device has WWAN capability, remove the SIM (see

6. Remove the keyboard (see

Battery on page 38).

SIM on page 39).

Keyboard on page 43).

To remove the hard drive or the solid state drive:

1. Loosen the Phillips PM2.5×10.0 captive screw (1), and remove the 2 Phillips PM2.0×3.0

screws (2) that secure the drive assembly to the base enclosure.

50 Chapter 4 Removal and replacement procedures

2. Use the Mylar tab to slide the assembly to the right (3) to disconnect it, and remove the

assembly (4).

3. Remove the mounting bracket.

On a hard drive:

a. Remove the 4 Phillips PM3.0×3.0 screws (1) that secure the hard drive bracket to the hard

drive.

b. Using the Mylar tab, lift the bracket (2) away from the hard drive.

– or –

On a solid state drive:

a. Remove the 4 Phillips PM2.0×3.0 screws (1) that secure the solid-state drive bracket to the

solid state drive.

b. Lift the solid-state drive module (2) to remove it.

Component replacement procedures 51

Reverse this procedure to install a hard drive or solid state drive.

52 Chapter 4 Removal and replacement procedures

WLAN module

Description Spare part number

Broadcom 43224 802.11a/b/g/n 2x2 WiFi Adapter

For use in Antigua and Barbuda, Barbados, Belize, Canada, the Cayman Islands, Guam,

●

Puerto Rico, Trinidad and Tobago, the U.S. Virgin Islands, and the United States

For use in Afghanistan, Albania, Algeria, Andorra, Angola, Argentina, Armenia, Aruba,

●

Australia, Austria, Azerbaijan, the Bahamas, Bahrain, Bangladesh, Barbados, Belarus,
Belgium, Belize, Benin, Bermuda, Bhutan, Bolivia, Bosnia and Herzegovina, Botswana, Brazil,
the British Virgin Islands, Brunei, Bulgaria, Burkina Faso, Burundi, Cambodia, Cameroon,
Cape Verde, the Central African Republic, Chad, Chile, Colombia, Comoros, the Congo,
Costa Rica, Croatia, Cyprus, the Czech Republic, Denmark, Djibouti, Dominica, the Dominican
Republic, East Timor, Ecuador, Egypt, El Salvador, Equatorial Guinea, Eritrea, Estonia,
Ethiopia, Fiji, Finland, France, French Guiana, Gabon, Gambia, Georgia, Germany, Ghana,
Gibraltar, Greece, Grenada, Guadeloupe, Guatemala, Guinea, Guinea-Bissau, Guyana, Haiti,
Honduras, Hong Kong, Hungary, Iceland, India, Indonesia, Ireland, Italy, the Ivory Coast,
Jamaica, Japan, Jordan, Kazakhstan, Kenya, Kiribati, Kuwait, Kyrgyzstan, Laos, Latvia,
Lebanon, Lesotho, Liberia, Liechtenstein, Lithuania, Luxembourg, Macedonia, Madagascar,
Malawi, Malaysia, the Maldives, Mali, Malta, the Marshall Islands, Martinique, Mauritania,
Mauritius, Mexico, Micronesia, Monaco, Mongolia, Montenegro, Morocco, Mozambique,
Namibia, Nauru, Nepal, the Nether Antilles, the Netherlands, New Zealand, Nicaragua, Niger,
Nigeria, Norway, Oman, Pakistan, Palau, Panama, Papua New Guinea, Paraguay, the
People’s Republic of China, Peru, the Philippines, Poland, Portugal, Qatar, the Republic of
Moldova, Romania, Russia, Rwanda, Samoa, San Marino, Sao Tome and Principe, Saudi
Arabia, Senegal, Serbia, the Seychelles, Sierra Leone, Singapore, Slovakia, Slovenia, the
Solomon Islands, Somalia, South Africa, South Korea, Spain, Sri Lanka, St. Kitts and Nevis,
St. Lucia, St. Vincent, Suriname, Swaziland, Sweden, Switzerland, Taiwan, Tajikistan,
Tanzania, Thailand, Togo, Tonga, Tunisia, Turkey, Turkmenistan, Tuvalu, Uganda, Ukraine,
the United Arab Emirates, the United Kingdom, Uruguay, Uzbekistan, Vanuatu, Venezuela,
Vietnam, Yemen, Zaire, Zambia, and Zimbabwe

Broadcom 4313AGN 802.11a/b/g/draft-n WiFi Adapter 593836-003

●

518434-001

518434-002

Broadcom 4313 802.11b/g/n 1x1 WiFi and 2070 Bluetooth 2.1+EDR Combo Adapter 600370-004

●

CAUTION: The WWAN module and the WLAN module are not interchangeable.

To prevent an unresponsive system, replace the wireless module only with a wireless module
authorized for use in the device by the governmental agency that regulates wireless devices in your
country or region. If you replace the module and then receive a warning message, remove the
module to restore device functionality, and then contact technical support through Help and Support.

Before removing the WLAN module:

1. Shut down the device. If you are unsure whether the device is off or in Hibernation, turn the

device on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the device.

3. Disconnect the power from the device by first disconnecting the power cord from the AC outlet

and then disconnecting the AC adapter from the device.

4. Remove the battery (see

Battery on page 38).

Component replacement procedures 53

5. If your device has WWAN capability, remove the SIM (see SIM on page 39).

6. Remove the following components:

a. Keyboard (see

b. Hard drive or solid state drive (see

Keyboard on page 43)

Mass storage devices on page 50)

Remove the WLAN module:

1. Pull back the Mylar shield (1) from WLAN module.

2. Disconnect the wireless antenna cables (2) from the terminals on the WLAN module.

3. Remove the 2 Phillips PM2.0×3.0 screws (3) that secure the WLAN module to the system board.

(The module tilts up.)

4. Remove the WLAN module (4) by pulling the module away from the slot at an angle.

NOTE: WLAN modules are designed with a notch (5) to prevent incorrect insertion into the

WLAN module slot.

Reverse this procedure to install the WLAN module.

54 Chapter 4 Removal and replacement procedures

SIM module

Description Spare part number

SIM module board (includes cable) 577923-001

Before removing the SIM module:

1. Shut down the device. If you are unsure whether the device is off or in Hibernation, turn the

device on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the device.

3. Disconnect the power from the device by first disconnecting the power cord from the AC outlet

and then disconnecting the AC adapter from the device.

4. Remove the battery (see

5. Remove the SIM (see

6. Remove the keyboard (see

7. Remove the hard drive or solid state drive (see

Battery on page 38).

SIM on page 39).

Keyboard on page 43).

Mass storage devices on page 50).

Remove the SIM module:

Disconnect the LIF cable (1) from the computer, and remove the SIM module (2).

▲

Reverse this procedure to install the SIM module.

Component replacement procedures 55

Top cover

Description Spare part number

Top cover with TouchPad, black 577926-001

Top cover with TouchPad, red 598461-001

Top cover with TouchPad, blue 598462-001

Dual-core top cover with Touchpad, espresso 625726–001

Before removing the top cover:

1. Shut down the device. If you are unsure whether the device is off or in Hibernation, turn the

2. Disconnect all external devices connected to the device.

3. Disconnect the power from the device by first disconnecting the power cord from the AC outlet

device on, and then shut it down through the operating system.

and then disconnecting the AC adapter from the device.

4. Remove the battery (see

Battery on page 38).

5. If your device has WWAN capability, remove the SIM (see

6. Remove the memory module (see

7. Remove the keyboard (see

Keyboard on page 43).

8. Remove the hard drive or solid state drive (see

9. Remove the WLAN module (see

Memory module on page 40).

Mass storage devices on page 50).

WLAN module on page 53)

Remove the top cover:

1. Turn the device upside down, with the front toward you.

2. Use a thin, flat tool to release the 4 rubber device feet.

SIM on page 39).

56 Chapter 4 Removal and replacement procedures

3. Remove the 4 Torx T8 2.5×5.0 screws (1), and the 4 Phillips PM2.0×3.0 screws (2) that secure

the top cover to the base enclosure.

4. Turn the device right-side up, with the front toward you.

5. Open the device as far as possible.

6. Release the ZIF connector (1) that connects the button board cable to the system board.

NOTE: If not done when removing the WLAN module on page 53, release any WLAN cable

routed along the top cover.

7. Remove the following screws that secure the top cover to the base enclosure:

(2) - 5 Phillips PM2.0×6.0

●

(3) - 1 Phillips PM2.0×2.5

●

8. Release the clips along the front edge of the top cover and open the front of the top cover (1)

enough to see the TouchPad and speaker cables.

Component replacement procedures 57

9. Lift the back edge of the top cover up and forward (2) to release the clips along the rear edge of

the top cover.

10. Release the ZIF connector (1) for the TouchPad button board cable, and disconnect the cable

(2) from the system board.

11. Disconnect the speaker cable (3) from the system board, and then remove the top cover.

Reverse this procedure to install the top cover.

58 Chapter 4 Removal and replacement procedures

Speaker

Before removing the speaker assembly:

1. Shut down the device. If you are unsure whether the device is off or in Hibernation, turn the

2. Disconnect all external devices connected to the device.

3. Disconnect the power from the device by first disconnecting the power cord from the AC outlet

Description Spare part number

Speaker assembly with cable 577967-001

device on, and then shut it down through the operating system.

and then disconnecting the AC adapter from the device.

4. Remove the battery (see

5. If your device has WWAN capability, remove the SIM (see

6. Remove the memory module (see

7. Remove the keyboard (see

8. Remove the hard drive (see

9. Remove the top cover (see

Battery on page 38).

SIM on page 39).

Memory module on page 40).

Keyboard on page 43).

Mass storage devices on page 50).

Top cover on page 56).

Remove the speaker assembly:

1. Turn the top cover upside down, with the front toward you.

2. Remove the 2 Phillips PM2.0×3.0 screws (1) that secure the assembly to the top cover, and

remove the speaker assembly (2) from the top cover.

NOTE: If seated tight, work the speaker back and forth to release the speaker from the

speaker alignment pins (3).

Reverse this procedure to install the speaker assembly.

Component replacement procedures 59

WWAN module

Description Spare part number

WWAN module, Qualcomm EV-DO HSPA (includes mounting bracket)

NOTE: Not supported by computers with Linux installed.

NOTE: Not supported by computers with the HD Enhanced Video Accelerator installed.

531993-001

CAUTION: The WWAN module and the WLAN module are not interchangeable.

To prevent an unresponsive system, replace the wireless module only with a wireless module
authorized for use in the device by the governmental agency that regulates wireless devices in your
country or region. If you replace the module and then receive a warning message, remove the
module to restore device functionality, and then contact technical support.

Before removing the WWAN module:

1. Shut down the device. If you are unsure whether the device is off or in Hibernation, turn the

device on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the device.

3. Disconnect the power from the device by first disconnecting the power cord from the AC outlet

and then disconnecting the AC adapter from the device.

4. Remove the battery (see

5. Remove the SIM (see

Battery on page 38).

SIM on page 39).

6. Remove the following components:

a. Keyboard (see

b. Hard drive (see

c. Top cover (see

Keyboard on page 43)

Mass storage devices on page 50)

Top cover on page 56)

Remove the WWAN module:

1. Disconnect the wireless antenna cables (1) from the terminals on the WWAN module.

NOTE: The red WWAN antenna cable is connected to the WWAN module “Main” terminal. The

blue WWAN antenna cable is connected to the WWAN module “Aux” terminal.

2. Remove the 2 Phillips PM2.0×4.0 screws (2) that secure the WWAN module (3) to the base

enclosure and mounting bracket. (The module tilts up.)

60 Chapter 4 Removal and replacement procedures

3. Remove the WWAN module (3) by pulling the module away from the mini-card slot at an angle.

NOTE: The mounting bracket on the right side of the WWAN module is only used with the

WWAN module mini-card and secures to the base enclosure with a PM 2.0×2.0 screw.

Reverse this procedure to install the WWAN module.

Component replacement procedures 61

RTC battery

Description Spare part number

RTC battery 507707-001

Before removing the real-time clock (RTC) battery:

1. Shut down the device. If you are unsure whether the device is off or in Hibernation, turn the

device on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the device.

3. Disconnect the power from the device by first disconnecting the power cord from the AC outlet

and then disconnecting the AC adapter from the device.

4. Remove the battery (see

5. If your device has WWAN capability, remove the SIM (see

6. Remove the Keyboard (see

7. Remove the Hard drive (see

8. Remove the Top cover (see

Battery on page 38).

SIM on page 39).

Keyboard on page 43).

Mass storage devices on page 50).

Top cover on page 56).

Remove the RTC battery:

1. Disconnect the RTC battery cable (1) from the system board.

2. Detach the RTC battery (2) from the system board.

NOTE: The RTC battery is attached to the system board with double-sided tape.

Reverse this procedure to install the RTC battery.

62 Chapter 4 Removal and replacement procedures

Bluetooth module

Description Spare part number

Bluetooth module 537921-001

Before removing the Bluetooth module:

1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn

the computer on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the computer.

3. Disconnect the power from the computer by first disconnecting the power cord from the AC

outlet and then disconnecting the AC Adapter from the computer.

4. Remove the battery (see

5. If your device has WWAN capability, remove the SIM (see

Battery on page 38).

SIM on page 39).

6. Remove the following components:

a. Keyboard (see

b. Hard drive (see

c. Top cover (see

Keyboard on page 43)

Mass storage devices on page 50)

Top cover on page 56)

Remove the Bluetooth module:

1. Disconnect the Bluetooth module cable (1).

2. Release the Bluetooth module from the adhesive pad to which it is affixed (2), and remove the

Bluetooth module.

Reverse this procedure to install the Bluetooth module.

Component replacement procedures 63

Power button board

Description Spare part number

Power button board with cable 598451-001

Before removing the power button board:

1. Shut down the device. If you are unsure whether the device is off or in Hibernation, turn the

device on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the device.

3. Disconnect the power from the device by first disconnecting the power cord from the AC outlet

and then disconnecting the AC adapter from the device.

4. Remove the battery (see

5. If your device has WWAN capability, remove the SIM (see

Battery on page 38).

SIM on page 39).

6. Remove the following components:

a. Keyboard (see

b. Hard drive (see

c. Top cover (see

Keyboard on page 43)

Mass storage devices on page 50)

Top cover on page 56)

Remove the power button board:

1. Disconnect the power button board cable (1).

2. Remove the 3 Phillips PM2.0×2.0×7.0 broad head screws (2) that secure the power button

board to the base enclosure.

3. Remove the power button board (3).

Reverse this procedure to install the power button board.

64 Chapter 4 Removal and replacement procedures

Display assembly

Description Spare part number

Display assembly (includes 1 webcam, 2 microphones, and 2 WLAN antenna with cables; WWAN antennas with cables on

select models)

25.7-cm (10.1-in), high-definition, AntiGlare, touch-screen display for use with

●

webcam and WWAN option, espresso

25.7-cm (10.1-in), high-definition, AntiGlare, touch-screen display for use with

●

webcam and WWAN option, red

25.7-cm (10.1-in), high-definition, AntiGlare, touch-screen display for use with

●

webcam and WWAN option, blue

25.7-cm (10.1-in), high-definition, AntiGlare, touch-screen display for use with

●

webcam, espresso

25.7-cm (10.1-in), high-definition, AntiGlare display assembly for use with

●

webcam and WWAN option, red

25.7-cm (10.1-in), high-definition, AntiGlare display assembly for use with

●

webcam and WWAN option, blue

25.7-cm (10.1-in), WSVGA, AntiGlare, touch-screen display for use with

●

webcam and WWAN option, espresso

25.7-cm (10.1-in), WSVGA, AntiGlare, touch-screen display for use with

●

webcam and WWAN option, red

25.7-cm (10.1-in), WSVGA, AntiGlare, touch-screen display for use with

●

webcam and WWAN option, blue

25.7-cm (10.1-in), WSVGA, AntiGlare display assembly for use with webcam

●

and WWAN option, espresso

25.7-cm (10.1-in), WSVGA, AntiGlare display assembly for use with webcam

●

and WWAN option, red

625728-001

607178-001

607180-001

625730-001

607182-001

607184-001

625727-001

607177-001

607179-001

625729-001

607181-001

25.7-cm (10.1-in), WSVGA, AntiGlare display assembly for use with webcam

●

and WWAN option, blue

Display bezel

For use with touch screen with webcam 598460-001

●

For use with non-touch screen with webcam 577929-001

●

Display hinge kit

(Includes left and right display panel hinges)

Touch screen LCD panel

For use with high-definition display assembly 624216-001

●

For use with WSVGA display assembly 624218-001

●

Webcam module 577927-001

Display panel/webcam cable for use in:

High-definition display assembly 577932-001

●

WSVGA display assembly 577931-001

●

High-definition display assembly w/ touchscreen 617082–001

●

607183-001

577930-001

Component replacement procedures 65

Description Spare part number

WSVGA display assembly w/ touchscreen 617081–001

●

Display cable kit includes the following cables: 577933-001

WLAN antennas (2) with cables

●

Dual microphone with cable

●

WWAN antennas (2) with cables on select models

●

Display back cover (includes logo)

For use with touch screen, espresso 625724-001

●

For use with touch screen, red 598458-001

●

For use with touch screen, blue 598459-001

●

For use with non-touch screen, espresso 625725-001

●

For use with non-touch screen, red 606201-001

●

For use with non-touch screen, blue 606970-001

●

Before removing the display assembly:

1. Shut down the device. If you are unsure whether the device is off or in Hibernation, turn the

device on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the device.

3. Disconnect the power from the device by first disconnecting the power cord from the AC outlet

and then disconnecting the AC adapter from the device.

4. Remove the battery (see

5. If your device has WWAN capability, remove the SIM (see

Battery on page 38).

SIM on page 39).

6. Remove the following components:

a. Keyboard (see

b. Hard drive (see

c. WLAN module (see

d. Top cover (see

Keyboard on page 43)

Mass storage devices on page 50)

WLAN module on page 53)

Top cover on page 56)

66 Chapter 4 Removal and replacement procedures

Remove the display assembly:

1. Disconnect the following cables and grounding tape from the system board and cable routing

clips:

(1) Display panel cable

(2) Display panel cable grounding tape

(3) WLAN cables

(4) WWAN cables (select models only)

(5) Microphone cable

CAUTION: Support the display assembly when removing the following screws. Failure to

support the display assembly can result in damage to the display assembly and other device
components.

2. Remove the 2 Phillips PM2.5×5.0 screws (1) that secure the display assembly to the device.

3. Remove the display assembly (2).

Component replacement procedures 67

4. To replace the display bezel:

a. Remove the 4 Mylar screw covers (1) from the corners of the display bezel, and then

remove the 4 2.5×3.0 screws (2) that secure the display bezel to the back cover.

b. Flex the inside edges of the left and right sides (1), and then the top and bottom (2) of the

display bezel until the bezel disengages from the display enclosure.

c. Remove the display bezel (3).

NOTE: Tabs on the hinge covers (4) lock to insets on the base enclosure.

5. To replace the webcam module:

a. Lift the webcam (1).

68 Chapter 4 Removal and replacement procedures

b. Disconnect the webcam cable (2) from the webcam.

c. Remove the webcam.

6. To replace the non-touch display panel:

a. Remove the 8 Phillips PM2.5×5.0 screws that secure the display panel to the display

enclosure.

b. Lift the bottom edge of the display panel up from the display back cover (1).

c. Disengage the display panel cable (2) from the left hinge clip.

d. Remove the display panel (3) from the display back cover.

Component replacement procedures 69

– or –

On touch-screen display assemblies:

a. Remove the 9 Phillips PM2.5×5.0 screws that secure the display panel to the display

enclosure.

b. Lift the top edge of the display panel up from the back cover (1).

c. Disengage the display panel cable (2) from the left hinge clip.

d. Disengage the touch-screen display board (3) from the snap hooks on the back cover.

CAUTION: Do not bend the cable when disengaging the touch-screen display board.

e. Release the touch-screen display board (4) from display back cover.

f. Remove the display panel from display back cover (5).

70 Chapter 4 Removal and replacement procedures

7. To replace the display panel/webcam cable:

a. Turn the display panel over, and peel back the Mylar shield (1) on the back of the display

panel.

b. Lift the adhesive strip (2) that secures the cable to the back of the display panel, and

disconnect the display panel/webcam cable (3).

Component replacement procedures 71

c. Release the display panel/webcam cable (1) from the adhesive points (2) along the cable

route on the back of the display panel.

d. Remove the display panel/wedcam cable.

8. To replace the display hinges:

a. Remove the 2 Phillips PM2.0×3.0 screws (1) that secure each hinge to the display panel.

b. Remove the hinges (2).

9. To replace the microphone receiver:

a. Release the microphone receiver from the clip (1) that secures it to the display enclosure.

72 Chapter 4 Removal and replacement procedures

b. Pull the receiver through the tabs (2), and remove the microphone receiver (3).

10. To replace the wireless antennas and cables:

a. Detach the WLAN antennas (1) and the WWAN antennas (2) from the adhesive on the

back cover, and then route the cables through the clips (3) that secure them to the display
back cover.

b. Remove the wireless antennas and cables.

Reverse this procedure to reassemble and install the display assembly.

Component replacement procedures 73

System board

Description Spare part number

System board (includes processor and replacement thermal material)

Includes Intel Atom N455 1.66-GHz processor, 512-KB Level 2 cache, 667-MHz front-side bus

●

(FSB)

Includes Intel Atom N475 1.83-GHz processor, 512-KB Level 2 cache, 667-MHz front-side bus

●

(FSB) for use in the People's Republic of China

Includes Intel Atom N550 1.50-GHz processor, 512-KB Level 2 cache, 667-MHz front-side bus

●

(FSB)

Includes Intel Atom N455 1.66-GHz processor, 512-KB Level 2 cache, 667-MHz front-side bus

●

(FSB) for use in the People's Republic of China and Russia

Includes Intel Atom N475 1.83-GHz processor, 512-KB Level 2 cache, 667-MHz front-side bus

●

(FSB) for use in the People's Republic of China and Russia

Includes Intel Atom N550 1.50-GHz processor, 512-KB Level 2 cache, 667-MHz front-side bus

●

(FSB) for use in the People's Republic of China and Russia

625687-001

625688-001

625689-001

626582-001

626583–001

626584–001

Before removing the system board:

1. Shut down the device. If you are unsure whether the device is off or in Hibernation, turn the

device on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the device.

3. Disconnect the power from the device by first disconnecting the power cord from the AC outlet

and then disconnecting the AC adapter from the device.

4. Remove the battery (see

5. If your device has WWAN capability, remove the SIM (see

Battery on page 38).

SIM on page 39).

6. Remove the following components:

a. Keyboard (see

b. Hard drive (see

c. Top cover (see

d. Display assembly (see

Keyboard on page 43)

Mass storage devices on page 50)

Top cover on page 56)

Display assembly on page 65)

When replacing the system board, be sure that the following components are removed from the
defective system board and installed on the replacement system board:

WLAN module (see

●

WWAN module, if included (see

●

Bluetooth module (see

●

WLAN module on page 53)

WWAN module on page 60)

Bluetooth module on page 63)

74 Chapter 4 Removal and replacement procedures

Remove the system board:

1. Remove the Phillips PM2.0×3.0 screw (1) that secures the bracket over the audio connectors to

the base enclosure, and then remove the bracket (2).

2. Remove the bracket that sec

3. On models with the WWAN option installed remove the Phillips PM2.0×2.0 screw (3) that

secures the WWAN bracket to the base enclosure, and then remove the WWAN bracket (4).

4. Grasp the system board at the midpoint of the board (1), and tilt it up to the left (2).

5. Remove the audio connector cover and pull the system board (3) out to the right at an angle to

remove the system board from the base enclosure.

Reverse the procedure to install the system board.

Component replacement procedures 75

Fan and heat sink assembly

Description Spare part number

Fan and heat sink assembly (includes replacement thermal material) 598452-001

Fan and heat sink assembly, for use with dual-core models (includes replacement thermal material) 627790–001

NOTE: To properly ventilate the device, allow at least a 7.6-cm (3-inch) clearance on the left side of

the device. The device uses an electric fan for ventilation. The fan is controlled by a temperature
sensor and is designed to turn on automatically when high temperature conditions exist. These
conditions are affected by high external temperatures, system power consumption, power
management/battery conservation configurations, battery fast charging, and software requirements.
Exhaust air is displaced through the ventilation grill located on the left side of the device.

Before removing the fan and heat sink assembly:

1. Shut down the device. If you are unsure whether the device is off or in Hibernation, turn the

device on, and then shut it down through the operating system.

2. Disconnect all external devices connected to the device.

3. Disconnect the power from the device by first disconnecting the power cord from the AC outlet

and then disconnecting the AC adapter from the device.

4. Remove the battery (see

Battery on page 38).

5. If your device has WWAN capability, remove the SIM (see

6. Remove the following components:

a. Keyboard (see

b. Hard drive (see

c. Top cover (see

d. WLAN module (see

e. Display assembly (see

f. System board (see

Keyboard on page 43)

Mass storage devices on page 50)

Top cover on page 56)

WLAN module on page 53)

Display assembly on page 65)

System board on page 74)

Remove the fan and heat sink assembly:

1. Turn the system board upside down.

SIM on page 39).

76 Chapter 4 Removal and replacement procedures

2. Disconnect the fan cable from the system board.

3. Turn the system board right side up.

4. Loosen the 4 Phillips PM2.5×5.0 captive screws (1) that secure the fan and heat sink assembly

to the system board.

NOTE: The screws are numbered 1 through 4. Follow this order when removing the screws.

5. Remove the Phillips PM2.0×3.0 screw (2) that secures the fan and heat sink assembly to the

system board.

6. If necessary, work the heat sink back and forth to release the heat sink from the thermal paste

(3) on the processor.

7. Remove the fan and heat sink assembly (4).

NOTE: The thermal material must be thoroughly cleaned from the surfaces of the fan and heat sink

assembly and the system board each time the fan and heat sink assembly is removed. Thermal paste
is used on the processor (1). Replacement thermal material is included with all fan and heat sink
assembly, and system board spare part kits.

Component replacement procedures 77

Reverse this procedure to install the fan and heat sink assembly.

78 Chapter 4 Removal and replacement procedures

5 Computer Setup

Computer Setup in Windows 7

To view the drives installed on the computer, select Start > Computer.

On models with a secondary hard drive (drive D), the optical drive becomes drive E. The next drive
added to the system, such as a new USB drive, will be assigned the next available drive letter.

Starting Computer Setup

Computer Setup is a preinstalled, ROM-based utility that can be used even when the operating
system is not working or will not load.

NOTE: Some of the Computer Setup menu items listed in this guide may not be supported by your

computer.

NOTE: An external keyboard connected by USB can be used with Computer Setup only if USB

legacy support is enabled.

To start Computer Setup, follow these steps:

1. Turn on or restart the computer.

2. Before your operating system opens and while the “Press the ESC key for Startup Menu”

message is displayed in the lower-left corner of the screen, press esc.

3. Press f10 to enter BIOS Setup.

Using Computer Setup

Navigating and selecting in Computer Setup

The information and settings in Computer Setup are accessed from the File, Security, Diagnostics,
and System Configuration menus.

Computer Setup in Windows 7 79

To navigate and select in Computer Setup, follow these steps:

1. Turn on or restart the computer, and then press esc while the “Press the ESC key for Startup

Menu” message is displayed at the bottom of the screen.

To select a menu or a menu item, use the tab key and the keyboard arrow keys and then

●

press enter, or use a pointing device to click the item.

To scroll up and down, click the up arrow or the down arrow in the upper-right corner of the

●

screen, or use the up arrow key or the down arrow key.

To close open dialog boxes and return to the main Computer Setup screen, press esc, and

●

then follow the on-screen instructions.

NOTE: You can use either a pointing device (TouchPad, pointing stick, or USB mouse) or the

keyboard to navigate and make selections in Computer Setup.

2. Press f10 to enter BIOS Setup.

3. Select the File, Security, Diagnostics, or System Configuration menu.

4. To exit Computer Setup, choose one of the following methods:

To exit Computer Setup without saving your changes, click the Exit icon in the lower-left

●

corner of the screen, and then follow the on-screen instructions.

– or –

use the tab key and the arrow keys to select File > Ignore changes and exit, and then
press enter.

– or –

To save your preferences and exit Computer Setup menus, click the Save icon in the

●

lower-left corner of the screen, and then follow the instructions on the screen.

– or –

Use the tab key and the arrow keys to select File > Save changes and exit and then press

enter.

Your changes go into effect when the computer restarts.

Restoring factory settings in Computer Setup

To return all settings in Computer Setup to the values that were set at the factory, follow these steps:

1. Open Computer Setup by turning on or restarting the computer, and then pressing esc while the

"Press the ESC key for Startup Menu" message is displayed in the lower-left corner of the
screen.

2. Press f10 to enter BIOS Setup.

3. Use the arrow keys to select File > Restore defaults, and then press enter.

4. When the confirmation dialog box opens, press f10.

5. To save your preferences and exit Computer Setup, use the arrow keys to select File > Save

changes and exit. Then follow the instructions on the screen.

80 Chapter 5 Computer Setup

Your preferences go into effect when the computer restarts.

NOTE: Your password settings and security settings are not changed when you restore the factory

settings.

Computer Setup menus

The menu tables in this section provide an overview of the Computer Setup options.

NOTE: Some of the Computer Setup menu items listed in this chapter may not be supported by

your computer.

File menu

Select To do this

System information

Set system date and time Change date and time

System Diagnostics

Restore defaults Replace the configuration settings in Computer Setup with

Reset BIOS security to factory default Restore the BIOS security settings to the factory default.

Ignore changes and exit Cancel any changes entered during the current session.

Save changes and exit Save any changes entered during the current session. Then

View identification information for the computer.

●

View specification information for the processor, cache

●

and memory size, and system ROM.

Set date—MM:DD:YYYY

●

Set time—HH:MM

●

F1—System information

●

F2—Start-up test

●

F3—Run-in test

●

F4—Hard disk test

●

the original factory settings. (Password settings and security
settings are not changed when you restore the factory
settings.)

Then exit and restart the computer.

exit and restart the computer. Your changes go into effect
when the computer restarts.

Computer Setup in Windows 7 81

Security menu

NOTE: Some of the menu items listed in this section may not be supported by your computer.

Select To do this

Administrator Tools

BIOS administrator password Enter, change, or delete a BIOS administrator password.

User Management (requires a BIOS administrator password)

Create New BIOS User Account password

Password Policy (requires a BIOS administrator password) Revise password policy criteria.

HP SpareKey Enable/disable HP SpareKey (enabled by default).

Always Prompt for HP SpareKey Enrollment Enable/disable HP SpareKey enrollment (enabled by

User Tools

Change Password Enter, change, or delete a BIOS administrator password.

HP SpareKey Enrollment Enroll or reset HP SpareKey, which is a set of security

Disk Sanitizer Run Disk Sanitizer to destroy all existing data on the primary

Select from a list of BIOS users.

●

Select from a list of ProtectTools users.

●

default).

questions and answers used if you forget your password.

hard drive. The following options are available:

Fast—Runs the Disk Sanitizer erase cycle once.

●

Optimum—Runs the Disk Sanitizer erase cycle 3 times.

●

Custom—Allows you to select the desired number of

●

Disk Sanitizer erase cycles from a list.

Last Pass—Displays Disk Sanitizer Completion Report

●

CAUTION: If you run Disk Sanitizer, the data on the

primary hard drive is destroyed permanently.

System IDs Enter a user-defined computer asset tracking number and

82 Chapter 5 Computer Setup

ownership tag.

System Configuration menu

NOTE: Some of the listed System Configuration options may not be supported by your computer.

Select To do this

Language Change the Computer Setup language.

Boot options

Set a Startup Menu delay in seconds.

●

Set the MultiBoot Express Boot Popup delay in

●

seconds.

Enable/disable Custom Logo (disabled by default).

●

Enable/display Display Diagnostic URL.

●

Enable/disable SD card boot.

●

Enable/disable floppy boot.

●

Enable/disable PXE Internal NIC boot.

●

Set the UEFI boot order: Windows Boot Manager.

●

Set the legacy boot order:

●

1st boot device—Notebook hard drive

◦

2nd boot device—USB floppy

◦

3rd boot device—USB CD-ROM

◦

4th boot device—USB hard drive

◦

5th boot device—Notebook Ethernet

◦

6th boot device—SD card

◦

Computer Setup in Windows 7 83

Select To do this

Device configurations

Enable Fn Key Switch

●

Enable/disable USB legacy support. When enabled,

●

USB legacy support allows the following:

Use of a USB keyboard in Computer Setup even

◦

when your operating system is not running.

Startup from bootable USB devices, including a

◦

hard drive, diskette drive, or optical drive
connected by a USB port to the computer.

Enable/disable fan always on while connected to an AC

●

outlet.

Enable/disable Data Execution Prevention (select

●

models only). When enabled, the processor can disable
some virus code execution, which helps to improve
computer security.

Enable/disable LAN power saving mode.

●

Set the SATA (Serial Advanced Technology

●

Attachment) device mode. The following options are
available:

AHCI (Advanced Host Controller Interface)

◦

IDE (Integrated Drive Electronics)

◦

Enable/disable HP QuickLook.

●

Enable/disable HP QuickLook preboot authentication on

●

HP QuickLook boot.

Enable/disable HP QuickWeb.

●

Enable/disable HP QuickWeb: Write Protect (disabled

●

by default).

Enable/disable Intel HT Technology.

●

Enable/disable Wake on USB (disabled by default).

●

Enable/disable Numlock state at boot: Off /On (disabled

●

by default).

84 Chapter 5 Computer Setup

Select To do this

Built-in device options

Port options Enable/disable USB port.

Set Security Level Change, view, or hide security levels for all BIOS menu

Enable/disable the wireless switch state.

●

Enable/disable embedded WLAN device radio.

●

Enable/disable Network Interface Controller (NIC).

●

Enable/disable LAN/WLAN Switching (disabled by

●

default).

Set the wake on LAN state.

●

Disabled

◦

Boot to Network

◦

Follow Boot Order

◦

Enable/disable the integrated camera (webcam).

●

Enable/disable Power Monitor Circuit.

●

Enable/disable the audio device.

●

Enable/disable the microphone.

●

Enable/disable the internal speakers.

●

items.

Restore Security Defaults Restore the default security settings.

Computer Setup in Windows 7 85

Computer Setup in Windows Vista®

Starting Computer Setup

Computer Setup is a preinstalled, ROM-based utility that can be used even when the operating
system is not working or will not load.

NOTE: Some of the Computer Setup menu items listed in this guide may not be supported by your

computer.

NOTE: An external keyboard or mouse connected to a USB port can be used with Computer Setup

only if USB legacy support is enabled.

To start Computer Setup, follow these steps:

1. Turn on or restart the computer, and then press esc while the “Press the ESC key for Startup

Menu” message is displayed at the bottom of the screen.

2. Press f10 to enter BIOS Setup.

Using Computer Setup

Navigating and selecting in Computer Setup

The information and settings in Computer Setup are accessed from the File, Security, Diagnostics,
and System Configuration menus.

To navigate and select in Computer Setup, follow these steps:

1. Turn on or restart the computer, and then press esc while the “Press the ESC key for Startup

Menu” message is displayed at the bottom of the screen.

To select a menu or a menu item, use the tab key and the keyboard arrow keys and then

●

press enter, or use a pointing device to click the item.

To scroll up and down, click the up arrow or the down arrow in the upper-right corner of the

●

screen, or use the up arrow key or the down arrow key.

To close open dialog boxes and return to the main Computer Setup screen, press esc, and

●

then follow the on-screen instructions.

NOTE: You can use either a pointing device (TouchPad, pointing stick, or USB mouse) or the

keyboard to navigate and make selections in Computer Setup.

2. Press f10 to enter BIOS Setup.

3. Select the File, Security, Diagnostics, or System Configuration menu.

86 Chapter 5 Computer Setup

To exit Computer Setup menus, choose one of the following methods:

To exit Computer Setup menus without saving your changes, click the Exit icon in the lower-left

●

corner of the screen, and then follow the on-screen instructions.

– or –

Use the tab key and the arrow keys to select File > Ignore changes and exit, and then press

enter.

– or –

To save your changes and exit Computer Setup menus, click the Save icon in the lower-left

●

corner of the screen, and then follow the on-screen instructions.

– or –

Use the tab key and the arrow keys to select File > Save changes and exit, and then press

enter.

Your changes go into effect when the computer restarts.

Restoring factory settings in Computer Setup

NOTE: Restoring defaults will not change the hard drive mode.

To return all settings in Computer Setup to the values that were set at the factory, follow these steps:

1. Turn on or restart the computer, and then press esc while the “Press the ESC key for Startup

Menu” message is displayed at the bottom of the screen.

2. Press f10 to enter BIOS Setup.

3. Use a pointing device or the arrow keys to select File > Restore defaults.

4. Follow the on-screen instructions.

5. To save your changes and exit, click the Save icon in the lower-left corner of the screen, and

then follow the on-screen instructions.

– or –

Use the arrow keys to select File > Save changes and exit, and then press enter.

Your changes go into effect when the computer restarts.

NOTE: Your password settings and security settings are not changed when you restore the factory

settings.

Computer Setup in Windows Vista® 87

Computer Setup menus

The menu tables in this section provide an overview of Computer Setup options.

NOTE: Some of the Computer Setup menu items listed in this chapter may not be supported by

your computer.

File menu

Select To do this

System Information

Set System Date and Time Set or change the date and time on the computer.

System Diagnostics Displays the following information:

View identification information for the computer and the

●

batteries in the system.

View specification information for the processor, cache

●

and memory size, system ROM, video revision, and
keyboard controller version.

System Information

●

Identification information for the computer and the

◦

batteries in the system.

Specification information for the processor, cache

◦

and memory size, system ROM, video revision,
and keyboard controller version.

Start-up Test—Verifies the system components needed

●

for starting the computer.

Run-In Test—Runs a comprehensive check on system

●

memory.

Hard Disk Test—Runs a comprehensive self-test on

●

any hard drive in the system.

Memory Test—Runs a comprehensive test on any

●

memory installed in the computer.

Reset BIOS security to factory default Restore the BIOS security settings to the factory default.

Restore defaults Replace the configuration settings in Computer Setup with

Ignore changes and exit Cancel any changes entered during the current session.

Save changes and exit Save any changes entered during the current session. Then

88 Chapter 5 Computer Setup

Battery Test—Runs a comprehensive test on any

●

batteries installed in the computer.

Error Log—Displays a log file if any errors have

●

occurred.

the original factory settings. (Hard drive mode, password
settings, and security settings are not changed when you
restore the factory settings.)

Then exit and restart the computer.

exit and restart the computer. Your changes go into effect
when the computer restarts.

Security menu

NOTE: Some of the menu items listed in this section may not be supported by your computer.

Select To do this

Setup BIOS Administrator Password Set up a BIOS administrator password.

Password Policy (requires a BIOS administrator password) Revise password policy criteria.

HP SpareKey Enable/disable HP SpareKey (enabled by default).

Always Prompt for HP SpareKey Enrollment Enable/disable HP SpareKey enrollment (enabled by

Fingerprint Reset on Reboot (If Present) Reset/clear the fingerprint reader ownership (select models

Change Password Enter, change, or delete a BIOS administrator password.

HP SpareKey Enrollment Enroll or reset HP SpareKey, which is a set of security

DriveLock Passwords

Automatic DriveLock Enable/disable Automatic DriveLock support.

TPM Embedded Security Enable/disable support for Trusted Platform Module (TPM)

default).

only; disabled by default).

questions and answers used if you forget your password.

Enable/disable DriveLock on any computer hard drive

●

(enabled by default).

Change a DriveLock user password or master

●

password.

NOTE: DriveLock settings are accessible only when you

enter Computer Setup by turning on (not restarting) the
computer.

Embedded Security, which protects the computer from
unauthorized access to owner functions available in
Embedded Security for ProtectTools. For more information,
refer to the ProtectTools software Help.

NOTE: You must have a setup password to change this

setting.

Disk Sanitizer Run Disk Sanitizer to destroy all existing data on the primary

hard drive or the drive in the upgrade bay.

CAUTION: If you run Disk Sanitizer, the data on the

selected drive is destroyed permanently.

System IDs Enter a user-defined computer asset tracking number and

ownership tag.

Computer Setup in Windows Vista® 89

System Configuration menu

NOTE: Some of the listed System Configuration options may not be supported by your computer.

Select To do this

Language Change the Computer Setup language.

Boot Options

Device Configurations

Set a Startup Menu delay (in seconds).

●

Enable/disable MultiBoot (enabled by default).

●

Set the Express Boot Popup delay in seconds.

●

Enable/disable Custom Logo (disabled by default).

●

Enable/disable Display Diagnostic URL (enabled by

●

default).

Enable/disable CD-ROM boot (disabled by default).

●

Enable/disable SD Card boot (enabled by default).

●

Enable/disable floppy boot (enabled by default).

●

Enable/disable PXE Internal NIC boot (enabled by

●

default).

Enable/Disable Unified Extensible Firmware Interface

●

(UEFI) Boot Mode (disabled by default).

Set the Legacy Boot Order.

●

Enable/disable USB legacy support (enabled by

●

default). When enabled, USB legacy support allows the
following:

Use of a USB keyboard in Computer Setup even

◦

when a Windows operating system is not running

Startup from bootable USB devices, including a

◦

hard drive, diskette drive, or optical drive
connected by a USB port to the computer

Select a parallel port mode: ECP (Enhanced

●

Capabilities Port), standard, bidirectional, or EPP
(Enhanced Parallel Port).

Enable/disable fan always on while connected to an AC

●

outlet (disabled by default).

Enable/disable Data Execution Prevention (select

●

models only). When enabled, the processor can disable
some virus code execution, which helps to improve
computer security (disabled by default).

SATA (Serial Advanced Technology Attachment) device

●

mode. The following options are available:

AHCI (Advanced Host Controller Interface)

◦

IDE (Integrated Drive Electronics)

◦

RAID (select models only)

◦

90 Chapter 5 Computer Setup

Select To do this

NOTE: Availability of these options varies by computer

model.

Enable/disable secondary battery fast charge (enabled

●

by default).

Enable/disable HP QuickLook (enabled by default).

●

Enable/disable Preboot Authentication on HP

●

QuickLook Boot (enabled by default).

Enable/disable HP QuickWeb (enabled by default).

●

Enable/disable HP QuickWeb Elevated Security

●

(disabled by default).

Enable/disable Virtualization Technology (select models

●

only; disabled by default).

Enable/disable Wake on USB (enabled by default).

●

Enable/disable Num lock state at boot (disabled by

●

default).

Enable/disable TXT (Intel Trusted Execution

●

Technology) (select models only; disabled by default).

Computer Setup in Windows Vista® 91

Select To do this

Built-In Device Options

Enable/disable the wireless button state (enabled by

●

default).

Enable/disable embedded WLAN device radio (select

●

models only; enabled by default).

Enable/disable the Network Interface Controller (LAN)

●

(enabled by default).

Enable/disable the embedded Bluetooth device radio

●

(enabled by default).

Enable/disable LAN/WLAN switching (disabled by

●

default).

Enable/disable LAN Power Save (select models only).

●

When enabled, saves power by turning off the LAN
when not in use (enabled by default).

Set the wake on LAN state. Options include the

●

following:

Disabled

◦

Boot to Network

◦

Follow Boot Order

◦

Enable/disable the Notebook Upgrade Bay device

●

(enabled by default).

Enable/disable the Power Monitor Circuit (enabled by

●

default).

Enable/disable the audio devices (enabled by default).

●

Enable/disable the fingerprint device (enabled by

●

default).

Enable/disable a modem device (enabled by default).

●

Enable/disable the microphone (enabled by default).

●

Enable/disable the internal speakers (enabled by

●

default).

92 Chapter 5 Computer Setup
