HP 3DaaS Plus User Manual

HP 3D as a Service
Plus
(HP 3DaaS Plus)

Freedom to innovate.
Pay-per-use model for low-risk, easy
access to fast, quality 3D printing.

Gain the freedom to innovate and bring products to market faster

Produce quality,

functional prototypes

and nal parts in-house.

HP 3DaaS Plus is an easy way to get started with 3D printing.1 Climb the learning curve for design for additive manufacturing with a low

commitment, pay-per-use model.

• Convenient, quality HP Multi Jet Fusion 3D Printing—now in-house.

• Predictable, aordable pay-per-use model—Reduce up-front investment and help align your costs directly with your revenue by paying

monthly.*

• A exible service to t your needs—easily scale your 3D printing technology and expertise in-house as your business grows with the help
of immediate access to support and comprehensive training.

HP 3DaaS Plus—How it works

Sign up for

the service

Receive

your printer

Print your

parts

Automatically

receive your supplies

Pay monthly

fee

Once you receive your printer, you’re free to print as much as you want, whenever you want. Access the online dashboard for easy tracking of billing
and usage. To help you avoid downtime, we'll automatically send you everything you need. Now you can manage your 3D printing cost variability
more eectively with a predictable monthly bill.

Easily scale your 3D printing technology and expertise in-house as your business grows.

Data courtesy of EBK-Hungary Kft.

*Requires a one-year commitment and start-up fee.

All-inclusive solution

1

The HP 3D as a Service Plus (HP 3DaaS Plus) pay-per-use

model1 includes everything you need to help accelerate your

creation workow and keep your designs condential.

Convenient, quality

HP Multi Jet Fusion 3D Printing

The HP Jet Fusion 340 3D Printer is the most compact HP Jet Fusion 3D device for
convenient in-house automated production designed for small/medium-sized product
development teams, design rms, and universities.

Accelerate your design cycles with rapid functional prototyping—produce multiple
design iterations in the same time it takes to print a single part.

Deliver the quality your company and your customers expect with HP’s recommended
bead and air blasting solution, tailored for post-processing 3D printed parts. At the
same time, HP's compact and easy-to-handle explosion-proof vacuum helps clean your
printer's build chamber and maintain maximum performance.

2

HP Jet Fusion

3D printer &

accessories

3

HP 3DaaS Plus

all-inclusive

HP 3D High

Reusability CB PA 12

material

Engineering-grade prototypes

and nal parts in-house

Produce accurate, functional thermoplastic white parts with ne detail and optimal
mechanical properties. Get the parts you want when you need them, easily, reliably, and
predictably—keeping your designs condential.

4

Data courtesy of Addit-ion

Intuitive user interface

Enclosed, automated

material mixing,

loading, and

reclamation systems

Multi-agent printing

with voxel-level

control

A customer-centric service to
maximize your outcomes

Get immediate access to remote and on-site support, HP Printing Care Services, a

full set of training—including ramp-up and best design practices—and a central
contact to help maximize your success with HP Multi Jet Fusion technology.

HP 3D

customer

success

New operational eiciencies

With HP 3DaaS Plus, you'll automatically receive all the supplies you need, as you
need them, for day-to-day functional prototyping and final part production.

Simplify supplies ordering and reduce inventory costs with convenient automatic
supplies replenishment and predictable monthly pay-per-build billing.

Original HP

agents, printhead,

and HP long-term

consumables

Reinventing 3D printing

HP Jet Fusion 340 3D Printer—How it works

* HP Jet Fusion 3D Printing Solutions using HP 3D High Reusability CB PA 12 provide up to 80% powder reusability ratio producing functional parts batch after batch.
For testing, material is aged in real printing conditions and powder is tracked by generations (worst case for reusability). Parts are then made from each generation and tested for
mechanical properties and accuracy.

Get set up to print

Successful installation relies on smart site preparation

Here are a few of the key considerations covered in the site preparation guide:

• Account for printer footprint and
operating space, plan space for the
bead blast solution and explosion-proof

vacuum

• Check printer dimensions and site
dimensions like doorways

• Plan for supplies storage space

• Access to 200-240V electrical service

• Ventilation required to maintain
recommended room temperatures
between 20 to 30° C (68 to 86° F)

• Floor must withstand 650 kg (1443 lbs)

weight; total weight with packaging
850 kg (1874 lbs)

• Keep a safe distance from other
machinery like CNCs, polishers, and
milling or cutting machines

• Ensure that the oor is levelled, smooth,
and vibration free—vibration can
interfere with the printing process and

compromise print quality

• Centralized air compression system or an

air compressor required for bead blast

solution

• For using HP SmartStream 3D software,

you’ll need a designated PC running the
server, always connected to the HP cloud
with your HP PrintOS credentials

Technical specications

HP Jet Fusion 340 3D Printer

HP 3DaaS Plus:

All-inclusive

Printer

performance

Technology HP Multi Jet Fusion technology

Eective building volume Up to 254 x 190 x 248 mm

(10 x 7.5 x 9.8 inches)

Building speed

Full build job time for 248-mm
(9.8-in) buildable height

5

6

1389 cm³/hr (85 in³/hr)

As fast as 20 hours

Layer thickness 0.08 mm (0.003 inches)

Printhead resolution 1200 dpi

Dimensions
(w x d x h)

Printer 1565 x 955 x 1505 mm

(61.6 x 37.6 x 59.3 inches)

Shipping 1770 x 1143 x 2013 mm

(69.7 x 45 x 79.3 inches)

Operating area 2785 x 2530 x 2440 mm

(109.6 x 99.3 x 96 inches)

Weight Printer 650 kg (1433 lb)

Shipping 850 kg (1874 lb)

Environmental

ranges

Acoustics

Operating temperature 20-30° C (68-86° F)

Operating humidity 20-70% RH without condensation

7

Front operating position 72 dB (without muer) / 70 dB (with muer)

Rear bystander position 80 dB (without muer) / 75 dB (with muer)

8

Network

Gigabit Ethernet (10/100/1000Base-T), supporting the following standards: TCP/IP,
DHCP (iPv4 only); TLS/SSL

Hard disk HDD 1TB (AES-256 encrypted, disk wipe DoD 5520M) & SSD 1TB (AES-256 encrypted)

Software Included software HP SmartStream 3D Build Manager

HP SmartStream 3D Command Center

Supported le formats 3MF, STL, OBJ, VRML v.2

Power Consumption 6300W or 2 x 3150W

Requirements

9

Single-circuit conguration: 221-240V 32A
Dual-circuit conguration: 221-240V 2 x 16A

Certication &
Statement

Safety NA (US & Canada) IFC 61010-1 compliant,

NRTL certied; EU: Machinery Directive, EN
61010-1, EN 60204-1, EN ISO 12100, and
EN ISO 13849-1 compliant

Electromagnetic compatibility EN 55032:2012 Class A; CISPR 32:2015

Class A; FCC CFR 47 Part 15 Class A;
ICES-003, Issue 6 Class A; EN 61000­3-12:2011; IEC 61000-3-12:2011; EN
61000-3-11:2017; IEC 61000-3-11:2017;
EN 55024:2010; CISPR 24:2010

Environmental REACH compilant

Warranty &
service coverage

One-year limited hardware

warranty

included

Printer HP Jet Fusion 340 3D Printer

Original HP 3D high

HP 3D High Reusability CB PA 12

reusability material

Post-processing

and cleaning
accessories

4

Original HP

Bead and air blasting solution

Explosion-proof vacuum

HP 3D400 Printhead Kit

printhead

Original HP agents HP 3D400 500-ml Detailing Agent

HP 3D400 500-ml Fusing Agent

HP 3D400 250-ml Bright Fusing Agent

HP long-term
consumables

HP Jet Fusion 500/300 Series 3D Printhead Cleaning Roll

HP Jet Fusion 500/300 Series 3D Printer Lamp Module

HP Jet Fusion 500/300 Series 3D Printer Air Inlet Filter

HP Jet Fusion 500/300 Series 3D Printer Print Area Filter

HP Jet Fusion 500/300 Series 3D Printer Air Exhaust Filter

HP 3D support Remote and onsite support (includes shipment,

installation, and training)

Eco Highlights

• Cleaner, more comfortable experience—enclosed printing system, and
automatic powder management

• Minimizes waste due to industry-leading reusability of powder

• Take-back program for eligible supplies available in select countries

Please recycle printing hardware and eligible printing supplies.

Find out how at our website: hp.com/ecosolutions

Dynamic security enabled printer. Only intended to be used with cartridges
using an HP original chip. Cartridges using a non-HP chip may not work, and
those that work today many not work in the future.
More at: hp.com/go/learnaboutssupplies

10

SPARK DESIGN AWARDS

PLATINUM WINNER

11

12

Learn more about HP 3DaaS Plus at: hp.com/go/3DaaSPlus

Request a free consultation on HP 3DaaS at hp.com/go/3DaaSContactUs

Sign up for more information on HP 3DaaS at hp.com/go/3DaaSSignUp

1. HP 3DaaS Plus now available in Austria, Belgium, Canada, Denmark, Finland, France, Germany, Ireland, Italy, Netherlands, Portugal,
Spain, Sweden, UK and US. Includes HP Jet Fusion 340 3D Printer for printing white parts, installation, support and maintenance services,
supplies and long-term consumables. HP 3DaaS Plus requires a one-year commitment and start-up fee.

2. Based on internal and third-party testing for HP Jet Fusion 340 3D Printer, printing and cooling time is a fraction of the time of the printing
times of comparable plastic fused deposition modeling (FDM), stereolithography (SLA), and material jetting solutions from $20,000 USD
to $120,000 USD on market as of July 2019. Testing variables for the HP Jet Fusion 340 3D Printer: Part quantity: 1 full build chamber of
parts from HP Jet Fusion 3D at 8% of packing density versus same number of parts on above-mentioned competitive devices; Part size:
30 cm3; Layer thickness: 0.08 mm/0.003 inches. Competitor testing variables are comparable.

3. Both the bead and air blasting solution and the explosion-proof vacuum are available as an option together.

4. HP Jet Fusion 3D Printing Solutions using HP 3D High Reusability CB PA 12 provide up to 80% powder reusability ratio producing functional
parts batch after batch. For testing, material is aged in real printing conditions and powder is tracked by generations (worst case for
reusability). Parts are then made from each generation and tested for mechanical properties and accuracy.

5. Based on 0.08-mm (0.003-in) layer thickness and 10 sec/layer.

© Copyr ight 2021 HP D evelopm ent Compan y, L.P.
The on ly warran ties for HP p roducts a nd servi ces are set fo rth in the e xpress wa rranty s tatement s accompa nying suc h product s and ser vices. Not hing here in should b e construe d as consti tuting
an add itional w arrant y. HP shall not b e liable fo r technic al or editor ial error s or omissi ons conta ined herei n.

4AA7-6795ENE, J anuary 2021

6. Assumes default "Auto Cool and Reclaim" print mode. Job duration begins at the moment the job is selected to print at the control panel
and ends at the time the parts are ready to be removed from the build chamber. Does not include part cleaning.

7. Measurement positions conform to ISO 11201-2010 for machinery, 1.0 meters horizontally and 1.55 meters above the oor.

8. The HP Jet Fusion 3D Printing Solution should be connected to the HP Cloud in order to enable the correct functioning of the printer and
to oer better support.

9. Consult the Site Preparation Guide for other electrical connection options and technical details on electrical installation.

10. Compared to manual print retrieval process used by other powder-based technologies. The term “cleaner” does not refer to any indoor air
quality requirements and/or consider related air quality regulations or testing that may be applicable.

11. Compared to PA 12 materials available as of June 2017. HP Jet Fusion 3D Printing Solutions using HP 3D High Reusability CB PA 12 provide
up to 80% powder reusability ratio, producing functional parts batch after batch.

12. Printing supplies eligible for recycling vary by supply and by printer. Visit hp.com/recycle to see how to participate and for HP Planet
Partners program availability; program may not be available in your area. Where this program is not available, and for other consumables
not included in the program, consult your local waste authorities on appropriate disposal.
