HP 2910 al, 2910-24G al, 2910-48G al, 2910-24G-PoE+ al, 2910-48G-PoE+ al Specification

HP 2910-24G al Switch

HP 2910-48G al Switch

HP 2910-48G-PoE+ al Switch

Models

HP 2910-24G al Switch

J9145A

HP 2910-48G al Switch

J9147A

HP 2910-24G-PoE+ al Switch

J9146A

HP 2910-48G-PoE+ al Switch

J9148A

Key Features

High-performance Gigabit Ethernet access switch
Four optional 10 GbE (CX4 and/or SFP+) ports
IEEE 802.3af/802.3at functionality ( PoE/PoE+)
Layer 2 and Layer 3 plus static IP and RIP routing
Lifetime warranty, sFlow, ACLs, and rate limiting

QuickSpecs

HP 2910 al Switch Series

Overview

DA - 13280 Worldwide — Version 20 — December 12, 2013

Page 1

Product overview

The HP 2910 al Switch Series consists of four switches: the HP 2910-24G al and 2910-24G-PoE+ al Switches with 24 10/100/1000
ports, and the HP 2910-48G al and 2910-48G-PoE+ al Switches with 48 10/100/1000 ports. Each switch has four dual-personality
ports for 10/100/1000 or mini-GBIC connectivity. In addition, the 2910 al Switch Series supports up to four optional 10 Gigabit Ethernet
(CX4 and/or SFP+) ports, thereby offering the most flexible and easy-to-deploy uplinks in its class. Together with static and RIP IPv4
routing, robust security and management, enterprise-class features, free lifetime warranty, and free software updates, the 2910
series is a cost-effective, scalable solution for customers who are building high-performance networks. These switches can be
deployed at enterprise edge and remote branch offices, converged networks, and data center top of rack.

Features and Benefits

Quality of Service

(QoS)

Traffic prioritization

(IEEE 802.1p): allows real-time traffic classification into eight priority levels mapped to eight queues

Layer 4 prioritization

: enables prioritization based on TCP/UDP port numbers

Class of Service

(CoS): sets the IEEE 802.1p priority tag based on IP address, IP Type of Service (ToS), Layer 3 protocol, TCP/UDP

port number, source port, and DiffServ

Rate Limiting

: per-port ingress enforced maximums

Connectivity

10 Gbps Ethernet connectivity

: up to four optional and flexible 10-Gigabit ports (CX4 and/or SFP+), with optional interconnect

kit for short-distance connectivity

IPv6

:

IPv6 host

: allows the switches to be managed and deployed at the edge of IPv6 networks

Dual stack

(IPv4/IPv6): provides transition mechanism from IPv4 to IPv6; supports connectivity for both protocols

MLD snooping

: forwards IPv6 multicast traffic to the appropriate interface; prevents IPv6 multicast traffic from flooding

the network

IEEE 802.3af Power over Ethernet

(PoE): provides up to 15.4 W per port to IEEE 802.3af-compliant PoE-powered devices such

as IP phones, wireless access points, and security cameras

IEEE 802.3at Power Over Ethernet Plus

: provides up to 30 W per port to IEEE 802.3 for PoE/PoE+ powered devices such as

video IP phones, IEEE 802.11n wireless access points, and advanced pan/zoom/tilt security cameras

Pre-standard PoE support

: detects and provides power to pre-standard PoE devices; see list of supported devices in the

product FAQ at:

www.hp.com/networking/support

Auto-MDIX

: automatically adjusts for straight-through or crossover cables on all 10/100 and 10/100/1000 ports

Dual-personality functionality

: includes four 10/100/1000 ports or SFP slots for optional fiber connectivity such as Gigabit-SX,

-LX, -LH, 100-FX, 100-BX, and 1000-BX

Single IP Address Management

: single IP address management for a virtual stack of up to 16 switches

Performance

High-performance architecture

: 128 Gbps switching fabric with up to 95 Mpps (24-port switches) and 176 Gbps switching fabric

with up to 131 Mpps (48-port switches)

Selectable queue configurations

: allows for increased performance by selecting the number of queues and associated memory

buffering that best meet the requirements of the network applications

Resiliency and high availability

IEEE 802.1s Multiple Spanning Tree

: provides high link availability in multiple VLAN environments by allowing multiple

spanning trees; provides legacy support for IEEE 802.1d and IEEE 802.1w

QuickSpecs

HP 2910 al Switch Series

Overview

DA - 13280 Worldwide — Version 20 — December 12, 2013

Page 2

IEEE 802.3ad Link Aggregation Protocol

(LACP)

and HP port trunking

: support up to 24 trunks, each with up to 8 links (ports)

per trunk

Optional redundant power supply

: supplies backup power in case of power failure (

NOTE:

HP 620 Redundant/External Power

Supply provides only RPS functionality

)

Manageability

RMON, XRMON, and sFlow

: provide advanced monitoring and reporting capabilities for statistics, history, alarms, and events

Uni-Directional Link Detection

(UDLD): monitors a link between two switches and blocks the ports on both ends of the link if

the link goes down at any point between the two devices

Command authorization

: leverages RADIUS to link a custom list of CLI commands to an individual network administrator's login;

also provides an audit trail

Dual flash images

: provides independent primary and secondary operating system files for backup while upgrading

Multiple configuration files

: allow multiple configuration files to be stored to a flash image

Friendly port names

: allow assignment of descriptive names to ports

Find-Fix-Inform

: finds and fixes common network problems automatically, then informs administrator

Software updates

: free downloads from the Web

Troubleshooting

: ingress and egress port monitoring enable network problem solving

Layer 2 switching

VLAN support and tagging

: supports IEEE 802.1Q (4,094 VLAN IDs) and 256 VLANs simultaneously

GARP VLAN Registration Protocol

(GVRP): allows automatic learning and dynamic assignment of VLANs

Jumbo packet support

: supports up to 9220-byte frame size to improve the performance of large data transfers

IEEE 802.1v protocol VLANs

: isolate select non-IPv4 protocols automatically into their own VLANs

Layer 3 routing

Static IP routing

: provides manually configured routing; includes ECMP capability

Routing Information Protocol

(RIP): provides RIPv1 and RIPv2 routing

Security

Multiple user authentication methods

:

IEEE 802.1X

: is an industry-standard method of user authentication using an IEEE 802.1X supplicant on the client in

conjunction with a RADIUS server

Web-based authentication

: is similar to IEEE 802.1X and provides a browser-based environment to authenticate clients

that do not support the IEEE 802.1X supplicant

MAC-based authentication

: authenticates the client with the RADIUS server based on the client's MAC address

Authentication flexibility

:

Multiple IEEE 802.1X users per port

: provides authentication of up to eight IEEE 802.1X users per port; prevents a user

from "piggybacking" on another user's IEEE 802.1X authentication

Concurrent IEEE 802.1X and Web or MAC authentication schemes per port

: switch port will accept any IEEE 802.1X and

either Web or MAC authentications

Access control lists

(ACLs): provide IP Layer 3 filtering based on source/destination IP address/subnet and source/destination

TCP/UDP port number

Identity-driven ACL

: enables implementation of a highly granular and flexible access security policy and VLAN assignment

specific to each authenticated network user

Dynamic ARP protection

: blocks ARP broadcasts from unauthorized hosts, preventing eavesdropping or theft of network data

DHCP protection

: blocks DHCP packets from unauthorized DHCP servers, preventing denial-of-service attacks

QuickSpecs

HP 2910 al Switch Series

Overview

DA - 13280 Worldwide — Version 20 — December 12, 2013

Page 3

Port monitoring for network threats

: provides sampled port traffic using sFlow technology to the HP Network Immunity
Manager (NIM) application for Network Behavior Anomaly Detection (NBAD) analysis to detect and mitigate threats at the port
where the threat originated

Source-port filtering

: allows only specified ports to communicate with each other

RADIUS/TACACS+

: eases switch management security administration by using a password authentication server

Secure shell

: encrypts all transmitted data for secure remote CLI access over IP networks

Secure FTP

: allows secure file transfer to and from the switch; protects against unwanted file downloads or unauthorized

copying of a switch configuration file

Secure Sockets Layer

(SSL): encrypts all HTTP traffic, allowing secure access to the browser-based management GUI in the

switch

Port security

: allows access only to specified MAC addresses, which can be learned or specified by the administrator

MAC address lockout

: prevents particular configured MAC addresses from connecting to the network

Switch management logon security

: helps secure switch CLI logon by optionally requiring either RADIUS or TACACS+

authentication

STP BPDU port protection

: blocks Bridge Protocol Data Units (BPDUs) on ports that do not require BPDUs, preventing forged

BPDU attacks

USB Secure Autorun

(requires HP PCM+): deploys, diagnoses, and updates a switch using a USB flash drive; works with a secure

credential to prevent tampering

STP Root Guard

: protects the root bridge from malicious attacks or configuration mistakes

Custom banner

: displays security policy when users log in to the switch

Per-port broadcast throttling

: selectively configures broadcast control on heavy traffic port uplinks

Convergence

IP multicast snooping and data-driven IGMP

: automatically prevent flooding of IP multicast traffic

LLDP-MED

(Media Endpoint Discovery): is a standard extension of LLDP that stores values for parameters such as QoS and VLAN

to automatically configure network devices such as IP phones

IEEE 802.1AB Link Layer Discovery Protocol

(LLDP): is an automated device discovery protocol that provides easy mapping of

network management applications

PoE and PoE+ allocations

: support multiple methods (automatic, IEEE 802.3at dynamic, LLDP-MED fine-grain, IEEE 802.3af

device class, or user specified) to allocate and manage PoE/PoE+ power for more efficient energy savings

Monitor and diagnostics

Port mirroring

: enables traffic on a port to be simultaneously sent to a network analyzer for monitoring

Warranty and support

Lifetime warranty

: for as long as you own the product with advance replacement and next-business-day delivery (available in

most countries)†

Electronic and telephone support

: limited electronic and telephone support is available from HP; to reach our support centers,

refer to

www.hp.com/networking/contact-support

; for details on the duration of support provided with your product purchase,

refer to

www.hp.com/networking/warrantysummary

Software releases

: to find software for your product, refer to

www.hp.com/networking/support

; for details on the software

releases available with your product purchase, refer to

www.hp.com/networking/warrantysummary

†HP warranty includes repair or replacement of hardware for as long as you own the product, with next business day advance
replacement (available in most countries). The disk drive included with HP AllianceOne Advanced Services and Services zl Modules, HP
Threat Management Services zl Module, HP AllianceOne Extended zl Module with Riverbed Steelhead, HP MSM765zl Mobility Controller
and HP Survivable Branch Communication zl Module powered by Microsoft Lync has a five-year hardware warranty. For details, refer to

QuickSpecs

HP 2910 al Switch Series

Overview

DA - 13280 Worldwide — Version 20 — December 12, 2013

Page 4

the Software license and hardware warranty statements at

www.hp.com/networking/warranty

.

QuickSpecs

HP 2910 al Switch Series

Overview

DA - 13280 Worldwide — Version 20 — December 12, 2013

Page 5

Build To Order:

BTO is a standalone unit with no integration. BTO products ship standalone are not part of a CTO or Rack-

Shippable solution.

HP 2910-24G al Switch

J9145A

20 autosensing 10/100/1000 port
4 dual-personality ports
min=0 \ max=4 SFP Transceivers
2 - Module Slots
1U - Height

See Configuration

Note:1, 2, 3

PDU Cable NA/MEX/TW/JP

J9145A#B2B

C15 PDU Jumper Cord (NA/MEX/TW/JP)

PDU Cable ROW

J9145A#B2C

C15 PDU Jumper Cord (ROW)

HP 2910-48G al Switch

J9147A

44 autosensing 10/100/1000 port
4 dual-personality ports
min=0 \ max=4 SFP Transceivers
2 - Module Slots
1U - Height

See Configuration

Note:1, 2, 3

PDU Cable NA/MEX/TW/JP

J9147A#B2B

C15 PDU Jumper Cord (NA/MEX/TW/JP)

PDU Cable ROW

J9147A#B2C

C15 PDU Jumper Cord (ROW)

HP 2910-24G-PoE+ al Switch

J9146A

20 autosensing 10/100/1000 port
4 dual-personality ports
min=0 \ max=4 SFP Transceivers
2 - Module Slots
1U - Height

See Configuration

Note:1, 2, 3

PDU Cable NA/MEX/TW/JP

J9146A#B2B

C15 PDU Jumper Cord (NA/MEX/TW/JP)

PDU Cable ROW

J9146A#B2C

C15 PDU Jumper Cord (ROW)

HP 2910-48G-PoE+ al Switch

J9148A

QuickSpecs

HP 2910 al Switch Series

Configuration

DA - 13280 Worldwide — Version 20 — December 12, 2013

Page 6

44 autosensing 10/100/1000 port
4 dual-personality ports
min=0 \ max=4 SFP Transceivers
2 - Module Slots
1U - Height

See Configuration

Note:1, 2, 3

PDU Cable NA/MEX/TW/JP

J9148A#B2B

C15 PDU Jumper Cord (NA/MEX/TW/JP)

PDU Cable ROW

J9148A#B2C

C15 PDU Jumper Cord (ROW)

Configuration Rules:

Note 1

The following Transceivers install into this switch:
HP X111 100M SFP LC FX Transceiver

J9054C

HP X112 100M SFP LC BX-D Transceiver

J9099B

HP X112 100M SFP LC BX-U Transceiver

J9100B

HP X121 1G SFP LC LH Transceiver

J4860C

HP X121 1G SFP LC LX Transceiver

J4859C

HP X121 1G SFP LC SX Transceiver

J4858C

HP X122 1G SFP LC BX-D Transceiver

J9142B

HP X122 1G SFP LC BX-U Transceiver

J9143B

HP X132 10G SFP+ LC SR Transceiver

J9150A

HP X132 10G SFP+ LC LR Transceiver

J9151A

HP X132 10G SFP+ LC LRM Transceiver

J9152A

HP X242 SFP+ SFP+ 1m Direct Attach Cable

J9281B

HP X242 SFP+ SFP+ 3m Direct Attach Cable

J9283B

HP X242 SFP+ SFP+ 7m Direct Attach Cable

J9285B

HP X244 XFP SFP+ 1m Direct Attach Cable

J9300A

HP X244 XFP SFP+ 3m Direct Attach Cable

J9301A

HP X244 XFP SFP+ 5m Direct Attach Cable

J9302A

HP X242 SFP+ 10m DAC Cable

J9286B

HP X242 SFP+ 15m DAC Cable

J9287B

Note 2

Localization required. (See Localization Menu for list.)

Note 3

Localization required on orders without #B2B or #B2C options.

Remarks:

Drop down under power supply should offer the following options and results:
Switch/Router/Power Supply to PDU Power Cord - #B2B in North America, Mexico, Taiwan, and
Japan or #B2C ROW. (Watson Default B2B or B2C for Rack Level CTO)
Switch/Router/Power Supply to Wall Power Cord - Localized Option (Watson Default for BTO and
Box Level CTO)

QuickSpecs

HP 2910 al Switch Series

Configuration

DA - 13280 Worldwide — Version 20 — December 12, 2013

Page 7

Factory Racked Models

HP 2910-24G al Switch

J9145A

20 autosensing 10/100/1000 port
4 dual-personality ports
min=0 \ max=4 SFP Transceivers
2 - Module Slots
1U - Height

See Configuration

Note:1, 2

HP 2910-24G Fact Integrated al Switch

J9145AZ

See Configuration

Note:1, 2

PDU Cable NA/MEX/TW/JP

J9145A#B2B

C15 PDU Jumper Cord (NA/MEX/TW/JP)

PDU Cable ROW

J9145A#B2C

C15 PDU Jumper Cord (ROW)

HP 2910-48G al Switch

J9147A

44 autosensing 10/100/1000 port
4 dual-personality ports
min=0 \ max=4 SFP Transceivers
2 - Module Slots
1U - Height

See Configuration

Note:1, 2

HP 2910-48G Factory Integrated al Switch

J9147AZ

See Configuration

Note:1, 2

PDU Cable NA/MEX/TW/JP

J9147A#B2B

C15 PDU Jumper Cord (NA/MEX/TW/JP)

PDU Cable ROW

J9147A#B2C

C15 PDU Jumper Cord (ROW)

HP 2910-24G-PoE+ al Switch

J9146A

20 autosensing 10/100/1000 port
4 dual-personality ports
min=0 \ max=4 SFP Transceivers
2 - Module Slots
1U - Height

See Configuration

Note:1, 2

HP 2910-24G-PoE+ Fact Integ al Switch

J9146AZ

See Configuration

Note:1, 2

QuickSpecs

HP 2910 al Switch Series

Configuration

DA - 13280 Worldwide — Version 20 — December 12, 2013

Page 8

PDU Cable NA/MEX/TW/JP

J9146A#B2B

C15 PDU Jumper Cord (NA/MEX/TW/JP)

PDU Cable ROW

J9146A#B2C

C15 PDU Jumper Cord (ROW)

HP 2910-48G-PoE+ al Switch

J9148A

44 autosensing 10/100/1000 port
4 dual-personality ports
min=0 \ max=4 SFP Transceivers
2 - Module Slots
1U - Height

See Configuration

Note:1, 2

HP 2910-48G-PoE+ Fact Integ al Switch

J9148AZ

See Configuration

Note:1, 2

PDU Cable NA/MEX/TW/JP

J9148A#B2B

C15 PDU Jumper Cord (NA/MEX/TW/JP)

PDU Cable ROW

J9148A#B2C

C15 PDU Jumper Cord (ROW)

Configuration Rules:

Note 1

The following Transceivers install into this switch:
HP X111 100M SFP LC FX Transceiver

J9054C

HP X112 100M SFP LC BX-D Transceiver

J9099B

HP X112 100M SFP LC BX-U Transceiver

J9100B

HP X121 1G SFP LC LH Transceiver

J4860C

HP X121 1G SFP LC LX Transceiver

J4859C

HP X121 1G SFP LC SX Transceiver

J4858C

HP X122 1G SFP LC BX-D Transceiver

J9142B

HP X122 1G SFP LC BX-U Transceiver

J9143B

HP X132 10G SFP+ LC SR Transceiver

J9150A

HP X132 10G SFP+ LC LR Transceiver

J9151A

HP X132 10G SFP+ LC LRM Transceiver

J9152A

HP X242 SFP+ SFP+ 1m Direct Attach Cable

J9281B

HP X242 SFP+ SFP+ 3m Direct Attach Cable

J9283B

HP X242 SFP+ SFP+ 7m Direct Attach Cable

J9285B

HP X244 XFP SFP+ 1m Direct Attach Cable

J9300A

HP X244 XFP SFP+ 3m Direct Attach Cable

J9301A

HP X244 XFP SFP+ 5m Direct Attach Cable

J9302A

HP X242 SFP+ 10m DAC Cable

J9286B

HP X242 SFP+ 15m DAC Cable

J9287B

QuickSpecs

HP 2910 al Switch Series

Configuration

DA - 13280 Worldwide — Version 20 — December 12, 2013

Page 9

Note 2

If this switch is factory installed in HP Universal Racks, Then the J9583A#0D1 or J9583AZ is
required.
AMS then J9583AZ is required.
EMEA then J9583A#0D1 is required.
APD, Japan and China then J9583A#0D1 is required.

CLIC Only - Allow the J9583AZ in all regions.

Note 3

Localization required on orders without #B2B or #B2C options.

Remarks:

Drop down under power supply should offer the following options and results:
Switch/Router/Power Supply to PDU Power Cord - #B2B in North America, Mexico, Taiwan, and
Japan or #B2C ROW. (Watson Default B2B or B2C for Rack Level CTO)
Switch/Router/Power Supply to Wall Power Cord - Localized Option (Watson Default for BTO and
Box Level CTO)

Internal Power Supplies

Power supplies included in base models.

Enter the following menu selections as integrated to the CTO Model X server above if order is factory built.

Modules

System (std 0 // max=2) User Selection (min 0 / max=2) per Chassis

HP 2-port 10GbE CX4 al Module

J9149A

HP 2p 10GbE CX4 Fact Integrated al Mod

J9149AZ

HP 2-port 10GbE SFP+ al Module

J9008A

min=0 \ max=2 SFP+ Transceivers

See Configuration

Note:2

HP 2-port 10GbE SFP+ Fact Integ al Mod

J9008AZ

min=0 \ max=2 SFP+ Transceivers

See Configuration

Note:2

HP 10GbE al Switch Interconnect Kit

J9165A

HP 10GbE Fact Intg al Switch Intrcon Kit

J9165AZ

Configuration Rules:

QuickSpecs

HP 2910 al Switch Series

Configuration

DA - 13280 Worldwide — Version 20 — December 12, 2013

Page 10

Note 2

The following Transceivers install into this Module:
HP X132 10G SFP+ LC ER Transceiver

J9153A

HP X132 10G SFP+ LC LR Transceiver

J9151A

HP X132 10G SFP+ LC LRM Transceiver

J9152A

HP X132 10G SFP+ LC SR Transceiver

J9150A

HP X242 SFP+ SFP+ 1m Direct Attach Cable

J9281B

HP X242 SFP+ SFP+ 3m Direct Attach Cable

J9283B

HP X242 SFP+ SFP+ 7m Direct Attach Cable

J9285B

HP X244 XFP SFP+ 1m Direct Attach Cable

J9300A

HP X244 XFP SFP+ 3m Direct Attach Cable

J9301A

HP X244 XFP SFP+ 5m Direct Attach Cable

J9302A

HP X242 SFP+ 10m DAC Cable

J9286B

HP X242 SFP+ 15m DAC Cable

J9287B

Transceivers

SFP Transceivers

HP X111 100M SFP LC FX Transceiver

J9054C

HP X112 100M SFP LC BX-D Transceiver

J9099B

HP X112 100M SFP LC BX-U Transceiver

J9100B

HP X121 1G SFP LC LH Transceiver

J4860C

HP X121 1G SFP LC SX Transceiver

J4858C

HP X121 1G SFP LC LX Transceiver

J4859C

HP X122 1G SFP LC BX-D Transceiver

J9142B

HP X122 1G SFP LC BX-U Transceiver

J9143B

HP X132 10G SFP+ LC SR Transceiver

J9150A

HP X132 10G SFP+ LC LR Transceiver

J9151A

HP X132 10G SFP+ LC LRM Transceiver

J9152A

SFP+ Transceivers

HP X132 10G SFP+ LC SR Transceiver

J9150A

HP X132 10G SFP+ LC LR Transceiver

J9151A

HP X132 10G SFP+ LC LRM Transceiver

J9152A

HP X132 10G SFP+ LC ER Transceiver

J9153A

HP X242 10G SFP+ SFP+ 1m DAC Cable

J9281B

HP X242 10G SFP+ SFP+ 3m DAC Cable

J9283B

HP X242 10G SFP+ SFP+ 7m DAC Cable

J9285B

HP X244 XFP SFP+ 1m Direct Attach Cable

J9300A

HP X244 XFP SFP+ 3m Direct Attach Cable

J9301A

HP X244 XFP SFP+ 5m Direct Attach Cable

J9302A

HP X242 SFP+ 10m DAC Cable

J9286B

QuickSpecs

HP 2910 al Switch Series

Configuration

DA - 13280 Worldwide — Version 20 — December 12, 2013

Page 11

HP X242 SFP+ 15m DAC Cable

J9287B

Cables

Multi-Mode Cables

HP .5m Multi-mode OM3 LC/LC FC Cable

AJ833A

HP 1m Multi-mode OM3 LC/LC FC Cable

AJ834A

HP 2 m Multimode OM3 LC/LC FC Cable

AJ835A

HP 5 m Multimode OM3 LC/LC FC Cable

AJ836A

HP 15 m Multimode OM3 LC/LC FC Cable

AJ837A

HP 30 m Multimode OM3 LC/LC FC Cable

AJ838A

HP 50 m Multimode OM3 LC/LC FC Cable

AJ839A

HP Premier Flex LC/LC OM4 2f 1m Cbl

QK732A

HP Premier Flex LC/LC OM4 2f 2m Cbl

QK733A

HP Premier Flex LC/LC OM4 2f 5m Cbl

QK734A

HP Premier Flex LC/LC OM4 2f 15m Cbl

QK735A

HP Premier Flex LC/LC OM4 2f 30m Cbl

QK736A

HP Premier Flex LC/LC OM4 2f 50m Cbl

QK737A

Switch Enclosure Options

Rack Mount Kit

HP 10GbE al Switch Interconnect Kit

J9165A

Used to connect two switches together

Rack Mount Kit

HP X410 1U Univ 4-post Rack Mnt Kit

J9583A

See Configuration

Note:1

HP X410 1U Integ Univ 4-post Rck Mnt Kit

J9583AZ

See Configuration

Note:1

Configuration Rules:

Note 1

If this Mounting Kit is order with #0D1 or Z then it integrates to the HP Universal Rack. (not the
switch)

Software

QuickSpecs

HP 2910 al Switch Series

Configuration

DA - 13280 Worldwide — Version 20 — December 12, 2013

Page 12

HP IDM v3 Software w/500-user License

J9438A

HP IDM v3 additional 1000-user License

J9440A

HP IDM v3 Software w/Unltd-user License

J9439A

External Power supplies

HP 620 Redundant/External Power Supply

J8696A

Height = 1U

See Configuration

Note:1, 2

HP 630 Red and/or External Power Supply

J9443A

Height = 1U

See Configuration

Note:1, 2

Configuration Rules:

Note 1

See HPN Rack Menu for integration details.

Note 2

Localization required. (See Localization Menu for list.)

QuickSpecs

HP 2910 al Switch Series

Configuration

DA - 13280 Worldwide — Version 20 — December 12, 2013

Page 13

HP 2910-24G al Switch

(J9145A)

Ports

20 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE

802.3ab Type 1000BASE-T); Media Type: Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or full;
1000BASE-T: full only

4 dual-personality ports; each port can be used as either an RJ-45 10/100/1000 port (IEEE 802.3 Type
10Base-T; IEEE 802.3u Type 100Base-TX; IEEE 802.3ab 1000Base-T Gigabit Ethernet) or as a mini-GBIC
slot (for use with mini-GBIC transceivers)

1 RJ-45 serial console port
Supports a maximum of 4 10GbE ports, with optional module

Physical characteristics

Dimensions

17.4(w) x 14.4(d) x 1.73(h) in (44.2 x 36.58 x 4.4 cm) (1U height)

Weight

10.92 lb (4.95 kg)

Memory and processor

Processor

Dual ARM1156T2S @ 515 MHz, 4 MB flash, 1 GB compact flash, 512 MB
SDRAM; packet buffer size: 6 MB

Mounting

Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included); horizontal surface
mounting only

Performance

1000 Mb Latency

< 2.9 µs (FIFO 64-byte packets)

10 Gbps Latency

< 1.3 µs (FIFO 64-byte packets)

Throughput

up to 95 million pps (64-byte packets)

Switching capacity

128 Gbps

Routing table size

2000 entries (IPv4)

MAC address table size

16000 entries

Environment

Operating temperature

32°F to 131°F (0°C to 55°C)

Operating relative
humidity

15% to 95% @ 104°F (40°C), noncondensing

Non-operating/
Storage temperature

-40°F to 158°F (-40°C to 70°C)

Non-operating/
Storage relative humidity

15% to 95% @ 149°F (65°C), noncondensing

Altitude

up to 10,000 ft (3 km)

Acoustic

Power: 53.5 dB, Pressure: 39.4 dB; DIN 45635T.19 per ISO 7779

Electrical characteristics

Description

The switch automatically adjusts to any voltage between 100-127 and 200­240 volts and either 50 or 60 Hz

Maximum heat
dissipation

279 BTU/hr (295 kJ/hr)

Voltage

100-127/200-240 VAC

Current

1.7/0.9 A

Idle power

49 W

Maximum power rating

82 W

Frequency

50/60 Hz

QuickSpecs

HP 2910 al Switch Series

Technical Specifications

DA - 13280 Worldwide — Version 20 — December 12, 2013

Page 14

Notes

Idle power is the actual power consumption of the device with no ports
connected.
Maximum power rating and maximum heat dissipation are the worst-case
theoretical maximum numbers provided for planning the infrastructure with
fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all
modules populated.

Safety

EN 60950/IEC 60950; CAN/CSA 22.2 No. 60950; EN 60825; UL 60950

Emissions

FCC part 15 Class A; EN 55022/CISPR-22 Class A; VCCI Class A

Immunity

EN

EN 55024, CISPR 24

ESD

IEC 61000-4-2; 4 kV CD, 8 kV AD

Radiated

IEC 61000-4-3; 3 V/m

EFT/Burst

IEC 61000-4-4; 1.0 kV (power line), 0.5 kV (signal line)

Surge

IEC 61000-4-5; 1 kV / 2 kV AC, 1 kV signal, 0.5 kV DC

Conducted

IEC 61000-4-6; 3 V

Power frequency
magnetic field

IEC 61000-4-8; 1 A/m

Voltage dips and
interruptions

IEC 61000-4-11; > 95% reductions, 0.5 period; 30% reduction, 25 periods

Harmonics

IEC 61000-3-2

Flicker

IEC 61000-3-3

Management

HP PCM+; HP PCM; command-line interface; Web browser; out-of-band management (serial RS-232C)

Notes

When using mini-GBICs with this product, mini-GBICs with revision "B" or later (product number ends with
the letter "B" or later, e.g., J4858B, J4859C) are required.

Services

3-year, 4-hour onsite, 13x5 coverage for hardware (U2855E)
3-year, 4-hour onsite, 24x7 coverage for hardware (U2856E)
3-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone support (U6304E)
3-year, 24x7 SW phone support, software updates (UE262E)
Installation with minimum configuration, system-based pricing (U4826E)
Installation with HP-provided configuration, system-based pricing (U4830E)
4-year, 4-hour onsite, 13x5 coverage for hardware (UR868E)
4-year, 4-hour onsite, 24x7 coverage for hardware (UR869E)
4-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone (UR870E)
4-year, 24x7 SW phone support, software updates (UR871E)
5-year, 4-hour onsite, 13x5 coverage for hardware (UR872E)
5-year, 4-hour onsite, 24x7 coverage for hardware (UR873E)
5-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone (UR874E)
5-year, 24x7 SW phone support, software updates (UR875E)
3 Yr 6 hr Call-to-Repair Onsite (UW356E)
4 Yr 6 hr Call-to-Repair Onsite (UW357E)
5 Yr 6 hr Call-to-Repair Onsite (UW358E)
1-year, 6 hour Call-To-Repair Onsite for hardware (HR893E)
1-year, 24x7 software phone support, software updates (HR892E)
1-year, 24x7 software phone support, software updates + Next Business Day Hardware Exchange
(HS610E)
1-year, 24x7 software phone support, software updates + 4 hour hardware exchange (HS611E)
3-year, 24x7 software phone support, software updates + Next Business Day Hardware Exchange

QuickSpecs

HP 2910 al Switch Series

Technical Specifications

DA - 13280 Worldwide — Version 20 — December 12, 2013

Page 15

(HS612E)
3-year, 24x7 software phone support, software updates + 4 hour Hardware Exchange (HS613E)
4-year, 24x7 software phone support, software updates + Next Business Day Hardware Exchange
(HS614E)
4-year, 24x7 software phone support, software updates + 4 hour Hardware Exchange (HS615E)
5-year, 24x7 software phone support, software updates + Next Business Day Hardware Exchange
(HS616E)
5-year, 24x7 software phone support, software updates + 4 hour Hardware Exchange (HS617E)

Refer to the HP website at:

www.hp.com/networking/services

for details on the service-level descriptions
and product numbers. For details about services and response times in your area, please contact your local
HP sales office.

HP 2910-48G al Switch

(J9147A)

Ports

44 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE

802.3ab Type 1000BASE-T); Media Type: Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or full;
1000BASE-T: full only

4 dual-personality ports; each port can be used as either an RJ-45 10/100/1000 port (IEEE 802.3 Type
10Base-T; IEEE 802.3u Type 100Base-TX; IEEE 802.3ab 1000Base-T Gigabit Ethernet) or as a mini-GBIC
slot (for use with mini-GBIC transceivers)

1 RJ-45 serial console port
Supports a maximum of 4 10GbE ports, with optional module

Physical characteristics

Dimensions

17.42(w) x 14.4(d) x 1.73(h) in (44.25 x 36.58 x 4.4 cm) (1U height)

Weight

11.2 lb (5.08 kg)

Memory and processor

Processor

Dual ARM1156T2S @ 515 MHz, 4 MB flash, 1 GB compact flash, 512 MB
SDRAM; packet buffer size: 6 MB

Mounting

Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included); horizontal surface
mounting only

Performance

1000 Mb Latency

< 2.9 µs (FIFO 64-byte packets)

10 Gbps Latency

< 1.3 µs (FIFO 64-byte packets)

Throughput

up to 131 million pps

Switching capacity

176 Gbps

Routing table size

2000 entries (IPv4)

MAC address table size

16000 entries

Environment

Operating temperature

32°F to 131°F (0°C to 55°C)

Operating relative
humidity

15% to 95% @ 104°F (40°C), non-condensing

Non-operating/
Storage temperature

-40°F to 158°F (-40°C to 70°C)

Non-operating/
Storage relative humidity

15% to 95% @ 149°F (65°C), non-condensing

Altitude

up to 10,000 ft (3 km)

Acoustic

Power: 53.5 dB, Pressure: 39.4 dB; DIN 45635T.19 per ISO 7779

Electrical characteristics

Achieved Miercom Certified Green Award

QuickSpecs

HP 2910 al Switch Series

Technical Specifications

DA - 13280 Worldwide — Version 20 — December 12, 2013

Page 16

* Products within this series have achieved sufficient scores in each of the rated criteria to achieve the
Miercom Certified Green distinction Award. See the Specifications section of this series for more
information.

Description

The switch automatically adjusts to any voltage between 100-127 and 200­240 volts and either 50 or 60 Hz

Maximum heat
dissipation

356 BTU/hr (376 kJ/hr)

Voltage

100-127/200-240 VAC

Current

2.1/1.1 A

Idle power

64 W

Maximum power rating

105 W

Frequency

50/60 Hz

Notes

Idle power is the actual power consumption of the device with no ports
connected.
Maximum power rating and maximum heat dissipation are the worst-case
theoretical maximum numbers provided for planning the infrastructure with
fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all
modules populated.

Safety

EN 60950/IEC 60950; CAN/CSA 22.2 No. 60950; EN 60825; UL 60950

Emissions

FCC part 15 Class A; EN 55022/CISPR-22 Class A; VCCI Class A

Immunity

EN

EN 55024, CISPR 24

ESD

IEC 61000-4-2; 4 kV CD, 8 kV AD

Radiated

IEC 61000-4-3; 3 V/m

EFT/Burst

IEC 61000-4-4; 1.0 kV (power line), 0.5 kV (signal line)

Surge

IEC 61000-4-5; 1 kV / 2 kV AC, 1 kV signal, 0.5 kV DC

Conducted

IEC 61000-4-6; 3 V

Power frequency
magnetic field

IEC 61000-4-8; 1 A/m

Voltage dips and
interruptions

IEC 61000-4-11; > 95% reductions, 0.5 period; 30% reduction, 25 periods

Harmonics

IEC 61000-3-2

Flicker

IEC 61000-3-3

Management

HP PCM+; HP PCM; command-line interface; Web browser; out-of-band management (serial RS-232C)

Notes

When using mini-GBICs with this product, mini-GBICs with revision "B" or later (product number ends with
the letter "B" or later, e.g., J4858B, J4859C) are required.

Services

3-year, 4-hour onsite, 13x5 coverage for hardware (H4496E)
3-year, 4-hour onsite, 24x7 coverage for hardware (H2893E)
3-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone support (U6319E)
3-year, 24x7 SW phone support, software updates (UE264E)
Installation with minimum configuration, system-based pricing (U4826E)
Installation with HP-provided configuration, system-based pricing (U4830E)
4-year, 4-hour onsite, 13x5 coverage for hardware (UR884E)
4-year, 4-hour onsite, 24x7 coverage for hardware (UR885E)
4-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone (UR886E)

QuickSpecs

HP 2910 al Switch Series

Technical Specifications

DA - 13280 Worldwide — Version 20 — December 12, 2013

Page 17
