QuickSpecs
HP 290 G3 Small Form Factor Business PC
Overview
Not all configuration components are available in all regions/countries.
c06636833 — DA 16664 — EMEA — Version 7— March 2, 2021
Page 1
HP 290 G3 Small Form Factor Business PC
Front
1.
Slim-height Bay - supporting an optical disk drive (optional)
2.
Power Button
3.
Microphone/Headphone Combo Jack
4.
(4) SuperSpeed USB 5Gbps signaling rate Ports1
5.
SD Media Card Reader
Not Shown
Slots
(1) PCI Express x16
(1) PCI Express x1
(1) M.2 for WLAN
(1) M.2 2242/2280 storage
Bays
(1) 3.5" or (2) 2.5” internal storage with caddy (share bay)
(1) 9.5mm internal optical drive bay
1. SuperSpeed USB 5Gbps = USB3.2 Gen1
QuickSpecs
HP 290 G3 Small Form Factor Business PC
Overview
Not all configuration components are available in all regions/countries.
c06636833 — DA 16664 — EMEA — Version 7— March 2, 2021
Page 2
HP 290 G3 Small Form Factor Business PC
Back
1.
Audio Line out
6.
Integrated accessories cable lock
2.
Audio Line in
7.
Serial Port
3.
HDMI Port1
8.
(4) USB 2.0 ports
4.
Standard lock slot
9.
RJ-45 Network Connector
5.
VGA Port1
10.
Power Cord Connector
11.
Padlock Loop
Not Shown
Parallel Port (Optional via PCIex1 slot)
4 Serial Port (Optional via PCIe slot)2
PS/2 Port (Optional)
Intrusion Sensor (Optional)
1. Port will be covered up when configured with processor which is without internal graphics.
2. Available to selected region.
AT A GLANCE
QuickSpecs
HP 290 G3 Small Form Factor Business PC
Standard Features and Configurable Modules
Not all configuration components are available in all regions/countries.
c06636833 — DA 16664 — EMEA — Version 7— March 2, 2021
Page 3
AT A GLANCE
• Windows 10 Pro, Windows 10 Home or FreeDos
• Intel® B460 chipset supporting Intel® 10
th
generation processors, featuring Intel® UHD Graphics
• Supports an optional discrete graphics card
• Integrated 10/100/1000 Ethernet Controller or 802.11a/b/g/n/ac (1x1) Wi-Fi® and Bluetooth® 4.2 Combo
• Up to 64GB DDR4-2933 Unbuffered Memory (UDIMM)
• Independent monitor support via VGA and HDMI interfaces
• TPM 2.0 support (firmware)
1
• Supports both Hard Disk Drives and SATA TLC / M.2 PCIe NVMe Solid State Drives
• 8 USB Ports (including 4 SuperSpeed USB 5Gbps ports)
• 180W Full range 115V/230V EPA 90%/85%
3
• Security cable lock supported (sold separately)
• Intrusion sensor supported (optional)
• Optional Care Services available; terms and conditions vary by country; certain restrictions and exclusions apply
2
1. TPM feature will be supported on machine pre-configured with FreeDOS, but will default set as disabled in BIOS setup menu. In some cases,
machines pre-configured with Windows OS might ship with TPM turned off.
2. HP Care Services sold separately. Service levels and response times for HP Care Services may vary depending on your geographic location.
Service starts on date of hardware purchase. Restrictions and limitations apply. For details, visit www.hp.com/go/cpc. HP services are governed
by the applicable HP terms and conditions of service provided or indicated to Customer at the time of purchase. Customer may have additional
statutory rights according to applicable local laws, and such rights are not in any way affected by the HP terms and conditions of service or the HP
Limited Warranty provided with your HP Product.
3. 85% is for specific regions only.
NOTE: See important legal disclosures for all listed specs in their respective features sections.
QuickSpecs
HP 290 G3 Small Form Factor Business PC
Standard Features and Configurable Modules
Not all configuration components are available in all regions/countries.
c06636833 — DA 16664 — EMEA — Version 7— March 2, 2021
Page 4
OPERATING SYSTEMS
Preinstalled (Windows)
Windows 10 Pro 641
Windows 10 Home 641
Pre-installed (Other)
FreeDOS
1. Not all features are available in all editions or versions of Windows. Systems may require upgraded and/or separately purchased hardware,
drivers, software or BIOS update to take full advantage of Windows functionality. Windows 10 is automatically updated, which is always enabled.
ISP fees may apply and additional requirements may apply over time for updates. See http://www.windows.com.
PROCESSORS
Intel® Celeron® Processors
2,3,4
CPU Intel Celeron G5900 Dual Core 3.4GHz 2666MHz 58W (3.4 GHz, 2 MB cache, 2 cores)
CPU Intel Celeron G5905 Dual Core 3.4GHz 2666MHz 58W (3.4 GHz, 2 MB cache, 2 cores)
Intel® Pentium®
2,3
CPU Intel Pentium G6400 Dual Core 4.0GHz 2666MHz 58W (4.0 GHz, 4 MB cache, 2 cores)
CPU Intel Pentium G6600 Dual Core 4.2GHz 2666MHz 58W (4.2 GHz 4 MB cache, 2 cores)
Intel 10th Processors
Intel® Core™ i3
2,3,4
CPU Intel Core i3-10100 4C 3.6GHz 2666MHz 65W (3.6GHz, turbo up to 4.1GHz, 6 MB cache, 4 cores)
Intel® Core™ i5
2,3,4
CPU Intel Core i5-10400 6C 2.9GHz 2666MHz 65W (2.9GHz, turbo up to 4.0GHz, 12 MB cache, 6 cores)
CPU Intel Core i5-10500 6C 3,1GHz 2666MHz 65W (3.1GHz, turbo up to 4.2GHz, 12 MB cache, 6 cores)
Intel® Core™ i7
2,3,4
CPU Intel Core i7-10700 8C 2.9GHz 2933MHz 65W (2.9GHz, Up to 4.8GHz with Intel® Turbo Boost5, 16MB cache, 8 cores)
2. Your product does not support Windows 8 or Windows 7, In accordance with Microsoft’s support policy, HP does not support the Windows® 8 or
Windows 7 operating system on products configured with Intel 8th generation and forward processors or provide any Windows® 8 or Windows 7
drivers on http://www.support.hp.com
3. Multicore is designed to improve performance of certain software products. Not all customers or software applications will necessarily benefit
from use of this technology. Performance and clock frequency will vary depending on application workload and your hardware and software
configurations. Intel’s numbering, branding and/or naming is not a measurement of higher performance.
4. In accordance with Microsoft’s support policy, HP does not support the Windows 8 or Windows 7 operating system on products configured with
Intel and AMD 7th generation and forward processors or provide any Windows 8 or Windows 7 drivers on http://www.support.hp.com.
5. Intel® Turbo Boost technology requires a PC with a processor with Intel Turbo Boost capability. Intel Turbo Boost performance varies depending
on hardware, software and overall system. See http://www.intel.com/technology/turboboost for more information.
QuickSpecs
HP 290 G3 Small Form Factor Business PC
Standard Features and Configurable Modules
Not all configuration components are available in all regions/countries.
c06636833 — DA 16664 — EMEA — Version 7— March 2, 2021
Page 5
CHIPSET
Intel® B460 Chipset
GRAPHICS
Integrated
6, 7
Intel® UHD
Graphics 630 (integrated on 10th Core i processors and Pentium Gold G6600 processor)
Intel® UHD
Graphics 610 (integrated on Pentium Gold G6400 and Celeron)
Discrete Graphics
AMD Radeon™ R7 430 2GB GFX
6. HD content required to view HD images.
7. Integrated Intel software is available on select models only and requires separately purchased projector, tv or computer monitor with an
integrated or external receiver. External receivers connect to the projector, tv or computer monitor via a standardVGA,HDMI cable, also sold
separately.
MEMORY
Both slots are customer accessible / upgradeable, Supports Dual Channel Memory
Form Factor
Type
Maximum
# of Slots
Small Form Factor
DDR4 2666 (Transfer rates up
to 2666 MT/s)
DDR4 2933 (Transfer rates up
to 2933 MT/s)
64 GB capacity
2 DIMM8
4 GB DDR4-2666 UDIMM (1x4GB)
4GB DDR4-2933 UDIMM NECC (1x4GB)
8GB DDR4-2933 UDIMM (1x8GB)
8GB DDR4-2933 UDIMM (1x4GB)
16GB DDR4-2933 UDIMM NECC (2x8GB)
16GB DDR4-2933 UDIMM NECC (1x16GB)
64GB DDR4-2933 UDIMM NECC (2x32GB)
8 GB DDR4-2666 UDIMM (1x8GB)
8 GB DDR4-2666 UDIMM (2x4GB)
16 GB DDR4-2666 UDIMM (1x16GB)
16 GB DDR4-2666 UDIMM (2x8GB)
64GB DDR4-2666 UDIMM (2x32GB)
8. Memory modules support data transfer rates up to 2933 MT/s; actual data rate is determined by the system's configured processor. See
processor specifications for supported memory data rate.
NOTE: DDR3-2933 UDIMM is only available for 10th Gen i7 processor.
QuickSpecs
HP 290 G3 Small Form Factor Business PC
Standard Features and Configurable Modules
Not all configuration components are available in all regions/countries.
c06636833 — DA 16664 — EMEA — Version 7— March 2, 2021
Page 6
STORAGE AND DRIVES
SATA3 - 3.5" or 2.5” 6Gb/s HDDs*
2TB 7200 RPM SATA Hard Disk Drive
1TB 7200 RPM SATA Hard Disk Drive
500GB 7200 RPM SATA Hard Disk Drive
M.2 Solid State Drives
128GB M.2 NVMe
256GB M.2 NVMe
512GB M.2 NVMe
SD Card Reader9
SD/SDHC/SDXC SD Card Reader
Intel Optane Memory*
SSD Intel 16GB 2280 Optane Memory
9. Card sold separately.
*NOTE: Optional per configuration
OPTICAL DISC DRIVES
DVD-ROM 9.5mm10
DVD-Writer 9.5mm10
10. Optical drives are optional or add on features. HD-DVD disks cannot be played on this drive. No support for DVD-RAM. Actual speeds may vary.
Don’t copy copyright-protected materials.
NETWORKING/COMMUNICATIONS
Networking
Integrated 10/100/1000M GbE LAN
Wi-Fi® and Bluetooth®11
802.11a/b/g/n/ac (1x1) Wi-Fi® and Bluetooth® 4.2 Combo
11. Wireless cards are optional or add-on features and requires separately purchased wireless access point and internet service. Availability of
public wireless access points limited. Wi-Fi 5 (802.11 ac) is backwards compatible with prior 802.11 specs.
AUDIO/MULTIMEDIA
Integrated Hi-Definition Audio
Combo Jack, Headphone/ Microphone
Line-in/ Line-out (3.5mm)
QuickSpecs
HP 290 G3 Small Form Factor Business PC
Standard Features and Configurable Modules
Not all configuration components are available in all regions/countries.
c06636833 — DA 16664 — EMEA — Version 7— March 2, 2021
Page 7
KEYBOARDS/POINTING DEVICES/BUTTONS AND FUNCTIONS KEYS
Keyboard
USB Business Slim Wired Keyboard
HP USB Wired Keyboard
Business Slim USB Antimicrobial Wired Keyboard (China)
No KB Option
Mouse
Antimicrobial USB Mouse (China)
HP Optical USB Mouse
Universal Wired USB Mouse
USB Hardened Mouse (Specific region)
No Mouse Option
PORTS
Front
Slim-height Bay - supporting an optical disk drive (optional)
(4) SuperSpeed USB 5Gbps signaling rate
SD Media Card Reader
Microphone/Headphone Combo Jack
Power Button
Not Shown
(1) PCI Express x16
(1) PCI Express x1
(1) M.2 for WLAN
(1) M.2 2242/2280 storage
Rear
Audio Line out
Audio Line in
HDMI Port
Standard lock slot
VGA Port
Serial Port
(4) USB 2.0 port
RJ-45 Network Connector
Power Cord Connector
Padlock loop
Integrated Accessories Cable Lock
QuickSpecs
HP 290 G3 Small Form Factor Business PC
Standard Features and Configurable Modules
Not all configuration components are available in all regions/countries.
c06636833 — DA 16664 — EMEA — Version 7— March 2, 2021
Page 8
Not Shown
(1) Parallel Port (Optional via PCIex1 slot)
(1) 4x Serial port (Optional via PCIex1 slot)
12
(1) PS/2 Port (Optional)
(1) Intrusion Sensor (Optional)
12. Available for selected regions
BAYS
(1) 3.5" or (2) 2.5" internal storage with caddy (share bay)
(1) 9.5mm internal optical drive bay
SOFTWARE COMPONENTS AND APPLICATIONS WITH WINDOWS
Security and Protection
McAfee* LiveSafe™ 13
Productivity
Buy Office (sold separately)
Dropbox
14
Xerox® DocuShare® (30 days free trial offer)18
ODD Playback
sMedio True DVD for HP
Movies
Netflix
16
App Stores and Content Purchasing
Amazon
15
HP Utilities and Support
HP Documentation
HP JumpStarts
HP Audio Switch
16
HP Support Assistant17
BTB HP Setup Integrated OOBE
Hardware Enabling Drivers or software utility
HP System Event Utility
QuickSpecs
HP 290 G3 Small Form Factor Business PC
Standard Features and Configurable Modules
Not all configuration components are available in all regions/countries.
c06636833 — DA 16664 — EMEA — Version 7— March 2, 2021
Page 9
*NOTE: Available for LA region only.
13. Free 1-year subscription of McAfee LiveSafe service included. Internet access required and not included. Subscription required after expiration
14. New Dropbox users are eligible to get 25 GB of Dropbox space free for 12 months from date of registration. For complete details and terms of
use, including cancellation policies, visit the Dropbox website at https://www.dropbox.com/help/space/hp-promotion. Internet service required
and not included.
15. Internet access required and not included.
16. Easily switch between speaker and microphone sources with intuitive controls and a consistent app experience
17. For more information visit hp.com/go/hpsupportassistant [Link will vary outside of the U.S.] HP Support Assistant is available for Android and
Windows based PCs.
18. Simply sign up and start using Xerox® DocuShare® Go. No credit card. No obligation. Data will become unavailable unless a subscription is
entered before the end of the 30 days free trial period. See visit https://www.xerox.com/docusharego for details.
POWER
Power Supply
180 W
EPA85 (Gold) Full range 115V/230V
WEIGHT AND DIMENSIONS
(configured with 1 HDD and 1 ODD)
Chassis (W x H x D)
3.74 x 10.63 x 11.65 in (95 x 270 x 296 mm)
System Weight
8.82 lbs / 4 kg*
*NOTE: Weight varies by configuration and component
UNIT ENVIRONMENTAL AND OPERATING CONDITIONS
General Unit Operating Guidelines
Environmental and Industry
• Keep the computer away from excessive moisture, direct moisture and the extremes
of heat and cold, to ensure that unit is operated within the specified operating range.
• Leave a 10.2 cm (4 in) clearance on all vented sides of the computer to permit the
required airflow.
• Never restrict airflow into the computer by blocking any vents or air intakes.
• Do not stack computers on top of each other or place computers so near each other
that they are subject to each other's re-circulated or preheated air.
• Occasionally clean the air vents on the front, back, and any other vented side of the
computer. Lint, dust and other foreign matter can block the vents and limit the airflow.
• If the computer is to be operated within a separate enclosure, intake and exhaust
ventilation must be provided on the enclosure, and the same operating guidelines
listed above will still apply.
Temperature Range
Operating:
5° to 35° C19
Non-operating:
-30° to 60°19
Relative Humidity
Operating:
5% to 90% (non-condensing at ambient)
Non-operating:
5% to 90% (non-condensing at ambient)
Maximum Altitude (unpressurized)
Operating:
5,000 m
QuickSpecs
HP 290 G3 Small Form Factor Business PC
Standard Features and Configurable Modules
Not all configuration components are available in all regions/countries.
c06636833 — DA 16664 — EMEA — Version 7— March 2, 2021
Page 10
Non-operating:
50,000 ft (15240 m)
19. Operating temperature is de-rated 1.0 deg C per 300 m (1000 ft) to 3000 m (10,000 ft) above sea level, no direct sustained sunlight.
Maximum rate of change is 10 deg C/Hr. The upper limit may be limited by the type and number of options installed.
Eco-Label Certifications &
declarations
This product has received or is in the process of being certified to the following approvals and
may be labeled with one or more of these marks:
• IT ECO declaration
• US ENERGY STAR®
• EPEAT® 2019 registered where applicable. EPEAT ® registration varies by country. See
http://www.epeat.net for registration status by country. Search keyword generator on HP’s 3rd
party option store for solar generator accessories at http://www.hp.com/go/options.
*Based on US EPEAT® registration according to IEEE 1680.1-2018 EPEAT®. Status varies by country. Visit
http://www.epeat.net for more information.
System Configuration
The configuration used for the Energy Consumption and Declared Noise Emissions data for the
Desktop model is based on a “Typically Configured Desktop”.
Energy Consumption
(in accordance with US
ENERGY STAR® test method)
115VAC, 60Hz
230VAC, 50Hz
100VAC, 50Hz
Normal Operation (Short idle)
19.49W
19.33W
19.3W
Normal Operation (Long idle)
17.74W
18.9W
18.5W
Sleep
1.45W
1.46W
1.47W
Off
0.28W
0.28W
0.28W
NOTE: Energy efficiency data listed is for an ENERGY STAR® compliant product if offered within the model
family. HP computers marked with the ENERGY STAR® Logo are compliant with the applicable U.S.
Environmental Protection Agency (EPA) ENERGY STAR® specifications for computers. If a model family does
not offer ENERGY STAR® compliant configurations, then energy efficiency data listed is for a typically
configured PC featuring a hard disk drive, a high efficiency power supply, and a Microsoft Windows®
operating system. Search keyword generator on HP’s 3rd party option store for solar generator accessories
at http://www.hp.com/go/options.
Heat Dissipation*
115VAC, 60Hz
230VAC, 50Hz
100VAC, 50Hz
Normal Operation (Short idle)
66.46 BTU/hr
65.92 BTU/hr
65.81 BTU/hr
Normal Operation (Long idle)
60.49 BTU/hr
64.45 BTU/hr
63.09 BTU/hr
Sleep
4.94 BTU/hr
4.98 BTU/hr
5.01 BTU/hr
Off
0.95 BTU/hr
0.95 BTU/hr
0.95 BTU/hr
NOTE: Heat dissipation is calculated based on the measured watts, assuming the service level is attained for
one hour.
Declared Noise Emissions
(in accordance with
ISO 7779 and ISO 9296)
Sound Power
(L
WAd
, bels)
Sound Pressure
(L
pAm
, decibels)
Typically Configured – Idle
3.8
26.1
Fixed Disk – Random writes
3.9
26.9
Longevity and Upgrading
This product can be upgraded, possibly extending its useful life by several years. Upgradeable
features and/or components contained in the product may include:
Spare parts are available throughout the warranty period and or for up to “3” years after the end
of production.
Batteries
This battery(s) in this product comply with EU Directive 2006/66/EC
QuickSpecs
HP 290 G3 Small Form Factor Business PC
Standard Features and Configurable Modules
Not all configuration components are available in all regions/countries.
c06636833 — DA 16664 — EMEA — Version 7— March 2, 2021
Page 11
Batteries used in the product do not contain:
Mercury greater the1ppm by weight
Cadmium greater than 20ppm by weight
Battery size: CR2032 (coin cell)
Battery type: Lithium
Additional Information
• This product is in compliance with the Restrictions of Hazardous Substances (RoHS) directive 2011/65/EC.
• This HP product is designed to comply with the Waste Electrical and Electronic Equipment
(WEEE) Directive – 2002/96/EC.
• This product is in compliance with California Proposition 65 (State of California; Safe Drinking
Water and Toxic Enforcement Act of 1986).
• This product is in compliance with the IEEE 1680.1 (EPEAT) standard at the <Silver> level, see
www.epeat.net
• Plastics parts weighing over 25 grams used in the product are marked per ISO11469 and
ISO1043.
• This product contains 28.2% post-consumer recycled plastic (by wt.)
• This product is 91.7% recycle-able when properly disposed of at end of life.
Packaging Materials
External:
PAPER/Paperboard
1220 g
Internal:
PAPER/Molded Pulp
520 g
PLASTIC/Polyethylene low density - LDPE
53 g
Material Usage
This product does not contain any of the following substances in excess of regulatory limits
(refer to the HP General Specification for the Environment at
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/gse.pdf):
• Asbestos
• Certain Azo Colorants
• Certain Brominated Flame Retardants – may not be used as flame retardants in plastics
• Cadmium
• Chlorinated Hydrocarbons
• Chlorinated Paraffins
• Formaldehyde
• Halogenated Diphenyl Methanes
• Lead carbonates and sulfates
• Lead and Lead compounds
• Mercuric Oxide Batteries
• Nickel – finishes must not be used on the external surface designed to be frequently handled or
carried by the user.
• Ozone Depleting Substances
• Polybrominated Biphenyls (PBBs)
• Polybrominated Biphenyl Ethers (PBBEs)
• Polybrominated Biphenyl Oxides (PBBOs)
• Polychlorinated Biphenyl (PCB)
• Polychlorinated Terphenyls (PCT)
• Polyvinyl Chloride (PVC) – except for wires and cables, and certain retail packaging has been
voluntarily removed from most applications.
• Radioactive Substances
• Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
QuickSpecs
HP 290 G3 Small Form Factor Business PC
Standard Features and Configurable Modules
Not all configuration components are available in all regions/countries.
c06636833 — DA 16664 — EMEA — Version 7— March 2, 2021
Page 12
Packaging Usage
HP follows these guidelines to decrease the environmental impact of product packaging:
• Eliminate the use of heavy metals such as lead, chromium, mercury and cadmium in packaging
materials.
• Eliminate the use of ozone-depleting substances (ODS) in packaging materials.
• Design packaging materials for ease of disassembly.
• Maximize the use of post-consumer recycled content materials in packaging materials.
• Use readily recyclable packaging materials such as paper and corrugated materials.
• Reduce size and weight of packages to improve transportation fuel efficiency.
• Plastic packaging materials are marked according to ISO 11469 and DIN 6120 standards.
End-of-life Management
and Recycling
HP Inc. offers end-of-life HP product return and recycling programs in many geographic areas. To
recycle your product, please go to: http://www.hp.com/go/reuse-recycle or contact your nearest
HP sales office. Products returned to HP will be recycled, recovered or disposed of in a
responsible manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information
for each product type for use by treatment facilities. This information (product disassembly
instructions) is posted on the Hewlett Packard web site at: http://www.hp.com/go/recyclers.
These instructions may be used by recyclers and other WEEE treatment facilities as well as HP
OEM customers who integrate and re-sell HP equipment.
Global Citizenship Report
http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html
Eco-label certifications
http://www8.hp.com/us/en/hp-information/environment/ecolabels.html
ISO 14001 certificates:
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/PC_GBU_Product_Design_ISO_1
4K_Certificate.pdf
and
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/cert.pdf
SERVICE AND SUPPORT
On-site Warranty20: Available three-year (3-3-3) or one-year (1-1-1) limited warranty (varies by country) delivers on-site,
next business day21 service for parts and labor and complimentary limited technical support22. Three-year onsite and labor
are not available in all countries. Service offers terms up to 5 years by choosing an optional HP Care Service23. To choose the
right level of service for your HP product, visit HP Care Pack Central: http://www.hp.com/go/cpc.
20. Terms and conditions may vary by country. Certain restrictions and exclusions apply. Other warranty variations may be offered in your region.
21. On-site service may be provided pursuant to a service contract between HP and an authorized HP third-party provider and is not available in
certain countries. Global service response times are based on commercially reasonable best effort and may vary by country.
22. Technical support applies only to HP-configured and third-party HP qualified hardware and software.
23. Service levels and response times for HP Care Services may vary depending on your geographic location. Service starts on date of hardware
purchase. Restrictions and limitations apply. For details, visit www.hp.com/go/cpc. HP services are governed by the applicable HP terms and
conditions of service provided or indicated to Customer at the time of purchase. Customer may have additional statutory rights according to
applicable local laws, and such rights are not in any way affected by the HP terms and conditions of service or the HP Limited Warranty provided
with your HP Product.
GRAPHICS
QuickSpecs
HP 290 G3 Small Form Factor Business PC
Technical Specifications - Graphics
Not all configuration components are available in all regions/countries.
c06636833 — DA 16664 — EMEA — Version 7— March 2, 2021
Page 13
GRAPHICS
Intel® UHD Graphics 630 (integrated on Core i7/i5/i3/Pentium G6500 and above processors)
Intel® UHD Graphics 610 (integrated on Pentium G6400 and below/ and Celeron)
DisplayPort™
Multimode capable; supports HDCP, DisplayPort™ Audio (2 streams), HBR2 link rates and
Multi-Stream Technology for a maximum of 3 displays (including the integrated panel)
Maximum Graphics Memory
Microsoft Windows 7
Windows 8.1
Windows 10
Up to 1.7GB
Up to 1.8GB
>4 GB
Note: the actual amount of maximum graphics memory can be less than the amounts listed above
depending upon your computer’s configuration.
Maximum Color Depth
32 bits/pixel
Graphics/Video API Support
10th Generation Intel® Core™ processors/Pentium G6500 and above:
• With Intel® UHD Graphics 630
• DirectX 12, OpenGL 4.3, OpenCL 1.2, Intel® Quick Sync Video
Pentium G6400 and below/ and Celeron
• With Intel® UHD Graphics 610
• DirectX 12, OpenGL 4.3, OpenCL 1.2, Intel® Quick Sync Video
Supported Display Resolutions
and Refresh Rates
Max. Resolution (VGA) 2048 x 1536@60Hz
Max. Resolution (HDMI) 4096 x 2160@60Hz
Note: other resolutions may be available but are not recommended as they may not have been tested and qualified by HP.
* Only supported on displays connected to the external DisplayPort connector.
AMD Radeon™ R7 430 2GB Graphics Card
Engine Clock
780 MHz
Memory Clock
1100 MHz
Memory Size(width)
2GB(64-bit)
Memory Type
256M x 32 GDDR5
Max. Resolution(VGA)
2048x1536
Max. Resolution(DP)
4096x2160@60Hz
Multi Display Support
2 displays
HDCP Compliance
yes
Rear I/O connectors(bracket)
VGA+DP
Cooling(active/passive)
Active fan-sink (Active cooling with dynamic speed)
Total power consumption(W)
<50W
PCB form-factor with bracket
LP PCB with FH/LP bracket
QuickSpecs
HP 290 G3 Small Form Factor Business PC
Technical Specifications - Storage
Not all configuration components are available in all regions/countries.
c06636833 — DA 16664 — EMEA — Version 7— March 2, 2021
Page 14
STORAGE
HP 2 TB* 7.2K rpm SATA 6.0Gb/s 3.5" Hard Disk Drive*
Capacity
2 TB
Rotational Speed
7,200 rpm
Interface
SATA 6Gb/s NCQ
Buffer Size
64 MB
Logical Blocks
3,907,029,168
Seek Time
Read: <8.5 ms
Write: <9.5 ms
Height
1.028 in/26.11 mm
Width
4.0 in/101.6 mm
Operating Temperature
32° to 140° F (0° to 60° C)
1TB 7.2K rpm SATA 6.0Gb/s 3.5” Hard Disk Drive
Capacity
1 TB
Rotational Speed
7,200 rpm
Interface
Serial ATA 3.0 (6.0 Gb/s)
Buffer Size
32 MB
Logical Blocks
1,953,525,168
Seek Time
Read: <8.5 ms
Write: <9.5 ms
Full-Stroke: 21 ms
Height
1 in/2.54 cm
Width
Media diameter: 3.5 in/8.89 cm
Physical size: 4 in/10.2 cm
Operating Temperature
41° to 131° F (5° to 55° C)
500GB 7.2K rpm SATA 6.0Gb/s 3.5” Hard Disk Drive
Capacity
500 GB
Rotational Speed
7,200 rpm
Drive Type
Serial ATA 3.0 (6.0 Gb/s)
Interface
32 MB
Buffer Size
976,773,168
Seek Time
Single Track: 2.0 ms
Average: 11 ms
Full-Stroke: 21 ms
Height
1 in/2.54 cm
Width
Media diameter: 3.5 in/8.89 cm
Physical size: 4 in/10.2 cm
QuickSpecs
HP 290 G3 Small Form Factor Business PC
Technical Specifications - Storage
Not all configuration components are available in all regions/countries.
c06636833 — DA 16664 — EMEA — Version 7— March 2, 2021
Page 15
Operating Temperature
41° to 131° F (5° to 55° C)
128 GB M.2 2280 PCIe NVMe Three Layer Cell SSD
Drive Weight
< 10g
Capacity
128 GB
Height
2.38mm
Length
80mm
Width
22mm
Interface
PCIE Gen3x4
Maximum Sequential Read
Up to 2800MB/s
Maximum Sequential Write
Up to 600MB/s
Logical Blocks
250,069,680
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
APST; ASPM L1.2; NVME spec 1.2
256 GB M.2 2280 PCIe NVMe Three Layer Cell SSD
Drive Weight
< 10g
Capacity
256 GB
Height
2.38mm
Length
80mm
Width
22mm
Interface
PCIE Gen3x4
Maximum Sequential Read
Up to 2700MB/s
Maximum Sequential Write
Up to 1000MB/s
Logical Blocks
500,118,192
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
APST; ASPM L1.2; NVME spec 1.2
512 GB M.2 2280 PCIe NVMe Three Layer Cell SSD
Drive Weight
< 10g
Capacity
512 GB
Height
2.38mm
Length
80mm
Width
22mm
Interface
PCIE Gen3x4
Maximum Sequential Read
Up to 2900MB/s
Maximum Sequential Write
Up to 1100MB/s
QuickSpecs
HP 290 G3 Small Form Factor Business PC
Technical Specifications - Storage
Not all configuration components are available in all regions/countries.
c06636833 — DA 16664 — EMEA — Version 7— March 2, 2021
Page 16
Logical Blocks
1,000,215,216
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
APST; ASPM L1.2; NVME spec 1.2
256 GB M.2 2280 PCIe NVMe SSD
Drive Weight
< 10g
Capacity
256 GB
Height
2.38mm
Length
80mm
Width
22mm
Interface
PCIE Gen3
Maximum Sequential Read
Up to 1600MB/s
Maximum Sequential Write
Up to 780MB/s
Logical Blocks
500,118,192
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
APST; ASPM L1.2; NVME spec 1.2
512 GB M.2 2280 PCIe NVMe SSD
Drive Weight
< 10g
Capacity
512 GB
Height
2.38mm
Length
80mm
Width
22mm
Interface
PCIE Gen3
Maximum Sequential Read
Up to 1600MB/s
Maximum Sequential Write
Up to 860MB/s
Logical Blocks
1,000,215,216
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
APST; ASPM L1.2; NVME spec 1.2
500 GB 7200RPM 2.5in SATA HDD
Capacity
500 GB
Rotational Speed
7,200 rpm
Interface
SATA 6 Gb/s
Buffer Size
32 MB
Logical Blocks
976,773,168
Seek Time
12 ms (Average)
Height
0.267 in/6.8 mm (nominal)
QuickSpecs
HP 290 G3 Small Form Factor Business PC
Technical Specifications - Storage
Not all configuration components are available in all regions/countries.
c06636833 — DA 16664 — EMEA — Version 7— March 2, 2021
Page 17
Width (nominal)
2.75 in/70 mm (nominal)
Operating Temperature
41° to 131° F (5° to 55° C)
1TB 7200RPM 2.5in SATA HDD
Capacity
1 TB
Rotational Speed
7,200 rpm
Interface
SATA 6 Gb/s
Buffer Size
32 MB
Logical Blocks
1,953,525,168
Seek Time
12 ms (Average)
Height
0.374 in/9.5 mm (nominal)
Width (nominal)
2.75 in/70 mm (nominal)
Operating Temperature
41° to 131° F (5° to 55° C)
NOTE*: For storage drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 30GB of disk is reserved for system
recovery software.
QuickSpecs
HP 290 G3 Small Form Factor Business PC
Technical Specifications – Optical Disc Drives
Not all configuration components are available in all regions/countries.
c06636833 — DA 16664 — EMEA — Version 7— March 2, 2021
Page 18
OPTICAL DISC DRIVES
HP 9.5mm Desktop G2 Slim DVD Writer Drive
Height
9.5 mm height
Orientation
Either horizontal or vertical
Interface type
SATA/ATAPI
Disc recording capacity
Up to 8.5 GB DL or 4.7 GB standard
Dimensions (W x H x D)
5.04 x 0.37 x 5.0 in (128 x 9.5 x 127 mm) without bezel
Weight (max)
0.31 lb (140 g)
Read Speeds
DVD-R DL - Up to 6X
DVD+R - Up to 8X
DVD+RW - Up to 8X
DVD+R DL - Up to 6X
DVD-R - Up to 8X
DVD-RW - Up to 6X
CD-R - Up to 24X
CD-RW - Up to 10X
DVD-RW, DVD+RW - Up to 8X
DVD-R DL, DVD+R DL - Up to 8X
DVD+R, DVD-R - Up to 8X
DVD-ROM DL, DVD-ROM - Up to 8X
CD-ROM, CD-R - Up to 24X
CD-RW - Up to 24X
Access time
(typical reads, including
settling)
Random DVD-ROM: 170 ms (typical), CD-ROM: 170 ms (typical)
Full Stroke DVD-ROM: 320 ms (typical), CD-ROM: 320 ms (typical)
Stop Time 6 seconds (typical)
Power
Source Slimline SATA DC power receptacle
DC Power Requirement 5 VDC ± 5%-100 mV ripple p-p
DC Current 5 VDC (< 1000 mA typical, 1600 mA maximum)
Environmental conditions
(operating - non-condensing)
Temperature 41° to 122° F (5° to 50° C)
Relative Humidity 10% to 80%
Maximum Wet Bulb Temperature 84° F (29° C)
HP 9.5mm Desktop G2 Slim DVD-ROM Drive
Height
9.5 mm height
Orientation
Either horizontal or vertical
Interface type
SATA/ATAPI
Disc recording capacity
Up to 8.5 GB DL or 4.7 GB standard
Dimensions (W x H x D)
5.04 x 0.37 x 5.0 in (128 x 9.5 x 127 mm) without bezel
Weight (max)
0.31 lb (140 g)
Read Speeds
DVD-R DL - Up to 6X
DVD+R - Up to 8X
DVD+RW - Up to 8X
DVD+R DL - Up to 6X
DVD-R - Up to 8X
DVD-RW - Up to 6X
CD-R - Up to 24X
QuickSpecs
HP 290 G3 Small Form Factor Business PC
Technical Specifications – Optical Disc Drives
Not all configuration components are available in all regions/countries.
c06636833 — DA 16664 — EMEA — Version 7— March 2, 2021
Page 19
CD-RW - Up to 10X
DVD-RW, DVD+RW - Up to 8X
DVD-R DL, DVD+R DL - Up to 8X
DVD+R, DVD-R - Up to 8X
DVD-ROM DL, DVD-ROM - Up to 8X
CD-ROM, CD-R - Up to 24X
CD-RW - Up to 24X
Access time
(typical reads, including
settling)
Random DVD-ROM: 170 ms (typical), CD-ROM: 170 ms (typical)
Full Stroke DVD-ROM: 320 ms (typical), CD-ROM: 320 ms (typical)
Stop Time 6 seconds (typical)
Power
Source Slimline SATA DC power receptacle
DC Power Requirement 5 VDC ± 5%-100 mV ripple p-p
DC Current 5 VDC (< 1000 mA typical, 1600 mA maximum)
Environmental conditions
(operating - non-condensing)
Temperature 41° to 122° F (5° to 50° C)
Relative Humidity 10% to 80%
Maximum Wet Bulb Temperature 84° F (29° C)
QuickSpecs
HP 290 G3 Small Form Factor Business PC
Technical Specifications – Audio
Not all configuration components are available in all regions/countries.
c06636833 — DA 16664 — EMEA — Version 7— March 2, 2021
Page 20
High Definition Audio
Type
Integrated
HD Audio Codec
Realtek ALC3601
Audio I/O Ports
Front side Combo jack for supporing CTIA, Rear side Line-in/ Line-out/ Mic-in jacks
Wavetable Syntheses
Yes
Analog Audio
Yes
Internal Speaker
NA
DAC Sampling Rates
16 to 24-bit; 44.1K/ 48 K/96K / 192K Hz
ADC Sampling Rates
16 bit, 44.1K/ 48K/ 96K/ 192K Hz
QuickSpecs
HP 290 G3 Small Form Factor Business PC
Technical Specifications - Power
Not all configuration components are available in all regions/countries.
c06636833 — DA 16664 — EMEA — Version 7— March 2, 2021
Page 21
POWER SUPPLY
P/S 180W SFF ENTS20L EAP85
Operating Voltage Range
180 – 264 VAC
Rated Voltage Range
200-240V AC
Rated Line Frequency
50/60 HZ
Operating Line Frequency
47 – 63 Hz
Rated Input Current
180W : <1.3A
Rated Input Current with
Energy Efficient* Power
Supply
82/85/82% efficient at 20/50/100% load (230V)
DC Output
+12.1V
Current Leakage (NFPA 99:
2102)
Less than 500 microamps of leakage current at 120 Vac with the ground wire disconnected, as
required for Non-patient Electrical Appliances and Equipment used in a patient care facility or
that contact patients in normal use. Per section 10.3.5.1.
Less than 100 microamps of leakage current at 120 Vac with the ground wire intact with normal
polarity, as required for Non-patient Electrical Appliances and Equipment used in a patient care
facility or that contact patients in normal use. Per section 10.3.5.1.
Power Supply Fan
50 x 20 mm (linear type)
P/S 180W SFF ENTS20L EAP90
Operating Voltage Range
90 – 264 VAC
Rated Voltage Range
100-240V AC
Rated Line Frequency
50/60 HZ
Operating Line Frequency
47 – 63 Hz
Rated Input Current
180W : <2.3A
Rated Input Current with
Energy Efficient* Power
Supply
87/90/87% efficient at 20/50/100% load (115Vac)
88/92/88% efficient at 20/50/100% load (230V)
DC Output
+12.1V
Current Leakage (NFPA 99:
2102)
Less than 500 microamps of leakage current at 120 Vac with the ground wire disconnected, as
required for Non-patient Electrical Appliances and Equipment used in a patient care facility or
that contact patients in normal use. Per section 10.3.5.1.
Less than 100 microamps of leakage current at 120 Vac with the ground wire intact with normal
polarity, as required for Non-patient Electrical Appliances and Equipment used in a patient care
facility or that contact patients in normal use. Per section 10.3.5.1.
Power Supply Fan
50 x 20 mm (linear type)
QuickSpecs
HP 290 G3 Small Form Factor Business PC
Technical Specifications – Weights and Dimensions
Not all configuration components are available in all regions/countries.
c06636833 — DA 16664 — EMEA — Version 7— March 2, 2021
Page 22
WEIGHTS AND DIMENSIONS
Chassis (W x D x H)
3.74 x 11.93 x 10.63 in (95 x 303 x 270 mm) (w/ bezel)
System Volume
463.16cu in
7.6L
System Weight*
8.82 lbs / 4 kg
Packaged
(H x W x D)
13.46 x 7.72 x 19.65 in
342 x 196 x 499 mm
Shipping Weight*
13.2 lb / 6 kg
Shipping Weight
(Molded Pulp)*
13.86 lb / 6.3 kg
Palletization
Profile
12-units per layer
6 layer max
72 per pallet
Footprint (H x W x D)
85.91 x 39.37 x 47.24 in
(2182 x 1000 x 1200 mm)
*NOTE: Weight varies by configuration and component
QuickSpecs
HP 290 G3 Small Form Factor Business PC
Technical Specifications – Networking
Not all configuration components are available in all regions/countries.
c06636833 — DA 16664 — EMEA — Version 7— March 2, 2021
Page 23
NETWORKING
10/100/1000 Integrated NIC
Ethernet Features
10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-14)
100 Mbit/s operation (100BASE-TX; IEEE 802.3u; IEEE 802.3 clauses 21-30)
1000 Mbit/s operation (1000BASE-T; IEEE 802.3ab; IEEE 8023 clauses 40)
Auto-Negotiation (Automatic Speed Selection)
Full Duplex Operation at all Speeds, Half Duplex operation at 10 and 100 Mbit/s
Power Management
ACPI compliant – multiple power modes
Situation-sensitive features reduce power consumption
Advanced link down power saving for reducing link down power consumption
Performance Features
TCP/IP/UDP Checksum Offload (configurable)
Protocol Offload (ARP & NS)
Large send offload and Giant send offload
Receiving Side Scaling
Jumbo Frame 9K
Manageability
Wake-on-LAN from standby and hibernation (Magic Packet and Microsoft Wake-Up
Frame); Wake-on-LAN from off (Magic Packet only)
PXE 2.1 Remote Boot
Statistics Gathering (SNMP MIB II, Ethernet-like MIB, Ethernet MIB (802.3x, clause 30))
Comprehensive diagnostic and configuration software suite
Virtual Cable Doctor for Ethernet cable status
Realtek 802.11ac (1x1) Wi-Fi® and Bluetooth® 4.2 Combo *
Wireless LAN Standards1
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac
1. Wireless access point and Internet service required and not included. Availability of public wireless
access points limited.
Interoperability
Wi-Fi® certified modules
Frequency Bands
802.11b/g/n
•2.402 – 2.482 GHz
Note: The FCC has declared as of January 1, 2015 products that utilize
passive scanning on channel 12/13 and are capable of transmitting must
fully comply with requirements of 15.247 or otherwise disable those
channels.
802.11a/n
•4.9 – 4.95 GHz (Japan)
•5.15 – 5.25 GHz
•5.25 – 5.35 GHz
•5.47 – 5.725 GHz
•5.825 – 5.850
QuickSpecs
HP 290 G3 Small Form Factor Business PC
Technical Specifications – Networking
Not all configuration components are available in all regions/countries.
c06636833 — DA 16664 — EMEA — Version 7— March 2, 2021
Page 24
Data Rates
• •802.11b: 1, 2, 5.5, 11 Mbps
• •802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• •802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• •802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)
• •802.11ac : MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, and 80MHz)
Modulation
Direct Sequence Spread Spectrum
BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM
Security2
• •IEEE and 64 / 128 bit WEP encryption for a/b/g mode only
• •AES-CCMP: 128 bit in hardware
• •802.1x authentication
• •WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.
• •WPA2 certification
• •IEEE 802.11i
• •Cisco Certified Extensions, all versions through CCX4 and CCX Lite
• •WAPI
2 Check latest software/driver release for updates on supported security features.
Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power3
• • 802.11b : +14dBm minimum
• • 802.11g : +12dBm minimum
• • 802.11a : +12dBm minimum
• • 802.11n HT20(2.4GHz) : +12dBm minimum
• • 802.11n HT40(2.4GHz) : +12dBm minimum
• • 802.11n HT20(5GHz) : +10dBm minimum
• • 802.11n HT40(5GHz) : +10dBm minimum
• • 802.11ac VHT80(5GHz) : +10dBm minimum
3. Maximum output power may vary by country according to local regulations.
Power Consumption
•Transmit mode2.0 W
•Receive mode1.6 W
•Idle mode (PSP)180 mW(WLAN Associated)
•Idle mode50 mW(WLAN unassociated)
•Connected Standby 10mW
•Radio disabled8 mW
Power Management
ACPI and PCI Express compliant power management
802.11 compliant power saving mode
Receiver Sensitivity4
802.11b, 1Mbps : -93.5dBm maximum
QuickSpecs
HP 290 G3 Small Form Factor Business PC
Technical Specifications – Networking
Not all configuration components are available in all regions/countries.
c06636833 — DA 16664 — EMEA — Version 7— March 2, 2021
Page 25
802.11b, 11Mbps : -84dBm maximum
802.11a/g, 6Mbps : -86dBm maximum
802.11a/g, 54Mbps : -72dBm maximum
802.11n, MCS07 : -67dBm maximum
802.11n, MCS15 : -64dBm maximum
802.11ac, MCS0 : -84dBm maximum
802.11ac, MCS9 : -59dBm maximum
4 Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a packet
error rate of 10% for 802.11a/g (OFDM modulation).
Antenna type
High efficiency antenna.
One embedded dual band 2.4/5 GHz antenna is provided to the card to support WLAN
communications and Bluetooth communications
Form Factor
PCI-Express M.2 MiniCard
Dimensions
Type 2230 : 2.3 x 22.0 x 30.0 mm
Weight
Type 2230 : 2.8g
Operating Voltage
3.3v +/- 9%
Temperature
Operating:
Non-operating:
14° to 158° F (-10° to 70° C)
-40° to 176° F (-40° to 80° C)
Humidity
Operating:
Non-operating:
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude
Operating:
Non-operating:
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
LED Activity
LED Amber – Radio OFF; LED White – Radio ON
HP Integrated Module with Bluetooth 4.0/4.1/4.2 Wireless Technology
Bluetooth Specification
4.0/4.1/4.2 Compliant
Frequency Band
2402 to 2480 MHz
Number of Available Channels
Legacy : 0~79 (1 MHz/CH)
BLE : 0~39 (2 MHz/CH)
Data Rates and Throughput
Legacy : 3 Mbps data rate; throughput up to 2.17 Mbps
BLE : 1 Mbps data rate; throughput up to 0.2 Mbps
Legacy : Synchronous Connection Oriented links up to 3, 64 kbps, voice channels
Legacy : Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric (3-DH5) or
864 kbps symmetric (3-EV5)
Transmit Power
The Bluetooth component shall operate as a Class II Bluetooth device with a maximum
transmit power of + 4 dBm for BR and EDR.
Receiver Sensitivity Legacy
Power Consumption
Peak (Tx) 330 mW
Peak (Rx) 230 mW
QuickSpecs
HP 290 G3 Small Form Factor Business PC
Technical Specifications – Networking
Not all configuration components are available in all regions/countries.
c06636833 — DA 16664 — EMEA — Version 7— March 2, 2021
Page 26
Selective Suspend 17 mW
Range
Legacy : 0~79 (1 MHz/CH)
BLE : 0~39 (2 MHz/CH)
Electrical Interface
USB 2.0 compliant
Bluetooth Software
Supported
Link Topology
Microsoft Windows Bluetooth Software
Power Management
Certifications
Microsoft Windows ACPI, and USB Bus Support
Certifications
Bluetooth Profiles Supported
BT4.1-ESR 5/6/7 Compliance
LE Link Layer Ping
LE Dual Mode
LE Link Layer
LE Low Duty Cycle Directed Advertising
LE L2CAP Connection Oriented Channels
Train Nudging & Interlaced Scan
BT4.2 ESR08 Compliance
LE Secure Connection- Basic/Full
LE Privacy 1.2 –Link Layer Privacy
LE Privacy 1.2 –Extended Scanner Filter Policies
LE Data Packet Length Extension
FAX Profile (FAX)
Basic Imaging Profile (BIP)2
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)
QuickSpecs
HP 290 G3 Small Form Factor Business PC
After-Market Options (availability may vary by region)
Not all configuration components are available in all regions/countries.
c06636833 — DA 16664 — EMEA — Version 7— March 2, 2021
Page 27
AFTER MARKET OPTIONS
Type
Description
Part #
Memory
HP 4GB DDR4-2666 DIMM
3TK85AA
HP 8GB DDR4-2666 DIMM
3TK87AA
HP 16GB DDR4-2666 DIMM
3TK83AA
Storage
HP 500GB SATA 6.0Gb/s Hard Drive
QK554AA
HP 1TB 7200rpm SATA 6Gbps Hard Drive
QK555AA
HP Turbo Drive Gen2 256GB M.2 SSD Drive
1CA51AA
HP 256GB SATA TLC Non-SED Solid State Drive
P1N68AA
HP 9.5mm G3 8/6/4 SFF G4 400 SFF/MT DVD Writer
1CA53AA
Graphics
AMD Radeon™ R7 430 2GB 2DP Card
5JW82AA
Security
HP Business PC Security Lock V3 Kit
3XJ17AA
HP Keyed Cable Lock 10mm kit
T1A62AA
Adapters
HP PCIe x1 Parallel Port Card
N1M40AA
HP HDMI Standard Cable Kit
T6F94AA
HP USB to Serial Port Adapter
J7B60AA
Networking
Intel Ethernet I210-T1 GbE NIC Card
E0X95AA
Input
HP USB Mouse
QY777AA
HP USB Hardened Mouse
P1N77AA
HP USB Grey v2 Mouse
Z9H74AA
HP USB Keyboard
QY776AA
HP USB Business Slim Keyboard
N3R87AA
HP USB Antimicrobial Slim Keyboard and Mouse
Z9H50AA
Others
HP Business Headset v2
T4E61AA
HP S101 Speaker bar
5UU40AA
QuickSpecs
HP 290 G3 Small Form Factor Business PC
Change Log
Not all configuration components are available in all regions/countries.
c06636833 — DA 16664 — EMEA — Version 7— March 2, 2021
Page 28
© Copyright 2021 HP Development Company, L.P.
The information contained herein is subject to change without notice. The only warranties for HP products are set forth in the
express limited warranty statements accompanying such products. Nothing herein should be construed as constituting an
additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
Microsoft and Windows are registered trademarks or trademarks of Microsoft Corporation in the U.S. and/or other countries. Intel,
Celeron®, Core, Pentium are registered trademarks or trademarks of Intel Corporation in the U.S. and/or other countries. Bluetooth
is a trademark of its proprietor, used by HP Inc. under license. NVIDIA, GeForce, Kepler and NVS are trademarks and/or registered
trademarks of NVIDIA Corporation in the U.S. and other countries. AMD and Radeon are trademarks of Advanced Micro Devices, Inc.
DisplayPort™ and the DisplayPort™ logo are trademarks owned by the Video Electronics Standards Association (VESA®) in the
United States and other countries.
Wi-Fi® is a registered trademark of Wi-Fi Alliance®.
Date of change:
Version History:
Description of change:
From v1 to v2
Added
Intel Celeron G5905
From v2 to v3
Correction
Dimensions order
From v3 to v4
Addition
Xerox® DocuShare® and footnote to software section.
From v4 to v5
Addition
Disclaimer and I7-10700 information update in processors section.
From v5 to v6
Addition
UNIT ENVIRONMENTAL AND OPERATING CONDITIONS
From v6 to v7
Update
Xerox specs and disclaimer updated in Software section
Loading...
