Page 1
QuickSpecs
HP 280 G6 Microtower Business PC
Overview
Not all configuration components are available in all regions/countries.
c06590382 — DA-16652 — Worldwide — Version 9 — March 3, 2021
Page 1
HP 280 G6 Microtower Business PC
Front
1.
Slim-height Bay - supporting an optical disk drive (Optional)
2.
Power Button
3.
Combo jack, Headphone/ Microphone
4.
(4) SuperSpeed USB 5Gbps port2
5.
(2) SuperSpeed USB 10Gbps port2
6.
SD Card Reader (Optional)
Not Shown
Slots
(1) PCI Express x16
(1) PCI Express x1
(1) PCI1
(1) M.2 for WLAN
(1) M.2 2242/2280 storage
Bays
(1) 3.5" or 2.5” internal HDD bay
(1) 3.5” or 2.5” internal HDD bay (share bay with caddy)
(1) 9.5mm internal optical drive bay
1. Available on select skus only.
2. SuperSpeed USB 10Gbps = USB 3.2 Gen2. SuperSpeed USB 5Gbps = USB 3.2 Gen1
Page 2
QuickSpecs
HP 280 G6 Microtower Business PC
Overview
Not all configuration components are available in all regions/countries.
c06590382 — DA-16652 — Worldwide — Version 9 — March 3, 2021
Page 2
HP 280 G6 Microtower Business PC
Back
1.
Audio Line out
7.
Serial Port3
2.
Audio Line in
8.
Connector (2) USB 2.0 port
3.
Standard lock slot
9.
RJ-45 Network
4.
HDMI Port1
10.
Serial Port (Optional)
5.
VGA Port1
11.
Integrated accessories cable lock
6.
Connector (2) USB 2.0 port (Optional)3
12.
Power Cord Connector4
13.
Padlock Loop
Not Shown
(1) PS/2 Port (Optional)
(1) Parallel Port (Optional via PCIex1 slot)
(1) 4 Serial Port (Optional via PCIex1 slot)2
(1) Internal Speaker (Optional)
(1) Intrusion Sensor (Optional)
1. Port will be covered up when configured with processor which is without internal graphics.
2. Available in select countries only.
3. Available on select skus only.
4. Power cord connector will be in different position, depends on which power supply configured.
Page 3
QuickSpecs
HP 280 G6 Microtower Business PC
Standard Features and Configurable Modules
Not all configuration components are available in all regions/countries.
c06590382 — DA-16652 — Worldwide — Version 9 — March 3, 2021
Page 3
AT A GLANCE
• Windows 10 Pro, Windows 10 Home or FreeDOS
• Intel® H470 chipset supporting Intel® 10
th
processors featuring Intel® UHD Graphics
• Supports an optional discrete graphics card
• Integrated 10/100/1000 Ethernet Controller or 802.11ac (1x1) Wi-Fi® and Bluetooth® 4.2 Combo
• Up to 64GB DDR4- 2933 Unbuffered Memory (UDIMM)
• Independent monitor support via VGA and HDMI interfaces
• TPM 2.0 support (either dTPM or fTPM)
1
• Supports both Hard Disk Drives and M.2 PCIe NVMe Solid State Drives
• Up to 10 USB Ports (including native 4 SuperSpeed USB 5Gbps ports and 2 SuperSpeed USB 10Gbps
3
and 2 USB 2.0 ports)
• 180W/310W 90% HE power supply
• Security cable lock supported (sold separately)
• Intrusion sensor supported (Optional)
• Optional HP Care Services available; terms and conditions vary by country; certain restrictions and exclusions apply
2
1. TPM feature will be supported on machine pre-configured with FreeDOS, and will be default set as enabled in BIOS setup menu if the machine is
dTPM, but will be default set as disabled in BIOS setup menu if the machine is fTPM.
2. HP Care Services are optional. Service levels and response times for HP Care Services may vary depending on your geographic location. Service
starts on date of hardware purchase. Restrictions and limitations apply. For details, visit www.hp.com/go/cpc. HP services are governed by the
applicable HP terms and conditions of service provided or indicated to Customer at the time of purchase. Customer may have additional statutory
rights according to applicable local laws, and such rights are not in any way affected by the HP terms and conditions of service or the HP Limited
Warranty provided with your HP Product.
3. SuperSpeed USB 10Gbps = USB 3.2 Gen2. SuperSpeed USB 5Gbps = USB 3.2 Gen1.
NOTE: See important legal disclosures for all listed specs in their respective features sections.
Page 4
QuickSpecs
HP 280 G6 Microtower Business PC
Standard Features and Configurable Modules
Not all configuration components are available in all regions/countries.
c06590382 — DA-16652 — Worldwide — Version 9 — March 3, 2021
Page 4
PRODUCT NAME
HP 280 G6 Microtower Business PC
OPERATING SYSTEM
Preinstalled
Windows 10 Pro 641
Windows 10 Home 641
Pre-installed (other)
FreeDOS
1. Not all features are available in all editions or versions of Windows. Systems may require upgraded and/or separately purchased hardware,
drivers, software or BIOS update to take full advantage of Windows functionality. Windows 10 is automatically updated, which is always enabled.
ISP fees may apply and additional requirements may apply over time for updates. See http://www.windows.com/
PROCESSORS
Intel® Celeron® Processors
2,3
CPU Intel Celeron G5900 Dual Core 3.4GHz 2666MHz 58W (3.4GHz, 2MB cache, 2 cores)
CPU Intel Celeron G5905 Dual Core 3.4GHz 2666MHz 58W (3.4GHz, 2MB cache, 2 cores)
Intel® Pentium® Processors
2,3
CPU Intel Pentium Gold G6400 Dual Core 4.0GHz 2666MHz 58W (4.0GHz, 4MB cache, 2 cores)
CPU Intel Pentium Gold G6600 Dual Core 4.2GHz 2666MHz 58W (4.2GHz, 4MB cache, 2 cores)
Intel 10th Processors
Intel® Core™ i3
2,3
CPU Intel Core i3-10100 4C 3.6GHz 2666MHz 65W (3.6GHz, turbo up to 4.1GHz, 6MB cache, 4 cores)
Intel® Core™ i5
2,3
CPU Intel Core i5-10400 6C 2.9GHz 2666MHz 65W (2.9GHz, turbo up to 4.0GHz, 12MB cache, 6 cores)
CPU Intel Core i5-10500 6C 3.1GHz 2666MHz 65W (3.1GHz, turbo up to 4.2GHz, 12MB cache, 6 cores)
Intel® Core™ i7
2,3
CPU Intel Core i7-10700 8C 2.9GHz 2933MHz 65W (2.9GHz, Up to 4.8GHz with Intel® Turbo Boost4, 16MB cache, 8 cores)
2.Your product does not support Windows 8 or Windows 7, In accordance with Microsoft’s support policy, HP does not support the Windows® 8 or
Windows 7 operating system on products configured with Intel 8th or 9th generation and forward processors or provide any Windows® 8 or Windows
7 drivers on http://www.support.hp.com
3. Multi-Core is designed to improve performance of certain software products. Not all customers or software applications will necessarily benefit
from use of this technology. 64-bit computing system required. Performance and clock frequency will vary depending on application workload
and your hardware and software configurations. Intel’s numbering, branding and/or naming is not a measurement of higher performance.
4. Intel® Turbo Boost technology requires a PC with a processor with Intel Turbo Boost capability. Intel Turbo Boost performance varies depending
on hardware, software and overall system. See http://www.intel.com/technology/turboboost for more information
*NOTE: Only available on selected region
CHIPSET
Intel® H470 Chipset
Page 5
QuickSpecs
HP 280 G6 Microtower Business PC
Standard Features and Configurable Modules
Not all configuration components are available in all regions/countries.
c06590382 — DA-16652 — Worldwide — Version 9 — March 3, 2021
Page 5
GRAPHICS
Integrated
5, 6
Intel® UHD
Graphics 630 (integrated on 10th Core i processors and Pentium Gold G6600)
Intel® UHD
Graphics 610 (integrated on Pentium Gold G6400 and Celeron)
Discrete Graphics
AMD Radeon™ R7 430 2GB GFX
AMD Radeon™ RX550X 4GB GFX
AMD Radeon™ 520 1GB GFX
NVIDIA® GeForce® GTX1660 Super 6GB GFX*
5. HD content required to view HD images.
6. Integrated Intel software is available on select models only and requires separately purchased projector, tv or computer monitor with an
integrated or external receiver. External receivers connect to the projector, tv or computer monitor via a standard VGA, HDMI cable, also sold
separately.
*NOTE: Available in select countries only.
MEMORY7
Form Factor
Type
Maximum
# of Slots
Microtower
DDR4 2933 (Transfer rates up
to 2933 MT/s)
DDR4 2666 (Transfer rates up
to 2666 MT/s)
64 GB capacity
2 DIMM
4GB DDR4-2933 UDIMM NECC (1x4GB)
8GB DDR4-2933 UDIMM NECC (1x8GB)
8GB DDR4-2933 UDIMM NECC (2x4GB)
16GB DDR4-2933 UDIMM NECC (2x8GB)
16GB DDR4-2933 UDIMM NECC (1x16GB)
64GB DDR4-2933 UDIMM NECC (2x32GB)
4GB DDR4-2666 UDIMM NECC (1x4GB)
8GB DDR4-2666 UDIMM NECC (1x8GB)
8GB DDR4-2666 UDIMM NECC (2x4GB)
16GB DDR4-2666 UDIMM NECC (1x16GB)
16GB DDR4-2666 UDIMM NECC (2x8GB)
64GB DDR4-2666 UDIMM NECC (2x32GB)
7. Memory modules support data transfer rates up to 2933 MT/s; actual data rate is determined by the system’s configured processor. See
processor specifications for supported memory data rate.
NOTE: DDR4-2933 UDIMM is only available for 10th Gen i7 processor.
STORAGE
SATA3 - 3.5" or 2.5” 6Gb/s HDDs
2TB 7200 RPM SATA Hard Disk Drive
1TB 7200 RPM SATA Hard Disk Drive
500GB 7200 RPM SATA Hard Disk Drive
Page 6
QuickSpecs
HP 280 G6 Microtower Business PC
Standard Features and Configurable Modules
Not all configuration components are available in all regions/countries.
c06590382 — DA-16652 — Worldwide — Version 9 — March 3, 2021
Page 6
Solid State Drives
128GB M.2 NVMe
256GB M.2 NVMe
512GB M.2 NVMe
SD Card Reader
7
SD/SDHC/SDXC SD Card Reader
Intel Optane Memory8
SSD Intel 16GB 2280 Optane Memory
8. Optional per configuration
OPTICAL DISC DRIVES
DVD-ROM 9.5mm
DVD-Writer9 9.5mm
9. HD-DVD disks cannot be played on this drive. No support for DVD-RAM. Actual speeds may vary. Don’t copy copyright-protected materials.
Double Layer discs can store more data than single layer discs. Discs burned with this drive may not be compatible with many existing singlelayer DVD drives and players.
NETWORKING
10
Ethernet (RJ-45)
Integrated 10/100/1000M GbE LAN
Wi-Fi® and Bluetooth®
802.11ac (1x1) Wi-Fi® and Bluetooth® 4.2 Combo
10. Wireless cards are optional or add-on features and requires separately purchased wireless access point and internet service. Availability of
public wireless access points limited.
Page 7
QuickSpecs
HP 280 G6 Microtower Business PC
Standard Features and Configurable Modules
Not all configuration components are available in all regions/countries.
c06590382 — DA-16652 — Worldwide — Version 9 — March 3, 2021
Page 7
AUDIO / MULTIMEDIA
Integrated Hi-Definition Audio
Combo Jack, Headphone / Microphone
Line-in / Line-out (3.5mm)
KEYBOARDS AND POINTING DEVICES
11
Keyboard
USB Business Slim Wired Keyboard
HP USB Wired Keyboard
Business Slim USB Antimicrobial Wired Keyboard (China)
Business Slim PS/2 Wired Keyboard (for machine configured with PS/2 port)
No KB Option
Mouse
Antimicrobial USB Mouse (China)
HP Optical USB Mouse
Universal Wired USB Mouse
USB Hardened Mouse (Specific region)
HP PS/2 Mouse (for machine configured with PS/2 port)
No Mouse Option
11. Keyboards and mouse are optional or add-on features.
PORTS
Front
Slim-height Bay - supporting an optical disk drive (Optional)
Power Button
Combo jack, Headphone / Microphone
SD Card Reader (Optional)
(2) SuperSpeed USB 10Gbps port**
(4) SuperSpeed USB 5Gbps port**
Not Shown
(1) PCI Express x16
(1) PCI Express x1
(1) Full-height PCI (Available on selected sku)
(1) M.2 for WLAN
(1) M.2 2242/2280 storage
Rear
Audio Line out
Audio Line in
Page 8
QuickSpecs
HP 280 G6 Microtower Business PC
Standard Features and Configurable Modules
Not all configuration components are available in all regions/countries.
c06590382 — DA-16652 — Worldwide — Version 9 — March 3, 2021
Page 8
HDMI Port
VGA Port
Serial Port (Optional on selected sku)
2nd Serial Port (Optional)
Standard Lock Slot
(2) USB 2.0 port
(2) USB 2.0 port (Optional on selected sku)
RJ-45 Network connector
Power cord connector
Padlock loop
Integrated accessories cable lock
Not Shown
(1) PS/2 Port (Optional)
(1) Parallel Port (Optional via PCIex1 slot)
(1) 4x Serial port (Optional via PCIex1 slot)*
(1) Internal Speaker (Optional)
(1) Intrusion Sensor (Optional)
NOTE*: Available in select countries only.
NOTE**: SuperSpeed USB 10Gbps = USB 3.2 Gen2. SuperSpeed USB 5Gbps = USB 3.2 Gen1
BAYS
(1) 9.5mm external slimline ODD bay (Optional)
(1) 3.5" or 2.5” internal HDD or bay
(1) 3.5 or 2.5” internal HDD bay (share bay with caddy)
Page 9
QuickSpecs
HP 280 G6 Microtower Business PC
Standard Features and Configurable Modules
Not all configuration components are available in all regions/countries.
c06590382 — DA-16652 — Worldwide — Version 9 — March 3, 2021
Page 9
SOFTWARE COMPONENTS AND APPLICATIONS WITH WINDOWS
Security and Protection
McAfee* LiveSafe™ 12
Productivity
Buy Office (sold separately)
Dropbox
13
Xerox® DocuShare® (90 days free trial offer)16
ODD Playback
sMedio True DVD for HP
Movies
Netflix
14
App Stores and Content Purchasing
Amazon
14
HP Utilities and Support
HP Documentation
HP JumpStarts
HP Audio Switch15
HP Support Assistant
BTB
HP Setup Integrated OOBE
Hardware Enabling Drivers or software utility
HP System Event Utility
12. Free 1-year subscription of McAfee LiveSafe service included. Internet access required and not included. Subscription required after expiration
13. New Dropbox users are eligible to get 25 GB of Dropbox space free for 12 months from date of registration. For complete details and terms of
use, including cancellation policies, visit the Dropbox website at https://www.dropbox.com/help/space/hp-promotion. Internet service
required and not included.
14. Internet access required and not included.
15. Easily switch between speaker and microphone sources with intuitive controls and a consistent app experience.
16. Simply sign up and start using Xerox® DocuShare® Go. No credit card. No obligation. Data will become unavailable unless a subscription is
entered before the end of the 90 day free trial period. See visit https://http://www.xerox.com/docusharego for details.
*NOTE: Available in Latin America countries only.
POWER SUPPLY
17
180 W
ENERGY® STAR® Libra2 EPA90 (Gold) Full range 115V/230V
310 W
SFF ENTL EPA90 (Gold) Full range 115V/230V
500 W
EPA90 (Gold) Full range 115V/230V
17. All power supplies are not available in every region.
Page 10
QuickSpecs
HP 280 G6 Microtower Business PC
Standard Features and Configurable Modules
Not all configuration components are available in all regions/countries.
c06590382 — DA-16652 — Worldwide — Version 9 — March 3, 2021
Page 10
DIMENSIONS AND WEIGHT
Dimensions
6.12 x 11.93 x 13.28 in
(155 x 303 x 337 mm)
Weight
10.4 lbs / 4.7 kg
UNIT ENVIRONMENT AND OPERATING CONDITIONS
General Unit Operating Guidelines
• Keep the computer away from excessive moisture, direct moisture and the extremes of heat and cold, to ensure that unit
is operated within the specified operating range.
• Leave a 10.2 cm (4 in) clearance on all vented sides of the computer to permit the required airflow.
• Never restrict airflow into the computer by blocking any vents or air intakes.
• Do not stack computers on top of each other or place computers so near each other that they are subject to each other's
re-circulated or preheated air.
• Occasionally clean the air vents on the front, back, and any other vented side of the computer. Lint, dust and other foreign
matter can block the vents and limit the airflow.
• If the computer is to be operated within a separate enclosure, intake and exhaust ventilation must be provided on the
enclosure, and the same operating guidelines listed above will still apply.
Temperature Range
Operating: 5° to 35° C18
Non-operating: -30° to 60° C18
Relative Humidity
Operating: 5% to 90% (non-condensing at ambient)
Non-operating: 5% to 90% (non-condensing at ambient)
Maximum Altitude (unpressurized)
Operating: 5000 m
Non-operating: 50000ft (15240 m)
18. Operating temperature is de-rated 1.0 deg C per 300 m (1000 ft) to 3000 m (10,000 ft) above sea level, no direct sustained sunlight.
Maximum rate of change is 10 deg C/Hr. The upper limit may be limited by the type and number of options installed.
Eco-Label Certifications
& declarations
This product has received or is in the process of being certified to the following approvals and may be
labeled with one or more of these marks:
• IT ECO declaration
• US ENERGY STAR®
• EPEAT® 2019 registered where applicable. EPEAT ® registration varies by country. See
http://www.epeat.net for registration status by country. Search keyword generator on HP’s 3rd party
option store for solar generator accessories at http://www.hp.com/go/options.
*Based on US EPEAT® registration according to IEEE 1680.1-2018 EPEAT®. Status varies by country. Visit
http://www.epeat.net for more information.
System Configuration
The configuration used for the Energy Consumption and Declared Noise Emissions data for the
Desktop model is based on a “Typically Configured Desktop”.
Energy Consumption
(in accordance with US
ENERGY STAR® test
method)
115VAC, 60Hz
230VAC, 50Hz
100VAC, 50Hz
Page 11
QuickSpecs
HP 280 G6 Microtower Business PC
Standard Features and Configurable Modules
Not all configuration components are available in all regions/countries.
c06590382 — DA-16652 — Worldwide — Version 9 — March 3, 2021
Page 11
Normal Operation (Short
idle)
35.98W
36.76W
36.52W
Normal Operation (Long
idle)
33.27W
33.03W
33.26W
Sleep
1.08W
1.1W
1.27W
Off
0.27W
0.3W
0.26W
NOTE: Energy efficiency data listed is for an ENERGY STAR® compliant product if offered within the model
family. HP computers marked with the ENERGY STAR® Logo are compliant with the applicable U.S.
Environmental Protection Agency (EPA) ENERGY STAR® specifications for computers. If a model family does not
offer ENERGY STAR® compliant configurations, then energy efficiency data listed is for a typically configured PC
featuring a hard disk drive, a high efficiency power supply, and a Microsoft Windows® operating system.
Heat Dissipation*
115VAC, 60Hz
230VAC, 50Hz
100VAC, 50Hz
Normal Operation (Short
idle)
122.69 BTU/hr
125.35 BTU/hr
124.53 BTU/hr
Normal Operation (Long
idle)
113.45 BTU/hr
112.63 BTU/hr
113.42 BTU/hr
Sleep
3.68 BTU/hr
3.75 BTU/hr
4.33 BTU/hr
Off
0.92 BTU/hr
1.02 BTU/hr
0.89 BTU/hr
NOTE: Heat dissipation is calculated based on the measured watts, assuming the service level is attained for one
hour.
Declared Noise
Emissions
(in accordance with
ISO 7779 and ISO 9296)
Sound Power
(L
WAd
, bels)
Sound Pressure
(L
pAm
, decibels)
Typically Configured –
Idle
3.7
24.7
Fixed Disk – Random
writes
4
28.2
Longevity and Upgrading
This product can be upgraded, possibly extending its useful life by several years. Upgradeable
features and/or components contained in the product may include:
Spare parts are available throughout the warranty period and or for up to “3” years after the end of
production.
Batteries
This battery(s) in this product comply with EU Directive 2006/66/EC
Batteries used in the product do not contain:
Mercury greater the1ppm by weight
Cadmium greater than 20ppm by weight
Battery size: CR2032 (coin cell)
Battery type: Lithium
Additional Information
• This product is in compliance with the Restrictions of Hazardous Substances (RoHS) directive 2011/65/EC.
• This HP product is designed to comply with the Waste Electrical and Electronic Equipment (WEEE)
Directive – 2002/96/EC.
• This product is in compliance with California Proposition 65 (State of California; Safe Drinking Water
and Toxic Enforcement Act of 1986).
• This product is in compliance with the IEEE 1680.1 (EPEAT) standard at the <Silver> level, see
www.epeat.net
• Plastics parts weighing over 25 grams used in the product are marked per ISO11469 and ISO1043.
• This product contains 28.2% post-consumer recycled plastic (by wt.)
• This product is 91.7% recycle-able when properly disposed of at end of life.
Packaging Materials
External:
PAPER/Paperboard
1220 g
Page 12
QuickSpecs
HP 280 G6 Microtower Business PC
Standard Features and Configurable Modules
Not all configuration components are available in all regions/countries.
c06590382 — DA-16652 — Worldwide — Version 9 — March 3, 2021
Page 12
Internal:
PAPER/Molded Pulp
520 g
PLASTIC/Polyethylene low density - LDPE
53 g
Material Usage
This product does not contain any of the following substances in excess of regulatory limits (refer to
the HP General Specification for the Environment at
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/gse.pdf):
• Asbestos
• Certain Azo Colorants
• Certain Brominated Flame Retardants – may not be used as flame retardants in plastics
• Cadmium
• Chlorinated Hydrocarbons
• Chlorinated Paraffins
• Formaldehyde
• Halogenated Diphenyl Methanes
• Lead carbonates and sulfates
• Lead and Lead compounds
• Mercuric Oxide Batteries
• Nickel – finishes must not be used on the external surface designed to be frequently handled or
carried by the user.
• Ozone Depleting Substances
• Polybrominated Biphenyls (PBBs)
• Polybrominated Biphenyl Ethers (PBBEs)
• Polybrominated Biphenyl Oxides (PBBOs)
• Polychlorinated Biphenyl (PCB)
• Polychlorinated Terphenyls (PCT)
• Polyvinyl Chloride (PVC) – except for wires and cables, and certain retail packaging has been
voluntarily removed from most applications.
• Radioactive Substances
• Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
Packaging Usage
HP follows these guidelines to decrease the environmental impact of product packaging:
• Eliminate the use of heavy metals such as lead, chromium, mercury and cadmium in packaging
materials.
• Eliminate the use of ozone-depleting substances (ODS) in packaging materials.
• Design packaging materials for ease of disassembly.
• Maximize the use of post-consumer recycled content materials in packaging materials.
• Use readily recyclable packaging materials such as paper and corrugated materials.
• Reduce size and weight of packages to improve transportation fuel efficiency.
• Plastic packaging materials are marked according to ISO 11469 and DIN 6120 standards.
End-of-life
Management and
Recycling
HP Inc. offers end-of-life HP product return and recycling programs in many geographic areas. To
recycle your product, please go to: http://www.hp.com/go/reuse-recycle or contact your nearest HP
sales office. Products returned to HP will be recycled, recovered or disposed of in a responsible
manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for
each product type for use by treatment facilities. This information (product disassembly instructions)
is posted on the Hewlett Packard web site at: http://www.hp.com/go/recyclers. These instructions
may be used by recyclers and other WEEE treatment facilities as well as HP OEM customers who
integrate and re-sell HP equipment.
Global Citizenship Report
http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html
Eco-label certifications
http://www8.hp.com/us/en/hp-information/environment/ecolabels.html
ISO 14001 certificates:
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/PC_GBU_Product_Design_ISO_14K_
Certificate.pdf
Page 13
QuickSpecs
HP 280 G6 Microtower Business PC
Standard Features and Configurable Modules
Not all configuration components are available in all regions/countries.
c06590382 — DA-16652 — Worldwide — Version 9 — March 3, 2021
Page 13
and
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/cert.pdf
SERVICE AND SUPPORT
On-site Warranty 1: Available three-year (3-3-3) or one-year (1-1-1) limited warranty (varies by country) delivers on-site, next
business day 2 service for parts and labor and complimentary limited technical support.3 Three-year onsite and labor are not
available in all countries. Service offers terms up to 5 years by choosing an optional HP Care Pack.4 To choose the right level of
service for your HP product, visit HP Care Pack Central: http://www.hp.com/go/cpc.
NOTE 1: Terms and conditions may vary by country. Certain restrictions and exclusions apply. Other warranty variations may be offered in
your region.
NOTE 2: On-site service may be provided pursuant to a service contract between HP and an authorized HP third-party provider, and is not
available in certain countries. Global service response times are based on commercially reasonable best effort and may vary by country.
NOTE 3: Technical support applies only to HP-configured and third-party HP qualified hardware and software.
NOTE 4: Service levels and response times for HP Care Packs may vary depending on your geographic location. Service starts on date of
hardware purchase. Restrictions and limitations apply. For details, visit http://www.hp.com/go/cpc. HP services are governed by the
applicable HP terms and conditions of service provided or indicated to Customer at the time of purchase. Customer may have additional
statutory rights according to applicable local laws, and such rights are not in any way affected by the HP terms and conditions of service or
the HP Limited Warranty provided with your HP Product.
Page 14
QuickSpecs
HP 280 G6 Microtower Business PC
Technical Specifications - Graphics
Not all configuration components are available in all regions/countries.
c06590382 — DA-16652 — Worldwide — Version 9 — March 3, 2021
Page 14
GRAPHICS
Intel® UHD Graphics 630 (integrated on Core i7/i5/i3/Pentium G6500 and above processors)
Intel® UHD Graphics 610 (integrated on Pentium G6400 and below/ and Celeron)
DisplayPort™
Multimode capable; supports HDCP, DisplayPort™ Audio (2 streams), HBR2 link rates and
Multi-Stream Technology for a maximum of 3 displays (including the integrated panel)
Memory
Additional memory is allocated for graphics as needed using Intel's Dynamic Video Memory
Technology (DVMT), to provide an optimal balance between graphics and system memory
use.
Maximum Graphics Memory
Windows 10: >4 GB
Maximum Color Depth
32 bits/pixel
Graphics/Video API Support
10th Generation Intel® Core Processors, Pentium and Celeron
With Intel® UHD Graphics 630
Pentium® and Celeron®
With Intel® UHD Graphics 610
Supported Display Resolutions
and Refresh Rates
Max. Resolution (VGA) 2048 x 1536@60Hz
Max. Resolution (HDMI) 4096 x 2160@60Hz
Note: The actual amount of maximum graphics memory can be less than the amounts listed above depending upon your computer’s
configuration.
Note: other resolutions may be available but are not recommended as they may not have been tested and qualified by HP
Only supported on displays connected to the external DisplayPort™ connector.
Page 15
QuickSpecs
HP 280 G6 Microtower Business PC
Technical Specifications - Graphics
Not all configuration components are available in all regions/countries.
c06590382 — DA-16652 — Worldwide — Version 9 — March 3, 2021
Page 15
AMD Radeon™ R7 430 2GB Graphics Card
Engine Clock
780 MHz
Memory Clock
1100 MHz
Memory Size(width)
2GB(64-bit)
Memory Type
256M x 32 GDDR5
Max. Resolution(VGA)
2048x1536
Max. Resolution(DP)
4096x2160@60Hz
Multi Display Support
2 displays
HDCP Compliance
yes
Rear I/O connectors(bracket)
VGA+DP
Cooling(active/passive)
Active fan-sink (Active cooling with dynamic speed)
Total power consumption(W)
<50W
PCB form-factor with bracket
LP PCB with FH/LP bracket
AMD® Radeon™ RX550X 4 GB FH PCIe x16
Engine Clock
1183MHz
Memory Clock
6 Gbps
Memory Size(width)
4 GB(128-bit)
Memory Type
GDDR5
Max. Resolution(HDMI)
4096x2160 @ 60Hz
Max. Resolution(DP)
5120x2880 @ 60Hz
Multi Display Support
2 displays
HDCP Compliance
Yes
Rear I/O connectors(bracket)
HDMI, DPx2
Cooling(active/passive)
Active fan-sink (Active cooling with dynamic speed)
Total power consumption(W)
<50W
PCB form-factor with bracket
LP (low profile) PCB with FH/LP bracket
AMD Radeon™ 520 1GB Graphics Card
Engine Clock
780 MHz
Memory Clock
1100 MHz
Memory Size(width)
1GB(32-bit)
Memory Type
256M x 32 GDDR5
Max. Resolution(VGA)
2048x1536
Max. Resolution(DP)
4096x2160@60Hz
Multi Display Support
2 displays
HDCP Compliance
yes
Rear I/O connectors(bracket)
VGA+DP
Cooling(active/passive)
Active fan-sink (Active cooling with dynamic speed)
Total power consumption(W)
<50W
PCB form-factor with bracket
LP PCB with FH/LP bracket
Page 16
QuickSpecs
HP 280 G6 Microtower Business PC
Technical Specifications - Graphics
Not all configuration components are available in all regions/countries.
c06590382 — DA-16652 — Worldwide — Version 9 — March 3, 2021
Page 16
NVIDIA® GeForce® GTX 1660 Super 6GB Graphics Card
Engine Clock
1785 MHz
Memory Clock
7000 MHz
Memory Size(width)
6GB(192-bit)
Memory Type
256M x 32 GDDR6 @6pcs
Max. Resolution(DVI)
7680x4320@120Hz
Max. Resolution(DP)
7680x4320@120Hz
Multi Display Support
3 displays
HDCP Compliance
yes
Rear I/O connectors(bracket)
DVI-D+DP+HDMI
Cooling(active/passive)
Active fan-sink(Active cooling with dynamic speed)
Total power consumption(W)
<125W
PCB form-factor with bracket
FH PCB with FH bracket
Page 17
QuickSpecs
HP 280 G6 Microtower Business PC
Technical Specifications - Storage
Not all configuration components are available in all regions/countries.
c06590382 — DA-16652 — Worldwide — Version 9 — March 3, 2021
Page 17
STORAGE*
HP 2 TB 7.2K rpm SATA 6.0Gb/s 3.5" Hard Disk Drive
Capacity
2 TB
Rotational Speed
7,200 rpm
Interface
SATA 6Gb/s NCQ
Buffer Size
64 MB
Logical Blocks
3,907,029,168
Seek Time
Read: <8.5 ms
Write: <9.5 ms
Height
1.028 in/26.11 mm
Width
4.0 in/101.6 mm
Operating Temperature
32° to 140° F (0° to 60° C)
1 TB 7.2K rpm SATA 6.0Gb/s 3.5” Hard Disk Drive
Capacity
1 TB
Rotational Speed
7,200 rpm
Interface
Serial ATA 3.0 (6.0 Gb/s)
Buffer Size
32 MB
Logical Blocks
1,953,525,168
Seek Time
Single Track: 2.0 ms
Average: 11 ms
Full-Stroke: 21 ms
Height
1 in/2.54 cm
Width
Media diameter: 3.5 in/8.89 cm
Physical size: 4 in/10.2 cm
Operating Temperature
41° to 131° F (5° to 55° C)
500 GB 7.2K rpm SATA 6.0Gb/s 3.5” Hard Disk Drive
Capacity
500 GB
Rotational Speed
7,200 rpm
Interface
Serial ATA 3.0 (6.0 Gb/s)
Buffer Size
32 MB
Logical Blocks
1,953,525,168
Seek Time
Single Track: 2.0 ms
Average: 11 ms
Full-Stroke: 21 ms
Height
1 in/2.54 cm
Width
Media diameter: 3.5 in/8.89 cm
Physical size: 4 in/10.2 cm
Operating Temperature
41° to 131° F (5° to 55° C)
Page 18
QuickSpecs
HP 280 G6 Microtower Business PC
Technical Specifications - Storage
Not all configuration components are available in all regions/countries.
c06590382 — DA-16652 — Worldwide — Version 9 — March 3, 2021
Page 18
128 GB M.2 2280 PCIe NVMe Three Layer Cell SSD
Drive Weight
< 10g
Capacity
128GB
Height
2.38mm
Length
80mm
Width
22mm
Interface
PCIE Gen3x4
Maximum Sequential Read
Up to 2800MB/s
Maximum Sequential Write
Up to 600MB/s
Logical Blocks
250,069,680
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
APST; ASPM L1.2; NVME spec 1.2
256 GB M.2 2280 PCIe NVMe Three Layer Cell SSD
Drive Weight
< 10g
Capacity
256GB
Height
2.38mm
Length
80mm
Width
22mm
Interface
PCIE Gen3x4
Maximum Sequential Read
Up to 2700MB/s
Maximum Sequential Write
Up to 1000MB/s
Logical Blocks
500,118,192
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
APST; ASPM L1.2; NVME spec 1.2
512 GB M.2 2280 PCIe NVMe Three Layer Cell SSD
Drive Weight
< 10g
Capacity
512GB
Height
2.38mm
Length
80mm
Width
22mm
Interface
PCIE Gen3x4
Maximum Sequential Read
Up to 2900MB/s
Maximum Sequential Write
Up to 1100MB/s
Logical Blocks
1,000,215,216
Page 19
QuickSpecs
HP 280 G6 Microtower Business PC
Technical Specifications - Storage
Not all configuration components are available in all regions/countries.
c06590382 — DA-16652 — Worldwide — Version 9 — March 3, 2021
Page 19
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
APST; ASPM L1.2; NVME spec 1.2
256 GB M.2 2280 PCIe NVMe SSD
Drive Weight
< 10g
Capacity
256 GB
Height
2.38mm
Length
80mm
Width
22mm
Interface
PCIE Gen3
Maximum Sequential Read
Up to 1600MB/s
Maximum Sequential Write
Up to 780MB/s
Logical Blocks
500,118,192
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
APST; ASPM L1.2; NVME spec 1.2
512 GB M.2 2280 PCIe NVMe SSD
Drive Weight
< 10g
Capacity
512 GB
Height
2.38mm
Length
80mm
Width
22mm
Interface
PCIE Gen3
Maximum Sequential Read
Up to 1600MB/s
Maximum Sequential Write
Up to 860MB/s
Logical Blocks
1,000,215,216
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
APST; ASPM L1.2; NVME spec 1.2
500 GB 7200RPM 2.5in SATA HDD
Capacity
500 GB
Rotational Speed
7,200 rpm
Interface
SATA 6 Gb/s
Buffer Size
32 MB
Logical Blocks
976,773,168
Seek Time
12 ms (Average)
Height
0.267 in/6.8 mm (nominal)
Width (nominal)
2.75 in/70 mm (nominal)
Page 20
QuickSpecs
HP 280 G6 Microtower Business PC
Technical Specifications - Storage
Not all configuration components are available in all regions/countries.
c06590382 — DA-16652 — Worldwide — Version 9 — March 3, 2021
Page 20
Operating Temperature
41° to 131° F (5° to 55° C)
1TB 7200RPM 2.5in SATA HDD
Capacity
1 TB
Rotational Speed
7,200 rpm
Interface
SATA 6 Gb/s
Buffer Size
32 MB
Logical Blocks
1,953,525,168
Seek Time
12 ms (Average)
Height
0.374 in/9.5 mm (nominal)
Width (nominal)
2.75 in/70 mm (nominal)
Operating Temperature
41° to 131° F (5° to 55° C)
Page 21
QuickSpecs
HP 280 G6 Microtower Business PC
Technical Specifications – Optical Drives
Not all configuration components are available in all regions/countries.
c06590382 — DA-16652 — Worldwide — Version 9 — March 3, 2021
Page 21
OPTICAL DISC DRIVES
HP 9.5mm Desktop G2 Slim DVD Writer Drive
Height
9.5 mm height
Orientation
Either horizontal or vertical
Interface type
SATA/ATAPI
Disc recording capacity
Up to 8.5 GB DL or 4.7 GB standard
Dimensions (W x H x D)
5.04 x 0.37 x 5.0 in (128 x 9.5 x 127 mm) without bezel
Weight (max)
0.31 lb (140 g)
Read Speeds
DVD-R DL
DVD+R
DVD+RW
DVD+R DL
DVD-R
DVD-RW
CD-R
CD-RW
DVD-RW, DVD+RW
DVD-R DL, DVD+R DL
DVD+R, DVD-R
DVD-ROM DL, DVD-ROM
CD-ROM, CD-R
CD-RW
Up to 6X
Up to 8X
Up to 8X
Up to 6X
Up to 8X
Up to 6X
Up to 24X
Up to 10X
Up to 8X
Up to 8X
Up to 8X
Up to 8X
Up to 24X
Up to 24X
Access time
(typical reads, including
settling)
Random DVD-ROM: 170 ms (typical), CD-ROM: 170 ms (typical)
Full Stroke DVD-ROM: 320 ms (typical), CD-ROM: 320 ms (typical)
Stop Time 6 seconds (typical)
Power
Source Slimline SATA DC power receptacle
DC Power Requirement 5 VDC ± 5%-100 mV ripple p-p
DC Current 5 VDC (< 1000 mA typical, 1600 mA maximum)
Environmental conditions
(operating - non-condensing)
Temperature 41° to 122° F (5° to 50° C)
Relative Humidity 10% to 80%
Maximum Wet Bulb Temperature 84° F (29° C)
HP 9.5mm Desktop G2 Slim DVD-ROM Drive
Height
9.5 mm height
Orientation
Either horizontal or vertical
Interface type
SATA/ATAPI
Disc recording capacity
Up to 8.5 GB DL or 4.7 GB standard
Dimensions (W x H x D)
5.04 x 0.37 x 5.0 in (128 x 9.5 x 127 mm) without bezel
Weight (max)
0.31 lb (140 g)
Read Speeds
DVD-R DL
DVD+R
DVD+RW
DVD+R DL
DVD-R
DVD-RW
CD-R
Up to 6X
Up to 8X
Up to 8X
Up to 6X
Up to 8X
Up to 6X
Up to 24X
Page 22
QuickSpecs
HP 280 G6 Microtower Business PC
Technical Specifications – Optical Drives
Not all configuration components are available in all regions/countries.
c06590382 — DA-16652 — Worldwide — Version 9 — March 3, 2021
Page 22
CD-RW
DVD-RW, DVD+RW
DVD-R DL, DVD+R DL
DVD+R, DVD-R
DVD-ROM DL, DVD-ROM
CD-ROM, CD-R
CD-RW
Up to 10X
Up to 8X
Up to 8X
Up to 8X
Up to 8X
Up to 24X
Up to 24X
Access time
(typical reads, including
settling)
Random DVD-ROM: 170 ms (typical), CD-ROM: 170 ms (typical)
Full Stroke DVD-ROM: 320 ms (typical), CD-ROM: 320 ms (typical)
Stop Time 6 seconds (typical)
Power
Source Slimline SATA DC power receptacle
DC Power Requirement 5 VDC ± 5%-100 mV ripple p-p
DC Current 5 VDC (< 1000 mA typical, 1600 mA maximum)
Environmental conditions
(operating - non-condensing)
Temperature 41° to 122° F (5° to 50° C)
Relative Humidity 10% to 80%
Maximum Wet Bulb Temperature 84° F (29° C)
Page 23
QuickSpecs
HP 280 G6 Microtower Business PC
Technical Specifications – Networking
Not all configuration components are available in all regions/countries.
c06590382 — DA-16652 — Worldwide — Version 9 — March 3, 2021
Page 23
NETWORKING
10/100/1000 NIC
Ethernet Features
10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-14)
100 Mbit/s operation (100BASE-TX; IEEE 802.3u; IEEE 802.3 clauses 21-30)
1000 Mbit/s operation (1000BASE-T; IEEE 802.3ab; IEEE 8023 clauses 40)
Auto-Negotiation (Automatic Speed Selection)
Full Duplex Operation at all Speeds, Half Duplex operation at 10 and 100 Mbit/s
Power
Management
ACPI compliant – multiple power modes
Situation-sensitive features reduce power consumption
Advanced link down power saving for reducing link down power consumption
Performance
Features
TCP/IP/UDP Checksum Offload (configurable)
Protocol Offload (ARP & NS)
Large send offload and Giant send offload
Receiving Side Scaling
Jumbo Frame 9K
Manageability
Wake-on-LAN from standby and hibernation (Magic Packet and Microsoft Wake-Up
Frame); Wake-on-LAN from off (Magic Packet only)
PXE 2.1 Remote Boot
Statistics Gathering (SNMP MIB II, Ethernet-like MIB, Ethernet MIB (802.3x, clause
30)
Comprehensive diagnostic and configuration software suite
Virtual Cable Doctor for Ethernet cable status
Interface
PCIe + SMBus
NIC Device Driver Name
PCIe GBE Ethernet Family Controller
Realtek 802.11ac (1x1) Wi-Fi® and Bluetooth® 4.2 Combo *
Wireless LAN Standards1
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac
1. Wireless access point and Internet service required and not included. Availability of public wireless
access points limited.
Interoperability
Wi-Fi® certified modules
Frequency Bands
802.11b/g/n
12/13 and are capable of transmitting must fully comply with requirements of
15.247 & 15.249 or otherwise disable those channels.
802.11a/n
Page 24
QuickSpecs
HP 280 G6 Microtower Business PC
Technical Specifications – Networking
Not all configuration components are available in all regions/countries.
c06590382 — DA-16652 — Worldwide — Version 9 — March 3, 2021
Page 24
Data Rates
Modulation
Direct Sequence Spread Spectrum
BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM
Security2
2 Check latest software/driver release for updates on supported security features.
Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power3
3. Maximum output power may vary by country according to local regulations.
Power Consumption
Power Management
ACPI and PCI Express compliant power management
802.11 compliant power saving mode
Page 25
QuickSpecs
HP 280 G6 Microtower Business PC
Technical Specifications – Networking
Not all configuration components are available in all regions/countries.
c06590382 — DA-16652 — Worldwide — Version 9 — March 3, 2021
Page 25
Receiver Sensitivity4
4 Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a packet
error rate of 10% for 802.11a/g (OFDM modulation).
Antenna type
High efficiency antenna with spatial diversity, mounted in the display enclosure
Two embedded dual band 2.4/5 GHz antennas are provided to the card to support WLAN MIMO
communications and Bluetooth communications
Form Factors
PCI-Express M.2 MiniCard
Dimensions
Type 2230 : 2.3 x 22.0 x 30.0 mm
Weight
Type 2230 : 2.8g
Operating Voltage
3.3v +/- 9%
Temperature
Operating:
Non-operating:
14° to 158° F (-10° to 70° C)
-40° to 176° F (-40° to 80° C)
Humidity
Operating:
Non-operating:
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude
Operating:
Non-operating:
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
LED Activity
LED Amber – Radio OFF; LED White – Radio ON
HP Integrated Module with Bluetooth 4.0/4.1/4.2 Wireless Technology
Bluetooth Specification
4.0/4.1/4.2 Compliant
Frequency Band
2402 to 2480 MHz
Number of Available Channels
Legacy : 0~79 (1 MHz/CH)
BLE : 0~39 (2 MHz/CH)
Data Rates and Throughput
Legacy : 3 Mbps data rate; throughput up to 2.17 Mbps
BLE : 1 Mbps data rate; throughput up to 0.2 Mbps
Legacy : Synchronous Connection Oriented links up to 3, 64 kbps, voice channels
Legacy : Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric (3-DH5) or
864 kbps symmetric (3-EV5)
Transmit Power
The Bluetooth component shall operate as a Class II Bluetooth device with a maximum
transmit power of + 4 dBm for BR and EDR.
Page 26
QuickSpecs
HP 280 G6 Microtower Business PC
Technical Specifications – Networking
Not all configuration components are available in all regions/countries.
c06590382 — DA-16652 — Worldwide — Version 9 — March 3, 2021
Page 26
Receiver Sensitivity Legacy
Power Consumption
Peak (Tx) 330 mW
Peak (Rx) 230 mW
Selective Suspend 17 mW
Range
Legacy : 0~79 (1 MHz/CH)
BLE : 0~39 (2 MHz/CH)
Electrical Interface
USB 2.0 compliant
Bluetooth Software Supported
Link Topology
Microsoft Windows Bluetooth Software
Power Management
Certifications
ETS 300 328, ETS 300 826
Low Voltage Directive IEC950
UL, CSA, and CE Mark
Certifications
Bluetooth Profiles Supported
FCC (47 CFR) Part 15C, Section 15.247 & 15.249
Power Management
Certifications
Microsoft Windows ACPI, and USB Bus Support
Certifications
Bluetooth Profiles Supported
BT4.1-ESR 5/6/7 Compliance
LE Link Layer Ping
LE Dual Mode
LE Link Layer
LE Low Duty Cycle Directed Advertising
LE L2CAP Connection Oriented Channels
Train Nudging & Interlaced Scan
BT4.2 ESR08 Compliance
LE Secure Connection- Basic/Full
LE Privacy 1.2 –Link Layer Privacy
LE Privacy 1.2 –Extended Scanner Filter Policies
LE Data Packet Length Extension
FAX Profile (FAX)
Basic Imaging Profile (BIP)2
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)
Page 27
QuickSpecs
HP 280 G6 Microtower Business PC
Technical Specifications - Audio
Not all configuration components are available in all regions/countries.
c06590382 — DA-16652 — Worldwide — Version 9 — March 3, 2021
Page 27
HIGH DEFINITION AUDIO
Type
Integrated
HD Stereo Codec
Realtek ALC3601
Audio I/O Ports
Front side Combo jack for supporting CTIA, Rear side Line-in/ Line-out/ Mic-in jacks
Internal Speaker Amplifier
2W class D mono amplifier for the internal speaker only. External speakers must be powered
externally.
Multi-streaming Capable
Playback multi-streaming can be enabled in the audio control panel to allow independent audio
streams to be sent to/from the front and rear jacks or integrated speaker.
HD Audio Codec
Realtek ALC3601
Sampling
Independent sampling rates for DAC’s and ADC’s; supports resolutions from 16 to 24-bit; 44.1K/
48 K/96K / 192K Hz for DAC and 44.1K/ 48K/ 96K/ 192K Hz Hz for ADC
Wavetable Syntheses
Yes
Analog Audio
Yes
# of Channels on Line-Out
Stereo
Internal Speaker
Yes
External Speaker Jack*
2W class D mono amplifier for the internal speaker only. External speakers must be powered
externally.
NOTE*: Optional
Page 28
QuickSpecs
HP 280 G6 Microtower Business PC
Technical Specifications - Power
Not all configuration components are available in all regions/countries.
c06590382 — DA-16652 — Worldwide — Version 9 — March 3, 2021
Page 28
POWER SUPPLY
Operating Voltage Range
90 – 264 VAC
Rated Voltage Range
100-240V AC
Rated Line Frequency
50/60 HZ
Operating Line Frequency
47 – 63 Hz
Rated Input Current
180W : <2.3A;
310W: <4A
500W: <6A
Rated Input Current with
Energy Efficient* Power
Supply
180W active PFC
87/90/87% efficient at 20/50/100% load (115V)
88/92/88% efficient at 20/50/100% load (230V);
310W active PFC
87/90/87% efficient at 20/50/100% load (115V)
88/92/88% efficient at 20/50/100% load (230V)
500W active PFC
87/90/87% efficient at 20/50/100% load (115V)
88/92/88% efficient at 20/50/100% load (230V)
DC Output
+12.1V
Current Leakage (NFPA 99:
2102)
Less than 500 microamps of leakage current at 120 Vac with the ground wire disconnected, as
required for Non-patient Electrical Appliances and Equipment used in a patient care facility or
that contact patients in normal use. Per section 10.3.5.1.
Less than 100 microamps of leakage current at 120 Vac with the ground wire intact with normal
polarity, as required for Non-patient Electrical Appliances and Equipment used in a patient care
facility or that contact patients in normal use. Per section 10.3.5.1.
Power Supply Fan
180W/310W: 70*25mm (linear type)
500W: 70*25mm (PWM type)
Page 29
QuickSpecs
HP 280 G6 Microtower Business PC
Technical Specifications – Weights and Dimensions
Not all configuration components are available in all regions/countries.
c06590382 — DA-16652 — Worldwide — Version 9 — March 3, 2021
Page 29
WEIGHT AND DIMENSIONS
Chassis (W x D x H)
6.12 x 11.93 x 13.28 in (155 x 303 x 337 mm) (w/ bezel)
System Volume
15.1 L
System Weight*
10.4 lbs / 4.7 kg
Packaged
(H x W x D)
11.3 x 15.75 x 19.65 in
287 x 400 x 499 mm
Shipping Weight
17.64lb / 8 kg
Palletization
Profile
6 units per layer
7layer max
42 per pallet
Footprint
-85.31x39.37x47.24 in (2167 x 1000 x1200 mm)
Page 30
QuickSpecs
HP 280 G6 Microtower Business PC
After-Market Options (availability may vary by region)
Not all configuration components are available in all regions/countries.
c06590382 — DA-16652 — Worldwide — Version 9 — March 3, 2021
Page 30
AFTERMARKET OPTIONS
Type
Description
Part #
Memory
HP 4GB DDR4-2666 DIMM
3TK85AA
HP 8GB DDR4-2666 DIMM
3TK87AA
HP 16GB DDR4-2666 DIMM
3TK83AA
Storage
HP 500GB SATA 6.0Gb/s Hard Drive
QK554AA
HP 1TB 7200rpm SATA 6Gbps Hard Drive
QK555AA
HP PCIe NVME TLC 256GB SSD M.2 Drive
1CA51AA
HP 256GB SATA TLC Non-SED Solid State Drive
P1N68AA
HP 9.5mm G3 8/6/4 SFF G4 400 SFF/MT DVD Writer
1CA53AA
Graphics
NVIDIA® GT 730 2GB DP Card
Z9H51AA
AMD Radeon™ R7 430 2GB 2DP Card
5JW82AA
Security
HP Business PC Security Lock V3 Kit
3XJ17AA
HP Keyed Cable Lock 10mm kit
T1A62AA
Adapters
HP HDMI Standard Cable Kit
T6F94AA
HP USB to Serial Port Adapter
J7B60AA
HP PCIe x1 Parallel Port Card
N1M40AA
Networking
Intel Ethernet I210-T1 GbE NIC Card
E0X95AA
Input
HP USB Mouse
QY777AA
HP USB Hardened Mouse
P1N77AA
HP USB Grey v2 Mouse
Z9H74AA
HP USB Keyboard
QY776AA
HP PS/2 Business Slim Keyboard
N3R86AA
HP USB Business Slim Keyboard
N3R87AA
HP Backlit USB Mechanical Keyboard
4RV35AA
HP USB Antimicrobial Slim Keyboard and Mouse
Z9H50AA
Others
HP Business Headset v2
T4E61AA
HP S101 Speaker bar
5UU40AA
Page 31
QuickSpecs
HP 280 G6 Microtower Business PC
Change Log
Not all configuration components are available in all regions/countries.
c06590382 — DA-16652 — Worldwide — Version 9 — March 3, 2021
Page 31
© Copyright 2021 HP Development Company, L.P. The information contained herein is subject to change without notice. The only
warranties for HP products are set forth in the express limited warranty statements accompanying such products. Nothing herein
should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions
contained herein. Microsoft and Windows are registered trademarks or trademarks of Microsoft Corporation in the U.S. and/or
other countries. Intel, Celeron®, Core, Pentium are registered trademarks or trademarks of Intel Corporation in the U.S. and/or
other countries. Bluetooth is a trademark of its proprietor, used by HP Inc. under license. NVIDIA, GeForce, Kepler and NVS are
trademarks and/or registered trademarks of NVIDIA Corporation in the U.S. and other countries. AMD and Radeon are trademarks
of Advanced Micro Devices, Inc. ENERGY STAR is a registered trademark owned by the U.S. Environmental Protection Agency.
Date of change:
Version
History:
Change
Description of change:
June 4, 2020
From v1 to v2
Removed
NVIDIA® GT 730 2GB DP Card from Graphics section
June 5, 2020
From V2 to V3
Added
Disclaimer #4 in rear call outs section
July 21, 2020
From V3 to V4
Added
Environmental section
July 24, 2020
From V4 to V5
Added
Intel Celeron G5905
July 29, 2020
From V5 to V6
Correction
Dimensions order
September 24, 2020
From V6 to V7
Addition
Xerox® DocuShare® and footnote to software section.
November 2, 2020
From V7 to V8
Addition
Disclaimer and I7-10700 information update in processors section
March 3, 2021
From V8 to V9
Update
Environmental specs updated
Loading...
