HP 2730p User Manual
QuickSpecs
Overview
HP EliteBook 2730p Notebook PC
HP recommends
Windows Vista® Business
1.
HP Presentation button with LED indicator
2.
Volume mute button with LED indicator
3.
Volume scroll zone with up/down LED indicators
4.
Pointstick
5.
Pointstick buttons
6.
Touchpad with scroll zone
7.
Touchpad buttons
8.
Business card slot
9.
Hard drive / optical drive activity / HP 3D DriveGuard
LED
10.
Battery charging LED
11.
Power/standby LED
12.
Power on/off
13.
USB 2.0 port (powered)
14.
HP Info / HP QuickLook button
15.
Wireless on/off with LED
16.
ExpressCard/54 slot or Smart Card Reader
17.
Pen holder
18.
Dual-microphone array
19.
Ambient light sensor
20.
Internal WWAN antenna
21.
Two internal WLAN antennas
22.
Optional 2 MP webcam with LED (select models)
23.
HP Night Light
24.
External WWAN antenna
DA - 13097 Worldwide QuickSpecs — Version 5 — 10.10.2008
Page 1
QuickSpecs
Overview
HP EliteBook 2730p Notebook PC
1.
Power/standby LED
2.
Battery charging LED
3.
Hard drive activity / HP 3D DriveGuard LED
4.
HP Night Light button
5.
External WWAN antenna button
6.
External WWAN antenna
7.
Display release latch
8.
Business Card slot
9.
Power on/off
10.
HP Fingerprint Sensor
11.
Kensington Lock slot
12.
USB 2.0 port
13.
Secure Digital (SD) slot
14.
Stereo microphone in
15.
Stereo headphone/line out
16.
1394a port
17.
Jog dial
18.
Esc button
19.
Convertible Hinge
20.
Rotate button
21.
Windows security button (ctl-alt-del)
22.
Power connector
23.
VGA/external monitor connector
24.
RJ-45/Ethernet port
25.
RJ-11/modem port
DA - 13097 Worldwide QuickSpecs — Version 5 — 10.10.2008
Page 2
QuickSpecs
Overview
HP EliteBook 2730p Notebook PC
1.
Docking connector
2.
Battery release latch
3.
Secondary battery connector
4.
Secondary battery connector door
NOTE:
On models with the optional WWAN module, the SIM card slot is located under the battery.
5.
Battery charge level indicator
6.
Battery bay
7.
Speaker
8.
Hard drive, memory, WLAN, WWAN module
compartment
At A Glance
Genuine Windows Vista Business 32, Genuine Windows Vista Business with downgrade to Windows XP Tablet
Edition custom installed, Genuine Windows Vista Ultimate 32, or FreeDOS
Convertible tablet design starting at 3.74 lb/1.70 kg and 1.11-inch/28.2 mm thin
Business Rugged –
altitude, and high temperature operation
12.1-inch diagonal Illumi-Lite WXGA ultra wide-viewing angle display with Digitizer, Ambient Light Sensor,
and optional Outdoor View
Intel® Core™2 Duo Low Voltage processor or Intel Core™2 Duo Ultra Low Voltage processor
Dual pointing device and jog dial
Connectors for HP 2700 Ultra-Slim Expansion Base and HP 2700 Ultra-Slim Battery
Up to 120-GB 5400 rpm, user-removable hard drive protected by HP 3D DriveGuard
Flexible wireless connectivity options:
Integrated HP un2400 EV-DO/HSDPA Mobile Broadband Module with worldwide Gobi mobile Internet
technology
Integrated 802.11 a/b/g/draft-n, a/b/g, or b/g wireless LAN module
Bluetooth®
Enhanced security features including HP ProtectTools, HP SpareKey, HP Fingerprint Sensor, TPM 1.2 Embedded
Security Chip**, and optional Smart Card Reader
Optional integrated camera
HP QuickLook 2 for instant access to email, calendar, and contact information
HP Night Light
Full magnesium alloy chassis, chemically-strengthened glass over display, HP DuraKeys and HP DuraFinish
ExpressCard/54 slot
Intel® Centrino® 2 with vPro™ technology capable
Up to 8 GB of 800 MHz DDR2 SDRAM supported, dual channel memory support
Touch-sensitive controls
Integrated Intel Gigabit Network Connection (10/100/1000 NIC)
Secure Digital (SD) slot
designed to meet the military standard Mil-Std-810F for shock, vibration, sand and dust, humidity,
*
DA - 13097 Worldwide QuickSpecs — Version 5 — 10.10.2008
Page 3
QuickSpecs
HP EliteBook 2730p Notebook PC
Overview
* Testing was not intended to demonstrate fitness for DOD contracts requirements or for military use. Test results are not a
guarantee of future performance under these test conditions.
** TPM module disabled where use is restricted by law; for example, Russia and China.
DA - 13097 Worldwide QuickSpecs — Version 5 — 10.10.2008
Page 4
QuickSpecs
Standard Features
HP EliteBook 2730p Notebook PC
Processors
Operating System
Intel Core 2 Duo LV Processor SL9400 (1.86 GHz, 6 MB L2 cache, 1066 MHz FSB)
Intel Core 2 Duo LV Processor SL9300 (1.60 GHz, 6 MB L2 cache, 1066 MHz FSB)
Intel Core 2 Duo ULV Processor SU9300 (1.20 GHz, 3 MB L2 cache, 800 MHz FSB)
* Intel's numbering is not a measurement of higher performance.
NOTE:
Processor speed denotes maximum performance mode; processors will run at lower
speeds in battery optimization mode.
Preinstalled
Supported
Certified
* Certain Windows Vista product features require advanced or additional hardware. See:
http://www.microsoft.com/windowsvista/getready/hardwarereqs.mspx
http://www.microsoft.com/windowsvista/getready/capable.mspx
Upgrade Advisor can help you determine which features of Windows Vista will run on your
computer. To download the tool, visit:
†
Windows Vista Business disk may be included for future upgrade if desired. To qualify for this
downgrade an end user must be a business (including governmental or educational institutions)
and is expected to order at least 25 customer systems with the same custom image.
Genuine Windows Vista Business 32
Genuine Windows Vista Business with downgrade to Windows XP
Tablet Edition custom installed
Genuine Windows Vista Ultimate 32
FreeDOS
Genuine Windows Vista Enterprise 32
Genuine Windows Vista Enterprise 64
SuSE Linux Enterprise Desktop 10
http://www.windowsvista.com/upgradeadvisor
*
†
*
*
*
*
and
for details. Windows Vista
*
*
*
.
Chipset
Intel Centrino 2 with
vPro technology
capable
Mobile Intel GS45 Express Chipset ICH9M-Enhanced
Intel Centrino 2 with vPro technology is a selectable feature that is available on units configured
with an Intel WiFi Link 5100. It provides advances in remote manageability, security, energy
efficient performance, and wireless connectivity. Intel Active Management Technology (AMT)
offers built-in manageability and proactive security for networked notebook PCs, even when they
are powered off* or when the operating system is inoperable. It can help identify threats before
they reach the operating system, isolate infected systems, and update PCs regardless of their
power state.
* Requires a Windows operating system, network hardware and software, connection with a
power source, and a direct (non-VPN) corporate network connection which is either cable or
wireless LAN.
NOTE:
Some functionality of Intel Centrino 2 and vPro technology, such as Intel Active
Management technology and Intel Virtualization technology, requires additional 3rd party software
in order to run. Availability of future “virtual appliances“ applications for Centrino 2 and vPro
technology is dependant on 3rd party software providers. Compatibility with future “virtual
appliances“and Microsoft Windows Vista operating system is yet to be determined.
DA - 13097 Worldwide QuickSpecs — Version 5 — 10.10.2008
Page 5
QuickSpecs
Standard Features
HP EliteBook 2730p Notebook PC
Business Rugged
Graphics
Display
Meets the military standard Mil-Std-810F* for:
Shock: Method 515.5 Proc. I (Functional)
Vibration: Method 514.5, Proc I, Cat. 20 & 24
High Temperature: Method 501.4, Proc I & II (140°F/60°C operational)
Sand and Dust: Method 510.4, Proc. I (Blowing Dust)
Humidity: Method 507.4 (95% relative humidity)
Altitude: Method 500.4 Low Pressure, Proc. I & II (15,000 feet operational)
*
Testing was not intended to demonstrate fitness for DOD contracts requirements or for military
use. Test results are not a guarantee of future performance under these test conditions.
Mobile Intel Graphics Media Accelerator 4500MHD, up to 384 MB of shared system memory
Microsoft DirectX 10 (Shader 4.0) and OpenGL 2.0 capable
Internal
External
* A display with optional Outdoor View is a 12.1-inch diagonal WXGA UWVA anti-glare display
with Digitizer that provides enhanced viewable improvements:
12.1-inch diagonal Illumi-Lite WXGA UWVA anti-glare with Digitizer
(1280 × 800 resolution)
Ambient light sensor
Optional Outdoor View
Up to 32-bit per pixel color depth
VGA
port supports resolutions up to 2048 x 1536 at 75 Hz, and lower
resolutions at up to 100 Hz
NOTE:
Resolutions are dependent upon monitor capability, and
resolution and color depth settings.
*
Memory
12% increase in front of screen display brightness with no loss of battery life
Up to 235% increase in contrast, resulting in better viewability, at wide viewing angles
25% less specular reflections in bright light
91% less diffuse reflections in bright light
67% more contrast in bright sunlight
NOTE:
This data is based on typical measurements by the display manufacturer. Actual
measurements may vary from panel to panel.
Standard
Maximum
Dual-channel
NOTE:
Due to the non-industry standard nature of some third-party memory modules, we
recommend HP branded memory to ensure compatibility. If you mix memory speeds, the system
will perform at the lower memory speed. Availability of 4 GB or more of memory requires
Windows Vista Business 64-bit or Linux. With Windows 32-bit operating systems, memory above
3 GB may not all be available due to system resource requirements.
800 MHz DDR2 SDRAM; two slots supporting dual channel memory
1024 MB, 2048 MB, 4096 MB, or 8192 MB
Upgradeable to 8192 MB with 4096 MB SODIMMs in slots 1 and 2
Maximized dual-channel performance requires SODIMMs of the same
size and speed in both memory slots.
DA - 13097 Worldwide QuickSpecs — Version 5 — 10.10.2008
Page 6
QuickSpecs
Standard Features
HP EliteBook 2730p Notebook PC
Communications
Wireless Devices
Integrated Intel Gigabit Network Connection (10/100/1000 NIC)
56K V.92 modem
* The term "10/100/1000" or "Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab
for Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/s. For high-speed
transmission, connection to a Gigabit Ethernet server and network infrastructure is required.
** Designed for downloads from 56K modem compliant sources. Maximum achievable download
transmission rates currently do not reach 56 KB/s, and will vary with line conditions. Modem
availability is subject to country regulatory approval.
Support for a broad range of secure, integrated wireless LAN and wireless WAN options featuring
support for the latest industry standards. Wireless LAN is factory configurable or available as an
option to be added later. Mobile Broadband (WWAN) requires Windows Vista Business or
Windows XP Tablet Edition and is available in select countries as a standard, factory configurable
feature or as an option to be added later. Integrated Bluetooth is also available (factory
configurable only) and can be combined with any of the supported wireless LAN and wireless
WAN options.
HP un2400
EV-DO/HSPA Mobile
Broadband Module
All 802.11 integrated
wireless LAN options
Intel WiFi Link 5100
Broadcom 4322AGN
802.11a/b/g/draft-n WiFi Adapter
Broadcom 4312G
802.11b/g
WiFi Adapter
HP Integrated Module
with Bluetooth
Wireless Technology
* The specifications for 802.11n draft 2.0 are draft specifications and are not final. If the final
specifications differ from the draft specifications, it may affect the ability of the notebook to
communicate with other 802.11n WLAN devices. In countries where n draft 2.0 is not allowed,
this capability is not enabled (Intel 802.11a/b/g only).
**
Integrated mobile broadband module with Gobi global mobile Internet
technology provides worldwide connection to both CDMA (EVDO) and
UMTS (HSPA) networks.
NOTE:
Separately purchased mobile network operator service is
required.
Two 850/900/1800/1900/2100 MHz antennas integrated in the top of
the display panel support current and future WWAN technologies.
Wi-Fi CERTIFIED*
Cisco Compatible Extensions support
Wired Equivalent Privacy (WEP) support up to 128-bit keys
Wi-Fi Protected Access (WPA) and WPA2 support
802.1x authentication support, including EAP-TLS, EAP-TTLS, PEAPGTC, PEAP-MSCHAPv2, and LEAP
Advanced Encryption Standard (AES) support
Two antennas integrated in the display enclosure
Integrated support for 802.11 a, b g, and n draft 2.0*
Up to 300 mbps data rate
Integrated support for 802.11a, b, g, and n draft 2.0*
Up to 300 mbps data rate
Integrated support for 802.11 b and g
Up to 54 mbps data rate
Bluetooth Specification v2.0 compliant
Works with a wide range of Bluetooth devices
*
DA - 13097 Worldwide QuickSpecs — Version 5 — 10.10.2008
Page 7
QuickSpecs
Standard Features
HP EliteBook 2730p Notebook PC
Keyboard
Touch-sensitive
controls
Pointing device
Expansion card slots
The 101/102-key compatible keyboard features an industry standard, full-pitch key layout with
desktop keyboard features, such as the isolated inverted-T cursor control keys, editing keys, both
left and right control and alt keys, and 12 function keys. US and International key layouts are
available. Other features include an integrated numeric keypad, hotkeys for instant access to
power conservation, brightness, and other features, 19-mm x 19-mm key pitch (center-to-center
spacing), 2.0-mm stroke, and comfort-dished keycaps.
HP DuraKeys is a clear coating applied over the notebook keyboard that helps protect the finish
and the printed characters on the keys.
HP DuraFinish helps protect the finish on the keyboard deck, graphics, and icons from normal
wear and tear.
Touch-sensitive controls provide easy access to the following features: HP Presentation button,
Volume mute button, and Volume scroll zone
Dual pointing (Touchpad with scroll zone and Pointstick, each with two pick buttons)
Digital Eraser Pen with tether and clip
ExpressCard/54 slot
or
Optional Integrated
Smart Card Reader
(replaces ExpressCard
slot)
Secure Digital slot
Supports ExpressCard/54 and ExpressCard/34
Compatible with ISO 7816 compliant Smart Cards
PC/SC interface support
Supports SD (Secure Digital), MMC (MultiMedia Card)
Storage
Internal Storage
Device
NOTE:
Hard drives are customer removable and will withstand multiple insertion/removal cycles.
Up to 10 GB is reserved for the system recovery software.
HP 3D DriveGuard
External Optical Drives
Second Hard Drive
80/120 GB 5400 rpm 1.8” SMART SATA II Hard Drive
80 GB Solid State Drive (available 4Q08)
The hard drive is mounted to the notebook frame, reducing the
transmission of shock away from the hard drive. Uses three-axis digital
motion detection with intelligent sensitivity to help protect the hard drive
during normal use from shock and vibration. The digital accelerometer
temporarily halts all data transfer and parks the hard drive when abrupt
motion is detected.
Via optional HP 2700 Ultra-Slim Expansion Base:
7mm DVD+/-RW SuperMulti Drive
Via optional HP External MultiBay II (9.5-mm):
MultiBay II DVD-ROM Drive
MultiBay II DVD+/-RW SuperMulti DL Drive
Via optional HP External MultiBay II (9.5-mm):
MultiBay II 80-GB 5400 rpm Hard Drive
DA - 13097 Worldwide QuickSpecs — Version 5 — 10.10.2008
Page 8
QuickSpecs
Standard Features
HP EliteBook 2730p Notebook PC
Interfaces
Audio/Visual
ExpressCard/54 slot
Smart Card Reader
External monitor
1394a
Stereo microphone in
Stereo headphone/line
out
Power connector
RJ-11/modem
RJ-45/Ethernet
USB 2.0
Docking connector
Secondary battery
connector
LED status indicators
High Definition Audio support w/24-bit DAC
Integrated mono speaker
Integrated dual-microphone array
Touch-sensitive controls for volume up, volume down, and mute
Stereo headphone/line out
Stereo microphone in
Supports ExpressCard/54 and ExpressCard/34
Optional (replaces ExpressCard/54 slot)
One – VGA
One
One
One
One
One
One
Two (including one powered USB 2.0 port to support HP External
MultiBay II)
For HP 2700 Ultra-Slim Expansion Base
For HP 2700 Ultra-Slim Battery
Thirteen
Software
Optional 2 MP Webcam with Business Card Reader Software
Supports videoconferencing and still image capture
Large image sensor for excellent color matching and good low light sensitivity
Up to 30 frames/sec
AutoMacro focus lens
Video capture at VGA, 1.3 Mpixel, and 2 Mpixel resolutions
16-bit true color (camera sensors output YCrCb format among others)
Preinstalled software
with Windows Vista or
Windows XP
HP Recovery Manager (Vista only)
HP Help and Support Center
HP QuickLook 2
HP Universal Print Driver
HP ProtectTools Security Manager:
BIOS Configuration for HP ProtectTools
Credential Manager for HP ProtectTools
Device Access Manager for HP ProtectTools
Drive Encryption for HP ProtectTools
Embedded Security for HP ProtectTools
HP Quick Launch Buttons
HP Wireless Assistant
Microsoft Office Ready with 60-day Office Professional 2007 Trial
Edition (select models)
PDF Complete Special Edition
Intervideo WinDVD – DVD Player
Roxio Creator Business (for optional DVD+/-RW and DVD/CD-RW
drives)
McAfee Total Protection
Microsoft Windows Live Messenger (select models)
HP Webcam Software
MS OneNote
*
DA - 13097 Worldwide QuickSpecs — Version 5 — 10.10.2008
Page 9
QuickSpecs
Standard Features
HP EliteBook 2730p Notebook PC
HP Recovery Manager
SMBIOS Version 2.4
HP ProtectTools
Security Manager
Additional software
available from the web
* 60 day trial period for McAfee Total Protection for Small Business software. Internet access
required to receive updates. First update included. Subscription required for updates thereafter.
Each Vista unit is shipped with HP Recovery Manager. HP Recovery Manager enables fast
recovery of the factory preinstalled image if the system becomes corrupted or if important system
files are accidentally deleted. Up to 10 GB of the hard drive is reserved for the system recovery
software.
System Management BIOS, previously known as DMI BIOS, is used to store system management
information.
HP ProtectTools Security Manager is the security platform for business notebooks and desktops.
The HP ProtectTools Security Manager is an extensible client security console that delivers
enhanced security capabilities through add-on software modules. Modules currently available
are:
BIOS Configuration for HP ProtectTools
Credential Manager for HP ProtectTools
Device Access Manager for HP ProtectTools
Drive Encryption for HP ProtectTools
File Sanitizer for HP ProtectTools
Set-up Wizard for HP ProtectTools
Privacy Manager for HP ProtectTools (Chat & Sign)
Embedded Security for HP ProtectTools
Java Card Security for HP ProtectTools
HP SoftPaq Download Manager
HP Client Manager Software
HP Client Management Solutions
Java Card Security for HP ProtectTools
Security
Standard Features
Optional Features
* TPM module disabled where use is restricted by law; for example, Russia and China.
For more information on HP security solutions refer to:
HP ProtectTools Security Manager
Enhanced Pre-Boot Security
HP SpareKey
One-Step Logon
HP Fingerprint Sensor
Integrated Smart Card Reader
Configuration Control Hardware
Memory Change Alert
Ownership Tag
Setup Password
Power-On Password
TPM 1.2 Embedded Security Chip*
TPM Enhanced DriveLock*
HP Disk Sanitizer
HP 3D DriveGuard
Kensington Lock Slot
Support for Computrace / LoJack for Laptops (must be purchased
separately)
Smart Card Reader
(replaces
ExpressCard/54 slot)
Compatible with ISO 7816 compliant Smart
Cards
PC/SC interface support
http://www.hp.com/go/security
.
DA - 13097 Worldwide QuickSpecs — Version 5 — 10.10.2008
Page 10
Loading...
