HP 2530p User Manual

QuickSpecs

Overview

HP EliteBook 2530p Notebook PC

HP recommends
Windows Vista® Business

1.

Dual-microphone array

2.

Volume mute button with LED indicator

3.

Volume scroll zone with up/down LED indicators

4.

Pointstick

5.

HP Fingerprint Sensor

6.

Speaker

7.

Touchpad buttons

8.

Touchpad with scroll zone

9.

Pointstick buttons

10.

Hard drive / optical drive activity / HP 3D DriveGuard LED

11.

Battery charging LED

12.

Power/standby LED

13.

Wireless on/off LED

14.

Optional optical drive available with 1.8-in internal storage,
or additional USB 2.0 port available without optical drive

15.

USB 2.0 Port (powered on select models)

16.

RJ-11/modem port

17.

Power connector

18.

Power button with LED

19.

HP Info / HP QuickLook button with LED indicator

20.

Wireless on/off button with LED indicator

21.

Ambient Light Sensor

22.

HP Presentation button with LED indicator

23.

Touchpad on/off button

24.

Two WLAN/WWAN combo antennas

25.

Optional 2 MP Webcam with LED

26.

HP NightLight and on/off button

DA - 13101 Worldwide QuickSpecs — Version 8 — 2.5.2009

Page 1

QuickSpecs

Overview

1.

ExpressCard/54 slot

2.

Secure Digital (SD) slot

3.

IEEE 1394a port

4.

Stereo headphone/line out

5.

Stereo microphone in

HP EliteBook 2530p Notebook PC

6.

USB 2.0 port

7.

VGA/external monitor connector

8.

Docking connector

9.

Kensington Lock slot

10.

RJ-45/Ethernet port

1.

Battery release latch

2.

Battery bay

3.

SIM slot for WWAN (select models) - inside battery bay

4.

WWAN module compartment

DA - 13101 Worldwide QuickSpecs — Version 8 — 2.5.2009

5.

Hard drive bay

6.

Bluetooth compartment

7.

Speaker

8.

Memory module and WLAN compartment

Page 2

QuickSpecs

HP EliteBook 2530p Notebook PC

Overview

At A Glance

Genuine Windows Vista Business 32, Genuine Windows Vista Home Basic, Genuine Windows Vista Business with
downgrade to Windows XP Professional custom installed, or FreeDOS
Starting at 3.19lb/1.45 kg and 0.99-inch/25.2 mm thin at front
Business Rugged – designed to meet the military standard Mil-Std-810F for drop, shock, vibration, sand and dust, humidity,
altitude, and high temperature operation
Intel® Centrino® 2 with vPro™ technology capable, with Intel Core™2 Duo ULV and LV processors
Two memory slots support up to 8 GB of 800 MHz DDR2 SDRAM, dual channel memory
Choice of 1.8-inch or 2.5-inch SMART SATA II hard drive up to 160-GB, protected by HP 3D DriveGuard;
or 80 GB 1.8-inch Solid State Drive
Optional integrated optical drive in models with1.8-inch hard drive or SSD; additional USB port in models without optical drive
Enhanced security features including HP ProtectTools, HP SpareKey, HP Fingerprint Sensor, TPM 1.2 Embedded Security
Chip**, and optional integrated Smart Card Reader
Optional 2 MP Webcam with Business Card Reader Software
HP QuickLook 2 for instant access to email, calendar, and contact information
Dual pointing devices (touchpad with scroll zone and pointstick)
HP Night Light
Enhanced reliability with HP DuraCase, HP DuraKeys and HP DuraFinish
Flexible wireless connectivity options:

Integrated HP un2400 EV-DO/HSDPA Mobile Broadband Module provides worldwide Gobi mobile Internet technology
Integrated 802.11 a/b/g/draft-n, a/b/g, or b/g wireless LAN module
Bluetooth®

12.1-inch diagonal Illumi-Lite WXGA display with Ambient Light Sensor and HP Privacy Filter support
3-, 6-, and 9-cell battery options
Connector for HP 2400/2500 Ultra-Light Docking Station
Integrated Intel Gigabit Network Connection (10/100/1000 NIC)
Secure Digital (SD) slot

*

* Testing was not intended to demonstrate fitness for DOD contracts requirements or for military use. Test results are not a guarantee
of future performance under these test conditions.
** TPM module disabled where use is restricted by law; for example, Russia and China.

DA - 13101 Worldwide QuickSpecs — Version 8 — 2.5.2009

Page 3

QuickSpecs

Standard Features

HP EliteBook 2530p Notebook PC

Processors

Operating System

Intel Core 2 Duo LV Processor SL9400 (1.86 GHz, 6 MB L2 cache, 1066 MHz FSB)
Intel Core 2 Duo LV Processor SL9300 (1.60 GHz, 6 MB L2 cache, 1066 MHz FSB)
Intel Core 2 Duo ULV Processor SU9300 (1.20 GHz, 3 MB L2 cache, 800 MHz FSB)

* Intel's numbering is not a measurement of higher performance.
NOTE:

battery optimization mode.

Preinstalled

Supported

Certified

* Certain Windows Vista product features require advanced or additional hardware. See:

http://www.microsoft.com/windowsvista/getready/hardwarereqs.mspx
http://www.microsoft.com/windowsvista/getready/capable.mspx

Advisor can help you determine which features of Windows Vista will run on your computer. To
download the tool, visit:

Processor speed denotes maximum performance mode; processors will run at lower speeds in

Genuine Windows Vista Business 32*
Genuine Windows Vista Home Basic*
Genuine Windows Vista Business with downgrade to Windows XP
Professional custom installed
FreeDOS

Genuine Windows Vista Business 64
Genuine Windows Vista Enterprise 32
Genuine Windows Vista Enterprise 64

SuSE Linux Enterprise Desktop 10

http://www.windowsvista.com/upgradeadvisor

†

*

*

*
*

and

for details. Windows Vista Upgrade

.

*
*

*

Chipset

Intel Centrino 2 with vPro
technology capable

†

Windows Vista Business disk may be included for future upgrade if desired. To qualify for this
downgrade an end user must be a business (including governmental or educational institutions) and is
expected to order at least 25 customer systems with the same custom image.

Mobile Intel GS45 Express Chipset ICH9M-Enhanced

Intel Centrino 2 with vPro technology is a selectable feature that is available on units configured with an
Intel WiFi Link 5100. It provides advances in remote manageability, security, energy efficient
performance, and wireless connectivity. Intel Active Management Technology (AMT) offers built-in
manageability and proactive security for networked notebook PCs, even when they are powered off* or
when the operating system is inoperable. It can help identify threats before they reach the operating
system, isolate infected systems, and update PCs regardless of their power state.

*Requires a Windows operating system, network hardware and software, connection with a power
source, and a direct (non-VPN) corporate network connection which is either cable or wireless LAN.

NOTE:
technology and Intel Virtualization technology, requires additional 3rd party software in order to run.
Availability of future "virtual appliances" applications for Centrino 2 and vPro technology is dependant on
3rd party software providers. Compatibility with future "virtual appliances" and Microsoft Windows Vista
operating system is yet to be determined.

Some functionality of Intel Centrino 2 and vPro technology, such as Intel Active Management

DA - 13101 Worldwide QuickSpecs — Version 8 — 2.5.2009

Page 4

QuickSpecs

Standard Features

HP EliteBook 2530p Notebook PC

Business Rugged

Graphics

Display

Meets the military standard Mil-Std-810F* for:

Drop: Method 516.5 Proc. IV (26 drops from 30")
Shock: Method 515.5 Proc. I (Functional)
Vibration: Method 514.5, Proc I, Cat. 20 & 24
High Temperature: Method 501.4, Proc I & II (140°F/60°C operational)
Sand and Dust: Method 510.4, Proc. I (Blowing Dust)
Humidity: Method 507.4 (95% relative humidity)
Altitude: Method 500.4 Low Pressure, Proc. I & II (15,000 feet operational)

*

Testing was not intended to demonstrate fitness for DOD contracts requirements or for military use. Test

results are not a guarantee of future performance under these test conditions.

Mobile Intel Graphics Media Accelerator 4500MHD, up to 384 MB of shared system memory
Microsoft DirectX 10 (Shader 4.0) and OpenGL 2.0 capable

Internal

External

12.1-inch diagonal Illumi-Lite WXGA anti-glare (1280 × 800 resolution)
Ambient light sensor
HP Privacy Filter support

Up to 32-bit per pixel color depth
VGA

port supports resolutions up to 2048 x 1536 at 75 Hz, and lower
resolutions at up to 100 Hz

NOTE:
and color depth settings.

Resolutions are dependent upon monitor capability, and resolution

Memory

Communications

Standard

Maximum
Dual-channel

NOTE:
branded memory to ensure compatibility. If you mix memory speeds, the system will perform at the lower
memory speed. Availability of 4 GB or more of memory requires Windows Vista Business 64-bit or Linux.
With Windows 32-bit operating systems, memory above 3 GB may not all be available due to system
resource requirements.

Integrated Intel Gigabit Network Connection (10/100/1000 NIC)
56K V.92 modem

* The term "10/100/1000" or "Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab for
Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/s. For high-speed transmission,
connection to a Gigabit Ethernet server and network infrastructure is required.

** Designed for downloads from 56K modem compliant sources. Maximum achievable download
transmission rates currently do not reach 56 KB/s, and will vary with line conditions. Modem availability
is subject to country regulatory approval.

Due to the non-industry standard nature of some third-party memory modules, we recommend HP

**

800 MHz DDR2 SDRAM; two slots supporting dual channel memory
1024 MB, 2048 MB, 4096 MB, or 8192 MB

Upgradeable to 8192 MB with 4096 MB SODIMMs in slots 1 and 2
Maximized dual-channel performance requires SODIMMs of the same size

and speed in both memory slots.

*

DA - 13101 Worldwide QuickSpecs — Version 8 — 2.5.2009

Page 5

QuickSpecs

Standard Features

HP EliteBook 2530p Notebook PC

Wireless Devices

Support for a broad range of secure, integrated wireless LAN and wireless WAN options featuring
support for the latest industry standards. Wireless LAN is factory configurable or available as an option to
be added later. Mobile Broadband (WWAN) requires Windows Vista Business or Windows XP
Professional and is available in select countries as a standard, factory configurable feature or as an
option to be added later. Integrated Bluetooth is also available (factory configurable only) and can be
combined with any of the supported wireless LAN and wireless WAN options.

HP un2400
EV-DO/HSPA Mobile
Broadband Module

All 802.11 integrated
wireless LAN options

Intel WiFi Link 5100

Broadcom 4322AGN

802.11a/b/g/draft-n
Wi-Fi Adapter

Broadcom 4312G

802.11b/g
WiFi Adapter

HP Integrated Module
with Bluetooth Wireless
Technology

* The specifications for 802.11n draft 2.0 are draft specifications and are not final. If the final
specifications differ from the draft specifications, it may affect the ability of the notebook to communicate
with other 802.11n WLAN devices. In countries where n draft 2.0 is not allowed, this capability is not
enabled (Intel 802.11a/b/g only).

Integrated mobile broadband module with Gobi global mobile Internet
technology that provides worldwide connection to both CDMA (EVDO) and
UMTS (HSPA) networks.

NOTE:

Two 850/900/1800/1900/2100 MHz antennas integrated in the top of
the display panel support current and future WWAN technologies.

Wi-Fi CERTIFIED
Cisco Compatible Extensions support
Wired Equivalent Privacy (WEP) support up to 128-bit keys
Wi-Fi Protected Access (WPA) and WPA2 support

802.1x authentication support, including EAP-TLS, EAP-TTLS, PEAP-GTC,
PEAP-MSCHAPv2, and LEAP
Advanced Encryption Standard (AES) support
Two antennas integrated in the display enclosure

Integrated support for 802.11 a, b g, and n draft 2.0
Up to 300 mbps data rate

Integrated support for 802.11a, b, g, and n draft 2.0
Up to 300 mbps data rate

Integrated support for 802.11 b and g
Up to 54 mbps data rate

Bluetooth Specification v2.0 compliant
Works with a wide range of Bluetooth devices

Separately purchased mobile network operator service is required.

*

*

*

DA - 13101 Worldwide QuickSpecs — Version 8 — 2.5.2009

Page 6

QuickSpecs

Standard Features

HP EliteBook 2530p Notebook PC

Keyboard

Touch-sensitive controls

Pointing device

The 101/102-key compatible keyboard features an industry standard, full-pitch key layout with desktop
keyboard features, such as the isolated inverted-T cursor control keys, editing keys, both left and right
control and alt keys, and 12 function keys. US and International key layouts are available. Other features
include an integrated numeric keypad, hotkeys for instant access to power conservation, brightness, and
other features, 19 mm x 19 mm key pitch (center-to-center spacing), 2.0 mm stroke, and comfort-dished
keycaps.

HP DuraKeys is a clear coating applied over the notebook keyboard that helps protect the finish and the
printed characters on the keys.

HP DuraFinish helps protect the finish on the keyboard deck, graphics, and icons from normal wear and
tear.

HP Night Light shines directly on keyboard for low-light conditions.

Touch-sensitive controls provide easy access to the following features: HP Info Center, HP QuickLook,
wireless on/off, HP Presentation button, touchpad on/off, volume up, volume down, and mute

Enhanced dual pointing devices:
Touchpad with scroll zone, two pick buttons
and
Pointstick, two pick buttons

Expansion card slots

Storage

ExpressCard/54 slot
or
Optional Integrated Smart

Card Reader
ExpressCard slot)

Secure Digital slot

Internal Storage Device

NOTE:
10 GB is reserved for the system recovery software.

HP 3D DriveGuard

Optical drives
(9.5mm SATA)

NOTE:

(replaces

Hard drives are customer removable and will withstand multiple insertion/removal cycles. Up to

Optical drive available only with 1.8-inch hard drive or Solid State Drive.

Supports ExpressCard/54 and ExpressCard/34

Compatible with ISO 7816 compliant Smart Cards

Supports SD (Secure Digital), MMC (MultiMedia Card)

80/120 GB 5400 rpm 1.8-inch SMART SATA II Hard Drive
120 GB 5400 rpm 2.5-inch SMART SATA II Hard Drive
160 GB 7200 rpm 2.5-inch SMART SATA II Hard Drive
80 GB 1.8-inch Solid State Drive

The hard drive is mounted to the notebook frame, reducing the transmission of
shock away from the hard drive. Uses three-axis digital motion detection with
intelligent sensitivity to help protect the hard drive during normal use from
shock and vibration. The digital accelerometer temporarily halts all data
transfer and parks the hard drive when abrupt motion is detected.

DVD-ROM Drive
DVD+/-RW SuperMulti DL Drive

DA - 13101 Worldwide QuickSpecs — Version 8 — 2.5.2009

Page 7

QuickSpecs

Standard Features

HP EliteBook 2530p Notebook PC

Interfaces

Audio/Visual

ExpressCard/54 slot
Smart Card Reader
External monitor
1394a
Stereo microphone in
Stereo headphone/line

out
Power connector
RJ-11/modem
RJ-45/Ethernet
USB 2.0

Docking connector
LED status indicators

High Definition Audio support w/24-bit DAC
Integrated mono speaker
Integrated dual-microphone array
Touch-sensitive controls for volume up, volume down, and mute
Stereo headphone/line out
Stereo microphone in

Supports ExpressCard/54 and ExpressCard/34
Optional (replaces ExpressCard/54 slot)
One – VGA
One
One
One

One
One
One
Two (including one powered USB 2.0 port to support HP External MultiBay II

on units without an integrated optical drive)
Third USB 2.0 port available without optical drive

For HP 2400/2500 Ultra-Light Docking Station
Sixteen

Optional 2 MP Webcam with Business Card Reader Software

Supports videoconferencing and still image capture
Large image sensor for excellent color matching and good low light sensitivity
Up to 30 frames/sec
AutoMacro focus lens
Video capture at VGA, 1.3 Mpixel, and 2 Mpixel resolutions
16-bit true color (camera sensors output YCrCb format among others)

DA - 13101 Worldwide QuickSpecs — Version 8 — 2.5.2009

Page 8

QuickSpecs

Standard Features

HP EliteBook 2530p Notebook PC

Software

Preinstalled software with
Windows Vista or
Windows XP

Additional software
available from the web

* 60 day trial period for McAfee Total Protection for Small Business software. Internet access required to
receive updates. First update included. Subscription required for updates thereafter.

HP Recovery Manager (Vista only)
HP Help and Support Center
HP QuickLook 2
HP Universal Print Driver
HP ProtectTools Security Manager
HP Quick Launch Buttons
HP Wireless Assistant
Microsoft Office Ready with 60-day Office Professional 2007 Trial Edition
(select models)
PDF Complete Special Edition
Intervideo WinDVD – DVD Player
Roxio Creator Business (for optional DVD+/-RW and DVD/CD-RW drives)
McAfee Total Protection
Microsoft Windows Live Messenger (select models)
HP Webcam Software

HP SoftPaq Download Manager
HP Client Manager Software
HP Client Management Solutions
Java Card Security for HP ProtectTools

*

HP Recovery Manager

SMBIOS Version 2.4

HP ProtectTools Security
Manager

Each Vista unit is shipped with HP Recovery Manager. HP Recovery Manager enables fast recovery of
the factory preinstalled image if the system becomes corrupted or if important system files are accidentally
deleted. Up to 10 GB of the hard drive is reserved for the system recovery software.

System Management BIOS, previously known as DMI BIOS, is used to store system management
information.

HP ProtectTools Security Manager is the security platform for business notebooks and desktops. The HP
ProtectTools Security Manager is an extensible client security console that delivers enhanced security
capabilities through add-on software modules. Modules currently available are:

BIOS Configuration for HP ProtectTools
Credential Manager for HP ProtectTools
Device Access Manager for HP ProtectTools
Drive Encryption for HP ProtectTools
File Sanitizer for HP ProtectTools
Set-up Wizard for HP ProtectTools
Privacy Manager for HP ProtectTools (Chat & Sign)
Embedded Security for HP ProtectTools
Java Card Security for HP ProtectTools

DA - 13101 Worldwide QuickSpecs — Version 8 — 2.5.2009

Page 9

QuickSpecs

Standard Features

HP EliteBook 2530p Notebook PC

Security

Standard Features

Optional Features

* TPM module disabled where use is restricted by law; for example, Russia and China.
For more information on HP security solutions refer to:

HP ProtectTools Security Manager
Enhanced Pre-Boot Security
HP SpareKey
One-Step Logon
HP Fingerprint Sensor
Integrated Smart Card Reader
Configuration Control Hardware
Memory Change Alert
Ownership Tag
Setup Password
Power-On Password
TPM 1.2 Embedded Security Chip
TPM Enhanced DriveLock
HP Disk Sanitizer
HP 3D DriveGuard
Kensington Lock Slot
Support for Computrace / LoJack for Laptops (must be purchased separately)

Smart Card Reader
(replaces ExpressCard/54
slot)

HP Privacy Filter

*

http://www.hp.com/go/security

*

Compatible with ISO 7816 compliant Smart
Cards

Narrows viewing area so that screen data is
visible only to persons directly in front of the
monitor

.

Power Supply

Battery

External 65-watt Smart AC adapter, 6-foot (1.8-meter) power cord included.
Total length including external AC adapter is 12 feet (3.66 meter).
HP Fast Charge

* HP Fast Charge recharges your battery up to 90% within 90 minutes when the system is off. Fast
Charge Technology does not apply to 9 cell primary batteries.

Primary Battery

Battery Fuel Gauge LEDs

*

3-cell (31 WHr) high capacity Lithium-Ion
6-cell (55 WHr) high capacity Lithium-Ion
9-cell (83 WHr) high capacity Lithium-Ion

6-cell high capacity and 9-cell high capacity

DA - 13101 Worldwide QuickSpecs — Version 8 — 2.5.2009

Page 10

QuickSpecs

Standard Features

HP EliteBook 2530p Notebook PC

Battery Life

System Standby Time

Power Conservation

Docking

(optional)

3-cell Primary Battery
6-cell Primary Battery
9-cell Primary Battery

NOTE:
Professional. Battery life will vary depending on the product configuration, product model, applications
loaded on the product, power management settings of the product, and the product features used by the
customer. As with all batteries, the maximum capacity of this battery will decrease with time and usage.

Up to 1 week

Supports enhanced Intel SpeedStep technology with Intel Core 2 Duo ULV processors (allows Battery
Optimized Mode, Maximum Performance Mode, or Automatic mode)

Intel Display Power Saving technology
Hibernation
Standby
ACPI compliance

HP 2400/2500 Ultra-Light Docking Station

The listed battery life measurements were taken on models running Microsoft Windows XP

Intel Core 2 Duo ULV Processor
Up to 4 hours and 30 minutes Up to 4 hours and 30 minutes
Up to 8 hours and 45 minutes Up to 8 hours and 15 minutes
Up to 13 hours and 30 minutes Up to 12 hours and 45 minutes

Intel Core 2 Duo LV Processor

Service and Support

Select Model(s)

HP Services offers limited 3-year, 1-year and 90-day warranty options depending on country;
1-year limited warranty on primary battery. On-site service and warranty upgrades are also available. HP
Care Pack Services extend service contracts beyond the standard warranties. To choose the right level of
service for your HP product, use the HP Care Pack Services Lookup Tool at:

http://www.hp.com/go/lookuptool

available at:

NOTE:

http://h20000.www2.hp.com/bizsupport/TechSupport/ProductRoot.jsp

HP's Global Product Offer includes Global Series Preconfigured (GS-P) and Configurable (GS-C)
products. GPO delivers globally consistent products, services, and solutions with End-of-Life (EOL)
transition management. These products reduce IT complexity, lower management costs, increase
productivity, and simplify product transitions.

http://www.hp.com/hps/carepack

Certain restrictions and exclusions apply. Consult the HP Customer Support Center for details.

. Additional HP Care Pack Services information by product is

.

.

DA - 13101 Worldwide QuickSpecs — Version 8 — 2.5.2009

Page 11

QuickSpecs

Standard Features

HP EliteBook 2530p Notebook PC

2530p
FV879AW#xxx
Global SKU (see
exceptions below)

FV880AW#xxx
(for Latin America,
Australia, New Zealand,
and Singapore)

NOTE:
vary based on local
regulatory requirements

Components may

Processor

Intel Centrino 2 Pro
processor technology

Operating System
System Memory
Hard Drive
Optical Drive
Display
Graphics
Webcam
Audio

Communications

Integrated Wireless
Integrated Security

Pointing Device
Battery
Power
Warranty

* TPM module disabled where use is restricted by law; for example, Russia.

Intel Core 2 Duo LV Processor SL9400 (1.86 GHz, 6 MB L2 cache, 1066
MHz FSB)

Enabled

Genuine Windows Vista Business 32 with Office Ready
2048 MB 800 MHz DDR2 (1 DIMM)
120 GB 5400 rpm 1.8" SMART SATA II
DVD+/-RW SuperMulti DL Drive

12.1-inch diagonal Illumi-Lite WXGA anti-glare
Mobile Intel GMA 4500MHD
No
ADI High Definition CODEC

Stereo headphone/line out and microphone in
Integrated microphone

Integrated Intel Gigabit Network Connection (10/100/1000 NIC)
56K V.92 modem

Intel WiFi Link 5100 (802.11 a/b/g/n draft 2.0)
Drive Encryption for HP ProtectTools

HP Fingerprint Sensor
TPM 1.2

Dual pointing devices (Touchpad and Pointstick)
6-cell (55 WHr) Lithium-Ion
External 65W adapter
3/3/0 or 3/3/3 depending on country

*

DA - 13101 Worldwide QuickSpecs — Version 8 — 2.5.2009

Page 12

QuickSpecs

Options

HP EliteBook 2530p Notebook PC

Memory

Storage

MultiBay II Storage
(9.5-mm)

NOTE:
External MultiBay II

Expansion Solutions

Communications

Requires HP

HP 1 GB (DDR2 800 MHz) SODIMM
HP 2 GB (DDR2 800 MHz) SODIMM
HP 4 GB (DDR2 800 MHz) SODIMM

HP Notebooks USB Diskette Drive
HP 250GB Pocket Media Drive

HP MultiBay II DVD-ROM Drive

HP MultiBay II DVD+/-RW SuperMulti DL Drive

HP 2400/2500 Ultra-Light Docking Station
HP Standard Monitor Stand
HP Adjustable Notebook Stand
HP External MultiBay II

Intel WiFi Link 5300
HP un2400 EVDO/HSUPA Mobile Broadband Module

KT292AA
KT293AA
KT294AA

DC361B

FE477AA

PA849A

PA851A

EQ773AA#xxx

PA507A
PA508A

PA509A#xxx

KM591AA#xxx

FN556AA

Power

Carrying Cases

HP 65W Smart AC Adapter
HP 90W Smart Auto Adapter
HP 90W Smart AC/Auto/Air Combo Adapter
65W Smart AC/Auto/Air Combo Adapter
HP 3-Cell Li-Ion Primary Battery
HP 6-Cell Li-Ion Primary Battery
HP 9-Cell Li-Ion Primary Battery
HP 2500 Series 9-cell Primary Battery
HP 1-bay Battery Charging Station
HP 5-bay Battery Charging Station
Battery Adapter Kit

HP Basic Carrying Case
HP Value Nylon Case
HP Universal Nylon Case
HP Executive Leather Case
HP Deluxe Nylon Backpack
HP Deluxe Roller Case

ED494AA#xxx

ED493AA

AJ652AA#xxx

ED993AA#xxx

RW556AA

EH767AA
EH768AA
KU529AA

RW635AA#xxx

RW636AA#ABA

RW640AA

AJ078AA
RR314AA
RR315AA
RR316AA
RR317AA

GD405AA

DA - 13101 Worldwide QuickSpecs — Version 8 — 2.5.2009

Page 13

QuickSpecs

Options

HP EliteBook 2530p Notebook PC

Security

Input/Output Devices

HP ExpressCard Smart Card Reader with Java Card
HP ProtectTools Java Card – 10 units
HP/Kensington MicroSaver Security Lock
HP Privacy Filter

HP USB Keyboard & Mouse Bundle
HP USB/PS2 Optical 2-Button Scroll Mouse
HP USB Optical Travel Mouse

AJ451AA

EL348AA

PC766A

AJ356AA

RC465AA#xxx

DC369A

RH304AA

DA - 13101 Worldwide QuickSpecs — Version 8 — 2.5.2009

Page 14

QuickSpecs

Memory

800-MHz DDR2 SDRAM
Two DIMM slots supporting dual channel memory
DIMM sizes supported: 1024 MB, 2048 MB, and 4096 MB

Standard Memory

1024 MB (1024 MB x 1)
2048 MB (2048 MB x 1)
4096 MB (4096 MB x 1 or 2048 MB x 2)

HP EliteBook 2530p Notebook PC

Optional Memory
Upgrades

Up to
1024 MB 1024 MB
2048 MB 1024 MB 1024 MB
3072 MB 2048 MB 1024 MB
4096 MB 2048 MB 2048 MB
8192 MB 4096 MB 4096 MB

NOTE:
memory modules, we strongly recommend using only HP branded memory modules to ensure compatibility. If you mix memory
speeds, the system will perform at the lower memory speed. Availability of 4 GB or more of memory requires Windows Vista Business
64-bit or Linux. With Windows 32-bit operating systems, memory above 3 GB may not all be available due to system resource
requirements.

Memory Upgrades

This chart does not represent all possible memory configurations. Due to the non-industry standard nature of some third-party

Support for up to 8192 MB of memory with the installation of optional DDR2 SDRAM memory kits. Both
memory slots are user accessible. Please refer to the Hardware and Software Guide for installation
procedures. Maximized dual-channel performance requires SODIMMs of the same size and speed in
both memory slots.

Slot 1 Slot 2

Empty

HP 1 GB (DDR2 800 MHz) SODIMM
HP 2 GB (DDR2 800 MHz) SODIMM
HP 4 GB (DDR2 800 MHz) SODIMM

KT292AA
KT293AA
KT294AA

DA - 13101 Worldwide QuickSpecs — Version 8 — 2.5.2009

Page 15

QuickSpecs

Storage

Optical Drive Support

Fixed optical drives
DVD-ROM Drive
DVD+/-RW SuperMulti DL Drive

NOTE:

Optical drive available only with 1.8-inch hard drive or Solid State Drive.

Internal Storage Device

1.8-inch SMART SATA II Hard Drives
80-GB 5400 rpm
120-GB 5400 rpm

- or -

2.5-inch SMART SATA II Hard Drives
120-GB 5400 rpm
160-GB 7200 rpm

- or -

1.8-inch Solid State Drive
80 GB Solid State Drive

(95mm SATA)

HP EliteBook 2530p Notebook PC

Quantity Supported
One
One

Quantity Supported
One
One

One
One

One

Drive Bay
Fixed optical drive bay
Fixed optical drive bay

Drive Bay
Dedicated hard drive bay
Dedicated hard drive bay

Dedicated hard drive bay
Dedicated hard drive bay

Dedicated hard drive bay

DA - 13101 Worldwide QuickSpecs — Version 8 — 2.5.2009

Page 16

QuickSpecs

Technical Specifications

HP EliteBook 2530p Notebook PC

System Unit

Dimensions

Weight

NOTE:
includes 3-cell battery, hard drive, 1 GB memory, 802.11 wireless communications module. Weight
varies by configuration and components.

Stand-Alone Power
Requirements
(AC Power)

Temperature

Relative Humidity

Shock

Random Vibration

Altitude
(unpressurized)

Industry Standard
Certifications

(HxWxD)

Height varies depending upon where on the notebook the measurement is made. Starting weight

0.99 in (at front) x 11.11 in x 8.44 in

25.2 mm (at front) x 282.3 mm x 214.3 mm
Starting from 3.19 lb (1.45 kg)

Nominal Operating
Voltage

Average Operating Power
Max Operating Power
Operating

Non-operating
Operating
Non-operating

Operating
Non-operating
Operating
Non-operating
Operating
Non-operating
UL
CSA
FCC Compliance
ENERGY STAR
EPEAT
ICES
GS Yes
Australia / NZ A-Tick

Compliance
CCC
Japan VCCI Compliance
MIC
BSMI
CE Marking Compliance
BNCI or BELLIS
CIT
GOST
Saudi Arabian

Compliance (ICCP)
SABS
UKRSERTCOMPUTER

®

18.5 V

14.0 W
< 65 W
32° to 95° F (0° to 35° C) (not writing optical)
41° to 95° F (5° to 35° C) (writing optical)
–4° to 140° F (–20° to 60° C)
10% to 90%, non-condensing
5% to 95%, 101.6° F (38.7° C) maximum wet

bulb temperature
125 G, 2 ms, half-sine
200 G, 2 ms, half-sine

0.75 grms

1.50 grms
–50 to 10,000 ft (–15.24 to 3,048 m)
–50 to 40,000 ft (–15.24 to 12,192 m)
Yes
Yes
Yes
Yes
Gold
Yes

Yes

Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes

Yes
Yes

DA - 13101 Worldwide QuickSpecs — Version 8 — 2.5.2009

Page 17

QuickSpecs

Technical Specifications

HP EliteBook 2530p Notebook PC

HP 65W Smart AC
Adapter

For accessibility information on HP products, please visit:

Dimensions
Weight
Input

Output

Connector
Environmental Design

EMI and Safety
Certifications

4.17 x 1.85 x 1.1 in (10.6 x 4.7 x 2.8 cm)

0.62 lb (280 g)
100 to 240 VAC
Input Efficiency
Input frequency range
Input AC current
Output power 65W
DC output
Hold-up time
Output current limit

3 pin/grounded, mates with interchangeable cords
Operating temperature
Non-operating (storage)

temperature
Altitude
Humidity
Storage Humidity
CE Mark – full compliance with LVD and EMC directives; Worldwide safety

standards – IEC60950, EN60950, UL60950, Class1, SELV; Agency
approvals – C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class
B, CISPR22 Class B, CCC, NOM-1 NYCE; MTBF – over 200,000 hours at
25°C ambient condition.

http://www.hp.com/accessibility

83% min at 115 VAC
47 to 63 Hz

1.7 A at 90 VAC, 0.85 A at 180 VAC
65W

18.5V
5 msec at 115 VAC inputOutput current limit
<11A, Over voltage protection- 29V max

automatic shutdown

32° to 104° F (0° to 40° C)
–4° to 149° F (–20° to 65° C)

0 to 10,000 ft (0 to 3,048 m)
20% to 80%
10% to 90%

.

9-Cell (83 WHr) Lithium­Ion battery

Dimensions
Weight
Cells/Type
Energy
Temperature

Battery Re-Charge Time

Fuel Gauge

(H x W x L)

1.6 x 2.3 x 8.1 in (4.1 x 5.9 x 20.6 cm)

1.07 lb (0.488 kg)
9-cell Lithium-Ion
Watt-hour Capacity
Operating (Charging)
Operating (Discharging)
Non-operating
System in OFF mode or

Standby
System ON

When pressed, LEDs light indicating level of charge remaining on battery

83 WHr
32° to 113° F (0° to 45° C)
14° to 140° F (–10° to 60° C)
–4° to 140° F (–20° to 60° C)
3 to 4 hours

4 to 5 hours (depending on system power
consumption)

DA - 13101 Worldwide QuickSpecs — Version 8 — 2.5.2009

Page 18

QuickSpecs

Technical Specifications

HP EliteBook 2530p Notebook PC

6-Cell (55 WHr) Lithium­Ion battery

Displays

12.1-inch Illumi-Lite
WXGA anti-glare

Dimensions
Weight
Cells/Type
Energy
Temperature

Battery Re-Charge Time

Fuel Gauge

Active Area
Diagonal Size
Surface Treatment
Contrast Ratio
Refresh Rate
Brightness
Pixel Resolution

Backlight
PPI
Viewing Angle

(H x W x L)

(W x H)

0.8 x 2.3 x 8.1 in (2.1 x 5.9 x 20.6 cm)

0.73 lb (0.332 kg)
6-cell Lithium-Ion
Watt-hour Capacity
Operating (Charging)
Operating (Discharging)
Non-operating
System in OFF mode or

Standby
System ON

HP Fast Charge
Technology

When pressed, LEDs light indicating level of charge remaining on battery

10.3 x 6.4 in (26.1 x 16.3 cm)

12.1 in (30.7 cm)
Anti-glare
300:1 (typical)
60 Hz
200 nit (typical)
Pitch
Format
Configuration
LED
125
±30° Horizontal, ±10° Vertical (minimum)

30/30/20/10 (Left/Right/Down/Up) (minimum) or
45/45/35/25 (Left/Right/Down/Up) (typical)

55 WHr
32° to 113° F (0° to 45° C)
14° to 140° F (–10° to 60° C)
–4° to 140° F (–20° to 60° C)

2.5 hours

3 to 5 hours (depending on system power
consumption)

Charges the battery up to 90% within 90 minutes
when system is OFF

0.204 mm
1280 x 800
RGB Stripe

Internal Storage

DA - 13101 Worldwide QuickSpecs — Version 8 — 2.5.2009

Page 19

QuickSpecs

Technical Specifications

HP EliteBook 2530p Notebook PC

160 GB 7200 rpm SATA
Hard Drive

120 GB 5400 rpm SATA
Hard Drive

Drive Weight
Capacity
Height
Width
Interface
Transfer Rate
Seek Time

(typical reads, including
settling)

Rotational Speed
Logical Blocks
Operating Temperature
Features

Drive Weight
Capacity
Height
Width
Interface
Transfer Rate
Seek Time

(typical reads, including
settling)

Rotational Speed
Logical Blocks
Operating Temperature
Features

0.25 lb (115 g)
160 GB

0.37 in (9.5 mm)

2.75 in (70 mm)
ATA-8, SATA 2.6, 3.0 Gb/s, NCQ
Synchronous
Single Track
Average
Maximum
7200 rpm
312,581,808
32° to 140° F (0° to 60° C) [case temp]
ATA Security

0.22 lb (101 g)
120 GB

0.37 in (9.5 mm)

2.75 in (70 mm)
ATA-8, SATA 2.6, 3.0 Gb/s, NCQ
Synchronous
Single Track
Average
Maximum
5400 rpm
234,441,648
32° to 140° F (0° to 60° C) [case temp]
ATA Security

(maximum)

(maximum)

100 MB/s (Drive Capability)

1.5 ms
11 ms
22 ms

100 MB/s (Drive Capability)
3 ms
13 ms
24 ms

DA - 13101 Worldwide QuickSpecs — Version 8 — 2.5.2009

Page 20

QuickSpecs

Technical Specifications

HP EliteBook 2530p Notebook PC

120 GB 5400 rpm

1.8" SATA Hard Drive

80 GB 5400 rpm

1.8" SATA Hard Drive

Drive Weight
Capacity
Height
Width
Interface
Transfer Rate
Seek Time

(typical reads, including
settling)

Rotational Speed
Logical Blocks
Operating Temperature
Features

Drive Weight
Capacity
Height
Width
Interface
Transfer Rate
Seek Time

(typical reads, including
settling)

Rotational Speed
Logical Blocks
Operating Temperature
Features

0.13 lb (62 g)
120 GB

0.31 in (8 mm)

2.12 in (54 mm)
ATA-8, SATA 2.5, 1.5 Gb/s
Synchronous
Single Track
Average
Maximum
5400 rpm
234,441,648
32° to 140° F (0° to 60° C) [case temp]
ATA Security

0.13 lb (62 g)
80 GB

0.31 in (8 mm)

2.12 in (54 mm)
ATA-8, SATA 2.5, 1.5 Gb/s
Synchronous
Single Track
Average
Maximum
5400 rpm
156,301,488
32° to 140° F (0° to 60° C) [case temp]
ATA Security

(maximum)

(maximum)

100 MB/s (Drive Capability)
3 ms
15 ms
26 ms

100 MB/s (Drive Capability)
3 ms
15 ms
26 ms

80 GB 1.8” SATA Solid
State Drive

Weight
Capacity
Height
Width
Interface
Performance

Logical Blocks
Operating Temperature
Features

DA - 13101 Worldwide QuickSpecs — Version 8 — 2.5.2009

0.08 lb (35 g)
80 GB

0.19 in (5 mm)

2.12 in (54 mm)
ATA-8 / SATA 2.6
Maximum Sequential

Read
250 MB/s
156,301,488
32° to 158°F (0° to 70°C) [case temp]
ATA Security

Maximum Sequential Write

70 MB/s

Page 21

QuickSpecs

Technical Specifications

Optical Drives

HP EliteBook 2530p Notebook PC

DVD+/-RW SuperMulti DL
Drive

Access Times

Max Data Transfer Rate

Transfer Mode
Interface
Supported Media

Supported Media
Max Media Capacity

(read)
Max Media Capacity

(write)
Transport

(read)

(write)

Random

24X CD-ROM
8X DVD
24X CD-R
10X CD-RW
4X DVD+R

2.4X DVD+RW
4X DVD-R
2X DVD-RW
2X DVD-RAM
UDMA Mode 5
Gen 1 SATA
CD-DA, CD+(E)G, CD-MIDI, CD-TEXT, CD-ROM, CD-ROM XA, MIXED

MODE CD, CD-I, CD-I Bridge (Photo-CD, Video CD), Multisession CD (Photo­CD, CD-EXTRA, Portfolio, CD-R, CD-RW), CD-R, CD-RW, DVD-ROM (DVD-5,
DVD-9, DVD-10, DVD-18), DVD-R, DVD-RW, DVD+R, DVD+RW, DVD-RAM

CD-R, CD-RW, DVD+R, DVD+RW, DVD-R, DVD-RW, DVD-RAM

8.5 GB

8.5 GB

Tray Loading

<150 ms CD (typical)
<125 ms DVD (typical)
Up to 3,600 KB/s
Up to 10,800 KB/s
Up to 3,600 KB/s
Up to 1,500 KB/s
Up to 5,400 KB/s
Up to 3,240 KB/s
Up to 5,400 KB/s
Up to 2,700 KB/s
Up to 2,700 KB/s

DVD-ROM Drive

Security

Access Times

Max Data Transfer Rate

Transfer Mode
Interface
Supported Media

Supported Media
Max Media Capacity

(read)
Transport

(read)

(write)

Random

24X-CD-ROM
8X-DVD
UDMA Mode 5
Gen 1 SATA
CD-DA, CD+(E)G, CD-MIDI, CD-TEXT, CD-ROM, CD-ROM XA, MIXED

MODE CD, CD-I, CD-I Bridge (Photo-CD, Video CD), Multisession CD (Photo­CD, CD-EXTRA, Portfolio, CD-R, CD-RW), CD-R, CD-RW, DVD-ROM (DVD-5,
DVD-9, DVD-10, DVD-18), DVD-R, DVD-RW, DVD+R, DVD+RW

None

8.5 GB

Tray Loading

<120 ms CD (typical)
<200 ms DVD (typical)
Up to 3,600 KB/s
Up to 10,800 KB/s

DA - 13101 Worldwide QuickSpecs — Version 8 — 2.5.2009

Page 22

QuickSpecs

Technical Specifications

HP EliteBook 2530p Notebook PC

HP Fingerprint Sensor

Audio

Hardware

Mobile Voltage
Operation

Operating Temperature
Current Consumption @

3.3V

High-Rate Image Capture
ESD Resistance
Detection Matrix

Implementation
Touch-Sensitive Volume

Controls
Full Duplex
Sound Blaster Pro

compatible
Microphone In
Headphone/Line Out

3.0V-3.6V Single Supply

32° – 158°F (0° – 70°C)
Less than 70 mA peak imaging and scrolling

Less than 25 mA hardware finger detection
Advanced Power Management

Up to 240 image frames /sec
IEC 61000-4-2 Level 4 (±15KV)
192 x 16 Pixels

9.7 mm x 0.81 mm
500 ppi High-Resolution Images

ADI1984A High Definition CODEC
Volume up, volume down, and mute

Yes
Yes

Stereo
Stereo

Integrated Mono Speaker

Communications

Integrated Intel Gigabit
Network Connection
(10/100/1000 NIC)

82567LM

Power Rating
Impedance

Ethernet Features

Power Management

Performance Features
Manageability

2 Watts
4 Ohms

10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-14)
100 Mbit/s operation (100BASE-TX; IEEE 802.3u; IEEE 802.3 clauses 21-

30)
1000 Mbit/s operation (1000BASE-T; IEEE 802.3z and 802.3ab; IEEE

802.3 clauses 34-42)
Auto-Negotiation (Automatic Speed Selection)
Full Duplex Operation at all Speeds, Half Duplex operation at 10 and 100
Mbit/s
IEEE 802.1p QoS (Quality of Service) Support
IEEE 802.3x Flow Control (IEEE 802.3 clauses 31-32; configurable)

ACPI compliant -- multiple power modes
Situation-sensitive features reduce power consumption

TCP/IP/UDP Checksum Offload (configurable)
Wake-on-LAN from standby and hibernation (Magic Packet and Microsoft

Wake-Up Frame); Wake-on-LAN from off (Magic Packet only)
PXE 2.1 Remote Boot
Statistics Gathering (SNMP MIB II, Ethernet-like MIB, Ethernet MIB (802.3x,

DA - 13101 Worldwide QuickSpecs — Version 8 — 2.5.2009

Page 23

QuickSpecs

Technical Specifications

Interface
NIC Device Driver Name

HP EliteBook 2530p Notebook PC

clause 30))
Comprehensive diagnostic and configuration software suite
Intel Advanced Management Technology (iAMT)

PCI Express x1
Intel 82567 Gigabit Network Connection

V.92 56K Data/Fax
Modem

Form Factor
Power Management

Support
Approvals/

Certifications

Data Mode Capabilities

Fax Mode Capabilities

Command Set

MDC 1.5 Daughtercard
APM Revision 1.2, ACPI

UL, CSA, NEMKO, CCIB, Industry Canada, FCC Part 68, CTR21, FCC Part
15 Class B, Canadian ICES-003 Class B, C.I.S.P.R.22, Australian ACA, CE
Mark, Other Countries

V.92 data
V.8bis
V.80
V44, V.42bis, MNP5 (Compression)
V.42 (LAPM, MNP2-4) (Error Correction)
Optional symbol rates:

2800, 3429
Asymmetric Symbol rates

Synchronous primary channel data signaling rates:
3600, 31200
Automatic rate re-negotiation
V.34
V.32bis
V.32
V.23
V.22bis
V.22
V.21
Bell 212A
Bell 103J

TIA/EIA-578-B (Class 1)
T.30, T.4 (Group 3)
V.17
V.29
V.27ter
V.21 Channel 2

V.250 (Partial)
TIA-602
Identification: +GMI, +GMM, +GMR
Port control: +IPR, +ICF, +IFC, +ILRR
Modulation: +MS, +MR, +MA
Error control: +ES, +ER, +EB, +ESR, +ETBM
Data compression: +DS, +DR
V.251

DA - 13101 Worldwide QuickSpecs — Version 8 — 2.5.2009

Page 24

QuickSpecs

Technical Specifications

HP EliteBook 2530p Notebook PC

HP un2400
EV-DO/HSPA Mobile
Broadband Module

Technology/Operating
Bands

Wireless Protocol
Standards

Wireless Parametric
Standards

Maximum Data Rates

Maximum Output Power

Maximum Power
Consumption

Power Consumption,
Sleep Mode

Power Management

Antenna Type

Form Factor
Weight
Dimensions

Width x Thickness)
Voltage, Operating
Temperature, Operating

(from TIA/EIA/IS-98-D)
Temperature, Non-

operating, 96 hours
MIL-STD 202 Method

108)
Humidity, Non-operating
Configuration Utilities
LED Activity

(Length x

(from

GSM/GPRS/EDGE: 850MHz(Cell), 900MHz(EGSM), 1800MHz(DCS),
1900MHz (PCS)
UMTS/WCDMA with receive diversity: 2100MHz (UTRA FDD Band I),
1900MHz (UTRA FDD Band II), 850MHz (UTRA FDD Band V)
1xEVDO/1xRTT with receive diversity: 850MHz (Band Class0-Cell),
1900MHz (Band Class1-PCS)

GSM/GPRS/EDGE: Class B, Multi-slot operation, coding schemes CS1 –
CS4 and MSC1 – MSC9.
UMTS/WCDMA: Release 99 and Release 5
CDMA: 1xEVDO Release 0 and Release A, IS-95A, IS-95B, IS-2000

Meets or exceeds TIA/EIA IS-98-D

UMTS (HSPA) – 7.2 Mbps (Download ), 2.0Mbps (Upload)
CDMA (EVDO Release A) – 3.1 Mbps (Download), 1.8Mbps (Upload)

GSM/GPRS/EDGE: 32dBm (+/-1)
WCDMA: 24dBm (+/-1)
CDMA: 24dBm (+/-1)

2500mA (peak); 1000mA (average)

5 mA

USB selective suspend
Integrated notebook wireless button

Dual high efficiency 5 band antennae with spatial diversity, mounted in the
display enclosure

PCI-Express MiniCard

11.5 g

2.01 x 1.18 x 0.18 in (51 x 30 x 4.5 mm)

3.3v +/- 10%
–22° to 140° F (–30° to 60° C) (full RF performance)

–22° to 167° F (–30° to 75° C) (reduced RF performance)
–40° to 185° F (–40° to 85° C)

85% relative humidity for 48 hours @ 185° F (85° C) (non-condensing)
HP Connection Manager
LED Off – Radio Off;

Solid LED On – Radio On

Intel WiFi Link 5100

Wireless LAN Standards

Interoperability

DA - 13101 Worldwide QuickSpecs — Version 8 — 2.5.2009

IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n (draft 2.0)

Wi-Fi certified (802.11abg only)
Cisco Compatible Extensions Program compliant (802.11abg only) with

Page 25

QuickSpecs

Technical Specifications

Frequency Band
Antenna Structure
Data Rates

Modulation

Security

HP EliteBook 2530p Notebook PC

Microsoft Windows Vista and XP (details at:

http://www.hp.com/go/notebooks/WLAN

Tested with wireless access points from several major manufacturers
(details at:

2.4 GHz and 5 GHz
1 transmit; 2 receive (1x2)

802.11b: 1, 2, 5.5, 11 Mbps

802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11n (draft): 66 possible data rates, ranging from 6 Mbps to 300
Mbps, depending on the combination of Bandwidth, Modulation Coding
Scheme, and Guard Interval used, as defined in IEEE 802.11n (draft)
specification

Direct Sequence Spread Spectrum
DBPSK, DQPSK, CCK, OFDM, BPSK, QPSK, 16-QAM, 64-QAM

1

Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated AES
(support for key sizes of 128, 192, and 256 bits), 802.1x authentication
types EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP-MSCHAPv2, LEAP, EAP-FAST.

http://www.hp.com/go/notebooks/WLAN/draft-n

)

)

Sub-channels

Media Access Protocol
Network Architecture

Models
Roaming
Output Power
Output Power

power varies by data

2

rate)
Power Consumption

Power Management

Receiver Sensitivity
Antenna Connections
Range

Form Factor
Weight

(for CCK)215 dBm
(for OFDM;

Support for Cisco Security Features (proven compatibility with Cisco Aironet
infrastructure products through the Cisco Compatible Extensions Program
Version 4) with Microsoft Windows Vista and XP only.

Multinational support with frequency bands and channels compliant to local
regulations.

CSMA/CA (Collision Avoidance) with ACK
Ad-hoc (Peer to Peer)

Infrastructure (Access Point Required)
IEEE 802.11 compliant roaming between access points

15 dBm

Transmit: 2.3 Watts (average, with one spatial streams)
Receive: 1.9 Watts (average with two receive chains)
Idle mode3: 30 mW (average)
Radio off: 20 mW (max)

ACPI compliant power management

802.11 compliant power saving mode

4

300 Mbps: -68 dBm, 54 Mbps: -74 dBm, 6 Mbps: -90 dBm
3 U.FL type connectors, 50 ohm nominal impedance

802.11 a – Typical
(@6 Mbps)

802.11 b – Typical
(@1 Mbps)

802.11 g – Typical
(@1 Mbps)

PCI-Express MiniCard

0.013 lb (6 g)

600 feet – Outdoor Open Area
150 feet – Indoor, Office environment

1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment

1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment

DA - 13101 Worldwide QuickSpecs — Version 8 — 2.5.2009

Page 26

QuickSpecs

Technical Specifications

HP EliteBook 2530p Notebook PC

Dimensions
Operating Voltage
Temperature

Humidity

Altitude

Configuration Utility

LED Activity

Check latest software/driver release for updates on supported security features.

1.
Maximum output power may vary by country according to local regulations.

2.
In Power Save Polling mode and on battery power.

3.
Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CCK modulation) and a

4.
packet error rate of 10% for 802.11a/g (OFDM modulation).
WLAN supplier's client utility is required for Cisco Compatible Extensions support with Microsoft

5.
Windows XP. WLAN may also be compatible with certain third-party software supplicants. WLAN
supplier IHV extensions required for Cisco Compatible Extensions support for Microsoft Windows
Vista.

0.19 x 1.2 x 2.0 in (4.75 x 29.85 x 50.8 mm)

3.3V +/- 9%, 1.5V +/- 5%
Operating

Non-operating
Operating

Non-operating
Operating

Non-operating

5

Microsoft Windows XP
Choice of Configuration Utility:

Microsoft Windows XP Wireless Network Connection Manager
Intel PROSet for Microsoft Windows XP (required for Cisco Compatible
Extensions support)

Microsoft Windows Vista

Microsoft Windows Vista Wireless Network Connection Manager.
Intel IHV extensions for Windows Vista available to support Cisco
Compatible Extensions.

LED Off – Radio OFF; Solid LED On – Radio ON

32° to 176° F (0° to 80° C)
–40° to 176° F (–40° to 80° C)

10% to 90% (non-condensing)
5% to 90% (non-condensing)

0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)

Broadcom 4322AGN

802.11a/b/g/draft-n
WiFi Adapter

Wireless LAN Standards

Interoperability

Frequency Band
Data Rates

Frequency Support

DA - 13101 Worldwide QuickSpecs — Version 8 — 2.5.2009

IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n (draft 2.0)

Wi-Fi certified (802.11abg only)
Cisco Compatible Extensions Program compliant (802.11abg only) with
Microsoft Windows Vista and XP (details at:

http://www.hp.com/go/notebooks/WLAN

Tested with wireless access points from several major manufacturers
(details at:

2.4 GHz and 5 GHz

802.11b: 1, 2, 5.5, 11 Mbps

802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11n (draft): 6, 6.5, 9, 12, 13, 13.5, 18, 19.5, 24, 26, 27, 36, 39,

40.5, 48, 52, 54, 58.5, 65, 78, 81, 104, 108, 117, 121.5, 130,
135, 162, 216, 243, 270, 300 Mbps

20 MHz: 2.4 GHz and 5 GHz bands
40 MHz: 2.4 GHz and 5 GHz band

http://www.hp.com/go/notebooks/WLAN/draft-n

)

)

Page 27

QuickSpecs

Technical Specifications

HP EliteBook 2530p Notebook PC

Modulation

Security

Sub-channels

Media Access Protocol
Network Architecture

Models
Roaming
Output Power
Output Power

power varies by data
rate)

Power Consumption

Power Management

Receiver Sensitivity

Antenna type

Range

Form Factor
Weight
Dimensions
Operating Voltage
Temperature

Humidity

Altitude

Configuration Utility

1

(for CCK)217 dBm
(for OFDM;

2

Direct Sequence Spread Spectrum
DBPSK, DQPSK, CCK, OFDM, BPSK, QPSK, 16-QAM, 64-QAM

Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated AES,

802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP­MSCHAPv2, LEAP, EAP-FAST.

Support for Cisco Security Features (proven compatibility with Cisco Aironet
infrastructure products through the Cisco Compatible Extensions Program
Version 4) with Microsoft Windows Vista and XP only.

Multinational support with frequency bands and channels compliant to local
regulations.

CSMA/CA (Collision Avoidance) with ACK
Ad-hoc (Peer to Peer)

Infrastructure (Access Point Required)
IEEE 802.11 compliant roaming between access points

15 dBm

Idle associated: 250 mW
Idle unassociated: 150 mW
Transmit/Receive 20 MHz channel: 2.0 W (max)
Transmit/Receive 40 MHz channel: 2.0 W (max)

ACPI compliant power management

802.11 compliant power saving mode

3

270 Mbps: -66dBm, 162 Mbps: -72 dBm, 54 Mbps: -72 dBm, 11 Mbps: ­85 dBm , 1 Mbps: -94 dBm

High efficiency dual band antenna with spatial diversity, mounted in the
display enclosure

802.11 a – Typical
(@6 Mbps)

802.11 b – Typical
(@1 Mbps)

802.11 g – Typical
(@1 Mbps)

PCI-Express MiniCard

0.026 lb (12 g)

0.19 x 1.2 x 2.0 in (4.75 x 29.85 x 50.8 mm)

3.3v +/- 10%
Operating

Non-operating
Operating

Non-operating
Operating

Non-operating

4

Microsoft Windows XP
Choice of Configuration Utility:

600 feet – Outdoor Open Area
150 feet – Indoor, Office environment

1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment

1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment

14° to 149° F (–10° to 65° C)
–40° to 176° F (–40° to 80° C)

10% to 90% (non-condensing)
5% to 95% (non-condensing)

0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)

DA - 13101 Worldwide QuickSpecs — Version 8 — 2.5.2009

Page 28

QuickSpecs

Technical Specifications

LED Activity

HP EliteBook 2530p Notebook PC

Microsoft Windows XP Wireless Network Connection Manager
Broadcom Wireless Configuration Utility (required for Cisco
Compatible Extensions support)

Microsoft Windows Vista

Microsoft Windows Vista Wireless Network Connection Manager
Broadcom IHV extensions for Windows Vista available to support
Cisco Compatible Extensions.

LED Off – Radio OFF; Solid LED On – Radio ON

Check latest software/driver release for updates on supported security features.

1.
Maximum output power may vary by country according to local regulations.

2.
Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CCK modulation) and a

3.
packet error rate of 10% for 802.11a/g (OFDM modulation).
WLAN supplier's client utility is required for Cisco Compatible Extensions support with Microsoft

4.
Windows XP. WLAN may also be compatible with certain third-party software supplicants. WLAN
supplier IHV extensions required for Cisco Compatible Extensions support for Microsoft Windows
Vista.

Broadcom 4312G

802.11b/g WiFi
Adapter

Wireless LAN Standards

Interoperability

Frequency Band
Data Rates

Modulation

Security

Sub-channels

Media Access Protocol
Network Architecture

Models
Roaming
Output Power

1

(for CCK)217 dBm

IEEE 802.11b
IEEE 802.11g

Wi-Fi certified (802.11abg only)
Cisco Compatible Extensions Program compliant (802.11abg only) with
Microsoft Windows Vista and XP (details at:

http://www.hp.com/go/notebooks/WLAN

Tested with wireless access points from several major manufacturers
(details at:

2.4 GHz

802.11b: 1, 2, 5.5, 11 Mbps

802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
Direct Sequence Spread Spectrum

DBPSK, DQPSK, CCK, OFDM
Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated AES,

802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP­MSCHAPv2, LEAP, EAP-FAST.

Support for Cisco Security Features (proven compatibility with Cisco Aironet
infrastructure products through the Cisco Compatible Extensions Program
Version 4) with Microsoft Windows Vista and XP only.

Multinational support with frequency bands and channels compliant to local
regulations.

CSMA/CA (Collision Avoidance) with ACK
Ad-hoc (Peer to Peer)

Infrastructure (Access Point Required)
IEEE 802.11 compliant roaming between access points

http://www.hp.com/go/notebooks/WLAN/draft-n

)

)

DA - 13101 Worldwide QuickSpecs — Version 8 — 2.5.2009

Page 29

QuickSpecs

Technical Specifications

HP EliteBook 2530p Notebook PC

Output Power
power varies by data

2

rate)
Power Consumption

Power Management

Receiver Sensitivity
Antenna type

Range

Form Factor
Weight
Dimensions
Operating Voltage
Temperature

Humidity

Altitude

Configuration Utility

(for OFDM;

15 dBm

Idle associated: 250 mW
Idle unassociated: 150 mW
Transmit: 2.0 W (max)
Receive: 2.0 W (max)

ACPI compliant power management

802.11 compliant power saving mode

3

54 Mbps: -71 dBm, 11 Mbps: -85 dBm , 1 Mbps: -95 dBm
High efficiency dual band antenna with spatial diversity, mounted in the

display enclosure

802.11 b – Typical
(@1 Mbps)

802.11 g – Typical
(@1 Mbps)

PCI-Express MiniCard

0.026 lb (12 g)

0.19 x 1.2 x 2.0 in (4.75 x 29.85 x 50.8 mm)

3.3v +/- 10%
Operating

Non-operating
Operating

Non-operating
Operating

Non-operating

4

Microsoft Windows XP
Choice of Configuration Utility:

1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment

1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment

14° to 149° F (–10° to 65° C)
–40° to 176° F (–40° to 80° C)

10% to 90% (non-condensing)
5% to 95% (non-condensing)

0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)

Microsoft Windows XP Wireless Network Connection Manager
Broadcom Wireless Configuration Utility (required for Cisco
Compatible Extensions support)

Microsoft Windows Vista

Microsoft Windows Vista Wireless Network Connection Manager
Broadcom IHV extensions for Windows Vista available to support
Cisco Compatible Extensions.

LED Activity

Check latest software/driver release for updates on supported security features.

1.
Maximum output power may vary by country according to local regulations.

2.
Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CCK modulation) and a

3.
packet error rate of 10% for 802.11a/g (OFDM modulation).
WLAN supplier's client utility is required for Cisco Compatible Extensions support with Microsoft

4.
Windows XP. WLAN may also be compatible with certain third-party software supplicants. WLAN
supplier IHV extensions required for Cisco Compatible Extensions support for Microsoft Windows
Vista.

DA - 13101 Worldwide QuickSpecs — Version 8 — 2.5.2009

LED Off – Radio OFF; Solid LED On – Radio ON

Page 30

QuickSpecs

Technical Specifications

HP EliteBook 2530p Notebook PC

HP Integrated Module
with Bluetooth Wireless
Technology

Bluetooth Specification
Dimensions
Frequency Band
Number of Available

Channels
Data Rates and

Throughput

Transmit Power
Receiver Sensitivity
Power Consumption

Antenna
Range
Electrical Interface

OS Support

Bluetooth Software
Supported

Link Topology
Security
Power Management

Certifications

Temperature

Humidity

Altitude

Bluetooth Profiles
Supported

2.0 Compliant

1.02 x 0.55 x 0.22 in (26 x 14 x 5.7 mm)
2402 to 2480 MHz
79 (1 MHz) available channels

3 Mbps data rate; throughput up to 2.17 Mbps
Synchronous Connection Oriented links up to 3, 64 kbps, voice channels
Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric

or 1306.9 kbps symmetric

-6 dBm to 4 dBm (Bluetooth Class II)
Better than -80 dBM at 0.1 % raw bit error rate
Peak (Tx) 264 mW
Peak (Rx) 231 mW
Sleep <1 mW
Internally integrated within module
Up 33 ft (10 m)
USB 2.0 compliant
Microsoft Windows Plug and Play compliant
Microsoft Windows XP Professional and Home
Microsoft Windows 2000
Broadcom Bluetooth for Windows
Microsoft Windows XP Bluetooth Software
Point to Point, Multipoint Pico Nets up to 7 slaves
Full support of Bluetooth Security Provisions
Microsoft Windows ACPI, and USB Bus Support
Self configurable to optimize power conservation in all operating modes,

including Standby, Hold, Park, and Sniff
All necessary regulatory approvals for supported countries, including:
FCC (47 CFR) Part 15C, Section 15.247 & 15.249
ETS 300 328, ETS 300 826
Low Voltage Directive IEC950
UL, CSA, and CE Mark
Operating
Non-operating
Operating
Non-operating
Operating
Non-operating
(with Bluetooth for Windows 4.0 software)
Serial Port Profile (SPP)*
Dial-Up Networking (DUN)*
Generic Object Exchange Profile (GOEP)
Object Push Profile (OPP)*

–4° to 158° F (–20° to 70° C)
–40° to 176° F (–40° to 80° C)
10% to 90%
5% to 95%
15,000 ft (4,572 m)
40,000 ft (12,192 m)

DA - 13101 Worldwide QuickSpecs — Version 8 — 2.5.2009

Page 31

QuickSpecs

Technical Specifications

* indicates the profile is also supported by Microsoft Windows XP SP2

HP EliteBook 2530p Notebook PC

File Transfer Profile (FTP)
Synchronization Profile (SYNC)
Hard Copy Cable Replacement (HCRP)*
Personal Area Networking Profile (PAN)*
Human Interface Device Profile (HID)*
FAX Profile (FAX)
Basic Imaging Profile (BIP)
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)

Eco Data

Eco-Label Certifications

System Configuration

Energy Consumption
Normal Operation
Sleep (Energy Star low

power mode)
Off

Heat Dissipation
Normal Operation
Sleep
Off

*

This product has received or is in the process of being certified to the
following approvals and may be labeled with one or more of these marks:

US Energy Star
Taiwan Green Mark
IT ECO declaration
EPEAT - Gold

The configuration used for the Energy Consumption and Declared Noise
Emissions data is based on a "Typically Configured Notebook"

115 VAC 230 VAC 100 VAC

7.134 W

1.573 W 1.652 W 1.583 W

0.579 W 0.643 W 0.579 W

115 VAC 230 VAC 100 VAC

24 BTU/hr 25 BTU/hr 24 BTU/hr

5 BTU/hr 6 BTU/hr 5 BTU/hr
2 BTU/hr 2 BTU/hr 2 BTU/hr

* Heat dissipation is calculated based on the measured watts, assuming the
service level is attained for one hour.

7.41 W 7.03 W

This product is in compliance with US executive order 13221, WOL (wake
on LAN) disabled.

Declared Noise Emissions
(in accordance with
ISO 7779 and ISO

9296)
System Fan Off

Idle
Fixed Disk

(random writes)

DA - 13101 Worldwide QuickSpecs — Version 8 — 2.5.2009

Sound Power

(LWAd, bels)

2.5 20

2.7 27

Sound Pressure

(LpAm, decibels)

Page 32

QuickSpecs

Technical Specifications

System fan is usually off except when charging the battery

Batteries

Additional
information:

HP EliteBook 2530p Notebook PC

This product complies with ISO standards:

EU Directive 91/ 157/ EEC
EU Directive 93/ 86/ EEC
EU Directive 98/ 101/ EEC

Batteries used in the product do not contain:

Mercury greater the 5ppm by weight
Cadmium greater than 10ppm by weight
Lead greater than 4000 ppm by weight.

The battery type and chemistry used in the product is:
CR2032 (coin cell), Lithium

This product is in compliance with the Restrictions of Hazardous Substances
(RoHS) directive - 2002/95/EC.

This HP product is designed to comply with the Waste Electrical and
Electronic Equipment (WEEE) Directive - 2002/96/EC.

This product is in compliance with California Proposition 65 (State of
California; Safe Drinking Water and Toxic Enforcement Act of 1986).

This product is in compliance with the IEEE 1680 (EPEAT) standard at the
Gold level, see:

Keyboard complies with ISO standard: ISO 9995, EN 29241-4, and
ISO/IEC 15412

Input devices of this product comply with ISO 9241, part 9.

Plastics parts weighing over 25 grams used in the product are marked per
ISO 11469 and ISO1043.

This product contains 0% recycled materials (by wt.)

This product is greater than 91.8% recycle-able when properly disposed of at
end of life.

Packaging Materials

External:

Internal:

The EPE foam packaging material is made from 100% recycled
content.
The corrugated paper packaging materials contains at least 80%
recycled content.

www.epeat.net

Polyethylene low density 13 g

Corrugated 458 g
EPE-Expanded Polyethylene 64 g

DA - 13101 Worldwide QuickSpecs — Version 8 — 2.5.2009

Page 33

QuickSpecs

Technical Specifications

Material Usage

HP EliteBook 2530p Notebook PC

HP follows these guidelines to decrease the environmental impact of product
packaging:

Eliminate the use of heavy metals such as lead, chromium, mercury and
cadmium in packaging materials.
Eliminate the use of ozone-depleting substances (ODS) in packaging
materials.
Design packaging materials for ease of disassembly.
Maximize the use of post-consumer recycled content materials in
packaging materials.
Use readily recyclable packaging materials such as paper and
corrugated materials.
Reduce size and weight of packages to improve transportation fuel
efficiency.
Plastic packaging materials are marked according to ISO 11469 and
DIN 6120 standards.

This product does not contain any of the following substances in excess of
regulatory limits (for reference of these limits please refer to the HP General
Specification of the
Environment (

supplychain/gen_specifications.html

http://www.hp.com/hpinfo/globalcitizenship/environment/

):

End-of-life Management
and Recycling

Asbestos
Certain Azo Colorants
Certain Brominated Flame Retardants - may not be used as flame
retardants in plastics
Cadmium
Chlorinated Hydrocarbons
Chlorinated Paraffins
Formaldehyde
Halogenated Diphenyl Methanes
Lead carbonates and sulfates
Lead and Lead compounds
Mercuric Oxide Batteries
Nickel - finishes must not be used on the external surface designed to
be frequently handled or carried by the user.
Ozone Depleting Substances
Polybrominated Biphenyls (PBBs)
Polybrominated Biphenyl Ethers (PBBEs)
Polybrominated Biphenyl Oxides (PBBOs)
Polychlorinated Biphenyl (PCB)
Polychlorinated Terphenyls (PCT)
Polyvinyl Chloride (PVC) - except for wires and cables, and certain
retail packaging has been voluntarily removed from most applications.
Radioactive Substances
Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)

Hewlett-Packard offers end-of-life HP product return and recycling programs in
many geographic areas. To recycle your product, please go to:

http://www.hp.com/go/reuse-recycle

office. Products returned to HP will be recycled, recovered or disposed of in a
responsible manner.

or contact your nearest HP sales

DA - 13101 Worldwide QuickSpecs — Version 8 — 2.5.2009

Page 34

QuickSpecs

Technical Specifications

Hewlett-Packard
Corporate Environmental
Information

HP EliteBook 2530p Notebook PC

The EU WEEE directive (2002/95/EC) requires manufacturers to provide
treatment information for each product type for use by treatment facilities. This
information (product disassembly instructions) is posted on the Hewlett
Packard web site at:
may be used by recyclers and other WEEE treatment facilities as well as HP
OEM customers who integrate and re-sell HP equipment.

For more information about HP's commitment to the environment:
Global Citizenship Report

http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html

Environment website

http://www.hp.com/environment

Eco-label certifications

http://www.hp.com/hpinfo/globalcitizenship/environment/
productdesign/ecolabels.html

ISO 14001 certificates:

http://www.hp.com/hpinfo/globalcitizenship/environment/
operations/envmanagement.html

http://www.hp.com/go/recyclers

. These instructions

Copyright © 2009 Hewlett-Packard Development Company, L.P.

All rights reserved. Microsoft, Windows, Windows Vista and Windows XP are registered trademarks or trademarks of Microsoft
Corporation in the U.S. and/or other countries. Core 2 Duo is a registered trademark or trademark of Intel Corporation in the U.S.
and/or other countries. Bluetooth is a registered trademark of Bluetooth SIG, Inc., in the U.S. and other countries. All other product
names mentioned herein may be trademarks of their respective companies.

The information contained herein is subject to change without notice and is provided "as is" without warranty of any kind. The
warranties for HP products are set forth in the express limited warranty statements accompanying such products. Nothing herein
should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions
contained herein.

DA - 13101 Worldwide QuickSpecs — Version 8 — 2.5.2009

Page 35
