QuickSpecs

Overview

Models

HP 1405-5G Switch
HP 1405-8G Switch
HP 1405-16G Desktop Switch
HP 1405-5 Switch
HP 1405-8 Switch
HP 1405-16 Desktop Switch
HP 1405-5G Switch
HP 1405-8G Switch
HP 1405-5 Switch
HP 1405-8 Switch

Key features

Entry-level switching for small offices
Plug-and-play; no configuration required
Energy saving; EEE and port power-down (v2 only)
Quality of Service (IEEE 802.1p)
3-year warranty

HP 1405 Small Office Series

J9792A
J9794A
JD844A
J9791A
J9793A
JD858A
JD869A
JD871A
JD866A
JD867A

Product overview

HP 1405 Series Switches are plug-and-play unmanaged fixed-port Layer 2 switches designed for small offices. The series includes 5-,
8-, and 16-port models in both Gigabit and Fast Ethernet configurations. The switches are preconfigured for fast, easy installation,
with connections using low-cost Ethernet copper cabling. They support administration-friendly features such as auto-negotiation and
automatic cable type detection (MDI/MDIX). They are Class B certified and approved for both business and home office locations. The
5- and 8-port v2 models (J9791A, J9792A, J9793A*, and J9794A) include energy-saving features such as Energy Efficient Ethernet
(EEE) and idle-port power down. (*The J9793A will be available as of July 2012.) They are fanless for quiet and "green" operation, and
designed for high reliability, long life, low power consumption, and low total cost of ownership. These switches come with a 3-year
warranty, covering unit and adapter, and 3-year access to HP phone support.

DA - 14090 Worldwide — Version 3 — May 14, 2012

Page 1

QuickSpecs

Overview

Features and benefits

Quality of Service

(QoS)

HP 1405 Small Office Series

IEEE 802.1p prioritization with DSCP

Differentiated Services Code Point (DSCP)

Connectivity

Auto-MDIX
Jumbo packet support

data transfers

Mini-Jumbo packet support

performance of large data transfers

Performance

Half-/Full-duplex auto-negotiating capability on every port

Ease of use

Flow control
Comprehensive LED display with per-port indicators

operation

Unmanaged

Flexibility

Fanless design
Additional information
Green initiative support
Energy savings

only)

: automatically adjusts for straight-through or crossover cables on all 10/100 and 10/100/1000 ports

(Gigabit Ethernet models only): supports up to 9216-byte frame size to improve performance of large

(Fast Ethernet models only): supports up to 1.5K-byte or 2K-byte frame size to improve

: helps ensure reliable communications during full-duplex operation

: provides plug-and-play simplicity

: enables quiet operation for deployment in open spaces (selected models)

: provides support for RoHS and WEEE regulations

: utilizes Energy Efficient Ethernet (EEE) standard IEEE 802.3az and idle-port power down for energy savings (v2

: v2 devices deliver data to devices based on the priority and type of traffic using

: doubles the throughput of every port

: provides an at-a-glance view of status, activity, speed, and full-duplex

Warranty and support

3-year warranty
Electronic and telephone support

refer to
refer to

www.hp.com/networking/warrantysummary

www.hp.com/networking/contact-support

: with advance replacement and next-business-day delivery (available in most countries)

: limited electronic and telephone support is available from HP; to reach our support centers,

; for details on the duration of support provided with your product purchase,

DA - 14090 Worldwide — Version 3 — May 14, 2012

Page 2

QuickSpecs

Technical Specifications

HP 1405 Small Office Series

HP 1405-5G Switch

Ports

Physical characteristics

Memory and processor

Mounting

Performance

Environment

Electrical characteristics

Safety

Emissions

Notes

Services

(J9792A)

5 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE

802.3ab Type 1000BASE-T); Media Type: Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or full;
1000BASE-T: full only

Dimensions

Weight

1 MB

Desktop (rear port)

100 Mb Latency

1000 Mb Latency

Throughput

Routing/Switching
capacity

MAC address table size

Operating temperature

Operating relative
humidity

Nonoperating/Storage
temperature

Nonoperating/Storage
relative humidity

Acoustic

Voltage

Frequency

UL 60950; IEC 60950-1; EN 60950-1; CAN/CSA-C22.2 No. 60950-1-03

EN 55022 Class B; ICES-003 Class B; FCC Part 15, Class B; AS/NZS CISPR22 Class B

Also known as HP 1405-5G v2 Switch.

Refer to the HP website at:
and product numbers. For details about services and response times in your area, please contact your local
HP sales office.

4.5(w) x 3.6(d) x 1.4(h) in (11.43 x 9.14 x 3.56 cm)

0.4 lb (0.18 kg)

< 4.1µs

< 2.6µs

up to 7.4 million pps

10 Gbps

2048 entries

32°F to 104°F (0°C to 40°C)

15% to 95%, noncondensing

-40°F to 158°F (-40°C to 70°C)

15% to 95%, noncondensing

Fanless

100-240 VAC

50/60 Hz

www.hp.com/networking/services

for details on the service-level descriptions

DA - 14090 Worldwide — Version 3 — May 14, 2012

Page 3

QuickSpecs

Technical Specifications

HP 1405 Small Office Series

HP 1405-8G Switch

Ports

Physical characteristics

Memory and processor

Mounting

Performance

Environment

Electrical characteristics

Safety

Emissions

Notes

Services

(J9794A)

8 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE

802.3ab Type 1000BASE-T); Media Type: Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or full;
1000BASE-T: full only

Dimensions

Weight

2 MB

Desktop (rear port)

100 Mb Latency

1000 Mb Latency

Throughput

Routing/Switching
capacity

MAC address table size

Operating temperature

Operating relative
humidity

Nonoperating/Storage
temperature

Nonoperating/Storage
relative humidity

Acoustic

Voltage

Frequency

UL 60950; IEC 60950-1; EN 60950-1; CAN/CSA-C22.2 No. 60950-1-03

EN 55022 Class B; ICES-003 Class B; FCC Part 15, Class B; AS/NZS CISPR22 Class B

Also known as HP 1405-8G v2 Switch.

Refer to the HP website at:
and product numbers. For details about services and response times in your area, please contact your local
HP sales office.

6.1(w) x 3.6(d) x 1.4(h) in (15.49 x 9.14 x 3.56 cm)

0.5 lb (0.23 kg)

< 3.9µs

< 2.6µs

up to 11.8 million pps

10 Gbps

2048 entries

32°F to 104°F (0°C to 40°C)

15% to 95%, noncondensing

-40°F to 158°F (-40°C to 70°C)

15% to 95%, noncondensing

Fanless

100-240 VAC

50/60 Hz

www.hp.com/networking/services

for details on the service-level descriptions

HP 1405-16G Desktop Switch

Ports

Physical characteristics

Memory and processor

Mounting

Performance

16 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE

802.3ab Type 1000BASE-T); Media Type: Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or full;
1000BASE-T: full only

Dimensions

Weight

2 MB

Desktop (rear port)

100 Mb Latency

1000 Mb Latency

(JD844A)

8.2(w) x 6.3(d) x 1.6(h) in (20.83 x 16 x 4.06 cm)

1.9 lb. (0.86 kg)

< 5 µs

< 5 µs
