www.easywatering.co.uk
44 Hoddesdon Industrial Centre, Pindar Road Hoddesdon, Hertfordshire, EN11 0FF
Hozelock UK Garden Irrigation & Automatic Watering Systems
ON for 60 minutes
or until turned OFF
Turns water OFF
Auto Programme OFF
Automatic watering duration
Sets automatic
start time
M
A
N
U
A
L
OFF
ON
2
3
5
10
15
20
30
45
60
90
7
M
I
N
S
1
120
AUTO
START
60 MINS
M A X
QUICK REFERENCE
AC1
2705
Note: After 60 minutes water shuts off. Knob will still
point to ON and needs to be manually set to OFF or to
desired number of automatic watering minutes.
Manual
OFF
Turn dial clockwise to OFF.
Note: Operation is only audible when valve opens and
closes. To check that timer is working, switch to manual
ON or OFF to hear valve operate.
CONNECTING THE TIMER TO THE TAP
Use supplied adaptors if required. Tighten to ensure no
leaks.
PROBLEM SOLVING
HOZELOCK AQUA CONTROL 1 WATER TIMER
WATERS ONCE A DAY, EVERY DAY
Please follow the instructions to make sure that you get the
most from your timer for simple and efficient watering.
INSTALLING THE BATTERIES
1. Remove screws and back cover.
2. Insert two 1.5V ‘C’ Alkaline batteries. (Check + and -
are correct.).
IMPORTANT: Rechargeable batteries must
not be used.
3. Replace batteries each season. (max 12 months use)
MAINTAINING THE WATERPROOF SEAL
1. Ensure that rubber seal is positioned correctly.
2. Replace back cover and screw down tightly
3. Repeat each time back cover is removed
HOW TO PROGRAMME THE TIMER
There are two watering operations - Automatic and
Manual.
AUTOMATIC OPERATION
Automatic ON
1. Turn dial clockwise to AUTO START at actual desired
start time (e.g. To start watering each day at 3:00pm you
must set your AC1 when the actual time of day is
3:00pm). The timer has now memorised the auto start
time until it is reset and will operate every day at this
time. Use of manual ON or OFF does not cancel memory.
2. Turn dial anti-clockwise to chosen number of minutes
for watering (e.g. 30 minutes).
The timer will now automatically water for the set number of minutes every day at the set time.
Automatic
OFF
Turn dial to Manual ON or OFF.
If you wish to return to Automatic watering re-select the
number of minutes for watering (e.g. 30 minutes) as your
auto start time is memorised until a new one is selected.
Changing star
t time
Turn dial clockwise to AUTO START at new chosen start
time.
Changing watering time duration
Turn dial to new desired number of minutes for watering.
Do not turn dial to AUTO START unless a new start time is
desired.
MANUAL OPERATION
Manual ON
Turn dial anti-clockwise to ON.
Water will flow for 60 minutes maximum or until turned
to OFF setting.
PROBLEM
Valve will not open or close
when dial is at ON or OFF.
Valve works but no water flows.
Valve works on manual but no
automatic watering.
Knob points to ON but no
watering.
SOLUTION
Clean battery connections or
replace with new batteries.
Check tap is turned on.
Set Auto Start time
Manual ON 60 minutes is fin-
ished. Switch off or turn to
desired automatic watering
time.
PROTECT YOUR
WATER TIMER
FROM FROST.
REMOVE FROM
THE TAP IN WINTER.
PRODUCT NOT GUARANTEED
AGAINST FROST DAMAGE.
REMOVE BATTERIES WHEN NOT IN
USE.
