GE Consumer & Industrial
Appliances
Conversion Instructions
Converting to LP (Propane) Gas or Converting Back to Natural Gas from LP
20” and 24” Standard Twin Burner Gas Range with Electric Ignition
BEFORE YOU BEGIN
Read these instructions completely and carefully.
IMPORTANT - Save these instructions for local inspector’s use. IMPORTANT - OBSERVE ALL GOVERNING CODES AND ORDINANCES.
Note to Installer - Be sure to leave these instructions, orifices and screws with the Consumer.
Note to consumer - Keep these instructions with your Owner’s Manual for future reference.
THIS RANGE IS FACTORY SET FOR USE WITH NATURAL GAS. USE THESE INSTRUCTIONS WHEN CONVERTING TO LP (PROPANE) GAS AND WHEN CONVERTING BACK TO NATURAL GAS.
WARNING
This conversion kit must be installed by a qualified service agency in accordance with the manufacturer’s instructions and all applicable codes and requirements of the authority having jurisdiction. If the information in these instructions is not followed exactly, a fire, explosion or production
of carbon monoxide may result, causing property damage, personal injury or loss of life. The qualified service agency is responsible for the proper installation of this kit. The installation is not proper and complete until the operation of the converted appliance is checked as specified in the manufacturer’s instructions supplied with the kit.
BURNER SPECIFICATIONS
BURNER OUTUPUT RATINGS: BTU/HR
Burner |
|
BTU Rate |
|
Orifice Size |
||
Surface |
|
|
9,100 |
|
#54 (0.057") |
|
Oven |
|
13,000 |
|
#51 (0.068") |
||
|
|
|||||
|
LP (PROPANE) GAS, 10" WCP |
|||||
Burner |
|
BTU Rate |
|
Orifice Size |
||
Surface |
|
|
8,000 |
|
#66 (0.033") |
|
Oven |
|
13,000 |
|
#58 (0.042") |
||
|
|
|
|
|
|
|
HIGH ALTITUDE OUTPUT RATINGS: BTU/HR |
||||||
|
NATURAL GAS–4" W.C.P. |
|
||||
|
|
High |
|
|
|
Prod. Service |
|
Altitude Rate |
|
Ofifice Size |
Number |
||
@ 3,000 FT |
8050 |
|
0.054" |
|
WB28K10304 |
|
@ 6,000 FT |
7100 |
|
0.050" |
|
WB28K10305 |
|
|
||||||
HIGH ALTITUDE OUTPUT RATINGS: BTU/HR |
||||||
|
|
LP–10" W.C.P. |
|
|||
|
|
High |
|
|
|
Prod. Service |
|
Altitude Rate |
|
Ofifice Size |
Number |
||
@ 3,000 FT |
7050 |
|
0.031" |
|
WB28K0046 |
|
@ 6,000 FT |
6250 |
|
0.029" |
|
WB28K10306 |
|
TOOLS REQUIRED
|
Adjustable wrench |
Flat-blade screwdriver (blade width |
|
|
1/2" open-end wrench |
approximately 3/32" across) |
|
|
Pliers |
Nut driver (5/16" or small |
|
Phillips head screwdriver |
adjustable wrench) |
||
|
