HOTPOINT NSWF 743U W UK Daily Reference Guide

Quick Guide

1

2

A

B

*

THANK YOU FOR PURCHASING A HOTPOINT PRODUCT.

To receive more comprehensive assistance, register the
appliance on

www.hotpoint.eu/register

CONTROL PANEL

1. ON/OFF button

2. CHILD LOCK button

3. EXTRA TOUCH button

4. EXTRA TOUCH indicator lights

5. START/PAUSE button and indicator light

6. OPTION button and indicator light

7. DELAY START button

8. SPIN button

9. TEMPERATURE button

10. WASH CYCLE SELECTOR KNOB

WASH CYCLE TABLE

Before using the appliance carefully read the Health and Safety guide.

Before using the machine, it is imperative that the transport bolts are removed. For more
detailed instructions on how to remove them, see the Installation Guide.

1

DISPLAY

9

10

8

7

3

2

6

5

GB

4

Maximum load 7 kg
Power input in o mode 0.5 W / in left-on mode 8 W

Wash cycle

1

2

Mixed 40°C - 40°C 1400 7 **

Eco Cotton

(1)

Temperature

Default Range

60°C

3 Cotton (2) 40°C

4 Synthetics (3) 40°C

5 Delicates 40°C

6 Wool 40°C

7 White 40°C

8 Duvet 30°C

9 Rapid 30 min 30°C

10 Full Load 45 min 40°C

11 Shirts 40°C

12 Baby 40°C

13 Anti Stain 40° 40°C

14 Anti Allergy 60°C

15

16



Required dosage  Optional dosage

Spin & Drain * – – 1400 7 ** – – – – – – –

Rinse & Spin – – 1400 7 ** –

Max.

spin speed

(rpm)

Max.
load

(kg)

Duration

(minutes)

60°C 1400 7 225

40°C 1400 7 220

- 60°C 1400 7 220

- 60°C 1200 4 155

- 40°C 1000 4 **

- 40°C 800 1,5 **

- 90°C 1400 7 **

- 30°C 1000 3 **

- 30°C 800 3,5 **

- 40°C 1200 7 **

- 40°C 600 1,5 **

- 40°C 800 3 **

- 40°C 1400 7 **

- 60°C 1400 4 **

Detergents and

Additives

Fabric

Wash

softener

Recommended

detergent

Powder Liquid

1 2

 

–

   

   

   

   

 

 

–

–

  

 

 

 

 
 
 

–

–

–

–

–

–

   



– – – – –

Residual

Energy con-

dampness %

sumption kWh

– – –



53 1,00 52,4

53 0,88 70

53 0,88 70

53 0,86 60

– – –



– – –



– – – –

– – –



– – –



– – –



– – –



– – –



– – –



– – –

Total water l

The cycle duration indicated on the display or instruction manual is an estimate based on
standard conditions. The actual duration may vary in relation to several factors, such as
the temperature and pressure of the incoming water, ambient temperature, amount of
detergent, load quantity and type, load balancing and any additional options selected.

1) Test wash cycle in compliance with regulation 1061/2010:
This cycle is designed for normally soiled cotton loads and is the most ecient in terms of
both electricity and water consumption; it should be used for garments washable at 60°C or
at 40°C. The actual washing temperature may dier from the indicated value.

PRODUCT DESCRIPTION

1. Top

2. Detergent dispenser drawer

3. Control panel

4. Handle

5. Porthole door

6. Drain pump (behind the plinth)

7. Plinth (removable)

8. Adjustable feet (2)

2.

7.

8.

For all testing institutes:

2) Long cotton cycle: set programme 3 at temperature 40°C.

3) Long synthetics cycle: set cycle 4 at a temperature of 40°C.

* By selecting the 15 cycle and excluding the spin cycle, the washing machine will drain only.
** The duration of the wash cycles can be checked on the display.

*** If “Steam Hygiene” option is set, the duration of the wash cycles will increase.

DETERGENT DISPENSER DRAWER

1.

Compartment *:

Do not insert detergent in this compartment.

3.

Compartment 1: Washing detergent (powder
or liquid)

If liquid detergent is used, the removable plastic

4.

partition A (supplied) should be used for proper
dosage.

5.

If powder detergent is used, place the partition
into slot B.

6.

Compartment 2: Additives (fabric softeners, etc.)

The fabric softener must not exceed the “MAX” level.
! Use powder detergent for white cotton garments, for pre-washing, and

for washing at temperatures over 60°C.
! Follow the instructions given on the detergent packaging.

WASH CYCLES

60°

40°

h

Follow the instructions on the symbols of the garment’s wash
care label. The value indicated in the symbol is the maximum
recommended temperature for washing the garment.

Mixed

For washing lightly to normally soiled resistant garments in cotton, linen,
synthetic bres and mixed bres.

Eco Cotton

Suitable for washing moderately soiled cotton garments. At 40°C and
60°C it is the standard cycle for washing cotton garments, and is the most

ecient in terms of combined water and electricity consumption.

Cotton

Suitable for washing towels, underwear, table cloths, etc. made of
resistant linen and cotton that are moderately to heavily soiled.

Synthetics

Suitable for washing moderately soiled garments made of synthetic bres
(e.g. polyester, polyacrylic, viscose, etc.) or mixed synthetic-cotton bres.

Delicates

Suitable for washing lightly soiled garments made of synthetic bres (e.g.
polyester, polyacrylic, viscose, etc.) or mixed synthetic-cotton bres.

Wool - Woolmark Apparel Care - Green:

The “Wool” wash cycle is approved by the Woolmark Company
for washing wool garments classied as “hand-washable”,
provided that the wash complies with the instructions
appearing on the garment’s label and with those provided by
the manufacturer of this washing machine.

White

For heavily soiled whites and resistant colours.

Duvet

Suitable for washing clothing padded with goose down, such as single
duvets (weighing under 3 kg), cushions or down jackets. Duvets should
be loaded into the drum with their edges folded inwards and no more
than ¾ of the total drum volume should be used up. For best results, it is
advisable to use liquid detergent to be poured into the detergent drawer.

Rapid 30 min

For washing lightly soiled garments in a short time. Not suitable for wool,
silk and garments to be washed by hand.

Full Load 45 min

Suitable for washing a full load of cotton clothes moderately soiled in 45
minutes.

Shirts

Use the special wash cycle to wash shirts in dierent fabrics and colours
to guarantee they receive the best possible care.

Baby

Use the special wash cycle to remove the soiling typically caused by
babies, while removing all traces of detergent from nappies in order to
prevent the delicate skin of babies from suering allergic reactions. The
cycle has been designed to reduce the amount of bacteria by using a
greater quantity of water and optimising the eect of special disinfecting
additives added to the detergent.

Anti Stain 40°

the programme is suitable to heavily-soiled garments with resistant
colours. It ensures a washing class that is higher than the standard class (A
class). When running the programme, do not mix garments of dierent
colours. We recommend the use of powder detergent. Pre-treatment with
special additives is recommended if there are particularly obstinate stains.

Anti Allergy

Suitable for removing major allergens such as pollen, mites and cat or
dog hair.

Spin & Drain

Spins the load then empties the water. For resilient garments. If you
exclude the spin cycle, the machine will drain only.

Rinse & Spin

Rinses and then spins. For resilient garments.

DISPLAY

The display is useful when programming the washing machine and
provides plenty of information.

The duration of the available wash cycles and the remaining time of a running
cycle appear (the display will show the maximum duration of the cycle chosen,
which may decrease after several minutes, since the eective duration of the
programme varies depending on the wash load and the settings chosen); if the
DELAY START option has been set, the countdown to the start of the selected
wash cycle will appear.
Pressing the corresponding but ton allows you to view the maximum spin speed
and temperature values attained by the machine during the set wash cycle, or
the values selected most recently, if these are compatible with the set wash cycle.

Locked door indicator
When lit, the symbol indicates that the door is locked. To prevent any
damage, wait until the symbol turns o before opening the door.
To open the door while a cycle is in progress, press the START/PAUSE
button ; if the symbol is o, the door can be opened.

FIRSTTIME USE

Once the appliance has been installed, and before it is used for the rst
time, run a wash cycle with a very little detergent and no laundry, by
setting the “Auto-Clean” cycle. (see “CARE AND MAINTENANCE”)

DAILY USE

Prepare the laundry by following the suggestions appearing under the
“TIPS AND SUGGESTIONS” section.

- Press the ON/OFF button ; the indicator light relative to START/PAUSE

will ash slowly green.

- Open the door. Load the laundry while making sure not to exceed the
maximum load quantity indicated in the wash cycle table.

- Pull out the detergent dispenser drawer and pour the detergent into the
relevant compartments, as described in the “DETERGENT DISPENSER
DRAWER” section.

- Close the door.

- The machine automatically displays the maximum temperature and spin
speed values for the selected cycle, or the most recently used settings if
they are compatible with the selected cycle. Pressing the
gradually reduces the temperature down to the cold wash “OFF” setting.
Pressing the button gradually reduces the spin speed until it is
completely excluded (“OFF” setting). Pressing the buttons further restores
the maximum allowed values for the selected cycle.

- Select the desired wash cycle.

- Select the desired options.

- Press the START/PAUSE button to start the wash cycle; the relative
indicator light will light up steady green and the door will lock ( symbol on).

button

PAUSING A CYCLE

To pause the wash cycle, press the START/PAUSE button again; the
indicator light will ash amber. To start the wash cycle from the point at
which it was interrupted, press the START/PAUSE button again.

OPENING THE DOOR, IF NECESSARY

Once a cycle starts, the symbol turns on to signal that the door cannot
be opened. While a wash cycle is running, the door remains locked. To
open the door while a cycle is under way, for example, to add or remove
garments, press the START/PAUSE button to pause the cycle; the
indicator light will ash amber. If the symbol is not lit, the door may be
opened. Press the START/PAUSE button again to continue the cycle.

CHANGING A RUNNING WASH CYCLE

To change a wash cycle while it is in progress, pause the washing machine
using the START/PAUSE button (the relative indicator light will ash amber),
then select the desired cycle and press the START/PAUSE button again.
! To cancel a cycle that has already begun, press and hold the ON/OFF
button. The cycle will be stopped and the machine will switch o.

AT THE END OF THE WASH CYCLE

This will be indicated by the word “END” on the display; when the symbol
switches o, the door may be opened. Open the door, unload the laundry and
switch o the machine. If you do not press ON/OFF button, the washing
machine will switch o automatically af ter about a half of an hour.

OPTIONS

- If the selected option is not compatible with the set wash cycle, the
indicator light will ash and the option will not be activated.

Extra Rinse

Selecting this option allows for enhancing rinsing eciency and fully
removing the detergent. It is particularly useful for sensitive skin.

EXTRA
TOUCH

Extra Touch

After pushing the button for the 1st time, option “Rapid Option” is
selected and the cycle duration will be reduced.
After pushing the button for the 2nd time, option “Steam Hygiene”
enhances washing performance by generating steam during the wash cycle
to remove any bacteria from the bres, which are treated at the same time.
! The steam generated during the operation of the washing machine may
cause the porthole door to become hazy.
