Hotpoint MTMN 1902 F User Manual
Operating Instructions
2-DOOR FRIDGE
GB F
Français, 9English, 1
PT
Portuges,
25
AR
40
MTMN 1901 F (EX)
MTMN 1902 F (EX)
ES
Espanol, 17
Contents
GB
Installation, 2
Positioning and connection
Description of the appliance, 3
Overall view
Start-up and use, 4-5
Starting the appliance
Using the refrigerator to its full potential
Using the freezer to its full potential
Maintenance and care, 6
Switching the appliance off
Cleaning the appliance
Avoiding mould and unpleasant odours
Replacing the light bulb
Precautions and tips, 7
General safety
Disposal
Respecting and conserving the environment
Troubleshooting, 8
Assistance, 8
Installation
GB
! Before placing your new appliance into operation
please read these operating instructions carefully. They
contain important information for safe use, for
installation and for care of the appliance.
! Please keep these operating instructions for future
reference. Pass them on to possible new owners of the
appliance.
Positioning and connection
Positioning
1. Place the appliance in a well-ventilated humidity-free
room.
2. Do not obstruct the rear fan grills. The compressor
and condenser give off heat and require good
ventilation to operate correctly and save energy.
3. Leave a space of at least 10 cm between the top part
of the appliance and any furniture above it, and at least
5 cm between the sides and any furniture/side walls.
4. Ensure the appliance is away from any sources of
heat (direct sunlight, electric stove, etc.).
5. In order to maintain the correct distance between the
appliance and the wall behind it, fit the spacers
supplied in the installation kit, following the
instructions provided.
Electrical connections
After the appliance has been transported, carefully place
it vertically and wait at least 3 hours before connecting it
to the electricity mains. Before inserting the plug into the
electrical socket ensure the following:
The appliance is earthed and the plug is compliant with
the law.
The socket can withstand the maximum power of the
appliance, which is indicated on the data plate located
on the bottom left side of the fridge (e.g. 150 W).
The voltage must be in the range between the values
indicated on the data plate located on the bottom left
side (e.g. 220-240V).
The socket is compatible with the plug of the appliance.
If the socket is incompatible with the plug, ask an
authorised technician to replace it (see Assistance). Do
not use extension cords or multiple sockets.
! Once the appliance has been installed, the power supply
cable and the electrical socket must be easily accessible.
! The cable must not be bent or compressed.
! The cable must be checked regularly and replaced by
authorised technicians only (see Assistance).
! The manufacturer declines any liability should these
safety measures not be observed.
Levelling
1. Install the appliance on a level and rigid floor.
2. If the floor is not perfectly horizontal, adjust the
refrigerator by tightening or loosening the front feet.
2
Description of the
appliance
Overall view
The instructions contained in this manual are applicable to different model refrigerators. The diagrams may not
directly represent the appliance purchased. For more complex features, consult the following pages.
ICE DEVICE
FAST FREEZER
compartment
STORAGE
compartment
FRESH BOX
Compartment
REFRIGERATOR
OPERATION
Knob
FREEZER
OPERATION
Knob
SHELVES
Removable
multipurpose
SHELVES
Removable lidded
shelf with EGG TRAY
BUTTER dish
BEVERAGE CAN
shelves
Removable
multipurpose
SHELVES
GB
*
MOISTIRE adjusted
FRUIT and
VEGETABLE
bin
Levelling FEET
Varies by number and/or position.
Available only on certain models.
*
BOTTLE shelf
3
Start-up and use
Starting the appliance
GB
! Before starting the appliance, follow the
installation instructions (see Installation).
! Before connecting the appliance, clean the
compartments and accessories well with lukewarm
water and bicarbonate.
1. Insert the plug into the socket and ensure that the
internal light illuminates.
2. Turn the TEMPERATURE ADJUSTMENT knob to an
average value. After a few hours you will be able to
put food in the refrigerator.
Using the refrigerator to its full potential
The temperature inside the
refrigerator compartment
automatically adjusts itself
according to the position of the
fridge
It is recognisable by aeration cells located on the back
walls of the compartments.
The No Frost system circulates cold air continuously to
collect humidity and prevent ice and frost formation. The
system maintains an optimal humidity level in the
compartment, preserving the original quality of the food,
preventing the food from sticking together and making
defrosting a thing of the past. Do not block the aeration
cells by placing food or containers in direct contact with
the refrigerating back panel. Close bottles and wrap
food tightly.
Place only cold or lukewarm foods in the compartment,
not hot foods (see Precautions and tips).
Remember that cooked foods do not last longer than raw
foods.
thermostat knob.
min = warmest
max = coldest
We recommend, however, a
medium position.
FRESH BOX: for fresh meat and
fish. Due to the compartments
low temperature (the coldest in
the refrigerator) and to the clear
door that provides protection
against oxidation and
blackening, food can be stored
for even up to one week. It can
also be used for cold meals.
FRUIT and VEGETABLE bin
The salad crispers fitted inside the fridge have been
specially designed for the purpose of keeping fruit and
vegetables fresh and crisp. Open the humidity regulator
(position B) if you want to store food in a less humid
environment, or close it (position A) to store food in a more
humid environment.
A
B
BEVERAGE CAN shelves.
The can rack on the inner
door allows you to store not
only cans, but also yoghurt,
butter and other containers,
according to your
requirements.
removal of the shelf.
4
SHELVES: with or without grill.
Due to the special guides the
shelves are removable and the
height is adjustable (see
diagram), allowing easy
storage of large containers
and food. Height can be
adjusted without complete
Using the freezer to its full potential
The temperature inside the
freezer compartment
automatically adjusts itself
according to the position of
the thermostat knob.
freezer
off, including the refrigerator.
Set the thermostat to the maximum max in order to freeze
foods quickly.
Set the thermostat to the medium med for normal use and
to store frozen foods for long periods.
Set the thermostat to the minimum min in order to keep
ice cubes frozen.
During hot seasons, when the knob is turned to max
position, your fridge will operate for elongated period. The
thermostat position should be brought to its initial position
when the freezer compartment is cooled sufficiently.
min = warmest
max = coldest
We recommend, however, a
medium position.
switches the appliance
ICE DEVICE
After pouring water in the special
ice cups, place them in their
places in the ice device. After
about 2 hours, the ice cubes will
be ready. In order to get the ice
cubes, it will be sufficient to turn
the two buttons to the right. The ice
cubes will fall in to the tray below,
ready to be used.
GB
Do not re-freeze food that is defrosting or that has
already been defrosted. These foods must be cooked
and eaten (within 24 hours).
Fresh food that needs to be frozen must not come
into contact with food that has already been
defrosted. Fresh food must be packed in the top
FAST FREEZER compartment where the temperature
drops below -18°C and guarantees rapid freezing.
Do not place glass bottles which contain liquids, and
which are corked or hermetically sealed in the freezer
because they could break.
The maximum quantity of food that may be frozen daily
is indicated on the plate containing the technical
properties located on the bottom left side of the
refrigerator compartment (for example: Kg/24h: 4)
! Do not open the door during freezing.
! If there is a power cut or malfunction, do not open the
freezer door. This will help maintain the temperature
inside the freezer, ensuring that foods are conserved for
at least 9 -14 hours.
! To avoid blocking the air circulation inside the freezer, it
is advisable not to obstruct the ventilation holes with food
or containers.
5
Maintenance and care
Switching the appliance off
GB
During cleaning and maintenance it is necessary to
disconnect the appliance from the electricity supply:
It is not sufficient to set the temperature adjustment
knobs on
contact.
(appliance off) to eliminate all electrical
Cleaning the appliance
The external and internal parts, as well as the rubber
seals may be cleaned using a sponge that has been
soaked in lukewarm water and bicarbonate of soda or
neutral soap. Do not use solvents, abrasive products,
bleach or ammonia.
The removable accessories may be soaked in warm
water and soap or dishwashing liquid. Rinse and dry
them carefully.
The back of the appliance may collect dust which can
be removed by delicately using the hose of a vacuum
cleaner set on medium power. The appliance must be
switched off and the plug must be pulled out before
cleaning the appliance.
Avoiding mould and unpleasant odours
The appliance is manufactured with hygienic
materials which are odour free. In order to maintain an
odour free refrigerator and to prevent the formation of
stains, food must always be covered or sealed
properly.
If you want to switch the appliance off for an extended
period of time, clean the inside and leave the doors
open.
Replacing the light bulb
To replace the light bulb
in the refrigerator
compartment, pull out the
plug from the electrical
socket. Follow the
instructions below.
Access the light bulb by
removing the cover as
indicated in the diagram.
Replace it with a similar
light bulb within the
power range indicated on the cover (10W).
To replace the light bulb
A
B
with a similar light bulb within the power range indicated
on the cover (10W or 15W).
in the freezer
compartment, pull out the
plug from the electrical
socket. Follow the
instructions below.
Access the light bulb (A)
by unscrewing the fixing
screw (B) which is
located at the back of the
lampcover, as shown
(see diagram). Replace it
6
Precautions and tips
! The appliance was designed and manufactured in
compliance with international safety standards. The
following warnings are provided for safety reasons
and must be read carefully.
This appliance complies with the following
Community Directives:
- 73/23/EEC of 19/02/73 (Low Voltage) and
subsequent amendments;
-89/336/EEC of 03.05.89 (Electromagnetic
Compatibility) and subsequent amendments;
- 2002/96/CE.
General safety
The appliance was designed for domestic use inside
the home and is not intended for commercial or
industrial use.
The appliance must be used to store and freeze food
products by adults only and according to the
instructions in this manual.
The appliance must not be installed outdoors, even
in covered areas. It is extremely dangerous to leave
the appliance exposed to rain and storms.
Do not touch the appliance with bare feet or with wet
or moist hands and feet.
Do not touch the internal cooling elements: this
could cause skin abrasions or frost/freezer burns.
When unplugging the appliance always pull the plug
from the mains socket, do not pull on the cable.
Before cleaning and maintenance, always switch off
the appliance and disconnect it from the electrical
supply. It is not sufficient to set the temperature
adjustment knobs on
all electrical contact.
In the case of a malfunction, under no circumstances
should you attempt to repair the appliance yourself.
Repairs carried out by inexperienced persons may
cause injury or further malfunctioning of the
appliance.
Do not use utensils other than the scraper provided,
or electrical equipment which is not of the type
specified by the manufacturer, inside the frozen food
storage compartments.
Do not put ice cubes taken directly from the freezer
into your mouth.
Do not allow children to tamper with the controls or
play with the appliance. Under no circumstance
should they be allowed to sit on the bins or to hang
from the door.
Keep packaging material out of the reach of children!
It can become a choking or suffocation hazard.
(appliance off) to eliminate
Disposal
GB
Observe local environmental standards when
disposing packaging material for recycling
purposes.
The European Directive 2002/96/EC on Waste
Electrical and Electronic Equipment (WEEE), requires
that old household electrical appliances must not be
disposed of in the normal unsorted municipal waste
stream. Old appliances must be collected separately
in order to optimise the recovery and recycling of the
materials they contain and reduce the impact on
human health and the environment. The crossed out
wheeled bin symbol on the product reminds you of
your obligation, that when you dispose of the
appliance it must be separately collected.
Consumers should contact their local authority or
retailer for information concerning the correct
disposal of their old appliance.
Respecting and conserving the
environment
Install the appliance in a fresh and well-ventilated
room. Ensure that it is protected from direct sunlight
and do not place it near heat sources.
Try to avoid keeping the door open for long periods
or opening the door too frequently in order to
conserve energy.
Do not fill the appliance with too much food:
cold air must circulate freely for food to be preserved
properly. If circulation is impeded, the compressor
will work continuously.
Do not place hot food directly into the refrigerator.
The internal temperature will increase and force the
compressor to work harder and will consume more
energy.
Defrost the appliance if ice forms (see Maintenance).
A thick layer of ice makes cold transference to food
products more difficult and results in increased
energy consumption.
Regularly check the door seals and wipe clean to
ensure they are free of debris and to prevent cold air
from escaping (see Maintenance).
7
Troubleshooting
195079493.00
Assistance
If the appliance does not work, before calling for Assistance (see Assistance), check for a solution from the following list.
GB
07/2009
Malfunctions:
The internal light does not
illuminate.
The refrigerator and the freezer do
not cool well.
The food inside the refrigerator is
beginning to freeze.
The motor runs continuously.
The appliance makes a lot of noise.
Possible causes / Solutions:
The plug has not been inserted into the electrical socket, or not far
enough to make contact, or there is no power in the house.
The doors do not close properly or the seals are damaged.
The doors are opened too frequently.
The TEMPERATURE ADJUSTMENT knob is not in the correct position
The refrigerator or the freezer have been over-filled.
The TEMPERATURE ADJUSTMENT knob is not in the correct
position.
The door is not closed properly or is continuously opened.
The outside ambient temperature is very high.
The appliance has not been installed on a level surface (see
Installation).
The appliance has been installed between cabinets that vibrate and
make noise.
The internal refrigerant makes a slight noise even when the
compressor is off. This is not a defect, it is normal.
Assistance
Before calling for Assistance:
Check if the malfunction can be solved on your own (see Troubleshooting).
If after all the checks, the appliance still does not operate or the problem persists, call the nearest Service Centre
Communicating:
type of malfunction
appliance model (Mod.)
serial number (S/N)
This information can be found on the data plate
located on the bottom left side of the refrigerator
compartment.
Never call on unauthorized technicians and always refuse spare parts which are not originals.
model serial number
8
Mode demploi
REFRIGERATEUR 2 PORTES
GB F
Français, 9English, 1
PT
Portuges,
25
AR
40
MTMN 1901 F (EX)
MTMN 1902 F (EX)
ES
Espanol, 17
Sommaire
F
Installation, 10
Mise en place et raccordement
Description de lappareil, 11
Vue densemble
Mise en marche et utilisation, 12-13
Mise en service de lappareil
Pour profiter à plein de votre réfrigérateur
Pour profiter à plein de votre congélateur
Entretien et soins, 14
Mise hors tension
Nettoyage de lappareil
Contre la formation de moisissures et de mauvaises odeurs
Remplacement de lampoule déclairage
Précautions et conseils, 15
Sécurité générale
Mise au rebut
Economies et respect de lenvironnement
Anomalies et remèdes, 16
Assistance, 16
Installation
! Conservez ce mode demploi pour pouvoir le consulter
F
à tout moment. En cas de vente, de cession ou de
déménagement, veillez à ce quil suive lappareil pour
informer le nouveau propriétaire sur son fonctionnement
et lui fournir les conseils correspondants.
! Lisez attentivement les instructions : elles contiennent
des conseils importants sur linstallation, lutilisation et la
sécurité de votre appareil.
Mise en place et raccordement
Mise en place
1. Placez lappareil dans une pièce bien aérée et non
humide.
2. Ne bouchez pas les grilles daération arrière: le
compresseur et le condensateur produisent de la
chaleur et exigent une bonne aération pour bien
fonctionner et réduire la consommation délectricité.
3. Prévoir au moins 10 cm entre le haut de lappareil et
les meubles installés au-dessus et au moins 5 cm
entre les côtés et les meubles/parois latérales.
4. Installez lappareil loin de sources de chaleur (rayons
directs du soleil, cuisinière électrique).
5. Pour maintenir une distance optimale entre le produit
et la paroi arrière, montez les cales despacement
comprises dans le kit dinstallation et suivez les
instructions de la notice spécialement prévue.
Raccordement électrique
Après le transport, placez lappareil à la verticale et
attendez au moins 3 heures avant de le raccorder à
linstallation électrique. Avant de brancher la fiche dans
la prise de courant, assurez-vous que:
la prise est bien munie dune terre conforme à la loi;
la prise est bien apte à supporter la puissance
maximale de lappareil, indiquée sur la plaquette
signalétique placée à lintérieur du compartiment
réfrigérateur en bas à gauche (ex. 150 W);
la tension dalimentation est bien comprise entre les
valeurs indiquées sur la plaquette signalétique,
placée en bas à gauche (ex.220-240 V);
la prise est bien compatible avec la fiche de lappareil.
En cas dincompatibilité, faites remplacer la fiche par
un technicien agréé (voir Assistance); nutilisez ni
rallonges ni prises multiples.
! Après installation de lappareil, le câble électrique et la
prise de courant doivent être facilement accessibles.
! Le câble ne doit être ni plié ni excessivement écrasé.
! Il doit être contrôlé prériodiquement et ne peut être
remplacé que par un technicien agréé (voir Assistance).
! Nous déclinons toute responsabilité en cas de non
respect des normes énumérées ci-dessus.
Mise à niveau
1. Installez lappareil sur un sol plat et rigide.
2. Si le sol nest pas parfaitement horizontal, vissez ou
dévissez les petits pieds avant pour bien niveler lappareil.
10
Description de
lappareil
Vue densemble
Ces instructions dutilisation sappliquent à plusieurs modèles, il se peut donc que les composants illustrés
présentent des différences par rapport à ceux de lappareil que vous avez acheté. Vous trouverez dans les pages
suivantes la description des objets plus complexes.
Bac à GLAÇONS
Compartiment FAST
FREEZER
Compartiment
CONSERVATION
Compartiment
FRESH BOX
Bouton
FONCTIONNEMENT
REFRIGERATEUR
Bouton
FONCTIONNEMENT
CONGELATEUR
CLAYETTE
Balconnet amovible
PORTE-OBJETS
Balconnet amovible à
abattant
Scatola
BURRO
Balconnet
PORTECANETTES
Balconnet amovible
PORTE-OBJETS
*
F
Reglage
DHUMIDITE
Bac FRUITS
et LEGUMES
PIED
de réglage
Leur nombre et/ou leur emplacement peut varier.
Nexiste que sur certains modèles.
*
Balconnet
BOUTEILLES
11
Mise en marche et
utilisation
Mise en service de lappareil
F
! Avant de mettre lappareil en service, suivez bien
les instructions sur linstallation (voir Installation).
! Avant de brancher votre appareil, nettoyez bien les
compartiments et les accessoires à leau tiède
additionnée de bicarbonate.
1. Branchez la fiche dans la prise de courant et
assurez-vous que léclairage intérieur sallume.
2. Amenez le bouton de REGLAGE DE LA
TEMPERATURE sur une valeur intermédiaire. Au bout
de quelques heures, vous pourrez commencer à
stocker des aliments dans le réfrigérateur.
Pour profiter à plein de votre réfrigérateur
Le réglage de la température à
lintérieur du compartiment
réfrigérateur est automatique
en fonction de la position du
fridge
dair froid qui absorbe lhumidité et empêche la formation
de glace et de givre: il maintient un niveau dhumidité
adéquat à lintérieur du compartiment réfrigérateur et, grâce
à labsence de givre, il préserve les qualités originaires des
aliments; dans le compartiment congélateur il évite la
formation de glace, il ny a par conséquent plus besoin de
dégivrer et les aliments ne collent plus entre eux. Ne placez
pas daliments ou de récipients contre la paroi refroidissante
arrière pour ne pas boucher les trous daération et éviter une
formation rapide deau condensée. Fermez bien les
bouteilles et emballez les aliments.
Nintroduisez que des aliments froids ou à peine tièdes,
jamais chauds (voir Précautions et conseils).
Les aliments cuits contrairement à ce que lon croit ne se
conservent pas plus longuement que les aliments crus.
bouton du thermostat.
min = moins froid
max = plus froid
Nous conseillons toutefois une
position intermédiaire
Le No Frost gère un flux continu
FRESH BOX: pour viandes et
poissons frais. Ce compartiment
sert à prolonger la durée de
conservation jusquà une
semaine, grâce à sa
température très basse la plus
froide du réfrigérateur et à son
volet transparent qui protège
contre les phénomènes
doxydation et de noircissement. Il peut aussi être utilisé
pour conserver des plats froids.
Bac FRUITS et LEGUMES
Les tiroirs à fruits et légumes qui équipent le
réfrigérateur sont spécialement conçus pour garder
vos fruits et légumes frais et savoureux. Ouvrez le
régulateur dhumidité (position B) si vous désirez
conserver vos aliments dans un environnement moins
humide ou bien fermez-le (position A) pour les
conserver dans un environnement plus humide.
A
B
Balconnet PORTECANETTES
Le porte-canettes placé
dans la contre-porte vous
permet de ranger non
seulement vos canettes
mais aussi vos yogurts,
votre beurre et vos autres
récipients selon vos
exigences.
12
CLAYETTES: pleines ou
grillagées. Elles sont amovibles
et réglables en hauteur grâce à
des glissières spéciales (voir
figure), pour le rangement de
récipients ou daliments de
grande dimension. Pour régler la
hauteur, pas besoin de sortir la
clayette complètement.
Loading...
