Hotpoint LST 216 A CN User Manual
Operating instructions
简体中文，13
DISHWASHER
EN
English,1
LST 216
ZH
Contents
Installation, 2-3
Positioning and levelling
Connecting the water and electricity supplies
Advice regarding the first wash cycle
Technical data
Description of the appliance, 4
Overall view
Control panel
Loading the racks, 5
Lower rack
Cutlery basket
Upper rack
Start-up and use, 6
Starting the dishwasher
Measuring out the detergent
Wash options
Wash cycles, 7
Table of wash cycles
Rinse aid and refined salt, 8
Measuring out the rinse aid
Measuring out the refined salt
Care and maintenance, 9
Shutting off the water and electricity supplies
Cleaning the dishwasher
Preventing unpleasant odours
Cleaning the sprayer arms
Cleaning the water inlet filter
Cleaning the filters
Leaving the machine unused for extended periods
Precautions and advice, 10
General safety
Disposal
Saving energy and respecting the environment
Troubleshooting, 11
Assistance, 12
Before calling for Assistance
Installation
EN
Keep this instruction manual in a safe place for
future reference. If the appliance is sold, given away or
moved, please ensure the manual is kept with the
machine, so that the new owner may benefit from the
advice contained within it.
Please read this instruction manual carefully: it
contains important information regarding the safe
installation, use and maintenance of the appliance.
If the appliance must be moved at any time, keep it in
an upright position; if absolutely necessary, it may be
tilted onto its back.
This appliance is intended to be used in household and
similar applications such as:
- staff kitchen areas in shops, offices and other working
environments;
- farm houses;
- by clients in hotels, motels and other residential type
environments;
- bed and breakfast type environments.
Positioning and levelling
1. Remove the appliance from all packaging and check
that it has not been damaged during transportation.
If it has been damaged, contact the retailer and do not
proceed any further with the installation process.
2. Check the dishwasher by placing it so that its sides or
back panel are in contact with the adjacent cabinets or
even with the wall. This appliance can also be recessed
* (
under a single worktop
sheet
).
see the Assembly instruction
Connecting the water inlet hose
• To a suitable cold water connection point: before
attaching the hose, run the water until it is perfectly
clear so that any impurities that may be present in the
water do not clog the appliance; after performing this
operation, screw the inlet hose tightly onto a tap with
a ¾ gas threaded connection.
• To a suitable hot water connection point: your
dishwasher may be supplied with hot water from the
mains supply (if you have a central heating system
with radiators) provided that it does not exceed a
temperature of 60°C.
Screw the hose to the tap as described for connection
to a cold water supply.
If the inlet hose is not long enough, contact a
specialist store or an authorised technician (
Assistance
The water pressure must be within the values
indicated in the Technical data table (
information
The hose should not be bent or compressed.
).
see adjacent
).
see
Connecting the water outlet hose
Connect the outlet hose (without bending it) to a drain
duct with a minimum diameter of 4 cm.
3. Position the dishwasher on a level and sturdy floor. If
the floor is uneven, the front feet of the appliance may be
adjusted until it reaches a horizontal position. If the
appliance is levelled correctly, it will be more stable and
much less likely to move or cause vibrations and noise
while it is operating.
4. Adjust the height of the rear foot from the front of the
appliance
a hexagonal spanner (red color) with an opening of 8 mm in a
clockwise direction to increase the height or in an
anticlockwise direction to decrease the height.
* on the central lower part of the dishwasher, turning
Connecting the water and electricity
supplies
Connection to the water and electricity supplies
should only be performed by a qualified technician.
The dishwasher should not stand on top of the water
hoses or the electricity supply cable.
The appliance must be connected to the water
supply network using new hoses.
Do not use old hoses.
The water inlet and outlet hoses and the electricity
supply cable may be positioned towards the right or the
left in order to achieve the best possible installation.
The outlet hose must be at a height ranging from 40 to
80 cm from the floor / surface where the dishwasher
rests (A).
Before connecting the water outlet hose to the sink
drain, remove the plastic plug (B).
* Only available in selected models.
2
Anti-flooding protection
To ensure floods do not occur, the dishwasher:
- is provided with a special system which blocks the
water supply in the event of anomalies or leaks from
inside the appliance.
Anti-condensation strip*
After installing the dishwasher, open the door and stick
the adhesive transparent strip under the wooden shelf in
order to protect it from any condensation which may
form.
EN
Some models are also equipped with the supplementary
safety device
flooding protection even in the event of a supply hose
rupture.
New Acqua Stop
*, which guarantees anti-
WARNING: HAZARDOUS VOLTAGE!
Under no circumstance should the water inlet hose be
cut as it contains live electrical parts.
Electrical connection
Before inserting the plug into the electrical socket, make
sure that:
• The socket is earthed and complies with current
regulations.
• The socket can withstand the maximum load of the
appliance, which is indicated on the data plate
located on the inside of the door (
Description of the appliance
• The power supply voltage falls within the values
indicated on the data plate on the inside of the door.
• The socket is compatible with the plug of the
appliance. If this is not the case, ask an authorised
technician to replace the plug (
not use extension cables or multiple sockets.
Once the appliance has been installed, the power
supply cable and the electrical socket should be easily
accessible.
The cable should not be bent or compressed.
If the power supply cable is damaged, it must be replaced by the manufacturer or its Technical Assistance
Service in order to prevent all potential hazards. (See Assistance)
The Company shall not be held responsible for any
incidents that occur if these regulations are not
observed.
see chapter entitled
).
see Assistance
); do
Advice regarding the first wash cycle
After the appliance has been installed, immediately
before running the first wash cycle, completely fill the
salt dispenser with water and add only then
approximately 1 kg of salt (
and refined salt
and is not a cause for concern. Select the water
hardness value (
refined salt
machine, the LOW SALT indicator light* switches off.
If the salt container is not filled, the water softener
and the heating element may be damaged as a result.
). The water may overflow: this is normal
see chapter entitled Rinse aid and
). - After the salt has been poured into the
Technical data
Dimensions
Capacity 10 standard place-settings
Water supply
pressure
Power supply
voltage
Total absorbed
power
Fuse See appliance data plate
see chapter entitled Rinse aid
width 44.5 cm
height 82 cm
depth 57 cm
0,05 ÷ 1MPa (0.5 ÷ 10 bar)
7,25 – 145 psi
See appliance data plate
See appliance data plate
This dishwasher conforms to the
following European Community
Directives:
-2006/95/EC (Low Voltage
-2004/108/EC (Electromagnetic
Compatibility)
-2005/32/EC (Comm. Reg.
1275/2008) (Ecodesign)
-2002/96/ EC (Waste Electrical
and Electronic Equipment WEEE)
* Only available in selected models.
3
Description of the
appliance
EN
Overall view
1. Upper rack
2. Upper sprayer arm
3. Tip-up compartments
4. Rack height adjuster
5. Lower rack
6. Lower sprayer arm
7. Cutlery basket
8. Washing filter
9. Salt dispenser
10. Detergent and rinse aid dispensers
11. Data plate
12. Control Panel
***
Control panel
Select wash
cycle button
ON/OFF
indicator light
ON/OFF/RESET
button
Low salt
indicator
light*
Wash cycle indicator lights
Low rinse aid
indicator light*
***Only in completely built-in models.
* Only available in selected models.
The number and type of wash cycles and options may vary depending on the dishwasher model.
4
Loading the racks
Before loading the racks, remove all food residues from
the crockery and empty liquids from glasses and cups.
After loading the appliance, check that the sprayer arms
can rotate freely.
Lower rack
The lower rack can hold pans, lids, plates, salad bowls,
cutlery, etc. as seen in the
Plates and large covers should be placed at the sides of the
rack, ensuring that they do not block the rotation of the upper
sprayer arm.
Loading examples.
Some dishwasher models are fitted
with tip-up sections
used in a vertical position when
arranging plates or in a horizontal
position when arranging pans and
salad bowls.
*, which can be
Cutlery basket
The type of cutlery basket may vary according to the
dishwasher model: The cutlery basket should be positioned at
the front of the lower rack, by sliding it between the fixed
inserts, or on the upper rack when the half load option has been
selected (in models featuring this option).
- It has a collapsible
sliding system which
means the cutlery can be
arranged in the best
possible way.
Adjusting the height of the upper rack
In order to make it easier to arrange the crockery, the upper
rack may be moved to a higher or lower level.
The height of the upper rack should ideally be adjusted
WHEN THE RACK IS EMPTY.
Never lift or lower the rack on one side only.
Open the left and right guide rail
stops and pull out the rack; position it
higher or lower as required, slide it
along the guide rails until the front
wheels are in place and close the
stops (
see figure
If the rack is fitted with Dual Space
handles
upper rack until it reaches its stop
point, grip the handles at the sides of
the rack and move it upwards or
downwards, then slowly let it fall back
into place.
* (
).
see figure
), pull out the
Loading examples for the upper rack
EN
Knives and other utensils with sharp edges must be
placed in the cutlery basket with the points facing
downwards, or they must be positioned horizontally in the tipup compartments on the upper rack.
Cutlery basket positioning examples
Upper rack
Load this rack with delicate and lightweight crockery:
glasses, tea and coffee cups, saucers, small salad bowls,
saucepans and small saucepans which are not too soiled,
using the
• Mugs and cups, long sharp knives and serving utensils:
place these on the tip-up compartments
Loading examples
as a guide.
**.
* Only available in selected models.
** The number and position may vary.
Loading examples for the lower rack
Items which should not be washed in the
dishwasher
• Wooden items, objects with wooden or horn handles or
glued-on parts.
• Items made from aluminium, copper, brass, pewter or tin.
• Items made from plastic material which is not heatresistant.
• Antique or hand-painted porcelain.
• Antique silver. Silver which is not antique may, however,
be washed in the dishwasher using a delicate wash cycle,
provided that it does not come into contact with other
metals.
We recommend the use of crockery which is dishwasher
safe.
5
Start-up and use
EN
Starting the dishwasher
1. Turn the water tap on.
2. Open the door and press the ON/OFF button: you will
hear a short beep and the ON/OFF and wash cycle
indicator lights switch on for a few seconds.
3. Measure out the detergent (
4. Load the racks (
racks
).
5. Select the wash cycle in accordance with the type of
crockery and its soil level (
pressing the P button; the indicator light corresponding
to the selected wash cycle will switch on.
7. Start the wash cycle by shutting the door: after a few
seconds have passed, a long beep signals the start of
the wash cycle.
8. Two short beeps and one long one indicate the end of
the wash cycle and the indicator light corresponding to
the wash cycle flashes slowly. Open the door, switch off
the appliance by pressing the ON/OFF button, shut off
the water tap and unplug the appliance from the
electricity socket.
9. Wait for a few minutes before removing the crockery,
in order to avoid burns. Unload the racks, beginning with
the lower level.
see chapter entitled Loading the
- The machine will switch off automatically
during certain periods of inactivity, in order to
minimise electricity consumption.
Modifying a wash cycle in progress
If a mistake was made during the wash cycle selection
process it is possible to change the cycle, provided that it
has only just begun: open the door, taking care to avoid the
escaping steam, and press and hold the ON/OFF button;
the machine will switch off with a long beep. Switch the
machine back on using the ON/OFF button and select the
new wash cycle using the P button; start the cycle by
closing the door.
see below
see Table of wash cycles
).
), by
Measuring out the detergent
A good wash result also depends on the correct
amount of detergent being used; exceeding the
stated amount does not result in a more effective
wash and increases environmental pollution.
Only use detergent which has been
specifically designed for dishwashers.
DO NOT USE washing up liquid.
Using excessive detergent may result in foam
residue remaining in the machine after the cycle
has ended.
The use of tablets is only recommended for
models which offer the MULTI-FUNCTIONAL
TABLETS option.
To achieve the best results from each washing
and drying cycle, powder detergent, rinse aid
liquid and salt should be used.
Compartment A: Washing detergent
Compartment B: Pre-wash detergent
D
A
B
C
tablet, place it in compartment A and close the cover;
when it requires 2, place the second tablet at the bottom
of the appliance.
3. Remove detergent residues from the edges of the
compartment and close the cover until it clicks.
1. Open cover C by pressing
button D.
2. Pour in the detergent after
consulting the
cycles
:
• For powder detergent use
compartments A and B.
• For detergent in tablet form:
when the cycle requires 1
Table of wash
Adding extra crockery
Without switching off the machine, open the door, taking
care to avoid the escaping steam, and place the
crockery inside the dishwasher. Close the door: the
cycle starts from the point at which it was interrupted.
Accidental interruptions
If the door is opened during the wash cycle, or if there is
a power cut, the cycle stops. It starts again from the point
at which it was interrupted once the door has been shut
or the electricity supply is restored.
6
* Only available in selected models.
Wash cycles
If the crockery is only lightly soiled or if it has been rinsed with water before being placed in the
dishwasher, reduce the amount of detergent used accordingly.
The number and type of wash cycles and options may vary depending on the dishwasher model.
Wash cycle
duration
(tolerance
±10%)
Hrs. Min.
Wash cycle selection
instructions
Extremely soiled dishes and
pans (not to be used for
delicate items).
Normally soiled pans and
dishes. Standard daily wash
cycle.
Preliminary wash cycle for
dishes while the load is
awaiting completion with the
dishes from the next meal.
Environmentally-friendly wash
cycle with low energy
consumption levels, suitable
for pans and dishes.
Economic and fast wash to be
used for lightly soiled dishes.
(Run cycle immediately after
use) (2 plates + 2 glasses + 4
pieces of cutlery + 1 saucepan
+ 1 small frying pan). Rapid
Economic and fast wash for
delicate items which are
sensitive to high
temperatures. (Run cycle
immediately after use)
(glasses upper rack + delicate
plates, lower rack). Crystal
Wash cycle
Intensive
Normal
Soak
Eco
*
Detergent
(A) = compartment A
(B) = compartment B
Powder Liquid Tablets
25 g (A)
21 g (A)
4 g (B)
No No No No 0:08’
25 g (A)
21 g (A) 21 g (A) 1 (A) No 0:35’
25 g (A) 25 g (A) 1 (A) Yes 1:35’
25 ml (A)
21 ml (A)
4 ml (B)
25 ml (A) 1 (A) Yes 2:35’
1 (A)
1 (A) Yes 1:50’
Drying
Yes 2:25’
EN
Notes:
Optimum performance levels when using the ""Rapid wash" cycle can be achieved by observing the maximum amounts
of crockery specified.
To make it easier to measure out the detergent, it is worth remembering that:
1 tablespoon = 15 grams of powder = approximately 15 ml of liquid - 1 teaspoon = 5 grams of powder = approximately 5
ml of liquid.
* The Eco wash cycle adheres to the regulation EN-50242. Although it has a longer duration than other wash cycles it
uses less energy and is les harmful to the environment.
Note for Test Laboratories: for information relating to comparative EN testing conditions, please send an email to the
following address: ASSISTENZA_EN_LVS@indesitcompany.com
7
Rinse aid and refined salt
EN
Only use products which have been
specifically designed for dishwashers.
Do not use table salt or industrial salt, or
washing up liquid.
Follow the instructions given on the packaging.
If using a multi-functional product it is not necessary to
add rinse aid; however, we recommend that you add salt,
especially if you live in an area where the water is hard
or very hard. Follow the instructions given on the
packaging.
If you do not add salt or rinse aid, the LOW
* and LOW RINSE AID* indicator lights
SALT
remain lit.
Measuring out the rinse aid
Rinse aid makes it easier for the crockery to dry, as water
runs off surfaces more readily and therefore does not leave
streaks or marks.
The rinse aid dispenser should be filled:
• When the LOW RINSE AID
panel is illuminated;
Adjusting the amount of rinse aid
If you are not completely satisfied with the drying results,
you may adjust the quantity of rinse aid used. Use a
screwdriver to turn the dosage adjuster (F) to one of the 6
pre-set positions (the default position is set to 4):
• If there are streaks on the crockery, set the adjustment
device to a lower number (1-3).
• If drops of water remain on the crockery or if there are
limescale marks present after the cycle has finished, set
the adjuster to a higher number (4-6).
Setting the water hardness
Every dishwasher is equipped with a water softener which, by
using refined salt designed especially for this type of
appliance, supplies water without limescale which is then used
to wash the crockery.
This dishwasher offers a setting which helps to reduce
pollution and optimises washing performance in accordance
with the water hardness level in your area. This information can
be obtained from the organisation which supplies your
household with water.
- Open the door and switch on the machine by pressing
the ON/OFF button.
- Press the P button and hold for approximately 5 seconds;
two short beeps will sound and the indicator light
corresponding to the set degree of hardness will flash
slowly on the control panel (the water softening system is
set to number 3).
* indicator light on the control
1. Open the dispenser by turning the
lid (G) in an anticlockwise direction.
2. Pour in the rinse aid, making sure it
does not overflow from the
dispenser. If this happens, clean the
spill immediately with a dry cloth.
F
3. Screw the lid back on.
G
NEVER pour the rinse aid directly
into the appliance tub.
- Press the P button repeatedly until the desired hardness
level has been reached (1-2-3-4-5
).
table
E.g. hardness 1 (indicator light 1 flashing)
hardness 2 (indicator light 1 illuminated, indicator light 2
flashing).
hardness 3 (indicator lights 1 and 2 illuminated, indicator light
3 flashing and so on).
- To exit the function, wait a few seconds or press one of the
option buttons
button.
Even if using multi-functional tablets, the salt dispenser should
still be filled.
(°dH = hardness measured in German degrees - °f = hardness
measured in French degrees - mmol/l = millimoles per litre)
*, or switch off the machine using the ON/OFF
Water Hardness Table
°dH °fH mmol/l level
0 6 0 10 0 1 1
6 11 11 20 1.1 2 2
12 17 21 30 2.1 3 3
17 34 31 60 3.1 6 4
34 50 61 90 6.1 9
For values between 0°f and 10°f, we do not
recommend the use of sal t.
* this setting m ay cause a slight increase in the
durat ion of the cycl e.
*
see Water hardness
*
5
Measuring out the refined salt
In order to achieve the best possible results using a wash
cycle, make sure that the dispenser is never empty.
Refined salt removes limescale from the water, thus
avoiding the formation of deposits on crockery.
The salt dispenser is located in the lower part of the
dishwasher (
• When the green float
the cap of the salt dispenser.
• When the LOW SALT
illuminated;
salt container right up to its edge (this should hold
approximately 1 kg); it is not unusual for a little water to leak
out.
4. Remove the funnel
the opening; rinse the cap under running water and then
screw it on, the head facing downwards so as to let the water
flow out of the four cracks which are arranged in a star shape
on the lower part of the cap. (Salt cap with green float
It is advisable to perform this procedure every time you
add salt to the container.
Make sure the cap is screwed on tightly, so that no detergent
can get into the container during the wash cycle (this could
damage the water softener beyond repair).
When necessary, measure out the salt before a wash
cycle so that any saline solution which has leaked out of the
salt dispenser is removed.
see Description
) and should be filled:
* cannot be seen by simply looking at
* indicator light on the control panel is
1. Remove the lower rack and unscrew the
container cap (anticlockwise).
2. The first time you do this: fill the water tank
right up to its edge.
3. Position the funnel
* (
see figure)
and fill the
* and wipe any salt residue away from
*)
8
* Only available in selected models.
Loading...
