Operating Instructions
HOB
GB
English,1
CRO 642 D B
CRO 742 DO B
Contents
Installation, 2-4
Positioning
Electrical connection
Description of the appliance, 5-6
Control panel
Extendable cooking zones
Start-up and use, 7-10
Switching on the hob
Switching on the cooking zones
Switching off the cooking zones
Power function
Heating elements
Programming the cooking duration
Timer
Control panel lock
Switching off the hob
Demo mode
Practical advice on using the appliance
Safety devices
Practical cooking advice
GB
Precautions and tips, 11
General safety
Disposal
Care and maintenance, 12
Switching the appliance off
Cleaning the appliance
Disassembling the hob
Technical description of the models, 13
After Sales Service, 14
Guarantee, 15
Key Contacts, 16
Installation
GB
Before operating your new appliance please read
this instruction booklet carefully. It contains
important information concerning the safe operation,
installation and maintenance of the appliance.
Please keep these operating instructions for future
reference. Pass them on to any new owners of the
appliance.
Positioning
Keep all packaging material out of the reach of
children. It may present a choking or suffocation
hazard (see Precautions and tips).
The appliance must be installed by a qualified
professional in accordance with the instructions
provided. Incorrect installation may cause harm to
people and animals or may damage property.
Bu ilt-in appliance
Use a suitable cabinet to ensure that the appliance
functions properly.
The supporting surface must be heat-resistant up
to a temperature of approximately 100°C.
If the appliance is to be installed above an oven,
the oven must be equipped with a forced
ventilation cooling system.
Avoid installing the hob above a dishwasher: if
this cannot be avoided, place a waterproof
separation device between the two appliances.
Depending on the hob you want to install, the
cabinet must have the following dimensions (see
figure):
590
690
5 mm
5 mm
UNDERSIDE
OF HOB
min. 20 mm
COMPARTMENT
min. 40 mm
min. 20 mm
FAN-ASSISTED
OVEN
min. 40 mm
FRONT SIDE
OF HOB
SUPPORTING
SURFACE
30
40
48
560 +/- 1
2
5
490 +/- 1
0
48
560 +/- 1
520
490 +/- 1
Ventilation
To allow adequate ventilation and to avoid overheating
of the surrounding surfaces the hob should be positioned
as follows:
At a minimum distance of 40 mm from the back
panel.
So that a minimum distance of 20 mm is
maintained between the installation cavity and the
cabinet underneath.
Kitchen cabinets adjacent to the appliance and
taller than the top of the hob must be at least 600
mm from the edge of
the hob.
2
Fixing
The appliance must be installed on a perfectly level
supporting surface.
Any deformities caused by improper fixing could
affect the features and operation of the hob.
The thickness of the supporting surface
taken into account when choosing
the length of the
should be
screws for the fixing hooks:
30 mm thick: 17.5 mm screws
40 mm thick: 7.5 mm screws
Fix the hob as follows:
1. Use short flat-bottomed screws to fix the 4
alignment springs in the holes provided at the
central point of each side of the hob.
2
. Place the hob in the cavity, make sure it is in a
central position and push down on the whole
perimeter until the hob is stuck to the supporting
surface.
3. For hobs with raised sides: After inserting the hob
into its cavity, insert the 4 fixing hooks (each has its
own pin)
into the lower edges of the hob, using the
long pointed screws to fix them in place, until the
glass is stuck to the supporting surface.
The screws for the alignment springs must remain
accessible.
In order to adhere to safety standards, the
appliance must not come into contact with electrical
parts once it has been installed.
All parts which ensure the safe operation of the
appliance must not be removable without the aid of
a tool.
Electrical connection
The electrical connection for the hob and for any
built-in oven must be carried out separately, both for
safety purposes and to make extracting the oven
easier.
Terminal board
On the lower part of the
UNDERSIDE OF HOB
appliance there is a
connection box for the
different types of electricity
supply (the picture is only an
indication and is not an exact
representation of the
purchased model).
Single-phase connection
The hob is equipped with a pre-connected electricity
supply cable, which is designed for single-phase
connection. Connect the wires in accordance with
the instructions given in the following table and
diagrams:
Voltage an d
mains freq uenc y
230-240V 1+N ~
220-240V 1+N ~
50/60 Hz
Electrical cable Wire connection
: yellow/green;
N: the t wo blu e wires
together
L: brown and black
together
Other types of connection
If the mains supply corresponds with one of the
following:
Voltage and mains frequency
400V - 2+N ~ 50/60 Hz
220-240V 3 ~ 50/60 Hz
230-240V 3 ~ 50/60 Hz
400V - 2+2N ~ 50/60 Hz
Separate the wires and connect them in accordance
with the instructions given in the following table and
diagrams:
Voltage and
mains frequency
400V - 2+N ~
50/60 Hz
230-240V 3 ~
220-240V 3 ~
50/60Hz
400V - 2+2N ~
50/60 Hz
Electrical cable Wire connection
: yellow/green;
N: the two blue wires together
L1: black
L2: brown
: yellow/green;
N1: blue
N2: blue
L1: black
L2: brown
If the mains supply corresponds with one of the
following:
Voltage and mains frequency
400V 3 - N ~ 50/60 Hz
proceed as follows:
The cable provided is not suitable for the following
types of installation.
1. Use a suitable supply cable, H05RR-F or higher,
with the right dimensions (cable cross section: 25
mm).
2. To open the terminal board, use a screwdriver as
a lever under the side tabs of the cover (see
Terminal board picture).
3. Loosen the cable clamp screw and the terminal
board screws in accordance with the type of
GB
3
GB
connection required and position the connection
supports as shown in the following table and
diagrams.
4. Position the wires in accordance with the
information given in the following table and diagrams
and connect the appliance by tightening all the
screws for the springs as much as possible.
Voltage and
mains frequenc y
400V 3-N ~
50/60 Hz
Electrical connections Terminal board
Three-phase 4 00
5. Secure the power supply cable by fastening the
cable clamp screw, then put the cover back on.
Phase Phase Phase
2
Earth
1
Neutral
5
connection support
U-bolt
3
Three-phase 400
4
Connecting the electricity supply cable to the
mains
If the appliance is being connected directly to the
electricity mains an omnipolar switch must be
installed with a minimum opening of 3 mm between
contacts.
The installer must ensure that the correct electrical
connection has been made and that it is fully
compliant with safety regulations.
Before connecting the appliance to the power
supply, make sure that:
The appliance is earthed and the plug is
compliant with the law.
The socket can withstand the maximum power of
the appliance, which is indicated on the data
plate located on the appliance itself.
The voltage falls within the range of values
indicated on the data plate.
The socket is compatible with the plug of the
appliance. If the socket is incompatible with the
plug, ask an authorised technician to replace it.
Do not use extension cords or multiple sockets.
Once the appliance has been installed, the power
supply cable and the electrical socket must be
easily accessible.
The cable must not be bent or compressed.
The cable must be checked regularly and replaced
by authorised technicians only.
The manufactur er declines any liability should
these safety measures not be observed.
Do not remove or replace the power supply cable
for any reason. Its removal or replacement will void
the warranty and the CE marking. INDESIT does not
assume liability for accidents or damage arising
from replacement/removal of the original power
supply cable. Replacement can only be accepted
when carried out by personnel authorised by
INDESIT and using an original spare part.
4
Description of the
appliance
Control panel
The control panel described in this manual is only a representative example: it may not exactly match the panel
on your appliance.
GB
INCREASE TIME button increases the time value
set on the timer (see Start-up and use).
DECREASE TIME button decreases the time
value set on the timer (see Start-up and use).
COOKING ZONE SELECTOR button shows a
particular cooking zone has been selected and
therefore various adjustments are possible.
COOKING ZONE SELECTOR button is used to
select the desired cooking zone.
POWER indicator provides a visual display for the
current heat level.
ON/OFF button switches the appliance on and off.
ON/OFF indicator light shows whether the
appliance is on or off.
PROGRAMME TIMER button controls the cooking
programme times (see Start-up and use).
PROGRAMME TIMER display shows which
programme has been selected (see Start-up and
use).
COOKING ZONE PROGRA
show which cooking zones are being used during
a cooking programme (see Start-up and use).
CONTROL PANEL LOCK button prevents
accidental changes to the hob settings (see Start-
up and use).
CONTROL PANEL LOCK indicator light shows
the control panel has been locked (see Start-up
and use).
COOKING ZONE POWER SELECTOR buttons
switch on the hotplate and control the power (see
Start-up and use).
TIMER indicator light shows that the timer has
been activated
MMED indicator lights
5
GB
Extendable cooking zones
Certain models are fitted with extendable cooking zones. These may be circular or oval and may vary in their
extensibility (they may be double or triple hotplates). A list of controls is given below (these controls are only
present in models with the extendable cooking zone option).
Circular extendable hotplate
DOUBLE
HOTPLATE ON
indicator light
DOUBLE
HOTPLATE ON
button
DOUBLE HOTPLATE ON button switches on the
double hotplate (see Start-up and use).
DOUBLE HOTPLATE ON indicator light shows
the double hotplate has been switched on.
Oval extendable hotplate
OVAL
HOTPLATE ON
indicator light
OVAL
PLATE ON
button
OVAL HOTPLATE ON button switches on the
oval hotplate (see Start-up and use).
OVAL HOTPLATE ON indicator light shows the
oval hotplate has been switched on.
6
Start-up and use
The glue applied on the gaskets leaves traces of
grease on the glass. Before using the appliance, we
recommend you remove these with a special nonabrasive cleaning product. During the first few hours
of use there may be a smell of rubber which will
disappear very quickly.
A few seconds after the hob is connected to the
electricity supply, a buzzer will sound. The hob may
now be switched on.
If the - or + button is pressed for an extended
period of time, the display scrolls quickly though the
power levels and timer minutes.
Switching on the hob
To switch the hob on, press and hold the button
for approximately one second.
Switching on the cooking zones
Each cooking zone is controlled using a selector
button
consisting of power level selector buttons between
the values of 0 and 9.
To begin operating a cooking zone, press the
corresponding control button and set the desired
power level using the power level selector buttons
between 0 and 9.
and a power adjustment device
Switching off the cooking zones
reached. Once this level has been reached, the
display will revert to showing the set power level. To
deactivate this function, press and hold for at least
2 seconds - the selector button corresponding to the
cooking zone on which the
activated; alternatively, select a different power level
between 0 and 9 using the power level selector
buttons.
function has been
Heating elements
Two types of heating element may be installed,
depending on the appliance model: halogen and
radiant elements.
Halogen elements emit heat via radiation from the
halogen lamps they contain.
They have similar properties to gas burners: they are
easy to control and reach set temperatures quickly,
allowing you to see the power level instantly.
Radiant elements consist of a series of coils which
allow heat to be distributed evenly at the base of the
cookware, so that all slow-flame cooking may be
performed successfully, for example stews, sauces
or reheated dishes.
Programming the cooking duration
All the cooking zones may be programmed
simultaneously, for a duration between 1 and 99
minutes.
1. Select the cooking zone using the corresponding
selector button.
2. Adjust the temperature.
GB
To switch off a cooking zone, select it using the
corresponding selector button
Press power level selector button 0: this
immediately returns the power setting to 0 and the
cooking zone switches off.
and:
Power function
The power function for the cooking zones may be
used to shorten heating-up times. Activate and set
the power level for the desired cooking zone as
described in the previous paragraph. Press and hold
the selector button corresponding to the desired
cooking zone
display, the power level indicator, will alternately
show the letter P and the power level set
previously until the desired power level has been
for at least 2 seconds. The
3. Press the
4. Set the cooking duration using the
buttons.
5. Confirm by pressing the
The timer begins counting down immediately. A
buzzer sounds for approximately 1 minute and the
cooking zone switches off when the set programme
has finished.
Repeat the above procedure for each hotplate you
wish to programme.
Using multiple programmes and the display
If one or more hotplates are programmed, the
display will show the data for the hotplate with the
least time remaining, and the light corresponding to
the position of the hotplate will flash. The lights
corresponding to the other hotplates programmed
programming button.
- and +
button.
7
GB
will be switched on.
To display the time remaining for the other
programmed hotplates, press the
repeatedly. The times remaining for each hotplate
will be shown in a clockwise order, beginning with
the front left hotplate.
Changing the programme
button
Switching off the hob
Press the button to switch the appliance off.
If the control panel lock has been activated, the
controls will continue to be locked even after the hob
is switched on again. In order to switch the hob on
again, you must first remove the lock function.
Demo mode
1. Press the
you wish to change is shown.
2. Use the
3. Confirm by pressing the
To cancel a programme, follow the above
instructions. At step 2, press the
duration decreases progressively until it reaches 0
and switches off. The programme resets and the
display exits programming mode.
button repeatedly until the duration
buttons to set the new duration.
button.
- button: the
Timer
The hob must be switched on.
The timer can be used to set a duration up to 99
minutes.
1. Press the
indicator light is illuminated.
2. Set the desired duration using the
buttons.
3. Confirm by pressing the
The timer begins counting down immediately. When
the time has elapsed, a buzzer will sound (for one
minute).
programming button until the timer
- and +
button.
It is possible to set the hob to a demonstration
mode where all the controls work normally but the
heating elements do not switch on. To activate the
demo mode the hob must be switched on, with all
the hotplates switched off.
Press and hold the
simultaneously for 6 seconds. When the 6
seconds have elapsed, the ON/OFF and
CONTROLS LOCKED indicator lights will flash for
one second. Release the
press the
The display will show the text DE and MO and the
hob will be switched off.
When the hob is switched on again it will be set to
the demo mode.
To exit this mode, follow the procedure described
above. The display will show the text DE and OF
and the hob will be switched off. When it is next
switched on, the hob will function normally.
+ and - buttons
+ and - buttons and
button;
Practical advice on using the appliance
To obtain the best results from your hob:
Use pans with a thick, flat base in order to fully
utilise the cooking zone.
Control panel lock
When the hob is switched on, it is possible to lock
the oven controls in order to avoid accidental
changes being made to the settings (by children,
during cleaning, etc.). Press the
the control panel: the indicator light above the button
will switch on.
To use any of the controls (e.g. to stop cooking),
you must switch off this function. Press the
button for a few moments, the indicator light will
switch off and the lock function will be removed.
8
button to lock
Always use pans with a diameter which is large
enough to cover the hotplate fully, in order to use all
the available heat.
Make sure that the base of the cookware is
always clean and dry, in order to fully utilise and
extend the life of both the cooking zones and the
cookware.
Avoid using the same cookware which has been
used on gas burners: the heat concentration on
gas burners may distort the base of the pan,
causing it not to adhere correctly.
Safety devices
Pan sensor
Each cooking zone is equipped with a pan sensor
device. The hotplate only emits heat when a pan
with suitable measurements for the cooking zone is
placed on it. If the indicator light is flashing, it may
indicate:
An incompatible pan
A pan whose diameter is too small
The pan has been removed from the hotplate.
Residual heat indicators
Each cooking zone is equipped with a residual heat
indicator. This indicator signals which cooking zones
are still at a high temperature. If the power display
shows
possible, for example, to keep a dish warm or melt
butter or chocolate. As the cooking zone cools, the
power display will show
when the cooking zone has cooled sufficiently.
Overheating protection
If the electronic elements overheat, the hob switches
off automatically and
followed by a flashing number. When the
temperature has reached a suitable level, this
message disappears and the hob may be used
again.
, the cooking zone is still hot. It is
. The display switches off
F appears on the display,
Safety switch
The appliance has a safety switch which
automatically switches the cooking zones off after
they have been in operation for a certain amount of
time at a particular power level. When the safety
switch has been triggered, the display shows 0.
For example: the right rear hotplate is set to 5 and
will switch off after 5 hours of continuous operation,
while the front left hotplate is set to 2 and will switch
off after 8 hours.
Power level
1 9
28
37
46
55
64
73
82
9 1
Buzzer
This can also indicate several irregularities:
An object (a pan, cutlery, etc.) has been placed
on the control panel for more than 10 seconds.
Something has been spilt on the control panel.
A button has been pressed for too long. All of the
above situations may cause the buzzer to sound.
Remove the cause of the malfunction to stop the
buzzer. If the cause of the problem is not
removed, the buzzer will keep sounding and the
hob will switch off.
Maximum operating
time in hours
GB
9
GB
Practical cooking advice
ª
Pressure cooking
cooking
Very high-flame
cooking
High-flame
¶
¶
§
§
Pressure cooker
Grilling Boiling
Crêpes Cooking on a high flame and browning
Fast thickening (liquid juices)
Boiling water (pasta, rice, vegetables)
Milk
Slow thickening (dense juices)
Frying
(roasts, steaks, escalopes, fish fillets,
fried eggs)
S
Medium-flame cooking
S
Bain-marie cooking Pressure cooking after whistle
¢
cooking
Low-flame
flame
cooking
Very low-
¢
£
Low-flame cooking
(stews)
Chocolate sauce Keeping food hot
¡
-{}Reheating dishes
10
Precautions and tips
This appliance has been designed and
manufactured in compliance with international safety
standards. The following warnings are provided for
safety reasons and must be read carefully.
This appliance conforms to the following
European Economic Community directives:
- 2006/95/EEC dated 12/12/06 (Low Voltage) and
subsequent amendments;
-89/336/EEC dated 03/05/89 (Electromagnetic
Compatibility) and subsequent amendments;
- 93/68/EEC dated 22/07/93 and subsequent
amendments.
General safety
Make sure that the air inlet behind the fan grille is
never obstructed. The built-in hob should, in fact, be
provided with suitable ventilation for the cooling of
the electronic components used in the appliance.
The appliance was designed for domestic use
inside the home and is not intended for
commercial or industrial use.
The appliance must not be installed outdoors,
even in covered areas. It is extremely dangerous
to leave the appliance exposed to rain and
storms.
Do not touch the appliance when barefoot or with
wet or damp hands and feet.
The appliance must be used by adults only for the
preparation of food, in accordance with the
instructions provided in this booklet. Do not use
the hob as a worktop or chopping board.
The glass ceramic hob is resistant to mechanical
shocks, but it may crack (or even break) if hit with
a sharp object such as a tool. If this happens,
disconnect the appliance from the electricity
mains immediately and contact a Service Centre.
Ensure that power supply cables of other
electrical appliances do not come into contact
with the hot parts of the hob.
Remember that the cooking zones remain
relatively hot for at least thirty minutes after they
have been switched off. An indicator light
provides a warning when residual heat is present
(see Start-up and use).
Keep any object which could melt away from the
hob, for example plastic and aluminium objects,
or products with a high sugar content. Be
especially careful when using plastic film and
aluminium foil or packaging: if placed on surfaces
which are still hot, they may cause serious
damage to the hob.
Always make sure that pan handles are turned
towards the centre of the hob in order to avoid
accidental burns.
When unplugging the appliance, always pull the
plug from the mains socket; do not pull on the
cable.
Never perform any cleaning or maintenance work
without having disconnected the appliance from
the electricity mains.
The appliance should not be operated by people
(including children) with reduced physical,
sensory or mental capacities, by inexperienced
individuals or by anyone who is not familiar with
the product. These individuals should, at the very
least, be supervised by someone who assumes
responsibility for their safety or receive
preliminary instructions relating to the operation of
the appliance.
Do not look at the halogen lamps in the cooking
zones for long if they are present.
Do not let children play with the appliance.
Disposal
When disposing of packaging material: observe
local legislation so that the packaging may be
reused.
The European Directive 2002/96/EC relating to
Waste Electrical and Electronic Equipment
(WEEE) states that household appliances should
not be disposed of using the normal solid urban
waste cycle. Exhausted appliances should be
collected separately in order to optimise the cost
of re-using and recycling the materials inside the
machine, while preventing potential damage to
the atmosphere and to public health. The
crossed-out dustbin is marked on all products to
remind the owner of their obligations regarding
separated waste collection.
For further information relating to the correct
disposal of exhausted household appliances,
owners may contact the public service provided
or their local dealer.
GB
11
Care and maintenance
GB
Switching the appliance off
Disconnect your appliance from the electricity
supply before carrying out any work on it.
Cleaning the appliance
Do not use abrasive or corrosive detergents (for
example, products in spray cans for cleaning
barbecues and ovens), stain removers, anti-rust
products, powder detergents or sponges with
abrasive surfaces: these may scratch the surface
beyond repair.
Never use steam cleaners or pressure cleaners on
the appliance.
It is usually sufficient simply to wash the hob
using a damp sponge and dry it with absorbent
kitchen towel.
If the hob is particularly dirty, rub it with a special
glass ceramic cleaning product, then rinse well
and dry thoroughly.
To remove more stubborn dirt, use a suitable
scraper. Remove spills as soon as possible,
without waiting for the appliance to cool, to avoid
residues forming crusty deposits. You can
achieve excellent results by using a rust-proof
steel wire sponge - specifically designed for
glass ceramic surfaces - soaked in soapy water.
Stainless steel frame (only in models with outer
frame)
Stainless steel can be marked by hard water which
has been left on the surface for a long time, or by
cleaning products containing phosphorus.
After cleaning, it is advisable to rinse the surface
well and dry it thoroughly. If water is spilt on the
surface, dry it quickly and thoroughly.
Some hobs have an aluminium frame which is
similar to stainless steel. Do not use any cleaning or
degreasing products which are not suitable for use
with aluminium.
Disassembling the hob
If it is necessary to disassemble the hob:
1. Loosen the screws fixing the alignment springs on
each side.
2. Loosen the screws holding the fixing hooks in
each corner.
3. Take the hob out of its installation cavity.
Do not attempt to repair the appliance yourself. If
the appliance breaks down, contact a Service
Centre.
If any plastic or sugary substances are
accidentally melted on the hob, remove them
immediately with the scraper, while the surface is
still hot.
Once it is clean, the hob may be treated with a
special protective maintenance product: the
invisible film left by this product protects the
surface from drips during cooking. This
maintenance task should be carried out while the
appliance is warm (not hot) or cold.
Always remember to rinse the appliance well with
clean water and dry it thoroughly: residues can
become encrusted during subsequent cooking
processes.
12
Technical description of
the models
This table provides a model-by-model list of the energy absorption values, type of heating elements and
diameters of each cooking zone.
Hobs
Cooking zone
Back Left
Back Right
Front Left
Front Right
Total power
Key:
H = single hilight
HO = oval hilight
HD = double hilight
Power (W)
HD 2200/1000 210/140 HD 2200/1000 210/140
H 1400 160 H 1200 145
H 1200 145 H 1200 145
HD 1700/700 180/120 HO 2400/1500 170x260
CRO 642 D B CRO 742 DO B
Diameter (mm)
6500 7000
Power (W)
Diameter (mm)
GB
13
GB
After Sales Service
"No company is better positioned to offer an after sales service on a
Hotpoint appliance than us - the manufacturer"
As part of our commitment to you, all Hotpoint appliances have the added benefit of a fully inclusive parts and
labour guarantee for the first 12 months. In addition to this you also have the advantage of free
replacement parts for the first 5 years when fitted by a Hotpoint
engineer. When the 12 months parts and labour guarantee expires we offer the following after sales service
options:
Repair Service and Information Help Desk
UK: 08709 066066
www.theservicecentre.co.uk
Republic of Ireland: 1850 302 200
Note: Our operators will require the Model number and the Serial number of your appliance
Available 364 days a year with a fast, effective and value for money service. We have the largest white goods
repair service in the UK with over 1200 of our own fully trained engineers. All repairs include a parts and labour
guarantee for 12 months from the date of the repair.
If you require any information or have any questions about your appliance, our operators are on hand with help
and advice.
All this ensures that you will receive the best available after sales service possible.
Extended Warranties
UK: 08709 088 088
www.theservicecentre.co.uk
Republic of Ireland: 1850 502 200
Whether you have just one or a number of Hotpoint appliances in your kitchen, we offer two service cover plans
to give you total peace of mind.
● Repair Protection Plan - FREE service repairs for a single Hotpoint appliance during the period
of cover.
● Kitchen Cover - FREE service repairs for all your Hotpoint appliances less than 8
years old.
Genuine Parts and AccessoriesUK: 08709 077 077
www.theservicecentre.co.uk
Republic of Ireland: (01) 842 6836
A wide range of genuine parts and accessories are available from our hotline or through our web site.
Genuine parts and accessories, extended warranties and service repairs are all
available on our web-site at:
14
www.theservicecentre.co.uk
Guarantee
"Satisfaction guaranteed or your money back"
We give you a unique 'satisfaction guaranteed' promise - valid for 90 days - after you have
purchased your Hotpoint appliance. If there is a technical problem simply call Hotpoint Repair
service or visit our web-site at
an engineer to call. If the technical problem is not resolved under this guarantee, we will replace
your machine or, if you prefer, give you your money back.
www.theservicecentre.co.uk and where necessary, we will arrange for
GB
All Hotpoint appliances carry a fully inclusive 12 month parts and labour guarantee as
replacement parts for the first 5 years (except microwaves, selected integrated appliances and
cooker hoods, which have a one year guarantee) provided that they are fitted by a Hotpoint engineer.
Guarantee terms and conditions
Your guarantee is only applicable in the United Kingdom or Republic of Ireland and is subject
following provisions that your appliance:
● Has been installed and used correctly in accordance with this instruction booklet.
● Has been used solely for domestic purposes and is located on domestic premises (ie. not for
commercial or trade use).
● Has been properly connected to a suitable electrical supply voltage as stated
rating plate.
● Has not been subject to misuse, accident, modified or repaired by anyone other than one of our
own service engineers.
For pre purchase information on any other Hotpoint product call: 08701 50 60 70
or visit: www.hotpoint.co.uk
well as free
to the
on the appliance
Recycling & Disposal Information
As part of Hotpoint's continued commitment to helping the environment, Hotpoint reserves the right to
use quality recycled components to keep down customer costs and minimise material wastage.
Please dispose of packaging and old appliances carefully.
To minimise risk of injury to children, remove the door, plug and cut mains cable
appliance. Dispose of these parts separately to ensure that the appliance can no longer be plugged
into a mains socket, and the door cannot be locked shut.
off flush with the
15
GB
04/2008 - 195069881.00
XEROX BUSINESS SERVICES
Key Contacts
After Sales Service
Over 1200 trained specialists, directly employed by us, ensure that you can have complete
confidence in both the appliances and services we offer.
Repair Service and Information Desk
UK: 08709 066 066
(Open 8 to 8 Mon - Fri, 8 to 6 Sat, 10 to 4 Sun & Bank Holidays)
www.theservicecentre.co.uk
Republic of Ireland: 1850 302 200
Note: Our operators will require the following information:
Model number:
Serial number:
Extended Warranties
UK: 08709 088 088
(Open 8 to 8 Mon - Sun)
www.theservicecentre.co.uk
Republic of Ireland: 1850 502 200
Genuine Parts and Accessories
UK: 08709 077 077
(Open 8-30 to 5-30 Mon - Fri & 9 to 12 Sat)
www.theservicecentre.co.uk
Republic of Ireland: (01) 842 6836
16
Indesit Company UK Ltd. Morley Way, Peterborough, PE2 9JB.
Loading...
