F-800MAF-C
Parts List
49 pgs900.81 Kb0

Hoshizaki F-800MAF-C Parts List

NO.
ISSUED:
71139
DEC. 9, 1998
REVISED:
SEPT. 10, 2002
HOSHIZAKI
MODULAR FLAKER
MODEL
(FINAL) PARTS LIST
HA
F-800MAF H-0 APRIL 1998
J-0 DEC. 1998 K-0 DEC. 1999 K-1 SEPT. 2000 L-0 DEC. 2000
F-800MAF-C H-0 SEPT. 1998
J-0 SEPT. 1999 K-1 DEC. 1999 K-2 SEPT. 2000 L-0 JAN. 2001
F-800MWF H-0 APR. 1998
J-0 FEB. 1999 K-1 DEC. 1999 K-2 SEPT. 2000 L-0 DEC. 2000
F-800MWF-C H-0 SEP. 1998
J-0 FEB. 1999 K-0 DEC. 1999 K-1 SEPT 2000
2
HA
MATERIAL ABBREVIATIONS
ALUMINUM AL = Aluminum
COPPER CU = Copper
PLASTIC
ABS = Acrylonitritrile -butadiene - styrene AC = Polyacetal EVA = Ethylene vinyl acetate PA = Polyamide = Nylon PC = Polycarbonate PE = Polyethylene PES = Polyester PETP = Polyethylene terephthalate = Tetlon PP = Polypropylene PS = Polystyrene PTFE = Polytetrafluoroethylene = Teflon PUR = Polyurethane PVC = Polyvinyl chloride
RUBBER
VN = Vinyl Nitrile EPDM = EP rubber NBR = Nitrile butadiene rubber NR = Natural rubber NP = Neoprene SI.R = Silicone rubber SY.R = Synthetic rubber EPH = Epichlorohydrin
STEEL
GS = Galvanized steel SS = Stainless steel PS = Plated steel PAS = Primed steel
AUXILIARY CODE
Ex.1 K-0
Parts are the same as in the preceding (Note) - = Part deleted.
year.
"K" is the tenth in alphabetical order with "I" by "o" (interchangeable) skipped. So, "K" indicates "2000". part.
x = Part deleted and replaced
Ex.2 L-0 o = New part for "x" in the
"L" is the next in alphabetical same auxiliary code. order. So, "L" indicates "2001".
Ex.3 L-1
Each time a part is changed non-interchangeably in a year, this number advances.
3
HA
F-800MAF(-C) A. ICE FLAKER ASSEMBLY H0, J-0, K-0, K-1, K-2, L-0
4
HA
F-800MAF
MODEL
INDEX
NO.
B ICE MAKING UNIT - 3A0962A03 1 1 x1
- 3A0962A01 o1
B1 SOCKET HEAD HEX BOLT 8X95, SS 7S12-0895 3 3 3 3
B2 SPRING WASHER 8, SS 7L22-0800 3 3 3 3
C REFRIGERATION UNIT - 2A1000A01 1 x1
- 2A1000A02 o1 1
D WATER CIRCUIT - 2A0968A01 1
E CONTROL BOX ASSEMBLY - 2A1045A03 1 x1
2A1045A05 o1 1
E1 TRUSS HEAD SCREW 4X8 7C31-0408 3
F CHUTE ASSEMBLY - 2A0941A02 1
- 2A1705A02
G LABEL LOCATION - 2A1038A01 1 x1
- 2A1038A05 o1 1
DESCRIPTION
:
MATERIAL OR MODEL NUMBER
TITLE
A. ICE FLAKER ASSEMBLY
:
PART
NUMBER
REQUIRED NUMBER
H-0
J-0
K-0 K-1 L-0
1
1
1 1 1
1
3 3 3
-
1 1 1
1
5
HA
F-800MAF-C
MODEL
INDEX
NO.
B ICE MAKING UNIT - 3A0962A04 1 1 x1
- 3A0962A02 o1
B1 SOCKET HEAD HEX BOLT 8X95, SS 7S12-0895 3 3 3 3
B2 SPRING WASHER 8, SS 7L22-0800 3 3 3 3
C REFRIGERATION UNIT - 2A1000A01 1 x1
- 2A1000A02 o1 1
D WATER CIRCUIT - 2A0968A01 1
E CONTROL BOX ASSEMBLY - 2A1045A03 x1
- 2A1045A05 o1 1
E1 TRUSS HEAD SCREW 4X8 7C31-0408 3
F CHUTE ASSEMBLY - 2A0941A02 1
- 2A1705A02
G LABEL LOCATION - 2A1038A01 x1
- 2A1038A05 o1 1
:
DESCRIPTION
TITLE
MATERIAL OR MODEL NUMBER
A. ICE FLAKER ASSEMBLY
:
PART
NUMBER
REQUIRED NUMBER
H-0
K-1 K-2 L-0
J-0
1
1
1 1 1
1 1
3 3 3
-
1 1 1
1 1
6
HA
F-800MAF(- C )
MODEL
INDEX
NO.
1 CHASSIS GS 2A1176G01 1 1 1 1 1
2 REAR PANEL GS 2A0322G02 1 1 1 1 1
2A T2 SCREW 4X8 7P31-0408 4 4 4 4 4
3 JUNCTION BOX COVER GS 433410-01 1 1 1 1 1
3A T2 SCREW 4X8 7P31-0408 1 1 1 1 1
4 SIDE FRAME (R) GS 2A1047G01 1 1 1 1 1
4A TRUSS HEAD SCREW 4X8 7C31-0408 2 2 2 2 2
5 FRONT FRAME GS 3A0324G01 1 1 1 1 1
5A TRUSS HEAD SCREW 4X8 7C31-0408 2 2 2 2 2
6 RESERVOIR BRACKET GS 2A1060-01 1 1 1 1 1
6A T2 SCREW 4X8 7P31-0408 4 4 4 4 4
7 BRACKET – GEAR MOTOR GS 3A0396G01 1 1 1 1 1
7A HEX BOLT 8X12, SS 7B02-0812 2 2 2 2 2
8 DRAIN PAN ABS 323765G02 1 1 1 1 1
9 STRAP GS 4A1474-01 1 1 1 1 1
9A T3 SCREW 5X12 7G31-0512 2 2 2 2 2
10 RING PA 432661-02 1 1 1 1 1
11 “O” RING G70 7616-G070 1 1 1 1 1
12 PACKING-SPOUT EPDM 321037-01 1 1 1 1 1
13 SPOUT PC 104797-01 1 1 1 1 1
14 THUMBSCREW SS, ABS 415949G04 3 3 3 3 3
15 STRAP SS 321038G02 1 1 1 1 1
16 STRAP SS 328703-02 1 1 1 1 1
16A WING NUT 6, SS 7E12-0600 2 2 2 2 2
17 BUSHING SB-1500-21 420470-09 1 1 1 1 1
18 BUSHING SB-1500-21 420470-06 3 3 3 3 3
19 CLAMP WS75-75-C 4A0337-12 3 3 3 3 3
20 BUSHING SR-30-1 420472-03 2 2 2 2 2
21 WIRE SADDLE LWS-2NS 4A0338-02 5 5 5 5 5
22 WIRE SADDLE LWS-4NS 4A0338-04 4 4 4 4 4
:
DESCRIPTION
TITLE
MATERIAL OR MODEL NUMBER
A. ICE FLAK ER ASS E MBLY
:
PART
NUMBER
REQUIRED NUMBER
H-0
K-0 K-1 K-2 L-0
J-0
7
HA
F-800MAF(-C)
MODEL
INDEX
NO.
23 BARRIER GS 4A0688-01 1 1 1 1 1
23A TRUSS HEAD SCREW 4X8 7C31-0408 2 2 2 2 2
24 SCREW-GROUNDING BRASS 433304-02 1 1 1 1 1
25 SQUARE WASHER BRASS 433537-02 1 1 1 1 1
25A TRUSS HEAD SCREW 4X8 7C31-0408 1 1 1 1 1
26 SIDE PANEL (RIGHT) SS 2A0324G01 1 1 1 1 1
26A TRUSS HEAD SCREW 4X8, SS 7C32-0408 1 1 1 1 1
27 SIDE PANEL (LEFT) SS 2A1014G01 1 1 1 1 1
27A TRUSS HEAD SCREW 4X8, SS 7C32-0408 1 1 1 1 1
28 TOP PANEL SS 2A1051-02 1 1 1 1 1
29 FRONT PANEL SS 3A0325G01 1 1 1 1 1
30 LOUVER (B) PP 103121-03 1 1 1 1 1
31 AIR FILTER (B) - 208283G03 1 1 1 1 1
32 TAPPING SCREW – BLACK - 433954-01 1 1 1 1 1
33 CABLE TIE CV-150 7920-0003 1 1 1 1 1
34 BRACKET-CHUTE SS 4A1712-01 1 1 1 1 1
35 BARRIER – GEAR MOTOR GS 3A1037-01 1 1 1 1 -
GS 3A1823-01 1
35A FT SCREW 4X8 7F31-0408 2 2 2 2 2
:
DESCRIPTION
TITLE
MATERIAL OR MODEL NUMBER
A. ICE FLAKER ASSEMBLY
:
PART
NUMBER
REQUIRED NUMBER
H-0
K-0 K-1 K-2 L-0
J-0
8
HA
F-800MWF(-C) A. ICE FLAKER ASSEMBLY H-0, J-0, K-0, K-1, K-2, L-0
9
HA
MODEL
INDEX
NO.
B ICE MAKING UNIT - 3A0962A03 1 1 x1
- 3A0962A01 o1
B1 SOCKET HEAD HEX BOLT 8X95, SS 7S12-0895 3 3 3
B2 SPRING WASHER 8, SS 7L22-0800 3 3 3
C REFRIGERATION UNIT - 2A1024A01 1 x1
- 2A1024A02 o1 1
D WATER CIRCUIT - 2A0968A01 1
E CONTROL BOX ASSEMBLY - 2A1045A04 1 x1
- 2A1045A06 o1 1
E1 TRUSS HEAD SCREW 4X8 7C31-0408 3
F CHUTE ASSEMBLY - 2A0941A02 1
- 2A1705A02
G LABEL LOCATION - 2A1038A02 1 x1
-
DESCRIPTION
: F-800MWF
: A. ICE FLAKER ASSEMBLY
TITLE
MATERIAL OR MODEL NUMBER
PART
NUMBER
2A1038A06
REQUIRED NUMBER
H-0
K-1 K-2 L-0
J-0
1 1 1
3 3 3
-
1 1 1
o1 1
1
3
3
1
1
1
10
HA
MODEL
INDEX
NO.
B ICE MAKING UNIT - 3A0962A04 1 1 x1
- 3A0962A02 o1
B1 SOCKET HEAD HEX BOLT 8X95, SS 7S12-0895 3 3 3
B2 SPRING WASHER 8, SS 7L22-0800 3 3 3
C REFRIGERATION UNIT - 2A1024A01 1 x1
- 2A1024A02 o1 1
D WATER CIRCUIT - 2A0968A01 1
E CONTROL BOX ASSEMBLY - 2A1045A04 1 x1
- 2A1045A06 o1 1
E1 TRUSS HEAD SCREW 4X8 7C31-0408 3
F CHUTE ASSEMBLY - 2A0941A02 1
- 2A1705A02
G LABEL LOCATION - 2A1038A04 1 x1
-
: F-800MWF-C
DESCRIPTION
MATERIAL OR MODEL NUMBER
: A. ICE FLAKER ASSEMBL Y
TITLE
PART
NUMBER
2A1038A08
REQUIRED NUMBER
H-0
K-0 K-1
J-0
1 1
3 3
-
1 1
o1 1
11
HA
MODEL
INDEX
NO.
1 CHASSIS GS 2A1176G01 1 1 1 1 1
2 REAR PANEL GS 2A1012G01 1 1 1 1 1
2A T2 SCREW 4X8 7P31-0408 4 4 4 4 4
3 JUNCTION BOX COVER GS 433410-01 1 1 1 1 1
3A T2 SCREW 4X8 7P31-0408 1 1 1 1 1
4 SIDE FRAME (R) GS 2A1047G01 1 1 1 1 1
4A TRUSS HEAD SCREW 4X8 7C31-0408 2 2 2 2 2
5 FRONT FRAME GS 3A0324G01 1 1 1 1 1
5A TRUSS HEAD SCREW 4X8 7C31-0408 2 2 2 2 2
6 RESERVOIR BRACKET GS 2A1059-01 1 1 1 1 1
6A T2 SCREW 4X8 7P31-0408 4 4 4 4 4
7 BRACKET – GEAR MOTOR GS 3A0396G01 1 1 1 1 1
7A HEX BOLT 8X12, SS 7B02-0812 2 2 2 2 2
8 DRAIN PAN ABS 323765G02 1 1 1 1 1
9 STRAP GS 4A1474-01 1 1 1 1 1
9A T3 SCREW 5X12 7G31-0512 2 2 2 2 2
10 RING PA 432661-02 1 1 1 1 1
11 “O” RING G70 7616-G070 1 1 1 1 1
12 PACKING-SPOUT EPDM 321037-01 1 1 1 1 1
13 SPOUT PC 104797-01 1 1 1 1 1
14 THUMBSCREW SS, ABS 415949G04 3 3 3 3 3
15 STRAP SS 321038G02 1 1 1 1 1
16 STRAP SS 328703-02 1 1 1 1 1
16A WING NUT 6, SS 7E12-0600 2 2 2 2 2
17 BUSHING SB-1500-21 420470-06 3 3 3 3 3
18 CLAMP WS75-75-C 4A0337-12 3 3 3 3 3
19 BUSHING SR-30-1 420472-03 2 2 2 2 2
20 WIRE SADDLE LWS-2NS 4A0338-02 5 5 5 5 5
21 WIRE SADDLE LWS-4NS 4A0338-04 4 4 4 4 4
22 BARRIER GS 4A0688-01 1 1 1 1 1
: F-800MWF(-C)
DESCRIPTION
MATERIAL OR MODEL NUMBER
: A. ICE FLAKER ASSEMBLY
TITLE
PART
NUMBER
REQUIRED NUMBER
H-0
K-0 K-1 K-2 L-0
J-0
12
HA
MODEL: F-800MWF(-C) TITLE: A. IC E FLAKER ASSEMBL Y
INDEX
NO.
23 SCREW-GROUNDING BRASS 433304-02 1 1 1 1 1
24 SQUARE WASHER BRASS 433537-02 1 1 1 1 1
24A TRUSS HEAD SCREW 4X8 7C31-0408 1 1 1 1 1
25 SIDE PANEL (RIGHT) SS 2A0324G01 1 1 1 1 1
25A TRUSS HEAD SCREW 4X8, SS 7C32-0408 1 1 1 1 1
26 SIDE PANEL (LEFT) SS 2A1014G01 1 1 1 1 1
26A TRUSS HEAD SCREW 4X8, SS 7C32-0408 1 1 1 1 1
27 TOP PANEL SS 2A1051-02 1 1 1 1 1
28 FRONT PANEL SS 3A0325G01 1 1 1 1 1
29 LOUVER (B) PP 103121-03 1 1 1 1 1
30 TAPPING SCREW - BLACK STEEL, 4X8 433954-01 1 1 1 1 1
31 BRACKET-CHUTE SS 4A1712-01 1 1 1 1 1
32 BARRIER – GEAR MOTOR GS 3A1039-01 1 1 1 1 -
GS 3A1823-01 1
DESCRIPTION
MATERIAL OR MODEL NUMBER
PART
NUMBER
REQUIRED NUMBER
H-0
J-0
K-0 K-1 K-2 L-0
13
HA
F-800MAF B. ICE MAKING UNIT H-0, J-0, K-0
14
HA F-800MAF B. ICE MAKING UNIT K-1, L-0
15
