Instruction Book

HNL 9166

Washing Machine

40002057Eng.qxd 04/11/2004 16:21 Page 1

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Delivery information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Do’s . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Don’ts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Unpacking the Product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Choose a location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Electricity supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Water supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Connecting to the cold water supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Connection of the machine to the drain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Moving the machine into position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Adjusting the feet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Testing the installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Washing advice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Loading your washing machine. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Sorting the laundry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

The Dispenser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Detergent dosage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Dispensing instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Using Inter@ct 3D for the first time. . . . . . . . . . . . . . . . . . . . 17

The Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Wash Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Automatic Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Programme Selector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Special Programmes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Daily Programmes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Programme Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

A Typical Wash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Selecting the wash programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Starting the wash cycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Cleaning and Routine Maintenance. . . . . . . . . . . . . . . . . . . . 35

Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Power Failure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

English . . . . . . . . . . . . . . . . . . 2

Dansk. . . . . . . . . . . . . . . . . . 40

Svenska . . . . . . . . . . . . . . . . 78

Norsk . . . . . . . . . . . . . . . . . 116

Suomi. . . . . . . . . . . . . . . . . 154

40002057Eng.qxd 04/11/2004 16:21 Page 2

Introduction

Please read and follow these instructions carefully and operate the machine accordingly. This booklet provides important guidelines for safe use, installation, maintenance and some useful advice for best results when using your machine.

Keep all documentation in a safe place for future reference or for any future owners.

Delivery information

Please check that the following items are delivered with the appliance:

● Instruction manual

● Guarantee card

● Blanking plug

● Inlet hose & hooked end support

(see Unpacking and Installation Instructions)

● Base panel & x2 push clips

● Energy Label

Do’s

● All packaging materials used are environmentally-friendly and recyclable. Please help dispose of the packaging via environmentally-friendly means. Your local council will be able to give you details of current means of disposal.

● To ensure safety when disposing of an old washing machine disconnect the mains plug from the socket, cut the mains power cable and destroy this together with the plug. To prevent children shutting themselves in the machine break the door hinges or the door lock.

● This machine is solely for domestic use, i.e. to wash, rinse and spin dry household textiles and garments.

Check that no

damage has

occurred to the

machine during

transit. If it has,

call for service

by GIAS.

40002057Eng.qxd 04/11/2004 16:21 Page 3

Don’ts

● Do not touch the appliance when hands or feet are damp or wet.

● Do not lean on the door when loading the machine or use the door to lift or move the machine.

● Do not use adapters, multiple connectors and/or extensions.

● Do not allow children to play with the machine or its controls.

● Do not try to open the door when water is visible in the drum, when the wash programme is in progress or when the DOOR LOCKED (LUCKAN ÄR LÅST) message appears on the display.

Failure to

comply with

the above can

compromise the

safety of the

appliance. You may be charged for a service call

if a problem

with your

machine is

caused by

misuse.

If the appliance

is not running

properly or

breaks down,

switch it off,

disconnect the

plug from the

socket, turn off

the water

supply and do

not tamper

with the

appliance.

Consult GIAS

Service for

possible repair.

40002057Eng.qxd 04/11/2004 16:21 Page 4

Unpacking the product

Remove the machine from its packaging close to the final location of the machine.

1. Cut carefully around the base of the packaging.

2. Lay the machine on its back and remove the base and the two polystyrene spacers on each side of the machine. We recommend that a second person assist in the lifting and manoeuvring of the machine.

3. Return the machine to the upright position, remove the remainder of the packaging and the central screw in the transit bar.

4. Remove the four retaining screws in the transit bar and pull out the transit bracket.

Dispose of the packaging safely.

Make sure it is out of the reach

of children, it is a potential

source of danger.

40002057Eng.qxd 04/11/2004 16:21 Page 5

5. Take the base panel provided and fit the two self adhesive strips by removing the backing paper on one side and locating the strips on each side of the base panel.

6. Tilt the machine forward and locate the base panel under the front of the machine. Remove the remaining backing paper from the self-adhesive strips and offer up the base panel to the bottom of the cabinet.

7. Take the two plastic fixing clips and fix the base panel to the base of the machine. Bring the machine back to the upright position.

We recommend you keep the transit bracket and

screws to protect the machine for future transit.

The manufacturers will not be responsible for any

damage to the machine caused by not following the

instructions relating to releasing the transit protection.

The user is responsible for all installation costs.

40002057Eng.qxd 04/11/2004 16:21 Page 6

8. Cover the central hole in the rear of the machine with the cap enclosed in the instruction bag.

Choose a location

● After the machine has been installed, ensure that the mains plug and water supply valves are easily accessible.

● Make sure there is enough space for the machine. Select a space at least 600mm wide and 850mm high. Also leave enough space to open the door fully so you can load and unload it easily.

● Keep the area underneath and around the machine free of combustible materials such as lint, paper, rags, chemicals etc.

Installation

Do not plug the

machine in and

switch it on at the mains until the installation

is completed.

40002057Eng.qxd 04/11/2004 16:21 Page 7

Electricity supply

Washing machines are supplied to operate at a voltage of 230V, 50 Hz single phase. Check that the supply circuit is rated to at least 10A.

Electricity can be extremely dangerous. This washing machine must be earthed. The socket outlet and the plug on the appliance

must be of the same type. Do not use multiple adapters and/or extension

leads.

The wires in the mains lead are coloured in accordance with the following codes:

Blue NEUTRAL Brown LIVE Green and Yellow EARTH

CE Appliance complies with European Directive 89/336/EEC, 73/23/EEC and subsequent amendments.

Water supply

● The cold water pressure should be between

0.05-0.8 Mpa.

● Do not connect the machine to a single outlet instantaneous water heater.

● The water supply tap should be accessible when the machine is installed.

● Before connecting the fill hose, check that the water is running from the water supply tap to be used.

You may be

charged for a

service call if a

problem with

your machine is

caused by

incorrect

installation.

If the mains cord on this appliance is damaged, it

must be

replaced by a

special cord

which is ONLY

obtainable from

the GIAS spares

service. It must

be installed by

a competent

person.

40002057Eng.qxd 04/11/2004 16:21 Page 8

Connecting to the cold water supply

This machine has an inlet hose with a 19mm (3/4") threaded ferrule fitted to the end, to attach between the threaded connector on the appliance and the water supply.

Only use the new hose supplied to connect the machine and ensure that the sealing washers are in place inside the hose connectors.

Do not re-use old hoses which are attached to existing installations.

Do not over-tighten the connections. Hand tight is sufficient.

Do not trap or kink the hose.

1. Connect the elbow end of the hose provided

to the threaded inlet on the back of the machine.

Grey pipe to the white threaded inlet on the machine.

2. Hand tighten the connector.

3. Connect the straight ends of the pipes to the water supply; ensure that there are no kinks.

4. Turn on the water supply and check for leaks. If there is a leak, turn off the water

supply, disconnect the hose and check the sealing washers are in place. Refit the hose and turn on the water supply.

Aqua-stop

Certain models will be supplied with a special hose that has a double skin and incorporates a water valve (A). If the inner hose bursts the valve will automatically shut off the water supply to prevent flooding. The indicator turns red (B). Should this happen, turn off the water supply immediately and obtain a replacement hose from GIAS Service.

The installation is the same as a conventional hose with the valve end of the aqua-stop hose fitted to the water supply.

40002057Eng.qxd 04/11/2004 16:22 Page 9

Connection of the machine to the drain

This machine must be connected in accordance with the water supply regulations. Water byelaws prohibit connection to a surface water drain.

Decide which plumbing option suits you best then follow the instructions below.

Option 1 Waste pipe connection (waste trap)

Fit the hooked end support to the outlet pipe. Position at least 800mm off the floor.

After removing the blanking plug or cutting the membrane from the waste system securely fix the outlet pipe to the drainage system, using a hose clip.

Secure the hooked end support up to at least 800mm to avoid water being drawn back into the machine.

All machines are tested with water prior to leaving the

factory so a small amount of water may remain in the

drum and drain hose.

Flooding could occur if any part of the installation is

not completed correctly.

800 mm

hose clip

hooked end support

sink

flexible

discharge hose

trap with hose

adaptor

40002057Eng.qxd 04/11/2004 16:22 Page 10

Option 2 Into a standpipe

Ensure that the standpipe is not located near an electrical socket.

Fit the hooked end support to the outlet pipe. Install the hose into the standpipe ensuring that the pipe is at least 500mm from the floor.

Insert the outlet pipe approximately 100mm into the standpipe.

Moving the machine into position

Your machine is heavy so care must be taken when moving it. We recommend that two people move the machine to avoid strain and possible injury.

● Take care not to damage flooring when moving the machine.

● When moving the machine to its final position take care not to kink or damage the hose at the back of the machine.

Adjusting the feet

Once the machine is in place the feet should be adjusted to ensure that the machine is level. If the machine is not level it may become noisy or move.

Adjust the feet on the front corners of the machine until the machine is firm and level.

When the machine is firm and level, tighten the locking nuts on the two feet.

Do not drag or

lift the machine

by its door.

100 mm

500 mm min

40002057Eng.qxd 04/11/2004 16:22 Page 11

Refer to ‘Selecting the wash programme’ for details of how to select programmes.

1. Turn on the water supply and check for leaks from the fill hose.

2. Switch on the electricity supply.

3. Select the spin programme and then

press the button to start the machine. Allow the programme to continue for one minute and then cancel the programme by returning the selector to the OFF position. This will remove any water remaining in the machine from factory testing.

4. To check for cold water filling to the machine:

Select the rinse programme and press the button to start the machine.

Allow the tumble action to continue until the water has pumped out. Check that the drain outlet is not leaking or overflowing.

5. Switch off the machine at the end of the cycle by turning the programme knob to the OFF position.

6. Select the spin programme and press the button to start the machine. If the machine takes longer than one minute to empty check the drain hose for kinks.

Installation testing is now complete.

Now you have successfully installed the machine we advise that you run the machine to ensure the drum is thoroughly clean after testing and storage. Select 90 and run the machine for a complete cycle using only wash detergent and water.

Testing the installation

This

programme

will take

approximately

2 hours to

complete.

40002057Eng.qxd 04/11/2004 16:22 Page 12

The following tips are designed to assist in getting the best results from your machine whilst using it in the most environmentally-friendly and economical way. It is also important to understand the items to avoid in your laundry, to ensure the continued safe and reliable operation of your machine.

Loading your washing machine

To make further reductions of energy, water and detergent consumption, we recommend that you put a full load into your machine. Energy savings of up to 50% can be achieved by washing one full load compared to two half loads.

Do not overload the machine as this will reduce the quality of the wash and may cause damage to the machine and your laundry.

When is prewashing really needed?

Only with particularly dirty loads! Energy savings of 5 to 15% are made by not selecting the prewash option for less dirty laundry. Pre-treat awkward stains with a washable stain remover.

Which wash temperature should you choose?

Using stain removers before machine washing reduces the need to wash at temperatures over 60°C.

Using a 40°C wash temperature can make energy savings of up to 50%.

Heavily soiled laundry

To ensure the best performance when washing a particularly dirty load, we recommend that you reduce the amount of items to be put into the machine. Allowing more space in the drum the

Washing advice

40002057Eng.qxd 04/11/2004 16:22 Page 13

items can circulate more freely and will wash better.

Sorting the laundry

Items to avoid

We recommend that you do not wash underwired bras in the machine. Should the wires become detached they could cause damage to your clothes and the machine. If the washcare label states that the bra is machine washable then we advise placing it in a wash bag.

Recommendations

Always follow the wash care labelling on the garments.

Fasten zips, tie strings and close press studs to prevent tangling. Ensure that pockets are emptied of loose change and other small items.

Check that there are no metal objects in the laundry as these may damage the laundry and the machine.

Place small items in a wash bag.

Do not use the

machine to

wash items that

do not have a

wash label.

Do not wash

items

previously

treated with

solvents.

40002057Eng.qxd 04/11/2004 16:22 Page 14

Detergent dosage

Only use detergents which are suitable for use in a washing machine. You will obtain the best results from your wash with the minimum use of chemical products, and the best care for your laundry if you take into consideration the degree of soiling as well as the type of detergent to choose.

The amount of detergent to use depends on:

● Water hardness.

Depending on the hardness of the water and the type of detergent used, it is possible to reduce the amount of detergent.

The softer the water supply, the less detergent is required.

● The degree of soiling.

It is possible to reduce the amount of detergent used depending on the degree of soiling.

Use less detergent for less soiled items.

● Amount of laundry.

It is possible to reduce the amount of detergent when washing only a small amount of laundry.

For smaller loads use less detergent.

The dosages shown on the packaging of detergents for washing delicates often already refer to a reduced wash size. Always follow the dosage

instructions on the detergent packaging.

The Dispenser

DO NOT exceed the maximum detergent dosage

COMPARTMENT I

Prewash detergent

Maximum dosage 100ml of powder

COMPARTMENT II

Mainwash detergent

Maximum dosage 200ml of powder

COMPARTMENT

Fabric Conditioner

Maximum dosage 100ml

40002057Eng.qxd 04/11/2004 16:22 Page 15

Dispensing instructions

The detergent drawer is split into 3 compartments:

● the first, labelled "I", is for detergent utilised during Prewash.

● the second, labelled "II", is for detergent utilised during the main wash.

● the third, labelled is for special additives such as fabric softeners, fragrances, starch, brighteners etc.

Dispensing in the drum

Liquid detergents and some tablets are dispensed via the machine drum using the recommended dispensing device which is placed upright on top of the washload towards the back of the drum. Some tablets are designed to be placed in the dispenser drawer, check the detergent pack for details.

Do not put any

items into the

drawer other

than detergents

that are

designed to be

dispensed from

the drawer as

they may cause

blockage or

damage.

40002057Eng.qxd 04/11/2004 16:22 Page 16

This machine will operate even if you do not programme the Inter@ct set-up. However, this machine has Start Delay and Programme Set End Time functions and for these functions to work efficiently the Inter@ct 3D must be programmed. This is a simple operation and special care has been taken during manufacture to ensure that the user can operate this machine simply and effectively.

Programming the machine

Inter@ct needs to be programmed so that the correct clock setting, language and personal requirements are set. When the machine is turned on and the programme dial is moved away from the OFF position to a programme selection, a welcome message will appear:

This message is displayed for a short time while the machine recognises which programme has been selected. When the machine is ready, the programme details will appear on the display and from here you may now begin programming the machine.

Example

Please note that when using the Inter@ct menu you have 30 seconds per operation to make your selection. Should you run out of time, the display will

Using Inter@ct 3D for the first time

VÄLKOMNA!

0:00

VITTVÄTT

GROV

Spin Speed

x100

Programme

selected

Temperature

(°C)

40002057Eng.qxd 04/11/2004 16:22 Page 17

return to the start screen, and you simply have to re-enter the Inter@ct menu and continue with the programming.

To enter the menu

Hold down the and the buttons together for 5 seconds or until the beep sounds.

The menu options can be changed by pressing the button. To confirm and enter an option press the button.

ADOPT LANGUAGE (default setting – SWEDISH)

Your washing machine is automatically set to Swedish. If you require another language you have the option to change it within this set-up menu. Press to change the language, keep pressing the button until the desired language is indicated. Press to confirm your selection. When you have entered your chosen language, the display will then ask you to Set the Time.

SET NEW TIME

This function needs to be set for two reasons, firstly to display the current time of day on the screen and secondly for the Programme Set End Time/Start Delay settings to work correctly.

You will notice in the display window that the hours on the clock will be flashing. To set the hours you must press the button until the required figure is displayed. Then press the button to enter the chosen figure. Now the minutes on the clock will begin to flash. Again, press the button until the required minutes are displayed and press to input the selection. When you have set the time, the display will ask if you wish to Set the Time Mode.

SET TIME MODE (default setting – KLOCKAN)

The Set Time Mode allows you choose how you wish the Programme Set End Time and Start Delay functions to be controlled.

You will be presented with two options. The first, called Absolute Time Mode (KLOCKAN), allows you to set the actual time you want the programme to begin or end, e.g. Programme to start/end at 08:00. The second, called Relative Time Mode (TIM/MIN FRÅNNU), allows you to delay the start or end of your wash cycle by adding hours to the current time displayed on the clock, e.g. Programme to start/end in 4 hours 30 minutes.

STÄLL NY TID

0:08

40002057Eng.qxd 04/11/2004 16:22 Page 18

You can select which option you require by pressing the button until your preferred option is displayed, and then pressing the button to accept the option you have chosen.

Both options are very useful, but Absolute Time Mode is easier to use since there is no need for you to calculate how many hours to leave before you want the machine to end or start your chosen cycle.

When you have entered your preferred Time Mode the display will then ask for Enable Final Beeping to be set.

SET FINAL BEEP (default setting – YES)

Here you have the option to have a beeping alarm to let you know the wash cycle has finished. By pressing the button you can scroll through the YES (JA) and NO (NEJ) options.

To confirm your selection press the button. The screen will then move to the next stage and ask you if you wish to Enable Memory.

ENABLE MEMORY? (default setting – NEJ)

This is a useful feature if you frequently wash laundry using the same programme. Selecting Enable Memory will tell the machine to remember the last programme/functions used and set them in the memory. This feature works only on the Cottons, Delicates, Synthetics and Woollens programmes. The memory does not retain settings within the Special Programmes group. Select JA or NEJ by using the button and confirm your selection by pressing the button.

SET DEMO MODE? (default setting – NEJ)

The display will now show a message asking if you require the demo mode to be set. Please set this option to NEJ if this has not already been done. This function is for SERVICE use only. If the demo mode option is set to JA, the wash programme WILL NOT commence when you exit the Inter@ct 3D menu. The Demo Mode must be set to NEJ for the wash cycle to commence. Select NEJ using the button and confirm your choice with the button. You will then be asked if you wish to Exit the Menu.

EXIT MENU?

If you are happy with the settings you have selected, you can now exit the menu by selecting JA via the button and confirm this selection using the

button. However, if you are not happy with some of the settings selected you must select NEJ and you can then start programming again from the beginning. By pressing the button you can enter and bypass each option individually until you reach the option you would like to change.

When you are completely satisfied with the menu options you have selected, you may exit the menu. Testing of the installation may now start. If you wish to change any of the menu settings at a later date, you can enter the menu as

40002057Eng.qxd 04/11/2004 16:22 Page 19

The Control Panel

The programme selector must be returned to the OFF

position to reset the controls between each wash cycle.

INTER@CT

Display

Fast Iron

Spin

Speed

Rapid Wash

Prewash Temperature

Selection

Extra Rinse

Start Pause

Start Delay/

Set End Time

Programme Lock

Programme

Selector

previously described, run through the menu options from the beginning and change whichever options you wish. This may be useful for changing Set New Time when Daylight Saving starts or ends.

Once set, the menu options will remain in the memory of the machine even if the machine is unplugged or there is a power cut.

40002057Eng.qxd 04/11/2004 16:22 Page 20

Turning the machine on

Turn the machine on by selecting a programme using the programme selector. The display will then indicate the name of the programme, the spin speed and temperature of the wash and this display will remain until you press the button or return the programme selector to the OFF position.

Start/Pause ( ) Start

After selecting the programme and the required options (see the Wash Options section of this manual), press the button once to start the wash cycle. The display will indicate that the door is locked and the machine will begin to sense the wash load and ask you to wait.

After the appropriate parameters have been programmed by the machine the display will indicate the approximate time until the end of the programme. This calculation is based on a full load and will be adjusted to suit the size and composition of the load as the machine progresses through the wash cycle.

VITTVÄTT

GROV

VAR GOD VÄNTA

PROGRAMMERAR

SLUT OM: 2H 45M

TVÄTTAR

40002057Eng.qxd 04/11/2004 16:22 Page 21

Pause

The programme may be paused at any time during the wash cycle by holding down the button for about three seconds. When the machine is in the paused mode the following display will appear:

After about two minutes the display will then change to the following, which means that the door can now be opened:

To restart the programme, close the door and press the button.

Cancelling and changing the programme

To cancel the programme the programme selector should be turned to the OFF position. In this mode the display will go blank because the machine is now OFF. When a new programme is selected the display will indicate that the programme has been cancelled as follows:

To start another wash cycle the programme selector must be returned to OFF once again BEFORE the next programme can be selected and started.

PAUS I PROGR.

LUCKAN ÄR LÅST

PAUS I PROGR.

LUCKA ÖPPEN

PROGR. ANNUL.

40002057Eng.qxd 04/11/2004 16:22 Page 22

Spin Speed Selection ( )

By pressing the option button it is possible to reduce the maximum spin speed of your selected programme to suit your needs and to help reduce any creasing of fabrics. The maximum spin speed will vary depending on the specification of the machine.

The light on the option button will come on if a spin speed lower than that stated in the programme guide has been selected.

Rapid Wash ( )

This option can be used on the Cottons ( ) and Synthetics ( ) programmes. By selecting the option, the wash time can be reduced by up to 50 minutes, depending on the selected programme, temperature and load, without affecting the quality of the wash.

Prewash ( )

This option is available on the Cottons ( ) and Synthetics ( ) programmes.

is set automatically on the Sports programme. This option is particularly useful for heavily soiled loads and can be used independently of the main wash programme. Detergent for this programme should be added to the first compartment of the soap drawer labelled "I" (please refer to The Dispenser section of this manual). We recommend you use only 20% of the quantity used for the main wash programme.

Wash Options

The following options should be selected BEFORE

pressing the button. The light on each option button

will come on if the option has been selected.

Spin Speed ÷ 100 rpm; so in this example 11 = 1100 rpm

VITTVÄTT

GROV

40002057Eng.qxd 04/11/2004 16:22 Page 23

Temperature Selection ( )

This washing machine is equipped with a variable temperature function. Each press of the button reduces the temperature of the wash. Greater energy savings can be achieved by setting the temperature between 15°C and 40°C. By setting the temperature to 15°C the wash temperature is equivalent to the water inlet temperature, thus reducing energy consumption further.

We recommend that the temperature shown on wash care garments should never be exceeded. The machine will not accept a temperature input that is higher than that stated in the programme guide.

The light on the option button will come on if a temperature lower than that stated in the programme guide has been selected.

Extra Rinse ( )

This option is available on the Cottons programmes ( ) and it increases the number of rinses to five (including the final conditioned rinse). This can help prevent skin irritation from detergent residue, which can affect people with particularly sensitive skin. Selecting the button is also recommended when washing heavily soiled fabrics which need a lot of detergent, or when the wash load contains towelling fabrics that have a greater tendency to retain detergent.

Temperature (°C)

VITTVÄTT

GROV

40002057Eng.qxd 04/11/2004 16:22 Page 24

Fast Iron ( )

This option is only available on the Synthetics, Acrylics, Woolmark and Silk programmes.

Start Delay ( )

The Programme Set End Time/Start Delay options can be used if you want the washing to be ready at a later time (but within 24 hours). The way these buttons function will depend on which Time Mode you have selected in the Inter@ct menu.

Programme

Synthetics ( 50)

Acrylics ( 40)

Woolmark ( )

Silk ( )

Fast Iron function

The programme is completed by a short spin, of very low speed.

The machine stops in the final rinse stage and the option indicators blink. The load is held in the water in the drum, thus reducing creasing and enabling easier ironing.

Action required to complete the cycle

To select a full spin cycle please turn the dial to the required spin programme (see Programme Guide).

Press the - button to continue with the programme. The machine will then pump out the water and the programme will conclude with a short spin. Finally, the programme carries out a brief tumbling action to loosen the items in the load.

Press the button and the machine will pump out the water and complete the cycle with a short spin.

Press the button and the machine will pump out the water to complete the cycle. The load will not be spun and will therefore be very wet.

40002057Eng.qxd 04/11/2004 16:22 Page 25

1. Set Start Delay

Press the button once and press the hours and minutes buttons ( and

) until the required time is set. The display returns to the programme option if you do not start to set the time within 5 seconds. Once you have set the required Start Delay, press the button.

If the Absolute Time Mode has been selected at the menu set-up stage and you wish to delay the start of the programme until 08.00, the display will appear as follows:

If the Relative Time Mode has been selected at the menu set-up stage and you wish to delay the start of the programme by 4 hours 30 minutes, the display will appear as follows:

2. Programme Set End Time

Press the button twice and press the hours and minutes buttons ( and

) until the required time is set. When you are entering the Set End Time option, the display will automatically show the earlier time at which the programme can end. This time may only be extended as you require.

If the Absolute Time Mode has been selected at the menu set-up stage and you wish to delay the end of the programme until 08.00, the display will appear as follows:

If the Relative Time Mode has been selected at the menu set-up stage and you wish to delay the end of the programme by 4 hours 30 minutes, the display will appear as follows:

STARTA TVÄTT

KL 08:00

FÖRDRÖJA START

M. 4H 30M

TVÄTT FÄRDIG

KL 08:00

40002057Eng.qxd 04/11/2004 16:22 Page 26

These options can be cancelled at any stage after they have been set by pressing the button for five seconds. The indicator light will go out and the buzzer will sound.

Programme Lock ( )

This is a useful feature to prevent children playing with the option buttons and tampering with the programme you have set. After you have set the programme and option buttons you require, press the button. Press the

button in order to lock the control panel.

You may cancel this function by pressing the button briefly until you see the light above the button flash. While this light is flashing, press the button – the display will inform you that the options are no longer locked and further changes can now be made.

When using the Start Delay/Set End Time functions, detergents must only be put in the dispenser drawer. Adding detergents etc. to the drum and then leaving them to stand for a long period of time may damage

your laundry.

FÖRDRÖJA SLUT

M. 4H 30M

KNAPPSATS LÅST

INGEN ÄNDRING

PROGR. ÖPPEN

ÄNDRING MÖJLIG

40002057Eng.qxd 04/11/2004 16:22 Page 27

Automatic Features

Automatic Variable Capacity (Half Load)

The washing machine is fitted with a self adjusting water level system. This system enables the machine to use the optimum amount of water needed to wash and rinse the laundry in relation to the particular load. This results in a reduction of the water and electricity used without in any way compromising the washing and rinsing performance. The amount of water and electricity used will always be appropriate for the clothes load.

The washing machine automatically ensures excellent washing results at minimum cost whilst respecting the environment.

Out of Balance protection

This model is fitted with an electronic sensor device that checks if the load is balanced correctly. If the load is slightly unbalanced the machine will re-balance it automatically to then carry out the normal spin.

If, after several attempts, balance is not restored a reduced spin speed will be used.

If loads are seriously unbalanced the spin stage will be cancelled. This helps limit vibration, reduce noise and improve the washing machine's reliability and life.

40002057Eng.qxd 04/11/2004 16:22 Page 28

Programme Selector

For handling the various types of fabric and their level of soiling in your laundry the washing machine has different programme groups according to type of wash, temperature, spin speeds and duration (see Programme Guide).

Cottons

The Cottons programmes are designed for maximum washing and rinsing. With spin cycles in between, they guarantee the laundry is rinsed perfectly. The final spin cycle ensures laundry is spun dry as much as possible up to the maximum speed.

Synthetics and mixed fabrics

Washing and rinsing performance is optimised through drum rotation speeds and water levels. The delicate spin action minimises creasing.

Delicates

This is a new concept in washing, with a cycle that consists of alternate periods of activity and pauses, particularly suitable for washing very delicate fabrics. Washing and rinsing are carried out using a high water level to provide the best results.

Rinse, Spin and Drain

Individual programmes are available for rinsing, (including the opportunity to add fabric conditioner), spinning, at 800rpm or less if selected via the button, and draining the water from the machine.

40002057Eng.qxd 04/11/2004 16:22 Page 29

Special Programmes

Woolmark ( )

This is a programme dedicated to washing fabrics labelled with the woolmark symbol . The cycle consists of alternate periods of activity and pauses. Washing and rinsing are carried out using a high water level to provide the best results. The programme has a maximum temperature of 30°C and concludes with 3 rinses, one for fabric conditioner, and a short spin.

Silk ( )

This washing machine also has a gentle Silk and Hand Wash programme. This programme allows a complete washing cycle for garments specified as “Hand Wash only” and laundry items made from silk or specified “Wash as silk” on the fabric label.

The programme has a maximum temperature of 30°C and concludes with 3 rinses, one for fabric conditioner, and no final spin.

Sports

This washing machine has a unique Sportswear programme.

It is specially designed to wash mixed sportswear fabrics that cannot be washed on hotter programmes and is designed to remove the soiling and staining created by participation in sports activities.

This programme starts with a cold prewash that breaks down and loosens any excess dirt and then washes at a cool 30°C, rinses twice (one is for fabric conditioner) and spins slowly for the best care of your heavily soiled, delicate garments.

Detergent for the prewash part of the programme should be added to compartment I and detergent for the mainwash should be added to compartment II. Follow the instructions given in 'The Dispenser' section.

40002057Eng.qxd 04/11/2004 16:22 Page 30

+ 162 hidden pages
