HOOVER HI 148, HI168 User Manual [fr]

Instruction Book

Washing Machine

English Français

40002960Eng.qxd 12/04/2005 15:10 Page 1

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Delivery information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Do’s . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Don’ts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Unpacking the Product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Choose a location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Electricity supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Water supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Connecting to the cold water supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Connection of the machine to the drain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Moving the machine into position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Adjusting the feet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Testing the installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Washing advice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Loading your washing machine. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Sorting the laundry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

The Dispenser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Detergent dosage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Dispensing instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Using Inter@ct for the first time. . . . . . . . . . . . . . . . . . . . . . . . 17

Programming the machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

The Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Wash Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Automatic Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Programme Selector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Special Programmes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Daily Programmes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Programme Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

A Typical Wash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Selecting the wash programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Starting the wash cycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Cleaning and Routine Maintenance. . . . . . . . . . . . . . . . . . . . 34

Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Power Failure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

English . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Français . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

40002960Eng.qxd 12/04/2005 15:10 Page 2

Introduction

Please read and follow these instructions carefully and operate the machine accordingly. This booklet provides important guidelines for safe use, installation, maintenance and some useful advice for best results when using your machine.

Keep all documentation in a safe place for future reference or for any future owners.

Delivery information

Please check that the following items are delivered with the appliance:

● Instruction manual

● Guarantee card

● Blanking plug

● Inlet hose & hooked end support

(see Unpacking and Installation Instructions)

● Base panel & x2 push clips

● Energy Label

Do’s

● All packaging materials used are environmentally-friendly and recyclable. Please help dispose of the packaging via environmentally-friendly means. Your local council will be able to give you details of current means of disposal.

● To ensure safety when disposing of an old washing machine disconnect the mains plug from the socket, cut the mains power cable and destroy this together with the plug. To prevent children shutting themselves in the machine break the door hinges or the door lock.

● This machine is solely for domestic use, i.e. to wash, rinse and spin dry household textiles and garments.

Check that no

damage has

occurred to the

machine during

transit. If it has,

call for service

by GIAS.

40002960Eng.qxd 12/04/2005 15:10 Page 3

Don’ts

● Do not touch the appliance when hands or feet are damp or wet.

● Do not lean on the door when loading the machine or use the door to lift or move the machine.

● Do not use adapters, multiple connectors and/or extensions.

● Do not allow children to play with the machine or its controls.

● Do not try to open the door when water is visible in the drum or the Porte Sécurisée indicator is on.

Failure to

comply with

the above can

compromise the

safety of the

appliance. You may be charged for a service call

if a problem

with your

machine is

caused by

misuse.

If the appliance

is not running

properly or

breaks down,

switch it off,

disconnect the

plug from the

socket, turn off

the water

supply and do

not tamper

with the

appliance.

Consult GIAS

Service for

possible repair.

40002960Eng.qxd 12/04/2005 15:10 Page 4

Unpacking the product

Remove the machine from its packaging close to the final location of the machine.

1. Cut carefully around the base of the packaging.

2. Lay the machine on its back and remove the base and the two polystyrene spacers on each side of the machine. We recommend that a second person assist in the lifting and manoeuvring of the machine.

3. Return the machine to the upright position, remove the remainder of the packaging and the central screw in the transit bar.

4. Remove the four retaining screws in the transit bar and pull out the transit bracket.

Dispose of the packaging safely.

Make sure it is out of the reach

of children, it is a potential

source of danger.

40002960Eng.qxd 12/04/2005 15:10 Page 5

5. Take the base panel provided and fit the two self adhesive strips by removing the backing paper on one side and locating the strips on each side of the base panel.

6. Tilt the machine forward and locate the base panel under the front of the machine. Remove the remaining backing paper from the self-adhesive strips and offer up the base panel to the bottom of the cabinet.

7. Take the two plastic fixing clips and fix the base panel to the base of the machine. Bring the machine back to the upright position.

We recommend you keep the transit bracket and

screws to protect the machine for future transit.

The manufacturers will not be responsible for any

damage to the machine caused by not following the

instructions relating to releasing the transit protection.

The user is responsible for all installation costs.

40002960Eng.qxd 12/04/2005 15:10 Page 6

8. Cover the central hole in the rear of the machine with the cap enclosed in the instruction bag.

Choose a location

● After the machine has been installed, ensure that the mains plug and water supply valves are easily accessible.

● Make sure there is enough space for the machine. Select a space at least 600mm wide and 850mm high. Also leave enough space to open the door fully so you can load and unload it easily.

● Keep the area underneath and around the machine free of combustible materials such as lint, paper, rags, chemicals etc.

Installation

Do not plug the

machine in and

switch it on at the mains until the installation

is completed.

40002960Eng.qxd 12/04/2005 15:10 Page 7

Electricity supply

Washing machines are supplied to operate at a voltage of 230V, 50 Hz single phase. Check that the supply circuit is rated to at least 16A.

Electricity can be extremely dangerous. This washing machine must be earthed. The socket outlet and the plug on the appliance

must be of the same type. Do not use multiple adapters and/or extension

leads.

The wires in the mains lead are coloured in accordance with the following codes:

Blue NEUTRAL Brown LIVE Green and Yellow EARTH

CE Appliance complies with European Directive 89/336/EEC, 73/23/EEC and subsequent amendments.

Water supply

● The cold water pressure should be between

0.05-0.8 Mpa.

● Do not connect the machine to a single outlet instantaneous water heater.

● The water supply tap should be accessible when the machine is installed.

● Before connecting the fill hose, check that the water is running from the water supply tap to be used.

You may be

charged for a

service call if a

problem with

your machine is

caused by

incorrect

installation.

If the mains cord on this appliance is damaged, it

must be

replaced by a

special cord

which is ONLY

obtainable from

the GIAS spares

service. It must

be installed by

a competent

person.

40002960Eng.qxd 12/04/2005 15:10 Page 8

This machine has an inlet hose with a 19mm (3/4") threaded ferrule fitted to the end, to attach between the threaded connector on the appliance and the water supply.

Only use the new hose supplied to connect the machine and ensure that the sealing washers are in place inside the hose connectors.

Do not re-use old hoses which are attached to existing installations.

Do not over-tighten the connections. Hand tight is sufficient.

Do not trap or kink the hose.

1. Connect the elbow end of the hose provided

to the threaded inlet on the back of the machine.

Grey pipe to the white threaded inlet on the machine.

2. Hand tighten the connector.

3. Connect the straight ends of the pipes to the water supply; ensure that there are no kinks.

4. Turn on the water supply and check for leaks. If there is a leak, turn off the water

supply, disconnect the hose and check the sealing washers are in place. Refit the hose and turn on the water supply.

Aqua-stop

Certain models will be supplied with special hose that has a double skin and incorporates a water valve (A). If the inner hose bursts the valve will automatically shut off the water supply to prevent flooding. The indicator turns red (B). Should this happen, turn off the water supply immediately and obtain a replacement hose from GIAS Service.

The installation is the same as a conventional hose with the valve end of the aqua-stop hose fitted to the water supply.

Connecting to the cold water supply

40002960Eng.qxd 12/04/2005 15:11 Page 9

Connection of the machine to the drain

This machine must be connected in accordance with the water supply regulations. Water byelaws prohibit connection to a surface water drain.

Decide which plumbing option suits you best then follow the instructions below.

Option 1 Waste pipe connection (waste trap)

Fit the hooked end support to the outlet pipe. Position at least 800mm off the floor.

After removing the blanking plug or cutting the membrane from the waste system securely fix the outlet pipe to the drainage system, using a hose clip.

Secure the hooked end support up to at least 800mm to avoid water being drawn back into the machine.

All machines are tested with water prior to leaving the

factory so a small amount of water may remain in the

drum and drain hose.

Flooding could occur if any part of the installation is

not completed correctly.

800 mm

hose clip

hooked end support

sink

flexible

discharge hose

trap with hose

adaptor

40002960Eng.qxd 12/04/2005 15:11 Page 10

Option 2 Into a standpipe

Ensure that the standpipe is not located near an electrical socket.

Fit the hooked end support to the outlet pipe. Install the hose into the standpipe ensuring that the pipe is at least 500mm from the floor.

Insert the outlet pipe approximately 100mm into the standpipe.

Moving the machine into position

Your machine is heavy so care must be taken when moving it. We recommend that two people move the machine to avoid strain and possible injury.

● Take care not to damage flooring when moving the machine.

● When moving the machine to its final position take care not to kink or damage the hose at the back of the machine.

Adjusting the feet

Once the machine is in place the feet should be adjusted to ensure that the machine is level. If the machine is not level it may become noisy or move.

Adjust the feet on the front corners of the machine until the machine is firm and level.

When the machine is firm and level, tighten the locking nuts on the two feet.

Do not drag or

lift the machine

by its door.

100 mm

500 mm min

40002960Eng.qxd 12/04/2005 15:11 Page 11

Refer to the programme guide for details of how to select programmes.

1. Turn on the water supply and check for leaks from the fill hose.

2. Switch on the electricity supply.

3. Select the Essorage programme (15) and

then press the Départ/Pause button to start the machine. Allow the programme to continue for one minute and then cancel the programme by returning the selector to the ARRÊT position. This will remove any water remaining in the machine from factory testing.

4. To check for cold water filling to the machine:

Select the Rinçage programme (14) and press the Départ/Pause button to start the machine.

Allow the tumble action to continue until the water has pumped out. Check that the drain outlet is not leaking or overflowing.

5. Switch off the machine at the end of the cycle by turning the programme knob to the ARRÊT position.

6. Select the Essorage programme (15) and press the Départ/Pause button to start the machine. If the machine takes longer than one minute to empty check the drain hose for kinks.

Installation testing is now complete.

Now you have successfully installed the machine we advise that you run the machine to ensure the drum is thoroughly clean after testing and storage. Select COTON RESISTANT 90 and run the machine for a complete cycle using only wash detergent and water.

Testing the installation

This

programme

will take

approximately

2 hours to

complete.

40002960Eng.qxd 12/04/2005 15:11 Page 12

The following tips are designed to assist in getting the best results from your machine whilst utilising it in the most environmentally-friendly and economical way. It is also important to understand the items to avoid in your laundry, to ensure the continued safe and reliable operation of your machine.

Loading your washing machine

To make further reductions of energy, water and detergent consumption, we recommend that you put a full load into your machine. Energy savings of up to 50% can be achieved by washing one full load compared to two half loads.

Do not overload the machine as this will reduce the quality of the wash and may cause damage to the machine and your laundry.

When is prewashing really needed?

Only with particularly dirty loads! Energy savings of 5 to 15% are made by not selecting the prewash option for less dirty laundry. Pre-treat awkward stains with a washable stain remover.

Which wash temperature should you choose?

Using stain removers before machine washing reduces the need to wash at temperatures over 60°C.

Using a 40°C wash temperature can make energy savings of up to 50%.

Heavily soiled laundry

To ensure the best performance when washing a particularly dirty load, we recommend that you reduce the amount of items to be put into the machine. Allowing more space in the drum the

Washing advice

40002960Eng.qxd 12/04/2005 15:11 Page 13

items can circulate more freely and will wash cleaner.

Sorting the laundry

Items to avoid

We recommend that you do not wash underwired bras in the machine. Should the wires become detached it could cause damage to your clothes and the machine. If the washcare label states that the bra is machine washable then we advise placing it in a wash bag.

Recommendations

Always follow the wash care labelling on the garments.

Fasten zips, tie strings and close press studs to prevent tangling. Ensure that pockets are emptied of loose change and other small items.

Check that there are no metal objects in the laundry as these may damage the laundry and the machine.

Place small items in a wash bag.

Do not use the

machine to

wash items that

do not have a

wash label.

Do not wash

items

previously

treated with

solvents.

40002960Eng.qxd 12/04/2005 15:11 Page 14

Detergent dosage

Only use detergents which are suitable for use in a washing machine. You will obtain the best results from your wash with the minimum use of chemical products, and the best care for your laundry if you take into consideration the degree of soiling as well as the type of detergent to choose.

The amount of detergent to use depends on:

● Water hardness.

Depending on the hardness of the water and the type of detergent used, it is possible to reduce the amount of detergent.

The softer the water supply, the less detergent is required.

● The degree of soiling.

It is possible to reduce the amount of detergent used depending on the degree of soiling.

Use less detergent for less soiled items.

● Amount of laundry.

It is possible to reduce the amount of detergent when washing only a small amount of laundry.

For smaller loads use less detergent.

The dosages shown on the packaging of detergents for washing delicates often already refer to a reduced wash size. Always follow the dosage

instructions on the detergent packaging.

The Dispenser

DO NOT exceed the maximum detergent dosage

COMPARTMENT I

Prewash detergent

Maximum dosage 100ml of powder

COMPARTMENT II

Mainwash detergent

Maximum dosage 200ml of powder

COMPARTMENT

Fabric Conditioner

Maximum dosage 100ml

40002960Eng.qxd 12/04/2005 15:11 Page 15

Dispensing instructions

The detergent drawer is split into 3 compartments:

● the first, labelled "I", is for detergent utilised during Prewash.

● the second, labelled "II", is for detergent utilised during the main wash.

● the third, labelled is for special additives such as fabric softeners, fragrances, starch, brighteners etc.

Dispensing in the drum

Liquid detergents and some tablets are dispensed via the machine drum using the recommended dispensing device which is placed upright on top of the washload towards the back of the drum. Some tablets are designed to be placed in the dispenser drawer, check the detergent pack for details.

Do not put any

items into the

drawer other

than detergents

that are

designed to be

dispensed from

the drawer as

they may cause

blockage or

damage.

40002960Eng.qxd 12/04/2005 15:11 Page 16

Using Inter@ct for the first time

This machine will operate even if you do not programme the Inter@ct set up. However, this machine has Départ Différé and Programmation Fin Du Cycle functions and for these functions to work efficiently Inter@ct must be programmed. This is a simple operation and special care has been taken during manufacture to ensure that the user can operate this machine simply and effectively.

Programming the machine

Inter@ct needs to be programmed so that the correct clock setting, language and personal requirements are set.

When the machine is turned on and the programme dial is moved away from the ARRÊT position to a programme selection a Welcome message will appear.

This message is displayed for a short time while the machine recognises which programme has been selected. When the machine is ready, the programme details will appear on the display and from here you may now beging programming the machine.

Example:

Please note that when using the Inter@ct menu you have 30 seconds per operation to make your selection. Should you run out of time, the display will return to the start screen, and you simply have to re-enter the Inter@ct menu and continue with the programming.

HOOVER INTER@CT

WELCOME 11:06

1 WHITE COTTON

90° HEAVY 1600 RPM

40002960Eng.qxd 12/04/2005 15:11 Page 17

To enter the Menu

Hold down the Super Rapide and the Extra Rinçage buttons together for 5 seconds or until the beep sounds.

The menu options can be changed by pressing the Extra Rinçage button. To confirm and enter an option press the Super Rapide button.

Set New Time

This function needs to be set for two reasons, firstly to display the current time of day on the screen and secondly for the Programmation Fin Du Cycle/Départ Différé settings to work correctly.

You will notice in the display window that the hours on the clock will be flashing. To set the hours you must press the Extra Rinçage button until the required figure is displayed. Then press the Super Rapide button to enter the chosen figure. Now the minutes on the clock will begin to flash. Again press the Extra Rinçage button until the required minutes are displayed and press Super Rapide to input the selection.

When you have Set the New Time, the display will ask if you wish to Set the Time Mode.

Setting the time mode (default setting – ABSOLUTE)

The Set Time Mode allows you choose how you wish the Programme Set End Time and Start Delay functions to be controlled.

The first, called Absolute Time Mode, allows you to set the actual time you want the programme to begin or end. An example can be seen below when the Absolute Time Mode has been selected in the menu set-up stage.

In this example, when setting the Programmation Fin Du Cycle the programme (as shown above) will end at 08.00.

The second, called Relative Time Mode, allows you to delay the start or end of your wash cycle by adding hours to the current time displayed on the clock, e.g. Programme to start/end in 1 hour 30 minutes. An example can be seen below when Relative Time Mode has been selected is the menu set-up stage.

PROGRAMME END

08:00 14:00

40002960Eng.qxd 12/04/2005 15:11 Page 18

In this example, when setting the Programmation Fin Du Cycle the programme (as shown above) will end at 15:30.

Both options are very useful, but Absolute Time Mode is easier to use since there is no need for you to calculate how many hours to leave before you want the machine to end or start your chosen cycle.

You can select which option you require by pressing the Extra Rinçage button until your preferred option is displayed, and then pressing the Super Rapide button to accept the option you have chosen.

When you have entered your preferred Time Mode, the display will then ask for Enable Final Beeping to be set.

Enable Final Beeping (default setting – YES)

Here you have the option to have a beeping alarm to let you know the wash cycle has finished. By pressing the Extra Rinçage button you can scroll through the YES and NO options.

To confirm your selection press the Super Rapide button and the screen will then move to the next stage and ask you if you wish to Enable Memory.

Enable Memory (default setting – NO)

This is a useful feature if you frequently wash laundry using the same programme. Selecting Enable Memory will tell the machine to remember the last programme/functions used and set them in the memory. This feature works only on the Cottons, Delicates, Synthetics and Woollens programmes. The memory does not retain settings within the Special Programmes group.

Select YES or NO by using the Extra Rinçage button and confirm your selection by pressing the Super Rapide button.

The display will now show a message asking if you require the Demo Mode to be set. Please set this option to NO if this has not already been done. This function is for SERVICE use only. If the demo mode option is set to YES, the wash programme WILL NOT commence when you exit the Inter@ct 3D menu. The Demo Mode must be set to NO for the wash cycle to commence. Select NO using the Super Rapide button and confirm your choice with the Extra Rinçage button. You will then be asked if you wish to Exit the Menu.

PROGRAMME END

BY 1H 30M 14:00

40002960Eng.qxd 12/04/2005 15:11 Page 19

Exit Menu

If you are happy with the settings you have selected, you can now exit the menu by selecting YES via the Extra Rinçage button and confirm this selection using the Super Rapide button. However, if you are not happy with some of the settings selected you must select NO and you can then start programming again from the beginning. By pressing the Super Rapide button you can enter and bypass each option individually until you reach the option you would like to change.

When you are completely satisfied with the menu options you have selected, you may exit the menu. Testing of the installation may now start. If you wish to change any of the menu settings at a later date, you can enter the menu as previously described, run through the menu options from the beginning and change whichever options you wish. This may be useful for changing Set New Time when Daylight Saving starts or ends.

Once set, the menu options will remain in the memory of the machine even if the machine is unplugged or there is a power cut.

40002960Eng.qxd 12/04/2005 15:11 Page 20

Turning the machine on

Turn the machine on by selecting a programme using the programme selector. When you turn the programme selector dial the Welcome message will appear and will then be replaced by a display showing the following details:

Reading from left to right:

1. The programme number

2. The programme name

3. The wash temperature

4. The degree of soiling (how dirty the wash load is)

5. The spin speed

The Control Panel

The programme selector must be returned to the ARRÊT

position to reset the controls between each wash cycle.

Door Locked

Indicator

(Porte Sécurisée)

Start/Pause

(Départ/

Pause)

Pre-Wash

(Prélavage)

Start Delay

(Départ Différé)

Inter@ct Display

(Affichage

Inter@ct)

Child Lock

(Verrouillage

Clavier)

Time Saver

(Super

Rapide)

Spin Speed

(Variateur

d’essorage)

Open

Door

(Porte)

Extra Rinse

(Extra

Rinçage)

Fast Iron

(Repassage

Facile)

Programme

Selector

1 WHITE COTTON

90° HEAVY 1600 RPM

40002960Eng.qxd 12/04/2005 15:11 Page 21

Départ/Pause Départ

To start a programme press this button once. The Porte Sécurisée light will illuminate. The machine will now be sensing the wash load and ask you to please wait.

Example:

The Inter@ct panel will then display the time to complete the programme and then the wash cycle will start. Inter@ct calculates the time to the end of the selected programme based upon a standard 7 Kg load. During the cycle, Inter@ct corrects the time to that applicable to the size and composition of the load.

Example:

This display also shows the current phase of the cycle and in the bottom right hand corner, the current time is displayed.

This display will change throughout the wash programme as the cycle progresses.

Pause

The programme may be paused at any time during the wash cycle by holding down the Départ/Pause button for about two seconds. A beep will then sound and a message will appear on the display to inform you that the programme has been paused.

Example:

To restart the programme press the Départ/Pause button once again. The display will inform you that the programme will continue.

SETTING WASHING

PARAMETERS:PLS WAIT.

WHITE COTTON

PROGRAMME PAUSED

TIME TO END 1H 30M

WASHING 19:30

40002960Eng.qxd 12/04/2005 15:11 Page 22

Cancel

To cancel the programme the Départ/Pause button must be pressed down for 5 seconds. A beep will then sound and the display will first inform you that the programme has been paused and then that it has been cancelled.

Example:

Porte Sécurisée

The Porte Sécurisée indicator light is illuminated when the door is fully closed and the machine is ON.

When Départ/Pause is pressed on the machine with the door closed the indicator will flash momentarily and then illuminate. If the door is not closed the indicator will continue to flash.

A special safety device prevents the door from being opened immediately after the end of the cycle. Wait for 2 minutes after the wash cycle has finished and the Porte Sécurisée light has gone out before opening the door. As a safety measure, check that there is no water evident in the drum. At the end of the cycle turn the programme selector to ARRÊT.

If the programme is paused, the Porte Sécurisée indicator will go out after 2 minutes and the door can be opened. Check there is no water evident in the drum before opening the door.

When starting a subsequent wash cycle the

programme selector must be returned to ARRÊT prior

to the next programme being selected and started.

PROGRAMME CANCELLED

40002960Eng.qxd 12/04/2005 15:11 Page 23

Intensif

By pressing this button, which can only be activated in the Cotton cycles, the sensors in the new Activa system come into operation. They affect both the selected temperature, keeping it at a constant level throughout the wash cycle, and the mechanical function of the drum. The drum is made to turn at two different speeds at crucial moments. When the detergent enters the garments, the drum rotates in such a way that the detergent is distributed in a uniform manner. However, during the wash and rinse procedures, the speed increases in order to maximise the cleaning action. Thanks to this special system, the efficiency of the wash procedure is improved WITHOUT ANY INCREASE IN THE LENGTH OF THE PROGRAM.

Super Rapide

This option can be used on the Cottons and Synthetics programmes. By selecting the Super Rapide option, the wash time can be reduced by up to 50 minutes, depending on the selected programme, temperature and load, without affecting the quality of the wash.

Prélavage

This option is particularly useful for heavily soiled loads and can be used before selecting the main wash programme. Detergent for this programme should be added to the first compartment of the soap drawer labelled "I" (Please refer to Detergent Drawer Section of manual). We recommend you use only 20% of the recommended quantities shown on the detergent pack and fabric conditioner should not be used for this programme.

Extra Rinçage

This option is available on the cottons programmes. The option increases the number of rinses to five (including the final conditioned rinse). This can help prevent skin irritation from detergent residue for people with particularly sensitive skin. Selecting the Extra Rinçage button is also recommended when washing heavily soiled fabrics which need a lot of detergent, or when the wash load contains towelling fabrics that have a greater tendency to retain detergent.

Wash Options

The options should be selected BEFORE pressing the

Départ/Pause button

40002960Eng.qxd 12/04/2005 15:11 Page 24

+ 56 hidden pages
