INSTRUCTION MANUAL
1
I
H
G
B
A
J
K
L
C
D
E
F
*
M
N
O
P
Q*
1 2
7 8
9 10
1
2
1
24 HRS
3 4
2
1
16 HRS
65
1
2
7 8
9 10
1
2
1
2
1211
INSTRUCTIONS FOR SAFE USE
This appliance should only be used for domestic cleaning, as
described in this user guide. Please ensure that this guide is fully
understood before operating the appliance.
Always switch o and remove the charger from the socket before
cleaning the appliance or any maintenance task.
This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall not be
made by children without supervision.
If the power cord is damaged stop using the appliance immediately.
To avoid a safety hazard, an authorised Hoover service engineer must
replace the power cord.
Keep hands, feet, loose clothing and hair away from rotating brushes.
Use only the original charger supplied with the appliance.
Check that your supply voltage is the same as that stated on the
charger.
This appliance is supplied with a double insulated battery charger
which is only suitable for insertion in a 230V (UK 240V) socket outlet.
Plug the charger in to suitable socket outlet and connect the power
cord connector to the DC socket on the appliance. [4]
When charging the appliance, the power switch must be o.
Before rst use, charge your appliance for 24 hours.
Do plug in the charger after use to recharge the batteries.
It is normal for the charger to become warm to the touch when charging.
Do not unplug the charger by pulling on the power cord.
Unplug the charger in the event of prolonged absence (holidays,
etc.). Recharge appliance again before use as batteries may self
discharge over increased periods of storage.
If the appliance is to be disposed of the batteries must rst be
removed. The appliance must be disconnected from the supply
mains when removing the battery. Dispose of the batteries safely.
6
Run the appliance until it stops because the batteries are fully
discharged. Used batteries should be taken to a recycling station
and not disposed of with household waste. To remove the batteries,
please contact the Hoover Customer Centre or proceed according to
the following instructions.
IMPORTANT: Always fully discharge the batteries before removal
and ensure the charger is unplugged.
1. Run the cleaner until the batteries are completely empty.
2. Remove the ergonomic handle and the screws, in the main
body to open the cleaner. [12]
3. Remove the motor battery housing and disconnect the cables.
4. Remove the batteries from the housing.
NOTE: Should you experience any diculty in dismantling the unit or
for more detailed information on treatment, recovery and recycling of
this appliance, please contact your local city oce or your household
waste disposal service.
DO NOT expose the batteries to a room temperature above 40°C.
Use only attachments, consumables or spares recommended or
supplied by Hoover.
Static electricity: Some carpets can cause a small build up of static
electricity. Any static discharge is not hazardous to health.
Do not use your appliance out of doors or on any wet surface or for
wet pick up.
Do not pick up hard or sharp objects, matches, hot ashes, cigarette
ends or other similar items.
Do not spray with or pick up ammable liquids, cleaning uids,
aerosols or their vapours.
Do not run over the power cord when using your appliance or remove
the plug by pulling on the power cord.
Do not continue to use your appliance or charger if it appears faulty.
Hoover service: To ensure the continued safe and ecient operation
of this appliance we recommend that any servicing or repairs are only
carried out by an authorised Hoover service engineer.
Do not use the appliance to clean animals or people.
7
Do not replace the batteries with non-rechargeable batteries.
Do frequently clean the dust cup and lter assembly.
The Environment:
This appliance is marked according to the European directive 2011/65/EC on Waste Electrical and Electronic
Equipment (WEEE). By ensuring this product is disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which could otherwise be caused by inappropriate waste
handling of this product. The symbol on the product indicates that this product may not be treated as household
waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic
equipment. Disposal must be carried out in accordance with local environmental regulations for waste disposal. For
more detailed information about treatment, recovery and recycling of this product, please contact your local city
oce, your household waste disposal service or the shop where you purchased the product.
This product complies with the European Directives 2006/95/EC, 2004/108/EC and 2011/65/EC.
Hoover Limited Pentrebach, Merthyr Tydl, Mid Glamorgan CF48 4TU
8
PRODUCT COMPONENTS
Main Cleaner Handheld cleaner Filters Accessories
A. Main Body
B. Push and Go Release Button
C. Handheld Cleaning Unit
D. Nozzle Release Button
E. Parking Lock
G. Dust Container
H. Bin Release Button
I. Charge Socket
J. On/O Switch
K. Bin Release Button
L. Shroud
M. Filter
N. Charger
*
O. Dusting Brush
P. Crevice Tool
Q. Rigid Extension Tube*
F. Nozzle Mode Selector
PREPARING YOU CLEANER
1. Assembly the handle by pushing it onto the main body until it locks in place [1].
2. Assembly the nozzle onto the neck of the main body. It will lock in place to remove press the nozzle
release button (D) and pull it from the main body [2].
3. Assembly the handheld cleaning unit to the main body [3].
4. Insert charger to handheld cleaning unit. For rst use charge your cleaner for 24 Hrs [4]. After rst use
the normal charging time is 16 Hrs.
NOTE: Use only the charger supplied with your cleaner to recharge.
IMPORTANT: When charging the cleaner the On/O switch must be OFF.
Keep the charger plugged into the socket at all times. It is normal for the charger to become warm to the
touch when charging.
If the operating times reduces after repeated use let the cleaner run until it stops then recharge for 24
hours, repeat this monthly for best results.
USING YOUR CLEANER
1. Prepare your cleaner for use by releasing the parking lock on the nozzle [5].
2. Turn on your cleaner by pressing the On/O switch on the handheld cleaning unit (J).
3. Use the nozzle mode selector to change between carpet and hard oor mode [6].
4. To use as a handheld cleaner press the “Push and Go” button to remove the handheld cleaning unit
from the main body [7].
5. The supplied accessories can be used in handheld mode [8].
CLEANER MAINTENANCE
Emptying the Dust Container
Hold the handheld cleaning unit over a bin and pull the bin empty trigger to empty the dust container [9].
Cleaning the Filters
1. Remove the handheld cleaning unit from the main body [7].
2. Press the bin release button and remove the dust container [10].
3. Remove the lter and shroud from the dust container [11].
4.
Wash the lter and shroud in lukewarm water.
NOTE: Do not use hot water or detergents when cleaning the lters.
Once thoroughly dry return them to the dust container.
In the unlikely event of the lters
becoming damaged, t a genuine HOOVER replacement. Do not try and use the product without a lter tted.
* Features vary according to model
1
End of Product Life Battery Disposal
If your cleaner is to be disposed ok, the batteries should be removed. Used batteries should be taken to a
recycling station and not disposed of with household waste.
IMPORTANT: Always fully discharge the batteries before removal.
1. Run the unit until the batteries are at.
2. Remove the handheld unit from the main body [7].
3. Press the bin release button and remove the dust container [10].
4. Remove 6 screws and to open the handheld cleaning unit [12].
5. Remove the Battery/Motor housing and disconnect the cables [12].
6. Remove the batteries from the housing [12].
NOTE: Should you experience any diculties in dismantling the unit or for more detailed information
about treatment, recovery and recycling of this product, please contact your local city oce or your
household waste disposal service.
HOOVER SPARES AND CONSUMABLES
Always replace parts with genuine HOOVER spares. These are available from your local HOOVER dealer or
direct from HOOVER. When ordering parts always quote your model number.
IMPORTANT: The battery in this cleaner is guaranteed for 6 months from purchase. After 6 months
the customer is liable for the cost of a new battery which will be tted free of charge by an authorised
HOOVER engineer.
Consumables
• PremotorHEPAlter:S9335600860
• Carpet&oornozzle:G14335601364
Spares
• Handheldunit:48007063
• Charger12V:48007064
• Charger14.4V:48007065
• Charger18V:48007066
YOUR GUARANTEE
The guarantee conditions for this appliance are as dened by our representative in the country in which
it is sold. Details regarding these conditions can be obtained from the dealer from whom the appliance
was purchased. The bill of sale or receipt must be produced when making any claim under the terms of
this guarantee.
Subject to change without notice.
2
11
PRINTED IN P.R.C.
48007739/01
