Honeywell VISTA-10P, VISTA-10PSIA User Manual

ADEMCO VISTA-10P

ADEMCO VISTA-10PSIA

Security Systems

User Guide

K0736V4 10/08 Rev. D

IMPORTANT!

PROPER INTRUSION PROTECTION

For proper intrusion coverage, sensors should be located at every possible point of entry to a home or commercial premises. This would include any skylights that may be present, and the upper windows in a multi-level building.

In addition, we recommend that radio backup be used in a security system so that alarm signals can still be sent to the Central Monitoring Station in the event that the telephone lines are out of order (alarm signals are normally sent over the phone lines).

EARLY WARNING FIRE DETECTION

Early warning fire detection is important in a home. Smoke and heat detectors have played a key role in reducing fire deaths in the United States. With regard to the number and placement of smoke/heat detectors, we subscribe to the recommendations contained in the National Fire Protection Association's National Fire Alarm Code (NFPA 72). These recommendations can be found on page 43 of this manual.

SYSTEM COMPATIBILITY NOTICE

Your Honeywell security system is designed for use with devices manufactured or approved by Honeywell for use with your security system. Your Honeywell security system is not designed for use with any device that may be attached to your security system's keypad or other communicating bus if Honeywell has not approved such device for use with your security system. Use of any such unauthorized device may cause damage or compromise the performance of your security system and affect the validity of your Honeywell limited warranty. When you purchase devices that have been manufactured or approved by Honeywell, you acquire the assurance that these devices have been thoroughly tested to ensure optimum performance when used with your Honeywell security system.

About This Manual

This manual is a step-by-step guide that will acquaint you with the system's features and benefits. It defines the components and their functions, describes their operation, and provides clear stepby-step instructions for normal and emergency procedures. Keep this manual in a convenient place so that you can refer to it as necessary.

– 2 –

Table of Contents

Table of ContentsTable of Contents

System Overview .................................................................................................................... 5

Introduction ........................................................................................................................... 5

System Basics ........................................................................................................................ 5

Using the Voice Message Center ......................................................................................... 7

About The Keypads ................................................................................................................ 8

General Information ............................................................................................................. 8

Functions of the Keypads ................................................................................................... 10

Entry/Exit Delays.................................................................................................................. 12

Exit Delay ............................................................................................................................ 12

Entry Delay ......................................................................................................................... 12

Exit Alarms ......................................................................................................................... 13

Checking For Open Zones .................................................................................................. 14

Using the [∗] Key................................................................................................................. 14

Arming the System ............................................................................................................... 15

Stay Mode: Arms Perimeter Only, Entry Delay On ......................................................... 15

Night-Stay Mode: Arms Perimeter Only, Plus Selected Zones ........................................ 15

Instant Mode: Arms Perimeter Only, Entry Delay Off .................................................... 15

Away Mode: Arms Entire System, Entry Delay On ......................................................... 15

Maximum Mode: Arms Entire System, Entry Delay Off ................................................. 15

Arming Commands ............................................................................................................. 16

Single Button Arming ......................................................................................................... 17

Step Arming Feature .......................................................................................................... 17

Using the Keyswitch ............................................................................................................ 18

Using the Keyswitch ........................................................................................................... 18

Disarming and Silencing Alarms ...................................................................................... 19

Using the [OFF] key ........................................................................................................... 19

Bypassing Protection Zones .............................................................................................. 20

Using the BYPASS Key ...................................................................................................... 20

Quick Bypass ....................................................................................................................... 21

Chime Mode ........................................................................................................................... 22

Date and Time ....................................................................................................................... 23

Viewing the Current Date and Time ................................................................................. 23

Setting the Date and Time ................................................................................................. 23

– 3 –

Table of Contents

Table of ContentsTable of Contents

Panic Keys .............................................................................................................................. 24

Using Panic Keys ................................................................................................................ 24

Macro Key Programming & Usage ................................................................................... 25

About Macro Keys ............................................................................................................... 25

Example of Macro Programming ....................................................................................... 26

Using a Programmed Macro Key ....................................................................................... 26

Using Device Commands .................................................................................................... 27

About Device Commands .................................................................................................... 27

Paging Feature ...................................................................................................................... 28

About Automatic Paging .................................................................................................... 28

Manual Paging .................................................................................................................... 29

Latch Key Paging ................................................................................................................ 29

Security Codes & Authority Levels .................................................................................. 30

About Security Codes .......................................................................................................... 30

Authority Level Definitions ................................................................................................ 30

How to Assign Security Codes and Attributes .................................................................. 31

Scheduling .............................................................................................................................. 32

About Scheduling ................................................................................................................ 32

Creating Schedules ............................................................................................................. 32

Event Logging Procedures ................................................................................................. 34

About Event Logging .......................................................................................................... 34

Viewing the Event Log ....................................................................................................... 34

Table of Event Log Codes ................................................................................................... 35

Testing the System (To Be Conducted Weekly) ............................................................ 36

About Testing the System ................................................................................................... 36

Trouble Conditions .............................................................................................................. 37

Maintaining Your System ................................................................................................... 40

Fire Alarm System (If Installed) ....................................................................................... 41

Quick Guide to Basic System Functions ......................................................................... 45

Summary of Audible/Visual Notifications ...................................................................... 46

Regulatory Statements and Warnings ............................................................................ 48

Charts of Your System’s Features .................................................................................... 50

– 4 –

Introduction

IntroductionIntroduction

Congratulations on your ownership of a Honeywell Security System. You've made a wise decision in choosing it, for it represents the latest in security protection technology today. This system provides:

• Three forms of protection: burglary, fire* and emergency

• At least one keypad which provides control of system and displays system status

• Various sensors for perimeter and interior burglary protection

• Smoke or combustion detectors* designed to provide early warning in case of fire. Your system may also have been programmed to automatically send alarm or status messages to a Central Monitoring Station.

* Commercial installations and some residential systems may not include fire protection – check with your installer.

NOTE: The features and procedures described in this manual apply to the ADEMCO VISTA-10P and ADEMCO VISTA-10PSIA. Differences are noted where applicable.

System Basics

System BasicsSystem Basics

Burglary Protection

• Several modes of burglary protection: Stay, Night-Stay, Away, Instant, Maximum. STAY: arms perimeter zones only and entry delay is on INSTANT: same as STAY, except entry delay is off NIGHT-STAY: arms perimeter zones and selected interior zones; entry delay on AWAY: arms perimeter and all interior zones, entry delay is on MAXIMUM: same as AWAY, except entry delay is off

• You can BYPASS selected zones while leaving the rest of the system armed.

• CHIME mode alerts you to the opening of protected doors and windows while the

system is disarmed.

Fire Protection and Carbon Monoxide Protection

• Fire and carbon monoxide protection is always active (if installed) and an alarm

sounds if a fire or carbon monoxide condition is detected

• If necessary, you can manually initiate a fire alarm using the keypad (if

programmed).

• Refer to the Fire Alarm System section for information regarding fire protection,

carbon monoxide protection, smoke detectors and planning emergency exit routes.

Security Codes

• You were assigned a 4-digit security code (master code) during installation.

• Use your security code when arming and disarming the system, and when

performing other system functions.

• Other users can be assigned different security codes, each with different

authority levels, which define the system functions a particular user can perform.

System Overview

System OverviewSystem Overview

– 5 –

System Overview

System Overview System Overview

Zones

• The system sensing devices have been assigned to various “zones,” which are

specific areas of protection (e.g., front door, kitchen window, etc.).

• Zone numbers are displayed at the keypad when an alarm or trouble condition

occurs on a sensor.

Arming, Step-Arming and Disarming Burglary Protection

• The system must be armed before the burglary protection can sense intrusions.

• To arm your system, enter your security code followed by the desired arming key.

• If programmed, the [#] key can be pressed in place of your security code when

arming the system (e.g., instead of entering your 4-digit security code + [3-STAY] to arm the system in STAY mode, you can press [#] + [3-STAY] ).

• You can also use the step-arming key, if programmed, to arm the system, which

lets you use a function key to arm the system in one of three modes by simply pressing the key repeatedly.

• To disarm the system, enter your security code then press the [OFF] key.

Alarms

• When an alarm occurs, the keypad sounds and displays the zone(s) causing the

alarm. For most alarms, the external sounder also sounds.

• If your system is connected to a Central Monitoring Station, an alarm message

will also be sent. (Delayed Reporting Note: By default, message reporting is not delayed. If desired, reporting can be delayed 15, 30, or 45 seconds to help reduce false alarms. See your installer if you want the delay time changed.)

• To stop the alarm sounding, simply disarm the system.

Memory of Alarm

• When an alarm condition occurs, the keypad displays the number(s) of the

zone(s) that caused the problem, and displays the type of alarm (e.g., “fire”).

• The message remains displayed even after disarming the system, but can be

cleared with another “off” sequence.

Phone Access

• If included, a phone module permits you to access the system via a touch-tone

phone, either on-premises or by calling-in when away.

• You can receive synthesized voice messages over the telephone regarding the

status of the security system.

• You can arm and disarm the system and perform most function commands

remotely via the telephone, with voice confirmation provided after each command entry.

• Complete information regarding the use of this feature is provided in a separate

manual entitled “Phone Access User's Guide” that is supplied with the voice module.

(Continued)

(Continued)(Continued)

– 6 –

OFF

MAX

INSTANT

READY

AWAY

TEST

CODE

STAY

BYPASS

CHIME

ARMED

READY

6160V-00-005-V0

MESSAGE

MIC

RECORD

VOLUME

PLAY

STATUS

VOICE

FUNCTION

VOLUME

KEY

VOICE

KEY

STATUS

KEY

FUNCTION

KEY

DOWN

VOLUME

PLAY KEY

AND

UP VOLUME

RECORD

KEY

SPEAKER

LCD

DISPLAY

MICROPHONE

LEDs

the red MESSAGE LED turns off.

System Overview

System Overview System Overview

(Continued)

(Continued)(Continued)

Paging Feature

• If programmed, the system can automatically send certain system condition

messages to a pager.

• The display consists of code numbers that indicate the type of condition that has

occurred.

Function Keys

• The “A”, “B”, “C”, and “D” keys on the keypad can be programmed to perform

various functions.

• Functions include: activate a Panic alarm; arm the system; provide step arming;

switch lights on/off; send a message to a pager; display Time/Date; start a Macro

Scheduling

• Your system can be programmed to automatically perform certain functions (e.g.,

arm the system) at a predetermined time each day.

Using the Voice Message Center (if Voice Keypad is installed)

Using the Voice Message Center (if Voice Keypad is installed)Using the Voice Message Center (if Voice Keypad is installed)

The Voice Keypads feature a voice message center that lets you record and playback one message.

• The message can be up to 2.5-minutes long

• The message remains in the keypad’s memory

until a new message is recorded.

• The volume control of the message is adjustable.

• Refer to the procedures below when using the

Message Center functions.

Message Center Functions

To… Press these keys… Notes…

record a message

end recording

play a message

adjust the volume

[#] FUNCTION + [0] VOICE + [1] RECORD

[1] RECORD

[#] FUNCTION + [0] VOICE + [3] PLAY

[#] FUNCTION + [0] VOICE + [2] VOLUME keys, then press volume key [3] ↑ (up) or [6] ↓ (down)

The red MESSAGE LED lights. Message remains in memory until a new message is recorded. The red MESSAGE LED flashes, indicating message waiting. The recorded message plays and

Adjusting message volume also adjusts status volume. Volume cannot be adjusted while playing.

– 7 –

About The Keypads

About The KeypadsAbout The Keypads

General Information

General InformationGeneral Information

Your keypads allow you to control all system functions. The keypads feature the following:

• A telephone style (digital) keypad

• Liquid Crystal Display (LCD) which shows the nature and location of all

occurrences

• Built-in sounder which will sound during alarms and troubles. The sounder also

"beeps" during certain system functions and when depressing any of the keys (to acknowledge the key press).

• Backlighting of the LCD display windows. Backlighting turns on when any key is

pressed, and when opening an entry/exit door while the system is armed. This feature is helpful when a keypad is located in a dimly lit area.

IMPORTANT: If the keypad beeps rapidly upon entering the premises, it indicates that an alarm has occurred during your absence and an intruder may still be on the premises. LEAVE IMMEDIATELY and CONTACT THE POLICE from a nearby safe location.

Your keypads are functionally the same, but may have different types of displays, depending on the type installed with your system.

Alpha Display 2-line alpha display keypads feature a 2-line, 32-character

alphanumeric LCD which can display system messages in friendly English. These keypads can also be programmed with

Fixed-Word Display Fixed-Word display keypads are functionally identical to Alpha

Voice Keypads Voice Keypads (if installed), are functionally the same as other

• Voice announcements of system status (see Checking for

• Voice chime, which can alert you to the opening of doors and

• Message center, which lets you record and playback

custom zone descriptors.

display keypads, but the LCD display uses pre-designated words to identify the nature and location of occurrences.

keypads, except that these keypads can provide the following:

Open Zones section)

windows while the system is disarmed (see Voice Chime in Chime mode section)

messages (see Using the Voice Message Center in the System Overview section).

– 8 –

ALARM FIRE

AWAY

BYPASS

STAY

CHECK INSTANT CANCELED

NIGHT NO AC

NOT READY

CHIME BAT

PHONE TEST

6150disp

About The Keypads (Con

About The Keypads (Continued)

About The Keypads (ConAbout The Keypads (Con

tinued)

tinued)tinued)

Fixed-Word Display Keypad

AWAY: All burglary zones, interior and

perimeter, are armed.

STAY: Perimeter burglary zones, such as

protected windows and doors, are armed.

INSTANT: Entry delay is turned off: Lit with STAY = Instant mode

Lit with AWAY = Maximum mode

BYPASS: This appears when one or more burglary protection zones have been

bypassed.

NOT READY: Appears when burglary portion of the system is not ready for arming

(due to open protection zones). The system is ready to arm when this message disappears and the READY indicator light comes on.

NO AC: Appears when AC power has been cut off. System is operating on

backup battery power.

AC: Appears when AC power is present. CHIME: Appears when the CHIME feature is activated.

BAT: Low battery condition in a wireless sensor (if zone number displayed)

or low system battery (if no zone number displayed).

ALARM: Appears when an intrusion has been detected and the system is armed

(also appears during a fire alarm or audible emergency alarm). Accompanied by the protection zone in alarm.

CHECK: Appears when a malfunction is discovered in the system at any time or

if an open is detected in a FIRE zone at any time or a fault in a DAY/NIGHT burglary zone during a disarmed period. Accompanied by a display of zone number in trouble.

FIRE: Appears when a fire alarm is present. Accompanied by a display of the

zone in alarm.

A FIRE display also appears when a fire alarm is manually activated,

accompanied by a display of emergency key zone number programmed for fire.

NIGHT: Appears with “STAY” when the system is armed in Night-Stay mode

(perimeter burglary zones and pre-selected interior zones set by your installer are armed).

CANCELED: Appears when an alarm has been canceled (see Exit Alarm section for

more information on canceled alarms and displays).

FIXED-WORD DISPLAY (6150 shown)

– 9 –

Functions of the Keypads

Functions of the KeypadsFunctions of the Keypads

NOTE: The functions printed directly on the keys indicate their primary purpose; the functions printed under some of the keys (shown in brackets under the respective key), indicate their alternate or secondary purpose.

DISPLAY WINDOW

Alpha Display Keypads:

Liquid Crystal Display (LCD) keypads that display protection points, system status, and messages.

Fixed-Word Display Keypads:

protection zone ID and system status messages using pre-designated words in the LCD display area.

[VOICE]

VOLUME and PLAY functions.

1 OFF

silences alarms and audible trouble indicators, and clears visual display after problem's correction.

[RECORD]

with the FUNCTION and VOICE keys to record up to a 2.5-minute message.

2 AWAY

perimeter and interior.

[VOLUME]

with the FUNCTION and desired volume control keys ↑ [3] or ↓ [6] to adjust the volume of a recorded message or voice system status.

3 STAY

system only. Interior protection is not armed, allowing movement within premises without causing an alarm. If pressed twice in succession, arms system in Night-Stay mode.

[PLAY]

the FUNCTION and VOICE keys to play the recorded message.

[ ↑ ]

FUNCTION and VOLUME keys to raise the message and voice system status volume.

4 MAXIMUM Arms the entire burglary system,

perimeter and interior, but without entry delay. Entering via an entry/exit door will cause an alarm.

5 TEST

disarmed. Refer to Testing The System section for test procedures.

On Voice keypads, enables the RECORD,

Disarms burglary portion of the

On Voice keypads, used in conjunction

Arms the entire burglary system,

On Voice keypads, used in conjunction

Arms perimeter portion of burglary

On Voice keypads, used in conjunction with

On Voice keypads, used in conjunction with the

Tests the system and alarm sounder if

2-line, 32-character

Display

system,

6 BYPASS

being monitored by the system.

[ ↓ ]

On Voice keypads, used in conjunction with the FUNCTION and VOLUME keys to lower the message and voice system status volume.

7 INSTANT

mode, but without the entry delay feature.

8 CODE

and attributes for other users of the system.

9 CHIME

opening of windows or doors while the system is disarmed sounds 3 beeps at the keypad(s).

KEYS 0–9:

perform their associated system functions.

∗ READY

[STATUS]:

STATUS key annunciates the current system status. Pressing the STATUS key a second time annunciates and displays system and/or zone faults (if they exist).

# T

the system without use of a security code (if programmed).

[FUNCTION]

voice or volume function.

FUNCTION KEYS:

programmed for a variety of functions, including panic (emergency) functions. For details, see the Function Keys section.

ARMED LED INDICATOR:

system has been armed.

READY LED INDICATOR:

system is ready to be armed (no faults present). While the system is disarmed, this indicator will go on and off as protection zones are closed and opened.

MESSAGE LED INDICATOR:

keypads, flashes red when message waiting or lights red (steady) when in record mode.

MIC:

recordings.

INTERNAL SPEAKER:

the alarm sounder during alarms, and will also "beep" during certain system functions. The speaker also provides voice playback for any recorded messages.

Removes individual protection zones from

Arms in manner similar to the STAY

Used to assign additional security codes

Turns

CHIME mode on and off.

Used to enter the security code(s) and to

Used to display all open protection zones.

On Voice keypads, a momentary press of the

his key can be used for "Quick Arming" of

On Voice keypads, enables the desired

Keys A, B, C, D may have been

(RED) Lit when the

(GREEN) Lit when the

(RED) On Voice

On voice keypads, microphone for Message Center

The built-in speaker mimics

When on, the

– 10 –

OFF

MAX

INSTANT

READY

AWAY

TEST

CODE

STAY

BYPASS

CHIME

ARMED

READY

6160V-003-V0

MESSAGE

MIC

SPEAKER

LCD

DISPLAY

FUNCTION

KEYS

MICROPHONE

LEDs

RECORD

VOLUME

PLAY

STATUS

VOICE

FUNCTION

Functions of the Keypads (Continued)

Functions of the Keypads (Continued)Functions of the Keypads (Continued)

Voice-capable 2-line Alpha keypad

(shown with flip-down front door removed)

IMPORTANT!

• When entering codes and commands, sequential key depressions must be made within 4-5 seconds of one another. If 4-5 seconds elapse without a key depression, the entry will be aborted and must be repeated from its beginning. Be sure to observe this precaution when performing any of the procedures in this manual.

• If you make a mistake while entering a security code, stop, press the [✱] key, and then start over. If you stop in the middle while entering a code, and then immediately start the entry over, an erroneous code might be entered.

Wireless Key Fobs

Your system may also include one or more wireless key fobs, which can perform various functions as programmed by your installer.

IMPORTANT SECURITY NOTICE

Your key fob is similar to your keys or access card. If lost or stolen, another person can compromise your security system. Immediately notify your Dealer/Installer of a lost or stolen key fob. The Dealer/Installer will then remove the key fob programming from the security system.

– 11 –

Entry/Ex

Entry/Exit Delays

Entry/ExEntry/Ex

Your system has preset time delays, known as exit delay and entry delay.

Exit Delay

Exit DelayExit Delay

Exit delay gives you time to leave through the designated exit door(s) without setting off an alarm. Exit delay begins immediately after arming your system in any arming mode and Alpha Display keypads display the message “You May Exit Now.” When “You may exit now” disappears, the system is fully armed. If programmed, a slow beeping will sound during the exit delay period until the last 10 seconds, which then changes to fast beeping (alerting you to the end of exit delay). If you cannot leave by this time, you should stop, disarm the system, and start over to avoid a false alarm.

Exit Delay Restart/Reset. If you wish to open the entry/exit door to let someone in after

arming STAY, you can re-start the exit delay at any time – simply press the [✱] key, then let that person in (the perimeter zones remain armed). The system automatically re-arms the entry/exit door when exit delay expires, which avoids having to disarm the system and then re-arm it again.

In addition, when the system is armed AWAY, reopening and closing the entry/exit door before exit delay time expires (e.g., reentering to get a forgotten item) will reset the exit delay time once.

Entry Delay

Entry DelayEntry Delay

Entry Delays give you time to disarm the system when you re-enter through the designated entrance door. There are two entry delays (if programmed). The first is for your primary entrance and the second can be used for a secondary entrance, where a longer delay is required to walk to the keypad to disarm the system.

You must disarm the system before the entry delay period ends, or an alarm will occur. The keypad beeps during the entry delay period, reminding you to disarm the system. The beeps stop when a code is entered, but will restart after about 15 seconds if an invalid code is entered.

You can also arm the system with no entry delay at all by using the INSTANT or MAXIMUM arming mode. This mode provides greater security while on the premises or while away for extended periods of time.

See your installer for your delay times.

it Delays

it Delaysit Delays

Exit Delay: seconds Entry Delay 1: seconds

– 12 –

Entry Delay 2: seconds

Exit Alarms

Exit AlarmsExit Alarms

Exit Error Conditions

Whenever you arm the system, the exit delay begins. If an entry/exit door or interior zone is faulted before exit delay expires and remains faulted (e.g., exit door left open), the system sounds an alarm and starts the entry delay timer. If you disarm the system before the entry delay ends, the alarm sound stops and the message "ALARM CANCELED " or "CA" is displayed on the keypad, along with a zone number indicating the faulted zone. No message is sent to the Central Monitoring Station.

To clear the exit error condition, the open zone must be made intact; to clear the display, enter your code plus OFF.

If you do not disarm the system before the entry delay ends and the faulted zone remains open, the alarm sound continues and an "exit alarm" message is sent to the Central Monitoring Station (after the installer-programmed dial delay expires). The message "EXIT ALARM" or "EA" is displayed on the keypad, along with a zone number indicating the faulted zone. To stop the alarm, the system must be disarmed (your code plus OFF); to clear the display, enter your code plus OFF a second time.

An “exit alarm” also results if an entry/exit door or interior zone is faulted within two minutes after the end of the exit delay.

Your system may have been programmed for this feature to minimize false alarms sent to the Central Monitoring

Station. Ask your installer if "Exit Alarm" is active in your system. If so, check this box.

VISTA-10PSIA: The Exit Error condition works the same as described above, except that in addition to the “EXIT ALARM” message, a “zone alarm” message is also sent to the Central Monitoring Station. In addition, if an entry/exit door or interior zone is faulted within two minutes after the end of the exit delay, a “Recent Closing” condition occurs instead of the “exit alarm.” Refer to the next paragraph for details.

“Recent Closing” Condition (VISTA-10PSIA only)

A Recent Closing condition is similar to the Exit Error condition described above, but occurs if an entry/exit door or interior zone is faulted within two minutes after the initial exit delay expires. If you disarm the system within the two minutes, the alarm sound stops and the message "ALARM CANCELED " or "CA" is displayed on the keypad, along with a zone number indicating the faulted zone. No message is sent to the Central Monitoring Station.

If you do not disarm the system within two minutes and the faulted zone remains open, the alarm sound continues and a “recent closing” and a “zone alarm” message are sent to the Central Monitoring Station (after the installer-programmed dial delay expires). The alarm message along with a faulted zone number is displayed on the keypad. To stop the alarm, the system must be disarmed (your code plus OFF); to clear the display, enter your code plus OFF a second time.

Entry/Exit Delays

Entry/Exit Delays Entry/Exit Delays

(Contin

(Continued)

(Contin(Contin

ued)

ued)ued)

– 13 –

Check

Checking For Open Zones

CheckCheck

Using the [

Using the [∗∗∗∗] Key

Using the [Using the [

ing For Open Zones

ing For Open Zonesing For Open Zones

] Key

] Key] Key

efore arming your system, all protected doors, windows and other protection zones must be

closed or bypassed, otherwise the keypad will display a "Not Ready" message.

1. Press [∗] READY (do not enter code first) to display

faulted zones.

2. Secure or bypass the zones displayed.

The keypad’s READY indicator lights when all protection zones have been either closed or bypassed.

4. Arm the system as desired.

Voice Status: Voice Keypads (if installed), can announce system status and faulted zones (up to 3 zone descriptors) if the Voice Status feature is turned on.

To turn the Voice Status feature on/off:

(also turns on Voice Chime mode; see Chime mode section)

To announce Status: Press [#] FUNCTION + [0] VOICE + [∗] STATUS key. (Announces current system status; e.g., “Disarmed Ready to Arm.”)

To announce faults: Press [#] FUNCTION + [0] VOICE + [∗] STATUS + [∗] again.

(Announces up to three faulted zones with their zone descriptors, if programmed.)

Alpha Display:

DISARMED - PRESS ∗ TO SHOW FAULTS

Fixed-Word Display:

Zone no. and “NOT READY”

# + 0 + 2 + 4

– 14 –

Arming the System

Arming the SystemArming the System

Stay Mode: Arms Perimeter Only, Entry Delay On

Stay Mode: Arms Perimeter Only, Entry Delay OnStay Mode: Arms Perimeter Only, Entry Delay On

• Used when you want to arm the system with persons staying inside (or if you have pets

that are moving throughout the premises).

• The perimeter sensors are armed, but interior sensors are left disarmed.

• Exit delay begins (you can leave through the entry/exit door, if desired).

• An alarm sounds if any protected window or non-entry/exit door is opened.

• You may otherwise move freely within the premises.

• Persons entering later can enter through an entry/exit door, but they must disarm the

system within the entry delay period to avoid sounding an alarm.

Night

Night----Stay Mode: Arms Perimeter Only, Plus Selected Zones

NightNight

Instant Mode: Arms Perimeter Only, Entry Delay Off

Instant Mode: Arms Perimeter Only, Entry Delay OffInstant Mode: Arms Perimeter Only, Entry Delay Off

Away Mode: Arms Entire System, Entr

Away Mode: Arms Entire System, Entry Delay On

Away Mode: Arms Entire System, EntrAway Mode: Arms Entire System, Entr

Maximum Mode: Arms Entire System, Entry Del

Maximum Mode: Arms Entire System, Entry Delay Off

Maximum Mode: Arms Entire System, Entry DelMaximum Mode: Arms Entire System, Entry Del

Stay Mode: Arms Perimeter Only, Plus Selected Zones

Stay Mode: Arms Perimeter Only, Plus Selected ZonesStay Mode: Arms Perimeter Only, Plus Selected Zones

• Use Night-Stay mode to provide increased security while staying inside.

• Arms same as Stay mode, but also arms pre-selected interior sensors (programmed by your

installer), while other interior sensors are left disarmed.

• Persons entering later can enter through an entry/exit door but they must disarm the

system and must not violate any of the programmed interior zones to avoid sounding an alarm.

• IMPORTANT: When Night-Stay mode is on, the selected interior zones are armed and cause an alarm if

anyone enters those areas (e.g., waking in the middle of the night). To avoid sounding an alarm, you must disarm the system before any activity takes place in those interior zones.

• Used when staying inside and do not expect anyone to use an entry/exit door.

• Arms same as Stay mode.

• An alarm sounds immediately if any protected perimeter window or any door is opened,

including entry/exit doors.

• IMPORTANT: Arming in this mode greatly increases the chance of false alarms. Use extreme care in

selecting this mode of arming.

y Delay On

y Delay Ony Delay On

• Used when nobody will be staying inside (including pets).

• The entire system (interior and perimeter) is armed.

• Exit delay begins letting you leave through the entry/exit door.

• An alarm sounds if a protected window or any door is opened, or if any movement is

detected inside your premises.

• You can reenter through an entry/exit door, but you must disarm the system within the

entry delay period to avoid sounding an alarm.

ay Off

ay Offay Off

• Used when leaving the premises for extended periods (e.g., vacation).

• Arms same as Away mode, but entry delay is off.

• An alarm sounds same as Away mode, and sounds upon opening entry/exit doors.

– 15 –

Arming the System

Arming the SystemArming the System

Arming Commands

Arming CommandsArming Commands

Before arming, close all perimeter doors and windows and make sure the Ready to Arm message is displayed.

Modes of Arming

Mode Press these keys… Keypad Confirms By…

Stay security code + [3] (STAY)

Night-Stay security code + [3] + [3]

Instant security code + [7] (INSTANT)

Away security code + [2] (AWAY)

Maximum security code + [4] (MAXIMUM)

† Arming Ding: In addition to the keypad beeps, the external sounder emits a short “ding” sound after arming, if programmed to do so. The ding confirms that the system is armed, and may occur immediately after the command or be delayed (until arm/disarm report is sent or exit delay expires). Ask your installer about how this feature is set for your system.

Quick Arming

If "Quick Arming" was programmed by the installer, the security code when arming the system in any of its arming modes (except Night-Stay). However, the security code must always be used when manually disarming the

system.

Function Key Arming

For any arming command, a function key may have also been programmed for your system. If so, you can press and hold the appropriate function key for 2 seconds to arm the system. See your installer for the designated functions (see Single Button Arming section).

• three beeps†

• armed STAY message displayed

• red ARMED indicator lights

• three beeps†

• NIGHT-STAY message displayed

• red ARMED indicator lights

• three beeps†

• armed STAY message displayed

• red ARMED indicator lights

• also note that entry delay is turned off.

• two beeps†, or, if programmed, beeping for

duration of exit delay

• armed AWAY message displayed

• red ARMED indicator lights

Leave the premises through an entry/exit door during the exit delay period to avoid causing an alarm. The keypad beeps rapidly during the last 10 seconds of the exit delay to warn you that it is ending.

• same as Away (described above) Note that entry delay is turned off.

[#]

key can be pressed in place of the

– 16 –

The keypad begins beeping and displays the ar

med

Single Button Arming

Single Button ArmingSingle Button Arming

The “A”, “B”, “C”, and/or “D” keys on your keypad may have been programmed for singlebutton arming. Note that while it will not be necessary to use a security code for arming, a security code must always be used when manually disarming the system.

If Single-Button Arming is programmed:

• A function key has been assigned to a specific type of arming: STAY mode, Night-STAY

mode, AWAY mode, or STEP-ARMING (see Step-Arming paragraph).

• You DO NOT need to enter your security code before pressing the function key (but you always need your security code to DISARM the system).

Before arming, close all perimeter doors and windows.

1. Press and hold the assigned function key for 2 seconds (no code is required). Function keys are shown below.

2. message. The red ARMED indicator also lights.

Step Arming Feature

Step Arming FeatureStep Arming Feature

Single-Button “Step” arming may have been programmed into one of the lettered keys (A, B, C, or D). Check with your installer to see if this has been done in your system.

If Step-Arming is programmed:

• The assigned key provides a choice of three levels of security.

• The selected key can be pressed once, twice, or three times, increasing the level of

security with each press, as follows

Key



A, B, C, D

Arming the System

Arming the SystemArming the System

First Press



Second Press



Armed-STAY Armed Night-STAY

(if programmed)

Alpha Display:

DISARMED READY TO ARM

Fixed-Word Display: READY

Alpha Display:

ARMED***AWAY*** YOU MAY EXIT NOW

Fixed-Word Display: AWAY

Third Press



Armed-AWAY

– 17 –

Using the Keyswitch

Using the KeyswitchUsing the Keyswitch

Using the Keyswitch

Using the KeyswitchUsing the Keyswitch

Your system may be equipped with a keyswitch for use when arming and disarming. Red and green lights on the keyswitch plate indicate the status of your system as follows: Green Light: Lights when the system is disarmed and ready to be armed (no open

zones). If the system is disarmed and the green light is off, it indicates the system is not ready (one or more zones are open).

Red Light: Lights or flashes when system is armed in AWAY or STAY mode. See your

installer for the meanings of the lit red light:

system armed STAY and exit delay has expired

Flashing = system armed STAY and exit delay timer active

Rapid flashing = an alarm has occurred (memory of alarm).

Before arming, close all perimeter doors and windows.

To arm in the AWAY mode:

Turn the key to the right for 1/2 second and

release. Keypads beep twice and the red indicator lights or flashes.

To arm in the STAY mode:

Turn the key to the right and hold for longer

than 1 second, then release. Keypads beep three times and the red indicator lights or flashes.

To disarm the system:

Turn the key to the right and release. The red

light turns off

Lit Steady = system armed AWAY or

GREEN RED

keyswitch-001-V1

– 18 –

Using the [OFF] key

Using the [OFF] keyUsing the [OFF] key

The OFF key is used to disarm the system, silence alarm and trouble sounds, and clear alarm memories.

IMPORTANT: If you return and the main burglary sounder is on, DO NOT ENTER, but CONTACT THE POLICE from a nearby safe location.

If you return after an alarm has occurred and the main sounder has shut itself off, the keypad will beep rapidly upon your entering, indicating that an alarm has occurred during your absence.

LEAVE AT ONCE, and CONTACT THE POLICE from a nearby safe location.

1. + 1

(Security Code)

The “READY” indicator light will be lit if all zones

are secure, and the keypad will emit a single tone to confirm that the system is disarmed.

NOTE: If entry delay has started (you’ve opened the

entry door), you do not need to press the OFF key; simply enter your security code. The system will disarm in about 15 seconds after the last digit of the code is entered.

2. To Silence a Burglary Alarm and Clear a Memory of Alarm

Enter your security code. This disarms the system and silences the alarm (or

warning tones of a Memory of Alarm).

Note the zone in alarm on the keypad display, and make that zone intact (close

door, window, etc.). Now enter the security code plus OFF to clear the keypad’s Memory of Alarm display.

3. To Silence a Fire Alarm or Carbon Monoxide Alarm and Clear Memory of Alarm

Simply press the OFF key to silence the alarm. Then enter the security code plus

OFF sequence to clear the keypad's Memory of Alarm display. See the Fire Alarm

System section.

Disarming and Silencing Alarms

Disarming and Silencing AlarmsDisarming and Silencing Alarms

Alpha Display:

OFF

DISARMED READY TO ARM

Fixed-Word Display: READY

– 19 –

After each command string

, the keypad

momentarily

Bypassing Protection Zones

Bypassing Protection ZonesBypassing Protection Zones

Using the BYPASS Key

Using the BYPASS KeyUsing the BYPASS Key

Use t

his key when you want to arm your system with one or more zones intentionally

unprotected.

Vent Zones: Your system may have certain windows set as “vent” zones, which are automatically bypassed if left open when arming the system (you do not need to manually bypass them). However, if a vent zone window is closed after arming, it becomes protected and will cause an alarm if opened again while the system is armed.

When bypassing zones:

• The system must be disarmed before you can bypass zones.

• Bypassed zones are unprotected and will not cause an alarm if violated.

• The system will not allow fire zones to be bypassed.

• Zones are automatically unbypassed when the system is disarmed.

1. + 6 + zone numbers (see below)

Alpha Display:

(Security Code)

BYPASS

Enter the 2-digit zone number for the zone to be

bypassed. Single digit zone numbers must be preceded by a zero (e.g. 05, 06).

Repeat the command string for each zone to be

bypassed.

displays a "Bypass" message for the bypassed zone number.

Arm the system as usual. When armed, the arming

message is displayed with “ZONE BYPASSED.”

To display bypassed zones prior to arming, enter

your security code and press the [6] BYPASS key.

DISARMED HIT * FOR FAULTS

Fixed-Word Display: NOT READY

Alpha Display:

DISARMED BYPASS READY TO ARM

Fixed-Word Display: BYPASS

ARMED: STAY ZONE BYPASSED

Typical armed alpha display after bypassing zones.

– 20 –

+ 44 hidden pages
