Honeywell VisionPRO 8000 Wi-Fi User Manual

Wi-Fi VisionPRO

User Guide

8000

Features of your Wi-Fi VisionPRO thermostat

With your new thermostat, you can:

• Connect to the Internet to monitor and control your heating/cooling system.

• View and change your heating/cooling system settings.

• View and set temperature and schedules.

• Receive alerts via email and get automatic upgrades.

• View outdoor temperature and humidity.

• Download the free Total Connect Comfort app.

Once connected to Wi-Fi and registered to Total Connect Comfort, you can control your thermostat from anywhere through your laptop, tablet, or smartphone with the Total Connect Comfort app. The Total Connect Comfort free app is available for Apple® iPhone®, iPad® and iPod touch® devices at iTunes® or at Google Play® for all Android™ devices.

For assistance please visit http://yourhome.honeywell.com,

33-00066EFS—03 1

GET IT ON

Need Help?

or call toll-free: 1-855-733-5465

Download on

iTunes

Table of contents

Programming and Operation

Quick reference ...........................................3

Connecting to Wi-Fi..................................... 5

Registering your thermostat online ............. 8

Setting the time/date ................................. 12

Setting the fan ........................................... 13

Setting system mode ................................14

Preset energy-saving schedules ............... 15

Adjusting program schedules .................... 16

Schedule overrides ...................................18

Menu Options

Viewing equipment status ......................... 20

Setting vacation, holiday, and events ........ 21

Setting holiday/event schedules:

commercial use ......................................... 22

Setting humidification and

dehumidification ........................................ 27

Setting ventilation ...................................... 30

Setting preferences ................................... 32

33-00066EFS—03 2

Cleaning the thermostat screen ................ 33

Security settings ........................................34

Viewing dealer information ........................ 35

Advanced features ....................................36

Disconnecting your Wi-Fi network ............37

Reconnecting your Wi-Fi network .............38

Unregistering your thermostat ..................39

Checking signal strength ........................... 40

Unsuccessful connection .......................... 41

Connecting to a hidden Wi-Fi network ...... 42

Appendices

Installer options ......................................... 44

Troubleshooting ......................................... 45

Regulatory information .............................. 47

Quick reference: residential use

HOME. Touch to display Home screen. FAN. Select fan mode. SYSTEM. Select system mode (Heat/Cool). MENU. Touch to display options. Start here to set

a program schedule. Current status. Shows system mode (heat/

cool), outdoor temperature and humidity (with optional outdoor sensor).

Current schedule. Touch an arrow to change temperature setting and select a Temporary or Permanent Hold.

Indoor conditions. Shows indoor temperature and humidity.

Current time. Touch to set the current time/date.

The screen lights when you press any button. It stays lit for 45 seconds after you complete changes. Depending on how your thermostat was installed, the screen light may always be on.

33-00066EFS—03 3

Alert Light. On when alert message is

active or system is set to EmHeat.

Quick reference: commercial use

HOME. Touch to display Home screen. FAN. Select fan mode. SYSTEM. Select system mode (Heat/Cool). MENU. Touch to display options. Start here to set a

program schedule. Current status. Shows system mode (heat/cool),

outdoor temperature and humidity (with optional outdoor sensor).

Override. Touch to override program schedule. Current schedule. Touch an arrow to change

temperature setting and set a temporary hold.

Current program status. Indoor conditions. Shows indoor temperature and

humidity.

The screen lights when you press any button. It stays lit for 45 seconds after you complete changes. Depending on how your thermostat was installed, the screen light may always be on.

4 33-00066EFS—03

Current time. Touch to set the current time/date.

Alert Light. On when alert message is active

or system is set to EmHeat.

Connecting to Wi-Fi

1 Connect to the Wi-Fi network.

1.1 Touch MENU

1.2 Select

1.3 The screen displays “Finding

1.4 Find the name of the network you

NOTE: If the Wi-Fi network name is

hidden, see “Connecting to a hidden Wi-Fi network” on page 42.

33-00066EFS—03 5

Wi-Fi Setup.

The thermostat will scan for available Wi-Fi networks.

Networks Please Wait” after which it displays a list of all Wi-Fi networks it can find.

want to use by pressing the arrow buttons to scroll up/down or left/ right. Press the Wi-Fi network name, then press Select.

DoaIol Inrol Madorl

Wi-Fi Setup

Installer Options

Finding Networks

Please Wait

Select Wi-Fi Network

Your Network

Connecting to Wi-Fi

1.5 When prompted, press the screen to edit the password (if necessary).

1.6 Enter the password. Press the s or t buttons to change the letter or number. Press the button to move to the next character, or the button to move to the previous character. Use the s or t buttons at the bottom to change letter case. Press Done when complete.

6 33-00066EFS—03

Enter Password

Press Here to Edit

Delete Space AC

Connecting to Wi-Fi

1.7 The screen will let you know when the connection is successful. Press Done when the connection is successful. If the connection is not successful, the screen will explain why not. See “Unsuccessful connection” on page 41. Follow instructions on the screen to try again.

NOTE: Press the t for more

information about an unsuccessful connection.

1.8 If you want remote access to the thermostat, you must set up an account at

mytotalconnectcomfort.com and add the thermostat to the account.

NOTE: You will need the thermostat MAC and CRC IDs to add the thermostat.

They are on the screen under Menu, Wi-Fi Setup and on the Thermostat ID Card packed with the thermostat.

To register your thermostat, follow the instructions beginning on page 8.

33-00066EFS—03 7

Connection

Successful

Registering your thermostat online

To view and set your Wi-Fi thermostat remotely, you must have a Total Connect Comfort account. Use the following steps.

1 Open the Total Connect Comfort web

site.

Go to mytotalconnectcomfort.com

8 33-00066EFS—03

M31570

Registering your thermostat online

2 Login or create an account.

If you have an account, click Login

– or – click Create An Account 2a Follow the instructions on the screen. 2b Check your email for an activation

message from My Total Connect Comfort. This may take several minutes.

NOTE: If you do not receive a response,

check your junk mailbox or use an alternate e-mail address.

2c Follow activation instructions in

the email.

2d Log in.

33-00066EFS—03 9

Printed in U.S.A.

69-2723EFS-01

Registering your thermostat online

3 Register your Wi-Fi thermostat.

After you are logged in to your Total Connect Comfort account, register your thermostat.

3a Follow the instructions on

the screen. After adding your thermostat location, you must enter the thermostat’s unique

Thermostat ID Card

Use the MAC ID and CRC ID to register this product at mytotalconnectcomfort.com

Carte d’identification de thermostat

Utilisez l’identication MAC et l’identication CRC pour

enregistrer ce produit à mytotalconnectcomfort.com

Tarjeta de identificación del termostato

Utilice la identicación MAC y la identicación CRC para

inscribir este producto en mytotalconnectcomfort.com

HONEYWELL MODEL: RTH8580WF

MAC ID: MAC CRC:

identifiers:

• MAC ID

MAC ID MAC CRC

• MAC CRC

NOTE: These IDs are listed on the

10 33-00066EFS—03

Registering your thermostat online

When the thermostat is successfully registered, the Total Connect Comfort registration screen will display a SUCCESS message.

You can now control your thermostat from anywhere through your laptop, tablet, or smartphone.

Total Connect Comfort free app is available for Apple® iPhone®, iPad® and iPod touch® devices at iTunes® or at Google Play® for all Android™ devices.

33-00066EFS—03 11

GET IT ON

Download on

iTunes

Setting the time/date

1 Touch the current time. The screen

displays Select Option.

2 Touch Time or Date, then touch Select. 3 Touch s or t until the proper time/date

is displayed.

4 Touch Done to save or Cancel to ignore

changes.

5 Touch Home to redisplay the Home

screen.

NOTE: When registered to Total Connect

Comfort, the thermostat automatically sets the time and adjusts for Daylight Saving Time.

12 33-00066EFS—03

Select Option

Time Date

Please Set Time

:30 PM

Setting the fan

1 Touch FAN to display fan settings. 2 Touch On, Auto, Circ, or Follow Schedule. 3 Touch Done to save and exit.

On: Fan is always on. Auto: Fan runs only when the heating

or cooling system is on. Circ: Fan runs randomly about 35% of

the time (residential use only). Follow Schedule: Fan controlled by

program (see pages 15–19).

33-00066EFS—03 13

On Auto Circ

NOTE: In commercial use,

touch Auto or On to temporarily override the programmed fan schedule.

Setting system mode

1 Touch SYSTEM to display system

settings.

2 Touch desired option:

Heat: Controls only the heating system.

Cool: Controls only the cooling system.

Off: Heating/cooling systems are off. Auto: Selects heating or cooling

depending on the indoor temperature.

Em Heat (heat pumps with aux. heat): Controls auxiliary/emergency

heat. Compressor is locked out.

3 Touch Done to save and exit.

14 33-00066EFS—03

Heat Cool Auto

Off

NOTE: The Auto and Em

Heat system settings may not

appear, depending on how your thermostat was installed.

Preset energy-saving schedules

This thermostat uses default Energy Saver settings that can reduce your heating/cooling expenses. To customize settings, see next page.

Heat

(Mon-Fri)Period

Wake 6:00 am 70° 78° 70° 78° Leave 8:00 am 62° 85° 62° 85° Return 6:00 pm 70° 78° 70° 78° Sleep 10:00 pm 62° 82° 62° 82°

Residential Use

Occupied 1 8:00 am 70° 75° On Unoccupied 1 10:00 pm 55° 85° Auto Occupied 2* 12:00 am 70° 75° On Unoccupied 2* 12:00 am 55° 85° Auto

Commercial Use

* Period 2 is cancelled by default. If you activate it, the values shown above are

default settings.

33-00066EFS—03 15

Cool

(Mon-Fri)Start time

Heat

(Sat-Sun)

CoolStart time HeatPeriod Fan

Cool

(Sat-Sun)

Adjusting program schedules

1 Touch MENU. 2 Select Edit Schedule to display Use

Scheduling Assistant?

• Touch Yes to create a schedule by answering simple questions.

• Touch No to manually create a program schedule. See page 17.

16 33-00066EFS—03

Edit Schedule

View Schedule

Use Scheduling

Assistant?

Adjusting program schedules (continued)

3 Select the days to schedule, touch Next. 4 Touch s or t to set your Wake time for

selected day(s).

5 Touch s or t to set Heat and Cool

temperatures for the Wake period.

6 Touch other time periods (Leave, Return,

Sleep) to set time and temperatures for

each.

7 Touch Done to save and exit (Touch Cancel

to exit without saving changes).

NOTE: Touch Cancel Period to eliminate

any unwanted time period.

NOTE: Touch Fan Setting to customize fan

settings for any time period.

33-00066EFS—03 17

Select the days

to schedule

Set Wake

time & temperature

Overriding schedules: residential use

1 Touch s or t to adjust the

temperature (right side of screen) and the Hold Until time (left side). The schedule will resume when the Hold Until time expires.

2 Select Permanent Hold to keep the

same temperature until you change it or resume the program schedule.

Touch Cancel Hold at any time to resume the program schedule.

18 33-00066EFS—03

Temporary Hold

Permanent Hold

Overriding schedules: commercial use

Touch s or t to adjust the temperature. It will be maintained until the hold time you set.

• To change the hold time, touch the Hold Until arrow buttons. This time can be adjusted up to the maximum time set by the installer.

• Touch Override to use a pre-set occupied temperature if a person uses the room during an unoccupied period. The new temperature will be maintained for 1 hour and can be adjusted up to the maximum time set by the installer.

The programmed schedule will resume when the override timer expires. Touch

Cancel Hold at any time to resume the

program schedule.

33-00066EFS—03 19

Viewing equipment status

1 Touch MENU. 2 Select Equipment Status. 3 Touch s or t to view the status of

all the equipment your thermostat is controlling. Depending on how your thermostat was installed, the Equipment Status screen can report data about the following systems:

• Heating and cooling

• Fan

• Humidification

• Dehumidification

• Ventilation

• Maintenance reminders

• Thermostat information.

20 33-00066EFS—03

Equipment Status

Date/Time

Heat Stage 1: Off Cool Stage 1: On

Setting vacation hold: residential use

This feature helps you save energy while you are away, and restores comfortable settings just before you return home.

1 Touch MENU. 2 Select Vacation Mode. 3 Touch s or t to select the date

you leave, then touch Next for further scheduling details, including times of day, temperature settings, return date, and return settings.

4 Review your selections on the last

display, and touch Done to save your settings. Touch Cancel to ignore the changes.

33-00066EFS—03 21

Vacation Mode

Equipment Status

Date You Leave

Jul 25 - Jul 26

Heat: 72 Cool: 78

Jul 17, 2012

Setting holiday/event schedules: commercial use

This feature helps you conserve energy when the workplace is unoccupied for special events and holidays.

1 Touch MENU. 2 Select Holiday Schedule. 3 Select the item you want to schedule

and touch Next for further scheduling details.

• Custom Events lets you set up other days for special schedules.

• US and Canadian Holiday options let you select from a list of holidays commonly observed in each country.

4 Make selections as prompted on each

screen. For more information, see next two pages.

5 Touch Done to save your settings.

22 33-00066EFS—03

Holiday Schedule

Holiday Mode

Custom Events

US Holidays

Setting custom events: commercial use

This feature lets you customize temperature settings to be maintained during a specific event. You can set up an event for a specific date or day in a month. The thermostat resumes normal scheduling after the event.

1 Select Custom Events from the Holiday

Schedule menu. 2 Select Create New Event. 3 Select Specific Date or Month/Weekday.

• For Specific Date, you are prompted to select the event’s start date, settings, end date, and frequency.

• For Month/Weekday, you are prompted to select the month, day of the week, week of the month, settings, length of event, and frequency for the event.

4 Review the settings and touch Done to save

them. Touch Cancel to ignore the changes.

33-00066EFS—03 23

Custom Events

US Holidays

Create New Event

Select Occurence

Specific Date

Schedule adjusted

to 62 in heating

Setting holiday schedule: commercial use

This feature lets you customize temperature settings to be maintained on specified national holidays. The thermostat resumes normal scheduling between selected holidays.

1 Select US Holidays or Canadian Holidays from

the Holiday Schedule menu.

2 Select Add/Edit Holidays. A list of national

holidays is displayed.

3 Touch the check box next to each holiday for

which you want to maintain specific settings, (Touch s or t to scroll through the holiday list.) then touch Next.

Set the holiday schedule for Occupied or Unoccupied temperatures, depending whether the building will be in use.

4 Touch s or t to select the Heat and Cool

temperatures.

5 Review the settings and touch Done to save

them. Touch Cancel to ignore changes.

24 33-00066EFS—03

Add / Edit Holidays

Select US holidays

New Year’s Day

Temperature

During Holiday

Setting holiday override: commercial use

This feature lets you customize temperature settings to be maintained from now until a specified date. The thermostat resumes normal scheduling on the date you select.

1 Touch MENU. 2 Select Holiday Mode to display

Temperature While Away.

3 Touch s or t to select the Heat and

Cool temperatures, then touch Next to select return date.

4 Review the settings and touch Done to

save them. Touch Cancel to ignore the changes.

NOTE: The cool temperature can only be

set higher than the unoccupied program setting and the heat temperature can only be set lower than the unoccupied program setting.

33-00066EFS—03 25

Holiday Mode

Equipment Status

Temperature

While Away

Initiating occupancy mode: commercial use

This feature keeps temperature at an energysaving level until you touch Press Start Occupancy. When you arrive, touch the message to maintain a comfortable temperature while the room is occupied.

Touch the s or t buttons to set the temperature or the Hold Until time. The temperature is maintained until the time you set. Temperature returns to an energy-saving level after the timer expires, or the “Occupied” period ends.

NOTE: This feature is available only when

programmed by the installer.

26 33-00066EFS—03

HERE

Press HERE to

Start Occupancy

Adjusting humidification settings

1 Touch MENU and select Humidification. 2 Select Auto. 3 Touch s or t to select humidity level. 4 Touch Done to save your settings. Touch

Cancel to ignore changes.

5 If frost or condensation appears on the

windows, touch MENU, then select Window

Protection. (Use a lower number to prevent

frost or condensation. Use a higher number if indoor air is too dry.)

NOTE: Window (frost) Protection is available

only if an outdoor air sensor is installed OR if using the outdoor temperature from the Wi-Fi connection to get local outdoor temperature from the Internet.

NOTE: The thermostat controls

humidification and dehumidification as needed to maintain the desired humidity level. Depending on how your thermostat was installed, the thermostat may maintain a 15% separation between humidification and dehumidification settings.

33-00066EFS—03 27

Humidification

Window Protection

Humidification

Off Auto

Adjusting dehumidification settings: residential use

This feature can control a dehumidifier or use your air conditioner to reduce humidity.

1 Touch MENU and select Dehumidification. 2 Select Auto. 3 Touch s or t to select humidity level. 4 Touch Done to save your settings. Touch

Cancel to ignore changes.

NOTE: If your air conditioner is used to

control humidity, the temperature may drop up to 3° F below your temperature setting until humidity reaches the desired level.

28 33-00066EFS—03

Dehumidification

Equipment Status

Dehumidification

Off Auto

Adjusting dehumidification settings: commercial use

This feature can control a dehumidifier or use your air conditioner to reduce humidity.

1 Touch MENU and select Dehumidification. 2 Select Auto. 3 Touch s or t to select humidity level. 4 Touch Done to save your settings. Touch

Cancel to ignore changes.

If your air conditioner is used to control humidity, the thermostat may use the following methods to maintain humidity:

• Cool from 1° to 5° F lower than your temperature setting.

• Run cooling for the minimum “on” time to reduce humidity.

• Run cooling and heating at the same time to reduce humidity without lowering the temperature.

33-00066EFS—03 29

Dehumidification

Equipment Status

Dehumidification

Off Auto

+ 120 hidden pages
