VFD Core
VFD CORE
VFD CORE addresses the need to save time for installation and
provides the lower total installed costs. VFD CORE is rated for
constant torque for industrial applications and variable torque for
HVAC applications.
Drive Family: VFD CORE
Acceleration time: 0.0 - 600 sec
Deceleration time: 0.0 - 6000 sec
Analog Current Input: 0 (4) - 20 mA, 250 ohm differential
Analog Voltage Input: 0 - 10 Vdc, 200K ohm
Analog Current Output: 0 (4) - 20 mA, max 500 ohm
Digital Output: Open collector, max. load 48V/50mA
Continuous Output Current: Full Amp 1.2
Relay Output: Max. switching load: 250Vac/2A or 250Vdc/0,4A
Reference Output Voltage: Maximum Load 10mA
Auxiliary Voltage: ± 20%, max. load 50 mA
Starting Torque: Depends on the Motor
Peak Current: 20% of rated current for 1 minute
Frequency (Hz): 0 Hz to 600 Hz
Operating Temperature: 14 to 104 F (10 to 40 C)
Type of Enclosure: NEMA1
Configuration: Drive alone
Product Number Voltage Horsepower
HCRDA0010A1000T/U 208 Vac/230 Vac 1 HP A 5A 4.6A 5.1 x 9.8 x 6.7 130 x 250 x 170 6.16 2.8
HCRDA0020A1000T/U 208 Vac/230 Vac 2 HP A 7.5A 5A 5.1 x 9.8 x 6.7 130 x 250 x 170 6.16 2.8
HCRDA0030A1000T/U 208 Vac/230 Vac 3 HP A 10A 8A 5.1 x 9.8 x 6.7 130 x 250 x 170 6.16 2.8
HCRDA0050A1000T/U 208 Vac/230 Vac 5 HP A 15A 11A 5.1 x 9.8 x 6.7 130 x 250 x 170 6.16 2.8
HCRDA0075A1000T/U 208 Vac/230 Vac 7.5 HP A 21A 17A 5.1 x 9.8 x 6.7 130 x 250 x 170 6.16 2.8
HCRDA0100B1000T/U 208 Vac/230 Vac 10 HP B 31A 25A 7.5 x 12.6 x 7. 5 190 x 320 x 190 10.12 4.6
HCRDA0150B1000T/U 208 Vac/230 Vac 15 HP B 46A 33A 7.5 x 12.6 x 7. 5 190 x 320 x 190 10.12 4.6
HCRDA0200B1000T/U 208 Vac/230 Vac 20 HP B 61A 49A 7.5 x 12.6 x 7. 5 190 x 320 x 190 12.32 5.6
HCRDA0250C1000T/U 208 Vac/230 Vac 25 HP C 75A 65A 9. 8 x 15.7 x 8.2 250 x 400 x 210 23.1 10.5
HCRDA0300C1000T/U 208 Vac/230 Vac 30 HP C 90A 75A 9. 8 x 15.7 x 8.2 250 x 400 x 210 23.1 10.5
HCRDA0400C1000T/U 208 Vac/230 Vac 40 HP C 105A 90A 9. 8 x 15.7 x 8.2 250 x 400 x 210 23.1 10.5
HCRDA0500D1000T/U 208 Vac/230 Vac 50 HP D 146A 120A 13 x 27 x 10.8 330 x 688 x 275 78.1 35.5
HCRDA0600D1000T/U 208 Vac/230 Vac 60 HP D 180A 146A 13 x 27 x 10.8 330 x 688 x 275 78.1 35.5
HCRDA0750E1000T/U 208 Vac/230 Vac 75 HP E 215A 180A 14.5 x 28.2 x 11.9 370 x 716 x 300 100.54 45.7
HCRDA1000E1000T/U 208 Vac/230 Vac 100 HP E 276A 215A 14.5 x 28.2 x 11.9 370 x 716 x 300 101.64 46.2
HCRDA1250E1000T/U 208 Vac/230 Vac
HCRDC0010A1000T/U 460 Vac 1 HP A 3A 2.8A 5.1 x 9.8 x 6.7 130 x 250 x 170 6.16 2.8
HCRDC0020A1000T/U 460 Vac
HCRDC0030A1000T/U 460 Vac
HCRDC0050A1000T/U 460 Vac 5 HP A 7.5A 6A 5.1 x 9.8 x 6.7 130 x 250 x 170 6.16 2.8
HCRDC0075A1000T/U 460 Vac
HCRDC0100A1000T/U 460 Vac
HCRDC0150B1000T/U 460 Vac 15 HP B 22.5A 18A 7.5 x 12.6 x 7. 5 190 x 320 x 190 9.68 4.4
HCRDC0200B1000T/U 460 Vac
HCRDC0250B1000T/U 460 Vac
HCRDC0300C1000T/U 460 Vac
HCRDC0400C1000T/U 460 Vac 40 HP C 56A 45A 9. 8 x 15.7 x 8.2 250 x 400 x 210 19.14 8.7
HCRDC0500C1000T/U 460 Vac
HCRDC0600D1000T/U 460 Vac 60 HP D 91A 73A 13 x 27 x 10.8 330 x 688 x 275 78.1 35.5
HCRDC0750D1000T/U 460 Vac
HCRDC1000D1000T/U 460 Vac 100 HP D 144A 110A 13 x 27 x 10.8 330 x 688 x 275 89.1 40.5
HCRDC1250D1000T/U 460 Vac
1
Drives should be selected so that the rated output current in Amps of the drive meets or exceeds the full load amps (FLA) of the motor and not based on the motor
horsepower.
2
Variable Torque loads are loads that drive a variable speed motor where the torque decreases as the speed decreases, i.e. centrifugal pumps, fans.
3
Constant Torque loads are loads where as the speed changes the torque remains constant, i.e. conveyors, positive displacement pumps.
125 HP E 322A 255A 14.5 x 28.2 x 11.9 370 x 716 x 300 120.34 54.7
2 HP A 3.7A 3A 5.1 x 9.8 x 6.7 130 x 250 x 170 6.16 2.8
3 HP A 5A 4A 5.1 x 9.8 x 6.7 130 x 250 x 170 6.16 2.8
7.5 HP A 12A 10.5A 5.1 x 9.8 x 6.7 130 x 250 x 170 6.16 2.8
10 HP A 14A 12A 5.1 x 9.8 x 6.7 130 x 250 x 170 6.16 2.8
20 HP B 30A 24A 7.5 x 12.6 x 7. 5 190 x 320 x 190 10.34 4.7
25 HP B 36A 32A 7.5 x 12.6 x 7. 5 190 x 320 x 190 12.54 5.7
30 HP C 45A 38A 9. 8 x 15.7 x 8.2 250 x 400 x 210 18.48 8.4
50 HP C 72A 60A 9. 8 x 15.7 x 8.2 250 x 400 x 210 20.68 9.4
75 HP D 110A 91A 13 x 27 x 10.8 330 x 688 x 275 78.1 35.5
125 HP D 180A 150A 13 x 27 x 10.8 330 x 688 x 275 89.1 40.5
1
Type
Torque
Varia bl e
Frame
Constant
Torque Current
2
Ratings
3
Dimensions, Approximate Weight
(inch) (mm) (lb) (kg)
610 customer.honeywell.com 70-6910
VFD Core
VFD CORE Bypass Assemblies
VFD CORE addresses the need to save time for installation and
provides the lower total installed costs. VFD CORE is rated for
constant torque for industrial applications and variable torque for
HVAC applications.
Drive Family: VFD CORE
Acceleration time: 0.0 - 600 sec
Deceleration time: 0.0 - 6000 sec
Analog Current Input: 0 (4) - 20 mA, 250 ohm differential
Analog Voltage Input: 0 - 10 Vdc, 200K ohm
Analog Current Output: 0 (4) - 20 mA, max 500 ohm
Digital Output: Open collector, max. load 48V/50mA
Continuous Output Current: Full Amp 1.2
Relay Output: Max. switching load: 250Vac/2A or 250Vdc/0,4A
Reference Output Voltage: Maximum Load 10mA
Auxiliary Voltage: ± 20%, max. load 50 mA
NOTE: All VFD Core Drives with Bypass are configured with 3 contractors and a fused disconnect.
Starting Torque: Depends on the Motor
Peak Current: 20% of rated current for 1 minute
Drive Input Disconnect: Ye s
Disconnect Type: Fused
Drive Input Fuses: Ye s
Pilot Lights: Ye s
Frequency (Hz): 0 Hz to 600 Hz
Operating Temperature: 14 to 104 F (10 to 40 C)
Configuration: Drive with 3 contactor bypass
Type of Enclosure: NEMA1
Commercial
Constant
2
Tor qu e
Current
Ratings
Frame
Product Number Voltage Horsepower
HCRBA0010A1300T/U
HCRBA0020A1300T/U
HCRBA0030A1300T/U
HCRBA0050A1300T/U
HCRBA0075A1300T/U
HCRBA0100B1300T/U
HCRBA0150B1300T/U
HCRBA0200B1300T/U
HCRBA0250C1300T/U
HCRBA0300C1300T/U
HCRBA0400C1300T/U
HCRBA0500D1300T/U
HCRBA0600D1300T/U
HCRBA0750E1300T/U
HCRBA1000E1300T/U
HCRBA1250E1300T/U
HCRBB0010A1300T/U
HCRBB0020A1300T/U
HCRBB0030A1300T/U
HCRBB0050A1300T/U
HCRBB0075A1300T/U
HCRBB0100B1300T/U
HCRBB0150B1300T/U
HCRBB0200B1300T/U
1
Drives should be selected so that the rated output current in Amps of the drive meets or exceeds the full load amps (FLA) of the motor and not based on the motor
horsepower.
2
Variable Torque loads are loads that drive a variable speed motor where the torque decreases as the speed decreases, i.e. centrifugal pumps, fans.
3
Constant Torque loads are loads where as the speed changes the torque remains constant, i.e. conveyors, positive displacement pumps.
208 Vac 1 HP A 5A 4.6A 8.9 x 35.2 x 10.6 226 x 894 x 270 37 17
208 Vac 2 HP A 7.5A 5A 8.9 x 35.2 x 10.6 226 x 894 x 270 37 17
208 Vac 3 HP A 10A 8A 8.9 x 35.2 x 10.6 226 x 894 x 270 37 17
208 Vac 5 HP A 15A 11A 8.9 x 35.2 x 10.6 226 x 894 x 270 40 18
208 Vac 7.5 HP A 21A 17A 8.9 x 35.2 x 10.6 226 x 894 x 270 63 29
208 Vac 10 HP B 31A 25A 12.4 x 49.1 x 11.5 315 x 1247 x 292.1 67 30
208 Vac 15 HP B 46A 33A 12.4 x 49.1 x 11.5 315 x 1247 x 292.1 75 34
208 Vac 20 HP B 61A 49A 12.4 x 49.1 x 11.5 315 x 1247 x 292.1 79 36
208 Vac 25 HP C 75A 65A 12.4 x 49.1 x 11.5 315 x 1247 x 292.1 83 38
208 Vac 30 HP C 90A 75A 12.4 x 49.1 x 11.5 315 x 1247 x 292.1 166 75
208 Vac 40 HP C 105A 90A 12.4 x 49.1 x 11.5 315 x 1247 x 292.1 176 80
208 Vac 50 HP D 146A 120A 19.6 x 53.5 x 13.3 497.8 x 1359 x 337.8 193 88
208 Vac 60 HP D 180A 146A 19.6 x 53.5 x 13.3 497.8 x 1359 x 337.8 255 116
208 Vac 75 HP E 215A 180A Contact Customer Care
208 Vac 100 HP E 276A 215A Contact Customer Care
208 Vac 125 HP E 322A 255A Contact Customer Care
230 Vac 1 HP A 5A 4.6A 8.9 x 35.2 x 10.6 226 x 894 x 270 37 17
230 Vac 2 HP A 7.5A 5A 8.9 x 35.2 x 10.6 226 x 894 x 270 37 17
230 Vac 3 HP A 10A 8A 8.9 x 35.2 x 10.6 226 x 894 x 270 37 17
230 Vac 5 HP A 15A 11A 8.9 x 35.2 x 10.6 226 x 894 x 270 40 18
230 Vac 7.5 HP A 21A 17A 8.9 x 35.2 x 10.6 226 x 894 x 270 63 29
230 Vac 10 HP B 31A 25A 12.4 x 49.1 x 11.5 315 x 1247 x 292.1 67 30
230 Vac 15 HP B 46A 33A 12.4 x 49.1 x 11.5 315 x 1247 x 292.1 75 34
230 Vac 20 HP B 61A 49A 12.4 x 49.1 x 11.5 315 x 1247 x 292.1 79 36
1
Type
Variable
Tor que
Dimensions, Approximate
3
(inch) (mm)
Weight
(lb) (kg)
Components
70-6910 611
VFD Core
Constant
2
Tor qu e
Current
Ratings
Frame
Product Number Voltage
HCRBB0250C1300T/U
HCRBB0300C1300T/U
HCRBB0400C1300T/U
HCRBB0500D1300T/U
HCRBB0600D1300T/U
HCRBB0750E1300T/U
HCRBB1000E1300T/U
HCRBB1250E1300T/U
HCRBC0010A1300T/U
HCRBC0020A1300T/U
HCRBC0030A1300T/U
HCRBC0050A1300T/U
HCRBC0075A1300T/U
HCRBC0100A1300T/U
HCRBC0150B1300T/U
HCRBC0200B1300T/U
HCRBC0250B1300T/U
HCRBC0300C1300T/U
HCRBC0400C1300T/U
HCRBC0500C1300T/U
HCRBC0600D1300T/U
HCRBC0750D1300T/U
HCRBC1000D1300T/U
HCRBC1250D1300T/U
1
Drives should be selected so that the rated output current in Amps of the drive meets or exceeds the full load amps (FLA) of the motor and not based on the motor
horsepower.
2
Variable Torque loads are loads that drive a variable speed motor where the torque decreases as the speed decreases, i.e. centrifugal pumps, fans.
3
Constant Torque loads are loads where as the speed changes the torque remains constant, i.e. conveyors, positive displacement pumps.
230 Vac 25 HP C 75A 65A 12.4 x 49.1 x 11.5 315 x 1247 x 292.1 83 38
230 Vac 30 HP C 90A 75A 12.4 x 49.1 x 11.5 315 x 1247 x 292.1 166 75
230 Vac 40 HP C 105A 90A 12.4 x 49.1 x 11.5 315 x 1247 x 292.1 176 80
230 Vac 50 HP D 146A 120A 19.6 x 53.5 x 13.3 497.8 x 1359 x 337.8 193 88
230 Vac 60 HP D 180A 146A 19.6 x 53.5 x 13.3 497.8 x 1359 x 337.8 255 116
230 Vac 75 HP E 215A 180A Contact Customer Care
230 Vac 100 HP E 276A 215A Contact Customer Care
230 Vac 125 HP E 322A 255A Contact Customer Care
460 Vac 1 HP A 3A 2.8A 8.9 x 35.2 x 10.6 226 x 894 x 270 37 17
460 Vac 2 HP A 3.7A 3A 8.9 x 35.2 x 10.6 226 x 894 x 270 37 17
460 Vac 3 HP A 5A 4A 8.9 x 35.2 x 10.6 226 x 894 x 270 37 17
460 Vac 5 HP A 7.5A 6A 8.9 x 35.2 x 10.6 226 x 894 x 270 37 17
460 Vac 7.5 HP A 12A 10A 8.9 x 35.2 x 10.6 226 x 894 x 270 37 17
460 Vac 10 HP A 14A 12A 8.9 x 35.2 x 10.6 226 x 894 x 270 40 18
460 Vac 15 HP B 22.5A 18A 12.4 x 49.1 x 11.5 315 x 1247 x 292.1 63 29
460 Vac 20 HP B 30A 24A 12.4 x 49.1 x 11.5 315 x 1247 x 292.1 67 30
460 Vac 25 HP B 36A 32A 12.4 x 49.1 x 11.5 315 x 1247 x 292.1 71 32
460 Vac 30 HP C 45A 38A 12.4 x 49.1 x 11.5 315 x 1247 x 292.1 75 34
460 Vac 40 HP C 56A 45A 12.4 x 49.1 x 11.5 315 x 1247 x 292.1 79 36
460 Vac 50 HP C 72A 60A 12.4 x 49.1 x 11.5 315 x 1247 x 292.1 83 38
460 Vac 60 HP D 91A 73A 19.6 x 53.5 x 13.3 497.8 x 1359 x 337.8 166 75
460 Vac 75 HP D 110A 91A 19.6 x 53.5 x 13.3 497.8 x 1359 x 337.8 176 80
460 Vac 100 HP D 144A 110A 19.6 x 53.5 x 13.3 497.8 x 1359 x 337.8 193 88
460 Vac 125 HP D 180A 150A 19.6 x 53.5 x 13.3 497.8 x 1359 x 337.8 255 116
Horsepower
1
Type
Var iable
Tor qu e
Dimensions, Approximate
3
(inch) (mm)
Weight
(lb) (kg)
VFD Core Accessories
Product Number Drive Family Description
HCRDFANFRA1H/U VFD CORE VFD CORE Replacement Fan Frame A (Heat Sink Cooling Fan for 3-7.5HP 208/ 230 V and 5-10 HP 460 V)
HCRDFANFRB1B/U VFD CORE VFD CORE Replacement Fan Frame B (Board Cooling Fan for 10-20 HP 208/230 V and 15-25 HP 460 V)
HCRDFANFRB1H/U VFD CORE VFD CORE Replacement Fan Frame B (Heat Sink Cooling Fan for 10 HP 208/230 V and 15 HP 460 V)
HCRDFANFRB2H/U VFD CORE VFD CORE Replacement Fan Frame B (Heat Sink Cooling Fan for 15-20 HP 208/230 V and 20-25 HP 460V)
HCRDFANFRC1B/U VFD CORE VFD CORE Replacement Fan Frame C (Board Cooling Fan for 25-40 HP 208/230 V)
HCRDFANFRC2B/U VFD CORE VFD CORE Replacement Fan Frame C (Board Cooling Fan for 30-50 HP 460 V)
HCRDFANFRD1B/U VFD CORE VFD CORE Replacement Fan Frame D (Board Cooling Fan for 50-60 HP 208/230 V and 60-125 HP 460V)
HCRDFANFRD1H/U VFD CORE VFD CORE Replacement Fan Frame D (Heat Sink Cooling Fan for 50-60 HP 208/230 V and 60-125 HP 460V)
HCRDFANFRE1B/U VFD CORE VFD CORE Replacement Fan Frame E (Board Cooling Fan for 75- 125 HP 208/230V)
HCRDFANFRE1H/U VFD CORE VFD CORE Replacement Fan Frame E (Heat Sink Cooling Fan for 75- 100 HP 208/230 V)
HCRDFANFRE2H/U VFD CORE VFD CORE Replacement Fan Frame E (Heat Sink Cooling Fan for 125 HP 208/230 V)
HCRDKEYPAD/U VFD CORE VFD CORE Replacement Keypad
HCRDMOUNTKIT/U VFD CORE VFD CORE Keypad Mounting Kit
HCRDTRAINER/U VFD CORE VFD CORE Training Demonstration Kit
