MagicStat® CT3300 Programmable Thermostat

Welcome

with your new Honeywell MagicStat® Programmable Thermostat. Your new thermostat will automatically control the temperature in your home, keeping you comfortable while saving energy.

If you have any questions about using this thermostat, visit our home expert Web site at

www.honeywell.com/yourhome

Customer Relations at 1-800-468-1502.

to the world of comfort and energy savings

or call Honeywell

Installation and Programming Instructions

Weekday/Weekend (5-day/2-day) Programmable Heat and/or Cool Low Voltage (20 to 30 Vac) Thermostat and Mounting Plate Model CT3300

Table of Contents

Installation 2 Programming 11 Operation 17

Change the clock for Daylight/ Standard Time

Set the Fan and System switches 17 Replace the batteries 18

Override the program settings 19 Frequently asked questions 22 Limited 1-Year Warranty 24

69- 0654- 5

Fig. 1

MERCURY SWITCH

Recycling thermostat

If you are removing an old thermostat that contains mercury in a sealed tube (Fig. 1),

place the old thermostat in the trash.

do not

Contact your local waste management authority for instructions regarding recycling and the proper disposal of the old thermostat.

M3701

Installation

Verify that you have the right thermostat

Make sure that the CT3300 is the right thermostat for your heating/cooling system. Read the compatibility chart below to determine which system you have. If your system is not compatible with the CT3300, the table recommends an alternate Honeywell model. If you are unsure what type of thermostat is right for your system, visit us on the Web at

www.honeywell.com/yourhome

or call Honeywell Customer Relations at 1-800-468-1502.

Heating/cooling system Conventional

Compatible with CT3300?

Yes

Alternate model

Single stage systems that include warm air furnaces and hot water.

Electric Baseboard

Electric powered heating strips located just above the floor, usually 120 to 240 volts.

Steam

No CT1950 for

240 volts

No CT3600

A steam boiler with radiator heat.

Heat Pump

No CT3600 Heating and cooling are produced from the same outdoor unit (compressor) with no auxiliary or backup heat.

Multistage Heat Pump

No CT3611 Heating and cooling are produced from the same outdoor unit (compressor) with auxiliary or backup heat.

Multistage Conventional

A heating or cooling system with more than one stage.

INSTALLATION 69-0654-5

No See your

contractor

Step 1. Prepare for installation

a. Carefully unpack your new thermostat. Save your receipt and make sure you have the following parts:

• Thermostat and mounting plate

• Labels

b. Gather the needed tools and supplies listed below.

Required tools and supplies Optional tools

• Two AA alkaline batteries. Honeywell recommends Energizer® batteries.

• Screwdriver

• Hand or power drill with 3/16-inch or 7/32-inch drill bit

•Pencil

c. Make sure that your heating and cooling systems are working properly. If there is a problem with either system, call a

heating/air conditioning contractor—the problem may persist after you install the new thermostat.

• Screws and anchors

• Installation and Programming Instructions

• Wire cutter/stripper or sharp knife

•Level

• Electrical tape

IMPORTANT:

temperature outdoors is below 50°F (10°C).

69-0654-5 INSTALLATION

To avoid damaging the compressor in the air conditioner, do not operate the cooling system when the

Step 2. Remove the old thermostat

Fig. 2

Fig. 3

Fig. 4

WIRES THROUGH WALL OPENING

M20140

M19086

Turn off power

to the heating/cooling system, either at the

furnace or at the fuse/circuit breaker panel. b. Remove the cover of your old thermostat (Fig. 2). c. Unscrew and remove the old thermostat’s mounting plate from

the wall, but

do not disconnect the wires

d. Inspect the old thermostat wiring.

If the wiring meets any of

the following conditions, see the special wiring

instructions on page 9.

• The old thermostat is a clock thermostat with wires attached to the C or C1 terminals.

• The old thermostat has 6 or more wires, excluding wires attached to C or C1 terminals.

• The old thermostat has 3 wires.

• There are 5 wires

connected

• There are extra wires that are

to the old thermostat.

connected to the old

not

thermostat.

e. Using the enclosed labels, mark the wires with the letter of the

terminal that it is attached to on the

old thermostat

(Fig. 3). Do

not label the wires by color. If the labels do not match the letters on the old thermostat

terminals, see the wiring cross reference table on page 10.

f. Disconnect the wires from the old thermostat and wrap the

wires around a pencil to keep them from

falling back into the

wall.

: Remember, if your old thermostat contains mercury, you

Note

must recycle it. See page 2 for more recycling information.

✓

Check

M20133

INSTALLATION 69-0654-5

Your wall should now look like Fig. 4.

our progress

Step 3. Install the mounting plate

Fig. 5

M20139

Fig. 6

M20129

Fig. 7

a. Separate the mounting plate from the thermostat using a coin,

as shown in Fig 5.

b. Position the mounting plate on the wall. Be sure the mounting

plate sits flush against the wall and none of the wires are trapped behind it.

c. Level the mounting plate and use a pencil to mark the center of

the mounting plate’s screw holes.

d. Remove the mounting plate and drill holes at the locations you

marked.

• For drywall, drill two 3/16 inch holes.

• For plaster or wood, drill two 7/32 inch holes.

e. If installing in drywall, gently tap the anchors that were provided

into the drilled holes until they are flush with the wall.

f. Reposition the mounting plate over the holes, pull the wires

through the wiring opening, and loosely insert the mounting screws into each of the drilled holes or anchors (Fig. 6).

g. Make sure the mounting plate is level and tighten the mounting

screws.

✓

Check your progress

The mounting plate is now mounted on the wall and should look like Fig. 7.

69-0654-5 INSTALLATION

M20128

Step 4. Set the thermostat for your type of heating system

)

Fig. 8

FOR HIGH EFFICIENCY FURNACE (90%+ AFUE) ADJUST: SCREW A–OUT ONE TURN

SCREW B–IN FUEL SWITCH – F POSITION

FUEL SWITCH

HEATING SYSTEM TYPE

DISPLAY F DISPLAY C

FUEL SWITCH

THERMOSTAT BACK

A C

C–IN C–OUT 1 TURN

B D

IMPORTANT:

SELECTING ºF OR ºC

heating system allows it to maintain accurate temperature control, minimize swings in the temperature of the room, and efficiently run the fan.

ADJUST SCREWS THROUGH HOLES TO SELECT OPERATION DESIRED

HEATING SYSTEM

WARM AIR FURNACE HOT WATER BOILER ELECTRIC FURNACE

W Y G

A–IN A–OUT

1 TURN A–IN

B–IN B–IN B–OUT

1 TURN

FUEL SWITCH

POSITION

F F E

a. Use the FUEL SWITCH on the back of the thermostat to set

your new thermostat for the type of fuel that your heating system uses: F–gas or oil, or E–electricity.

Note:

b. Use the A and B screws on the back of the thermostat to set

your new thermostat for your type of heating system. See the heating system table on the next page to find the correct settings.

M20145

Note

heating system.

c. The thermostat is set to display the temperature in degrees

Fahrenheit ( degrees Celsius (

d. You can install the batteries and program your thermostat now,

or you can wait until the thermostat is mounted on the wall. To install the batteries, see the instructions on page 8. To program the thermostat, see the instructions that begin on page 12.

Setting your thermostat correctly for your type of

This setting enables proper fan operation.

: These screws are factory-set for a warm air, gas, or oil

. If you want to display the temperature in

°F

, adjust screw C out one turn.

°C

INSTALLATION 69-0654-5

Heating system table

: Setting the screw “out one turn” means turning the screw 360° counter-clockwise, or one complete turn.

Note

Type of system Screws A and B Fuel switch

Warm air, gas, or oil heating system with an efficiency rating under 90%. (The furnace efficiency rating should be on the furnace.)

Use factory setting A–leave in

B–leave in

High-efficiency furnace such as a 90% or greater AFUE (Average Fuel Utilization Efficiency) unit

Hot water boiler A–out one turn

A–out one turn B–leave in

B–leave in

Electric furnace A–leave in

B–out one turn

Step 5. Wire the thermostat terminals

Fig. 9

Fig. 10

5/16 in. (8 mm) STRIP

INSERT STRAIGHT UNDER SCREW HEAD

M20125

a. Hold the thermostat as shown in Fig. 9. b. Using the labels on the wires, match the letter of your old

thermostat wire with the corresponding terminal on the back of your new thermostat.

If the letters on the old thermostat terminals do not match

Note:

the letters on the new thermostat terminals, you might not need to connect all of the old wires to the new thermostat. See the wiring cross reference table on page 10 for details.

c. Loosen the terminal screws and slip each wire beneath its

matching terminal (Fig 10).

d. Securely tighten the terminals.

END OF WIRE VISIBLE HERE

69-0654-5 INSTALLATION

M20126

Step 6. Mount the thermostat

M20130

Fig. 11 Fig. 12

Step 7. Install the batteries

M20131

a. Align the tabs at the

of the mounting plate (Fig. 11).

top

of the thermostat with the tabs at the

top

b. Press the lower edge of the case to latch the bottom of the

thermostat (Fig. 12).

Fig. 13

IMPORTANT:

operation of the thermostat and heating/cooling system.

Batteries must be installed for programming and

Honeywell recommends using Energizer® batteries.

a. Make sure that the System switch is set in the OFF position. b. Using a coin, open the battery door as shown in Fig. 13.

c. Install the batteries.

Make sure that the positive and negative terminals are oriented correctly as marked inside the battery case.

M1719C

REMOVING BATTERY DOOR

d. Replace the battery door.

e. Remove the clear plastic label from the digital display.

Fig. 14

✓

Check

our progress

When the batteries are installed correctly, the digital display flashes all entries once, then begins to flash a default time and the current temperature (Fig. 14). The flashing continues until you begin to program the thermostat.

You are now ready to program the thermostat. Go to page 12.

INSTALLATION 69-0654-5
