Xenon™ 1932/Xenon™ 1932BF CCB04-010BT/CCB05-010BT
Cordless Area-Imaging Scanner and Charge Bases
Quick Start Guide
1932-EN-QS Rev (a)
3/18
Note: Refer to your user’s guide for information about cleaning your device.
Getting Started
Turn off computer’s power before connecting the scanner, then power up the computer once the scanner is fully connected. When the base is connected and powered up, put the scanner in the base to establish a link. The green LED on the base flashes to indicate the scanner’s battery or charge pack is charging.
Power Supply Assembly (if included)
Note: The power supply must be ordered separately, if needed.
1
Connecting the Scanner
USB:
CCB04-010BT Base:
CCB05-010BT Base:
2
Keyboard Wedge:
CCB04-010BT Base:
CCB05-010BT Base:
3
RS232 Serial Port:
CCB04-010BT Base:
CCB05-010BT Base:
4
RS485:
CCB04-010BT Base:
CCB05-010BT Base:
5
