Honda Pilot 2019, Pilot 2019 Owner's Manual

2019

OWNER’S MANUAL

3

WARNING

California Proposition 65 Warning

Operating, servicing and maintaining a
passenger vehicle or off-highway motor
vehicle can expose you to chemicals including
engine exhaust, carbon monoxide,
phthalates, and lead, which are known to the
State of California to cause cancer and birth
defects or other reproductive harm. To
minimize exposure, avoid breathing exhaust,
do not idle the engine except as necessary,
service your vehicle in a well-ventilated area
and wear gloves or wash your hands
frequently when servicing your vehicle. For
more information go to

www.P65Warnings.ca.gov/passenger-vehicle

.

Event Data Recorders

This vehicle is equipped with an event data recorder (EDR).

The main purpose of an EDR is to record, in certain crash or near
crash-like situations, such as an air bag deployment or hitting a
road obstacle, data that will assist in understanding how a vehicle’s
systems performed. The EDR is designed to record data related

to vehicle dynamics and safety systems for a short period of
time, typically 30 seconds or less. The EDR in this vehicle is
designed to record such data as:

• How various systems in your vehicle were operating;

• Whether or not the driver and passenger safety belts were

buckled/fastened;

• How far (if at all) the driver was depressing the accelerator
and/or brake pedal; and,

• How fast the vehicle was traveling.

These data can help provide a better understanding of the
circumstances in which crashes and injuries occur. NOTE: EDR data
are recorded by your vehicle only if a non-trivial crash situation
occurs; no data are recorded by the EDR under normal driving
conditions and no personal data (e.g., name, gender, age, and
crash location) are recorded. However, other parties, such as law
enforcement, could combine the EDR data with the type of
personally identifying data routinely acquired during a crash
investigation.

To read data recorded by an EDR, special equipment is required,
and access to the vehicle or the EDR is needed. In addition to the
vehicle manufacturer, other parties, such as law enforcement, that
have the special equipment, can read the information if they have
access to the vehicle or the EDR.

The data belongs to the vehicle owner and may not be accessed by
anyone else except as legally required or with the permission of the
vehicle owner.

Service Diagnostic Recorders

This vehicle is equipped with service-related devices that record
information about powertrain performance. The data can be used
to verify emissions law requirements and/or help technicians
diagnose and solve service problems. It may also be combined with
data from other sources for research purposes, but it remains
confidential. Some diagnostic and maintenance information is
uploaded to Honda upon vehicle start up.

California Perchlorate Contamination Prevention Act

NOTICE

3DANGER

3WARNING

3CAUTION

The airbags, seat belt tensioners, and CR type batteries in this
vehicle may contain perchlorate materials - special handling may
apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate/

To help you make informed decisions about safety, we have
provided operating procedures and other information on labels and
in this manual. This information alerts you to potential hazards that
could hurt you or others.

As you read this manual, you will find information that is preceded
by a symbol. This information is intended to help you avoid
damage to your vehicle, other property, or the environment.

Software End User License Agreement

Your vehicle comes equipped with software, which is governed by
the End User License Agreement in Owner’s Manual, and which
contains a binding arbitration clause. Please refer to the End User
License Agreement for the terms and conditions governing your
use of the installed software, as well as the applications, services,
functions, and content provided through the software. Your use of
the installed software will serve as your consent to the terms and
conditions of the End User License Agreement.
You may opt out within 30 days of your initial use of the Software
by sending a signed, written notice to HONDA at American Honda
Motor Co., Inc. Honda Automobile Customer Services Mail Stop
100-5E-8A, 1919 Torrance Blvd. Torrance, CA 90501-2746.

Privacy Notice

This vehicle may share location and usage information. To manage
this setting, visit www.hondalink.com/vehicle-data-choices.

A Few Words About Safety

Your safety, and the safety of others, is very important. And
operating this vehicle safely is an important responsibility.

Of course, it is not practical or possible to warn you about all the
hazards associated with operating or maintaining your vehicle. You
must use your own good judgment.

You will find this important safety information in a variety of forms,
including:

● Safety Labels - on the vehicle.

● Safety Messages - preceded by a safety alert symbol

one of three signal words: DANGER, WARNING, or CAUTION.
These signal words mean:

You WILL be KILLED or SERIOUSLY HURT if
you don't follow instructions.

You CAN be KILLED or SERIOUSLY HURT if
you don't follow instructions.

You CAN be HURT if you don't follow
instructions.

● Safety Headings - such as Important Safety Precautions.

● Safety Section - such as Safe Driving.

● Instructions - how to use this vehicle correctly and safely.

This entire book is filled with important safety information - please
read it carefully.

3 and

Contents

This owner’s manual should be considered a permanent part of the
vehicle and should remain with the vehicle when it is sold.

This owner’s manual covers all models of your vehicle. You may find
descriptions of equipment and features that are not on your
particular model.

Images throughout this owner’s manual (including the front cover)
represent features and equipment that are available on some, but
not all, models. Your particular model may not have some of these
features.

This owner’s manual is for vehicles sold in the United States and
Canada.

The information and specifications included in this publication were
in effect at the time of approval for printing. Honda Motor Co., Ltd.
reserves the right, however, to discontinue or change specifications
or design at any time without notice and without incurring any
obligation.

2 Safe Driving P. 33

For Safe Driving P. 34 Seat Belts P. 39 Airbags P. 47

2 Instrument Panel P. 79

Indicators P. 80 Gauges and Displays P. 110

2 Controls P. 135

Clock P. 136 Locking and Unlocking the Doors P. 139
Moonroof
Adjusting the Seats P. 194 Interior Lights/Interior Convenience Items P. 209

*

P. 169 Panoramic Roof* P. 170

2 Features P. 243

Audio System P. 244
General Information on the Audio System P. 353
HomeLink® Universal Transceiver

*

P. 451 Bluetooth® HandsFreeLink® P. 454, 479

2 Driving P. 507

Before Driving P. 508 Towing a Trailer P. 514
Parking Your Vehicle P. 615

Multi-View Rear Camera P. 626

2 Maintenance P. 633

Before Performing Maintenance P. 634 Maintenance MinderTM P. 637
Checking and Maintaining Wiper Blades P. 659
Remote Control and Wireless Headphone Care
Accessories and Modifications P. 684

*

P. 675

2 Handling the Unexpected P. 687

Tools P. 688 If a Tire Goes Flat P. 689
Overheating P. 705 Indicator, Coming On/Blinking P. 707
When You Cannot Unlock the Fuel Fill Door P. 717

2 Information P. 721

Specifications P. 722 Identification Numbers P. 724
Emissions Testing P. 728 Warranty Coverages P. 730

Contents

Child Safety P. 60 Exhaust Gas Hazard P. 76 Safety Labels P. 77

Opening and Closing the Tailgate P. 153 Security System P. 163 Opening and Closing the Windows P. 166
Operating the Switches Around the Steering Wheel P. 171 Adjusting the Mirrors P. 192
Heating and Cooling

Audio System Basic Operation P. 251, 269 Audio Error Messages P. 348
Blu-ray/DVD Rear Entertainment System

TM*

CabinTalk

Off-Highway Driving Guidelines P. 525 When Driving P. 527 Honda Sensing® P. 566 Braking P. 611
Refueling P. 628 Fuel Economy and CO

Maintenance Under the Hood P. 642 Replacing Light Bulbs P. 654
Checking and Maintaining Tires P. 663 Battery P. 672 Remote Transmitter Care P. 674
Heating and Cooling System

Engine Does Not Start P. 697 Shift Lever Does Not Move* P. 701 Jump Starting P. 702
Fuses P. 711 Emergency Towing P. 716
Refueling P. 718 When You Cannot Open the Tailgate P. 719

*

P. 230 Climate Control System* P. 235

*

P. 377 Customized Features P. 425, 432

P. 505

Emissions P. 631

2

*

/Climate Control System* Maintenance P. 677 Cleaning P. 679

Quick Reference Guide

Safe Driving

Instrument Panel

Controls

Features

Driving

Maintenance

Handling the Unexpected

Information

Index

P. 4

P. 33

P. 79

P. 135

P. 243

P. 507

P. 633

P. 687

P. 721

P. 735

Devices that Emit Radio Waves P. 725 Reporting Safety Defects P. 727
Authorized Manuals P. 732 Customer Service Information P. 733
