Honda Dio (2021) User guide

This manual should be considered a permanent part of the vehicle and should remain with the vehicle when it is resold.

This publication includes the latest production information available before printing. Honda Motor Co., Ltd. reserves the right to make changes at any time without notice and without incurring any obligation.

No part of this publication may be reproduced without written permission.

The vehicle pictured in this owner’s manual may not match your actual vehicle.

Welcome

Congratulations on your purchase of a new Honda vehicle. Your selection of a Honda makes you part of a worldwide family of satisfied customers who appreciate Honda's reputation for building quality into every product.

To ensure your safety and riding pleasure:

● Read this owner's manual carefully.

● Follow all recommendations and

procedures contained in this manual.

● Pay close attention to safety messages

contained in this manual and on the vehicle.

● The following codes in this manual

indicates the country.

Country Codes

Code Country SCV110F

Philippines

A Few Words About Safety

Your safety, and the safety of others, is very important. Operating this vehicle safely is an important responsibility. To help you make informed decisions about safety, we have provided operating procedures and other information on safety labels and in this manual. This information alerts you to potential hazards that could hurt you or others. Of course, it is not practical or possible to warn you about all hazards associated with operating or maintaining a vehicle. You must use your own good judgement.

You will find important safety information in a variety of forms, including:

● Safety labels on the vehicle

●

Safety Messages preceded by a safety alert symbol and one of three signal words: DANGER, WARNING, or CAUTION. These signal words mean:

3DANGER

You WILL be KILLED or SERIOUSLY HURT if you don’t follow instructions.

3WARNING

You CAN be KILLED or SERIOUSLY HURT if you don’t follow instructions.

3CAUTION

You CAN be HURT if you don’t follow instructions.

Other important information is provided under the following titles:

NOTICE

Information to help you avoid damage to your vehicle, other property, or the environment.

Contents

Vehicle Safety P. 2

Operation Guide P. 12

Maintenance P. 35

Troubleshooting P. 68

Information P. 76

Specifications P. 87

Index P. 90

Vehicle Safety

This section contains important information for safe riding of your vehicle. Please read this section carefully.

Safety Guidelines................................................. P. 3

Safety Precautions............................................... P. 6

Riding Precautions .............................................. P. 7

Accessories & Modifications........................... P. 10

Loading ................................................................ P. 11

Safety Guidelines

Follow these guidelines to enhance your safety:

● Perform all routine and regular inspections

specified in this manual.

● Stop the engine and keep sparks and flame

away before filling the fuel tank.

● Do not run the engine in enclosed or partly

enclosed areas. Carbon monoxide in exhaust gases is toxic and can kill you.

Always Wear a Helmet

It's a proven fact: helmets and protective apparel significantly reduce the number and severity of head and other injuries. So always wear an approved helmet and protective apparel. 2 P. 6

Before Riding

Make sure that you are physically fit, mentally focused and free of alcohol and drugs. Check

that you and your passenger are both wearing an approved helmet and protective apparel. Instruct your passenger on holding onto the grab rail or your waist, leaning with you in turns, and keeping their feet on the when the

vehicle

is stopped.

footpegs, even

Take Time to Learn & Practice

Even if you have ridden other vehicles, practice riding in a safe area to become familiar with how this vehicle works and handles, and to become accustomed to the vehicles size and weight.

Ride Defensively

Always pay attention to other vehicles around you, and do not assume that other drivers see you. Be prepared to stop quickly or perform an evasive maneuver.

Continued

Vehicle Safety

Safety Guidelines

Make Yourself Easy to See

Vehicle Safety

Make yourself more visible, especially at night, by wearing bright reflective clothing, positioning yourself so other drivers can see you, signaling before turning or changing lanes, and using your horn when necessary.

Ride within Your Limits

Never ride beyond your personal abilities or faster than conditions warrant. Fatigue and inattention can impair your ability to use good judgement and ride safely.

Don't Drink or Use Drugs and Ride

Alcohol or drugs and riding don't mix. Even one alcoholic drink can reduce your ability to respond to changing conditions, and your reaction time gets worse with every additional drink. The same is true for drug use. Don't drink or use drugs and ride, and don't let your friends do it either.

Keep Your Honda in Safe Condition

It's important to keep your vehicle properly maintained and in safe riding condition. Inspect your vehicle before every ride and perform all recommended maintenance. Never exceed load limits (2 P. 11), and do not modify your vehicle or install accessories that would make your vehicle unsafe (2 P. 10).

If You are Involved in a Crash

Personal safety is your first priority. If you or anyone else has been injured, take time to assess the severity of the injuries and whether it is safe to continue riding. Call for emergency assistance if needed. Also follow applicable laws and regulations if another person or vehicle is involved in the crash.

Safety Guidelines

If you decide to continue riding, first turn the ignition switch to the OFF position, and evaluate the condition of your vehicle. Inspect for fluid leaks, check the tightness of critical nuts and bolts, and check the handlebar, control levers, brakes, and wheels. Ride slowly and cautiously. Your vehicle may have suffered damage that is not immediately apparent. Have your vehicle thoroughly checked at a qualified service facility as soon as possible.

Carbon Monoxide Hazard

Exhaust contains poisonous carbon monoxide, a colourless, odorless gas. Breathing carbon monoxide can cause loss of consciousness and may lead to death.

If you run the engine in confined or even partly enclosed area, the air you breathe could contain a dangerous amount of carbon monoxide.

Never run your vehicle enclosure.

inside a garage or other

3WARNING

Running the engine of your vehicle while in an enclosed or even partially enclosed area can cause a rapid buildup of toxic carbon monoxide gas.

Breathing this colourless, odorless gas can quickly cause unconsciousness and lead to death.

Only run your vehicle engine when it is located in a well ventilated area outdoors.

Vehicle Safety

Safety Precautions

Vehicle Safety

● Ride cautiously and keep your hands on the

handlebar and feet on the floor.

● Keep passenger's hands onto the grab rail

or your waist, passenger's feet on the footpegs while riding.

● Always consider the safety of your

passenger, as well as other drivers and riders.

Protective Apparel

Make sure that you and any passenger are wearing an approved helmet, eye protection, and high-visibility protective clothing. Avoid wearing loose clothes that could get caught on any part of your vehicle. Ride defensively in response to weather and road conditions.

Helmet

Safety-standard certified, high-visibility, correct size for your head

● Must fit comfortably but securely, with the

chin strap fastened.

● Face shield with unobstructed field of vision

or other approved eye protection

3WARNING

Not wearing a helmet increases the chance of serious injury or death in a crash.

Make sure that you and any passenger always wear an approved helmet and protective apparel.

Gloves

Full-finger leather gloves with high abrasion resistance

Boots or Riding Shoes

Sturdy boots with non-slip soles and ankle protection

Jacket and Trousers

Protective, highly visible, long-sleeved jacket and durable trousers for riding (or a protective suit)

Riding Precautions

Running-in Period

During the first 500 km (300 miles) of running, follow these guidelines to ensure your vehicles future reliability and performance.

● Avoid full-throttle starts and rapid

acceleration.

● Avoid hard braking.

● Ride conservatively.

Brakes

Observe the following guidelines:

● Avoid excessively hard braking.

u Sudden braking can reduce the vehicle

stability.

u Where possible, reduce speed before

turning; otherwise you risk sliding out.

● Exercise caution on low traction surfaces.

u The tyres slip more easily on such

surfaces and braking distances are longer.

● Avoid continuous braking.

u Repeated braking, such as when

descending long, steep slopes can seriously overheat the brakes, reducing their effectiveness.

● For full braking effectiveness, operate both

the front and rear brakes together.

Combi Brake

Your vehicle is equipped with a brake system that distributes the braking force between the front and rear brakes. The distribution of the braking force applied to the front and rear brakes when operating the front brake lever only and when operating the rear brake lever only is different. For full braking effectiveness, operate both the front and rear brakes together.

Continued

Vehicle Safety

Riding Precautions

Wet or Rainy Conditions

Vehicle Safety

Road surfaces are slippery when wet, and wet brakes further reduce braking efficiency. Exercise extra caution when braking in wet conditions. If the brakes get wet, apply the brakes while riding at low speed to help them dry.

Parking

● Park on a firm, level surface.

● If you must park on a slight incline or loose

surface, park so that the vehicle cannot move or fall over.

● Make sure that high-temperature parts

cannot come into contact with flammable materials.

● Do not touch the engine, muffler, brakes

and other high-temperature parts until they cool down.

● To reduce the likelihood of theft, always lock

the handlebar and remove the key and close the shutter when leaving the vehicle unattended. Use of an anti-theft device is also recommended.

Parking with the Centre Stand

Stop the engine.

To lower the centre stand, stand on the left side of the vehicle. Hold the left handle grip and the grab rail. Press down on the tip of the centre stand with your right foot and, simultaneously, pull up and back.

Riding Precautions

Left handle grip

Centre stand

Grab Rail

Turn the handlebar fully to the left.

Turn the ignition switch to the LOCK position (2 P. 20), remove the key and close the shutter (2 P. 21).

Refuelling and Fuel Guidelines

Follow these guidelines to protect the engine, fuel system and catalytic converter:

● Use only unleaded petrol.

● Use recommended octane number. Using

lower octane petrol will result in decreased engine performance.

● Do not use fuels containing a high

concentration of alcohol. 2 P. 85

● Do not use stale or contaminated petrol or

an oil/petrol mixture.

● Avoid getting dirt or water in the fuel tank.

Vehicle Safety

Accessories & Modifications

Accessories &

Vehicle Safety

Modifications

We strongly advise that you do not add any accessories that were not specifically designed for your vehicle by Honda or make modifications to your vehicle from its original design. Doing so can make it unsafe. Modifying your vehicle may also void your warranty and make your vehicle illegal to operate on public roads. Before deciding to install accessories on your vehicle be certain the modification is safe and legal.

3WARNING

Improper accessories or modifications can cause a crash in which you can be seriously hurt or killed.

Follow all instructions in this owner's manual regarding accessories and modifications.

Do not pull a trailer with, or attach a sidecar to, your vehicle. Your vehicle was not designed for these attachments, and their use can seriously impair your vehicle handling.

●

Carrying extra weight affects your vehicles handling, braking and stability. Always ride at a safe speed for the load you are carrying.

●

Avoid carrying an excessive load and keep within specified load limits.

Maximum weight capacity / Maximum luggage weight 2 P. 87

● Tie all luggage securely, evenly balanced

and close to the centre of the vehicle.

● Do not place objects near the lights or the

muffler.

3WARNING

Overloading or improper loading can cause a crash and you can be seriously hurt or killed.

Follow all load limits and other loading guidelines in this manual.

Vehicle Safety

Braking

Stopping

If pulling off the road, signal early enough to show traffic that you are pulling over, and pull over smoothly.

(P.28)

Close the throttle and apply the front and rear brakes together.

u The brakelight will indicate

that you have applied the brakes.

Turning Corners

Do your braking before entering corners.

Refuelling

Gradually reapply throttle when exiting turn.

Parking

Park on a firm level surface. Use the stand, lock the steering and close the shutter.

(P.8)

(P.29)
