T E C H N O L O G Y
R E F E R E N C E
G U I D E
o w n e r s . h o n d a . c o m
2012 H o n d a CR-V E X - L with N a v i g a t i o n
31 T 0 BT 00 Technology R e f e r e n c e Guide
00X31-T0B-T001 ©2011 American Honda Motor Co., Inc. — All Rights Reserved Pr i n te d i n J a pa n
2012 CR-V EX-L
with Navigation
TE C H N O L O G Y R E FERENCE GUIDE
The Technology Reference Guide is designed to help you get
INSTRUMENT
PANEL p.4
MULTI-INFORMATION
DISPLAY p.8
acquainted with your new Honda and provide basic
instructions on some of its technology and convenience
features. This guide covers the CR-V EX-L with Navigation.
This guide is not intended as a substitute for the Owner’s
Manual. For complete information on vehicle controls and
operation, please refer to the respective sections in the
Owner’s Manual.
ECON
BUTTON p.6
AUDIO p.26
NAVIGATION p.16
Auto Door Locks .....................................................................................................2
Instrument Panel Indicators ...................................................................................4
TM
Eco Assist System
Tire Pressure Monitoring System (TPMS)...........................................................7
Multi-Information Display (MID)...........................................................................8
Voice Recognition...................................................................................................10
Navigation.................................................................................................................16
®
Bluetooth
HandsFreeLink®(HFL)........................................................................20
..................................................................................................6
SMS Text Messaging................................................................................................24
®
or USB Flash Drive .....................................................................................26
iPod
®
Bluetooth
Pandora
Multi-View Rear Camera ......................................................................................29
Owner Link..............................................................................................................30
Safety Reminder......................................................................................................31
Fuel Recommendation...........................................................................................31
Audio......................................................................................................27
®
...................................................................................................................28
AU TO DOOR L OCKS
Program how and when the vehicle doors automatically lock and unlock.
Default Lock/Unlock Setting
Default Lock Setting
All doors and the tailgate are
preset to lock when your vehicle
reaches about 10 mph.
Default Unlock Setting
Only the driver’s door is preset to
unlock when you shift into Park (P).
Programmable Auto Door Lock/Unlock Settings
Below are the options you can choose.See Auto Door Locking/Unlocking in your Owner’s
Manual for instructions on programming these settings.
Programming the Auto Door Unlock Setting
Press the (+/-) buttons on the steering wheel to scroll through the menu options.
Press SOURCE to select an option. See page 9 for more information on the multi-
information display and its controls.
1. Press MENU.
2. Select Customize Settings.
3. Select Door Setup.
4. Select Auto Door Unlock.
5. Select All Doors with Shift to P.
6. Press MENU to exit.
AUTO DOOR UNLOCK
(all doors)
the ignition OFF
door)
the ignition OFF
Turn off
When you turn
When you turn
Operate manually
When you shift
into Park
When you shift
into Park
Auto Lock
(all doors)
Turn off
Auto Lock
AUTO DOOR LOCK
When you
reach 10 mph
Operate manually
When you shift
out of Park
Auto Unlock
Auto Unlock
(only driver’s
Auto Unlock
2 3
INSTRUMENT PANEL INDICATORS
PASSENGER
AIRBAG
OFF
Briefly appear with each engine start. Red and amber indicators are most critical.
Blue and green indicators are used for general information.
If an indicator remains on, there may be a problem; see your dealer
Malfunction Indicators
Charging system
Low brake fluid, Brake system
Low oil pressure
EPS (electric power steering)
Malfunction indicator lamp
(check engine light)
®
VSA
(vehicle stability assist)
Door/Tailgate open:
Close door(s) / tailgate
Low tire pressure:
Add air
All-Wheel Drive* (blinks):
Pull over and idle
Low fuel:
Refill
Maintenance MinderTM:
Make service appointment
On/Off Indicators
SRS (supplemental restraint system)
Transmission (blinking)
D
ABS (anti-lock brake system)
Condition Indicators
Action is needed by driver
Parking brake on:
Release
4 5
TPMS (tire pressure monitoring
system)
E-DPS* (all-wheel drive)
DRL (Daytime running lights)
Seat belt reminder:
Fasten seat belt(s)
PASSENGER AIRBAG OFF
(next to multi-information display)
SIDE AIRBAG OFF
VSA®OFF
CRUISE MAIN on
CRUISE CONTROL on
ECON Mode on
Immobilizer (blinks): improperly
coded key; use correct key
1st detent: parking lights on
2nd detent: headlights on
Turn signals/hazards on
Fog lights on
High beams on
* if equipped
EC O ASSIST SY ST EM
TI RE PRESSUR E MONITORING SYSTEM (TP MS )
When turned on, performance of the vehicle’s engine, transmission,cruise control, and
air conditioning system may be affected to achieve maximum fuel economy.
ECON Button
1. Press ECON to turn the
system on.
2.The ECON mode indicator
comes on.
3. Press ECON again to turn the
system off.
Monitors the vehicle’s tire pressures.
How It Works
Each tire valve stem contains
a TPMS sensor.
When the tire pressure drops
significantly below recommended
levels, the low tire pressure
indicator comes on.
If the TPMS indicator appears,there
may be a problem with the system.
See your dealer.
What to Do
1. Visually inspect the tires for
damage.
2. Use a tire air pressure gauge to
Ambient Meter
Indicates instant fuel efficiency using color-coded bars.
High fuel efficiency Moderate fuel efficiency Low fuel efficiency
check which tire(s) have low
pressure.
3. Inflate the tire(s), if necessary,
to the recommended pressures
listed on the label on the
driver’s doorjamb.
6 7
MU LTI-INFORMATI ON DISPLA Y (MID)
Consists of several displays that provide you with useful information.
Accessing the MID
Press the Display button to
change the main displays.
Main Displays
Main display
Steering Wheel Controls
Use the steering wheel controls to navigate through the Vehicle Menu.
(+) Button:
Press to scroll
upward.
() Button:
Press to go back to
the previous display.
(-) Button:
Press to scroll
downward.
SOURCE Button:
Press to enter your
selection.
() Button:
Press to go to the next
display.
MENU Button:
Press to go to the Vehicle
Menu for customization
and other settings.
Trip
computer
Audio display
(or Phone
display during
call)
Clock
(or wallpaper)
8 9
VO ICE RECOGNITI ON
Key Functions by Voice Command
Control four different systems with the steering wheel buttons and the ceiling
microphone.
To prevent driver distraction, certain manual and touch screen functions
may be inoperable or grayed out while the vehicle is moving. Voice
commands are always available.
To keep your eyes on the road and hands on the wheel, use voice commands for
hands-free calling, navigation, and audio. For a full list of commands, say “Information”
and “Voice Info.”
N A V I G A T I O N p. 16
Pick-Up button: Answer an incoming call,
or go directly to the Phone screen.
Hang-Up/Back button: End a call, decline
an incoming call, or cancel a selection.
Talk button: Give navigation, HFL, audio,
or climate control commands.
Voice Command Tips
• Press and release the Talk button, wait for a beep, then give a command.
• All available voice commands are highlighted in blue when you press the Talk
button.
• For a list of available commands, press and release the Talk button and say
“Help” at any time.
• Speak in a clear, natural voice.
• Reduce all background noise.
• Adjust the dashboard and side vents away from the microphone in the ceiling.
• Close the windows.
• The system also uses a touch screen display. You can select options or icons by
touching them on the screen. This is limited while the vehicle is moving.
B L U E T O O T H
C L I M A T E C O N T R O L p. 15
®
H A N D S F R E E L I N K
A U D I O p. 15
®
p. 20
10 11
Commonly Used Voice Commands
Here are some examples of commonly used voice commands. Try some of these
to familiarize yourself with the voice command system.
Press and release the Talk button before you give a command.
Locate Points of Interest
Say a command like “Display
restaurant” to see restaurant
icons appear on the map.
Say a command like “Display gas
station” to see gas station icons
appear on the map.
Press and release the Talk button before you give a command.
Get Navigation Route
Information
After a destination is entered,
say “How far to the destination?”
to hear the remaining distance.
Press and release the Talk button before you give a command.
Make Audio Selections
Say a command like “Radio 97.1
FM” to select that station.
Say a command like “CD play
track 1” to hear that song on a
currently inserted CD.
Press and release the Talk button before you give a command.
Adjust the Vehicle’s
Climate Setting
Say a command like “Air
conditioner on” to start the
air conditioning system.
Say “Display entire route” to see
the routing method the system
mapped for your destination.
Say a command like “Fan speed
4” to adjust the fan speed.
12 13
Commonly Used Voice Commands (continued)
Here are some examples of commonly used voice commands. Try some of these
to familiarize yourself with the voice command system.
Press and release the Talk button before you give a command.
G e n e r a l C o m m a n d s
(Accepted on most screens to change displays)
• Display map
• Display menu
• Display information
• Display audio
• What time is it?
• Next/previous
• Left/right
• Up/down
F i n d P l a c e C o m m a n ds
(Accepted on Map screen)
• Find nearest:
- ATM - Honda dealer
- gas station - airport
- Mexican - hospital
restaurant - bank
- post office
N a v i ga t i o n C o m m a n ds
(Accepted on Map screen)
• How long/far to the destination?
• Display destination map
• Display entire route
(to change pages)
(to change tabs)
(to scroll lists up to three pages)
Press and release the Talk button before you give a command.
A u d i o C o m m a n d s
(Accepted on most screens)
• Audio on
• Radio # FM/AM
• Radio preset 1/2/3/4/5/6
• DISC/USB/iPod play
• DISC/USB/iPod skip forward/back
• Auxiliary (AUX) play
P h o n e C o m m a nd s
(Accepted on Phone screen)
• Dial
• Speed Dial 1 (or 2)
• Redial
• Phonebook
• Phone setup
(Accepted on any screen)
• Dial by number
• Dial by voice tag
Climate Control Commands
(Accepted on most screens)
• Air conditioner on/off
• Rear defrost on/off
• Climate control recirculate/
fresh air
• Fan speed up/down
• Temperature # degrees
(# = 57–87)
• Temperature max hot/cold
D i s p la y C o mm a n d s
(Accepted on Map screen)
• Display/Hide:
- ATM
- gas station
- restaurant
- post office
• Display north up/heading up
• Zoom in/out
• Go home
• Display current location
H e l p C o m m a n ds
(Accepted on most screens)
• Help (list of available commands
for current screen)
• Voice command help - from
INFO screen (list of all
available navigation and audio
commands)
14 15
NA VIGATION
Real-time navigation system uses GPS and a map database to show your current
location and help guide you to a desired destination.
Entering a Destination Using Voice Commands
Set a destination using a street address. For other destination options, see the
Navigation Manual.
Press and release the Talk button before you give a command.
1. Say“Display menu.” Say “Address.”
2. Say “Street,” then say the street
name on the next screen. Do
not include the direction (N, S, E,
W) or type (St., Ave., Blvd., etc.).
4. Say the entire street address
number. For example, “1-2-3-4.”
If necessary, say “OK” to
proceed.
5. If the street address is in more
than one city, a list of city names
appears. Say the number next to
the city you want to select.
Map Screen Legend
Calculated route
Direction of destination
Distance to go
Time to go
Current vehicle
location
Turn-by-Turn Directions
Shows a more detailed view of the next maneuvers during route guidance on the
multi-information display. See your Owner’s Manual for instructions on how to
turn this feature on or off.
3. A list of street names appears.
Say the number next to the
street you want to select.
6. The system displays the
“Calculate route to” screen. Say
“Set as destination” to set the
route.
Distance to next
maneuver
Upcoming maneuver
NOTE: If menu options are grayed out, they are only available using
voice commands. It is recommended that you enter your destination
Current route
before driving or when the vehicle is stopped.
16 17
Using the Find Nearest Command
FM Traffic
F ind a nearby point of interest, such as a gas station, movie theater, restaurant, etc.
Press and release the Talk button before you give a command.
1. From the map screen, say “Find
nearest ATM.”
2. A list of the nearest ATMs in
your area is displayed by
shortest distance to destination.
3. Say the number next to the
destination you want to select.
4. The system displays the
“Calculate route to” screen.
Say “Set as destination” to set
the route.
Provides continuously updated information, including traffic speed, incidents, and
construction in major metro areas. Works in cities where a clear FM traffic signal
is available.
Press and release the Talk button before you give a command.
Displaying Traffic Information
Say “Display traffic” to view traffic flow and icons.
Incident
Incident
icon
icon
Traffic
Traffic
Flow
Flow
data
data
Heavy traffic
Moderate traffic
NOTE:Traffic flow and incident icons are
only displayed on map scales of 5 miles
(8 km) or less.
Traffic Icons
Incident
Construction
Road closed
Weather
Traffic Rerouting
The system can automatically provide detours around traffic or incidents
when a destination is set.
1. Say “Display traffic list” to view
a list of incidents on your
route.
3. Say “Avoid,” and the incident
list returns.
2. Say the number of the incident
you want to avoid. When the
4. Say “Reroute” to set the new
route.
incident appears, say “Traffic
detail.”
18 19
BLUETOOTH
1. Press the Pick-Up button to
go to the Phone screen.
If a prompt appears asking to
connect to a phone, say “No”
and go to step 2.
5. Make sure your phone is in
Discovery mode, and say “OK.”
6. HFL searches for your phone. Say
the number next to the phone
when it appears on the list.
7. HFL gives you a four-digit code.
Enter it on your phone when
prompted. The phone is now
paired.
If your phone does not appear:
Say “Find Another Phone” and
search for HandsFreeLink from
your phone. Connect to HFL.
2. Say “Phone setup.”
3. Say “Bluetooth setup add
select a phone.”
4. Say “Search.”
Place and receive phone calls through your vehicle’s audio system. Visit
handsfreelink.honda.com to check if your phone is compatible.
To prevent driver distraction, certain manual and touch screen functions
may be inoperable or grayed out while the vehicle is moving. Voice
commands are always available.
®
HANDSFREELINK®(HFL)
How to Use HFL
Pick-Up button: Answer an incoming call, or
go directly to the Phone screen.
Hang-Up/Back button: End a call, decline an
incoming call, or cancel a selection.
Talk button: Give HFL commands.
Pairing Your Phone (continued)
Use this pairing method when a phone has already been paired to the system, or
when you want to pair an additional phone.
Press and release the Talk button before you give a command.
Pairing Your Phone
Use this pairing method when no phone has ever been paired to the system. You
can only pair your Bluetooth-compatible phone when the vehicle is stopped.
Press and release the Talk button before you give a command.
1. Press the Pick-Up button to
access the Phone screen. A
prompt appears. Say “Yes.”
2. Make sure your phone is in
discovery mode, and say “OK.”
3. HFL searches for your phone.
Select it when it appears on the
list. Go to step 4.
If your phone does not appear:
Select “Find Another Phone” and
search for a HandsFreeLink
device from your phone.
Connect to HFL. Go to step 4.
4. HFL gives you a four-digit code.
Enter it on your phone when
prompted.The phone is now paired.
20 21
Dialing a Number
Using the Phonebook
Enter a 10-digit phone number to call.
Press and release the Talk button before you give a command.
1. Press the Pick-Up button to
go to the Phone screen.
2. Say “Dial.”
Receiving a Call
1. A notification is heard and
the incoming phone number
appears on the navigation
screen.
3. Say the entire phone number,
then say “Dial” to call.
4. The call is connected and heard
through the vehicle speakers.
3. Press the Hang-Up button to
end or decline the call.
When your phone is paired, its entire phonebook is automatically imported to
the system.
Press and release the Talk button before you give a command.
1. Press the Pick-Up button
to go to the Phone screen.
2. Say “Phonebook.”
3. Scroll through the list to find
the name and number you want
to call. Say “Dial,” or press the
Pick-Up button to call.
4. The call is connected and heard
through the vehicle speakers.
Using Speed Dial
Up to 15 numbers can be stored with voice tags (see your Navigation Manual for
instructions).
Press and release the Talk button before you give a command.
1. Press the Pick-Up button
to go to the Phone screen.
If an entry has a stored voice tag,
say “Dial by voice tag,” followed
by the voice tag name and “Dial”
from any screen.
2. Say “Speed Dial 1” (or “Speed
2. Press the Pick-Up button to
accept the call.
Dial 2”) and the number next
to the entry. For example,
“One.” Say “Call,” or press the
Pick-Up button to call.
3. The call is connected and heard
through the vehicle speakers.
22 23
SM S TE XT MES SA GING
Replying to Text Messages
Receive and send text messages from your paired and linked Message Access Profile
(MAP)-compatible phone.Visit handsfreelink.honda.com to see if this feature is
compatible on your phone. Standard message rates apply.This feature is limited while
the vehicle is moving.
Receiving Text Messages
Press and release the Talk button before you give a command.
1. A notification appears on the
navigation screen when you
receive a text message.
2. Say “Read” to open the
message. The message is
displayed, and the system reads
it aloud.
Displaying Messages
Press and release the Talk button before you give a command.
1. Press the Pick-Up button to go
to the Phone menu.
3. Say the number next to the
message you want. The message
is displayed, and the system
reads it aloud.
Press and release the Talk button before you give a command.
1. With the message open, say
“Reply.”
2. Say the corresponding
number of one of the six
available reply messages.
Calling the Sender
Press and release the Talk button before you give a command.
“Call.”
3. Say “Send” to send the
message.
4. A notification appears after
the message is sent.
2. HFL begins dialing the number.1. With the message open, say
2. Say “Text Message.” The 20
most recent text messages
from your phone are displayed.
24 25
iP od®OR USB FLASH DR IV E
BLUETOOTH
®
AUDIO
*
Play audio files from your compatible iPod or USB flash drive through your vehicle’s
audio system.
Connecting Devices and Playing Audio Files
1. Pull out the USB adapter cable from
the center console.
2. Connect the USB adapter cable to your
iPod dock connector or flash drive.
3. Press SOURCE or CD/XM until
iPod or USB mode appears. Audio
begins to play.
4. Press
press
wheel.
() or ()
() or ()
to change tracks, or
on the steering
Play stored or streaming audio from your compatible phone through your vehicle’s audio
system. Visit handsfreelink.honda.com to check if this feature is available on your phone.
Playing
1. Make sure your phone is on and
2. Press SOURCE or CD/XM until
3. From your phone, open the desired
Bluetooth
paired to Bluetooth® HandsFreeLink
(see page 20).
Bluetooth Audio mode appears.
audio player or app and begin playing.
Sound is redirected to the audio
system.
Audio Files
®
4. Press
press
wheel*.
() or ()
() or ()
to change tracks, or
on the steering
Notes:
• Make sure the volume on your phone is properly adjusted.
• You may need to enable additional Bluetooth settings on your phone for playback.
• The play/pause function may not be supported on all phones.
iPod is a registered trademark of Apple Computer, Inc., registered in the U.S. and other countries. iPod not included.
*not supported on all phones
26 27
PA NDORA
®
MU LTI-VIEW REAR C AMERA
Play and operate Pandora®streaming radio from your iPhone®through your vehicle’s
audio system. Standard data rates apply.
Playing Pandora
1. Pull out the USB adapter cable
from the center console.
Connect your phone using a
USB dock connector.
2. Open Pandora from your phone.
Press SOURCE or CD/XM until
Pandora mode appears and
streaming begins.
3. From the audio screen, select
items such as Station List,
Like/Dislike, and Pause/Resume.*
For added convenience, the area behind your vehicle is displayed to help you navigate
while backing up.
How It Works
• When you shift into Reverse (R), a real-time image
of the area behind your vehicle is shown in the
navigation display.
• The rearview display turns off when you shift out of
Reverse.
Parking Guide Lines
• Yellow parking guide lines also appear to help
you judge distance. They can be turned on or
off.
• Press and hold CANCEL until the guide
lines turn on or off. They remain off until you
turn them on again.
Switching Views
Wide (default)
Normal
Top down
Notes:
• If Pandora is not selected from your phone, iPod music is played.
• Press the Home button on your iPhone to switch from Pandora to iPod.
To play Pandora again, you must reopen the app from your phone.
• If you cannot operate Pandora through the audio system, it may be
streaming through Bluetooth
audio system is selected.
iPhone is a registered trademark of Apple Computer, Inc ., registered in the U.S. and other countries.
®
Audio. Make sure Pandora mode on your
*Menu functions not available on all phones
There are three rearview modes: wide
(default view), normal, and top down.
• Select the corresponding icon to change
views.
Press ZOOM () or () to adjust the
•
screen brightness.
28 29
OW NER LINK
SA FETY REMINDER
Owner Link allows you to explore features and technologies specific to your vehicle,
schedule service appointments, obtain and update maintenance and service records,
manage your financial services account, and access other useful information. Register
at owners.honda.com to ensure that you continue to enjoy the experience of owning
a Honda.
Your vehicle is equipped with airbags. Airbags do not replace seat belts; they add to
the protection offered by seat belts. Airbags can help protect you in some types of
collisions, but they do not provide protection in all collisions.
Always make sure you and your passengers wear seat belts, and that young children
are properly secured in a child seat or booster in the rear seat. Never place an infant
seat in the front passenger’s seat as the force of a deploying airbag can seriously
injure an infant.
FU EL RECOMMENDA TI ON
• Only use unleaded gasoline of 87 octane or higher.
• Some gasoline in North America contains MMT, a manganese-based fuel additive.
Prolonged and consistent use of gasoline containing MMT can deteriorate your
vehicle’s performance, fuel economy, and the emissions control system. Always use
MMT-free gasoline if available. Failures caused by use of gasoline containing MMT
may not be covered under warranty.
• “TOP TIER Detergent Gasoline” meets a new gasoline standard jointly established
by leading automotive manufacturers to meet the needs of today’s advanced
engines. In most cases, qualifying gasoline retailers will identify their gasoline as
having met “TOP TIER Detergent Gasoline” standards at the retail location.This
fuel is guaranteed to contain the proper level of detergent additives and be free of
metallic additives. This helps avoid build-up of deposits in your engine and emission
control system. Because the level of detergency and harmful metallic additives
(such as MMT) in gasoline vary in the market, Honda endorses the use of “TOP
TIER Detergent Gasoline” where available to help maintain the performance and
reliability of your vehicle. For more information, visit www.toptiergas.com.
• For further important information on fuel and lubricants for your car and
information on gasoline that does not contain MMT, contact your dealer or visit
Owner Link at owners.honda.com.
30 31
Loading...
