Honda Civic Coupe EX with Navigation, Civic Coupe EX-L with Navigation, Civic Coupe Si with Navigation Technical Reference Guide

0 (0)

T E C H N O L O G Y

R E F E R E N C E

G U I D E

w w w . o w n e r s . h o n d a . c o m

2012 Honda C ivic C oupe E X, E X-L, and S i w it h N av ig ation 31 TS 8D 00 Technology Reference G uide 00 X3 1- TS8 -D 00 0 ©2011 American Honda Mot or Co., I nc. — All Rights Res erved Pr in te d i n U .S .A .

2012 CIVIC COUPE

EX, EX-L, and Si

with Navigation

TE C HNO LOG Y REF ERE NCE G UID E

INSTRUMENT PANEL p.4

The Technology Reference Guide is designed to help you get

acquainted with your new Honda and provide basic

instructions on some of its technology and convenience

features. This guide covers the Civic Coupe EX, EX-L, and Si

with Navigation trim levels.

This guide is not intended as a substitute for the Owner’s

Manual. For complete information on vehicle controls and

operation, please refer to the respective sections in the

Owner’s Manual.

Civic Coupe EX with Navigation shown throughout guide

BLUETOOTH

HANDSFREELINK®p.20

VOICE RECOGNITION p.10

NAVIGATION p.16

AUDIO p.23

Auto Door Locks .....................................................................................................2

Instrument Panel Indicators ...................................................................................4

Econ Button/Ambient Meter..................................................................................6

Tire Pressure Monitoring System (TPMS)...........................................................7

Multi-Information Display (MID)...........................................................................8

Voice Recognition...................................................................................................10

Navigation.................................................................................................................16

Bluetooth®HandsFreeLink®(HFL)........................................................................20

iPod

or USB Flash Drive .....................................................................................23

Bluetooth

Owner Link..............................................................................................................25

Safety Reminder......................................................................................................26

Fuel Recommendation...........................................................................................26

Audio......................................................................................................24

AU TO DOOR L OCKS

Program how and when the vehicle doors automatically lock and unlock.

Default Lock Setting

Default Unlock Setting

The doors are preset to lock when your vehicle reaches about 10 mph.

Programming the Auto Door Unlock Setting

Press the (+/-) buttons on the steering wheel to scroll through the menu options. Press SOURCE to select an option. See page 9 for more information on the multi-

information display and its controls.

1. Press MENU.

2. Select Customize Settings.

3. Select Door Setup.

4. Select Auto Door Unlock.

5. Select All Doors with Shift to P*.

6. Press MENU to exit.

Programmable Auto Door Lock/Unlock Settings

Below are the options you can choose.See Auto Door Locking/Unlocking in your owner’s manual for instructions on programming these settings.

AUTO DOOR LOCK

AUTO DOOR UNLOCK

Auto Unlock

(all doors)

Auto Unlock (only driver’s

door)

When you turn

the ignition OFF

When you turn

the ignition OFF

When you shift

into Park*

When you shift

into Park*

Only the driver’s door is preset to unlock when you:

Auto Lock

Turn off

Auto Lock

When you

reach 10 mph

Operate manually

When you shift

out of Park*

• Shift into Park (P) for automatic transmission vehicles.

• Turn the ignition switch to LOCK (0) for manual transmission vehicles.

*IGNOFF for manual transmission vehicles

Turn off

Auto Unlock

Operate manually

2 3

PASSENGER

AIRBAG

OFF

INSTRUMENT PANEL INDICATORS

Briefly appear with each engine start. Red and amber indicators are most critical. Blue and green indicators are used for general information.

Si only

i-VTEC indicator

REV indicators

Malfunction Indicators

If an indicator remains on, there may be a problem; see your dealer

Charging system

Low brake fluid, Brake system

Low oil pressure

SRS (supplemental restraint system)

Transmission (blinking)

(automatic transmission)

EPS (electric power steering)

Malfunction indicator lamp

(check engine light)

VSA

(vehicle stability assist)

TPMS (tire pressure monitoring

system)

Low temperature

ABS (anti-lock brake system)

Condition Indicators

Action is needed by driver

Parking brake on:

Release

Seat belt reminder:

Fasten seat belt(s)

Door/Trunk open:

Close door(s) / trunk

High temperature:

Drive slowly or pull over

Low tire pressure:

Add air

On/Off Indicators

PASSENGER AIRBAG OFF

(next to multi-information display)

SIDE AIRBAG OFF

VSA OFF

CRUISE CONTROL on

CRUISE MAIN on

ECON on*

Si only

Message indicator:

See MID

Low fuel:

Refill

Immobilizer Flashes: improperly coded key;

use correct key

1st detent: parking lights on 2nd detent: headlights on

Turn signals/hazards on

Fog lights on

High beams on

* not on Si

4 5

EC ON BUTTON*

mph

When turned on, the vehicle’s engine performance, transmission, and air conditioning system are adjusted for maximum fuel economy.

Turning the ECON Mode On/Off

TI RE PRESSUR E MONITORING SYSTEM (TPMS )

Monitors the vehicle’s tire pressures.

How It Works

Helps you further maximize your fuel economy by modifying some vehicle functions.

1. Press ECON.

2. The ECON mode indicator comes on.

3. Check the multi-information display for the system status.

4. Press ECON again to turn the system off.

AM BIENT M ET ER*

Each tire valve stem contains a TPMS sensor.

When the tire pressure drops significantly below recommended levels, the low tire pressure indicator comes on.

If a message also appears on the multi-information display, there may be a problem with the system. See your dealer.

What to Do

1. Visually inspect the tires for damage.

2. Use a tire air pressure gauge to check which tire(s) have low pressure.

Indicates instant fuel efficiency using color-coded bars.

Ambient Meter Color-Coded Bars

3. Inflate the tire(s), if necessary,

High fuel efficiency Moderate fuel efficiency Low fuel efficiency

* not on Si

6 7

to the recommended pressures listed on the label on the driver’s doorjamb.
