Page 1
T E C H N O L O G Y
R E F E R E N C E
G U I D E
o w n e r s . h o n d a . c o m
201 4 Ho nda Ci vic C ou pe E X, E X-L, a nd Si
31TS8B20 T ec hnol og y Ref er ence G ui de
00X31-TS 8-B200 ©2013 Americ an Honda Motor Co., Inc. — All R ights R eserved P ri nte d in U. S.A.
2014 Civic Coupe
EX, EX-L, and Si
Page 2
TEC HNO LOG Y R EFER ENC E G UID E
This Technology Reference Guide is designed to help you
get acquainted with your 2014 Honda Civic Coupe EX,
EX-L, or Si and provide basic instructions on some of its
INSTRUMENT PANEL p.4
BLUETOOTH
HANDSFREELINK®p.16
®
p.16
DISPLAY AUDIO p.14
technology and convenience features.
This guide is not intended to be a substitute for the
Owner’s Manual. For more detailed information on vehicle
controls and operation, please refer to the respective
sections in the Owner’s Manual.
Civic EX-L shown throughout guide
Smart Entry with Push Button Start.....................................................................2
Instrument Panel Indicators ...................................................................................4
Intelligent Multi-Information Display (i-MID).....................................................6
Eco Assist
Tire Pre ssure Monitoring System (TPMS)...........................................................9
Auto Door Locks ...................................................................................................10
One-Touch Turn Signal...........................................................................................11
Auto Headlights with Wiper Integration...........................................................11
Rearview Camera...................................................................................................12
LaneWatch™...........................................................................................................13
Display Audio ...........................................................................................................14
Bluetooth
TM
*..............................................................................................................8
®
HandsFreeLink®(HFL)........................................................................16
ECO
i-MID p.6
ASSISTTMp.8
SMS Text Messaging and E-Mail............................................................................20
Siri Eyes Free Mode ...............................................................................................21
HondaLink Assist ....................................................................................................22
Basic Audio Operation ..........................................................................................23
®
or USB Flash Drive .....................................................................................24
iPod
Bluetooth
Pandora
HDMI Video .............................................................................................................27
Settings for Your Vehicle ........................................................................................28
Honda Owners .......................................................................................................29
Safety Reminder......................................................................................................29
Fuel Information......................................................................................................29
®
Audio......................................................................................................25
®
...................................................................................................................26
*if equipped
Page 3
SMART E NT RY WITH P US H BUTTON ST AR T
Operate certain functions of your vehicle by simply having the remote transmitter
within operating range.
Unlocking the Doors
Locking the Doors
Grab either one of the front door handles
when the vehicle is off. Wait until the doors
unlock, then pull the handle to open.
Press the door lock button on either front
door handle when the vehicle is off.
Engine Start/Stop Button
Accessory or On Mode
Press ENGINE START/STOP once without pressing the brake pedal for Accessory
mode. Press it again for On mode.
Starting the Engine
Press and hold the brake pedal*, then press ENGINE START/STOP.
*For manual transmission, press and hold the clutch.
Turning the Vehicle Off
Shift to Park*, then press ENGINE START/STOP.
*For manual transmission, apply the parking brake.
Note: If you press ENGINE START/STOP and the shift lever is not in Park, the vehicle goes
into Accessory mode.
Opening the Trunk
Press the trunk release button under the
trunk handle. The vehicle can be on or off.
2 3
Page 4
PASSENGER
AIRBAG
OFF
INSTRUMENT PANEL INDICATORS
Briefly appear with each engine start. Red and amber indicators are most critical.
Blue and green indicators are used for general information. See your Owner’s
Manual for more information.
Si only
i-VTEC indicator
REV indicators
Malfunction Indicators
If an indicator remains on, there may be a problem; see your dealer
Charging system
Low brake fluid, Brake system
Low oil pressure
Supplemental Restraint System
(SRS)
Transmission (blinking)
D
Smart Entry System
Anti-Lock Brake System (ABS)
Electric Power Steering (EPS)
Malfunction indicator lamp
(check engine light)
Vehicle Stability Assist®(VSA)
Tire Pressure Monitoring System
(TPMS) (blinks and stays on)
Low temperature
Door/Trunk open:
Close door(s) / trunk
Low fuel:
Refill
Low tire pressure:
Add air
On/Off Indicators
PASSENGER AIRBAG OFF
(next to i-MID)
VSA OFF
CRUISE MAIN on
Si only
High temperature:
Drive slowly or pull over
Message indicator:
See i-MID
Immobilizer (blinks):
Use other vehicle key
and see dealer
Exterior lights on
Turn signals/hazards on
Fog lights* on
Condition Indicators
Action is needed by driver
Parking brake on:
Release
4 5
Seat belt reminder:
Fasten seat belt(s)
CRUISE CONTROL on
ECON* on
High beams on
*if equipped
Page 5
INTELLI GE NT MULTI- IN FORMATION DI SPLAY (i- MI D)
Consists of several displays that provide you with useful information.
Accessing the i-MID
Press the Display/Info button to
change main displays.
Main Displays
Main display Power
monitor
(Si only)
Sub-displays
Press the SEL/RESET button
to change sub-displays.
Steering Wheel Controls
Use these buttons to operate the i-MID and the Vehicle Menu.
Outside
temperature
Odometer
Trip A
Trip B
Clock
Clock
(or wallpaper)
Audio display
(or Phone
display during
call)
A warning or indicator message
may appear as necessary. Press
the INFO button to clear it.
*Press and hold the Display/Info button to enter the trip computer menu. Press Display/Info to scroll
through range, elapsed time, and average speed.
Trip
computer*
(+) Button:
Press to scroll
upward in the
Vehicle Menu.
) Button:
(
t
Press to go back to
the previous Vehicle
Menu screen.
(-) Button:
Press to scroll
downward in the
Vehicle Menu.
Display/Information
Button:
Change i-MID displays.
SOURCE Button:
Press to enter a
selection.
(
) Button:
u
Press to go to the next
Vehicle Menu screen.
MENU Button:
Press to go to Vehicle
Menu for customization
and other settings.
6 7
Page 6
ECO ASS IS T
mph
mph
mph
TM
TIRE PR ES SURE MONITO RI NG SYSTEM ( TPMS)
When turned on, performance of the vehicle’s engine, transmission, cruise control, and
air conditioning system are adjusted to maximize fuel efficiency. Available on EX and
EX-L.
Turning ECON Mode On/Off
1. Press ECON.
2. The ECON mode indicator
comes on.
3. Check the i-MID for the
system status.
4. Press ECON again to turn the
system off.
Monitors the vehicle’s tire pressures.
How It Works
When the tire pressure drops
significantly below recommended
levels, the low tire pressure
indicator comes on.
If a message also appears on
the i-MID, there may be a
problem with the system.
See your dealer.
What to Do
1. Visually inspect the tires for damage.
2. Use a tire air pressure gauge to
check which tire(s) have low
pressure.
3. Inflate the tire(s), if necessary, to the
recommended pressures listed on
the label on the driver’s doorjamb.
4. Start TPMS calibration.
What to Do
Ambient Meter
Indicates real-time fuel efficiency using color-coded bars.
High fuel efficiency Moderate fuel efficiency Low fuel efficiency
This feature can be turned off in the Customize Settings Menu. See your Owner’s
Manual for more information.
8 9
Any time you inflate, change, or rotate one or more of your tires, you need to
recalibrate the system. Use the buttons on the steering wheel to operate the
Vehicle Menu (see page 7).
1. Press MENU.
2. Select Customize Settings.
3. Select TPMS Calibration.
4. Select Initialize.
5. Select Yes.
Calibration begins and will finish automatically.
The process takes about 30 minutes of driving
30-60 mph.
6. Press MENU to exit.
Page 7
AUTO DO OR LOCKS
ONE-TOU CH TURN SIG NA L
Program how and when the vehicle doors automatically lock and unlock.
Door Locks
D e f a u l t L o c k S e t t i n g
The doors are preset to lock when
your vehicle reaches about 10 mph.
D e f a u l t U n l o c k S e t ti n g
Only the driver’s door is preset to
unlock when you:
• Shift into Park (P) for automatic
transmission vehicles.
• Turn the ignition switch to LOCK (0)
for manual transmission vehicles.
Changing Settings
Use this quick and convenient method to signal a lane change.
How It Works
• Lightly push the turn signal lever up or
down for a three-blink sequence.
• For a continuous signal, push the lever
up or down until it locks into place.
AUTO HE AD LIGHTS WITH W IPER INTE GR ATION
For your convenience, your vehicle’s headlights automatically turn on when the
windshield wipers operate.
How It Works
Use the buttons on the steering wheel to operate the Vehicle Menu (see page 7).
See your Owner’s Manual for a complete list of settings.
1. Press MENU.
2. Select Customize Settings.
3. Select Door Setup.
4 . Select Auto Door Lock or Auto Door Unlock.
5. Select one of the options.
6. Press MENU to exit.
Note: The driver’s and front passenger’s door can be opened by pulling the inner front door
handle, regardless of the setting.
Make sure your headlights are in
the AUTO position.
Turn on your windshield wipers.
The headlights also turn on.
When you turn off the windshield
wipers, the headlights turn off
shortly after.
10 11
Page 8
REARVIE W CAMERA
LANEWAT CH
TM
For added convenience, the area behind your vehicle is displayed to help you navigate
while backing up.
How It Works
• When you shift into Reverse (R), a real-time image of the area behind your vehicle
is shown in the screen, along with parking guidelines.
• The rearview display turns off when you shift out of Reverse.
Changing Settings
Turn the guidelines on or off.
Touch items on the screen to make selections.
1. From the HOME screen, select SETTINGS.
2. Select Camera.
3. Select Rear Camera.
4. Select one of the options.
Fixed Guidelines: Guidelines appear when
you shift into Reverse. Select On or Off.
Dynamic Guidelines: Guidelines move as you
turn the steering wheel. Select On or Off.
5. Press BACK to exit the menu.
Helps you check your right blind spot when you make a lane change to the right.
How It Works
When the right turn signal is activated, a camera located in the passenger side
door mirror shows the right rear area outside your vehicle on the display.
Display
Visibility Area
LaneWatch Display
Press the LaneWatch button on the turn signal switch to view a constant real-time
display. Press it again to turn the display off. The display still appears when the right
turn signal is activated.
See your Owner’s Manual for information on adjusting LaneWatch settings.
12 13
Page 9
DISPLAY AU DIO
Control various features of your vehicle using a touchscreen interface that is similar to
a smartphone.
Home Screen
Select HOME to view the main menu to select vehicle functions.
Touch items to select them.
HOME
screen
Volume
MENU:
Display the
menu for
the selected
screen.
BACK:
Return to
the previous
screen.
Phone
screen
Settings
screen
Info
screen
HondaLink
apps*
Audio
screen
Smartphone
connection:
View apps
when your
phone is
connected
through
HondaLink.
Using the Touchscreen
Use simple gestures to operate the screen.
Touch items on the
screen to select them.
Notes:
• Wearing gloves may limit or prevent touchscreen response.
• Some items may be grayed out during driving to reduce the potential for distraction. You can
select them when the vehicle is stopped.
Swipe to scroll through
a list.
Smartphone Connection
You can connect a compatible smartphone to the Display Audio system to enable
integration between the smartphone's approved apps and the vehicle. This allows
you to control the phone through the vehicle display.
To check smartphone compatibility and connection instructions, visit
handsfreelink.honda.com.
To get more information on HondaLink features and apps, visit www.hondalink.com.
*HondaLink can only be accessed if the app is installed on your smartphone, and
the phone is connected to the system (see opposite page).
14 15
Page 10
BLUETOOTH
Place and receive phone calls through your vehicle’s audio system. Visit
handsfreelink.honda.com to check if this feature is compatible with your phone.
To reduce the potential for driver distraction, certain functions may be
inoperable or grayed out while the vehicle is moving. Stop or pull over to
perform the function.
®
HANDSFREELINK® (HFL)
How to Use HFL
Pick-Up button: Answer an incoming
call.
Hang-Up/Back button: End a call,
decline an incoming call, or cancel a
selection.
Talk button: Make a call using a stored
voice tag or phone number.
+/- buttons: Scroll the list.
SOURCE button: Press to enter a selection.
MENU button: From the phone screen, press and
hold to display speed dial, call history, or redial.
Pairing Your Phone
Pair your phone when the vehicle is stopped to begin using hands-free phone and
related audio functions.
Touch items on the screen to make selections.
1. From the Home screen, select Settings.
2. Select Phone.
3. Select Bluetooth Device List.
4. Select Add Bluetooth Device.
5. Make sure your phone is in discovery
mode and select OK.
6. HFL searches for your phone. Select
your phone when it appears on the list.
If your phone does not appear:
Select Phone Not Found and search for
HandsFreeLink from your phone.
7. HFL gives you a six-digit code. Compare
it to the code that appears on your
phone. Connect to HFL from your
phone.
8. The system asks if you want to enable
options:
HondaLink Assist: Select On to enable
emergency notification in the event of a
collision (see page 22).
Phone Synchronization: Select On to
automatically import contacts and call
history from your phone.
Phone: Display the phone screen.
Settings: Display the settings
screen and select Phone for phone
pairing and more.
MENU: From the phone screen,
select various call options.
BACK: Return to the previous
screen.
16 17
Page 11
Dialing a Number
Using Speed Dial or Call History
Enter a 10-digit phone number to call. This feature is inoperable when the
vehicle is moving.
Touch items on the screen to make selections.
1. From the Home screen, select Phone.
2. Select MENU.
3. Select Dial.
4. Enter the phone number.
5. Select the green Dial icon to begin the
call.
Using the Phonebook
When your phone is paired, its entire phonebook is automatically imported to
the system. This feature is inoperable when the vehicle is moving.
Touch items on the screen to make selections.
1. From the Home screen, select Phone.
2. Select MENU.
3. Select Phonebook.
4. Scroll through the list to find the
name and number you want.
5. Select the entry to begin the call.
Store up to 20 speed dial entries, or view the last 20 calls for quick calling.
Touch items on the screen to make selections.
1. From the Home screen, select Phone.
2. Select a speed dial entry to call, or
select Call History and a number.
Scroll through the list if necessary.
For the full list of entries, select MENU
and Speed Dial or Call History.
When a speed dial entry is stored with a voice tag, you can make a call using
voice commands at any time. Press the Talk button and follow the prompts.
See your Owner’s Manual for more information.
Receiving a Call
A notification is heard and the following screen appears:
Press the Pick-Up button
or select Answer on the screen
to answer the call.
Press the Hang-Up/Back
button or select Ignore on the
screen to decline the call.
18 19
Page 12
SMS TEX T MESSAGING A ND E-MAIL
SIRI EYES FREE MODE
Receive and send text messages or e-mails from your paired and linked compatible
phone. Visit handsfreelink.honda.com to check if this feature is compatible with your
phone. Standard message rates apply. This feature is limited while the vehicle is moving.
Receiving Messages
Touch items on the screen to make selections.
1. A notification appears on the screen.
Select Read to open the message.
2. The message is displayed, and the system
reads it aloud.
Replying to Messages
Touch items on the screen to make selections.
1. With the message open, select Reply.
2. Select one of the six available reply
messages.
3. Select Send.
Activate Siri through your vehicle when an iPhone®is paired to the system. Visit
handsfreelink.honda.com to check if this feature is compatible with your phone.
How It Works
Make sure your phone is paired to Bluetooth®HandsFreeLink®before using Siri in
the vehicle (see page 17).
Hang-Up/
Back button
Talk button
To activate Siri: Press and hold the Talk button
until the Smartphone screen appears and you
hear the Siri tone. Say your Siri command.
If you only press and release the Talk button, the
standard voice recognition system is activated.
To cancel a command: Press the Back button.
Siri Commands
Here are some examples of Siri commands:
Calling the Sender
Touch items on the screen to make selections.
1. With the message open, select Call.
2. The system begins dialing the number.
Note: Notifications and operation for SMS Text and E-mail are separate. Choose your
desired account in Phone Settings (see page 28).
•“Call John Smith”
•“Read my new text message”
•“Find a nearby sushi restaurant”
Notes:
• Any requests that include visual feedback from Siri on your phone are not displayed in the
vehicle.
• Certain commands rely on the iPhone’s features and existing apps.
• To hear turn-by-turn directions or songs through the vehicle, set the audio mode to
Bluetooth®Audio.
•“Remind me to pick up dinner”
•“Set up a meeting today at 3 p.m.”
•“Play song XYZ”
Siri and iPhone are trademarks of Apple, Inc.
20 21
Page 13
HONDALI NK ASSIST BASIC A UD IO OPERAT IO N
Automatically connect and talk to an operator who can locate your vehicle and
request emergency help in the event of a collision. Visit www.hondalink.com for more
information.
How It Works
Make sure your phone is on and paired to Bluetooth®HandsFreeLink®(see page 17).
Touch items on the screen to make selections.
1. Select Call Now, or the system
automatically connects after 10 seconds.
The vehicle information and its location
is sent to the operator.
2. Select Talk Now to immediately talk to
the operator.
3. When the call is complete, select Hang
Up or press the Hang-Up/Back
button.
Operate basic controls of your audio system using several convenient methods.
Steering Wheel Controls
+ button: Increase
volume, or scroll up
in a menu.
button: Go to
t
previous stations
or tracks.
- button: Decrease
volume, or scroll
down in a menu.
SOURCE button:
Select an audio source,
or make a selection in
a menu.
button: Go to next
u
stations or tracks.
MENU button: From
the audio screen, press
and hold to display
audio options.
Touchscreen Controls
From the Home screen, select Audio to view or control audio being played.
SOURCE: Select
an audio source.
Volume
MENU: Choose
menu options for
the selected source.
FM screen shown
Open/close tab:
View and select
presets or tracks.
Audio control:
Tune to a station,
change tracks, or
other options.
USB/HDMI Connection
HDMI
port
Connect an iPhone or iPod cable or a
USB flash drive to the USB port in the
front console. There is an additional
Connect your device only when your
vehicle is stopped.
USB port in the center console.
Connect an HDMI cable to the HDMI
port.
22 23
USB
port
Page 14
iPod®OR USB FL ASH DRIVE
BLUETOOTH
®
AUDIO
Play audio files from your compatible iPod or USB flash drive through your vehicle’s
audio system. See your Owner’s Manual for a list of compatible devices.
Playing Audio Files
Select the iPod
or USB icon
from Source.
1. Connect the iPod cable or USB flash drive to the USB port in the front or
center console (see page 23).
2. From the Home screen, select Audio. Select Source and select the iPod or USB
icon.
3. Use the touchscreen or steering wheel controls to change tracks.
iPod is a trademark of Apple, Inc .
Searching for Music
Touch items on the screen to make selections.
1. From the Audio screen, select the
open/close tab.
2. Select the left tab to view categories
or folders.
3. Select a category or folder.
4. Select a track to begin playing.
Play stored or streaming audio from your compatible phone through your vehicle’s audio
system. Visit handsfreelink.honda.com to check if this feature is compatible with your phone.
Playing
Bluetooth
Select the
Bluetooth icon
from Source.
1. Make sure your phone is on and paired to Bluetooth® HandsFreeLink®(see
page 17).
2. From the Home screen, select Audio. Select Source and select the Bluetooth
icon.
3. From your phone, open the desired audio player or app and begin playing.
Sound is redirected to the audio system. Make sure the volume on your
phone is properly adjusted.
4. Use the touchscreen or steering wheel controls to change tracks.
Notes:
• You may need to enable additional settings on your phone for playback.
• The play/pause function and remote audio controls are not supported on all phones.
• Operate your phone only when your vehicle is stopped.
Audio
24 25
Page 15
PANDORA
®
HDMI VI DE O
Play and operate Pandora from your compatible phone through your vehicle’s audio
system. Visit handsfreelink.honda.com to check if this feature is compatible with your
phone. Standard data rates apply.
Playing Pandora
Select the
Pandora icon
from Source.
1. For Bluetooth connection: Make sure your phone is paired to Bluetooth
HandsFreeLink®(see page 17) and the screen is on and unlocked.
For USB connection: Connect the dock connector to the USB port in the front
or center console (see page 23).
2. From the Home screen, select Audio. Select Source and select the Pandora
icon. Streaming begins.
3. Use the touchscreen to like/dislike songs, and the touchscreen or steering
wheel controls to change tracks.
iPhone is a trademark of Apple, Inc.
®
Play video from a compatible device through your vehicle when it is stopped.
Playing HDMI Video
Select the
HDMI icon
from Source.
1. Connect a compatible device to an HDMI cable. Connect the HDMI cable to
the HDMI port in the front console (see page 23).
2. From the Home screen, select Audio. Select Source and select the HDMI icon.
3. From the connected device, launch the video to view on the display in the
vehicle.
Notes:
• Video will not display while the vehicle is moving.
• The device or video resolution must be 720p or lower to view in the vehicle.
Notes:
• iPhone can connect via Bluetooth or USB; Android and BlackBerry can connect via
Bluetooth only.
• If you cannot operate Pandora through the audio system, it may be streaming through
Bluetooth®Audio. Make sure the Pandora source on your audio system is selected.
• A pop-up may appear on your phone requesting you to allow access for the app to be
launched.
• Operate your phone only when your vehicle is stopped.
26 27
Page 16
SETTING S FOR YOUR VEHICLE
HONDA O WN ERS
Change different settings for many features in your vehicle. See your Owner’s Manual
for detailed information on settings and options.
Adjusting Vehicle Settings
From the Home screen,
select Settings.
Choose from the available options:
Phone
Pair a phone, change call and
text/e-mail settings, and more.
Audio
Change sound settings and
connection methods.
Bluetooth
Change Bluetooth settings.
Info
Import wallpaper and select
clock settings.
Camera
Change rear camera and
LaneWatch settings.
System
Adjust display settings, system
sounds, and more.
Visit owners.honda.com and register to explore features and technologies specific to
your vehicle, obtain and update maintenance and service records, manage your
financial services account, and access other useful information. For added convenience,
Honda Owners can also be accessed on a mobile device.
SAFETY RE MINDER
Your vehicle is equipped with airbags. Airbags do not replace seat belts; they add to
the protection offered by seat belts. Airbags can help protect you in some types of
collisions, but they do not provide protection in all collisions.
Always make sure you and your passengers wear seat belts, and that young children
are properly secured in a child seat or booster in the rear seat. Never place an
infant seat in the front passenger’s seat as the force of a deploying airbag can
seriously injure an infant.
See your Owner’s Manual for more information.
FUEL IN FO RMATION
Civic Coupe: Use of unleaded gasoline of 87 octane or higher is recommended.
Civic Coupe Si: Use of unleaded gasoline of 91 octane or higher is required.
• Honda recommends TOP TIER Detergent Gasoline where available.
• Do NOT use gasoline containing more than 15% ethanol.
• Do NOT use gasoline containing methanol.
• Do NOT use gasoline containing MMT.
See your Owner’s Manual for more information.
Some gasoline in North America contains MMT, a manganese-based fuel additive.
Prolonged and consistent use of gasoline containing MMT can deteriorate your
vehicle’s performance, fuel economy, and the emission control system. Always use
MMT-free gasoline if available. Failures caused by use of gasoline containing MMT may
not be covered under your new vehicle warranty.
TOP TIER Detergent Gasoline (recommended) never contains MMT and has
detergent additives to keep your engine clean. For further information on fuel and
lubricants for your car and information on gasoline that does not contain MMT,
contact your dealer or visit owners.honda.com.
28 29
Loading...
