Heart-Rate Smartwatch

Impulse 8100

User Manual

V1.0

HOLUX Heart-Rate Smartwatch Impulse 8100

1

Safety instructions

• Read this manual carefully before use to ensure safe
operation of the device.

• The device is not a medical device and only used f or the
measurement in normal exercises. Make sure the device is
worn in the correct measuring position. If you feel
uncomfortable during the exercise, stop and seek medical
advice immediately. The user must use the device carefully
and it is up to the user rather than HOLUX to take all safety
responsibilities.

• If you feel discomfort in your skin or an allergic reaction
occurs, stop wearing the device and seek medical advice
immediately.

• Do not use or store t he devi ce in the foll owing envi ronments
to avoid failure or damage.

- Don’t expose the device to extreme temperatures or

humidity or operate it in such environments;

- Do not use the device in dusty areas.

• Though the device provides waterproof function (IP67 water
resistance), the following instructions must be followed
when you use the device:

- Don’t soak the device or use it in water;

- Don’t take shower or sauna bath with the device worn

around the wrist to avoid affecting or damaging the

HOLUX Heart-Rate Smartwatch Impulse 8100

2

waterproof function;

- Do not rinse the device directly under a faucet to avoid

affecting or damaging the waterproof function.

• Do not remove or replace the battery. Only well trained
service personnel are allowed to disassemble/install the
internal compon en ts. Note: Explosion m a y occur if the
battery is not replaced with a new one of the same model or
equivalent type. Contact the manufacturer to dispatch
professional service personnel for battery replacement.

• Do not try to disassemble or repair device yourself to avoid
failure or device malfunction or occurrence of accidents.

HOLUX Heart-Rate Smartwatch Impulse 8100

3

Warranty Statement

• This warranty applies to parts and services that are
manufactured and sold through HOLUX. The warranty length
is one year from date of purchase (starting from the date on
the sales receipt). Under normal user operation, HOLUX
provides free repair services.

• HOLUX is not respon s ible for providing repairs or
replacements of any software; HOLUX does not provide any
warranty service for third party software/hardware.

• Important instructions

1. Note: This warranty does not cover damage or

malfunction from the below causes: unauthorized
disassembly/modification of unit, abuse or incorrect
usage, accidental and other unpreventable causes,
operation under variables mentioned that are different
from those in this product user manual, using parts not
made or sold by HOLUX, or repairs done by anyone other
than HOLUX and authorized retail/service providers.

2. Expendable parts are not covered in the warranty.

3. HOLUX is not responsible for any program, data, or

portable storage media damages or loss. Please contact
your local HOLUX authorized service provider to learn
more about geographical limitations, proof of purchase
requests, response time agreements, and other specific
maintenance service requests.

HOLUX Heart-Rate Smartwatch Impulse 8100

4

4. The content of this user manual is subject to change

without prior notice. Please contact us if you have any
question or notice any errors in descriptions in the user
manual.

HOLUX Heart-Rate Smartwatch Impulse 8100

5

Copyright Information

No part of this manual, including the products and software
described in it, may be reproduced, transmitted, transcribed,
stored in a retrieval system, or translated into any language in
any form or by any mean, without the express written
permission of Holu x Technolog y, Inc.

Copyright, All Rights Reserved.

HOLUX Heart-Rate Smartwatch Impulse 8100

6

Federal Communications Commission (FCC)
Statement

This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communic a tions. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the inter f erence by one or more of t he following
measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and

receiver.

• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician
for help.

CAUTION: Any changes or modificati on s not expressly
approved by the grantee of this device could void the user's

HOLUX Heart-Rate Smartwatch Impulse 8100

7

authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is

subject to the fol lowing two conditi ons: (1) This devi ce may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.

For product available in the USA/Canada market, only channel
1~11 can be operated. Selection of other channels is not
possible.

RF Exposure Warning

This equipment must be installed and operated in accordance
with provided instructions and the antenna(s) used for this
transmitter must be installed to End-users and installers must
be provided with antenna installation instructions and
transmitter operating conditions for satisfying RF exposure
compliance.

HOLUX Heart-Rate Smartwatch Impulse 8100

8

Content

PRODUCT INTRODUCTION .......................................... 10

P

RODUCT OVERVIEW ........................................................ 11

B

ASIC KEY FUNCTIONS ...................................................... 12

A

CCESSORIES ................................................................ 13

C

HARGING THE BATTERY ................................................... 14

H

OW TO WEAR THE SMARTWATCH ........................................ 15

M

AINTENANCE OF THE PRODUCT .......................................... 15

HOW TO USE IMPULSE 8100 ....................................... 16

OWER ON/OFF .............................................................. 16

P
I

NITIAL SETUP ................................................................ 17

M

ENU FUNCTION ............................................................. 18

Legends................................................................... 20

Step Function ........................................................... 21

Distance Function ..................................................... 24

Calorie Calculation .................................................... 27

Exercise Functi on ...................................................... 30

Heart-rate Measurement Function ............................... 36

Sleep Monitor Function .............................................. 40

Fatigue Detection Function ......................................... 45

Music Playback ......................................................... 49

Stopwatch ............................................................... 51

Countdown .............................................................. 53

Electronic Compass ................................................... 56

Setup Mode.............................................................. 58

HOLUX Heart-Rate Smartwatch Impulse 8100

9

APP INSTALLATION .................................................... 73

NORMAL CARE AND MAINTENANCE ............................ 77

SPECIFICATION.......................................................... 79

HOLUX Heart-Rate Smartwatch Impulse 8100

10

Product Introduction

Thank you for purchasing HOLUX Heart-Rate Smartwatch
Impulse 8100.

Impulse 8100 is a smartwatch designed for people who are in
pursuit of a healthy lifestyle and convenience in exercising. It
has the most advanced integrated physical monitoring
technology and can accurately measure the heart-rate for long
periods continuously so that users can monitor their heart and
lung functions an d exercise effectiveness. It can also detect
when the user is tired and notify him/her to drive safely, and
provides sleep analyses. It also uses the steps function that
allows the setting of walking target value as needed, and
calculates calorie consumption to help remind the amount of
daily exercise achieved.

Impulse 8100 supports Bluetooth pairing with various
smartphones to be used to remind users of incoming calls and
messages, and record their exercising status. It can also be
used with a dedicated APP to help tracking the exercising
results. Results are integrated into cloud data to perform
analysis and management of the physical conditions.

11

Product Overview

Touch

screen

Power

Front View

HOLUX Heart-Rate Smartwatch Impulse 8100

Backlight/ Menu

Rear View

Back

Shortcut ­Media play

Micro USB Port

OHR

HOLUX Heart-Rate Smartwatch Impulse 8100

12

Basic key functions

Key Operation and Function

 Press and hold the key for 3 seconds

to turn on the power.

Power

Backlight/Menu

 Press and hold the key for 8 seconds

to reset the system if the device
cannot operate normally.

 Backlight: Press the key for 1 second

to turn on/off the backlight.

 Menu: Press and hold the key for 3

seconds to open the menu scr een and
show the power on/off, Bluetooth
connection, heart rate detection, and
warning messages. You can select the
function that you need from the
screen.

 Screen lock: Press the key for 1

second and follow the on-screen

instructions to unlock the screen.
Back Return to the previous page.
Shortcut –

Press to enter the music play page.

Media play

HOLUX Heart-Rate Smartwatch Impulse 8100

13

Accessories

Check the box for the following supplied accessories. If any is
missing, contact your supplier immediately.

Impulse 8100 Micro USB cable Quick Guide

HOLUX Heart-Rate Smartwatch Impulse 8100

14

Charging the Battery

Using the AC charger (Optional)

Plug the micro USB plug of the AC charger into the micro USB
port on the rear of the Smartwatch. Plug the AC charger into a
wall outlet.

Connecting to a PC

Connect the micro USB plug of the USB cable to the mini USB
port on the rear of the Smartwatch. Connect the USB plug
(larger) or the USB cable to a USB port on your computer.

HOLUX Heart-Rate Smartwatch Impulse 8100

15

How to wear the Smartwatch

When using Impulse 8100, wear your watch on the wrist below
the wrist bone as shown in the following figure. To measure the
heart rate correctly, make sure the strap fits snugly around the
wrist to ensure the watch is pressed against the skin.

Wrist bone

Maintenance of the product

• You can use a damp cloth to wipe the watch or use gentle
soap solution to remove oil or dirt.

• Use a wet cotton swab to clean the area around the sensor.
Clean it every week if you use the product frequently.

• Be careful not to scratch the sensor part to avoid damage.

• Keep the watch away from any powerful chemical agents,

such as gasoline and acetone, to avoid damage.

HOLUX Heart-Rate Smartwatch Impulse 8100

16

Power

Menu

How to use Impulse 8100

Power on/off

Power on: Press and hold the Power key until the boot page
appears on the LCD screen.

※ Make sure the battery is fully charged (charging time: about

2 hours) before using the product to ensure normal
operation of the system.

Backlight/

Power off: Press and hold the Power key for 3 seconds and the

following options appear on the screen. Press
the device.

to turn off

HOLUX Heart-Rate Smartwatch Impulse 8100

17

Initial setup

When using the device for the first time, follow the on-screen
instructions to complete the initial set u p process. If you reset
the device to its default settings, the initial setup process will be
activated automatically when the device is turned on.

Slide the screen to the right and configure the following
settings:

→ → → →

Boot screen Slide the

Set the date Set the time
screen to the
right

→

→

→ →

Set the unit Set the age Set the height Set the weight

Setting
Complete

→ →

Read the
Disclaimer

Main menu

HOLUX Heart-Rate Smartwatch Impulse 8100

18

Menu function

The time page appears once you turn on the device. Slide the
screen to the left or right to navigate the function pages. The
following table lists the available functions.

Main menu page
Display the basic information including

the date, time, and power status.

Menu page 2 (slide to the right)
Display total steps taken, total distance

travelled, total calories burned, and
exercise functi on s.

Menu page 3 (slide to the right)
Display the heart rate measurement,

sleep, fatigue measurement, and music
play functions.

※To m easure your heart rate, stay calm

and relax for 20-30 seconds after
activating the HR function. After the
device detects your heart rate, only then
you can do normal activities.

HOLUX Heart-Rate Smartwatch Impulse 8100

19

Menu page 4 (slide to the right)
Display the stopwatch, countdown,

compass, and setup functions.

Slide the screen upward in any menu
page to display the information of the
current measurement. Press the Back key

to return to the previous page.

HOLUX Heart-Rate Smartwatch Impulse 8100

20

Legends

The icons on the main page are described below.

Bluetooth on

Missed Calls prompt on
mobile phone

Event notification
prompt on mobile
phone

Alarm clock
Vibrate mode
Power level display

Power level 65~100%;
Power level 35~65%;
Power level 10~35%;

Connected to mobile
phone via Bluetoot h

Unread Messages
prompt on mobile
phone

Unread app Messages
prompt on mobile
phone

Buzzer mode
Screen lock

Power l evel <10%; a low power message appears.

HOLUX Heart-Rate Smartwatch Impulse 8100

21

Step Function

The step function can help the user calculate the number of

steps you have walked. Select the
Step mode.

Enabling Step Mode

In the “Step” page, slide the screen to the right

and select
and start calculating and recording the number
of steps taken.

Once the function is enabled, the icon will be

function button to enter

to enable the step function

displayed as “solid” (

).

Disabling Step Mode
To stop or clear the step record, slide the

screen to the right again.

: Stop counting and save the

HOLUX Heart-Rate Smartwatch Impulse 8100

22

record.

continue counting.
In the step function page, slide the screen

downwards to configure the target value,
browse the history lists, and delete history
records.

: Clear the current record and

Set target value

Slide the screen
upwards/downwards to

select a target value.
will appear once the value

is selected. Press the

return button

to save

the target value and return
to the previous page.

The target value set will be
displayed on the main step
function page.

HOLUX Heart-Rate Smartwatch Impulse 8100

23

Browse History Record

All step records are
displayed according to the
date.

Slide the screen to the
left/right to display the
records of other dates.

Slide the screen upwards to display related
information currently detected.

Press the return button

to return to the

previous page.
