Holmes HM3655 User Manual

STORAGE INSTRUCTIONS

REPLACEMENT ACCESSORIES

SERVICE INSTRUCTIONS

1. DO NOT attempt to repair or adjust any electrical or mechanical functions on this unit. Doing so will void the
warranty.

2. If you have any questions regarding this unit’s operation or believe any repair is necessary, please write to our
Consumer Service Department.

3. If you need to exchange the unit, please return it in its original carton, with a sales receipt, to the store where you
purchased it. If you are returning the unit more than 30 days after the date of purchase, please see the enclosed
warranty.

4. If you have any other questions or comments, see our correspondence below or visit our website at
www.holmesproducts.com.

Sunbeam Products, Inc. doing business as Jarden Consumer Solutions
303 NELSON AVENUE

NEOSHO, MO 64850
For your own records, staple or attach your sales receipt to this manual. Also, please take a moment to write the store
name/location and date purchase below.

STORE NAME:
LOCATION:
DATE PURCHASED:

(STAPLE RECEIPT HERE)

PLEASE READ AND SAVE THESE IMPORTANT INSTRUCTIONS

WARRANTY INFORMATION

© 2007 Sunbeam Products, Inc. doing business as Jarden Consumer Solutions. All Rights Reserved.

6 YEAR LIMITED WARRANTY

Sunbeam Products, Inc. doing business as Jarden Consumer Solutions or if in Canada, Sunbeam Corporation (Canada)
Limited doing business as Jarden Consumer Solutions (collectively “JCS”) warrants that for a period of six years from
the date of purchase, this product will be free from defects in material and workmanship. JCS, at its option, will repair
or replace this product or any component of the product found to be defective during the warranty period. Replacement
will be made with a new or remanufactured product or component. If the product is no longer available, replacement
may be made with a similar product of equal or greater value. This is your exclusive warranty. Do NOT attempt to
repair or adjust any electrical or mechanical functions on this product. Doing so will void this warranty.

This warranty is valid for the original retail purchaser from the date of initial retail purchase and is not transferable.
Keep the original sales receipt. Proof of purchase is required to obtain warranty performance. JCS dealers, service centers,
or retail stores selling JCS products do not have the right to alter, modify or any way change the terms and conditions of this
warranty.

This warranty does not cover normal wear of parts or damage resulting from any of the following: negligent use or
misuse of the product, use on improper voltage or current, use contrary to the operating instructions, disassembly, repair
or alteration by anyone other than JCS or an authorized JCS service center. Further, the warranty does not cover: Acts
of God, such as fire, flood, hurricanes and tornadoes.

What are the limits on JCS’s Liability?

JCS shall not be liable for any incidental or consequential damages caused by the breach of any express, implied or
statutory warranty or condition.

Except to the extent prohibited by applicable law, any implied warranty or condition of merchantability or fitness for a
particular purpose is limited in duration to the duration of the above warranty.

JCS disclaims all other warranties, conditions or representations, express, implied, statutory or otherwise.
JCS shall not be liable for any damages of any kind resulting from the purchase, use or misuse of, or inability to use the

product including incidental, special, consequential or similar damages or loss of profits, or for any breach of contract,
fundamental or otherwise, or for any claim brought against purchaser by any other party.

Some provinces, states or jurisdictions do not allow the exclusion or limitation of incidental or consequential damages or
limitations on how long an implied warranty lasts, so the above limitations or exclusion may not apply to you.

This warranty gives you specific legal rights, and you may also have other rights that vary from province to province,
state to state or jurisdiction to jurisdiction.

How to Obtain Warranty Service

In the U.S.A.
If you have any question regarding this warranty or would like to obtain warranty service, please call 1-800-546-5637

and a convenient service center address will be provided to you.
In Canada

If you have any question regarding this warranty or would like to obtain warranty service, please call 1-800-546-5637
and a convenient service center address will be provided to you.

In the U.S.A., this warranty is offered by Sunbeam Products, Inc. doing business as Jarden Consumer Solutions located
in Boca Raton, Florida 33431. In Canada, this warranty is offered by Sunbeam Corporation (Canada) Limited doing
business as Jarden Consumer Solutions, located at 5975 Falbourne Street, Mississauga, Ontario L5R 3V8. If you have
any other problem or claim in connection with this product, please write our Consumer Service Department. PLEASE

DO NOT RETURN THIS PRODUCT TO ANY OF THESE ADDRESSES OR TO THE PLACE OF PURCHASE.

9100030004522 HM365507EM1 Printed in China

Owner’s Guide

HM3655

TROUBLESHOOTING

FREQUENTLY ASKED QUESTIONS

Console

Humidifier

REPLACEMENT ACCESSORIES

To order the replacement accessories you can do any of the following:

• Fill out the accessories card found with the product

• Visit your local retailer

• Go to www.holmesproducts.com

• Call consumer service at 1-800-546-5637

FREQUENTLY ASKED QUESTIONS

QUESTIONS ANSWER

The estimated run time for this humidifier is based on average room conditions. The
actual run time of your humidifier is dependent on numerous variables such as:

1. Air exchange in the room where the humidifier is placed.

2. Room construction where the humidifier is placed.

3. Temperature of the room where the humidifier is placed.

4. Humidity levels in the room where the humidifier is placed.

5. Movement of occupants and the opening and closing of doors in the room
where the humidifier is placed.

6. Home furnishings in the room where the humidifier is placed.

See Daily Maintenance instructions. Regular cleaning is recommended.

1. Run your unit on the lowest setting.

2. If your unit has electronics, set it to your desired humidity level. The unit will
turn on and off, which will extend the run time.

3. Fill the tank all the way full, place it on the base, let the water empty into
the base until it stops bubbling, then refill the tank full again. This ensures
maximum water capacity and will extend run time.

What are the variables that
affect run time?

How do I remove film on
water tank?

How can I extend the run
time?

☎

INFO HOT-LINE: If, after reading this owner’s guide you have
any questions or comments, please call 1-800-546-5637 and a
Customer Service Representative will be happy to assist you.

FILTER #: HWF75/HF221

FILTER TYPE: WICK

TROUBLE PROBABLE CAUSE SOLUTION

Unit does not turn on Not plugged in Plug in unit

Mist output minimal to none Filter has not absorbed water Wait 15 minutes for filter to absorb water

Filter turns brown The filter has absorbed minerals Replace your filter (HWF75/HF221) by

calling 1-800-546-5637, or visit

www.holmesproducts.com

STORAGE INSTRUCTIONS

When not using your humidifier for an extended period of time:

1. Dispose of the filters. DO NOT leave in unit.

2. Clean, rinse and thoroughly dry the humidifier as directed in weekly maintenance. DO NOT leave any water in the
unit when storing. Leaving water in the unit may render the unit inoperable for the following season.

3. Place the humidifier in the original carton and store in a cool, dry place.

4. Order your replacement filter for next year’s use.

HM365507EM1.qxd:HM495UC07EFM1.qxd 4/25/07 5:00 PM Page 1

will move from the OFF position and
indicate your filter condition. A brand
new filter will register in the blue
section reading GOOD filter. After
frequent use of your humidifier, the
FilterCheck®Indicator will let you know
when the filters need to be changed,
(see Fig. 2).

When the needle is in the light red (CHANGE) section, this
means the proper amount of moisture is not getting into
your air due to the excessive minerals and sediment that
have become trapped on your filters. At this point, you
should replace your filter. It is important to change your
filter as indicated to obtain stated performance level.

To replace the filter, follow the steps below:

1. Turn the unit off and disconnect from the electrical outlet.

2. Remove the tank and main housing to access the base tray.

3. Remove wick and discard.

4. Follow the weekly cleaning instructions.

5. Insert new filter.

6. Repeat Operating Instructions steps.
It will take about 30 minutes for the humidifier to reach
maximum output.
NOTE: You can purchase replacement filters (model
HWF75/HF221) at a local retailer, by calling 1-800-546­5637, filling out the accessory card, or by visiting

www.holmesproducts.com.

It is recommended that a

replacement filter is purchased for uninterrupted use.

CLEANING AND MAINTENANCE INSTRUCTIONS

Humidifiers provide comfort by adding moisture to dry,
heated indoor air. To benefit most from the humidifier and
avoid product misuse, follow all instructions carefully.
Please note that this is an electrical appliance and requires
attention when in use.

In addition, if you do not follow the recommended care
and maintenance guidelines, micro-organisms may be
able to grow in the water within the water tank. You must
routinely follow the cleaning procedures that follow in
order to ensure proper, efficient operation of your
humidifier. Proper maintenance and cleaning is essential
to the continued performance of your unit and the
avoidance of algae or bacteria build-up.

DAILY MAINTENANCE

1. Be sure the unit is OFF and is disconnected from the
electrical outlet.

2. Remove the housing and the tank from the humidifier
and place in sink or tub.

3. Carry the base of the unit to the sink, remove the
wick, place in sink, drain any remaining water and
rinse thoroughly to remove any sediment or dirt. Wipe
clean, and dry with a clean cloth or paper towel.

4. Drain the water from the tank into the sink and rinse
tank thoroughly. Wipe clean, and dry with a clean
cloth or paper towel.

5. Put filter back in, replace the housing, then refill tank
with cool tap water as instructed earlier in the Filling
Instructions. Do not overfill.

6. Follow Operating Instructions.

WEEKLY MAINTENANCE
To Remove Scale:

1. Repeat steps 1-4 above.

2. Clean the base by partially filling the base with one
8-oz cups of undiluted white vinegar, or by using
Cleanse Clean™ (Model S1710) by the manufacturer.
Leave this solution in the base for 20 minutes, while
cleaning the all interior surfaces with a soft brush.
Remove base scale by wiping the base with a cloth
dampened with undiluted white vinegar.

3. Rinse with clean warm water to remove the cleaning
solution before disinfecting the tank.

To Disinfect Humidifier Base and Tank:

1. Fill humidifier base with 1/2 gallon of water and 1/2
teaspoon of chlorine bleach.

2. Fill each tank 1/2 full with water and 1/2 teaspoon of
chlorine bleach.

3. Let the solution stand for 20 minutes, swishing every
few minutes. Wet all surfaces.

4. Carefully empty the base and tank after 20 minutes,
and rinse with water until you cannot detect any
bleach smell. Dry with a clean cloth or paper towel.

5. Check the FilterCheck

®

Indicator to see if it is time to
replace the filters. Depending on water hardness in
your area, it may be necessary to change the filter
every 1-2 months. Re-insert the wick filter.

6. Refill the water tank as directed with cool tap water,
replace the humidifier housing, and turn the unit on.

serviceable parts. All servicing should be performed
by qualified personnel only.

21. Never place housing under water flow or immerse in liquids.

22. Do not plug in the cord with wet hands: electric shock
could result.

23. Do not pour water in any openings other than the
water tank.

24. To prevent damage to surfaces, do not place humidifier
under overhanging surfaces.

25. NEVER operate unit without water in the tank.

26. Do not move unit after it has been used until unit cools
completely.

27. Use both hands when carrying full tank of water.

PLEASE READ AND SAVE

THESE IMPORTANT SAFETY

INSTRUCTIONS

Consumer Safety Information
NOTE: This is an electrical appliance and requires

attention when in use.
NOTE: If moisture forms on the walls or windows of the

room, turn off the humidifier. The room already has plenty
of humidity and additional moisture may cause damage.

NOTE: DO NOT block air inlet or outlet.
Cord and Plug Installation Safety Instructions

The length of cord used on this appliance was selected to
reduce the hazards of becoming tangled in, or tripping
over a longer cord. If a longer cord is necessary an
approved extension cord may be used. The electrical rating
of the extension cord must be equal to or greater than the
rating of the humidifier. Care must be taken to arrange the
extension cord so that it will not drape over the countertop
or tabletop where it can be pulled on by children or
accidentally tripped over.

HOW COOL MIST WORKS

Your Holmes®Cool Mist humidifier draws dry air through
the rear air intake grill area. This air is then passed
through a moisture–laden wick filter, which retains the
minerals and deposits in the water. The resulting moist air

is directed back into the room from the top air grill.
NOTE: This humidification system provides a cool,

invisible moisture output. It is normal not to see the mist.
NOTE: A humidity level below 20% can be unhealthy and

uncomfortable. The recommended humidity level is
between 40%-50%.

PRE-OPERATING INSTRUCTIONS

1. Be sure the humidifier is switched to OFF and the unit
is disconnected from the electrical outlet.

2. Select a location for your humidifier, on a flat surface,
about 4” away from the wall. DO NOT place the
humidifier on a finished floor or near furniture, which
can be damaged by moisture or water. Place on a
moisture-resistant surface.

3. Humidifier can be used with or without wheels. Locate
the four wheels in the box. Turn base of humidifier
over to reveal underside. Locate the two stationary
wheels and push the wheel posts into one end of the
base (Fig. 1). Locate the two swivel wheels and push the
wheel posts into the opposite end of the base (Fig. 1).

FILLING THE WATER TANK

1. Remove the tank from the base of the humidifier and
bring to the faucet. Turn the tank upside down and
twist off the tank cap by turning counter clockwise. Fill
tank with cool, fresh tap water.

DO NOT fill with warm water as this may cause
leaking. Replace the cap on each tank FIRMLY.

2. When full, carry each tank to the humidifier and place
onto the base (use both hands when carrying each
tank). Each tank holds 1.6 gallons of water, and the
base holds 1/2 gallons of water.

3. Plug the power cord into a 120V AC electrical outlet.

PLEASE READ AND SAVE THESE

IMPORTANT SAFETY INSTRUCTIONS

FEATURES - OPERATIONS

FEATURES - OPERATIONS

Thank you for purchasing this Holmes®product. We
understand the value of quality and are committed to
making superior products that stand the test of time. We
trust this product will exceed your expectations of quality
and reliability. We hope that you enjoy this product and
will consider purchasing another Holmes®product in the
future. To see our full product line or if you have any
questions or comments about this product, please visit our
website at: www.holmesproducts.com.

When using electrical appliances, basic safety precautions
should always be followed to reduce the risk of fire, electric
shock, and injury to persons, including the following:

1. Read all instructions before using the appliance.

2. To avoid fire or shock hazard, plug the appliance
directly into a 120V AC electrical outlet.

3. Keep the cord out of heavy traffic areas. To avoid fire
hazard, NEVER put the cord under rugs or near heat
registers.

4. DO NOT place humidifier near heat sources such as
stoves, radiators, and heaters. DO locate your humidifier
on an inside wall near an electrical outlet. The humidifier
should be at least 4” away from the wall for best results.

5. NEVER place humidifier in an area where it is accessible
to children. NEVER use humidifier in a closed room,
particularly where a child may be sleeping, resting, or
playing (a closed room may result in excessive humidity).

6. WARNING: Do not attempt to refill humidifier without
first unplugging the unit from its electrical outlet. Failure
to heed this warning may cause personal injury. Be sure
to unplug the unit by pulling on the plug and not the cord.

7. Never place anything over moisture outlet when the
unit is running.

8. NEVER drop or insert any object into any openings.

9. DO NOT operate any appliance with a damaged cord
or plug, after the appliance malfunctions, or if it has
been dropped or damaged in any manner. Return

appliance to manufacturer for examination, electrical
or mechanical adjustment, or repair.

10. Use appliance only for intended household use as described
in this manual. Any other use not recommended by the
manufacturer may cause fire, electric shock, or injury to
persons. The use of attachments not recommended or sold
by the manufacturer may cause hazards.

11. DO NOT use outdoors.

12. Always place humidifier on a firm, flat, level surface.
A waterproof mat or pad is recommended for use
under the humidifier. NEVER place it on a rug or
carpet, or on a finished floor that may be damaged by
exposure to water or moisture.

13. DO NOT allow the Moisture Outlet to directly face the wall.
Moisture could cause damage, particularly to wall paper.

14. Humidifier should be unplugged when not in use.

15. NEVER tilt, move, or attempt to empty unit while it is
operating. Shut off and unplug before removing the
water tank and moving the unit.

16. This humidifier requires daily and weekly maintenance to
operate appropriately. Refer to daily and weekly
cleaning procedures. Use only cleaners and additives
recommended by the manufacturer.

17. NEVER use detergents, gasoline, glass cleaner,
furniture polish, paint thinner, or other household
solvents to clean any part of the humidifier.

18. Excessive humidity in a room can cause water
condensation on windows and some furniture. If this
happens, turn the humidifier OFF.

19. Do not use humidifier in an area where humidity level
is in excess of 50%. Use a hygrometer, available at
your local retailer or through the manufacturer, to
measure the humidity.

20. DO NOT attempt to repair or adjust any electrical or
mechanical functions on this unit. Doing so will void
your warranty. The inside of the unit contains no user

OPERATING INSTRUCTIONS

Your humidifier is equipped with a technologically advanced
Accuset Plus™ Digital Humidistat. You can set the humidifier to
run continuously in manual mode or set the Accuset Plus™
Digital Humidistat to your desired humidity setting. The Accuset
Plus™ Digital Humidistat will automatically turn the humidifier
ON or OFF, depending on the preset comfort level. The comfort
level ranges between 35% and 65% relative humidity.

MANUAL MODE INSTRUCTIONS

1. Plug the humidifier into a 120V AC electrical outlet.

2. The display will show the current room humidity.

3. To start the unit, push the MODE/OFF ( ) button
once for the HIGH (3) manual setting.

4. Press the button again for the MEDIUM (2) manual setting
and again for LOW (1). After the selection is made, the
display will return to show the current room humidity.

5. To stop the unit, press and hold the button for two seconds,
or keep pressing the button until the display reads OFF (OF).

AccuSet Plus™ HUMIDISTAT INSTRUCTIONS

To take advantage of the AccuSet Plus™ Digital
Humidistat, press the MODE/OFF ( ) button until the
speed is set in either the AUTO HIGH (A3), AUTO MEDIUM
(A2) or AUTO LOW (A1) setting. Then adjust the set
humidity by using the up and down buttons. Humidity will
increase in increments of 5%. When the humidity level is
set, the display will return to show the current room
humidity. When the room humidity level rises above the
set humidity, the humidifier will stop. When the humidity
level drops below the set humidity, the humidifier will turn
on automatically.

NOTE: Allow up to 30 minutes for the filter to fully absorb
water and for the unit to produce moisture.

NOTE: The AccuSet Plus™ Humidifier has memory. This
means that when you turn the unit back on, it will be at
the last setting the humidifier was set at.

If you do not plan to use the humidifier for two or more days,
make sure any residual water is drained from the water tank,
base and wick filter to prevent algae or bacteria growth.

USING THE PROGRAMMABLE TIMER

AccuSet Plus™ allows the user to program the humidifier to
come on at a preset time, or turn off after a set amount of time.

Setting the Off Timer:

1. Select the Mode and or humidity you wish the
humidifier to run in.

2. While the humidifier is running, press and hold the up
and down buttons simultaneously for 2 seconds. The
display will flash “00”.

3. By pressing the up and down buttons, program the
humidifier to turn off up to 16 hours later in
increments of 1 hour.

4. After setting the timer, the display will return to show
the current room humidity. A light will illuminate to
show that the timer is activated.

5. After the predetermined length of time has passed,
the humidifier will automatically shut off.

Setting the On Timer:

1. While the humidifier is off, press and hold the up and
down buttons simultaneously for 2 seconds.

2. By pressing the up and down buttons, program the
humidifier to turn on up to 16 hours in advance in
increments of 1 hour.

3. After the preset length of time has passed, the
humidifier will automatically turn on Auto Mode HI
speed at 45% for a preset time of 2 hours.

EXTENDED RUN TIME SETTING

By setting your humidifier to a specific humidity level, you
are actually also extending the run time. Since the unit will
turn on and off to maintain the set humidity level, less
water will be used on manual setting.

REPLACING THE FILTERS

Through normal use, waterborne minerals and sediment
become trapped in the wick filter. The harder your water,
the greater the amount of minerals in the water, and the
more often you will need to change your filter.

You will be able to monitor the life of the filter in your
humidifier by checking the FilterCheck

®

Indicator. When
the unit is off, the FilterCheck®Indicator will read in the
OFF position. After 60 minutes of use, FilterCheck® Indicator

REPLACING/CLEANING

CLEANING AND MAINTENANCE

THIS APPLIANCE HAS A POLARIZED PLUG (one blade is wider than the
other). To reduce the risk of electric shock, this plug is intended to fit in
a polarized outlet only one way. If the plug does not fit fully in the
outlet, reverse the plug. If it still does not fit, contact a qualified
electrician to install the proper outlet.

DO NOT ATTEMPT TO MODIFY THIS PLUG OR DEFEAT THIS

SAFETY FEATURE IN ANY WAY.

Fig. 1

A. STATIONARY WHEELS
B. SWIVEL WHEELS
C. UNDER –SIDE OF

HUMIDIFIER BASE

WHEEL INSTALLATION

B

C

A

Fig. 2

HM365507EM1.qxd:HM495UC07EFM1.qxd 4/25/07 5:00 PM Page 2
